HP NetServer LC 3
The rock-solid workgroup server that keeps
your growing business up and running
The HP NetServer LC 3 is unmatched for manageability, availability, and
performance by any other server in its class through this unique combination
of features built into its core design:
Manageability
• Integrated HP Remote Assistant
• HP Navigator for ease of installation
• HP TopTools for Servers Web-based device management
• HP OpenView ManageX/SE (Special Edition) for NOS and application
management
Availability
• Support for Microsoft®Cluster Server
• ECC memory and memory scrubbing
• Variety of disk array controllers to meet budget and performance needs
• Hot-swap drives
• One-Button Disaster Recovery with HP SureStore DDS backup
accessories
Scalable Performance
specifications
• Support for Pentium II and Pentium III dual processing
• I2O-ready system
• Upgrade path from HP NetServer LC II to HP NetServer LC 3
HP’s Commitment to Service
• Package fully designed by HP for easy access and quick serviceability
• Package design partitions key components to enable easy access to
processor and I/O slots
• Optional service packets for higher levels of hardware and software
support
• HP service available worldwide
As your business grows and your network
needs become more critical, you need a
server that can expand and be reliable so
that you can trust it to run your business.
HP NetServer LC 3 is engineered to
deliver superior manageability, high
availability, and performance wherever
you install your next workgroup server.
specifications
HP NetServer LC 3
Features
Performance
Processor Up to 2 Intel Pentium II 400MHz, 450MHz or Pentium III 500MHz, 550MHz
processors with 100MHz bus
Cache
512KB ECC L2 cache per processor
ECC Memory • 64MB high-performance 100MHz ECC SDRAM standard with memory scrubbing
•
1GB maximum capacity
I/O Expansion Slots 5 PCI (one occupied by preinstalled 10/100TX NIC)
1 PCI/ISA
•
Integrated Ultra/Wide SCSI
Controllers
Mass Storage System
Hot-Swap • 3 half-height hot-swap shelves, plus 1 half-height common tray shelf
•
72.8GB maximum internal capacity, 54.6GB hot-swap
•
Optional external storage solutions
Video • Integrated; supports 1024x768, 256-color resolution at 72Hz
•
1MB standard video memory, upgradeable to 2MB
•
Super VGA drivers available with operating system
CD-ROM Drive
Flexible Disk Drive
24x Max IDE
3.5” 1.44MB flexible disk drive
Built-in I/O Ports • One 25-pin parallel port
•
Two 9-pin Serial/RS-232 ports
•
Video port
•
Mini-DIN keyboard and mouse ports
•
Management port (9-pin)
Keyboard and Mouse
Localized keyboard and two-button mouse
2
specifications
HP NetServer LC 3
Features
Availability
Clustering Support for Microsoft Cluster Server
Self-Restart Capability • Automatic Server Restart (ASR) that reboots in the event of a NOS hang
•
Temperature, voltage, and fan-speed monitoring
Self-Correcting Memory Manageable Error Checking and Correcting (ECC) system and cache memory
Hot-Swap Subsystem • Supports 4.2GB, 9.1GB, and 18.2GB disk drives
•
Supports high-performance 10,000rpm 4.2GB and 9.1GB disk drives
•
Up to 54.6GB of hot-swappable internal storage
Disk Array Controller • Optional HP NetRAID-1or HP NetRAID-3Si I2O disk array controller
•
Supports RAID 0, 1, 3, 5, 10, 30, 50
IPMI Intelligent Platform Management Interface to simplify and standardize system
communication for device management
Network Interface Preinstalled 10/100TX network interface card with support for optional network
interface card to support redundancy, load balancing, and Cisco®Fast EtherChannel
One-Button Disaster Recovery Simple and reliable data restoration with the world's first hardware-based One-Button
Disaster Recovery solution
Manageability
1
®
Installation and Configuration • HP NetServer Navigator with automated, menu-driven system setup and
configuration
•
Guided network operating system installation
•
Automatic installation of monitoring tools
•
IntranetWare from Novell distributed with every system (requires customer
purchase for activation)
Management Software • HP TopTools for Servers, a comprehensive server management solution with
intuitive browser-based user interface, facilitates troublesh oot ing, adm inistration,
and asset information collection
•
Detailed inventory information provided through standard DMI 2.0 protocol
•
Award-winning HP OpenView™ ManageX/SE for complete NOS and application
management
•
Easy integration with other leading network and system management products
Remote Administration • Integrated HP Remote Assistant provides emergency remote access with a single
event log and expanded inventory data collection for faster troubleshooting
•
Optional HP TopTools Remote Control card for remote LAN access and increased
security
•
File transfer capabilities for secure and easy remote updates
Expandability
Design Features • Mezzanine design partitions key components and to provide easy access to
memory, I/O slots, and CPU
•
Vertically mounted electronics with suspension rails to improve access without
requiring disassembly
•
Easy-release processor cartridge
•
Ample top and side access
•
Rack-friendly design
1
See HP NetServer Management Web site at http://www.hp.com/go/netserver_mgmt
3
specifications
HP NetServer LC 3
Features
Flexibility
Supported Operating Systems Microsoft® Windows NT
SCO®OpenServerTMand UnixWare®, IBM® OS/2® Warp Server and
Warp Server SMP, Banyan®VINES®, Linux
Security and Safety
•
Startup password
System Security
Service and Support
•
Power switch cover and keyboard lock button
•
Chassis intrusion alert
•
Provision for padlock
•
System lock and hot-swap hard disk drive lock
•
Enable or disable serial port, parallel port, flexible disk drive, and write operations
to the flexible disk drive
®
, Novell® NetWare® and IntranetWareTM,
Warranty 3-year, next-business-day, onsite limited warranty from HP or authorized resellers
(standard business hours) worldwide
HP SupportPack Options • Free telephone support for basic setup, installation, and troubleshooting in North
America, Europe, and Asia Pacific during warranty
•
Optional HP SupportPack for 4-hour response during standard business hours
•
Optional HP SupportPack for 24 hours a day, 7 days a week
•
Optional HP SupportPack for 6-hour Hardware Call-to-Repair Commitment Service
•
Optional HP SupportPack for Comprehensive Technical Support
Reseller Support Services Comprehensive reseller support framework to ensure successful support of
HP NetServers includes
•
Proactive Notification e-mail service
•
Service and support Web site
•
Server management and hardware troubleshooting courses (STAR)
•
Troubleshooting Toolkit
•
24x7 telephone support for authorized resellers
•
HP Business Builders blueprints for new business opportunities
1
See http://www.hp.com/netserver/servsup for details
1
1
1
1
4
specifications
HP NetServer LC 3
Features
Regulatory Compliance
Electromagnetic Emissions
•
CFR 47 part 15, Class B: Self Declaration, C63.4 - 1992 (USA)
•
Industry Canada, ICES-003, CISPR 22, Class B (Canada)
•
EN 50081, EN 55022, Class B (EU Countries)
•
EN 55022, Class B (Eastern Europe (ISE) Countries)
•
M of C, Class A (Korea)
•
VCCI, CISPR 22 Class B ITE (Japan)
•
AS/NZS 3548 - EN 55022B (Australia/ New Zealand)
•
BCIQ, Class A (Taiwan)
•
GOST 29216 (Russia)
1
1
1
1
1
Electromagnetic Immunity
Safety
Generic Immunity (EN 50082-1, EU countries), including:
•
ESD, IEC-801-2:1984, 4KV Contact, 8KV Air
•
Radiated Immunity, IEC-801-3:1984:
3V/m, 80% AM Mod, 27MHz–1000MHz
•
EFT, IEC-801-4:1988 1.0KV Power, 0.5KV I/O lines
•
UL 1950 (File E139742) (USA and Canada)
•
EN 60950 (International)
•
NOM (Mexico)
1
Class A for Pentium III 500MHz and 550MHz processors.
5
specifications
HP NetServer LC 3
Accessories
Product Acc essory
1
Memory • 64MB 100MHz ECC SDRAM DIMM
•
128MB 100MHz ECC SDRAM DIMM
•
256MB 100MHz ECC SDRAM DIMM
•
1MB Video RAM
Processors • Pentium II 450MHz, 512KB L2 cache
•
Pentium III 500MHz, 512KB L2 cache
•
Pentium III 550MHz, 512KB L2 cache
Internal Storage • 4.2GB Ultra/Wide SCSI disk drive (7,200rpm)
•
9.1GB Ultra/Wide SCSI disk drive (7,200rpm)
•
18.26GB Ultra/Wide SCSI disk drive (7,200rpm)
•
9.1GB Ultra/Wide SCSI disk drive (10,000rpm)
•
4.2GB hot-swap Ultra/Wide SCSI disk drive (7,200rpm)
•
4.2GB hot-swap Ultra/Wide SCSI disk drive (10,000rpm)
•
9.1GB hot-swap Ultra/Wide SCSI disk drive (7,200rpm)
•
9.1GB hot-swap Ultra/Wide SCSI disk drive (10,000rpm)
•
18.2GB hot-swap Ultra/Wide SCSI disk drive (7,200rpm)
Disk Controllers & SCSI Cables • HP NetRAID-1 Disk Array Controller (1 channel)
•
HP NetRAID-3Si I2O Disk Array Controller (3 channels)
•
HP Ultra/Wide SCSI PCI Controller
•
2.5m SCSI Cable to connect from HP NetRAID Family Controller
to External Storage
•
HP NetServer LC 3 Internal SCSI Cable Kit
2
3
Product No.
D6097A
D6098A
D6099A
D4219A
D7032A
D7129A
D8583A
D4910A
D4911A
D7176A
D7049A
D3583C
D4903A
D4289A
D6019A
D5039A
D4992A
D5955A
D5025A
D6020A
D5968A
External Storage Solutions • HP NetServer Rack Storage/6
•
HP NetServer Rack Storage/12 (Ultra2 SCSI)
•
HP NetServer Rack Storage/12 SCSI Card
Backup Devices
4
•
Internal HP SureStore T20i Travan TR-5 tape drive
•
Internal HP SureStore DAT8i DDS-2 tape drive
•
Internal HP SureStore DAT24i DDS-3 tape drive
•
Internal HP SureStore DLT 40i DLT 4000 tape drive
•
External HP SureStore T20e Travan TR-5 tape drive
•
External HP SureStore DAT8e DDS-2 tape drive
•
External HP SureStore DAT24e DDS-3 tape drive
•
External HP SureStore DLT 40e DLT 4000 tape drive
•
External HP SureStore DAT24x6e DDS-3 Autoloader
Network Interface Cards • HP NetServer 10/100TX PCI LAN adapter
•
HP DeskDirect 10/100VG PCI LAN adapter
D3604B
D5989A
D6025A
C4394A
C1528J
C1555C
C5647A
C4395A
C1529J
C1556C
C5679A
C1559B
D5013A
J2585B
5
5
6
specifications
HP NetServer LC 3
Accessories
Product Acc essory
Remote Management • Integrated HP Remote Assistant
•
HP TopTools Remote Control card
•
Optional AC adapter for HP TopTools Remote Control card
1
Product No.
Included
D6028A
D6138A
Uninterruptible Power Supply UPS devices are available from American Power Conversion (APC).
For additional information, contact your local APC reseller, or see
APC’s Web page at http://www.apcc.com .
•
HP NetServer LC II to LC 3 upgrade kit
Upgrades
Monitors • HP 50 15" Color Monitor
•
HP M500 15" Color Monitor
•
HP 70 17" Color Monitor
•
HP M700 17" Color Monitor
Disk Tray • 3.5-inch hard disk drive mounting trays (3-pack, non-hot-swap)
•
Tape/DAT/CD-ROM mounting trays (3-pack, no front panel)
•
Hot-swap disk mounting tray (for selected third-party drives)
•
2-meter rack with side panels and rear door
•
2-meter rack only
•
HP NetServer LC II/LC 3 rackmount kit
HP NetServer Racks
7
6
D6135A
D2826A
D2832A
D2837A
D2838A
D2198A
D2199A
D3349B
J1487B
J1488A
J1456B
HP SupportPack Offer ing
Support can be delivered either by your local reseller or by the Hewlett-Packard Customer Support organization. For more
information, visit our Web site at www.hp.com/go/netserver .
HP SupportPack Order No.
3-year onsite support, 4-hour response (standard business hours)
3-year onsite support, 4-hour response (24 hours/day, 7 days/week)
3-year onsite support, Hardware Call-to-Repair Commitment service within a maximum of 6 hours
Onsite installation and network configuration
Comprehensive Technical Support
1
Please see the
accessories.
2
2.5m SCSI Cable 68-pin male ultra-high-density offset connector to 68-pin male high-density connector.
3
Use in HP NetServer LC 3 when HP NetRAID Family Controller is used with internal storage.
4
HP SureStore offers a complete range of tape backup solutions for HP NetServers. For more information on
HP SureStore tape backup products, please check the
SureStore Web site at http://ww.hp.com/storage.
5
One-Button Dis as ter Re cov ery wi ll be available with these backu p dev ices May 1, 1999.
6
HP NetServer LC I I to LC 3 upgrade kit includes system board and 64MB 100MHz ECC SDRAM
7
For additional rack accessories and kits, please see the
http://www.hp.com/netserver/products/racks. Use HP NetServer Rack Assistant to
configure your complete rackmount ed solution.
HP NetServers Configuration Guide
for important technical information when choosing your
HP NetServers Configuration Guide
HP NetServer Rack Configuration Guide
H5519A
H5513A
H1820A
H5751A
H1847A
or go to the HP
or
7
specifications
HP NetServer LC 3
LC 3 Hot-Swap Drive Model
8S WR 3HQWLXP,, 0+] 0+]RU
3HQWLXP ,,, 0+] 0+] SURFHVVRUV ZLWK
.% LQWHJUDWHG ZULWHEDFN (&& FDFKH
8S WR *% WRWDO (&&
6'5$0 ',00 PHPRU\
+DOIKHLJKW
KRWVZDS VKHOYHV
8
specifications
HP NetServer LC 3
Specifications
Operating Temperature
Operating Humidity
Acoustic Emissions
Power Supply
Power Availability
Power Consumption
System Dimensions
System Weight
41 to 95 degrees F (5 to 35 degrees C)
20% to 80% noncondensing
Sound pressure (LpA): <55 dB(A), bystander position
Auto-ranging 90 to 240 VAC at 47–63Hz
350W maximum
470W; recommended UPS 700VA and 1000VA
21.7"H x 8.5"W x 20.8"D (552mm H x 217mm W x 527mm D)
46-60lbs (21-27.5kg), depending on configurat ion
Choose Your HP NetServer LC 3
Model Storage Processor ECC Memory HDD Product No*
HP NetServer LC 3 PII/400 Model 1 Hot-Swap Pentium II 400MH z 64MB None D6125A
HP NetServer LC 3 PII/400 Model 4 Hot-Swap Pentium II 400MHz 64MB 4.2GB D6126T
HP NetServer LC 3 PII/450 Model 1 Hot-Swap Pentium II 450MH z 64MB None D7028A
HP NetServer LC 3 PII/450 Model 9 Hot-Swap Pentium II 450MHz 64MB 9.1GB D7030T
HP NetServer LC 3 PIII/500 Model 1 Hot-Swap Pentium III 500MHz 64MB None D7126A
HP NetServer LC 3 PIII/550 Model 1 Hot-Swap Pentium III 550MHz 64MB None D8591A
* Product availability varies from country to country. Please check with your reseller for details.
HP Select Express Program:
HP NetServer LC 3 is also available through
HP Select Express Program. This program
offers custom integration of HP hardware
offered at HP’s lowest price. For more
information visit our Web site at:
http://www.hp.com/netserver/products/sep.
IBM and OS/2 are registered trademarks of IBM Corporation. Intel and Pentium are U.S. registered trademarks of, and Xeon is a trademark of, Intel Corporation.
Microsoft and Windows NT are registered trademarks of Microsoft Corporation. Novell and NetWare are registered trademarks of, and IntranetWare is a
trademark of, Novell, Inc. OpenView is a trademark of
Hewlett-Packard Company. SCO and UnixWare are registered trademarks of, and OpenServer is a trademark of, The Santa Cruz Operation. All other brand
names are trademarks of their respective owners.
Information in this document is subject to change without notice.
© Copyright Hewlett-Packard Company 1999. All Rights Reserved. Reproduction, adaptation, or translation without prior written permission is prohibited, except
as allowed under the copyright laws.
Printed in USA M0599
For the latest information
HP NetServer Web site
HP NetServer FTP Site
HP Fax Response system 1-208-344-4809
http://www.hp.com/go/netserver
ftp://ftp.hp.com/pub/servers
(available worldwide, fax only)
9
Loading...
