User’s Guide
HP iPAQ Pocket PC h6300 Series
First Edition (June 2004)
Document Part Number: 353283-001
Use this chapter to find out about setting up your Pocket PC and
to learn about how it works.
The software programs described below are preinstalled on your
Pocket PC or included on the Companion CD. These preinstalled
programs are not deleted if your Pocket PC loses power.
You can find detailed information for using these programs in the
Help files on your HP iPAQ Pocket PC. To access these Help
files, from the Start menu, tap Help and select a program.
In addition, Microsoft Pocket PC Basics provides instructions on
operating the Pocket PC. To locate Pocket PC Basics, go to the
Tod ay screen and tap Start > Help > Pocket PC Basics.
HP iPAQ Software
HP Asset ViewerLists detailed information about your system
and its configuration. From the Start menu, tap Settings > System tab > HP Asset Viewer.
HP Image CaptureTake digital photographs and modify settings
with your iPAQ Pocket PC Camera.
HP Image TransferTransfer digital photographs from the Pocket
PC to your personal computer. This software is
included on the Companion CD.
HP Image ZoneDisplay individual images and run slideshows
on your Pocket PC. Also print, send, record
and email images from your Pocket PC.
User’s Guide1–1
Functions
Getting to Know Your HP iPAQ Pocket PC
HP iPAQ Software
iPAQ BackupBack up your data to protect it from loss due to
a drained battery, accidental deletion, or
hardware failure.
iPAQ WirelessProvides a centralized control to all wireless
features on your Pocket PC. It allows you to
turn all wireless features on and off and
configure settings for phone and data functions
using GSM/GPRS, Wi-Fi, and Bluetooth.
Self-TestRun a basic diagnostic test on the device.
Functions
(Continued)
1–2User’s Guide
Getting to Know Your HP iPAQ Pocket PC
Microsoft Pocket PC
Software
ActiveSyncSynchronize information between your Pocket
PC and personal computer so you have the
latest information in both locations. Be sure you
install ActiveSync on your personal computer
before connecting the cradle and Pocket PC to
your computer.
CalculatorPerform calculations.
CalendarSchedule appointments, meetings, and other
events, and set an alarm to remind you of the
appointments. Appointments for the day are
displayed on the Today screen.
ConnectionsConnect your Pocket PC to the Internet and
intranet to browse Web sites, send and receive
e-mail, and synchronize information using
ActiveSync.
Functions
ContactsKeep an updated list of friends and colleagues
to e-mail, message, and telephone.
InboxReceive and send Internet e-mail, SMS and
NotesCreate handwritten or typed notes, drawings,
Pocket ExcelCreate and edit workbooks or view and edit
Pocket Internet ExplorerBrowse the Internet and download pages
User’s Guide1–3
MMS messages in Inbox on your Pocket PC or
from your computer if ActiveSync is installed.
You must have an e-mail address provided by
your Internet Service Provider (ISP) or
employer to send and receive e-mail.
and recordings.
Excel workbooks created on your computer.
through synchronization or by connecting to the
Internet.
Microsoft Pocket PC
Software
Getting to Know Your HP iPAQ Pocket PC
Functions
(Continued)
Pocket WordCreate new documents or view and edit Word
Ring Tones Select different sounds to notify you of
SettingsObtain quick access to settings for the
TasksKeep track of your to-do list.
Terminal Services ClientLog onto your computer and use all the
Windows Media Player
9Series
documents created on your computer.
incoming calls.
backlight, clock, memory, power, regional
settings, Today screen, password, sounds and
notifications, etc.
programs available on that computer from your
Pocket PC (Windows 2000 and XP or later).
Play digital audio and video files in Windows
Media or MP3 format on your device.
Using the Stylus
Your Pocket PC comes with a stylus that you should use to tap or
write on your screen.
NOTE: Use the stylus to tap and write on the screen, and use your
fingers to press the Power button, application buttons on the
bottom of the device, and the camera’s on-screen shutter button.
CAUTION: To prevent damage to your Pocket PC screen, never use any
device other than the stylus that comes with the Pocket PC or an
Ä
approved replacement to tap or write on the screen. If you lose or break
your stylus, you can order extras at www.hp.com/Go/iPAQaccessories.
You can perform three basic actions using the stylus:
1–4User’s Guide
Getting to Know Your HP iPAQ Pocket PC
Tap —Lightly touch the screen to select or open an item. Lift the
stylus after you tap an item. Tapping is equivalent to clicking an
item with the mouse on your computer.
Drag—Place the point of the stylus on the screen and drag an
item across the screen without lifting the stylus until you have
completed the selection. Dragging is equivalent to dragging with
the left mouse button pressed on your computer.
Tap and hold—Hold the stylus pointer on an item for a short
time until a menu displays. Tapping and holding is equivalent to
right-clicking your computer mouse button. When you tap and
hold, a circle of blue dots appears around the stylus to indicate
that the menu will soon pop up.
Setting the Date and Time
When you turn on your Pocket PC for the first time, you are
requested to select your time zone. After setting the time zone,
you still need to set the time and date on your unit. Tap the Clock
icon on the Today screen to set the time and date. All three
settings are located in the Clock Settings screen and can be set
at the same time.
NOTE: By default, the time on the Pocket PC is synchronized with
your computer each time the two devices connect using
ActiveSync.
User’s Guide1–5
Getting to Know Your HP iPAQ Pocket PC
Setting the Time for Home and Locations
You Are Visiting
From the Start menu, tap Settings > System tab > Clock icon.
Shortcut: From the Tod ay screen, tap the Clock icon to set
the time.
1. Tap either Home or Visiting.
2. Tap the time-zone down arrow, and select the appropriate
time zone.
3. Tap the hour, minutes, or seconds, and use the up and down
arrows to adjust the time.
Shortcut: You can also adjust the time by moving the hands of
the clock with the stylus.
4. Tap AM or PM.
5. Tap OK.
6. Tap Ye s to save the time.
Setting the Date
1. From the Start menu, tap Settings > System tab > Clock
icon.
Shortcut: From the Toda y screen, tap the Clock icon to set
the date.
2. Tap the down arrow by the date.
3. Tap the left or right arrow to select a month and year.
4. Tap a day.
5. Tap OK.
6. Tap Ye s to save the date settings.
You need to reset your time zone, time, and date if:
■ The location time (Home or Visiting) needs to be changed.
■ All power to the Pocket PC is lost, which removes all saved
settings.
1–6User’s Guide
Getting to Know Your HP iPAQ Pocket PC
■ You perform a full reset of your Pocket PC.
Shortcut: From the Toda y screen, tap the Clock icon to set
the time zone, time, and date.
Entering Owner Information
You can personalize your HP iPAQ Pocket PC by entering owner
information. To enter owner information:
1. From the Toda y screen, tap Start > Settings > Personal tab
> Owner Information.
Shortcut: From the Tod ay screen, tap Tap here to set owner
information.
2. Tap in the Name field. A keyboard appears at the bottom of
the screen. Tap on the characters to enter your name.
NOTE: If you prefer, you can use Letter Recognizer, Microsoft
Transcriber, or Block Recognizer to input information. Refer to
Chapter 3, “Learning Input Methods,” for more information.
3. Tap the Ta b key on the keyboard to move the cursor to the
next field.
4. Continue entering whatever information you want to include.
5. To display owner information at startup, tap in the Show information when device is turned on checkbox.
6. Tap on the Notes tab to enter any notes.
7. Tap OK to save the information and return to the Today
screen.
Setting a Password
You can set a password to prevent unauthorized access to or use
of your Pocket PC.
1. From the Start menu, tap Settings > Personal tab >
Password.
User’s Guide1–7
Getting to Know Your HP iPAQ Pocket PC
2. On the Password screen, tap the box next to Prompt if device
unused for, then set the timed prompt.
3. Tap the circle next to Simple 4 digit password or next to
Strong alphanumeric password.
4. Enter your password in the Password box using the screen
keyboard and tap OK.
NOTE: Keep a record of your password in a safe place in case you
forget it. If you are unable to retrieve your password, you must
perform a hard reset on your Pocket PC and will lose settings and
information that are not saved in ROM. See the section in this
chapter “Performing a Hard Reset” for more information.
1–8User’s Guide
Resetting the Unit
Performing a Soft Reset
A soft reset (also known as a normal reset) stops all running
applications, but does not erase any programs or saved data.
CAUTION: Be sure to save any unsaved data before performing a
Ä
soft reset since soft reset erases all unsaved data.
To perform a soft reset:
1. Locate the recessed Reset button on the left side of your
iPAQ Pocket PC.
2. Use the stylus to lightly press the Reset button until the
screen fades.
Getting to Know Your HP iPAQ Pocket PC
3. Remove the stylus to restart the Pocket PC.
The Pocket PC restarts and displays the Today screen.
User’s Guide1–9
Getting to Know Your HP iPAQ Pocket PC
Performing a Hard Reset
Perform a hard reset (also known as a full reset) when you want
to clear all settings, programs, and data from RAM.
CAUTION: If you perform a hard reset, your Pocket PC returns to its
default settings and loses all information that is not recorded in ROM or
Ä
iPAQ File Store. Also, all of your GPRS connection methods are erased
with a hard reset, except the default GPRS connection with T-Mobile if
T-Mobile is your service provider.
To perform a hard reset:
1. Press and hold down the Power button.
2. While holding the Power button, use the stylus to lightly
press the Reset button on the left side of the Pocket PC for
about five seconds.
3. The Pocket PC screen fades and the device resets. Once the
device resets and the screen comes back on, release the Power
button and remove the stylus from the Reset button.
1–10User’s Guide
Aligning the Screen
When the Pocket PC is turned on for the first time, you are guided
through a screen alignment process. You must realign your screen
if:
■ The Pocket PC does not respond accurately to your taps.
■ You perform a hard reset of your Pocket PC.
To realign the Pocket PC screen:
1. From the Start menu, tap Settings > System tab > Screen
icon.
2. Tap the Align Screen button.
Shortcut: To access the Align Screen application without
tapping on the screen, push down and hold the 5-Way
Navigation button, then press the Contacts application button
on the bottom of the Pocket PC.
3. Tap the cross-hair object at each location. Be precise when
tapping the cross-hair object.
4. Tap OK.
Getting to Know Your HP iPAQ Pocket PC
User’s Guide1–11
Status Icons
You may see the following status icons displayed on the
Navigation or Command bar. Tap the icon on the screen to view
more information related to the item.
IconDefinition
Inactive connection to computer or wireless network.
Active connection to computer or wireless network.
Microsoft ActiveSync is synchronizing.
Speaker is on.
Speaker is off or in mute position.
Getting to Know Your HP iPAQ Pocket PC
GPRS service is registered and available if you are
subscribed to the GPRS service.
Active data connection to GPRS network.
Active Wi-Fi connection to computer or wireless network.
Phone is powered off.
Phone is powered on.
1–12User’s Guide
Getting to Know Your HP iPAQ Pocket PC
IconDefinition
Network is searching or unavailable.
Phone connection unavailable or network error.
Signal strength indicator for phone functions.
A missed call. Tap this screen icon to view missed calls.
Call Forwarding Active.
iPAQ Wireless icon—Tap to display the iPAQ Wireless
screen. The iPAQ Wireless screen provides a control center
to turn all wireless activities on and off, and to configure
their settings.
One or more instant messages have been received. Tap
this screen icon to view the messages.
One or more e-mail/SMS/MMS, or voice messages have
been received. Tap this screen icon to view the messages.
(Continued)
Message Center indicates messages received from
different communication areas such as phone or voice
messages, e-mail/SMS/MMS, announcements, etc. Tap
this screen icon to view all messages in the message
center.
User’s Guide1–13
Getting to Know Your HP iPAQ Pocket PC
IconDefinition
Tap to mute your phone conversation. Tap it again to
continue the phone conversation.
Event notification set to vibrate instead of alarm. To set to
vibrate: Tap the Speaker icon in the Navigation bar and, in
the pop-up menu, tap Vibrate.
Battery power is low.
Battery power is very low.
Your iPAQ Pocket PC is connected with your personal
computer. This icon appears in the Command bar only
when there is an active connection.
Routine Care
To keep your Pocket PC in good condition and working properly,
follow these guidelines:
■ Keep your Pocket PC away from excessive moisture and
temperature extremes.
(Continued)
■ Do not expose your Pocket PC to liquids or precipitation.
■ Do not place anything on top of your Pocket PC to prevent
damage to the screen.
■ Clean your Pocket PC by wiping the screen and the exterior
with a soft, damp cloth lightly moistened only with water.
■ Avoid exposing your Pocket PC to direct sunlight or strong
ultraviolet light for extended periods of time.
■ Avoid scratching the surface of the screen and banging it
against hard objects.
1–14User’s Guide
Getting to Know Your HP iPAQ Pocket PC
■ Use only the stylus that comes with your Pocket PC or an
approved replacement on the screen to prevent scratching it.
CAUTION: To reduce the risk of damage to the internal components,
Ä
do not spray liquid directly on the screen, or allow excess liquid to drip
inside your Pocket PC. Using soap or other cleaning products on the
screen may discolor the finish and damage it.
Traveling with Your Pocket PC
Use the following guidelines when traveling with your Pocket
PC:
■ Back up your information.
■ Take a copy of your backup with you on an SD memory card.
■ Disconnect all external devices.
■ Take the AC Adapter and AC Charger Adapter with you.
■ Keep your Pocket PC in a protective case and keep it in your
carry-on luggage.
■ For air travel, be sure to turn off the Phone, Bluetooth, and
Wi-Fi. To turn off all wireless features, from the Tod ay
screen, tap the iPAQ Wireless icon in the Command bar, then
tap the ALL OFF button on the iPAQ Wireless screen to turn
all wireless features off.
■ If you are traveling internationally, be sure you have the plug
adapter appropriate for the country you are visiting.
User’s Guide1–15
Learning the Basics
Using the Today Screen
When you first turn on your Pocket PC, the Tod ay screen
displays. You can also display it by tapping Start, and Toda y.
Use the Toda y screen to view:
■ Date and time
■ Owner information
■ Upcoming appointments
■ Unread and unsent messages
2
■ Tasks that need to be completed
Tap to s w i tch
to a program.
Tap to create a new item.
User’s Guide2–1
Tap to set Wireless connections.
Tap to change Phone settings.
Tap to change volume or mute all sounds.
Tap to change date and time.
Tap to set appointment or
view existing appointments.
Tap to read e-mail.
Tap to add tasks.
Tap to launch the iPAQ
Wireless screen.
.
Navigation Bar
The Navigation bar is located at the top of the screen. It displays
the active program, wireless status, and current time, and allows
you to close screens. Use the Start menu to select a program.
Tap to view online Help.
Learning the Basics
Navigation Bar
Tap to select a program you used
recently.
Tap to select a program.
Tap to see additional programs.
Tap to customize the settings.
Tap to launch the iPAQ Wireless screen..
Command Bar
Within each program, use the Command bar located at the bottom
of the screen to perform tasks. Tap New to create a new item in
the current program.
Create new item
Menu Record or write
actions
2–2User’s Guide
a note.
Input panel button
Pop-Up Menus
Pop-up menus allow you to quickly perform an action. Use the
pop-up menu to cut, copy, rename, and delete an item, also send
an e-mail or send a file to another device.
To access a pop-up menu, tap and hold the stylus on the item on
which you want to perform the action. When the menu appears,
tap the desired action, or tap anywhere outside the menu to close
it without performing an action.
Learning the Basics
Tap and hold to display
the pop-up menu.
Tap the action you want.
Tap outside the menu to close
it without performing an action.
Creating information
From the Toda y screen, you can create new information,
including:
■ Appointments
■ Contacts
■ Excel Workbooks
■ Messages
■ Notes
■ Ta sk s
■ Word documents
User’s Guide2–3
1. Tap , or from the Start menu, tap To da y > New.
2. Tap an option to create a new item.
3. Tap OK after you finish creating a new item.
Customizing the Today Screen
From the Settings Today screen, you can:
■ Add a picture as the background.
■ Select the information you see.
■ Set the order of the information.
■ Set when to see the To day screen.
1. Tap , or from the Start menu, tap Settings > Personal tab
> Tod ay.
2. Select Use this picture as the background checkbox.
Learning the Basics
3. Tap Browse to select a picture from File Explorer.
2–4User’s Guide
Learning the Basics
4. Tap the Items tab to select or reorder the information on the
Tod ay screen.
5. Tap an item to highlight it.
6. Tap Move Up or Move Down to change the order of items on
the Tod ay screen.
NOTE:You cannot change the placement of the Date on the
Today screen.
7. Tap the down arrow associated with Display Today screen if
device is not used for...hours checkbox to determine how
many hours must pass before the Today screen displays.
8. Tap OK.
Customizing the Application Buttons
You can change the Contacts and Inbox programs currently
assigned to two of the application buttons on the bottom of the
Pocket PC. You can replace these assignments with two programs
that you use the most.
NOTE: The Phone application buttons cannot be reassigned.
User’s Guide2–5
To change the Button assignment:
1. From the Start menu, tap Settings > Personal tab > Buttons.
2. Highlight the button to be changed, for instance - Button 1.
3. Tap the down arrow in the Button Assignment box and
select your preferred program.
4. Tap OK.
Locking the Application Buttons
To prevent the application buttons on your Pocket PC from
accidentally turning on and discharging the battery, the Buttons
Settings include a Lock feature to disable the buttons.
To disable the buttons when the Pocket PC is in standby:
1. From the Start menu, tap Settings > Personal tab > Buttons.
2. Tap the Lock tab.
3. Tap the check box next to Disable all buttons except power
button.
4. Tap OK.
Learning the Basics
Using Applications
Opening Applications
Open any application on your Pocket PC from the Start menu.
NOTE: You can also open an application by assigning it to one of
the two available Application Buttons. The Phone Application
Buttons cannot be reassigned. To assign the Application
Buttons, from the Toda y screen, tap Start > Settings > Buttons.
To open an application:
1. Tap Start > Programs.
2. Tap the desired application title or logo.
2–6User’s Guide
Minimizing Applications
To minimize an open application, tap the x at the top right of the
screen.
Closing Applications
Applications automatically close based on available memory.
However, if your Pocket PC is running slowly, you can close
applications by manually closing them.
1. From the Start menu, tap Settings > System tab >
Memory > Running Programs tab.
2. Tap Stop All or select a particular application, then tap Stop.
NOTE: To bring a currently running program to the foreground,
tap Activate.
Installing Applications
Learning the Basics
Install applications on your Pocket PC from your:
■ Computer by using Microsoft ActiveSync.
■ Pocket PC if the application file has a .cab extension.
■ Pocket PC or your computer by copying an application file
that has an .exe or .cef extension.
When installing applications, look for the correct version for your
HP iPAQ h6300 model or Microsoft Windows Mobile™ 2003
Software for Pocket PC Edition.
■ Follow the instructions provided with the application and by
the Installation Wizard to install applications from your
computer.
■ Tap the application file in File Explorer on your Pocket PC
and follow the instructions on the Installation Wizard to
install applications on your Pocket PC.
User’s Guide2–7
Backing Up Information
Use iPAQ Backup or Microsoft ActiveSync Backup to back up
and restore information on your Pocket PC.
NOTE: iPAQ Backup is already installed on the Pocket PC. You
must install ActiveSync on your computer before using
ActiveSync Backup.
To help reduce the chance of losing information, you should back
up information on a regular schedule.
Backup/Restore using iPAQ Backup
iPAQ Backup saves your data in a backup file. You may designate
a file name and a location for the file to be saved. iPAQ Backup
backs up to a memory card, main memory, or the iPAQ File Store
folder. Close all programs on your Pocket PC before backing
up or restoring your information.
CAUTION: Restoring your information replaces the current information
on your Pocket PC with the information saved in your backup.
Ä
If you perform a hard reset on your Pocket PC, any user installed
information stored in main memory including backup files will be
deleted. For this reason, it is suggested that backup files always be
saved to a memory card or to the iPAQ File Store folder.
Learning the Basics
To backup/restore using iPAQ Backup:
1. From the Start menu, tap Programs > iPAQ Backup.
2. Tap Options > Switch to Advanced Mode and select the
files and folders to be backed up or restored.
3. Tap the ... box next to File to select the name, location, and
folder name for backed-up data.
4. Tap OK.
5. Press the Backup or Restore button, and press the Start
button on the next screen.
2–8User’s Guide
Backup/Restore Using ActiveSync
Close all programs on your Pocket PC before backing up or
restoring your information.
CAUTION: Restoring your information replaces the current information
Ä
on your Pocket PC with the information saved in your backup.
To backup/restore using ActiveSync:
1. Be sure the Pocket PC is connected to your computer.
2. From your computer, open Microsoft ActiveSync. From the
Start menu, click Programs > Microsoft ActiveSync.
3. From the Tools menu in ActiveSync, click Backup/Restore.
4. Click the Backup or Restore tab, and select your options.
5. Click Backup Now or Restore Now.
Using iPAQ File Store Folder
You can install programs and save files to the iPAQ File
Store folder, which is accessed from File Explorer on your Pocket
PC.
Programs and files stored in iPAQ File Store are stored in ROM
and are saved if you perform a full reset of your Pocket PC or if
the battery discharges completely.
To save to iPAQ File Store:
1. Copy the files to be saved to the iPAQ File Store folder.
Learning the Basics
2. From the Start menu, tap Programs > File Explorer >
My Device > iPAQ File Store.
3. Paste the selected files.
NOTE: Before saving files to the iPAQ File Store folder, it is a
good idea to determine how much memory is available in the
folder. To view the amount of memory, from the Start menu, tap Settings > System tab > Memory > Storage Card tab, then
select iPAQ File Store from the drop-down menu.
User’s Guide2–9
Learning Input Methods
Using Input Software
CAUTION: To avoid damaging your Pocket PC screen, always use a
Ä
stylus or your finger. Never use a pen or any type of metal pointer on
the screen.
To input information to your Pocket PC, you can tap the
keyboard or write with the Letter Recognizer, Microsoft
Transcriber, or Block Recognizer in any application. You can use
the stylus to draw and write on the screen in the Notes application
and from any Notes tab in the Calendar, Contacts, and Tasks
applications.
NOTE: A Removable Thumb Keyboard is included on certain
Pocket PC models. For information on using this keyboard, see
the section “Using the Removable Thumb Keyboard” in this
chapter.
3
Changing Word Suggestion Options
As you type or write, the Pocket PC suggests words for you in a
box above the keyboard, Letter Recognizer, or Block Recognizer,
but not in the Transcriber.
You determine:
■ If words are suggested.
■ The number of letters you enter before a word is suggested.
■ The number of words that are suggested per entry.
User’s Guide3–1
Learning Input Methods
To change settings for word suggestions:
1. From the Start menu, tap Settings > Personal tab > Input.
2. Tap the Word Completion tab.
SHORTCUT: From within any application, tap the up arrow
next to the Input Panel icon and tap Options > Word Completion tab.
3. Tap the down arrow associated with letters and select the
number of letters you want to type before a word is
suggested.
t
3–2User’s Guide
Learning Input Methods
4. Tap the down arrow associated with words and select the
number of words you want suggested.
5. Tap OK.
NOTE: If you do not want any words suggested, tap the
checkbox to remove the checkmark next to Suggest words when entering text.
Using the On-Screen Keyboard
Use the stylus to tap letters, numbers, and symbols on the
on-screen keyboard to enter typed text directly onto the screen.
NOTE: A question mark within a program indicates a Help file.
Tap the ? to open the Help file.
User’s Guide3–3
Learning Input Methods
1. From any application, tap the up arrow next to the Input
Panel icon.
2. Tap Keyboard to display a keyboard on the screen.
NOTE: To see symbols on the keyboard, tap the 123 or Shift key.
3. Tap a letter, symbol, or number to enter information.
4. Tap OK.
Writing with the Stylus and the Letter
Recognizer
Use the stylus and Letter Recognizer to write letters, numbers,
and symbols on the screen. Create words and sentences by
writing in uppercase (ABC), lowercase (abc), and symbols (123)
as instructed here.
To write with the stylus and Letter Recognizer:
1. From any application, tap the up arrow next to the Input Panel icon.
2. Tap Letter Recognizer.
3. Write a letter or symbol between the dashed line and
baseline.
3–4User’s Guide
a. To display in uppercase, write a letter between the hatch
marks labeled ABC.
b. To display in lowercase, write a letter between the hatch
marks labeled abc.
c. Write a number or draw a symbol between the hatch
marks labeled 123.
What you write will be converted to text.
NOTE: For the Letter Recognizer to work effectively, write
characters between the dashed line and baseline.
■ If you are writing a letter like “p,” write the top portion
within the dashed line and baseline, and the tail portion
below the baseline.
■ If you writing a letter like “b,” write the bottom portion
within the dashed line and baseline, and the top portion
above the dashed line.
Writing with the Stylus and
Learning Input Methods
Microsoft Transcriber
Use the stylus and Microsoft Transcriber to write words, letters,
numbers, and symbols anywhere on the screen.
1. From any application, tap the up arrow next to the Input Panel icon.
2. Tap Transcriber to display the Transcriber Intro screen.
3. Tap OK.
4. Tap New at the bottom of the screen.
User’s Guide3–5
Learning Input Methods
5. Begin writing on the screen. What you write will be
converted to text.
NOTE: To “teach” Transcriber your style of writing, tap on the
a” icon at the bottom of the screen to display the Letter Shapes
“
screen and follow the instructions.
Writing with the Stylus and Block
Recognizer
Write letters, numbers, and symbols using the stylus and Block
Recognizer. Create words and sentences by writing letters and
numbers in specific areas.
1. From any application, tap the up arrow next to the Input Panel button.
2. Tap Block Recognizer.
NOTE: For online Help, tap the ?
3–6User’s Guide
Learning Input Methods
3. Write a word, letter, or symbol between the hatch marks.
a. To type text, write a letter between the hatch marks
labeled “abc.”
b. To type numbers or symbols, write a number or symbol
between the hatch marks labeled “123.”
What you write will be converted to text.
Drawing and Writing on the Screen
Use the stylus as a pen to draw and write on the screen in the
Notes program or from the Notes tab in Calendar, Contacts,
or Tasks.
1. From the Start menu, tap Notes > New.
2. Draw and write on the screen.
3. Tap the Pen icon.
4. Tap OK.
User’s Guide3–7
Converting Writing to Text
You can convert your writing to text when you write with the
stylus in the Notes program or from the Notes tab in:
■ Calendar
■ Contacts
■ Ta sk s
To convert writing to text:
1. From the Start menu, tap Notes.
NOTE: Otherwise, tap the Notes tab in Calendar, Contacts, or
Tasks.
2. Tap a note to open it.
3. Tap Tools.
4. Tap Recognize.
NOTE: To convert a particular word or phrase, highlight it before
you tap Recognize. If a word is not recognized, it will not be
converted.
Learning Input Methods
5. Tap OK.
3–8User’s Guide
Using the Removable
Thumb Keyboard
NOTE: Some iPAQ Pocket PC models may not include the
keyboard.
The iPAQ Removable Thumb Keyboard is a convenient, portable
input device for your HP iPAQ Pocket PC h6300 Series product.
The Thumb Keyboard does not require batteries and it uses a very
small amount of power that is drawn from your Pocket PC.
With the Thumb Keyboard, you can:
■ Easily type text into your iPAQ Pocket PC.
■ Quickly access your favorite iPAQ Pocket PC applications.
■ Enter commands with special function keys.
■ Use Send and End buttons for phone calls.
NOTE: If you regularly use an additional keyboard such as the HP
Foldable Keyboard with your iPAQ Pocket PC, you may need to
manually enable and disable the appropriate keyboards before
use.
Learning Input Methods
User’s Guide3–9
Keyboard Components
When the Thumb Keyboard is installed on the Pocket PC, use the
microphone and buttons on the keyboard to perform the same
functions as on the Pocket PC.
Learning Input Methods
1MicrophoneSpeak into the microphone for phone calls or to
record notes.
2Phone ButtonPress to answer or send phone calls, access the
dialer keypad, or activate the speakerphone
function.
3Phone ButtonPress and Hold to turn on/off the Phone or end
a call.
4Inbox ButtonPress to display your e-mail Inbox.
5Contacts ButtonPress to display your Contacts list.
3–10User’s Guide
Learning Input Methods
Keyboard Connectors
1Disconnect ButtonsPress the buttons on each side of the
keyboard to disconnect the keyboard from
the Pocket PC.
2Release ConnectorsWhen the above buttons are pressed in,
these connectors release the keyboard from
the Pocket PC.
3GuidesAlign the guides with the holes on the
bottom of the Pocket PC when attaching the
keyboard.
4Communications ConnectorThis connector must be connected to the
Communications port on the bottom of the
Pocket PC for the keyboard to operate.
User’s Guide3–11
Learning Input Methods
Connecting the Keyboard to Your iPAQ
Pocket PC
To connect the Removable Thumb Keyboard to your iPAQ
Pocket PC h6300 Series:
1. Line up the guides on the bottom of the keyboard with the
holes on the bottom of the Pocket PC.
2. Slide the Pocket PC into the Thumb Keyboard until it is
firmly seated.
Need illustration
NOTE: Repeat the above procedure to connect the Thumb
Keyboard to your iPAQ Pocket PC with an Extended Battery
attached.
3–12User’s Guide
Learning Input Methods
Checking the Keyboard Connection
After you’ve connected the keyboard to your iPAQ Pocket PC, if
you press a key on the keyboard and the letter does not register,
perform the following steps to check your keyboard connection:
1. Be sure the Thumb Keyboard is securely connected to your
iPAQ Pocket PC.
2. If the connection is secure, go to Start > Settings > System
tab > iPAQ Keyboard and be sure the Enable Keyboard
check box is checked.
3. Insert your cursor in the Test here box and tap the keyboard
to see if it types characters in the box.
4. If characters appear in the Test here box, tap OK.
5. Use your stylus to press the Reset button on the left side of
your iPAQ Pocket PC.
Disconnecting the Keyboard
To disconnect the keyboard from your iPAQ Pocket PC, push in
the two buttons on the side of the keyboard to release it, then pull
the Pocket PC from the keyboard.
Configuring the Keyboard
You can configure several features on your Thumb Keyboard. To
customize your keyboard:
1. On your Pocket PC, select Start > Settings > System tab >
iPAQ Keyboard.
2. Select the Setting tab.
3. Do one or more of the following:
❏ Ta p t h e Enable Keyboard check box to enable or
disable the keyboard functionality.
❏ Ta p t h e Enable Sound check box to hear a click every
time you press a key.
User’s Guide3–13
Learning Input Methods
❏ Tap and slide the Delay until Repeat scale to change the
speed at which the keyboard types a character when
individual keys are pressed.
❏ Tap and slide the Key Repeat Rate scale to change the
speed at which the keyboard repeatedly types a character
when the key is held down.
❏ Tap in the Test here: field to verify the keyboard settings
before exiting the Removable Thumb Keyboard
application.
Using the Function and Shortcut Keys
The Thumb Keyboard keys perform additional functions when
pressed in the combinations indicated.
The Blue Key is a function (Fn) key on the left side of the
keyboard. Blue symbols used in conjunction with the Blue Key
are located on the upper left of the keys.
Keystroke CombinationAction
Blue Key + any keyEnters characters printed on the
upper left of the key (indicated in
blue).
Blue Key pressed twiceToggles on blue keys. Press Blue
Key once to toggle off.
Blue Key + down
arrow
Blue Key + up arrowPage up
Blue Key + left arrowScrolls left
Blue Key + right arrowScrolls right
Blue Key + OKCloses program
3–14User’s Guide
Page down
Learning Input Methods
“Sticky” Keys
The integrated keyboard uses a “Sticky Key” feature for the Shift
and BlueFn keys (known as “key modifiers”). This means that
when you enter a number or symbol requiring a combination of
keys to be pressed, the key modifier will stay engaged until you
press the second key. It is not necessary to press both keys at the
same time.
Special Keys
KeyFunctionDescription
Function (Fn) key“Sticky Key” for invoking
+
Symbol (Sym) or
space bar key
(English only)
Symbol (Sym) or
space bar key (all
other languages)
Note: To type a backslash (\) on the Thumb keyboard, first press
the Blue Fn Key + P to create a forward slash (/), then the
Symbol/Space Bar key to modify it as necessary. Refer to the
following “Accent Characters” section for more information on
modifying characters.
Accent Characters
To type any of the accent characters, press the letter you require
to be accented, then press the Blue Fn Key and the
Symbol/Space bar. Continue pressing the Blue Fn Key and the
Space bar until you reach the desired special character. For
example, if you press a, then the Blue Key and the
Symbol/Space Bar, the a will result in
alternate function or symbols
on most keys.
Used for selecting alternate
characters and symbols to
replace a character.
Used for selecting alternate
characters and symbols to
replace a character.
à. If you press the Blue
User’s Guide3–15
Learning Input Methods
À Á Â
ç
Ç
ì
Ì
ł
Ł
Fn Key and Space Bar again, the à will change to á. If you
continue to press the Blue Fn Key and the Space Bar, the accent
mark over the a will continue to change.
To type a capital letter with an accent, press and hold down the
Shift key and press the desired letter, then press the Blue Fn Key
and the Space Bar. For example, press Shift + a, then press the
Blue Fn Key and the Space Bar, the A will result in
À.
Refer to the table below for a list of special characters.
NOTE: It is recommended that you print this table for future
You are now ready to install and connect another keyboard.
3–18User’s Guide
Using the Phone Features
Use the iPAQ Pocket PC phone to make and receive telephone
calls and send and receive SMS (Short Message Service) and
MMS (Multimedia Message Service) messages. Your mobile
phone service provider may provide other useful services such as
voice mail.
The phone can also be used to connect to an Internet Service
Provider (ISP) or work network so you can browse the Web and
read e-mail. You can connect to the Internet or work network over
GPRS (General Packet Radio Service), or you can use GSM
(Global System for Mobile Communications) for dial-up access.
For information on establishing GSM/GPRS data connections,
refer to Chapter 6, “Making Your Data Connections.”
SIM Card
A SIM (Subscriber Identity Module) card is required to operate
the phone features on your iPAQ Pocket PC. The SIM card is a
plastic card embedded with a computer chip that stores and
transacts data. After the SIM card is activated by your mobile
phone service provider, the computer chip will contain
information about your phone number, service, registration
information, and contacts, as well as memory to store speed dial
numbers and text or SMS/MMS messages that you receive.
With the exception of emergency calls, the SIM card must be
inserted into the SIM slot under the battery on the back of the
Pocket PC in order for voice/data calls to work.
4
User’s Guide4–1
To dial an emergency number, from the Phone keypad, tap the
emergency number appropriate for your region, and then tap Tal k
or Send.
NOTE: See your local telephone directory for emergency numbers
used in your area.
Inserting a SIM Card
NOTE: If the battery is already installed, you must remove it
before inserting the SIM card. For more information on this, see
Chapter 13, “Managing the Battery.”
To insert the SIM card into the Pocket PC:
1. On the back of your Pocket PC, push the SIM tray to the right
to unlock 1 and lift up 2 to open it.
2. Insert the SIM card (with the gold side facing the inside of the
tray) into the SIM tray by aligning the notched corner on the
card with the notched corner in the SIM slot 3.
Using the Phone Features
4–2User’s Guide
Using the Phone Features
3. Press the SIM tray (with the SIM card inserted) down 4 into
the SIM slot and lock it into place 5 by sliding the tray to the
left.
NOTE: Repeat the same steps to remove the SIM card from the
SIM tray.
Activating Your Phone Service
Before you are able to use the phone feature on your Pocket PC,
you will need to subscribe with a mobile phone service provider.
NOTE: If you have purchased a prepaid SIM card to use with your
iPAQ Pocket PC, the following information is not applicable.
You can place a phone call to the service provider to activate your
mobile phone service. Your carrier may require the following
information to activate your card:
❏ SIM Card Serial Number (printed on the box label or on
the back of the SIM card)
❏ IMEI Number (printed on the system label under the
removable battery)
Your mobile phone service representative will give you your
wireless phone number and walk you through setting up your
service.
Phone Features
The following features are supported on your iPAQ Pocket PC;
however, these features must be activated by your mobile phone
service provider:
❏ Call Forwarding
❏ CSD—Circuit Switched Data
❏ GPRS—General Packet Radio Service
User’s Guide4–3
❏ International Dialing
❏ International Roaming
❏ Internet access
❏ SMS/MMS—Short Message Service/Multimedia
❏ Voice Mail
❏ VPN—Virtual Private network
❏ WAP—Wireless Application Protocol
You can obtain additional information on these services from
your mobile phone service provider.
Your PIN
After your SIM card is activated, it may be configured with a PIN
(Personal Identification Number) to prevent unauthorized use of
your mobile phone.
NOTE: Emergency phone calls do not require entering a PIN.
Using the Phone Features
Message Service
You can disable your PIN; however, for security reasons, it is
recommended that you keep it enabled. While enabled, you must
enter your PIN every time you turn on your phone features.
CAUTION: After three consecutive, incorrect PINs are entered, the SIM
card locks to prevent further use. If the letters PUK (PIN Unblocking Key)
Ä
display on your Pocket PC screen, you have locked your SIM card and
must enter your PUK on the screen to unlock it. If you did not receive a
PUK with your SIM card, you must contact your service provider to
unlock it.
If your Pocket PC is ever stolen or lost, the PIN will safeguard
your phone against fraudulent use.
To enable your PIN:
1. From the Phone keypad, tap Tools > Options > Phone tab.
4–4User’s Guide
2. Select Require PIN when phone is used.
NOTE: To change the PIN at any time, tap CHANGE PIN.
NOTE: To safeguard your Pocket PC device from unauthorized
use, see Chapter 1, “Getting to Know Your HP iPAQ Pocket PC.”
Phone Buttons and Icons
Phone IconsDefinition
■
Press this Application Button to
answer a call, access the dialer keypad,
and send a call.
■ Press and hold this Button to activate
the speakerphone function.
Press and hold this Application Button to
turn on/off the phone or end a call.
Phone is powered off.
Using the Phone Features
Phone is powered on.
Network is searching or unavailable.
Phone connection unavailable or network
error.
Signal strength indicator for phone functions.
Call missed. Tap this icon to view missed
calls.
Call Forwarding Active
User’s Guide4–5
Using the Phone Features
Phone Icons Definition (Continued)
Phone Volume is active.
Microphone is in mute position.
GPRS Service is available.
Active data connection to GPRS network.
Event notifications set to vibrate instead of
alarm. To set to vibrate: Tap Speaker icon in
the Navigation bar and in the pop-up menu,
tap Vibrate.
One or more instant messages have been
received. Tap this icon to view messages.
One or more e-mail/SMS/MMS or voicemail
messages have been received. Tap this icon
to view messages.
Message Center indicates messages
received from different communication areas
such as phone or voice messages,
e-mail/SMS/MMS, announcements, etc. Tap
this screen icon to view all messages in the
message center.
4–6User’s Guide
Checking Your Connection
and Signal Strength
After you insert the activated SIM card into your Pocket PC, your
unit will connect to your service provider’s network.
The powered on icon () indicates that you are connected to
your service provider’s network. After that, a full strength is
indicated by the signal strength icon (). The number of
vertical bars in the icon diminish as the signal strength
diminishes. The phone icon() indicates no signal.
Selecting a Frequency Band
Your iPAQ Pocket PC has an integrated GSM/GPRS feature that
supports four different frequency bands which allows for
international roaming. When traveling between countries and
wireless network operators, it may be necessary to change the
frequency bands of the GSM/GPRS connection settings. HP has
provided a selection feature that initiates an automatic search for
network frequency bands when your home bands are not
available. This automatic selection feature is the default setting
on your Pocket PC.
Using the Phone Features
NOTE: Automatic band selection may not be available on all
models.
To change the frequency band manually:
1. From the Phone dialer pad,tap Tools > Options > Band.
2. Tap the square or circle next to one of the following items:
❏ Automatic (default setting)
❏ North America (850/1900)
❏ Europe, Asia (900/1800)
User’s Guide4–7
Using the Phone Features
NOTE: Automatic band selection may not be available on all
models.
3. Tap OK.
Select the correct frequency band for the country or region you
are traveling through. To change back to automatic selection,
repeat step 1 and select Automatic.
Turning the Phone On and Off
You can turn your Phone on and off while keeping your actual
Pocket PC turned on.
There are several ways to turn on your Phone:
■ Press and hold the Red application button on the front of
your Pocket PC, or
■ From the Start menu, tap Phone. Enter the phone number
you wish to dial on the screen, and tap Ye s when asked if you
want to turn on the phone.
■ From the To day screen, tap the iPAQ Wireless icon in the
Command bar at the bottom of the screen, then tap the Phone
button.
■ If the Pocket PC is in Flight Mode, from the Today screen,
tap the icon in the Navigation bar and, from the Pop-up
menu, tap Turn off flight mode.
NOTE: Flight mode turns on/off all wireless functions on
your Pocket PC. Turn on Flight mode when you are
traveling by air to prevent a wireless function from
automatically turning on.
There are several ways to turn off your phone:
■ Press and hold the Red application button on the front of
the unit, or
4–8User’s Guide
■ From the To day screen, tap the iPAQ Wireless icon in the
Command bar, then tap the Phone button to turn off the
phone.
■ From the To day Screen, tap the icon in the Navigation
bar and, from the Pop-up menu, tap Turn on flight mode.
NOTE: Leave the phone turned on to receive calls when your
Pocket PC is powered off.
You can use other programs on your device during a call. To
quickly switch back to Phone, tap the Green application button, or tap Start > Phone.
HP Profiles
■ To access HP Profiles, from the Start menu, tap Settings >
System tab > HP profiles.
HP Profiles allows you to create system profiles for alerts, display
power, and wireless settings to match your current environment
or location. You can set up and name profiles to use at different
times and for different functions. For example, you can set a
certain Ring type or tone to be silent or vibrate when you are in a
meeting, or loud when you are outdoors in a crowd.
Using the Phone Features
User’s Guide4–9
There are four button icons that allow you to modify settings for
Alert, Display, Power, and Wireless.
There are five predefined profiles—Silent, Normal, Meeting,
Outdoor, and User. You can rename these profiles, but you cannot
add or delete any profiles.
Setting a Profile
Using the Phone Features
Tap to select Profile
Name
Alert
Display
Power
Wireless
To set a profile:
1. From the Start menu, tap Settings > System tab > HP Profiles icon.
2. Tap the <Current> box on the HP Profiles screen and, from
the drop-down list, select a profile name or rename a profile.
NOTE: Clicking the Rename button brings up a dialog box. Enter
the new name in the dialog box and tap OK.
3. On the right of the screen, tap the icon button that you want to
set (Alert, Display, Power, or Wireless).
4. Select the desired settings:
4–10User’s Guide
a. Use Alert to select a ring type and tone, set the type to
On, Vibrate, or Off, and set the volumes for device and
phone.
b. Use Display to adjust backlight brightness and set a timer
to turn off the backlight if device is not used.
c. Use Power to set a timer to turn off the power if device is
not used.
d. Use Wireless to keep wireless settings On or Off
(wireless, phone, and Bluetooth).
5. Tap OK when you have finished setting the profile.
Switching a Profile
To quickly switch a profile from within any application:
1. Press and hold the Power button to bring up the quick access
menu.
NOTE: The quick access menu includes five tasks in addition to
the profile selections that allow you to switch tasks.
Using the Phone Features
2. Tap the desired profile.
User’s Guide4–11
Using the Phone Features
NOTE: The quick access menu disappears after 30 seconds.
NOTE: When the Backlight is adjusted to its lowest setting, it
cannot be turned on from the quick access menu. It can only be
turned back on by accessing the Start menu > Settings > System > Backlight > Brightness tab and adjusting the brightness level.
Making and Receiving Phone Calls
You can now make local or long distance domestic calls and, if
you requested setup, you can also make international calls.
Making a Call
When you turn on the Phone, the Phone keypad displays on the
Pocket PC screen.
■ From the Phone keypad, tap the number you want to call, and
then tap Tal k or press the Send button.
Refer to the following sections for alternate ways to make a call:
❏ “Making a Call From Contacts”
❏ “Making a Call Using Speed Dial”
❏ “Making a Call from Call History”
❏ “Making a Conference Call”
Answering a Call
When you receive a phone call, the iPAQ Pocket PC rings or
vibrates and a message will appear on the screen, giving you an
option to either answer or ignore the incoming call.
4–12User’s Guide
■ Ta p Answer or press the Green application button to
receive the call.
NOTE: To silence the phone and reject the call, tap Ignore. This
may send the caller to your voice mail or send out a busy signal,
depending on your service provider.
Ending a Call
When your phone call is finished, tap End on the Phone keypad
or press and hold the Red Application Button to end the call.
Making a Call from Contacts
■ From the Contacts list, tap and hold the contact’s phone
number, then tap Call Work, Call Home, or Call Mobile.
■ To make a call from an open contact, tap the number you
want to call.
Using the Phone Features
SIM Contacts Help
When switching SIM cards between devices, use SIM Contacts to
copy contacts from a new SIM card to Contacts on your device.
❏ To copy a contact from your SIM card onto your device,
in SIM Contacts, select the contact you want to copy to
your device and tap COPY NOW.
❏ To verify that your contacts have been copied to your
device, switch to Contacts and search for the added
contacts.
NOTE: This feature may not be available on all models.
User’s Guide4–13
Making a Call Using Speed Dial
■ From the Phone keypad, tap Speed Dial, and then select the
speed dial location number of the desired contact. You can
also press and hold the speed dial location number assigned
to a contact directly from the Phone keypad.
NOTE:
■ To dial a one-digit speed dial number from the Phone
keypad, tap and hold a single keypad key.
■ To dial a two-digit speed dial number from the Phone
keypad, tap the first digit, then tap and hold the second
digit.
Creating a Speed Dial Entry
You can create up to 99 speed dial entries to call frequently-dialed
numbers. Before you can create a speed dial entry for a phone
number, that number must already exist in Contacts.
1. From the Phone keypad, tap Speed Dial > New.
Using the Phone Features
2. Tap the desired contact name and number.
3. In the Location field, tap the Up/Down arrows to select
an available location to assign as the new speed dial
entry. The first speed dial location is reserved for your
voice mail.
4. Tap OK.
Creating a Speed Dial Entry from Contacts
1. Tap and hold the contact name.
2. Tap Add to Speed Dial.
3. Tap the Up/Down arrows to select an available location to
assign as the new speed dial entry.
4. Tap OK.
4–14User’s Guide
Editing a Speed Dial Entry
1. From the Speed Dial list, tap and hold the contact name in
the box to the right of the assigned speed dial number.
2. Tap Edit or Delete.
Making a Call from Call History
■ From the Phone keypad, tap Call History, and then tap the
icon next to the desired number.
Making a Conference Call
You can create a three-way conference call between yourself and
two other parties.
■ From the Phone keypad, dial the first number, tap Talk and
after the call is initiated, tap Hold, dial the second number,
tap Talk and then tap Conference.
Adjusting Phone Volume
Using the Phone Features
During a phone call, press the up (+) or down (-) buttons located
on the right side of the Pocket PC to adjust the Phone volume.
NOTE: The Phone volume can only be adjusted during a phone
call.
Enabling the Mute Function
During a call, you can mute your microphone so that the person
with whom you are speaking cannot hear you, but you can still
hear him or her. This is useful if you do not want the other person
to hear a conversation or background noise on your side of the
call.
■ From the Phone keypad, tap the microphone icon in the
Command bar to mute or unmute a call.
User’s Guide4–15
Setting Ring Tones
1. Tap > Settings > System tab > HP Profiles.
2. On the Sound Notification tab, tap the drop-down list under
Ring type and select the type of ring to be used.
3. Then tap the drop-down list under Ring tone and select the
ring tone to be used.
4. To listen to the selected sounds, tap the Play icon. When you
are finished listening, tap the red Stop icon.
NOTE: To use custom.wav, .mid, or .wma files as ring tones, use
ActiveSync on your personal computer to copy the file to the My
Device\Windows\Rings folder on your device. Then, select the
sound from the Ring tone list.
To control tapping sounds for the keypad:
1. From the Start menu, tap Settings > Personal tab > Sounds & Notifications.
2. Place a checkmark in the box next to Screen taps and select
Soft or Loud. If set to Off, a tone is not played.
3. Tap OK to save the settings.
Using the Phone Features
Changing Ring Tones
You can select a different sound to notify you of incoming calls.
1. From the Phone keypad, tap Tools > Options.
2. Tap the Ring tone list, and select the sound you want to use.
Changing Keypad Tone
You can change the tone you hear when entering a phone number
on the keypad. If set to Tones, the tone is heard continuously for
as long as the number on the keypad is pressed. If set to Beep, the
tone is heard only for one or two seconds.
1. From the Phone keypad, tap Tools > Options.
4–16User’s Guide
2. Tap the Keypad list, and select the option you want.
To prevent tones from being heard when entering a phone
number, select Off.
Enabling Speakerphone Mode
Your iPAQ Pocket PC has a speakerphone mode that allows you
to talk hands-free or allows other people to listen to the caller.
To enable the speakerphone mode:
1. First make a phone call.
2. Hold down the Green application button until the
speakerphone dialog box comes on and the speakerphone
icon () appears in the top Navigation bar.
SHORTCUT: From the Phone keypad, tap Tools > Speakerphone.
3. To turn off the speakerphone, hold down the application
button again.
Using the Phone Features
WARNING: Do not leave the phone in speakerphone mode and hold
Å
it to your ear, the sound may temporarily impair your hearing.
Taking Notes During a Call
■ To create a note during a call, tap the Note icon in the
Command bar and enter or record your note.
Using Voice Mail
The first speed dial location is set as a default for your voice
mailbox number. When you insert your SIM card into your
Pocket PC, it sets as default the voice mailbox number of your
mobile service provider. You may need to configure your phone
to the Voice Mail setting by dialing or setting the Voice Mail dial
number.
User’s Guide4–17
To retrieve your voice mail:
■ With the Phone turned on and the Phone keypad visible on
the screen, press and release the left side of the 5-way
navigation button, select 1 Voice Mail, then press .
Putting a Call on Hold
During a phone call, tap Hold on the Phone keypad to put the call
on hold. The call on hold appears on the top right of the dialer
screen. You may switch between calls by tapping on the call on
hold.
Using Call Waiting
Call waiting notifies you of incoming calls when you are already
in a phone session.
To activate Call Waiting:
1. From the Phone keypad, tap Tools > Options > Services
tab.
2. Tap Call Waiting > Get Settings.
Using the Phone Features
3. Select Notify me.
NOTE: To stop using call waiting, select Do not notify me.
To use Call Waiting to answer an incoming call during a phone
conversation, tap Answer to move the current phone call to Call Waiting. The phone call on Call Waiting displays on the screen.
Tap Ignore if you do not want to answer the incoming call.
Displaying Caller ID
You can display your caller ID when placing a phone call.
1. From the Phone keypad, tap Tools > Options > Services
tab.
2. Tap Caller ID > Get Settings.
4–18User’s Guide
3. Select Everyone.
NOTE: To prevent your caller ID from being displayed to others,
select No One.
Blocking Calls
Use call barring to block certain types of incoming and/or
outgoing calls.
1. From the Phone keypad, type Tools > Options >
Services tab.
2. Tap Call Barring > Get Settings.
3. Select the type of incoming and/or outgoing calls you
want to block.
Forwarding Calls
Use call forwarding to forward all incoming calls to a different
number.
1. From the Phone keypad, tap Tools > Options > Services
tab.
2. Tap Call Forwarding > Get Settings.
Using the Phone Features
3. Select Forward all incoming phone calls, and specify
the phone number to receive forwarded calls.
You can also use call forwarding to forward incoming calls to a
different number based on your situation.
❏ Select Unavailable to forward calls only when your
phone is turned off or you are unreachable.
❏ Select Busy to forward calls only when the line is busy.
User’s Guide4–19
❏ Select No answer to forward calls only when you can’t
answer your phone.
NOTE: To stop using Call Forwarding, clear the box next to
Forward all incoming phone calls.
Change the System Volume
You can adjust the volume for system sounds, such as the sound
you hear when you tap on program names and menu options.
■ Tap the icon in the Navigation bar.
■ In the pop-up volume box, move the system volume ()
slider to the desired volume level.
Select On, Vibrate, or Off to quickly change both the system and
ringer volume settings.
NOTE: You can also press the volume control on your device to
quickly change both the ringer and system volume settings.
Using the Phone Features
Change the Ringer Volume
There may be times when you want to change the ringer volume
on your device. For example, you may want to increase the ringer
volume when you're anticipating an important call, or
immediately silence the ringer when you receive a call during a
meeting or when you're in a quiet environment.
■ Tap the icon in the Navigation bar.
■ In the pop-up volume box, move the ringer volume ()
slider to the desired volume level.
Select On, Vibrate, or Off to quickly change both the ringer and
system volume settings.
4–20User’s Guide
Using the Phone Features
You can also press the volume control on your device to quickly
change both the ringer and system volume settings.
Changing the Phone Settings
Tap Start > Settings > Phone.
You can customize phone settings such as the ring type and ring
tone to be used for incoming calls, and the keypad tone to be used
when entering phone numbers. You can also protect your phone
from unauthorized use with a PIN.
■ To change phone settings from the Phone keypad, tap Tools >
Options > Phone tab.
From the Phone tab, you can change the following items:
❏ Ring type—Tap the Ring type list and select the desired
option.
❏ Ring tone—Tap the Ring tone list and select the sound
you want.
NOTE: To use custom .wav, .mid, or .wma files as ring
tones, use ActiveSync on your personal computer to copy
the file to the /Windows/Rings folder on your device. Then,
select the sound from the Ring tone list.
❏ Keypad tone—Tap the Keypad list, and select the option
you want.
❏ Secure your Phone
Changing Services Settings
You can change service settings by either of the following
methods:
■ From the Start menu, tap Settings > Phone > Services tab,
tap a service, and then tap Get Settings.
■ From the Phone keypad, tap Tools > Options > Services tab,
tap a service, and then tap Get Settings.
User’s Guide4–21
Using the Phone Features
You can configure settings for phone services you subscribe to
through your mobile phone service provider. For example, you
may want to block certain types of incoming and/or outgoing
calls, forward incoming calls to a different phone number based
on your situation, be notified of incoming calls when you’re
already in a phone session, or let others know your identity when
making calls.
Viewing Available GSM/GPRS
Networks
You can view all GSM/GPRS wireless networks available to you.
1. From the Phone keypad, tap Tools > Options > Network
tab.
2. Tap Find Network.
Changing Network Settings
You can change Network Settings by either of the following
methods:
■ From the Start menu, tap Settings > Phone > Network tab.
■ From the Phone keypad, tap Tools > Options > Network tab.
The GSM/GPRS connection your device is currently using
will be listed at the top of the screen.
You can view available networks, determine the order in which
your phone accesses another network if the current one is
unavailable, and specify whether you want to change networks
manually or automatically. The current network will remain
active until you change it, lose your signal, or change your SIM
card.
4–22User’s Guide
Using the Phone Features
Manually Selecting a Network
You may want to manually select a different wireless network to
use, instead of your device automatically doing this for you. For
example, you may want to control costs by knowing when
connectivity for your current, selected network is unavailable, and
deciding whether you want to select a different network to use.
1. From the Phone keypad, tap Tools > Options > Network
tab.
2. Under Network selection, select Manual and select the
network you want to use.
NOTE: When your current network is unavailable, tap Select
Network, and manually select a different network to use.
Configuring Your Pocket PC for
Your SIM Card
When the SIM card connects to your service provider’s network,
it may be updated by your service provider to include new
network parameters for faster connection. The GPRS Settings
Manager automatically updates your Pocket PC’s device files
with the new network parameters on your SIM card.
At times, you may need to manually edit the network settings or
create your own personal network settings. To do that, you will
need to modify the GPRS Settings.
The GPRS Settings Manager has the following features:
■ Automatically detects the carrier and sets up the GPRS
connection information.
User’s Guide4–23
Using the Phone Features
■ Launches on all hard and soft resets to check for SIM
changes and updates the network settings.
■ Provides the User with the ability to edit network settings
including GPRS, CSD, SMS, MMS, and WAP information.
■ Provides the User with the ability to create their own network
settings and save them under a user defined name in the iPAQ
File Store folder.
Modifying the GPRS Network Settings
The first time you use your SIM Card, the GPRS (General Packet
Radio Service) Settings Manager automatically updates changes
in the network parameters if there are any. You can modify these
settings to your own preference or create your own network
settings.
NOTE: If the automatic network detection fails, you can manually
relaunch it by pressing the Automatic detection button on the
GSM/GPRS Settings screen below.
1. To access the GSM/GPRS Settings, from the Start menu, tap
Settings > Connections tab > GSM/GPRS Settings icon.
2. On the GSM/GPRS Settings screen:
4–24User’s Guide
Using the Phone Features
a. Under Country, tap the down arrow in the box to open
the drop-down menu, then select the correct country
name.
b.Under Operator, tap the down arrow in the box to open
the drop-down menu, then select the correct operator
name.
NOTE: If your operator name appears in the drop-down list,
it is recommended that you use that connection and, if
needed, edit the default settings.
c. Tap OK when the correct Country and Operator are
shown, or tap the following buttons to manually modify
your settings.
d. Tap one of the following, then continue with the
following appropriate section:
◆ Automatic Detection launches the automatic
detection for the network number and the operator
default.
◆ Edit Network Properties to edit the network
settings. This button is grayed out unless an operator
is selected on the screen.
◆ Create Connection to create your own operator
connection setting.
◆ Cancel to close the application without saving any of
the new settings.
NOTE: If a change to the network properties or a new connection
is created, a Warning displays asking you to save the new data.
Automatic Detection
1. When you tap on Automatic Detection on the GSM/GPRS
Settings screen, it launches the network number and operator
default.
2. Tap OK to accept it and exit the GSM/GPRS Settings screen.
User’s Guide4–25
Editing Network Properties
Tapping on the Edit Network Properties bar on the GSM/GPRS
Settings screen gives you access to the following areas:
❏ Internet Connection Information—Walks you through the
different settings for GPRS (General Packet Radio
Service) and CSD (Circuit Switched Data) connections.
❏ SMS Text Message—Allows you to modify the SMS
(Short Message Service) service center number.
❏ MMS Multimedia Messages—Allows you to modify the
MMS (Multimedia Message Service) Center address.
❏ WAP Information—Allows you to modify the WAP
(Wireless Application Protocol) gateway and Port.
Using the Phone Features
Editing an Internet Connection
If you tapped Internet Connection Information on the above
Edit Properties screen:
1. Under Select a Country, tap on the drop-down arrow and
select a country from the list.
2. Enter a name for the connection such as the carrier name.
3. Tap Next.
4–26User’s Guide
Using the Phone Features
If you select the GPRS Network:
1. Select the GPRS network to edit.
2. Tap Next.
3. After APN: enter the Access Point Name of the server you
are attempting to connect.
4. After Name: enter the Log on for your connection.
5. After Password: enter the password for your connection.
6. Tap Next.
7. On the next screen, tap one of the following:
❏ Dynamic IP address
❏ Static IP address
8. Tap Next.
9. On the next screen, tap one of the following:
❏ Dynamic DNS addresses
❏ Static DNS addresses
10. Tap OK.
If you select the CSD Network:
1. Select the CSD network to edit.
2. Tap Next.
3. After Number: enter the Phone Number of the server you are
attempting to connect.
4. After Name: enter the Login for your connection such as
mtaylor@yahoo.com.
5. After Password: enter the password for your connection.
6. Tap Next.
7. On the next screen, tap one of the following:
❏ Dynamic IP address
User’s Guide4–27
Using the Phone Features
❏ Static IP address
8. Tap OK.
Editing SMS Text Message Settings
If you tap SMS Text Message on the Edit Properties screen:
1. Under Enter the Service Center Number, enter the Phone
Number to which all SMS messages will be sent for delivery
by the network.
2. Tap OK.
Editing MMS Multimedia Messages Settings
If you tapped MMS Multimedia Messages on the Edit
Properties screen:
1. Under Enter the MMS Center Address, enter the URL
where all MMS messages are sent for delivery by the network
(for example, enter http://mms.mobilelife.co.th).
2. Enter the following information:
❏ APN: Access Point Name of the MMS server being
connected.
❏ Name: Log on name for the MMS server.
❏ Password: Password for the MMS server.
3. Tap OK.
Editing WAP Information
If you tapped WAP Information on the Edit Properties screen:
1. Under WAP Settings, enter the IP address and port for the
WA P Ga t ew a y.
2. Tap OK.
4–28User’s Guide
Creating a Connection
1. When you tap Create Connection on the GSM/GPRS
Settings screen, the next screen requests the Internet
connection name:
a. In the Country drop-down menu, select a country for the
carrier you are creating.
b. Enter a name for the connection you are creating.
Using the Phone Features
c. Tap Next.
2. On the next screen, select the network to use:
❏ Ta p GPRS to connect to a high-speed GSM data
network.
❏ Ta p CSD (Circuit Switched Data) to connect to your own
ISP over the Voice channel.
3. After you have selected a network, tap Next.
NOTE: If you tapped CSD above, skip the following section and
go to the section titled “Creating a CSD Connection.”
User’s Guide4–29
Using the Phone Features
Creating a GPRS Connection
1. If you tapped GPRS, the next screen requires you to fill in the
following GPRS configuration information. You can get this
information from your GPRS Service Provider if you do not
have it.
❏ APN: Access Point Name of the server that you want to
connect.
❏ Name: Log On name for your connection.
❏ Password: Password for your connection.
2. Tap Next to continue.
3. In the next screen, select the IP Address to be used during
your connection:
❏ Dynamic IP Address
❏ Static IP Address
4. Tap Next.
5. In the next screen, configurate the name-servers to be used
during your connection.
a. Select one of the following:
◆ Dynamic IP addresses
◆ Static IP addresses
b. Enter the required information (DNS, DNS aux, WINS,
and WINS aux).
6. Tap Next.
NOTE: When you are creating a new connection, the next screen
to display at this point is the SMS Text Message screen. Skip to
the section on “Creating an SMS Text Message Connection.”
4–30User’s Guide
Using the Phone Features
Creating a CSD Connection
1. If you tapped CSD (Circuit Switched Data) on the network
selection screen, the next screen requires you to fill in the
following CSD configuration information. You can get this
information from your CSD Service Provider (ISP provider)
if you do not have it.
❏ Number: The phone number of the ISP that you want to
connect to.
❏ Name: Log On name for your connection.
❏ Password: Password for your connection.
❏ Ta p Next to continue.
2. On the next screen, select the IP Address to be used during
your connection:
❏ Dynamic IP Address
❏ Static IP Address
3. Tap Next.
4. On the next screen, select the name-server to be used during
your connection.
❏ Dynamic IP address
❏ Static IP address
5. Enter the required information (DNS, DNS aux, WINS, and
WINX aux).
6. Tap Next.
NOTE: When you are creating a new connection, the next screen
to display is the SMS Text Messaging screen.
Creating an SMS Text Message Connection
1. On the SMS Text Messaging screen, under Enter the Service
Center Number box, enter the phone number to which all
SMS messages will be sent for delivery by the network.
User’s Guide4–31
Using the Phone Features
2. Tap Next to go to the MMS Multimedia Messages settings
screen.
Creating an MMS Multimedia Messages
Connection
1. On the MMS Multimedia Messages screen, under Enter the
MMS Center Address box, enter the URL or path to which
all MMS messages are sent to for delivery by the network.
(For example: http://mms.mobilelife.co.th)
2. Enter the following information:
❏ APN: Access Point Name of the MMS server you are
connecting to.
❏ Name: Log on name for the MMS server.
❏ Password: Password for the MMS server.
3. Tap Next to go to the WAP Settings screen.
Creating a WAP Gateway
1. On the WAP Settings screen, enter the following information:
❏ IP address of the WAP Gateway.
❏ Port information for the WAP Gateway.
2. Tap OK.
4–32User’s Guide
Using the Phone Features
Failed Automatic SIM Detection
If the SIM card is not detected by the application:
■ Check to see if the SIM card is present in the Pocket PC. If it
is not present, insert the SIM card and relaunch the
application.
■ If the SIM card is not recognized by the application, create a
new connection.
TTY Functionality for the Hearing-Impaired
NOTE: The TTY software application is included on the
Companion CD and must be downloaded onto the Pocket PC
before it can be enabled.
This Pocket PC supports TTY (Tele-typewriter) functionality.
This functionality allows hearing-impaired persons to
communicate using existing telephony infrastructure, including
cellular phones. To achieve this, separately purchased TTY
devices must be connected to the telephones on both ends of a
telephone call session, and the TTY software application must be
downloaded from the Companion CD onto the Pocket PC. The
sending TTY device generates a distinct audio tone for every
supported character, and these tones are decoded and converted
back into text on the receiving TTY device.
Due to the use of audio compression codecs in modern digital
cellular telephones, these TTY audio tones may be
unintentionally distorted while being transmitted through cellular
telephones. In order for TTY devices to continue to work in
cellular networks, the cellular telephone must be set into a mode
that optimizes the compression codec to handle TTY tones
instead of the human voice.
NOTE: For information on connecting TTY devices to the iPAQ
Pocket PC, refer to the TTY device manufacturer’s
documentation.
User’s Guide4–33
Using the Phone Features
Enabling TTY Support
Before connecting the optional TTY device to the phone, you
must enable TTY support in order to prepare the Pocket PC
Phone to expect a TTY device to be connected.
To enable TTY support:
1. From the Start menu, tap Settings > Personal tab > TTY
icon.
2. Place a checkmark in the Enable TTY support box by
tapping it.
3. Tap OK.
4. Connect the optional TTY device or plug to the headphone as
stated in the device manufacturer’s documentation and
connect the headphone to the Pocket PC. This connection
activates the TTY audio mode.
Making a Phone Call Using the TTY Device
1. Press the green phone button on the bottom front of the
Pocket PC to launch the dialer keypad, then turn on the phone
functions of the Pocket PC.
2. Dial the phone number of the person you are trying to reach
who also has a TTY device connected to their phone.
3. When the phone call is answered, start typing onto the TTY
keyboard.
The letters typed into the machine are turned into electrical
signals that travel over regular telephone lines. When the
signals reach their destination (another TTY), they are
converted back into letters which appear on a display screen,
are printed out on paper, or both.
When you are finished typing your phone conversation, the
person on the other end of the line may begin typing their
answers or comments to you.
4–34User’s Guide
4. To end a phone call, press and hold the red phone button on
the bottom of the Pocket PC.
NOTE: TTY audio mode activation may not be possible while a
telephone call is already in progress.
NOTE:
■ If a normal headset is connected while TTY support is
enabled, the audio quality may be decreased.
■ If a Bluetooth headset is connected while TTY support is
enabled, the audio quality will not change because TTY
audio mode has not been activated.
■ However, if you make a phone call using a Bluetooth
headset while TTY mode is enabled AND a plug has been
inserted into the headphone jack, TTY audio mode will be
activated and voice quality will decrease.
Deactivating TTY Audio Mode
Using the Phone Features
To deactivate TTY audio mode:
■ Remove the plug from the headphone jack or
■ Uncheck the Enable TTY support checkbox in the Settings
> Connections tab.
Disabling TTY Support
To disable TTY support:
1. From the Start menu, tap Settings > Connections.
2. Uncheck the Enable TTY support box.
NOTE: It has not been determined if deactivation by either method
is possible while a TTY telephone call is in progress.
User’s Guide4–35
Managing Multiple Wireless
Connections
Using the iPAQ Wireless Manager
The iPAQ Wireless Manager application provides a centralized
control for you to manage all wireless features on the Pocket PC.
The iPAQ Wireless screen has individual power buttons to turn
wireless features on and off—one at a time, and one All Off
button to turn off all wireless features at the same time. The
screen also includes Settings buttons to configure GPRS, Wi-Fi,
and Bluetooth.
■ To access the iPAQ Wireless screen, from the Toda y screen,
tap the iPAQ Wireless icon () in the Command bar at the
bottom of the screen.
The iPAQ Wireless screen displays showing the current state
of all wireless activities (
- x indicates Off).
5
NOTE: For an alternate path to the iPAQ Wireless screen, tap
Start menu > iPAQ Wireless.
User’s Guide5–1
Managing Multiple Wireless Connections
T
■ To power on one or more wireless activities, tap the desired
buttons.
■ To power off one or more wireless activities, tap the desired
buttons or tap the All Off button () to power off all
activities.
Power Buttons
All Power buttons (with the exception of the All Off button)
display:
■ Gray background with an x () when they are powered
off.
■ Amber background when they are powered on and signals are
available, but not connected.
■ Green background when they are powered on and connected
or associated with another device.
NOTE: If a button does not immediately respond when tapped, it
may be busy performing a task you requested.
5–2User’s Guide
The All Off button displays:
■ Gray background with the x () when all wireless features
are powered off.
■ Green background when one or more wireless features are
powered on.
Settings Buttons
Each of the four settings buttons—Phone Settings, Wi-Fi
Settings, Bluetooth Settings, and Bluetooth Manager— only
function when they are enabled. In enabled status, press the
Settings button to open a page with information about
configuration and settings for that particular wireless feature.
NOTE: You cannot access these configuration pages if you press
the Settings buttons while in a disabled state.
Phone Settings Button
First, tap the Phone Power button to power it on; then press the
Settings button to open the configuration screen.
Managing Multiple Wireless Connections
NOTE: For information on configuring the Phonesettings, refer to
Chapter 4, “Using the Phone Features” and Chapter 6, “Making
Your Data Connections.”
Wi-Fi Settings Button
First, tap the Wi-Fi Power button to power it on; then press the
Settings button to open the Wi-Fi configuration screen.
NOTE: For information on configuring the Wi-Fi settings, refer to
Chapter 7, “Using Wi-Fi.”
User’s Guide5–3
Managing Multiple Wireless Connections
Bluetooth Settings and Manager Buttons
First press the Bluetooth Power button to power it on; then press
either the Settings or Manager button to open the Bluetooth
settings and configuration screens.
NOTE: For information on configuring Bluetooth settings or
manager, refer to Chapter 8, “Using Bluetooth.”
Managing Data Connections
When you tap a Data Connectivity icon in the Navigation bar, it
opens a drop-down Connectivity box that displays the status of
your wireless data connections and information about which
service is connected. From this drop-down box, you can also
create new connections, access wireless settings menus, and turn
on or off the wireless features.
Data Connectivity Icons
Inactive connection to computer or wireless network.
Active connection to computer or wireless network.
GPRS service is registered and available if you are
subscribed to the GPRS service.
Active data connection to GPRS network.
Active Wi-Fi connection.
5–4User’s Guide
Managing Multiple Wireless Connections
Tap a Data Connectivity icon to display the drop-down
Connectivity box.
User’s Guide5–5
6
Making Your Data Connections
The iPAQ Pocket PC h6300 Series offers you the most
comprehensive set of wireless capabilities to keep you connected
in or out of the office. With Global System for Mobile
Communications/General Packet Radio Service (GSM/GPRS),
Wireless Fidelity (Wi-Fi) also known as Wireless Local Area
Network (WLAN), and Bluetooth integrated into a single device,
you have broad coverage offering high speed access to the
Internet, and to business and personal information.
You can use the following options to get connected:
■ Use the Wi-Fi technology integrated on your Pocket PC to
connect to a Virtual Private Network (VPN)
■ Use the Wi-Fi technology integrated on your Pocket PC to
remotely connect to your mobile Internet Service Provider
(ISP), or connect to hotspots in public places
■ Make a wireless GSM/GPRS connection to place a phone call
or send or receive e-mail and text or Short Message
Service/Multimedia Message Service (SMS/MMS)
messages.
■ Transfer information between Bluetooth enabled devices
■ Transfer information between two Infrared (IrDA) enabled
ports
User’s Guide6–1
Making Your Data Connections
NOTE: Use of dial-up and wireless Internet, e-mail, corporate
networks, and other wireless communications, such as
Bluetooth-enabled devices, may require separately purchased
additional hardware and other compatible equipment, in addition
to a separately purchased service contract. Check with your
service provider for availability and coverage in your area. Not all
Web content may be available. Some Web content may require
installation of additional software.
NOTE: For more information on this subject, refer to the Help file
on your Pocket PC by tapping Start > Help > Connections.
Impact of Data Connection When
Phone Call is Received
Class B mobile phones may be attached to both GPRS and GSM
services, using one service at a time. Class B enables making/
receiving a voice call, or sending/receiving an SMS during a
GPRS connection. During voice calls or SMS, GPRS services are
suspended and then resumed automatically after the call or SMS
session has ended.
Using GSM/GPRS Connections
GSM/GPRS technology is integrated into your HP iPAQ Pocket
PC. To send or receive data over a GSM/GPRS network, you
must have an account with a mobile telephone service provider
that supports GSM/GPRS data services and an activated SIM
card. The service provider must enable the GPRS data features on
your account to activate it.
For a list of GSM/GPRS service providers, go to your
GSM/GPRS service provider’s Web site.
6–2User’s Guide
Making Your Data Connections
Creating a GPRS Connection
A General Packet Radio Service (GPRS) connection provides
high-speed data transfer and is typically used for Web browsing
and to send and receive small bursts of data such as e-mail and
MMS messages.
To create a GPRS connection, you must subscribe with a GSM
service provider that supports GPRS. After you configure your
GPRS connection and connect to the GPRS network, you may be
required to authenticate GPRS.
NOTE: Your service provider must enable the GPRS features on
your account.
Configuring your GPRS connection on
your Pocket PC
1. From the Start menu, tap Settings > Connections tab >
Connections icon.
2. Select Add a new modem connection from either the ISP
section or My Work Network section.
3. Enter a descriptive name for the connection (for example,
Phone Dialup or anything you want).
4. In the Select a modem list, tap Cellular Line (GPRS).
5. Tap Next.
6. Under Access Point Name, enter the APN provided by your
GPRS service provider.
7. Tap Next.
8. If required, enter your User name, Password and, if provided
by your ISP or network administrator, your Domain name.
You should not need to change any settings in Advanced.
Most ISPs now use a dynamically assigned address. If your
GPRS service provider specified the IP addresses for your
User’s Guide6–3
DNS servers, tap Advanced, then tap the Name Servers tab.
Select Use specific server addresses, and then enter the DNS
addresses provided by your GPRS service provider. Tap OK.
9. Tap Finish.
Connecting to the GPRS Network
1. From the Start menu, tap Settings > Connections tab >
Connections icon.
2. In the drop-down list, select the service you want to use.
3. Tap Connect.
Your service provider can provide additional information on
connecting to the Internet using GPRS.
Creating a GSM Connection
Global System for Mobile Communications (GSM) technology is
used to make mobile phone calls and provide data service with
roaming capabilities throughout the world.
To create a cellular GSM connection, you must first subscribe to
Circuit Switching Data (CSD), and you must have your phone
number. Make sure you insert your activated SIM card into your
iPAQ Pocket PC before you configure your GSM connection.
After you configure the connection, dial the phone number of the
remote server you are connecting to, and use the GSM connection
to browse the Internet or send or receive e-mail.
Making Your Data Connections
Configuring your GSM connection on
your Pocket PC
1. From the Start menu, tap Settings > Connections tab >
Connections icon.
2. In the drop-down list, select Add a new modem connection
from either ISP or My Work Network.
3. Enter a descriptive name for the connection (for example,
iPAQ dialup).
6–4User’s Guide
4. In the Select a modem list, select Cellular Line.
5. Tap Next.
6. You should not need to change any settings in Advanced.
Most ISPs and Networks use a dynamically assigned address.
If the ISP or Network you are using does not use a
dynamically assigned address, enter the connection number
that was given to you by your ISP or Network Administrator
and tap Next.
7. Enter your User name, Password, and Domain if provided by
your ISP or Network Administrator.
8. Tap Finish.
Dialing a GSM Connection
1. From the Start menu, tap Settings > Connections tab >
Connections icon.
2. In the drop-down list, select the service you want to use.
3. Tap Connect.
Closing a GSM Connection
Making Your Data Connections
1. First, close Inbox or Pocket Internet Explorer if they are
open.
2. Then tap the Data Connections icon in the Navigation
bar of the Today screen, and tap End.
Switching Between GPRS and Wi-Fi
NOTE: Before the wireless networks can perform these activities,
you must have already set up your GPRS and Wi-Fi connections
on your iPAQ Pocket PC.
If you have an active GPRS connection on your Pocket PC and
walk into an area with a Wi-Fi network, the system forces a
GPRS disconnect and connects to the available Wi-Fi network.
User’s Guide6–5
Making Your Data Connections
If you want to connect back to GPRS while you are still in Wi-Fi
network coverage, you can manually connect to the GPRS
network by tapping Start > Settings > Connections tab > GPRS,
or by turning off the Wi-Fi. For infomation on making a GPRS
connection, refer to the section in this chapter on “Connecting to
GPRS.”
When you move out of Wi-Fi range and launch a wireless
application such as Pocket Internet Explorer or e-mail, the system
automatically connects back to the GPRS network.
NOTE: Automatic switching cannot be disabled.
To disconnect from Wi-Fi, from the Today screen, tap the iPAQ
Wireless icon () in the Command bar, then tap the Wi-Fi icon.
Switching Between Wi-Fi Access Points
Switching between access points (AP) is automatic and does not
require any user input. To see which AP you are connected to,
launch iPAQ Wireless.
You can prioritize the profiles by accessing the Wi-Fi settings and
prioritizing the connection.
Setting Up a WAP Browser
Wireless application protocol (WAP) delivers content in a
reduced format to fit the Pocket PC screen. WAP protocol can
accommodate the low memory limitations of handheld devices
and the low-bandwidth limitations of a wireless-handheld
connection.
NOTE: This protocol requires a GPRS connection.
Before you can use the WAP browser, you must set it up.
1. From the Start menu, tap Settings > Connections tab >
Connections.
6–6User’s Guide
Making Your Data Connections
2. Under My Work Network, select Manage Existing
Connections > Proxy Settings tab.
3. Place a checkmark in the two boxes on the My Work
Network screen and tap Advanced.
4. Next to WA P enter Server and Port information
supplied by your Mobile Service Provider, and tap OK.
Viewing WAP Pages
Once you have set up your WAP browser, you can view WAP
pages by starting a GSM or GPRS connection and using Pocket
Internet Explorer. When you enter a Web site using Pocket
Internet Explorer, remember WAP addresses are prefixed by
“wsp” not “http” (example: wsp://www.xxx.com).
Connecting to a Private Network
Setting Up VPN Server Connections
A VPN connection enables you to securely connect to a private or
a corporate network, via the Internet. To set up a VPN server
connection:
1. Contact your network administrator for your user name,
password, domain name, TCP/IP settings, and host name
or IP address of the VPN server.
2. Be sure Wi-Fi is powered on.
3. From the Toda y screen, tap Start > Settings > Connections
tab > Connections > Tas ks tab.
4. Under My Work Network, tap Add a new VPN server
connection.
5. Follow the instructions in the New Connection wizard.
Note: For online Help for any screen in the New Connection
wizard or while changing settings, tap the ?.
User’s Guide6–7
Loading...
+ hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
