QuickSpecs

Overview

HP ProDisplay P19A 19-inch LED Backlit Monitor
1.
OK/Menu
2.
Auto/Minus
If the OSD menu is on, press to select the highlighted menu item. Opens, selects or exits the OSD menu.
If the OSD menu is inactive, press to activate the auto adjustment feature to optimize the screen image. If the OSD menu is on, press to navigate backward through the OSD menu and decrease adjustment levels.
HP ProDisplay 19A dual monitor configuration shown.
(Note: monitors sold separately)
3.
Plus
4.
Power LED
5.
Power
HP recommends a dual monitor configuration for a more productive work environment. *
*NOTE: Multi-monitor support is dependent on your system. Check your user guide or technical specifications for compatibility. Optional accessories may be required.
If the OSD menu is on, press to navigate forward through the OSD menu and increase adjustment levels.
White = Fully powered. Amber = Sleep mode. Flashing Amber = Sleep Timer mode.
Turns the monitor on or off.
DA - 14553 North America — Version 4 — November 12, 2013
Page 1
QuickSpecs
Overview
Model
: D2W67AA
HP ProDisplay P19A 19-inch LED Backlit Monitor
DA - 14553 North America — Version 4 — November 12, 2013
Page 2
QuickSpecs

Technical Specifications

HP ProDisplay P19A 19-inch LED Backlit Monitor
Panel
User Controls
Signal Interface/ Performance
Type
Viewable Image Area (diagonal)
Active Area (W x H)
Aspect Ratio
Viewing Angle (typical)
Brightness (typical)
Static Contrast Ratio (typical)
Dynamic Contrast Ratio (typical)
Response Time (typical)*5 ms (on/off)
Pixel Pitch
Backlight Lamp Life (to half brightness)
Color Gamut (typical)*
Color Support**
*All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. ** With the use of FRC technology.
Buttons or Switches
Languages
On Screen Display (OSD) User Controls
Horizontal Frequency
Vertical Frequency
Native Resolution
Preset VESA Graphic Modes
Maximum Pixel Clock Speed
User Programmable Modes
Anti-Glare
Default Color Temperature
*
*
(non-interlaced)
TN (Twisted Nematic) LED Backlit LCD
48,26 cm
37,63 x 30,1 cm
5:4
Up to 170° horizontal/160° vertical (10:1 minimum contrast ratio)
*
250 nits (cd/m2)
1000:1
1,000,000:1
0.294 mm
30,000 hours minimum
72%
Can display up to 16.7 million colors
OK/Menu, Auto/Minus, Plus, Power
10 (English, Spanish, German, French, Italian, Netherlands, Portuguese, Japanese, T-Chinese and S-Chinese)
Brightness, Contrast, Color, Image Control, OSD Control, Management, Language, Information, Factory Reset, Exit
30k-83 kHz
50 to 76 Hz
1280x1024 @ 60 Hz
1280 x 1024 @ 60 Hz 1280 x 960 @ 60 Hz 1024 x 768 @ 60 Hz 800 x 600 @ 60 Hz 720 x 400 @ 60 Hz 640 x 480 @ 60 Hz 108 MHz
Yes (16)
Yes
6500 K
(19 in), diagonally measured
(14.82 x11.85 in)
DA - 14553 North America — Version 4 — November 12, 2013
Page 3
QuickSpecs
Technical Specifications
HP ProDisplay P19A 19-inch LED Backlit Monitor
Video/Other Inputs
Power
Mechanical
Environmental
Plug and Play
Input Connectors
USB
Video Cables
Video Cable Length
Audio
Power Supply
Input Power
Typical Power Consumption
Maximum
Power Saving
Power Cable Length
Dimensions
Weight
Tilt Range
Swivel Range
Height Adjustable
Pivot Rotation
Detachable Base
Temperature ­Operating
Temperature - Non­operating
Humidity - Operating
Humidity - Non­operating
Altitude - Operating
Altitude - Non-operating
White LED Backlights
CCFL Panel
(W x D x H)
Yes
VGA (analog)
None
(1) VGA
1,8 m
(5.9 ft)
None
Internal
100~240Vac, 50/60 Hz
15 W
25 W
0.5 W
1,9 m
(6.2 ft)
Unpacked w/stand
Unpacked w/o stand
(head only)
Packaged
Base area
Head Only
Unpacked
Packaged
-5° to +25°
None
No
No
Yes
5° to 35° C
-20° to 60° C
20% to 80% non-condensing
5% to 95%, 38.7° C max wet-bulb
0 to 5,000 m
0 to 12,192 m
Yes
No
(footprint)
(41° to 95° F)
(-4° to 140° F)
(16,404 ft)
(0 to 40,000 ft)
41,4 x 20,64 x 41,82 cm
(16.3 x 8.13 x 16.46 in)
41,4 x 5,75 x 34,7 cm
(16.3 x 2.3 x 13.7 in)
48,6 x 13,9 x 50,6 cm
(19.1 x 5.5 x 19.9 in)
21,05 x 14,82 cm
(8.29 x 5.83 in)
2,99 kg
3,5 kg
4,5 kg
(6.59 lb)
(7.72 lb)
(9.92 lb)
DA - 14553 North America — Version 4 — November 12, 2013
Page 4
QuickSpecs
Technical Specifications
HP ProDisplay P19A 19-inch LED Backlit Monitor
Environmental Data
Arsenic-Free Display
4
Glass
Mercury-Free Display Backlighting
Low Halogen
Eco-Label Certifications & declarations
Energy Consumption (in accordance with US Energy Star® test method)
Normal Operation Sleep Off
Heat Dissipation
Normal Operation Sleep Off
* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.
Additional Information
Packaging Materials
5
*
Yes
Yes
Yes
This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:
IT ECO declaration US ENERGY STAR® TCO 06 EPEAT® Gold where HP registers Commercial Display products. See
http://www.epeat.net
Energy Management Program (FEMP)
115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
15.12 W 14.92 W 15.18 W
0.24 W 0.31 W 0.24 W
0.09 W 0.14 W 0.09 W
115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
52 BTU/hr 51 BTU/hr 52 BTU/hr
0.8 BTU/hr
0.3 BTU/hr 0.4 BTU/hr 0.3 BTU/hr
This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive - 2002/95/EC. This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive - 2002/96/EC. This product is in compliance with California Proposition 65 (State of California; Safe Drinking Water and Toxic Enforcement Act of 1986). This product is in compliance with the IEEE 1680 (EPEAT) standard at the Gold level, see: Plastics parts weighing over 25 grams used in the product are marked per ISO 11469 and ISO1043. This product contains 16.2 % post-consumer recycled plastic (by wt.) This product is 97.5 % recycle-able when properly disposed of at end of life.
External:
Internal:
for registration status in your country US Federal
1 BTU/hr
www.epeat.net
PAPER/Corrugated
PLASTIC/EPS (Expanded Polystyrene)
PLASTIC/EPE-Expanded Polyethylene
0.8 BTU/hr
808 g
328 g
28 g
DA - 14553 North America — Version 4 — November 12, 2013
Page 5
QuickSpecs
Technical Specifications
HP ProDisplay P19A 19-inch LED Backlit Monitor
RoHS Compliance
Material Usage
Packaging
Hewlett-Packard is committed to compliance with all applicable environmental laws and regulations, including the European Union Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by meeting the requirements of the RoHS Directive on a worldwide basis. By July 1, 2006, RoHS substances will be virtually eliminated (virtually = to levels below legal limits) for all HP electronic products subject to the RoHS Directive, except where it is widely recognized that there is no technically feasible alternative (as indicated by an exemption under the EU RoHS Directive).
This product does not contain any of the following substances in excess of regulatory limits (refer to the HP General Specification for the Environment at:
http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/ gen_specifications.html
Asbestos Certain Azo Colorants Certain Brominated Flame Retardants - may not be used as flame retardants in plastics Cadmium Chlorinated Hydrocarbons Chlorinated Paraffins Formaldehyde Halogenated Diphenyl Methanes Lead carbonates and sulfates Lead and Lead compounds Mercuric Oxide Batteries Nickel - finishes must not be used on the external surface designed to be frequently handled or carried by the user. Ozone Depleting Substances Polybrominated Biphenyls (PBBs) Polybrominated Biphenyl Ethers (PBBEs) Polybrominated Biphenyl Oxides (PBBOs) Polychlorinated Biphenyl (PCB) Polychlorinated Terphenyls (PCT) Polyvinyl Chloride (PVC) - except for wires and cables, and certain retail packaging has been voluntarily removed from most applications. Radioactive Substances Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
HP follows these guidelines to decrease the environmental impact of product packaging:
):
Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging materials. Eliminate the use of ozone-depleting substances (ODS) in packaging materials. Design packaging materials for ease of disassembly. Maximize the use of post-consumer recycled content materials in packaging materials. Use readily recyclable packaging materials such as paper and corrugated materials. Reduce size and weight of packages to improve transportation fuel efficiency.
DA - 14553 North America — Version 4 — November 12, 2013
Page 6
QuickSpecs
Technical Specifications
End-of-life Management and Recycling
Hewlett-Packard Corporate Environmental Information
Accessories
(sold separately)
What's in the box?
HP LCD Monitor Quick Release—Part number EM870AA
HP USB Graphics Adapter—Part number NL571AA
HP Business PC Security Lock Kit—Part number PV606AA
HP LCD Speaker Bar—Part number NQ576AA
HP Integrated Work Center Stand - USDT and Thin Clients) —Part number LH526AA
Monitor and Accessories
Documentation
Featured Software
HP ProDisplay P19A 19-inch LED Backlit Monitor
Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to:
http://www.hp.com/go/reuse-recycle
Products returned to HP will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/operations/ envmanagement.html
An easy-to-use, VESA-compliant, LCD monitor mounting solution that allows you to quickly and securely attach an LCD monitor to a variety of stands, brackets, arms or wall mounts. For more information, refer to this product's QuickSpecs document.
Enables connection of up to six simultaneous displays to help you boost productivity and multi-task across several open applications. Use one Adapter to bridge between a notebook or desktop PC and second monitor or use multiple Adapters to connect several displays to each other.
Attaches to the rear of the PC with a six-foot steel cable that can be used to secure a PC or peripherals such as mice, keyboards, monitors or USB security devices to protect them against unauthorized removal by physically connecting the system to an anchor point.
Powered directly by the connected PC, the Speaker Bar seamlessly attaches to the monitor's lower bezel to bring full audio support to select HP flat panel monitors. Features include dual speakers with full sound range and dual external headphone jacks. Sold separately. For more information, refer to the product's QuickSpecs.
Allows mounting of a 17 - 24 inch diagonal HP LCD monitor and an HP Compaq dc8000 series Ultra-slim Desktop PC as well as select HP Thin Clients on a single stand for the convenience of an "all-in-one" form factor. For more information, refer to this product's QuickSpecs document.
HP P19A 19-inch LED Backlit Monitor; VGA cable; AC Power cable
Printed documentation and CD
HP Display Assistant and Adobe Acrobat Reader
http://www.hp.com/go/recyclers
or contact your nearest HP sales office.
. These instructions may be used by
DA - 14553 North America — Version 4 — November 12, 2013
Page 7
QuickSpecs
Technical Specifications
HP ProDisplay P19A 19-inch LED Backlit Monitor
Other
Certification and Compliance
Compatibility
Service and Warranty
© Copyright 2013 Hewlett-Packard Development Company, L.P.
ENERGY STAR® is a US registered mark of the United States Environmental Protection Agency.
User Guide Languages
Warranty Languages
Color
Warranty Languages
VESA External Mounting
Security Lock-Ready
Country of Origin
CB, CE, TCO, CCC, CEL 1, CECP, BSMI, S-Mark, VCCI, FCC, CSA, GS mark, ICES, C-Tick, e-Standby, ENERGY STAR® qualified, EPEAT® Gold3 (select regions)
Compatible with platforms using the VESA standard video modes. Recommended for use with HP products.
Protected by HP, including a 3 year standard limited warranty. Optional Care Pack Services are extended service contracts which go beyond your standard warranties.
English, Arabic, S. Chinese, T. Chinese, Czech, Danish, Dutch, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Kazakh, Korean, Norwegian, Polish, Brazilian Portuguese, Russian, Slovenian, Spanish, Swedish and Turkish.
English, Arabic, S. Chinese, T. Chinese, Czech, Danish, Dutch, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Kazakh, Korean, Norwegian, Polish, Brazilian Portuguese, Russian, Slovenian, Spanish, Swedish and Turkish.
Black
English, Spanish, Portuguese
Yes (one set of standard 4-hole pattern, 100 mm).
Yes
China
2
1
The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg) for all devices mounted. Because mounting surfaces vary widely and the final mounting method and configuration may vary, mounting fasteners are not supplied (other than the VESA-compliant screws). HP recommends that you consult with a qualified engineering, architectural or construction professional to determine the appropriate type and quantity of mounting fasteners required for your application and to ensure that your mounting solution is properly installed to support applied loads.
2
HP Care Pack Services extend service contracts beyond the standard warranties. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts from date of hardware purchase. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at Services information by product is available at
3
EPEAT® Gold registered models of this product are available where HP registers commercial display products. See registration status in your country.
4
Arsenic and its compounds were not detected using US EPA Test Methods 3052 & 3052/6010b by ICP or ICP-AES with a with a Method Detection Limit of 10 ppm.
5
External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be Low Halogen.
All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or lower. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
http://www.hp.com/hps/carepack
http://www.hp.com/go/lookuptool
.
. Additional HP Care Pack
www.epeat.net
for
DA - 14553 North America — Version 4 — November 12, 2013
Page 8
