HP V202 Quickspecs
QuickSpecs
HP V202 19.5-inch Monitor
Overview
c04882265 —DA– 15466 — Worldwide — Version 2 — November 30, 2015
Page 1
.
HP V202 19.5-inch Monitor
1.
Menu button
4.
OK
2.
Minus ("-")
5.
Power button
3.
Plus ("+")
6.
Power indicator LED
1.
VGA input
2.
Security lock slot
QuickSpecs
HP V202 19.5-inch Monitor
Overview
c04882265 —DA– 15466 — Worldwide — Version 2 — November 30, 2015
Page 2
Your ideal office configuration begins with two HP
V202 monitors combined with an HP Adjustable Dual
Display Stand (AW664AA) for a small footprint, high
productivity work solution.*
HP V202 and HP Adjustable Dual Display Stand dual monitor configuration
shown. (Note: monitors and stands sold separately)
*NOTE: Multi-monitor support is dependent on your system. Check your user
guide or technical specifications for compatibility. Optional accessories may be
required.
Overview
Get quality presentation features at a price point that doesn’t break the bank with the HP V202 19.5-inch Monitor, a sleek, thinprofile monitor in a compact, space-saving screen size with an unbelievably low price point.
Key features:
Enjoy quality front-of-screen performance for all of your daily tasks.
Make a good impression and leave plenty of room with a design that complements HP PCs and has a small footprint.
Reduce power consumption and help lower your costs with an energy-efficient design.
Attach your HP 260 Desktop Mini PC directly behind the display.
1
Find your best display position with customizable tilt settings.
Mount the display on a wall or swing arm with the HP Quick Release.
4
Rest assured that your IT investment is supported by a three-year standard limited warranty.
1 Requires HP Quick Release, sold separately. See product QuickSpecs for exact PC and thin client compatibility.
2 Each accessory sold separately. Mounting hardware sold separately.
QuickSpecs
HP V202 19.5-inch Monitor
Technical Specifications
c04882265 —DA– 15466 — Worldwide — Version 2 — November 30, 2015
Page 3
Models: P0Q48AA - HP V202 19.5-inch Monitor
Panel
Type
19.45-inch TN w/LED backlight
Viewable Image Area
(diagonal)
49,4 cm (19.45-inch) widescreen; diagonally measured
Panel Active Area
(W × H)
43,2 x 23,97 cm (17 x 9.43 in)
Resolution
1600 x 900 @ 60 Hz*
*The video card of the connected PC must be capable of supporting
1600 x 900 at 60 Hz.
Aspect Ratio
16:9
Viewing Angle
Up to 90° horizontal/50° vertical typical
Brightness
200 cd/m2
Contrast Ratio (Typical)
600:1 Static; 5,000,000:1 Dynamic (DCR)
Response Times*
5 ms typical on/off
Pixel Pitch
.27 mm
Pixels Per Inch (PPI)
94.1 DPI
Pixel Clock
170 MHz
Backlight Lamp Life
(to half brightness)
30,000 hours minimum
Color Support
Up to 16.7 million colors with the use of FRC technology
Color Gamut (Typical)
72%
* Performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
User Controls
Buttons or Switches
Menu, Minus ("-"), Plus ("+"), OK, Power
Languages
10 (English, Spanish, German, French, Italian, Netherlands, Portuguese,
Japanese, T-Chinese and S-Chinese)
On Screen Display
(OSD) User Controls
Brightness, Contrast, Color Control, Image Control, Power Control, Menu
Control, Management, Language, Information
Signal Interface/
Performance
Horizontal Frequency
30-70 kHz
Vertical Frequency
50-60 Hz
Native Resolution
1600 x 900 @ 60 Hz
Preset Graphic Modes
(non-interlaced)
640 x 480 @ 60Hz
800 x 600 @ 60 Hz
1024 x 768 @ 60 Hz
1280 x 720 @ 60 Hz
1280 x 800 @ 60 Hz
1280 x 1024 @ 60 Hz
1440 x 900 @ 60 Hz
1600 x 900 @ 60 Hz
