HP NC360T PCI Express Dual Port Gigabit
J
Server Adapter
User Guide
Part Number 432551-00B
une 2007 (Second Edition)
© Copyright 2006, 2007 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP
shall not be liable for technical or editorial errors or omissions contained herein.
Audience assumptions
This document is for the person who installs, administers, and troubleshoots servers and storage systems. HP assumes you are qualified in the
servicing of computer equipment and trained in recognizing hazards in products with hazardous energy levels.
Contents
Technician notes........................................................................................................................... 4
Where to go for additional help.................................................................................................................. 5
HP contact information..................................................................................................................... 5
Introduction.................................................................................................................................. 6
Overview ................................................................................................................................................. 6
UTP CAT5 cable ....................................................................................................................................... 6
LED indicators........................................................................................................................................... 6
Installing an adapter ..................................................................................................................... 8
Installation overview .................................................................................................................................. 8
Preventing electrostatic discharge................................................................................................................ 8
Installing a low profile bracket .................................................................................................................... 9
Installing an adapter in a server .................................................................................................................. 9
Connecting the network cable................................................................................................................... 10
Specifications............................................................................................................................. 11
HP NC360T PCI Express Dual Port Gigabit Server Adapter specifications ...................................................... 11
UTP cable specifications........................................................................................................................... 12
RJ-45 pinouts and crossover function.......................................................................................................... 12
10/100 pinouts using internal, straight-through crossover................................................................... 12
10/100 pinouts using external crossover through twisted-pair media ................................................... 13
Gigabit over copper pinouts using internal crossover for RJ-45 ............................................................ 14
Gigabit over copper pinouts using external crossover through twisted pair media .................................. 15
Regulatory compliance notices ..................................................................................................... 17
Regulatory compliance identification numbers............................................................................................. 17
Federal Communications Commission notice............................................................................................... 17
Class A equipment ..................................................................................................................................17
Class B equipment................................................................................................................................... 18
Declaration of conformity for products marked with the FCC logo, United States only....................................... 18
Modifications.......................................................................................................................................... 18
Canadian notice (Avis Canadien).............................................................................................................. 19
European Union regulatory notice .............................................................................................................19
Japanese notice ...................................................................................................................................... 20
Korean class A notice .............................................................................................................................. 20
Korean class B notice............................................................................................................................... 20
BSMI notice............................................................................................................................................ 20
Disposal of waste equipment by users in private households in the European Union......................................... 21
Electrostatic discharge................................................................................................................. 22
Preventing electrostatic discharge.............................................................................................................. 22
Grounding methods to prevent electrostatic discharge.................................................................................. 22
Acronyms and abbreviations........................................................................................................ 23
Index......................................................................................................................................... 25
Contents 3
Technician notes
In this section
Where to go for additional help ................................................................................................................ 5
WARNING: Only authorized technicians trained by HP should attempt to repair this
equipment. All troubleshooting and repair procedures are detailed to allow only
subassembly/module-level repair. Because of the complexity of the individual boards and
subassemblies, no one should attempt to make repairs at the component level or to make
modifications to any printed wiring board. Improper repairs can create a safety hazard.
WARNING: To reduce the risk of electric shock, personal injury, and damage to the
equipment:
• Do not attempt to service any parts of the equipment other than those specified in the
following procedure. Any other activities may require that you shut down the server and
remove the power cord.
• Installation and maintenance of this product must be performed by individuals who are
knowledgeable about the procedures, precautions and hazards associated with the
product.
WARNING: To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding plug. The grounding plug is an important safety
feature.
• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all
times.
• Unplug the power cord from the power supply to disconnect power to the equipment.
• Do not route the power cord where it can be walked on or pinched by items placed against
it. Pay particular attention to the plug, electrical outlet, and the point where the cord
extends from the server.
CAUTION: To properly ventilate the system, you must provide at least 7.6 cm (3.0 in) of
clearance at the front and back of the server.
CAUTION: The server is designed to be electrically grounded (earthed). To ensure proper
operation, plug the AC power cord into a properly grounded AC outlet only.
NOTE: Any indications of component replacement or printed wiring board modifications may
void any warranty.
Technician notes 4
Where to go for additional help
1. Go to the HP website (http://www.hp.com).
2. Click Software & Driver Downloads from the left menu bar.
3. Type the product name in the For product box and press Enter. For example, type NC370T.
4. Download the drivers, firmware, or documentation as needed.
HP contact information
For the name of the nearest HP authorized reseller:
• In the United States, see the HP US service locator webpage (http://www.hp.com/service_locator).
• In other locations, see the Contact HP worldwide (in English) webpage
(http://welcome.hp.com/country/us/en/wwcontact.html
For HP technical support:
• In the United States, for contact options see the Contact HP United States webpage
(http://welcome.hp.com/country/us/en/contact_us.html
o Call 1-800-HP-INVENT (1-800-474-6836). This service is available 24 hours a day, 7 days a
week. For continuous quality improvement, calls may be recorded or monitored.
o If you have purchased a Care Pack (service upgrade), call 1-800-633-3600. For more
information about Care Packs, refer to the HP website (http://www.hp.com
• In other locations, see the Contact HP worldwide (in English) webpage
(http://welcome.hp.com/country/us/en/wwcontact.html
).
). To contact HP by phone:
).
).
Technician notes 5
Introduction
In this section
Overview ................................................................................................................................................ 6
UTP CAT5 cable ...................................................................................................................................... 6
LED indicators.......................................................................................................................................... 6
Overview
The HP NC360T PCI Express Dual Port Gigabit Server Adapter is a high-performance, low-profile, PCA
PCI Express Ethernet adapter that delivers up to 1000 Mb/s Ethernet over twisted-pair (copper) category
5 or better cabling. It is powered by an Intel 82571EB chipset. The NC360T adapter, which ships with a
standard-height chassis bracket and also includes a low-profile chassis bracket, has a fully integrated
controller capable of auto-negotiating a link at 10, 100, or 1000 Mb/s. Network connection is made
through the two RJ-45 connectors. LED indicators show the link speed and activity. See LED indicators (on
page 6) for details. The adapter is a supported option for selected HP ProLiant servers. The adapter must
be installed in a PCI Express slot.
For the latest functionality, features, and operating system support for this adapter, see the HP website
(http://h18004.www1.hp.com/products/servers/networking/index-nic.html
UTP CAT5 cable
The NC360T adapter can use existing UTP CAT5 (or better) cable to deliver Gigabit Ethernet over
copper, according to the IEEE 802.3ab specifications. For new installations, CAT5e (enhanced CAT5)
cable is recommended.
For troubleshooting and other information about cabling, see UTP Cable Specifications (on page 12).
LED indicators
The NC360T adapter has two auto-negotiating 10/100/1000 RJ-45 ports. LED indicators show
activity/link and port speed. Standard-height and low-profile brackets are shown below with RJ-45 ports
and LED indicators.
).
Introduction 6
The NC360T Gigabit Server Adapter LED indicators operate as described in the following table.
LED indicator Status Description
Activity/Link On This mono-color green LED indicates that the
link to the adapter is established. The adapter is
receiving power and the cable connection is
working.
Speed Off The adapter is connected at 10 Mb/s.
Off No link to the adapter is established. The
adapter is not receiving power or the cable
connection is faulty.
Flashing The adapter is sending or receiving network
data at 10/100/1000 Mb/s, as indicated by
the 10/100/1000 (speed) LED. The adapter is
receiving power, and the cable connection is
working.
Green The adapter is connected at 100 Mb/s.
Orange The adapter is connected at 1000 Mb/s.
Introduction 7
Installing an adapter
In this section
Installation overview ................................................................................................................................. 8
Preventing electrostatic discharge............................................................................................................... 8
Installing a low profile bracket................................................................................................................... 9
Installing an adapter in a server................................................................................................................. 9
Connecting the network cable.................................................................................................................. 10
Installation overview
This section describes installation precautions, how to install the adapter, and how to connect the network
cable.
WARNING: To reduce the risk of personal injury or damage to the equipment, consult the
safety information and user documentation provided with the server before attempting the
installation.
Many servers are capable of providing energy levels that are considered hazardous and are
intended to be serviced only by qualified personnel who have been trained to deal with these
hazards. Do not remove enclosures or attempt to bypass any interlocks that may be provided
for the purpose of removing these hazardous conditions.
WARNING: Installation of this adapter should be performed by individuals who are both
qualified in the servicing of computer equipment, and trained in the hazards associated with
products capable of producing hazardous energy levels.
This adapter is intended to be installed in Certified (UL or CSA) ITE equipment having
instructions for adding and removing user installed components such as PCI, PCI-X, and PCI
Express devices. Refer to the equipment instructions to verify that it is suitable for user installed
components and that it has the power capacity to support all of the installed components.
NOTE: Before removing the cover of your server, refer to the HP documentation for the proper
methods for installing a PCI Express card and avoiding electric shock hazards.
Preventing electrostatic discharge
To prevent damaging the system, be aware of the precautions you need to follow when setting up the
system or handling parts. A discharge of static electricity from a finger or other conductor may damage
system boards or other static-sensitive devices. This type of damage may reduce the life expectancy of the
device.
To prevent electrostatic damage:
• Avoid hand contact by transporting and storing products in static-safe containers.
• Keep electrostatic-sensitive parts in their containers until they arrive at static-free workstations.
Installing an adapter 8
• Place parts on a grounded surface before removing them from their containers.
• Avoid touching pins, leads, or circuitry.
• Always be properly grounded when touching a static-sensitive component or assembly.
Installing a low profile bracket
You may have to install a low profile bracket to complete the product installation. The low profile bracket
replaces the existing standard profile bracket shipped on the product.
To install a low profile bracket:
1. Using a correctly sized slotted screwdriver, carefully remove the two board lock screws located at
the top and bottom of the connector.
2. Remove the standard profile bracket and place the low profile bracket over the connector. Be careful
not to damage the connector or bind the low profile bracket to the connector.
Installing an adapter in a server
The NC360T can be installed in a standard or low-profile PCI Express slot. The kit includes brackets for
both slot types. See the HP ProLiant server documentation for additional information on how to safely
install a PCI Express card in the server.
1. Power down the server, unplug the power cord from the power outlet, and then remove the server
access panel.
2. Remove the expansion slot cover from a PCI Express slot.
WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the
internal system components to cool before touching them.
3. Firmly seat the adapter in a PCI Express slot and secure the adapter bracket.
4. Replace the access panel and plug in the power cord.
Installing an adapter 9
Connecting the network cable
To secure the cable, plug the cable connector into the RJ-45 port. Ensure that the tab on the plug clicks
into position indicating that it is properly seated.
For more information, see UTP cable specifications (on page 12).
Installing an adapter 10
Specifications
In this section
HP NC360T PCI Express Dual Port Gigabit Server Adapter specifications..................................................... 11
UTP cable specifications.......................................................................................................................... 12
RJ-45 pinouts and crossover function ........................................................................................................ 12
HP NC360T PCI Express Dual Port Gigabit Server Adapter specifications
Specification Value
Network Controller Chipsets Intel® 82571EB Dual MAC/PHY
Bus Type x4 PCI Express v1.0a
Bus Width Four lane
Clock Speed 100 MHz
On-board Memory 96 KB
Data Transfer Method Bus Master DMA
Boot ROM Support Yes
Management Capabilities WOL, PXE 2.2, ACPI 1.1a
Power Requirement 1280 mA @ 3.3 VDC max
Data Transmission Rate 10 Full/10 Half, 100 Full/100 Half, 1000 Full
Standards Supported IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x (flow control), IEEE
802.3ad (link aggregation), IEEE 802.1p (QoS), IEEE 802.1q (VLAN tagging)
Dimensions 12.95 cm x 6.86 cm [5.1 in x 2.7 in (L x W)] (without bracket)
Connector and Distances 10BASE-T: Category 3, 4, or 5 UTP 100 M (328 ft)
100BASE-TX: CAT5 UTP 100 M (328 ft)
1000BASE-TX: CAT5 UTP 100 M (328 ft)
Interrupts Supported Automatically configured
Temperature Range Operating: 0°C to 55°C (32°F to 131°F)
Storage: -30°C to 60°C (-22°F to 140°F)
Relative Humidity (non-
condensing)
Safety Compliance UL Mark (US and Canada)
Operating: 20% to 75%
Storage: 20% to 80%
CE Mark
EN 60590
RoHS (European Union)
Specifications 11
UTP cable specifications
The NC360T adapter can use existing UTP CAT5 (or better) cable to deliver Gigabit Ethernet over
copper, according to the IEEE 802.3ab specifications. For new installations, CAT5e (enhanced CAT5)
cable is recommended.
Maximum distances for Gigabit over copper cable are 100 meters (328 feet).
To connect to the network, the NC360T uses the following cable for 1000Base-T transmission:
• CAT5 UTP or better twisted-pair
• 22-26 AWG, 100Ω @ 1 MHz
• EIA/TIA 568a or EIA/TIA 568b
RJ-45 pinouts and crossover function
The Ethernet standard also specifies that each segment implement a crossover function to connect the
transmitter of one device to the receiver of a device at the other end, and vice-versa. The crossover
10/100 pinouts using internal, straight-through crossover
function may be implemented internally at the hub or switch or externally through the twisted-pair media.
If the crossover function is implemented internally, the port is labeled MDI-X (Medium Dependent InterfaceCrossover). When an MDI-X port is connected to an MDI port, the twisted pair media should be wired
straight-through using the physical pinouts indicated.
Pin Function Color match Function Pin
1 TD+ Orange TD+ 1
2 TD- Orange/White TD- 2
3 RD+ Green RD+ 3
4
5
Blue/White
Blue
4
5
6 RD- Green/White RD- 6
7
8
Brown
Brown/White
7
8
Specifications 12
10/100 pinouts using external crossover through twisted-pair media
When the crossover function is not provided within the hub or switch, you must implement the crossover
through the twisted-pair media using the physical pinouts indicated.
Pin Function Color match Function Pin
1 TD+ Orange RD+ 3
2 TD- Orange/White RD- 6
3 RD+ Green TD+ 1
4
5
6 RD- Green/White TD- 2
7
8
Blue/White
Blue
Brown
Brown/White
Specifications 13
Gigabit over copper pinouts using internal crossover for RJ-45
Unlike connections in which the crossover function is implemented internally at the hub or switch, the
NC360T provides its own automatic crossover function. This means you can wire twisted-pair media
straight-through for adapter-to-hub, adapter-to-switch, or adapter-to-adapter connections using the pinouts
indicated.
NOTE: To operate at Gigabit speeds, all four pairs of wires must be terminated within the RJ-
Pin Function Color match Function Pin
1 BI_DA+ Orange BI_DA+ 1
2 BI_DA- Orange/White BI_DA- 2
3 BI_DB+ Green BI_DB+ 3
4 BI_DC+ Blue/White BI_DC+ 4
5 BI_DC- Blue BI_DC- 5
6 BI_DB- Green/White BI_DB- 6
7 BI_DD+ Brown BI_DD+ 7
8 BI_DD- Brown/White BI_DD- 8
45 connector.
Specifications 14
Gigabit over copper pinouts using external crossover through twisted pair media
When a crossover function is not provided by the adapter, hub or switch, you must implement it through
the twisted-pair media using the physical pinouts indicated.
Pin Function Color match Function Pin
1 BI_DA+ Orange BI_DB+ 3
2 BI_DA- Orange/White BI_DB- 6
3 BI_DB+ Green BI_DA+ 1
4 BI_DC+ Blue/White BI_DD+ 7
5 BI_DC- Blue BI_DD- 8
6 BI_DB- Green/White BI_DA- 2
7 BI_DD+ Brown BI_DC+ 4
8 BI_DD- Brown/White BI_DC- 5
Specifications 15
Specifications 16
Regulatory compliance notices
In this section
Regulatory compliance identification numbers ........................................................................................... 17
Federal Communications Commission notice ............................................................................................. 17
Class A equipment ................................................................................................................................. 17
Class B equipment.................................................................................................................................. 18
Declaration of conformity for products marked with the FCC logo, United States only..................................... 18
Modifications......................................................................................................................................... 18
Canadian notice (Avis Canadien) ............................................................................................................ 19
European Union regulatory notice ............................................................................................................ 19
Japanese notice ..................................................................................................................................... 20
Korean class A notice ............................................................................................................................. 20
Korean class B notice.............................................................................................................................. 20
BSMI notice........................................................................................................................................... 20
Disposal of waste equipment by users in private households in the European Union....................................... 21
Regulatory compliance identification numbers
For the purpose of regulatory compliance certifications and identification, this product has been assigned
a unique regulatory model number. The regulatory model number can be found on the product nameplate
label, along with all required approval markings and information. When requesting compliance
information for this product, always refer to this regulatory model number. The regulatory model number is
not the marketing name or model number of the product.
Federal Communications Commission notice
Part 15 of the Federal Communications Commission (FCC) Rules and Regulations has established Radio
Frequency (RF) emission limits to provide an interference-free radio frequency spectrum. Many electronic
devices, including computers, generate RF energy incidental to their intended function and are, therefore,
covered by these rules. These rules place computers and related peripheral devices into two classes, A
and B, depending upon their intended installation. Class A devices are those that may reasonably be
expected to be installed in a business or commercial environment. Class B devices are those that may
reasonably be expected to be installed in a residential environment (for example, personal computers).
The FCC requires devices in both classes to bear a label indicating the interference potential of the device
as well as additional operating instructions for the user.
Class A equipment
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. Operation of this equipment in a
Regulatory compliance notices 17
residential area is likely to cause harmful interference, in which case the user will be required to correct
the interference at personal expense.
Class B equipment
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit that is different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio or television technician for help.
Declaration of conformity for products marked with the FCC logo, United States only
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
For questions regarding this product, contact us by mail or telephone:
• Hewlett-Packard Company
P. O. Box 692000, Mail Stop 530113
Houston, Texas 77269-2000
• 1-800-HP-INVENT (1-800-474-6836). (For continuous quality improvement, calls may be recorded
or monitored.)
For questions regarding this FCC declaration, contact us by mail or telephone:
• Hewlett-Packard Company
P. O. Box 692000, Mail Stop 510101
Houston, Texas 77269-2000
• 1281-514-3333
To identify this product, refer to the part, series, or model number found on the product.
Modifications
The FCC requires the user to be notified that any changes or modifications made to this device that are
not expressly approved by Hewlett-Packard Company may void the user’s authority to operate the
equipment.
Regulatory compliance notices 18
Canadian notice (Avis Canadien)
Class A equipment
This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
Class B equipment
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment
Regulations.
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel
brouilleur du Canada.
European Union regulatory notice
This product complies with the following EU Directives:
• Low Voltage Directive 2006/95/EC
• EMC Directive 2004/108/EC
Compliance with these directives implies conformity to applicable harmonized European standards
(European Norms) which are listed on the EU Declaration of Conformity issued by Hewlett-Packard for this
product or product family.
This compliance is indicated by the following conformity marking placed on the product:
This marking is valid for non-Telecom products and EU harmonized Telecom products (e.g. Bluetooth).
This marking is valid for EU non-harmonized Telecom products.
*Notified body number (used only if applicable—refer to the product label)
Hewlett-Packard GmbH, HQ-TRE, Herrenberger Strasse 140, 71034 Boeblingen, Germany
Regulatory compliance notices 19
Japanese notice
Korean class A notice
Korean class B notice
BSMI notice
Regulatory compliance notices 20
Disposal of waste equipment by users in private households in the European Union
This symbol on the product or on its packaging indicates that this product must not be disposed of with
your other household waste. Instead, it is your responsibility to dispose of your waste equipment by
handing it over to a designated collection point for the recycling of waste electrical and electronic
equipment. The separate collection and recycling of your waste equipment at the time of disposal will
help to conserve natural resources and ensure that it is recycled in a manner that protects human health
and the environment. For more information about where you can drop off your waste equipment for
recycling, please contact your local city office, your household waste disposal service or the shop
where you purchased the product.
Regulatory compliance notices 21
Electrostatic discharge
In this section
Preventing electrostatic discharge............................................................................................................. 22
Grounding methods to prevent electrostatic discharge ................................................................................ 22
Preventing electrostatic discharge
To prevent damaging the system, be aware of the precautions you need to follow when setting up the
system or handling parts. A discharge of static electricity from a finger or other conductor may damage
system boards or other static-sensitive devices. This type of damage may reduce the life expectancy of the
device.
To prevent electrostatic damage:
• Avoid hand contact by transporting and storing products in static-safe containers.
• Keep electrostatic-sensitive parts in their containers until they arrive at static-free workstations.
• Place parts on a grounded surface before removing them from their containers.
• Avoid touching pins, leads, or circuitry.
• Always be properly grounded when touching a static-sensitive component or assembly.
Grounding methods to prevent electrostatic discharge
Several methods are used for grounding. Use one or more of the following methods when handling or
installing electrostatic-sensitive parts:
• Use a wrist strap connected by a ground cord to a grounded workstation or computer chassis. Wrist
straps are flexible straps with a minimum of 1 megohm ±10 percent resistance in the ground cords.
To provide proper ground, wear the strap snug against the skin.
• Use heel straps, toe straps, or boot straps at standing workstations. Wear the straps on both feet
when standing on conductive floors or dissipating floor mats.
• Use conductive field service tools.
• Use a portable field service kit with a folding static-dissipating work mat.
If you do not have any of the suggested equipment for proper grounding, have an authorized reseller
install the part.
For more information on static electricity or assistance with product installation, contact an authorized
reseller.
Electrostatic discharge 22
Acronyms and abbreviations
ACPI
Advanced Configuration and Power Interface
APM
advanced power management
CSA
Canadian Standards Association
DMA
direct memory access
IEEE
Institute of Electrical and Electronics Engineers
LED
light-emitting diode
MDI
medium dependent interface
MDI-X
medium dependent interface-crossover
NIC
network interface controller
PCI Express
Peripheral Component Interconnect Express
PXE
Preboot Execution Environment
RoHS
Restriction of Hazardous Substances
Acronyms and abbreviations 23
UTP
unshielded twisted pair
VDC
voltage direct-current
WOL
Wake-on LAN
Acronyms and abbreviations 24
Index
C
cable configuration 11
cable connectors 11
cable, Ethernet crossover 11
cables, networking 9
cautions 3
E
electrostatic discharge 7, 21
F
features 5
G
grounding methods 21
I
installation overview 7
installing adapters 8
N
NIC LEDs 5
R
regulatory compliance notices 16
RJ-45 connectors 11, 12, 13, 14
S
specifications 10
U
UTP CAT5 cable 11
Index 25
Loading...
