HP M610dn Data sheet

Data sheet
HP LaserJet Enterprise M610dn
This HP LaserJet with JetIntelligence combines performance, energy efficiency, and security.
This HP LaserJet Printer with JetIntelligence combines exceptional performance and energy efficiency with professional-quality documents right when you need them—all while protecting your network from attacks with the industry’s deepest security.
The worlds most secure printing
High-speed performance meets energy efficiency
Speed through tasks and save paper. Print two-sided documents nearly as fast as single-sided. This printer wakes up and prints your first page fast—in as quickly as 7.8 seconds. This printer uses low amounts of energy thanks to its innovative design and toner technology. Easily manage print jobs directly at the printer—just tap and swipe the 4.3-inch (10.9 cm) color touchscreen.
Performance and protection you can count on
Produce sharp text, bold blacks, and crisp graphics with precision black toner. Help retain the Original HP quality you paid for with anti-fraud and cartridge authentication technology. Spend less time replacing toner, and more on business. Choose high-yield toner cartridges.
Dynamic security enabled printer. Only intended to be used with cartridges using an HP original chip. Cartridges using a non-HP chip may not work, and those that work today may not work in the future. Learn more at http://www.hp.com/go/learnaboutsupplies
1
1
1
2
4
5
Data sheet | HP LaserJet Enterprise M610dn
Series at a glance
Product walkaround
Hardware Integration Pocket
10.9 cm (4.3-inch) colour touchscreen control panel
Easy-access USB port
100-sheet multipurpose tray 1
Front door access to toner cartridges
550-sheet input tray 2
1
500-sheet output bin
Automatic two-sided printing
Host USB port
Gigabit Ethernet network port
Hi-Speed USB 2.0 printing port
Slot for cable-
H
P LaserJet Enterprise M610dn shown
type security lock
Rear I/O panel close-up
M610dn
Part number 7PS82A
Print speeds (A4)2 Up to 52 ppm
Control panel 10.9 cm (4.3-inch) colour touchscreen
Automatic two-sided printing
Hardware Integration Pocket1
100-sheet tray 1, 550-sheet tray 2
550-sheet paper feeder3 Optional (up to four)
2,100-sheet paper feeder3 Optional
Envelope feeder Optional (up to two)
Printer stand Optional
5-bin stapler/stacker/mailbox with job offset Optional
Direct mobile printing Optional wireless direct4/NFC5
Wireless networking Optional6
HP High-Performance Secure Hard Disk Optional
1
Solutions deployed through the Hardware Integration Pocket (HIP) may require additional purchase.
2
Measured usin g ISO/IEC 24734; excludes first set of t est documents. For more informati on, see hp.com/go/printercla ims. Exact speed varies depending on the system configuration, software application, driver, and
document complexity..
3
All models come standard with the 100-sheet multipurpose tray and 550-sheet tray 2. The HP Las erJet Enterprise M611x and M612x models come with on e additional 550 -sheet paper feed er standard, and can add up to three additional optional 550-sheet paper feeders and th e optional 2,100-sheet paper feeder. The M610dn, M611dn, and M612dn models can add up to four additional optional 550-sheet paper feeders and the optional 2,100-sheet paper feeder.
4
Wi-Fi Direct prin ting is embedded in the HP LaserJet Enterp rise M611x and M612x models. All other models can add wireless direct with the purchase of the optional HP Jetdirect 3000w NFC/Wireless Direct Accessory. Mobile device n eeds to be connected directly to the si gnal of a Wi-Fi Direct® supported MFP or printer prior to printing. Depending on mobile device, an app or driver may also be required. For details, see hp.com/go/mobileprinting. Wi-Fi Direct is a registered trad emark of Wi-Fi Alliance.
5
Touch-to-print capability is optional for all models (except M611x and M612x) with purchase of the optional HP Jetdirect 3000w NFC/Wireless Direct Accessory. Mobi le device must support Near Field Commun ication (NFC)-enabled pri nting. For more information, see hp.com/go/businessmobileprinting.
6
All models can add wireless networ king with the purchase of the option al HP Jetdirect 2900nw Print Server. Wi reless performance is dependent on physical environment and distance from access point, and may be limited during active VPN connections.
7
Bluetooth Low En ergy is standard only on the HP LaserJet En terprise M611x and M612x models , and it cannot be added to other models. Bluetooth is a trademark owned by its proprietor and used by HP Inc. under license.
  
Data sheet | HP LaserJet Enterprise M610dn
Technical specifications
Product name HP LaserJet Enterprise M610dn Product number 7PS82A Functions Print Print Duplex printing Automatic (standard) Print speed Black (A4, normal) Up to 52 ppm; Black (A4, duplex): Up to 43 ipm; Black (letter, normal): Up to 55 ppm; Black (letter, duplex): Up to 45 ipm; First page out Black (A4, ready): As fast as 5.1 sec; Black (A4, sleep): As fast as 7.9 sec in mm Print technology Laser Print resolution Black (best): Up to 1200 x 1200 dpi; Black (normal): FastRes 1200 Print resolution technology Normal FastRes 1200; Fine Lines (1200 x 1200 dpi), Quickview (300 x 300 dpi), Economode (600 x 600 dpi) Print cartridges number 1 (black) Standard print languages HP PCL 6, HP PCL 5, HP postscript level 3 emulation, native PDF printing (v 1.7), Apple AirPrint™
Printer management
HP Printer Assistant, HP Device Toolbox, HP Web JetAdmin Software, HP JetAdvantage Security Manager, HP SNMP Proxy Agent, HP WS Pro Proxy Agent, Printer Administrator Resource Kit for
HP Universal Print Driver (Driver Configuration Utility - Driver Deployment Utility - Managed Printing Administrator); Connectivity Standard connectivity 1 Hi-Speed USB 2.0 Device; 2 Hi-Speed USB 2.0 Host; 1 Gigabit Ethernet 10/100/1000T network; 1 Hardware Integration Pocket Mobile printing capability HP ePrint; Apple AirPrint™; Mopria™ Certified; Google Cloud Print™; ROAM optional for easy printing
Wireless capability
Optional, enabled with purchase of a wireless hardware accessory. Single band Wireless Station and Wi-Fi Direct functionality available with HP Jetdirect 3000w NFC/Wireless Accessory J8030A,
Dual band Wireless Station and Wi-Fi Direct functionality available with HP Jetdirect 3100w BLE/NFC/Wireless Accessory 3JN69A, Dual band Wireless Station functionality available with HP
Jetdirect 2900nw Print Server J8031A
Network capabilities
Yes, via HP Jetdirect Ethernet embedded print server (standard) which supports: 10Base-T, 100Base-Tx, 1000Base-T; 802.3az (EEE) support on Fast Ethernet and Gig Links; IPsec (standard);
802.11a/b/g/n wireless networking (optional). Memory Standard: 512 MB; Maximum: 1.5 GB, MAX memory, when 1GB Accessory DIMM is installed Hard disk Optional, 500 GB (with accessory B5L29A) Processor speed 1.2 GHz Warm-up time 130 sec Paper handling Duty cycle (monthly) Duty cycle (monthly, A4): Up to 250,000 pages; Recommended monthly page volume: 5000 to 20,000
Input capacity
100-sheet multipurpose feeder, 550-sheet input feeder; Optional 1x550-sheet paper feeder, optional 1x550 paper feeder and stand with cabinet, optional 3x550-sheet paper feeder and stand,
optional high-capacity paper feeder and stand with 1x550 sheet feeder and 1x2,000-sheet feeder Output capacity 500 sheet output bin Number of paper trays Standard: 2; Maximum: Up to 6 Media types Paper (plain, light, bond, recycled, heavy, extra heavy, cardstock, pre-printed, pre-punched, colored, rough, heavy rough), mono transparency, labels, letterhead, envelope, heavy envelope Media weight Feeder 1: 60 to 200 g/m²; feeder 2: 60 to 120 g/m²; Automatic Duplexer: 60 to 120 g/m²
Media size
Custom (metric): 100-sheet multipurpose Tray 1: 76 x 127 to 216 to 356 mm; 550-sheet input Tray 2: 99 x 148 to 216 x 356 mm; 550-sheet optional feeder: 99 x 148 to 216 x 356 mm; 75-
sheet envelope feeder: 90 x 148 to 178 x 254 mm; Supported (metric): 100-sheet multipurpose Tray 1: A4, A5, A6, RA4, B5 (JIS), B6 (JIS), 10 x 15 cm, Oficio (216 x 340), 16K (195 x 270), 16K
(184 x 260), 16K (197 x 273), Postcard (JIS), Dpostcard (JIS), Envelope: B5, C5, C6, DL; 550-sheet input Tray 2: A4, A5, A6, RA4, B5 (JIS), B6 (JIS), 10 x 15 cm, Oficio (216 x 340), 16K (195 x 270),
16K (184 x 260), 16K (197 x 273), Postcard (JIS), Dpostcard (JIS); 550-sheet optional feeder: A4, A5, A6, RA4, B5 (JIS), B6 (JIS), 10 x 15 cm, Oficio (216 x 340), 16K (195 x 270), 16K (184 x 260),
16K (197 x 273), Postcard (JIS), Dpostcard (JIS); 2000-sheet optional HCI: A4; 75-sheet optional envelope feeder: B5, C5, C6, DL Printer dimensions (W x D x H) 431 x 466 x 380 mm Printer weight 21.6 kg Software included No software solutions are included in the Box, only on http://hp.com, http://123.hp.com; What's in the box HP LaserJet Multifunction Printer; HP Black Original LaserJet Toner Cartridge (~10.5K yield); Documentation (Hardware Install Guide, Regulatory Flyer); Power cord.
Warranty
One-year warranty. Warranty and support options vary by product, country and local legal requirements. Go to http://www.hp.com/support to learn about HP award winning service and support
options in your region. Systems
Compatible operating systems
Windows Client OS (32/64 bit)-, Win10, Win8.1, Win7 Ultimate, Mobile OS-, iOS, Android, Mac-, Apple® macOS Sierra v10.13, Apple® macOS High Sierra v10.14, Apple® macOS Mojave v10.15,
Discrete PCL6 Printer Driver-, For more information on the supported operating systems go to http://support.hp.com, Enter your product name and search, Click on User Guides and enter your
product name and search for User Guide, Search for your (Product Name) - User Guide, Search for the Supported Operating Systems section, UPD PCL6 / PS Printer Drivers-, For more
information on the supported operating systems go to http://support.hp.com, Enter your product name and search, Click on User Guides and enter your product name and search for User Guide,
Search for your (Product Name) - User Guide, Search for the Supported Operating Systems section, UPD PCL6 / PS Printer Drivers, Supported Operating systems, For more information on the
supported operating systems see www.hp.com/go/upd;
Minimum system requirements
Windows: 2 GB available hard disk space, Internet connection, or USB port, Internet browser. For additional OS hardware requirements see microsoft.com; Mac: 2 GB available hard drive space,
Internet connection, or USB port, Internet browser. For additional OS hardware requirements see apple.com
Security management
Identity management: Kerberos authentication; LDAP authentication; 1000 user PIN codes; optional HP and 3rd party advanced authentication solutions (e.g.; badge readers); Network:
IPsec/firewall with Certificate; Pre-Shared Key; and Kerberos authentication; Supports WJA-10 IPsec configuration Plug-in; 802.1X authentication (EAP-PEAP; EAP-TLS); SNMPv3; HTTPS;
Certificates; Access Control List; Data: Storage Encryption; Encrypted PDF & Email (uses FIPS 140 validated cryptographic libraries from Microsoft); Secure Erase; SSL/TLS (HTTPS); Encrypted
Credentials; Device: Security lock slot; USB port disablement; hardware integration pocket for security solutions; Intrusion Detection with Red Balloon Security Technology - Constant in-device
monitoring for attacks; SureStart Secure Boot - BIOS Integrity Checking with self-healing capability; Whitelisting - loads only known good code (DLLs, EXEs, ...); Security management: Compatible
with HP JetAdvantage Security Manager, Device Security Syslog Messages processed and accessable in Arcsight and Splunk SIEMs
Fonts and typefaces
105 internal TrueType fonts scalable in HP PCL, 92 internal scalable fonts in HP postscript level 3 emulation (Euro symbol built-in); 1 internal Unicode Fonts (Andale Mono WorldType); 2 Internal
Windows Vista 8 Fonts (Calibri, Cambria); Additional font solutions available via third-party flash memory cards; HP LaserJet Fonts and IPDS Emulation available at
http://www.hp.com/go/laserjetfonts Control panel 4.3-in (10.92 cm) Color Graphics Display (CGD) with touchscreen; rotating (adjustable angle) display; Home button Display 4.3-in (10.92 cm) Color Graphics Display (CGD) with touchscreen; rotating (adjustable angle) display
Power
Requirements: 100V - 127V nominal @ +/-10% (min 90V, max 140V); 50 - 60Hz nominal +/- 3Hz (min 47Hz, max 63Hz), 12 A; 220V - 240V nominal, @ +/-10% (min 198V, Max 264V); 50 -
60Hz nominal +/- 3Hz (min 47Hz, max 63Hz), 6 A; Consumption: 775 watts (printing), 14.98 watts (ready), 4.28 watts (sleep), < 0.1 watts (Auto Off/Manual On), < 0.1 watts (Manual Off); Typical
Electricity Consumption (TEC) : Blue Angel: 2.113 kWh/Week; Energy Star: 0.621 kWh/Week; Power supply type: Built in 115V or 220V Power Supply (Not dual voltage, power supply varies by
part number with # Option code identifier)
Operating environment
Operating temperature range: 10 to 32.5°C; Recommended operating temperature range: 15 to 27°C
Operating humidity range: 10 to 80% RH; Recommended operating humidity range: 30 to 70% RH Acoustics Acoustic power emissions: 6.9 B(A); Acoustic power emissions (ready): Inaudible; Acoustic pressure emissions: 55 dB(A); Acoustic pressure emissions bystander (ready): Inaudible
Safety approvals and requirements
IEC 60950-1:2005 +A1:2009 +A2:2013 (International); EN60950-1:2006 +A11:2009 +A1:2010 +A12:2011 +A2:2013 (EU); EN 60825-1:2014/IEC 60825-1:2014 (Class 1 Laser Product); EN
62479:2010/IEC 62479:2010; Low Voltage Directive 2014/35/EU with CE Mark (Europe); GS Certificate (Germany, Europe); UL/cUL Listed and UC CoC (US/Canada); CAN/CSA C22.2 No. 60950-1-
07 2nd Ed. 2011-12; Compliance with Laser safety standards 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser notice No. 50, Dated June 24, 2007; Other safety approvals
as required by individual countries.
Supported network protocols
Via built-in networking solution: TCP/IP, IPv4, IPv6; Print: TCP-IP port 9100 Direct Mode, LPD (raw queue support only), Web Services Printing, IPP 2.0, Apple AirPrint™, HP ePrint, FTP Print,
Google Cloud Print; DISCOVERY: SLP, Bonjour, Web Services Discovery; IP CONFIG: IPv4 (BootP, DHCP, AutoIP, Manual, TFTP Config, ARP-Ping), IPv6 (Stateless Link-Local and via Router, Statefull via
DHCPv6); Management: SNMPv2/v3, HTTP/HTTPs, Telnet, TFTP Config, FTP FW Download, Syslog; Security: SNMPv3, SSL Cert Management, Firewall, ACL, 802.1x
8
9
6
2
3
4
Data sheet | HP LaserJet Enterprise M610dn
Ordering information
Accessories
Original HP ink cartridges and maintenance supplies
Number Description 3JN69A HP Jetdirect 3100w BLE/NFC/Wireless Accessory 4QL32A HP Legic Secure USB Reader
B5L28A HP Internal USB Ports B5L29A HP High-Performance Secure Hard Disk G6W84A HP 1 GB 90-pin DDR3 DIMM J8031A HP Jetdirect 2900nw Print Server L0H17A HP LaserJet 550-sheet Paper Tray L0H18A HP LaserJet 2100 Sheet Paper Tray L0H19A HP LaserJet Printer Stand L0H20A HP LaserJet Stapler/Stacker/Mailbox L0H21A HP LaserJet Envelope Feeder L0H22A HP LaserJet Extension Tray Cover X3D03A HP Universal USB Proximity Card Reader Y7C05A HP HIP2 Keystroke Reader
HP Care Packs
Number Description U9MU0E HP 3 Year Next Business Day HW Support w/Defective Media Retention U9MU1E HP 4 Ye U9MU2E HP 5 Year Next Business Day HW Support w/Defective Media Retention U9MU3E HP 3 Year 4 Hour 9x5 HW Support W/Defective Media Retention U9MU4E HP 4 Year 4 Hour 9x5 HW Support W/Defective Media Retention U9MU5E HP 5 Year 4 Hour 9x5 HW Support W/Defective Media Retention U9MV5E HP 3 Year Return for Repair Service U9MV6E HP 4 Year Return for Repair Service U9MV7E HP 5 Year Return for Repair Service U9MV8E HP 3 year Next Business Day Parts Exchange Service U9MV9E HP 4 year Next Business Day Parts Exchange Service U9MW0E HP 5 year Next Business Day Parts Exchange Service U9MW4PE HP 1 Year Post Warranty Next Business Day Hardware Support w/DMR U9MW5PE HP 2 Year
Protect your investment with HP Care Pack. Let HP certified engineers resolve your technical issues. For more details on HP Care Pack, go to hp.com/go/cpc
ar Next Business Day HW Support w/Defective Media Retention
Post Warranty Next Business Day Hardware Support w/DMR
Supported paper
Number Description
4WM80A HP CHP113 Office Paper-2500 sht/A4/210 x 297 mm 4WM81A HP CHP150 Home and Office Paper-500 sht/A4/210 x 297 mm 4WM82A HP CHP650 Everyday Paper 75 gsm-500 sht/A4/210 x 297 mm 4WM83A HP CHP755 Color Choice Paper 200 gsm-250 sht/A4/210 x 297 mm 4WM84A HP CHP855 Premium Paper 80 gsm-250 sht/A4/210 x 297 mm 4WM85A HP CHP910 Copy Paper 80 gsm
Contact HP via phone: Asia: 65 6253 8500
500 sht/A4/210 x 297 mm
Number Description
J8J96A HP Staple Catridge Refill (5,000 staples)
L0H24A HP LaserJet 110v Maintenance Kit (225,000 pages) L0H25A HP LaserJet 220v Maintenance Kit (225,000 pages)
HP Inc. offices
Australia (613) 8833 5000 hp.com.au China (010) 6564 3888 hp.c Hong Kong (852) 3077 2688 hp.com.hk India (80) 2612 9000 hp.com/in Indonesia (62-21) 5799 1088 hp.com/id Korea (02) 2199 0114 hp.co.kr Malaysia (603) 2332 3333 hp.com.my New Zealand (09) 918 9555 hp.co.nz Philippines (632) 888 5900 hp.com/ph Singapore (65) 6275 3888 hp.com.sg Taiwan (02) 3789 9900 hp.com.tw Thailand (662) 353 9500 hp.com/th Vietnam (84
For the following countries, please fax your queries to (65) 6275 6707 Bangladesh, Bhutan, Brunei, Cambodia, Maldives, Nepal, Pakistan, Sri Lanka
8) 3823 4151 hp.com/vn
om.cn
Solutions
For more solutions information, please visit hp.com/go/gsc
Footnotes
HP’s most advanced embedded security features are available on HP Enterprise and HP Managed devices with HP FutureSmart firmware 4.5 or above. Claim based on HP review of 2019 published features of competitive in-class printers. Only HP offers a combination of security features to automatically detect, stop, and recover from attacks with a self-healing reboot, in alignment with NIST SP 800-193 guidelines for device cyber resiliency. For a list of compatible products, visit: hp.com/go/PrintersThatProtect. For more information, visit: http://www.hp.com/go/PrinterSecurityClaims
HP Web Jetadmin is available for download at no additional charge at http://www.hp.com/go/webjetadmin
Measured using ISO/IEC 24734, excludes first set of test documents. For more information, see http://www.hp.com/go/printerclaims. Exact speed varies depending on the system configuration, software application, driver, and document complexity.
Measured after 15 min in sleep. Exact speed varies depending on the system configuration, software application, driver, document complexity and time in sleep.
HP 147X High Yield Black Original LaserJet Toner Cartridges not included; please purchase separately.
An FCC Class A emissions compliant device meets the less stringent (higher) levels of emissions allowed by the FCC for a product operation in a commercial environment. An FCC class A device cannot be marketed for use in a residential environment and an FCC class A device should not be purchased for use in a residential environment due to the increased risk of interference to radio communications.
Technical specifications disclaimers
EPEAT® registered where applicable. EPEAT registration varies by country. See http://www.epeat.net for registration status by country.
With print cartridges
Power requirements are based on the country/region where the printer is sold. Do not convert operating voltages. This will damage the printer and void the product warranty. Power consumption values typically based on measurement of 115V device.
BA TEC is equal to Best TEC. Power requirements are based on the country/region where the printer is sold. Do not convert operating voltages. This will damage the printer and void the product warranty. Energy Star Version 3.0 TEC is not comparable to Energy Star Version 2.0 TEC values or BA TEC values. BA uses Energy Star Version 2.0 TEC. Energy Star value typically based on measurement of 115V device
Average black declared yields based on ISO/IEC 19752 and continuous printing. Actual yields vary considerably based on images printed and other factors. For details see http://www.hp.com/go/learnaboutsupplies.
To enable HP Roam, some devices may require firmware to be upgraded and an optional accessory to add Bluetooth® Low Energy (BLE) beaconing capabilities. Subscription may be required. For more information, visit http://hp.com/go/roam
Acoustic values are subject to change. For current information see http://www.hp.com/support. Noise measured during printing mono simplex A4 at 53 ppm.
Measured using ISO/IEC 24734, excludes first set of test documents. For more information see http://www.hp.com/go/printerclaims. Exact speed varies depending on the system configuration, software application, driver, and document complexity.
Measured using ISO/IEC 17629. For more information see http://www.hp.com/go/printerclaims. Exact speed varies depending on the system configuration, software application, driver, and document complexity.
Duty cycle is defined as the maximum number of pages per month of imaged output. This value provides a comparison of product robustness in relation to other HP LaserJet or HP Color LaserJet devices, and enables appropriate
deployment of printers and MFPs to satisfy the demands of connected individuals or groups.
HP recommends that the number of printed pages per month be within the stated range for optimum device performance, based on factors including supplies replacement intervals and device life over an extended warranty period. Measured using ISO 24734 Feature Test, A5 Landscape Feed. Speed may vary based on content, PC, media orientation, and media type. An FCC Class A emissions compliant device meets the less stringent (higher) levels of emissions allowed by the FCC for a product operation in a commercial environment. An FCC class A device cannot be marketed for use in a residential
environment and an FCC class A device should not be purchased for use in a residential environment due to the increased risk of interference to radio communications.
To learn more, visit hp.com
© Copyright 2020 HP Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. ENERGY STAR and the ENERGY STAR logo are registered U.S. marks. Microsoft and Windows are registered trademarks of Microsoft Corporation. AirPrint and the AirPrint logo are trademarks of Apple Inc., registered in the U.S. and other countries. Linux is a U.S. registered trademark of Linus Torvalds. UNIX is a registered trademark of The Open Group.
Published in APJ 4AA7-6732EEP, June 2020
