User's Manual

Digital Satellite Receiver

KSC-570

General Safety

Warning

Always follow these instructions to avoid the risk of injury to

yourself or damage to your equipment.

Unplug the receiver from the AC power outlet before cleaning.

Use only a damp cloth for cleaning the exterior of the receiver.

Do not use accessories or attachments not recommended by the receiver manufacturer

as they may cause problems to the equipment and will void the warranty.

Do not place the receiver on an unstable cart, stand, tripod, bracket, or table.

The receiver may fall, causing serious personal injury and damage to the receiver.

Do not block or cover the slot opening in the receiver.

These are provided for ventilation and protection from overheating.

Never place the receiver near or over a radiator or any heat source.

Do not place the receiver in an enclosure such as a cabinet without proper ventilation

Do not stack the receiver on top of or below other electronic devices.

The apparatus shall not be exposed to dripping or splashing and with no object filled with liquids,

such as vases, shall be placed on the apparatus.

Operate the receiver using only the type of power source indicated on the marking label.

Unplug the receiver power cord by gripping the power plug, not the cord.

General Safety

Route power supply cord so that are not likely to be walked on or pinched by items

placed upon or against them. Pay particular attention to the cords that plugs in the convenience receptacles,

and the point where they exit from the unit.

Use an outlet that contains surge suppression or ground fault protection.

For added protection during a lightning storm, or when the receiver is left unattached

and unused for long periods of time, unplug it from the wall outlet and disconnect

the lines between the receiver and the antenna. This will provide some protection

against electrical damage caused by lightning or power line surges.

Servicing

Do not attempt to service the receiver yourself, as opening or

removing covers may expose you to dangerous voltage,

and will void warranty.

Refer all servicing to authorized service personnel.

DIGITAL SATELLITE RECEIVER OWNER’S MANUAL SIMPLE & SPEEDY

OPERATION HANDBOOK

Before operation,

Please read the entire manual thoroughly

and retain it for future reference.

Channel Search

Channel List

Edit Channel List

Program Guide

System Setting

Common Interface

Utility (Option)

Contents

Remote Control Unit ...........................................................................

Front Panel ..........................................................................................

Rear Panel ..........................................................................................

Connecting Your Equipment ...............................................................

Basic Operation ..................................................................................

Menu Guide ........................................................................................

Easy Installation .......................................................................................

Main Menu ............................................................................................

Channel Search .......................................................................................

Channel Search / Installation (None, DiSEqC Switch) ...........................................

Channel Search / Installation (DiSEqC 1,2) .......................................................

Channel Search / Installation (USALS) ............................................................

Channel List ...........................................................................................

Edit Channel List ......................................................................................

Program Guide ........................................................................................

System Setting ........................................................................................

Menu Language ....................................................................................

Audio Language ....................................................................................

Subtitle Language ..................................................................................

SCART Output (option) ............................................................................

Screen Type .........................................................................................

Banner Time ........................................................................................

RF Mode (option) ...................................................................................

RF Channel (option) ................................................................................

Local Time ..........................................................................................

DIGITAL SATELLITE RECEIVER

Contents

Menu Transparency ............................................................................

Change PIN Code ............................................................................

Parental Lock .................................................................................

Receiver Lock .................................................................................

Menu Lock .....................................................................................

S/PDIF Output (option) ........................................................................

Auto Power (option) ...........................................................................

Factory Reset ..................................................................................

System Information ............................................................................

Common Interface .................................................................................

Utility (option) .......................................................................................

PVR Guide (Option Function) ....................................................................

Recording ......................................................................................

Record Menu ..................................................................................

File List .........................................................................................

Fast-Forward & Rewind .......................................................................

Quick Search ..................................................................................

Slow-Motion ...................................................................................

Time-Shift ......................................................................................

Instant-Replaying ..............................................................................

Delayed Recording ............................................................................

Format HDD ....................................................................................

Troubleshooting ................................................................................

Technical Specifications ...................................................................

Menu Map .........................................................................................

DIGITAL SATELLITE RECEIVER

Remote Control Unit

DIGITAL SATELLITE RECEIVER

Remote Control Unit

DIGITAL SATELLITE RECEIVER

Front Panel

1. POWER Switch the receiver power “ON” or “OFF”.

2. CH …/†( Program… / †) Channel Up/Down or select item of sub-menu.

3. VOL - / + ( Program / ) Volume Up/Down or select item of sub-menu.

4. OK Select a program, a highlighted line or parameter value.

5. EXIT Exit from parameter and cancel selected function.

6. MENU To see main menu.

7. SEG. DISP. 4-digit 7-segment display channel information.

8. CAM Slots (Depending on model)

2 Slots for Common Interface CAM (VIACCESS, IRDETO,

NAGRAVISION, CRYPTOWORKS, CONAX) with SmartCard.

DIGITAL SATELLITE RECEIVER

Rear Panel

1. POWER SUPPLY 90 ~ 250V AC, 50/60Hz.

2. S/PDIF Output for connection to a digital amplifier.

3. SCART FOR VCR Connect this port to the VCR via SCART cable.

4. SCART FOR TV Connect this port to the TV via SCART cable.

5. VIDEO Video connection port to the TV or other equipment.

6. AUDIO Audio connection port to the TV or other equipment.

7. 0/12V To connect 12V to an external 0/12V switch.

8. TV OUT To connect a TV via a coaxial cable.

9. ANT IN To connect to television antenna input.

10. RS-232 To connect to a personal computer for software upgrade.

11. LNB To connect to a satellite antenna and cable jacks.

12. LOOP THROUGH Used to connect a RF signal from the STB to either the RF

input jack on your television or to the STB.

DIGITAL SATELLITE RECEIVER

Connecting Your Equipment

How to connect your STB to various systems

There are several ways of connecting the STB to your TV, VCR and/or Hi-Fi SYSTEM. Consult your local supplier for assistance in setting-up your system that is best suited to your requirements.

1. Connect STB to a TV set

Connect your STB to a TV set with SCART, if your TV set is equipped for it. Alternatively you can use A/V, TV out (UHF) or S/Video jacks.

2. Connect STB to a VCR

Connect the SCART jack from the VCR to the back of your STB. Alternatively you can use A/V, TV out (UHF) or S/Video jacks.

3. Connect STB to a Hi-Fi System

Connect a RCA stereo cable from the AUDIO L/R jacks, S/PDIF on your STB to the LINE, AUX, SPARE or EXTRA input jacks on your Hi-Fi System.

DIGITAL SATELLITE RECEIVER

Connecting Your Equipment

4. Connect STB to a Digital Audio System

If you have a DAC with S/PDIF coaxial cable input, you can connect the STB with it to enjoy higher quality sound. Connect S/PDIF coaxial cable to a digital amplifier.

5. Loop Through

If you have another analogue or digital STB and you wish to use the same LNB then you can connect it via the loop through. Connect one end of the coaxial cable to the Loop Through on the STB and connect the other end to the LNB IN on your second STB.

CAM (Conditional Access Module) and Smart Card

CAUTION

Please do not plug in the main power supply cord until you have finished all of the connections!

If you want to enjoy watching scrambled broadcasting channels, you need to purchase the CAMs and smart cards from a service provider’s sales department. However, broadcasting channels from multiple service providers call for multiple CAMs and Smart cards. STB which who have only the CAMs and smart cards provided by the one service provider can show several broadcasting channels of the provider.

Please refer to manuals provided by service providers for details because the CAM and smart

cards are featured with unique menus, apart from menus given by STB. Watching "Free-To-Air" channel is available regardless of the CAM and smart cards. As service providers download new information to smart cards if necessary, those who have CAMs and smart cards should always put the smart cards in proper slots.

DIGITAL SATELLITE RECEIVER

Connecting Your Equipment

TV with Terrestrial Antenna

1. Connect one end of RCA/Cinch cable to

the RCA/Cinch jack on the back of the STB

and the other end to a RCA/Cinch jack on

your TV.

If your TV doesn’t have a RCA/Cinch jack,

connect one end of RF cable to the TV OUT

on the back of the STB and the other end to

a RF input jack on your TV.

2. Connect one end of RF cable to the ANT IN

on the back of the STB and the other end to a

terrestrial antenna connection or the jack for

the public antenna on the wall.

3. Finally connect the coaxial cable from the LNB to the LNB IN jack on back of the STB.

TV with Motorized System (DiSEqC 1.2)

(To RCA/Cinch on your TV)

(If your TV doesn’t have RCA/ Cinch Jack)

1. Connect one end of RCA/Cinch cable to the

RCA/Cinch jack on the back of the STB and

the other end to a RCA/Cinch jack on your TV.

If your TV doesn’t have a RCA/Cinch jack,

connect one end of RF cable to the TV OUT

on the back of the STB and the other end to a

RF input jack on your TV.

2. Connect one end of your coaxial cable to

the LNB IN connector on the STB and

the other end to the REC or Receiver

connector on the DiSEqC 1.2 motor.

3. Connect the coaxial cable from the LNB to the LNB connector on the DiSEqC 1.2 motor.

DIGITAL SATELLITE RECEIVER

(To RCA/Cinch on your TV)

(If your TV doesn’t RCA / Cinch Jack)

Connecting Your Equipment

Reference

1. DiSEqC 1.0 Connection

All our receivers are designed to be DiSEqC 1.0 and DiSEqC 1.2 compatible.

This allows multiple antennas to be connected to the STB at the same time.

If you have two or more fixed antennas or LNBs then we recommend you use a DiSEqC 1.0 switch.

Connect the coaxial cable from the first LNB to the LNB 1 or LNB A input connector of the DiSEqC switch.

Do the same for any other LNBs that you have.

Connect one end of a coaxial cable to the RF output connector of the DiSEqC switch,

connect the other end to the LNB IN socket on the STB.

2. DiSEqC 1.2/ USALS Connection

To the digital receiver, you can connect either a single satellite antenna directly or LNB of multi-feed

equipment.

When installing the USALS please consult and receive assistance from an installation specialist,

or ensure that the 0-degree angle of the motor is facing due south when installing,

for proper operation.

DIGITAL SATELLITE RECEIVER

Connecting Your Equipment

Front Panel Display Message

KEY & DISPLAY The message of the 7-segment LED (Light-Emitting Diode) on the STB

Standby Mode Current Program Number on TV List

System Booting Current Program Number on Radio Location

Power Off TV Mode

MICOM Version STB Mode

Boot Loader Version

Download

Down Load Procedure

and keys are explained as below.

Upgrade

Upgrade Procedure

Upgrade Complete

DIGITAL SATELLITE RECEIVER

Basic Operation

Basic Function

1. Program Information

After the television channels have been programmed, you will see the information box each time you change the channels.

1. Every time you change channels you will receive program information for a

few seconds. (In the “Banner Time” menu you can select how long this

information will be shown.)

2. You may change channel lists with the UP or DOWN button.

You can get “Channel Banner” on the bottom of the screen.

3. When you press the COLOR button, you can use banner as a simple channel

operation. In this case, you can get a simple EPG on right view.

2. Favorite Banner

1. During “Channel Banner” is appearing, when you press SUB-T(RED)

Button, you can get “Favorite Banner” and “Lock Banner”.

2. If you already made your favorite channel in “Channel Control” menu,

you can get favorite channel on this view.

3. The banner will disappeared automatically after banner-time out.

3. Now-Information Banner

1. During “Channel Banner” is appearing, when you press GREEN

Button, you can get “Now-Information Banner”.

2. Using “Now-Information Banner”, you can get a simple EPG of

“Now-Information”.

DIGITAL SATELLITE RECEIVER

Basic Operation

Basic Function

4. Next-Information Banner

1. During “Channel Banner” is appearing, when you press YELLOW Button,

you can get “Next-Information Banner”

2. Using “Next-Information Banner”, you can get a simple EPG of

“Next-Information”.

5. Channel-Information Banner

1. During “Channel Banner” is appearing, when you press INFO(BLUE) Button,

you can get “Channel-Information Banner”.

2. Using “Channel-Information Banner”, you can get a detailed channel listing

information.

DIGITAL SATELLITE RECEIVER

6. Volume Control/Mute

1. To control audio volume, press Volume / Volume buttons.

2. Volume control bar will be appeared in bottom of the TV screen

3. After time-out in 1 second, volume control bar will disappear.

To temporarily stop the volume, press the MUTE button.

To cancel mute, press the MUTE button again or press

the Vol ume / Volume buttons.

+ 40 hidden pages
