HP SW452 Quick Start Guide

SW450

Digital Camera

Quick Start Guide

For more details about the camera operation and troubleshooting, please read the
User Manual located on the CDROM disc included with your camera or visit
http://www.hp.com/support and download it for the camera support page.

Getting Started

Attach the Camera Strap

To reduce the risk of dropping the camera, it is strongly recommended to attach and use
the provided camera strap.

To reduce the risk of dropping the camera, it is strongly
recommended to attach and use the provided camera strap.

Charging the Battery

The battery that comes along with your package is not fully charged. You need to charge
the battery before using the camera.

Insert the battery into the battery charger as 1.

shown.

Connect the power cord to the battery charger.2.
Plug the power cord to the main outlet.3.

The battery charging time is 2 hours.

1

Inserting the Battery

Follow these instructions to insert the battery into the battery/memory card compartment.

If the battery is already installed, make sure to 4.
power off the camera before removing and inserting a
recharged or new battery

Open the battery/memory card compartment at 5.
the bottom of the camera as illustrated

Insert the battery into the compartment with 6.
correct orientation as illustrated.

Close and secure the battery/memory card compartment.7.

2 3

Inserting an SD/SDHC Memory Card

It is highly recommended that the camera storage is expanded by inserting a SD or SDHC
memory card. These memory cards are available at most consumer store and online
locations

Make sure to power off the camera before proceeding. 1.
Inserting the memory card while powered on may damage
the card and camera.

Open the Battery/memory card compartment at the 2.
bottom of the camera

Insert the SD/SDHC card into the memory card slot with 3.
the metallic connectors facing the front side of the camera
as illustrated below.

Push the SD/SDHC card into the memory slot until it clicks into place. If the card does 4.
not click into place, repeat the previous step to ensure proper orientation.

Close the Battery/memory card compartment.5.

To remove the SD/SDHC card

Make sure to power off the camera before proceeding. 1.
Removing the memory card while powered on may damage
the card and camera.

Open the battery/memory card compartment. 2.

Gently push the card until it clicks and pushes our of 3.
position.

Carefully pull out the card.4.

4 5
