HP FlexNetwork 6600, FlexNetwork HSR6600 High Availability Command Reference

HPE FlexNetwork 6600/HSR6600 Routers

High Availability Command Reference

Part number: 5998-1494R Software version: A6600_HSR6602-CMW520-R3303P25 Document version: 6W105-20151231

Enterprise products and services are set forth in the express warranty statements acco mpanying such products and services. Nothing herein should be construe d as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions co ntained herein.

Confidential computer software. V alid license from Hewlett Packard Enterprise required for possession, use, or copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software Documentation, and T e chnical Data for Commercial Items are licensed to the U.S. Government under vendor’s standard commercial license.

Links to third-party websites take you outside the Hewlett Packard Enterprise website. Hewlett Packard Enterprise has no control over and is not responsible for information outside the Hewlett Packard Enterprise website.

Acknowledgments

Intel®, Itanium®, Pentium®, Intel Inside®, and the Intel Inside logo are trademarks of Intel Corporation in the United States and other countries.

Microsoft® and Windows® are trademarks of the Microsoft group of companies. Adobe® and Acrobat® are trademarks of Adobe Systems In corporated. Java and Oracle are registered trademarks of Oracle and/or its affiliates. UNIX® is a registered trademark of The Open Group.

Active and standby switchover configuration commands ································ 1

display switchover state ····························································································································· 1 ha slave-ignore-version-check ··················································································································· 2 slave restart ················································································································································ 2 slave switchover ········································································································································· 3 slave switchover { disable | enable } ·········································································································· 3

Ethernet OAM configuration commands ························································· 5

display oam ················································································································································ 5 display oam configuration ·························································································································· 8 display oam critical-event ························································································································· 10 display oam link-event ······························································································································ 11 oam enable ·············································································································································· 13 oam errored-frame period ························································································································ 14 oam errored-frame threshold ··················································································································· 14 oam errored-frame-period period ············································································································· 15 oam errored-frame-period threshold ········································································································ 16 oam errored-frame-seconds period ·········································································································· 16 oam errored-frame-seconds threshold ····································································································· 17 oam errored-symbol period ······················································································································ 18 oam errored-symbol threshold ················································································································· 18 oam loopback ··········································································································································· 19 oam loopback interface (system view) ····································································································· 19 oam loopback interface (user view) ········································································································· 20 oam loopback reject-request ···················································································································· 21 oam mode ················································································································································ 22 oam timer hello ········································································································································· 22 oam timer keepalive ································································································································· 23 reset oam ················································································································································· 24

CFD configuration commands ······································································ 25

cfd cc enable ············································································································································ 25 cfd cc interval ··········································································································································· 25 cfd enable ················································································································································· 26 cfd linktrace ·············································································································································· 27 cfd linktrace auto-detection ······················································································································ 28 cfd loopback ············································································································································· 29 cfd ma ······················································································································································ 30 cfd md ······················································································································································ 31 cfd mep ···················································································································································· 32 cfd mep enable ········································································································································· 33 cfd meplist ················································································································································ 34 cfd mip-rule ·············································································································································· 34 cfd service-instance ································································································································· 35 cfd service-instance maid format ············································································································· 36 cfd version ················································································································································ 37 display cfd linktrace-reply ························································································································· 38 display cfd linktrace-reply auto-detection ································································································· 40 display cfd ma ·········································································································································· 42 display cfd md ·········································································································································· 44 display cfd mep ········································································································································ 45 display cfd meplist ···································································································································· 47 display cfd mp ·········································································································································· 48 display cfd remote-mep ···························································································································· 49 display cfd service-instance ····················································································································· 50 display cfd status ······································································································································ 52 display cfd version ···································································································································· 52

DLDP configuration commands ···································································· 54

display dldp ·············································································································································· 54 display dldp statistics ······························································································································· 56 dldp authentication-mode ························································································································· 57 dldp delaydown-timer ······························································································································· 58 dldp enable ··············································································································································· 58 dldp interval ·············································································································································· 59 dldp reset ················································································································································· 60 dldp unidirectional-shutdown ···················································································································· 60 dldp work-mode ········································································································································ 61 reset dldp statistics ··································································································································· 62

RPR configuration commands ······································································ 63

bandwidth ················································································································································· 63 description ················································································································································ 63 display interface rpr ·································································································································· 64 display interface rprpos ···························································································································· 66 display rpr bind-info ·································································································································· 69 display rpr defect ······································································································································ 70 display rpr fairness ··································································································································· 71 display rpr protection ································································································································ 73 display rpr rs-table ···································································································································· 74 display rpr statistics ·································································································································· 76 display rpr timers ······································································································································ 77 display rpr topology ·································································································································· 78 display rpr vrrp-info ·································································································································· 85 flag ··························································································································································· 85 flag j1 ignore ············································································································································· 86 frame-format ············································································································································· 87 interface rpr ·············································································································································· 87 interface rprpos ········································································································································ 88 mtu ··························································································································································· 88 reset counters interface rpr ······················································································································ 89 reset counters interface rprpos ················································································································ 89 reset rpr protection statistics ···················································································································· 90 rpr admin-request ····································································································································· 90 rpr bind ····················································································································································· 91 rpr default-rs ············································································································································· 92 rpr echo mac ············································································································································ 93 rpr mate smart-connect ···························································································································· 94 rpr protect-mode ······································································································································· 94 rpr rate-limiter ··········································································································································· 95 rpr reversion-mode ··································································································································· 96 rpr static-rs ··············································································································································· 97 rpr station-name ······································································································································· 97 rpr timer ···················································································································································· 98 rpr weight ················································································································································· 99 service ······················································································································································ 99 shutdown ················································································································································ 100 threshold ················································································································································ 101

RRPP configuration commands ·································································· 102

control-vlan ············································································································································· 102 display rrpp brief ····································································································································· 102 display rrpp ring-group ··························································································································· 104 display rrpp statistics ······························································································································ 106 display rrpp verbose ······························································································································· 108 domain ring ············································································································································ 111 protected-vlan ········································································································································ 112 reset rrpp statistics ································································································································· 113 ring ························································································································································· 113

ring enable ············································································································································· 115 rrpp domain ············································································································································ 116 rrpp enable ············································································································································· 117 rrpp ring-group ······································································································································· 117 timer ······················································································································································· 118

Smart Link configuration commands ··························································· 119

display smart-link flush ··························································································································· 119 display smart-link group ························································································································· 119 flush enable ············································································································································ 121 port ························································································································································· 121 port smart-link group ······························································································································ 122 port smart-link group track ····················································································································· 123 preemption delay ···································································································································· 124 preemption mode ··································································································································· 125 protected-vlan ········································································································································ 125 reset smart-link statistics ························································································································ 126 smart-link flush enable ··························································································································· 126 smart-link group ····································································································································· 127

VRRP configuration commands ·································································· 129

Common VRRP configuration commands ····································································································· 129

vrrp mode ··············································································································································· 129 vrrp version ············································································································································ 129

IPv4-based VRRP configuration commands ·································································································· 130

display vrrp ············································································································································· 130 display vrrp statistics ······························································································································ 138 reset vrrp statistics ································································································································· 141 vrrp dot1q ··············································································································································· 142 vrrp method ············································································································································ 143 vrrp un-check ttl ······································································································································ 144 vrrp vrid authentication-mode ················································································································· 144 vrrp vrid backup-arp ······························································································································· 145 vrrp vrid preempt-mode ·························································································································· 146 vrrp vrid priority ······································································································································ 147 vrrp vrid source-interface ······················································································································· 148 vrrp vrid timer advertise ·························································································································· 149 vrrp vrid track ········································································································································· 149 vrrp vrid track interface ··························································································································· 151 vrrp vrid virtual-ip ···································································································································· 152 vrrp vrid weight track ······························································································································ 153

IPv6-based VRRP configuration commands ·································································································· 154

display vrrp ipv6 ····································································································································· 154 display vrrp ipv6 statistics ······················································································································ 161 reset vrrp ipv6 statistics ·························································································································· 164 vrrp ipv6 method ···································································································································· 165 vrrp ipv6 vrid authentication-mode ········································································································· 166 vrrp ipv6 vrid preempt-mode ·················································································································· 167 vrrp ipv6 vrid priority ······························································································································· 168 vrrp ipv6 vrid timer advertise ·················································································································· 168 vrrp ipv6 vrid track ·································································································································· 169 vrrp ipv6 vrid track interface ··················································································································· 171 vrrp ipv6 vrid virtual-ip ···························································································································· 172 vrrp ipv6 vrid weight track ······················································································································ 173

Stateful failover configuration commands ··················································· 175

dhbk enable ············································································································································ 175 dhbk interface ········································································································································· 175 display dhbk status ································································································································· 176

BFD configuration commands ····································································· 178

bfd detect-multiplier ································································································································ 178

iii

bfd echo-source-ip ································································································································· 178 bfd min-echo-receive-interval ················································································································· 179 bfd min-receive-interval ·························································································································· 179 bfd min-transmit-interval ························································································································· 180 bfd multi-hop destination-port ················································································································· 180 bfd session init-mode ····························································································································· 181 display bfd debugging-switches ············································································································· 182 display bfd interface ······························································································································· 182 display bfd session ································································································································· 184 reset bfd session statistics ····················································································································· 186 snmp-agent trap enable bfd ··················································································································· 186

Track configuration commands ··································································· 187

display track ··········································································································································· 187 track bfd echo ········································································································································· 189 track nqa ················································································································································ 190 track interface ········································································································································· 191 track interface protocol ··························································································································· 192

Document conventions and icons ······························································· 194

Conventions ··················································································································································· 194 Network topology icons ·································································································································· 195

Support and other resources ······································································ 196

Accessing Hewlett Packard Enterprise Support ···························································································· 196 Accessing updates ········································································································································· 196

Websites ················································································································································ 197 Customer self repair ······························································································································· 197 Remote support ······································································································································ 197 Documentation feedback ······················································································································· 197

Index ··········································································································· 199

Active and standby switchover configuration commands

The following matrix shows the command and router compatibility:

Command HSR6602 6604/6608/6616

Active and standby switchover commands

No Yes

display switchover state

Use display switchover state to display the backup state of the specified MPU.

Syntax

display switchover state [ slot slot-number ] [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

slot slot-number: Displays the backup state of a specified card, where slot-number represents the

slot number of a card. If no slot number is specified, the backup state of the active MPU is displayed. |: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

begin: Displays the first line that matches the specified regular expression and all lines that follow. exclude: Displays all lines that do not match the specified regular expression. include: Displays all lines that match the specified regular expression.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display the backup state on the active MPU.

<Sysname> display switchover state Master HA State to Slot [1]: Realtime backup to slave.

Table 1 Command output

Field Description

Backup state between the active MPU and the standby MPU,

Master HA State to Slot 1

Slave is absent The standby MPU is not in the slot. Waiting batch backup request from slave Waiting for the batch backup requests from the standby MPU. Batch backup Batch backup state. Realtime backup to slave Real-time backup state.

where 1 represents the number of the slot where the standby MPU resides.

Field Description

Data smooth Data smoothing state.

# Display the backup state on the standby MPU in slot 1.

<Sysname> display switchover state slot 1 Slave HA State: Receiving realtime data.

The output indicates that the standby MPU is slot 1 is receiving real-time backup data.

Table 2 Command output

Field Description

Slave HA State

It indicates that the output is generated by the standby MPU and it describes the backup state of the standby MPU.

Waiting

The standby MPU is in the slot and waiting to enter batch backup state.

ha slave-ignore-version-check

Use ha slave-ignore-version-check to ignore version check of the standby MPU, meaning not to check whether the version of the standby MPU is consistent with that of the active MPU.

Use undo ha slave-ignore-version-check to enable version check of the stand by MPU.

Syntax

ha slave-ignore-version-check undo ha slave-ignore-version-check

Default

Version check of the stand by MPU is enabled.

Views

System view

Default command level

2: System level

Usage guidelines

Inconsistency of the software version of the active MPU and standby MPU might result in system failure when the system is running.

Examples

# Ignore version check of the standby MPU.

<Sysname> system-view [Sysname] ha slave-ignore-version-check

slave restart

Use slave restart to manually restart the standby MPU.

Syntax

slave restart

Views

System view

Default command level

2: System level

Examples

# Restart the standby MPU.

<Sysname> system-view [Sysname] slave restart The slave will reset! Continue?[Y/N]:y

slave switchover

Use slave switchover to manually configure the switchover between the active MPU and standby MPU.

Syntax

slave switchover

Views

System view

Default command level

2: System level

Examples

# Manually configure the switchover between the active MPU and the standby MPU.

<Sysname> system-view [Sysname] slave switchover Caution!!! Confirm to switch slave to master?[Y/N] y

Starting.....

RAM Line....OK

Related commands

slave switchover { disable | enable }

Use slave switchover disable to disable manual switchover function between the active MPU and standby MPU.

Use slave sw itchover enable to enable manual switchover function between the active MPU and standby MPU.

Syntax

slave switchover { disable | enable }

Default

Views

Manual configuration of the switchover between the active MPU and standby MPU is enabled.

System view

Default command level

2: System level

Parameters

disable: Disables manual switchover between the active MPU and standby MPU. enable: Enables manual switchover between the active MPU and standby MPU.

Examples

# Enable manual switchover between the active MPU and standby MPU.

<Sysname> system-view [Sysname] slave switchover enable

Related commands

slave switchover

Ethernet OAM configuration commands

The commands in this chapter are supported only when the SAP module is operating in bridge mode.

display oam

Use display oam to display the information about an Ethernet OAM connection, including connection status, information contained in Ethernet OAM packet header, and Ethernet OAM packet statistics.

Syntax

display oam { local | remote } [ interface interface-type interface-number ] [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

2: System level

Parameters

local: Displays the Ethernet OAM connection information of the local end. remote: Displays the Ethernet OAM connection information of the remote end. interface interface-type interface-number: Specifies a port by its type and number. |: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

If you do not specify the interface keyword, this command displays the information about all the Ethernet OAM connections.

Examples

# Display the information about the Ethernet OAM connection established on the local port GigabitEthernet 3/0/1.

<Sysname> display oam local interface gigabitethernet 3/0/1 Port : GigabitEthernet3/0/1 Link Status : Up EnableStatus : Enable Local_oam_mode : Active Local_pdu : ANY Local_mux_action : FWD Local_par_action : FWD

OAMLocalFlagsField :

-------------------------------------------------------------------------Link Fault : 0 Dying Gasp : 0

Critical Event : 0 Local Evaluating : COMPLETE Remote Evaluating : COMPLETE

Packets statistic : Packets Send Receive

-------------------------------------------------------------------------OAMPDU 645 648 OAMInformation 645 648 OAMEventNotification 0 -OAMUniqueEventNotification -- 0 OAMDuplicateEventNotification -- 0

Table 3 Command output

Field Description

Port

Port index. Link Status EnableStatus

Local_oam_mode

Local_pdu

Local_mux_action

Local_par_action

Link status (up or down).

Ethernet OAM state (enabled or disabled).

Local Ethernet OAM mode:

• Active—The port operates in the active Ethernet OAM mode.

• Passive—The port operates in the passive Ethernet OAM mode.

The way in which the local end processes Ethernet OAMPDUs:

• RX_INFO—The port only receives Information OAMPDUs and does not send any Ethernet OAMPDUs.

• LF_INFO—The port only sends the Information OAMPDUs without Information TLV triplets and with their link error flag bits being set.

• INFO—The port sends and receives only Information OAMPDUs.

• ANY—The por t sends and receives Ethernet OAMPDUs of any

type.

Working mode of the local transmitter:

• FWD—The port can send any packets.

• DISCARD—The port only sends Ethernet OAMPDUs.

Working mode of the local receiver:

• FWD—The port can receive any packets.

• DISCARD—The port only receives Ethernet OAMPDUs.

• LB—The local receiver is in loopback state. All the packets other

than Ethernet OAMPDUs received on the local receiver are returned to their sources along the ways they come.

OAMLocalFlagsField Local flags inserted in the local flag fields of the Ethernet OAMPDUs sent.

Link Fault

Dying Gasp Indicates whether a fatal error is present: 0 for no and 1 for yes. Critical Event Indicates whether a critical error is present: 0 for no and 1 for yes.

Local Evaluating

Indicates whether an Ethernet OAM link error is present: 0 for no and 1 for yes.

Indicates whether the local-to-remote configuration negotiation is complete:

• COMPLETE—The negotiation is completed.

• NOTCOMPLETE—The negotiation is uncompleted.

Field Description

Indicates whether the remote-to-local configuration negotiation is

Remote Evaluating

Packets statistic Statistics about Ethernet OAMPDUs sent and received. OAMPDU Total number of the Ethernet OAMPDUs sent and received. OAMInformation Number of the Information OAMPDUs sent and received. OAMEventNotification Number of the Event notification OAMPDUs sent and received.

complete:

• COMPLETE—The negotiation is completed.

• NOTCOMPLETE—The negotiation is uncompleted.

OAMUniqueEventNotification

OAMDuplicateEventNotificatio n

Number of the unduplicated Event notification OAMPDUs sent or received uniquely.

Number of the duplicate Event notification OAMPDUs sent or received.

# Display the Ethernet OAM information of the peer port GigabitEthernet 3/0/1.

<Sysname> display oam remote interface gigabitethernet 3/0/1 Port : GigabitEthernet3/0/1 Link Status : Up Information of the latest received OAM packet: OAMRemoteMACAddress : 00e0-fd73-6502 OAMRemotePDUConfiguration : 1500

OAMRemoteState :

-------------------------------------------------------------------------Remote_mux_action : FWD Remote_par_action : FWD

OAMRemoteConfiguration :

-------------------------------------------------------------------------OAM Mode : Active Unidirectional Support : YES Loopback Support : YES Link Events : YES Variable Retrieval : NO

OAMRemoteFlagsField :

-------------------------------------------------------------------------Link Fault : 0 Dying Gasp : 0 Critical Event : 0 Local Evaluating : COMPLETE Remote Evaluating : COMPLETE

Table 4 Command output

Field Description

Port Port index. Link Status Link status. Information of the latest received

OAM packet OAMRemoteMACAddress MAC address of the Ethernet OAM peer. OAMRemotePDUConfiguration Maximum Ethernet OAMPDU size allowed.

Information about the latest received Ethernet OAMPDU.

Field Description

OAMRemoteState State of the Ethernet OAM peer. Remote_mux_action Peer sending mode. For more information, see Table 3. Remote_par_action Peer receiving mode. For more information, see Table 3. OAMRemoteConfiguration Configuration of the peer Ethernet OAM entity. OAM Mode Ethernet OAM mode. Unidirectional Support Indicates whether unidirectional transmission is supported (YES or NO).

Loopback Support

Link Events

Variable Retrieval Indicates whether MIB variable retrieval is supported (YES or NO). OAMRemoteFlagsField Values of the peer Ethernet OAM flag fields in OAM packets. Link Fault Indicates whether a link fault is present: 0 for no and 1 for yes. Dying Gasp Indicate whether a fatal fault is present: 0 for no and 1 for yes. Critical Event Indicate whether a critical fault is present: 0 for no and 1 for yes.

Local Evaluating

Remote Evaluating

Related commands

reset oam

Indicates whether Ethernet OAM remote loopback is supported (YES or NO).

Indicates whether Ethernet OAM link error events are supported (YES or NO).

Indicates whether the local-to-remote configuration negotiation is complete:

• COMPLETE—The negotiation is completed.

• NOTCOMPLETE—The negotiation is uncompleted.

Indicates whether the remote-to-local configuration negotiation is complete:

• COMPLETE—The negotiation is completed.

• NOTCOMPLETE—The negotiation is uncompleted.

display oam configuration

Use display oam configu ration to display global Ethernet OAM configuratio n, including the periods and thresholds for Ethernet OAM link error event detection.

Syntax

display oam configuration [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

2: System level

Parameters

|: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

begin: Displays the first line that matches the specified regular expression and all lines that follow. exclude: Displays all lines that do not match the specified regular expression.

include: Displays all lines that match the specified regular expression. regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display global Ethernet OAM configuration.

<Sysname> display oam configuration Configuration of the link event window/threshold :

-------------------------------------------------------------------------Errored-symbol Event period(in seconds) : 1 Errored-symbol Event threshold : 1 Errored-frame Event period(in seconds) : 1 Errored-frame Event threshold : 1 Errored-frame-period Event period(in ms) : 1000 Errored-frame-period Event threshold : 1 Errored-frame-seconds Event period(in seconds) : 60 Errored-frame-seconds Event threshold : 1

Configuration of the timer :

-------------------------------------------------------------------------Hello timer(in ms) : 1000 Keepalive timer(in ms) : 5000

Table 5 Command output

Field Description

Configuration of the link event window/threshold

Errored-symbol Event period (in seconds)

Errored-symbol Event threshold

Errored-frame Event period (in seconds)

Errored-frame Event threshold Errored frame event triggering threshold, which defaults to 1. Errored-frame-period Event

period (in ms) Errored-frame-period Event

threshold Errored-frame-seconds Event

period (in seconds) Errored-frame-seconds Event

threshold Configuration of the timer Ethernet OAM connection detection timers.

Detection intervals and triggering thresholds configured for link ev ents.

Errored symbol event detection interval, which defaults to one second.

Errored symbol event triggering threshold, which defaults to 1.

Errored frame event detection interval, which defaults to one second.

Errored frame period event detection interval, which defaults to 1000 milliseconds.

Errored frame period event triggering threshold, which defaults to 1.

Errored frame seconds event detection interval, which defaults to 60 seconds.

Errored frame seconds event triggering threshold, which defaults to 1.

Hello timer(in ms)

Keepalive timer(in ms)

Ethernet OAM handshake packet transmission interval, the value of which defaults to 1000 milliseconds.

Ethernet OAM connection timeout timer, the value of which defaults to 5000 milliseconds.

Related commands

• oam errored-symbol period

• oam errored-symbol threshold

• oam errored-frame period

• oam errored-frame threshold

• oam errored-frame-period period

• oam errored-frame-period threshold

• oam errored-frame-seconds period

• oam errored-frame-seconds threshold

• oam timer hello

• oam timer keepalive

display oam critical-event

Use display oam critical-event to display the statistics on critical Ethernet OAM link events occurred on a port.

Syntax

display oam critical-event [ interface interface-type interface-number] [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

2: System level

Parameters

interface interface-type interface-number: Specifies a port by its type and number. |: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

If you do not specify the interface keyword, this command displays the statistics on the critical Ethernet OAM link events occurred on all the ports of the switch.

Examples

# Display the statistics on critical Ethernet OAM link events occurred on all the ports.

<Sysname> display oam critical-event Port : GigabitEthernet3/0/1 Link Status : Up Event statistic :

------------------------------------------------------------------------Link Fault :0 Dying Gasp : 0 Critical Event : 0

Table 6 Command output

Field Description

Port Port index. Link Status Link status. Event statistic Statistics on critical Ethernet OAM link events. Link Fault Indicates whether a link fault is present: 0 for no and 1 for yes. Dying Gasp Indicate whether a fatal fault is present: 0 for no and 1 for yes. Critical Event Indicate whether a critical fault is present: 0 for no and 1 for yes.

display oam link-event

Use display oam link-event to display the statistics o n Ethernet OAM link error events o ccurred on a local port or a peer port. Ethernet OAM link error events include errored symbol events, errored frame events, errored frame period events, and errored frame seconds events.

Syntax

display oam link-event { local | remote } [ interface interface-type interface-number ] [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

2: System level

Parameters

local: Displays the statistics on the local Ethernet OAM link error events. remote: Displays the statistics on the peer Ethernet OAM link error events. interface interface-type interface-number: Specifies a port by its type and number. |: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

If you do not specify the interface keyword, this command displays the statistics on the Ethernet OAM link error events occurred on all the local/peer ports.

Examples

# Display the statistics on Ethernet OAM link error events occurred on all the local ports.

<Sysname> display oam link-event local Port : GigabitEthernet3/0/1 Link Status : Up

OAMLocalErrFrameEvent : (ms = milliseconds)

-------------------------------------------------------------------------Event Time Stamp : 3539 Errored Frame Window : 10(100ms) Errored Frame Threshold : 5 Errored Frame : 1488111 Error Running Total : 260908758 Event Running Total : 307

OAMLocalErrFramePeriodEvent :

-------------------------------------------------------------------------Event Time Stamp : 3539 Errored Frame Window : 976500 Errored Frame Threshold : 1 Errored Frame : 1042054 Error Running Total : 260909151 Event Running Total : 471

OAMLocalErrFrameSecsSummaryEvent : (ms = milliseconds)

-------------------------------------------------------------------------Event Time Stamp : 3389 Errored Frame Second Summary Window : 600(100ms) Errored Frame Second Summary Threshold : 1 Errored Frame Second Summary : 60 Error Running Total : 292 Event Running Total : 5

Table 7 Command output

Field Description

Port Port index. Link Status Link status.

Information about local errored frame events:

• Event Time Stamp—Time when an errored frame event occurred (in 100 milliseconds).

• Errored Frame Window—Error frame detection interval (in 100 milliseconds).

OAMLocalErrFrame Event

OAMLocalErrFrame PeriodEvent

• Errored Frame Threshold—Error threshold that triggers an errored frame event.

• Errored Frame—Number of detected error frames over the specific detection interval.

• Error Running Total—Total number of error frames.

• Event Running Total—Total number of errored frame events that have

occurred.

Information about local errored frame period events:

• Event Time Stamp—Time when an errored frame event occurred (in 100 milliseconds).

• Errored Frame Window—Maximum number of 64-byte frames that can be transmitted through an Ethernet port over the configured error frame period detection interval. For more information, see the "oam errored-frame-period

peri

od" command.

• Errored Frame Threshold—Error threshold that triggers an error frame period event.

• Errored Frame—Number of detected error frames over a detection interval.

• Error Running Total—Total number of error frames that have detected.

• Event Running Total—Total number of error frame period events.

Field Description

Information about local errored frame seconds events:

• Event Time Stamp—Time when an error frame seconds event occurred (in terms of 100 milliseconds).

• Errored Frame Second Summary Window—Error frame second detection interval (in 100 milliseconds).

OAMLocalErrFrame SecsSummaryEvent

• Errored Frame Second Summary Threshold—Error threshold that triggers an error frame seconds event.

• Errored Frame Second Summary—Number of detected error frame seconds over a detection interval.

• Error Running Total—Total number of error frame seconds.

• Event Running Total—Total number of error frame seconds events that have

occurred.

# Display Ethernet OAM link event statistics of the remote ends of all the ports.

<Sysname> display oam link-event remote Port :GigabitEthernet3/0/1 Link Status :Up OAMRemoteErrFrameEvent : (ms = milliseconds)

--------------------------------------------------------------------Event Time Stamp : 5789 Errored Frame Window : 10(100ms) Errored Frame Threshold : 1 Errored Frame : 3 Error Running Total : 35 Event Running Total : 17

Table 8 Command output

Field Description

Port Port index. Link Status Link status.

OAMLocalErrFra meEvent

Related commands

• display oam configuration

• reset oam

oam enable

Information about remote errored frame events:

• Event Time Stamp—Time when an errored frame event occurred (in 100 milliseconds).

• Errored Frame Window—Error frame detection interval (in 100 milliseconds).

• Errored Frame Threshold—Error threshold that triggers an errored frame event.

• Errored Frame—Number of detected error frames over the specific detection

interval.

• Error Running Total—Total number of error frames.

• Event Running Total—Total number of errored frame events that have occurred.

Syntax

Use oam enable to enable Ethernet OAM on the Ethernet port. Use undo oam enable to disable Ethernet OAM on the Ethernet port.

oam enable undo oam enable

Default

Ethernet OAM is disabled on all Ethernet ports.

Views

Layer 2 Ethernet port view

Default command level

2: System level

Examples

# Enable OAM on port GigabitEthernet 3/0/1.

<Sysname> system-view [Sysname] interface gigabitethernet 3/0/1 [Sysname-GigabitEthernet3/0/1] oam enable

oam errored-frame period

Use oam errored-frame period to set the errored frame event detection interval. Use undo oam errored-frame period to restore the default.

Syntax

oam errored-frame period period-value undo oam errored-frame period

Default

The errored frame event detection interval is one second.

Views

System view

Default command level

2: System level

Parameters

period-value: Errored frame event detection interval in the range of 1 to 60 (in seconds).

Examples

# Set the errored frame event detection interval to 10 seconds.

<Sysname> system-view [Sysname] oam errored-frame period 10

Related commands

• oam errored-frame threshold

• display oam link-event

• display oam configuration

oam errored-frame threshold

Use oam errored-frame threshold to set the errored frame event triggering threshold. Use undo oam errored-frame threshold to restore the default.

Syntax

oam errored-frame threshold threshold-value undo oam errored-frame threshold

Default

The errored frame event triggering threshold is 1.

Views

System view

Default command level

2: System level

Parameters

threshold-value: Errored frame event triggering threshold in the range of 0 to 4294967295.

Examples

# Set the errored frame event triggering threshold to 100.

<Sysname> system-view [Sysname] oam errored-frame threshold 100

Related commands

• oam errored-frame period

• display oam link-event

• display oam configuration

oam errored-frame-period period

Use oam errored-frame-period period to set the errored frame period event detection interval. Use undo oam errored-frame-period period to restore the default.

Syntax

oam errored-frame-period period period-value undo oam errored-frame-period period

Default

The errored frame period event detection interval is 1000 milliseconds.

Views

System view

Default command level

2: System level

Parameters

period-value: Errored frame period event detection interval in the range of 100 to 60000 (in milliseconds).

Usage guidelines

As for errored frame period event detection, the system first uses the following expre ssion to convert the errored frame period event detection interval to the maximum number of 64-byte frames that can be transmitted through an Ethernet port in the period:

bandwidth * period / (64 * 8 * 1000),

where bandwidth is the port bandwidth (in bps) and "period" is the configured period (in milliseconds).

Examples

# Set the errored frame period event detection interval to 10 seconds (10000 milliseconds).

<Sysname> system-view [Sysname] oam errored-frame-period period 10000

Related commands

• oam errored-frame-period threshold

• display oam link-event

• display oam configuration

oam errored-frame-period threshold

Use oam errored-frame-period threshold to set the errored frame period event triggering threshold.

Use undo oam errored-frame-period threshold to restore the default.

Syntax

oam errored-frame-period threshold threshold-value undo oam errored-frame-period threshold

Default

The errored frame period event triggering threshold is 1.

Views

System view

Default command level

2: System level

Parameters

threshold-value: Errored frame period event triggering threshold in the range of 0 to 4294967295.

Examples

# Set the errored frame period event triggering threshold to 100.

<Sysname> system-view [Sysname] oam errored-frame-period threshold 100

Related commands

• oam errored-frame-period period

• display oam link-event

• display oam configuration

oam errored-frame-seconds period

Use oam errored-frame-second s period to set the errored frame seconds event detection i nterval. Use undo oam errored-frame-seconds period to restore the default.

Syntax

oam errored-frame-seconds period period-value

undo oam errored-frame-seconds period

Default

The errored frame seconds event detection interval is 60 seconds.

Views

System view

Default command level

2: System level

Parameters

period-value: Errored frame seconds event detection interval in the rang e of 10 t o 900 (in se cond s).

Examples

# Set the errored frame seconds event detection interval to 100 seconds.

<Sysname> system-view [Sysname] oam errored-frame-seconds period 100

Related commands

• oam errored-frame-seconds threshold

• display oam link-event

• display oam configuration

oam errored-frame-seconds threshold

Use oam errored-frame-seconds threshold to set the errored frame seconds event triggering threshold.

Use undo oam errored-frame-seconds threshold to restore the default.

Syntax

oam errored-frame-seconds threshold threshold-value undo oam errored-frame-seconds threshold

Default

The errored frame seconds event triggering threshold is 1.

Views

System view

Default command level

2: System level

Parameters

threshold-value: Errored frame seconds event triggering threshold in the range of 0 to 900.

Examples

# Set the errored frame seconds event triggering threshold to 100.

<Sysname> system-view [Sysname] oam errored-frame-seconds threshold 100

Related commands

• oam errored-frame-seconds period

• display oam link-event

• display oam configuration

oam errored-symbol period

Use oam errored-symbol period to set the errored symbol event detection interval. Use undo oam errored-symbol period to restore the default.

Syntax

oam errored-symbol period period-value undo oam errored-symbol period

Default

The errored symbol event detection interval is one second.

Views

System view

Default command level

2: System level

Parameters

period-value: Errored symbol event detection interval in the range of 1 to 60 (in seconds).

Examples

# Set the errored symbol event detection interval to 10 seconds.

<Sysname> system-view [Sysname] oam errored-symbol period 10

Related commands

• oam errored-symbol threshold

• display oam link-event

• display oam configuration

oam errored-symbol threshold

Use oam errored-symbol threshold to set the errored symbol event triggering threshold. Use undo oam errored-symbol threshold to restore the default.

Syntax

oam errored-symbol threshold threshold-value undo oam errored-symbol threshold

Default

The errored symbol event triggering threshold is 1.

Views

System view

Default command level

2: System level

Parameters

threshold-value: Errored symbol event triggering threshold in the range of 0 to 4,294,967,295.

Examples

# Set the errored symbol event triggering threshold to 100.

<Sysname> system-view [Sysname] oam errored-symbol threshold 100

Related commands

• oam errored-symbol period

• display oam link-event

• display oam configuration

oam loopback

Use oam loopback to enable Ethernet OAM remote loopback on the specified Ethernet port. Use undo oam loopback to disable Ethernet OAM remote loopback on the Ethernet port.

Syntax

oam loopback undo oam loopback

Default

Ethernet OAM remote loopback is disabled on the Ethernet port.

Views

Layer 2 Ethernet port view

Default command level

2: System level

Usage guidelines

Ethernet OAM remote loopback is available only after the Ethernet OAM connection is established and can be performed only by the Ethernet OAM entities operating in active Ethernet OAM mode.

Examples

# Configure the active Ethernet OAM mode and enable Ethernet OAM on GigabitEthernet 3/0/1, and then enable Ethernet OAM remote loopback on GigabitEthernet 3/0/1 in Layer 2 Ethernet port view.

<Sysname> system-view [Sysname] interface gigabitethernet 3/0/1 [Sysname-GigabitEthernet3/0/1] oam mode active [Sysname-GigabitEthernet3/0/1] oam enable [Sysname-GigabitEthernet3/0/1] oam loopback

Related commands

• oam enable

• oam loopback interface (system view)

• oam loopback interface (user view)

• oam mode

oam loopback interface (system view)

Use oam loopback interface to enable Ethernet OAM remote loopback on an Ethernet port in system view.

Use undo oam loopback interface to disable Ethernet OAM remote loopback on an Ethernet port in system view.

Syntax

oam loopback interface interface-type interface-number undo oam loopback interface interface-type interface-number

Default

Ethernet OAM remote loopback is disabled on an Ethernet port.

Views

System view

Default command level

2: System level

Parameters

interface-type interface-number: Specifies a port by its type and number.

Usage guidelines

Ethernet OAM remote loopback is available only after the Ethernet OAM connection is established and can be performed only by the Ethernet OAM entities operating in active Ethernet OAM mode.

Examples

# Configure the active Ethernet OAM mode and enable Ethernet OAM on GigabitEthernet 3/0/1, and then enable Ethernet OAM remote loopback on GigabitEthernet 3/0/1 in system view.

<Sysname> system-view [Sysname] interface gigabitethernet 3/0/1 [Sysname-GigabitEthernet3/0/1] oam mode active [Sysname-GigabitEthernet3/0/1] oam enable [Sysname-GigabitEthernet3/0/1] quit [Sysname] oam loopback interface gigabitethernet 3/0/1

Related commands

• oam enable

• oam loopback

• oam loopback interface (user view)

• oam mode

oam loopback interface (user view)

Use oam loopback interface to enable Ethernet OAM remote loopback on an Ethernet port in use r view.

Use undo oam loopback interface to disable Ethernet OAM remote loopback on an Ethernet port in user view.

Syntax

Default

oam loopback interface interface-type interface-number undo oam loopback interface interface-type interface-number

Ethernet OAM remote loopback is disabled on an Ethernet port.

Views

User view

Default command level

1: Monitor level

Parameters

interface-type interface-number: Specifies a port by its type and number.

Usage guidelines

Ethernet OAM remote loopback is available only after the Ethernet OAM connection is established and can be performed only by the Ethernet OAM entities operating in active Ethernet OAM mode.

Examples

# Configure the active Ethernet OAM mode and enable Ethernet OAM on GigabitEthernet 3/0/1, and then enable Ethernet OAM remote loopback on GigabitEthernet 3/0/1 in user view.

<Sysname> system-view [Sysname] interface gigabitethernet 3/0/1 [Sysname-GigabitEthernet3/0/1] oam mode active [Sysname-GigabitEthernet3/0/1] oam enable [Sysname-GigabitEthernet3/0/1] return <Sysname> oam loopback interface gigabitethernet 3/0/1

Related commands

• oam enable

• oam loopback

• oam loopback interface (system view)

• oam mode

oam loopback reject-request

Use oam loopback reject-request to configure a port to reject the Ethernet OAM remote loopback request from a remote port.

Use undo oam loopback reject-request to restore the default.

Syntax

oam loopback reject-request undo oam loopback reject-request

Default

A port does not reject the Ethernet OAM remote loopback request from a remote port.

Views

Layer 2 Ethernet port view

Default command level

2: System level

Examples

# Configure GigabitEthernet 3/0/1 to reject the Ethernet OAM remote loopback request from a remote port.

<Sysname> system-view [Sysname] interface gigabitethernet 3/0/1

[Sysname-GigabitEthernet3/0/1] oam loopback reject-request

oam mode

Use oam mode to set the Ethernet OAM mode for an Ethernet port. Use undo oam mode to restore the default.

Syntax

oam mode { active | passive } undo oam mode

Default

An Ethernet OAM-enabled Ethernet port operates in the active Ethernet OAM mode.

Views

Layer 2 Ethernet port view

Default command level

2: System level

Parameters

active: Specifies the active Ethernet OAM mode. passive: Specifies the passive Ethernet OAM mode.

Usage guidelines

To change the Ethernet OAM mode of an Ethernet OAM-enabled Ethernet port, you need to disable Ethernet OAM on the port first.

Examples

# Disable Ethernet OAM on GigabitEthernet 3/0/1, and then configure GigabitEthernet 3/0/1 to operate in passive Ethernet OAM mode.

<Sysname> system-view [Sysname] interface gigabitethernet 3/0/1 [Sysname-GigabitEthernet3/0/1] undo oam enable [Sysname-GigabitEthernet3/0/1] oam mode passive

Related commands

oam enable

oam timer hello

Use oam timer hello to configure the Ethernet OAM handshake packet transmission interval. Use undo oam timer hello to restore the default.

Syntax

Default

oam timer hello interval undo oam timer hello

The Ethernet OAM handshake packet transmission interval is 1000 milliseconds.

Views

System view

Default command level

2: System level

Parameters

interval: Ethernet OAM handshake packet transmission interva in the range of 500 to 5000 milliseconds. The value of this argument must be a multiple of 100.

Usage guidelines

After the timeout timer for an Ethernet OAM connection expires, the local OAM entity ages out its connection with the peer OAM entity, causing the OAM connection to be disconnected. Hewlett Packard Enterprise recommends setting the connection timeout timer at least five times the handshake packet transmission interval, ensuring the stability of Ethernet OAM conne ction s.

Examples

# Set the Ethernet OAM handshake packet transmission interval to 600 milliseconds—assume that the Ethernet OAM connection timeout timer is 5000 milliseconds.

<Sysname> system-view [Sysname] oam timer hello 600

Related commands

• oam timer keepalive

• display oam configuration

oam timer keepalive

Use oam timer keepalive to configure the Ethernet OAM connection timeout timer. Use undo oam timer keepalive to restore the default.

Syntax

oam timer keepalive interval undo oam timer keepalive

Default

The Ethernet OAM connection timeout timer is 5000 milliseconds.

Views

System view

Default command level

2: System level

Parameters

interval: Ethernet OAM connection timeout timer in the range of 1000 to 25000 milliseconds. The value of this argument must be a multiple of 100.

Usage guidelines

Examples

# Set the Ethernet OAM connection timeout timer to 6000 milliseconds—assume that the Ethernet OAM handshake packet transmission interval is 1000 milliseconds.

<Sysname> system-view [Sysname] oam timer keepalive 6000

Related commands

• oam timer hello

• display oam configuration

reset oam

Use reset oam to clear the statistics on Ethernet OAM packets and Ethernet OAM link error events of an Ethernet port.

Syntax

reset oam [ interface interface-type interface-number ]

Views

User view

Default command level

2: System level

Parameters

interface interface-type interface-number: Specifies a port by its type and number.

Usage guidelines

If you do not specify the interface keyword, this command clears the statistics on Ethernet OAM packets and Ethernet OAM link error events of all the ports.

Examples

# Clear the statistics on Ethernet OAM packets and Ethernet OAM link error events of all the ports.

<Sysname> reset oam

Related commands

• display oam

• display oam link-event

CFD configuration commands

The commands in this chapter are supported only when the SAP module is operating in bridge mode.

cfd cc enable

Use cfd cc enable to enable CCM sending on a specified MEP. Use undo cfd cc enable to disable CCM sending on a specified MEP.

Syntax

cfd cc service-instance instance-id mep mep-id enable undo cfd cc service-instance instance-id mep mep-id enable

Default

The CCM sending function is disabled.

Views

Layer 2 Ethernet interface view

Default command level

2: System level

Parameters

service-instance instance-id: Specifies the service instance ID in the range of 1 to 32767. mep mep-id: Specifies the ID of a MEP, in the range of 1 to 8191.

Examples

# On port GigabitEthernet 3/0/1, enable CCM sending on MEP 3 in service instance 5.

<Sysname> system-view [Sysname] interface gigabitethernet 3/0/1 [Sysname-GigabitEthernet3/0/1] cfd cc service-instance 5 mep 3 enable

Related commands

cfd cc interval

Use cfd cc interval to set the value of the interval field in the CCM messages. Use undo cfd cc interval to restore default.

Syntax

Default

Views

cfd cc interval interval-value service-instance instance-id undo cfd cc interval service-instance instance-id

The value of this field is 4 for all CCMs sent.

System view

Default command level

2: System level

Parameters

interval interval-value: Specifies the value of the interval field in CCM messages, in the range of 2 to

service-instance instance-id: Specifies the service instance ID in the range of 1 to 32767.

Usage guidelines

The relationship between the interval field value in the CCM messages, the int erval for sending CCM messages, and the timeout time of the remote MEP is shown in Table 9.

9 Relationship between the interval field value, interval for sending CCMs, and timeout

Table time of remote MEP

Interval field value Interval for sending CCMs Timeout time of remote MEP

2 10 milliseconds 35 milliseconds 3 100 milliseconds 350 milliseconds 4 1 second 3.5 seconds 5 10 seconds 35 seconds 6 60 seconds 210 seconds 7 600 seconds 2100 seconds

Examples

# Set the value of the interval field in CCMs sent by MEPs in service instance 2 to 7.

<Sysname> system-view [Sysname] cfd cc interval 7 service-instance 2

Related commands

cfd cc enable

cfd enable

Use cfd enable to enable CFD. Use undo cfd enable to disable CFD.

Syntax

cfd enable undo cfd enable

Default

CFD is disabled.

Views

System view

Default command level

2: System level

Examples

# Enable CFD.

<Sysname> system-view [Sysname] cfd enable

cfd linktrace

Use cfd linktrace to find the path between the source and target MEPs, which is achieved through the transmission of LTMs between the two and detection of the responding LTRs.

Syntax

cfd linktrace service-instance instance-id mep mep-id { target-mep target-mep-id | target-mac mac-address } [ ttl ttl-value ] [ hw-only ]

Views

Any view

Default command level

0: Visit level

Parameters

service-instance instance-id: Specifies the service instance ID in the range of 1 to 32767. mep mep-id: Specifies the ID of the source MEP, in the range of 1 to 8191. target-map target-mep-id: Specifies the ID of the destination MEP, in the range of 1 to 8191. target-mac mac-address: Specifies the destination MAC add ress, in the format of H-H-H. ttl ttl-value: Specifies the time to live value in the range of 1 to 255. The default is 64. hw-only: Sets the hw-only bits of the LTMs sent. When this keyword is specified and the MIP that

receives LTMs cannot find the destination MAC address in its forwarding table, the MIP does not broadcast these LTM messages. Otherwise, the MIP broadcasts these LTM messages.

Examples

# Identify the path between source MEP 1101 and target MEP 2001 in service instance 1 when the standard version (IEEE 802.1ag) of CFD is used.

<Sysname> system-view [Sysname] cfd version standard [Sysname] cfd linktrace service-instance 1 mep 1101 target-mep 2001 Linktrace to MEP 2001 with the sequence number 1101-43361 MAC Address TTL Last MAC Relay Action 0010-FC00-6512 63 0010-FC00-6500 Hit

# Identify the path between source MEP 1101 and target MEP 2001 in service instance 1 when the IEEE 802.1ag draft 5.2 version of CFD is used.

<Sysname> system-view [Sysname] cfd version draft5 [Sysname] cfd linktrace service-instance 1 mep 1101 target-mep 2001 Linktrace to MEP 2001 with the sequence number 1101-43361 : MAC Address TTL Forwarded Relay Action 0010-FC00-6512 63 No None

# Identify the path between source MEP 1101 and target MEP 2001 in service instance 1 when the IEEE 802.1ag draft 5.2 interim version of CFD is used.

<Sysname> system-view [Sysname] cfd version draft5-plus [Sysname] cfd linktrace service-instance 1 mep 1101 target-mep 2001

Linktrace to MEP 2001 with the sequence number 1101-43361 : MAC Address TTL Forwarded Relay Action 0010-FC00-6512 63 No None

NOTE:

The output varies by CFD protocol version.

Table 10 Command output

Field Description

Linktrace to MEP 2001 with the sequence number 1101-43361

MAC Address Source MAC address in the LTR messages. TTL Hop count when the LTM passes the device. Last MAC MAC address of the last-hop device the LTM passes.

Forwarded

Relay Action

Related commands

Linktrace to target MEP 2001 with the sequence number 1101-43361.

Indicates whether the device forwards LTMs:

• Yes—The current device forwards LTMs.

• No—The current device does not forward LTMs.

Indicates whether the forwarding device found the destination MAC address in its MAC address table.

When the standard version (IEEE 802.1ag) of CFD is used:

• Hit—The current device is the destination device.

• FDB—The forwarding device found the destination MAC address.

• MPDB—The destination MAC address is not found, or the

destination MAC address is found in the MEP or MIP database.

When the IEEE 802.1ag draft5.2 version or the IEEE 802.1ag draft 5.2 interim version of CFD is used:

• Found—The forwarding device found the destination MAC address.

• Unknown—The forwarding device failed to find the destination MAC address.

• None—It is a MEP that responded to the LTM message. A MEP does not need to find the destination MAC address.

cfd linktrace auto-detection

Use cfd linktrace auto-detection to enable the auto sending of linktrace messages. Use undo cfd linktrace auto-detection to disable this function.

Syntax

cfd linktrace auto-detection [ size size-value ] undo cfd linktrace auto-detection

Default

This function is disabled.

Views

System view

Default command level

2: System level

Parameters

size size-value: Specifies the size of the buffer used to store the auto-dete ction result, in the range of

1 to 100 (in terms of sending times). This value defaults to 5, which means the buffer stores the results of the recent five auto-d etections.

Usage guidelines

After LT messages automatic sending is enabled, if the source MEP fails to receive the CCMs from the target MEP within 3.5 times the sending interval, the link between the two is regarded as faulty and L TMs will be sent out. (The destination of the LTMs is the target MEP, and the TTL field value is

255.) Based on the LTRs that echo back, the fault source can be located. Once you disable LT messages automatic sending, the content stor ed in the buffer will be removed.

Examples

# Enable automatic LT messages sending, and specify the size of the buffer used to store the auto-detection result to 100 (in terms of sending times).

<Sysname> system-view [Sysname] cfd linktrace auto-detection size 100

Related commands

cfd linktrace

cfd loopback

Use cfd loopback to enable LB function so that LBMs can be sent from the source MEP to the target MP, and LBR messages can be received.

Syntax

cfd loopback service-instance instance-id mep mep-id { target-mep target-mep-id | target-mac mac-address } [ number number ]

Default

LB is not enabled.

Views

Any view

Default command level

0: Visit level

Parameters

service-instance instance-id: Specifies the service instance ID in the range of 1 to 32767. mep mep-id: Specifies the ID of the source MEP, in the range of 1 to 8191. target-mep target-mep-id: Specifies the ID of the target MEP, in the range of 1 to 8191. target-mac mac-address: Specifies the destination MAC address of the MP, in the format of H-H-H. number number: Specifies the number of the LBMs packets sent, in the range of 1 to 10 . The

default is 5.

Examples

# Enable LB to check the status of the link between MEP 1101 and MEP 2001 in service instance 1 (assume that the link status is normal).

<Sysname> cfd loopback service-instance 1 mep 1101 target-mep 2001 Loopback to 0010-FC00-6512 with the sequence number start from 1101-43404: Reply from 0010-FC00-6512: sequence number=1101-43404 time=5ms Reply from 0010-FC00-6512: sequence number=1101-43405 time=5ms Reply from 0010-FC00-6512: sequence number=1101-43406 time=5ms Reply from 0010-FC00-6512: sequence number=1101-43407 time=5ms Reply from 0010-FC00-6512: sequence number=1101-43408 time=5ms Send:5 Received:5 Lost:0

# Enable LB to check the status of the link between MEP 1101 and MEP 2001 in service instance 1 (assume that the link status is abnormal).

<Sysname> cfd loopback service-instance 1 mep 1101 target-mep 2001 Sequence number=1101-43404: Request timed out Sequence number=1101-43405: Request timed out Sequence number=1101-43406: Request timed out Sequence number=1101-43407: Request timed out Sequence number=1101-43408: Request timed out Send:5 Received:0 Lost:5

Table 11 Command output

Field Description

Loopback to 0010-FC00-6512 with the sequence number start from 1101-43404

sequence number Sequence number in the LBR messages.

time=5ms

Request timed out

Send Number of LBMs sent. Received Number of LBR messages received. Lost Number of lost LBRs.

cfd ma

Use cfd ma to create MAs in an MD. Use undo cfd ma to delete MAs in an MD.

Syntax

Sends LBMs to 0010-FC00-6512 with the sequence number starting with 1101-43404.

The interval between the sending of LBMs and receiving of LBRs is 5 milliseconds.

The request is timed out because no LBR is received within 5 milliseconds.

Default

cfd ma ma-name md md-name vlan vlan-id undo cfd ma ma-name md md-name

No MA is created.

Views

System view

Default command level

2: System level

Parameters

ma ma-name: Specifies the name of the MA, which is a string of 1 to 43 characters. IEEE 802.1ag

standard version allows an MA name to contain letters, numbers, and special characters such as tilde (~), exclamation mark (!), at sign (@), number sign (#), dollar sign ($), percent (%), caret (^), ampersand (&), asterisk(*), brackets ({ }, ( ),[ ], < >), hyphen (-), underscore (_), plus (+), equal sign (=), vertical bar (|), backslash (\), colon (:), semicolon (;), quotation marks (", '), comma (,), period (.), and slash (/). IEEE 802.1ag draft5.2 version and IEEE 802.1ag draft5.2 interim version allow an MA name to contain letters, numbers, and special characters such as hyphen (–) and underscore (_), but do not allow an MA name to start or end with a special character.

md md-name: Specifies the name of an MD, a string of 1 to 43 characters. IEEE 802.1ag standard version allows an MD name to contain letters, numbers, and special characters such as tilde (~), exclamation mark (!), at sign (@), number sign (#), dollar sign ($), percent (%), caret (^), ampersan d (&), asterisk(*), brackets ({ }, ( ),[ ], < >), hyphen (-), underscore (_), plus (+), equal sign (=), vertical bar (|), backslash (\), colon (:), semicolon (;), quotation marks (", '), comma (,), period (.), and slash (/). IEEE 802.1ag draft5.2 version and IEEE 802.1ag draft5.2 interim version allow an MD name to contain letters, numbers, and special characters such as hyphen (–) and underscore (_), but do not allow an MD name to start or end with a special character.

vlan vlan-id: Specifies the ID of the VLAN where MA is in service, i n the range of 1 to 4094.

Usage guidelines

Before creating an MA, you must create an MD first. The total length of the MA and MD names should not exceed 44 characters. When deleting an MA, you will also delete the configurations related to that MA.

Examples

# Create an MA named test_ma in an MD named test_md, and configure the MA to serve VLAN

100.

<Sysname> system-view [Sysname] cfd md test_md level 3 [Sysname] cfd ma test_ma md test_md vlan 100

Related commands

cfd md

Use cfd md to create an MD. Use undo cfd md to delete an MD.

Syntax

Default

cfd md md-name level level-value undo cfd md md-name

No MD is created.

Views

System view

Default command level

2: System level

Parameters

md md-name: Specifies the name of an MD, which is a string of 1 to 43 characters. IEEE 802.1ag

standard version allows an MD name to contain letters, numbers, and special characters such as tilde (~), exclamation mark (!), at sign (@), number sign (#), dollar sign ($), percent (%), caret (^), ampersand (&), asterisk(*), brackets ({ }, ( ),[ ], < >), hyphen (-), underscore (_), plus (+), equal sign (=), vertical bar (|), backslash (\), colon (:), semicolon (;), quotation marks (", '), comma (,), period (.), and slash (/). IEEE 802.1ag draft5.2 version and IEEE 802.1ag draft5.2 interim version allow an MD name to contain letters, numbers, and special characters such as hyphen (–) and underscore (_), but do not allow an MD name to start or end with a special character.

level level-value: Specifies an MD level, in the range of 0 to 7.

Usage guidelines

You can create only one MD with a specific level. MD cannot be created if you enter an invalid MD name or an existing MD name.

When deleting an MD, you will also delete the configurations related to that MD.

Examples

# Create an MD named test_md, with its level being 3.

<Sysname> system-view [Sysname] cfd md test_md level 3

cfd mep

Use cfd mep to create a MEP. Use undo cfd mep to delete the specified MEP.

Syntax

cfd mep mep-id service-instance instance-id { inbound | outbound } undo cfd mep mep-id service-instance instance-id

Default

No MEP exists on a port.

Views

Layer 2 Ethernet interface view

Default command level

2: System level

Parameters

mep mep-id: Specifies the ID of a MEP, in the range of 1 to 8191. service-instance instance-id: Specifies the service instance ID in the range of 1 to 32767. inbound: Creates an inward-facing MEP. outbound: Creates an outward-facing MEP.

Usage guidelines

In creating a MEP, the service instance you specified defines the MD and MA that the MEP belongs to.

You cannot create a MEP if the MEP ID is not included in the MEP list of the relevant service instance.

Examples

# Configure a MEP list in service instance 5, and create and enable inward-facing MEP 3 in service instance 5 on GigabitEthernet 3/0/1.

<Sysname> system-view [Sysname] cfd md test_md level 3 [Sysname] cfd ma test_ma md test_md vlan 100 [Sysname] cfd service-instance 5 md test_md ma test_ma [Sysname] cfd meplist 3 service-instance 5 [Sysname] interface gigabitethernet 3/0/1 [Sysname-GigabitEthernet3/0/1] cfd mep 3 service-instance 5 inbound

Related commands

cfd meplist

cfd mep enable

Use cfd mep enable to enable the MEP configured on a port. Use undo cfd mep enable to disable the MEP.

Syntax

cfd mep service-instance instance-id mep mep-id enable undo cfd mep service-instance instance-id mep mep-id enable

Default

MEP is disabled on a port and cannot respond to various CFD frames (such as LTM frames and LBMT frames) unless you enable it.

Views

Layer 2 Ethernet interface view

Default command level

2: System level

Parameters

service-instance instance-id: Specifies the service instance ID in the range of 1 to 32767. mep mep-id: Specifies the ID of a MEP, in the range of 1 to 8191.

Examples

# Enable MEP 3 in service instance 5 on GigabitEthernet 3/0/1.

<Sysname> system-view [Sysname] interface gigabitethernet 3/0/1 [Sysname-GigabitEthernet3/0/1] cfd mep service-instance 5 mep 3 enable

Related commands

cfd mep

cfd meplist

Use cfd meplist to create a MEP list, which is a collection of local MEPs allowed to be configured and the remote MEPs to be monitored in the same MA.

Use undo cfd meplist to delete existing MEP lists.

Syntax

cfd meplist mep-list service-instance instance-id undo cfd meplist mep-list service-instance instance-id

Default

No MEP list is created.

Views

System view

Default command level

2: System level

Parameters

meplist mep-list: Specifies a list of MEP IDs, indicating multiple MEPs, in the format of mep-list =

{ mep-id [ to mep-id ] }&<1-10>, in which mep-id represents the MEP ID and is in the range of 1 to

8191. &<1-10> indicates you can specify up to 10 MEP ID ranges.

service-instance instance-id: Specifies the service instance ID in the range of 1 to 32767.

Usage guidelines

Before creating a MEP list, create the relevant MD, MA, and service instance. After you delete a MEP list, all local MEP configurations based on this list are deleted.

Examples

# Create a MEP list that includes MEP 9 through MEP 15 in service instance 5.

Related commands

• cfd ma

• cfd md

• cfd service-instance

cfd mip-rule

Use cfd mip-rule to configure the rules for generating MIPs. MIPs are generated on each port automatically according to the rules configured.

Syntax

Use undo cfd mip-rule to delete the rule for generating MIPs.

cfd mip-rule { default | explicit } service-instance instance-id undo cfd mip-rule service-instance instance-id

Default

No rules for generating MIPs are configured and no MIPs exist.

Views

System view

Default command level

2: System level

Parameters

default: This rule means that if the lower level MA is not configured with MIPs, the current MA will

create MIPs. explicit: This rule means that if the lower level MA is not configured with MIPs, whether the current

MA will create MIPs depends on whether the lower level MA is configured with MEPs.

service-instance instance-id: Specifies the service instance ID in the range of 1 to 32767.

Examples

# Configure the MIP generation rule as default in service instance 5.

<Sysname> system-view [Sysname] cfd mip-rule default service-instance 5

cfd service-instance

Use cfd service-instance to create a service instance with the MD name. Use undo cfd service-instance to delete the service instance.

Syntax

cfd service-instance instance-id md md-name ma ma-name undo cfd service-instance instance-id

Default

No service instance is created.

Views

System view

Default command level

2: System level

Parameters

service-instance instance-id: Specifies a service instance by its ID in the range of 1 to 32767. md md-name: Specifies the name of an MD. The md-name argument is a string of 1 to 43 characters.

IEEE 802.1ag standard version allows an MD name to contain letters, numbers, and special characters such as tilde (~), exclamation mark (!), at sign (@), number sign (#), dollar sign ($), percent (%), caret (^), ampersand (&), asterisk(*), brackets ({ }, ( ),[ ], < >), hyph en (-), underscore (_), plus (+), equal sign (=), vertical bar (|), backslash (\), colon (:), semicolon (;), quotation marks (", '), comma (,), period (.), and slash (/). IEEE 802.1ag draft5.2 version and IEEE 802.1ag draft5.2 interim version allow an MD name to contain letters, numbers, and special characters such as hyphen (–) and underscore (_), but do not allow an MD name to start or end with a special character.

ma ma-name: Specifies the name of an MA. The ma-name argument is a string of 1 to 43 characters. IEEE 802.1ag standard version allows an MA name to contain letters, numbers, and special characters such as tilde (~), exclamation mark (!), at sign (@), number sign (#), dollar sign ($), percent (%), caret (^), ampersand (&), asterisk(*), brackets ({ }, ( ),[ ], < >), hyph en (-), underscore (_),

plus (+), equal sign (=), vertical bar (|), backslash (\), colon (:), semicolon (;), quotation marks (", '), comma (,), period (.), and slash (/). IEEE 802.1ag draft5.2 version and IEEE 802.1ag draft5.2 interim version allow an MA name to contain letters, numbers, and special characters such as hyphen (–) and underscore (_), but do not allow an MA name to start or end with a special character.

Usage guidelines

You must create the relevant MD and MA prior to creating a service instance. The service instance ID uniquely identifies an MA in an MD. When deleting a service instance, you are deleting the configurations related to that service instance

as well. Deleting a service instance breaks up the connection between the service instance and the rele vant

MA, the MA itself is not deleted.

Examples

# Create a level-3 MD named test_md, create an MA named test_ma, which serves VLAN 100, in test_md, and then create service instance 5 with the MD name for test_md and test_ma.

<Sysname> system-view [Sysname] cfd md test_md level 3 [Sysname] cfd ma test_ma md test_md vlan 100 [Sysname] cfd service-instance 5 md test_md ma test_ma

cfd service-instance maid format

Use cfd service-instance maid format to create a service instance with no MD name. Use undo cfd service-instance to delete the service instance.

Syntax

cfd service-instance instance-id maid format { icc-based ma-name | string ma-name } level level-value vlan vlan-id

undo cfd service-instance instance-id

Default

No service instance is created.

Views

System view

Default command level

2: System level

Parameters

service-instance instance-id: Specifies a service instance by its ID in the range of 1 to 32767. icc-based ma-name: Specifies the name of an MA in Y.1731 format. The ma-name argument is a

string of 1 to 13 characters. IEEE 802.1ag standard version allows an MA name to contain letters, numbers, and special characters such as tilde (~), exclamation mark (!), at sign (@), number sign (#), dollar sign ($), percent (%), caret (^), ampersand (&), asterisk(*), brackets ({ }, ( ),[ ], < >), hyphen (-), underscore (_), plus (+), equal sign (=), vertical bar (|), backslash (\), colon (:), semicolon (;), quotation marks (", '), comma (,), period (.), and slash (/). IEEE 802.1ag draft5.2 version and IEEE

802.1ag draft5.2 interim version allow an MA name to contain letters, numbers, and special characters such as hyphen (–) and underscore (_), but do not allow an MA name to start or end with a special character.

string ma-name: Specifies the name of an MA in IEEE 802.1ag format. The ma-name argument is a string of 1 to 45 characters. IEEE 802.1ag standard version allows an MA name to contain letters,

numbers, and special characters such as tilde (~), exclamation mark (!), at sign (@), number sign (#), dollar sign ($), percent (%), caret (^), ampersand (&), asterisk(*), brackets ({ }, ( ),[ ], < >), hyphen (-), underscore (_), plus (+), equal sign (=), vertical bar (|), backslash (\), colon (:), semicolon (;), quotation marks (", '), comma (,), period (.), and slash (/). IEEE 802.1ag draft5.2 version and IEEE

level level-value: Specifies an MD level in the range of 0 to 7. vlan vlan-id: Specifies the ID of the VLAN where MA is in service, i n the range of 1 to 4094.

Usage guidelines

When you create a service instance with no MD name, the system automatically cre ates an MA and MD for the service instance.

The service instance ID, MA name, and MD level uniquely identify an MA in an MD. When deleting a service instance, you are deleting the configurations related to that service instance

as well. Deleting a service instance not only breaks up the connection between the servi ce instance a nd the

relevant MA but also deletes the MA itself. After all MAs in an MD are deleted, the MD is automatically deleted. Service instances with no MD name only apply to the IEEE 802.1ag version.

Examples

# Create service instance 5 with no MD name in the IEEE 802.1ag standard version. Create an MA named test_ma1 in Y.1731 format, with the MD level 3 and serving VLAN 100.

<Sysname> system-view [Sysname] cfd version standard [Sysname] cfd service-instance 5 maid format icc-based test_ma1 level 3 vlan 100

# Create service instance 6 with no MD name in the IEEE 802.1ag standard version. Create an MA named test_ma2 in IEEE 802.1ag format, with the MD level 4 and serving VLAN 200.

<Sysname> system-view [Sysname] cfd version standard [Sysname] cfd service-instance 6 maid format string test_ma2 level 4 vlan 200

Related commands

cfd version

Use cfd version to configure the CFD protocol version. Use undo cfd version to restore the default.

Syntax

cfd version { draft5 | draft5-plus | standard }

Default

Views

undo cfd version

CFD uses the standard version of IEEE 802.1ag.

System view

Default command level

2: System level

Parameters

draft5: Specifies that IEEE 802.1ag draft5.2 be used. draft5-plus: Specifies that the IEEE 802.1ag draft5.2 interim version be used. standard: Specifies that the standard version of IEEE 802.1ag be used.

Usage guidelines

If an MD is created by using the cfd md command or automatically generated by using the cfd service-instance maid format command on a device, you cannot switch between the standard

version and draft5.2 version (or draft5.2 interim version); however, you can switch between the draft5.2 version and draft5.2 interim version. This restriction does not apply to the device without an MD configured.

Examples

# Configure the CFD protocol version as IEEE 802.1ag draft5.2.

<Sysname> system-view [Sysname] cfd version draft5

Related commands

• cfd md

• cfd service-instance maid format

display cfd linktrace-reply

Use display cfd linktrace-reply to display the LTR information received by a MEP.

Syntax

display cfd linktrace-reply [ service-instance instance-id [ mep mep-id ] ] [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

service-instance instance-id: Specifies the service instance ID in the range of 1 to 32767. mep mep-id: Specifies the ID of a MEP, in the range of 1 to 8191. |: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

If this command is used without specifying MEP, the information of LTRs of all MEPs in the current service instance is displayed.

If this command is used without specifying any service instance, the information of LTRs of all MEPs is displayed.

Examples

# Display the LTR information saved on all the MEPs in every service instance when the standard version (IEEE 802.1ag) of CFD is used.

<Sysname> system-view [Sysname] cfd version standard [Sysname] display cfd linktrace-reply Service instance: 1 MEP ID: 1003 MAC Address TTL Last MAC Relay Action 0000-FC00-6505 63 0000-FC00-6504 MPDB 000F-E269-A852 62 0000-FC00-6505 FDB 0000-FC00-6508 61 000F-E269-A852 Hit Service instance: 2 MEP ID: 1023 MAC Address TTL Last MAC Relay Action 0000-FC00-6508 61 000F-E269-A852 Hit

# Display the LTR information saved on all the MEPs in every service instance when the IEEE

802.1ag draft5.2 version of CFD is used.

<Sysname> system-view [Sysname] cfd version draft5 [Sysname] display cfd linktrace-reply Service instance: 1 MEP ID: 1003 MAC Address TTL Forwarded Relay Action 00E0-FC27-6502 63 Yes Found 00E0-FC00-6510 62 Yes Found 00E0-FC52-BAA0 61 No None

Service instance: 2 MEP ID: 1023 MAC Address TTL Forwarded Relay Action 00E0-FC27-6502 63 No None

# Display the LTR information saved on all the MEPs in every service instance when the IEEE

802.1ag draft5.2 interim version of CFD is used.

<Sysname> system-view [Sysname] cfd version draft5-plus [Sysname] display cfd linktrace-reply Service instance: 1 MEP ID: 1003 MAC Address TTL Forwarded Relay Action 00E0-FC27-6502 63 Yes Found 00E0-FC00-6510 62 Yes Found 00E0-FC52-BAA0 61 No None

Service instance: 2 MEP ID: 1023 MAC Address TTL Forwarded Relay Action 00E0-FC27-6502 63 No None

NOTE:

The output varies by CFD protocol version.

Table 12 Command output

Field Description

Service instance Service instance to which the MEPs that send LTMs belong. MEP ID ID of the MEP that sends LTMs. MAC Address Source MAC address in the LTR message. TTL Hop count when LTM passes the device. Last MAC MAC address of the last-hop device the LTM passes.

Indicates whether the device forwards LTMs:

Forwarded

Relay Action

• Yes—The device has forwarded the LTMs.

• No—The device did not forward the LTMs.

Indicates whether the forwarding device found the destination MAC address in its MAC address table.

When the standard version (IEEE 802.1ag) of CFD is used:

• Hit—The current device is the destination device.

• FDB—The forwarding device found the destination MAC address.

• MPDB—The destination MAC address is not found, or the destination MAC

address is found in the MEP or MIP database.

When the IEEE 802.1ag draft5.2 version or the IEEE 802.1ag draft5.2 interim version of CFD is used:

• Found—The forwarding device found the destination MAC address in its MAC address table.

• Unknown—The forwarding device failed to find the destination MAC address in its MAC address table.

• None—It is a MEP that responded to the LTM message. A MEP does not need to find the destination MAC address.

display cfd linktrace-reply auto-detection

Use display cfd linktrace-reply auto-detection to display the content of the LTR messages received as responses to the automatically sent LTMs.

Syntax

display cfd linktrace-reply auto-detection [ size size-value ] [ | { begin | exclude | include }

regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

size size-value: Specifies the times of recent auto-detections, in the range of 1 to 100. |: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

These LTR messages received as responses to automatically sent LTMs are stored in the buffer after you executed the cfd linktrace auto-detection command.

With the size keyword not specified, this command displays the information of all LTRs stored in the buffer.

Examples

# Display the contents of the LTRs received as responses to the LTMs automatically sent when the standard version (IEEE 802.1ag) of CFD is used.

<Sysname> system-view [Sysname] cfd version standard [Sysname] display cfd linktrace-reply auto-detection Service instance: 1 MEP ID: 1003 Time: 2009/05/22 10:43:57 Target MEP ID: 2005 TTL: 64 MAC Address TTL Last MAC Relay Action 0000-FC00-6505 63 0000-FC00-6504 MPDB 000F-E269-A852 62 0000-FC00-6505 FDB 0000-FC00-6508 61 000F-E269-A852 Hit Service instance: 2 MEP ID: 1023 Time: 2009/05/22 10:44:06 Target MEP ID: 2025 TTL: 64 MAC Address TTL Last MAC Relay Action 0000-FC00-6508 61 000F-E269-A852 Hit

# Display the contents of the LTRs received as responses to the LTMs automatically sent when the IEEE 802.1ag draft5.2 version of CFD is used.

<Sysname> system-view [Sysname] cfd version draft5 [Sysname] display cfd linktrace-reply auto-detection Service instance: 1 MEP ID: 1003 Time: 2009/05/22 10:43:57 Target MEP ID: 2005 TTL: 64 MAC Address TTL Forwarded Relay Action 00E0-FC27-6502 63 Yes Found 00E0-FC00-6510 62 Yes Found 00E0-FC52-BAA0 61 No None

Service instance: 2 MEP ID: 1023 Time: 2009/05/22 10:44:06 Target MEP ID: 2025 TTL: 64 MAC Address TTL Forwarded Relay Action 00E0-FC27-6502 63 No None

# Display the contents of the LTRs received as responses to the LTMs automatically sent when the IEEE 802.1ag draft5.2 interim version of CFD is used.

<Sysname> system-view [Sysname] cfd version draft5-plus [Sysname] display cfd linktrace-reply auto-detection Service instance: 1 MEP ID: 1003 Time: 2009/05/22 10:43:57 Target MEP ID: 2005 TTL: 64 MAC Address TTL Forwarded Relay Action 00E0-FC27-6502 63 Yes Found 00E0-FC00-6510 62 Yes Found 00E0-FC52-BAA0 61 No None

Service instance: 2 MEP ID: 1023 Time: 2009/05/22 10:44:06 Target MEP ID: 2025 TTL: 64 MAC Address TTL Forwarded Relay Action 00E0-FC27-6502 63 No None

NOTE:

The output varies by CFD protocol version.

Table 13 Command output

Field Description

Service instance Service instance to which the MEPs that sent LTM messages belong. MEP ID ID of the MEP that sends LTMs. Time Time of the LTMs automatically sent. Target MEP ID ID of the target MEP. TTL Initial hop count of the automatically sent LTMs. MAC Address Source MAC address in the LTR messages. TTL Hop count when LTM passes the device. Last MAC MAC address of the last-hop device the LTM passes.

Forwarded

Relay Action

Related commands

cfd linktrace auto-detection

Indicates whether the device forwards LTMs:

• Yes—The device has forwarded the LTMs.

• No—The device did not forward the LTMs.

Indicates whether the forwarding device found the destination MAC address in its MAC address table.

When the standard version (IEEE 802.1ag) of CFD is used:

• Hit—The current device is the destination device.

• FDB—The forwarding device found the destination MAC address.

• MPDB—The destination MAC address is not found, or the destination

MAC address is found in the MEP or MIP database.

When the IEEE 802.1ag draft5.2 version or the IEEE 802.1ag draft5.2 interim version of CFD is used:

• Found—The forwarding device found the destination MAC address.

• Unknown—The forwarding device failed to find the destination MAC

address.

• None—It is a MEP that responded to the LTM message. A MEP does not need to find the destination MAC address.

display cfd ma

Use display cfd ma to display the configuration of a specified MA.

Syntax

display cfd ma [ [ ma-name ] md { md-name | level level-value } ] [ | { begin | exclude | include }

regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

ma-name: Name of MA, a character string of 1 to 43 characters. IEEE 802.1ag standard version allows an MA name to contain letters, numbers, and special characters such as tilde (~), exclamation mark (!), at sign (@), number sign (#), dollar sign ($), percent (%), caret (^), ampersand (&), asterisk(*), brackets ({ }, ( ),[ ], < >), hyphen (-), underscore (_), plus (+), equal sign (=), vertical bar (|), backslash (\), colon (:), semicolon (;), quotation marks (", '), comma (,), pe riod (.), and slash (/ ). IEEE

802.1ag draft5.2 version and IEEE 802.1ag draft5.2 interim version allow an MA name to contain letters, numbers, and special characters such as hyphen (–) and underscore (_), but do not allow an MA name to start or end with a spe cial character.

md-name: Name of an MD, a character string of 1 to 43 characters. IEEE 802.1ag standard version allows an MD name to contain letters, numbers, and special characters such as tilde (~), exclamation mark (!), at sign (@), number sign (#), dollar sign ($), percent (%), caret (^), ampersan d (&), asterisk(*), brackets ({ }, ( ),[ ], < >), hyphen (-), underscore (_), plus (+), equal sign (=), vertical bar (|), backslash (\), colon (:), semicolon (;), quotation marks (", '), comma (,), period (.), and slash (/). IEEE 802.1ag draft5.2 version and IEEE 802.1ag draft5.2 interim version allow an MD name to contain letters, numbers, and special characters such as hyphen (–) and underscore (_), but do not allow an MD name to start or end with a special character.

level level-value: Specifies an MD level in the range of 0 to 7. |: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

If MD is not specified, this command will display the MA configurations of all MDs on the device. If both MD and MA are specified, this co mmand will display the specified MA con f iguration. If only MD is specified, this command will display the configurations of all MAs in that MD.

Examples

# Display the MA configurat ion information in all MDs.

<Sysname> display cfd ma 3 maintenance domain(s) configured. Maintenance domain: mdtest_5 1 maintenance association(s) belong(s) to maintenance domain mdtest_5:: Maintenance association: matest_5 Service instance: 5 VLAN: 5 Level: 5

Maintenance domain: mdtest_6 1 maintenance association(s) belong(s) to maintenance domain mdtest_6: Maintenance association: matest_6 Service instance: 6 VLAN: 6 Level: 6

Maintenance domain: mdtest_7 1 maintenance association(s) belong(s) to maintenance domain: mdtest_7 Maintenance association: matest_7 Service instance: 7 VLAN: 7 Level: 7

Table 14 Command output

Field Description

3 maintenance domain(s) configured. Number of MDs configured. Maintenance domain Name of the MD. 1 maintenance association(s) belong(s) to

this maintenance domain Maintenance association Name of the MA. Service instance Service instance of the MA. VLAN VLAN to which the service instance belongs. Level Level of the MD to which the MA belongs.

display cfd md

Use display cfd md to display the MD configuration information.

Syntax

display cfd md [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

|: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

Number of MAs configured in the MD.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display the MD configuration information.

<Sysname> display cfd md CFD is enabled. 8 maintenance domain(s) configured: Level: 0 Maintenance domain: mdtest_0 Level: 1 Maintenance domain: mdtest_1 Level: 2 Maintenance domain: mdtest_2 Level: 3 Maintenance domain: mdtest_3 Level: 4 Maintenance domain: mdtest_4 Level: 5 Maintenance domain: mdtest_5

Level: 6 Maintenance domain: mdtest_6 Level: 7 Maintenance domain: mdtest_7

Table 15 Command output

Field Description

8 maintenance domain(s) configured Number of MDs configured. Level MD level, each level allows only one MD. Maintenance domain MD name.

display cfd mep

Use display cfd mep to display the attribute and operating information of a MEP.

Syntax

display cfd mep mep-id service-instance instance-id [ | { begin | exclude | include }

regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

mep mep-id: Specifies a MEP by its ID in the range of 1 to 8191. service-instance instance-id: Specifies a service instance by its ID in the range of 1 to 32767. |: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display the attribute and operating information of MEP 50 in service instance 1 .

<Sysname> display cfd mep 50 service-instance 1 Interface: GigabitEthernet3/0/2 Maintenance domain: mdtest_1 Maintenance association: matest_1 Level: 1 VLAN: 1 Direction: Outbound Administrative state: Active CCM send: Enable FNG state: FNG_DEFECT_REPORTED

CCM: Current state: CCI_WAITING Interval: 1s SendCCM: 12018

Loopback:

NextSeqNumber: 8877 SendLBR: 0 ReceiveInOrderLBR: 0 ReceiveOutOrderLBR: 0

Linktrace: NextSeqNumber: 8877 SendLTR: 0 ReceiveLTM: 0

No CCM from some remote MEPs is received.

One or more streams of error CCMs is received. The last-received CCM: Maintenance domain: mdtest1 Maintenance association:matest1 MEP:5 Sequence Number:0x50A Received Time: 02/3/6 13:01:34

One or more streams of cross-connect CCMs is received. The last-received CCM: Maintenance domain:mdtest1 Maintenance association:matest1 MEP:6 Sequence Number:0x63A Received Time: 02/3/6 13:01:34

Some other MEPs are transmitting the RDI bit.

Table 16 Command output

Field Description

Interface Interface that an MD belongs to. Maintenance domain MD that a MEP belongs to. Maintenance association MA that a MEP belongs to. Level Level of the MD. VLAN VLAN that the MA belongs to. Direction Direction of the MEPs. Administrative state State of MEP, either Active or Inactive. CCM send Whether the MEP sends CCM.

State of FNG (Fault Notification Generator):

• FNG_RESET—A fault has been cleared.

• FNG_DEFECT—A fault has been detected.

FNG state

CCM Information related to CCM.

• FNG_REPORT_DEFECT—Report a fault.

• FNG_DEFECT_REPORTED—A fault has been reported.

• FNG_DEFECT_CLEARING—A fault is being cleared.

If this field is not supported, a hyphen (-) is displayed.

State of CCMs sent:

Current state

• CCI_IDLE—Initial state.

• CCI_WAITING—Sending state.

Interval Interval to send CCM.

Field Description

SendCCM

Loopback Information related to Loopback. NextSeqNumber Sequence number of the next LBM to be sent.

Number of CCMs that have been sent by the MEPs. If this field is not supported, a hyphen (-) is displayed.

SendLBR

ReceiveInOrderLBR Number of LBR messages received in correct sequence. ReceiveOutOrderLBR Number of LBR messages received out of order. Linktrace Information related to linktrace. NextSeqNumber Sequence number of the next LTM to be sent.

SendLTR

ReceiveLTM Number of LTMs received. No CCM from some remote

MEPs is received. One or more streams of error

CCMs is received. The last-received CCM:

Maintenance domain

Maintenance association

MEP

Number of LBRs that have been sent. If the MEP is inward-facing, the number of LBRs will not be counted.

Number of LTRs sent. If the MEP is inward-facing, the number of LTRs will not be counted.

Failure to receive CCMs from some remote MEPs. (This information is displayed only when some CCMs are lost.)

Display the content of the last error CCM when one or more error CCMs are received. (This information is displayed only when error CCMs is/are received.)

MD of the last error CCM message. If this field is not supported, a hyphen (-) is displayed.

MA of the last error CCM message. If this field is not supported, a hyphen (-) is displayed.

ID of the MEP that sent the last error CCM message. If this field is not supported, a hyphen (-) is displayed.

Sequence Number

Received Time Time when the last error CCM is received. One or more streams of

cross-connect CCMs is received. The last-received CCM:

Some other MEPs are transmitting the RDI bit.

display cfd meplist

Use display cfd meplist to display the MEP list in a service instance.

Syntax

display cfd meplist [ service-instance instance-id ] [ | { begin | exclude | include }

regular-expression ]

Views

Any view

Sequence number of the last error CCM. If this field is not supported, a hyphen (-) is displayed.

Cross-connect CCMs are received, and the content of the last cross-connect CCM is displayed. (This information is displayed only when cross-connect CCMs is/are received.)

CCMs with the RDI flag bits set are received from other MEPs. (This information is displayed only when this type of CCMs is/are received.)

Default command level

1: Monitor level

Parameters

service-instance instance-id: Specifies a service instance by its ID in the range of 1 to 32767. |: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

If the service instance ID is not specified, this command displays MEP lists in all service instances.

Examples

# Display the MEP list in service instance 5.

<Sysname> display cfd meplist service-instance 5 Service instance: 5 MEP list: 1 to 20, 30, 50.

display cfd mp

Use display cfd mp to display the MP information.

Syntax

display cfd mp [ interface interface-type interface-number ] [ | { begin | exclude | include }

regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

interface interface-type interface-number: Displays the MP information on a port specified by its port

type and port number. |: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

If no port is specified, this command displays the MP information on all ports. The output is arranged by port name, then in the ascending VLAN I D order o n the same p ort, and in

the order of outward-facing MEPs (from low to high level), MIPs, and inward-facing MEPs (from high to low level) within the same VLAN.

Examples

# Display the MP information on all ports.

<Sysname> display cfd mp Interface GigabitEthernet3/0/1 VLAN 100 MEP ID: 100 Level: 0 Service instance: 100 Direction: Outbound Maintenance domain: mdtest0 Maintenance association: mainmd0

MEP ID: 105 Level: 5 Service instance: 105 Direction: Outbound Maintenance domain: mdtest5 Maintenance association: mainmd5

MIP Level: 6 Service instance: 106 Maintenance domain: mdtest6 Maintenance association: mainmd6

MEP ID: 104 Level: 4 Service instance: 104 Direction: Inbound Maintenance domain: mdtest4 Maintenance association: mainmd4

MEP ID: 102 Level: 2 Service instance: 102 Direction: Inbound Maintenance domain: mdtest2 Maintenance association: mainmd2

Interface GigabitEthernet3/0/4 VLAN 1 MEP ID: 9 Level: 6 Service instance: 6 Direction: Outbound Maintenance domain: mdtest6 Maintenance association: matest6

Table 17 Command output

Field Description

Interface GigabitEthernet3/0/1 VLAN 100

MEP ID ID of the MEP. MIP A MIP in the MP. Level MD level that an MP belongs to. Service instance Service instance to which the MP belongs. Direction Direction of the MEP. Maintenance domain MD to which an MP belongs. Maintenance association MA to which an MP belongs.

display cfd remote-mep

Use display cfd remote-mep to display the information of a remote MEP.

MP configuration of the specified VLAN on the specified port.

Syntax

display cfd remote-mep service-instance instance-id mep mep-id [ | { begin | exclude | include }

regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

service-instance instance-id: Specifies the service instance ID in the range of 1 to 32767. mep mep-id: Specifies the ID of a remote MEP, in the range of 1 to 8191. |: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display the information of remote MEP 10 in service instance 4.

<Sysname> display cfd remote-mep service-instance 4 mep 10 MEP ID MAC Address State Time MAC Status 20 00E0-FC00-6565 OK 2009/03/06 02:36:38 UP 30 00E0-FC27-6502 OK 2009/03/06 02:36:38 DOWN 40 00E0-FC00-6510 FAILED 2009/03/06 02:36:39 DOWN 50 00E0-FC52-BAA0 OK 2009/03/06 02:36:44 DOWN 60 0010-FC00-6502 OK 2009/03/06 02:36:42 DOWN

Table 18 Command output

Field Description

MEP ID ID of the remote MED.

MAC Address

State Running state of the remote MEP: OK or FAILED.

Time

MAC Status

MAC address of the remote MEP device. If this field is not supported, a hyphen (-) is displayed.

Time when the remote MEP entered the FAILED or OK state for the last time.

State of the port indicated by the last CCM received from the remote MEP: UP or DOWN.

If this field is not supported, a hyphen (-) is displayed.

display cfd service-instance

Use display cfd service-instance to display the configuration information of service instance.

Syntax

display cfd service-instance [ instance-id ] [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

instance-id: Service instance ID in the range of 1 to 32767.

|: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

Without specifying the service instance ID, the command will display the configuration information of all service instances.

Examples

# Display the configuration information of all service instances.

<Sysname> display cfd service-instance 2 service instance(s) configured: Service instance 5: Maintenance domain: mdtest_5 Maintenance association: matest_5 Level: 5 VLAN: 5 MIP rule: None CCM interval: 1s

Service instance 6: Maintenance domain: mdtest_6 Maintenance association: matest_6 Level: 6 VLAN: 6 MIP rule: None CCM interval: 1s

Table 19 Command output

Field Description

2 service instance(s) are configured. Number of service instance configured. Service instance 5 Service instance ID. Maintenance domain MD of the service instance. Maintenance association: MA of the service instances. Level MD level. VLAN VLAN that the MA belongs to. MIP rule MIP generation rules configured on service instance. CCM interval Interval to send CCMs. MEP ID ID of MEPs configured on the service instance. Interface Interface of the MEP configured on the service instance. Direction Direction of the MEPs configured on the service instance.

display cfd status

Use display cfd status to display the status of CFD (enabled or disabled).

Syntax

display cfd status [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

|: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display the status of CFD and AIS.

<Sysname> display cfd status CFD is enabled.

display cfd version

Use display cfd version to display the CFD protocol version.

Syntax

display cfd version [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

|: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display the CFD protocol version.

<Sysname> display cfd version The current CFD version is standard.

Table 20 Command output

Field Description

The current CFD version is draft5 Indicates that the current CFD protocol is IEEE 802.1ag draft5.2.

The current CFD version is draft5-plus

The current CFD version is standard

Indicates that the current CFD protocol is the IEEE 802.1ag draft5.2 interim version.

Indicates that the current CFD protocol is the standard version of IEEE 802.1ag.

DLDP configuration commands

The commands in this chapter are supported only when the SAP module i s operating inbridge mode.

display dldp

Use display dldp to display the DLDP configuration of a port.

Syntax

display dldp [ interface-type interface-number ] [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

interface-type interface-number: Port type and port number.

|: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

If you do not provide the interface-type interface-number argument, this command displays the DLDP configuration of all the DLDP-enabled ports.

Examples

# Display the DLDP configuration of all the DLDP-enabled ports.

<Sysname> display dldp DLDP global status : enable DLDP interval : 5s DLDP work-mode : enhance DLDP authentication-mode : simple DLDP unidirectional-shutdown : auto DLDP delaydown-timer : 2s The number of enabled ports is 2.

Interface GigabitEthernet3/0/1 DLDP port state : advertisement DLDP link state : up The neighbor number of the port is 1 (the maximum number ever detected is 2). Neighbor mac address : 0000-0000-0100 Neighbor port index : 79 Neighbor state : two way Neighbor aged time : 13

Interface GigabitEthernet3/0/2 DLDP port state : advertisement DLDP link state : up The neighbor number of the port is 1. Neighbor mac address : 0000-0000-1100 Neighbor port index : 81 Neighbor state : two way Neighbor aged time : 12

# Display the DLDP configuration of GigabitEthernet 3/0/1.

<Sysname> display dldp gigabitethernet 3/0/1 Interface GigabitEthernet3/0/1 DLDP port state : advertisement DLDP link state : up The neighbor number of the port is 1. Neighbor mac address : 0000-0000-0100 Neighbor port index : 79 Neighbor state : two way Neighbor aged time : 13

Table 21 Command output

Field Description

DLDP global status Global DLDP state (enable or disable).

DLDP interval

DLDP work-mode DLDP mode (enhance or normal). DLDP authentication-mode DLDP authentication mode (none, simple, or md5).

DLDP unidirectional-shutdown

DLDP delaydown-timer Setting of the DelayDown timer. The number of enabled ports Number of the DLDP-enabled ports. Interface Index of a DLDP-enable d port.

DLDP port state

Interval for sending Advertisement packets (in seconds) to maintain neighbor relations.

Port shutdown mode (auto or manual) after unidirectional links are detected.

DLDP state on a port:

• initial.

• inactive.

• active.

• advertisement.

• probe.

• disable.

• disable (loopback)—The port is in disable state because it

has received loopback packets.

• delaydown. DLDP link state Port state (up or down). The neighbor number of the port Current number of neighbors.

the maximum number ever detected is 2

Maximum number of neighbors once detected on the port. This field appears only when the current number of neighbors is different from the maximum number of neighbors once detected.

Field Description

Neighbor mac address MAC address of the neighbor. Neighbor port index Neighbor port index. Neighbor state Neighbor state (unknown, one way, or two way). Neighbor aged time Neighbor aging time.

display dldp statistics

Use display dldp statistics to display the statistics on the DLDP packets passing through a port.

Syntax

display dldp statistics [ interface-type interface-number ] [ | { begin | exclude | include }

regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

interface-type interface-number: Port type and port number.

|: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

If you do not provide the interface-type interface-number argument, this command displays the statistics on the DLDP packets passing through all the DLDP-enabled ports.

Examples

# Display the statistics on the DLDP packets passing through all the DLDP-enabled ports.

<Sysname> display dldp statistics Interface GigabitEthernet3/0/1 Packets sent : 6 Packets received : 5 Invalid packets received : 2 Loop packets received : 0 Authentication failed packets received : 0 Valid packets received : 3

Interface GigabitEthernet3/0/2 Packets sent : 7 Packets received : 7 Invalid packets received : 3

Loop packets received : 0 Authentication failed packets received : 0 Valid packets received : 4

# Display the statistics on the DLDP packets passing through GigabitEthernet 3/0 / 1.

<Sysname> display dldp statistics gigabitethernet 3/0/1 Interface GigabitEthernet3/0/1 Packets sent : 6 Packets received : 5 Invalid packets received : 2 Loop packets received : 0 Authentication failed packets received : 0 Valid packets received : 3

Table 22 Command output

Field Description

Interface Port index. Packets sent Total number of DLDP packets sent. Packets received Total number of DLDP packets received. Invalid packets received Number of the invalid packets received. Loop packets received Number of the loopback packets received. Authentication failed packets

received Valid packets received Number of the valid packets received.

dldp authentication-mode

Use dldp authentication-mode to configure DLDP authentication. Use undo dldp authentication-mode to restore the default.

Syntax

dldp authentication-mode { none | { md5 | simple } password } undo dldp authentication-mode

Default

DLDP authentication is not performed.

Views

System view

Default command level

Number of the received packets that failed to pass the authentication.

2: System level

Parameters

none: Specifies not to perform authentication. md5: Specifies the MD5 authentication mode and sets a plaintext or ciphertext password. simple: Specifies the simple authentication mode and sets a plaintext or ciphertext password.

password: Sets the DLDP authentication password. This argument is case sensitive. It must be a plaintext string of 1 to 16 characters, or a ciphertext string of 33 to 53 characters.

Usage guidelines

To enable DLDP to operate correctly , make sure the DLDP authentication modes and the passwords configured on the two ends of a link are the same.

For security purposes, all DLDP authentication passwords, including passwords configured in plain text, are saved in cipher text.

Examples

# Configure the simple authentication mode and set the plaintext password to abc (assuming that Router A and Router B are connected by a DLDP link).

• Configure Router A:

<RouterA> system-view [RouterA] dldp authentication-mode simple abc

• Configure Router B:

<RouterB> system-view [RouterB] dldp authentication-mode simple abc

dldp delaydown-timer

Use dldp delaydown-timer to set the DelayDown timer . Use undo dldp delaydown-timer to restore the default.

Syntax

dldp delaydown-timer time undo dldp delaydown-timer

Default

The setting of the DelayDown timer is 1 second.

Views

System view

Default command level

2: System level

Parameters

Time: Sets the DelayDown timer in the range of 1 to 5 (in seconds).

Usage guidelines

The DelayDown timer configured by using this command applies to all DL DP-enabled ports.

Examples

# Set the DelayDown timer to 2 seconds.

<Sysname> system-view [Sysname] dldp delaydown-timer 2

dldp enable

Use dldp enable to enable DLDP. Use undo dldp enable to disable DLDP.

Syntax

dldp enable undo dldp enable

Default

DLDP is disabled both globally and on each port.

Views

System view, Ethernet interface view, port group view

Default command level

2: System level

Usage guidelines

When executed in system view, this command enables/disables DLDP globally. When executed in Ethernet interface view, this command enables/disables DLDP on the current port. When executed in port group view, this command e nables/disables DLDP on all the ports in the port group.

DLDP can take effect only after you enable it globally and then on a port.

Examples

# Enable DLDP globally, and then enable DLDP on GigabitEthernet 3/0/1.

<Sysname> system-view [Sysname] dldp enable [Sysname] interface gigabitethernet 3/0/1 [Sysname-GigabitEthernet3/0/1] dldp enable

# Enable DLDP globally, and then enable DLDP for all the ports in port group 1.

<Sysname> system-view [Sysname] dldp enable [Sysname] port-group manual 1 [Sysname-port-group-manual-1] group-member gigabitethernet 3/0/1 to gigabitethernet

3/0/3 [Sysname-port-group-manual-1] dldp enable

dldp interval

Use dldp interval to set the interval for sending Advertisement packets. Use undo dldp interval to restore the default.

Syntax

dldp interval time undo dldp interval

Default

The interval for sending Advertisement packets is 5 seconds.

Views

System view

Default command level

2: System level

Parameters

time: Specifies the interval for sending Advertisement packets, in the range of 1 to 100 (in seconds).

Usage guidelines

This command applies to all DLDP-enabled ports.

Examples

# Set the interval for sending Advertisement packets to 20 seconds.

<Sysname> system-view [Sysname] dldp interval 20

dldp reset

Use dldp reset to reset DLDP state for ports, thus enabling DLDP down ports to perform unidirectional link detection.

Syntax

dldp reset

Views

System view, Ethernet interface view, port group view

Default command level

2: System level

Usage guidelines

When executed in system view, this command applies to all ports of the device. When executed in Ethernet interface view, this command applie s to the current port. When executed in port group view , this command applies to all ports in the port group.

Examples

# Reset DLDP state for all ports.

<Sysname> system-view [Sysname] dldp reset

# Reset DLDP state for port GigabitEthernet 3/0/1.

<Sysname> system-view [Sysname] interface gigabitethernet 3/0/1 [Sysname-GigabitEthernet3/0/1] dldp reset

# Reset DLDP state for all ports in port group 1.

<Sysname> system-view [Sysname] port-group manual 1 [Sysname-port-group-manual-1] group-member gigabitethernet 3/0/1 to gigabitethernet

3/0/3 [Sysname-port-group-manual-1] dldp reset

Related commands

• dldp enable

• dldp unidirectional-shutdown

dldp unidirectional-shutdown

Use dldp unidirectional-shutdown to set the port shutdown mode.

Use undo dldp unidirectional-shutdown to restore the default.

Syntax

dldp unidirectional-shutdown { auto | manual } undo dldp unidirectional-shutdown

Default

The port shutdown mode is auto mode.

Views

System view

Default command level

2: System level

Parameters

auto: Configures the port shutdown mode as auto mode, where, when a unidirectional link is

detected, the port involved is shut down by DLDP. manual: Configures the port shutdown mode as manual mode, where, when a unidirectional link is

detected, DLDP generates log and traps to prompt you to shut down the involved port instead of doing so automatically.

Examples

# Set the port shutdown mode to auto mode.

<Sysname> system-view [Sysname] dldp unidirectional-shutdown auto

Related commands

dldp work-mode

Use dldp work-mode to set the DLDP mode. Use undo dldp work-mode to restore the default DLDP mode.

Syntax

dldp work-mode { enhance | normal } undo dldp work-mode

Default

A device operates in normal DLDP mode.

Views

System view

Default command level

2: System level

Parameters

enhance: Specifies the enhanced DLDP mode. normal: Specifies the normal DLDP mode.

Examples

# Configure the device to operate in enhanced DLDP mode.

<Sysname> system-view [Sysname] dldp work-mode enhance

reset dldp statistics

Use reset dldp statistics to clear the statistics on DLDP packets passing through a port.

Syntax

reset dldp statistics [ interface-type interface-number ]

Views

User view

Default command level

1: Monitor level

Parameters

interface-type interface-number: Port type and port number.

Usage guidelines

If you do not provide the interface-type interface-number argument, this command clears the statistics on the DLDP packets passing through all the DLDP-enabled ports.

Examples

# Clear the statistics on the DLDP packets passing through all the DLDP-enabled ports.

<Sysname> reset dldp statistics

RPR configuration commands

bandwidth

Use bandwidth to set the maximum available bandwidth for the RPR logical interface or RPR physical port.

Use undo bandwidth to restore the default.

Syntax

bandwidth bandwidth-value undo bandwidth

Views

Layer 3 RPR logical interface view , RPRPOS interface view

Default command level

2: System level

Parameters

bandwidth-value: Maximum available bandwidth, ranging from 1 to 4294967295 (in kbps).

Usage guidelines

The maximum available bandwidth is used by network management to monitor the interface bandwidth and does not affect the actual bandwidth of the interface. The maximum available bandwidth can be obtained by querying the ifspeed value from the management information base (MIB) through the third-party software.

Examples

# Set the maximum available bandwidth to 10000 kbps for Layer 3 RPR logical interface RPR 1.

<Sysname> system-view [Sysname] interface rpr 1 [Sysname-RPR1] bandwidth 10000

# Set the maximum bandwidth to 10000 kbps for RPR physical port RPRPOS 2/1/1.

<Sysname> system-view [Sysname] interface rprpos 2/1/1 [Sysname-RPRPOS2/1/1] bandwidth 10000

description

Use description to set the description of the current RPR logical interface or RPR physical port. Use undo description to restore the default.

Syntax

Default

description text undo description

The description of an RPR logical interface or RPR physical port is interface-name Interface, for example, RPR1 Interface.

Views

Layer 3 RPR logical interface view , RPRPOS interface view

Default command level

2: System level

Parameters

text: Description information of an RPR logical interface or RPR physical port, a string of 1 to 80 characters.

Examples

# Configure the description of Layer 3 RPR logical interface RPR 1 as RPR-1.

<Sysname> system-view [Sysname] interface rpr 1 [Sysname-RPR1] description RPR-1

# Configure the description of RPR physical port RPRPOS 2/1/1 as RPRPOS-1.

<Sysname> system-view [Sysname] interface rprpos 2/1/1 [Sysname-RPRPOS2/1/1] description RPRPOS-1

Related commands

• display interface rprpos

• display interface rpr

display interface rpr

Use display interface rpr to display the running state and information about an RPR logical interface.

Syntax

display interface [ rpr ] [ brief [ down ] ] [ | { begin | exclude | include } regular-expression ] display interface rpr interface-number [ brief [ description ] ] [ | { begin | exclude | include }

regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

rpr: Displays information about the Layer 3 RPR logical interfaces.

interface-number: Number of an RPR logical interface. It is the number of an existing interface.

brief: Displays brief interface information. If you do not specify this keyword, this command displays detailed interface information.

description: Displays complete interface description. If you do not specify this keyword, this command displays only the first 27 characters of the interface description.

down: Displays information about interfaces in DOWN state and the causes. If you do not specify this keyword, this command displays information about interfaces in all states.

|: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

If rpr is not specified, this command displays information about all types of interfaces. If an interface type (rpr) is specified but the interface number (interface-number) is not specified, this

command displays information about RPR logical interfaces of the specified type. If both the interface type and interface number are specified, this command displays information

about the specific RPR logical interface.

Examples

# Display the information about Layer 3 RPR logical interface RPR 1.

<Sysname> display interface rpr 1 RPR1 current state: UP Line protocol current state: DOWN Description: RPR1 Interface The Maximum Transmit Unit is 1500 Internet protocol processing : disabled IP Packet Frame Type: PKTFMT_ETHNT_2, Hardware Address: 0000-0000-0000 IPv6 Packet Frame Type: PKTFMT_ETHNT_2, Hardware Address: 0000-0000-0000 Output queue : (Urgent queuing : Size/Length/Discards) 0/100/0 Output queue : (Protocol queuing : Size/Length/Discards) 0/500/0 Output queue : (FIFO queuing : Size/Length/Discards) 0/75/0 Last clearing of counters: Never

# Display the brief information about Layer 3 RPR logical interface RPR 1.

<Sysname> display interface rpr 1 brief The brief information of interface(s) under route mode: Link: ADM - administratively down; Stby - standby Protocol: (s) - spoofing Interface Link Protocol Main IP Description RPR1 DOWN DOWN --

# Display the brief information about all Layer 3 RPR logical interfaces in DOWN state.

<Sysname> display interface rpr brief down The brief information of interface(s) under route mode: Link: ADM - administratively down; Stby - standby Interface Link Cause RPR1 DOWN Not connected RPR2 DOWN Not connected

Table 23 Command output

Field Description

State of the Layer 3 RPR logical interface:

• DOWN (Administratively)—The interface has been

RPR1 current state

Internet protocol processing : disabled

administratively shut down with the shutdown command.

• DOWN—The interface is administratively up but physically down, maybe because no physical link is present or the link has failed.

• UP—The interface is up both administratively and physicall y.

IP packet processing capability. Disabled indicates that IP packet processing is disabled. If an IP address is configured for the interface, Internet Address is

displayed for the field.

Internet Address is

192.168.2.1/24 Primary IP Packet Frame Type Frame type for IPv4 packets. IPv6 Packet Frame Type Frame type for IPv6 packets. Output queue : (Urgent

queuing : Size/Length/Discards)

Output queue : (Protocol queuing : Size/Length/Discards)

Output queue : (FIFO queuing : Size/Length/Discards)

Last clearing of counters: Never

The brief information of interface(s) under route mode

Link: ADM - administratively down; Stby - standby

IP address of the RPR logical interface.

Output queue type (urgent queue: packet number/queue length/discarded packets).

Output queue type (protocol queue: packet number/queue length/discarded packets).

Output queue type (FIFO queue: packet number/queue length/discarded packets).

The latest time when the interface statistics were cleared with the

counts interface

have never been cleared.

Brief information about Layer 3 interfaces.

Link status:

• ADM—The interface has been administrativel y shut down. To recover its physical state, perform the undo shutdown command.

• Stby—The interface is operating as a backup interface. To see the primary interface, use the display standby state command.

command.

Never

indicates that the interface statistics

reset

Protocol: (s) - spoofing

Interface Abbreviate d interface name. Link Physical link state of the interface. Protocol Protocol connection state of the interface. Main IP Primary IP address of the interface. Cause Cause of a DOWN physical link.

display interface rprpos

Use display interface rprpos to display information about an RPR physical port.

If the network layer protocol state of an interface is shown as UP, but its link is an on-demand link or not present at all, its protocol attribute includes the spoofing flag (an s in parentheses).

Syntax

display interface [ rprpos ] [ brief [ down ] ] [ | { begin | exclude | include } regular-expression ] display interface { rprpos } interface-number [ brief [ description ] ] [ | { begin | exclude | include }

regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

rprpos: Displays information about an RPRPOS interface.

interface-number: Number of an RPR physical port.

brief: Displays brief interface information. If you do not specify this keyword, this command displays detailed interface information.

description: Displays complete interface description. If you do not specify this keyword, this command displays only the first 27 characters of the interface description.

down: Displays information about interfaces in DOWN state and the causes. If you do not specify this keyword, this command displays information about interfaces in all states.

|: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

If no interface type (rprpos) is specified, this command displays information about all types of interfaces.

If an interface type (rprpos) is specified but the interface number (interface-number) is not specified, this command displays information about all RPR physical ports of the specified type.

If both the interface type and interface number are specified, this command displays the information about the specific RPR physical port.

Examples

# Display information about RPRPOS 2/1/1.

<Sysname> display interface rprpos 2/1/1 RPRPOS2/1/1 current state: DOWN Line protocol current state: DOWN Description: RPRPOS2/1/1 Interface The Maximum Frame Length is 1500

Link delay is 1(sec) Internet protocol processing : disabled Physical layer is STM-16/OC-48 Frame-format is SDH, Current baudrate is 2488320000 bps Clock master, scramble enabled, loopback not set SD Threshold: 5, SF Threshold: 3

Optical:Absent, Mate optical:Absent Output queue : (Urgent queuing : Size/Length/Discards) 0/100/0 Output queue : (Protocol queuing : Size/Length/Discards) 0/500/0 Output queue : (FIFO queuing : Size/Length/Discards) 0/75/0

SDH alarm: section layer: LOS line layer: NONE path layer: NONE TxFlag: J0: "" RxFlag: J0: 0x00 TxFlag: J1: "" RxFlag: J1: "unknown" TxFlag: C2: 0x16 RxFlag: C2: 0x16 SDH error: section layer: RS_BIP(B1) 0 line layer: MS_BIP(B2) 0, MS_REI 0 path layer: HP_BIP(B3) 0, HP_REI 0, HP_PJE 0, HP_NJE 0

Last clearing of counters: Never Host receive Packets Bytes unicast 0 0 multicast 0 0 Line receive Packets Bytes unicast 0 0 multicast 0 0 Host send Packets Bytes unicast 0 0 multicast 0 0 Line send Packets Bytes unicast 0 0 multicast 0 0 Input Errors parity 0 short 0 crc 0 ringiderr -Output Errors parity 0 short 0 giant 0 fifo 0 Control Frame In Out Oam 0 0 Atd 0 0 Tc 0 1 Tp 0 774 Mode Packets Bytes SaStrip 0 0 TtlDrop 0 0 TxFlood 0 0 RxFlood 0 0

Last 5 second Host input : 0.00 packets/sec 0.00 bytes/sec 0.00% Last 5 second Line input : 0.00 packets/sec 0.00 bytes/sec 0.00% Last 5 second Host output: 0.00 packets/sec 0.00 bytes/sec 0.00% Last 5 second Line output: 0.00 packets/sec 0.00 bytes/sec 0.00%

Table 24 Command output

Field Description

Physical state of the RPR physical port:

RPRPOS2/1/1 current state

Link delay is Delay interval before the interface takes an action for an alarm.

• DOWN (Administratively)—The port has been administratively shut down with the shutdown command.

• DOWN—The port is administratively up but physically down.

• UP—The port is up both administratively and physically.

Internet protocol processing

Last clearing of counters

Last 5 second Host input Number of packets received by the host in the last 5 seconds. Last 5 second Line input Number of packets received by the line in the last 5 seconds. Last 5 second Host output Number of packets sent by the host in the last 5 seconds. Last 5 second Line output Number of packets sent by the line in the last 5 seconds.

display rpr bind-info

Use display rpr bind-info to display the binding information of the specified RPR physical port or RPR logical interface.

Syntax

display rpr bind-info [ { rprpos | rpr } interface-number ] [ | { begin | exclude | include }

regular-expression ]

Views

Any view

IP packets processing capability of the interface:

disabled

Latest time when the interface statistics were cleared. interface statistics have never been cleared.

—The interface does not process IP packets.

Never

indicates that the

Default command level

1: Monitor level

Parameters

{ rprpos | rpr } interface-number: Specifies an RPR physical port or RPR logical interface by its type and number. I f no RPR physical port or RPR logical interface is specified, this command displays the binding information of all RPR logical interfaces.

|: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display the binding information of all RPR logical interfaces.

<Sysname> display rpr bind-info Bind information on interface: RPR1 Smart-connection: Enabled/Connected PHY-Interface Ringlet-ID Role Mate-Port

-------------------------------------------------- RPRPOS1/0 Ringlet0 Master Up RPRPOS1/1 Ringlet1 Slave Up

Bind information on interface: RPR2 Smart-connection: Enabled/Connected PHY-Interface Ringlet-ID Role Mate-Port

-------------------------------------------------- None N/A N/A N/A None N/A N/A N/A

Table 25 Command output

Field Description

Bind information on interface Binding information of an RPR logical interface.

Smart-connection: Enabled/Connected

PHY-Interface Physical port bound to the RPR logical interface.

Ringlet-ID

Role Role of the physical port. It can be Master, Slave, or N/A. Mate-Port State of the mate port connected to the physical port.

display rpr defect

Use display rpr defect to display RPR defect information.

State of the RPR mate port smart connection function and connection state of the mate ports:

• Enabled/Connected—The RPR mate port smart connection function is enabled, and the mate ports have been connected internally.

• Enabled/Disconnected—The RPR mate port smart connection function is enabled, and the mate ports are not connected internally.

• Disabled—The RPR mate port smart connection function is disabled.

Binding relationship between the physical port and the RPR logical interface:

• Ringlet0—The physical port is the west interface.

• Ringlet1—The physical port is the east interface.

• N/A—No binding relationship exists.

Syntax

Views

display rpr defect [ rpr interface-number ] [ | { begin | exclude | include } regular-expression ]

Any view

Default command level

1: Monitor level

Parameters

rpr interface-number: Specifies an RPR logical interface by its type and number. If no RPR logical

interface is specified, this command displays the RPR defect information of the stations corresponding to all the RPR logical interfaces on your device.

|: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display the ring defect information for RPR logical interface RPR 1.

<Sysname> display rpr defect rpr 1 RPR defects on interface: RPR1 Excess reserved rate defect: ringlet0: 0, ringlet1: 0 Jumbo configuration defect: 0 Maximum number of stations exceeded defect: 0 Miscabling defect: ringlet0: 0, ringlet1: 0 Protection mode configuration defect: 0 Inconsistent topology defect: 0 Topology instability defect: 0 IP address duplicate defect: 0 MAC address duplicate defect: 1

In the output, the value 0 means that no defects are present and 1 means at least a defect is present.

display rpr fairness

Use display rpr fairness to display information about RPR fairness parameters.

Syntax

display rpr fairness [ rpr interface-number ] [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

rpr interface-number: Specifies an RPR logical interface by its type and number. If no RPR logical

interface is specified, this command displays the RPR fairness settings of the RPR stations corresponding to all the RPR logical interfaces on your device.

|: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.

begin: Displays the first line that matches the specified regular expression and all lines that follow. exclude: Displays all lines that do not match the specified regular expression.

include: Displays all lines that match the specified regular expression. regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display the RPR fairness settings for Layer 3 RPR logical interface RPR 1.

<Sysname> display rpr fairness rpr 1 RPR fairness parameters on interface: RPR1 Station's fairness weight on ringlet0: 0 Station's fairness weight on ringlet1: 0 Local reserved bandwidth for class A0 service on ringlet0: 0 Mbps Local reserved bandwidth for class A0 service on ringlet1: 0 Mbps Local rate-limiter bandwidth for high priority service on ringlet0: 5 Mbps Local rate-limiter bandwidth for high priority service on ringlet1: 5 Mbps Local rate-limiter bandwidth for medium priority service on ringlet0: 0 Mbps Local rate-limiter bandwidth for medium priority service on ringlet1: 0 Mbps Local rate-limiter bandwidth for low priority service on ringlet0: 2500 Mbps Local rate-limiter bandwidth for low priority service on ringlet1: 2500 Mbps Total reserved bandwidth for class A0 service on ringlet0: 0 Mbps Total reserved bandwidth for class A0 service on ringlet1: 0 Mbps

# Display the information about RPR fairness parameters for Layer 3 RPR logical interface RPR 2.

<Sysname> display rpr fairness rpr 2 RPR fairness parameters on interface: RPR2 Station's fairness weight on ringlet0: 0 Station's fairness weight on ringlet1: 0 Local reserved bandwidth for class A0 service on ringlet0: 0 in permillage Local reserved bandwidth for class A0 service on ringlet1: 0 in permillage Local rate-limiter bandwidth for high priority service on ringlet0: 2 in permillage Local rate-limiter bandwidth for high priority service on ringlet1: 2 in permillage Local rate-limiter bandwidth for medium priority service on ringlet0: 0 in permillage Local rate-limiter bandwidth for medium priority service on ringlet1: 0 in permillage Local rate-limiter bandwidth for low priority service on ringlet0: 1000 in permillage Local rate-limiter bandwidth for low priority service on ringlet1: 1000 in permillage

NOTE:

For an RPR logical interface that is not bound to any physical port, the reserved bandwidth for each class of service is displayed as a permillage of the total bandwidth.

Table 26 Command output

Field Description

Local rate-limiter bandwidth for high priority service on ringlet0

Local rate-limiter bandwidth for high priority service on ringlet1

Local rate-limiter bandwidth for medium priority service on ringlet0

Local rate-limiter bandwidth for medium priority service on ringlet1

Rate limit setting of the local station for the class A1 service on Ringlet 0.

Rate limit setting of the local station for the class A1 service on Ringlet 1.

Rate limit setting of the local station for the class B CIR service on Ringlet 0.

Rate limit setting of the local station for the class B CIR service on Ringlet 1.

Field Description

Local rate-limiter bandwidth for low priority service on ringlet0

Rate limit setting of the local station for the class B EIR and class C services on Ringlet 0.

Local rate-limiter bandwidth for low priority service on ringlet1

display rpr protection

Use display rpr protection to display RPR protection information.

Syntax

display rpr protection [ { rpr | rpr-bridge } interface-number ] [ | { begin | exclude | include }

regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

{ rpr | rpr-bridge } interface-number: Specifies an RPR logical interface by its type and number . If no RPR logical interface is specified, this command displays the RPR protection information of all the RPR stations on your device. Support for the types of RPR logical interfaces depends on the device model.

|: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.

Rate limit setting of the local station for the class B EIR and class C services on Ringlet 1.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

The protection mode can be configured protection mode and active protection mo de. The configured protection mode is administratively configured but does not necessarily take effect. RPR automatically checks the protection modes of all the stations to make sure that the same active protection mode is used on the ring.

Examples

# Display the protection information of Layer 3 RPR logical interface RPR 1.

<Sysname> display rpr protection rpr1 Protection information on interface: RPR1 Configured protection mode: steer Active protection mode: steer Protection reversion mode: revertible Context containment active: 0 Protection state on the west span: sf Protection state on the east span: sf Edge state on the west span: edged Edge state on the east span: edged

Last known neighbour on the west span: 000f-e245-7a43 Last known neighbour on the east span: 000f-e23f-2e80 The number of protections on the west span: 1 The number of protections on the east span: 1 Last protection time on the west span: Last protection time on the east span: Protection start time on the west span: 2007.06.12 17:11:43 Protection start time on the east span: 2007.06.12 17:11:43

# Display the protection information of Layer 3 RPR logical interface RPR 2.

<Sysname> display rpr protection rpr2 Protection information on interface: RPR2 Configured protection mode: steer Protection reversion mode: revertible

NOTE:

For an RPR logical interface not bound with any physical port, this command displays only its protection mode and protection reversion mode.

Table 27 Command output

Field Description

Protection information on interface

Configured protection mode Protection mode configured administratively. Active protection mode Protection mode that is taking effect. Protection reversion mode Protection reversion mode.

Context containment active

Last known neighbour on the west span

Last known neighbour on the east span MAC address of the adjacent station on the east. The number of protections on the west

span The number of protections on the east

span

Last protection time on the west span

Last protection time on the east span

Protection start time on the west span

RPR protection information of the station corresponding to the specified interface.

Indicates whether the CC mechanism is taking effect: 0 for active, 1 for inactive.

MAC address of the adjacent station on the west.

Number of protection reversions on the west span.

Number of protection reversions on the east span.

Time when the last protection reversion occurred on the west span.

Time when the last protection reversion occurred on the east span.

Starting time of the protection reversion occurring on the west span.

Protection start time on the east span

display rpr rs-table

Use display rpr rs-table to display information about RPR ringlet selection table.

Starting time of the protection reversion occurring on the east span.

Syntax

display rpr rs-table { default | dynamic | ipv6 | overall | static | vrrp } [ rpr interface-number ] [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

default: Displays information about the default ringlet selection table. dynamic: Displays information about the dynamic ringlet selection table. ipv6: Displays information about the IPv6 ringlet selection table. overall: Displays information about the overall ringlet selection table. static: Displays information about the static ringlet selection table. vrrp: Displays information about the VRRP ringlet selection table. rpr interface-number: Specifies an RPR logical interface by its type and number. If no RPR logical

interface is specified, this command displays the ringlet selection table information of all the RPR stations on your device. Support for the types of RPR logical interfaces depends on the device model.

|: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display information about the dynamic ringlet selection tables of all RPR stations on your device.

<Sysname> display rpr rs-table dynamic Dynamic ringlet selection table on interface: RPR1 MAC-Address Ringlet-ID TTL IP-Address Station-Name

---------------------------------------------------------------------- 00e0-fc00-1a01 Ringlet0 1 0.0.0.0

--- Total entrie(s): 1 ---

# Display information about the static ringlet selection tables of all RPR stations on your device.

<Sysname> display rpr rs-table static Static ringlet selection table on interface: RPR1 MAC-Address Ringlet-ID Status

---------------------------------- 0003-0002-0002 Ringlet0 Invalid

--- Total entrie(s): 1 ---

Table 28 Command output

Field Description

Dynamic ringlet selection table on interface

Dynamic ringlet selection table of the station corresponding to the specified interface.

Static ringlet selection table on interface

MAC-Address Destination MAC address. Ringlet-ID Sending ringlet: 0 for Ringlet 0, 1 for Ringlet 1. TTL Time to live. Number of hops for reaching the destination.

IP-Address

Station-Name Name of the destination station. Status Status of the entry: valid or invalid.

display rpr statistics

Use display rpr statistics to display traffic statistics for the specified or all RPR stations on the device.

Syntax

display rpr statistics { dmac | smac } [ mac-address ] [ rpr interface-number ] [ | { begin | exclude | include } regular-expression ]

Views

Any view

Static ringlet selection table of the station corresponding to the specified interface.

IP address of the destination. If the destination station has no IP address, 0.0.0.0 is displayed.

Default command level

1: Monitor level

Parameters

dmac: Displays statistics for traffic sent to destination stations specified by their MAC address. smac: Displays statistics for traffic received from source stations specified by their source MAC

addresses. mac-address: Specifies the MAC address of a source or destination station. If the argument is

specified, this command displays statistics about the traffic sent to or received from the specified station.

rpr interface-number: Specifies an RPR logical interface by its type and number. If no RPR logical interface is specified, this command displays traffic statistics of all the RPR stations on your device.

|: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display traffic statistics sent out from the station whose MAC address is 00E0-FC00-1A01 on the ring.

<Sysname> display rpr statistics smac 00e0-fc00-1a01 Traffic statistics from the source station on interface: RPR1 MAC-Address Packets Bytes

------------------------------------00e0-fc00-1a01 0 0

Table 29 Command output

Field Description

Traffic statistics from the source station on interface

Source MAC address-based traffic statistics for the station corresponding to the specified interface.

Traffic statistics to the destination station on interface

MAC-Address MAC address of the source or destination station.

display rpr timers

Use display rpr timers to display RPR timers.

Syntax

display rpr timers [ rpr interface-number ] [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

rpr interface-number: Specifies an RPR logical interface by its type and number. If no RPR logical

interface is specified, this command displays the RPR timers for all the RPR stations on your device. |: Filters command output by specifying a regular expression. For more information about regular

expressions, see Fundamentals Configuration Guide.

Destination MAC address-based traffic statistics for the station corresponding to the specified interface.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display the settings of all RPR timers.

<Sysname> display rpr timers Value of all the timers on interface: RPR1 Fast TP timer: 10 ms Slow TP timer: 100 ms Fast TC timer: 10 ms Slow TC timer: 100 ms ATD timer: 1 s WTR timer: 10 s Holdoff timer: 0 ms Keepalive timer: 3 ms

Topology stability timer: 40 ms

display rpr topology

Use display rpr topology to display RPR topology information.

Syntax

display rpr topology { all | local | ring | stations } [ summary ] [ rpr interface-number ] [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

all: Displays all topology information. local: Displays the topology information of the local station. ring: Displays the ring topology information. stations: Displays the topology information of all the stations on the ring. summary: Displays the RPR topology summary. rpr interface-number: Specifies an RPR logical interface by its type and number. If no RPR logical

interface is specified, this command displays the topology information of all the RPR stations on your device.

|: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Examples

# Display all topology information.

<Sysname> display rpr topology all Ring-level topology information on interface: RPR1 Stations on ringlet0: 1 Stations on ringlet1: 1 Total stations on ring: 2 Jumbo preference: regular Ring topology type: closed ring

Local station topology information on interface: RPR1 Station name: Mac address: 00e0-fc00-1001 IP address: 0.0.0.0 Jumbo preference: regular Active protection mode: steer Protection state on the west span: idle Protection state on the east span: idle

Edge state on the west span: unedged Edge state on the east span: unedged Sequence number: 10 Last known neighbour on the west span: 00e0-fc00-1a01 Last known neighbour on the east span: 00e0-fc00-1a01 Local topology state: valid

Station topology information on interface: RPR1 Station entry on ringlet0 Mac address: 00e0-fc00-1a01 Station name: IP address: 0.0.0.0 Hops: 1 Jumbo preference: regular Protection mode: steer Protection state on the west span: idle Protection state on the east span: idle Edge state on the west span: unedged Edge state on the east span: unedged Sequence number: 9 Reachability: reachable Valid: 1

Station entry on ringlet1 Mac address: 00e0-fc00-1a01 Station name: IP address: 0.0.0.0 Hops: 1 Jumbo preference: regular Protection mode: steer Protection state on the west span: idle Protection state on the east span: idle Edge state on the west span: unedged Edge state on the east span: unedged Sequence number: 9 Reachability: reachable Valid: 1

# Display the topology information of the RPR station corresponding to Layer 3 RPR logical interface RPR 2.

<Sysname> display rpr topology all rpr 2 Ring-level topology information on interface: RPR2 Stations on ringlet0: 0 Stations on ringlet1: 0 Total stations on ring: 1 Jumbo preference: regular Ring topology type: open ring

Local station topology information on interface: RPR2 Station name:

IP address: 0.0.0.0

Station topology information on interface: RPR2

Table 30 Command output

Field Description

Ring-level topology information on interface

Stations on ringlet0 Number of stations on the west span. Stations on ringlet1 Number of stations on the east span. Total stations on ring Total number of stations on the ring.

Jumbo preference

Ring topology type Ring status: open ring or closed ring.

Ring topology information of the station corresponding to the specified interface.

Indicates whether Jumbo frames are supported:

• regular—Not supported.

• jumbo—Supported.

Local station topology information on interface

Local topology information of the station corresponding to the interface.

Hops Number of hops from the specific station to the local station.

Protection mode:

Active protection mode

• wrap—Wrapping mode.

• steer—Steering mode.

Protection state on the west span:

• fs—Forced switch.

• sf—Signal fail.

Protection state on the west span

• sd—Signal degrade.

• ms—Manual switch.

• wtr—Wait to restore.

• idle.

Protection state on the east span:

• fs—Forced switch.

• sf—Signal fail.

Protection state on the east span

• sd—Signal degrade.

• ms—Manual switch.

• wtr—Wait to restore.

• idle.

Sequence number Sequence number of the TP frame. Last known neighbour on the west

span

MAC address of the last learned neighbor on the west span.

Last known neighbour on the east span MAC address of the last learned neighbor on the east span. Local topology state Start (for topology initializing), stable, unstable, valid, or invalid. Station topology information on

interface

Topology information of other RPR stations on the ring.

Station entry on ringlet0 Topology information of the neighbor on the west span. Station entry on ringlet1 Topology information of the neighbor on the east span. Valid Status of the entry: 1 (valid) or 0 (invalid).

# Display the RPR topology summary.

<Sysname> display rpr topology all summary Topology information items Psw:protection state, west Pse:protection state, east Esw:edge state, west Ese:edge state, east Wc:wrap protection configured Jp:jumbo frame preferred

Ring-level topology information on interface: RPR1 Ringlet0 Ringlet1 Ring Jumbo-Prefer Topology-Type

------------------------------------------------ 1 1 2 Regular Closed ring

Local station topology information on interface: RPR1 MAC-Address Psw Pse Esw Ese Wc Jp IP-Address Station-Name

-------------------------------------------------------------------- 00e0-fc00-1001 Idle Idle 0 0 0 0 0.0.0.0 StationA

Station topology information on interface: RPR1 Station entry on ringlet0 MAC-Address Psw Pse Esw Ese Wc Jp IP-Address Station-Name

-------------------------------------------------------------------- 00e0-fc00-1a01 Idle Idle 0 0 0 0 0.0.0.0 StationB

Station entry on ringlet1 MAC-Address Psw Pse Esw Ese Wc Jp IP-Address Station-Name

-------------------------------------------------------------------- 00e0-fc00-1a01 Idle Idle 0 0 0 0 0.0.0.0 StationB

Table 31 Command output

Field Description

Topology information items Items of topology information.

Protection state of the east span:

• Fs—Forced switch.

• Sf—Signal fail.

Pse:protection state, east

Psw:protection state, west

Ese:edge state, east

• Sd—Signal degrade.

• Ms—Manual switch.

• Wtr—Wait to restore.

• Idle.

Protection state of the west span:

• Fs—Forced switch.

• Sf—Signal fail.

• Sd—Signal degrade.

• Ms—Manual switch.

• Wtr—Wait to restore.

• Idle.

Edge state of the east span:

• 1—An edge has been detected.

• 0—No edge has been detected.

Field Description

Edge state of the west span:

Esw:edge state, west

Wc:wrap protection configured

Jp:jumbo frame preferred

• 1—An edge has been detected.

• 0—No edge has been detected.

Wrap protection mode configured:

• 1—Wrapping mode.

• 0—Steering mode.

Indicates whether Jumbo frames are supported:

• 1—Supported.

• 0—Not supported.

Ring-level topology information on interface

Topology information of the RPR station corresponding to the

specific interface. Ringlet0 Number of stations on the west span. Ringlet1 Number of stations on the east span. Ring Total stations on the ring.

Indicates whether Jumbo frames are supported: Jumbo-Prefer

• Regular—Not supported.

• Jumbo—Supported.

Topology-Type Ring status, either open ring or closed ring. Local station topology information on

interface

Summary of local topology information of the station that

corresponds to the interface. MAC-Address MAC address of the station. IP-Address IP address of the station. Station-Name Station name. Station topology information on

interface

Topology summary for the other stations on the same ring to

which the specified interface belongs. Station entry on ringlet0 Topology summary for the neighbor stations on the west span. Station entry on ringlet1 Topology summary for the neighbor stations on the east span.

# Display the topology information of the local station.

<Sysname>display rpr topology local Local station topology information on interface: RPR1 Station name:StationB Mac address: 00e0-fc00-1001 IP address: 0.0.0.0 Jumbo preference: regular Active protection mode: steer Protection state on the west span: idle Protection state on the east span: idle Edge state on the west span: unedged Edge state on the east span: unedged Sequence number: 10 Last known neighbour on the west span: 00e0-fc00-1a01 Last known neighbour on the east span: 00e0-fc00-1a01 Local topology state: valid

Table 32 Command output

Field Description

Local station topology information on interface

Mac address MAC address of the station. Station name Station name. IP address IP address of the station.

Jumbo preference

Sequence number Sequence number of the TP frame.

Topology information of the local stations mapping to the logical

interfaces of the device.

Indicates whether Jumbo frames are supported:

• regular—Not supported.

• jumbo—Supported.

Last known neighbour on the west span

MAC address of the last learned neighbor on the west span.

Last known neighbour on the east span MAC address of the last learned neighbor on the east span. Local topology state Start (for topology initializing), stable, unstable, valid, or invalid.

# Display the ring-level topology information.

<Sysname>display rpr topology ring Ring-level topology information on interface: RPR1 Stations on ringlet0: 1 Stations on ringlet1: 1 Total stations on ring: 2 Jumbo preference: regular Ring topology type: closed ring

Table 33 Command output

Field Description

Ring-level topology information on interface

Stations on ringlet0 Number of stations on the west span. Stations on ringlet1 Number of stations on the east span.

Ring topology information of the station that corresponds to the

specified interface.

Total stations on ring Total stations on the ring.

Indicates whether Jumbo frames are supported: Jumbo preference

• regular—Not supported.

• jumbo—Supported.

Ring topology type Ring status, either open ring or closed ring.

# Display all the station topology information on the ring.

<Sysname>display rpr topology stations Station topology information on interface: RPR1 Station entry on ringlet0 Mac address: 00e0-fc00-1a01 Station name:StationA IP address: 0.0.0.0 Hops: 1 Jumbo preference: regular

Protection mode: steer Protection state on the west span: idle Protection state on the east span: idle Edge state on the west span: unedged Edge state on the east span: unedged Sequence number: 9 Reachability: reachable Valid: 1

Station entry on ringlet1 Mac address: 00e0-fc00-1a01 Station name:StationB IP address: 0.0.0.0 Hops: 1 Jumbo preference: regular Protection mode: steer Protection state on the west span: idle Protection state on the east span: idle Edge state on the west span: unedged Edge state on the east span: unedged Sequence number: 9 Reachability: reachable Valid: 1

Table 34 Command output

Field Description

Station topology information on interface

Station entry on ringlet0 Topology information of the neighbor o n the west span. Station entry on ringlet1 Topology information of the neighbor on the east span. MAC-Address MAC address of the station. Station name Station name. IP address IP address of the station. Hops Number of hops from the specified station to the local station.

Jumbo preference

Sequence number Sequence number of the TP frame. Valid Status of the entry: 1 (valid) or 0 (invalid).

NOTE:

Topology information of other RPR stations.

Indicates whether Jumbo frames are supported:

• regular—Not supported.

• jumbo—Supported.

For an RPR logical interface not bound to any RPR physical port, the display rpr topology local command displays only the station name and station IP address, and the display rpr topology stations command displays nothing.

display rpr vrrp-info

Use display rpr vrrp-info to display RPR VRRP standby group information.

Syntax

display rpr vrrp-info [ rpr interface-number ] [ | { begin | exclude | include } regular-expression ]

Views

Any view

Default command level

1: Monitor level

Parameters

rpr interface-number: Specifies an RPR logical interface by its type and number. If no RPR logical

interface is specified, this command displays the VRRP standby group information of all the RPR stations on your device.

|: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.

regular-expression: Specifi es a regular expression, a case-sensitive string of 1 to 256 characters.

Usage guidelines

For more information about VRRP, see High Availability Configuration Guide.

Examples

# Display VRRP standby group information of RPR.

<Sysname> display rpr vrrp-info VRRP info on interface: RPR1 Index Virtual-Group Status MAC-Address

------------------------------------------------- 0 N/A N/A N/A 1 N/A N/A N/A

flag

Use flag to set the overhead bytes of the interface. Use undo flag to restore the default.

Syntax

flag { c2 | { j0 | j1 } { sdh | sonet } } flag-value

Default

Views

undo flag { c2 | { j0 | j1 } { sdh | sonet } }

The C2 byte value of an RPRPOS interface is 0x16, and the SDH J0 and J1 byte values are null.

RPRPOS interface view

Default command level

2: System level

Parameters

c2 flag-value: Specifies the path signal label byte. It is a hexadecimal number in the range of 0x00 to

0xFF.

sdh: Sets the framing format to synchronous digital hierarchy (SDH). sonet: Sets the framing format to synchronous optical network (SONET). j0 flag-value: Specifies the regeneration section trace message. If the sdh keyword is configured,

the flag-value argument is a string of 1 to 15 characters. If the sonet keyword is configured, the argument is a hexadecimal number in the range of 0x00 to 0xFF.

j1 flag-value: Specifies the higher-Order VC-N path trace byte. If the sdh keyword is configured, the flag-value argument is a string of 1 to 15 characters. If the sonet keyword is configured, the

argument is a string of 1 to 62 characters.

Usage guidelines

Inconsistency between the c2 and j1 settings of the sending and receiving interfaces causes alarms. The J0 byte can be any character in the network of the same carrier. If networks of two carriers are

involved, however, the sending and rece iving devices at network borders must use the same J0 byte. With the J0 byte, operators can detect and troubleshoot faults in advance or use l ess time to recover networks.

Examples

# Set the framing format on interface RPRPOS 2/1/1 to SONET, and set the SONET overhead byte J0 of RPRPOS 2/1/1 interface to 0xFF.

<Sysname> system-view [Sysname] interface rprpos 2/1/1 [Sysname-RPRPOS2/1/1] frame-format sonet [Sysname-RPRPOS2/1/1] flag j0 sonet ff

flag j1 ignore

Use flag j1 ignore to ignore CRC of the J1 byte. Use undo flag j1 ignore to restore the default.

Syntax

flag j1 ignore undo flag j1 ignore

Default

CRC is performed for the J1 byte.

Views

RPRPOS interface view

Default command level

2: System level

Examples

# Ignore CRC of the J1 byte on interface RPRPOS 2/1/1.

<Sysname> system-view [Sysname] interface rprpos 2/1/1

[Sysname-RPRPOS2/1/1] flag j1 ignore

frame-format

Use frame-format to set the framing format on the interface. Use undo frame-format to restore the default.

Syntax

frame-format { sdh | sonet } undo frame-format

Default

The framing format is SDH.

Views

RPRPOS interface view

Default command level

2: System level

Parameters

sdh: Sets the framing format to SDH. sonet: Sets the framing format to SONET.

Examples

# Set the framing format on interface RPRPOS 2/1/1 to SONET.

<Sysname> system-view [Sysname] interface rprpos 2/1/1 [Sysname-RPRPOS2/1/1] flag j1 ignore

interface rpr

Use interface rpr to create an RPR logical interface and enter RPR logical interface view. Use undo interface rpr to remove an RPR logical interface.

Syntax

interface rpr interface-number undo interface rpr interface-number

Views

System view

Default command level

2: System level

Parameters

rpr: Specifies a Layer 3 RPR logical interface.

interface-number: Number of the RPR logical interface.

Usage guidelines

If the specified RPR logical interface does not exist, executing this command first creates an RPR logical interface and then enters its view.

You cannot delete an RPR logical interface bound to RPR physical ports.

Examples

# Create a Layer 3 RPR logical interface RPR 1 and enter its view.

<Sysname> system-view [Sysname] interface rpr 1 [Sysname-RPR1]

interface rprpos

Use interface rprpos to enter RPR physical port view.

Syntax

interface rprpos interface-number

Views

System view

Default command level

2: System level

Parameters

rprpos: Creates an RPRPOS port.

interface-number: Number of an RPR physical port.

Examples

# Enter RPR physical port RPRPOS 2/1/1 view.

<Sysname> system-view [Sysname] interface rprpos 2/1/1 [Sysname-RPRPOS2/1/1]

mtu

Use mtu to configure the MTU for the Layer 3 RPR logical interface. Use undo mtu to restore the default.

Syntax

mtu size undo mtu

Default

The MTU of a Layer 3 RPR logical interface is 1500 bytes.

Views

Layer 3 RPR logical interface view

Default command level

2: System level

Parameters

size: Specifies an Maximum Transmission Unit (MTU) value. The value range is 128 to 9600 bytes. The maximum MTU configurable on an interface might be lower than 9600 bytes depending on the device model, interface module model, and interface type.

Examples

# Configure the MTU of Layer 3 RPR logical interface RPR 1 as 1492.

<Sysname> system-view [Sysname] interface rpr 1 [Sysname-RPR1] mtu 1492

Related commands

display interface rpr

reset counters interface rpr

Use reset counters interface rpr to clear statistics of the specified RPR logical interfaces.

Syntax

reset counters interface [ rpr [ interface-number ] ]

Views

User view

Default command level

2: System level

Parameters

rpr: Clears statistics of the RPR logical interfaces.

interface-number: Number of the RPR logical interface. It is the number of an existing interface.

Usage guidelines

T o collect stat istics of an RPR logical interface within a specific period, you must clear statistics of the interface before starting statistics collection.

If you do not specify rpr, this command clears the statistics of all interfaces. If you specify the rpr keyword but not the interface-number argument, this command clears the

statistics of all RPR logical interfaces. If you specify the rpr keyword and the interface-number argument, this command clears the

statistics of the specified RPR logical interface.

Examples

# Clear the statistics of Layer 3 RPR logical interface RPR 1.

<Sysname> reset counters interface rpr 1

reset counters interface rprpos

Use reset counters interface to clear statistics of the specified RPR physical ports.

Syntax

reset counters interface [ rprpos [ interface-number ] ]

Views

User view

Default command level

2: System level

Parameters

rprpos: Clears statistics of RPRPOS ports.

interface-number: Specifies the number of an RPR physical port for which statistics are to be cleared.

Usage guidelines

T o coll ect statistics of an RPR physical port within a specific period, you need to clear statistics of the port before starting statistics collection.

If you do not specify the rprpos keyword, this command clears the statistics of all ports. If you specify the rprpos keyword but not the interface-number argument, this command clears the

statistics of all RPRPOS ports. If you specify the rprpos keyword and the interface-number argument, this command clears the

statistics of the specified RPRPOS port.

Examples

# Clear the statistics of RPR physical port RPRPOS 2/1/1.

<Sysname> reset counters interface rprpos 2/1/1

reset rpr protection statistics

Use reset rpr protection statistics to clear RPR protection events statistics.

Syntax

reset rpr protection statistics [ rpr interface-number ]

Views

User view

Default command level

1: Monitor level

Parameters

rpr interface-number: Specifies an RPR logical interface by its type and number. If no RPR logical

interface is specified, the RPR protection events statistics for the RPR stations corresponding to all the RPR logical interfaces on your device are cleared.

Examples

# Clear all RPR protection events statistics.

<Sysname> reset rpr protection statistics

rpr admin-request

Use rpr admin-request to send an RPR protection request on the specified ri nglet.

Syntax

Default

Views

rpr admin-request { fs | idle | ms } { ringlet0 | ringlet1 }

Idle protection applies.

Layer 3 RPR logical interface view

Default command level

2: System level

Parameters

fs: Sends a forced switch (FS) protection request. idle: Sends an idle protection request. ms: Sends a manual switch (MS) protection request. ringlet0: Sends a protection request on Ringlet 0. ringlet1: Sends a protection request on Ringlet 1.

Usage guidelines

Six types of protection requests, FS, signal fail (SF), signal degrade (SD), MS, wait to restore (WT R), and idle, are available with decreased priorities. Among them, FS and MS requests are sent manually, whereas SF, SD, and WTR requests are sent automatically.

• Use the rpr admin-request fs command to send an FS protection request. As the FS request takes priority over all other requests, you can remove it from the RPR ring only with the rpr admin-request idle command.

• Use the rpr admin-request ms command to send an MS protection request. As the priority of the MS request is the lowest, RPR ring does not perform MS switching if any other type of protection request is present. On the contrary, the FS, SF, or SD reque st can override the MS request.

• Use the rpr admin-request idle command to clear the FS or MS protection request.

Examples

# Configure Layer 3 RPR logical interface RPR 1 to send an FS protection request on Ri nglet 0.

<Sysname> system-view [Sysname] interface rpr 1 [Sysname-RPR1] rpr admin-request fs ringlet0

rpr bind

Use rpr bind to bind an RPR logical interface with an RPR physical port. Use undo rpr bind to remove the binding.

Syntax

In Layer 3 RPR logical interface view:

rpr bind rprpos interface-number { ringlet0 | ringlet1 } undo rpr bind rprpos interface-number

In RPRPOS interface view:

rpr bind rpr interface-number { ringlet0 | ringlet1 } undo rpr bind

Default

No RPR physical ports are bound with any RPR logical interface.

Views

Layer 3 RPR logical interface view , RPRPOS interface view

Default command level

2: System level

Parameters

rprpos interface-number: Specifies an RPR physical port by its type and number. rpr interface-number: Specifies an RPR logical interface by its type and number. ringlet0: Uses the RPR physical port that receives data frames on Ringlet 0 and sends data frames

on Ringlet 1 as the west port of the current or specified RPR logical interface. ringlet1: Uses the RPR physical port that sends data frames on Ringlet 0 and receives data frames

on Ringlet 1 as the east port of the current or specified RPR logical interface.

Usage guidelines

An RPR logical interface can be bound with two RPR physical ports, and an RPR physical port can be bound with only one RPR logical interface.

For an RPR station to operate correctly, an RPR logical interface must be bound with at least one RPR physical port.

Each RPR physical port is accompanied by a mate port. For an RP R station to operate correctly, you must use optical fibers to connect the mate ports of the two RPR physical ports bound with its corresponding RPR logical interface.

Examples

# Configure RPR physical port RPRPOS 2/1/1 as the west port of Layer 3 RPR logical interface RPR

<Sysname> system-view [sysname] interface rpr 1 [sysname-RPR1] rpr bind rprpos 2/1/1 ringlet0

# Configure Layer 3 RPR logical interface RPR 1 as the east port of RPR physical port RPRPOS 2/1/2.

<Sysname> system-view [sysname] interface rprpos 2/1/2 [sysname-RPRPOS2/1/2] rpr bind rpr 1 ringlet1

rpr default-rs

Use rpr default-rs to configure the default RPR ringlet for sending data frames. Use undo rpr default-rs to restore the default.

Syntax

rpr default-rs { ringlet0 | ringlet1 } undo rpr default-rs

Default

The default ringlet is Ringlet 0.

Views

Layer 3 RPR logical interface view

Default command level

2: System level

Parameters

ringlet0: Specifies Ringlet 0 as the default ringlet. ringlet1: Specifies Ringlet 1 as the default ringlet.

Usage guidelines

In case the default ringlet you configured is faulty, the other ringlet works as the default ringlet to forward data.

Examples

# Specify Ringlet 1 as the default ringlet on Layer 3 RPR logical interface RPR 1.

<Sysname> system-view [Sysname] interface rpr 1 [Sysname-RPR1] rpr default-rs ringlet1

rpr echo mac

Use rpr echo mac to test the connectivity between the current station and a peer station.

Syntax

rpr echo mac mac-address [ -c c-value | -r { ringlet0 | ringlet1 | reverse } | -s { ringlet0 | ringlet1 } | -t t-value ] *

Default

Five Echo Request packets are sent. It is the default ringlet in use that sends Echo Response packets and Echo Request packets. The response timeout time is 10 milliseconds.

Views

Layer 3 RPR logical interface view

Default command level

2: System level

Parameters

mac-address: Tests the connectivity to the station identified by the MAC address.

-c c-value: Specifies the number of Echo Requests to be sent for testing connectivity, in the range of

1 to 1000.

-r: Specifies the ringlet for the destination to send Echo Respo nses. It could be ringlet0, ringlet1, or

reverse. If the reverse keyword is specified, the destination station is expected to send Echo

Reponses from the ringlet different from the one from which it receives Echo Requests. For example, if the destination station receives Echo Requests from Ringlet 0, it should send out Echo Responses onto Ringlet 1.

-s: Specifies the ringlet for sending Echo Requests, either ringlet0 or ringlet1.

-t t-value: Specifies the echo response timeout in the range of 10 to 65535 milliseconds. If it is not

specified, the default of 10 milliseconds applies.

Usage guidelines

If neither the sending ringlet nor the receiving ringlet is specified, the default ringlet in use will be used for transmitting Echo Request packets and Echo Response packets.

The connectivity between the current station and a peer station is considered normal only when the connections between the two stations operate correctly on both the sending ringlet and the receiving ringlet. The peer station can receive Echo Request packets from the current node on a specific ringlet and the current station can receive Echo Response packets from the peer station on a specific ringlet. Otherwise, the connections between the current station and the peer station are considered faulty.

Examples

# Test the connectivity between the current station and the station with MAC address 0012-3F83-A1E3, and specify ringlet 0 as the sending ringlet and rin glet 1 as the receiving ringlet on Layer 3 RPR logical interface RPR 1.

<Sysname> system-view [Sysname] interface rpr 1 [Sysname-RPR1] rpr echo mac 0012-3F83-A1E3 -s ringlet0 -r ringlet1 PING 0012-3F83-A1E3: press CTRL+C to break Reply from 0012-3F83-A1E3: ringlet=1 hops=1 seq=2 time=1 ms Reply from 0012-3F83-A1E3: ringlet=1 hops=1 seq=3 time=1 ms Reply from 0012-3F83-A1E3: ringlet=1 hops=1 seq=4 time=1 ms Reply from 0012-3F83-A1E3: ringlet=1 hops=1 seq=5 time=1 ms Reply from 0012-3F83-A1E31: ringlet=1 hops=1 seq=6 time=1 ms

--- echo 0012-3F83-A1E3 statistics ---

100 packet(s) transmitted 100 packet(s) received

0.0% packet loss

round-trip min/avg/max = 1/1/16 ms

rpr mate smart-connect

Use rpr mate smart-connect to enable the RPR mate port smart connection function. Use undo rpr mate smart-connect to disable the function.

Syntax

rpr mate smart-connect undo rpr mate smart-connect

Default

RPR mate port smart connection is disabled.

Views

Layer 3 RPR logical interface view

Default command level

2: System level

Usage guidelines

When the two RPR physical ports are on the same subcard—in centralized RPR, you can enable RPR mate port smart connection. With the function enabled, RPR automatically connects the two mate ports without you having to connect them manually.

Examples

# Enable RPR mate port smart connection on Layer 3 RPR logical interface RPR 1.

<Sysname> system-view [Sysname] interface rpr 1 [Sysname-RPR1] rpr mate smart-connect

rpr protect-mode

Use rpr protect-mode to set the RPR protection mode for the station.

HP FlexNetwork 6600, FlexNetwork HSR6600 High Availability Command Reference

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Active and standby switchover configuration commands

display switchover state

ha slave-ignore-version-check

slave restart

slave switchover

slave switchover { disable | enable }

Ethernet OAM configuration commands

display oam

display oam configuration

display oam critical-event

display oam link-event

oam enable

oam errored-frame period

oam errored-frame threshold

oam errored-frame-period period

oam errored-frame-period threshold

oam errored-frame-seconds period

oam errored-frame-seconds threshold

oam errored-symbol period

oam errored-symbol threshold

oam loopback

oam loopback interface (system view)

oam loopback interface (user view)

oam loopback reject-request

oam mode

oam timer hello

oam timer keepalive

reset oam

CFD configuration commands

cfd cc enable

cfd cc interval

cfd enable

cfd linktrace

cfd linktrace auto-detection

cfd loopback

cfd ma

cfd md

cfd mep

cfd mep enable

cfd meplist

cfd mip-rule

cfd service-instance

cfd service-instance maid format

cfd version

display cfd linktrace-reply

display cfd linktrace-reply auto-detection

display cfd ma

display cfd md

display cfd mep

display cfd meplist

display cfd mp

display cfd remote-mep

display cfd service-instance

display cfd status

display cfd version

DLDP configuration commands

display dldp

display dldp statistics

dldp authentication-mode

dldp delaydown-timer

dldp enable

dldp interval

dldp reset

dldp unidirectional-shutdown

dldp work-mode

reset dldp statistics

RPR configuration commands

bandwidth

description

display interface rpr

display interface rprpos

display rpr bind-info

display rpr defect

display rpr fairness

display rpr protection
