HP LC3760N User Manual
HP LCD HDTV
User’s Guide
HP LC3760N 37-Inch (94-Centimeter) LCD High-Definition Television
The only warranties for HP products and services are set forth in the
express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
HP assumes no responsibility for the use or reliability of its software
on equipment that is not furnished by HP.
This document contains proprietary information that is protected by
copyright. No part of this document may be photocopied,
reproduced, or translated to another language without the prior
written consent of HP.
Hewlett-Packard Company
P.O. Box 4010
Cupertino, CA 95015-4010
USA
Copyright © 2006 Hewlett-Packard Development Company, L.P.
May be licensed in the United States by one or both of U.S. Patents
Nos. 4,930,158 and 4,930,160 until August 28, 2008.
Manufactured under license from Dolby Laboratories. Dolby, and the
double-D symbol are trademarks of Dolby Laboratories.
HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
HP supports lawful use of technology and does not endorse or
encourage the use of our products for purposes other than those
permitted by copyright law.
The information in this document is subject to change without notice.
.
n
Text set off in this manner indicates
information you need.
!
Text set off in this manner indicates
important information you need.
c
CAUTION: Text set off in this manner
indicates that failure to follow directions
could result in damage to equipment or
loss of information.
w
WARNING: This symbol is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompanying
the appliance.
e
DANGEROUS VOLTAGE: Text set off in this
manner indicates the presence of
uninsulated voltages within the product
enclosure that may be of sufficient
magnitude to constitute a risk of electrical
shock to persons.
Important Safeguards
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
e CAUTION: RISK OF ELECTRICAL SHOCK w
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
e
THIS SYMBOL IS INTENDED TO ALERT THE USER TO THE PRESENCE OF UNINSULATED
“DANGEROUS VOLTAGES” WITHIN THE PRODUCT’S ENCLOSURE THAT MAY BE OF
SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRICAL SHOCK TO PERSONS.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
w
THIS SYMBOL IS INTENDED TO ALERT THE USER TO THE PRESENCE OF IMPORTANT
OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN THE LITERATURE
ACCOMPANYING THE APPLIANCE.
CAUTION: TO PREVENT ELECTRICAL SHOCK, DO NOT USE THIS POLARIZED AC PLUG WITH AN
EXTENSION CORD, RECEPTACLE, OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY
INSERTED TO PREVENT BLADE EXPOSURE.
CAUTION: TO PREVENT ELECTRICAL SHOCK, MATCH WIDE BLADE OR PLUG TO WIDE SLOT, AND
FULLY INSERT.
CAUTION: DO NOT PLACE THIS PRODUCT ON AN UNSTABLE CART, STAND, TRIPOD,
BRACKET, OR TABLE. THE PRODUCT MAY FALL CAUSING SERIOUS
PERSONAL INJURY AND SERIOUS DAMAGE TO THE PRODUCT. USE ONLY
WITH A CART, STAND, TRIPOD, BRACKET, OR TABLE RECOMMENDED BY
THE MANUFACTURER OR SOLD WITH THE PRODUCT. FOLLOW THE
MANUFACTURER’S INSTRUCTIONS WHEN INSTALLING THE PRODUCT
AND USE MOUNTING ACCESSORIES RECOMMENDED BY THE
MANUFACTURER. A PRODUCT AND CART COMBINATION SHOULD BE
MOVED WITH CARE. QUICK STOPS, EXCESSIVE FORCE, AND UNEVEN
SURFACES MAY CAUSE THE PRODUCT AND CART COMBINATION TO
OVERTURN.
iii
INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
■ Reorient or relocate the receiving antenna.
■ Increase the separation between the equipment and receiver.
■ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
■ Consult the dealer or an experienced radio/TV technician for help.
Closed caption notice
This television receiver provides display of television closed captioning in accordance with § 15.119 of the FCC Rules.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with a minimum distance of 20 cm between the radiator and your body.
Modifications
The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly
approved by Hewlett-Packard Company may void the authority to operate the equipment.
Cables
Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods in order to
maintain compliance with FCC Rules and Regulations.
RESPONSIBLE PARTY:
Hewlett-Packard Company
Attn: Product Regulations Manager
10955 Tantau Avenue
Building 45NL
Cupertino, CA 95014 USA
iv HP LCD HDTV User’s Guide
Important Safety Instructions
Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if
improperly handled. This product has been engineered and manufactured with the highest priority on safety. However,
improper use can result in electric shock and/or fire. In order to prevent potential danger, please observe the following
instructions when installing, operating, and cleaning the product. To ensure your safety and prolong the service life of
your television, please read the following precautions carefully before using the product.
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8 Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that
produce heat.
9 Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two
blades with one wider than the other. A
grounding-type plug has two blades and a third
grounding prong. The wide blade or the third
prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10 Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11 Only use attachments/accessories specified by
the manufacturer.
12 Use only with the cart, stand,
tripod, bracket, or table specified
by the manufacturer, or sold with
the apparatus. When a cart is
used, use caution when moving
the cart/apparatus combination
to avoid injury from tip-over.
13 Unplug this apparatus during lightning storms or
when unused for long periods of time.
14 Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, the power-supply cord
or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
15 Power sources — This product should be operated
only from the type of power source indicated on
the marking label. If you are not sure of the type of
power supply to your home, consult your product
dealer or local power company. For products
intended to operate from battery power, or other
sources, refer to the operating instructions.
16 Overloading — Do not overload wall outlets,
extension cords, or integral convenience
receptacles as this can result in a risk of fire or
electric shock.
17 Replacement parts — When replacement parts
are required, be sure the service technician has
used replacement parts specified by the
manufacturer or have the same characteristics as
the original part. Unauthorized substitutions may
result in fire, electric shock, or other hazards.
18 Safety check — Upon completion of any service
or repairs to this product, ask the service
technician to perform safety checks to determine
that the product is in proper operating condition.
19 The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids,
such as vases, shall be placed on apparatus.
20 WARNING: Plug the power cord into a power
outlet where access to the power cord connector is
readily accessible in case power disconnection is
required.
v
21 Servicing: The user should not attempt to service
the appliance beyond that described in the
operating instructions. All other servicing should
be referred to qualified service personnel.
■ Water and moisture — Do not use this product near water; for example, near a bath tub, wash bowl, kitchen sink,
or laundry tub; in a wet basement; or near a swimming pool; and the like.
■ Stand — Do not place the product on an unstable cart, stand, tripod, or table. Placing the product on an unstable
base can cause the product to fall, resulting in serious personal injuries as well as damage to the product. Use
only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with the product.
■ Selecting the location — Select a place with no direct sunlight and good ventilation.
■ Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block
these vents and openings since insufficient ventilation can cause overheating and/or shorten the life of the
product. Do not place the product on a bed, sofa, rug, or other similar surface, since they can block ventilation
openings. This product is not designed for built-in installation; do not place the product in an enclosed place such
as a bookcase or rack, unless proper ventilation is provided or the manufacturer’s instructions are followed.
■ The display panel used in this product is made of glass. Therefore, it can break when the product is dropped or
applied with impact. Be careful not to be injured by broken glass pieces in case the panel breaks.
■ Heat — The product should be situated away from heat sources such as fireplaces, chimneys, radiators, heat
registers, stoves, or other products (including amplifiers) that produce heat.
■ Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green, or red. Please
note that this does not affect the performance of your product.
■ Cautions regarding use in high- and low-temperature environments:
When the unit is used in low-temperature space (e.g., room, office), the picture may leave trails or appear slightly
delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.
Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location exposed to direct sunlight
or near a heater, as this may cause the cabinet to deform and the display panel to malfunction. Storage
temperature: –4
■ Precautions when transporting the TV — When transporting the TV, be sure to always carry the TV by two people
o
F to +140o F (–20o C to +60o C).
holding it with two hands — one hand on each side of the Display.
■ Lightning — For added protection for this television equipment during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the antenna. This
will prevent damage to the equipment due to lightning and power-line surges.
■ Power lines — An outside antenna system should not be located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such power lines or circuits. When installing an outside
antenna system, extreme care should be taken to keep from touching such power lines or circuits as contact with
them might be fatal.
vi HP LCD HDTV User’s Guide
■ Outdoor antenna grounding — If an outside
antenna is connected to the television equipment,
be sure the antenna system is grounded so as to
provide some protection against voltage surges
and built-up static charges. Article 810 of the
National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper
grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection to
grounding electrodes, and requirements for the
grounding electrode.
■ To prevent fire, never place any type of candle or flames on the top or near the TV set.
■ To prevent fire or shock hazard, do not expose this product to dripping or splashing. No objects filled with liquids,
Antenna Grounding
Reference
1
2
3
4
5
6
7
1
Antenna Grounding
Grounding Component
Electric Service Equipment
Power Service Grounding Electrode System
(NEC Art 250, Part H)
Ground Clamps
Grounding Conductors (NEC Section 810-21)
Antenna Discharge Unit (NEC Section 810-20)
Ground Clamp
Antenna Lead in Wire
3
2
7
6
5
4
such as vases, should be placed on the product.
■ To prevent fire or shock hazard, do not place the AC power cord under the TV set or other heavy items.
■ Turn off the main power and unplug the AC cord from the wall outlet before handling.
■ Use a soft cloth and gently wipe the surface of the TV panel. Using a hard cloth may scratch the panel surface.
■ Use a soft damp cloth to gently wipe the panel when it is really dirty. (It may scratch the panel surface when
wiped strongly.)
■ If the panel is dusty, use an anti-static brush, which is commercially available, to clean it.
■ To protect the panel, do not use a dirty cloth, liquid cleaners, or chemical cloth to clean it; such materials may
damage the panel surface.
vii
Important Information
The TV must be serviced by an authorized service
technician. The TV is not user serviceable.
Changes can damage your TV and void your
warranty. Changes or modifications not expressly
approved by the manufacturer could void the user’s
authority to operate the equipment.
Recycling Information
For information about how to recycle this product
through HP, see:
http://www.hp.com/recycle
Other recycling options may also be available in your
area. If located within the U.S. and Canada, you may
also call (1) (888) 485-1849.
Materials disposal
This HP product contains the following materials that
might require special handling at end-of-life:
■ Mercury in the fluorescent lamp in the LCD.
Disposal of mercury may be regulated because of
environmental considerations. For disposal or
recycling information, please contact your local
authorities or the Electronic Industries Alliance (EIA)
(http://www.eia.org).
Cleaning precautions
Unplug the TV before cleaning the screen.
Using solvents, such as alcohol, or abrasive material,
such as a premoistened or chemically treated towel,
may affect the TV or bezel paint.
Do not expose the product to volatile gas or fluid such
as a pesticide.
Do not put the TV in contact with vinyl or rubber
products for a long period of time. Extended contact
may result in the removal of or degradation of the
surface.
Lifting precautions
The TV is heavy; be sure to use ergonomically correct
lifting procedures when moving the TV.
Due to the size and weight of the TV, it is
recommended that a minimum of two people move it.
For transport, grasp the display in the area under and
above the screen.
Never place the display with the glass screen facing
downward, unless it is protected with pads.
viii HP LCD HDTV User’s Guide
Table of Contents
Important Safeguards ..................................... iii
Modifications .................................................iv
Cables ..........................................................iv
Important Safety Instructions ..............................v
Important Information ....................................viii
Getting to Know Your TV................. 1
Identifying Items in the Box .................................... 2
Locating TV Buttons and Connectors........................2
Cleaning ............................................................. 6
Cleaning precautions ......................................6
Cleaning the TV.............................................. 6
Setting Up....................................... 7
Selecting a Good Location.....................................7
Unpacking..................................................... 8
Lifting the TV .................................................. 8
Attaching or removing the stand ....................... 8
Setting Up the TV.................................................. 9
Connecting the TV signal source.......................9
Connecting the cable TV or the
air antenna.................................................. 10
Connecting cable or satellite with a
set-top box................................................... 10
Connecting a DVD player, VCR, DVR,
game console, or camcorder..........................11
Connecting a VCR for recording..................... 15
Connecting an external sound system.............. 15
Connecting power to the TV........................... 16
Turning On the TV..........................17
Turning the TV On and Off (Standby) ....................17
Using the First-Time Setup
Wizard..........................................19
Initial Setup........................................................19
Using the Remote Control ..............21
Operating the TV................................................21
Using universal remote controls.......................21
Installing or replacing remote control
batteries.......................................................21
Identifying the remote control buttons...............22
Adjusting the Volume ..........................................24
Muting the sound ..........................................24
Changing the Picture Mode..................................24
Changing Channels ............................................24
Selecting the last channel...............................24
Displaying program information......................25
Selecting the Input Source....................................25
Changing the View with the Aspect Button .............25
Turning On Captions...........................................25
Setting SAP/MTS stereo mode..............................26
Changing Audio Mode........................................26
Setting the Sleep Timer ........................................26
Adjusting TV Settings...........................................26
Opening and exiting the OSD ........................26
Table of Contents
Table of Contents ix
Changing the TV Settings...............27
Using the OSD Menus......................................... 27
Using the Picture Menu........................................ 28
Adjusting the picture settings .......................... 28
Using the Audio Menu ........................................ 29
Adjusting the audio....................................... 29
Using the Power Control Menu.............................29
Using the Setup Menu ......................................... 30
Starting EZ Setup.......................................... 30
Using CH Setup............................................ 30
Using Antenna Setup — Digital ...................... 31
Using Parental CTRL...................................... 31
Setting Input Skip.......................................... 31
Setting Position.............................................31
Setting Input Label ........................................ 31
Setting Picture Flip ........................................ 31
Setting Standby Mode................................... 32
Setting Language.......................................... 32
Using Reset.................................................. 32
Using the Option Menu ....................................... 32
Using the Digital Setup Menu............................... 33
Using Audio Setup........................................33
Selecting the view aspect .................................... 33
Using Closed Caption......................................... 34
Selecting closed caption options..................... 35
Using Parental Controls ....................................... 35
Secret number setting for parental control ........ 35
Setting the parental control
V-Chip level ................................................. 36
How to temporarily release a blocked
program...................................................... 40
Reactivating parental controls after a
temporary release......................................... 40
Finding Answers to Questions ....... 41
Understanding TV Terms......................................41
What are analog TV, digital TV, and
high-definition (HDTV)?..................................41
What is the difference between progressive
and interlaced signal formats for digital TVs? ...41
What is variable aspect ratio?........................41
What is HDMI?.............................................42
Identifying Cable Usage ......................................42
Specifications................................ 45
Troubleshooting ............................ 49
x HP LCD HDTV User’s Guide
Getting to Know Your TV
Thank you for purchasing an HP LCD High-Definition
Television. HP’s array of high-definition televisions
delivers a world-class picture in a design that is sleek
and stylish.
Features:
■ Premium LCD panel technology that delivers a
contrast ratio of up to 1,200:1 for rich detail, and
as fast as 6 ms response time for no-smear motion
video and ultra wide viewing angles with a
minimum of color shift. HP LCD TVs deliver the
detail and color that HP is known for.
■ Fantastic sound that emanates from the integrated
speaker design, which provides 20 watts of
power. HP’s high-fidelity speaker system is
complemented by 3D surround sound audio
technology, which emulates a 5.1-channel
surround sound system for an enhanced home
theater experience.
■ A comprehensive array of digital and analog
inputs, including an integrated HDTV tuner, two
HDMI, and two component video ports. Analog
and digital audio output connectors enable
seamless connectivity to external audio speakers
or an audio receiver.
■ Dolby Digital 5.1 channel digital audio output that
enables a full home theater sound experience
when attached to an external Dolby Digital
decoder and a multi-channel amplifier.
■ A classic black-finish panel that blends with any
décor. The tabletop stand is sleek, stylish, and
detachable.
■ 3D color enrichment system that reproduces
vibrant colors and natural skin tones.
■ Photorealistic sharpness enhancement that yields
crystal-clear and sharp pictures.
■ HP Visual Fidelity technologies combine scene-by-
scene contrast adaptation with information about
your room’s ambient lighting to deliver an
optimum picture.
■ Motion adaptive noise reduction, which greatly
reduces visual noise without reducing detail.
■ Advanced scaling and film-processing technology,
which enables enjoyment of DVDs and standarddefinition TV on a big screen.
■ Integrated digital HDTV/analog tuner — for HD
shows from cable or off-the-air sources.
■ Two HDMI ports that provide digital video and
audio through a single cable.
■ Ultra-long-life panel that provides up to
60,000 hours of operation.
All specifications represent the typical specifications provided by
HP’s component manufacturers; actual performance may vary either
higher or lower.
The panel life is determined as the time at which luminance is 50%
compared to that of initial value at the typical lamp current on
condition of continuous operation at 25 +/–° C. 60,000 hours
equates to more than twenty-three years at seven hours a day
viewing.
Getting to Know Your TV
Getting to Know Your TV 1
Identifying Items
Locating TV Buttons and
in the Box
SAP
Sound
MTS
Source
OK
Menu
Aspect
back
Info
Ch+
Last
Ch-
CC Sleep Ant
3
1
2
6
4
5
89
7
Enter
0
Television (with stand
detached)
TV stand (two pieces)
with mounting
hardware and tool
Remote control unit
AC cord
Cable clamp
Connectors
The TV contains controls, indicators, and connectors.
The TV indicators are located on the front of the TV,
and the controls are located on the top.
TV Front
TV front Description
A: Remote
control sensor
Remote control sensor is
the location where to point the
remote control unit.
A
B
D
C
Cable tie
Basic Se
Connect your system to the bac
Your connector locations and system components may var
tup
k panel.
y.
Documentation
2 HP LCD HDTV User’s Guide
B: OPC
sensor
C: Power
indicator
D: OPC
indicator
Optical picture control
(OPC) sensor senses the
surrounding light and
automatically adjusts the
backlight brightness. Make sure
no object obstructs the OPC
sensor, which could affect its
ability to sense surrounding
light.
Power indicator light is
green when TV is on and is off
when TV is in off/standby
mode.
OPC indicator indicates
status when the OPC is on. For
information on the OPC, refer
to “Turning On the TV” on
page 17.
Top TV controls
TV top control Description
Vol Volume lowers or raises the sound level.
CH Channel selects the next lower or higher channel.
Input Input selects the TV input source.
Power Power turns on the TV or places it in standby mode.
Getting to Know Your TV 3
Getting to Know Your TV
Rear TV connectors
The connectors are located on the rear of the TV.
4 HP LCD HDTV User’s Guide
TV (rear)
connector Item name Description
■ HDMI
■ HDMI
Digital Audio
Output
Ant/Cable
Input 4 (audio)
Input 3:
■ S-video
■ Video
■ Audio L/R
■ Input 5
HDMI
■ Input 4
HDMI
■ Optical
digital
audio
output
■ TV signal
input
■ Input 4
audio
■ Input 3
Input 5 or Input 4, HDMI in: Connect an HDMI cable from optional
digital, high-definition equipment.
Use Input 4 audio R and L only when using an DVI-to-HDMI converter at
HDMI Input 4.
Digital audio output, optical: Connect an optical cable for digital
sound out to an optional external digital audio system.
Antenna or cable in: Connect a coaxial cable from an air antenna or
a cable signal source.
Input 4 audio in: Connect left and right audio cables only when using
a DVI-to-HDMI converter at HDMI Input 4.
Input 3 audiovisual in:
■ Connect an S-video cable and left and right audio cables from
optional equipment.
Or
■ Connect a composite video cable and left and right audio cables from
optional equipment.
(Audio connectors are shared.)
Input 1:
■ Component
■ Video
■ Audio L/R
Or
Input 2:
■ Component
■ Video
■ Audio L/R
Audio Output
AC In
■ Input 1
■ Input 2
■ Audio
output,
analog
■ AC power
Input 1 or Input 2 in:
■ Connect a component video cable and left and right audio cables
from optional equipment. Supports standard inputs 480i, 480p,
720p, and 1080i. Some set-top boxes must be set for a specific
resolution.
Or
■ Connect a composite video cable and left and right audio cables from
optional equipment.
(Audio connectors are shared.)
Audio output, analog: Connect left and right audio cables for analog
stereo sound out to an optional external audio system. Use the left (white)
connector for mono sound (single cable).
AC power: Connect the included power cord. NOTE: Use only the
provided power cord.
Getting to Know Your TV 5
Getting to Know Your TV
Cleaning
Cleaning precautions
Unplug the TV before cleaning the screen.
A special antiglare coating is applied to the screen of
your TV. Using solvents, such as alcohol, or abrasive
material, such as a premoistened or chemically treated
towel, may affect the screen coating or bezel paint.
Do not expose the product to volatile gas or fluid such
as a pesticide.
Do not put the TV in contact with vinyl or rubber
products for a long period of time. Extended contact
may result in the removal of the coating or degradation
of the surface.
Cleaning the TV
Clean the screen by spraying a soft lint-free cloth with
water to lightly moisten it. Gently wipe the screen, and
avoid pressing on the screen.
To clean the outer cabinet, use the same method.
Do not use liquid or aerosol cleaners.
6 HP LCD HDTV User’s Guide
8
Setting Up
HP recommends professional installation from an
authorized installer to ensure maximum enjoyment of
your HP LCD HDTV. Be sure to read all the safety
information and precautions before starting installation.
See these topics:
■ “Important Safeguards” on page iii.
■ “Important Safety Instructions” on page v.
Selecting a Good Location
Select the location for your HP LCD HDTV. Consider the
following situations when positioning the TV:
■ Power cord length: Choose a location with easy
access to an AC power outlet.
■ Cable lengths and distances to attached units:
Check that cables can reach the TV.
■ Do not install the TV on an unstable cart or stand;
the unit may fall over and cause injury.
■ Do not install the TV where it has a protruding
edge, such as on a small table where the display
overhangs the table surface.
■ Do not hang the TV from the ceiling; the unit may
fall and cause injury.
■ Avoid direct sunlight that may damage the display
or interfere with the operation of the remote
control.
■ Avoid areas of high humidity or damp conditions
that may cause fire or electrical shock.
■ Do not install TV near appliances, such as a
microwave, or near a heat source, such as a
fireplace or radiator.
■ Provide adequate ventilation clearance around
the TV.
■ “Important Information” on page viii.
A
B
B
C
Setting Up
A 1.4 in. (3.5 cm) minimum above TV
B 1.4 in. (3.5 cm) minimum at sides
C 1.4 in. (3.5 cm) minimum behind TV
Setting Up 7
Unpacking
Attaching or removing the stand
Be sure to read through “Lifting the TV” for important
information.
Unpack the TV and put it on a stable surface:
1 Use the cardboard holders on either side of the TV
to remove it from the box.
2 Remove the cardboard; however, keep the
wrapping on the TV to protect it while moving.
3 Lift the TV onto the installation location.
Lifting the TV
The TV is heavy; be sure to use ergonomically correct
lifting procedures when moving the TV.
Due to the size and weight of the TV, it is
recommended that a minimum of two people move it.
To transport the TV, grasp the display in the area under
and above the screen.
Your TV comes with a stand that must be attached to
the display. Reverse these steps to remove the stand.
c
CAUTION: Use two people to assemble
the TV.
Before attaching the stand, unplug the AC cord from
the AC input.
1 Locate the TV stand (two pieces), eight screws of
mounting hardware, and tool from the box.
2 Place the base onto the pedestal, insert four short
screws, and tighten using the provided tool.
Move the product gently. Never place the TV with the
glass screen facing downward, unless it is protected
with pads.
8 HP LCD HDTV User’s Guide
3 Carefully place the TV panel with the glass screen
facing downward on a padded, stable table.
Position the bottom of the TV near the edge of the
table.
w
WARNING: Do not drop the stand onto
the TV.
Insert the assembled stand into the opening on the
4
bottom of the TV.
5 Insert four long screws into the holes on the back
of the TV and tighten using the provided tool.
Connecting the TV signal source
w
WARNING: Before connecting the TV to any
other electronic device, unplug the TV and
electronic device AC cords from the AC
input.
The following is an explanation of the types of
connections that are used for a coaxial cable. If your
outdoor antenna uses a 75-ohm coaxial cable with an
F-type connector, plug it into the antenna/cable
terminal at the rear of the TV set.
■ A 75-ohm system is generally a round cable with
an F-type connector that can easily be attached to
a terminal without tools (sold separately).
■ A 300-ohm system is a flat, twin-lead cable that
can be attached to a 75-ohm terminal through a
300/75-ohm adapter (sold separately).
6 Carefully lift the TV and set it upright.
Setting Up the TV
Set up the TV by connecting cables and connecting the
power cord.
n
An F-type connector should be fingertightened only. When connecting the RF
cable to the TV set, do not use tools to
tighten the F-type connector, as it may
cause damage to your TV set.
C
A
B
A: 75-ohm coaxial cable, round
B: 300-ohm twin-lead cable, flat
C: F-type connector
Setting Up
Setting Up 9
Connect the input source to the TV according to the
type of connection:
■ Antenna or basic cable (TV cable or satellite)
without using a set-top box; see “Connecting the
cable TV or the air antenna” on page 10.
■ Cable or satellite with a separate set-top box; see
“Connecting cable or satellite with a set-top box”
on page 10.
Connecting the cable TV or the
air antenna
Use standard 75-ohm coaxial cable to connect a
ground antenna or cable TV input source to the TV. Use
shielded coaxial cable to reduce radio frequency (RF)
interference.
Optional equipment, cable TV service, and all cables
are sold separately.
n
■ To connect an external sound system, see
“Connecting an external sound system”
on page 15.
■ To connect a device that records TV, see
“Connecting a VCR for recording” on
page 15.
About the Emergency Alert System (EAS)
■ In the case of a national emergency, natural
disaster, or other emergency situation, an EAS
message broadcasts. When this unit receives an
EAS message, if the level of emergency is
comparatively low, an alert text message displays
on screen. If the level of emergency is high, the
receiver is forced-tuned to a details channel.
■ Alert text messages display, and forced tuning
occurs, even during paid programming. Even
when forced tuning is active, the user can still
change the channel.
■ If the unit is forced-tuned to a channel that has
been blocked by Parental Control, the Parental
Control setting is given priority, and the EAS
message is not broadcast.
■ EAS messages may be broadcast not only through
digital cable, but also through analog cable or
over-the-air analog transmission. EAS alert
messages broadcasted through cable are not
received on this TV.
c
CAUTION: Unplug power for the TV and all
connected components before connecting
the antenna or cable.
1 Connect the input source coaxial cable to the
Ant/Cable connector on the back of the TV.
2 Connect power to the TV; see “Connecting power
to the TV” on page 16.
3 Turn on the TV; see “Turning the TV On and Off
(Standby)” on page 17.
Connecting cable or satellite
with a set-top box
Connecting your TV directly to the audio and video
output of your set-top box assures a more vivid picture
and enhances your viewing enjoyment.
Optional equipment and all cables are sold separately.
You can connect a digital TV set-top box (air or cable)
and other audiovisual equipment by using:
■ Component video and audio cables connected to
Input 1 or Input 2 connectors on the TV.
■ S-video and audio cables connected to Input 3
connectors on the TV.
10 HP LCD HDTV User’s Guide
■ Video (composite) and audio cables connected to
Input 1, 2, or 3 connectors on the TV.
■ HDMI cable connected to Input 4 or 5 connectors
on the TV.
■ DVI video cable with a DVI-to-HDMI converter and
audio cables connected to the Input 4 (HDMI) and
audio connectors on the TV.
c
CAUTION: Unplug power for the TV and all
connected components before connecting
the set-top box.
1 Connect the set-top box input source cable(s) to
the back of the TV using one of the connector sets.
■ HDMI cable connected to Input 4 or 5
connectors on the TV.
■ DVI video cable with a DVI-to-HDMI converter
and audio cables connected to the Input 4
(HDMI) and audio connectors on the TV.
n
The Video (composite) connector in each of
the Inputs 1, 2, and 3 connector sets shares
audio connectors with the Component or
the S-video connector in the set. If cables
are connected to both video connectors in a
set, the Component or S-video connector
has priority over the Video connector.
2 Connect the cables to the set-top box.
3 Turn on the set-top box.
4 Connect power to the TV; see “Connecting power
to the TV” on page 16.
■ Component video and audio cables
connected to Input 1 or Input 2 connectors on
the TV.
■ S-video and audio cables connected to Input 3
connectors on the TV.
■ Video (composite) and audio cables
connected to Input 1, 2, or 3 connectors on
the TV.
5 Turn on the TV; see “Turning the TV On and Off
(Standby)” on page 17.
6 Open the OSD and specify settings as needed;
see “Changing the TV Settings” on page 27.
Connecting a DVD player, VCR,
DVR, game console, or
camcorder
You can connect optional equipment (sold separately),
such as a DVD player, VCR, DVR, and so on to the TV
by using the AV input connectors.
Optional equipment, including an external sound
system, and all cables are sold separately.
You can connect a DVD by using:
■ Component video and audio cables connected to
Input 1 or Input 2 connectors on the TV.
■ S-video and audio cables connected to Input 3
connectors on the TV.
■ Video (composite) and audio cables connected to
Input 1, 2, or 3 connectors on the TV.
Setting Up
Setting Up 11
■ HDMI cable connected to Input 4 or 5 connectors
on the TV.
■ DVI video cable with a DVI-to-HDMI converter and
audio cables connected to the Input 4 (HDMI) and
audio connectors on the TV.
You can connect a VCR by using Input 3 terminals with
either S-video or composite video connections for
playback. To connect a VCR for recording, see
“Connecting a VCR for recording” on page 15.
Choosing the AV connection to use
You can connect a game console, camcorder, and
some other AV equipment by using Input 3 terminals
with either S-video or composite video connections.
You can connect HDMI equipment by using Input 4 or
Input 5 terminal with an HDMI connection.
You can connect DVI equipment by using a DVI video
cable with a DVI-to-HDMI converter and audio cables
connected to the Input 4 (HDMI) and audio connectors
on the TV.
When connecting optional equipment as signal
sources, the connectors on the equipment may limit the
type of connection you can use.
When your optional equipment has more than one
type of output connector, choose the connection that
provides the best-quality playback image.
For best results, choose the best-quality connection type
that is supported by your optional equipment.
AV connection to use, listed from best to good video playback
Connector types on
Connection description
optional equipment Cable plug
HDMI transmits an all-digital signal and is the
recommended choice for playback from a digital DVD
or DVR.
DVI transmits an all-digital video signal for playback from
a digital DVD or DVR.
(At the TV, use a DVI video cable with a DVI-to-HDMI
converter and audio cables connected to the Input 4
HDMI and audio connectors.)
Component (Y, Pb, Pr) transmits video as separate
red, green, and blue signals. Use this connection for
high-definition video signals in 480i, 480p, 720p, or
1080i format from a progressive scan DVD or other
equipment.
S-video transmits video in separate color and black-andwhite image signals and delivers a sharper image than a
composite video connection.
Composite video transmits video as a single signal.
12 HP LCD HDTV User’s Guide
The procedures that follow, presented in the order
listed in the table, describe connecting optional
equipment, including the audio connections when
applicable.
c
CAUTION: Unplug power for the TV and all
connected components before connecting
optional equipment. Ensure that the
optional equipment is powered off.
Connecting an HDMI device
This is the recommended connection for video and
audio. The HDMI cable is sold separately.
1 Connect the HDMI cable to Input 4 or Input 5.
(There are no separate audio inputs for HDMI.)
Connecting a DVI device
The DVI cable, DVI-to-HDMI converter, and audio
cables are sold separately.
1 Connect the DVI video cable with a DVI-to-HDMI
converter and the audio cables to the DVI
equipment.
2 Connect the HDMI end of the converter to Input 4
on the TV. Connect the audio cables to the audio
connectors for Input 4 on the TV.
2 Connect the cable to the HDMI device.
3 Turn on the device, and start play.
4 Connect power to the TV; see “Connecting power
to the TV” on page 16.
5 Turn on the TV; see “Turning the TV On and Off
(Standby)” on page 17.
6 Define the HDMI Setup items in the Option menu;
refer to “Using the Option Menu” on page 32.
3 Turn on the DVI device, and start play.
4 Connect power to the TV; see “Connecting power
to the TV” on page 16.
5 Turn on the TV; see “Turning the TV On and Off
(Standby)” on page 17.
6 Define the HDMI Setup items in the Option menu;
refer to “Using the Option Menu” on page 32.
Setting Up
Setting Up 13
Connecting a component device
Cables are sold separately.
!
Input 1 and 2 each have both Component
and Video connectors, which share L/R
audio connectors. Connect only one video
input for each input set.
1 Connect the component cable to the Component
(Y, Pb, Pr) connectors. There are two sets of
Component connectors you can use: Input 1 or
Input 2.
6 Turn on the TV; see “Turning the TV On and Off
(Standby)” on page 17.
7 Define the Input Select for the connector in the
Option menu; refer to “Using the Option Menu”
on page 32.
Connecting an S-video or video device
A VCR, game console, camcorder, or some other
audiovisual equipment can be connected using Input 3
terminals.
!
Input 3 has both S-video and Video
connectors, which share L/R audio
connectors. Connect only one video input
for Input 3.
Cables are sold separately.
1 Connect the video equipment to the Input 3
connectors:
2 Connect the component audio cable to the L/R
audio connectors for Input 1 or Input 2.
3 Connect the cables to the component device.
4 Turn on the device, and start play.
5 Connect power to the TV; see “Connecting power
to the TV” on page 16.
■ For a VCR, DVR, or other device that has an
S-video connector, use an S-video cable and
the S-video connector.
Or
■ For a VCR, DVR, or other device that has a
composite video connector, use a composite
video cable and the Video connector.
14 HP LCD HDTV User’s Guide
Connect the audio cable connectors to the left and
2
right audio connectors for Input 3.
3 Connect the cables to the device.
4 Turn on the device, and start play.
5 Connect power to the TV; see “Connecting power
to the TV” on page 16.
6 Turn on the TV; see “Turning the TV On and Off
(Standby)” on page 17.
Connecting a VCR for recording
1 Connect the external sound system to the TV:
■ For a digital audio connection, connect an
optical cable to the Digital Audio Out
connector on the back of the TV and to an
external sound system.
The TV does not output a signal for recording.
Connect a VCR or other device for recording to the
signal source (antenna or cable), and then connect the
device to the Ant/Cable connector on the TV. See
“Connecting the cable TV or the air antenna” on
page 10. Use the recording device to tune to the
channel you want to record.
Connecting an external sound
system
You can connect an external sound system to the TV
using a digital audio or an analog audio signal:
■ Use the Digital Audio Out connector on the back
of the TV to provide a digital audio signal to an
optional external sound system, such as a digital
receiver or a surround sound system.
■ Use the Audio Out left and right connectors on the
back of the TV to provide an analog audio signal
to an optional external sound system, such as an
analog amplifier or stereo system.
Cables are sold separately.
Or
■ For an analog connection, connect audio
cables to the Audio Out left and right
connectors on the back of the TV and to an
external sound system.
2 Connect power to the TV; see “Connecting power
to the TV” on page 16.
3 Turn on the TV; see “Turning the TV On and Off
(Standby)” on page 17.
4 Connect power and turn on the external sound
system.
c
CAUTION: Unplug power for the TV and all
connected components before connecting
an external sound system. Ensure that the
external sound system is powered off.
5 Define the digital audio format in the Option
menu; refer to “Using the Option Menu” on
page 32.
Setting Up
Setting Up 15
Connecting power to the TV
Use these steps to attach the cable clamp, bundle cords
with the cable clamp and the cable tie, and connect the
AC power cord.
1 Connect the power cord to the connector on the back
of the TV, and secure it in the clamp.
2 Insert the cable clamp from the box into the hole on
the back of the TV.
3 Route the cords through the cable clamp, and bundle
the cords in the cable tie from the box.
4 Connect the power cord to the AC power outlet.
16 HP LCD HDTV User’s Guide
Turning On the TV
Turning the TV On and Off (Standby)
The TV has a Power button on the top of the display.
You can also use the remote control Power button to
turn on the TV.
Pressing the Power button either turns the TV on or
places it into standby, which is a reduced power state.
The Power indicator light on the front of the TV shows
the power status of the TV.
A
B
D
C
A: Remote control sensor
If the TV is not used for an extended period of time,
press the Power button to place the TV into standby,
and then unplug the power cord.
The optical picture control (OPC) indicator on the front
of the display shows the TV OPC status for backlight
brightness control.
Turning On the TV
OPC
indicator TV OPC status
Off OPC disabled (Off)
Lights green OPC enabled (On or On:Display)
When enabled, the OPC sensor on the front of the TV
senses the surrounding light and automatically adjusts
the backlight brightness. For more information, see
“Choosing OPC” on page 28.
Using the TV buttons
1 Press the Power button on the top of the TV.
The TV is on or in standby.
2 Press the Input button as needed to select the TV
input source to view.
B: OPC sensor
C: Power indicator
D: OPC indicator
Power indicator Power status
Off Standby (off)
Lights green Ready (on)
Turning On the TV 17
Using the remote control buttons
1 Point the remote control at the remote control
sensor on the display, and press the remote
control Power button.
The TV is on or in standby.
2 Press the Source button as needed to select the TV
input source to view.
Source
n
The initial setup starts when the TV powers
on for the first time. If the TV has been
turned on before, the EZ setup does not
start. See “Using the First-Time Setup
Wizard” on page 19.
18 HP LCD HDTV User’s Guide
Using the First-Time Setup Wizard
Initial Setup
When turning on the TV for the first time, it
automatically memorizes the channels where you live.
Perform the following steps before you press TV Power
on the remote control unit:
1 Insert the batteries into the remote control unit.
2 Connect the antenna cable to the TV.
3 Plug in the AC cord to the AC outlet.
Language setting
Select from among three languages: English, French,
or Spanish:
1 Press the up arrow and down arrow buttons on the
remote control to select the desired language
listed on the screen.
2 Press OK.
Standby mode setting
1 Select the standby mode setting.The default setting
is Mode 2.
■ Mode 1: Starting TV is quick from standby.
■ Mode 2: Power consumption is low when in
standby.
Language
Standby Mode
Air/Cable
CH Search
Mode 1
Mode 2
2 Press OK.
Antenna setting
1 Press the left arrow and right arrow buttons on the
remote control to select Air or Cable.
2 Press OK.
Using the First-Time Setup Wizard
Using the First-Time Setup Wizard 19
Channel search
Example
Channel search automatically searches for a signal
from all available channels:
1 Press the left arrow and right arrow buttons on the
remote control to select Yes or No for Air Analog
& Digital, and then press the down button to move
down.
2 Press the left arrow and right arrow buttons on the
remote control to select Yes or No for Cable
Analog, and then press the down button to move
down.
3 Press the left arrow and right arrow buttons on the
remote control to select Yes or No for Cable
Analog & Digital, and then press the down button
to move down.
4 Select Search Start, and then press OK.
...
[
Setup
Setup
Setup
CH Setup
...
CH Setup
...
CH Setup
MENU
ANALOG [ ]25 [ ]20
MENU
DIGITAL [ ]25 [ ]20
MENU
DIGITAL [ ]25 [ ]25
[
[
...
CH Search
...
CH Search
...
CH Search
]
FoundAir
]
FoundAir
]
FoundCable
Air ANALOG
2
Audio : MONO
20 HP LCD HDTV User’s Guide
n
If no channel is found, check the input
connection to your TV, and run the EZ setup
again using the Setup menu; see “Starting
EZ Setup” on page 30.
Loading...
