HP t730 Quick Specs

QuickSpecs

HP t730 Thin Client

Overview

c04743502 — DA – 15345 Worldwide — Version 7 — January 14, 2021

Page 1

HP t730 Thin Client

FRONT

BACK

Power button (with integrated power indicator light)

Parallel port

Flash memory activity indicator light

PS/2 ports for keyboard and mouse

Hi-Speed USB 2.0 ports (2)

Serial ports (2)

SuperSpeed USB 3.0 ports (2)

DisplayPort 1.2 digital video outputs (4)

3.5 mm headset port

Hi-Speed USB 2.0 ports (4)

3.5 mm headphone/ microphone port

SuperSpeed USB 3.0 port (1) secured inside

Agency label pull-out tab (on side panel)

Gigabit Ethernet RJ45 connector

System stand

Audio line in port

Audio line out port

10.

+19V DC power input

11.

Cable lock slot

12.

Retractable power cord retention hook

13.

PCI Express (low profile) expansion slot

14.

Fiber Optic NIC expansion slot

QuickSpecs

HP t730 Thin Client

Overview

c04743502 — DA – 15345 Worldwide — Version 7 — January 14, 2021

Page 2

AT A GLANCE

• AMD R-Series RX-427BB 2.7 GHz – 3.6 GHz quad-core APU with a Radeon HD 9000 based graphics core

• DDR3L SDRAM dual-channel system memory; two SODIMM slots; up to 16 GB supported

• 4 x DisplayPort 1.2 digital video outputs supporting up to Ultra HD/4K (3840 x 2160) resolutions

• Optional AMD FirePro W2100 discrete graphics card installed in PCI Express expansion slot providing an additional 2 x

DisplayPort 1.2 digital video outputs for a system total of six outputs

• Solid-state NAND flash memory storage; M.2 form factor modules

• Active thermal management technology monitors component operating temperatures, throttles SOC operation if

appropriate, and prevents unit thermal shutdown

• Gigabit Ethernet (GbE) network connection supported via an embedded Realtek GbE NIC module

• Optional Allied Telesis Fiber Optic NICs; Fast Ethernet (100 Mb/s) or Gigabit (1,000 Mb/s)

• Optional Wi-Fi adapters including antennas integrated internally in the chassis

NOTE: Fiber optic and Wi-Fi NIC options cannot be supported together2

• 2 x SuperSpeed USB 3.0 and 2 x Hi-Speed USB 2.0 on front, 4 x Hi-Speed USB 2.0 on rear and 1 x SuperSpeed USB 3.0 inside

the chassis.

• Legacy ports include PS/2 keyboard and mouse, 2 x serial ports and 1 x parallel port

• Integrated PC speaker for basic audio playback; 3.5 mm audio ports on front and rear supporting headphones, microphones

and external speaker systems

• Security features include a TCG certified Trusted Platform Module (TPM) 1.2 chipset, BIOS designed to address NIST SP 800-

147 guidelines, cable lock slot, and power cord retention clip to prevent accidental disconnects; 1 x internal SuperSpeed USB

3.0 ports for securing USB flash drives inside the chassis

• Low profile PCI Express x8 (physical x16) expansion slot supports a variety of optional sub-systems including discrete

graphics and I/O adapter cards

• Post-consumer recycled plastics content greater than 25% total unit plastics (by weight)

• Low halogen

material content

• All models TAA compliant (in North America & EMEA); TAA models available in APJ by request

If configured with a Windows Embedded 32-bit operating system, memory above 3.2 GB may not be available due to operating system limitations

Wireless access point and Internet access is required; availability of public wireless access points is limited

This product is low halogen except for power cords, cables and peripherals, as well as the optional Fiber Optic NIC module; service parts obtained aftermarket

may not be low halogen

QuickSpecs

HP t730 Thin Client

Overview

c04743502 — DA – 15345 Worldwide — Version 7 — January 14, 2021

Page 3

HP ThinPro / Smart Zero Core Operating Systems:

• HP ThinPro and HP Smart Zero Core are HP’s purpose-built Linux® based thin client operating systems

• HP ThinPro offers an easy-to–use, easy-to-configure, locked-down interface -- HP Connection Manager -- that allows

administrators to quickly create server connections for end users

• HP Smart Zero clients using Smart Zero Client Core boot directly into a user log-in on the server or portal for which they are

configured. No local thin client user interface means the end-user can get to work without special training on the access device. The Smart Zero Core technology reduces the administrative burden by enabling the IT administrator to perform the configuration settings on the server and the settings will be automatically applied to HP thin clients plugged in to the network

• ICA and RDP support for accessing Citrix® and Windows® resources

• VMware® Horizon RDP, PCoIP, Blast Extreme support for accessing VMware® Horizon View™ sessions

• VDI broker support includes VMware™ Horizon View™, Citrix® XenDesktop® (with CDA mode utility)

• Multimedia and USB redirection support

o Citrix® HDX MediaStream (multimedia redirection) o Citrix® HDX Plug-n-Play (USB redirection)

• Improved end user experience with HP Velocity

o Enables IT managers to monitor network activity and optimize end-user experience o Intelligently reduces network retransmissions due to packet loss o Built in monitors enable remote debugging and troubleshooting o For details visit: http://www.hp.com/go/velocity

Windows® Embedded Standard 7P Operating System:

• Internet Explorer 11 for genuine browsing and web-application interfaces

• A 64-bit operating system for improved performance and support for larger memory installations

• Excellent rich multimedia experience and enhanced USB device support in VDI environments

• Latest protocol support from Citrix® On-Line Plug in (ICA) 4.1, RDP 8.1 w/RemoteFX, and VMware® Horizon Client 2.3.3

• Enhanced Write Filter and File-Based Write Filter provide complete flexibility to protect the entire Flash disk, or configure

areas of the disk for persistent access by local applications

• Microsoft Firewall for enhanced data security

• Support 802.1x LAN-based authentication for greater security

• HP Universal Print Driver provides instant access to a range of HP print devices without downloading separate

• Improved end user experience with HP Velocity

QuickSpecs

HP t730 Thin Client

Overview

c04743502 — DA – 15345 Worldwide — Version 7 — January 14, 2021

Page 4

Windows® 10 IoT Enterprise Operating System:

• The newest Microsoft embedded operating system based on Windows® 10

• A 64-bit operating system for improved performance and support for larger memory installations

• Smooth, immersive experiences with technologies like advanced Multi Touch and Windows® 10 applications

• The latest RDP8.1 and Remote FX client software

• Latest Internet Explorer 11 for genuine browsing, HTML 5 support and web-application interfaces

• Latest protocol support from Citrix®, VMware® and RDP

• Excellent rich multimedia experience and enhanced USB device support in VDI environments

• Improved end-user experience with HP Velocity

o Enables IT managers to monitor network activity and optimize end-user experience o Intelligently reduces network retransmissions due to packet loss, providing a better user experience o Built in monitors enable remote debugging and troubleshooting o For details visit: http://www.hp.com/go/velocity

Warranty

HP Customer Support: limited three-year hardware limited warranty in most regions; HP Care Packs are extended service contracts that go beyond your standard limited warranties; for more details visit http://www.hp.com/go/cpc

QuickSpecs

HP t730 Thin Client

Technical specifications

c04743502 — DA – 15345 Worldwide — Version 7 — January 14, 2021

Page 5

OPERATING SYSTEMS

HP Smart Zero Core HP ThinPro Windows® Embedded Standard 7P** Windows® 10 IoT Enterprise*

* Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for updates. See

http://www.microsoft.com.

PROCESSOR

Model

CPU Frequency

Max/Base

Cores

GPU CUs

TDP

L2 Cache

GPU

Max/Base

Memory

AMD RX-427BB

3.6/2.7 GHz

4 8 35W

4 MB

686/600 MHz

DDR3

GRAPHICS

AMD RadeonTM HD 9000 Graphics Core

AMD 2nd Generation Embedded R-Series APU delivers graphics performance and power efficiency designed to provide ultraimmersive HD multimedia experiences and parallel processing compute performance with a new graphics core based on the AMD Radeon™ HD 9000 platform

Native support for up to four (4) displays @ Ultra HD/4K (3840 x 2160) resolution. System provides four (4) DisplayPort 1.2 digital video output ports at the back of the unit

The HP t730 Thin Client supports a 60 Hz screen refresh rate for up to two Ultra HD displays set for UHD/4K resolution; when three or four Ultra HD displays set for UHD/4K resolution are connected the maximum screen refresh rate supported for all displays is 30 Hz. All displays set for resolutions lower than UHD/4K support a maximum screen refresh rate of 60 Hz.

NOTE: the screen refresh rate is set by default to 60 Hz. When configuring support for three or four displays @ UHD/4K resolution the screen refresh rate must be changed in the screen resolution settings to 30 Hz. This change should be made by an Administrator after disabling the Write Filter. The Write Filter should then be enabled after making the change.

AMD FirePro™ W2100 2 GB Professional Graphics (optional discrete graphics solution)

The AMD FirePro W2100 graphics board utilizes state-of-the-art professional GPU technologies to deliver outstanding professional 3D performance in a cost effective low profile package.

Performance and Features:

• AMD Graphics Core Next (GCN) architecture designed to effortlessly balance GPU compute and 3D workloads efficiently

• Optimized and certified for leading workstation ISV applications. The AMD FirePro™ professional graphics family is certified

on more than 100 different applications for reliable performance.

• AMD PowerTune and AMD ZeroCore Power technologies that allows for state-of-the-art dynamic power management of the

GPU

• Two (2) DisplayPort 1.2 outputs

QuickSpecs

HP t730 Thin Client

Technical specifications

c04743502 — DA – 15345 Worldwide — Version 7 — January 14, 2021

Page 6

• PCI Express® 3.0 compliant Technical Specifications

Form Factor

Low profile, half length

Graphics Controller

AMD FirePro W2100 professional graphics based on Oland GPU. GPU: 320 Stream processors organized into 5 Compute Units GPU Frequency: 630 Mhz Power: 26W Cooling: Active

Bus Type

PCI Express, Generation 3.0

Memory

2 GB DDR3 Bandwidth up to 28.8 GB/s Width: 128 bit

Connectors

2 x DisplayPort 1.2 No video cables or adapters are provided. Several aftermarket kits are available (see

Options and Accessories section at the end of this document).

Maximum Resolution

DisplayPort 1.2: up to 3840 x 2160 x 24 bpp @ 60 Hz Dual Link DVI-I: up to 2560 x 1600 x 32 bpp @ 60 Hz (requires DP to DL DVI-I adapter) Single Link DVI-I: up to 1920 x 1200 x 32 bpp @ 60 Hz (requires DP to SL DVI-I adapter) VGA: up to 1920 x 1200 x 32 bpp @ 60 Hz (requires DP to VGA adapter)

Image Quality Features

Advanced support for 8-bit, 10-bit and 16-bit per RGB color component. High bandwidth scaler for high quality up and down scaling.

Display Output

Maximum of 2 displays supported

Shading Architecture

Shader Model 5.0

Supported Graphics APIs

OpenCL™ 1.2, DirectX® 11.2/12, OpenGL 4.4 OpenGL 4.4 support with driver release 14.301.xxx OpenCL 1.2 conformance expected with drive release 14.301.xxx

The AMD FirePro W2100 supports a maximum screen refresh rate of 60 Hz for one Ultra HD display set for UHD/4K resolution; when two Ultra HD displays set for UHD/4K resolution are connected the maximum screen refresh rate supported for both displays is 30 Hz.

NOTE: the screen refresh rate is set by default to 60 Hz. When configuring support for two displays @ UHD/4K resolution the screen refresh rate must be changed in the screen resolution settings to 30 Hz. This change should be made by an Administrator after disabling the Write Filter. The Write Filter should then be enabled after making the change.

MEMORY

Type:

Dual Channel DDR3L SDRAM

Data Transfer Rate:

Up to 1,600 MT/s

Peak Transfer Rate:

12,800 MB/s

Number of Slots

2 x SODIMM

Capacities:

4 GB (1 x 4 GB) 8 GB (2 x 4 GB) 16 GB (2 x 8 GB)

Reserved for Graphics:

256 MB, 512 MB (default) or 1 GB

QuickSpecs

HP t730 Thin Client

Technical specifications

c04743502 — DA – 15345 Worldwide — Version 7 — January 14, 2021

Page 7

NOTE: The system’s Graphics Processing Unit (GPU) uses part of the total system memory. System memory dedicated to graphics performance is not available for use by other programs

STORAGE MEMORY

Type:

NAND flash memory; non-volatile

Number of Sockets:

1 x M.2

Capacities:

8 GB, 16 GB, 32 GB, 64 GB, 128 GB

Solid-state flash-based memory modules are the primary operating system storage media for thin clients supporting highly virtualized operating environments. Thin clients display a hosted session from a data center through standard IP networks which minimizes the required size of local flash-based storage. In a traditional thin client environment, data and application files are stored securely in the remote data center and not on the local storage device.

The HP t730 thin client uses three types of flash memory: MLC (2-bits per cell), Ultra MLC (2-bits per cell, but only 1 is utilized) and TLC (3-bits per cell). Because the classic thin client use cases seldom require writing to flash memory storage, a relatively low capacity MLC flash memory module is typically used to provide the best cost and performance. However, when the use case calls for writing to the local flash memory storage module careful consideration should be given to the selection of the proper storage module. A larger capacity and/or the use of Ultra MLC technology could be required to adequately support the usage being planned or expected from the thin client.

Flash Memory Specification

MLC (Multi-level Cell)

UMLC (Ultra MLC)

TLC (Triple-level Cell)

Bits per cell

2 (only 1 is used)

Terabytes Written (TBW) *

5 TBW* – 8GB 10 TBW* – 16GB 20 TBW* – 32GB

50 TBW* – 16GB 100 TBW* – 32GB

70 TBW* - 128GB

* Terabytes Written (TBW) calculated based on JESD-219 SSD Client workload

INPUT / OUTPUT

Keyboard

USB or PS/2 (varies by region)

Mouse

USB or PS/2 (varies by region)

Printer

Local and/or network printers (RDP, ICA, LPD)

Display / Monitor

All models include four (4) DisplayPort 1.2 digital video outputs supporting up to UHD/4K (3840 x 2160) resolution

Models can be configured with an optional AMD FirePro W2100 discrete graphics solution that provides two (2) additional digital video streams for a system total of six (6) video outputs

I/O PORTS, EXPANSION SLOTS & CONNECTORS

6 x Hi-Speed USB 2.0 ports (two in front, four in rear) 2 x SuperSpeed USB 3.0 ports (in front) 1 x SuperSpeed USB 3.0 ports (inside chassis) 4 x DisplayPort 1.2 digital video outputs (rear) 2 x PS/2 keyboard/mouse ports (rear) 2 x serial port (rear) 1 x parallel port (rear) 1 x RJ45 Ethernet port (rear) 1 x 3.5 mm headset port (front)
