HP Pavilion H8-1040 Specifications

HP Pavilion Elite h8-1040 PC

Highlights:

•

2nd Generation Intel® Core™ i7-2600 Processor

• Genuine Windows® 7 Home Premium 64-bit

• Get powerful 64-bit performance with 10GB DDR3 system memory

• 1.5TB (Terabyte) hard drive

• SuperMulti DVD burner and Blu-ray Disc player

• NVIDIA® GeForce® GTX 550 Ti graphics card

• Wireless LAN 802.11b/g/n

• Front-panel 15-in-1 memory card reader

• Built in TV Tuner: watch, pause, rewind, and record live TV

• HP Media Center remote control with IR (infrared) receiver

• 24 x 7 toll-free phone support, one-year HP limited warranty, lifetime use of

HP Support Assistant provide priceless peace of mind

(4)

stores up to 335,000 songs or 268,000 photos

(19)

HP recommends Windows® 7.

(2)

(1)

(6)

(3)

(17)

(5)

Designed for powerful performance and elegance

Get serious about computing with the HP Pavilion h8-1040 PC, a stylish,
high-performance PC for your most demanding digital tasks. Premium
performance levels enable an optimized experience whether you’re working,
e-mailing, editing photos or videos, gaming or connecting with friends

(10)

online

. The HP Pavilion h8-1040 PC's expandability lets you add devices
and features to support your growing needs. The elegant accented design will
attract attention in any home décor.

• Handles multiple demanding projects easily and simultaneously.

• Top-positioned power button enables convenient use.

• A built-in valet tray on top of the tower provides convenient access and

cable management for a variety of small peripherals and accessories.

• A sliding panel offers quick access to front-mounted ports while keeping

them hidden when they’re not in use.

• The front-panel 15-in-1 memory card reader makes it easy to transfer

photos, music, and other files to and from your digital camera and other
peripheral devices.

• Convenient, tool-free access to various internal components makes user

upgrades a snap.

• The HP Pavilion h8 PC also features Wireless LAN 802.11b/g/n

networking.

(19)

HP LinkUp software

HP LinkUp software lets you access the content and programs on your
notebook

(37)

from your HP desktop PC

(38)

—without file mix-ups or complex

synchronization.

• Get the freedom and mobility of your notebook PC with the comfort and

convenience of your HP desktop’s full-size monitor and keyboard.

• Stop spreading files across e-mail, flash drives, and multiple PCs—all of

your files and applications stay up to date on your notebook
access them from your desktop

• No cables or docking stations required—once you install the free client

software on your notebook PC
through your wireless home network.

• Access your work, school, or personal notebook

with HP LinkUp software

(38)

.

(37)

, it links up with your HP desktop

(38)

.

(37)

using any HP desktop PC

(37)

, while you

(38)

Latest processor technology

New Intel® Core™ Processors plus HP-exclusive features propel you into a vivid
PC experience. Extra speed and performance adapts to your needs while
delivering spectacular visuals in a smooth, seamless flow. With HP convenience
and security, it’s an unbeatable combination. HP + Intel: It’s not just the speed,
it’s the experience.

Hear the music you've been missing

In an exclusive partnership with music industry leaders, HP has engineered an
audio system that unlocks all the sounds that musicians and producers have
perfected in the studio. What you hear: the highs, lows and subtle in-betweens
that standard PCs can’t touch. What you get: goose bumps, shivers down the
spine and all the feeling that artists put into their music. Beats Audio™ is all
about the music. Revolutionary Beats Audio™ system, configurable on select
models, was designed by music industry giants Jimmy Iovine and Dr. Dre to let
users enjoy their music “the way the artists intended”.

Relax with 24/7 Support

While your PC is within Warranty, HP Care Pack Support gives you access to
complimentary help whichever way you prefer:

(10)

• From your desktop: Click the HP Support Assistant icon for quick access to
preinstalled content and diagnostic tools.

• Through the Internet: Visit our Consumer Support Forum, available 24/7 in
English, French or Spanish at www.hp.ca/support/consumer-forum.
www.hp.ca/go/notebookcare.

• By telephone: 1.800.HP.INVENT (1.800.474.6836).

To continue complimentary access to support, you can extend your Standard
Warranty with an HP Care Pack service. Visit www.hp.ca/go/totalcare for
your choice of plans.

If your PC is out-of-warranty, you can visit the Consumer Support Forum (
www.hp.ca/support/consumer-forum) at no charge. You can also call

1.800.HP.INVENT (1.800.474.6836), but support charges will apply.

HP Pavilion Elite h8-1040 PC

HP recommends Windows® 7.

SPECIFICATIONS

OPERATING SYSTEM • Genuine Windows® 7 Home Premium 64-bit - makes everyday tasks

simple—and makes new things possible

PROCESSOR • 2nd Generation Intel® Core™ i7-2600 Processor
PROCESSOR SPEED • 3.40GHz

(2)

CACHE • 8MB Cache
BUS SPEED
CHIPSET • Intel® H67 PCH Chipset
MEMORY • 10GB PC3-10600 DDR3 SDRAM memory

performance) (expandable to 16GB)

HARD DRIVE • 1.5TB (Terabyte) 5400RPM Serial ATA hard drive
OPTICAL DRIVE(S) • SuperMulti Blu-ray Player

(6)

• Write: 16x max DVD±R, 8x max DVD±R DL, 8x max DVD+RW, 6x max
DVD-RW, 5x max DVD-RAM, 40x max CD-R, 24x max CD-RW
Read: 12x max BD-ROM, 16x max DVD-ROM, 40x max CD-ROM
Data transfer rates up to 6,000 KB/s (CD read/write), 21,600 KB/s (DVD
read/write) and 54,000 KB/s (BD read)

VIDEO GRAPHICS • NVIDIA® GeForce® GTX 550 Ti graphics card with 1GB GDDR5 dedicated

graphics memory, 2xDVI and mini-HDMI (VGA & HDMI via adapter)
capabilities and support for Blu-ray and Microsoft® DirectX® 11

• Up to 4095MB Total Available Graphics Memory as
allocated by Windows® 7

NETWORK

• 10/100/1000Base-T network interface

INTERFACE
WIRELESS

• Wireless LAN 802.11b/g/n

(19)

CONNECTIVITY
SOUND • High Definition Audio with up to 7.1 surround sound capabilities

• Beats AudioTM Studio Quality Sound. Hear music the way the artist intended

TV TUNER • Built in TV Tuner: watch, pause, rewind, and record live TV
REMOTE CONTROL • HP Media Center remote control with IR (infrared) receiver
MEMORY SLOTS • 4 DIMM (240-pin, DDR3) (occupied)
EXPANSION SLOTS • 3 PCI Express x1 (two available)

• 1 PCI Express x16 (occupied)

• 1 MiniCard (occupied)

EXPANSION BAYS • 2 external 5.25" (one available)

• 2 internal 3.5" (one available)

EXTERNAL PORTS • Front panel 15-in-1 memory card reader: supports SmartMedia, xD,

MultiMedia Card, Secure Digital (SD), Mini Secure Digital, Compact Flash I,
Compact Flash II, IBM Microdrive, Memory Stick, Memory Stick Pro, Memory
Stick Duo, Memory Stick Pro Duo, RSMMC, MMC Mobile, MMC+

• 4 USB 2.0 ports (Back)

• 2 USB 2.0 ports (Front)

• 2 USB 3.0 ports

• Headphone, Microphone (Top I/O)

• Optical Audio Out, LAN, Microphone/Line-in/Line-out, Rear speaker-out,
Side speaker out, Center (subwoofer)

MULTI-DISPLAY
CAPABLE

MOUSE AND

• 2xDVI and mini-HDMI (VGA & HDMI via adapter) capabilities and support
for one or two monitors, Blu-ray and Microsoft® DirectX® 11

• HP wireless keyboard and wireless optical mouse

KEYBOARD
DIMENSIONS • Unpackaged: 16.22"(L) x 6.88"(W) x 16.34"(H/D) approx.

• Packaged: 19.65"(L) x 11.22"(W) x 20.51"(H/D) approx.

WEIGHT • Unpackaged: 24.20 lbs. approx

• Packaged: 34.17 lbs. approx

(1)

(2)

(3)

(3x2GB and 1x4GB for ultimate

(4)

(17)

WARRANTY AND
SUPPORT

• Warranty:

- 1 year limited hardware warranty and 1 year software support, offering
24x7 technical assistance available online

(10)

or toll-free by phone

- 24x7 toll-free phone support

- Lifetime use of HP Support Assistant to keep your Windows 7 PC up to date
and get assistance when you need it. Learn more at
www.hp.ca/go/hpsupportassistant

• Service:

- Service Delivery: Customer Replaceable Parts; Return to hp for repair;
Authorized Service Provider

- For information, visit www.hp.ca/support

• Support:

- Desktop icon provides one-click access to built-in HP Support Assistant to
keep your PC up to date and get assistance when you need it.

- Visit our Consumer Support Forum, available 24/7 in English, French or
Spanish at www.hp.ca/support/consumer-forum. In the US, go to
www.hp.ca/go/totalcare.

- Direct, knowledgeable assistance available 24/7 toll-free by phone.

- Chat with a support specialist

SOFTWARE

PRODUCTIVITY &
LIFESTYLE

SECURITY &
PROTECTION

SUPPORT • HP Support Assistant: helps you maintain the performance of your PC and

(34)

• HP LinkUp lets you wirelessly access, edit, and save content on your notebook

(37)

PC

while using your desktop PC

(38)

• Windows Live™ Essentials - Create, connect and share with the Cloud

• Office 2010 preloaded (purchase of a Product Key required to activate a full
Office 2010 suite)

• Protection against cybercrime. Free 60-day Norton Internet Security
subscription
performance

(14)

(11)

, optimized for your PC and ranked #1 in protection and

(39)

. Surf, shop and bank online safely.

resolve problems with automated updates and tune-ups, built-in diagnostics,
and guided assistance.

• HP Setup Manager: Learn about your new PC and explore key activities that
can help you transition smoothly and easily from your old PC.

ADDITIONAL INFORMATION

PRODUCT NUMBER • QN562AA#ABC
UPC CODE • 886111453139
COUNTRY OF

ORIGIN
TARIFF NUMBER • 8471500085
PALLET

INFORMATION

• Mexico

• Dimensions: 47.24"(L) x 40.16"(W) x 87.40"(H/D) approx.

• Total weight: 1,115.5 lbs. approx.

• Layers: 8

• Products per layer: 4

• Total products per pallet: 32

VISIT WWW.HP.CA FOR MORE DETAILS!

(1)

Microsoft® and Windows® are registered trademarks of Microsoft Corporation. This system may require upgraded and/or separately purchased hardware and/or a DVD drive to install the Windows 7 software and take full advantage of Windows 7 functionality. This

version contains all product updates (SP1). See http://www.microsoft.com/windows/windows-7/ for details.

(2)

Processor speed 3.40GHz, 8MB cache.

(5)

software.

Capacity based on average compressed .jpg size of 5MB/image. Capacity based on 4 minutes per song and 128-Kbps AAC encoding.
materials. Intended only for creation and storage of original material and other lawful uses. Double Layer is a new technology. Double Layer media compatibility will widely vary with some home DVD players and DVD-ROM drives. 16x max DVD-ROM drive data transfer
rates up to 6,000 KB/s (CD read) and 21,632 KB/s (DVD read). Note that DVD-RAM cannot read or write to 2.6GB Single Sided/5.2 GB Double Sided – Version 1.0 media. As Blu-Ray is a new format containing new technologies, certain disc, digital connection,
compatibility and/or performance issues may arise, and do not constitute defects in the product. Flawless playback on all systems is not guaranteed. In order for some Blu-ray titles to play, they may require a DVI or HDMI digital connection and your display may require
HDCP support. HD-DVD movies cannot be played on this Desktop PC.
and Excel. Purchase of Product Key required to activate full Office 2010 suite available at participating resellers/retailers and www.office.com
and other factors. An external over-the-air antenna that receives UHF and VHF signals is required for ATSC reception. Viewing HD content will require a compatible high-definition display. Ability to record, edit, or transfer broadcast content such as TV programming may
be limited depending on the type of content. Performance issues may arise, and do not constitute defects in the product.

(38)

7.

Internet connection and home network required.
Monitor and speakers sold separately. Actual product may vary from image shown on datasheet. ©2011 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are
set forth in the express warranty statements accompanying such products and services. Nothing shall be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. 05/13_r1 jf

Product Number: QN562AA#ABC

(3)

Up to 256MB of main system memory may be allocated to support video graphics.

(10)

Internet access required and sold separately.

(39)

Based on Passmark Report www.norton.com/passmark2011 and Dennis Technology Labs www.norton.com/dennislabs2011.

(11)

(19)

(4)

For hard drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 14GB of storage space is reserved for the system recovery

Internet access required. First 60 days included; subscription required for live updates afterwards.

Wireless access point and Internet service sold separately.

(6)

Actual speeds may vary. Does not permit copying of commercially available DVD movies or other copyright-protected

(14)

(17)

ATSC high-definition (HD) and NTSC source content varies and will depend on broadcast signal, antenna, geographic location

(37)

Compatible with any notebook or desktop PC running Windows XP, Vista, or Windows

Includes reduced functionality versions of Word
