HP StorageWorks EVAInfo release notes
8.0
Par t number: T5494-96032
ifth edition: April 2008
F
Legal and notice information
© Copyright 2008 Hewlett-Packard Development Company, L.P.
Version: 8.0
Description
EVAInfo is a com
special files to LUNs presented from the EVAs to the server or host and the associated port and array
controller on the EVA. This document is specific to EVAInfo 8.0.
NOTE:
Starting with
Utility (SSSU) CD.
Update recommendation Routine
Synopsis
The evainfo [options][raw_device_file] comm a nd identifies the logical unit numbers (LUNs)
presented to a host from an HP EVA, and displays information about the connected port and c ontroller.
The command output also indicates if the device path is active and optimized for I/O for the LUN. The
active and optimized path information is s upported for HP StorageWorks 3000/5000 Enterprise Virtual
Array (EVA3000/5000) with Active/Active firmware, and HP StorageWorks 4x00/6x00/8x00 and
4400 Enterprise Virtual Array storage systems. The command is run as root or as a user with root
privileges.
IMPORTANT:
The command output is displayed in horizontal format, one LUN per line, and therefore is best viewed in
a window with a width of at least 80 columns. HP recommends that you use a window with a width of
at least 132 columns. However, the optional long format output contains more details and is optimally
viewed in an even wider window.
mand line utility developed for the HP Enterprise Virtual Array (EVA). It maps device
this version (8.0), EVAInfo is distributed on the HP StorageWorks Storage System Scripting
Product models
EVAInfo is supported on:
• EVA4x00/6x00/8x00
• EVA3000/5000 with Active/Active firmware
• EVA3000/5000 with Active/Passive firmware, with the restriction that controller information is not
displayed in the output
• EVA4400
Operating systems
EVAInfo is supported on the following operating systems: HP-UX 11.11 (PA), 11. 23 (PA and IA), 11.31
(PA and IA).
HP StorageWorks EVAInfo release notes 8.0
3
Installation instructions
Install EVAInfo from the HP StorageWorks System Scripting Utility (SSSU) CD that cam e with your HP
Command View
EVA media kit.
1. Download EVAInfo to a directory on the server or host.
2. Ensure that the binary file has execute permission.
You c an use th
e chmod command to set the execute permission. For example, # chmod 555
evainfo or # chmod u+x evainfo.
3. Execute the binary as root.
For a list of
supported options, enter # ./evainfo -h.
Options
This section describes the options available for the evainfo [options][raw_device_file]
command.
Basic options:
-a
-d raw_device
-h
-v
-W
-w wwn
Display information on all EVA LUNs presented to the host.
Display information for the specified EVA LUN:
F o r H P - U X 11.11 a n d 11. 2 3 , t h e r a w _ d e v i c e i s i n t h e f o r m a t /dev/rdsk/cXtYdZ
(for example, /dev/rdsk/c23t0d1).
Display help on options.
Display version details. When specified with other options, only the version
information appears.
Display device paths based on the LUN WWN.
Display information for the EVA LUN with the specified WWN.
Format options:
-f format
-l
-u unit
1
Devicefile, path, target, LUN, array, host port, vendor, product, revision, controller number, and WWN.
Display information in the specified format. The supported format values are tab
(default) and csv (comma-separated values).
1
Display information in long format, including all details
Display capacity in the specified unit. The supported unit values are KB, MB
(default) or GB.
about the LUN.
Platform specificoption:
-g
For HP-UX, specifying the -g option has no effect on processing or output
-P
-p
Display persistent device special files (HP-UX 11.31 with –a, –w, –W, and –l
options only).
Display agile device special files and their persistent device special files (HP-UX
11.31 with –a, –w, –W, and –l options only). See Sample Output.
NOTE:
EVAInfo might not display all possible device paths if Autopath is installed on your system.
4
Important note
sforHP-UX11.31systems
On systems runn
load_bal_pol
On systems run
Commands
Table 1 provides examples of commands executed from an HP-UX 11.23 system.
Table 1 HP-UX command examples
To obtain: Command example:
Usage information
Version
AlistofallEVALUNs
A list of all EVA LUNs in long format
AlistofallEV
comma-separ
AlistofallEVALUNsbasedonLUN
WWN
AlistforaspecificLUN
1
If the LUN is connected to an EVA3000/5000 (Active/Passive), the output does not provide controller, port, or mode
informatio
n.
ing HP-UX 11.31, EVAInfo might not display optimized paths. Use scsimgr
icy tosettheloadbalancepolicyfortheLUN.
ning HP-UX 11.31, EVAInfo with [-a -l -p] or [-a -l -P] op tions display the path as -1.
# ./evainfo-hpux_v11.11 -h
# ./evainfo-hpux_v11.11 -v
# ./evainfo-hpux_v11.11 -a
# ./evainfo-hpux_v11.11 -a –l
ALUNsin
ated values format
1
# ./evainfo-hpux_v11.11 -a –f csv
# ./evainfo-hpux_v11.11 -W
# ./evainfo-hpux_v11.11 -w 6005-08B4-0010-470B0001-1000-0457-0000
Sample output
Version example
#./evainfo-v
EVAInfo v8.0_071213
Agile device special file and its persistent device special file display
# ./evainfo_hpux_11.31_PARISC -a -p
Devicefile Array WWNN
Capacity Controller/Port/Mode
/dev/rdisk/disk5165 5000-1FE1-5002-E1B0 6005-08B4-0010-2AB1-0000-F000-0053-0000
10240MB Ctl-B/FP-2/NonOptimized
/dev/rdsk/c232t15d7 5000-1FE1-5002-E1B0 6005-08B4-0010-2AB1-0000-F000-0053-0000
10240MB Ctl-A/FP-1/Optimized
/dev/rdsk/c233t15d7 5000-1FE1-5002-E1B0 6005-08B4-0010-2AB1-0000-F000-0053-0000
10240MB Ctl-B/FP-2/NonOptimized
/dev/rdsk/c230t15d7 5000-1FE1-5002-E1B0 6005-08B4-0010-2AB1-0000-F000-0053-0000
10240MB Ctl-A/FP-1/Optimized
/dev/rdsk/c231t15d7 5000-1FE1-5002-E1B0 6005-08B4-0010-2AB1-0000-F000-0053-0000
10240MB Ctl-B/FP-2/NonOptimized
HP StorageWorks EVAInfo release notes 8.0
5
