Page 1

QuickSpecs

HP P24 G4 Monitor

Technical Specifications

c06724394 — DA16772 — Worldwide — Version 1 —July 29, 2020

Page 1

HP P24 G4 Monitor

Front

Function Buttons

Power Button

Page 2

QuickSpecs

HP P24 G4 Monitor

Technical Specifications

c06724394 — DA16772 — Worldwide — Version 1 —July 29, 2020

Page 2

HP P24 G4 Monitor

Back

Power Connector

VGA Port

DisplayPort™ Connector

Security Cable Slot

HDMI Port

Page 3

QuickSpecs

HP P24 G4 Monitor

Technical Specifications

c06724394 — DA16772 — Worldwide — Version 1 —July 29, 2020

Page 3

Models: 1A7E5AA

Panel Specifications

Display Size (Diagonal)

23.8-in

Display Panel Type

IPS Micro-Edge Bezel

Yes, 3-sided

Native Resolution/Timing

1920×1080 @ 60 Hz

Native Resolution Note*

1 VGA, 1 HDMI 1.4, 1 DisplayPort 1.2

Panel Bit Depth

6bit + AFRC

Aspect Ratio

16:9

Brightness - Typical

250 cd/m²

Static Contrast Ratio - Typical

1000:1

Dynamic Contrast Ratio (DCR)

8,000,000:1

Flicker Free

Yes Pixel Pitch

0.2745 x 0.2745 mm

Pixels Per Inch (PPI)

Backlight Lamp Life (to half brightness in hours)

30k minimum

Anti-Glare Panel

Yes Response Time - Typical

5ms GtG (with overdrive)

Horizontal Viewing Angle (typical CR>10)

178°

Vertical Viewing Angle (typical CR>10)

178°

Panel Active Area (w x h)

527.04 mmx 296.46 mm

Preset Graphic Modes/Supported Resolutions

640 x 480 @ 60 Hz 720 x 400 @ 70 Hz 800 x 600 @ 60 Hz 1024 x 768 @ 60 Hz 1280 x 720 @ 60 Hz 1280 x 800 @ 60 Hz 1280 x 1024 @ 60 Hz 1366 x 768 @ 60 Hz 1440 x 900 @ 60 Hz 1600 x 900 @ 60 Hz 1680 x 1050 @ 60 Hz 1920 x 1080 @ 60 Hz

Maximum Resolution

1920 x 1080 @ 75 Hz

Recommended Resolution

1920 x 1080 @ 60 Hz

Vertical Scan Range

48Hz - 75Hz

Horizontal Scan Range

30KHz - 86KHz

Default Color Temperature

Neutral (6500K)

Maximum Pixel Clock Speed

180MHz

*VGA or DisplayPort™ 1.2 or HDMI 1.4 required to drive panel at its native resolution

NOTE: Performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower.

Color Gamut Coverage

NTSC

72%

Color Management

Factory Color Calibrated

Yes

Factory Color Presets

Warm - 5000K Neutral - 6500K Cool - 9300K

Color Space / Subsampling Support

RGB 4:4:4, YCBCR 4:4:4, YCBCR 4:2:2

Page 4

QuickSpecs

HP P24 G4 Monitor

Technical Specifications

c06724394 — DA16772 — Worldwide — Version 1 —July 29, 2020

Page 4

Default Color Temperature

Neutral (6500 K)

Low Blue Light Modes

Yes RGB Channel Adjust

Yes, Gain

Monitor Specifications

Exterior Color of Monitor Bezel and Stand

Black

Plug & Play

Yes Tilt

–5° to +23°

Swivel

No Pivot

No VESA Mounting

Yes Security Lock Ready

Yes Detachable Base

Yes Warranty

Based on region

On Screen Display (OSD)

On Screen Display User Controls

Brightness+, Color, Image, Input, Power, Menu, Management, Information, Exit

User Programmable Modes

Yes, 20

Monitor Control Buttons or Switches

Menu/OK, Minus ("-")/Brightness, Plus ("+")/Color, Back/Input, Power

User-Assignable Function Buttons

Yes, 3 (5 options)

Audio Controls

Yes, Volume

Languages

10 (English, Spanish, German, French, Italian, Netherlands, Portuguese, Japanese, T-Chinese and S-Chinese)

Connector Types

DisplayPort™

1, DisplayPort™ 1.2

HDMI

1, HDMI1.4

VGA 1

HDCP support

Yes, (DisplayPort™ and HDMI)

Power & Operating Specs

Power Supply

Internal

Power Source

100 – 240 VAC 50/60 Hz

Power Consumption - Maximum

24 W

Energy Saving/Standby Mode

0.5 W

Power Consumption - Typical

22 W

Power cable length

1.9 m

Energy Star Data

Operational Mode at 100 VAC

12.1 W >13.1 W

Operational Mode at 115 VAC

12.1 W >13.1 W

Operational Mode at 230 VAC

12.1 W >13.1 W

EU Energy Efficiency Class (EC1062)

On-mode Power Consumption (EC 1062/2010)

63.03 W >14.28 W

Annual Power Consumption (EC 1062/2010)

17.7 kWh >20.8 kWh

Energy Efficiency Class (EC 1062/2010)

A >A+

Operating Conditions

Operating Temperature - Celsius

5o – 35oC

Operating Temperature - Fahrenheit

41oC -95oF

Non-operating Temperature - Celsius

–20° – 60°C

Non-operating Temperature - Fahrenheit

29° - 140°F

Operating Humidity

20 – 80% Relative Humidity (non-condensing)

Non-operating Humidity

5 – 95%

Operating Altitude

0 - 5,000 m (16,400 ft.)

Non-operating Altitude

0 – 12,192 m (40,000 ft.)

Page 5

QuickSpecs

HP P24 G4 Monitor

Technical Specifications

c06724394 — DA16772 — Worldwide — Version 1 —July 29, 2020

Page 5

Environmental Features and Certifications

Mercury-free LED display backlighting

Yes, Mercury-free LED backlighting

Arsenic-Free Display Glass

Yes

Low Halogen**

Yes GSE HP-00011-01B, table 2 defines low-halogen (BFR, CFR, PVC) NOTE: External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be Low Halogen.

Agency Approvals and Certifications

CE,CB,KC/KCC/NOM/PSB/ICE/TUV-S/ISO 9241-307/ EAC/UL/CSA/PSB/ISC/CCC/CEL/Energy Star/ISC/VCCI/FCC/BSMI/Vietnam MEPS/Australian-New Zealand MEPS/WEEE

Microsoft WHQL Certification

Win 10, Win 8, Win 7

ENERGY STAR®

Yes, ENERGY STAR® 8

EPEAT® 2019 Registered*

Yes, Sliver

China Energy Label

CEL Grade 1

TCO Certified

Yes

SmartWay Transport Partnership - NA only

Yes (NA SKU)

* Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit

http://www.epeat.net for more information.

**External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be Low Halogen.

Note: DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®) in the United States and other countries.

Metric

Imperial

Unit Product/Package Specifications

Product Dimensions

(Unpacked with stand) (W x D x H)

53.82 x 21.16 x 46.43 cm

21.19 x 8.33 x 18.28 in

Product Dimensions

(Packed) (W x D x H)

59.8 x 16.5 x 41.5 cm

23.54 x 6.50 x 16.34 in

Display Head Dimensions

(Unpacked without stand) (W x D x H)

53.82 x 4.59 x 32.56 cm

21.19 x 1.80 x 12.82 in

Base Area Footprint

(w x d mm)

214.6 x 211.6 mm

8.45 x 8.33 in

Bezel Measurements

Bottom 22.5 mm

Bottom 0.89 in

Product Weight

(Unpacked with stand)

4.61 kg

9.94 lb

Product Weight

(Packed)

6.14 kg

13.51 lb

Product Weight

(Head Only)

2.53 kg

5.56 lb

Pallet Information

Pallet Dimensions (L x W x H)

1216 x 960 x 126 mm

47.84 x 37.80 x 4.96 in

Pallet Total Weight (L x W x H)

323.55 Kg

712.46 lbs

Pallet Layers

5 Pallet Product per Layer

10 Total Products per Pallet

50 Container Load, 20-Foot

500 units

Page 6

QuickSpecs

HP P24 G4 Monitor

Technical Specifications

c06724394 — DA16772 — Worldwide — Version 1 —July 29, 2020

Page 6

Container Load, 40-Foot

1,100 units

Container Load, 40-Foot HighQ

1,100 units

Software Included

HP Display Assistant

What's in the box?

AMS: AC Power Cord (1.8m) 5.9 ft, HDMI Cable (1.8m) 5.9 ft, DP Cable (1.8m) 5.9 ft LA: AC Power Cord (1.8m) 5.9 ft, HDMI Cable (1.8m) 5.9 ft, DP Cable (1.8m) 5.9 ft APJ (exclude Japan): AC Power Cord (1.8m) 5.9 ft, VGA Cable (1.8m) 5.9 ft, HDMI Cable (1.8m) 5.9 ft APJ Japan: AC Power Cord (1.8m) 5.9 ft, VGA Cable (1.8m) 5.9 ft, HDMI Cable (1.8m) 5.9 ft, DP Cable (1.8m)

5.9 ft EMEA: AC Power Cord (1.8m) 5.9 ft, HDMI Cable (1.8m) 5.9 ft, DP Cable (1.8m) 5.9 ft

User Guide and Warranty Languages

User Guide Languages

English, Arabic, S. Chinese, T. Chinese, Czech, Danish, Dutch, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Kazakh, Korean, Norwegian, Polish, Brazilian Portuguese, Russian, Slovenian, Spanish, Swedish and Turkish.

Warranty Languages

Environmental Data

Eco-Label Certifications & declarations

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:

• IT ECO declaration

• US ENERGY STAR®

• TCO or TCO Certified Edge

• EPEAT® Silver registered in the United States. Based on US EPEAT

registration according to IEEE 1680.1-2018 EPEAT. Status varies by country. See http://www.epeat.net for more information.

Energy Consumption (in accordance with US ENERGY STAR® test method)

115VAC, 60Hz

230VAC, 50Hz

100VAC, 50Hz

Normal Operation

11.86 W

11.88 W

11.90 W

Sleep

0.18 W

0.19 W

0.18 W

Off

0.12 W

0.13 W

0.12 W

Heat Dissipation*

115VAC, 60Hz

230VAC, 50Hz

100VAC, 50Hz

Normal Operation

40 BTU/hr

Sleep

1 BTU/hr

Off

1 BTU/hr

*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.

Page 7

QuickSpecs

HP P24 G4 Monitor

Technical Specifications

c06724394 — DA16772 — Worldwide — Version 1 —July 29, 2020

Page 7

Additional Information

• This product is in compliance with the Restrictions of Hazardous

Substances (RoHS) directive - 2002/95/EC.

• This HP product is designed to comply with the Waste Electrical and

Electronic Equipment (WEEE) Directive – 2002/96/EC.

• This product is in compliance with California Proposition 65 (State of

California; Safe Drinking Water and Toxic Enforcement Act of 1986).

• This product is in compliance with the IEEE 1680.1 (EPEAT) standard at

the Silver level, see http://www.epeat.net

• Plastics parts weighing over 25 grams used in the product are marked

per ISO 11469 and ISO1043.

• This product contains 26.9% post-consumer recycled plastic (by wt.)

according to IEEE 1680.1-2018 standard, criterion 4.2.1.1.

• This product is 96.6% recycle-able when properly disposed of at end of

life.

Packaging Materials

External:

PAPER/Corrugated

735 g

Internal:

PLASTIC/Polystyrene Expanded - EPS

326 g

PLASTIC/Polyethylene Expanded - EPE

32 g

PLASTIC/Polyethylene high density - HDPE

8 g

RoHS Compliance

HP Inc. complies fully with materials regulations. We were among the first companies to extend the restrictions in the European Union (EU) Restriction of Hazardous Substances (RoHS) Directive to our products worldwide through the HP GSE. HP has contributed to the development of related legislation in Europe, as well as China, India, and Vietnam.

We believe the RoHS directive and similar laws play an important role in promoting industry-wide elimination of substances of concern. We have supported the inclusion of additional substances—including PVC, BFRs, and certain phthalates—in future RoHS legislation that pertains to electrical and electronics products.

We met our voluntary objective to achieve worldwide compliance with the new EU RoHS requirements for virtually all relevant products by July 2013, and we will continue to extend the scope of the commitment to include further restricted substances as regulations continue to evolve.

To obtain a copy of the HP RoHS Compliance Statement, see HP RoHS position

statement.

Page 8

QuickSpecs

HP P24 G4 Monitor

Technical Specifications

c06724394 — DA16772 — Worldwide — Version 1 —July 29, 2020

Page 8

Material Usage

This product does not contain any of the following substances in excess of regulatory limits (refer to the HP General Specification for the Environment at

http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/gen_spe cifications.html):

• Asbestos

• Certain Azo Colorants

• Certain Brominated Flame Retardants – may not be used as flame

retardants in plastics

• Cadmium

• Chlorinated Hydrocarbons

• Chlorinated Paraffins

• Bis(2-Ethylhexyl) phthalate (DEHP)

• Benzyl butyl phthalate (BBP)

• Dibutyl phthalate (DBP)

• Diisobutyl phthalate (DIBP)

• Formaldehyde

• Halogenated Diphenyl Methanes

• Lead carbonates and sulfates

• Lead and Lead compounds

• Mercuric Oxide Batteries

• Nickel – finishes must not be used on the external surface designed to

be frequently handled or carried by the user.

• Ozone Depleting Substances

• Polybrominated Biphenyls (PBBs)

• Polybrominated Biphenyl Ethers (PBBEs)

• Polybrominated Biphenyl Oxides (PBBOs)

• Polychlorinated Biphenyl (PCB)

• Polychlorinated Terphenyls (PCT)

• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail

packaging has been voluntarily removed from most applications.

• Radioactive Substances

• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

Packaging

HP follows these guidelines to decrease the environmental impact of product packaging:

• Eliminate the use of heavy metals such as lead, chromium, mercury and

cadmium in packaging materials.

• Eliminate the use of ozone-depleting substances (ODS) in packaging

materials.

• Design packaging materials for ease of disassembly.

• Maximize the use of post-consumer recycled content materials in

packaging materials.

• Use readily recyclable packaging materials such as paper and corrugated

materials.

• Reduce size and weight of packages to improve transportation fuel

efficiency.

• Plastic packaging materials are marked according to ISO 11469 and DIN

6120 standards.

Page 9

QuickSpecs

HP P24 G4 Monitor

Technical Specifications

c06724394 — DA16772 — Worldwide — Version 1 —July 29, 2020

Page 9

End-of-life Management and Recycling

Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to:

http://www.hp.com/go/reuse-recycle or contact your nearest HP sales office.

Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.

HP, Inc. Corporate Environmental Information

For more information about HP’s commitment to the environment:

Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Eco-label certifications

http://www.hp.com/hpinfo/globalcitizenship/environment/productdesi gn/ecolabels.html

ISO 14001 certificates:

http://h20195.www2.hp.com/V2/GetDocument.aspx?docname=c04755 842

and

http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf

Page 10

QuickSpecs

HP P24 G4 Monitor

Technical Specifications

c06724394 — DA16772 — Worldwide — Version 1 —July 29, 2020

Page 10

Copyright © 2020 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. ENERGY STAR is a registered trademark owned by the U.S. Environmental Protection Agency.

Page 11

QuickSpecs

HP P24 G4 Monitor

Summary

c06724394 — DA16772 — Worldwide — Version 1 —July 29, 2020

Page 11

Change Log

From V1 to V2
