QuickSpecs
Overview
HP Compaq nx6110 Notebook PC
HP Compaq nx6110 Notebook PC
HP recommends Microsoft® Windows® XP Professional
1. Stereo Speakers 9. IEEE 1394 Port
2. Touchpad with Scroll Zone 10. RJ-45 Port (NIC)
3. Hard Drive Activity LED 11. RJ-11 Port (Modem)
4. Battery Charging LED 12. VGA/External Monitor Connector
5. Power/Standby LED 13. 2 USB 2.0 Ports
6. Wireless On/Off LED 14. Power Button with LED
7. PC Card Eject Button 15. Wireless On/Off Button with LED
8. PC Card Slot
DA – 12135 North America — Version 16 — October 4, 2005 Page 1
QuickSpecs
HP Compaq nx6110 Notebook PC
Overview
1. Headphone Jack 4. Optical Drive Release Button
2. Microphone Jack 5. Kensington Lock Slot
3. Optical Drive 6. DC Power Connector
At A Glance
Microsoft Windows XP Professional, Microsoft Windows XP Home Edition (select countries), or FreeDOS
Intel® Pentium® M processors 730 to 770* or Intel Celeron® M processors 360J to 380*
Sleek, industrial design starting at 6.06 lb/2.75 kg and 1.2-inch/30.3-mm thin at front
Mobile Intel 915GM or 910GML Express Chipset
256-MB DDR SDRAM, upgradeable to 2048-MB maximum
Up to 80-GB 5400 rpm user-removable hard drive
Intel Graphics Media Accelerator 900
Optional Integrated 802.11a/b/g or 802.11b/g wireless LAN modules
Support for optional Intel Centrino™ mobile technology
Optional integrated Bluetooth®
NetXtreme 10/100 Ethernet Controller
Touchpad with scroll zone
Protected by one-year standard parts and labor warranty - certain restrictions and exclusions apply
*Intel's numbering system is not a measurement of performance.
What's Special
Security features:
o HP ProtectTools o HP Drivelock o Kensington lock slot
Ease of use features
o HP Mobile Print Driver for on-the-go printing o HP Wireless Assistant o HP Info Center o HP Fast Charge technology o Up to 4 hours of battery life
Integrated reliability features:
o HP Mobile Data Protection System
DA – 12135 North America — Version 16 — October 4, 2005 Page 2
QuickSpecs
Overview
o HP Panel Protection System
HP Compaq nx6110 Notebook PC
DA – 12135 North America — Version 16 — October 4, 2005 Page 3
QuickSpecs
HP Compaq nx6110 Notebook PC
Standard Features
Processors
FreeDOS NOTE: Microsoft Windows 2000 Professional is not available pre-installed, but drivers for it are
Intel Pentium M processor 770* (2.13-GHz, 533-MHz FSB, 2-MB L2 cache) Intel Pentium M processor 760* (2.0-GHz, 533-MHz FSB, 2-MB L2 cache) Intel Pentium M processor 750* (1.86-GHz, 533-MHz FSB, 2-MB L2 cache) Intel Pentium M processor 740* (1.73-GHz, 533-MHz FSB, 2-MB L2 cache) Intel Pentium M processor 730* (1.6-GHz, 533-MHz FSB, 2-MB L2 cache) Intel Celeron M processor 380* (1.6-GHz, 400-MHz FSB, 1-MB L2 cache) Intel Celeron M processor 370* (1.5-GHz, 400-MHz FSB, 1-MB L2 cache) Intel Celeron M processor 360J* (1.4-GHz, 400-MHz FSB, 1-MB L2 cache)
* Intel's numbering is not a measurement of higher performance. NOTE: Intel Pentium M processors support enhanced Intel SpeedStep™ technology.
Processor speed denotes maximum performance mode; Intel Pentium M processors will run at approximately 800 MHz in battery optimization mode.
Microsoft Windows XP Professional SP2 Operating System Microsoft Windows XP Home Edition SP2 (select countries only)
downloadable from http://www.hp.com
.
Chipset Mobile Intel 910GML Express Chipset Mobile Intel 915GM Express Chipset
Graphics Intel Graphics Media Accelerator 900 with up to 128-MB shared system memory
Display
Memory
Communications
Internal 15.0-inch TFT XGA (1024 x 768 resolution and 16 M colors)
15.0-inch TFT SXGA+ (1400 x 1050 resolution and 16 M colors)
External Up to 32-bit per pixel color depth
Supports 640 x 480, 800 x 600, 1024 x 768, 1280 x 768, 1280 x 1024, or 1600 x 1200 resolutions up to 100-Hz refresh rate, dependent upon monitor capability, and resolution and color depth settings
Standard 256-MB, 512-MB, or 1024-MB 333-MHz DDR SDRAM; two SODIMM
slots
Maximum Upgradeable to 2048-MB maximum (1024-MB SODIMM in slots 1
and 2)
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
NetXtreme 10/100 Ethernet Controller 56K modem* with digital line guard
* Designed for downloads from 56K modem compliant sources. Maximum achievable download transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is subject to country regulatory approval.
DA – 12135 North America — Version 16 — October 4, 2005 Page 4
QuickSpecs
Standard Features
Wireless Devices
Support for a broad range of secure, integrated wireless LAN options. Integrated Bluetooth is also an option (factory configurable only) and can be combined with any one of the supported wireless LAN options.
All integrated wireless LAN options
Broadcom 802.11b/g WLAN
Broadcom 802.11a/b/g WLAN
Intel PRO/Wireless 2200BG 802.11 b/g WLAN
Intel PRO/Wireless 2915ABG 802.11 a/b/g WLAN
Integrated Bluetooth Bluetooth Specification v1.2 compliant
HP Compaq nx6110 Notebook PC
Wi-Fi certified Cisco Compatible Extensions support (Version 3.0) Wired Equivalent Privacy (WEP) support up to 128-bit keys Wi-Fi Protected Access (WPA) and WPA2 support
802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, and LEAP Advanced Encryption Standard (AES) support WiFi certified for WPA2, WMM Dual antennas integrated in the display enclosure
Integrated support for 802.11 b and g Up to 54-mbps data rate
Integrated support for 802.11a, b and g Up to 54-mbps data rate
Intel Centrino mobile technology Integrated support for 802.11b and g Up to 54-mbps data rate
Intel Centrino mobile technology Integrated support for 802.11a, b and g Up to 54-mbps data rate
Works with a wide range of Bluetooth devices
Keyboard The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with
desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right control and alt keys, and 12 function keys. U.S. and International key layouts are available. Other features include an integrated numeric keypad, hotkeys for instant access to power conservation, brightness, and other features, 19-mm x 19-mm key pitch (center-to­center spacing), 2.5-mm stroke, comfort-dished keycaps, and bright key legends for improved visibility in low light conditions.
Wireless On/Off Button Provides one-touch on/off control of the integrated wireless device(s).
Pointing Device Touchpad with scroll zone, two soft-touch buttons
Expansion Card Slots One Type I/II/III PC
Card
Storage
Hard Drives 40-, 60-, 80-GB 5400 rpm SMART
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal cycles.
Optical Drives Integrated (12.7-mm) DVD-ROM
Supports 32-bit CardBus and 16-bit PC Cards
DVD/CD-RW Combo DVD+/-RW
Interfaces PC Card Slot One – Type I/II/III
DA – 12135 North America — Version 16 — October 4, 2005 Page 5
QuickSpecs
Standard Features
External Monitor One – VGA IEEE 1394 Port One External Microphone One Headphone/Line out One Power Connector One RJ-11 (Modem) One RJ-45 (NIC) One USB 2.0 Two Travel Battery
Connector LED Status Indicators Eleven
Audio ADI AC '97 CODEC
Integrated 16-bit Sound Blaster Pro compatible audio Integrated stereo speakers Stereo headphone/line out Stereo microphone in
HP Compaq nx6110 Notebook PC
One
Software
System Recovery for Microsoft Windows XP systems only
Preloaded Software for Microsoft Windows XP
Software on CD Intervideo WinDVD Creator - DVD Authoring (for optional DVD+/- RW
Additional software available from the Web
* Software is loaded on the hard drive and must be installed by running the Software Setup utility
Each unit is shipped with a recovery kit containing Operating System Recovery and Driver/Application Recovery discs. These discs allow users to either recover or repair the notebook operating system and select drivers without losing personal data. The Operating System disc also provides the option of reinstalling the operating system software provided with the notebook.
Adobe Acrobat Reader HP Local Recovery provided by Altiris* HP One-Touch Button Software HP Mobile Print Driver Synaptics Touchpad Driver HP Help and Support HP ProtectTools Security Manager: BIOS Configuration for HP ProtectTools Credential Manager for HP ProtectTools HP Wireless Assistant Sonic RecordNow! (for optional DVD+/-RW and DVD/CDRW drives)* Symantec Norton Antivirus with complimentary 60-day live update Intervideo WinDVD – DVD Player (for optional DVD+/-RW, DVD/CDRW and DVD drives)*
drives) HP Client Manager Software
HP ProtectTools Security Manager: Smart Card Security for HP ProtectTools
Client Management Software
HP Client Manager Software (CMS) provides asset tracking, alerting, diagnostics, and SoftPaq distribution for HP business desktops, notebooks, and workstations. HP CMS is the foundation for HP Client Management Solutions. For more information and to download HP Client
DA – 12135 North America — Version 16 — October 4, 2005 Page 6
QuickSpecs
HP Compaq nx6110 Notebook PC
Standard Features
Manager Software, please refer to the HP website at http://www.hp.com/go/easydeploy.
SMBIOS Version 2.3.4 System Management BIOS, previously known as DMI BIOS, is used to store system
management information.
HP Local Recovery Provided by Altiris
HP ProtectTools Security Manager
Security
Provides data and system file protection for HP business PCs to enable fast recovery of information that is accidentally deleted or if the system becomes corrupted. Designed for disconnected or seldom-connected users, Local Recovery protects your HP computer's data and system state by taking scheduled snapshots, which are then stored in a protected area on the local hard disk. System backup and disaster recovery is now simple and fast for all users, regardless of connectivity. For more information and to download, please refer to the HP website at http://www.hp.com/go/easydeploy
HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP ProtectTools Security Manager is an extensible client security console that delivers enhanced security capabilities through add-on software modules. Modules currently available are:
- Smart Card Security for HP ProtectTools
- BIOS Configuration for HP ProtectTools
- Credential Manager for HP ProtectTools
Standard Features Configuration Control Hardware
Memory Change Alert Ownership Tag Setup Password Power-On Password Drivelock Enabled for PC Smart Card options Kensington Lock Slot
For more information on HP security solutions refer to http://www.hp.com/go/security
.
.
Power Supply External 65-watt slim AC adapter, 6-foot (1.8-meter) power cord included.
Total length including External AC adapter is 12 feet (3.66 meter). HP Fast Charge technology
Primary Battery 6-cell high capacity Lithium-Ion (42Wh) – one-year warranty Battery Optional Travel Battery 8-cell high capacity Lithium-Ion (52Wh)
Battery Life
System Standby Time Up to 1 week
Primary Battery Up to 4 hours and 30 minutes Primary Battery and
optional HP Travel Battery
NOTE: Battery life will vary depending on the product configuration, product model, applications loaded on the product, power management settings of the product, and the product features used by the customer. As with all batteries, the maximum capacity of this battery will decrease with time and usage.
DA – 12135 North America — Version 16 — October 4, 2005 Page 7
Up to 10 hours
QuickSpecs
Standard Features
HP Compaq nx6110 Notebook PC
Power Conservation
Hibernation Standby ACPI compliance
Service and Support
Select Model(s)
nx6110 PR124UA#ABA
* Intel's numbering is not a measurement of higher performance. ** Certain restrictions and exclusions apply.
Supports enhanced Intel SpeedStep technology with Intel Pentium M processors (allows Battery Optimized Mode, Maximum Performance Mode, or Automatic mode)
Intel Display Power Saving technology
HP Services includes a one-year standard parts and labor warranty, pick-up or carry-in, and toll-free 7 x 24 hardware technical phone support. On-site service and warranty upgrades are also available.
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Cente r for details.
http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp
Processor Intel Celeron M processor 360J* (1.4-GHz, 400-MHz FSB, 1-MB L2
cache) Operating System Microsoft Windows XP Home System Memory 256-MB 333-MHz DDR SDRAM (256-MB SODIMM in slot 1) Hard Drive 40-GB 5400 rpm Display 15.0-inch TFT XGA with 1024 x 768 resolution (up to 16.7 M colors
internal) Graphics Intel Graphics Media Accelerator 900 Video Memory Up to 128 MB of shared system memory Audio ADI AC '97 CODEC, Line out/headphone and microphone jacks Optical Drive 24X DVD/CDRW Combo Communications 56K Fax/Modem,
Integrated NetXtreme Ethernet Controller
(10/100 NIC) Integrated Wireless Broadcom 802.11b/g WLAN Pointing Device Touchpad with scroll zone Battery 6-cell high capacity Lithium-Ion (42Wh) Power External 65W adapter Warranty** 1/1/0
.
nx6110 PT602AA#ABA
Processor Intel Celeron M processor 360J* (1.4-GHz, 400-MHz FSB, 1-MB L2
cache) Operating System Microsoft Windows XP Professional System Memory 512-MB 333-MHz DDR SDRAM (256-MB SODIMM in slot 1 and 2) Hard Drive 60-GB 5400 rpm Display 15.0-inch TFT XGA with 1024 x 768 resolution (up to 16.7 M colors
internal)
DA – 12135 North America — Version 16 — October 4, 2005 Page 8
QuickSpecs
Standard Features
Graphics Intel Graphics Media Accelerator 900 Video Memory Up to 128 MB of shared system memory Audio ADI AC '97 CODEC, Line out/headphone and microphone jacks Optical Drive 24X DVD/CDRW Combo Communications 56K Fax/Modem,
Integrated NetXtreme Ethernet Controller
(10/100 NIC) Integrated Wireless Broadcom 802.11b/g WLAN Pointing Device Touchpad with scroll zone Battery 6-cell high capacity Lithium-Ion (42Wh) Power External 65W adapter Warranty** 1/1/0
* Intel's numbering is not a measurement of higher performance. ** Certain restrictions and exclusions apply.
HP Compaq nx6110 Notebook PC
nx6110 PZ065UA#ABA Smart Buy
* Intel's numbering is not a measurement of higher performance. ** Certain restrictions and exclusions apply.
Processor Intel Pentium M processor 740* (1.73-GHz, 533-MHz FSB, 2-MB L2
cache) Operating System Microsoft Windows XP Professional System Memory 512-MB 333-MHz DDR SDRAM (256-MB SODIMM in slot 1 and slot
2) Hard Drive 40-GB 5400 rpm Display 15.0-inch TFT XGA with 1024 x 768 resolution (up to 16.7 M colors
internal) Graphics Intel Graphics Media Accelerator 900 Video Memory Up to 128 MB of shared system memory Audio ADI AC '97 CODEC, Line out/headphone and microphone jacks Optical Drive DVD/CD-RW Communications 56K Fax/Modem,
Integrated NetXtreme Ethernet Controller
(10/100 NIC) Integrated Wireless Intel PRO/Wireless 2915ABG 802.11a/b/g WLAN Pointing Device Touchpad with scroll zone Battery 6-cell high capacity Lithium-Ion (42Wh) Power External 65W adapter Warranty** 1/1/0
nx6110 PZ120UA#ABA
Processor Intel Pentium M processor 750* (1.86-GHz, 533-MHz FSB, 2-MB L2
cache) Operating System Microsoft Windows XP Professional System Memory 512-MB 333-MHz DDR SDRAM (256-MB SODIMM in slot 1 and slot
2) Hard Drive 60-GB 5400 rpm Display 15.0-inch TFT XGA with 1024 x 768 resolution (up to 16.7 M colors
internal)
DA – 12135 North America — Version 16 — October 4, 2005 Page 9
QuickSpecs
Standard Features
Graphics Intel Graphics Media Accelerator 900 Video Memory Up to 128 MB of shared system memory Audio ADI AC '97 CODEC, Line out/headphone and microphone jacks Optical Drive DVD+/-RW DL Communications 56K Fax/Modem,
Integrated NetXtreme Ethernet Controller
(10/100 NIC) Integrated Wireless Intel PRO/Wireless 2200BG 802.11b/g WLAN Pointing Device Touchpad with scroll zone Battery 6-cell high capacity Lithium-Ion (42Wh) Power External 65W adapter Warranty** 1/1/0
* Intel's numbering is not a measurement of higher performance. ** Certain restrictions and exclusions apply.
HP Compaq nx6110 Notebook PC
nx6110 PZ866UA#ABA Smart Buy
* Intel's numbering is not a measurement of higher performance. ** Certain restrictions and exclusions apply.
Processor Intel Pentium M processor 730* (1.6-GHz, 533-MHz FSB, 2-MB L2
cache) Operating System Microsoft Windows XP Professional System Memory 512-MB 333-MHz DDR SDRAM (256-MB SODIMM in slot 1 and slot
2) Hard Drive 40-GB 5400 rpm Display 15.0-inch TFT XGA with 1024 x 768 resolution (up to 16.7 M colors
internal) Graphics Intel Graphics Media Accelerator 900 Video Memory Up to 128 MB of shared system memory Audio ADI AC '97 CODEC, Line out/headphone and microphone jacks Optical Drive DVD/CD-RW Communications 56K Fax/Modem,
Integrated NetXtreme Ethernet Controller
(10/100 NIC) Integrated Wireless Broadcom 802.11b/g WLAN Pointing Device Touchpad with scroll zone Battery 6-cell high capacity Lithium-Ion (42Wh) Power External 65W adapter Warranty** 1/1/0
nx6110 PZ867UA#ABA Smart Buy
Processor Intel Pentium M processor 740* (1.73-GHz, 533-MHz FSB, 2-MB L2
cache) Operating System Microsoft Windows XP Professional System Memory 1024-MB 333-MHz DDR SDRAM (512-MB SODIMM in slot 1 and slot
2) Hard Drive 40-GB 5400 rpm Display 15.0-inch TFT SXGA+ with 1400 x 1050 resolution (up to 16.7 M
colors internal)
DA – 12135 North America — Version 16 — October 4, 2005 Page 10
QuickSpecs
Standard Features
Graphics Intel Graphics Media Accelerator 900 Video Memory Up to 128 MB of shared system memory Audio ADI AC '97 CODEC, Line out/headphone and microphone jacks Optical Drive DVD+/-RW DL Communications 56K Fax/Modem,
Integrated NetXtreme Ethernet Controller
(10/100 NIC) Integrated Wireless Broadcom 802.11b/g WLAN Pointing Device Touchpad with scroll zone Battery 6-cell high capacity Lithium-Ion (42Wh) Power External 65W adapter Warranty** 1/1/0
* Intel's numbering is not a measurement of higher performance. ** Certain restrictions and exclusions apply.
HP Compaq nx6110 Notebook PC
DA – 12135 North America — Version 16 — October 4, 2005 Page 11
QuickSpecs
Options
Memory
256-MB 333-MHz DDR SDRAM DC389B 512-MB 333-MHz DDR SDRAM DC390B 1024-MB 333-MHz DDR SDRAM DC890B
HP Compaq nx6110 Notebook PC
Storage
HP 40-GB Mobile USB Hard Drive DQ549A
Communications Intel PRO/Wireless 2200BG 802.11b/g WLAN option kit PF952AA#ABA
Expansion Solutions HP 4-port USB 2.0 Hub DG954A
Battery Adapter kit #1 PK402A 65W AC Adapter DC359A#ABA 90W AC Adapter DC895B#ABA 90W Auto Adapter DC303B 90W Air/Auto/AC Combo Adapter DV574A#ABA 90W Aircraft Cables DC899A Primary 6-cell Battery Pack PB994A HP Travel Battery PB993A
60-GB 5400 rpm Primary Hard Drive PA852A USB Diskette Drive DC361B HP USB Digital Drive + 128-MB Secure Digital Card DL702A
HP 2-bay Battery Charging Station DT533A#ABAPower HP 10-bay Battery Charging Station DT534A#ABA
Carrying Cases
Security PC Card Smart Card Reader DC350B HP/Kensingto n Cable Lock PC766A
Input/Output Devices
Rechargeable Wireless Mouse DU960A
HP Entry Value Case DL617A HP Top Load Nylon DC915A HP Executive Leather case PA847A HP Sport Backpack DG102A
USB/PS2 Keyboard DC852A#ABA USB/PS2 Optical Mouse DC369A HP USB Optical Travel Mouse F2100A
DA – 12135 North America — Version 16 — October 4, 2005 Page 12
QuickSpecs
HP Compaq nx6110 Notebook PC
Memory
Up to 2048 MB of 333-MHz DDR SDRAM Two DIMM slots (user accessible - one under keyboard deck, one via panel on bottom of unit) DIMM sizes supported: 256 MB, 512 MB, or 1024 MB
Standard Memory
Optional Memory Upgrades
256 MB (256 MB x 1)
512 MB (512 MB x 1 or 256 MB x 2)
1024 MB (1024 MB x 1 or 512 MB x 2)
Support for up to 2048 MB of memory is available (with the installation of optional DDR SDRAM memory kits). Both memory slots are user accessible. Please refer to the Hardware and Software Guide for installation procedures.
Up to Slot 1 Slot 2
768 MB 512 MB 256 MB 1024 MB 1024 MB Empty 1024 MB 512 MB 512 MB 1280 MB 1024 MB 256 MB 1536 MB 1024 MB 512 MB 2048 MB 1024 MB 1024 MB
NOTE: This chart does not represent all possible memory co nfigurations. Due to the non-
industry standard nature of some third-party memory modules, we strongly recommend using only HP branded memory modules to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
Memory Upgrades 1024-MB 333-MHz DDR SDRAM DC890B 512-MB 333-MHz DDR SDRAM DC390B 256-MB 333-MHz DDR SDRAM DC389B
DA – 12135 North America — Version 16 — October 4, 2005 Page 13
QuickSpecs
HP Compaq nx6110 Notebook PC
Storage
Removable Media Drive Support
Quantity Supported Drive Bay DVD+/-RW Drive One Fixed optical drive bay DVD/CD-RW Combo Drive One Fixed optical drive bay DVD-ROM Drive One Fixed optical drive bay
Hard Drive Support
Quantity Supported Drive Bay 80-GB 5400 rpm SMART Hard
Drive 60-GB 5400 rpm SMART Hard
Drive 40-GB 5400 rpm SMART Hard
Drive
One Dedicated hard drive bay
One Dedicated hard drive bay
One Dedicated hard drive bay
DA – 12135 North America — Version 16 — October 4, 2005 Page 14
QuickSpecs
Technical Specifications
System Unit
Dimensions (HxWxD) 1.2 (at front) x 12.9 x 10.5 in (30.3 (at front) x 328.6 x 267 mm) Weight nx6110 with 15.0-inch
NOTE: Height varies depending upon where on the notebook the measurement is made. Weight varies by configuration and components. Weight includes 6-cell battery, 30-GB hard drive, 256-MB memory, and CD-ROM drive. Weight varies by configuration and components.
Stand-Alone Power Requirements
Temperature
Relative Humidity
Random Vibration Operating 0.75 grms Non-operating 1.50 grms
(unpressurized) Industry Standard
Certifications
HP Compaq nx6110 Notebook PC
6.06 lb (2.75 kg)
display
Nominal Operating Voltage
Average Operating Power
Max Operating Power < 65W Operating 32° to 95° F (0° to 35° C) (not writing
41° to 95° F (5° to 35° C) (writing optical) Non-operating -4° to 140° F (-20° to 60° C) Operating 10% to 90% relative humidity, non-
Non-operating 5% to 95%, 101.6° F (38.7° C) maximum
Operating 125 G, 2 ms, half-sine Shock Non-operating 200 G, 2 ms, half-sine
Operating -50 to 10,000 ft (-15.24 to 3,048 m) Altitude Non-operating -50 to 40,000 ft (-15.24 to 12,192 m) Blue Angel No UL Yes Energy Star Yes Canadian Safety Yes CSA (Canada) Yes ICES Yes TUV GS No Nordic Safety No Mexican Safety Yes Poland Compliance Yes Australia / NZ
Compliance CCC Yes Japan Compliance Yes MIC Yes BSMI Yes CE Marking Compliance Yes KONCAR Yes GOST Yes SASO Yes SABS Yes
18.5 V
20 W
optical)
condensing
wet bulb temperature
Yes
DA – 12135 North America — Version 16 — October 4, 2005 Page 15
QuickSpecs
Technical Specifications
HP Compaq nx6110 Notebook PC
UKRSERTCOMPUTER Yes
65W External AC Adapter
Weight 0.62 lb (0.28 kg) (adapter)
0.29 lb (0.13 kg) (power cord) Dimensions 4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm) Input
Output Output Power 65 W DC Output Current 18.5 V Environmental
EMI and Safety Certifications
MTBF Over 200,000 hours at 25°C ambient condition
Operating Input Voltage 100 to 240 VAC Operating Input Current 1.7A at 90 VAC
0.85A at 180 VAC
Operating Frequency Range
Efficiency 83% minimum at 115 VAC
Operating Temperature 32° to 104° F (0° to 40° C) Non-operating (storage)
Temperature Altitude 0 to 10,000 ft (0 to 3,048 m) Humidity 20% to 80% Storage Humidity 10% to 90% CE Mark: full compliance with LVD and EMC directives
Worldwide safety standards: IEC950, EN60950, UL1950, Class2, SELV Agency approvals: C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCIB, NOM-1 NY CE
47 to 63 Hz AC
-4° to 149° F (-20° to 65° C)
42Wh Primary Lithium­Ion Battery Pack
Optional 52Wh Travel Battery
Dimensions (H x W x L) 0.8 x 2.1 x 8.0 in (2.0 x 5.3 x 20.3 cm) Weight 0.715 lb (0.325 kg) Cells/Type 6-cell Lithium-Ion Energy
Temperature
Battery Re-Charge Time System in OFF mode or
System ON 3 to 5 hours (depending on system power
HP Fast Charge
Dimensions (H x W x L) 1.0 x 3.9 x 8.7 in (2.5 x 10.0 x 22.0 cm) Weight 1.00 lb (0.455 kg) Cells/Type 8-cell Lithium-Ion Energy
Voltage 10.8 V Amp-hour capacity 4.0Ah Watt-hour capacity 42Wh Operating (Charging) 32° to 113° F (0° to 45° C) Operating (Discharging) 14° to 140° F (-10° to 60° C) Non-operating -4° to 140° F (-20° to 60° C)
2.5 hours
Standby
consumption) Charges the battery up to 90% within 1.5
Technology
Voltage 14.4 V Amp-hour Capacity 3.6Ah
hours when system is OFF
DA – 12135 North America — Version 16 — October 4, 2005 Page 16
QuickSpecs
Technical Specifications
Temperature
Battery Re-Charge Time System in OFF mode or
System ON 3 to 5 hours (depending on system power
Fuel Gauge When pressed, LEDs light indicating level of charge remaining on
HP Compaq nx6110 Notebook PC
Watt-hour Capacity 52Wh Operating (Charging) 32° to 113° F (0° to 45° C) Operating (Discharging) 14° to 140° F (-10° to 60° C) Non-operating -4° to 140° F (-20° to 60° C)
3 hours
Standby
consumption)
battery
15.0-Inch Color TFT XGA Display
15.0-Inch Color TFT SXGA+ Display
Active Area (W x H) 12.0 x 9.0 in (30.4 x 22.8 cm) Diagonal Size 15.0 in (38.0 cm) Surface Treatment Anti-glare Number of Colors Up to 16 M Contrast Ratio 250:1 (typical) Refresh Rate 60 Hz Brightness 150 nit (typical) Pixel Resolution
Backlight CCFL PPI 85 Character Display 80 x 25 Total Power
Consumption Viewing Angle ±45° Horizontal, +15°/-35° Vertical (typical)
Active Area (W x H) 12.0 x 9.0 in (30.4 x 22.8 cm) Diagonal Size 15.0 in (38.0 cm) Surface Treatment Anti-glare Number of Colors Up to 16 M Contrast Ratio 300:1 (typical) Refresh Rate 60 Hz Brightness 180 nit (typical) Pixel Resolution
Backlight CCFL PPI 116 Character Display 80 x 25 Total Power
Consumption Viewing Angle ±45° Horizontal, +15°/-35° Vertical (typical)
Pitch 0.297 mm Format 1024 x 768 Configuration RGB Stripe
5.7 W
Pitch 0.217 mm Format 1400 x 1050 Configuration RGB Stripe
5.8 W
DA – 12135 North America — Version 16 — October 4, 2005 Page 17
QuickSpecs
Technical Specifications
Hard Drives
HP Compaq nx6110 Notebook PC
80-GB 5400 rpm
60-GB 5400 rpm
Drive Weight 0.22 lb (99 g) Capacity 80 GB Height 0.37 in (9.5 mm) Width 2.75 in (70 mm) Interface ATA-6 Transfer Rate Synchronous
(maximum)
Seek Time (typical reads, including settling)
Rotational Speed 5400 rpm Logical Blocks 156,301,488 Operating Temperature 41° to 131° F (5° to 55° C) Features ATA Security
Drive Weight 0.22 lb (99 g) Capacity 60 GB Height 0.37 in (9.5 mm) Width 2.75 in (70 mm) Interface ATA-6 Transfer Rate Synchronous
Seek Time (typical reads, including settling)
Rotational Speed 5400 rpm Logical Blocks 117,210,240 Operating Temperature 41° to 131° F (5° to 55° C) Features ATA Security
Single Track 3 ms Average 13 ms Maximum 24 ms
(maximum) Single Track 3 ms Average 13 ms Maximum 24 ms
100 MB/s (Drive Capability)
100 MB/s (Drive Capability)
40-GB 5400 rpm
Drive Weight 0.22 lb (99 g) Capacity 40 GB Height 0.37 in (9.5 mm) Width 2.75 in (70 mm) Interface ATA-6 Transfer Rate Synchronous
(maximum)
Seek Time (typical reads, including settling)
Rotational Speed 5400 rpm Logical Blocks 78,140,160 Operating Temperature 41° to 131° F (5° to 55° C)
DA – 12135 North America — Version 16 — October 4, 2005 Page 18
Single Track 3 ms Average 13 ms Maximum 24 ms
100 MB/s (Drive Capability)
QuickSpecs
Technical Specifications
Features ATA Security
Removable Storage Drives – Fixed Bay
HP Compaq nx6110 Notebook PC
DVD-ROM Drive
DVD/CD-RW Combo Drive
Access Times Random <100 ms CD <125 ms DVD
24X-CD-ROM 3,600 KB/s Max Data Transfer Rate
8X-DVD 10,800 KB/s Transfer Mode Multiword DMA Mode 2 Interface EIDE Supported Media (read) CD -DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA,
MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD),
Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW),
CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-
R, DVD-RW, DVD+R, DVD+RW Supported Media (write) None Max Media Capacity
(read) Transport Tray Loading
Access Times Random <110 ms CD <130 ms DVD Max Data Transfer Rate
Transfer Mode Multiword DMA Mode 2 Interface EIDE Supported Media (read) CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA,
Supported Media (write) CD-R, CD-RW Max Media Capacity
(read) Max Media Capacity
(write) Transport Tray loading
4.7 GB
24X CD-ROM 3,600 KB/s
8X DVD 10,800 KB/s
24X CD-R 3,600 KB/s
24X CD-RW 3,600 KB/s
MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD),
Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW),
CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-
R, DVD-RW, DVD+R, DVD+RW
4.7 GB
700 MB
DVD+/-RW Drive
Access Times Random <175 ms CD <230 ms DVD Max Data Transfer Rate
DA – 12135 North America — Version 16 — October 4, 2005 Page 19
24X CD-ROM 3,600 KB/s
8X DVD 10,800 KB/s
16X CD-R 2,400 KB/s
10X CD-RW 1,500 KB/s
QuickSpecs
Technical Specifications
4X DVD-R 5,400 KB/s 2X DVD-RW 2,700 KB/s Transfer Mode Multiword DMA Mode 2 Interface EIDE Supported Media (read) CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA,
Supported Media (write) CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW Max Media Capacity
(read) Max Media Capacity
(write) Transport Tray Loading
HP Compaq nx6110 Notebook PC
4X DVD+R 5,400 KB/s
4X DVD+RW 5,400 KB/s
MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD),
Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW),
CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-
R, DVD-RW, DVD+R, DVD+RW
4.7 GB
4.7 GB
Audio
Hardware
Audio Output Quality
Implementation ADI AC '97 CODEC Volume Controls Up, down, and mute buttons Full Duplex Yes Sound Blaster Pro
compatible Microphone Jack Stereo or mono Headphone/Line Out
Jack
Frequency Response 20 Hz - 20 kHz Signal to Noise Ratio >85 dB Total Harmonic
Distortion Noise Floor -110 dB Play/Record Sampling
Rate(s) AD/DA Resolution 16 bit
Power Rating 2 Watts Internal Speakers Impedance 4 Ohms
Yes
Stereo
0.01%
7 kHz - 48 kHz
Communications
Integrated NetXtreme 10/100 Ethernet Controller
Ethernet Features 10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-
14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3
DA – 12135 North America — Version 16 — October 4, 2005 Page 20
QuickSpecs
Technical Specifications
Auto-Negotiation (Automatic Speed Selection) Full Duplex Operation at all Speeds, Half Duplex operation at 10 and
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable) Power Management ACPI 1.1a compliant -- multiple power modes
Manageability Wake-on-LAN from all Power-Managed States (configurable; Magic
PXE 2.0 Remote Boot Statistics Gathering (RMON, Ethernet-like MIB, Ethernet MIB (802.3x,
Comprehensive diagnostic and configuration software suite NIC Device Driver Name Broadcom 440X 10/100 Integrated Controller Drivers Available
HP Compaq nx6110 Notebook PC
clauses 21-30)
100 Mbit/s
Situation-sensitive features reduce power consumption
Packet and Microsoft Wake-Up Frame)
clause 30))
Windows XP Windows 2000 DOS NDIS2 and ODI
Agere Systems AC'97 Modem
Form Factor MDC Daughtercard Power Management
Support Approvals/
Certifications
Data Mode Capabilities
Fax Mode Capabilities TIA/EIA-578-B (Class 1)
APM Revision 1.2, ACPI
UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE Mark, Other Countries
56K modem (a-law, mu-law) V.8bis V.80 V44, V.42bis, MNP5 (Compression) V.42 (LAPM, MNP2-4) (Error Correction) V.34 (file date: 10/96) Optional symbol rates:
2800, 3429 Asymmetric Symbol rates
Synchronous primary channel data signaling rates: 3600, 31200 Automatic rate re-negotiation V.32bis V.32 V.23 V.22bis V.22 V.21 Bell 212A Bell 103J
T.30, T.4 (Group 3) V.17 V.29 V.27ter
DA – 12135 North America — Version 16 — October 4, 2005 Page 21
QuickSpecs
Technical Specifications
Command Set V.250 (Partial)
HP Compaq nx6110 Notebook PC
V.21 Channel 2
TIA-602 Identification: +GMI, +GMM, +GMR Port control: +IPR, +ICF, +IFC, +ILRR Modulation: +MS, +MR, +MA Error control: +ES, +ER, +EB, +ESR, +ETBM Data compression: +DS, +DR V.251
Broadcom 802.11b/g WLAN
Wireless LAN Standards IEEE 802.11b
IEEE 802.11g Interoperability Wi-Fi certified
Cisco Compatible Extensions Program compliant
(details at http://www.hp.com/go/notebooks/WLAN
) Frequency Band 2.4 GHz Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco Aironet infrastructure products through the Cisco Compatible Extensions Program).
Sub-channels Multinational support with frequency bands and channels compliant to
local regulations. Media Access Protocol CSMA/CA (Collision Avoidance) with ACK Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required) Roaming IEEE 802.11 compliant roaming between access points. Output Power (for CKK) Output Power (for
OFDM; power varies by data rate)
2
2
17.5 dBm +/- 1.5 dB
13.5 dBm +/- 1.5 dB
Power Consumption Transmit: 2.0 W (max)
Receive: 1.5 W (max)
Idle mode: 248 mW (nominal)
Sleep mode: 20 mW (max) Power Management ACPI compliant power management
802.11 Compliant Power Saving Mode
Receiver Sensitivity
3
54 Mbps: -72 dBm,1 Mbps: -94 dBm
Antenna type High efficiency dual band antenna with polarization diversity, mounted
in the display enclosure Range 802.11 b – Typical
(@1 Mbps)
802.11 g – Typical
(@1 Mbps)
1200 feet – Outdoor Open Area 300 feet – Indoor, Office environment
1200 feet – Outdoor Open Area 300 feet – Indoor, Office environment
DA – 12135 North America — Version 16 — October 4, 2005 Page 22
QuickSpecs
HP Compaq nx6110 Notebook PC
Technical Specifications
Form Factor MiniPCI Type IIIB Weight 0.026 lb (12 g) Dimensions 0.20 x 1.75 x 2.34 in (4.9 x 44.6 x 59.8 mm) Operating Voltage 3.3v Temperature Operating
Non-operating Humidity Operating
Non-operating Altitude Operating
Non-operating
Configuration Utility
4
Choice of Configuration Utility:
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco Compatible Extensions support)
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4. WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN may also be compatible with certain third-party software supplicants.
32° to 122° F (0° to 50° C)
-14° to 158° F (-10° to 70° C) 10% to 90% (non-condensing)
5% to 95% (non-condensing) 0 to 15,000 ft (4,572 m)
0 to 40,000 ft (12,192 m)
Broadcom 802.11a/b/g WLAN
Wireless LAN Standards IEEE 802.11a
IEEE 802.11b IEEE 802.11g
Interoperability Wi-Fi certified
Cisco Compatible Exensions Program compliant (details at http://www.hp.com/go/notebooks/WLAN
) Frequency Band 2.4 GHz and 5 GHz Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco Aironet infrastructure products through the Cisco Compatible Extensions Program).
Sub-channels Multinational support with frequency bands and channels compliant to
local regulations. Media Access Protocol CSMA/CA (Collision Avoidance) with ACK Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required) Roaming IEEE 802.11 compliant roaming between access points
DA – 12135 North America — Version 16 — October 4, 2005 Page 23
QuickSpecs
Technical Specifications
Output Power (for CKK)217.5 dBm +/- 1.5 dB Output Power (for
OFDM; power varies by data rate)
Power Consumption Transmit: 2.0 W (max)
Power Management ACPI compliant power management
Receiver Sensitivity
Antenna type High efficiency dual band antenna with polarization diversity, mounted
Range 802.11 a – Typical
802.11 b – Typical
802.11 g – Typical
Form Factor MiniPCI Type IIIA Weight 0.035 lb (16 g) Dimensions 0.19 x 2.00 x 2.35 in (4.8 x 50.95 x 59.75 mm) Operating Voltage 3.3v Temperature Operating
Humidity Operating
Altitude Operating
Configuration Utility
2
HP Compaq nx6110 Notebook PC
13.5 dBm +/- 1.5 dB
Receive: 1.5 W (max)
Idle mode: 248 mW (nominal)
Sleep mode: 20 mW (max)
802.11 compliant power saving mode
3
802.11a - 54 Mbps: -70 dBm; 802.11g - 54 Mbps: -72 dBm, 1 Mbps: ­94 dBm
in the display enclosure
1000 feet – Outdoor Open Area
(@6 Mbps)
(@1 Mbps)
(@1 Mbps)
Non-operating
Non-operating
Non-operating
4
Choice of Configuration Utility:
300 feet – Indoor, Office environment 1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment 1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
32° to 122° F (0° to 50° C)
-14° to 158° F (-10° to 70° C) 10% to 90% (non-condensing)
5% to 95% (non-condensing) 0 to 15,000 ft (4,572 m)
0 to 40,000 ft (12,192 m)
Microsoft Windows XP Wireless Network Connection Manager
Broadcom Wireless Configuration Utility (required for Cisco Compatible Extensions support)
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4. WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN may also be compatible with certain third-party software supplicants.
Intel PRO/Wireless 2200BG 802.11b/g WLAN
Wireless LAN Standards IEEE 802.11b
IEEE 802.11g
Interoperability Wi-Fi certified
Cisco Compatible Exensions Program compliant (details at http://www.hp.com/go/notebooks/wlan
DA – 12135 North America — Version 16 — October 4, 2005 Page 24
)
QuickSpecs
Technical Specifications
Frequency Band 2.4 GHz Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
Modulation Direct Sequence Spread Spectrum
Security
Sub-channels Multinational support with frequency bands and channels compliant to
Media Access Protocol CSMA/CA (Collision Avoidance) with ACK Network Architecture
Models Roaming IEEE 802.11 compliant roaming between access points. Output Power (for CKK) Output Power (for
OFDM; power varies by data rate)
Power Consumption Transmit: 1.8 Watts (max)
Power Management ACPI compliant power management
Receiver Sensitivity Antenna type High efficiency dual band antenna with polarization diversity, mounted
Range 802.11 b – Typical
802.11 g – Typical
Form Factor MiniPCI Type IIIB Weight 0.026 lb (11.75 g) (max) Dimensions 0.20 x 1.75 x 2.34 in (4.9 x 44.6 x 59.8 mm) Operating Voltage 3.3v Temperature Operating
Humidity Operating
Altitude Operating
Configuration Utility
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
2
HP Compaq nx6110 Notebook PC
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
DBPSK, DQPSK, CCK, OFDM
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco Aironet infrastructure products through the Cisco Compatible Extensions Program).
local regulations.
Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)
2
16 dBm +/- 2 dB 15 dBm +2/-5 dB
Receive: 1.4 Watts (max) Idle mode: 75 mW (nominal) Sleep mode: 60 mW
802.11 Compliant Power Saving Mode
3
54 Mbps: -72 dBm, 11 Mbps: -88 dBm , 1 Mbps: -97 dBm
in the display enclosure
1200 feet – Outdoor Open Area
(@1 Mbps)
(@1 Mbps)
Non-operating
Non-operating
Non-operating
4
Choice of Configuration Utility:
300 feet – Indoor, Office environment 1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
32° to 158° F (0° to 70° C)
-40° to 176° F (-40° to 80° C) 10% to 90% (non-condensing)
5% to 95% (non-condensing) 0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
Intel PROSet for Microsoft Windows 2000 or XP (required for Cisco Compatible Extensions support)
DA – 12135 North America — Version 16 — October 4, 2005 Page 25
QuickSpecs
HP Compaq nx6110 Notebook PC
Technical Specifications
Microsoft Windows XP Wireless Network Connection Manager
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4. WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN may also be compatible with certain third-party software supplicants.
Intel PRO/Wireless 2915ABG 802.11a/b/g WLAN
Wireless LAN Standards IEEE 802.11a
IEEE 802.11b IEEE 802.11g
Interoperability Wi-Fi certified
Cisco Compatible Exensions Program compliant (details at http://www.hp.com/go/notebooks/WLAN
) Frequency Band 2.4 GHz and 5 GHz Data Rates 802.11b: 1, 2, 5.5, 11 Mbps
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Modulation Direct Sequence Spread Spectrum
DBPSK, DQPSK, CCK, OFDM
Security
1
Supports 64- and 128-bit WEP, WPA, WPA2, hardware-accelerated
AES, 802.1x authentication types EAP-TLS, EAP-TTLS, PEAP-GTC, PEAP-MSCHAPv2, LEAP, EAP-FAST.
Support for Cisco Security Features (proven compatibility with Cisco Aironet infrastructure products through the Cisco Compatible Extensions Program).
Sub-channels Multinational support with frequency bands and channels compliant to
local regulations. Media Access Protocol CSMA/CA (Collision Avoidance) with ACK Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required) Roaming IEEE 802.11 compliant roaming between access points Output Power (for CKK) Output Power (for
OFDM; power varies by data rate)
2
2
16 dBm +/- 2 dB
15 dBm +2/-5 dB
Power Consumption Transmit: 1.8 Watts (max)
Receive: 1.4 Watts (max)
Idle mode: 100 mW (nominal)
Sleep mode: 60 mW (max) Power Management ACPI compliant power management
802.11 Compliant Power Saving Mode
Receiver Sensitivity
3
54 Mbps: -72 dBm, 11 Mbps: -89 dBm , 1 Mbps: -97 dBm
Antenna type High efficiency dual band antenna with polarization diversity, mounted
in the display enclosure Range 802.11 a – Typical
(@6 Mbps)
600 feet – Outdoor Open Area 150 feet – Indoor, Office environment
DA – 12135 North America — Version 16 — October 4, 2005 Page 26
QuickSpecs
Technical Specifications
802.11 b – Typical
802.11 g – Typical
Form Factor MiniPCI Type IIIB Weight 0.026 lb (11.75 gm) (max) Dimensions 0.20 x 1.75 x 2.34 in (4.9 x 44.6 x 59.8 mm) Operating Voltage 3.3v +/- 10% Temperature Operating
Humidity Operating
Altitude Operating
Configuration Utility
HP Compaq nx6110 Notebook PC
1200 feet – Outdoor Open Area
(@1 Mbps)
(@1 Mbps)
Non-operating
Non-operating
Non-operating
4
Choice of Configuration Utility:
Intel PROSet for Microsoft Windows 2000 or XP (required for Cisco Compatible Extensions support)
Microsoft Windows XP Wireless Network Connection Manager
300 feet – Indoor, Office environment 1200 feet – Outdoor Open Area
300 feet – Indoor, Office environment
32° to 176° F (0° to 80° C)
-40° to 176° F (-40° to 80° C) 10% to 90% (non-condensing)
5% to 95% (non-condensing) 0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).
4. WLAN supplier's client utility is required for Cisco Compatible Extensions support. WLAN may also be compatible with certain third-party software supplicants.
Bluetooth by HP
Name HP Integrated module with Bluetooth wireless technology Bluetooth Specification 1.2 Compliant Dimensions 1.02 x 0.55 x 0.22 in (26 x 14 x 5.7 mm) Frequency Band 2402 to 2480 MHz Number of available
channels Data Rates and
throughput
Transmit Power -6 dBm to 4 dBm (Bluetooth Class II) Receiver Sensitivity Better than -80 dBM at 0.1 % raw bit error rate Power Consumption Peak (Tx) 264 mW Peak (Rx) 231 mW Sleep <1 mW Antenna Internally integrated within module Range Up 33 ft (10 m) Electrical Interface USB 1.1 compliant
79 (1 MHz) available channels
1 Mbps data rate; throughput up to 720 Kbps Synchronous Connection Oriented links up to 3, 64 kbps, voice
channels Asynchronous Connection Less links 723.2 kbps/57.6 kbps
asymmetric or 433.9 kbps symmetric
DA – 12135 North America — Version 16 — October 4, 2005 Page 27
QuickSpecs
Technical Specifications
Microsoft Windows Plug and Play compliant OS Support Microsoft Windows XP Professional and Home Microsoft Windows 2000
Supported Link Topology Point to Point, Multipoint Pico Nets up to 7 slaves
Security Full support of Bluetooth Security Provisions Power Management Microsoft Windows ACPI, and USB Bus Support Self configurable to optimize power conservation in all operating
Certifications All necessary regulatory approval s for supported countries, including: FCC (47 CFR) Part 15C, Section 15.247 & 15.249 ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark Temperature Operating -4° to 158° F (-20° to 70° C) Non-operating -40° to 176° F (-40° to 80° C) Humidity Operating 10% to 90% Non-operating 5% to 95% Altitude Operating 15,000 ft (4,572 m) Non-operating 40,000 ft (12,192 m) Bluetooth Profiles
Supported
FAX Profile (FAX) Basic Imaging Profile (BIP) Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)
*
indicates the profile is also supported by Microsoft Windows XP SP2
HP Compaq nx6110 Notebook PC
Widcomm Bluetooth for Windows Bluetooth Software Microsoft Windows XP Bluetooth Software
modes, including Standby, Hold, Park, and Sniff
(with Bluetooth for Windows 4.0 software) Serial Port Profile (SPP)* Dial-Up Networking (DUN)* Generic Object Exchange Profile (GOEP) Object Push Profile (OPP)* File Transfer Profile (FTP) Synchronization Profile (SYNC) Hard Copy Cable Replacement (HCRP)* Personal Area Networking Profile (PAN)* Human Interface Device Profile (HID)*
Copyright © 2005 Hewlett-Packard Development Company, L.P.
All rights reserved. Microsoft, Windows and Windows XP are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. Pentium, Celeron, Centrino, and SpeedStep are registered trademarks or trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth is a registered trademar k of Bluetooth SIG, Inc., in the U.S. and other countries. All other product names mentioned herein may be trademarks of their respective companies.
DA – 12135 North America — Version 16 — October 4, 2005 Page 28
QuickSpecs
HP Compaq nx6110 Notebook PC
Technical Specifications
The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
DA – 12135 North America — Version 16 — October 4, 2005 Page 29
Loading...
