HP G250, G350 User Manual

Overview for the Avaya G250 and Avaya G350 Media Gateways

03-300435

Issue 5

June 2008

Notice

While reasonable efforts were made to ensure that the infor mation in this document was complete and accurate at the time of printing, Avaya Inc. can assume no liability for any errors. Changes and corrections to the information in this document may be incorporated in future releases.

For full legal page information, please see the complete document, A vaya Legal Page for Software Documentation, Document number 03-600758.

To locate this document on the website, simply go to

http://www.avaya.com/support

the search box. Documentation disclaimer

Avaya Inc. is not responsible for any modifications, addition s, or deletions to the original published version of this documentation unless such modifications, additions, or deletions were performed by Avaya. Customer and/or End User agree to indemnify and hold harmless Avaya, Avaya's agents, servants and employees against all claims, lawsuits, demands and judgments arising out of, or in connection with, subsequent modifications, additions or deletions to this documentation to the extent made by the Customer or End User.

Link disclaimer

Avaya Inc. is not responsible for the contents or reliability of any linked web sites referenced elsewhere within this documentation, and Avaya does not necessarily endorse the products, services, or informa tion described or o ff ered within them. We cannot guarantee that these links will work all of the time and we have no control over the availability of the linked pages.

Warranty

Avaya Inc. provides a limited warranty on this product. Refer to your sales agreement to establish the terms of the limited warran ty. In addition, Avaya’s standard warranty language, as well as information regarding support for this product, while under warranty, is available through the following web site:

http://www.avaya.com/support

Except where expressly stated otherwise, the Product is protected by copyrigh t and other laws respecting proprietary rights. Unauthorized reproduction, transfer, and or use can be a criminal, as well as a civil, offense un der the applicable law.

Avaya support

Avaya provides a telephone number for you to use to report pro blems or t o ask questions about your product. The support telephone number is 1-800-242-2121 in the United States. For additional support telephone numbers, see the Avaya web site:

http://www.avaya.com/support

and search for the document number in

About this book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Downloading this book and updates from the web . . . . . . . . . . . . . . . . . 7

Downloading this book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Related resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Technical assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Within the US. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

International . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Sending us comments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Avaya G350 Media Gateway Overview . . . . . . . . . . . . . . . . . . . . . . . . 12

Avaya G250 Media Gateway Overview . . . . . . . . . . . . . . . . . . . . . . . . 12

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

G250 physical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

G350 physical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Chapter 2: Optional components. . . . . . . . . . . . . . . . . . . . . . 23

Supported media modules in the G350 . . . . . . . . . . . . . . . . . . . . . . . 23

S8300 server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Telephony media modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

WAN media modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

LAN media modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Media module slot configurations in the G350 . . . . . . . . . . . . . . . . . . . 34

Permitted slots. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Combination limitations in the G350 . . . . . . . . . . . . . . . . . . . . . . . 35

Supported media modules in the G250 . . . . . . . . . . . . . . . . . . . . . . . 35

Chapter 3: Summary of services . . . . . . . . . . . . . . . . . . . . . . 37

Media gateway services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Voice over IP (VoIP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Physical media — G350 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

Physical media — G250 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Media Gateway Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Additional features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

LAN services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Physical media. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Power over Ethernet (PoE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Issue 5 June 2008 3

Contents

VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Rapid Spanning Tree Protocol (RSTP) . . . . . . . . . . . . . . . . . . . . . . 47

Port mirroring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Port redundancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

WAN services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Physical media. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

WAN features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Routing features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Chapter 4: Management, Security, Alarms and Troubleshooting . . . . 53

Management applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Avaya G250 and Avaya G350 Command Line Interfaces (CLI) . . . . . . . . . 53

Avaya G250/G350 Manager and Embedded Web Manager . . . . . . . . . . . 54

Avaya Integrated Management . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Avaya QoS Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Management access security features. . . . . . . . . . . . . . . . . . . . . . . . 54

Network security features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Alarms and troubleshooting features . . . . . . . . . . . . . . . . . . . . . . . . 55

Front panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Automatic error detection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Packet sniffing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

VoIP debugging using RTP-MIB . . . . . . . . . . . . . . . . . . . . . . . . . 57

Object tracking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Converged Network Analyzer (CNA) test plug. . . . . . . . . . . . . . . . . . 57

Link Layer Discovery Protocol (LLDP) . . . . . . . . . . . . . . . . . . . . . . 57

Chapter 5: Documentation . . . . . . . . . . . . . . . . . . . . . . . . . 59

Appendix A: G250 and G350 capacities . . . . . . . . . . . . . . . . . . 61

G250 maximum media gateway capacities . . . . . . . . . . . . . . . . . . . . . 61

G350 maximum media gateway capacities . . . . . . . . . . . . . . . . . . . . . 63

S8300 maximum capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Appendix B: Supported Avaya telephones . . . . . . . . . . . . . . . . 67

Appendix C: G250 technical specifications . . . . . . . . . . . . . . . . 69

G250 specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

G250 power cord specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

4 Overview for the Avaya G250 and Avaya G350 Media Gateways

G250 media module specifications. . . . . . . . . . . . . . . . . . . . . . . . . . 70

Appendix D: G350 technical specifications . . . . . . . . . . . . . . . . 71

G350 specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

G350 power cord specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

G350 media module specifications. . . . . . . . . . . . . . . . . . . . . . . . . . 72

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Contents

Issue 5 June 2008 5

Contents

6 Overview for the Avaya G250 and Avaya G350 Media Gateways

About this book

This guide contains information that you need to consider before implementing the A vaya G250

or Avaya G350 Media Gateway. Use this guide to learn what the G250/G350 can do and to plan

how you will deploy a G250/G350 in your environment.

Audience

The information in this book is intended for use by Avaya technicians, provisioning specialists,

Business Partners, and customers.

Downloading this book and updates from the web

You can download the latest version of Overview for the Avaya G250 and Avaya G350 Media

Gateways from the Avaya web site. You must have access to the Internet, and a copy of

Acrobat Reader must be installed on your personal computer.

Avaya makes every effort to ensure that the information in this book is complete and accurate.

However, information can change after we publish this book. Therefore, the Avaya web site

might also contain new product information and updates to the information in this book. You can

also download these updates from the Avaya web site.

Downloading this book

1. Access the Avaya web site at http://www.avaya.com/support.

2. Click FIND DOCUMENTATION and TECHNICAL INFORMATION by PRODUCT NAME.

3. Type this book’s document number (03-300435) in the Search box.

4. Click GO. The search results appear.

5. Locate the latest version of the book.

6. Click the book title. Your browser downloads the book.

Issue 5 June 2008 7

About this book

Related resources

Title Number

Quick Start for Hardware Installation: The Avaya G250 Media Gateway 03-300433 Quick Start for Hardware Installation: The Avaya G350 Media Gateway 03-300148 Installing and Upgrading the Avaya G250 Media Gateway 03-300434 Installing and Upgrading the Avaya G350 Media Gateway 03-300394 Administration for the Avaya G250 and Avaya G350 Media Gateways 03-300436 Avaya G250 and Avaya G350 CLI Reference 03-300437 Maintenance Alarms for Avaya Communication Manager,

Media Gateways and Servers Maintenance Commands for Avaya Communication Manager,

Media Gateways and Servers Maintenance Procedures for Avaya Communication Manager,

Media Gateways and Servers

Technical assistance

Avaya provides resources for technical assistance within the US and internationally.

Within the US

For help with:

● Feature administration and system applications, call the Avaya Technical Consulting

Support System at 1-800-225-7585

03-300430

03-300431

03-300432

● Maintenance and repair, call the Avaya National Customer Care Support Line at

1-800-242-2121

● Toll fraud, call Avaya Toll Fraud Intervention at 1-800-643-2353

8 Overview for the Avaya G250 and Avaya G350 Media Gateways

International

For all international resources, contact your local Avaya authorized dealer.

Sending us comments

Avaya welcomes your comments about this book. To reach us by:

● Mail, send your comments to:

Avaya Inc. Product Documentation Group Room B3-H13 1300 W. 120th Ave. Westminster, CO 80234 USA

Sending us comments

● E-mail, send your comments to:

document@avaya.com

● Fax, send your comments to:

1-303-538-1741

Ensure that you mention the name and number of this book, Overview for the Avaya G250 and Avaya G350 Media Gateways, 03-300435.

Issue 5 June 2008 9

About this book

10 Overview for the Avaya G250 and Avaya G350 Media Gateways

Chapter 1: Introduction

The Avaya CM Branch Gateways (Avaya G250 and A vaya G3 50 Media Gateways) form p art of Avaya’s solution for extending communication capabilities from the headquarters of an organization to all collaborative branch locations. Avaya CM Branch Gateways h elp you provide the same high quality services to all organization members, regardless of their location.

The Branch Gateways are high-performance converged telephony and networking devices that are located in small branch locations, providing all infrastructure needs in one box — telephone exchange and data networking. The Branch Gateways each feature a V oIP engine, W AN router , and Power over Ethernet LAN connectivity. The G350 provides full support for legacy IP, DCP, and analog telephones. The G250 supports legacy IP and analog telephones. In addition, the G250-DCP model supports DCP telephones.

The G350 is designed for use in an eight to 72 user environment, aimed at branch offices with 16 to 40 stations. The G250 is designed for use in a two t o 12 user environment, aimed at small branch offices with two to eight stations.

Telephone services on a Branch Gateway are controlled by a Media Gateway Controller (MGC). You can use an Avaya S8XXX Server running Communication Manager (CM) call processing software as an MGC. The gateway integrates seamlessly with Avaya S8700, S8710, S8720, S8730, S8500, S8400, and S8300 Servers to provide the same top quality telephony services to the small branch office as to the headquarters of the organization.

Note:

Note: The S8700 Server cannot be upgraded to CM 5.0.

The Branch Gateways can subtend to an MGC located at the headquarters or the MGC can be installed locally. The Branch Gateways can optionally house an internal Avaya S8300 server for Enhanced Local Survivability (ELS), providing full MGC functionality in the event that the connection with the primary MGC is lost, or as the primary MGC for standalone deployment. When the primary MGC is located at a remote location, the Branch Gateway features Standard Local Survivability (SLS). SLS provides partial backup MGC functionality in the event that the connection with the primary MGC is lost.

In addition to advanced and comprehensive telephony services, the Branch Gateways provide full data networking services, precluding the need for a WAN router or LAN switch.

Issue 5 June 2008 11

Introduction

Avaya G350 Media Gateway Overview

The G350 is a modular device, adaptable to support different combinations of en dpoint devices. Pluggable media modules provide interfaces for different types of telephones and trunks. A combination is selected to suit the needs of the branch. A LAN media module with PoE standard compliant Ethernet ports provides support for IP telephones as well as all other types of data devices. A range of telephony modules provides full support for legacy equipment such as analog and digital telephones.

Avaya G250 Media Gateway Overview

The G250 supports the connection of PCs, LAN switches, IP telephones, analog telephones, and trunks, via fixed analog and PoE ports on the chassis. A media module slot supports either of two WAN media modules, for connection to a WAN. There are several models of the G250, with various port combinations for support of analog, BRI, or T1/E1 trunks or DCP telephones, as described below.

The G250 is available in the following models:

● Analog model (G250-Analog). The G250-Analog includes four analog trunk ports, two

analog line ports, a Fast Ethernet WAN port, and eight PoE LAN ports.

● BRI model (G250-BRI). The G250-BRI includes two ISDN BRI trunk ports, one analog

trunk port, two analog line ports, a Fast Ethernet WAN port, and eight PoE LAN ports.

● DCP model (G250-DCP). The G250-DCP provides twelve DCP (Digital Communications

Protocol) ports, as well as four analog trunk ports, two analog line ports, a Fast Ethernet WAN port, and two LAN ports.

● DS1 model (G250-DS1). The G250-DS1 provides a T1/E1 and a PRI trunk port, enabling

support of fractional T1/E1 and PRI. The G250-DS1 also includes one analog trunk port, two analog line ports, a Fast Ethernet WAN port, and eight PoE LAN ports.

Features

G250 and G350 features include:

● Voice

- Support for traditional telephones and trunks. In particular, the G250 and G350 support:

12 Overview for the Avaya G250 and Avaya G350 Media Gateways

● Two built-in line ports to support two analog telephones or incoming analog DID

trunks

● One analog trunk (fou r in the G250-Analog and the G250-DCP) to support a trunk

or trunks of the following types:

- Loop start

- Ground start (G350 only)

- CAMA (G350 only)

- DIOD (Japan only)

- Survivability features for continuous voice services

- VoIP Media Gateway services

- Call center capabilities

● WAN

- WAN Quality of Service (QoS)

- Routing protocols (OSPF, RIP)

- PPPoE

Features

- Weighted Fair Queuing (WFQ)

- Policy-based routing

- DHCP client, server, and relay functions

- GRE tunneling

- Dynamic IP addressing

- Fax and modem over IP

- Object tracking

● Server

- DHCP servers

- TFTP servers

● LAN

- Power-over-Ethernet LAN Switching

-VLANs

- Spanning Tree Protocols

- IEEE 802.1D (STP)

- IEEE 802.1w (RSTP) (G350 only)

- Port mirroring

- Port redundancy (G350 only)

Issue 5 June 2008 13

Introduction

● Security

● Provisioning

● Survivability

- RADIUS Authentication support

- SNMP traps (v1 and v2 only) sent to the primary controller

-SNMP v3

- SSH Authentication support

- VPN support

- 802.1x support

- Secrets management with Master Configuration Key (MCK) encryption

- Avaya Communication Manager (CM) server management

- Extensive alarming and troubleshooting features

- Modem access for remote administration

- MGC automatic switchover, migration, and survivability features

- Modem backup connection to the MGC

- Standard Local Survivability (SLS)

- Dynamic Call Admission Control (CAC) for Fast Ethernet, Serial, and GRE tunnel interfaces

- Inter-Gateway Alternate Routing (IGAR)

● Management applications

- Avaya G250/G350 Manager

- Embedded Web Manager (G350 only)

14 Overview for the Avaya G250 and Avaya G350 Media Gateways

G250 physical description

Figure 1: The Avaya G250-Analog Media Gateway Chassis

G250 physical description

Figure notes:

1. V1 — ICC/LSP Slot

2. V2 — WAN Media Module Slot

3. Analog port LEDs

4. Analog trunks

5. Analog line ports

6. System LEDs

7. Console port

8. USB port

9. Contact Closure (CCA) port

10. Ethernet WAN (ETH WAN) port

11. PoE LAN (ETH LAN PoE) ports

12. Reset (RST) button

13. Alternate Software Bank (ASB) button

Figure 2: The Avaya G250-BRI Media Gateway Chassis

Figure notes:

1. V1 — ICC/LSP Slot

2. V2 — WAN Media Module Slot

3. Analog port LEDs

4. Analog trunk

5. Analog line ports

6. ISDN BRI LEDs

7. ISDN BRI trunks

8. System LEDs

9. Console port

10. USB port

11. Contact Closure (CCA) port

12. Ethernet WAN (ETH WAN) port

13. PoE LAN (ETH LAN PoE) ports

14. Reset (RST) button

15. Alternate Software Bank (ASB) button

Issue 5 June 2008 15

Introduction

Figure 3: The Avaya G250-DCP Media Gateway Chassis

Figure notes:

1. V1 — ICC/LSP Slot

2. V2 — WAN Media Module Slot

3. Analog port LEDs

4. Analog trunks

5. Analog line ports

6. System LEDs

7. Console port

8. USB port

9. Contact Closure (CCA) port

10. Ethernet WAN (ETH WAN) port

11. ETH LAN ports

12. DCP ports

13. DCP port LEDs

Figure 4: The Avaya G250-DS1 Media Gateway Chassis

Figure notes:

1. V1 — ICC/LSP Slot

2. V2 — WAN Media Module Slot

3. Analog port LEDs

4. Analog trunk

5. Analog line ports

6. T1/E1/PRI trunk interface LEDs

7. T1/E1 interface

8. Service

10. Console port

11. USB port

12. Contact Closure (CCA) port

13. Ethernet WAN (ETH WAN) port

14. PoE LAN (ETH LAN PoE) ports

15. Reset (RST) button

16. Alternate Software Bank (ASB) button

9. System LEDs

16 Overview for the Avaya G250 and Avaya G350 Media Gateways

G250 physical description

For information about the different media modules that can be housed in the G250 media module slots, see Chapter 2: Optional components

Table 1: Fixed ports and buttons on the G250 front panel

Port Description

TRUNK Four analog trunk ports (G250-Analog Media

Gateway, G250-DCP Media Gateway) or one analog trunk port (G250-BRI Media Gateway, G250-DS1 Media Gateway). These fixed trunk ports support loop-start, DIOD (for Japan only) trunks, and caller ID detection.

LINE Two analog telephone ports. An analog relay

provides Emergency Transfer Relay (ETR) feature. For the G250-Analog and G250-DCP, the relay is between TRUNK port 304 and LINE port 305. For the G250-BRI and G250-DS1, the relay is between TRUNK port 301 and LINE port 302. Also used for incoming analog DID trunks with either wink-start or immediate-start.

ISDN BRI TRUNK (G250-BRI Media Gateway)

Two 4 wire S/T ISDN BRI (Basic Rate Interface) 2B+D access ports with RJ-45 jacks. Each port interfaces to the central office at the ISDN T reference point. The ISDN BRI trunk ports do not support:

● BRI stations

● Combining both B channels together to form

a 128-kbps channel

CONSOLE Console RS-232 interface port for direct

connection of CLI console. RJ-45 connector.

USB USB port. Supports the connection of

● USB flash drive

● USB externally powered hub

● The Multitech MultiModemUSB

MT5634ZBA-USB-V92 USB modem

CCA RJ-45 port for ACS (308) contact closure adjunct

box.

ETH WAN RJ-45 10/100 Base TX Ethernet port for

connection to a cable or DSL broadband modem/ router.

1 of 2

Issue 5 June 2008 17

Introduction

Table 1: Fixed ports and buttons on the G250 front panel (continued)

Port Description

ETH LAN POE (G250-Analog, G250-BRI, and G250-DS1)

Eight Power over Ethernet (PoE) LAN ports with 80 watts (aggregated for all ports) for connecting

IP phones or any Ethernet devices, such as PCs. RST Reset button. Resets chassis configuration. ASB Alternate Sof tware Bank button. Reboot s the G250

with the software image in the alternate bank. DCP (G250-DCP) Twelve DCP ports. These DCP ports are intended

for in-building use only. T1/E1 port (G250-DS1) For T1, this port is capable of supporting inband

signalling across all 24 channels (supports a

maximum bandwidth of 1.536 Mbps).

For E1, this port is capable of supporting R2MFC

signalling across all 30 channels (supports a

maximum bandwidth of 1.92 Mbps). PRI port (G250-DS1) The PRI port is capable of supporting PRI

signalling for 23 or 30 bearer channels. NFAS

signalling is not supported.

2 of 2

18 Overview for the Avaya G250 and Avaya G350 Media Gateways

G350 physical description

Figure 5: The Avaya G350 Media Gateway Chassis

G350 physical description

8 9

Figure notes:

1. V6 — high-density media module slot

2. V2 — standard media module slot

3. V5 — standard media module slot

4. V1 — slot for standard media module or S8300 Server

5. V4 — standard media module slot

6. V3 — standard media module slot

7. Analog port LEDs

8. Analog trunk

9. Analog line ports

10. CCA (Contact Closure) port

11. ETH WAN port

12. ETH LAN port

13. System LEDs

14. Console port

15. USB port

16. RST button

17. ASB button

For information about the different media modules that can be housed in the G350 media module slots, see Chapter 2: Optional components

Table 2: Fixed ports and buttons on the G350 front panel

Port/Button Description

TRUNK An analog trunk port. Part of an integrated analog

media module. The fixed trunk port supports

loop-start, ground-start, CAMA, and DIOD (for

Japan only) trunks. LINE Two analog telephone ports of the integrated

analog media module. An analog relay between

TRUNK port 7/1 and the furthest left LINE port 7/2

provides Emergency Transfer Relay (ETR) feature.

Also used for incoming analog DID trunks.

1 of 2

Issue 5 June 2008 19

Introduction

Table 2: Fixed ports and buttons on the G350 front panel (continued)

Port/Button Description

CCA RJ-45 port for ACS (308) contact closure adjunct

box. ETH WAN RJ-45 10/100 Base TX Ethernet WAN port. ETH LAN RJ-45 10/100 Base TX Ethernet LAN port. CONSOLE Console port for direct connection of CLI console.

RJ-45 connector. USB USB port. Supports the connection of:

● USB flash drive

● USB externally powered hub

● The Multitech MultiModemUSB

MT5634ZBA-USB-V92 USB modem RST Reset button. Resets chassis configuration. ASB Alternate Software Bank button. Reboot s the G350

with the software image in the alternate bank.

2 of 2

20 Overview for the Avaya G250 and Avaya G350 Media Gateways

Figure 6: The G350 front panel ports and slots

G350 physical description

8 9

Figure notes:

1. V6 — high-density media module slot

2. V2 — standard media module slot

3. V5 — standard media module slot

4. V1 — slot for standard media module or S8300 server

5. V4 — standard media module slot

6. V3 — standard media module slot

7. Analog port LEDs

8. Analog trunk

9. Analog line ports

Table 3: Permitted slots for media modules

Media

Permitted slots Description

module

10. CCA (Contact Closure) port

11. ETH WAN port

12. ETH LAN port

13. System LEDs

14. Console port

15. USB port

16. RST button

17. ASB button

MM312 V6 Provides 24 ports for connecting DCP telephones. MM314 V6 Provides one copper Gigabit Ethernet port and 24

10/100 Ethernet ports for connecting data devices. The 24 10/100 Ethernet ports can provide power to connected devices using Power over Ethernet (PoE).

MM316 V6 Provides one copper Gigabit Ethernet port and 40

10/100 Ethernet ports for connecting data devices. The 40 10/100 Ethernet ports can provide power to connected devices using Power over Ethernet (PoE).

MM340 V2, V3, V4, V5 Provides one E1/T1 data WAN port for connecting

to a WAN endpoint device.

1 of 2

Issue 5 June 2008 21

Introduction

Table 3: Permitted slots for media modules (continued)

Media

Permitted slots Description

module

MM342 V2, V3, V4, V5 Provides one universal serial data W AN access port

for connecting to a WAN endpoint device.

MM710 V1, V2, V3, V4, V5 Provides one E1/T1 trunk port for connecting an E1/

T1 telephone trunk.

MM711 V1, V2, V3, V4, V5 Provides eight universal analog ports for connecting

analog telephones or trunks.

MM712 V1, V2, V3, V4, V5 Provides eight ports for connecting DCP

telephones.

MM714 V1, V2, V3, V4, V5 Provides four analog ports for analog telephones

and four analog ports for analog trunks.

MM716 V1, V2, V3, V4, V5 Provides one amphenol connector that connects to

a punch down block to provide 24 analog line ports.

MM717 V1, V2, V3, V4, V5 Provides one amphenol connector that connects to

a punch down block to provide 24 ports for connecting DCP telephones.

MM720 V1, V2, V3, V4, V5 Provides eight ports for connecting up to eight ISDN

trunks or 16 ISDN BRI stations. MM722 V1, V2, V3, V4, V5 Provides two ports for connecting ISDN trunks. S8300 V1 Server

2 of 2

22 Overview for the Avaya G250 and Avaya G350 Media Gateways

Chapter 2: Optional components

The Avaya G350 Media Gateway is a versatile device with powerful capabilities. To implement the various services that are supported, a variety of swappable internal components called media modules are available.

Unlike the G350, the Avaya G250 Media Gateway LAN switching and voice ports are built into the G250’s chassis. However, the G250’s WAN and call controller options are modular, and accommodate the G350’s data WAN media modules, as well as the S8300 server.

Supported media modules in the G350

Table 4: Supported media modules

Media module Description

S8300 CM server

Telephony media modules

MM711 8 universal analog ports MM714 4 analog telephone ports and 4 analog trunk ports MM716 24 analog ports MM312 24 DCP telephone ports MM712 8 DCP telephone ports MM717 24 DCP telephone ports MM710 1 T1/E1 ISDN PRI trunk port MM720 8 ISDN BRI trunk or endpoint (telephone or data) ports MM722 2 ISDN BRI trunk ports

WAN media modules

MM340 1 E1/T1 data WAN port

1 of 2

Issue 5 June 2008 23

+ 53 hidden pages
