HP Pavilion dm1-4171nr User Manual
User Guide
HP Notebook
© Copyright 2011 Hewlett-Packard
Development Company, L.P.
Bluetooth is a trademark owned by its
proprietor and used by Hewlett-Packard
Company under license. Intel is a
trademark of Intel Corporation in the U.S.
and other countries. Microsoft and Windows
are U.S. registered trademarks of Microsoft
Corporation. SD Logo is a trademark of its
proprietor.
The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
First Edition: August 2011
Document Part Number: 667976-001
Product notice
This guide describes features that are
common to most models. Some features
may not be available on your computer.
Software terms
By installing, copying, downloading, or
otherwise using any software product
preinstalled on this computer, you agree to
be bound by the terms of the HP End User
License Agreement (EULA). If you do not
accept these license terms, your sole
remedy is to return the entire unused
product (hardware and software) within 14
days for a refund subject to the refund
policy of your place of purchase.
For any further information or to request a
full refund of the computer, please contact
your local point of sale (the seller).
Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not
place the computer directly on your lap or obstruct the computer air vents. Use the computer only on
a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft
surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to
come into contact with the skin or a soft surface, such as pillows or rugs or clothing, during operation.
The computer and the AC adapter comply with the user-accessible surface temperature limits defined
by the International Standard for Safety of Information Technology Equipment (IEC 60950).
iii
iv Safety warning notice
Table of contents
1 Introduction ..................................................................................................................................................... 1
Important first steps .............................................................................................................................. 1
Finding information ............................................................................................................................... 2
2 Getting to know your computer ..................................................................................................................... 4
Top ....................................................................................................................................................... 4
TouchPad ............................................................................................................................ 4
Lights ................................................................................................................................... 5
Buttons ................................................................................................................................. 6
Keys ..................................................................................................................................... 8
Front ..................................................................................................................................................... 9
Right side ........................................................................................................................................... 10
Left side .............................................................................................................................................. 11
Display ................................................................................................................................................ 12
Bottom ................................................................................................................................................ 13
Labels ................................................................................................................................................. 14
3 HP QuickWeb (select models only) ............................................................................................................. 15
Getting started .................................................................................................................................... 15
Starting HP QuickWeb ....................................................................................................................... 16
4 Networking .................................................................................................................................................... 17
Using an Internet service provider ...................................................................................................... 18
Creating a wireless connection .......................................................................................................... 19
Identifying wireless and network status icons .................................................................... 19
Turning wireless devices on or off ..................................................................................... 20
Using HP Connection Manager (select models only) ........................................................ 20
Using operating system controls ........................................................................................ 21
Using a WLAN .................................................................................................................................... 21
Connecting to an existing WLAN ....................................................................................... 21
Setting up a new WLAN network ....................................................................................... 22
v
Configuring a wireless router ............................................................................ 22
Protecting your WLAN ....................................................................................... 23
Roaming to another network ............................................................................. 23
Using HP Mobile Broadband (select models only) ............................................................................. 24
Inserting a SIM ................................................................................................................... 24
Removing a SIM ................................................................................................................ 25
Using Bluetooth wireless devices (select models only) ...................................................................... 25
Bluetooth and Internet Connection Sharing (ICS) ............................................................. 25
Connecting to a wired network ........................................................................................................... 26
Connecting to a local area network (LAN) (select models only) ........................................ 26
5 Pointing devices and keyboard ................................................................................................................... 27
Using pointing devices ....................................................................................................................... 27
Setting pointing device preferences ................................................................................... 27
Using the TouchPad .......................................................................................................... 27
Turning the TouchPad off or on ........................................................................ 28
Navigating ......................................................................................................... 29
Selecting ........................................................................................................... 29
Using TouchPad gestures ................................................................................. 30
Scrolling ............................................................................................ 31
Pinching/Zooming ............................................................................. 31
Rotating ............................................................................................ 32
Flicking ............................................................................................. 32
Using the keyboard ............................................................................................................................ 33
Using the action keys ......................................................................................................... 33
Using the hotkeys .............................................................................................................. 34
6 Multimedia and other features ..................................................................................................................... 35
Using the media activity controls ........................................................................................................ 35
Audio .................................................................................................................................................. 35
Adjusting the volume ......................................................................................................... 36
Checking audio functions on the computer ........................................................................ 36
Using Beats Audio (select models only) ............................................................................................. 37
Webcam (select models only) ............................................................................................................ 37
Video .................................................................................................................................................. 38
VGA ................................................................................................................................... 38
HDMI .................................................................................................................................. 39
Configuring audio for HDMI ............................................................................... 39
Intel Wireless Display (select models only) ....................................................................... 40
Using CyberLink PowerDVD (select models only) ............................................................................. 40
vi
7 Power management ...................................................................................................................................... 41
Inserting or removing the battery ........................................................................................................ 41
Inserting the battery ........................................................................................................... 41
Removing the battery ......................................................................................................... 42
Shutting down the computer ............................................................................................................... 43
Setting power options ......................................................................................................................... 43
Using power-saving states ................................................................................................. 43
Initiating and exiting Sleep ................................................................................ 44
Initiating and exiting Hibernation ....................................................................... 44
Using the power meter ....................................................................................................... 45
Using power plans ............................................................................................................. 45
Viewing the current power plan ......................................................................... 45
Selecting a different power plan ........................................................................ 45
Customizing power plans .................................................................................. 45
Setting password protection on wakeup ............................................................................ 46
Using HP Power Manager (select models only) ................................................................................. 46
Using battery power ........................................................................................................................... 47
Finding battery information ................................................................................................ 47
Using Battery Check .......................................................................................................... 47
Displaying the remaining battery charge ........................................................................... 48
Maximizing battery discharge time .................................................................................... 48
Managing low battery levels .............................................................................................. 48
Identifying low battery levels ............................................................................. 48
Resolving a low battery level ............................................................................. 49
Resolving a low battery level when external power is available ....... 49
Resolving a low battery level when a charged battery is available ... 49
Resolving a low battery level when no power source is available .... 49
Resolving a low battery level when the computer cannot exit
Hibernation ....................................................................................... 49
Conserving battery power .................................................................................................. 49
Storing a battery ................................................................................................................ 50
Disposing of a used battery ............................................................................................... 50
Replacing the battery ......................................................................................................... 50
Using external AC power .................................................................................................................... 51
Testing an AC adapter ....................................................................................................... 52
8 External cards and devices .......................................................................................................................... 53
Using Digital Media Slot cards (select models only) .......................................................................... 53
Inserting a digital card ........................................................................................................ 53
Removing a digital card ..................................................................................................... 54
Using a USB device ........................................................................................................................... 54
vii
Connecting a USB device .................................................................................................. 55
Removing a USB device .................................................................................................... 55
Using optional external devices .......................................................................................................... 56
Using optional external drives ............................................................................................ 56
9 Drives ............................................................................................................................................................. 57
Handling drives ................................................................................................................................... 57
Using hard drives ............................................................................................................................... 58
Improving hard drive performance ..................................................................................... 58
Using Disk Defragmenter .................................................................................. 58
Using Disk Cleanup ........................................................................................... 58
Using HP 3D DriveGuard (select models only) .................................................................. 59
Identifying HP 3D DriveGuard status ................................................................ 59
Managing power with a parked hard drive ........................................................ 59
Using HP 3D DriveGuard software ................................................................... 60
Adding or replacing a hard drive ........................................................................................................ 60
Removing the hard drive .................................................................................................... 60
Installing a hard drive ......................................................................................................... 62
10 Memory modules ........................................................................................................................................ 64
Replacing the memory module ........................................................................................................... 64
11 Security ........................................................................................................................................................ 67
Protecting the computer ..................................................................................................................... 67
Using passwords ................................................................................................................................ 68
Setting passwords in Windows .......................................................................................... 68
Setting passwords in Setup Utility (BIOS) ......................................................................... 69
Managing an administrator password ............................................................... 70
Entering an administrator password .................................................................. 70
Managing a power-on password ....................................................................... 70
Entering a power-on password ......................................................................... 71
Using antivirus software ..................................................................................................................... 71
Using firewall software ....................................................................................................................... 71
Installing critical security updates ....................................................................................................... 72
Installing an optional security cable lock ............................................................................................ 72
12 Backup and recovery .................................................................................................................................. 73
Restoring the system .......................................................................................................................... 74
Creating restore media ....................................................................................................................... 74
Performing a system recovery ............................................................................................................ 75
viii
Using the dedicated recovery partition (select models only) ............................................. 75
Restoring using the restore media ..................................................................................... 76
Changing the computer boot order .................................................................................... 76
Backing up and recovering your information ...................................................................................... 77
Using Windows Backup and Restore ................................................................................ 78
Using Windows system restore points ............................................................................... 78
When to create restore points ........................................................................... 78
Create a system restore point ........................................................................... 79
Restore to a previous date and time ................................................................. 79
13 Setup Utility (BIOS) and System Diagnostics .......................................................................................... 80
Using Setup Utility (BIOS) .................................................................................................................. 80
Starting Setup Utility (BIOS) .............................................................................................. 80
Changing the language of Setup Utility (BIOS) ................................................................. 80
Navigating and selecting in Setup Utility (BIOS) ................................................................ 81
Displaying system information ........................................................................................... 82
Restoring factory settings in Setup Utility (BIOS) .............................................................. 82
Exiting Setup Utility (BIOS) ................................................................................................ 83
Updating the BIOS ............................................................................................................. 83
Determining the BIOS version ........................................................................... 83
Downloading a BIOS update ............................................................................. 84
Using System Diagnostics .................................................................................................................. 85
Appendix A Troubleshooting and support .................................................................................................... 86
Troubleshooting .................................................................................................................................. 86
The computer is unable to start up .................................................................................... 86
The computer screen is blank ............................................................................................ 86
Software is functioning abnormally .................................................................................... 86
The computer is on but not responding ............................................................................. 87
The computer is unusually warm ....................................................................................... 87
An external device is not working ...................................................................................... 87
The wireless network connection is not working ................................................................ 88
Contacting customer support ............................................................................................................. 88
Appendix B Cleaning your computer ............................................................................................................. 89
Cleaning the display ........................................................................................................................... 89
Cleaning the sides and cover ............................................................................................................. 89
Cleaning the TouchPad and keyboard ............................................................................................... 89
Appendix C Traveling with the computer ...................................................................................................... 90
ix
Appendix D Updating programs and drivers ................................................................................................ 92
Appendix E Electrostatic Discharge .............................................................................................................. 93
Appendix F Specifications .............................................................................................................................. 94
Input power ......................................................................................................................................... 94
DC plug of external HP power supply ................................................................................ 94
Operating environment ....................................................................................................................... 95
Index ................................................................................................................................................................... 96
x
1Introduction
This guide contains details about your computer's components, such as ports and jacks. It describes
multimedia and other features. And it provides important security, backup, and recovery information.
NOTE: Some of the features described in this guide may not be available on your computer.
Important first steps
After you set up and register the computer, it is important to take the following steps:
1. Set up your wired or wireless network. For more information, refer to
2. Update your antivirus software. For more information, refer to
on page 71.
3. Create recovery discs or a recovery flash drive. For instructions, refer to
on page 73.
4. Get to know your computer. Refer to
devices and keyboard on page 27 for additional information.
5. Discover the software that is already installed on the computer by selecting Start > All
Programs.
Getting to know your computer on page 4 and Pointing
Using antivirus software
Networking on page 17.
Backup and recovery
Important first steps 1
Finding information
The computer comes with several resources to help you perform various tasks.
Resource Contents
Instructions for setting up the computer
User Guide
To access this guide:
Select Start > Help and Support > User Guides.
How to set up the computer
●
● Identification of computer components
Computer features
●
● Power management features
● Instructions for the following:
◦ Connecting to a wireless network
Using the keyboard and pointing devices
◦
Using the multimedia features of the computer
◦
Maximizing battery life
◦
Replacing or upgrading the hard drive and memory
◦
modules
Protecting the computer
◦
◦ Performing a backup and a recovery
◦ Contacting customer support
◦ Caring for the computer
Updating the software
◦
Help and Support
To access Help and Support, select Start > Help and
Support.
NOTE: For country- or region-specific support, go to
http://www.hp.com/support, select your country or
region, and follow the on-screen instructions.
Regulatory, Safety and Environmental Notices
To access this guide:
Select Start > Help and Support > User Guides.
Safety & Comfort Guide
To access this guide:
Select Start > Help and Support > User Guides.
– or –
Go to
http://www.hp.com/ergo.
Worldwide Telephone Numbers booklet
This booklet is provided with your computer.
Computer specifications
●
Operating system information
●
● Software, driver, and BIOS updates
Troubleshooting tools
●
Instructions for contacting customer support
●
● Regulatory and safety information
Battery disposal information
●
Proper workstation setup
●
● Guidelines for posture and work habits that maximize your
comfort and decrease your risk of injury
Electrical and mechanical safety information
●
HP customer support telephone numbers
2 Chapter 1 Introduction
Resource Contents
HP Web site
To access this Web site, go to
support.
Limited Warranty*
To access the warranty:
Select Start > Help and Support > User Guides.
– or –
Go to
http://www.hp.com/go/orderdocuments.
*You can find the expressly provided HP Limited Warranty applicable to your product located with the electronic guides on
your computer and/or on the CD/DVD provided in the box. In some countries/regions, HP may provide a printed HP Limited
Warranty in the box. For some countries/regions where the warranty is not provided in printed format, you may request a
printed copy from
North America: Hewlett-Packard, MS POD, 11311 Chinden Blvd, Boise, ID 83714, USA
●
● Europe, Middle East, Africa: Hewlett-Packard, POD, Via G. Di Vittorio, 9, 20063, Cernusco s/Naviglio (MI), Italy
Asia Pacific: Hewlett-Packard, POD, P.O. Box 200, Alexandra Post Office, Singapore 911507
●
When you request a printed copy of your warranty, please include your product number, warranty period (found on your
serial number label), name, and postal address.
http://www.hp.com/go/orderdocuments or write to:
http://www.hp.com/
Customer support information
●
● Information for ordering parts
Software, driver, and BIOS updates
●
Information about accessories for the computer
●
Warranty information
IMPORTANT: Do NOT return your HP product to the addresses above. For product support, refer to your product home
page at
http://www.hp.com/go/contactHP.
Finding information 3
2 Getting to know your computer
Top
TouchPad
Component Description
(1) TouchPad light ● On: The TouchPad is off.
(2) TouchPad on/off button Turns the TouchPad on or off. Quickly double-tap the
(3) TouchPad zone Moves the pointer and selects or activates items on the
(4) Left TouchPad button Functions like the left button on an external mouse.
(5) Right TouchPad button Functions like the right button on an external mouse.
4 Chapter 2 Getting to know your computer
Off: The TouchPad is on.
●
TouchPad on/off button to turn the TouchPad on and off.
screen.
Lights
Component Description
(1)
(2)
(3)
(4) Caps lock light On: Caps lock is on.
(5) TouchPad light ● On: The TouchPad is off.
Power light
Mute light
Wireless light
White: The computer is on.
●
● Blinking white: The computer is in the Sleep state.
● Off: The computer is off or in Hibernation.
Amber: Computer sound is off.
●
● Off: Computer sound is on.
White: An integrated wireless device, such as a
●
wireless local area network (WLAN) device and/or a
Bluetooth® device, is on.
Amber: All wireless devices are off.
●
Off: The TouchPad is on.
●
Top 5
Buttons
6 Chapter 2 Getting to know your computer
Component Description
(1)
(2)
Power button
QuickWeb button Opens QuickWeb (select models only).
When the computer is off, press the button to turn on
●
the computer.
● When the computer is on, press the button briefly to
initiate Sleep.
When the computer is in the Sleep state, press the
●
button briefly to exit Sleep.
When the computer is in Hibernation, press the button
●
briefly to exit Hibernation.
If the computer has stopped responding and Windows®
shutdown procedures are ineffective, press and hold the
power button for at least 5 seconds to turn off the computer.
To learn more about your power settings, select Start >
Control Panel > System and Security > Power Options,
or refer to
● When the computer is off or in Hibernation, press the
●
●
Setting power options on page 43.
button to open HP QuickWeb.
When the computer is in Microsoft Windows, press the
button to open the default Web browser.
When the computer is in HP QuickWeb, press the
button to open the Web browser.
QuickWeb allows you to browse the Internet, communicate
with Skype, and explore other HP QuickWeb programs.
When the computer is off or in Hibernation, you can press
the QuickWeb button to access these features without
waiting for the operating system to start.
NOTE: For more information, refer to
(select models only) on page 15 and to the HP QuickWeb
software Help. If your computer does not have HP
QuickWeb software, the button opens the Web browser.
HP QuickWeb
Top 7
Keys
Component Description
(1) esc key Displays system information when pressed in combination
with the fn key.
(2) fn key Executes frequently used system functions when pressed
in combination with the b key or the esc key.
(3)
(4)
(5) Action keys Execute frequently used system functions.
Windows logo key Displays the Windows Start menu.
Windows applications key Displays a shortcut menu for items beneath the pointer.
8 Chapter 2 Getting to know your computer
Front
Component Description
Speakers (2) (select models only) Produce sound.
Front 9
Right side
Component Description
(1) Digital Media Slot Supports the following digital card formats:
MultiMediaCard
●
Secure Digital (SD) Card
●
● Secure Digital High-Capacity (SDHC) Card
Secure Digital Extended Capacity (SDxC) Card
●
(2)
(3)
(4)
(5)
(6)
Audio-out (headphone) jack Produces sound when connected to optional powered
stereo speakers, headphones, earbuds, a headset, or
television audio.
WARNING! To reduce the risk of personal injury, adjust
the volume before putting on headphones, earbuds, or a
headset. For additional safety information, refer to the
Regulatory, Safety and Environmental Notices.
NOTE: When a device is connected to the headphone
jack, the computer speakers are disabled.
Audio-in (microphone) jack Connects an optional computer headset microphone,
stereo array microphone, or monaural microphone.
USB 2.0 ports (2) Connect optional USB 2.0 devices.
External monitor port Connects an external VGA monitor or projector.
RJ-45 (network) jack Connects a network cable.
10 Chapter 2 Getting to know your computer
Left side
Component Description
(1)
(2) Battery light
(3)
(4) Vent Enables airflow to cool internal components.
(5)
Power connector Connects an AC adapter.
White: The computer is connected to external power.
●
If a battery installed, the battery is fully charged.
● Amber: The computer is connected to external power
and the battery is charging.
Off: The computer is not connected to external power.
●
Blinking: The computer is in the Sleep state.
●
Security cable slot Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a
deterrent, but it may not prevent the computer from being
mishandled or stolen.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and off during routine
operation.
Hard drive light
Blinking white: The hard drive is being accessed.
●
● Amber: HP 3D DriveGuard has temporarily parked the
hard drive.
(6)
(7)
HDMI port Connects an optional video or audio device, such as a
high-definition television, or any compatible digital or audio
component.
USB 2.0 port Connects an optional USB 2.0 device.
Left side 11
Display
Component Description
(1) Internal display switch Turns off the display or initiates Sleep if the display is closed
(2) WLAN antennas (2)* Send and receive wireless signals to communicate with wireless
(3) WWAN antennas (2)* (select models only) Send and receive wireless signals to communicate with wireless
(4) Internal microphone Records sound.
(5) Webcam Records video and captures still photographs.
(6) Webcam light On: The webcam is in use.
*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately
around the antennas free from obstructions. To see wireless regulatory notices, refer to the section of the Regulatory, Safety
and Environmental Notices that applies to your country or region. These notices are located in Help and Support.
while the power is on.
NOTE: The display switch is not visible from the outside of the
computer.
local area networks (WLAN).
wide-area networks (WWAN).
To use the webcam, select Start > All Programs >
Communication and Chat > CyberLink YouCam.
12 Chapter 2 Getting to know your computer
Bottom
Component Description
(1) Battery bay Holds the battery.
(2) SIM slot (select models only) Supports a wireless subscriber identity module (SIM) (select
models only). The SIM slot is located inside the battery bay.
(3)
(4) Vent Enables airflow to cool internal components.
(5) Service door Provides access to the hard drive bay, the memory module
Battery/service door latch Releases the battery from the battery bay and the service
door from the computer.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and off during routine
operation.
slot, the wireless local area network (WLAN) module, and
the WWAN module (select models only).
Bottom 13
Labels
The labels affixed to the computer provide information you may need when you troubleshoot system
problems or travel internationally with the computer:
●
Serial number label—Provides important information, including the following:
Component
(1) Product name
(2) Serial number
(3) Product part number
(4) Warranty period
(5) Model description
Have this information available when you contact customer support. The serial number label is
affixed inside the battery bay.
Microsoft® Certificate of Authenticity—Contains the Windows Product Key. You may need the
●
Product Key to update or troubleshoot the operating system. The Microsoft Certificate of
Authenticity is located inside the battery bay.
Regulatory label—Provides regulatory information about the computer. The regulatory label is
●
affixed inside the battery bay or under the service door.
Wireless certification label or labels (select models only)—Provide information about optional
●
wireless devices and the approval markings of some of the countries or regions in which the
devices have been approved for use. You may need this information when traveling
internationally. If your computer model includes one or more wireless devices, one or more
certification labels are included with your computer. Wireless certification labels are located
under the service door.
SIM (subscriber identity module) label (select models only)—Provides the ICCID (Integrated
●
Circuit Card Identifier) of the SIM. This label is located under the service door.
HP Mobile Broadband Module serial number label (select models only)—Provides the serial
●
number of the HP Mobile Broadband Module. This label is located under the service door.
14 Chapter 2 Getting to know your computer
3 HP QuickWeb (select models only)
Getting started
The HP QuickWeb environment provides a fun and engaging way to perform many of your favorite
activities. Your computer is ready to go within seconds of starting QuickWeb, allowing you to rapidly
access the Internet, widgets, and communication programs. To use QuickWeb, press the QuickWeb
button, and then start browsing the Web, communicating with others using Skype, and exploring other
HP QuickWeb programs.
Your HP QuickWeb Home screen includes the following features:
Web browser—Search and browse the Internet, and create links to your favorite Web sites.
●
Skype (select models only)—Communicate using Skype, an application that uses voice over
●
Internet protocol (VoIP). Skype lets you make conference calls or have video chats with one or
more people at a time. You can also make long-distance phone calls to land lines.
● Widgets—Start using widgets for news, weather, social networking, stocks, a calculator, sticky
notes, and more. You can also use Widget Manager to add more widgets to the HP QuickWeb
Home screen.
NOTE: For additional information about using HP QuickWeb, refer to the HP QuickWeb software
Help.
Getting started 15
Starting HP QuickWeb
To start HP QuickWeb, press the QuickWeb button when the computer is off or in Hibernation.
▲
The following table explains the different behaviors of the QuickWeb button.
Button Behavior
QuickWeb button
When the computer is off or in Hibernation, press the
●
button to open HP QuickWeb.
● When the computer is in Microsoft Windows, press the
button to open the default Web browser.
When the computer is in HP QuickWeb, press the
●
button to open the Web browser.
NOTE: If your computer does not have HP QuickWeb
software, the button opens the Web browser.
NOTE: For more information, refer to the HP QuickWeb software Help.
16 Chapter 3 HP QuickWeb (select models only)
4Networking
Your computer supports two types of Internet access:
● Wireless—Refer to
Wired—Refer to
●
NOTE: You must set up Internet service before you can connect to the Internet.
Creating a wireless connection on page 19.
Connecting to a wired network on page 26.
17
Using an Internet service provider
Before you can connect to the Internet, you must establish an account with an Internet service
provider (ISP). To purchase Internet service and a modem, contact a local ISP. The ISP will help set
up the modem, install a network cable to connect your wireless computer to the modem, and test the
Internet service.
NOTE: Your ISP will give you a user ID and password to access the Internet. Record this
information and store it in a safe place.
The following features will help you set up a new Internet account or configure the computer to use an
existing account:
● Internet Services & Offers (available in some locations)—This utility assists with signing up
for a new Internet account and configuring the computer to use an existing account. To access
this utility, select Start > All Programs > Online Services > Get Online.
ISP-provided icons (available in some locations)—These icons may be displayed either
●
individually on the Windows desktop or grouped in a desktop folder named Online Services. To
set up a new Internet account or configure the computer to use an existing account, double-click
an icon, and then follow the on-screen instructions.
Windows Connect to the Internet Wizard—This wizard allows you to connect to the Internet in
●
any of the following situations:
You already have an account with an ISP.
◦
You do not have an Internet account and want to select an ISP from the list provided within
◦
the wizard. (The list of ISP providers is not available in all regions.)
You have selected an unlisted ISP, and the ISP has provided you with information such as
◦
a specific IP address and POP3 and SMTP settings.
To access the Windows Connect to the Internet Wizard and instructions for using it, select
Start > Control Panel > Network and Internet > Network and Sharing Center.
NOTE: If you are prompted within the wizard to choose between enabling or disabling
Windows Firewall, choose to enable the firewall.
18 Chapter 4 Networking
Creating a wireless connection
Your computer may be equipped with one or more of the following wireless devices:
Wireless local area network (WLAN) device
●
HP Mobile Broadband Module (wireless wide area network (WWAN))
●
Bluetooth® device (select models only)
●
For more information on wireless technology, refer to the information and Web site links provided in
Help and Support.
Identifying wireless and network status icons
Icon Name Description
HP Connection Manager Opens HP Connection Manager, which enables you to create and manage
WLAN, WWAN (select models only), and Bluetooth (select models only)
connections.
Wired network (connected) Indicates that one or more network devices are connected to the network.
Network (disabled/
disconnected)
Network (connected) Indicates that one or more network devices are connected to a network.
Network (disconnected) Indicates that network devices are not connected to a network.
Network (disabled/
disconnected)
Indicates that all network devices are disabled in Windows Control Panel.
Indicates that no wireless connections are available.
Creating a wireless connection 19
Turning wireless devices on or off
You can use the wireless key or HP Connection Manager (select models only) to turn on and turn off
wireless devices. Refer to
location of the wireless key on your computer.
To turn off wireless devices using HP Connection Manager:
Right-click the HP Connection Manager icon in the notification area, at the far right of the
▲
taskbar, and then click the power button next to the desired device.
– or –
Select Start > All Programs > HP Help and Support > HP Connection Manager, and then
click the power button next to the desired device.
Using the action keys on page 33 for information on identifying the
Using HP Connection Manager (select models only)
HP Connection Manager provides a central location for managing your wireless devices, an interface
for connecting to the Internet using HP Mobile Broadband, and an interface for sending and receiving
SMS (text) messages. HP Connection Manager allows you to manage the following devices:
Wireless local area network (WLAN)/Wi-Fi
●
Wireless wide area network (WWAN)/HP Mobile Broadband
●
Bluetooth® (select models only)
●
HP Connection Manager provides information and notifications on connection status, power status,
SIM details, and SMS messages. Status information and notifications are provided in the notification
area, at the far right of the taskbar.
To open HP Connection Manager:
Click the HP Connection Manager icon in the notification area, at the far right of the taskbar.
▲
– or –
Select Start > All Programs > HP Help and Support > HP Connection Manager.
For more information, refer to the HP Connection Manager software Help.
20 Chapter 4 Networking
Loading...
