QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Overview

HPE FlexNetwork 3100 EI Switch Series

Models

HPE 3100 48 v2 Switch

JG315B

HPE 3100 8 v2 EI Switch

JD318B

HPE 3100 16 v2 EI Switch

JD319B

HPE 3100 24 v2 EI Switch

JD320B

HPE 3100 24 PoE v2 EI Switch

JD313B

Key features

• Comprehensive security control policies

Product overview

HPE FlexNetwork 3100 EI series switches are Layer 2 Ethernet switches designed for enterprise networks demanding high security and intelligence. They provide 10/100 Mbps downlink and 1000 Mbps uplink Ethernet ports, and Mbps end users or aggregate client devices with 10/100 Mbps connections, converging at a higher interfaces. Features include advanced Quality of Service (QoS), rate limiting, QinQ (virtual LAN [VLAN]/VPN), SSHv2, Multicas VLAN Registration (MVR), Virtual Cable Tester (VCT), HGMP V2, GARP VLAN Registration Protocol (GVRP), acc (ACL), media access control (MAC) Management Protocol snooping, and Power over Ethernet (PoE).

Features and benefits

Quality of Service

Management

allow assignment of descriptive names to ports

• High reliability with improved backup redundancy

• Simplified deployment and ease of use

• Highly expandable and highly reliable

• Diversified management modes and maintenance

-to-desktop applications in enterprise networks. In metropolitan area networks or various industry networks, they connect

• Broadcast control

allows limitation of broadcast traffic rate to cut down on unwanted network broadcast traffic

• Advanced classifier-based QoS

classifies traffic using multiple match criteria based on Layer 2, 3, and 4 information; applies QoS policies such as setting priority level and rate limit to selected traffic on a per-port or per-VLAN basis

• Powerful QoS feature

supports the following congestion actions: strict priority queuing (SP), weighted round robin (WRR) queuing, and SP+WRR

• Traffic policing

supports Committed Access Rate (CAR) and line rate

serve as access devices for 100

-capacity switch with 1000 Mbps t

ess control list

-IP-port binding, Endpoint Admission Defense, voice and protocol-based VLAN, Internet Group

(QoS)

• Friendly port names:

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Overview

• Remote configuration and management

Connectivity

are dual-personality ports for either 10/100/1000 or mini-GBIC SFP connectivity for increased connectivity flexibility

enables configuration and management through a secure Web browser or a CLI located on a remote device

• Manager and operator privilege levels

provides read-only (operator) and read/write (manager) access on CLI and Web browser management interfaces

• Command authorization

leverages HWTACACS to link a custom list of CLI commands to an individual network administrator's login; also provides an audit trail

• Secure Web GUI

provides a secure, easy-to-use graphical interface for configuring the module via HTTPS

• Multiple configuration files

stores easily to the flash image

• Complete session logging

provides detailed information for problem identification and resolution

• SNMPv1, v2c, and v3

facilitate centralized discovery, monitoring, and secure management of networking devices

• Remote monitoring (RMON)

uses standard SNMP to monitor essential network functions; supports events, alarm, history, and statistics group plus a private alarm extension group

• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

advertises and receives management information from adjacent devices on a network, facilitating easy mapping by network management applications

• Management VLAN

segments traffic to and from management interfaces, including CLI/Telnet, a Web browser interface, and SNMP

• Local and Remote Intelligent Mirroring

mirror traffic from a switch port to a local or remote switch port anywhere on the network; mirror ACL-selected traffic to a local switch port

• Device Link Detection Protocol (DLDP)

monitors a cable between two switches and shuts down the ports on both ends if the cable is broken, preventing network problems such as loop

• Troubleshooting

ingress and egress port monitoring enable network problem solving; virtual cable tests provide visibility into cable problems

• Stacking capability

single IP address management for a stack of up to 16 switches

• IPv6 (on v2 products):

• Auto-MDIX

• Flow control

• Gigabit Ethernet uplinks

− Telnet v6

to allow IPv6 management

− DNSv6 Client

for IPv6 host management

− SNMPv6

for IPv6 switch management

− DHCPv6 Client

for automatic IPv6 address configuration of a switch

automatically adjusts for straight-through or crossover cables on all 10/100 and 10/100/1000 ports

provides back pressure using standard IEEE 802.3x, reducing congestion in heavy traffic situations

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Overview

• IEEE 802.3af Power over Ethernet

(PoE)

Performance

Resiliency and high availability

based link aggregation

Layer 2 switching

provides up to 15.4 W per port to IEEE 802.3af-compliant PoE-powered devices such as IP phones, wireless access points, and security cameras

• Ethernet operations, administration and maintenance (OAM)

detects data link layer problems that occurred in the "last mile" using the IEEE 802.3ah OAM standard; monitors the status of the link between two devices

• Hardware-based wire-speed access control lists (ACLs)

help provide high levels of security and ease of administration without impacting network performance with a feature-rich TCAM-based ACL implementation

• Gigabit Ethernet interface

provides a connection to the network that eliminates the network as a bottleneck

• Separate data and control paths

increase security and performance

• External redundant power supply

provides high reliability

• Smart link

allows 50 ms failover between links

• Spanning Tree/MSTP, RSTP

provides redundant links while preventing network loops

• Port trunking

provides higher switch-to-switch throughput and link-level redundancy, with support for standards(IEEE 802.3ad); supports up to 13 trunks, each with up to 8 links (ports) per trunk

• Device Link Detection Protocol (DLDP)

monitors link connectivity and shuts down ports at both ends if unidirectional traffic is detected, preventing loops in STPbased networks

• NEW PVST+ on v2 products

provides greater interoperability

• 8K MAC addresses

provide access to many Layer 2 devices

• VLAN support and tagging

supports the IEEE 802.1Q, with 4,094 simultaneous VLAN IDs; supports port-based VLANs, MAC-based VLANs, and protocol-based VLANs

• GARP VLAN Registration Protocol

allows automatic learning and dynamic assignment of VLANs

• IEEE 802.1ad QinQ and Selective QinQ

increase the scalability of an Ethernet network by providing a hierarchical structure; connect multiple LANs on a highspeed campus or metro network

• Gigabit Ethernet port aggregation

allows grouping of ports to increase overall data throughput to a remote device

• Internet Group Management Protocol (IGMP) and Multicast Listener Discovery (MLD) protocol snooping

control and manage the flooding of multicast packets in a Layer 2 network

Page

QuickSpecs

Overview

Layer 3 services

Security

blocks ARP broadcasts from unauthorized hosts, preventing eavesdropping or theft of network data

• Address Resolution Protocol (ARP)

• Dynamic Host Configuration Protocol (DHCP)

• Loopback interface address

• Access control lists (ACLs)

• Multiple user authentication methods:

• Identity-driven security and access control:

• Secure management access

• Secure FTP

• Guest VLAN

• Endpoint Admission Defense (EAD)

• Port security

• Port isolation

• STP BPDU port protection

• STP Root Guard

• DHCP protection

• Dynamic ARP protection

HPE FlexNetwork 3100 EI Switch Series

determines the MAC address of another IP host in the same subnet

simplifies the management of large IP networks and supports client and server

defines an address in Routing Information Protocol (RIP) and Open Standard Path First (OSPF), improving diagnostic capability

provide IP Layer 2 to Layer 4 traffic filtering; support global ACL, VLAN ACL, and IPv6 ACL

− IEEE 802.1X

uses an IEEE 802.1X supplicant on the client in conjunction with a RADIUS server to authenticate in accordance with industry standards

− Web-based authentication

provides a browser-based environment, similar to IEEE 802.1X, to authenticate clients that do not support the IEEE 802.1X supplicant

− MAC-based authentication

authenticates the client with the RADIUS server based on the client's MAC address

− Per-user ACLs

permits or denies user access to specific network resources based on user identity and time of day, allowing multiple types of users on the same network to access specific network services without risking network security or allowing unauthorized access to sensitive data

− Automatic VLAN assignment

automatically assigns users to the appropriate VLAN based on their identities

delivers secure encryption of all access methods (CLI, GUI, or MIB) through SSHv2, SSL, and/or SNMPv3

allows secure file transfer to and from the switch; protects against unwanted file downloads or unauthorized copying of a switch configuration file

provides a browser-based environment to authenticated clients that is similar to IEEE 802.1X

provides security policies to users accessing a network

allows access only to specified MAC addresses, which can be learned or specified by the administrator

secures and adds privacy, and prevents malicious attackers from obtaining user information

blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged BPDU attacks

protects the root bridge from malicious attacks or configuration mistakes

blocks DHCP packets from unauthorized DHCP servers, preventing denial-of-service attacks

Page

QuickSpecs

Overview

• IP Source Guard

Convergence

Device support

Flexibility

Additional information

Warranty and support

product purchase.

• RADIUS/HWTACACS

• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

• LLDP-MED

• LLDP-CDP compatibility

• IEEE 802.3af Power over Ethernet

• PoE allocations

• Voice VLAN

• Multicast VLAN

• IGMP/MLD snooping

HPE FlexNetwork 3100 EI Switch Series

filters packets on a per-port basis, which prevents illegal packets from being forwarded

eases switch management security administration by using a password authentication server

facilitates easy mapping using network management applications with LLDP automated device discovery protocol

is a standard extension that automatically configures network devices, including LLDP-capable IP phones

receives and recognizes CDP packets from Cisco's IP phones for seamless interoperation

provides up to 15.4 W per port to PoE-powered devices such as IP phones, wireless access points, and video cameras

supports multiple methods (automatic, IEEE 802.3af class, LLDP-MED, or user-specified) to allocate PoE power for more efficient energy savings

automatically assigns VLAN and priority for IP phones, simplifying network configuration and maintenance

allows multiple VLANs to receive the same IPv4 or IPv6 multicast traffic, lessening network bandwidth demand by reducing or eliminating multiple streams to each VLAN

effectively controls and manages the flooding of multicast packets in a Layer 2 network

• Cisco prestandard PoE support

detects and provides power to Cisco's prestandard PoE devices such as wireless LAN access points and IP phones

• Fanless design

enables quiet operation for deployment in open spaces (selected models)

• Green initiative support

provides support for RoHS and WEEE regulations

• Green IT and power

uses the latest advances in silicon development and shuts off unused ports to improve power efficiency

• Limited Lifetime Warranty

see http://www.hpe.com/networking/warrantysummary

for warranty and support information included with your

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Overview

• Software releases

to find software for your product, refer to releases available with your product purchase, refer to http://www.hpe.com/networking/warrantysummary

http://www.hpe.com/networking/support; for details on the software

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Configuration

Build To Order:

BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack solution.

HPE 3100 8 v2 EI Switch

JD318B

•

• 1U - Height

See Configuration

No Power Cord

JD318B#AC3

• No Localized Power Cord Selected

HPE 3100 16 v2 EI Switch

JD319B

•

• 1U - Height

See Configuration

No Power Cord

JD319B#AC3

• No Localized Power Cord Selected

HPE 3100 24 PoE v2 EI Switch

JD313B

•

• 1U - Height

See Configuration

No Power Cord

JD313B#AC3

• No Localized Power Cord Selected

HPE 3100 24 v2 EI Switch

JD320B

•

• 1U - Height

See Configuration

No Power Cord

JD320B#AC3

• No Localized Power Cord Selected

HPE 3100 48 v2 Switch

JG315B

•

• 1U - Height

8 autosensing 10/100 ports

• 1 dual-personality port; auto-sensing

• 10/100/1000BASE-T or SFP

• min=0 \ max=1 SFP Transceiver

16 autosensing 10/100 ports

• 2 dual-personality port; auto-sensing 10/100/1000Base-T or SFP

• min=0 \ max=2 SFP Transceivers

-Shippable

NOTE:1, 3

24 autosensing 10/100 PoE ports

• 2 dual-personality port; auto-sensing 10/100/1000Base-T or SFP

• min=0 \ max=2 SFP Transceivers

24 autosensing 10/100 ports

• 2 dual-personality port; auto-sensing 10/100/1000Base-T or SFP

• min=0 \ max=2 SFP Transceivers

48 RJ-45 autosensing 10/100 ports

• 2 SFP dual-personality 10/100/1000 ports

• 2 SFP fixed Gigabit Ethernet SFP ports

• min=0 \ max=4 SFP Transceivers

NOTE:1, 3

See Configuration

NOTE:4, 5, 6

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Configuration

PDU Cable NA/MEX/TW/JP

JG315B#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JG315B#B2C

• C15 PDU Jumper Cord (ROW)

High Volt Switch/Router to Wall Power Cord

JG315B#B2E

• NEMA L6-20P Cord (NA/MEX/JP/TW)

Configuration Rules:

Note 1

The following Transceivers install into this switch:

HPE X115 100M SFP LC BX 10-U Transceiver

JD100A

HPE X115 100M SFP LC BX 10-D Transceiver

JD101A

HPE X115 100M SFP LC FX Transceiver

JD102B

HPE X110 100M SFP LC LX Transceiver

JD120B

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

Note 3

Localization required. (See Localization Menu for list.)

Note 4

The following Transceivers install into this switch: (SFP 1000 Mbps ports only)

HPE X125 1G SFP LC LH40 1310nm Transceiver

JD061A

HPE X120 1G SFP LC LH40 1550nm Transceiver

JD062A

HPE X125 1G SFP LC LH70 Transceiver

JD063B

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

Note 5

Localization (Wall Power Cord) required on Cord) or #B2E. (See Localization Menu)

Note 6

#B2E is Offered only in NA, Mexico, Taiwan and Japan.

Remarks:

Drop down under power supply should offer the following options and results: Switch/Router/Power Supply to PDU Power Cord Taiwan, and Japan or #B2C ROW. (Watson Default B2B or B2C for Rack Level CTO) Switch/Router/Power Supply to Wall Power Cord - Localized Option (Watson Default for BTO and Box Le High Volt Switch/Router/Power Supply to Wall Power Cord only in North America, Mexico, Taiwan, and Japan)

Rack Level Integration CTO Models

orders without #B2B, #B2C (PDU Power

- #B2B in North America, Mexico,

vel CTO)

- #B2E Option. (Offered

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Configuration

Switch Chassis

HPE 3100 48 v2 Switch

JG315B

•

• 1U - Height

See Configuration

PDU Cable NA/MEX/TW/JP

JG315B#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JG315B#B2C

• C15 PDU Jumper Cord (ROW)

Configuration Rules:

Note 1

The following Transceivers install into this switch: (SFP 1000 Mbps ports only)

HPE X125 1G SFP LC LH40 1310nm Transceiver

JD061A

HPE X120 1G SFP LC LH40 1550nm Transceiver

JD062A

HPE X125 1G SFP LC LH70 Transceiver

JD063B

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

Note 3

When Switches are Factory Racked, Then #B2B, or #B2C should be the Defaulted Power Cable option on the Switches.

Note 4

Localization (Wall Power Cord) required on orders without #B2B, #B2C (PDU Cord). (See Localization Menu)

Note 5

If the CTO Switch Chassis needs to be racked, Then the CTO Base Model needs to integrate (with #0D1) to the HPE Network Rack.

Remarks:

Drop down under power supply should offer the following Switch/Router/Power Supply to PDU Power Cord Taiwan, and Japan or #B2C ROW. (Watson Default B2B or B2C for Rack Level CTO) Switch/Router/Power Supply to Wall Power Cord

lt for

BTO and Box Level CTO)

Transceivers

SFP Transceivers

HPE X125 1G SFP LC LH40 1310nm Transceiver

JD061A

48 RJ-45 autosensing 10/100 ports

• 2 SFP dual-personality 10/100/1000 ports

• 2 SFP fixed Gigabit Ethernet SFP ports

• min=0 \ max=4 SFP Transceivers

NOTE:1, 3, 4, 5

Power

options and results:

- #B2B in North America, Mexico,

- Localized Option (Watson Defau

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Configuration

HPE X120 1G SFP LC LH40 1550nm Transceiver

JD062A

HPE X125 1G SFP LC LH70 Transceiver

JD063B

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

HPE X115 100M SFP LC BX 10-U Transceiver

JD100A

HPE X115 100M SFP LC BX 10-D Transceiver

JD101A

HPE X115 100M SFP LC FX Transceiver

JD102B

HPE X110 100M SFP LC LX Transceiver

JD120B

Internal Power Supplies

No Power supplies

Cables

Multi-Mode Cables

HPE LC to LC Multi-mode OM3 2-Fiber 0.5m 1-Pack Fiber Optic Cable

AJ833A

HPE LC to LC Multi-mode OM3 2-Fiber 1.0m 1-Pack Fiber Optic Cable

AJ834A

HPE LC to LC Multi-mode OM3 2-Fiber 2.0m 1-Pack Fiber Optic Cable

AJ835A

HPE LC to LC Multi-mode OM3 2-Fiber 5.0m 1-Pack Fiber Optic Cable

AJ836A

HPE LC to LC Multi-mode OM3 2-Fiber 15.0m 1-Pack Fiber Optic Cable

AJ837A

HPE LC to LC Multi-mode OM3 2-Fiber 30.0m 1-Pack Fiber Optic Cable

AJ838A

HPE LC to LC Multi-mode OM3 2-Fiber 50.0m 1-Pack Fiber Optic Cable

AJ839A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable

QK732A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable

QK733A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable

QK734A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable

QK735A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable

QK736A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable

QK737A

Switch Enclosure Options

Stacking Cable kit

HPE FlexNetwork 3600 Switch SFP Stacking Kit

JD324B

Mounting Kits

HPE 3100/4210 16 Rackmount Kit

JD321A

See Configuration

NOTE:1

HPE 3100/4210 9 Rackmount Kit

JD322A

See Configuration

NOTE:2

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Configuration

Configuration Rules:

Note 1

The following switches require this kit when mounting into a rack:

HPE 3100 16 v2 EI Switch

JD319B

Note 2 The following switches require this kit when mounting into a rack:

HPE 3100 8 v2 EI Switch

JD318B

Remark:

The 24 and 48 port devices come with rack mount ears.

External Redundant Power Supplies

System (std 0 // max 1) User Selection (min 0 / max 1) per Switch

HPE RPS1600 Redundant Power System

JG136A

•

• includes 1 x c13, 1600w and Power Supply port

See Configuration

NOTE:2, 4

HPE RPS1600 1600W AC Power Supply

JG137A

• Installs into JG136A only

See Configuration

Configuration Rules:

Note 2 This power supply is support only on the following switches:

HPE 3100 24 PoE v2 EI Switch

JD313B

Note 3

If this power supply is selected, The JG136A System must be on order or onsite.

Note 4

Localization required. (See Localization Menu for list.)

External Redundant Power Cables

System (std 0 // max 1) User Selection (min 0 / max 1) per RPS

HPE X290 1000 A JD5 2m RPS Cable

JD187A

HPE X290 500 C 1m RPS Cable

JD184A

Height = 1U

NOTE:3

- HPE A-RPS1600 Redundant Power

Page

QuickSpecs

HPE FlexNetwork

3100 EI Switch Series

Technical Specifications

I/O ports and slots

48 RJ-45 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX); Duplex: half or full

2 SFP dual-personality 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASETX, IEEE 802.3ab Type 1000BASE-T)

4 SFP fixed Gigabit Ethernet SFP ports

slots

1 RJ-45 serial console port

Dimensions

17.32(w) x 10.24(d) x 1.72(h) in (43.99 x 26.01 x 4.37 cm) (1U height)

Weight

7.72 lb (3.5 kg)

Memory and processor

256 MB SDRAM, 128 MB flash; Packet buffer size: 4 MB

Mounting and enclosure

100 Mb Latency

1000 Mb Latency

up to 13.1 Mpps

Routing/Switching capacity

17.6 Gbps

Routing table size

32 entries (IPv4)

32000 entries

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

humidity

10% to 90%, noncondensing

temperature

-40°F to 158°F (-40°C to 70°C)

relative humidity

5% to 95%, noncondensing Low-speed fan: 43.2 dB, High-speed fan: 50.0 dB

Electrical characteristics

Maximum heat dissipation

140 BTU/hr

Voltage

100 - 240 VAC, rated

41 W

Frequency

50/60 Hz

Maximum power rating and maximum heat dissipation are the worst-case

all modules populated.

Safety

UL 60950; NOM-019-SCFI Mexico; EN 60950: 2000, ZB and ZC Deviations; IEC 60950: 1999, Corr Feb 2000, all national deviations; AS/NZS 60950: 2000 Australia, Russian GOST Safety Approval

FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003 Class A; ANSI C63.4

2:2006; EN

61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Management

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager

HPE 3100 48 v2 Switch (JG315B)

Additional ports and

Physical characteristics

Performance

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)

< 6 µs (64-byte packets)

Throughput

MAC address table size

Operating relative

Nonoperating/Storage

Acoustic

< 5 µs (64-byte packets)

Maximum power rating

Notes

theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and

Emissions

2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR22 Class A; EN 61000-3-2; EN 61000-3-3; EN 61000-4EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-4-11; EN 61000-3-

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Technical Specifications

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE 3100 8 v2 EI Switch (JD318B)

half or full

1 dual-personality port; auto-sensing 10/100/1000Base-T or SFP

1 RJ-45 serial console port

Physical characteristics

Dimensions

9.06(w) x 6.3(d) x 1.72(h) in (23.01 x 16 x 4.37 cm) (1U height)

Weight

3.97 lb (1.8 kg)

Memory and processor

128 MB SDRAM; Packet buffer size: 384 KB, 16 MB flash

Mounting and enclosure

Requires angle mounting set if rack mounted (not included)

Performance

100 Mb Latency

< 6 µs (64-byte packets)

1000 Mb Latency

< 5µ

Throughput

up to 2.6 Mpps

capacity

3.6 Gbps

Routing table size

16 entries (IPv4)

MAC address table size

8192 entries

32°F to 113°F (0°C to 45°C)

Operating relative humidity

10% to 90%, noncondensing

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage relative humidity

5% to 95%, noncondensing

Acoustic

N/A (fanless)

dissipation

31 BTU/hr

Voltage

100 - 240 VAC, rated

Maximum power rating

9 W

50/60 Hz

Notes

Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated.

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2;

Subchapter J; NOM; ROHS Compliance

FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003 Class A; ANSI C63.4 2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR22 Class A; EN 61000-3-2; EN 61000-3-3; EN 61000-4-2;

Services Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for

details on the service-level descriptions and product numbers. For details about services and

I/O ports and slots

Additional ports and slots

Environment

8 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX); Duplex:

s (64-byte packets)

Routing/Switching

Operating temperature

Nonoperating/Storage temperature

Electrical characteristics Maximum heat

Frequency

Safety

IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR

Emissions

infrastructure

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Technical Specifications

EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-4-11; EN 61000-3-2:2006; EN 61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Management

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE 3100 16 v2 EI Switch

16 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX) Duplex: half or full

2 dual-personality ports auto-sensing 10/100/1000BASE-T or SFP

Additional ports and slots

1 RJ-45 serial console port

Dimensions

14.17(w) x 6.3(d) x 1.72(h) in (35.99 x 16 x 4.37 cm) (1U height)

5.51 lb (2.5 kg)

Memory and processor

128 MB SDRAM; Packet buffer size: 384 KB, 16 MB flash

Mounting and enclosure

Requires angle mounting set if rack mounted (not included)

100 Mb Latency

< 5µs (64-byte packets)

Throughput

up to 5.3 Mpps

capacity

7.2 Gbps 16 entries

MAC address table size

8192 entries

Operating temperature

32°F to 113°F (0°C to 45°C)

10% to 90%, noncondensing

Nonoperating/Storage temperature

-40°F to 158°F (-40°C to 70°C)

5% to 95%, noncondensing

Acoustic

N/A (fanless)

dissipation

41 BTU/hr 100 - 240 VAC, rated

Maximum power rating

12 W

Frequency

50/60 Hz

Maximum power rating and maximum heat dissipation are the worst-case

modules populated.

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2;

Subchapter J; NOM; ROHS Compliance

Services Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for

details on the service-level descriptions and product numbers. For details about services and

(JD319B)

I/O ports and slots

Physical characteristics

Performance

Environment

Weight

1000 Mb Latency

Routing/Switching

Routing table size

Operating relative humidity

< 6 µs (64-byte packets)

Nonoperating/Storage relative humidity

Electrical characteristics Maximum heat

Voltage

Notes

theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all

Safety

IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Technical Specifications

FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003 Class A; ANSI C63.4

61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Management

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager

times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE 3100 24 v2 EI Switch

24 autosensing 10/100 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX) Duplex: half or full

2 dual-personality ports auto-sensing 10/100/1000BASE-T or SFP

slots

1 RJ-45 serial console port

17.32(w) x 6.3(d) x 1.72(h) in (43.99 x 16 x 4.37 cm) (1U height)

Weight

7.72 lb (3.5 kg)

Memory and processor

128 MB SDRAM; Packet buffer size: 384 KB, 16 MB flash

Mounting and enclosure

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)

1000 Mb Latency

< 6 µs (64-byte packets)

10 Gbps Latency

< 5 µs (64-byte packets)

Throughput

up to 6.5 Mpps

8.8 Gbps

Routing table size

16 entries (IPv4)

MAC address table size

8192 entries

Operating temperature

32°F to 113°F (0°C to 45°C)

humidity

10% to 90%, noncondensing

temperature

-40°F to 158°F (-40°C to 70°C)

relative humidity

5% to 95%, noncondensing

Acoustic

N/A (fanless)

44 BTU/hr

Voltage

100 - 240 VAC, rated

Maximum power rating

13 W

Frequency

50/60 Hz

Maximum power rating and maximum heat dissipation are the worst-case

all modules populated.

Emissions

2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR22 Class A; EN 61000-3-2; EN 61000-3-3; EN 61000-4-2; EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-4-11; EN 61000-3-2:2006; EN

Services Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for

details on the service-level descriptions and product numbers. For details about services and response

(JD320B)

I/O ports and slots

Additional ports and

Physical characteristics Dimensions

Performance

Routing/Switching capacity

Environment

Operating relative

Nonoperating/Storage

Electrical characteristics Maximum heat

dissipation

Notes

theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Technical Specifications

UL 60950; NOM-019-SCFI Mexico; EN 60950: 2000, ZB and ZC Deviations; IEC 60950: 1999, Corr Feb 2000, all national deviations; AS/NZS 60950: 2000 Australia, Russian GOST Safety Approval

FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003 Class A; ANSI C63.4

61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Management

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE 3100 24 PoE v2 EI Switch (JD313B)

24 autosensing 10/100 PoE ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE

2 dual-personality ports; auto-sensing 10/100/1000BASE-T or SFP

slots

1 RJ-45 serial console port

17.32(w) x 16.54(d) x 1.72(h) in (44 x 42 x 4.36 cm) (1U height)

Weight

14.33 lb. (6.5 kg)

Memory and processor

128 MB SDRAM; Packet buffer size: 384 KB, 16 MB flash

Mounting and enclosure

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)

< 6 µs (64-byte packets)

1000 Mb Latency

< 5 µs (64-byte packets)

Throughput

up to 6.5 Mpps

8.8 Gbps

MAC address table size

8192 entries

Operating temperature

32°F to 113°F (0°C to 45°C)

10% to 90%, noncondensing

Nonoperating/Storage temperature

-40°F to 158°F (-40°C to 70°C)

5% to 95%, noncondensing

Acoustic

Low-speed fan: 42.2 dB, High-speed fan: 51.5 dB

dissipation

1586 BTU/hr (1673.23 kJ/hr) 100 - 240 VAC, rated

Maximum power rating

465 W

PoE power

370 W PoE

Frequency

50/60 Hz

Maximum power rating and maximum heat dissipation are the worst-case

with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and

Safety

Emissions

2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR22 Class A; EN 61000-3-2; EN 61000-3-3; EN 61000-4EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-4-11; EN 61000-3-2:2006; EN

Services Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for

details on the service-level descriptions and product numbers. For details about services and

I/O ports and slots

802.3af PoE); Duplex: half or full

Additional ports and

Physical characteristics Dimensions

Performance

100 Mb Latency

Routing/Switching capacity

Environment

Operating relative humidity

Nonoperating/Storage relative humidity

Electrical characteristics Maximum heat

Voltage

Notes

theoretical maximum numbers provided for planning the infrastructure

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Technical Specifications

all modules populated.

With DC input, the maximum power is 400 W; PoE power is 370 W.

UL 60950-1; CAN/CSA 22.2 No. 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2

Subchapter J; NOM; ROHS Compliance

FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003 Class A; ANSI C63.4

61000-3-3:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

Management

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

Standards and protocols (applies to all products in series)

SSHv1/SSHv2 Secure Shell

IEEE 802.1ad Q-in-Q

RFC 854 TELNET

PoE power is the power supplied by the internal power supply. It is dependent on the type and quantity of power supplies and may be supplemented with the use of an external power supply (EPS).

Safety

Safety of Laser Products-Part 2; IEC 60950-1; Anatel; ULAR; GOST; EN 60950-1/A11; FDA 21 CFR

Emissions

2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR22 Class A; EN 61000-3-2; EN 61000-3-3; EN 61000-4EN 61000-4-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-4-11; EN 61000-3-2:2006; EN

Services Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for

details on the service-level descriptions and product numbers. For details about services and

Device Management

General Protocols

RFC 1157 SNMPv1/v2c RFC 1901-1907 SNMPv2c, SMIv2 and Revised MIB-II RFC 2573 (SNMPv3 Applications) RFC 2578-2580 SMIv2 RFC 2819 (RMON groups Alarm, Event, History and Statistics only) RFC 3410 (Management Framework) RFC 3416 (SNMP Protocol Operations v2) RFC 3417 (SNMP Transport Mappings) HTML and telnet management Multiple Configuration Files SNMP v3 and RMON RFC support

IEEE 802.1ag Service Layer OAM IEEE 802.1D MAC Bridges IEEE 802.1p Priority IEEE 802.1Q VLANs IEEE 802.1s (MSTP) IEEE 802.1w Rapid Reconfiguration of Spanning Tree IEEE 802.1X PAE IEEE 802.3ad Link Aggregation Control Protocol (LACP) IEEE 802.3af Power over Ethernet IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-X IEEE 802.3x Flow Control IEEE 802.3z 1000BASE-X RFC 768 UDP RFC 783 TFTP Protocol (revision 2) RFC 791 IP RFC 792 ICMP RFC 793 TCP RFC 826 ARP

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Technical Specifications

RFC 951 BOOTP RFC 959 File Transfer Protocol (FTP

IPv6

RFC 1881 IPv6 Address Allocation Management (v2 models only)

RFC 5095 Deprecation of Type 0 Routing Headers in IPv6

IEEE 8021-PAE-MIB

RFC 3414 SNMP-User based-SM MIB

RFC 1887 IPv6 Unicast Address Allocation Architecture (v2 models only) RFC 1981 IPv6 Path MTU Discovery (v2 models only) RFC 2080 RIPng for IPv6 (v2 models only) RFC 2373 IPv6 Addressing Architecture (v2 models only) RFC 2375 IPv6 Multicast Address Assignments (v2 models only) RFC 2460 IPv6 Specification (v2 models only) RFC 2461 IPv6 Neighbor Discovery (v2 models only) RFC 2462 IPv6 Stateless Address Auto-configuration (v2 models only) RFC 2463 ICMPv6 (v2 models only) RFC 2464 Transmission of IPv6 over Ethernet Networks (v2 models only) RFC 2475 IPv6 DiffServ Architecture (v2 models only) RFC 2893 Transition Mechanisms for IPv6 Hosts and Routers (v2 models only) RFC 2925 Definitions of Managed Objects for Remote Ping, Traceroute, and Lookup Operations (Ping only) (v2 models only) RFC 2925 Remote Operations MIB (Ping only) (v2 models only) RFC 3056 Connection of IPv6 Domains via IPv4 Clouds (v2 models only) RFC 3162 RADIUS and IPv6 (v2 models only) RFC 3306 Unicast-Prefix-based IPv6 Multicast Addresses (v2 models only) RFC 3307 IPv6 Multicast Address Allocation (v2 models only) RFC 3315 DHCPv6 (client and relay) (v2 models only) RFC 3484 Default Address Selection for IPv6 (v2 models only) RFC 3493 Basic Socket Interface Extensions for IPv6 (v2 models only) RFC 3513 IPv6 Addressing Architecture (v2 models only) RFC 3542 Advanced Sockets API for IPv6 (v2 models only) RFC 3587 IPv6 Global Unicast Address Format (v2 models only) RFC 3596 DNS Extension for IPv6 (v2 models only) RFC 4113 MIB for UDP (v2 models only) RFC 4291 IP Version 6 Addressing Architecture RFC 4443 ICMPv6 (v2 models only) RFC 4861 IPv6 Neighbor Discovery RFC 4862 IPv6 Stateless Address Auto-configuration

MIBs

IEEE 8023-LAG-MIB RFC 1213 MIB II RFC 1493 Bridge MIB RFC 2011 SNMPv2 MIB for IP RFC 2013 SNMPv2 MIB for UDP RFC 2233 Interface MIB RFC 2273 SNMP-NOTIFICATION-MIB RFC 2571 SNMP Framework MIB RFC 2572 SNMP-MPD MIB RFC 2573 SNMP-Notification MIB RFC 2618 RADIUS Authentication Client MIB RFC 2620 RADIUS Accounting Client MIB RFC 2665 Ethernet-Like-MIB RFC 2674 802.1p and IEEE 802.1Q Bridge MIB RFC 2819 RMON MIB RFC 2925 Ping MIB

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Technical Specifications

RFC 3418 MIB for SNMPv3

LLDP-MIB

IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

SNMPv1/v2c/v3

IEEE 802.1p (CoS) RFC 2474 DSCP DiffServ

Network Management

QoS/CoS

RFC 3621 Power Ethernet MIB RFC 3826 AES for SNMP's USM MIB RFC 4133 Entity MIB (Version 3) LLDP-EXT-DOT1-MIB LLDP-EXT-DOT3-MIB

RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events) ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED)

Page

QuickSpecs

Accessories

HPE FlexNetwork 3100 EI Switch Series accessories

Transceivers

HPE X120 1G SFP LC BX 10-U Transceiver

JD098B

HPE X120 1G SFP LC BX 10-D Transceiver

JD099B

HPE X120 1G SFP LC SX Transceiver

JD118B

HPE X120 1G SFP LC LX Transceiver

JD119B

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE FlexNetwork 3600 Switch SFP Stacking Kit

JD324B

HPE LC to LC Multi-mode OM3 2-Fiber 0.5m 1-Pack Fiber Optic Cable

AJ833A

HPE LC to LC Multi-mode OM3 2-Fiber 1.0m 1-Pack Fiber Optic Cable

AJ834A

HPE LC to LC Multi-mode OM3 2-Fiber 2.0m 1-Pack Fiber Optic Cable

AJ835A

HPE LC to LC Multi-mode OM3 2-Fiber 5.0m 1-Pack Fiber Optic Cable

AJ836A

HPE LC to LC Multi-mode OM3 2-Fiber 15.0m 1-Pack Fiber Optic Cable

AJ837A

HPE LC to LC Multi-mode OM3 2-Fiber 30.0m 1-Pack Fiber Optic Cable

AJ838A

HPE LC to LC Multi-mode OM3 2-Fiber 50.0m 1-Pack Fiber Optic Cable

AJ839A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable

QK732A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable

QK733A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable

QK734A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable

QK735A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable

QK736A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable

QK737A

Power Supply

HPE RPS1600 Redundant Power System

JG136A

HPE RPS1600 1600W AC Power Supply

JG137A

Mounting Kit

HPE 3100/4210 16 Rackmount Kit

JD321A

HPE 3100/4210 9 Rackmount Kit

JD322A

HPE 3100/4210 16/8 PoE Rackmount Kit

JD323A

Power Cords and Adapters

HPE X290 500 C 1m RPS Cable

JD184A

HPE X290 1000 A JD5 2m RPS Cable

JD187A

HPE 3100 48 v2 Switch (JG315B)

HPE X125 1G SFP LC LH40 1310nm Transceiver

JD061A

HPE X120 1G SFP LC LH40 1550nm Transceiver

JD062A

HPE X125 1G SFP LC LH70 Transceiver

JD063B

Cables

HPE FlexNetwork 3100 EI Switch Series

Page

QuickSpecs

HPE 3100 EI Switch Series

Accessories

HPE X120 1G SFP RJ45 T Transceiver

JD089B

HPE X115 100M SFP LC FX Transceiver

JD102B

HPE X110 100M SFP LC LX Transceiver

JD120B

HPE 3100 24 PoE v2 EI Switch (JD313B)

Page

QuickSpecs

HPE FlexNetwork 3100 EI

Switch Series

Accessory Product Details

NOTE: Details are not available for all accessories. The following specifications were available at the time of publication.

1 LC 1000BASE-BX10 port (IEEE 802.3ah Type 1000BASE-BX10-U); Duplex: full only

Connectivity

Connector type

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

weight

0.04 lb. (0.02 kg)

typical

0.8 W

maximum

1.0 W

Maximum distance:

• 10km

Fiber type

Single Mode

TX 1310nm RX 1490nm

Services

Refer to the Hewlett Packard Enterprise website

Enterprise sales office.

1 LC 1000BASE-BX10 port (IEEE 802.3ah Type 1000BASE-BX10-D); Duplex: full only

Connectivity

Connector type

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption typical

0.8 W

1.0 W

Maximum distance:

• Up to 10km

Fiber type

Single Mode

Notes

TX 1490nm RX 1310nm

Refer to the Hewlett Packard Enterprise website

Enterprise sales office.

HPE X120 1G SFP LC BX 10-U Transceiver

(JD098B)

A small form-factor pluggable (SFP) Gigabit LX-BX10-U transceiver that provides a full duplex Gigabit solution up to 10km on a single mode cable.

Ports

Physical characteristics Dimensions

Full configuration

Electrical characteristics Power consumption

Power consumption

Cabling

Notes

at http://www.hpe.com/networking/services for details on the servicelevel descriptions and product numbers. For details about services and response times in your area, please contact your local Hewlett Packard

HPE X120 1G SFP LC BX

Ports

10-D Transceiver

(JD099B)

Physical characteristics Dimensions

A small form-factor pluggable (SFP) Gigabit LX-BX10-D transceiver that provides a full duplex Gigabit solution up to 10km on a single mode cable.

Full configuration weight

Power consumption maximum

Cabling

Services

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Accessory Product Details

Ports

1 LC 1000BASE-SX port

Connector type

Wavelength

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

weight

0.04 lb. (0.02 kg)

typical

0.8 W

maximum

1.0 W

Maximum distance:

• OM3 = Not Specified by standard

Cable length

up to 550m

Fiber type

Multi Mode

Refer to the Hewlett Packard Enterprise website

Enterprise sales office.

Ports

1 SFP 1000BASE-LX port (IEEE 802.3z Type 1000BASE-LX)

Connector type

Wavelength

1300 nm

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

Full configuration weight

0.04 lb. (0.02 kg)

0.8 W

Power consumption maximum

1.0 W

Cable type:

• 10km for Singlemode

Fiber type

Both

Refer to the Hewlett Packard Enterprise website

Enterprise sales office.

HPE X120 1G SFP LC SX Transceiver (JD118B)

A small form-factor pluggable (SFP) Gigabit SX transceiver that provides a full-duplex Gigabit solution up to 550m on a Multimode fiber.

Connectivity

Physical characteristics Dimensions

Full configuration

Electrical characteristics Power consumption

Power consumption

Cabling

• FDDI Grade distance = 220m

• OM1 = 275m

• OM2 = 500m

850 nm

HPE X120 1G SFP LC LX Transceiver (JD119B)

A small form-factor pluggable (SFP) Gigabig LX transceiver that provides a full duplex Gigabit solution up to 550m on MMF or 10Km on SMF

Services

Connectivity

Physical characteristics Dimensions

Electrical characteristics Power consumption

typical

Cabling

Either single mode or multimode;

Maximum distance:

• 550m for Multimode

Services

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Accessory Product Details

HPE LC to LC Multi-

Cabling

Cable type

50/125 modal bandwidth of 2000 MHz/km as detailed in TIA distances of up to 300 m

Maximum

10Gbps Transfer Rate (Ethernet): 300m

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um fiber optic cable and Ethernet assembly with LC duplex connectors on one end and LC duplex connectors on other end.

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. For details about services and

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

Cable type

50/125 modal bandwidth of 2000 MHz/km as detailed in TIA

distances of up

Maximum distance

10Gbps Transfer Rate (Ethernet): 300m

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um fiber optic cable and Ethernet assembly with LC duplex connectors on one end and LC duplex connectors on other

2.0um Coating diameter: 245 ± 10um

mode OM3 2-Fiber 0.5m 1-Pack Fiber Optic Cable

(AJ833A)

Notes

Services

µm (core/cladding) diameter, mulitimode fiber optic, with effective

• Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

2.0um Coating diameter: 245 ± 10um

• Optical glass: Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

• Optical glass: Bandwidth: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: 600 / 600 meters @850/1300nm for Gigabit Ethernet compliant links.

• CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber and designed to work in both the 850 and 1300 nm wavelength windows.

• BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

• Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

• Jacket Color: Aqua for OM3 multimode per TIA 598

• Boot Color: White

• Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

dB/M added for lengths > 30 meters.

• Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @

1310 nm @ 23°C as tested in accordance with EIA 455-46.

• Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

http://www.hpe.com/networking/services for details on the service-

-492AAAC for

distance:

HPE LC to LC Multimode OM3 2-Fiber 1.0m

Cabling

µm (core/cladding) diameter, mulitimode fiber optic, with effective

1-Pack Fiber Optic Cable (AJ834A)

Notes

• Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

-492AAAC for

to 300 m

end.

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Accessory Product Details

•

Services

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. For details about services and

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

Cable type

50/125 modal bandwidth of 2000 MHz/km as detailed in

distances of up to 300 m;

Maximum distance

10Gbps Transfer Rate (Ethernet): 300m

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um fiber optic cable and Ethernet assembly with LC duplex connectors on one end an

dB/M added for lengths > 30 meters.

Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km @850/1300nm.

• Optical Glass: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for Gigabit Ethernet compliant links.

• CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber. The cable is designed to work in both the 850 and 1300 nm wavelength windows.

• BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

• Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

• Jacket Color: Aqua for OM3 multimode per TIA 598

• Boot Color: White

• Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

dB/M added for lengths > 30 meters.

• Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @

1310 nm @ 23°C as tested in accordance with EIA 455-46.

• Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

http://www.hpe.com/networking/services for details on the service-

HPE LC to LC Multimode OM3 2-Fiber 2.0m

Cabling

µm (core/cladding) diameter, mulitimode fiber optic, with effective

1-Pack Fiber Optic Cable (AJ835A)

Notes

d LC duplex connectors on other end.

• Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

2.0um Coating diameter: 245 ± 10um

• Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

• Optical Glass: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for Gigabit Ethernet compliant links.

• CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber. The cable is designed to work in both the 850 and 1300 nm wavelength windows.

• BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

• Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

• Jacket Color: Aqua for OM3 multimode per TIA 598

• Boot Color: White

• Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

TIA-492AAAC for

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Accessory Product Details

•

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. For details about services and

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE LC to LC Multi-

Cabling

Cable type

50/125 modal bandwidth of 2000 MHz/km as detailed in TIA distances of up to 300 m;

Maximum distance

10Gbps Transfer Rate (Ethernet): 300m

Cable Specs: This specification defines the detail requirements for a tight buffered duplex fiber optic multimode OM3 50/125 um fiber optic cable and Ethernet assembly with LC duplex connectors on one end and LC duplex connectors on other end.

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. For details about services and

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

Cable type

50/125 µ

mode OM3 2-Fiber 5.0m 1-Pack Fiber Optic Cable

(AJ836A)

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310 nm @ 23°C as tested in accordance with EIA 455-46.

• Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

http://www.hpe.com/networking/services for details on the service-

µm core/cladding) diameter, mulitimode fiber optic, with effective

-492AAAC for

Notes

• Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

2.0um Coating diameter: 245 ± 10um

• Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

• Optical Glass: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for Gigabit Ethernet compliant links.

• CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber. The cable is designed to work in both the 850 and 1300 nm wavelength windows.

• BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

• Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

• Jacket Color: Aqua for OM3 multimode per TIA 598

• Boot Color: White

• Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

dB/M added for lengths > 30 meters.

• Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @

1310 nm @ 23°C as tested in accordance with EIA 455-46.

• Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

http://www.hpe.com/networking/services for details on the service-

Cabling

m (core/cladding) diameter, mulitimode fiber optic, with effective

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Accessory Product Details

Pack Fiber Optic

modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances

Maximum distance

10Gbps Transfer Rate (Ethernet): 300m

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um fiber optic cable and Ethernet assembly with LC duplex connectors on one end and LC duplex connectors on

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. For details about services and

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

Cable type

50/125 modal bandwidth of 2000 MHz/km as detailed in TIA distances of up to 300 m;

Maximum distance

10Gbps Transfer Rate (Ethernet): 300m

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um fiber optic cable and Ethernet assembly with LC duplex connectors on one end and LC duplex

@850/1300nm.

HPE LC to LC Multimode OM3 2-Fiber

15.0m 1Cable (AJ837A)

of up to 300 m;

Notes

other end.

• Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

2.0um Coating diameter: 245 ± 10um

• Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

• Optical Glass: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for Gigabit Ethernet compliant links.

• CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber. The cable is designed to work in both the 850 and 1300 nm wavelength windows.

• BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

• Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

• Jacket Color: Aqua for OM3 multimode per TIA 598

• Boot Color: White

• Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

dB/M added for lengths > 30 meters.

• Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @

1310 nm @ 23°C as tested in accordance with EIA 455-46.

• Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

http://www.hpe.com/networking/services for details on the service-

HPE LC to LC Multimode OM3 2-Fiber

Cabling

µm (core/cladding) diameter, mulitimode fiber optic, with effective

30.0m 1-Pack Fiber Optic Cable (AJ838A)

Notes

• Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

2.0um Coating diameter: 245 ± 10um

• Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

-492AAAC for

connectors on other end.

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Accessory Product Details

•

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. For details about services and

response times in your area, please contact your local Hewlett Enterprise sales office.

Cable type

50/125 modal bandwidth of 2000 MHz/km as detailed in

distances of up to 300 m;

Maximum distance

10Gbps Transfer Rate (Ethernet): 300m

Notes

Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um fiber optic cable and Ethernet assembly with LC duplex connectors on one end

1310 nm @ 23°C as tested in accordance with EIA 455-46.

Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm. VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for Gigabit Ethernet compliant links.

• CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber. The cable is designed to work in both the 850 and 1300 nm wavelength windows.

• BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

• Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

• Jacket Color: Aqua for OM3 multimode per TIA 598

• Boot Color: White

• Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

dB/M added for lengths > 30 meters.

• Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @

1310 nm @ 23°C as tested in accordance with EIA 455-46.

• Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

Services

http://www.hpe.com/networking/services for details on the service-

HPE LC to LC Multimode OM3 2-Fiber

Cabling

µm (core/cladding) diameter, mulitimode fiber optic, with effective

50.0m 1-Pack Fiber Optic Cable (AJ839A)

and LC duplex connectors on other end.

• Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ±

2.0um Coating diameter: 245 ± 10um

• Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

• Optical Glass: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for Gigabit Ethernet compliant links.

• CABLE: The cable is duplex zipcord graded index 50/125um

multimode optical fiber. The cable is designed to work in both the 850 and 1300 nm wavelength windows.

• BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

• Jacket Material: Riser Grade - Low Smoke Zero Halogen

thermoplastic.

• Jacket Color: Aqua for OM3 multimode per TIA 598

• Boot Color: White

• Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003

dB/M added for lengths > 30 meters.

• Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @

Packard

TIA-492AAAC for

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Accessory Product Details

•

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. For details about services and

response times in your area, please contact Enterprise sales office.

HPE Premier Flex LC/LC

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um duplex cable and Ethernet assembly with LC duplex on each end.

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. For details about services and

response times in your area, please contact your local Hewlett Pac Enterprise sales office.

HPE Premier Flex LC/LC

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um duplex cable and Ethernet assembly with LC duplex connectors on each end.

0.003dB/m added for lengths >30m

Multi-mode OM4 2 fiber 1m Cable (QK732A)

Services

Notes

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

http://www.hpe.com/networking/services for details on the service-

your local Hewlett Packard

connectors

• Core Diameter: 50um ±3um, Cladding diameter: 125um ±2um;

Coating diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)

thermoplastic

• Boot Color: White

• Outer Jacket Print: HPE PremierFlex OM3+ Fiber Optic Cable,

50/125um, Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source,

0.003dB/m added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @

1310nm @ 23°C as tested in accordance with EIA 455-45

Services

http://www.hpe.com/networking/services for details on the service-

Notes

Multi-mode OM4 2 fiber 2m Cable (QK733A)

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um;

Coating diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)

thermoplastic

• Boot Color: White

• Outer Jacket Print: HPE PremierFlex OM3+ Fiber Optic Cable,

50/125um, Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source,

kard

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Accessory Product Details

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. For details about services and

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um duplex cable and Ethernet assembly with LC duplex connectors on each end.

Refer to the Hewlett Packard Enterprise website at leve

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE Premier Flex LC/LC

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um duplex cable and Ethernet assembly with LC duplex connectors on each end.

0.003dB/m added for lengths >30m

1310nm @ 23°C as tested in accordance with EIA 455-45

Services

http://www.hpe.com/networking/services for details on the service-

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable (QK734A)

Notes

Services

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um;

Coating diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)

thermoplastic

• Boot Color: White

• Outer Jacket Print: HPE PremierFlex OM3+ Fiber Optic Cable,

50/125um, Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source,

0.003dB/m added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @

1310nm @ 23°C as tested in accordance with EIA 455-45

http://www.hpe.com/networking/services for details on the service-

l descriptions and product numbers. For details about services and

Multi-mode OM4 2 fiber 15m Cable (QK735A)

Notes

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um;

Coating diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)

thermoplastic

• Boot Color: White

• Outer Jacket Print: HPE PremierFlex OM3+ Fiber Optic Cable,

50/125um, Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source,

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Accessory Product Details

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. For details about services and

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE Premier Flex LC/LC

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um duplex cable and Ethernet assembly with LC duplex connectors on each end.

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. Fo

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE Premier Flex LC/LC

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um duplex cable and Ethernet assembly with LC duplex connectors on each end.

0.003dB/m added for lengths >30m

Multi-mode OM4 2 fiber 30m Cable (QK736A)

Services

Notes

1310nm @ 23°C as tested in accordance with EIA 455-45

http://www.hpe.com/networking/services for details on the service-

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um;

Coating diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)

thermoplastic

• Boot Color: White

• Outer Jacket Print: HPE PremierFlex OM3+ Fiber Optic Cable,

50/125um, Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source,

0.003dB/m added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @

1310nm @ 23°C as tested in accordance with EIA 455-45

Services

Multi-mode OM4 2 fiber 50m Cable (QK737A)

Notes

http://www.hpe.com/networking/services for details on the service-

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um;

Coating diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH)

thermoplastic

• Boot Color: White

• Outer Jacket Print: HPE PremierFlex OM3+ Fiber Optic Cable,

50/125um, Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source,

r details about services and

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Accessory Product Details

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. For details about services and

response times in your area, Enterprise sales office.

8 redundant power supply ports Restrictions: two -56V/25A DC(PoE); six -56V/8A DC(non-PoE)

15.63(d) x 17.32(w) x 1.74(h) in. (39.7 x 44 x 4.42 cm)

Weight

14.11 lb. (6.4 kg)

weight

16.75 lb. (7.6 kg) 14°F to 122°F (-10°C to 50°C)

humidity

5% to 95%

-40°F to 158°F (-40°C to 70°C)

relative humidity

5% to 95%

Altitude

up to 13,123 ft. (4 km)

Acoustic

Pressure: 53 dB; ISO 7779, ISO 9296

Voltage

100-120/200-240 VAC

Current

30/60 A

Idle power

38 W

3550 W

RPS power

3200 W

PoE power

2800 W

RPS

-55 V

Frequency

50/60 Hz

Idle power is the actual power consumption of

equipped), 100% traffic, all ports plugged in, and

Supplies, the output power is 3200W.

1310nm @ 23°C as tested in accordance with EIA 455-45

Services

http://www.hpe.com/networking/services for details on the service-

please contact your local Hewlett Packard

HPE RPS1600 Redundant Power System (JG136A)

Ports

Physical characteristics Dimensions

Full configuration

Environment

Operating temperature

Operating relative

Nonoperating/Storage temperature

Nonoperating/Storage

Electrical characteristics

Maximum power rating

PoE

Notes

the device with no ports connected. Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if

all modules populated. With one RPS1600 Power Supply, the PRS1600 Redundant Power System can provide 1600W power output; With two PRS1600 Power

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Accessory Product Details

CE Labeled; UL 60950-1; IEC 60950-1; ICES-003; FCC Part 15, Subpart B; EU

EN 300386

Refer to the Hewlett Packard Enterprise website

Enterprise sales office.

Physical

8.19(d) x 4.96(w) x 1.63(h) in. (20.8 x 12.6 x 4.15 cm)

3.02 lb. (1.37 kg)

Environment

Operating temperature

14°F to 122°F (-10°C to 50°C)

humidity

5% to 95%

temperature

-40°F to 158°F (-40°C to 70°C)

relative humidity

5% to 95%

Electrical characteristics

100-120/200-240 VAC

Current

15/30 A

Maximum power rating

1600 W

Frequency

50/60 Hz

Maximum power rating and maximum heat

equipped), 100% traffic, all ports plugged in, and all modules populated.

Services

Refer to the Hewlett Packard Enterprise website

Enterprise sales office.

HPE X125 1G SFP LC LH40 1310nm Transceiver

A small form pluggable SFP Gigabit LH40 transceiver that provides a full duplex Gigabit solution up to 40km on a single fiber.

Ports

1 LC 1000Base-LH port (no IEEE standard exists for 1550 nm optics)

Connectivity

Connector type

Wavelength

1310 nm

Physical characteristics

Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm) Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption typical

0.8 W

Power consumption maximum

1.0 W

Cabling

Cable type: Single

Safety

RoHS Compliant; EN 60950-1/A11; C-Tick; VCCI Class A; ROHS Compliance;

Services

HPE RPS1600 1600W AC Power Supply

(JG137A)

characteristics Dimensions

Weight

Operating relative

Nonoperating/Storage

Voltage

Notes

dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if

(JD061A)

-factor

-mode

-mode fiber optic, complying with ITU-T G.652;

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Accessory Product Details

Maximum distance:

Fiber type

Single Mode

Services

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. For details about services and

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

HPE X120 1G SFP LC LH40 1550nm Transceiver

A s pluggable (SFP) Gigabit LH40 transceiver that provides a full Gigabit solution up to 40 km on a single mode fiber.

Ports

1 LC 1000BASE-LH port (no IEEE standard exists for 1550 nm optics)

Connectivity

Connector type

Wavelength

1550 nm

Physical characteristics

Dimensions

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

Full configuration weight

0.04 lb. (0.02 kg)

Electrical characteristics

Power consumption typical

0.8 W

Power consumption maximum

1.0 W

Cabling

Cable type: Single

Maximum distance:

Fiber type

Single Mode

Services

Refer to the Hewlett Packard Enterprise website at level descriptions and product numbers. For details about services and

response times in your area, please contact your local Hewlett Packard Enterprise sales office.

Ports

1 LC 1000BASE-LH port (no IEEE standard exists for 1550 nm optics)

Connector type

Wavelength

1550 nm

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

Full configuration weight

0.04 lb. (0.02 kg)

0.8 W

Power consumption maximum

1.0 W

Cable type:

• 40km distance

http://www.hpe.com/networking/services for details on the service-

(JD062A)

mall form-factor

-duplex

-mode fiber optic, complying with ITU-T G.652;

• 40km distance

http://www.hpe.com/networking/services for details on the service-

HPE X125 1G SFP LC LH70 Transceiver

(JD063B)

A small form-factor pluggable (SFP) Gigabit LH70 transceiver that provides a full-duplex Gigabit solution up to 70km on a single-mode fiber.

Connectivity

Physical characteristics Dimensions

Electrical characteristics Power consumption

typical

Cabling

Single-mode fiber optic, complying with ITU-T G.652;

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Accessory Product Details

Maximum distance:

Fiber type

Single Mode

Refer to the Hewlett Packard Enterprise website

Enterprise sales office.

Ports

1 RJ-45 1000BASE-T port (IEEE 802.3ab Type 1000BASE-T)

Connectivity

Connector type

RJ-45

2.71(d) x 0.54(w) x 0.55(h) in. (6.88 x 1.37 x 1.4 cm)

Full configuration weight

0.07 lb. (0.03 kg)

Power consumption typical

0.8 W

Power consumption maximum

1.0 W

Cable type:

Refer to the Hewlett Packard Enterprise website

contact your local Hewlett Packard Enterprise sales office.

• 70km

Services

HPE X120 1G SFP RJ45 T Transceiver

(JD089B)

A small form factor pluggable (SFP) Gigabit 1000Base-T transceiver that provides a full duplex Gigabit solution up to 100m on a Cat5+ cable.

Physical characteristics

Electrical characteristics

Cabling

Services

Dimensions

1000BASE-T: Category 5 (5E or better recommended), 100 Ù differential 4-pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced, complying with IEEE 802.3ab 1000BASE-T;

Maximum distance:

• 100m

at http://www.hpe.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Summary of Changes

Date

Version History

Action

Description of Change:

01-Aug-2016

From Version 18 to 19

Changed

Adding #AC3 Option on the Configuration section

27-May-2016

From Version 17 to 18

Changed

Document name changed to HPE FlexNetwork 3100 EI

descriptions updated.

01-Dec-2015

From Version 16 to 17

Changed

Overview and Technical Specifications updated

21-Aug-2015

From Version 15 to 16

Changed

Configuration menu updated

29-May-2015

From Version 14 to 15

Changed

Configuration menu updated

20-Apr-2015

From Version 13 to 14

Added

Added Configuration section

Changed

Updated Features and benefits, Technical Specifications

Updated model JG315A to JG315B

01-Dec-2014

From Version 12 to 13

Changed

Warranty and support updated

10-Jun-2013

From Version 10 to 11

Added

OM4 cables were added.

25-Oct-2012

From Version 9 to 10

Removed

Removed the information for two models.

18-Oct-2012

From Version 8 to 9

Changed

Updated Features and Benefits and also added the Mac address table size to the specifications for several models.

30-Jul-2012

From Version 7 to 8

Changed

Minor updates were made to the specifications for each

Accessories.

22-Jun-2012

From Version 6 to 7

Changed

Updated the models JD313B, Introduction, Features and

for JD313B).

04-Apr-2012

From Version 5 to 6

Changed

Updated the ports for JG315A.

26-Mar-2012

From Version 4 to 5

Changed

The document was revised throughout, including adding some new models.

07-Nov-2011

From Version 3 to 4

Changed

The product name was updated throughout the document.

28-Sep-2011

From Version 2 to 3

Added

Accessory Product Details was added.

16-Mar-2011

From Version 1 to 2

Changed

Specifications were revised.

© Copyright 2016 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such pro Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

To learn more, visit:

Microsoft is a U.S. registered trademark of Microsoft Corporation.

c04111573

Switch Series. Technical Specifications, Overview and product

and Accessories

model, the list of models supported in the series and

Benefits, Specifications (for JD313B) and Accessories (also

http://www.hpe.com/networking

- 13848 - Worldwide - V19 - 1-August-2016

ducts and services.

Page

QuickSpecs

HPE FlexNetwork 3100 EI Switch Series

Summary of Changes

Page

HP FlexNetwork 3100 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Configuration

Technical Specifications

Accessories

Accessory Product Details

Summary of Changes
