Data sheet
HP Officejet Pro 6230 ePrinter
Stand out with affordable business printing.
Enjoy professional colour
documents and eye-catching
marketing materials – for up to
50% less cost per page than
lasers.1This ePrinter is designed for
productivity and mobile printing to
keep business moving – at work,
home or on the go.
2
Enjoy professional colour for less than lasers.
●
Look professional with every page, using Original HP pigment inks for vibrant, durable prints.
●
Count on a better value for frequent printing with Original HP high-yield individual ink cartridges.
●
Boost productivity with speeds up to 18 pages per minute (ppm) black-and-white and 10 ppm
5
colour.
●
Save up to 50% on paper with automatic two-sided printing of documents and borderless colour
brochures.
1
3
4
Print speed: Up to 18 ppm black ISO (A4); Up to
10 ppm colour ISO (A4)
Paper handling: Automatic 2-sided printing
Duty cycle: Up to 15,000 pages (A4)
RMPV: 200 to 800 pages
Print on your terms.
●
Print wirelessly from your smartphone, tablet and notebook – no router or access to local network
required.
●
Print photos, documents and more when you're on the go – from virtually anywhere – using HP
ePrint.
●
Easily connect to your local network and the Internet, wirelessly or using the 10/100 Ethernet
port.
●
Boost productivity with the free HP All-in-One Printer Remote mobile app for high-quality mobile
scanning.
6
7
8
9
Work smarter and effortlessly.
●
Reload paper less often and handle large print jobs, using the 225-sheet paper tray.
●
Depend on a printer with an up to 15,000-page monthly duty cycle – the perfect fit for reliable
colour printing.
●
Lock in quality. For fast-drying results that resist fading for decades, HP recommends ColorLok®
3
paper.
Conserve resources without sacrificing performance.
●
Use up to 50% less energy compared with the majority of colour laser AiOs.
●
Use up to 80% less supplies and packaging by weight compared with lasers.
●
Help reduce energy costs. This ePrinter turns off automatically when it’s not needed.
●
Reduce your environmental impact – easily recycle your Original HP ink cartridges for free.
10
11
12
13
Page 2
HP Officejet Pro 6230 ePrinter
Technical specifications
Functions
Print speed
Print resolution
Print technology
Print Area
Print languages
Print capabilities
Print cartridges number
Mobile printing capability
Monthly dutycycle
Automatic papersensor
Processor speed
Display
Wireless capability
Connectivity
Memory
Media types
Media sizes
Media Handling
Printer smart softwarefeatures
Printer management
Print
General Office (black) Upto 29 ppm; General Office (colour)Up to 24 ppm
First page out: Asfast as 14 sec black (A4, ready);As fast as 17 sec colour (A4,
ready)
After first page.See http://www.hp.com/go/inkjetprinter fordetails. Print speed
may vary depending on thetype of output.
Up to 600 x1200 dpi black; Up to 600 x 1200 dpicolour
HP Thermal Inkjet
Print margins: Top: 2.9 mm; Bottom:2.9 mm; Left: 2.9 mm; Right: 2.9 mm
HP PCL 3 GUI, HPPCL 3 Enhanced
Borderless printing:Yes (up to 210 x 297mm); Direct print supported: Storage
devices not supported
4 (1 each black,c yan,magenta, yellow)
HP ePrint; Apple AirPrint™;Mopria™-certified; Wireless Direct Printing
Up to 15,000 pages(A4); Recommended monthly page volume: 200to 800
No
500 MHz
Buttons (Power, Cancel, Resume,Information, Wireless, Wi-fi Direct,ePrint, Media
Size), LEDs (Ink colour for Black, Magenta, Cyan,Yellow, Resume,Wireless, Wi-fi
Direct, ePrint, Media size)
Yes, built-in Wi-Fi 802.11b/g/n
Standard: 1 Hi-SpeedUSB 2.0; 1 Ethernet; Wi-Fi 802.11b/g/n
Standard: 256 MB;Maximum: 128 MB DDR3, 2 KB EEPROM, 128 MB SPIFlash
Plain paper, HP PhotoPapers, HP Matte Brochure or ProfessionalPaper, HPMatte
Presentation Paper, HP GlossyBrochure or Professional Paper, otherphoto inkjet
papers, other matteinkjet papers, other glossy inkjet papers, inkjet hagaki,photo
hagaki, thick plain paper
A4, A5, A6, B5(JIS),Index card A4, 13 x 18 cm, 10 x 15cm, Envelope C5, Envelope
C6, Envelope DL;Custom: 101.6 x 127 mm to 215 x355 mm (simplex); 101.6 x
140 mm to 215x 309 mm (auto duplex)
Input standard: 225-sheetinput tray; Up to 60 sheets photo paper;Maximum
envelopes: Up to15 envelopes
Output standard: 60-sheetoutput trayMaximum: Up to 60 sheets
Duplex printing: Automatic(standard)
Orientation: Portrait/Landscape; Print onBoth Sides: None/Flip on Long Edge/Flip
on Short Edge; Pagesper Sheet: 1, 2, 4, 6, 9, 16 (i.e. N-upprinting); Quality
Settings: Draft/Normal/Best; Colour:Black & White/Colour; Printing Shortcuts;Print
in Greyscale:Of f/High Quality Greyscale/BlackInk Only; Pages Per Sheet Layout:
Right then Down/Down thenRight/Left then Down/Down then Left; Borderless
Printing: Off/On;HP Real Life Technologies:Off/On; Booklet: None/Booklet-Left
Binding/Booklet-Right Binding;Pages to Print: Print All Pages/PrintOdd Pages
Only/Print EvenPages Only; Print in Max DPI: No/Yes; Page Borders: Off/On
No
What's inthe box
Supplies
Compatible operatingsystems
Minimum systemrequirements
Software included
Media weight
Printer dimensions (Wx D x H)
Package dimensions(W x D x H)
Printer Weight
Package weight
Operating environment
Storage
Acoustics
Power
Certifications
Country oforigin
Warranty
Service and support
E3E03A HP OfficeJet Pro6230 ePrinter; Power cord; HP 934Setup Black Ink
Cartridge (~300 pages); HP935 Setup CMY Ink Cartridge (~380 pages); UserGuide;
Set up poster
C2P19AE HP 934 BlackOriginal Ink Cartridge ~400 pages
C2P20AE HP 935 CyanOriginal Ink Cartridge ~400 pages
C2P21AE HP 935 Magenta OriginalInk Cartridge ~400 pages
C2P22AE HP 935 Yellow Original Ink Cartridge ~400pages
C2P23AE HP 934XL High YieldBlack Original Ink Cartridge ~1,000 pages
C2P24AE HP 935XL High YieldCyan Original Ink Cartridge ~825 pages
C2P25AE HP 935XL High YieldMagenta Original Ink Cartridge ~825 pages
C2P26AE HP 935XL High YieldYellow Original Ink Cartridge~825 pages
F6U78AE HP 935XL OfficeValue Pack-75 sht/A4/210x 297 mm
C6818A HP ProfessionalGlossy Inkjet Paper-50 sht/A4/210x 297 mm
Q6593A HP ProfessionalMatt Inkjet Paper-200 sht/A4/210x 297 mm
CHP710 HP All-in-OnePrinting Paper-500 sht/A4/210 x 297mm
For information oncartridge page and photo yields, see
http://www.hp.com/go/pageyield.
Windows 10 (32-bit/64-bit), Windows8.1 (32-bit/64-bit), Windows 8
(32-bit/64-bit), Windows 7 (32-bit/64-bit), WindowsVista (32-bit/64-bit); Mac OS X
v10.7, v10.8 or v10.9; Linux(for more information, see
http://hplipopensource.com/hplip-web/index.html)
Windows: Windows 10, 8.1,8, 7: 1 GHz 32-bit (x86) or 64-bit (x64) processor,2 GB
available harddisk space, Internet Explorer, CD-ROM/DVD or Internet,USB;
Windows Vista: 800 MHz32-bit (x86) or 64-bit (x64) processor, 2 GB availablehard
disk, Internet Explorer, CD-ROM/DVDor Internet, USB
Mac: Mac OS X Lion,OS X Mountain Lion, OS X Mavericks: 1GB available hard disk
space, Internet,USB
HP Printer Software,Google Toolbar, HP Update, Shopfor Supplies Online
Media Weight Recommended:60 to 105 g/m² (plain); 220 to280 g/m² (photo); 75
to 90 g/m²(envelope); 163 to 200 g/m²(card)
464 x 385 x 145.5mm
508 x 194 x 449mm
5.1 kg
7 kg
Temperature:5 to 40ºC, Humidity: 20 to 80% RH(non-condensing)
Temperature:-40 to 60ºC, Humidity: 20 to 90% RH(non-condensing)
Acoustic power emissions:6.8 B(A)(normal mode mono); 6.4 B(A)(normal mode
colour);Acoustic pressure emissions: 63 dB(A) (draftprinting mono); 61 dB(A)
(normal printing mono)
Requirements: Input voltage:100 to 240 VAC (+/- 10%),50/60 Hz (+/- 3 Hz)
Consumption: 24 watts(maximum), 3.3 watts (active), 0.5 watts (manual-off), 1.16
watts (sleep)
Power supply:Internal
EU EMC Directive2004/108/EC, CISPR 22: 2008/EN 55022: 2010 Class B, EN
55024: 2010, EN 61000-3-2: 2006+A1:2009 +A2:2009, EN 61000-3-3: 2008
(Europe); ENERGYSTAR® qualified
Made in Thailand
Standard one-yearHP limited hardware warranty. Three-yearHP limited hardware
warranty after registrationwithin 60 days of purchase (see
www.hp.com/eu/3yearwarranty).Warranty and support options vary byproduct,
country and locallegal requirements.
UG185E HP 3 yearCare Pack w/Standard Exchangefor Single Function Printers
UG060E HP 3 yearCare Pack w/Next Day Exchangefor Single Function Printers
(UG185E: all EMEA countries,UG060E: only Austria, Baltics, Belgium,Denmark,
Finland, France, Germany, Ireland, Italy, Netherlands, Norway,Portugal, Spain,
Sweden, Switzerland, UK,Czech, Greece, Hungary, Poland,Slovakia)
Footnotes
1
Cost-per-page(CPP) claim compares the majorityof multi-pass colour laser printers< €200 excluding VAT, as ofFeb 2014 based on market share asreported by Q4 2013 IDC. CPP forlaser supplies are based on published specificationsof the manufacturers’ highest
capacity cartridges. HP OfficejetPro CPP based on HP 934XL/935XL ink cartridges estimatedstreet price, published yield and continuousprinting. Actual prices may vary. Actual yieldsmay vary based on images printed and otherfactors. See
hp.com/go/learnaboutsupplies.2Local printing requiresmobile device and printer to beon the same wireless network or havea direct wireless connection. Wirelessperformance is dependent on physical environment anddistance from access point. Wireless
operations are compatible with 2.4 GHz operationsonly. Remote printing requires an Internetconnection to an HP web-connected printer.App or software and HP ePrint accountregistration may also be required. Wireless broadband use requiresseparately
purchased service contractfor mobile devices. Check with serviceprovider for coverage and availabilityin your area. See http://www.hp.com/go/mobileprinting formore details.3Fade resistancebased on paper-industry predictions foracid-free papers and Original
HP inks; colourantstability data at room temperaturebased on similar systems tested per ISO11798 and ISO 18909. Water resistancebased on HP internal testing, using paper withthe ColorLok® logo.4Based on HP 934XL HighYield Black Original Ink Cartridges and
HP 935XL High Yieldcolour ink cartridges. High-yield ink cartridgesnot included; purchase separately. Formore information, see http://www.hp.com/go/learnaboutsupplies. Valuecompared with estimated street priceand average page yield of standard-yield HP
934/935 ink cartridges. Actualpricing may vary.5After first setof ISO test pages. For more information,see http://www.hp.com/go/printerclaims.6Mobile device mustbe connected directly to the printer’swireless network prior to printing. Dependingon mobile
device, an appor driver may also be required. Wirelessperformance is dependent on physical environmentand distance from access point.7Check your compatibledevice's official app storefor HP ePrint app download availability.Requires an Internet connection to
an HP ePrint-enabledprinter. Printer requires ePrint accountregistration. App or software may berequired. Wireless operations arecompatible with 2.4 GHz operations only.Print times and connection speeds may vary. Wirelessbroadband use requires separately
purchased service contractfor mobile devices. Check with serviceprovider for coverage and availabilityin your area. Learn more athttp://www.hp.com/go/mobileprinting.8Wireless performanceis dependent on physical environment and distancefrom access point.
Wireless operationsare compatible with 2.4 GHz routersonly.9Mobile device requires wireless accesspoint and an Internet connection. Compatiblewith iPhone® 4 and later, iPad® 4th generation,iPad mini™, iPad Air™ and iPod® 5G using iOS7or later and mobile
devices using Android™4.0.x or later. Features controlledmay vary by mobile deviceoperating system. Scan/copy controlrequires mobile device andprinter be on the same wireless networkor through wireless direct connectionto printer. For mobile scanning, device
camera requires5 megapixels or greater with autofocuscapability.10Majority of multi-passcolour laser printers.11Compared with themajority of multi-pass colour laser printers.12HP Auto-Off Technology capabilities subject todevice and settings.13Program
availability varies. Original HPcartridge return and recycling is currently available in more than 50countries, territories and regions in Asia, Europeand North and South America through theHP Planet Partners program. For moreinformation, visit
http://www.hp.com/recycle.
http://www.hp.com/uk
The product coulddiffer from the images shown. © Copyright2016 HP Development Company,L.P. The information contained herein issubject to change without notice. The onlywarranties for HP products and services areset forth in
the express warrantystatements accompanying such products and services.Nothing herein should be construed asconstituting an additional warranty. HP shall notbe liable for technical or editorial errorsor omissions contained
herein.
4AA5-4923EEE, 11/16
