QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Overview

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 1

HP Docking Solutions for HP ZBook G3/G4 Mobile Workstations

Models

HP UltraSlim Docking Station

D9Y32AA

HP ZBook Dock with Thunderbolt™ 3 (150W)

P5Q58AA

HP ZBook Dock with Thunderbolt™ 3 (200W)

P5Q61AA

HP Thunderbolt™ Dock 120W G2

2UK37AA

HP Thunderbolt™ Dock 230W G2

2UK38AA

HP TB Dock G2 w/ Combo Cable (230W)

3TR87AA

HP Thunderbolt Dock G2 Audio Module

3AQ21AA

HP Thunderbolt Dock 230W G2 Cable

3XB95AA

HP Thunderbolt Dock G2 Combo Cable

3XB96AA

HP Thunderbolt Dock G2 120W Cable

3XB94AA

Compatiblity

Docking Station

Mobile Workstation

HP UltraSlim Docking Station

HP ZBook 15u G3/G4/G5, HP ZBook 14u G4/G5

HP ZBook Dock with Thunderbolt™ 3 (150W)

HP ZBook 15 G3/G4/G5, HP ZBook Studio G3/G4/G5

HP ZBook Dock with Thunderbolt™ 3 (200W)

HP ZBook 17 G3/G4/G5 , HP ZBook 15 G3/G4/G5, HP ZBook Studio
G3/G4/G5

HP Thunderbolt Dock 120W G2

HP ZBook x2, HP ZBook 15u G4/G5, HP ZBook 14u G5

HP Thunderbolt Dock 230W G2

HP ZBook x2, HP ZBook 15u G4/G5, HP ZBook 14u G5, HP ZBook 15
G3/G4/G5, HP ZBook Studio G3/G4/G5, HP ZBook 17 G3/G4/G5, HP
ZBook Studio x360 G5

HP Thunderbolt Dock G2 w/ Combo Cable

HP ZBook x2, HP ZBook 15u G4/G5, HP ZBook 14u G5, HP ZBook 15
G3/G4/G5, HP ZBook Studio G3/G4/G5, HP ZBook 17 G3/G4/G5, HP
ZBook Studio x360 G5

NOTE: Your mobile workstation, docking station, and monitor must all support USB 3.0 and DisplayPort 1.2 to benefit from the
advanced speeds or features that these technologies provide. If one of the devices does not support these technologies, you will
still have USB 2.0 and DisplayPort 1.1 functionality.

NOTE: Thunderbolt™ 3 Dock Cable 1m could be ordered as an option with the part number: Z4P20AA.

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Overview of HP UltraSlim Docking Station

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 2

HP UltraSlim Docking Station – Front side

1.

Docking posts

3.

Side docking connector

2.

Locking mechanism

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Overview of HP UltraSlim Docking Station

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 3

HP UltraSlim Docking Station – Rear side

1.

Docking station cable lock slot (lock not included)

8.

DisplayPort 1.2 (2)

2.

Connection button

9.

USB 3.0 ports (3)

3.

Power on/off

10.

USB 3.0 charging port (1)

4.

Lock slot (lock not included)

11.

Power connector

5.

Docking station cable lock slot (lock not included)

12.

Line in jack

6.

VGA port

13.

Line out jack

7.

LAN/Ethernet port

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Technical Specifications of HP UltraSlim Docking Station

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 4

HP UltraSlim Docking Station

D9Y32AA

Front Components

Docking posts (2)

Align and secure the computer for proper connection to the docking station

Computer connect/
release mechanisms (2)

Connect and release the computer when you press the connection button

Docking connector

Docking connector for mobile workstation

Connect button

Secures and releases the computer
Slide in to secure the computer
Slide out to release the computer

LEDs

AC present: aqua white; Dock connected: white; two RJ45 LEDs: amber/green

Rear Components

AC power port

Energy-efficient 65W Smart AC adapter features integrated surge protection to help against power
fluctuations.

Integrated cable lock slot

Supports the HP Docking Station Cable Lock with a simplified locking mechanism. Gives you two security
options: lock the docking station only (which also prevents access to the Station drive bay); or lock both
the docking station and your mobile workstation for additional security. Also supports an industry
standard mobile workstation lock.

Network connectors

RJ-45 / Ethernet pass through

USB ports

3 USB 3.0 ports, 1 USB 3.0 charging port

Audio connectors

Line-In; Line-Out

Other connectors

VGA, DisplayPort 1.1a (DP 1.2 capable)

NOTE: Your mobile workstation, docking station, and monitor must all support USB 3.0 and DisplayPort 1.2 to benefit from the
advanced speeds or features that these technologies provide. If one of the devices does not support these technologies, you will
still have USB 2.0 and DisplayPort 1.1 functionality.

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Technical Specifications of HP UltraSlim Docking Station

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 5

HP UltraSlim Docking Station

Dimensions (H x W x D)

1.7 x 14.5 x 4.2 in (4.4 x 36.8x 10.7 cm)

Weight

1.69 lb (0.76 kg)

Stand-alone power requirements

Normal Operating Voltage

18.5 V

Average Operating Power

18.5 W

Max Operating Power

< 65 W

Temperature

Operating

32° to 95° F (0° to 35° C)

Non-operating

4° to 140° F (-20° to 60° C)

Relative humidity

Operating

10% to 90%, non-condensing

Non-operating

5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature

Altitude

Operating

-50 to 10,000 ft (-15.24 to 3,048 m)

Non-operating

-50 to 40,000 ft (-15.24 to 12,192 m)

Shock

Operating

125 G, 2 ms, half-sine

Non-operating

200 G, 2 ms, half-sine

Random vibration

Operating

0.75 grms

Non-operating

1.50 grms

Option Kit Contents

2013 HP UltraSlim Docking Station, AC power adapter, documentation

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Overview of HP ZBook Thunderbolt 3 Dock - 150W and 200W

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 6

HP ZBook Thunderbolt™ 3 Dock– Front side

1.

Power button

3.

Headphone/microphone combo jack

2.

USB 3.0 ports (2)

HP ZBook Thunderbolt™ 3 Dock – Back side

1.

Security lock slot

6.

Thunderbolt™3 port

2.

Ethernet port

7.

Power connector

3.

VGA port

8.

Thunderbolt™3 / power cable connector

4.

USB 3.0 ports (2 total, 1 charging)

5.

DisplayPort 1.2 (2)

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Technical Specifications of HP ZBook Thunderbolt 3 Dock - 150W and 200W

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 7

HP ZBook 150W Thunderbolt™ 3 Dock

P5Q58AA

HP ZBook 200W Thunderbolt™ 3 Dock

P5Q61AA

Front Components

Power button

Turns on the power to the computer

Computer power light

Light on: docked computer is turned on
Light blinking: docked computer is in standby mode

Connect light

Light on: computer is fully docked
Light blinking: computer is in standby mode

Audio connector

Combo audio mic/headphones

USB 3.0 ports

(2) Two USB 3.0 ports allow you to connect to standard USB devices.

Rear/Right-Side Components

AC power port

Energy-efficient 150W or 200W Smart AC adapter features integrated surge protection to help against
power fluctuations.

Powered USB 3.0 port

(1) One powered USB 3.0 port allows you to connect to select USB devices

USB 3.0 ports

(1) One USB 3.0 port allows you to connect to standard USB devices.

Thunderbolt™ 3 Port

(1) One Thunderbolt™3 port provides external device charging up to 15 watts;

Video Connectors

(2) Two DisplayPort 1.2 ports, (1) one VGA port

Power Connectors

(1) One Thunderbolt™/Power combination cable connector to connect to ZBook system (1) One 4.5mm

power connector for 150W or 200W AC Adapter.

Integrated cable lock slot

Supports HP Cable Locks. Also supports HP Dual Head Cable Lock.

Network connectors

(1) Ethernet port; Broadcom NetXtreme Gigabit Ethernet

Docking Cable

Thunderbolt™ 3 power cable connects the computer to the docking station

NOTE: Your mobile workstation must support Thunderbolt™ 3 to enable the docking station. Docking station, and monitor must all
support USB-C™, USB 3.0 and DisplayPort 1.2 to benefit from the advanced speeds or features that these technologies provide. If
one of the devices does not support these technologies, you will still have USB 2.0 and DisplayPort 1.1 functionality.

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Technical Specifications of HP ZBook Thunderbolt 3 Dock - 150W and 200W

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 8

HP ZBook 150W Thunderbolt™3 Dock

Dimensions (H x W x D)

230 x 57 x 16mm (w/o feet), 9.05 x 2.24 x 0.63 in

230 x 57 x 17.5mm(w/ feet), 9.05 x 2.24 x 0.69 in

Weight
227g (0.5 lb)

Stand-alone power requirements

Normal Operating Voltage

19.5V

Average Operating Power

0.29W

Max Operating Power

150W

Temperature

Operating

32° to 95° F (0° to 35° C)

Non-operating

4° to 140° F (-20° to 60° C)

Relative humidity

Operating

10% to 90%, non-condensing

Non-operating

5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature

Altitude

Operating

-50 to 10,000 ft (-15.24 to 3,048 m)

Non-operating

-50 to 40,000 ft (-15.24 to 12,192 m)

Shock

Operating

125 G, 2 ms, half-sine

Non-operating

200 G, 2 ms, half-sine

Random vibration

Operating

0.75 grms

Non-operating

1.50 grms

Option Kit Contents

HP ZBook 150W Thunderbolt™3 Dock, Thunderbolt™/AC power cable, 150W A/C power

adapter, documentation

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Technical Specifications of HP ZBook Thunderbolt 3 Dock - 150W and 200W

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 9

HP ZBook 200W Thunderbolt™ 3 Dock

Dimensions (H x W x D)

230 x 57 x 16mm (w/o feet), 9.05 x 2.24 x 0.63 in

230 x 57 x 17.5mm(w/ feet), 9.05 x 2.24 x 0.69 in
Weight

227g (0.5 lb)

Stand-alone power requirements

Normal Operating Voltage

19.5V

Average Operating Power

0.368W

Max Operating Power

200W

Temperature

Operating

32° to 95° F (0° to 35° C)

Non-operating

4° to 140° F (-20° to 60° C)

Relative humidity

Operating

10% to 90%, non-condensing

Non-operating

5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature

Altitude

Operating

-50 to 10,000 ft (-15.24 to 3,048 m)

Non-operating

-50 to 40,000 ft (-15.24 to 12,192 m)

Shock

Operating

125 G, 2 ms, half-sine

Non-operating

200 G, 2 ms, half-sine

Random vibration

Operating

0.75 grms

Non-operating

1.50 grms

Option Kit Contents

HP ZBook 200W Thunderbolt™ 3 Dock, Thunderbolt/AC power cable, 200W A/C power

adapter, documentation

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Overview of HP Thunderbolt Docks G2

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 10

HP Thunderbolt™ Dock G2– Left Angle

1.

Power button

4.

1 powered USB 3.0 port

2.

1 USB-C port with data and power out (15W)

5.

Kensington lock slot

3.

Headphone/microphone combo jack

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Overview of HP Thunderbolt Docks G2

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 11

HP Thunderbolt™ Dock G2 – Back side

1.

2 USB 3.0 ports

6.

AC Adapter connector

2.

1 VGA port

7.

1 ThunderboltTM port

3.

2 DisplayPortTM ports

4.

1 USB-C DisplayPortTM, data and power out (15W) port

5.

Ethernet port

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Technical Specifications of HP Thunderbolt Docks G2

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 12

HP Thunderbolt Dock 120W G2

2UK37AA

HP Thunderbolt Dock 230W G2

2UK38AA

HP Thunderbolt Dock G2 w/Combo Cable

3TR87AA

Top Components

Power button and LED

LED and power button to power or wake host system1

Front Components

USB-C port

(1) One USB-C port with data and power out (15W)

USB-C cable

(1) One USB-C cable to connect to host system (0.7 meter cable length)

Side Components

Powered USB 3.0 port

(1) One powered USB 3.0 port allows you to connect to select USB devices

combo Audio Jack

(1) One combo Audio Jack

Kensington lock slot

(1) One Kensington lock slot

Back Components

Thunderbolt™ port

(1) One Thunderbolt port

USB-C DisplayPort

(1) One USB-C DisplayPort, data and power out (15W) port

DisplayPort ports

(2) Two DisplayPort ports

VGA port

(1) One VGA port

USB 3.0 ports

(2) Two USB 3.0 ports

Network connectors

(1) Ethernet port

AC power port

AC Adapter connector

Network manageability
features

-PXE Boot

-Wake on LAN (from the Off, Sleep or Hibernation States)2

-MAC Address Pass Through (from the On, Off, Sleep or Hibernation States)3

-WLAN-LAN Switching4

External monitor support

Up to 4

HP Thunderbolt™ Dock G2 video resolution specifications when the dock is connected to a USB-C™ alt-mode system1:

Host Specification

# of monitors

DP 1.2 USB-C™ host

HP EliteBook 840r G4
HP ProBook 600 G4, 400 G5
HP Pro x2 612 G2

1

2560x1440 @ 60Hz

2

1920x1200 @ 60Hz

3

(1) 1920x1200 @ 60Hz
(2) 1280x768 @ 60Hz

DP 1.3 USB-C™ host

HP EliteBook 700 G5
HP ProBook 645 G4, 455 G5

1

3840x2160 @ 60hz

2

2560x1600 @ 60Hz

3

(1) 2560x1600 @ 60Hz
(2) 1680x1050 @ 60Hz

4

1680 x 1050 @ 60Hz (requires MST)

1. USB-C™ systems will perform at USB 3.0 Gen1 speeds

Thunderbolt™ port will function as a USB 2.0 port with only data and power out (15W); no video

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Technical Specifications of HP Thunderbolt Docks G2

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 13

NOTE 1: Requires host mobile workstation to support in its BIOS
NOTE 2: Your computer might support Wake on Lan from the Off, Sleep or Hibernate States, or only when the computer is On or in

Sleep.
NOTE 3: Your computer might support MAC Address Pass Through the On, Off, Sleep or Hibernate States, or only when the computer
is On or in Sleep

NOTE 4: WLAN – LAN switching is supported only on select computers running Windows 10 operating system

NOTE: Your mobile workstation must support Thunderbolt™ 3 to enable the docking station. Docking station and monitor must all

support USB-C™, USB 3.0 and DisplayPort 1.2 to benefit from the advanced speeds or features that these technologies provide. If
one of the devices does not support these technologies, you will still have USB 2.0 and DisplayPort 1.1 functionality.

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Technical Specifications of HP Thunderbolt Docks G2

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 14

HP Thunderbolt Dock G2 (120W & 230W)

Dimensions (H x W x D)

3.9 x 3.9 x 2.7 in (98 x 98 x 69 mm)

Weight

1.76 lbs (0.800 Kg)

Power delivery (PD) Profiles

5V/5A, 9V/5A, 12V/5A, 15V/5A, 20V/5A

Power to system

Up to 100W via USB-C™and up to 200W through 230W power barrel

Operating voltage and current

- 19.7 V dc @ 6.1 A – 120W

- 19.7 V dc @ 11.8 A – 230W

Temperature

Operating

32° to 95° F (0° to 35° C)

Relative humidity

Operating

10% to 90%, non-condensing

Maximum altitude unpressurized

Operating

-50 to 10,000 ft (-15 to 3,048 m)

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Technical Specifications of HP Thunderbolt Docks G2

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 15

Service and Support

HP Docking Stations for HP ZBook G3/G4/G5 Mobile Workstations are supported by a one-year limited warranty. Additional
support is available 24 hours a day, seven days a week by phone as well as online support forums.

http://h20565.www2.hp.com/portal/site/hpsc/public/psi/home/

NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

Summary of Changes

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 16

Date of change

Version History

Description of change

From v1 to v2

Stand-alone power requirements from 19.7V to 19.5V

July 1, 2016

From v2 to v3
Added

Link in Service and Support Section

Changed

Network Connector type for 150/200W Dock

May 1, 2017

From v3 to v4

Added

Compatibility with G4 Mobile Workstations

August 14, 2017

From v4 to v5

Added

Footnote about the Thunderbolt 3 Dock Cable 1m

February 7, 2018

From v5 to v6

Added

HP Thunderbolt Dock G2 (120W), HP Thunderbolt Dock G2 (230W), HP
Thunderbolt 230W 1m cable, HP Thunderbolt 1m combo cable & HP
Thunderbolt Dock Audio

July 24, 2018

From v6 to v7

Update

General re-arrange

QuickSpecs

HP Docking Solutions for

HP ZBook G3/G4/G5 Mobile Workstations

c04834949 – DA – 15447– Worldwide – Version 7 – July 24, 2018

Page 17

© Copyright 2018, 2017 HP Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set
forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as
constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Thunderbolt and the Thunderbolt logo are trademarks of Intel Corporation in the U.S. and/or other countries.
