QuickSpecs
HPE Advanced Series Racks
Overview
Page 1
HPE Advanced Series Racks
Designed for server rooms to datacenters, the HPE Advanced Series Racks include a fully welded frame and advanced perforated
door design
With multiple size, width and depth options, Data Center managers can choose the right rack for the compute technology and
customize the rack solution with accessories to fit their computing environment.
convenience bracket to ease installation of cable management and power distribution and they are fully compatible with Locati
Discovery Services.
. HPE Advanced Series Racks provide durability and cooling capabilities with a streamlined appearance and function.
The Advanced Series also includes a rear
on
QuickSpecs
HPE Advanced Series Racks
Mod
els
Page 2
HPE Advanced Series Racks
600mm Wide Racks
HPE 48U 600mm x 1075mm Advanced Pallet Rack
H6J87A
HPE 48U 600mm x 1075mm Advanced Shock Rack
H6J88A
HPE 42U 600mm x 1075mm Kitted Advanced Pallet Rack with Side Panels and Baying
TL253A
HPE 42U 600mm x 1075mm Kitted Advanced Shock Rack with Side Panels and Baying
TL254A
HPE 42U 600mm x 1075mm Advanced Pallet Rack
H6J65A
HPE 42U 600mm x 1075mm Advanced Shock Rack
H6J66A
HPE 42U 600mm x 1200mm Advanced Pallet Rack
H6J67A
HPE 42U 600mm x 1200mm Advanced Shock Rack
H6J68A
HPE 36U 600mm x 1075mm Advanced Pallet Rack
H6J77A
HPE 36U 600mm x 1075mm Advanced Shock Rack
H6J78A
HPE 22U 600mm x 1075mm Advanced Pallet Rack
H6J83A
HPE 22U 600mm x 1075mm Advanced Shock Rack
H6J84A
HPE 14U 600mm x 1075mm Advanced Shock Rack
H6J82A
NOTE: HPE 14U and 22U Advanced Series Racks include side panels.
800mm Wide Racks
HPE 42U 800mm x 1200mm Advanced Pallet Rack
H6J69A
HPE 42U 800mm x 1200mm Advanced Shock Rack
H6J70A
Network Racks
HPE 42U 600mm x 1200mm Advanced Shock Network Rack
H6J72A
HPE 42U 800mm x 1200mm Advanced Shock Network Rack
H6J74A
QuickSpecs
HPE Advanced Series Racks
Standard Features
Page 3
At A Glance
r in the rack. Once the server knows exactly where it is located this information
Insight Control to automatically update new rack configuration.
The 800mm wide HPE Network Racks include slotted vertical cable channels on both sides in the rear of the rack.
Industry Standard
The HPE Advanced Series Racks are industry standard EIA-310 19 inch RETMA and will support all
Industry Standards
EIA
Conforms to EIA-310D Type A cabinet per section 4.1.1
UL/CES Certification
Yes
WEEE
Yes
RoHS compliant
Yes
TAA compliant
No
• Fully welded frame provides multiple planes of support in all directions
• 81% open perforation door design allows for more efficient cooling
• 3000 lbs static load and 2500 lbs dynamic load (rolling) weight capacities
• Capable of shipping up to 2250 lbs (rack plus installed equipment) using shock pallet options
• Cable management, rack stabilizer, baying, grounding kit and other options available allow you to customize your rack
• Tool less accessory mounting brackets in rear of rack for simple PDU integration
• Supports integrated servers asset management capabilities with HPE Location Discovery Services options
• Wide range of rack model configurations including kitted racks that include side panels and a baying kit
Innovative Breakthroughs
• Improved cooling with 81% total open area on HPE rack front doors
• Improved data center space utilization with high weight load capacities
• Improved asset integration and management with HPE Location Discovery Services
HPE Location Discovery Services
HPE Location Discovery Services is the first solution that merges the physical rack with IT equipment to provide automated
location awareness of installed servers for advanced asset management and workload placement.
HPE Advanced and Enterprise Series Racks equipped with the Location Discovery option provide detailed location information to
ProLiant servers to track new installations and equipment moves. Upon installation the server's iLO queries and records the rack
identifier as well as the exact U location of the serve
can be forwarded to other systems such as HPE OneView and HPE
This saves time in configuring hardware and software to manage the data center while eliminating constant manual updates and
the associated human errors that can slow resolution to issues and even cause down time and loss of business.
HPE Advanced Series Network Racks
HPE Network Racks are designed for dense network equipment. These racks have the front vertical rails moved back 75mm to
facilitate front to rear cabling and have additional bristle covered cable access slots in the front and on top of the racks to prevent
mixing of hot and cold air and to allow for large cable bundles. These racks are available in standard 600mm and 800mm widths.
Support
Compliance
HPE rack mountable equipment as well as third-party equipment designed to mount in 19-inch wide
racks.
QuickSpecs
HPE Advanced Series Racks
Service and Support
Page 4
Warranty / Service
HPE Racks are covered by a 3 year limited warranty.
HPE Foundation Care
For HPE ProLiant servers and storage systems, the service on the main product covers HPE-branded
branded rack hardware options that are qualified for inclusion with the server at
http://www.hp.com/services/bladesystemservices
Service and Support
NOTE: HPE Racks are supported as a part of the HPE Server Infrastructure. No separate HPE Care
HPE Technology Services delivers confidence, reduces risk and helps customers realize agility and
Coverage
For HPE ProLiant servers and storage systems, the service on the main product covers HPE-branded
hardware options not designated by HPE as requiring separate coverage, that are qualified for the
server, are purchased at the same time or afterward, and are internal to the enclosure, as well as HPEsupported and -supplied tower UPS products. These items will be covered at the same service level as
the main product.
Coverage of the UPS battery is not included; standard warranty terms and conditions apply.
Services
hardware options not designated by HPE
as requiring separate coverage, that are qualified for the server, are purchased at the same time or
afterward, and are internal to the enclosure, as well as HPE-supported and -supplied tower UPS
products. These items will be covered at the same service level as the main product.
For the BladeSystem enclosures, the service covers the enclosure, power supplies, fans and enclosure
devices including pass-thru, Ethernet interconnect and virtual connect modules. For ProLiant servers,
storage, or BladeSystem enclosures installed within a rack, service also covers all HPE qualified racks
and rack options including UPS products not exceeding 12kVA, KVM switches, consoles and power
distribution units installed within the same rack. The UPS battery is covered separately under its own
warranty terms and conditions, limited to the term of the applicable warranty period.
• HPE Services
o To help streamline implementation and enhance ongoing support of rack solution,
Hewlett Packard Enterprise provides cost-effective service options with resources
and specialized expertise to complement customers’ in-house capabilities.
• Installation and Startup services
o Take advantage of complete installation and implementation support-including
global rollout capabilities-to get rack solutions up-and-running rapidly, with minimal
business disruption.
• Rack Option Hardware Support
o Cover rack options with a single convenient service package. HPE Care Pack Services
for rack-mounted ProLiant DL servers and storage products provide support for all
HPEthe time of or after purchase. In addition, 22-inch and smaller external monitors,
tower units, and UPS options up to 3KVA are covered at the same service level and
for the same period as the server at no additional cost. Also covered are any
additional HPE-qualified rack options installed within the same rack.
HPE Care Pack Services help increase uptime and productivity with rapid response on a 24x7 or 13x5
basis. Both options feature same-day, 4-hour onsite assistance when service issues cannot be resolved
remotely. And both help enhance the return on server investment with proven HPE Services expertise
and consistent support levels across geographically dispersed sites.
NOTE: To learn more, please visit:
http://www.hp.com/services/proliantservices
Packs need to be purchased.
HPE Technology Services for Industry Standard Servers
QuickSpecs
HPE Advanced Series Racks
Service and Support
Page 5
stability. Connect to HPE to help prevent problems and solve issues faster. Our support technology lets
For more information
To learn more on services for HPE Server Options, please contact your Hewlett Packard Enterprise
http://www.hpe.com/info/serveroptions
you to tap into the knowledge of millions of devices and thousands of experts to stay informed and in
control, anywhere, any time.
sales representative or Hewlett Packard Enterprise Authorized Channel Partner. Or visit:
QuickSpecs
HPE Advanced Series Racks
Related Option
s
Page 6
Hewlett Packard Enterprise offers a full line of accessories and options that can be added to HPE Racks allowing you to customize
each rack to fit your IT requirements.
kits, drawers, shelving, and filler panels. To build a complete rack and power infrastructure for your IT env
Hewlett Packard
Enterprise also offers
KVM (keyboard, video, mouse) consoles and switches.
http://www.hp.com/
NOTE: 0D1 may appear after the above selected part numbers on yours sales order if factory integration is indicated.
HPE Location
Discovery
HPE 48U Location Discovery Kit
F9V74A
HPE 42U Location Discovery Kit
BW946A
HPE 36U Location Discovery Kit
BW945A
HPE 22U Location Discovery Kit
BW944A
HPE 14U Location Discovery Kit
BW943A
HPE Location Discovery Contact Cover Kit
NOTE:
Advanced integration with Insight Control requires Insight Control version 7.1.1 or
greater
http://www.hp.com/go/discoveryservices
BW942A
Rack Baying Kits
HP Rack Baying Kit
NOTE:
together. Includes (6) 24
30 Torx screws.
BW902A
HPE 1075-1200mm Offset Baying Kit
NOTE: This kit can be used to connect 42U 1075mm to 42U 1200mm racks. Includes
(3) 24-inch baying brackets, (3) 600mm baying brackets, and T-30 Torx screws.
BW941A
HPE 1M-1075mm Offset Baying Kit
NOTE:
racks. Includes (3) 24
Torx screws.
BW952A
Airflow Optimization
HPE Air Flow Optimization Kit
NOTE:
racks, and the clearance from the floor to the rack to prevent hot and cold air from
mixing thus optimizing the temperature at which the chilled air enters the racked
servers.
NOTE
automatically ship with the rack. This kit is recommended for all other bayed rack
configurations also.
BW930A
Sidewall Panel Kits
HP 42U 1075mm Side Panel Kit
BW906A
HP 42U 1200mm Side Panel Kit
BW909A
HPE 48U 1075mm Side Panel Kit
H6J91A
HP 36U 1075mm Side Panel Kit
BW898A
NOTE: The lightweight, locking side panels come in 3 sections for better handling.
NOTE: HPE 14U and 22U Advanced Series Racks include side panels.
Rack Stabilization Kits
HPE 600mm Rack Stabilizer Kit
BW932A
HPE 600mm Heavy Duty V2 Stabilizer Kit
BW961A
HPE 800mm Rack Stabilizer Kit
BW933A
NOTE: The anti-tip stabilizer kits provide stability and support when equipment is
installed, removed or accessed within the rack. Heavy Duty stabilizer kits should be
HPE Rack accessories include upgrades such as side panels, baying kits, cable management
ironment,
a full line of options that include power distribution units (PDU), uninterruptible power systems (UPS), and
See HPE Rack and Power Infrastructure for more complete information at:
go/rackandpower.
Kits
Location Discovery Services requires iLO Advanced v1.20 or greater.
. For additional information on HPE Discovery Services please go to
This kit can be used to connect HPE racks of the same U height and depth
-inch baying brackets, (6) 600mm baying brackets, and T-
This kit can be used to connect 42U 1075mm racks to 42U 1000mm depth
-inch baying brackets, (3) 600mm baying brackets, and T-30
The Airflow Optimization kit seals air gaps inside the rack, in between bayed
: When configuring racks through Factory Express, a Rack Optimization kit will
QuickSpecs
HPE Advanced Series Racks
Related Options
Page 7
used when a single racked component exceeds 200 lbs.
HP 9000 and 10000 Rack Ballast Kit
120672-B21
NOTE: The Ballast Kit is designed to provide additional stability and support when
used with the Stabilizer Kit. It is typically used when very heavy equipment is
routinely installed, removed or accessed within the rack. Compatible with
Advanced and Enterprise Series racks.
Tie Down Kit
HP 11K G2 Rack Tie Down Kit
AF076A
NOTE: The tie down kit is used to secure the rack to the datacenter floor for seismic
anchoring.
Universal 1U
Filler Panels
HP 1U 10-pack Black Universal Filler Panel
BW928A
HP 1U 100-pack Black Universal Filler Panel
BW929A
NOTE: The blanking panels are made from high grade molded plastic, and are
designed to be installed without tools. The use of blanking panels is recommended to
ensure proper airflow.
Rack Shelves
HP 10000 Rack 1U Monitor Utility Shelf
253449-B21
NOTE: This 1U fixed shelf can be mounted at any height to place a monitor or
another component within the rack. The shelf has a maximum weight capacity of 150
lb (68kg) and ships with bezels for both a 15” and 17” monitor.
HP 100kg Sliding Shelf
234672-B21
Adjustable Rails
Depth Adjustable Fixed Rail Kit
332558-B21
NOTE: The kit contains two depth adjustable rails that allow Hewlett Packard
Enterprise servers
party racks. Maximum weight capacity is 300 lb (136 kg).
Rack Light Kit
HPE Rack LED Light Kit
BW939A
NOTE: The Rack Light Kit is mounted under the roof of the rack and is used to
illuminate the rear section of the rack. The light is turned on and off with the opening
and closing of the rear doors.
Locking Drawer
HP 2U Universal Locking Drawer
NOTE:
sliding rails and is used to store CD's, Instruction manuals, tools, and any other items
that are frequently used at the rack. Drawer includes lock.
361591-B21
Cable Management
Kits
HPE Quarter Turn Hook and Loop 10 Pack Kit
BW963A
HPE Quarter Turn Hook and Loop 100 Pack Kit
BW964A
NOTE: Quarter turn hook and loop straps attach to the accessory bracket in the rear
of the rack without tools.
Compaq Cable Management D Rings
168233-B21
NOTE: This kit consists of 10 "D" rings that can be used for cable management.
HP Rack Cable Management Velcro Clips
379820-B21
HP Rack Cable Management Kit
NOTE:
panel with brush inserts, 2x crossover cable brackets, 10x D-rings, 10x hook and loop
straps 8 inch, 10x hook and loop straps 10 inch, mounting hardware.
AF099A
Rack Top Cable Trays
HP 600 Wide Rack Top Cable Tray
383982-B21
HP 800 Wide Rack Top Cable Tray
383983-B21
HP Rack Top Cable Mgmt Transfer Tray
NOTE:
Cable Trays to run overhead cables.
383984-B21
HPE
, storage, UPSs and other products to be mounted in HPE or third-
This product mounts on HPE Advanced and Enterprise Series racks with
The HPE Rack Cable Management Kit includes a 1U and 2U front cable entry
HPE Rack Top Cable Tray connects two aisles of racks with HPE Rack Top
QuickSpecs
HPE Advanced Series Racks
Related Options
Page 8
Rack Fan Kits
HP 10000 Rack Roof Mount Fan (110V) Kit
257413-B21
HP 10000 Rack Roof Mount Fan (220V) Kit
257414-B21
NOTE: The Rack Fan Kit mounted extractor fan kit enhances natural convection
cooling by increasing airflow in the rack. The Rack Roof Mount Fan Kit is not
compatible with 14U racks.
Grounding Kit
HP Rack Grounding Kit
BW891A
NOTE: The Rack Grounding Kit can be used to reduce the level of electromagnetic
emissions outside the rack. Includes (3) 6” Grounding Straps, (3) 14.5” Grounding
Straps, (6) 6” Gro
w/connectors.
Hardware Kit
HPE Rack Hardware Kit
H6J85A
NOTE: The HPE Rack Hardware Kit includes 24x M6 cage nuts, 24x M6x16 T25
screws, 10x 5mm thread clip nuts, 10x 6mm thread clip nuts, cage
Quarter turn hook and loop straps.
Rack Branding Kit
HPE Custom Door Branding Kit
BW935A
NOTE: Blank that allows you to customize the rack with rack location information,
branding, or other description information.
Enterprise Series Door
HPE 42U Front Door Kit
NOTE:
doors are made available for customers that wish to
door for uniformity of appearance in the datacenter.
BW934A
HPE Basic Distribution
Units
NOTE: HPE Basic PDU’s provide reliable, low-cost power distribution throughout the rack and are
available in both vertical and horizontal form factors to allow for flexible installation in your rack. For
more informatio
100-120V Input, Single Phase, North America/Japan
HPE G2 Basic 1.9kVA/IEC C20 Detachable 16A/120V Outlets (12) 5-20R/1U
Horizontal NA/JP PDU
P9Q31A
HPE G2 Basic 1.9kVA/IEC C20 Detachable 16A/120V Outlets (16) 5-20R/Vertical
NA/JP PDU
P9Q32A
HPE G2 Basic Modular 2.8kVA/L5-30P 24A/120V Outlets (6) IEC C19/1U Horizontal
NA/JP PDU
P9Q33A
HPE G2 Basic 2.8kVA/L5-30P 24A/120V Outlets (22) 5-20R/Vertical NA/JP PDU
P9Q34A
HPE G2 Basic 2.8kVA/L5-30P 24A/120V Outlets (16) 5-20R/2U Horizontal NA/JP
PDU
P9Q35A
NOTE: Models P9Q31A and P9Q32A include a C19 to NEMA 5-15 input power cord.
200-240V Input, Single Phase, Worldwide
HPE G2 Basic Modular 3.6kVA/IEC C20 Detachable 16A/100-240V Outlets (2)
C19/1U Horizontal WW PDU
P9Q36A
HPE G2 Basic 3.6kVA/IEC C20 Detachable 16A/100-240V Outlets (12) C13/1U
Horizontal WW PDU
P9Q37A
HPE G2 Basic 3.6kVA/IEC C20 Detachable 16A/100-240V Outlets (20) C13 (2)
C19/Vertical WW PDU
P9Q38A
HPE G2 Basic 9.2kVA/50A Term Block 40A/208V Outlets (30) C13 (6) C19/Vertical
WW PDU
P9Q49A
NOTE: Worldwide models do not include an input power cord. Please go to the
Related Options section and select the a
geographic location.
200-208V Input, Single Phase, North America/Japan
HPE G2 Basic Modular 4.9kVA/L6-30P 24A/208V Outlets (6) IEC C19/1U Horizontal
P9Q39A
unding Straps w/connectors, (6) 14.5” Grounding Straps
nut tool, and 5x
Doors are included in all HPE Advanced Series racks. Enterprise Series Rack
change the Advanced Series
n, please review the HPE Basic PDU QuickSpecs.
ppropriate input power cord for your
QuickSpecs
HPE Advanced Series Racks
Related Options
Page 9
NA/JP PDU
HPE G2 Basic 4.9kVA/L6-30P 24A/208V Outlets (12) C13/1U Horizontal NA/JP PDU
P9Q40A
HPE G2 Basic 4.9kVA/L6-30P 24A/208V Outlets (20) C13/Vertical NA/JP PDU
P9Q41A
HPE G2 Basic 4.9kVA/L6-30P 24A/208V Outlets (36) C13 (6) C19/Vertical NA/JP
PDU
P9Q42A
HPE G2 Basic Modular 8.3kVA/CS8265C 40A/208V Outlets (6) C19/1U Horizontal
NA/JP PDU
P9Q47A
HPE G2 Basic 8.3kVA/CS8265C 40A/208V Outlets (30) C13 (6) C19/Vertical NA/JP
PDU
P9Q48A
200-208V Input, Three Phase, North America/Japan
HPE G2 Basic Modular 3Ph 8.6kVA/L15-30P 24A/208V Outlets (6) C19/1U
Horizontal NA/JP PDU
P9Q52A
HPE G2 Basic 3Ph 8.6kVA/L15-30P 24A/208V Outlets (18) C13/Vertical NA/JP PDU
P9Q54A
HPE G2 Basic 3Ph 8.6kVA/L21-30P 24A/208V Outlets (24) C13 (3) C19 (3) 520R/Vertical NA/JP PDU
P9Q55A
HPE G2 Basic 3Ph 8.6kVA/L15-30P 24A/208V Outlets (30) C13 (6) C19/Vertical
NA/JP PDU
P9Q53A
HPE G2 Basic 3Ph 10kVA/CS8365C 28A/208V Outlets (36) C13 (6) C19/Vertical
NA/JP PDU
P9Q56A
HPE G2 Basic Modular 3Ph 14.4kVA/CS8365C 40A/208V Outlets (6) C19/1U
Horizontal NA/JP PDU
P9Q59A
HPE G2 Basic Modular 3Ph 17.3kVA/60309 60A 4-wire 48A/208V Outlets (6)
C19/1U Horizontal NA/JP PDU
P9Q60A
HPE G2 Basic 3Ph 17.3kVA/60309 60A 4-wire 48A/208V Outlets (18) C13 (6)
C19/Vertical NA/JP PDU
P9Q61A
HPE G2 Basic 3Ph 17.3kVA/60309 60A 4-wire 48A/208V Outlets (36) C13 (12)
C19/Vertical NA/JP PDU
P9Q62A
NOTE: Models P9Q61A and P9Q62A are double-sided models that have circuit
breakers on the back side of the unit.
220-240V Input, Single Phase, International
NOTE: Additional HPE Power Distribution Units are available. For a complete list of
all HPE PDUs and additional information: please visit http://www.hp.com/go/pdu.
HPE Metered Power
Distribution Unit
NOTE: HPE Monitored PDU’s provide reliable power distribution within your rack combined with highly
accurate power metering available for each power load segment. For more information, please review
the HPE Monitored PDU QuickSpecs
HPE Monitored Power Distribution Unit: 1U Version
HPE Metered 2.8kVA/L5-30P 24A/120V Outlets (12) 5-20R/Horizontal NA/JP PDU
D9N43A
HPE Metered 3.6kVA/60320 C20 Detachable 16A/230V Outlets (12) C13/Horizontal
WW PDU
D9N46A
HPE Metered 4.9kVA/L6-30P 24A/208V Outlets (12) C13/Horizontal NA/JP PDU
D9N44A
HPE Monitored Power Distribution Unit: Half Height Version
HPE Metered 3.6kVA/60320 C20 Detachable 16A/230V Outlets (16) C13/Vertical
WW PDU
D9N45A
HPE Monitored Power Distribution Unit: Mid Height Version
HPE Metered 4.9kVA/L6-30P 24A/208V Outlets (20) C13 (4) C19/Vertical NA/JP
PDU
D9N47A
HPE Metered 7.3kVA/60309 32A 3-wire/230V Outlets (20) C13 (4) C19/Vertical
INTL PDU
D9N48A
HPE Metered 3Ph 8.6kVA/L15-30P 24A/208V Outlets (18) C13 (3) C19/Vertical
NA/JP PDU
D9N51A
HPE Metered 3Ph 8.6kVA/L21-30P 24A/120-208V Outlets (18) C13 (3) C19 (3) 5-
D9N53A
.
QuickSpecs
HPE Advanced Series Racks
Related Options
Page 10
20R/Vertical NA/JP PDU
HPE Metered 3Ph 11kVA/60309 5-wire 16A/230V Outlets (18) C13 (3) C19/Vertical
INTL PDU
D9N55A
HPE Monitored Power Distribution Unit: Full Height Version
HPE Metered 8.3kVA/CS8265C 40A/208V Outlets (30) C13 (3) C19/Vertical NA PDU
D9N49A
HPE Metered 7.3kVA/60309 32A 3-wire/230V Outlet (32) C13 (4) C19/Vertical INTL
PDU
D9N50A
HPE Metered 3Ph 11kVA/60309 5-wire 16A/230V Outlets (30) C13 (3) C19/Vertical
INTL PDU
D9N57A
HPE Metered 3Ph 14.4kVA/CS8365C 40A/208V Outlets (12) C13 (12) C19/Vertical
NA/JP PDU
D9N58A
HPE Metered 3Ph 16.6kVA/60309 32A-30A 5-wire 24A/230V Outlets (30) C13 (3)
C19/Vertical NA/JP PDU
D9N61A
HPE Metered 3Ph 17.3kVA/60309 60A 4-wire 48A/208V Outlets (24) C13 (3)
C19/Vertical NA/JP PDU
D9N54A
HPE Metered 3Ph 17.3kVA/60309 60A 4-wire 48A/208V Outlets (12) C13 (12)
C19/Vertical NA/JP PDU
D9N59A
HPE Metered 3Ph 22kVA/60309 5-wire 32A/230V Outlets (12) C13 (12)
C19/Vertical INTL PDU
D9N60A
HPE Metered 3Ph 22kVA/60309 5-wire 32A/230V Outlet (30) C13 (3) C19/Vertical
INTL PDU
D9N56A
HPE Metered 3Ph 16.6kVA/60309 32A-30A 5-wire 24A/230V Outlets (12) C13 (12)
C19/Vertical NA/JP PDU
D9N62A
HPE Metered 3Ph 19.9kVA/L22-30P 24A/277V Outlets (30) RF-203P-HP/Vertical
NA PDU
D9N63A
HPE Environmental Sensor for Remote Monitored PDUs
HP Environmental Sensor for Remote Monitored and Managed PDUs
E2D53A
NOTE: Additional HPE Power Distribution Units are available. For a complete list of
all HPE PDUs and additional information: please visit http://www.hp.com/go/pdu
HPE Metered and
Switched
Distribution Unit
NOTE: HPE Managed PDU’s provide reliable power distribution combined with highly accurate power
metering and switching that provide you with the ability to monitor and control each outlet. For more
information, please review the HPE Managed PDU QuickSpecs.
100-120V Single Phase
HPE Metered Switched 2.8kVA/L5-30P 24A/120V Outlets (24) 5-20R /Vertical NA/JP
PDU
H8B48A
200-240V Single Phase
HPE Metered Switched 3.6kVA/60320 C20 Detachable 16A/230V Outlets (7) C13 (1)
C19/Vertical WW PDU
H8B49A
HPE Metered Switched 4.9kVA/L6-30P 24A/208V Outlets (20) C13 (4) C19/Vertical
NA/JP PDU
H8B50A
HPE Metered Switched 7.3kVA/60309 3-wire 32A/230V Outlets (20) C13 (4)
C19/Vertical INTL PDU
H8B51A
200-240V Three Phase
HPE Metered Switched 3Ph 8.6kVA/L15-30P 24A/208V Outlets (18) C13 (6)
C19/Vertical NA/JP PDU
H8B52A
HPE Metered Switched 3Ph 8.6kVA/L21-30P 24A/208V Outlets (20)C13 (3)C19
(1)5-20R/Vertical NA/JP PDU
H8B53A
HPE Metered Switched 3Ph 11kVA/60309 5-wire 16A/230V Outlets (21) C13 (3)
C19/Vertical INTL PDU
H8B54A
HPE Metered Switched 3Ph 14.4kVA/CS8365C 40A/208V Outlets (12) C13 (12)
C19/Vertical NA/JP PDU
H8B55A
HPE Metered Switched 3Ph 17.3kVA/60309 4-wire 48A/208V Outlets (12) C13 (12)
H8B56A
Power
QuickSpecs
HPE Advanced Series Racks
Related Options
Page 11
C19/Vertical NA/JP PDU
NOTE: Additional HPE Power Distribution Units are available. For a complete list of
all
HPE Intelligent Power
Distribution Unit
(iPDU)
NOTE: HPE Intelligent PDU’s deliver a unique set of capabilities that not only allow you to meter and
switch individual outlets, but also communicate directly with each server to understand and track
power usage, configur
Intelligent Power PDU QuickSpecs.
HPE 6 Outlet Intelligent Power Distribution Unit Cores
HPE Intelligent Modular 4.9kVA/L6-30P 24A/208V Outlets (6) C19/Horizontal NA/JP
PDU
AF520A
HPE Intelligent Modular 8.3kVA/CS8265C 40A/208V Outlets (6) C19/Horizontal
NA/JP PDU
AF521A
HPE Intelligent Modular 3Ph 8.6kVA/L15-30P 24A/208V Outlets (6) C19/Horizontal
NA/JP PDU
AF522A
HPE Intelligent Modular 3Ph 14.4kVA/CS8365C 40A/208V Outlets (6) C19/Horizontal
NA/JP PDU
AF533A
HPE Intelligent Modular 3Ph 17.3kVA/60309 60A 4-wire 48A/208V (6)
C19/Horizontal NA/JP PDU
AF523A
HPE Intelligent Modular 3Ph 17.3kVA/60309 30A 5-wire 24A/240V (6)
C19/Horizontal NA/JP PDU
AF901A
HPE Intelligent Modular 7.3kVA/60309 3-wire 32A/230V Outlets (6) C19/Horizontal
INTL PDU
AF525A
HPE Intelligent Modular 3Ph 11kVA/60309 5-wire 16A/230V Outlets (6)
C19/Horizontal INTL PDU
AF526A
HPE Intelligent Modular 3Ph 22kVA/60309 5-wire 32A/230V Outlets (6)
C19/Horizontal INTL PDU
AF527A
HPE 12 Outlet Intelligent Power Distribution Unit Cores
HPE Intelligent Modular 3Ph 17.3kVA/IEC 60309 60A 4-wire 48A/208V (12)
C19/Horizontal NA/JP PDU
AF535A
HPE Intelligent Modular 3Ph 22kVA/60309 5-wire 32A/230V Outlets (12)
C19/Horizontal INTL PDU
AF538A
HPE Intelligent Power Distribution Unit Extension Bar Kits
HP 5xC13 Intelligent PDU Extension Bar G2 Kit
AF547A
Intelligent Extensions Bars have individually monitored outlets that are also individually
switchable for power cycling attached equipment. Each individual C13 outlet has Power
Line Communications to support Intelligent Power Discovery when connected to PLC
enabled common slot power supplies.
HP 5xC13 Outlets Power and UID LEDs Pair Standard Extension Bar
AF528A
NOTE: Standard (non-intelligent) Extension Bars are monitored as a single load
segment and do not support Intelligent Power Discovery AF528A
NOTE: Additional HPE Power Distribution Units are available. For a complete list of
all HPE PDUs and additional information: please visit http://www.hp.com/go/pdu.
HPE R1500 G4
Uninterruptible Power
Supply (UPS)
Line Interactive Single Phase UPS that provides up to 1.5kVA in a 1U rack mount form factor.
HPE R1500 G4 NA Uninterruptible Power System
J2Q99A
HPE R1500 G4 JP/TWN Uninterruptible Power System
J2R05A
HPE R1500 G4 INTL Uninterruptible Power System
J2R03A
NOTE: Please see the QuickSpecs for additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04154342
(Worldwide)
HPE PDUs and additional information: please visit http://www.hp.com/go/pdu
ation, and redundancy information. For more information, please review the HPE
QuickSpecs
HPE Advanced Series Racks
Related Options
Page 12
HPE R/T2200 G4
Uninterruptible Power
System
Line Interactive Single Phase UPS that provides up to 2.2kVA in a 2U rack mount form factor. System
can be converted for either rack or tower use.
HPE R/T2200 G4 NA/JP Uninterruptible Power System
J2R00A
NOTE: Please see the QuickSpecs for additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04154342
(Worldwide)
HPE R/T3000
G4Uninterruptible
Power System (UPS)
Line Interactive Single Phase UPS that provides up to 3kVA in a 2U rack mount form factor. System can
be converted for either rack or tower use.
HPE R/T3000 G4 Low Voltage NA/JP Uninterruptible Power System
J2R01A
HPE R/T3000 G4 High Voltage NA/JP Uninterruptible Power System
J2R02A
HPE R/T3000 G4 High Voltage INTL Uninterruptible Power System
J2R04A
NOTE: Please see the QuickSpecs for additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname
(Worldwide)
HPE R5000
Uninterruptible Power
Systems (UPS)
Line Interactive Single Phase UPS that provides up to 5kVA in a 3U rack mount form factor.
HPE R5000 3U L630 High Voltage NA/JP Uninterruptible Power System
AF460A
HPE R5000 3U IEC309-32A High Voltage INTL Uninterruptible Power System
AF461A
NOTE: Please see the QuickSpecs additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c0415
(Worldwide)
HPE R7000
Uninterruptible Power
Systems (UPS)
Line Interactive Single Phase UPS that provides up to 7kVA in a 4U rack mount form factor.
HPE R7000 4U 50A High Voltage NA/JP Uninterruptible Power System
AF462A
HPE R7000 4U IEC-32A High Voltage INTL Uninterruptible Power System
AF463A
NOTE: Please see the QuickSpecs additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04154342
(Worldwide)
HPE Online On
Demand 3 Phase
Uninterruptible Power
Systems (UPS)
Online On-Demand Three-Phase UPS solution that is scalable to 72kVA.
HPE R8000/3 8000kVA Three Phase NA 6U Rackmount Uninterruptible Power
System
AF431A
HPE R8000/3 8000kVA Three Phase INTL 6U Rackmount Uninterruptible Power
System
AF432A
HPE R12000/3 12000VA Three Phase NA 6U Rackmount Uninterruptible Power
System
AF429A
HPE R12000/3 12000VA Three Phase INTL 6U Rackmount Uninterruptible Power
System
AF430A
NOTE: Please see the QuickSpecs additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04123376
(Worldwide)
HPE DirectFlow 3
Phase Uninterruptible
Power Systems
Enterprise level rack-based UPS that can provide up to 19.9kVA of power in as little as 5U of rack
space.
1U UPS
HPE R12000 DirectFlow - 1U Rackmount Uninterruptible Power System
G9Y75A
HPE R12000 DirectFlow - POD 1U Rackmount Uninterruptible Power System
AF478A
2U UPS
HPE
AF479A
NOTE: Please see the QuickSpecs additional information:
https://www.hpe.com/h20195/v2/gethtml.aspx?docname=c04376695
(UPS)
=c04154342
4342
(UPS)
R18000 DirectFlow - 2U Rackmount Uninterruptible Power System
QuickSpecs
HPE Advanced Series Racks
Related Options
Page 13
(Worldwide)
HPE KVM Consoles
The HPE LCD8500 1U Rackmount Console Kit is an ultra-dense, high-performance KVM console that
combines a full 18.5-inch LCD monitor with keyboard and touch pad in a 1U form factor.
HPE LCD8500 1U Rackmount Console Kit Models
HP LCD8500 1U US Rackmount Console Kit
AF630A
HP LCD8500 1U UK Rackmount Console Kit
AF631A
HP LCD8500 1U DE Rackmount Console Kit
AF632A
HP LCD8500 1U FR Rackmount Console Kit
AF633A
HP LCD8500 1U JP Rackmount Console Kit
AF642A
HP LCD8500 1U RU Rackmount Console Kit
AF643A
HP LCD8500 1U INTL Rackmount Console Kit
AF644A
HP LCD8500 1U US TAA Rackmount Console Kit
AF645A
KVM Switch Options
Simple to deploy and intuitive solution that allows you to access and manage servers across your entire
network locally or remotely.
HPE Analog KVM Switches
HP 1x4 USB/PS2 KVM Console Switch
AF611A
HP 1x4 KVM Console 6ft PS2 Cable
AF612A
HP 1x4 KVM Console 6ft USB Cable
NOTE:
AF613A
NOTE: Please see the QuickSpecs for additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04164460
(Worldwide)
HP 0x1x8 G3 KVM Console Switch
AF651A
HP 0x2x16 G3 KVM Console Switch
AF652A
HP KVM Console USB Interface Adapter
AF628A
NOTE: Please see the QuickSpecs for additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04123433
(Worldwide)
HPE Analog KVM Switches with Virtual Media & CAC
HP 0x2x16 KVM Server Console Switch G2 with Virtual Media CAC Software
AF618A
HP 0x2x32 KVM Server Console Switch G2 with Virtual Media CAC Software
AF619A
HP KVM Console USB 2.0 Virtual Media CAC Interface Adapter
AF629A
HP KVM Console Serial/Power G2 Interface Adapter
AF625A
NOTE: Please see the QuickSpecs for additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04168373
(Worldwide)
HPE Digital KVM Switches with Virtual Media & CAC
HP 1x1Ex8 KVM IP Console Switch G2 with Virtual Media CAC Software
AF620A
HP 2x1Ex16 KVM IP Console Switch G2 with Virtual Media CAC Software
AF621A
HP 4x1Ex32 KVM IP Console Switch G2 with Virtual Media CAC Software
AF622A
Interface Adapters
HP KVM Console USB Interface Adapter
AF628A
HP KVM CAT5 1-pack Serial Interface Adapter
373035-B21
NOTE: Please see the QuickSpecs for additional information:
https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04168374
(Worldwide)
NOTE: Cat5e cables are required to connect Interface Adapters to Console Switches.
Cat5e cables can be found at the following URL: http://www.hp.com/go/kvm
USB cable required for supporting USB peripherals.
.
QuickSpecs
HPE Advanced Series Racks
Related Options
Page 14
NOTE: For additional information regarding KVM console and switches and related
options please see: http://www.hp.com/go/kvm.
HPE Support Services
HPE Install Rack and Rack Options Service
U2871E
HPE Factory Express
Services
HPE Hardware Customization Service
HA838A1
HPE 3rd Party Hardware Install Service
HA844A1
HPE Customer Defined Rack Cable Labeling Service
HA850A1
HPE Customer Furnished Equipment Handling Service
HA851A1
HPE Custom Placement within Rack Service
HA864A1
NOTE: HPE Factory Express offers a full line of services. For more information visit
http://www.hp.com/go/factoryexpress
QuickSpecs
HPE Advanced Series Racks
Technical Specifications
Page 15
Understanding rack
HPE Racks are designed to support high capacity weight loads that include the weight of the rack and all
(Rolling and configured) weight capacity of up to 3000 lbs.
HPE 42U 600mm x 1075mm Advanced
Pallet Rack
H6J65A
TL253A
Dimensions (HxDxW)
Total Cabinet Area
78.97 x 44.30 x 23.54 in (200.60 x 112.52 x 59.78 cm))
Shipping
84.17 x 47.24 x 27.95 in (213.80 x 120.00 x 71.00 cm)
Weight
Rack
233 lbs. (106 kg)
323.33 lbs (146.66 kg)
Shipping
266 lbs. (121 kg)
356.42 lbs (161.67 kg)
Load
Static
3000 lbs. (1361 kg)
Dynamic (rolling)
2500 lbs. (1134 kg)
Dynamic (configured)
Not supported
Color
Doors
Black with flush locking handle
Frame
Black
HPE 42U 600mm x 1075mm Advanced
Shock Rack
H6J66A
TL254A
Dimensions (HxDxW)
Total Cabinet Area
78.97 x 44.30 x 23.54 in (200.60 x 112.52 x 59.78 cm)
Shipping
85.35 x 50.87 x 35.43 in (216.80 x 129.20 x 90.00 cm)
Weight
Rack
233 lb (106 kg)
323.33 lbs (146.66 kg)
Shipping
446 lb (203 kg)
537.20 lbs (243.668 kg)
Max Shipping
2464 lb (1117.58 kg)
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
2250 lb (1020.58 kg)
Color
Doors
Black with flush locking handle
Frame
Black
HPE 42U 600mm x 1200mm Advanced Pallet Rack (H6J67A)
Dimensions (HxDxW)
Total Cabinet Area
78.97 x 49.61 x 23.50 in (200.60 x 126.02 x 59.78 cm)
Shipping
84.17 x 54.92 x 27.95 in (218.80 x 139.50 x 71.00 cm)
Weight
Rack
282 lb (128 kg)
weights and loads
the equipment installed. All HPE racks are tested to provide the following maximum weight loads:
• Shipping - rack including shipping packaging and materials.
• Static Load – maximum loaded weight that a rack can support when stationary.
• Dynamic Load (rolling) – maximum loaded weight a rack can support when moved (or rolled).
• Dynamic Load (Shipping/configured) – maximum loaded weight a rack can support when
shipped – this includes services such as HPE Factory Express.
• Shipping – Max configured – maximum loaded weight that a rack can support including rack
and packaging.
HPE Racks are rated for Static Loads of up to 3000 lbs. If you require a rack that can be moved or
shipped while fully loaded with equipment, HPE Enterprise Series Racks can support a Dynamic Load
(Includes side panels and baying.)
(Includes side panels and baying)
QuickSpecs
HPE Advanced Series Racks
Technical Specifications
Page 16
Shipping
320 lb (145 kg)
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
Not supported
Color
Doors
Black with flush locking handle
Frame
Black
HPE 42U 600mm x 1200mm Advanced Shock Rack (H6J68A)
Dimensions (HxDxW)
Total Cabinet Area
78.97 x 49.61 x 23.54 in (200.60 x 126.02 x 59.78 cm)
Shipping
85.35 x 57.87 x 35.43 in (216.80 x 147.00 x 90.00 cm)
Weight
Rack
282 lb (128 kg)
Shipping
507 lb (230 kg)
Shipping - Max configured
2474 lb (1122.58 kg)
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
2250 lb (1020.58 kg)
Color
Doors
Black with flush locking handle
Frame
Black
HPE 48U 600mm x 1075mm Advanced Pallet Rack (H6J87A)
Dimensions (HxDxW)
Total Cabinet Area
90.39 x 43.63 x 23.54 in (229.58 x 110.82 x 59.78 cm)
Shipping
96.46 x 47.24 x 27.95 in (245 x 120.00 x 71.00 cm)
Weight
Rack
256 lb (116 kg)
Shipping
287 lb (130 kg)
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
Not supported
Color
Doors
Black with flush locking handle
Frame
Black
HPE 48U 600mm x 1075mm Advanced Shock Rack (H6J88A)
Dimensions (HxDxW)
Total Cabinet Area
90.39 x 43.63 x 23.54 in (229.58 x 110.82 x 59.78 cm)
Shipping (with packaging
materials)
97.64 x 50.50.98 x 35.43 in (248 x 129.50 x 90.00 cm)
Weight
Rack
256 lb (116 kg)
Shipping
467 lb (212 kg)
Shipping - Max configured
2462 lb (1116.58 kg)
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
2250 lb (1020.58 kg)
Color
Doors
Black with flush locking handle
Frame
Black
HPE 36U 600mm x 1075mm Advanced Pallet Rack (H6J77A)
QuickSpecs
HPE Advanced Series Racks
Technical Specifications
Page 17
Dimensions (HxDxW)
Total Cabinet Area
68.66 x 42.72 x 23.54 in (174.39 x 108.52 x 59.78 cm)
Shipping
84.17 x 47.24 x 27.95 in (213.80 x 120.00 x 71.00 cm)
Weight
Rack
205 lb (93 kg)
Shipping
243 lb (110 kg)
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
Not supported
Color
Doors
Black with flush locking handle
Frame
Black
HPE 36U 600mm x 1075mm Advanced Shock Rack (H6J78A)
Dimensions (HxDxW)
Total Cabinet Area
68.66 x 42.72 x 23.50 in (174.39 x 108.521 x 59.78 cm)
Shipping
85.35 x 50.87 x 35.43 in (216.80 x 129.20 x 90.00 cm)
Weight
Rack
205 lb (93 kg)
Shipping
421 lb (191 kg)
Shipping - Max configured
2466.05 lb (1118.58 kg)
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
2250 lb (1020.58 kg)
Color
Doors
Black with flush locking handle
Frame
Black
HPE 22U 600mm x 1075mm Advanced Pallet Rack (H6J83A)
Dimensions (HxDxW)
Total Cabinet Area
43.64 x 44.30 x 23.54 in (110.84 x 112.52 x 59.78 cm)
Shipping
50.79 x 47.24 x 27.95 in (129.00 x 120.00 x 71.00 cm)
Weight
Rack
203 lb (92 kg)
Shipping
231 lb (105 kg)
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
Not supported
Color
Doors
Black with flush locking handle
Frame
Black
HPE 22U 600mm x 1075mm Advanced Shock Rack (H6J84A)
Dimensions (HxDxW)
Total Cabinet Area
43.64 x 44.30 x 23.54 in (110.84 x 112.52 x 59.78 cm)
Shipping
59.49 x 50.87 x 35.43 in (151.00 x 129.20 x 90.00 cm)
Weight
Rack
203 lb (92 kg)
Shipping
389 lb (176.5 kg)
Shipping - Max configured
2436 lb (1105.08 kg)
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
2250 lb (1020.58 kg)
Color
Doors
Black with flush locking handle
Frame
Black
QuickSpecs
HPE Advanced Series Racks
Technical Specifications
Page 18
HPE 14U 600mm x 1075mm Advanced Shock Rack (H6J82A)
Dimensions (HxDxW)
Total Cabinet Area
28.60 x 43.63 x 23.74 in (72.65 x 110.82 x 60.30 cm)
Shipping
35.75 x 50.87 x 35.43 in (90.80 x 129.20 x 90.00 cm)
Weight
Rack
180 lb (82 kg)
Shipping
320 lb (145 kg)
Shipping - Max configured
2388.89 lb (1083.58 kg)
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
2250 lb (1020.58 kg)
Color
Doors
Black with flush locking handle
Frame
Black
HPE 42U 800mm x 1200mm Advanced Pallet Rack (H6J69A)
Dimensions (HxDxW)
Total Cabinet Area
78.97 x 49.61 x 31.38 in (200.60 x 126.02 x 79.70 cm)
Shipping
84.17 x 54.84 x 35.83 in (218.80 x 139.30 x 91.00 cm)
Weight
Rack
373 lb (169 kg)
Shipping
428 lb (194kg)
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
Not supported
Color
Doors
Black with flush locking handle
Frame
Black
HPE 42U 800mm x 1200mm Advanced Shock Rack (H6J70A)
Dimensions (HxDxW)
Total Cabinet Area
78.97 x 49.61 x 31.38 in (200.60 x 126.02 x 79.70cm)
Shipping (with packaging
materials)
85.35 x 57.87 x 43.43 in (216.80 x 147.00 x 110.3 cm)
Weight
Rack
373 lb (169 kg)
Shipping
628 lb (285 kg)
Shipping - Max configured
2506 lb (1136.58 kg)
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
2250 lb (1020.58 kg)
Color
Doors
Black with flush locking handle
Frame
Black
HPE 42U 600mm x 1200mm Advanced Shock Network Rack (H6J72A)
Dimensions (HxDxW)
Total Cabinet Area
78.97 x 49.61 x 23.54 in (200.60 x 126.02 x 59.78 cm)
Shipping (with packaging
materials)
85.35 x 57.87 x 35.43 in (216.80 x 147 x 90.00 cm)
Weight
Rack
287 lb (130 kg)
Shipping
511 lb (232kg)
Shipping - Max configured
2475 lb (1122.58kg)
QuickSpecs
HPE Advanced Series Racks
Technical Specifications
Page 19
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
2250 lb (1020.58 kg)
Color
Doors
Black with flush locking handle
Frame
Black
HPE 42U 800mm x 1200mm Advanced Shock Network Rack (H6J74A)
Dimensions (HxDxW)
Total Cabinet Area
78.97 x 49.61 x 31.38 in (200.60 x 126.02 x 79.70cm
Shipping (with packaging
materials)
85.35 x 57.87 x 43.43 in (216.80 x 147.00 x 110.3 cm)
Weight
Rack
373 lb (169 kg)
Shipping
628 lb (285 kg)
Shipping - Max configured
2506 lb (1136.58 kg)
Load
Static
3000 lb (1360.77 kg)
Dynamic (rolling)
2500 lb (1133.98 kg)
Dynamic (configured)
2250 lb (1020.58 kg)
Color
Doors
Black with flush locking handle
Frame
Black
Environment-friendly
Products and
Approach
End-of-life Management
and Recycling
Hewlett Packard Enterprise offers end-of-life product return, trade-in, and
recy
returned to Hewlett Packard Enterprise will be recycled, recovered or
disposed of in a responsible manner.
http://www8.hp.com/us/en/hpe/hp
information/livingprogress/environmentalprogress/product
recycling.html#.V
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment inf
This information (product disassembly instructions) is posted on the
Hewlett Packard Enterprise web site. These instructions may be used by
recyclers and other WEEE treatment facilities as wel
Enterprise OEM customers who integrate and re
Enterprise equipment.
http://www8
information/livingprogress/environmentalprogress/product
recycling.html#.V
cling programs, in many geographic areas, for our products. Products
-
-
-lPA_krKiM
ormation for each product type for use by treatment facilities.
.hp.com/us/en/hpe/hp-
-lPA_krKiM
l as Hewlett Packard
-sell Hewlett Packard
-
QuickSpecs
HPE Advanced Series Racks
Summary of Changes
Page 20
Date
Version History
Action
Description of Change
13-Feb-2017
From Version 11 to 12
Changed
Service and Support and Related Options were revised.
26-Oct-2016
From Version 10 to 11
Changed
QuickSpecs was rebranded.
17-Aug-2015
From Version 9 to 10
Changed
Content changed throughout the entire QuickSpecs.
Note the title was changed to HPE Advanced Series Racks.
10-Jun-2015
From Version 8 to 9
Added
Note was added to the HP Rack Fan Kits section.
01-Jun-2015
From Version 7 to 8
Added
Added part numbers TL253A and TL253A.
Changed
Changed What's New section to read:
Specifications were revised.
Removed
HPE Keyboard and Monitors section was removed.
30-Mar-2015
From Version 6 to 7
Added
HPE 600m Rack Tie Down Kit and HPE 800mm Rack Tie
Down Kit were added to Related Options.
09-Feb-2015
From Version 5 to 6
Added
Changed What's New to:
Added HPE Rack LED Light to Related Options Section.
Changed
Models, Service and Support, and Related Options sections
were revised.
18-Feb-2014
From Version 4 to 5
Changed
Changed What's New to:
11642 and 11842 1200mm deep network racks
09-Dec-2013
From Version 3 to 4
Changed
Product descriptions were changed throughout Related
Specifications sections.
30-Sep-2013
From Version 2 to 3
Changed
Product descriptions were changed throughout Related
Options.
04-Sep-2013
From Version 1 to 2
Changed
Correction was made to the title.
HPE 11642 1075mm Kitted Pallet Rack with Side Panels
and Baying (TL253A)
HPE 11642 1075mm Kitted Shock Rack with Side Panels
and Baying (TL253A)
HPE 48U Location Discovery Kit (F9V74A)
Service and Support, Related Options, and Technical
HPE Rack LED Light Kit (BW939A)
11648 48U 1075mm deep racks
11842 42U 1200mm deep wide racks
Options.
Other changes made to the Overview and Technical
Options.
11647 G2 1075mm Pallet and Shock Universal Racks and
11622 G2 1075mm Pallet and Shock Universal Racks
were added.
HPE Rack Shelves, HPE Rack Top Cable Trays, HPE Rack
Fan Kits, and HPE Adjustable Rails were added to Related
QuickSpecs
HPE Advanced Series Racks
Summary of Changes
Page 21
Sign up for updates
© Copyright 2017 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties for Hewlett Packard Enterprise products and
services are set forth in the express warranty statements accompanying such products and services.
Nothing herein should be construed as constitut
shall not be liable for technical or editorial errors or omissions contained herein.
c04123187
ing an additional warranty. Hewlett Packard Enterprise
- 14546 - Worldwide - V12 - 13-February-2017
Loading...
