QuickSpecs
Overview
HP Compaq nx9000 Business Notebook
1.
Easy Access Buttons (5)
2.
Stereo Speakers
3.
PS/2 Port
4.
Touch Pad On/Off Button
5.
Fixed Optical Drive
6.
Touch Pad
7.
Primary Battery
8.
Wireless LED
9.
Wireless On/Off Button
10.
Battery Charging LED
11.
Hard Drive Activity LED
12.
System Power LED
13.
Mute Lock LED
1.
Air Vent
2.
VGA Video
3.
Serial
4.
Parallel Port
14.
Volume Controls
15.
Headphone
16.
Audio In
17.
1394 Port
18.
Diskette Drive
19.
PC Card Slots (2)
20.
RJ-11 (Modem)
21.
Air Vent
22.
Kensington Lock
23.
Power Button
24.
Caps Lock LED
25.
Num Lock LED
26.
Keypad LED
5.
S-Video
6.
RJ-45 (NIC)
7.
USB Ports (2)
8.
DC In
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 1
QuickSpecs
HP Compaq nx9000 Business Notebook
Overview
At A Glance
Mobile Intel® Pentium® 4 processors – up to 2.5 GHz
Mobile Intel Celeron™ processors – up to 2.4 GHz
Microsoft Windows XP Professional,
Microsoft Windows XP Home, or
Microsoft Windows 2000 driver support via web.
15-inch TFT XGA and SXGA+, 14.1-inch TFT XGA display
Configurations as light as 6.75 lb (3.06 kg) and as thin as 1.51 in (3.85 cm) (14-inch panel)
128MB, 256MB or 512MB DDR SDRAM (266 MHz), Upgradeable to 1GB
Up to 60 GB (4200 rpm) hard drive
Integrated NIC, modem and available 802.11b and 802.11g Wireless LAN
Full-size keyboard with (5) Quick Launch Buttons
Includes a one-year, Worldwide Limited Warranty – Certain restrictions and exclusions apply. Consult the HP Customer Support Center for
details.
What's New
Mobile Intel Pentium 4 processors – up to 2.5 GHz
Mobile Intel Celeron processors – up to 2.4 GHz
Microsoft Windows XP Professional,
Microsoft Windows XP Home, or
Microsoft Windows 2000 driver support via web.
400-MHz FSB
Two Type II PC Card Slots
Available Integrated 802.11b WLAN
Available Integrated 802.11g WLAN
Touchpad with dedicated On/Off button and dedicated scroll
What's Special
Mobile Intel Pentium 4 –M processors
Microsoft Windows XP Professional,
Microsoft Windows XP Home, or
Microsoft Windows 2000 driver support via web.
All-in-one convenient design
Designed for mobility
USB 2.0 and IEEE 1394
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 2
QuickSpecs
Standard Features
HP Compaq nx9000 Business Notebook
Processors and Chipset
One of the following:
Operating System
Displays
2.5 GHz Mobile Intel Pentium 4-M processor 400-MHz Front Side Bus and 512-KB L2 cache
2.4 GHz Mobile Intel Pentium 4-M processor 400-MHz Front Side Bus and 512-KB L2 cache
2.2 GHz Mobile Intel Pentium 4-M processor 400-MHz Front Side Bus and 512-KB L2 cache
2.0 GHz Mobile Intel Pentium 4-M processor 400-MHz Front Side Bus and 512-KB L2 cache
2.4 GHz Mobile Intel Celeron processor 400-MHz Front Side Bus and 256-KB L2 cache
2.2 GHz Mobile Intel Celeron processor 400-MHz Front Side Bus and 256-KB L2 cache
2.0 GHz Mobile Intel Celeron processor 400-MHz Front Side Bus and 256-KB L2 cache
1.8 GHz Mobile Intel Celeron processor 400-MHz Front Side Bus and 256-KB L2 cache
1.7 GHz Mobile Intel Celeron processor 400-MHz Front Side Bus and 256-KB L2 cache
Chipset: ATI Radeon IGP 340M (RS200MP)/ALI M1535+
Microsoft Windows XP Professional, (requires 256MB of memory minimum) or
Microsoft Windows XP Home (limited language availability) preinstalled
Microsoft Windows 2000 Driver support via web
Internal
External
15-inch color TFT UXGA (wide viewing angle) with 1600 x 1200 resolution
(up to 16.7M colors internal)
15-inch color TFT SXGA+ with 1400 x 1050 resolution
(up to 16.7M colors internal)
15-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
14.1-inch color TFT XGA with 1024 x 768 resolution (up to 16.7M colors internal)
Up to 32-bit per pixel color depth Supports 640 x 480, 800 x 600, 1024 x 768, 1280 x 768, 1280
x 1024, or 1600 x 1200 resolutions up to 100-Hz refresh rate, dependent upon monitor
capability, and resolution and color depth settings
Memory
Communications
Keyboard
Easy Access Buttons
Standard
Maximum
NOTE:
128MB of DDR (16MB standard shared video memory).
NOTE:
256MB of DDR (64MB standard shared video memory).
NOTE:
Up to 64MB shared video memory user configurable.
10/100 NIC is integrated on the system board
High speed 56K modem
802.11b on select models
802.11g on select models
Wireless on/off Button
Full-size desktop-compatible keyboard; special feature hotkeys for instant access to toggling between internal and
external displays, or simultaneous displays and brightness Oversized keys and separate cursor control keys (87
keys) – 101-key compatible
Five-One Touch Quick Launch Buttons.
128 MB (266 MHz) DDR SDRAM (128 MB SODIMM in slot 1) or
256 MB (266 MHz) DDR SDRAM (256 MB SODIMM in slot 1) or
512 MB (266 MHz) DDR SDRAM (512 MB SODIMM in slot 1)
1 GB (266 MHz) DDR SDRAM (512MB (266 MHz) in slot 1 and 2)
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 3
QuickSpecs
Standard Features
HP Compaq nx9000 Business Notebook
Pointing Device
PC Card Slots
Storage
Audio
Multimedia
Touch pad with on/off button and dedicated scroll up/down surface
Two Type II PC Card slots with support for 16-bit PCMCIA and 32-bit Cardbus
Fixed Diskette Drive
Primary Hard Drive
Fixed Optical Drive
Integrated Speakers, Volume control andMute buttons, AC/97, SoundBlaster Pro compatible, 16- bit stereo sound
Dual Speakers and 16-bit stereo sound
Dedicated Hardware and Hotkey volume controls
Headphone-out port
Microphone in port
Software MPEG1 support, MPEG2 and DVD
DVD/CD-RW Combination Drive (on select models)
DVD-ROM Drive with movie playback software (on select models)
CD-ROM Drive (on select models)
S-video Port
IEEE 1394 Port
USB 2.0 Ports
4X AGP graphics
16MB or 64MB of DDR (Double Date Rate) shared video memory
1.44 MB Diskette Drive (optional)
60-GB 4200 rpm Hard Drive
40-GB 4200 rpm Hard Drive
30-GB 4200 rpm Hard Drive
20-GB 4200 rpm Hard Drive
DVD/CD-RW combo Drive<
CD-RW Drive
DVD Drive
CD Drive
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 4
QuickSpecs
Standard Features
HP Compaq nx9000 Business Notebook
Interfaces
PC Card
Enhanced Parallel EPP/ECP
PS/2
S-Video
VGA
1394 1
Port Replicator – select
models
Headphone/Line-out
Microphone-in
Serial Port
DC Power
RJ-11 (modem)
RJ-45 (NIC)
Infrared Port – select models
USB 2.0
LED status indicators
System power
Battery charging
Hard drive activity
Caps lock
Num lock
Keypad
Wireless
Mute Lock
1 Type II
1
1
1
1
1
1
1
1
1
1
1
1 (4 Mb/s support)
(IrDA 4 MB compliant. IR performance will vary depending on performance of IR
peripherals and application used.)
2
8
Graphics
Software
System Recovery
Security
UMA architecture – ATI Mobility™ Radeon™, AGP 4x and 3D Architecture, MPEG2 and DVD playback, standard
16MB shared w/128MB main memory, 64MB shared w/256MB or more main memory, configurable up to 64MB.
Intervideo WinDVD Playback Software
Roxio Easy CD Creator (on CDRW, DVD/CDRW)
Safety and Comfort Guide
Acrobat Reader
Reference Guide
One touch button software
Symantec Norton Anti-virus
HP Help and Support
Microsoft Office on select models
NOTE:
Symantec Norton Antivirus 2003 (Complimentary 60 days Live Update)
Each unit is shipped with a recovery CD kit containing a system restore and Operating System CD. These CDs allow
users to either recover or repair their notebook's operating system without losing personal data. The Operating
System CD also provides the option of reinstalling the operating system software provided with the notebook.
(Erases hard disk and restores the manufacturer installed image.)
Power-on Password
Kensington MicroSave security slot; accepts 3rd party security lock devices.
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 5
QuickSpecs
Standard Features
HP Compaq nx9000 Business Notebook
Power Supply
Battery
Power Conservation
Service and Support
External 90-Watt AC adapter, power cord included.
The HP Compaq Business Notebook nx9000 provides up to 2 ½ hours of battery life using the standard 8-cell
Lithium-Ion battery, 4.4Ahr and Smart Battery Technology (provides accurate, instantaneous battery status).
NOTE:
Actual results may vary with product model, configuration, and individual usage. Hewlett-Packard testing of a
nx9000 with a Pentium 4 M 2.4 GHz CPU, Windows XP Pro, 15.0-inch XGA LCD, 512-MB RAM, 60-GB HDD, DVD,
Lithium-Ion battery, and NIC/modem, achieved an overall Business Winstone 2002 BatteryMark score of 2h 59m
Business Winstone® 2002 BatteryMark™ Version 1.0 units. Winstone® is a registered trademark and BatteryMark™
is a trademark of Ziff Davis Publishing Holdings Inc. in the U.S. and other countries. Copyright 2002 Ziff Davis Media
Inc. All Rights Reserved. System parameters followed test recommendations: panel brightness 50%, power
management scheme - Laptop/Portable, hard drive, standby and video timers set to never.
NOTE:
This test was performed without independent verification by eTesting Labs Inc. eTesting Labs Inc. makes no
representations or warranties as to the result of the test. BatteryMark is a trademark of Ziff Davis Publishing
Holdings Inc., and affiliate of eTesting Labs Inc., in the U.S. and other countries.
Hibernation
Instant-on via Standby
One custom level of power conservation
Energy Star Compliant
HP Services includes a one-year, Worldwide Limited Warranty, pick-up or carry-in; upgraded warranty and toll-free
7 x 24 hardware technical phone support available.
NOTE:
Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details.
Naming Convention
The Etymology of a Model name:
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 6
QuickSpecs
Options
HP Compaq nx9000 Business Notebook
Storage
Memory
Expansion
Power
USB 16MB Disk on Key
IBM 1GB Microdrive
USB Diskette Drive
USB Diskette Drive
USB Diskette Drive
128MB (266 MHz) DDR RAM Memory Upgrade
256MB (266 MHz) DDR RAM Memory Upgrade
512MB (266 MHz) DDR RAM Memory Upgrade
128MB (266 MHz) DDR RAM Memory Upgrade
256MB (266 MHz) DDR RAM Memory Upgrade
512MB (266 MHz) DDR RAM Memory Upgrade
Simple Port Replicator (USB 2.0)
Primary Battery Pack
AC Adapter 90W
Auto/Truck Adapter 90W
DF517A
217390-B25
F5101A
230330-B25
DC361A
269085-B25 or
DC388A
269086-B25 or
DC389A
269087-B25 or
DC390A
F4694A
F4695A
F4696A
F4811B
F4809A
F4813A
DC303A
Carrying Cases
Security
External Drives
Compaq Nylon
Compaq Leather
HP Nylon
HP Leather
HP Top Load Nylon Carrying Case
HP Top Load Leather Carrying Case
PC Card Biometrics ID Device
PC Card Smart Card Reader
Security Cable Lock
Zip 250 External Drive (USB)
249246-001
249245-001
F1606A
F1607A
DC915A
DC917A
146805-B25
135646-B25
294316-B21
174255-001
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 7
QuickSpecs
Options
HP Compaq nx9000 Business Notebook
Input/Output Devices
Monitors
2 button Mouse (carbon) (PS/2)
USB 2 Button Scroll Mouse (Carbon)
External 10-Key Numeric Keypad (PS/2)
Keyboard (carbon) (PS/2)
USB Keyboard
USB/PS2 Keyboard
USB/PS2 Mouse
USB Diskette Drive
USB Travel Mouse
USB Travel Mouse (optical scroll mouse)
HP s9500 19" (18.0" vis) CRT Monitor
HP v7550 17" (16.0" vis) Flat-face CRT Monitor
103180-B21
195255-B25
294317-B21
118003-xxx
222726-xxx
118003-xx9
103180-B22
F5101A
F2100A
F4815A
P9010A#ABA
P9013A#ABA
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 8
QuickSpecs
HP Compaq nx9000 Business Notebook
Memory
HP Compaq nx9000 Business Notebook
Standard Memory Plus Optional Memory
Support for up to 1024 MB total of DDR SDRAM memory is available with the installation of optional DDR SDRAM Memory Kits.
Memory
128 MB 128 MB
256 MB 256 MB
384 MB 256 MB 128 MB
512 MB 512 MB
768 MB 512 MB 256 MB
1024 MB
NOTE:
This chart does not represent all possible memory configurations. Due to the non-industry standard nature of some third-party memory
modules, we strongly recommend using only Compaq branded memory modules to ensure compatibility.
Following are memory options available from Compaq:
512-MB (266 MHz) Memory Upgrade 269087-B25 or DC390A
256-MB (266 MHz) Memory Upgrade 269086-B25 or DC389A
128-MB (266 MHz) Memory Upgrade 269085-B25 or DC388A
Slot 1 Slot 2
512 MB 512 MB
-
-
-
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 9
QuickSpecs
Storage
Drive Support
HP Compaq nx9000 Business Notebook
System Drive Support
1.44-MB Diskette Drive
DVD/CD-RW Combo Drive
CD-RW Drive
DVD-ROM Drive
Max CD-ROM Drive
Hard Drives
60-GB Hard Drive
40-GB Hard Drive
30-GB Hard Drive
20-GB Hard Drive
Quantity
Supported
1/0
1
1
1
1
1
1
1
1
Drive Supported
Dedicated diskette drive
Dedicated optical drive
Dedicated optical drive
Dedicated optical drive
Dedicated optical drive
Dedicated hard drive bay
Dedicated hard drive bay
Dedicated hard drive bay
Dedicated hard drive bay
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 10
QuickSpecs
Technical Specifications
HP Compaq nx9000 Business Notebook
System Unit
Dimensions
Weight
NOTE:
Stand-Alone Power
Requirements
Power Supply
Temperature
Relative Humidity
Shock
Vibration
Maximum Altitude
(unpressurized)
(HxWxD)
* = Weight varies by configuration.
14.1-inch TFT panel displays
15-inch TFT panel displays
14.1-inch TFT panel displays
15-inch TFT panel displays
Nominal Operating Voltage
(Li-Ion)
Average Operating Power
Peak Operating Power
Power in suspend mode
Power in hibernation mode
Rated Input Voltage
Rated Input Current
Rated Frequency
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
Operating
Non-operating
1.51 x 12.96 x 10.72 in (3.84 x 32.75 x 27.23 cm)
1.62 x 12.96 x 10.72 in (4.12 x 32.75 x 27.23 cm)
6.75 lb (3.06 kg)
7.25 lb (3.29 kg)
14.4 V (8-cell)
29.7 W Desktop
82 W on AC
55 W on DC
< 1000 mW
< 100 mW
100 to 240 VAC
4.74 A
50 to 60 Hz
50° to 95° F (10° to 35° C)
14° to 140° F (–10° to 60° C)
10% to 90% relative humidity, non-condensing
5% to 90% relative humidity, 101.6° F (38.7° C)
Maximum wetbulb temperature
10 G, 11 ms, half-sine
60 G, 11 ms, half-sine
0.5 G zero-to-peak, 10 to 500 Hz, 0.25 oct/min sweep
rate
1.0 G, zero-to-peak, 10 to 500 Hz, 0.5 oct/min sweep
rate
0 to 10,000 ft (0 to 3,048 m)
0 to 30,000 ft (0 to 9,144 m)
14.1-Inch Color TFT XGA
Display
Dimensions
Diagonal Size
Mounting
Number of Colors
Contrast Ratio
Brightness
Pixel Resolution
Backlight
Character Display
Total Power Consumption
(H x W)
DA - 11598 Worldwide — Version 11 — December 8, 2004
11.22 x 8.46 in (28.5 x 21.5 cm)
14.1 in (35.81 cm)
Internal Panel Supports, Side Mounted
Up to 16.8M
150:1
120nt typ
Pitch
Format
Configuration
Edge Lit
80 x 25
4.2W
0.264 x 0.264 mm
1024 x 768
RGB stripe
Page 11
QuickSpecs
Technical Specifications
HP Compaq nx9000 Business Notebook
15-Inch Color TFT SXGA+
Display
15-Inch Color TFT XGA
Display
Dimensions
Diagonal Size
Mounting
Number of Colors
Contrast Ratio
Brightness
Pixel Resolution
Backlight
Character Display
Total Power Consumption
Dimensions
Diagonal Size
Mounting
Number of Colors
Contrast Ratio
Brightness
Pixel Resolution
Backlight
Character Display
Total Power Consumption
(H x W)
(H x W)
11.8 x 9 in (30.4 x 22.8 cm)
15 in (38 cm)
Internal Panel Supports, Side Mounted
Up to 16.8M
150:1
150nt typ
Pitch
Format
Configuration
Edge Lit
80 x 25
5.75W
11.8 x 9 in (30.4 x 22.8 cm)
15 in (38 cm)
Internal Panel Supports, Side Mounted
Up to 16.8M
150:1
150nt typ
Pitch
Format
Configuration
Edge Lit
80 x 25
5.0W
0.218264 x 0.218264 mm
1400 x 1050
RGB stripe
0.297 x 0.297 mm
1024 x 768
RGB stripe
15-Inch Color TFT UXGA
Display with wide viewing
angle
Dimensions
Diagonal Size
Mounting
Number of Colors
Contrast Ratio
Brightness
Pixel Resolution
Backlight
Character Display
Total Power Consumption
Viewing Angle
(H x W)
11.8 x 9.0 in (30.4 x 22.8 cm)
15.0 in (38.0 cm)
Internal Panel Supports, Side Mounted
Up to 16.8M
250:1
140nt typ
Pitch
Format
Configuration
Edge Lit
80 x 25
6.5W
+/-85° degrees Horizontal, +15° /-35° Vertical (typical)
0.191 x 0.191 mm
1600 x 1200
RGB stripe
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 12
QuickSpecs
Technical Specifications
Hard Drives
HP Compaq nx9000 Business Notebook
60-GB
(4200 rpm)
40-GB
(4200 rpm)
Drive Weight
Capacity
Height
Width
Interface
Transfer Rate
Seek Time
(typical reads, including
settling)
Rotational Speed
Logical Blocks
Operating Temperature
Features
Drive Weight
Capacity
Height
Width
Interface
Transfer Rate
Seek Time
(typical reads, including
settling)
Rotational Speed
Logical Blocks
Operating Temperature
0.34 lb (155 g)
60 GB
0.374 in (9.5 mm)
70 mm
ATA-5
Synchronous (maximum)
Security
Single Track
Average
Maximum
4200 rpm
117,210,240
41° to 131° F (5° to 55° C)
Security
0.21 lb (95 g)
40 GB
0.374 in (9.5 mm)
2.75 in (70 mm)
ATA-5
Synchronous (maximum)
Security
Single Track
Average
Maximum
4200 rpm
78,140,160
41° to 131° F (5° to 55° C)
100 MB/s (Drive Capability)
ATA Security
3 ms
13 ms
25 ms
ATA Security
100 MB/s (Drive Capability)
ATA Security
3.0 ms
13 ms
25 ms
30-GB
(4200 rpm)
Drive Weight
Capacity
Height
Width
Interface
Transfer Rate
Seek Time
(typical reads, including
settling)
Rotational Speed
Logical Blocks
Operating Temperature
DA - 11598 Worldwide — Version 11 — December 8, 2004
0.22 lb (99 g)
30 GB
0.374 in (9.5 mm)
2.75 in (70 mm)
ATA-5
Synchronous (maximum)
Security
Single Track
Average
Maximum
4200 rpm
58,605,120
41° to 131° F (5° to 55° C)
100 MB/s (Drive Capability)
ATA Security
2.5 ms
12 ms
23 ms
Page 13
QuickSpecs
Technical Specifications
HP Compaq nx9000 Business Notebook
20-GB
(4200 rpm)
Diskette Drive
Drive Weight
Capacity
Height
Width
Interface
Transfer Rate
Seek Time
(typical reads, including
settling)
Rotational Speed
Logical Blocks
Operating Temperature
Diskette Size
Height
Bytes per Sector
Sectors per track
Tracks per side
Read/Write heads
Access Times
0.21 lb (95 g)
20 GB
0.374 in (9.5 mm)
2.75 in (70 mm)
ATA-5
Synchronous (maximum)
Security
Single Track
Average
Maximum
4200 rpm
~ 39,070,080
41° to 131° F (5° to 55° C)
3.5 in
0.5 in (12.7 mm)
512
High density
Low density
High density
Low density
2
Track-to track (high/low)
Average (high/low)
Settling time
Latency average
100 MB/s (Drive Capability)
ATA Security
2.5 ms
12 ms
23 ms
18 (1.44 MB)/15 (1.2 MB)
9
80 (1.44 MB)/80 (1.2 MB)
80
3 ms/6 ms
94 ms/174 ms
15 ms
100 ms
External AC Adapter
without Power Faction
Correction
External AC Adapter with
Power Faction Correction
(EMEA/PRC)
Lithium-Ion Battery Pack
(8-cell)
Weight
Power Supply
Weight
Power Supply
Dimensions
Weight
Energy
Temperature
(Input)
(Input)
(L x W x D)
0.67 lb (0.304 kg)
Operating Voltage
Operating Current
Operating Frequency Range
0.76 lb (0.345 kg)
Operating Voltage
Operating Current
Operating Frequency Range
5.25 x 3.63 x 0.75 in (13.4 x 9.2 x 1.9 cm)
0.96 lb (0.43 kg)
Voltage
Amp-hour capacity
Watt-hour capacity
Operating
Non-operating
100 to 240 VAC RMS
1.7 A RMS
47 to 63 Hz AC
100 to 240 VAC RMS
1.0 A RMS
47 to 63 Hz AC
14.8 V
Typical 4.4 Ah
Typical 64 Wh
32° to 140° F (0° to 60° C)
–4° to 140° F (–20° to 60° C)
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 14
QuickSpecs
Technical Specifications
HP Compaq nx9000 Business Notebook
DVD/CD-RW Drive
DVD-ROM Drive
Center Hole Diameter
Disk Diameter
Disk Thickness
Track Pitch
Access Times
(typical reads, including
settling)
Audio Output Level
Cache Buffer
Data Transfer Rate
(typical, including settling)
Start-up Time
Stop Time
Center Hole Diameter
Disk Diameter
Disk Thickness
Track Pitch
Access Times
(typical reads, including
settling)
Cache Buffer
Data Transfer Rate
(typical, including settling)
Start-up Time
Stop Time
15 mm
12 cm, 8 cm
1.2 mm
1.6 µm
Random CD
Full-Stroke CD
Random DVD
Full-Stroke DVD
0.7 – 0.9 Vrms
2 Mbytes (minimum)
CD-R (24X)
CD-RW (10X)
CD-ROM (24X)
DVD (8X)
Normal PIO Mode 4
(single burst)
Single
Multi-Session
< 6 seconds (typical)
0.59 in (1.5 cm)
12 cm/8 cm
1.2 mm
0.74 µm (DVD)/1.6 µm (CD)
Random (typical)
Full-Stroke (typical)
Random (typical)
Full-Stroke (typical)
512 KB/s (minimum)
Max 24X CD
Max 8X DVD
< 12 seconds Typical
< 3 seconds Typical
< 110 ms
< 210 ms
< 130 ms
< 225 ms
3600 KB/s (150 KB/s at 1X CD rate)
1200 KB/s (150 KB/s at 1X CD rate)
3600 KB/s (150 KB/s at 1X CD rate)
10,800 KB/s (1352 KB/s at 1X DVD rate)
16.6 MB/s
< 9 seconds (typical)
< 30 seconds (typical)
< 125 ms DVD Media
< 225 ms DVD Media
< 100 ms CD Media
< 175 ms CD Media
3600 KB/s (150 KB/s at 1X CD rate)
10,800 KB/s (1352 KB/s at 1X DVD rate)
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 15
QuickSpecs
Technical Specifications
HP Compaq nx9000 Business Notebook
24X CD-ROM Drive
Applicable Disk
Center Hole Diameter
Disk Diameter
Disk Thickness
Track Pitch
Access Times
(typical reads, including settling)
Audio Output Level
Cache Buffer
Data Transfer Rate
(typical, including settling)
Start-up Time
Stop Time
CD-ROM (Mode 1, 2 and 3), CD-XA ready (Mode 2, Form 1 and 2), CD-I ready
(Mode 2, Form 1 and 2), CD-R (read only), CD Plus, Photo CD (Single and Multisession), CD-Extra, Video CD, CD-WO (fixed packets only), CD-Bridge
0.59 in (15 mm)
12 cm, 8 cm
0.047 in (1.2 mm)
1.6 µm
Random
Full-Stroke
Line-out
128 KB
CD-ROM
< 10 seconds
< 5 seconds
< 110 ms
< 220 ms
0.7-0.9 Vrms
3600 KB/s Maximum
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 16
QuickSpecs
Technical Specifications
HP Compaq nx9000 Business Notebook
Integrated Conexant 56K
ACLink Modem
Form Factor
Power Management
Support
Approvals/
Certifications
Data Mode Capabilities
Fax Mode Capabilities
Command Set
Integrated on motherboard
APM Revision 1.2, ACPI
UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part 15 Class B,
Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE Mark, Other Countries
High speed 56K modem (a-law, mu-law)
K56flex (a-law, mu-law)
V.8bis
V.80
V44.bis, MNP5 (Compression)
V42.bis, MNP5 (Compression)
V.42 (LAPM, MNP2-4) (Error Correction)
V.34 (file date: 10/96)
Optional symbol rates:
2800, 3429
Asymmetric Symbol rates
Synchronous primary channel data signaling rates:
3600, 31200
Automatic rate re-negotiation
V.32bis
V.32
V.23
V.22bis
V.22
V.21
Bell 212A
Bell 103J
TIA-578-S (Class 1)
T.30, T.4 (Group 3)
V.17
V.29
V.27ter
V.21 Channel 2
V.250 (Partial)
TIA-602
Identification: +GMI, +GMM, +GMR
Port control: +IPR, +ICF, +IFC, +ILRR
Modulation: +MS, +MR, +MA
Error control: +ES, +ER, +EB, +ESR, +ETBM
Data compression: +DS, +DR
V.251
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 17
QuickSpecs
Technical Specifications
HP Compaq nx9000 Business Notebook
Integrated 10/100 NIC
© Copyright 2003-2004 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. Pentium, the Intel Inside
Logo, Centrino and SpeedStep are registered trademarks or trademarks of Intel Corporation in the U.S. and/or other countries. BatteryMark is a
trademark of Ziff Davis Publishing Holdings Inc., and affiliate of eTesting Labs Inc., in the U.S. and other countries. All other product names mentioned
herein may be trademarks of their respective companies.
NIC Device Driver Name
Data Link Layers
Ethernet Features
Software support
Protocol support
National Semiconductor Corp. DP83815/816 10/100 MacPhyter PCI Adapter
IEEE 802.2 LLC
SNAP
10 Mbps Ethernet: IEEE 802.3 standard 10BASE-T
100 Mbps Ethernet: IEEE 802.3u standard 100BASE-TX
Full Duplex at 10 and 100Mbps
Auto-Negotiation
Wake on LAN from Standby (S3)
Lower Power State on Link Loss
IBM LAN Server Version 1.2, 1.3, 2.0, 4.0
Microsoft NT 3.51, NT 4.0. Microsoft Windows 2000
Novell Netware 3.1x, 4.x, 5.x
TCP/IP
Novell IPX/SPX and Microsoft compatible
Novel IPX ODI
Microsoft NetBEUI
IBM DLC
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services.
Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions
contained herein.
DA - 11598 Worldwide — Version 11 — December 8, 2004
Page 18
Loading...
