HP Phoneline Gateway hn200p User Manual

hp digital home networking

phoneline gateway

model hn200p

phoneline gateway

acknowledgements and notices

hewlett-packard company notices

The information contained in this document is subject to change without notice. Hewlett-Packard (HP) makes no warranty of any kind with regard to this material including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for any errors or for incidental or consequential damages in connection with the furnishing, performance, or use of this material. All rights reserved. Reproduction, adaptation, or translation of this material is prohibited without prior written permission of Hewlett-Packard, except as allowed under copyright laws.

acknowledgements

Microsoft, MS, MS-DOS, and Windows are registered trademarks of Microsoft Corporation.

conventions

The following conventions are used in this guide:

symbols

The > symbol guides you through a series of software steps. For example:

Click Start > Settings > Control Panel to view the active control panels.

warnings

A Warning indicates possible damage to the HP Gateway or to other equipment. A Warning can also indicate a possible harm to yourself or to others.

For example:

Warning: Plugging into a nongrounded electrical socket can damage your

Gateway.

contents

introduction .............................................................5

hp digital home networking phoneline gateway.................. 5

features ......................................................................... 6

getting to know the phoneline gateway.......................7

phoneline gateway rear panel.......................................... 7

phoneline gateway front panel LEDs.................................. 9

telephone jack splitter.................................................... 10

resetting the gateway .................................................... 11

gateway system tray application ..............................13

overview...................................................................... 13

status notification windows............................................. 15

pop-up menu................................................................ 18

gateway control panel ............................................31

overview...................................................................... 31

accessing the gateway control panel............................... 32

gateway control panel screen......................................... 35

gateway control panel tabs............................................ 36

frequently asked questions (FAQs)............................41

gateway general information.......................................... 41

installation and configuration options .............................. 43

supported software ....................................................... 45

supported features ........................................................ 47

upgrade information ..................................................... 48

phoneline gateway

troubleshooting ......................................................49

appendix: the expert interface ................................. 51

advanced administration ............................................... 51

screens and functions .................................................... 52

setup ........................................................................... 53

password..................................................................... 56

status........................................................................... 58

DHCP.......................................................................... 60

log.............................................................................. 62

help ............................................................................ 63

advanced .................................................................... 64

specifications.........................................................77

general........................................................................ 77

environmental............................................................... 78

glossary ................................................................ 79

index....................................................................89

regulatory notices...................................................91

introduction

hp digital home networking phoneline gateway

Congratulations on your purchase of the HP Digital Home Networking Phoneline Gateway. The Phoneline Gateway is the perfect solution for connecting your multiple PCs to a high-speed broadband cable modem or Digital Subscriber Line (DSL) Internet connection.

Your Gateway can be configured as a Dynamic Host Conffiguration Protocol (DHCP) server, which means that it can automatically assign Internet Protocol (IP) addresses to PCs in your Local Area Network (LAN). The Gateway becomes your only visible network device on the Internet.

The Gateway also serves as your Internet firewall, protecting your networked PCs from access by external users. All incoming data is monitored and filtered using a firewall. You can configure your Gateway to permit playing Internet games and video conferencing, and you can use IP filtering to block your users from access to the Internet as needed.

The groundbreaking technology inside every HP Digital Home Networking Phoneline Gateway delivers Internet and network connectivity at speeds up to 10 Mbps. Now all of your network users can enjoy fast broadband Internet access and share internal data.

phoneline gateway

features

Gateway allows:

❑ Sharing your cable/DSL connection with every PC in your house using your

standard telephone line

❑ Adding a PC to your home network by simply plugging the PC’s phoneline

network adapter into a standard phone jack

❑ Full compatability with HomePNA 1.0, 1.1, and 2.0 ❑ Remote administration over the Internet ❑ Configuration as a DHCP server on your network ❑ Creating an Internet-sharing home network that works with your PC’s phoneline

network adapter

❑ Configuration through a Web browser such as Internet Explorer or Netscape

Navigator

Gateway provides:

❑ A bridge between your home phoneline network and an Ethernet network and

shares broadband access between them

❑ Exceptional network security with the built-in NAT firewall, which protects your

PCs from outside intruders from the Internet.

❑ All-in-one box for Internet sharing through Ethernet and home phoneline

networks

❑ Built-in Ethernet-to-phoneline network bridge for local computer connections ❑ Easy installation ❑ Control of Internet access ❑ Demilitarized Zone (DMZ) hosting for Internet multimedia applications such as

video conferencing and Internet gaming

❑ Support for port, IP, and Media Access Control (MAC) address filtering ❑ Supports to Internet Protocol Security (IPSec) pass-through for Virtual Private

Networking (VPNs)

getting to know the phoneline gateway

phoneline gateway rear panel

The Phoneline Gateway ports, to which network cables are connected, are located on the rear panel of the Gateway.

Phoneline Gateway Rear Panel

PHONE

DEVICE WALL HPNA

WAN LAN

UPLINK

DIRECT

RESET

power

phoneline gateway ports

Phone (green)

You may plug the telephone into the phone port, which uses a microfilter for signal clarity. Do not plug the telephone into any other port.

HPNA: Device (green)

Any phoneline-enabled device, such as a computer or print server, may be connected to the HPNA: Device port using a phoneline cable.

HPNA: Wall (green)

You will connect this port to a wall phone jack using a phoneline cable.

WAN (dark gray)

Connect the Digital Subscriber Line (DSL) or cable modem to the Wide Area Network (WAN) port.

LAN (blue)

You can connect an Ethernet PC or other Ethernet device to your phoneline network through the LAN 10/100BaseT port.

phoneline gateway

Crossover Switch

The Crossover Switch (X II) toggles the LAN Port between crossover mode (X) and straight-through mode (II). Choose one of the following options:

❑ When connecting the Gateway directly to a computer or to an uplink port via

the LAN port, choose crossover.

❑ When connecting any other configuration, choose straight-through.

Power

You will connect the included AC Power Adapter to the Power port.

Reset button

To refresh Gateway connections and attempt to fix routing problems, very briefly depress the Reset button with a paper clip or pencil tip.

If you have exhausted all troubleshooting options (see the troubleshooting section of this user’s guide) and continue to experience serious routing problems, depress the Reset button for about five seconds to clear all of the Gateway data and restore the factory default settings.

Warning: Resetting the Gateway may create conflicts between your PC’s

actual IP addresses and what the Gateway expects them to be. You may be forced to restart the entire system.

If the Gateway locks up, unplug the Power Adapter from the Gateway’s Power Port for 3 to 5 seconds (but not longer) and then plug it back in. Leaving the power off for too long could result in the loss of network connections.

phoneline gateway front panel LEDs

Phoneline Gateway Front Panel LEDs

POWER

LAN WAN HPNA

LAN indicators

Power

Green. The Power LED lights green when the Gateway is powered on. There is no ON/OFF switch; plug or unplug the power to turn Gateway on or off.

LAN

Green. If the LAN LED is continuously lit, the Gateway is successfully connected to the device plugged into that port (1, 2, 3, or 4). If the LED is flickering, the Gateway is actively sending or receiving data through that port.

WAN

Green. The wide area network WAN LED lights when a successful connection is made between the Gateway and the Internet through your broadband modem.

HPNA

Green. The HPNA LED lights up when the HPNA port connects successfully to your home phoneline network.

phoneline gateway

telephone jack splitter

A telephone jack splitter (which can be purchased with two or more ports) allows you to plug a telephone and multiple computers into a single phone wall jack. Plug your telephone (or fax machine) into one of the splitter’s ports and the phoneline cable from the computer's network adapter into the other.

resetting the gateway

If your network connections are erratic, reset the Gateway:

1 Shut down all network components.

2 Disconnect the power supply at the Power port and wait five seconds.

3 Plug the Gateway’s power supply back into the Power port.

phoneline gateway

gateway system tray application

overview

The Gateway installation wizard installed an application on your computer that functions as a tool kit for your Gateway. The application is accessed from a green, red, or yellow house icon in the Windows System Tray. The Window System Tray is in the recessed area of the Windows taskbar in the lower right of your screen.

If you did not authorize installation of the icon during Gateway installation, or if you deleted the icon by choosing Exit from the pop-up menu, you can reinstall the icon from the Windows Start menu. Click Start > Programs > HP Digital Home Networking > Gateway System Tray Application. You can access the System Tray application from any computer on your network.

The color of the house icon (green, red, or yellow) reflects the status of the network’s Internet connection and your computer’s ability to communicate with the Gateway:

❑ Green: all is well This computer is connected to the home network with an

active Internet connection.

Gateway System Tray icon (green)

❑ Red: no Internet connection This computer is connected to the home

network, but there is no active Internet connection.

Gateway System Tray icon (red)

phoneline gateway

❑ Yellow: connection to Gateway lost This computer is no longer

connected to the home network or to the Internet.

Gateway System Tray icon (yellow)

Besides providing constant feedback through the icon color, the Gateway System Tray application provides additional functionality:

❑ If there is any change in network status, a status notification window appears

on your screen describing the changed situation.

❑ Right-click the Gateway System Tray icon to bring up a menu allowing you to

access the Gateway Control Panel, generate special status or diagnostic reports, download and install software or firmware upgrades, and launch additional Gateway utilities.

status notification windows

Any change in network status generates a status notification window describing the change and, if needed, suggests actions to take. The change may also cause a color change in the System Tray icon. (These same windows appear when you select Get current network status from the System Tray pop-up menu. If all the results are "ok", the utility has not detected any connection problems. If you do receive an error message, however, see the table “Internet Connection Diagnostic” on page 27 for more information.)

Note: This automatic notification feature is controlled by a toggle option in the System Tray pop-up menu described in “Notify me when network events occur” on page 29.

The following are examples of status notification windows, along with explanatory comments (notice that the color of the house icon on the screen matches the color of the icon on the System Tray):

Internet Connection Down

phoneline gateway

This window appears when the Gateway attempts to access the Internet and cannot detect a connection.

Connection to Gateway Lost

This window appears when your computer cannot establish a link to the Gateway.

Caution: If you reset the Gateway, be sure to do so only briefly (a second or

two) or the Gateway will be reset to the factory defaults and any modifications you have made will be lost.

status notification windows

Internet Connection Operational

This window appears when the Internet connection is restored. It also appears when when you first start your computer.

phoneline gateway

pop-up menu

Right-clicking the Gateway System Tray icon to display the following pop-up menu:

Gateway System Tray pop-up menu

This menu provides convenient access to Gateway tools, which are described in this section.

Accessing a menu choice:

1 Right-click the icon, move cursor to highlight the desired option.

2 Highlight the desired option.

3 Left-click the option to launch it.

pop-up menu

Check for upgrade

Check for upgrade...

When a software or firmware upgrade becomes available on the HP Web site, you are notified automatically by a notification window (assuming you have enabled this option — see “Notify me when network events occur” on page 29) and prompted to download and install the upgrade.

Since the automatic notification may not be as frequent as you would like, you can also manually check for the availability of upgrades by selecting Check for upgrade... from the System Tray application pop-up menu. The application checks the HP Web site, determines which upgrade (if any) is available for your configuration, gives you an opportunity to confirm that you wish to download and install the upgrade, and performs the download and installation of your new software or firmware upgrade.

phoneline gateway

Internet speed meter

Internet speed meter...

Selecting Internet speed meter... launches a utility that monitors your upstream and downstream Internet connection speed. When you select this choice, the following window appears:

speed meter start window

Click Start, and the following window appears displaying the speed of your Internet connection (it may take a few seconds to display both downstream and upstream parameters). With DSL, the downstream speed (the speed data is downloaded from the Internet to your computer) is typically much faster than the

pop-up menu

upstream speed (the speed at which data is uploaded from your computer to the Internet), as shown in the example. Contact your DSL or broadband cable provider for specifications.

speed meter report

Gateway control panel

Gateway control panel...

The Gateway Control Panel allows you to adjust the settings of your Gateway. Access to the Control Panel requires the Gateway’s administrative password.

phoneline gateway

Save the current Gateway configuration

Save the current Gateway configuration...

This option provides a backup copy of your current Gateway settings in the event that you need to restore them. This is especially useful if you modify your settings using the Gateway Control Panel, upgrade Gateway software or firmware, or experience a system crash.

1 Select Save the current Gateway configuration… The following screen

appears:

Save configuration backup file location

pop-up menu

2 Click Browse to select a location to store the Gateway configuration backup

file. The following dialog box appears:

Choose location for configuration backup file

3 Navigate to a location of your choice for the backup file, or accept the default.

4 Click Save to save the file. The file is identified by a date and time, so you can

save a series of different configurations if desired.

Note: It is recommended that you save the current Gateway configuration on a

diskette for safekeeping after installing the Gateway.

phoneline gateway

Restore a previous Gateway configuration

Restore a previous Gateway configuration...

Select this choice to restore a previously saved configuration. If you have saved more than one configuration, you can select a specific one.

Internet connection diagnostic

Internet connection diagnostic... menu choice

pop-up menu

This utility checks your Internet connection to identify problems when a loss of connection occurs. Select the Internet connection diagnostic... to display the Internet connection diagnostic start window:

Internet connection diagnostic start window

The utility checks for Internet connections via the Gateway or directly from your computer.

phoneline gateway

Click Start to begin the diagnostic routine. The Internet Connection Diagnostic screen appears:

Internet connection diagnostic report window

pop-up menu

If all results are “ok”, the utility has not detected any connection problems.

Internet Connection Diagnostic

Parameter Message Meaning

Connection to the Gateway

Connection to the Internet via Gateway (Ping)

Connection to the Internet (Ping)

Ping primary DNS Failed Contact your ISP.

Failed Requires a “soft” reset of

the Gateway. Depress the Reset button briefly (one or two seconds) with a paperclip. Depressing the Reset button longer that two seconds can cause the factory default settings to activate.

Failed Contact your ISP.

Interpreting a “failed” report for any parameter:

❑ Connection to the Gateway. “Failed” means you should perform a soft reset of

your Gateway. To do this, briefly depress the Reset button (only a second or two) on your Gateway with a paper clip or pencil tip. Be careful not to hold it down any longer than one to two seconds or the Gateway will be reset to the factory defaults and any modifications you have made will be lost.

❑ Connection to the Internet via Gateway. “Failed” means you should contact

your Internet service provider (ISP).

❑ Connection to the Internet. “Failed” means you should contact your Internet

service provider.

❑ Ping primary DNS. “Failed” implies an Internet Service Provider problem.

Contact your ISP to report the problem.

phoneline gateway

Get current network status

Get current network status...

Selecting this choice generates one of the status notification windows discussed and illustrated in the section “status notification windows” on page 15. If all is well and the diagnostic utility detects no changes, the window appears:

example of a current network status window

+ 64 hidden pages
