Full Color Inkjet Printer

RJ-6000 Series

Functions Edition

RJ600EX-B-01

USER GUIDE

RJ-6000 Series

Full-Color Inkjet Printer

Functions Edition

Mutoh Industries Ltd.

1-3 Ikejiri 3-chome

Setagaya-ku, Tokyo 154-8560

Japan

RJ-6000 Series USER GUIDE Functions Edition

Types and Usage of User Guide

This product is supplied with the following three types of User Guide:

Basic Edition

This manual deals with unpacking, installation, preparing for printing, test printing, direct access key operations from online printing, menu maps, daily maintenance, trouble shooting, etc. All the important essentials for every-day use of the printer are here, so please be sure to read it.

Functions Edition

This manual which you now have open is the Functions edition of the User Guide. This explains the printer's functions. Essential information for using this printer, such as functions and operations, are explained in detail. "What does this function do to the printing?" and "Which function do I use when I want to print like this?" are separated for easy searching. Details and technical terms for the fitting of options and error messages are included for you to read as required.

Drivers Edition

You may need to install drivers for output from computer. The Drivers Manual explains about installation and settings to suit your computer operating system. Please read it when you are installing drivers.

RJ-6000 Series USER GUIDE Functions Edition

This equipment complies with radio interference regulations for data processing devices. When used in a residential area, this equipment may cause radio interference, in which case the user may be required to take appropriate corrective measures.

#Concerning radio interference

This product generates weak radio signals and may interfere with radio and television reception if not installed and used correctly. If you suspect that it is causing interference with radio and television reception, try one or more of the following measures:

• Change the direction of your reception antennae and feeders

• Change the direction of this product

• Change the distance between your receiver and this product

• Use separate power supply circuits for your receiver and this product

#Trademarks mentioned in this manual

• MUTOH, RJ-6000, FALCON, FALCON Graphics, MH-GL, MH-GL/2, MH-RTL and RTL-PASS are trademarks or product names of MUTOH Industries Ltd.

• HP, HP-GL, HP-GL/2, HP-RTL are trademarks or product names of HewlettPackard Inc.

• Centronics, Bitronics are trademarks or product names of Centronics Data Computer Corp.

• Windows 95, Windows 98, Windows NT 4.0 are trademarks or product names of Microsoft Corp.

• DOS-V, PC-DOS are trademarks or product names of IBM (International Business Machines Inc.)

• NetWare is a trademark or product name of Nobel Inc.

• EtherTalk is a trademark or product name of Apple Computer Inc.

• Other names of companies or products are trademarks or product names of the respective companies.

IMPORTANT

• Details of this product and this manual are protected by copyright held by this company and except for legitimate use by individuals, may not be copied, reproduced or distributed in whole or in part.

• Details contained in this manual may be subject to future alteration without notice.

• Details contained in this manual are believed to be correct but please contact this company or your dealer if you suspect an error or a point is not clear.

• In no event will this company be responsible for the consequences of using this product or this manual.

RJ-6000 Series USER GUIDE Functions Edition

Introduction

Thank you for purchasing a RJ-6000 Series (RJ-6000-43, RJ-6000-54, RJ6000-62) Full-color Inkjet Printer.

This RJ-6000 Series is a full-color inkjet printer equipped with 360 dpi, 720 dpi and simulated 1440 dpi resolution, that supports Centronics (bi-directional parallel interface, IEEE1284 compatible, with Nibble and ECP modes) and, optionally, Ethernet interfaces.

This User Guide deals with printer installation and operation methods as well as usage precautions. In order to use the printer safely and effectively, please read the User Guide carefully before you use the printer and then use it correctly.

Keep the manual beside the printer. It is sure to be useful in case something that you are not sure about should occur while you are using the printer.

IMPORTANT

• Because the RJ-6000 Series is an inkjet printer, it needs to be cleaned and inspected periodically. User registration and a service contract are recommended for prompt detecting trouble promptly and maintaining printing quality in top condition. For details, contact your local Mutoh dealer.

In order to operate the printer's functions, first look up the operation you wish to perform by referring to "When you want to do this".

Then check the explanation of the function under "Understanding the functions".

Next, refer to the actual operation under "How to set parameters".

RJ-6000 Series USER GUIDE Functions Edition

Contents

Types and Usage of User Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Control Panel and Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Control Panel for Menu Mode Operations . . . . . . . . . . . . . . . . . . . . . . 10

Menu Mode Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Menu Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

When You Want to Do This . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

When You Want to Do This . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

To use roll media efficiently . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

To speed up printing time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

To improve printing quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

To connect with Centronics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

To connect with network (Ethernet) . . . . . . . . . . . . . . . . . . . . . . . . . 17

To cut roll media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

To place printed output in a specified position . . . . . . . . . . . . . . . . . 18

To use color effectively . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

To check the status of the printer . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

To check printer set-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Contents

Explanation of Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Understanding the Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Command Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Function Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Centronics Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Network Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Utility Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

RJ-6000 Series USER GUIDE Functions Edition

Contents

How to Set Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Command Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Prot Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Terminator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Online Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Overwrite . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Function Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Ink Dry Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Halftone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

CMY -> Black . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Scale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

FMirror . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Direction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Cut Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Media Cut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Copy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Ink Density . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Distance Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Centronics Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Network Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

IP Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Utility Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Error Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Initial: All . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Initial: Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Initial: Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Initial: Centronics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Initial: Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Dump . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Head Wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Data Order . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Accuracy Adjustment Plot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

RJ-6000 Series USER GUIDE Functions Edition

Contents

Installation of Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Network Interface Board Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Memory Extension . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Details of the Display

Printer Status Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Messaged Errors and Countermeasures . . . . . . . . . . . . . . . . . . . . . . . 88

Data error Display and Countermeasures . . . . . . . . . . . . . . . . . . . . . . 91

Command Error Display and Countermeasures . . . . . . . . . . . . . . . . . . 92

Errors Requiring a Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Errors Requiring Restart that Involve the Mechanical System . . . . . 94

Errors Requiring Restart that Involve the CPU System . . . . . . . . . . . 96

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Contents

RJ-6000 Series USER GUIDE Functions Edition

Control Panel and Menus

This section gives an overview of the control panel for various types of menu settings and explains the menu structure.

Control Panel for Menu

Mode Operations

Menu Mode Operations

Menu Levels

Control Panel and Menus

PAGE 10

PAGE 11

PAGE 13

RJ-6000 Series USER GUIDE Functions Edition

Control Panel for Menu Mode Operations

For all types of menu operations, shift to menu mode by pressing the [Menu] key. This switches the functions of the keys to the functions shown in the purplish-red frame.

Menu Up key

MENU key Menu Down key

Back key

VALUE + key VALUE - key ENTER key

Direct access keys do not work in menu mode. Menu mode will be cancelled if no key operation has been made for three minutes.

REFERENCE

For direct access key operations, see the section on "

• Access Keys" in the Basic Edition of the User Guide.

RJ-6000 Series USER GUIDE Functions Edition

Direct

Menu Mode Operations

Shift to setting mode for practical functions than cannot be set up by direct access keys.

Step 1

Press the [MENU] key to shift to setting mode. Direct access key operation does not work.

Step 2

By pressing the [MENU] key, the control panel keys take on the functions shown in purplish-red. Press the Select setting mode by pressing the [Menu

Down] key or the [Menu Up] key.

[Menu Up]

*Menu* Command>

> : sub-menu for detailed settings

[ENTER]

to "Command" settings

Control Panel and Menus

[Menu Down]

*Menu* Funct ion>

[Menu Down]

*Menu* Cent ro>

[Menu Down]

*Menu* Network>

[Menu Down]

*Menu* Ut i l i t y>

[Menu Down]

[Menu Up]

[ENTER]

to "Function" settings

[ENTER]

to "Centronics" settings

[ENTER]

to "Network" settings

[ENTER]

to "Utility" settings

* Reference The "Network" settings is displayed only if the Ethernet board option has been installed.

RJ-6000 Series USER GUIDE Functions Edition

Menu Mode Operation

Step 3

* Press the [ENTER] to proceed with the setting * The part of the display that is flashing can be altered. To change a setting,

select a value by pressing the [VALUE +] or [VALUE -] keys. * The setting will not change unless the [ENTER] key is pressed. * If the set-up is complete, press the [Menu Up] key. If there is no key opera-

tion in Menu setting mode for 3 minutes, direct access key input standby

(permanent display) is restored.

RJ-6000 Series USER GUIDE Functions Edition

Menu Levels

*Menu* Command>

Command RTL-PASS / MH-GL, GL2 / MH-GL2 Plot Area Normal / Expand Position P1 / (hardclip) LL / Full Terminat Special / Normal Resolut. 300 dpi / 360 dpi / 720 dpi Online Timer Off / 10 sec to 30 sec to 800 sec Overwrite Last / Mix

*Menu* Funct ion>

Ink Dry Time 0 sec to 5 sec to 30 sec to 60 min Halftone Speed / Quality / Thin CMY->BLACK No / Yes Scale 25% to 100% to 400% Mirror Off / Y On Direct. Command / MAX-MIN Cut Pos. Data / Standard Media Cut Auto / Manual / Off Copy 1 to 99 Ink Density Normal / Thin / Faint Dist. Adj. No / Clear / Change / Confirm

Control Panel and Menus

*Menu* Cent ro>

Mode Centro / Bitro Timing A-B / B-A

*Menu* Network>

IP Address 000.000.000.000 to 192.034.043.015 to 255.255.255.255

*Menu* Ut i l i t y>

Error Display On / Off Initial OK / No

All OK / No

Command OK / No

Functi. OK / No

Centro OK / No

Network OK / No Dump Start-End / All (cancel with [CANCEL] key Data Order 5Lc6Lm / 5Lm6Lc

This item is effective later than the firmware version 1.04.

Head Wash Yes / No

RJ-6000 Series USER GUIDE Functions Edition

When You Want to Do This

This section makes it easy for you to look up what sort of function to use when you want to do a particular sort of operation. It asks the questions and then tells you on which page of which User Guide you can find the answers.

When You Want to Do This PAGE 16

When You Want to Do This

RJ-6000 Series USER GUIDE Functions Edition

When You Want to Do This

To use roll media efficiently

Question Answer ExplanationOperation I want to print without making waste spaces on the media. I want to make a print that aligns the data with spaces. I want to cut the media to the size that has been printed. I want to cut the media to the standard size.

I want to make a series of prints on one sheet without cutting.

Set “Direction” to “MAXMIN” in “Function” settings. Set “Direction” to “Command” in “Function” settings. Set “Cut Position” to “Data” precedence in “Function” settings. Set “Cut Position” to “Standard” size in “Function” settings. Set “Media Cut” to “Off” in “Function” settings.

To speed up printing time

Page 25 Page 47

Page 26 Page 48

Page 27 Page 49

Question Answer ExplanationOperation If I want to shorten the time between finishing the print and cutting the roll media? If I want to print quickly even if resolution is reduced? If I want to print quickly even if graphic quality is reduced?

If I want to print faster without reducing resolution or quality?

RJ-6000 Series USER GUIDE Functions Edition

Change “Ink Dry Time”.

Light up the Low LED by pressing the [RESOLUTION] key. Set “Harftone” to “Speed” diffusion for the user number that you want to change. Change the interface connection (from Centronics to Network)

Page 24 Page 41

Basic

Page 61

Page 24 Page 43

Page 80 Page 28 Page 57

To improve printing quality

Question Answer ExplanationOperation If I want to give priority to quality rather than speed? If I want to give priority to graphic quality rather than speed?

Light up the Quality LED by pressing the [QUALITY / SPEED] key. Set “Harftone” to “Quality” diffusion for the user number that you want to change.

To connect with Centronics

Question Answer ExplanationOperation If I want to have bidirectional communication with Centronics? If I want to change Centronics ACK/BUSY timing control?

Change the Centronics mode setting to “Bi Centronics”. Change “Timing” in “Centronics” settings.

When You Want to Do This

Basic

Page 62

Page 24 Page 43

When You Want to Do This

Page 28 Page 55

Page 28 Page 56

To connect with network (Ethernet)

Question Answer ExplanationOperation If I want to change the IP address?

Change “IP address” in “Network” settings.

Page 28 Page 57

To cut roll media

Question Answer ExplanationOperation If I want to feed and cut the finished part of a print?

Check that printing data are not being received then feed the media by pressing the [MENU] key while you are pressing the [Shift] key and cut the roll media by pressing the [CANCEL] key.

Basic

Page 67

Basic

Page 64

RJ-6000 Series USER GUIDE Functions Edition

When You Want to Do This

To place printed output in a specified position

Question Answer ExplanationOperation If I want to print in the middle of the page with maximum and minimum data values? If I want to print on media of a different size from that specified in the data.

If I want to print with reversed data?

Change “Direction” to “MAX-MIN”.

Set “Scale”. *Examples of scales

between standard sizes:

•A4 > A3, A3 > A2, A2 > A1, A1 > A0, B4 > B3, B3 > B2, B2 > B1, B1 > B0 : 141%

•A4 > B4, A3 > B3, A2 > B2, A1 > B1, A0 > B0 : 122%

•B4 > A3, B3 > A2, B2 > A1, B1 > A0 : 115%

•B0 > A0, B1 > A1, B2 > A2, B3 > A3, B4 > A4 : 86%

•A0 > B1, A1 > B2, A2 > B3, A3 > B4 : 81%

•A0 > A1, A1 > A2, A2 > A3, A3 > A4, B0 > B1, B1 > B2, B2 > B3, B3 > B4 : 70%

Set “Mirror” for the user number you want to change.

Page 25 Page 47

Page 24 Page 45

Page 25 Page 46

RJ-6000 Series USER GUIDE Functions Edition

To use color effectively

Question Answer ExplanationOperation If I want to print after changing the graphic quality?

If I want to print after changing the resolution. If I want to print after mixing overlapping colors (over print)?

Press the [QUALITY / SPEED] key and select “Quality”, “Normal” or “Speed”. Change “Harftone” There are three type of tone processing: “Speed” diffusion, “Quality” diffusion and “Thin” diffusion. Change “Resolution”.

Change “Overwrite”.

To check the status of the printer

When You Want to Do This

Basic

Page 62

Page 24 Page 43

When You Want to Do This

Page 23 Page 37

Page 23 Page 40

Question Answer ExplanationOperation If I don't want nonproblematical errors to be displayed? If I want to restore error display without switching off the power?

Set “Error Display” to “Off” in “Utility” settings.

Set “Error Display” to “On” in “Utility” settings.

Page 29 Page 59

RJ-6000 Series USER GUIDE Functions Edition

When You Want to Do This

To check printer set-up

Question Answer ExplanationOperation If I want to know what are the current printer settings?

If I want to restore the original factory Command settings? If I want to restore the original factory Function settings? If I want to restore the original factory Function settings? If I want to restore all of the printer's original factory settings?

Print the setup list print by pressing the [MEDIA] key while you are pressing the [Shift] key. Initial “Command” under “Initial”in“Utility”settings. Initial “Function” under “Initial” in “Utility” settings. Initial “Centronics” or “Network” under “Initial” in “Utility” settings. Initial “All” under “Initial” in “Utility” settings

Basic

Page 66

Page 29 Page 62

Page 29 Page 64

Page 30 Page 66

Page 68

Page 29 Page 60

RJ-6000 Series USER GUIDE Functions Edition

Explanation of Functions

This section explains the content of each function in detail and gives the page number for you to look it up easily in the User Guide.

Understanding the Functions PAGE 22

Explanation of Functions

RJ-6000 Series USER GUIDE Functions Edition

Understanding the Functions

Command Settings

Name of Function

Command

This specifies the commands and conditions that are transferred from the computer. The following commands are supported:

•RTL-PASS:

•MH-GL, GL2 (MH-RTL): Mutoh MH-GL/MH-GL/2 (MH-RTL)

commands (conform to HewlettPackard HP-GL, HP-GL/2 (HP-RTL) commands)

•MH-GL2 (MH-RTL): Mutoh MH-GL/2 (MH-RTL) commands

(conform to Hewlett-Packard HP-GL/2 (HP-RTL) commands)

(MH-GL, GL2 printing unit is 0.025 mm)

Plot Area

This specifies environmental functions for the printer. It specifies the printing area (hardclip area) for the media size.

•Normal: Specifies the standard printing area for RJ-6000

Series printers

Distance from edges of media:

Cut sheet - Front 25 mm, Back 20 mm, Sides 10 mm Roll media - Front 25 mm, Back 20 mm, Sides 10 mm

•Expanded: Specifies a printing range for the RJ-6000 printer

that is interchangeable with Mutoh XP Series pen

plotters. However, since the maximum printing range is 1351.6 mm for a 54-inch printer and 1554.8 mm for a 62-inch printer, if expanded mode is specified with media wider than 1361.6 mm for a 54-inch printer, or 1564.8 mm for a 62-inch printer, the left and right margin shown below will be differed.

Distance from edges of media:

Cut sheet - Front 25 mm, Back 20 mm, Sides 5 mm

Roll media - Front 25 mm, Back 20 mm, Sides 5 mm (media width 54 inch: 1361.6 mm or less, 62 inch: 1564.8 mm or less)

Reference

Page

Page 33

Page 34

RJ-6000 Series USER GUIDE Functions Edition

Understanding the Functions

Command Settings

Name of Function

Position

In the case of MH-GL, GL2 (MH-RTL) and MH-GL/2 (MH-RTL), this specifies the initial pen position in printer commands.

•P1: The initial position is P1 (scaling point)

•LL: The initial position is at the lower left of the hardclip.

•Full: The initial position is at the lower left of the media.

Terminator

In the case of MH-GL, GL2 (MH-RTL) and MH-GL/2 (MH-RTL), this specifies a function that is different from the original command function as the terminator with respect to some commands in each of the printer's command modes.

•Normal: Only the original command is used

•Special: Recognizes end of data as the terminator SP0; (SP;)

Resolution

In the case of MH-GL, GL2 (MH-RTL) and MH-GL/2 (MH-RTL), this specifies the resolution for image data in MH-RTL commands.

•300 dpi: Sets image data resolution to 300 dpi

•360 dpi: Sets image data resolution to 360 dpi

•720 dpi: Sets image data resolution to 720 dpi

Reference

Page

Page 35

Page 36

Explanation of Functions

Page 37

Online Timer

When online data is broken off, this specifies a certain period of time, the elapsing of which is taken to be the end of image data.

•Online timeout: Off, 10 sec, 20 sec, 30 sec, 40 sec, 50 sec, 60 sec, 90 sec, 120 sec, 150 sec, 180 sec, 210 sec then in 30-sec increments to 720 sec, 750 sec, 780 sec, 800 sec.

Overwrite

This specifies functions related to the printer's own environment. Specifies the method for controlling the overwritten portions of a diagram.

•Last: Overwritten portion takes a color to be printed later

•Mix: Overwritten portion takes mixed colors

RJ-6000 Series USER GUIDE Functions Edition

Page 38

Page 40

Understanding the Functions Function Settings

Function Settings

Name of Function

Ink Dry Time

Ink drying times differ according to the type of media. After the printing is finished, roll media is cut off and falls into the ejected media basket. If the ink is not yet dry, the media will be soiled. Ink drying time is the delay to allow the ink to dry between the end of printing and the cutting of the roll media.

•Ink drying time: 0 sec, 5 sec, 10 sec, 20 sec, 30 sec, 40 sec,

50 sec, 60 sec, 90 sec, 120 sec, 150 sec, 180 sec, 210 sec, 240 sec, 270 sec, 300 sec, 6M, 7M, 8M, 9M, 10M, 15M, 20M, 25M, 30M, 35M, 40M, 45M, 50M, 55M, 60M.

Halftone

This specifies the method for expressing pseudo-halftone processing of MH-GL/2 (vector) data or unbinarized MH-RTL (raster) data.

•Speed diffusion: Rapid expression of tones with an

error diffusion matrix

•Quality diffusion: High quality expression of tones by

mean error minimization

•Thin diffusion: Try this if the data was prepared for

another brand of printer and high speed diffusion appears too dense.

Reference

Page

Page 41

Page 43

CMY -> Black

Specifies whether black is to be expressed by CMY (mixture) or K. In graphic language mode, it appears as follows:

Yes No

RTL-PASS Black must be K ink CMY black may be

mixed with K

MH-GL/MH-GL2 Black must be K ink Black must be CMY

mixed

Scale

This function prints with expanded or reduced printing data

•25% to 100% to 400% (in 1% steps)

RJ-6000 Series USER GUIDE Functions Edition

Page 44

Page 45

Understanding the Functions

MAX - MINCommand

Media size specified by command

Printing Area Printing Area

Direction of feed

Function Settings

Name of Function

Mirror

This function prints with printing data reversed in the Y-axis direction. Mirror may not work with some image data.

•Off: No reversal

•Y on: Reversing in the Y direction

Direction

In a case where data is to be printed on roll media, this function specifies whether the layout of the image on the media is to be based on the size of the data including spaces or only on the area that will actually be printed.

•Command: If a command specifying page size is contained in

the data, media size will be judged from that command.

•MAX-MIN: The maximum and minimum values of the data

determine the size of media that will contain that data, regardless of origin coordinates or page size commands, and the layout matches the center of the area to the center of the media.

Reference

Page

Page 46

Page 47

Explanation of Functions

RJ-6000 Series USER GUIDE Functions Edition

Understanding the Functions

Cut Position

Rear Margin

Series A media recognized by loading A1 roll media

Area specified by page size command

Printing Area

Data

Cut Position

Series A media recognized by loading A1 roll media

A3 Printable Area

Printing Area

A3 Standard Size

Area specified by page size command

Standard

Function Settings

Name of Function

Cut Position

This function specifies where the roll media will be cut in accordance with the specified layout of the printing.

•Data: Cuts the media at the position determined

after adding a margin at the rear edge of the page size specified by command or the printing area prescribed by max-min in layout.

•Standard: Cuts to the smallest standard size in the

same series as the loaded media that will accommodate the printing area determined by layout.

Reference

Page

Page 48

RJ-6000 Series USER GUIDE Functions Edition

Understanding the Functions

Rear margin of first copy and leading margin of second are missing

* Printing area determined

by layout

Cut off

Printing area for second copy

Printing area for first copy

Function Settings

Name of Function

Media cut

Selects whether roll media will be cut at the end of printing. If off is selected, the data can be printed again on the same page.

•Off:

•Auto: Roll media is cut automatically when printing

Auto-cut ends.

•Manual: Roll media is cut manually when printing

Manual cut ends. Use this for cutting media than can not

be cut automatically (fireproof cloth or outdoors cloth). (See Basic edition page 57, "Making a Manual Cut".)

Reference

Page

Page 49

Explanation of Functions

Copy

Specifies number of copies when the data is to be printed several times.

•1 to 99

Ink Density

Set printing density.

•Normal: Ordinary density printing

•Thin: Printing density lighter than "Normal"

•Faint: Printing density lighter than "Thin"

Distance Adjustment

Enter the length according to the data and the actual X-axis distance based on the actual printed document. If there is no setting, the length and width of the previously printed document is displayed. The distance adjustment is for adjusting to the user's scale, not for ensuring distance precision.

RJ-6000 Series USER GUIDE Functions Edition

Page 50

Page 51

Page 52

Understanding the Functions Function Settings / Centronics Settings / Network Settings

Name of Function

*"Normal", "Thin" and "Faint" are all valid if the resolution is

set to pseudo-1440 dpi or 720 dpi but please note that if 360 dpi is set, the printing density will be "Normal" even when "Thin" or "Faint" is set.

•No: No distance adjustment is made

•Clear: To erase the current distance adjustment setting

•Change: To set a distance adjustment

•Confirm: To confirm a distance adjustment

Centronics Settings

Name of Function

Mode

Sets the mode for the Centronics connection.

•Centronics: Selects fixed one-way Centronics communica-

tion

•BiCentronics: Selects Bitronics that allows two-way commu-

nication (supports compatible mode, nibble mode, ECP mode)

Reference

Page

Reference

Page

Page 55

Timi ng

Sets ACK timing for Centronics online communication

•A-B: Selects ACK timing for the A-B busy method

•B-A: Selects ACK timing for the B-A busy method

Network Settings

Name of Function

IP address

Sets up IP address for the network connection (Ethernet). Enter the IP address assigned by your network administrator After making the setting, turn the printer off momentarily and restart it.

•000.000.000.000 to 192.034.043.015 to 255.255.255.255

RJ-6000 Series USER GUIDE Functions Edition

Page 56

Reference

Page

Page 57

Utility Settings

Understanding the Functions

Utility Settings

Name of Function

Error Display

Specifies whether the error LED will light and error details will be displayed in the liquid crystal display unit when a minor error has occurred.

•On: The error LED will light and error details will be dis-

played in the liquid crystal display unit when a minor error has occurred

•Off: No indication will be given of a minor error occurring,

either by error LED or by the liquid crystal display unit

Initial All

Restores the contents of all backed up settings to the values set when shipped by Mutoh.

•OK: All backed up settings are restored to the factory set-

tings

•No: Factory settings are not restored

Initial Command

Restores the backed up command settings to the values set when shipped by Mutoh.

•OK: The backed up command settings are restored to the

factory settings

•No: Factory settings are not restored

Reference

Page

Page 59

Explanation of Functions

Page 60

Page 62

Initial Function

Restores the backed up function settings to the values set when shipped by Mutoh.

•OK: The backed up function settings are restored to the fac-

tory settings

•No: Factory settings are not restored

RJ-6000 Series USER GUIDE Functions Edition

Page 64

Understanding the Functions Utility Settings

Name of Function

Initial Centronics

Restores the backed up Centronics settings to the values set when shipped by Mutoh.

•OK: The backed up Centronics settings are restored to the

factory settings

•No: Factory settings are not restored

Initial Network

Restores the backed up Network settings to the values set when shipped by Mutoh.

•OK: The backed up Network settings are restored to the fac-

tory settings

•No: Factory settings are not restored

Dump

Prints a dump for the serviceman to check online.

•Start-End: Prints a dump from start to end

•All: Prints a dump for all data

Head Wash

Withdraws the filled ink and cleans the interior of the head. After cleaning, the head must be filled with ink for printing.

•Yes: Head is cleaned.

•No: Head is not cleaned.

Reference

Page

Page 66

Page 68

Page 70

Page 72

Data Order

In case light-cyan and light-magenta is being used, sometimes no desired color will be produced depending on the kind of RIP to be used. In such a case, please try to use this Data Order function.

•5Lc6Lm: An ordinary color pattern is specified.

•5Lm6Lc: A specific color pattern is used.

RJ-6000 Series USER GUIDE Functions Edition

Page 75

How to Set Parameters

This section explains how to set parameters for all types of menu.

Command settings:

Command PAGE 33

Terminator Resolution

Online Timer PAGE 38

Function settings:

Ink Dry Time PAGE 41

CMY -> Black PAGE 44

Plot Area

Position

Overwrite

Halftone

Scale

Mirror

PAGE 34 PAGE 35 PAGE 36 PAGE 37

PAGE 40

How to Set Parameters

PAGE 43

PAGE 45 PAGE 46

Direction PAGE 47

Cut Position PAGE 48

Media Cut PAGE 49

Copy PAGE 50

Ink Density

Distance Adjustment

RJ-6000 Series USER GUIDE Functions Edition

PAGE

PAGE 52

How to Set Parameters

Centronics Settings:

Mode PAGE 55

Timing PAGE 56

Network Setting:

IP Address PAGE 57

Utility Settings:

Error Display PAGE 59

Utility Settings: Initial

Utility Settings:

Accuracy Adjustment Plot

All PAGE

Command

Function

PAGE 62 PAGE 64

Centronics PAGE 66

Network

Dump

PAGE 68

PAGE 70

Head Wash PAGE 72

Data Order

PAGE 75 PAGE 76

RJ-6000 Series USER GUIDE Functions Edition

Command Settings: Command

Step 1

Plot OK

*Menu* Command>

Command :MHGL ,GL2

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Command" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Display a Command item by pressing the [Menu Up] key or [Menu Down] key.

Step 4

Specify “MHGL, GL2”, “MH-GL2” or “RTL-PASS” by pressing the [VALUE +] or [VALUE -] key.

How to Set Parameters

Step 5

Command :RTL-PASS

PlotArea: Normal

*Menu* Command>

Plot OK

Press the [ENTER] key to confirm "Command" setting and shift to the next item to be set.

Step 6

If no other items are to be changed, press the [Back] key.

Step 7

Do not press any other keys for 3 minutes or press [Back] key again.

Step 8

The permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

Command Settings: Plot Area

Step 1

Plot OK

*Menu* Command>

Command :MHGL ,GL2

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Command" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Command" menu and shift to the next level.

Step 4

Bring up the "Plot Area" item by pressing the [Menu Up] key or [Menu

Down] key.

PlotArea: Normal

PlotArea: Expand

Pos i t i on : P1

*Menu* Command>

Plot OK

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to select "Normal" or "Expand".

Step 6

Press the [ENTER] key to confirm "Plot Area" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

Command Settings: Position

Step 1

Plot OK

*Menu* Command>

Command :MHGL ,GL2

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Command" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Command" menu and shift to the next level.

Step 4

Bring up the "Position" item by pressing the [Menu Up] key or [Menu

Down] key.

How to Set Parameters

Step 5

Pos i t i on : P1

Pos i t i on : LL

Terminat :Special

*Menu* Command>

Plot OK

Press the [VALUE +] or [VALUE -] key to select "P1" or "LL (Hardclip lower left)" or "Full".

Step 6

Press the [ENTER] key to confirm "Position" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

Command Settings:Terminator

Step 1

Plot OK

*Menu* Command>

Command :MHGL ,GL2

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Command" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Command" menu and shift to the next level.

Step 4

Bring up the "Terminat" item by pressing the [Menu Up] key or [Menu

Down] key.

Terminat :Special

Terminat : Norma l

Resolut.: 360dpi

*Menu* Command>

Plot OK

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to select "Special" or "Normal".

Step 6

Press the [ENTER] key to confirm "Terminat" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

Command Settings: Resolution

Step 1

Plot OK

*Menu* Command>

Command :MHGL ,GL2

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Command" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Command" menu and shift to the next level.

Step 4

Bring up the "Resolut." item by pressing the [Menu Up] key or [Menu

Down] key.

How to Set Parameters

Step 5

Resolut.: 360dpi

Resolut.: 720dpi

On l i neT ime r : 30s

*Menu* Command>

Plot OK

Press the [VALUE +] or [VALUE -] key to select "360dpi", "720dpi" or "300dpi".

Step 6

Press the [ENTER] key to confirm "Resolution" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

Command Settings: Online Timer

Step 1

Plot OK

*Menu* Command>

Command :MHGL ,GL2

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Command" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Command" menu and shift to the next level.

Step 4

Bring up the "Online Timer" item by pressing the [Menu Up] key or [Menu

Down] key.

On l i neT ime r : 30s

Onl ineTimer:270s

Overwr i te: Last

*Menu* Command>

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to select "Off", "10s", "10s", "20s", "30s", "40s", "50s", "60s", "90s", "120s", "150s", "180s", "210s", "240s", "270s" or "800s".

Step 6

Press the [ENTER] key to confirm "Online Timer" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Plot OK

Command Settings: Online Timer

Step 9

The permanent display is restored.

How to Set Parameters

RJ-6000 Series USER GUIDE Functions Edition

Command Settings: Overwrite

Step 1

Plot OK

*Menu* Command>

Command :MHGL ,GL2

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Command" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Command" menu and shift to the next level

Step 4

Bring up the "Overwrite" item by pressing the [Menu Up] key or [Menu

Down] key.

Overwr i te: Last

Ove rwr i t e : Mi x

Command :MHGL ,GL2

*Menu* Command>

Plot OK

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to select "Last" or "Mix".

Step 6

Press the [ENTER] key to confirm "Overwrite" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

Function Settings:Ink DryTime

Step 1

Plot OK

*Menu* Command>

*Menu* Funct ion>

InkDryTime: 30s

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Function" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Function" menu and shift to the next level.

Step 4

Bring up the "Ink Dry Time" item by pressing the [Menu Up] key or [Menu

Down] key.

How to Set Parameters

Step 5

InkDryTime: 30s

InkDryTime: 60s

Hal f tone: Speed

Press the [VALUE +] or [VALUE -] key to select "0s", "5s", "10s", "20s", "30s", "40s", "50s", "60s", "90s", "120s", "150s", "180s", "210s", "240s", "270s" or "300s", "6M", "7M", "8M", "9M", "10M", "15M", "20M", "25M", "30M", "35M", "40M", "45M", "50M", "55M", or "60M"

Step 6

Press the [ENTER] key to confirm "Ink Dry Time" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

RJ-6000 Series USER GUIDE Functions Edition

Function Settings: Ink Dry Time

*Menu* Funct ion>

Plot OK

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

Function Settings: Halftone

Step 1

Plot OK

*Menu* Command>

*Menu* Funct ion>

InkDryTime: 30s

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Function" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Function" menu and shift to the next level.

Step 4

Bring up the "Halftone" item by pressing the [Menu Up] key or [Menu

Down] key.

How to Set Parameters

Step 5

Hal f tone: Speed

Hal f tone:Qual i ty

CMY - >BLACK No

*Menu* Funct ion>

Plot OK

Press the [VALUE +] or [VALUE -] key to set halftone to "Speed" diffusion, "Quality" diffusion or "Thin" diffusion.

Step 6

Press the [ENTER] key to confirm "Halftone" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

Function Settings: CMY -> Black

Step 1

Plot OK

*Menu* Command>

*Menu* Funct ion>

InkDryTime: 30s

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Function" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Function" menu and shift to the next level.

Step 4

Bring up the "CMY -> BLACK" item by pressing the [Menu Up] key or [Menu

Down] key.

CMY - >BLACK No

CMY - >BLACK Yes

Sca l e: 100%

*Menu* Funct ion>

Plot OK

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to set "No" or "Yes".

Step 6

Press the [ENTER] key to confirm "CMY -> BLACK" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

Function Settings: Scale

Step 1

Plot OK

*Menu* Command>

*Menu* Funct ion>

InkDryTime: 30s

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Function" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Function" menu and shift to the next level.

Step 4

Bring up the "Scale" item by pressing the [Menu Up] key or [Menu Down] key.

How to Set Parameters

Step 5

Sca l e: 100%

Sca l e: 120%

Mi r ror: Of f

*Menu* Funct ion>

Plot OK

Press the [VALUE +] or [VALUE -] key to set scale magnification between "25%" and "400%".

Step 6

Press the [ENTER] key to confirm "Scale" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] again.

Step 9

The permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

Function Settings: Mirror

Step 1

Plot OK

*Menu* Command>

*Menu* Funct ion>

InkDryTime: 30s

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Function" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Function" menu and shift to the next level.

Step 4

Bring up the "Mirror" item by pressing the [Menu Up] key or [Menu Down] key.

Mi r ror: Of f

Mi r ror: Y On

Direct . : Command

*Menu* Funct ion>

Plot OK

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to set mirror to "Off" or "Y On".

Step 6

Press the [ENTER] key to confirm "Mirror" for the applicable print and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

Function Settings: Direction

Step 1

Plot OK

*Menu* Command>

*Menu* Funct ion>

InkDryTime: 30s

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Function" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Function" menu and shift to the next level.

Step 4

Bring up the "Direct." item by pressing the [Menu Up] key or [Menu Down] key.

How to Set Parameters

Step 5

Direct . : Command

Direct . : MAX-MIN

CutPos . : Da t a

*Menu* Funct ion>

Plot OK

Press the [VALUE +] or [VALUE -] key to specify "Command" or "MAX-MIN".

Step 6

Press the [ENTER] key to confirm "Direction" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

Function Settings: Cut Position

Step 1

Plot OK

*Menu* Command>

*Menu* Funct ion>

InkDryTime: 30s

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Function" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Function" menu and shift to the next level.

Step 4

Bring up the "Cut Pos." item by pressing the [Menu Up] key or [Menu

Down] key.

CutPos . : Da t a

CutPos. :Standard

MediaCut: Auto

*Menu* Funct ion>

Plot OK

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to specify "Data" or "Standard".

Step 6

Press the [ENTER] key to confirm "Cut Position" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

Function Settings: Media Cut

Step 1

Plot OK

*Menu* Command>

*Menu* Funct ion>

InkDryTime: 30s

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Function" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Function" menu and shift to the next level.

Step 4

Bring up the "Media cut" item by pressing the [Menu Up] key or [Menu

Down] key.

How to Set Parameters

Step 5

MediaCut: Auto

Med i aCu t : Manua l

Copy : 1

*Menu* Funct ion>

Plot OK

Press the [VALUE +] or [VALUE -] key to specify "Off", "Auto" cut or "Manual" cut.

Step 6

Press the [ENTER] key to confirm "Media Cut" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

Function Settings: Copy

Step 1

Plot OK

*Menu* Command>

*Menu* Funct ion>

InkDryTime: 30s

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Function" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENETR] key to confirm the "Function" menu and shift to the next level.

Step 4

Bring up the "Copy" item by pressing the [Menu Up] key or [Menu Down] key.

Copy : 1

Copy : 15

InkDensityNormal

*Menu* Funct ion>

Plot OK

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to set the number of copies between "1" and "99".

Step 6

Press the [ENTER] key to confirm the number of copies of the applicable print and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

Function Settings: Ink Density

Step 1

Plot OK

*Menu* Command>

*Menu* Funct ion>

InkDryTime: 30s

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Function" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Function" menu and shift to the next level

Step 4

Bring up the "Ink Density" item by pressing Down] key.

the [Menu Up] key or [Menu

How to Set Parameters

Step 5

InkDensityNormal

InkDensity: Thin

Dist.Adj: No

*Menu* Funct ion>

Plot OK

Press the [VALUE +] or [VALUE -] key to set the density to "Normal", "Thin" or "Faint".

Step 6

Press the [ENTER] key to confirm "Ink Density" shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

FunctionSettings:DistanceAdjustment

Step 1

Plot OK

*Menu* Command>

*Menu* Funct ion>

InkDryTime: 30s

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Function" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Function" menu and shift to the next level

Step 4

Bring up the "Dist. Adj." item by pressing the [Menu Up] key or [Menu

Down] key.

Dist .Adj : No

Dist .Adj : Change

Data X: 00841.00

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to set "Change".

Step 6

Press the [ENTER] key to confirm the "Distance Adjustment" submenu and shift to the next level.

Step 7

Press the [Menu Up] key or [Menu Down] key to shift to the panel for

changing "Distance Adjustment X-axis Data". the value that is displayed becomes the currently set value. If no setting is to be made, it will be the width of the previously printed document. An underline shows the digit to be altered.

Function Settings: Distance Adjustment

Data X: 00841.00

Data X: 00801.00

Data X: 00800.00

Real X: 00800.00

Step 8

Set the value of the digit to be altered by pressing the[VALUE+] or [VALUE-] key.

Step 9

Continue by pressing the [Menu Up] key or [Menu Down] key to shift to another digit to be altered.

Step 9

Set the value of the digit to be altered by pressing the [VALUE+] or [VALUE-] key.

Step 10

Press [ENTER] to set "Distance Adjustment X-axis Data Value".

How to Set Parameters

Step 11

Specify the X measurement from the printed document in order to display the "Distance Adjustment X-axis Data Value". Press the [Menu Up] key or [Menu Down] key to shift to the "X-axis Data" digit that is to be altered.

Step 12

Real X: 00800.00

Set the value of the digit in the measured value by pressing the [VALUE +] or [VALUE -] key.

Step 13

Real X: 00800.20

Continue by pressing the [Menu Up] key or [Menu Down] key to shift to another digit to be altered.

Step 14

Real X: 00800.20

Set the value of the digit in the measured value by pressing the [VALUE +] or [VALUE -] key.

RJ-6000 Series USER GUIDE Functions Edition

Function Settings: Distance Adjustment

Step 15

Real X: 00800.25

Dist .Adj : Change

*Menu* Funct ion>

Plot OK

Press [ENTER] key to set "Distance Adjustment X-axis Measured Value".

Step 16

Distance Correction item is restored. If no other items are to be changed, press the [Back] key.

Step 17

Do not press any other keys for 3 minutes or press [Back] key again

Step 18

The permanent display is restored

RJ-6000 Series USER GUIDE Functions Edition

Centronics Settings: Mode

Step 1

Plot OK

*Menu* Command>

*Menu* Cent ro>

Mode : Cen t r o

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Centronics" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Centronics" menu and shift to the next level.

Step 4

Bring up the "Mode" item by pressing the [Menu Up] key or [Menu Down] key.

How to Set Parameters

Step 5

Mode : Cen t r o

Mode : B i Cen t r o

Timing: A-B

*Menu* Cent ro>

Plot OK

Press the [VALUE +] or [VALUE -] key to switch to "Centro" or "Bi Centro".

Step 6

Press the [ENTER] key to confirm "Mode" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

Centronics Settings: Timing

Step 1

Plot OK

*Menu* Command>

*Menu* Cent ro>

Mode : Cen t r o

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Centronics" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Centronics" menu and shift to the next level.

Step 4

Bring up the "Timing" item by pressing the [Menu Up] key or [Menu Down] key.

Timing: A-B

Timing: B-A

Mode : Cen t r o

*Menu* Cent ro>

Plot OK

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to switch to "A-B" or "B-A".

Step 6

Press the [ENTER] key to confirm "Timing" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

Network Setting: IP Address

Step 1

Plot OK

*Menu* Command>

*Menu* Network>

->192.034.043.015

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Network" menu by pressing the [Menu Up] key or [Menu

Down] key.

Step 3

Press the [ENTER] key to confirm the "Network" menu and shift to the next level.

Step 4

Press the [VALUE +] or [VALUE -] key to set the first part of the IP address to a number between "001" and "255". (The first part identifies the country and 192 is usually used in a LAN environment.

How to Set Parameters

Step 5

->192.034.043.015

192->034.043 .015

192->168.043 .015

Press the [ENTER] key to confirm the first address and shift to the second address.

Step 6

Press the [VALUE +] or [VALUE -] key to set the second part of the IP address to a number between "001" and "255".

Step 7

Press the [ENTER] key to confirm the second address and shift to the third address.

RJ-6000 Series USER GUIDE Functions Edition

Network Setting: IP Address

192. 168->043 .015

192. 168->001 .015

192. 168.001->015

192. 168.001->007

->192.168.001.007

Step 8

Press the [VALUE +] or [VALUE -] key to set the third part of the IP address to a number between "001" and "255".

Step 9

Press the [ENTER] key to confirm the third address and shift to the fourth address.

Step 10

Press the [VALUE +] or [VALUE -] key to set the fourth part of the IP address to a number between "001" and "255".

Step 11

Press the [ENTER] key to confirm the fourth address and shift to the first address.

Step 12

Press the [Back] key.

*Menu* Network>

Plot OK

RJ-6000 Series USER GUIDE Functions Edition

Step 13

Do not press any other keys for 3 minutes or press [Back] key again.

Step 14

The permanent display is restored.

Utility Settings: Error Display

Step 1

Plot OK

*Menu* Command>

*Menu* Ut i l i t y>

ErrorDisplay:Of f

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Utility" menu by pressing the [Menu Up] key or [Menu Down] key.

Step 3

Press the [ENTER] key to confirm the "Utility" menu and shift to the next level.

Step 4

Bring up the "Error Display" item by pressing the [Menu Up] key or [Menu

Down] key.

How to Set Parameters

Step 5

ErrorDisplay:Of f

ErrorDisplay: On

Initial: No

*Menu* Ut i l i t y>

Plot OK

Press the [VALUE +] or [VALUE -] key to switch to "Off" or "On".

Step 6

Press the [ENTER] key to confirm "Error display" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

Utility Settings: Initial: All

Step 1

Plot OK

*Menu* Command>

*Menu* Ut i l i t y>

ErrorDisplay:Of f

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Utility" menu by pressing the [Menu Up] key or [Menu Down] key.

Step 3

Press the [ENTER] key to confirm the "Utility" menu and shift to the next level.

Step 4

Bring up the "Initial" item by pressing the [Menu Up] key or [Menu Down] key.

Init ial: No

Init ial: Yes>

Init ial All: No

Init ial All: OK

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to specify "Yes".

Step 6

Press the [ENTER] key to confirm "Initial" and shift to "Initial All".

Step 7

Bring up the "Initial All" item by pressing the [Menu Up] key or [Menu

Down] key.

Step 8

Press the [VALUE +] or [VALUE -] key to specify "OK".

Step 9

Press the [ENTER] key to confirm "Initial All" and shift to to the next item to be set.

Init ialCommandNo

Initial: No

*Menu* Ut i l i t y>

Plot OK

Utility Settings: Initial: All

Step 10

If no other items are to be changed, press the [Back] key.

Step 11

If no other items are to be changed, press the [Back] key.

Step 12

Do not press any other keys for 3 minutes or press [Back] key again.

Step 13

The permanent display is restored.

How to Set Parameters

RJ-6000 Series USER GUIDE Functions Edition

Utility Settings: Initial: Command

Step 1

Plot OK

*Menu* Command>

*Menu* Ut i l i t y>

ErrorDisplay:Of f

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Utility" menu by pressing the [Menu Up] key or [Menu Down] key.

Step 3

Press the [ENTER] key to confirm the "Utility" menu and shift to the next level.

Step 4

Bring up the "Initial" item by pressing the [Menu Up] key or [Menu Down] key.

Init ial: No

Init ial: Yes>

Init ial All: No

Init ialCommandNo

Init ialCommandOK

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to specify "Yes".

Step 6

Press the [ENTER] key to confirm "Initial" and shift to "Initial All".

Step 7

Bring up the "Initial Command" item by pressing the [Menu Up] key or [Menu

Down] key.

Step 8

Press the [VALUE +] or [VALUE -] key to specify "OK".

Step 9

Press the [ENTER] key to confirm "Initial Command" and shift to the next item to be set.

Init ialFunct i.No

Initial: No

*Menu* Ut i l i t y>

Plot OK

Utility Settings: Initial: Command

Step 10

If no other items are to be changed, press the [Back] key.

Step 11

If no other items are to be changed, press the [Back] key.

Step 12

Do not press any other keys for 3 minutes or press [Back] key again.

Step 13

The permanent display is restored.

How to Set Parameters

RJ-6000 Series USER GUIDE Functions Edition

Utility Settings:Initial:Function

Step 1

Plot OK

*Menu* Command>

*Menu* Ut i l i t y>

ErrorDisplay:Of f

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Utility" menu by pressing the [Menu Up] key or [Menu Down] key.

Step 3

Press the [ENTER] key to confirm the "Utility" menu and shift to the next level.

Step 4

Bring up the "Initial" item by pressing the [Menu Up] key or [Menu Down] key.

Init ial: No

Init ial: Yes>

Init ial All: No

InitialFuncti.No

InitialFuncti.OK

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to specify "Yes".

Step 6

Press the [ENTER] key to confirm "Initial" and shift to "Initial All".

Step 7

Bring up the "Initial Functi." item by pressing the [Menu Up] key or [Menu

Down] key.

Step 8

Press the [VALUE +] or [VALUE -] key to specify "OK".

Step 9

Press the [ENTER] key to confirm "Initial Function" and shift to the next item to be set.

Init ialCentro:No

Initial: No

*Menu* Ut i l i t y>

Plot OK

Utility Settings: Initial: Function

Step 10

If no other items are to be changed, press the [Back] key.

Step 11

If no other items are to be changed, press the [Back] key.

Step 12

Do not press any other keys for 3 minutes or press [Back] key again.

Step 13

The permanent display is restored.

How to Set Parameters

RJ-6000 Series USER GUIDE Functions Edition

UtilitySettings:Initial:Centronics

Step 1

Plot OK

*Menu* Command>

*Menu* Ut i l i t y>

ErrorDisplay:Of f

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Utility" menu by pressing the [Menu Up] key or [Menu Down] key.

Step 3

Press the [ENTER] key to confirm the "Utility" menu and shift to the next level.

Step 4

Bring up the "Initial" item by pressing the [Menu Up] key or [Menu Down] key.

Init ial: No

Init ial: Yes>

Init ial All: No

Init ialCentro:No

Init ialCentro:OK

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to specify "Yes".

Step 6

Press the [ENTER] key to confirm "Initial" and shift to "Initial All".

Step 7

Bring up the "Initial Centro" item by pressing the [Menu Up] key or [Menu

Down] key.

Step 8

Press the [VALUE +] or [VALUE -] key to specify "OK".

Step 9

Press the [ENTER] key to confirm "Initial Centronics" and shift to the next item to be set.

Init ialNetworkNo

Initial: No

*Menu* Ut i l i t y>

Plot OK

Utility Settings: Initial: Centronics

Step 10

If no other items are to be changed, press the [Back] key.

Step 11

If no other items are to be changed, press the [Back] key.

Step 12

Do not press any other keys for 3 minutes or press [Back] key again.

Step 13

The permanent display is restored.

How to Set Parameters

RJ-6000 Series USER GUIDE Functions Edition

Utility Settings:Initial:Network

Step 1

Plot OK

*Menu* Command>

*Menu* Ut i l i t y>

ErrorDisplay:Of f

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Utility" menu by pressing the [Menu Up] key or [Menu Down] key.

Step 3

Press the [ENTER] key to confirm the "Utility" menu and shift to the next level.

Step 4

Bring up the "Initial" item by pressing the [Menu Up] key or [Menu Down] key.

Init ial: No

Init ial: Yes>

Init ial All: No

Init ialNetworkNo

Init ialNetworkOK

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Press the [VALUE +] or [VALUE -] key to specify "Yes".

Step 6

Press the [ENTER] key to confirm "Initial" and shift to "Initial All".

Step 7

Bring up the "Initial Network" item by pressing the [Menu Up] key or [Menu

Down] key.

Step 8

Press the [VALUE +] or [VALUE -] key to specify"OK".

Step 9

Press the [ENTER] key to confirm "Initial Network" and shift to the next item to be set.

Init ial All: No

Initial: No

*Menu* Ut i l i t y>

Plot OK

Utility Settings: Initial: Network

Step 10

If no other items are to be changed, press the [Back] key.

Step 11

If no other items are to be changed, press the [Back] key.

Step 12

Do not press any other keys for 3 minutes or press [Back] key again.

Step 13

The permanent display is restored.

How to Set Parameters

RJ-6000 Series USER GUIDE Functions Edition

Utility Settings: Dump

Step 1

Plot OK

*Menu* Command>

*Menu* Ut i l i t y>

ErrorDisplay:Of f

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Utility" menu by pressing the [Menu Up] key or [Menu Down] key.

Step 3

Press the [ENTER] key to confirm the "Utility" menu and shift to the next level.

Step 4

Bring up the "Dump" item by pressing the [Menu Up] key or [Menu Down] key.

Dump: St a r t /End

Dump: Al l

** Dump Mode **

*Menu* Ut i l i t y>

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Select "Start/End" or "All" by pressing the [Menu Up] key or [Menu Down] key.

Step 6

Press the [ENTER] key to confirm Dump mode.

Step 7

Send printing data from the host computer. print with Dump Mode.

Step 8

To terminate Dump Mode, press the

[CANCEL] key.

Step 9

Do not press any other keys for 3 minutes or press [Back] key again.

Plot OK

Utility Settings: Dump

Step 10

The permanent display is restored.

How to Set Parameters

RJ-6000 Series USER GUIDE Functions Edition

Utility Settings: Head Wash

Step 1

Plot OK

*Menu* Command>

*Menu* Ut i l i t y>

ErrorDisplay:Of f

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Utility" menu by pressing the [Menu Up] key or [Menu Down] key.

Step 3

Press the [ENTER] key to confirm the "Utility" menu and shift to the next level.

Step 4

Bring up the "Head Wash" item by pressing the [Menu Up] key or [Menu

Down] key.

HeadWash: No

HeadWash: Yes

Change Was te Ink

ChangeTank? No

ChangeTank? Yes

RJ-6000 Series USER GUIDE Functions Edition

Step 5

Select "Yes" by pressing the [Menu Up] key or [Menu Down] key.

Step 6

Press the [ENTER] key to confirm "Head Wash".

Step 7

Remove the currently installed waste box and insert a new waste liquid box from the cleaning set.

Step 8

Select "Yes" by pressing the [Menu Up] key or [Menu Down] key.

Step 9

Press the [ENTER] key to confirm waste box replaced.

Remove Ca r t r idge

Set Wash Car t

HeadWash

Remove Wash Car t

Utility Settings: Head Wash

Step 10

Remove the currently installed ink cartridges.

Step 11

Insert wash cartridges.

Step 12

Cleaning begins when wash cartridges are installed. Cleaning time is about 25 minutes.

Step 13

Remove the cleaning cartridges when head wash finishes and "Remove Wash Cart" appears.

HeadWash

Change Was te Ink

ChangeTank? No

ChangeTank? Yes

[ 65YMCK]NoCha r ge

Step 14

When the wash cartridges are removed, the operation to discharge cleaning liquid remaining inside the printer begins.

Step 15

Remove the waste box that was used for cleaning and insert another new waste liquid box from the cleaning set.

Step 16

Select "Yes" by pressing the [Menu Up] key or [Menu Down] key.

Step 17

Press the [ENTER] key to confirm waste box replaced.

Step 18

Ink filling begins automatically when ink cartridges are installed.

How to Set Parameters

RJ-6000 Series USER GUIDE Functions Edition

Utility Settings: Head Wash

Plot OK

Step 19

When ink filling is finished, the permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

Utility Settings: Data Order

Step 1

Plot OK

*Menu* Command>

*Menu* Ut i l i t y>

ErrorDisplay:Of f

If a menu is to be specified, press the

[MENU] key.

Step 2

The key contents change to the purple section on the outside of the control panel. Bring up the "Utility" menu by pressing the [Menu Up] key or [Menu Down] key.

Step 3

Press the [ENTER] key to confirm the "Utility" menu and shift to the next level.

Step 4

Bring up the "Data Order" item by pressing either [Menu Up] key or

[Menu Down] key.

How to Set Parameters

Step 5

DataOrder :5Lc6Lm

DataOrder :5Lm6Lc

ErrorDisplay:Of f

*Menu* Ut i l i t y>

Plot OK

Press the [VALUE +] or [VALUE -] key to select to "5Lc6Lm" or "5Lm6Lc".

Step 6

Press the [ENTER] key to confirm "Data Order" and shift to the next item to be set.

Step 7

If no other items are to be changed, press the [Back] key.

Step 8

Do not press any other keys for 3 minutes or press [Back] key again.

Step 9

The permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

Accuracy Adjustment Plot

Although your printer was adjusted for optimum quality at the time of shipment, the printing quality may vary according to the type of media. In such cases, an accuracy adjustment plot can be made with the following procedure.

IMPORTANT

• Unless you understand this function fully, there is a risk that the fine adjustment may make the quality even worse. Normally, no adjustment should be made.

Step 1

Plot OK

Accu r . Ad j Pl o t

With an A3 or larger sheet of media loadedvertically,press the [Fine adjust- ment] key (CLEANING, MenuUp key) while you are pressing the [Shift] key.

Step 2

The accuracy adjustment plot is printed automatically. Move to Step 3 when the accuracy adjustment plot is finished.

RJ-6000 Series USER GUIDE Functions Edition

Pat ternA: 4

Pat ternA: 6

Pat ternB: 4

Pat ternB: 5

Pat ternC: 4

Accracy Adjustment Plot

Step 3

Look at pattern A on your print. Use the [VALUE +] and [VALUE -] keys to enter the number of a line with no offset.

Step 4

Press [ENTER] key to confirm the value specified for pattern A.

Step 5

Look at pattern B on your print. Use the [VALUE +] and [VALUE -] keys to enter the number of a line with no offset.

Step 6

Press [ENTER] key to confirm the value specified for pattern B.

Step 7

Look at pattern C on your print. Use the [VALUE +] and [VALUE -] keys to enter the number of a line with no offset.

How to Set Parameters

Step 8

Pat ternC: 4

Plot OK

Press [ENTER] key to confirm the value specified for pattern C.

Step 9

Permanent display is restored.

RJ-6000 Series USER GUIDE Functions Edition

Accuracy Adjustment Plot

NOTE

• The accuracy adjustment adjusts the left head repeatability printing position (pattern A) and the right head repeatability printing position (Pattern B) as well as aligning the printing position between the right head and the left head (pattern C).

• Pressing the [ENTER] key will confirm all adjustments from pattern A to pattern C. No adjustments will be made if the [ENTER] key is pressed before the end.

• If the cancel key is pressed during fine adjustment printing or it is interrupted by raising the hold lever, there will be no input display screen.

RJ-6000 Series USER GUIDE Functions Edition

Installation of Options

In this section we explain about installing the optional network interface board and extended memory.

Network Interface Board

Installation

PAGE 80

Memory Extension

PAGE 82

Installation of Options

RJ-6000 Series USER GUIDE Functions Edition

Network Interface Board Installation

The standard interface for the RJ-6000 Series printer has a parallel Centronics compatible interface as standard equipment. The network interface board, RJETH13TX, for connection to EtherNet is also available as an option. The following procedure explains how to install the network interface board.

CAUTION

• The power to the RJ-6000 Series must be switched off and the power cord removed before the network interface board is installed.

Step 1

Undo the screws holding the silver colored interface plate on the left side of the board box below the printer and remove the interface plate.

Interface Plate Board Box

Step 2

Insert the optional interface board into the slot as shown in the diagram. When the interface board has reached the back, push it again to ensure it is pushed fully back.

Interface Board

RJ-6000 Series USER GUIDE Functions Edition

Network Interface Board Installation

CAUTION

• Electronic components are susceptible to damage by static electricity. Remove static charge from your clothes and body by touching your hands to the board box before you touch the network interface board.

Step 3

Fasten the two interface mounting screws.

Step 4

Connect a Category 5 Ethernet cable compatible with both 10BASE-T and 100BASE-TX to the connector on the interface board. Connect the other end of the Ethernet cable to the 10BASE-T or 100BASE-TX network hub.

10BASE-T/100BASE-TX Compatible Ethernet Cable (Category 5)

RJ-6000 Series USER GUIDE Functions Edition

Installation of Options

Memory Extension

Standard internal memory for the RJ-6000 Series printer is 8 MB + 32 MB (slot

1) but this can be extended by fitting an additional 16 MB (SIM16M) or 32 MB (SIM32M) memory chips (sold separately). The following procedure explains how to install extended memory.

CAUTION

• The power to the printer must be switched off and the power cord removed before the additional memory is installed.

Step 1

Remove roll media and scroller from the printer. Undo the three screws holding the board box on the printer main unit and carefully lower the board box. Remove two thumb screws to reveal the memory slot.

Board Box Fastening Screws

CAUTION

• Dust in the slot may cause damage. Blow it out with an air duster before installing the additional memory.

Step 2

The optional memory chip to be added should be inserted in slot 2 on the lower right of the board with the nicked end of the chip at the right hand end of the slot.

RJ-6000 Series USER GUIDE Functions Edition

Slot 2 Additional Memory Nicked End

Slot 1 (already in use)

Step 3

Return the board box to its original position.

Memory Extension

RJ-6000 Series USER GUIDE Functions Edition

Installation of Options

RJ-6000 Series USER GUIDE Functions Edition

Details of the Display

This section explains about displays while the printer is working, messages when an error has occurred and how to deal with them.

Printer Status Display PAGE 86

Messaged Errors and

Countermeasures PAGE 88

Data error Display and

Countermeasures PAGE 91

Command Error Display and

Countermeasures

Errors Rrequiring a Restart PAGE 94

PAGE 92

RJ-6000 Series USER GUIDE Functions Edition

Details of the Display

Printer Status Display

The normal operating condition of the printer is displayed.

Normal (when media is loaded)

Plot OK

Normal (when media is not loaded)

Paper End

Lever up

Lever Up

Cover open

Cove r Open

Data can be received and printed.

Media is not loaded or printing on a cut sheet is finished. Data can be received but can not be printed unless media is loaded.

(See Basic Edition page 37)

The hold lever is up. Put the hold lever down.

The cover is open. Close the cover.

Cover open, lever up

Lever and Cover

Data reception in progress

Receive [Por t1]

Converting the data

Conver t [Po r t 1 ]

Printing in progress

Print ing

RJ-6000 Series USER GUIDE Functions Edition

The cover is open and the hold lever is up. Close the cover and lower the hold lever.

Data is being received. Printing will begin after the data has been processed.

Data is being processed. Printing will begin after the data has been processed.

Processed data is being printed.

Cleaning in progress

Cleaning

Media initialization in progress

Con f i rmPaperK i nd

Printer Status Display

The print heads are being cleaned. Please wait.

(See Basic Edition page 63)

Media is being initialized. Please wait.

RJ-6000 Series USER GUIDE Functions Edition

Details of the Display

Messaged Errors and Countermeasures

A messaged error impedes the operation of the printer. Sometimes an error is displayed and printing continues or printing may cease when an error is displayed. If printing stops, it will be reprinted when the cause of the error is removed. When a messaged error occurs, the beeper will beep twice unless there is insufficient memory.

Capping position not set

No Cap Pos i t i on

Media recognition error

Undef ined Paper

The capping position is not recorded. The error will not be cancelled until the capping position is adjusted. Contact your local Mutoh dealer regarding capping position adjustment.

An error has occurred during media detection. Either media smaller than the minimum size or larger than the maximum size was detected or the hold lever was up or a media jam occurred during media detection. This error also occurs if the media is not loaded in the correct position. Put the hold lever up and reload the media.

(See Basic Edition page 38, 41)

Media skew error

Paper Sl ant

Media replacement error

Paper Cut Er ror

RJ-6000 Series USER GUIDE Functions Edition

Roll media has slipped obliquely. Reload the media.

(See Basic Edition page 41)

Roll media cutting failed. Cut the media, raise the hold lever and reload the media.

(See Basic Edition page 41)

Messaged Errors and Countermeasures

Media replacement request

Remove Medi a

Roll media end

End o f Rol l

No waste box

No Waste-InkTank

Check waste box

Check Waste Ink

Media is loaded but the next process has failed. The lever was raised during printing or cutting and lowered again without the media having been removed. Remove the media.

The end of the media was detected when roll media was initialized. Replace the roll media.

(See Basic Edition page 41)

The waste box is not installed. Install a waste box containing a waste liquid absorbent sheet.

(See Basic Edition page 84)

The waste box is becoming full. Obtain a waste box from supplies and have it ready for replacement.

(See Basic Edition page 84)

Waste box full

Ful lWasteI nkTank

Request to insert ink cartridges of the same type

Ink Change

The waste box is full of waste liquid. Take out the waste box and replace the waste liquid absorbent sheet. Install a waste box that contains a waste liquid absorbent sheet.

(See Basic Edition page 84)

The type of ink cartridges was changed (from dye to pigment or from pigment to dye) during cleaning or ink filling. Replace with original cartridge type.

(See Basic Edition page 80)

RJ-6000 Series USER GUIDE Functions Edition

Details of the Display

Messaged Errors and Countermeasures

Request to insert exclusive or same type ink cartridges

Differ Ink Kind

Low ink warning

[65YMCK]Near End

No ink

[65YMCK] Ink End

Either ink cartridges other than the exclusive type or mixed dye and pigment ink cartridges have been installed. Make sure exclusive ink cartridges of the same type (all dye or all pigment) are loaded.

(See Basic Edition page 80)

The remaining ink is low. Prepare a new ink cartridge of the color that is displayed.

(See Basic Edition page 79)

The ink cartridge of the color that is displayed is empty. Replace with a new cartridge.

(See Basic Edition page 79)

1 to 5 ink cartridges missing

[65YMC]Cartridge

All ink cartridges missing

Car t r idge None

Insufficient memory

NoMemo r yS IMM12MB

RJ-6000 Series USER GUIDE Functions Edition

The ink cartridge of the color that is displayed is not installed. Insert a cartridge.

(See Basic Edition page 79)

No ink cartridges are installed. Insert cartridges.

(See Basic Edition page 79)

There was insufficient memory during data processing or printing. In this case the beeper gives three long beeps. Printing continues but the result can not be guaranteed. Since the required memory size is displayed, you should consider extending the memory.

(See page 82)

Data Error Display and Countermeasures

Data errors occur when there is a fault in communication between the printer and the computer. There are three types of data error:

• Errors related to communication conditions

• Errors caused by faulty handshaking

• Escape sequence command format errors

The beeper gives three long beeps when a data error occurs.

NOTE

• The command that caused the error may be shown enclosed in brackets in the data error message.

Network board detection error

Netw. Check Err

A board other than a prescribed network interface board has been installed. Replace with a prescribed network interface board.

(See page 80)

Network board initialization error

Netw. Init. Err

An error occurred when the network interface board was installed. The network interface board may be faulty. Replace the network interface board.

(See page 80)

RJ-6000 Series USER GUIDE Functions Edition

Details of the Display

Command Error Display and Countermeasures

Command errors occur during the processing of command data received from the computer.

If the printer's command set-up differs from the type of command data sent from the computer

If there is a grammatical error in the command data sent from the computer

The beeper gives three long beeps when a data error occurs.

NOTE

• A command error may occur together with a data error (related to error code I15). In this case the communication settings should be checked.

• The command that caused the error may be shown enclosed in brackets in the data error message.

Undefined command error

MH0 1 E r r o r [ ]

Parameter error

MH0 2 E r r o r [ ]

Numerical value error

MH0 3 E r r o r [ ]

Undefined character set

MH0 4 E r r o r [ ]

RJ-6000 Series USER GUIDE Functions Edition

A command that is undefined by MHGL command mode was analyzed.

(See pages 22, 33)

An invalid number of parameters follow the command.

(See pages 22, 33)

An invalid parameter follows the command.

(See pages 22, 33)

A non-existent character set has been selected.

(See pages 22, 33)

Command Error Display and Countermeasures

Position overflow

MH0 6 E r r o r [ ]

Buffer overflow

MH0 7 E r r o r [ ]

The polygon buffer or downloadable buffer has overflowed.

(See pages 22, 33)

NOTE

• In each case, first check that the command modes of the computer and printer are compatible. Refer to your computer manual for computer settings.

RJ-6000 Series USER GUIDE Functions Edition

Details of the Display

Errors Requiring a Restart

Errors requiring a restart are fatal to the operation of the printer. The power to the printer must be switched off and the printer must be restarted. They are caused by an obstruction to the printer drive or damage related to a printer board.

When an error requiring restart occurs, the printer behaves as follows.

(a) Drive power is shut down automatically. (b)All LEDs on the control panel flash and the beeper sounds continu-

ously. The beeper will not stop until a key is pressed.

play section.

Errors Requiring Restart that Involve the Mechanical System

If an error has occurred in the mechanical system, remove the foreign object, paper scraps, etc. that are causing the obstruction and restart the printer.

Feed motor error

E065Er r X Motor

An error with the media feed motor has occurred.

Carriage motor error

E066Er r Y Motor

Feed encoder error

E069Er r Xencoder

Carriage encoder error

E070Er r Yencoder

Feed imposition timeout

E071Er r Xt imeout

Carriage imposition timeout

E072Er r Yt imeout

RJ-6000 Series USER GUIDE Functions Edition

An error with the carriage motor has occurred.

An error with the media feed encoder has occurred.

An error with the carriage encoder has occurred.

An error with the media feed imposition has occurred.

An error with the carriage imposition has occurred.

Errors Requiring a Restart

Errors Requiring Restart that Involve the Mechanical System

Feed motor overcurrent

E073Er r Xcur rent

Carriage motor overcurrent

E074Er r Ycur rent

An error with the media feed motor has occurred.

An error with the carriage motor has occurred.

NOTE

• When an error occurs in the XY drive systems, check for an obstruction in the XY drive systems. If there is an obstruction, remove it before the power is switched on again.

Sensor detection error

E075Er r Sensor

NVRAM error

E129Er r NVRAM

A sensor can not be detected.

An error has occurred when writing to the flash RAM.

Sum-check error

E016 CPUEr r [ 3 5 ]

A flash RAM sum-check error has occurred.

NOTE

• In the case of a Sensor detection error, NVRAM error or Sumcheck error, switch on the power again. If the error persists, contact your MUTOH local dealer.

RJ-6000 Series USER GUIDE Functions Edition

Details of the Display

Errors Requiring a Restart Errors Requiring Restart that Involve the CPU System

Errors Requiring Restart that Involve the CPU System

Standard DRAM error

E001Er r DRAM

Optional DRAM error

E002Er r Opt .DRAM

Interrupt exception error

E016 CPUEr r [ 0 0 ]

Command environment exception error

E016 CPUEr r [ 0 2 ]

An access error has occurred in standard DRAM.

An access error has occurred in extended DRAM (option: sold separately).

An interrupt exception error has occurred in the CPU.

A command environment exception error has occurred in the CPU.

Data environment exception error

E016 CPUEr r [ 0 3 ]

Address exception error

E016 CPUEr r [ 0 4 ]

Address exception error

E016 CPUEr r [ 0 5 ]

Bus exception error

E016 CPUEr r [ 0 6 ]

Bus exception error

E016 CPUEr r [ 0 7 ]

A data environment exception error has occurred in the CPU.

An address exception error has occurred in the CPU.

A bus exception error has occurred in the CPU.

RJ-6000 Series USER GUIDE Functions Edition

Errors Requiring Restart that Involve the CPU System

System call exception error

E016 CPUEr r [ 0 8 ]

Break point exception error

E016 CPUEr r [ 0 9 ]

Reserved command exception error

E016 CPUEr r [ 1 0 ]

Unusable co-processor exception error

E016 CPUEr r [ 1 1 ]

Operation overflow exception error

E016 CPUEr r [ 1 2 ]

A system call exception error has occurred in the CPU.

A break point exception error has occurred in the CPU.

A reserved command exception error has occurred in the CPU.

An unusable co-processor exception error has occurred in the CPU.

An operation overflow exception error has occurred in the CPU.

Errors Requiring a Restart

Trap exception error

E016 CPUEr r [ 1 3 ]

Watch exception error

E016 CPUEr r [ 2 2 ]

Watchdog timeout error

E016 CPUEr r [ 3 2 ]

Abort error

E016 CPUEr r [ 3 3 ]

A trap exception error has occurred in the CPU.

A watch exception error has occurred in the CPU.

A watchdog timeout error has occurred in the CPU.

An abort error has occurred in the CPU.

NOTE

• In each case, switch off, wait 10 seconds and switch on.

RJ-6000 Series USER GUIDE Functions Edition

Details of the Display

RJ-6000 Series USER GUIDE Functions Edition

Contents

Read this if you can't find an item you want to look up.

Control Panel and Menus

This outlines the control panel for menu settings and explains menu levels.

When You Want to Do This

When you want to do something, this explains which function to use and provides page numbers for easier manual look-up.

Explanation of Functions

Details of each function are explained and manual page numbers are provided for easier look-up.

How to Set Parameters

Detailed explanation of setting parameters in each menu.

Installation of Options

This explains how to fit the optional network interface board and extended memory.

Details of the Display

This section explains displays for normal operation as well as error messages and how to handle them.

MUTOH INDUSTRIES LTD. Tel.:81-(0)3-54867145 Fax:81-(0)3-54867163 E-mail:ibd@mutoh.co.jp http://www.mutoh.co.jp

MUTOH EUROPE N.V. Tel.:32-(0)59-807908 Fax:32-(0)59-807117 E-mail:mutoh@mutoh.be http://www.mutoh.be

MUTOH DEUTSCHLAND GmbH. Tel.:49-(0)2159 913430 Fax:49-(0)2159 913456 E-mail:Mutoh-Sales@t-online.de

HP RJ600EX-B-01 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
