The HP SC44Ge Host Bus Adapter provides customers with the flexibility and speed they have come to expect from HP. The SC44Ge
Host Bus Adapter is ideal for basic RAID (0, 1) and low cost connectivity to tape and HDDs. This adapter supports both 3G SAS and
1.5 G SATA devices. Providing up to 2 Gb/s maximum bandwidth, this HBA provides nearly four times the speed of a dual channel
U320 SCSI adapters. The HP SC44Ge Host Bus Adapter has been thoroughly tested and integrated into many of the HP ProLiant
and Integrity servers. The SC44Ge supports both a 1 x4 internal connection and a 1 x4 external connection.
What's New
What's NewWhat's New
What's New
Updating supported hard drives.
Models
ModelsModels
Models
Serial Attached SCSI (SAS)
Serial Attached SCSI (SAS)Serial Attached SCSI (SAS)
Serial Attached SCSI (SAS)
HBA
HBAHBA
HBA
HP Modular Smart Array SC44Ge 1-ports Int/1-ports Ext PCIe x8 SAS Host Bus
Adapter
416096-B21
HP PCIe SC44Ge SAS Host Bus Adapter
NOTE:
NOTE:NOTE:
NOTE:
This adapter supports Integrity servers only.
AH303A
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Overview
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 1
Page 2
Compatibility
CompatibilityCompatibility
Compatibility
Supported Servers
Supported ServersSupported Servers
Supported Servers
ProLiant DL (rack-optimized)
ProLiant DL (rack-optimized)ProLiant DL (rack-optimized)
ProLiant DL (rack-optimized)
:
HP ProLiant DL120 G5
HP ProLiant DL140 G2
HP ProLiant DL140 G3
HP ProLiant DL145 G3
HP ProLiant DL160 G5
HP ProLiant DL160 G5 Storage
HP ProLiant DL165 G5
HP ProLiant DL165 G5p
HP ProLiant DL180
HP ProLiant DL180 G5
HP ProLiant DL185
HP ProLiant DL185 G5 Storage
HP ProLiant DL320 G4
HP ProLiant DL320 G5
HP ProLiant DL320 G5p
HP ProLiant DL320s
NOTE:
NOTE:NOTE:
NOTE:
External Tape support only
HP ProLiant DL360 G5
HP ProLiant DL365
HP ProLiant DL365 G5
HP ProLiant DL380 G5
HP ProLiant DL380 G5 Storage
HP ProLiant DL385 G2
HP ProLiant DL385 G5
HP ProLiant DL385 G5p
HP ProLiant DL580 G4
HP ProLiant DL580 G5
HP ProLiant DL585 G2
HP ProLiant DL585 G5
HP ProLiant DL785 G5
ProLiant ML (expansion-optimized)
ProLiant ML (expansion-optimized)ProLiant ML (expansion-optimized)
ProLiant ML (expansion-optimized)
:
HP ProLiant ML110 G4
HP ProLiant ML110 G5
HP ProLiant ML110 G5 Storage
HP ProLiant ML115
HP ProLiant ML115 G5
HP ProLiant ML150 G3
HP ProLiant ML150 G5
HP ProLiant ML310 G3
HP ProLiant ML310 G4
HP ProLiant ML310 G5
HP ProLiant ML310 G5p
HP ProLiant ML350 G5
HP ProLiant ML370 G4
HP ProLiant ML370 G5
HP ProLiant ML570 G4
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Overview
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 2
Page 3
Integrity Servers (RAID not supported. External Port connections only)
Integrity Servers (RAID not supported. External Port connections only)Integrity Servers (RAID not supported. External Port connections only)
Integrity Servers (RAID not supported. External Port connections only)
:
HP Integrity Rx 2660
HP Integrity Rx 3600
HP Integrity Rx 6600
HP Integrity Rx 7640
HP Integrity Rx 8640
HP Superdome sx2000 (PCI-e models only)
NOTE:
NOTE:NOTE:
NOTE:
This is a list of supported servers. Some may be discontinued.
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Overview
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 3
Page 4
Performance
PerformancePerformance
Performance
Designed to be as flexible as HP servers, the HP SC44Ge Host Bus Adapter provides support for up to 8
devices (with support for even greater numbers when connected to devices with SAS expander
technology). The HP adapter delivers exceptional system performance, with eight 3 Gbps SAS ports
providing up to 24 Gb/s total storage bandwidth.
HP Server Integration
HP Server IntegrationHP Server Integration
HP Server Integration
Fully integrated and tested with most HP ProLiant servers and management software.
Key Features
Key FeaturesKey Features
Key Features
SAS technology delivers high performance and data bandwidth up to 3 Gbps per physical link
Mix-and-match SAS and SATA hard drives, lets you deploy drive technology as needed to fit your
computing environment (ProLiant systems only)
Support for SAS tape products
PCIe x8 (2.5 Gb/s bandwidth)
PCI Express x8 capable
Ports
PortsPorts
Ports
Eight (8) SAS physical links distributed across 1 x4 internal SFF-8484 and 1x4 external SFF-8470
connectors
Provides the ability to support up to 8 devices in a RAID configuration (additional drives
supported through expander technology) or 3.6TB of SAS storage when connected to an
MSA70 external drive enclosure with (25) 146GB drives (HP-UX and OpenVMS only).
Performance
PerformancePerformance
Performance
HP's High Performance Architecture sets new boundaries for industry performance expectations!
Transfer rate: 3 Gbps SAS, 1.5 Gb/s SATA (bandwidth per physical link)
24 Gbps total available bandwidth (8 physical links x 3Gbps)
PCIe x8 (2.5 Gb/s bandwidth)
Capacity
CapacityCapacity
Capacity
Given the increasing need for high performance and rapid capacity expansion, the SC44Ge SAS HBA
with RAID offers:
Eight 3 Gbps SAS physical links supporting up to 2 simultaneous x4 Wide SAS Ports
Up to 3.6TB of storage per PCI slot of SAS storage when connected to an MSA70 external drive
enclosure with (25) 146GB drives (HP-UX and OpenVMS only).
Fault Tolerance
Fault ToleranceFault Tolerance
Fault Tolerance
Keeps data available and server running while a failed drive is being replaced (ProLiant models only)
Drive Mirroring (RAID 1): This allocates half of the drive array to data and the other half to
mirrored data, providing two copies of every file.
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Standard Features
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 4
Page 5
Supported Enclosures
Supported EnclosuresSupported Enclosures
Supported Enclosures
50 Modular Smart Array
Supports one MSA50 - additional tiered enclosures are not supported
60 Modular Smart Array (only in HP-UX and OpenVMS environments with selected HP Integrity
Servers only)
Supports 1+3 MSA60's cascaded off the single x4 port - additional tiered enclosures are
not supported
70 Modular Smart Array (only in HP-UX and OpenVMS environments with selected HP Integrity
Servers only)
Supports 1+1 MSA70's cascaded off the single x4 external port - additional tiered
enclosures are not supported
Operating Systems
Operating SystemsOperating Systems
Operating Systems
Microsoft Windows 2003 Standard 32 Bit
Microsoft Windows 2003 Enterprise 32 Bit
Microsoft Windows 2003 Web
Microsoft Windows 2003 SBS
Microsoft Windows 2003 Standard x64
Microsoft Windows 2003 Enterprise x64
Microsoft Windows Server 2008
SCO UnixWare 7.1.3
SCO UnixWare 7.1.4
SCO Openserver 6.0.0
HP-UX 11iv2 and 11iv3
OpenVMS V8.3-1H1
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
NOTE:
NOTE:NOTE:
NOTE:
For more Linux OS support & certification information, please visit our the ProLiant &
BladeSystem Server Linux matrix:
http://h18004.www1.hp.com/products/servers/linux/hplinuxcert.html
LSI Off Line
LSI Off LineLSI Off Line
LSI Off Line
LSI Off Line option ROM Utility
Warranty
WarrantyWarranty
Warranty
The warranty for this device is 1 year parts only.
Warranty Upgrade Options
Warranty Upgrade OptionsWarranty Upgrade Options
Warranty Upgrade Options
Response - Upgrade on-site response from next business day to same day 4 hours
Coverage - Extend hours of coverage from 9 hours x 5 days to 24 hours x 7 days
Duration - Select duration of coverage for a period of 1, 3, or 5 years
Warranty upgrade options can come in the form of Care Packs, which are sold at the HP System
level this product attaches too
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Standard Features
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 5
Page 6
Service and Support
Service and SupportService and Support
Service and Support
HP Care Pack Services: Packaged server and storage services for increased uptime, productivity and
HP Care Pack Services: Packaged server and storage services for increased uptime, productivity andHP Care Pack Services: Packaged server and storage services for increased uptime, productivity and
HP Care Pack Services: Packaged server and storage services for increased uptime, productivity and
ROI
ROIROI
ROI
When you buy HP server and storage products and solutions, it's also a good time to think about what
levels of support you may need. Our portfolio of service options reduce deployment and management
worries while helping you get the most out of your server and storage investments. We take a holistic
approach to your environment, bridging servers, blades, storage, software and network infrastructures
with our packaged HP Care Pack Services for servers and storage.
Protect your business beyond warranty
Protect your business beyond warrantyProtect your business beyond warranty
Protect your business beyond warranty
When it comes to robustness and reliability, standard computing equipment warranties have matured
along with technology. Good news that can also create problems stemming from depending on standard
warranties designed to only protect against product defects and some downtime causes. Using a
standard approach to warranty uplifts, such as HP Care Pack Services, helps reduce downtime risks and
provides operational consistency for mission-critical and standard business computing.
HP Care Pack Services: Upgrading or extending standard server and storage warranties cost
HP Care Pack Services: Upgrading or extending standard server and storage warranties costHP Care Pack Services: Upgrading or extending standard server and storage warranties cost
HP Care Pack Services: Upgrading or extending standard server and storage warranties cost
effectively
effectivelyeffectively
effectively
HP Care Pack Services offer a standard reactive hardware and software support services suite sold
separately, or combined with our Support Plus and Support Plus 24 services. The portfolio also provides
a combination of integrated proactive and reactive services, such as Proactive 24 Service and Critical
Service. In addition with HP Proactive Select, you can acquire the specific proactive constancy and
technical services. HP Proactive Select menu offers a broad set of service options that you can mix and
match depending on your specific requirements. Proactive service options include offers for server,
storage, network, SAN device, software, environment and education services.
HP server and storage lifecycle support services offers a full spectrum of customer care-from technology
support to complex migrations to complete managed services. HP Factory Express provides
customization, integration and deployment services for turnkey solutions. HP Education Services offer
flexible, comprehensive training on to help your IT staff get the most out of your server and storage
investments. HP Financial solutions extend innovative financing and cost-effective asset management
programs-from purchase to equipment retirement.
Learn more:
www.hp.com/services/servers
and
www.hp.com/services/storage
NOTE:
NOTE:NOTE:
NOTE:
Care Pack Services availability may vary by product and country.
HP Care Pack Services are sold by HP and HP Authorized Service Partners:
Services for customers purchasing from HP or an enterprise reseller are quoted using HP order
configuration tools.
Customers purchasing from a commercial reseller can find HP Care Pack Services at
http://www.hp.com/go/lookuptool
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Service and Support
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 6
Page 7
Recommended HP Care Pack Services for optimal satisfaction with your HP product
Recommended HP Care Pack Services for optimal satisfaction with your HP productRecommended HP Care Pack Services for optimal satisfaction with your HP product
Recommended HP Care Pack Services for optimal satisfaction with your HP product
Recommended Services
Recommended ServicesRecommended Services
Recommended Services
Hardware Options Support
Hardware Options SupportHardware Options Support
Hardware Options Support
HP Care Packs provide support for all HP-branded hardware options qualified for inclusion in your server
or storage solution. Any additional HP-qualified options installed within the server are covered at the
same service level and for the same period as the server and no additional cost.
Help improve or maintain system uptime
Convenient onsite support
Committed response time
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EEE
3-Year HP Hardware Support Onsite Service, 4-hour response, 24x7
3-Year HP Hardware Support Onsite Service, 4-hour response, 24x73-Year HP Hardware Support Onsite Service, 4-hour response, 24x7
3-Year HP Hardware Support Onsite Service, 4-hour response, 24x7
Provides you with rapid remote support and if required an HP authorized representative who will arrive
on site any time and day of the year to begin hardware maintenance service within 4 hours of the service
request being logged.
This service provides a trained HP service specialist to perform an installation that meets HP quality
standards, for:
Help improve or maintain system uptime
Convenient onsite support
Committed response time
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EEE
HP Installation and Startup of HP ProLiant Servers
HP Installation and Startup of HP ProLiant ServersHP Installation and Startup of HP ProLiant Servers
HP Installation and Startup of HP ProLiant Servers
Provides for the installation of your new HP ProLiant server and operating system to assist you in bringing
your new HP ProLiant server and operating system into operation in a timely and professional manner.
This service provides a trained HP service specialist to perform an installation that meets HP quality
standards, for:
Delivery of the service at a mutually scheduled time convenient to your organization
Availability of an HP service specialist to answer basic questions during the onsite delivery of this
service
Custom installation as detailed in "Delivery specifications" or in a Statement of Work (SOW)
Verification prior to installation that all service prerequisites are met
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982?7572ENN
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Service and Support
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 7
Page 8
Optional HP Care Pack Services that will enhance your HP product experience
Optional HP Care Pack Services that will enhance your HP product experienceOptional HP Care Pack Services that will enhance your HP product experience
Optional HP Care Pack Services that will enhance your HP product experience
Optional Services
Optional ServicesOptional Services
Optional Services
3-Year HP Hardware Support Onsite Call-to-Repair (CTR) Service, 6- or 24-hour
3-Year HP Hardware Support Onsite Call-to-Repair (CTR) Service, 6- or 24-hour3-Year HP Hardware Support Onsite Call-to-Repair (CTR) Service, 6- or 24-hour
3-Year HP Hardware Support Onsite Call-to-Repair (CTR) Service, 6- or 24-hour
As an alternative to our recommended support level, for customers who need committed call-to-repair
for server hardware.
Provides your IT manager with a team of support specialists who will quickly begin troubleshooting the
system to help return the hardware to operating condition within 6 or 24 hours of the initial service
request to the HP Global Solution Center.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-6547EN.pdf
3-Year HP Support Plus 24
3-Year HP Support Plus 243-Year HP Support Plus 24
3-Year HP Support Plus 24
As an alternative to our recommended support level, for customers who need access to responsive 24x7
hardware and software support plus software updates on HP and selected third party products:
For a higher return on your server and storage technology, our 3-year combined reactive support service
delivers integrated onsite hardware/software support services available 24x7x365, including access to
HP technical resources, 4-hour response onsite hardware support and software updates.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6638EEE
HP Proactive Select Service
HP Proactive Select ServiceHP Proactive Select Service
HP Proactive Select Service
Customer needs on demand access to consulting, technical proactive services and education courses
Provides a flexible way to purchase HP best-in-class consultancy and technical services. You can buy
Proactive Select Service Credits when you purchase your hardware and then use the credits over the next
12 months.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENN
eSupport
eSupporteSupport
eSupport
HP eSupport is a portfolio of technology-based services that assist you with managing your business
environment - from the desktop to the data center.
Support Portal
Support PortalSupport Portal
Support Portal
The HP support portal provides one-stop access to the information, tools and services you need to
manage the daily operations of your IT environment.
Features include
Features includeFeatures include
Features include
:
Access to self-solve tools (including search technical knowledge base)
Efficient logging and tracking of support cases
Collaboration with other business and IT professionals
Download of patches and drivers
Access to diagnostic tools
Proactive notification of relevant information
Access to certain features of the support portal requires an HP service agreement. To access the support
portal, visit:
http://www.hp.com/support
HP Insight Remote Support software delivers secure remote support for your HP Servers and Storage, 24
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Service and Support
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 8
Page 9
X 7, so you can spend less time solving problems and more time focused on your business. You can have
your systems remotely monitored for hardware failure using secure technology that's been proven at
thousands of companies around the world. In many cases, you can avoid problems before they occur.
Customer Technical
Customer TechnicalCustomer Technical
Customer Technical
Training
TrainingTraining
Training
In today's cost-conscious business environment, IT professionals, developers, consultants and users face
an interesting challenge: how to keep up with the latest technologies and expand important skills while
delivering profitable results on current projects. To help address this challenge, HP offers innovative
training solutions that help keep you up-to-date on virtualization, server, storage, Insight Control, Citrix,
Microsoft® and open source/Linux-related topics-while spending less time away from business-critical
activities.
HP Services Awards
HP Services AwardsHP Services Awards
HP Services Awards
HP Technology Services continues to be recognized for service and support excellence by customers,
partners, industry organizations and publications around the world. Recent honors and award reflect our
services team's dedications, technical expertise, professionalism and uncompromising commitment to
customer satisfaction.
Additional Services
Additional ServicesAdditional Services
Additional Services
Information
InformationInformation
Information
To learn more on HP ProLiant servers, HP BladeSystem servers and HP storage products, please contact
your HP sales representative or HP Authorized Channel Partner. Or visit:
www.hp.com/services/proliant
or
www.hp.com/services/bladesystem
or
http://www.hp.com/hps/storage
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Service and Support
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 9
Page 10
NOTE:
NOTE:NOTE:
NOTE:
This is a list of supported options. Some may be discontinued.
Hard Drives
Hard DrivesHard Drives
Hard Drives
NOTE:
NOTE:NOTE:
NOTE:
The components of a storage subsystem (e.g. the drive, the HBA/controller,
firmware, and the server backplane) should operate at the same data transfer rate or
the system bandwidth will be negotiated down to an acceptable level for all
components.
NOTE:
NOTE:NOTE:
NOTE:
Hard drives have either a one year or three year warranty; refer to the specific
hard drive QuickSpecs for details.
SAS Hot Plug SFF (2.5-inch) Enterprise (ENT) Drives
SAS Hot Plug SFF (2.5-inch) Enterprise (ENT) DrivesSAS Hot Plug SFF (2.5-inch) Enterprise (ENT) Drives
SAS Hot Plug SFF (2.5-inch) Enterprise (ENT) Drives
HP 900GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
619291-B21
HP 600GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
581286-B21
HP 450GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
581284-B21
HP 300GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
507127-B21
HP 300GB 3G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
492620-B21
HP 146GB 6G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
512547-B21
HP 146GB 3G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
504062-B21
HP 146GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
507125-B21
HP 146GB 3G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
418367-B21
HP 72GB 6G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
512545-B21
HP 72GB 3G SAS 15K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
418371-B21
HP 72GB 10K rpm Hot Plug SAS 2.5 Dual Port Hard Drive
384842-B21
SAS Non-Hot Plug SFF (2.5-inch) Enterprise (ENT) Drives
SAS Non-Hot Plug SFF (2.5-inch) Enterprise (ENT) DrivesSAS Non-Hot Plug SFF (2.5-inch) Enterprise (ENT) Drives
SAS Non-Hot Plug SFF (2.5-inch) Enterprise (ENT) Drives
HP 600GB 6G SAS 10K rpm SFF (2.5-inch) Non-hot Plug Dual Port Enterprise 3yr
Warranty Hard Drive
590698-B21
HP 300GB 6G SAS 10K rpm SFF (2.5-inch) Non-hot Plug Dual Port Enterprise 3yr
Warranty Hard Drive
537809-B21
HP 146GB 6G SAS 10K rpm SFF (2.5-inch) Non-hot Plug Dual Port Enterprise 3yr
Warranty Hard Drive
537807-B21
HP 72GB 6G SAS 15K rpm SFF (2.5-inch) Non-hot Plug Dual Port Enterprise 3yr
Warranty Hard Drive
537805-B21
SAS Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives
SAS Hot Plug LFF (3.5-inch) Enterprise (ENT) DrivesSAS Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives
SAS Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives
HP 600GB 6G SAS 15K rpm LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
516828-B21
HP 450GB 6G SAS 15K rpm LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
516816-B21
HP 450GB 3G SAS 15K rpm LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
454232-B21
HP 400GB 10K rpm Hot Plug SAS 3.5 Dual Port Enterprise Hard Drive
459508-B21
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Related Options
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 10
Page 11
HP 300GB 6G SAS 15K rpm LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
516814-B21
HP 300GB 3G SAS 15K rpm LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
416127-B21
HP 146GB 3G SAS 15K rpm LFF (3.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
384854-B21
HP 72GB 15K rpm Hot Plug SAS 3.5 Dual Port Hard Drive
384852-B21
SAS Non-Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives
SAS Non-Hot Plug LFF (3.5-inch) Enterprise (ENT) DrivesSAS Non-Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives
SAS Non-Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives
HP 600GB 6G SAS 15K rpm LFF (3.5-inch) Non-hot Plug Dual Port Enterprise 3yr
Warranty Hard Drive
516830-B21
HP 450GB 6G SAS 15K rpm LFF (3.5-inch) Non-hot Plug Dual Port Enterprise 3yr
Warranty Hard Drive
516826-B21
HP 450GB 3G SAS 15K rpm LFF (3.5-inch) Non-hot Plug Dual Port Enterprise 3yr
Warranty Hard Drive
454234-B21
HP 400GB 10K rpm Non Hot Plug SAS 3.5 Dual Port Enterprise Hard Drive
508232-B21
HP 300GB 6G SAS 15K rpm LFF (3.5-inch) Non-hot Plug Dual Port Enterprise 3yr
Warranty Hard Drive
516824-B21
HP 300GB 3G SAS 15K rpm LFF (3.5-inch) Non-hot Plug Dual Port Enterprise 3yr
Warranty Hard Drive
417950-B21
HP 146GB 3G SAS 15K rpm LFF (3.5-inch) Non-hot Plug Dual Port Enterprise 3yr
Warranty Hard Drive
417855-B21
SAS Hot Plug SFF (2.5-inch) Midline (MDL) Drives
SAS Hot Plug SFF (2.5-inch) Midline (MDL) DrivesSAS Hot Plug SFF (2.5-inch) Midline (MDL) Drives
SAS Hot Plug SFF (2.5-inch) Midline (MDL) Drives
HP 900GB 6G SAS 10K rpm SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard
Drive
605835-B21
HP 500GB 6G SAS 7.2K rpm SFF (2.5-inch) Dual Port Midline 1yr Warranty Hard
Drive
507610-B21
SAS Hot Plug LFF (3.5-inch) Midline (MDL) Drives
SAS Hot Plug LFF (3.5-inch) Midline (MDL) DrivesSAS Hot Plug LFF (3.5-inch) Midline (MDL) Drives
SAS Hot Plug LFF (3.5-inch) Midline (MDL) Drives
HP 3TB 6G SAS 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive
625031-B21
HP 2TB 6G SAS 7.2K rpm LFF (3.5-inch) Dual Port Midline 1yr Warranty Hard Drive
507616-B21
HP 1TB 6G SAS 7.2K rpm LFF (3.5-inch) Dual Port Midline 1yr Warranty Hard Drive
507614-B21
HP 1TB 3G SAS 7.2K rpm LFF (3.5-inch) Dual Port Midline 1yr Warranty Hard Drive
461137-B21
HP 750GB 3G SAS 7.2K rpm LFF (3.5-inch) Dual Port Midline 1yr Warranty Hard
Drive
461135-B21
SAS Hot Plug SFF Enterprise (ENT) Drives
SAS Hot Plug SFF Enterprise (ENT) DrivesSAS Hot Plug SFF Enterprise (ENT) Drives
SAS Hot Plug SFF Enterprise (ENT) Drives
HP 146GB 10K rpm Hot Plug SAS 2.5 Single Port Hard Drive
431958-B21
HP 72GB 10K rpm Hot Plug SAS 2.5 Hard Drive
375861-B21
HP 72GB 15K rpm Hot Plug SAS 2.5 Single Port Hard Drive
431935-B21
HP 36GB 15K rpm Hot Plug SAS 2.5 Single Port Hard Drive
431933-B21
SAS Hot Plug 3.5" Enterprise (ENT) Drives
SAS Hot Plug 3.5" Enterprise (ENT) DrivesSAS Hot Plug 3.5" Enterprise (ENT) Drives
SAS Hot Plug 3.5" Enterprise (ENT) Drives
HP 300GB 15K rpm Hot Plug SAS 3.5 Single Port Hard Drive
431944-B21
HP 146GB 15K rpm Hot Plug SAS 3.5 Single Port Hard Drive
375872-B21
HP 72GB 15K rpm Hot Plug SAS 3.5 Single Port Hard Drive
375870-B21
SAS Non-Hot Plug 3.5" Enterprise (ENT) Drives
SAS Non-Hot Plug 3.5" Enterprise (ENT) DrivesSAS Non-Hot Plug 3.5" Enterprise (ENT) Drives
SAS Non-Hot Plug 3.5" Enterprise (ENT) Drives
HP 300GB 15K rpm Non Hot Plug SAS 3.5 Single Port Hard Drive
431950-B21
HP 146GB 15K rpm Non Hot Plug SAS 3.5 Single Port Hard Drive
432093-B21
HP 72GB 15K rpm Non Hot Plug SAS 3.5 Single Port Hard Drive
432095-B21
SATA Hot Plug SFF (2.5-inch) Midline (MDL) Drives
SATA Hot Plug SFF (2.5-inch) Midline (MDL) DrivesSATA Hot Plug SFF (2.5-inch) Midline (MDL) Drives
SATA Hot Plug SFF (2.5-inch) Midline (MDL) Drives
HP 1TB 3G SATA 7.2K rpm SFF (2.5-inch) Hot Plug Midline 1yr Warranty Hard Drive
625609-B21
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Related Options
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 11
Page 12
HP 500GB 3G SATA 7.2K rpm SFF (2.5-inch) Midline 1yr Warranty Hard Drive
507750-B21
HP 160GB 3G SATA 7.2K rpm SFF (2.5-inch) Midline 1yr Warranty Hard Drive
530888-B21
SATA Non-Hot Plug SFF (2.5-inch) Midline (MDL) Drives
SATA Non-Hot Plug SFF (2.5-inch) Midline (MDL) DrivesSATA Non-Hot Plug SFF (2.5-inch) Midline (MDL) Drives
SATA Non-Hot Plug SFF (2.5-inch) Midline (MDL) Drives
HP 500GB 3G SATA 7.2K rpm SFF (2.5-inch) Non-hot Plug Midline 1yr Warranty
Hard Drive
507753-B21
HP 160GB 3G SATA 7.2K rpm SFF (2.5-inch) Non-hot Plug Midline 1yr Warranty
Hard Drive
530891-B21
SATA Hot Plug LFF (3.5-inch) Midline (MDL) Drives
SATA Hot Plug LFF (3.5-inch) Midline (MDL) DrivesSATA Hot Plug LFF (3.5-inch) Midline (MDL) Drives
SATA Hot Plug LFF (3.5-inch) Midline (MDL) Drives
HP 3TB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive
628059-B21
HP 2TB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive
507632-B21
HP 1TB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive
454146-B21
HP 750GB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive
458930-B21
HP 500GB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive
458928-B21
HP 250GB 3G SATA 7.2K rpm LFF (3.5-inch) Midline 1yr Warranty Hard Drive
458926-B21
SATA Non-Hot Plug LFF (3.5-inch) Midline (MDL) Drives
SATA Non-Hot Plug LFF (3.5-inch) Midline (MDL) DrivesSATA Non-Hot Plug LFF (3.5-inch) Midline (MDL) Drives
SATA Non-Hot Plug LFF (3.5-inch) Midline (MDL) Drives
HP 3TB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot plug Midline 1yr Warranty Hard
Drive
628063-B21
HP 2TB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Midline 1yr Warranty Hard
Drive
507774-B21
HP 1TB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Midline 1yr Warranty Hard
Drive
507772-B21
HP 750GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Midline 1yr Warranty
Hard Drive
462595-B21
HP 500GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Midline 1yr Warranty
Hard Drive
458941-B21
HP 250GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Midline 1yr Warranty
Hard Drive
458939-B21
SATA Hot Plug SFF (2.5-inch) Entry (ETY) Drives
SATA Hot Plug SFF (2.5-inch) Entry (ETY) DrivesSATA Hot Plug SFF (2.5-inch) Entry (ETY) Drives
SATA Hot Plug SFF (2.5-inch) Entry (ETY) Drives
HP 250GB 3G SATA 5.4K rpm SFF (2.5-inch) Entry 1yr Warranty Hard Drive
460355-B21
HP 120GB 1.5G SATA 5.4K rpm SFF (2.5-inch) Entry 1yr Warranty Hard Drive
458924-B21
SATA Non-Hot Plug SFF (2.5-inch) Entry (ETY) Drives
SATA Non-Hot Plug SFF (2.5-inch) Entry (ETY) DrivesSATA Non-Hot Plug SFF (2.5-inch) Entry (ETY) Drives
SATA Non-Hot Plug SFF (2.5-inch) Entry (ETY) Drives
HP 500GB 3G SATA 7.2K rpm SFF (2.5-inch) Non-hot plug Entry 1yr Warranty Hard
Drive
628033-B21
HP 250GB 3G SATA 5.4K rpm SFF (2.5-inch) Non-hot Plug Entry 1yr Warranty Hard
Drive
460357-B21
HP 120GB 1.5G SATA 5.4K rpm SFF (2.5-inch) Non-hot Plug Entry 1yr Warranty
Hard Drive
459357-B21
SATA Hot Plug LFF (3.5-inch) Entry (ETY) Drives
SATA Hot Plug LFF (3.5-inch) Entry (ETY) DrivesSATA Hot Plug LFF (3.5-inch) Entry (ETY) Drives
SATA Hot Plug LFF (3.5-inch) Entry (ETY) Drives
HP 250GB 3G SATA 7.2K rpm LFF (3.5-inch) Entry 1yr Warranty Hard Drive
571230-B21
HP 160GB 3G SATA 7.2K rpm LFF (3.5-inch) Entry 1yr Warranty Hard Drive
458945-B21
SATA Non-Hot Plug LFF (3.5-inch) Entry (ETY) Drives
SATA Non-Hot Plug LFF (3.5-inch) Entry (ETY) DrivesSATA Non-Hot Plug LFF (3.5-inch) Entry (ETY) Drives
SATA Non-Hot Plug LFF (3.5-inch) Entry (ETY) Drives
HP 250GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Entry 1yr Warranty Hard
Drive
571232-B21
HP 160GB 3G SATA 7.2K rpm LFF (3.5-inch) Non-hot Plug Entry 1yr Warranty Hard
Drive
458947-B21
3.5" SATA Hot Plug Drives
3.5" SATA Hot Plug Drives3.5" SATA Hot Plug Drives
3.5" SATA Hot Plug Drives
HP 80GB 7.2K rpm Hot Plug SATA 1yr Warranty Hard Drive
349237-B21
3.5" SATA Non-Hot Plug Drives
3.5" SATA Non-Hot Plug Drives3.5" SATA Non-Hot Plug Drives
3.5" SATA Non-Hot Plug Drives
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Related Options
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 12
Page 13
HP 80GB 7.2K rpm Non Hot Plug SATA 1yr Warranty Hard Drive
383410-B21
SATA Hot Plug 2.5" Enterprise Mainstream Solid State Drives
SATA Hot Plug 2.5" Enterprise Mainstream Solid State DrivesSATA Hot Plug 2.5" Enterprise Mainstream Solid State Drives
SATA Hot Plug 2.5" Enterprise Mainstream Solid State Drives
HP 400GB 3G SATA MLC SFF (2.5-inch) Enterprise Mainstream 3yr Warranty Solid
State Drive
636597-B21
HP 200GB 3G SATA MLC SFF (2.5-inch) Enterprise Mainstream 3yr Warranty Solid
State Drive
636595-B21
HP 120GB 3G SATA SFF (2.5-inch) Midline 1yr Warranty Solid State Drive
572073-B21
HP 100GB 3G SATA MLC SFF (2.5-inch) Enterprise Mainstream 3yr Warranty Solid
State Drive
636593-B21
HP 60GB 3G SATA SFF (2.5-inch) Midline 1yr Warranty Solid State Drive
572071-B21
SATA Hot Plug 3.5" Midline (MDL) Solid State Drives
SATA Hot Plug 3.5" Midline (MDL) Solid State DrivesSATA Hot Plug 3.5" Midline (MDL) Solid State Drives
SATA Hot Plug 3.5" Midline (MDL) Solid State Drives
HP 400GB 3G SATA MLC LFF (3.5-inch) Enterprise Mainstream 3yr Warranty Solid
State Drive
636611-B21
HP 200GB 3G SATA MLC LFF (3.5-inch) Enterprise Mainstream 3yr Warranty Solid
State Drive
636609-B21
HP 120GB 3G SATA LFF (3.5-inch) Midline 1yr Warranty Solid State Drive
570763-B21
HP 100GB 3G SATA MLC LFF (3.5-inch) Enterprise Mainstream 3yr Warranty Solid
State Drive
636607-B21
HP 60GB 3G SATA LFF (3.5-inch) Midline 1yr Warranty Solid State Drive
570761-B21
SATA Non-hot Plug 2.5" Midline (MDL) Solid State Drives
SATA Non-hot Plug 2.5" Midline (MDL) Solid State DrivesSATA Non-hot Plug 2.5" Midline (MDL) Solid State Drives
SATA Non-hot Plug 2.5" Midline (MDL) Solid State Drives
HP 400GB 3G SATA MLC SFF (2.5-inch) Non-hot plug Enterprise Mainstream 3yr Wty
Solid State Drive
636605-B21
HP 200GB 3G SATA MLC SFF (2.5-inch) Non-hot plug Enterprise Mainstream 3yr Wty
Solid State Drive
636601-B21
HP 120GB 3G SATA SFF (2.5-inch) Non-hot plug Midline 1yr Wty Solid State Drive
572077-B21
HP 100GB 3G SATA MLC SFF (2.5-inch) Non-hot plug Enterprise Mainstream 3yr Wty
Solid State Drive
636599-B21
HP 60GB 3G SATA SFF (2.5-inch) Non-hot plug Midline 1yr Wty Solid State Drive
572075-B21
6G SAS Hot Plug Enterprise Performance Solid State Drives
6G SAS Hot Plug Enterprise Performance Solid State Drives6G SAS Hot Plug Enterprise Performance Solid State Drives
6G SAS Hot Plug Enterprise Performance Solid State Drives
HP 200GB 6G SAS SLC SFF (2.5-inch) Enterprise Performance 3yr Warranty Solid
State Drive
632492-B21
HP 400GB 6G SAS SLC SFF (2.5-inch) Enterprise Performance 3yr Warranty Solid
State Drive
632494-B21
6G SAS Hot Plug Enterprise Mainstream Solid State Drives
6G SAS Hot Plug Enterprise Mainstream Solid State Drives6G SAS Hot Plug Enterprise Mainstream Solid State Drives
6G SAS Hot Plug Enterprise Mainstream Solid State Drives
HP 200GB 6G SAS MLC SFF (2.5-inch) Enterprise Mainstream 3yr Warranty Solid
State Drive
632502-B21
HP 400GB 6G SAS MLC SFF (2.5-inch) Enterprise Mainstream 3yr Warranty Solid
State Drive
632504-B21
HP 800GB 6G SAS MLC SFF (2.5-inch) Enterprise Mainstream 3yr Warranty Solid
State Drive
632506-B21
NOTE:
NOTE: NOTE:
NOTE:
Go to the HP Hard Drive Compatibility table for complete drive compatibility
information (
http://www.hp.com/products/harddiskdrives
). Using hard drives in
unsupported configurations will result in voiding the warranty and could result in
damage to the drive and/or loss of data.
NOTE:
NOTE:NOTE:
NOTE:
When using the SC44Ge with SATA Hard Drives, 1.5G SATA Hard Drives are
required.
Tape Storage
Tape StorageTape Storage
Tape Storage
Tape Drives
Tape DrivesTape Drives
Tape Drives
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Related Options
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 13
Page 14
DAT Tape Drives (Integrity support for External only)
DAT Tape Drives (Integrity support for External only)DAT Tape Drives (Integrity support for External only)
DAT Tape Drives (Integrity support for External only)
HP DAT 160 SAS Internal Tape Drive
Q1587A
HP DAT 160 SAS External Tape Drive
Q1588A
LTO Ultrium Tape Drives
LTO Ultrium Tape DrivesLTO Ultrium Tape Drives
LTO Ultrium Tape Drives
HP Ultrium 448 SAS Internal Drive
DW085A
HP Ultrium 448 SAS External Drive
DW086A
HP Ultrium 920 SAS Internal Tape Drive
EH847A
HP Ultrium 920 SAS External Tape Drive
EH848A
HP LTO-4 Ultrium 1840 SAS Internal Tape Drive
EH860A
HP LTO-4 Ultrium 1840 SAS External WW Drive
EH861A
Rack-mount Tape Drive Enclosures
Rack-mount Tape Drive EnclosuresRack-mount Tape Drive Enclosures
Rack-mount Tape Drive Enclosures
HP 1U SAS Rack-mount Kit
NOTE:
NOTE:NOTE:
NOTE:
The 1U SAS Rack-Mount Kit can support up to (2) half-height tape drives and
is compatible with the DAT 160 SAS, Ultrium 448 SAS and Ultrium 920 SAS tape
drives.
AE459A
HP 3U SAS Rack-mount Kit
NOTE:
NOTE:NOTE:
NOTE:
The 3U Rack-mount Kit can support up to (2) full-height or (4) half-height tape
drives and compatible with multiple SAS tape drives including DAT 160 SAS, LTO-2
Ultrium 448 SAS, LTO-3 Ultrium 920 SAS, and LTO-4 Ultrium 1840 SAS tape drives.
AG576A
Tape Autoloaders
Tape AutoloadersTape Autoloaders
Tape Autoloaders
HP 1/8 G2 LTO-4 Ultrium 1760 SAS Tape Autoloader
AK377A
HP 1/8 G2 Ultrium 920 SAS Autoloader
AH558A
Tape Libraries
Tape LibrariesTape Libraries
Tape Libraries
HP MSL2024 Ultrium 920 SAS Tape Library
AH559A
HP StorageWorks MSL4048 Ultrium 920 SAS Tape Library
AH560A
HP StorageWorks MSL8096 2 Ultrium 920 SAS Tape Library
AH561A
SAS Cables for Tape Drives
SAS Cables for Tape DrivesSAS Cables for Tape Drives
SAS Cables for Tape Drives
2M External SAS (SFF8470) to Mini SAS (SFF8088) 1x SAS Cable
NOTE:
NOTE: NOTE:
NOTE:
Use this cable to connect HP Ultrium SAS External Tape Drives to SAS
Controllers with SAS (SFF8470) connectors.
AE466A
HP 1U SAS TP I-E 3HDDs X 1Tape Drive X4M Server Cable Assembly Kit
NOTE:
NOTE:NOTE:
NOTE:
This split cable connects internally to SAS Hard Drive Cage (3x) and externally
to the HP Storage Works 1U SAS Rack-Mount Kit (1x) with other connector going to
internal SAS Controller port inside the server. Requires additional PCI slot on server for
threading 1x split cable to SAS tape.
AE464A
HP 1U SAS Ext-Min 1x-4M Cable Assembly Kit
NOTE:
NOTE:NOTE:
NOTE:
Use this cable to connect HP 1U SAS Rack-mount Kit to SAS Controllers with
SAS (SFF8470) connectors.
AE468A
HP SAS Min-Min 1x-2M Cable Assembly Kit
NOTE:
NOTE:NOTE:
NOTE:
Use this cable to connect HP Ultrium SAS External Tape Drives.
AE470A
HP SAS MIN-MIN 1X-4M Cable Assembly Kit
NOTE:
NOTE:NOTE:
NOTE:
Use this cable to connect HP 1U SAS Rack-mount Kit.
AE465A
HP SAS MIN-MIN 3X1X-5M Cable Assembly Kit
NOTE:
NOTE:NOTE:
NOTE:
This split cable connects internally to SAS Hard Drive Cage (3x) and externally
to the HP Storage Works 1U SAS Rack-Mount Kit (1x) with other connector going to
internal SAS Controller port inside the server. Requires additional PCI slot on server for
threading 1x split cable to SAS tape. Valid only for ProLiant DL360 G5 and ProLiant
DL365 servers.
AG452A
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Related Options
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 14
Page 15
HP External SAS to mini-SAS Fanout Cable
NOTE:
NOTE:NOTE:
NOTE:
Use this cable to connect HP 1/8 G2 SAS tape autoloaders and
MSL2024/MSL4048/MSL8096 SAS tape libraries to SAS Controllers with Infiniband
(SFF8470) connectors.
AH587A
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Related Options
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 15
Page 16
Dimensions
DimensionsDimensions
Dimensions
(excluding
bracket)
6.6 x 2.5 x 0.6 in (16.8 x 6.4 x 1.6 cm)
Disk Drive and Enclosure
Disk Drive and EnclosureDisk Drive and Enclosure
Disk Drive and Enclosure
Protocol Support
Protocol SupportProtocol Support
Protocol Support
3 Gbps SAS (Serial Attached SCSI)
1.5 Gbps SATA (Serial Advanced Technology Attachment)
Architecture
ArchitectureArchitecture
Architecture
Serial Attached SCSI (SAS)
Serial Advanced Technology Attachment (SATA)
PCI-Express x8
SAS Connectors
SAS ConnectorsSAS Connectors
SAS Connectors
1 x4 internal SFF-8484 and 1x4 external SFF-8470
Data Transfer Method
Data Transfer MethodData Transfer Method
Data Transfer Method
300 MB/s bandwidth (600 MB/s, full duplex) on each port for combined throughput of up to 2 Gb/s
PCIe Bus Speed
PCIe Bus SpeedPCIe Bus Speed
PCIe Bus Speed
PCIe x8 (2.5 Gb/s maximum bandwidth)
Simultaneous Drive
Simultaneous DriveSimultaneous Drive
Simultaneous Drive
Transfer Ports
Transfer PortsTransfer Ports
Transfer Ports
2 x4 Wide SAS Connectors (1 external only for Integrity Servers)
Port Transfer Rate
Port Transfer RatePort Transfer Rate
Port Transfer Rate
12 Gb/s per x4 Wide SAS Port (4 x 3 Gb/s)
Software upgradeable
Software upgradeableSoftware upgradeable
Software upgradeable
Firmware
FirmwareFirmware
Firmware
Yes
Maximum Capacity
Maximum CapacityMaximum Capacity
Maximum Capacity
8.7TB of SAS storage when connected to (4) 300GB drives internal to the Server and an MSA70 external
drive enclosure with (25) 300GB drives.
Memory Addressing
Memory AddressingMemory Addressing
Memory Addressing
64-bit, supporting servers memory greater than 4 GB
Logical Drives Supported
Logical Drives SupportedLogical Drives Supported
Logical Drives Supported
(ProLiant only)
Up to 2 Logical Volumes
Up to 8 drives total in all RAID volumes
2 Drives per RAID 1
Up to 8 Drives per RAID 0
RAID Support
RAID SupportRAID Support
RAID Support
(ProLiant only)
RAID 1 (Mirroring)
RAID 0 (Striping)
Upgradeable Firmware
Upgradeable FirmwareUpgradeable Firmware
Upgradeable Firmware
4-MB flashable ROM
Disk Drive and Enclosure
Disk Drive and EnclosureDisk Drive and Enclosure
Disk Drive and Enclosure
Protocol Support
Protocol SupportProtocol Support
Protocol Support
3Gb/s SAS and 1.5Gb/s SATA
Environment-friendly
Environment-friendlyEnvironment-friendly
Environment-friendly
Products and Approach
Products and ApproachProducts and Approach
Products and Approach
End-of-life Management
End-of-life ManagementEnd-of-life Management
End-of-life Management
and Recycling
and Recyclingand Recycling
and Recycling
Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling
programs in many geographic areas. For trade-in information, please go to
http://www.hp.com/go/green
. To recycle your product, please go to:
http://www.hp.com/go/green
or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities.
This information (product disassembly instructions) is posted on the Hewlett
Packard web site at:
http://www.hp.com/go/green
. These instructions may be
used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Technical Specifications
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 16
Page 17
© Copyright 2011 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. Microsoft and Windows are registered trademarks or
trademarks of Microsoft Corporation in the U.S. and/or other countries. The only warranties for HP products and services are set
forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as
constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
For hard drives, 1 GB = 1 billion bytes. Actual formatted capacity is less.
QuickSpecs
HP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus AdapterHP SC44Ge Host Bus Adapter
HP SC44Ge Host Bus Adapter
Technical Specifications
DA - 12617 Worldwide — Version 20 — September 26, 2011
Page 17
Loading...
