HP Thunderbolt-2 PCIe 1-port I-O Card Setup and Install

Printed in

*753804-001*

753804-002

© 2014 Hewlett-Packard Development Company, L.P.

HP Thunderbolt 2 PCIe Card installation

The information contained herein is subject to
change without notice. The only warranties for
HP products and services are set forth in the
express warranty statements accompanying
such products and services. Nothing herein
should be construed as constituting an
additional warranty. HP shall not be liable for
technical or editorial errors not be liable for
technical or editorial errors

© 2014 Hewlett-Packard Development

Second Edition: September 2014

Document Part Number: 753804-002

Table of contents

Thunderbolt 2 PCIe Card Installation .................................................................................................................. 1

Introduction ........................................................................................................................................................... 1

Kit contents ............................................................................................................................................................ 1

Warnings and cautions .......................................................................................................................................... 2

Step 1—Preparing for component installation .................................................................................................... 3

Accessing the internal components of the computer ........................................................................ 3

Step 2—Installing the Thunderbolt add-in card ................................................................................................... 3

Step 3—Reassembling the computer ................................................................................................................... 9

Step 4—Loading the Thunderbolt add-in card driver .......................................................................................... 9

iii

iv

Thunderbolt 2 PCIe Card Installation

Introduction

This installation guide explains how to install the Thunderbolt™ 2 PCIe card into HP workstations.

Kit contents

●

HP Thunderbolt 2 PCIe Card

●

GPIO (General-Purpose Input/Output) cable for use with HP Zx40 models (part number 751366-001)

●

GPIO (General-Purpose Input/Output) cable for use with HP Zx20 models (part number 751363-001)

●

GPIO (General-Purpose Input/Output) cable for use with HP Z230 model (part number 751364-001)

●

DisplayPort cable

●

Extra bulkhead

●

Installation instructions (this document)

●

Warranty information

IMPORTANT: Use of the Thunderbolt add-in card requires installation of a PCI Express graphics card. Go to
http://www.hp.com/support for the System Quick Specs, including a list of supported graphics cards.

Introduction 1
