User’s Guide

hp iPAQ Pocket PC h4000 Series

Document Part Number: 343434-001

August 2003

Note: Not all models described are available in all regions.

Note: Model shown in illustrations is iPAQ Pocket PC h4100 Series

HP, Hewlett Packard, and the Hewlett-Packard logo are trademarks of Hewlett-Packard Company in the U.S. and other countries.

iPAQ is a trademark of Hewlett-Packard Development Company, L.P. in the U.S. and other countries.

Microsoft, Windows, the Windows logo, Outlook, and ActiveSync are trademarks of Microsoft Corporation in the U.S. and other countries.

hp iPAQ Pocket PC is Powered by Microsoft® Windows®.

SD Logo is a trademark of Secure Digital.

Bluetooth

All other product names mentioned herein may be trademarks of their respective companies.

Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material. The information in this document is provided “as is” without warranty of any kind, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, and is subject to change without notice. The warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty.

This document contains proprietary information that is protected by copyright. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of Hewlett-Packard Company.

WARNING: Text set off in this manner indicates that failure to

follow directions could result in bodily harm or loss of life.

CAUTION: Text set off in this manner indicates that failure to follow

directions could result in damage to equipment or loss of information.

is a trademark owned by the Bluetooth SIG, Inc.

User’s Guide hp iPAQ Pocket PC h4000 Series First Edition (August 2003) Document Part Number: 343434-001

Contents

1 Getting to Know Your iPAQ Pocket PC

Using the Stylus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–4

Setting the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . 1–5

Setting the Time for Home and Locations

You Are Visiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–5

Setting the Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–6

Entering Owner Information . . . . . . . . . . . . . . . . . . . . . . 1–7

Resetting the Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–7

Performing a Normal Reset . . . . . . . . . . . . . . . . . . . . 1–7

Performing a Full Reset. . . . . . . . . . . . . . . . . . . . . . . 1–8

Aligning the Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–9

Routine Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1–10

2 Using ActiveSync

Connecting to a Computer . . . . . . . . . . . . . . . . . . . . . . . . 2–2

Installing ActiveSync . . . . . . . . . . . . . . . . . . . . . . . . 2–2

Synchronizing with Your Computer . . . . . . . . . . . . . 2–3

Changing Synchronization Settings. . . . . . . . . . . . . . 2–4

Copying Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–5

Installing Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–6

Backing up and Restoring . . . . . . . . . . . . . . . . . . . . . . . . 2–6

Synchronizing Links . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–6

Sending and Receiving E-mail. . . . . . . . . . . . . . . . . . . . . 2–7

Requesting Meetings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2–7

iii

3 Managing the Battery

Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–1

Installing the Battery in the h4100 Model. . . . . . . . . 3–2

Installing the Battery in the h4300 Model. . . . . . . . . 3–5

Removing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–8

Removing the Battery from the h4100 Model. . . . . . 3–8

Removing the Battery from the h4300 Model. . . . . . 3–9

Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–9

Charging with the AC Adapter . . . . . . . . . . . . . . . . 3–10

Charging with the Desktop Cradle and

AC Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3–11

Charging a Spare Battery. . . . . . . . . . . . . . . . . . . . . 3–12

Changing the Backlight Settings . . . . . . . . . . . . . . . 3–13

Changing the Wireless LAN Power Saving Modes 3–13

Disabling the Application Buttons . . . . . . . . . . . . . 3–14

Manually Monitoring the Battery . . . . . . . . . . . . . . 3–14

4 Learning the Basics

Using the Today Screen . . . . . . . . . . . . . . . . . . . . . . . . . . 4–1

Navigation Bar and Command Bar . . . . . . . . . . . . . . 4–2

Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–3

Pop-Up Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–3

Creating information . . . . . . . . . . . . . . . . . . . . . . . . . 4–4

Customizing the Today Screen . . . . . . . . . . . . . . . . . 4–5

Using Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4–7

Opening Applications . . . . . . . . . . . . . . . . . . . . . . . . 4–7

Minimizing Applications. . . . . . . . . . . . . . . . . . . . . . 4–7

Closing Applications . . . . . . . . . . . . . . . . . . . . . . . . . 4–7

Installing Applications. . . . . . . . . . . . . . . . . . . . . . . . 4–8

Using iPAQ Image Zone . . . . . . . . . . . . . . . . . . . . . . 4–9

Backing Up Information . . . . . . . . . . . . . . . . . . . . . 4–11

Using iPAQ File Store Folder . . . . . . . . . . . . . . . . . 4–13

Contents

User’s Guide iv

5 Learning Input Methods

Using Input Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–1

Changing Word Suggestion Options . . . . . . . . . . . . . 5–1

Using the On-Screen Keyboard. . . . . . . . . . . . . . . . . 5–4

Writing with the Stylus and the

Letter Recognizer . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–5

Writing with the Stylus and Microsoft Transcriber . . . . . 5–6

Writing with the Stylus and Block Recognizer . . . . . 5–6

Drawing and Writing on the Screen . . . . . . . . . . . . . 5–7

Using the Integrated Keyboard (HP iPAQ

Pocket PC h4300 Series only) . . . . . . . . . . . . . . . . . . . . . 5–8

Configuring the Keyboard. . . . . . . . . . . . . . . . . . . . . 5–9

Special Key Features . . . . . . . . . . . . . . . . . . . . . . . . 5–10

Keyboard Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . 5–15

6 Expansion Cards

Installing a Secure Digital (SD) Expansion Card . . . . . . 6–2

Removing a Secure Digital (SD) Expansion Card. . . . . . 6–3

Viewing the Content of Memory Cards. . . . . . . . . . . . . . 6–3

Contents

7 Connecting to the Internet

Connecting to a Private Network . . . . . . . . . . . . . . . . . . . 7–2

Entering an Internet Address . . . . . . . . . . . . . . . . . . . . . . 7–2

Using a Favorites List . . . . . . . . . . . . . . . . . . . . . . . . . . . 7–3

8 Using Bluetooth

Getting Acquainted with Bluetooth . . . . . . . . . . . . . . . . . 8–2

Understanding Terms . . . . . . . . . . . . . . . . . . . . . . . . 8–3

Supported Services . . . . . . . . . . . . . . . . . . . . . . . . . . 8–4

Working with Bluetooth Settings. . . . . . . . . . . . . . . . . . . 8–4

Opening Bluetooth Settings. . . . . . . . . . . . . . . . . . . . 8–5

Setting Accessibility Properties. . . . . . . . . . . . . . . . . 8–6

User’s Guide v

Contents

Enabling Bluetooth Services . . . . . . . . . . . . . . . . . . . 8–8

Setting a Shared Folder . . . . . . . . . . . . . . . . . . . . . . 8–10

Understanding Profiles . . . . . . . . . . . . . . . . . . . . . . 8–11

Working with Bluetooth Manager . . . . . . . . . . . . . . . . . 8–13

Opening Bluetooth Manager . . . . . . . . . . . . . . . . . . 8–14

Locating and Selecting a Device . . . . . . . . . . . . . . . 8–14

Connecting to Other Devices . . . . . . . . . . . . . . . . . . . . . 8–16

Identifying the Communications Port . . . . . . . . . . . 8–16

Establishing an ActiveSync Connection . . . . . . . . . 8–16

Establishing a Serial Connection. . . . . . . . . . . . . . . 8–20

Dial-Up Networking . . . . . . . . . . . . . . . . . . . . . . . . 8–21

Joining a Personal Area Network . . . . . . . . . . . . . . 8–22

Establishing a Cell Phone Partnership. . . . . . . . . . . 8–22

Working with Files. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–23

Creating a File Transfer Connection . . . . . . . . . . . . 8–23

Sending Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8–23

Creating a Folder on a Remote Device . . . . . . . . . . 8–23

Receiving a File from a Remote Device . . . . . . . . . 8–24

Deleting a File from a Remote Device . . . . . . . . . . 8–24

Using Business Card Exchange. . . . . . . . . . . . . . . . 8–24

Setting Up Your Business Card Information. . . . . . 8–25

Opening a Connection . . . . . . . . . . . . . . . . . . . . . . . . . . 8–27

Viewing Connection Status . . . . . . . . . . . . . . . . . . . 8–27

Closing a Connection. . . . . . . . . . . . . . . . . . . . . . . . 8–28

Viewing Connection Information . . . . . . . . . . . . . . 8–28

Working with Connections . . . . . . . . . . . . . . . . . . . 8–28

9 Using the Wireless LAN

Getting Acquainted . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9–1

Learning the Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9–2

Getting Started with the Wireless LAN . . . . . . . . . . . . . . 9–3

Powering the WLAN On or Off . . . . . . . . . . . . . . . . 9–3

Automatically Connecting to a Network . . . . . . . . . . 9–4

Manually Entering New Network Settings . . . . . . . . 9–5

Searching for Networks to Access. . . . . . . . . . . . . . . 9–6

User’s Guide vi

Managing Wireless Network Settings . . . . . . . . . . . . . . . 9–7

Viewing or Editing a Wireless Network . . . . . . . . . . 9–7

Deleting a Wireless Network. . . . . . . . . . . . . . . . . . . 9–7

Monitoring Signal Strength and Status . . . . . . . . . . . . . . 9–8

Working with Network Settings. . . . . . . . . . . . . . . . . . . . 9–9

Looking Up an IP Address . . . . . . . . . . . . . . . . . . . . 9–9

Changing TCP/IP Settings. . . . . . . . . . . . . . . . . . . . 9–10

Changing DNS and WINS Settings. . . . . . . . . . . . . 9–11

Setting Up VPN Server Connections. . . . . . . . . . . . 9–12

Changing VPN Server Connections . . . . . . . . . . . . 9–12

Starting VPN Server Connections . . . . . . . . . . . . . . 9–14

Setting Up Proxy Server Settings . . . . . . . . . . . . . . 9–14

10Troubleshooting

Common Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–1

ActiveSync . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–5

Expansion Cards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–7

Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–8

Wireless LAN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10–10

Contents

A Regulatory Notices

Federal Communications Commission Notice. . . . . . . . . A–1

Declaration of Conformity for products marked

with the FCC logo—United States only . . . . . . . . . . A–2

Canadian Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–3

Avis Canadien . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–3

Japanese Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–3

Korean Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–3

European Union Notice . . . . . . . . . . . . . . . . . . . . . . . . . . A–4

Battery Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–5

Equipment Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–6

Airline Travel Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–6

User’s Guide vii

Wireless Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A–6

U.S. Regulatory Wireless Notice. . . . . . . . . . . . . . . . A–7

Canadian Regulatory Wireless Notice. . . . . . . . . . . . A–7

Japanese Regulatory Wireless Notice . . . . . . . . . . . . A–8

Brazilian Regulatory Wireless Notice . . . . . . . . . . . . A–8

B Specifications

System Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . B–1

Physical Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . B–2

Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . B–3

Contents

User’s Guide viii

Getting to Know Your iPAQ

Pocket PC

Congratulations on purchasing an HP iPAQ Pocket PC h4000 Series. Use this guide to find out about setting up your Pocket PC and to learn about how it works.

The software programs described below are preinstalled on your iPAQ Pocket PC. These preinstalled programs are not deleted if your Pocket PC loses power.

You can find detailed information for using these programs in the Help files on your iPAQ Pocket PC. To access these Help files, from the Start menu, tap Help and select a program.

In addition, Microsoft Pocket PC Basics provides instructions on operating the Pocket PC. To locate Pocket PC Basics, go to the Tod ay screen and tap Start > Help > Pocket PC Basics.

hp iPAQ Software

iPAQ Backup Back up your data to protect it from loss due to

a drained battery, accidental deletion, or hardware failure.

iPAQ Image Zone Display individual images and run slide shows.

Also display images from a digital camera’s SD storage card.

Self-Test Run a basic diagnostic test on the device.

User’s Guide 1–1

Functions

(Continued)

Getting to Know Your iPAQ Pocket PC

hp iPAQ Software

Asset Viewer List detailed information about your system

and its configuration.

Bluetooth Enables short-range wireless communications

technology capable of exchanging information up to a distance of about 30 feet (10 meters).

hp Mobile Print Center Enable printing. (On CD for all models.)

iPAQ Wireless Allows you to turn Wireless LAN and/or

Bluetooth on and off.

iTask Allows you to quickly access the most

frequently used features on your iPAQ Pocket PC.

Functions

Note: Press and hold the iTask button ( ) on the front of your iPAQ Pocket PC to switch between the current application and the last application you were running.

User’s Guide 1–2

Getting to Know Your iPAQ Pocket PC

Microsoft Pocket PC Software

ActiveSync Synchronize the information between your

Pocket PC and computer so you have the latest information in both locations. Be sure you install ActiveSync on your computer before connecting the cradle and iPAQ Pocket PC to your computer.

Calculator Perform calculations and convert currency.

Functions

Calendar Schedule appointments, meetings, and other

Connections Connect your Pocket PC to the Internet and

Contacts Keep an updated list of friends and colleagues

Inbox Receive and send Internet e-mail messages

Notes Create handwritten or typed notes, drawings,

Pictures View individual pictures, run a slide show, or

Pocket Excel Create and edit workbooks or view and edit

events, and set an alarm to remind you of the appointments. Appointments for the day are displayed on the To d ay screen.

intranet to browse Web sites, send and receive e-mail, and synchronize information using ActiveSync.

to e-mail and telephone.

in Inbox on your iPAQ Pocket PC or your computer if ActiveSync is installed. You must have an e-mail address provided by your Internet Service Provider (ISP) or employer to send and receive e-mail.

and recordings.

set a picture as the background on the Today screen.

Excel workbooks created on your computer.

(Continued)

User’s Guide 1–3

Getting to Know Your iPAQ Pocket PC

Microsoft Pocket PC Software

Pocket Internet Explorer Browse the Internet and download pages

through synchronization or by connecting to the Internet.

Pocket Word Create new documents or view and edit Word

documents created on your computer.

Settings Obtain quick access to settings for the

backlight, clock, memory, power, regional settings, Today screen, password, sounds and notifications, etc.

Tasks Keep track of your to-do list.

Terminal Services Client Log onto your computer and use all the

programs available on that computer from your Pocket PC (Windows 2000 and XP or later).

Functions

Windows Media Player 9Series

Play digital audio and video files in Windows Media or MP3 format on your device.

Battery Saving Tip: You can program an Application Button to turn off the screen when an MP3 is playing, saving battery power used to run the screen. Tap Start > Windows Media > Tools > Settings > Buttons. From the Select Function drop down list, tap Screen Toggle. Press one of the programmable buttons on the front of your iPAQ Pocket PC, then tap OK.

Using the Stylus

Your iPAQ Pocket PC comes with a stylus that you should use to tap or write on your screen.

CAUTION: To prevent damage to your iPAQ Pocket PC screen, never

use any device other than the stylus that comes with the Pocket PC or an approved replacement to tap or write on the screen. If you lose or break your stylus, you can order extras at

www.hp.com/products/pocketpc/options.

User’s Guide 1–4

Getting to Know Your iPAQ Pocket PC

You can perform three basic actions using the stylus:

Tap —Lightly touch the screen to select or open an item. Lift the stylus after you tap an item. Tapping is equivalent to clicking an item with the mouse on your computer.

Drag—Place the point of the stylus on the screen and drag an item across the screen without lifting the stylus until you have completed the selection. Dragging is equivalent to dragging with the left mouse button pressed on your computer.

Tap and hold—Hold the stylus pointer on an item for a short time until a menu displays. Tapping and holding is equivalent to right-clicking your computer mouse button. When you tap and hold, a circle of red dots appears around the stylus to indicate that the menu will soon pop up.

Setting the Date and Time

When you turn on your iPAQ Pocket PC for the first time, you are requested to select your time zone. After setting the time zone, you still need to set the time and date on your unit. All three settings are located in the Clock Settings screen and can be set at the same time.

Note: By default, the time on the iPAQ Pocket PC is synchronized with your computer each time the two devices connect using ActiveSync.

Setting the Time for Home and Locations You Are Visiting

From the Start menu, tap Settings > System tab > Clock icon.

Shortcut: From the To da y screen, tap the Clock icon to set the time.

1. Tap either Home or Visiting.

2. Tap the time-zone down arrow, and select the appropriate

time zone.

User’s Guide 1–5

3. Tap the hour, minutes, or seconds, and use the up and down arrows to adjust the time.

Shortcut: You can also adjust the time by moving the hands of the clock with the stylus.

4. Tap AM or PM.

5. Tap OK.

6. Tap Ye s to save the time.

Setting the Date

1. From the Start menu, tap Settings > System tab > Clock icon.

Shortcut: From the To da y screen, tap the Clock icon to set the date.

2. Tap the down arrow by the date.

3. Tap the left or right arrow to select a month and year.

4. Tap a day.

5. Tap OK.

6. Tap Ye s to save the date settings.

You need to reset your time zone, time, and date if:

Getting to Know Your iPAQ Pocket PC

■ The location time (Home or Visiting) needs to be changed.

■ All power to the iPAQ Pocket PC is lost, which removes all

saved settings.

■ You perform a full reset of your iPAQ Pocket PC.

Shortcut: From the Tod ay screen, tap the Clock icon to set the time zone, time, and date.

User’s Guide 1–6

Getting to Know Your iPAQ Pocket PC

Entering Owner Information

You can personalize your iPAQ Pocket PC by entering owner information. To enter owner information:

1. From the To da y screen, tap Start > Settings > Owner

Information.

Shortcut: From the To da y screen, tap Tap here to set owner information.

2. Tap in the Name field. A keyboard appears at the bottom of the screen. Tap on the characters to enter your name.

Note: If you prefer, you can use Letter Recognizer, Microsoft Transcriber, or Block Recognizer to input information. Refer to Chapter 5, “Learning Input Methods,” for more information.

3. Tap the Ta b key on the keyboard to move the cursor to the next field.

4. Continue entering whatever information you want to include.

5. To display owner information at startup, tap in the Show information when device is turned on checkbox.

6. Tap on the Notes tab to enter any notes.

7. Tap OK to save the information and return to the Tod ay screen.

Resetting the Unit

Performing a Normal Reset

A normal reset is sometimes referred to as a “soft reset.” A normal reset stops all running applications, but does not erase any programs or saved data.

CAUTION: Be sure to save any unsaved data before performing a

normal reset since normal reset erases all unsaved data.

User’s Guide 1–7

To perform a normal reset:

1. Locate the recessed Reset button on the side (h4100) or bottom (h4300) of your iPAQ Pocket PC.

2. Use the stylus to lightly press the Reset button. The Pocket PC restarts and displays the Today screen.

Performing a Full Reset

A full reset is sometimes referred to as a “hard reset.” Perform a full reset when you want to clear all settings, programs, and data from RAM.

CAUTION: If you perform a full reset, your iPAQ Pocket PC returns to its

default settings and loses all information that is not recorded in iPAQ File Storage.

To perform a full reset:

1. Press and hold the Power button.

2. Press the Reset button on the side (h4100) or bottom (h4300) of the iPAQ Pocket PC with the stylus.

Getting to Know Your iPAQ Pocket PC

HP iPAQ Pocket PC h4100 series

User’s Guide 1–8

hp iPAQ Pocket PC h4300 series

3. Release the Power button first, then the Reset button.

4. The Pocket PC resets and powers on.

Aligning the Screen

Getting to Know Your iPAQ Pocket PC

When the iPAQ Pocket PC is turned on for the first time, you are guided through a screen alignment process. You must realign your screen if:

■ The Pocket PC does not respond accurately to your taps.

■ You perform a full reset of your Pocket PC.

To realign the iPAQ Pocket PC screen:

1. From the Start menu, tap Settings > System tab > Screen icon.

2. Tap the Align Screen button.

Shortcut: To access the Align Screen application without tapping on the screen, push down and hold the 5-Way Navigation button, then press the Calendar button ( ).

User’s Guide 1–9

3. Tap the cross-hair object at each location. Be precise when tapping the cross-hair object.

4. Tap OK.

Routine Care

To keep your iPAQ Pocket PC in good condition and working properly, follow these guidelines:

■ Keep your Pocket PC away from excessive moisture and

temperature extremes.

■ Do not expose your Pocket PC to liquids or precipitation.

■ Do not place anything on top of your Pocket PC to prevent

damage to the screen.

■ Clean your Pocket PC by wiping the screen and the exterior

with a soft, damp cloth lightly moistened only with water.

■ Avoid exposing your Pocket PC to direct sunlight or strong

ultraviolet light for extended periods of time.

■ Avoid scratching the surface of the screen and banging it

against hard objects.

Getting to Know Your iPAQ Pocket PC

■ Use only the stylus that comes with your Pocket PC or an

approved replacement on the screen to prevent scratching it.

CAUTION: To reduce the risk of damage to the internal components,

do not spray liquid directly on the screen or allow excess liquid to drip inside your iPAQ Pocket PC. Using soap or other cleaning products on the screen may discolor the finish and damage it.

User’s Guide 1–10

Using ActiveSync

You can use Microsoft ActiveSync to:

■ Synchronize information between your iPAQ Pocket PC and

up to two computers or one server so that you have the latest information in all locations.

■ Change synchronization settings and the synchronization

schedule.

■ Copy files between your device and computer.

■ Install applications on your iPAQ Pocket PC.

■ Back up and restore device information.

■ Synchronize links.

■ Send and receive e-mail.

■ Request meetings.

CAUTION: For synchronization to work properly, install Microsoft ActiveSync on your computer before you connect your iPAQ Pocket PC

to your computer.

User’s Guide 2–1

Connecting to a Computer

Connect your iPAQ Pocket PC to your computer using Microsoft ActiveSync and the desktop cradle, a wireless infrared connection, or Bluetooth. For more information on using ActiveSync with Bluetooth, refer to Chapter 8,

“Using Bluetooth.”

Note: When using Microsoft ActiveSync to synchronize e-mail on your computer with your iPAQ Pocket PC, you must have Microsoft Outlook 98 or later installed on your computer. If you do not have Outlook, install the Microsoft Outlook 2002 software from the CD. Microsoft Outlook Express will not work with the iPAQ Pocket PC and ActiveSync.

Installing ActiveSync

CAUTION: For synchronization to work properly, install Microsoft ActiveSync on your computer before you connect your iPAQ Pocket PC

to your computer.

Using ActiveSync

To install Microsoft ActiveSync on your computer:

1. Insert the Companion CD into the CD tray or slot on your computer.

2. Select the link to install Microsoft ActiveSync.

3. Follow the instructions in the installation wizard. For more help, click the ActiveSync Help button during installation.

4. After installing ActiveSync on your computer, connect the iPAQ Pocket PC to the computer using the desktop cradle.

User’s Guide 2–2

Synchronizing with Your Computer

After you have installed ActiveSync, you can:

■ Create partnerships that enable you to synchronize

information with up to two computers.

■ Select information to be synchronized with your iPAQ Pocket

PC (for example, Contacts, Calendar, Inbox, Tasks, Favorites, Files, Notes, and AvantGo).

Note: When you synchronize files, you can drag and drop the selected files from your computer to the synchronized folder on your iPAQ Pocket PC. If you named your device “PC1” when you created your partnership, then the synchronized folder is named “PC1.” When you synchronize, the files move to and from your iPAQ Pocket PC.

Using the Serial Infrared (IR) Connection

As an alternative to using the desktop cradle, you can synchronize your iPAQ Pocket PC and your computer using an infrared connection if you have an infrared port or an infrared USB adapter installed on your computer. The infrared connection option works only on computers that have Microsoft Windows 98SE, Me, 2000, or XP operating systems installed.

To set up an infrared connection to a computer:

1. Synchronize your iPAQ Pocket PC with your computer using the desktop cradle before the first time you establish an ActiveSync connection via infrared.

2. Follow your computer manufacturer’s instructions to install and set up an infrared port.

3. Remove the iPAQ Pocket PC from the cradle and line up the infrared port with the computer infrared port so they are unobstructed and within 12 inches (30.5 cm) of each other.

Using ActiveSync

User’s Guide 2–3

4. Initiate a connection by tapping Start > ActiveSync > Too ls > Connect via IR. Synchronization begins on your

device.

5. To disconnect, move the devices away from each other or tap X in the upper right of the screen to turn off.

Changing Synchronization Settings

You can modify your synchronization settings for Microsoft ActiveSync to:

■ Change when your iPAQ Pocket PC synchronizes with your

computer or server.

■ Change the type of connection from your iPAQ Pocket PC

to your computer (for example, serial, USB, infrared connections).

■ Select the files and information to synchronize with your

computer.

■ Select the files and information you do not want to

synchronize with your computer (for example, e-mail attachments).

Using ActiveSync

■ Determine how conflicts between information on your

iPAQ Pocket PC and information on your computer are handled.

To change synchronization settings:

1. From the Start menu on your computer, click Programs > Microsoft ActiveSync > Tool s > Options.

a. On the Sync Options tab, select the files and information

to synchronize with your computer.

b. On the Schedule tab, select when your iPAQ Pocket PC

synchronizes with your computer.

c. On the Rules tab, determine how conflicts between

information on your iPAQ Pocket PC and information on your computer are handled.

User’s Guide 2–4

2. Tap OK when you are finished.

3. From the File menu, click Connection Settings. Select the type of connection to be allowed between the iPAQ Pocket PC and the computer.

Copying Files

You can copy files to and from your computer using Explore in ActiveSync and Windows Explorer.

To co p y file s :

1. Insert your iPAQ Pocket PC into the desktop cradle.

2. From the Start menu on your computer, click Programs >

Microsoft ActiveSync.

3. Click Explore.

4. Double-click the My Pocket PC icon.

5. On your computer, right-click the Start menu, and select

Explore.

6. Locate the file to be moved.

Using ActiveSync

Note: You cannot copy preinstalled files or system files.

7. Drag and drop your files between your iPAQ Pocket PC and your computer. ActiveSync converts the files so that they can be used by the Pocket Office applications, if necessary.

Note: Move your files directly into My Documents on your iPAQ Pocket PC (or into a folder inside My Documents), so the applications on your iPAQ Pocket PC can locate them.

User’s Guide 2–5

Installing Programs

To install programs on your iPAQ Pocket PC from your computer using ActiveSync:

1. Connect your iPAQ Pocket PC to your computer using the desktop cradle.

2. Follow the instructions provided with the program and by the installation wizard.

3. Check the screen of your iPAQ Pocket PC to see if any further steps are necessary to complete the program installation.

Backing up and Restoring

To help reduce the chance of losing information, you should back up information to your computer regularly. For more information on backing up and restoring information using Microsoft ActiveSync, refer to “Backing Up Information” in Chapter 4.

Using ActiveSync

Synchronizing Links

You can synchronize links to Web sites from your Favorites list on your computer to view them offline with Pocket Internet Explorer.

1. From the Start menu on your computer, click Programs and double-click the Internet Explorer icon.

2. Click Favorites to see the list of links to your favorite Web sites.

3. To save a Web site link to Mobile Favorites, open the Web site, and click Create Mobile Favorite.

If you select “Favorites” as an information type to be synchronized, ActiveSync copies your mobile favorite to your Pocket PC the next time you synchronize.

4. Follow the instructions in Synchronize information to manually synchronize your favorite links.

User’s Guide 2–6

Sending and Receiving E-mail

You can send and receive e-mail messages by synchronizing your iPAQ Pocket PC with your computer using ActiveSync. If you are using ActiveSync to send and receive e-mail messages, the name of the folder you are using is displayed at the bottom of the screen. For more information on sending and receiving e-mail using ActiveSync, from the Start menu, tap Help > Inbox.

Requesting Meetings

You can schedule a meeting and send a meeting request through ActiveSync. For more information, from the Start menu, tap Help > Calendar.

Using ActiveSync

User’s Guide 2–7

Managing the Battery

Installing the Battery

The Pocket PC has a small internal backup battery that allows you to change the main battery without losing RAM data (user-installed programs and data) as long as it is replaced immediately.

It is recommended that you fully charge the iPAQ Pocket PC battery before setting up the unit, and recharge regularly. Your Pocket PC uses some power to maintain files in RAM and the clock. While working at your desk, keep the Pocket PC and Charger Adapter connected through the desktop cradle. When you travel, it is recommended that you carry the AC Adapter, Charger Adapter plug, or an optional spare battery with you.

Your iPAQ Pocket PC is shipped with the battery partially charged.

User’s Guide 3–1

Managing the Battery

Installing the Battery in the h4100 Model

To install the removable/rechargeable battery in the HP iPAQ Pocket PC h4100 series:

1. On the back of the iPAQ Pocket PC, slide the Cover Release latch up 1 and pull the cover away from the unit 2.

User’s Guide 3–2

Managing the Battery

2. Insert the battery into the battery slot on the right side of the Pocket PC 1, and push the left side of the battery into place 2 with the connectors lined up on the lower right.

Note: Ensure the large battery label is visible when the battery is installed.

User’s Guide 3–3

Managing the Battery

3. Replace the cover by matching the tabs on the cover to the latches on the iPAQ Pocket PC, and snap into place.

CAUTION: The cover must be tightly latched in place for the iPAQ

Pocket PC to operate.

Note: If the battery is not fully charged, you must connect the AC Adapter to the Pocket PC to fully charge it before continuing. It takes about four hours to fully charge the battery.

User’s Guide 3–4

Managing the Battery

Installing the Battery in the h4300 Model

To install the removable/rechargeable battery in the HP iPAQ Pocket PC h4300 series:

1. On the back of the iPAQ Pocket PC, hold down the Cover Release Button 1 as you slide the cover down and away from the unit 2.

User’s Guide 3–5

Managing the Battery

2. Insert the battery into the battery slot on the right side of the Pocket PC 1, and push the left side of the battery into place 2 with the connectors lined up on the lower right.

Note: Ensure the large battery label is visible when the battery is installed.

User’s Guide 3–6

Managing the Battery

3. Replace the cover by lining up the cover with the sides of the iPAQ Pocket PC and sliding the cover up until it snaps into place.

CAUTION: The cover must be tightly latched in place for the iPAQ

Pocket PC to operate.

Note: If the battery is not fully charged, you must connect the AC Adapter to the Pocket PC to fully charge it before continuing. It takes up to four hours to fully charge the battery.

User’s Guide 3–7

Managing the Battery

Removing the Battery

Removing the Battery from the h4100 Model

To remove the battery from the iPAQ Pocket PC h4100 series:

1. Remove the stylus.

2. Remove the battery cover.

3. Place your thumb in the recess 1, then lift the left side of the battery 2 and pull it out 3.

CAUTION: Because most of the applications and data you install on your iPAQ Pocket PC are held in memory (RAM), you need to reinstall

them if the battery completely discharges or if the battery is removed from the unit for extended periods of time.

You do not need to reinstall applications and data installed in the iPAQ File Store folder because they are saved in nonvolatile memory.

User’s Guide 3–8

Managing the Battery

Removing the Battery from the h4300 Model

To remove the battery from the iPAQ Pocket PC h4300 series, remove the battery cover, place your thumb in the recess 1, then lift the left side of the battery 2 and pull it out 3.

CAUTION: Because most of the applications and data you install on your iPAQ Pocket PC are held in memory (RAM), you need to reinstall

them if the battery completely discharges or if the battery is removed from the unit for extended periods of time.

You do not need to reinstall applications and data installed in the iPAQ File Store folder because they are saved in nonvolatile memory.

Charging the Battery

Battery Saving Tip: Leave your iPAQ Pocket PC connected to AC power at all times when you’re not using it.

User’s Guide 3–9

Charging with the AC Adapter

The standard AC Adapter works in any household outlet. You can also purchase one that works in your vehicle’s cigarette lighter or a 12-volt power outlet.

CAUTION: Use only HP recommended AC adapters.

To charge the iPAQ Pocket PC using the AC Adapter:

1. Plug the AC Adapter into an electrical outlet 1.

2. Insert the AC Adapter plug into the charging adapter 2.

3. Insert the charging adapter into the bottom of the iPAQ Pocket PC 3.

CAUTION: To avoid damaging your iPAQ Pocket PC or the AC Adapter, check to be sure all connectors are properly aligned before

connecting them.

Managing the Battery

4. When the power indicator on the top of the iPAQ Pocket PC turns solid amber, the unit is fully charged and you can disconnect the AC Adapter. The approximate time to fully charge a unit is four hours.

User’s Guide 3–10

Managing the Battery

Charging with the Desktop Cradle and AC Adapter

Use the Desktop Cradle to:

■ Charge the iPAQ Pocket PC.

■ Synchronize the Pocket PC with your computer.

(For information on synchronizing, refer to Chapter 2,

“Using ActiveSync.”)

To charge the iPAQ Pocket PC using the desktop cradle:

1. Plug the AC Adapter into an electrical outlet 1 and connect the other end of the AC Adapter to the AC connector on the desktop cradle 2.

2. Slide the bottom of your iPAQ Pocket PC into the cradle 3 and push firmly to seat it.

CAUTION: To avoid damaging your iPAQ Pocket PC or the cradle, check to be sure the iPAQ Pocket PC and cradle connectors are properly

aligned before pushing the Pocket PC into the cradle.

Note: The amber charge light on the iPAQ Pocket PC blinks while the battery is recharging and turns solid (nonblinking) when the battery is fully charged.

User’s Guide 3–11

Charging a Spare Battery

Battery Saving Tip: To ensure you always have battery power available, invest in an extra Standard Battery or Extended Battery. These batteries can be charged in the Desktop Cradle. To purchase an extra battery, refer to the HP Web site at

www.hp.com/products/pocketpc.

To charge an extra battery in the Desktop Cradle:

1. Plug the AC Adapter into an electrical outlet 1 and connect the other end of the AC Adapter to the AC connector on the desktop cradle 2.

2. Insert the battery into the battery compartment with the connectors lined up on the lower right 3, and push the left side of the battery into place 4.

3. When the Battery Light on the front of the Desktop Cradle 5 is amber, the battery is charging. When the light is green, the battery is completely charged and ready to use.

Managing the Battery

User’s Guide 3–12

Changing the Backlight Settings

To change the backlight settings in order to conserve more battery power:

1. From the Start menu, tap Settings > System tab >

Backlight.

Shortcut: Press Application Button 4 (iTask), then tap the

Light bulb icon.

2. Select the following backlight settings:

■ Brightness

■ Battery Power

■ External Power

Battery Saving Tip: Set the backlight to go off quickly after you stop using your iPAQ Pocket PC, or move the slide bar to Power Save mode to turn off the backlight completely. You can turn the backlight back on (or off) by pressing and holding the Power button for three seconds.

Managing the Battery

Changing the Wireless LAN Power Saving Modes

To change Wireless LAN (WLAN) power saving modes:

1. From the Start menu, tap Settings > System tab > Power > Control tab.

2. For WLAN Power Save mode, select:

■ OFF—No WLAN Power Save. Use only if the absolute

highest WLAN throughput is required.

■ Auto—Automatically switches between Power Save and

no power save.

■ Extended—Uses the least battery power while

maintaining a WLAN connection. This mode significantly reduces the WLAN data throughput. It is not recommended for large file transfers.

User’s Guide 3–13

Disabling the Application Buttons

Pressing the Application Buttons on your iPAQ Pocket PC will turn your device on by default.

Battery Saving Tip: To reduce incidence of accidentally powering on the iPAQ Pocket PC, you may choose to disable the Application and Record Buttons Auto Power On feature.

To disable the Auto Power On function of the Application Buttons or the Record Button:

1. Tap Start > Settings > Buttons > Lock tab.

2. Tap in the Disable the application buttons checkbox AND/OR tap in the Disable the record button checkbox.

3. Tap OK.

Note: If you disable the Auto Power On feature for the Application Buttons, the Power Button still turns the unit on. Once the unit is turned on, all buttons will function according to their programmed functions.

Managing the Battery

Manually Monitoring the Battery

To manually monitor the battery power:

1. From the Start menu, tap Settings > System tab > Power icon.

2. Tap OK.

Battery Saving Tip: Tap Start > Settings > System tab > Power > Control tab, then tap the On battery power checkbox and set

it to turn your iPAQ Pocket PC off after a short time of not being used.

User’s Guide 3–14

Learning the Basics

Using the Today Screen

When you first turn on your iPAQ Pocket PC, the To da y screen displays. You can also display it by tapping Start, and Tod ay. Use the To da y screen to view:

■ Owner information

■ Upcoming appointments

■ Unread and unsent messages

■ Tasks that need to be completed

Tap t o s w i t c h to a program.

Tap to create a new item.

User’s Guide 4–1

Tap to set ISP or Work connections. Tap to change volume or mute all sounds.

Tap to change date and time.

Tap to set appointment or view existing appointment.

Tap to read e-mail.

Tap to turn Bluetooth on/off

Navigation Bar and Command Bar

The Navigation bar is located at the top of the screen. It displays the active program and current time, and allows you to close screens. Use the Start menu to select a program.

Tap to select a program you used recently.

Tap to select a program.

Tap to see additional programs.

Tap to customize the settings.

Learning the Basics

Tap to view online Help.

Tap for Bluetooth features.

Within each program, use the Command bar located at the bottom of the screen to perform tasks. Tap New to create a new item in the current program.

New button

actions

User’s Guide 4–2

Buttons

Input panel button

Status Icons

You may see the following status icons displayed on the Navigation bar or Command bar. Tap the icon on the screen to view more information related to the item.

Learning the Basics

Active connection to computer or wireless network.

Inactive connection to computer or wireless network.

Microsoft ActiveSync is synchronizing.

Speaker is on.

Speaker is off.

iPAQ Pocket PC is connected with the desktop cradle. This icon appears only when there is an active connection.

Bluetooth power-on/off icon. When the Bluetooth icon is blue, Bluetooth is active. When the Bluetooth icon is grayed with a red X, Bluetooth is inactive.

Pop-Up Menus

Pop-up menus allow you to quickly perform an action. Use the pop-up menu to cut, copy, rename, and delete an item, also send an e-mail or send a file to another device.

To access a pop-up menu, tap and hold the stylus on the item on which you want to perform the action. When the menu appears, tap the desired action, or tap anywhere outside the menu to close it without performing an action.

User’s Guide 4–3

Creating information

From the To da y screen, you can create new information, including:

■ Appointments

■ Contacts

Learning the Basics

Tap and hold to display the pop-up menu.

Tap the action you want.

Tap outside the menu to close it without performing an action.

■ Messages

■ Excel Workbook

■ Notes

■ Ta sk s

■ Word documents

1. Tap , or from the Start menu, tap Tod ay > New.

2. Tap an option to create a new item.

3. Tap OK after you finish creating a new item.

User’s Guide 4–4

Customizing the Today Screen

From the Settings Today screen, you can:

■ Add a picture as the background.

■ Select the information that appears on the Tod ay screen.

■ Set the order of the information.

■ Set when to see the To day screen.

1. Tap , or from the Start menu, tap Settings > Tod ay.

2. Select Use this picture as the background checkbox.

Learning the Basics

3. Tap Browse to select a picture from File Explorer.

User’s Guide 4–5

Learning the Basics

4. Tap the Items tab to select or reorder the information on the Tod ay screen.

5. Tap an item to highlight it.

6. Tap Move Up or Move Down to change the order of items on the Tod ay screen.

Note: You cannot change the placement of the Date on the Toda y screen.

7. Tap the down arrow associated with Display Today screen if device is not used for...hours checkbox to determine how many hours must pass before the To day screen displays.

8. Tap OK.

User’s Guide 4–6

Using Applications

Opening Applications

Open any application on your iPAQ Pocket PC from the Start menu.

Note: You can also open an application by assigning it to an Application Button. To assign Application Buttons, from the Tod ay screen, tap Start > Settings > Buttons.

To open an application:

1. Tap Start > Programs.

2. Tap the desired application title or logo.

Minimizing Applications

To minimize an open application, tap the x at the top right of the screen.

Learning the Basics

Closing Applications

Applications automatically close based on available memory. However, if your iPAQ Pocket PC is running slowly, you can close applications using iTask or by manually closing them.

Closing with iTask

1. Press the iTask button (Application Button 4 on the lower right side of your unit).

2. Tap and hold the program to be closed.

3. From the pop-up menu, tap Close This Task.

User’s Guide 4–7

Closing Manually

1. From the Start menu, tap Settings > System tab > Memory > Running Programs tab.

2. Tap Stop All or select a particular application, then tap Stop.

Note: To bring a currently running program to the foreground, tap Activate.

Installing Applications

Install applications on your iPAQ Pocket PC from your:

■ Computer by using Microsoft ActiveSync.

■ iPAQ Pocket PC if the application file has a .cab extension.

■ iPAQ Pocket PC or your computer by copying an application

file that has an .exe or .cef extension.

When installing applications, look for the correct version for your iPAQ model or Pocket PC 2003.

Learning the Basics

■ Follow the instructions provided with the application and by

the installation Wizard to install applications from your computer.

■ Tap the application file in File Explorer on your iPAQ Pocket

PC and follow the instructions on the installation Wizard to install applications on your Pocket PC.

User’s Guide 4–8

Using iPAQ Image Zone

Using iPAQ Image Zone, you can:

■ View pictures stored on your iPAQ Pocket PC or on a storage

card

■ Record sounds with pictures

■ View a slideshow

■ Print pictures

Viewing Pictures

1. From the Start menu, tap Programs > iPAQ Image Zone.

Note: The viewer opens in Browse mode by default. Browse mode displays thumbnail view of the pictures in the current folder.

2. Tap a thumbnail to select the picture. A preview of the picture and information about it will be displayed.

To view images in a different folder:

1. Tap File > Change Folder.

2. Select the desired folder.

3. Tap OK.

Learning the Basics

Viewing a Picture Full-Screen

To view a picture full-screen, and to be able to zoom in or out:

1. Select the picture by tapping on it thumbnail.

2. Tap View > Image, or tap on the preview window.

3. Zoom in or out using the toolbar buttons. If the picture is too large to fit on the screen, you can display other parts of the picture by dragging the stylus on the screen, or by using the Navigation Buttons.

User’s Guide 4–9

Recording Sound With a Picture

You can record sound for each picture. When the picture is displayed, the associated sound is played. Pictures with sound have a speaker icon in their thumbnails.

To add sound to a picture:

1. Select the picture by tapping on its thumbnail.

2. Tap the Cassette icon on the menu bar.

3. Tap the Record button on the Recording toolbar.

4. Speak into the microphone or record the sound.

5. Tap the Stop button on the Recording toolbar.

To change audio options:

1. Tap File > Options > Audio tab.

2. Select your audio options.

3. Tap OK.

Viewing a Slideshow

Learning the Basics

You can view a slideshow of the images in the current folder. To start the slideshow, tap View > Slideshow.

During the slideshow, tap anywhere on the screen to display the on-screen controls which you can use to move forward or backward through the slides, or to end the slideshow. You can also use the Navigation Buttons to move forward or backward through the slides.

You can control display options such as:

■ Sequence

■ Delay

■ Rotation

■ Transition Effect

User’s Guide 4–10

To change slideshow settings:

1. Tap File > Options > Slideshow tab.

2. Select the settings and effects you want to use in your slideshow.

3. Tap OK.

Printing Pictures

You can print pictures from iPAQ Image Zone if HP Mobile Printing has been installed from the Companion CD.

To print a picture:

1. Select the picture to be printed by tapping on its thumbnail.

2. Tap File > Print.

Note: For more information on using iPAQ Image Zone, tap Start > Programs > iPAQ Image Zone, then tap > Help.

Backing Up Information

Learning the Basics

Use iPAQ Backup or Microsoft ActiveSync Backup to back up and restore information on your iPAQ Pocket PC.

Note: iPAQ Backup is already installed on the iPAQ Pocket PC. You must install ActiveSync on your computer before using ActiveSync Backup.

To help reduce the chance of losing information, you should back up information on a regular schedule.

User’s Guide 4–11

Backup/Restore using iPAQ Backup

iPAQ Backup saves your data in a backup file. You may designate a file name and a location for the file to be saved. iPAQ Backup backs up to a memory card, main memory, or the iPAQ File Store folder. Close all programs on your iPAQ Pocket PC before backing up or restoring your information.

CAUTION: Restoring your information replaces the current information

on your iPAQ Pocket PC with the information saved in your backup.

To backup/restore using iPAQ Backup:

1. Tap , or from the Start menu, tap Programs > iPAQ

Backup.

2. Tap the Backup tab or the Restore tab.

3. Select the files and folders to be backed up or restored.

4. Select file location for backed-up data.

5. Set backup or restore options.

6. Press the Backup or Restore button, and press the Start button on the next screen.

Learning the Basics

Backup/Restore Using ActiveSync

Close all programs on your iPAQ Pocket PC before backing up or restoring your information.

CAUTION: Restoring your information replaces the current information

on your iPAQ Pocket PC with the information saved in your backup.

To backup/restore using ActiveSync:

1. Be sure the iPAQ Pocket PC is connected to your computer.

2. From your computer, open Microsoft ActiveSync. From the Start menu, click Programs > Microsoft ActiveSync.

3. From the To ol s menu, click Backup/Restore.

4. Click the Backup or Restore tab, and select your options.

5. Click Backup Now or Restore Now.

User’s Guide 4–12

Using iPAQ File Store Folder

You can install programs and save files to the iPAQ File Store folder, which is accessed from File Explorer on your iPAQ Pocket PC.

Programs and files stored in iPAQ File Store are held in ROM and are saved if you perform a full reset of your iPAQ Pocket PC or if the battery discharges completely.

To save to iPAQ File Store:

1. Copy the files to be saved to the iPAQ File Store folder.

2. From the Start menu, tap Programs > File Explorer > My Device > iPAQ File Store.

3. Paste the selected files.

Note: Before saving files to the iPAQ File Store folder, it is a good idea to determine how much memory is available in the folder. To view the amount of memory, from the Start menu, tap Settings >

System tab > Memory > Storage Card tab, then select iPAQ File Store from the drop down menu.

Learning the Basics

User’s Guide 4–13

Learning Input Methods

Using Input Software

CAUTION: To avoid damaging your iPAQ Pocket PC screen, always

use a stylus. Never use a pen or any type of metal pointer on the screen.

To input information to your Pocket PC, you can tap the on-screen keyboard or write with the Letter Recognizer, Microsoft Transcriber, or Block Recognizer in any application. On the HP iPAQ Pocket PC h4300 Series, the integrated keyboard can also be used to input information. You can use the stylus to draw and write on the screen in the Notes application and from any Notes tab in the Calendar, Contacts, and Tasks applications.

Changing Word Suggestion Options

As you type or write, the Pocket PC suggests words for you in a box above the keyboard, Letter Recognizer, or Block Recognizer, but not in the Transcriber.

You determine:

■ If words are suggested.

■ The number of letters you enter before a word is suggested.

■ The number of words that are suggested per entry.

User’s Guide 5–1

Learning Input Methods

To change settings for word suggestions:

1. From the Start menu, tap Settings > Input.

2. Tap the Word C o mp le t ion tab.

3. Tap the down arrow associated with letters and select the number of letters you want to type before a word is suggested.

User’s Guide 5–2

Learning Input Methods

4. Tap the down arrow associated with words and select the number of words you want suggested.

5. Tap OK.

Note: If you do not want any words suggested, remove the checkmark by tapping the checkbox next to Suggest Words

When Entering Text.

User’s Guide 5–3

Using the On-Screen Keyboard

Use the stylus to tap letters, numbers, and symbols on the on-screen keyboard to enter typed text directly onto the screen.

1. From any application, tap the up arrow next to the Input Panel icon.

2. Tap Keyboard to display a keyboard on the screen.

Learning Input Methods

Note: To see symbols, tap the 123 or Shift key.

3. Tap a letter, symbol, or number to enter information.

4. Tap OK.

User’s Guide 5–4

Learning Input Methods

Writing with the Stylus and the Letter Recognizer

Use the stylus and Letter Recognizer to write letters, numbers, and symbols on the screen. Create words and sentences by writing in uppercase (ABC), lowercase (abc), and symbols (123) as instructed here.

To write with the stylus and Letter Recognizer:

1. From any application, tap the up arrow next to the Input Panel icon.

2. Tap Letter Recognizer.

3. Write a letter or symbol between the dashed line and baseline.

a. To display in uppercase, write a letter between the hatch

marks labeled ABC.

b. To display in lowercase, write a letter between the hatch

marks labeled abc.

c. Write a number or draw a symbol between the hatch

marks labeled 123.

What you write will be converted to text.

Note: A question mark within a program indicates a Help file.

Note: For the Letter Recognizer to work effectively, write

characters between the dashed line and baseline.

■ If you are writing a letter like “p,” write the top portion

within the dashed line and baseline, and the tail portion below the baseline.

■ If you writing a letter like “b,” write the bottom portion

within the dashed line and baseline, and the top portion above the dashed line.

User’s Guide 5–5

Learning Input Methods

Writing with the Stylus and Microsoft Transcriber

Use the stylus and Microsoft Transcriber to write words, letters, numbers, and symbols anywhere on the screen.

1. From any application, tap the up arrow next to the Input Panel icon.

2. Tap Tra nscr ibe r to display the Transcriber Intro screen.

3. Tap OK.

4. Tap New at the bottom of the screen.

5. Begin writing on the screen. What you write will be converted to text.

Note: To “teach” Transcriber your style of writing, tap on the “a” icon at the bottom of the screen to display the Letter Shapes screen and follow the instructions.

Writing with the Stylus and Block Recognizer

Write letters, numbers, and symbols using the stylus and Block Recognizer. Create words and sentences by writing letters and numbers in specific areas.

1. From any application, tap the up arrow next to the Input Panel button.

2. Tap Block Recognizer.

Note: For online Help, tap the ?

User’s Guide 5–6

Learning Input Methods

3. Write a word, letter, or symbol between the hatch marks.

a. To type text, write a letter between the hatch marks

labeled “abc.”

b. To type numbers or symbols, write a number or symbol

between the hatch marks labeled “123.”

What you write will be converted to text.

Drawing and Writing on the Screen

Use the stylus as a pen to draw and write on the screen in the Notes program or from the Notes tab in Calendar, Contacts, or Tasks.

1. From the Start menu, tap Notes > New.

2. Draw and write on the screen.

3. Tap the Pen icon.

4. Tap OK.

User’s Guide 5–7

Converting Writing to Text

You can convert your writing to text when you write with the stylus in the Notes program or from the Notes tab in:

■ Calendar

■ Contacts

■ Ta sk s

To convert writing to text:

1. From the Start menu, tap Notes or tap the Notes tab in Calendar, Contacts, or Tasks.

2. Tap a note to open it.

3. Tap To ol s.

4. Tap Recognize.

Note: To convert a particular word or phrase, highlight it before you tap Recognize. If a word is not recognized, it will not be converted.

Learning Input Methods

5. Tap OK.

Using the Integrated Keyboard (HP iPAQ Pocket PC h4300 Series only)

Your HP iPAQ Pocket PC h4300 Series comes with an integrated keyboard for convenient data input. It includes a handy backlight feature for enhanced visibility in low light.

Note: If the on-screen keyboard is displayed, press any key on the integrated keyboard to minimize it.

User’s Guide 5–8

Configuring the Keyboard

You can configure several features on the integrated keyboard. To customize your keyboard:

1. On your iPAQ Pocket PC, tap Start > Settings > System tab > Keyboard.

2. Do one or more of the following:

■ Tap th e Disable Keyboard checkbox to disable the

keyboard functionality.

■ Tap th e Turn on keyboard backlight checkbox to turn

the Pocket PC backlight on whenever you press a key on the keyboard.

■ Tap and slide the Turn on keyboard backlight scale to

change the length of time the backlight stays on after a key is pressed.

■ Tap th e Keyboard Repeat Control button to change the

Delay before first repeat and Repeat rate functions for

the keyboard keys.

Learning Input Methods

Note: Changing the keyboard repeat rate controls also affects the same settings for the Application Buttons and 5-Way Navigation Button.

User’s Guide 5–9

Learning Input Methods

Special Key Features

The integrated keyboard takes advantage of several special features to make using a small keyboard easier.

“Sticky” Keys

The integrated keyboard uses a “Sticky Key” feature for the Shift, Menu, and Fn keys (known as “key modifiers”). This means that

when you enter a number or symbol requiring a combination of keys to be pressed, the key modifier will stay engaged until you press the second key. It is not necessary to press both keys at the same time.

Special Keys

There are several keys on the integrated keyboard that, when used in combination with other keys, make it easier to navigate the keyboard or have special modifier capabilities.

Key Function Desciption

Function (Fn) key “Sticky Key” for invoking

alternate function or symbols on most keys.

Symbol (Sym) key (English only)

Used for selecting alternate characters and symbols to replace a character.

Symbol (Sym) key (all other languages)

Menu key Context-sensitive menu key

Start key Instantly displays the Start

User’s Guide 5–10

Used for selecting alternate characters and symbols to replace a character.

which is used in place of the CTRL key for shortcuts such as cutting and pasting.

menu from any application without tapping the screen.

Symbol Key

À Á Â Ä Å

To add a special character using the Symbol key, type the related character first, then press the Symbol key. Continue pressing the Symbol key until you reach the special character you are looking for. If you want to modify an existing character on a document, move the cursor to the right of the character you want to change, then press the Symbol key until the special character you want to replace the original with is reached.

Refer to the table below for a list of special characters.

Original Character Modified Character

Learning Input Methods

à á â ä å ą ã ă æ

Ą Ã Ă Æ

ć č ©

Ć Č ©

è é ê ë ę

È É Ê Ë Ę

í î ï

Í Î Ï

(Continued)

User’s Guide 5–11

Learning Input Methods

ò ó ô õ ö ő ø œ

Ò Ó Ô Õ Ö Ő Ø Œ

þ ¶

ş š ß

Ş Š ß

ù ú û ü ű

Ù Ú Û Ü Ű

“

(

)

User’s Guide 5–12

ź ż

Ź Ż

€

£ ¥

' « »

[ { < «

] } > »

(Continued)

Learning Input Methods

[space]

± & - _

¡ ? ¿

: , ;

User’s Guide 5–13

Function Keys

The integrated keyboard keys perform additional functions when pressed in the combinations indicated.

Keystroke Combination Action

Shift + any letter key Enters capital letter

Shift + right Navigation

Button

Shift + left Navigation Button Highlights area to the left of the cursor

Shift + up Navigation Button Highlights area from the cursor to one

Shift + down Navigation

Button

Fn + Shift Shift lock on/off

Fn + any key Enters function characters on key

Fn + Deletes characters without

Fn + Enter (

Fn + right arrow (B) Moves cursor to the right

Learning Input Methods

Highlights area to the right of the cursor

row above the cursor

Highlights area from the cursor to one row below the cursor

(indicated in blue)

backspacing.

! ) Minimizes the current application

Fn + left arrow (C) Moves cursor to the left

Fn + up arrow (G) Moves cursor up one row

Fn + down arrow (V) Moves cursor down one row

Note: The stylus can be used to select text or scroll through the displayed page.

User’s Guide 5–14

Menu Key Functions

The Menu key is application- and context-sensitive. It pulls up a menu specific to what you are doing. Not all applications support functions for the Menu key. The following table shows some examples of how Pocket Word use the Menu key when text is selected. Different menu options are shown if no text is selected.

Menu + C Copies highlighted selection into buffer

Menu + P Pastes text from buffer

Menu + T Cuts highlighted selection

Menu + L Clears highlighted selection

Menu + F Opens the Format menu

Menu + A Starts a new paragraph

Menu + S Opens the spell check program

Keyboard Layout

Below is an illustration of the keyboard layout for reference purposes.

Learning Input Methods

English

User’s Guide 5–15

French

Learning Input Methods

German

User’s Guide 5–16

Latin American Spanish

Learning Input Methods

Brazilian Portuguese

User’s Guide 5–17

Expansion Cards

You can expand the memory and connectivity of your iPAQ Pocket PC. Use optional expansion cards for:

■ Adding functionality such as a an SDIO camera

■ Expanding the memory of your iPAQ Pocket PC

■ Viewing the content of memory cards (SD/MMC)

Note: Expansion cards must be purchased separately and are not included with your iPAQ Pocket PC.

To locate information about expansion cards, visit the following HP Web site:

www.hp.com/products/pocketpc/options

User’s Guide 6–1

Installing a Secure Digital (SD) Expansion Card

To install a Secure Digital (SD) card into the expansion slot on the iPAQ Pocket PC:

1. Locate the slot on the top of the iPAQ Pocket PC.

2. Remove the protective plastic card.

3. Insert the expansion card into the expansion slot and push the connection edge of the card firmly into the expansion slot.

Expansion Cards

Note: If your expansion card is not recognized, follow the card manufacturer’s instructions to install it.

User’s Guide 6–2

Removing a Secure Digital (SD) Expansion Card

To remove a Secure Digital (SD) expansion card from the expansion slot on the iPAQ Pocket PC:

1. Close all applications that are using the expansion card.

2. Remove a card from the Secure Digital expansion slot by slightly pushing down on the card 1 to unlock it.

Expansion Cards

3. When the card disengages and pops up 2, pull it from the expansion slot.

CAUTION: SD cards must first be unlocked before removal.

Viewing the Content of Memory Cards

Use File Explorer to view the files that are located on your optional Secure Digital card.

1. From the Start menu, tap Programs > File Explorer.

2. Tap the root directory of My Device, and select the Storage Card folder to see a list of files and folders.

User’s Guide 6–3

Connecting to the Internet

Use your iPAQ Pocket PC to connect to the Internet or your Work network.

To send and receive e-mail with Inbox and to view Web sites with Pocket Internet Explorer, you must set up a remote connection with devices such as a Secure Digital Input/Output (SDIO) modem card, ethernet card, or the wireless 802.11b internal radio. Another option is to use a Bluetooth-enabled device such as a phone or LAN Access point.

Note: Use of dial-up and wireless Internet, e-mail, corporate networks, and other wireless communications, such as Bluetooth-enabled devices, may require separately purchased additional hardware and other compatible equipment, in addition to a standard Wireless LAN (WLAN) infrastructure and a separately purchased service contract. Check with your service provider for availability and coverage in your area. Not all Web content may be available. Some Web content may require installation of additional software.

Note: For more information on this subject, refer to the Help file on your iPAQ Pocket PC by tapping Start > Help >

Connections.

User’s Guide 7–1

Connecting to the Internet

Connecting to a Private Network

1. Before you start, be sure to have your server phone number, user name, and password. This information can be obtained from your network administrator.

2. Tap Start > Settings > Connections tab > Connections icon.

3. In My Work Network, follow the instructions for each type of connection. For more information on Bluetooth connections, see Chapter 8, “Using Bluetooth.” For more information on Wireless LAN connections, see “Setting Up

VPN Server Connections” or “Setting Up Proxy Server Settings” in Chapter 9, “Using the Wireless LAN.”

Entering an Internet Address

With Pocket Internet Explorer and a connection to the Internet, you can view Web sites on your iPAQ Pocket PC by typing an address or Universal Resource Locator (URL) in the Address bar.

Note: Web sites that use HTML 4.0, DHTML, animated GIF images, and Java applets may not work correctly in Pocket Internet Explorer without additional software.

To enter an Internet address (URL) on your iPAQ Pocket PC:

1. From the Start menu, tap Internet Explorer > Address Bar.

Note: If the Address Bar is not visible, tap the View tab > Address Bar to turn it on.

2. Enter the Internet address (URL) in the Address bar.

3. Tap the Go icon.

User’s Guide 7–2

Using a Favorites List

With Pocket Internet Explorer and a connection to the Internet, you can view Web sites on your iPAQ Pocket PC by selecting one from your Favorites list.

To select a Web site from your Favorites list:

1. From the Start menu, tap Internet Explorer.

2. Tap the Favorites icon and the Web site you want to view.

Connecting to the Internet

User’s Guide 7–3

Using Bluetooth

Your iPAQ Pocket PC comes with built-in Bluetooth technology that allows short-range connections and provides fast, reliable, and secure wireless communication.

With Bluetooth powered on, you can send information or perform the following tasks wirelessly between two Bluetooth devices, within a range of approximately 10 meters (30 feet):

■ Exchange contacts, calendar items, and tasks

■ Send or exchange business cards

■ Transfer files

■ Synchronize with a computer through an ActiveSync

connection

■ Partner with a Bluetooth-enabled cell phone and use the cell

phone as a wireless modem

■ Connect to other Bluetooth devices (Virtual COM port)

■ Print to a Bluetooth printer

User’s Guide 8–1

Using Bluetooth

■ Create a personal area network (PAN) to chat, play

games, etc.

Getting Acquainted with Bluetooth

Before you start using Bluetooth to establish wireless connections, take a few minutes and familiarize yourself with:

■ Terms used in this chapter

■ Supported Services

■ Bluetooth Settings

■ Bluetooth Manager

Note: For more detailed help, refer to the Help files installed on your iPAQ Pocket PC. From the Start menu, tap Help >

Bluetooth.

User’s Guide 8–2

Understanding Terms

The following Bluetooth terms are used throughout this chapter.

The Term... Means...

Authentication Verification of a numeric passkey before a

connection or activity can be completed.

Authorization Approval of a connection or activity before

it can be completed.

Bonding (Paired devices)

Create a trusted connection between your device and another. After a bond is created, the two devices become paired.

A paired device does not require authentication or authorization.

Using Bluetooth

Device address Unique electronic address of a Bluetooth

Device discovery Location and recognition of another

Device name Name that a Bluetooth device provides

Encryption Method of protecting data.

Link key Code used to securely pair devices.

Passkey Code you enter to authenticate

Personal Information Manager (PIM)

Profiles Collection of Bluetooth settings.

Service discovery Determination of which programs you have

device.

Bluetooth device.

when discovered by another device.

connections or activities requested by other devices.

Collection of programs used to manage daily business tasks (for example: Contacts, Calendar, and Tasks).

in common with other devices.

User’s Guide 8–3

Supported Services

The functions that Bluetooth supports are called services. You can communicate only with Bluetooth devices that support at least one of the following services:

■ BPP (Basic Printer profile)

■ DUN (Dial-up Networking profile)

■ FA X

■ FTP (File Transfer profile)

■ GAP (Generic Access profile)

■ HCRP (Hard Cable Replacement profile)

■ LAP (LAN Access profile)

■ OBEX (Object Exchange profile)

■ OPP (Object Push profile)

■ PAN (Personal Area Network profile)

■ SPP (Serial Port profile)

Using Bluetooth

■ ActiveSync (Uses SPP to connect to ActiveSync on a

computer)

Working with Bluetooth Settings

From the tabs in Bluetooth Settings, you can:

■ Turn Bluetooth on and off

■ Enter or change your iPAQ Pocket PC Bluetooth name

■ Set your connection preferences

■ Enable Bluetooth services

■ Specify security settings

■ Define settings for sharing and connecting

User’s Guide 8–4

■ Select a user profile

■ View software and port information

Use the arrows to the right to scroll through the tabs.

Opening Bluetooth Settings

1. From the To da y screen, tap the Bluetooth icon.

2. From the pop-up menu, tap Bluetooth Settings.

Using Bluetooth

Turning On Bluetooth

To turn on Bluetooth from Bluetooth Settings:

1. From the To da y screen, tap the Bluetooth icon.

2. From the pop-up menu, tap Bluetooth Settings.

3. Tap the Tur n on button to enable.

Shortcut: From the Bluetooth pop-up menu, tap Turn Bluetooth ON.

When Bluetooth is turned on, the Bluetooth icon turns blue and the wireless indicator LED, located to the left of the power button, blinks blue or alternates between blinking blue and blinking green if the Wireless LAN is also turned on.

User’s Guide 8–5

Tap t h e Turn off button to disable. When Bluetooth is turned off, the Bluetooth icon is grayed with a red X, and no incoming or outgoing connections are possible.

Battery Saving Tip: Turn Bluetooth off when you are not using it.

Setting Accessibility Properties

You can enter or change accessibility properties to define how your iPAQ Pocket PC interacts with other Bluetooth devices.

Entering a Device Name

The device name is what other devices see when they locate your device.

To enter a device name:

1. From the To da y screen, tap the Bluetooth icon > Bluetooth Settings > Accessibility tab.

2. Highlight the name in the Name field and enter your new name.

3. Tap OK to save your changes.

Using Bluetooth

Allowing Connections

You can determine if all devices or only paired devices can connect to your iPAQ Pocket PC.

Allowing All Devices to Connect

1. From the To da y screen, tap the Bluetooth icon > Bluetooth Settings > Accessibility tab.

2. Select Allow other devices to connect, and All devices.

3. Tap OK.

CAUTION: This allows any device, even those unknown to you, to

connect to your iPAQ Pocket PC. After they are connected, security settings for specific services apply as specified in the Bluetooth Settings.

User’s Guide 8–6

Using Bluetooth

Allowing Paired Devices to Connect

Paired devices share and exchange an internally generated Link Key before connecting. The Link Key is derived from a unique Bluetooth device address, a random number, and a user-defined passkey.

This feature allows only devices that you trust to connect to your iPAQ Pocket PC.

To allow paired devices to connect:

1. From the To da y screen, tap the Bluetooth icon > Bluetooth Settings > Accessibility tab.

2. Select Allow other devices to connect, and Paired

devices only.

3. Tap OK.

Allowing Others to Locate Your Device

You can allow other devices to search and locate your iPAQ Pocket PC.

Note: If another remote device has your device’s address, that device may be able to locate and connect to you even though you did not select for your device to be discovered.

To allow others to locate your device:

1. From the To da y screen, tap the Bluetooth icon > Bluetooth Settings > Accessibility tab.

2. Select Other devices can discover me.

3. Tap OK to save the changes.

User’s Guide 8–7

Enabling Bluetooth Services

You can select to enable certain services:

■ Automatically when Bluetooth is activated

■ When you permit the connection

■ When a passkey or link key is correctly entered

You can use any of these security options when transferring files, creating a serial port connection, exchanging business card information, configuring dial-up networking, and joining a personal network.

Automatically Enabling Services

You can allow devices to connect without any authorization so that any time Bluetooth is on it is ready for connections.

To automatically enable services:

1. From the To da y screen, tap the Bluetooth icon > Bluetooth

Settings.

2. Tap the tab for the service you want to enable: File Transfer, Information Exchange, Serial Port, Dial-up Networking,

or Personal Network Server.

3. Select Enable service.

4. Ensure there are no check marks in the Authorization required or Authentication (Passkey) required checkboxes.

5. Tap OK.

Using Bluetooth

User’s Guide 8–8

Using Bluetooth

Requiring Authorization to Access Services

If you elect to require authorization to access services, you must authorize each connection. Then, your iPAQ Pocket PC will always ask you if the connection should be permitted.

To require authorization to access services:

1. From the To da y screen, tap the Bluetooth icon > Bluetooth

Settings.

2. Tap the tab for the service you want to enable: File Transfer, Information Exchange, Serial Port, Dial-up Networking,

or Personal Network Server.

3. Select Authorization required.

4. Tap OK.

Secure Connections using a Passkey or Bond

To establish a secure connection with another device, you can use the passkey feature or an established bond. You can also add data encryption to this type of security.

A passkey is a code you enter to authenticate connections requested by other devices. The passkey must be known and used by both parties or the connection will not be allowed.

To require a passkey or bond:

1. From the To da y screen, tap the Bluetooth icon > Bluetooth

Settings.

2. Tap the tab for the service you want to enable: File Transfer, Information Exchange, Serial Port, Dial-up Networking,

or Personal Network Server.

3. Select Authentication (Passkey) required.

4. Select Encryption Required if you want to require all data exchanged between the devices to be encrypted.

5. Tap OK.

User’s Guide 8–9

Setting a Shared Folder

You can determine the folder that other devices access when they connect to your iPAQ Pocket PC.

To select a shared folder:

1. From the To da y screen, tap the Bluetooth icon > Bluetooth

Settings.

2. Tap the File Transfer tab.

3. Tap the Folder icon and locate a desired file folder.

Using Bluetooth

4. Tap OK.

User’s Guide 8–10

Understanding Profiles

Use profiles to quickly enable selected personal settings in multiple environments.

Creating a Profile

To create a profile:

1. From the To da y screen, tap the Bluetooth icon > Bluetooth Settings > General tab > Profile icon.

Using Bluetooth

2. Tap the New button.

3. Enter a descriptive name.

4. Select an existing profile to use as a template.

5. Tap OK.

User’s Guide 8–11

Activating a Profile

When a new profile is created, you will need to activate it.

To activate a profile after creating it:

1. From the To da y screen, tap the Bluetooth icon > Bluetooth

Settings.

2. From the General tab, select it from the Current Profile down arrow list.

Using Bluetooth

3. Tap

OK.

Saving Bluetooth Configuration Settings in a Profile

To save the iPAQ Pocket PC Bluetooth configuration settings to any profile:

Note: Bluetooth must be turned on for changes to be saved.

1. From the To da y screen, tap the Bluetooth icon > Bluetooth

Settings.

2. From the

3. Select a profile from the Add/Delete Profiles list or create a new one.

4. Tap OK.

5. Set up your iPAQ Pocket PC. You should specify the desired connection, sharing, and security settings in all Bluetooth Settings tabs.

6. Tap OK to close the Bluetooth Settings. The changes are automatically saved.

General tab, tap the Profile icon.

User’s Guide 8–12

Renaming a Profile

1. From the To da y screen, tap the Bluetooth icon > Bluetooth Settings.

2. From the General tab, tap the Profile icon.

3. Select a profile from the Add/Delete Profiles list.

4. Tap the Rename button.

5. Enter a new descriptive name.

6. Tap Enter.

7. Tap OK.

Deleting a Profile

1. From the To da y screen, tap the Bluetooth icon > Bluetooth Settings.

2. From the General tab, tap the Profile icon.

3. Select a profile from the Add/Delete Profiles list.

4. Tap the Delete button.

5. Tap Ye s to confirm you want to delete the profile.

6. Tap OK.

Using Bluetooth

Working with Bluetooth Manager

Use Bluetooth Manager to:

■ Establish connections

■ Display shortcuts

■ Exchange business cards

■ Control the on-screen display

User’s Guide 8–13

Opening Bluetooth Manager

From the To da y screen, tap the Bluetooth icon > Bluetooth Manager.

The first screen that displays is My Shortcuts.

Note: Opening Bluetooth Manager automatically turns on Bluetooth.

Locating and Selecting a Device

Several tasks require you to locate a device and connect to it. When you are required to locate a device, the Bluetooth browser assists by searching for your desired function that supports other Bluetooth devices.

Pairing Devices

You can pair devices so they must exchange a computer generated security key prior to each connection. The security key is also called a “Link Key.” It is generated from a unique Bluetooth device address, a random number, and a user-defined password.

After two devices are paired, they have a trusted relationship with each other that can be verified using a link key. No additional input is needed from the user. Therefore, connections and activities can be performed between the paired devices without constant authorization from the user.

To pair devices:

1. From the To da y screen, tap Start > Bluetooth Manager.

2. Tap To o ls > Paired devices.

3. Tap Add.

4. Tap the Lookup icon.

5. Tap a device.

6. Enter a password in the Passkey field.

Using Bluetooth

User’s Guide 8–14

7. Tap OK.

8. Enter the same passkey into the other device.

Note: Some devices, such as mobile phones, need to be placed in a mode to accept a bond from another device. Refer to that device’s user instructions for more information.

Unpairing Devices

You can remove a paired relationship between devices.

1. From the To da y screen, tap Start > Bluetooth Manager.

2. Tap To ol s > Paired devices.

3. Tap a device name.

4. Tap Remove.

5. Tap Ye s to remove the pairing.

Using Bluetooth

User’s Guide 8–15

Connecting to Other Devices

Use ActiveSync, serial and dial-up connections to communicate with other Bluetooth devices. Establish a partnership with a cell phone and set up the Bluetooth services it offers.

Identifying the Communications Port

You can identify the virtual COM ports used to create a serial port connection. You may need to identify these COM ports for activities such as printing.

Use the inbound COM port when other devices initiate a serial connection. Use the outbound COM port when you initiate a serial connection to another device.

To identify the communications port:

1. From the To da y screen, tap the Bluetooth icon > Bluetooth

Settings.

2. Tab over to the Serial Port tab and tap it.

3. Note the names of your inbound and outbound COM ports.

4. Tap OK.

Using Bluetooth

Establishing an ActiveSync Connection

You can set up an ActiveSync partnership with a Bluetooth-enabled computer by first setting up your computer, then setting up your iPAQ Pocket PC.

If you own an HP Evo Notebook or Desktop computer, you can use the Bluetooth Multiport Module presinstalled on that computer with your iPAQ Pocket PC.

If you are using other Bluetooth modules or cards on your computer, refer to the Bluetooth Configuration Manager or Settings for similar setup procedures, then skip to “Setting Up an

ActiveSync Partnership on Your iPAQ Pocket PC.”

User’s Guide 8–16

Using Bluetooth

Using the HP Bluetooth Multiport Module for Evo Notebooks and Desktops

1. Remove your iPAQ Pocket PC from the USB Synchronization Cradle.

2. Turn on Bluetooth on both the iPAQ Pocket PC and the Evo computer.

3. Right click the Bluetooth icon in the system tray on your computer, then click Advanced Configuration.

4. Select the Client Applications tab, then write down the COM port number listed next to Bluetooth Serial Port.

5. Select Bluetooth Serial Port, then click on the Delete COM Port button.

6. Click on the Local Services tab, then click Add Serial

Service.

7. Type a name for the serial service, then select Startup Automatically.

User’s Guide 8–17

Using Bluetooth

8. Remove the checkmark from the Secure Connection box, then select the COM port that is the same as the one you wrote down earlier. Click Apply > OK > OK.

9. Open ActiveSync on your computer, then click File >

Connection Settings.

10. Check the Allow Serial Cable or Infrared Connection to this COM Port box.

11. Select the COM port that is the same as the one you wrote down earlier, then click OK.

User’s Guide 8–18

Using Bluetooth

Setting Up an ActiveSync Partnership on Your iPAQ Pocket PC

To establish an ActiveSync connection:

1. From the To da y screen, tap Bluetooth icon > Bluetooth

Manager.

2. Tap New > ActiveSync via Bluetooth > Next.

3. Follow the connection wizard instructions.

Note: Be sure the ActiveSync COM port setting on your computer is the same as the COM port setting used for Bluetooth on your computer.

4. From the Bluetooth Browser screen, select the computer you want to synchronize with. Tap Next.

User’s Guide 8–19

Using Bluetooth

5. Under Serial Port Selection, select the name of the serial port for the computer selected above, then tap Next > Finish.

Note: If you are setting up the ActiveSync partnership with an Evo Notebook or Desktop computer, select the name you typed in Step 7 of “Using the HP Bluetooth Multiport Module for Evo

Notebooks and Desktops.”

Establishing a Serial Connection

Use the wireless Bluetooth serial port connection just as you would a physical serial cable connection. You must configure the application that will use the connection to the correct serial port.

To establish a serial connection:

1. From the To da y screen, tap the Bluetooth icon > Bluetooth

Manager.

2. Tap New > Explore a Bluetooth device > Next.

3. Follow the connection wizard instructions.

User’s Guide 8–20

Dial-Up Networking

When you use dial-up networking (DUN), the remote device providing the dial-up networking service and the remote computer to which you are connecting must both have telephone access.

Devices that can provide dial-up networking include Bluetooth:

■ Mobile phones

■ Desktop computers

■ Modems

Using Dial-Up Networking

To connect to a device that provides modem access:

1. From the To da y screen, tap the Bluetooth icon > Bluetooth

Manager.

2. Tap New > Connect to the Internet > Next.

3. Follow the connection wizard instructions.

Using Bluetooth

Note: After you create the dial-up networking shortcut with a device, tap and hold the shortcut icon in the My Shortcuts tab of the Bluetooth Manager, and tap Connect.

4. Tap New Connection.

5. Tap OK.

6. Enter a name in the Connection Name field.

7. Enter a phone number. You must sometimes enter the country code and area code, depending on where you are calling.

8. Tap OK to begin dialing.

Note: Some mobile phones require a bond between devices (see the section “Pairing Devices”).

User’s Guide 8–21

To connect to the Internet and use Pocket Internet Explorer, you must first connect to a Bluetooth phone from Bluetooth Manager. To make this connection the default dial-up connection for Pocket Internet Explorer:

1. From the To da y screen, tap Start > Settings > Connections tab.

2. Tap the Connections icon > Advanced tab.

3. Tap Select Networks.

4. Enable Bluetooth Settings from the dropdown list.

Note: The Bluetooth modem connection you created can be viewed only from the Bluetooth Settings on the Connections Task page.

Joining a Personal Area Network

Connect two or more Bluetooth devices to share files, collaborate or play multiplayer games.

To establish a Personal Area Network connection:

1. From the To da y screen, tap the Bluetooth icon > Bluetooth

Manager.

Using Bluetooth

2. Tap New > Join a personal network > Next.

3. Follow the Connection Wizard instructions.

Establishing a Cell Phone Partnership

You can establish a partnership with a cell phone, then set up the Bluetooth services it offers.

To establish a cell phone partnership:

1. From the To da y screen, tap Start > Bluetooth Manager.

2. Tap New > Connect to Internet via phone.

3. Follow the connection wizard instructions.

User’s Guide 8–22

Working with Files

You can exchange information with a connected device and use the Bluetooth File Explorer to:

■ Navigate through the directories.

■ View files and folders.

■ Create new folders.

■ Send and receive files from a remote device.

■ Delete and rename files on a remote device.

Creating a File Transfer Connection

1. From the To da y screen, tap Start > Bluetooth Manager.

2. Tap New > Browse files on a remote device > Next.

3. Follow the connection wizard instructions.

Sending Files

Using Bluetooth

1. Tap and hold a file transfer shortcut icon, and tap Connect.

2. Tap File > Send a File…

3. Locate a file to send.

4. Tap the file to send it.

5. Tap OK.

Creating a Folder on a Remote Device

1. Tap and hold a file transfer shortcut icon, and tap Connect.

2. Navigate to the location you want for the new folder.

3. Tap File > Create a folder.

4. Enter a folder name while New Folder is selected, and tap

Enter.

5. Tap OK.

User’s Guide 8–23

Using Bluetooth

Receiving a File from a Remote Device

1. Tap and hold a file transfer shortcut icon, and tap Connect.

2. Navigate to the file location on the remote device.

3. Tap the file.

4. Tap File > Get.

5. Tap OK.

Deleting a File from a Remote Device

1. Tap and hold a file transfer shortcut icon, and tap Connect.

2. Navigate to the file location on the remote device.

3. Tap the file.

4. Tap File > Delete.

5. Tap Ye s to verify you want to delete the selected file.

6. Tap OK.

Using Business Card Exchange

Using the business card exchange, you can:

■ Set up your own business card

■ Send a business card to one or more devices

■ Request a business card from one or more devices

■ Exchange business cards with one or more devices

You must establish a default contact name to send or exchange business card information.

You must first specify your default business card on the Information Exchange tab in Bluetooth Settings. This name becomes the default for business card transfers.

User’s Guide 8–24

Using Bluetooth

Setting Up Your Business Card Information

To set up your business card information:

1. Create a contact in the Contacts program that includes your name, title, and other relevant information.

2. From the To da y screen, tap the Bluetooth icon > Bluetooth

Settings.

3. Tap the Information Exchange tab.

4. Tap the My business card (vCard) icon.

5. Choose your contact from the list.

6. Tap OK.

User’s Guide 8–25

HP h4000 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Using the Stylus

Setting the Date and Time

Setting the Time for Home and Locations You Are Visiting

Setting the Date

Entering Owner Information

Resetting the Unit

Performing a Normal Reset

Performing a Full Reset

Aligning the Screen

Routine Care

Using ActiveSync

Connecting to a Computer

Installing ActiveSync

Synchronizing with Your Computer

Using the Serial Infrared (IR) Connection

Changing Synchronization Settings

Copying Files

Installing Programs

Backing up and Restoring

Synchronizing Links

Sending and Receiving E-mail

Requesting Meetings

Managing the Battery

Installing the Battery

Installing the Battery in the h4100 Model

Installing the Battery in the h4300 Model

Removing the Battery

Removing the Battery from the h4100 Model

Removing the Battery from the h4300 Model

Charging the Battery

Charging with the AC Adapter

Charging with the Desktop Cradle and AC Adapter

Charging a Spare Battery

Changing the Backlight Settings

Changing the Wireless LAN Power Saving Modes

Disabling the Application Buttons

Manually Monitoring the Battery

Learning the Basics

Using the Today Screen

Navigation Bar and Command Bar

Status Icons

Pop-Up Menus

Creating information

Customizing the Today Screen

Using Applications

Opening Applications

Minimizing Applications

Closing Applications

Closing with iTask

Closing Manually

Installing Applications

Using iPAQ Image Zone

Viewing Pictures

Viewing a Picture Full-Screen

Recording Sound With a Picture

Viewing a Slideshow

Printing Pictures

Backing Up Information

Backup/Restore using iPAQ Backup

Backup/Restore Using ActiveSync

Using iPAQ File Store Folder

Learning Input Methods

Using Input Software

Changing Word Suggestion Options

Using the On-Screen Keyboard

Writing with the Stylus and the Letter Recognizer

Writing with the Stylus and Microsoft Transcriber

Writing with the Stylus and Block Recognizer

Drawing and Writing on the Screen

Converting Writing to Text

Configuring the Keyboard

Special Key Features

“Sticky” Keys

Special Keys

Symbol Key

Function Keys
