QuickSpecs

HP 3600 SI Switch Series

Overview

Models

HP 3600-24 v2 SI Switch HP 3600-48 v2 SI Switch HP 3600-24-PoE+ v2 SI Switch HP 3600-48-PoE+ v2 SI Switch

JG304A JG305A JG306B JG307B

Key features

Robust switching at the enterprise network edge Static and RIP Layer 3 routing Automatic stacking with IRF Integrated and distributed security enforcement Enterprise-level nonblocking performance

Product overview

The HP 3600 SI Switch Series delivers intelligent, resilient performance, security, and reliability for robust switching at the enterprise network edge. The series consists of Fast Ethernet and PoE/PoE+ switches, with features that can accommodate large enterprise and SMB applications. Secure, resilient connectivity, as well as the latest traffic-prioritization technologies, enhance converged networks. The switches are designed for improved flexibility and scalability.

Features and benefits

Quality of Service

Broadcast control

allows limitation of broadcast traffic rate to cut down on unwanted network broadcast traffic

Advanced classifier-based QoS

classifies traffic using multiple match criteria based on Layer 2, 3, and 4 information; applies QoS policies such as setting priority level and rate limit to selected traffic on a per-port or per-VLAN basis

Powerful QoS feature

supports the following congestion actions: strict priority (SP) queuing, weighted round robin (WRR), weighted fair queuing (WFQ), and WRED

Traffic policing

supports Committed Access Rate (CAR) and line rate

Management

Friendly port names

allows assignment of descriptive names to ports

Remote configuration and management

enables configuration and management through a secure Web browser or a CLI located on a remote device

Manager and operator privilege levels

provides read-only (operator) and read/write (manager) access on CLI and Web browser management interfaces

Command authorization

leverages HWTACACS to link a custom list of CLI commands to an individual network administrator's login; also provides an audit trail

(QoS)

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 1

QuickSpecs

HP 3600 SI Switch Series

Overview

Secure Web GUI

provides a secure, easy-to-use graphical interface for configuring the module via HTTPS

Multiple configuration files

stores easily to the flash image

Complete session logging

provides detailed information for problem identification and resolution

SNMPv1, v2c, and v3

facilitate centralized discovery, monitoring, and secure management of networking devices

Remote monitoring (RMON)

uses standard SNMP to monitor essential network functions; supports events, alarm, history, and statistics group plus a private alarm extension group

Local and remote intelligent mirroring

mirrors traffic from a switch port to a remote switch port anywhere on the network, or mirror ACL-selected traffic to a local switch port

Management VLAN

segments traffic to and from management interfaces, including CLI/telnet, a Web browser interface, and SNMP

IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

advertises and receives management information from adjacent devices on a network, facilitating easy mapping by network management applications

Device Link Detection Protocol (DLDP)

monitors a cable between two switches and shuts down the ports on both ends if the cable is broken, preventing network problems such as loops

sFlow (RFC 3176)

provides scalable ASIC-based wirespeed network monitoring and accounting with no impact on network performance; this allows network operators to gather a variety of sophisticated network statistics and information for capacity planning and realtime network monitoring purposes

IPv6 management

future-proofs networking, as the switch is capable of being managed whether the attached network is running IPv4 or IPv6; supports pingv6, tracertv6, Telnetv6, TFTPv6, DNSv6, syslogv6, FTPv6, SNMPv6, DHCPv6, and RADIUS for IPv6

Troubleshooting

ingress and egress port monitoring enable network problem solving; virtual cable tests provide visibility into cable problems

Connectivity

IPv6

Telnet

for allowing CLI access via IPv6

SNMP

for IPv6 switch management

DNS

for IPv6 host management

DHCP

for auto IPv6 address configuration of a switch

Auto-MDIX

provides automatic adjustments for straight-through or crossover cables on all 10/100 and 10/100/1000 ports

Jumbo packet support

supports up to 9216-byte frame size to improve the performance of large data transfers

Gigabit Ethernet uplinks

are dual-personality ports for either 10/100/1000 or mini-GBIC SFP connectivity for increased connectivity flexibility

High-density access

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 2

QuickSpecs

HP 3600 SI Switch Series

Overview

provides up to 48 fixed 10/100BASE-T PoE or non-PoE ports in a Layer 2 or Layer 3 switch

Ethernet operations, administration and maintenance (OAM)

detects data link layer problems that occurred in the "last mile" using the IEEE 802.3ah OAM standard; monitors the status of the link between two devices

IEEE 802.3af Power over Ethernet (PoE)

provides up to 15.4 W per port to IEEE 802.3af-compliant PoE-powered devices such as IP phones, wireless access points, and security cameras

IEEE 802.3at Power over Ethernet (PoE+)

provides up to 30 W per port that allows support of the latest PoE+-capable devices such as IP phones, wireless access points, and security cameras, as well as any IEEE 802.3af-compliant end device; eliminates the cost of additional electrical cabling and circuits that would otherwise be necessary in IP phone and WLAN deployments

Performance

Nonblocking performance

up to 17.6 Gbps nonblocking switching fabric provides wire-speed switching with up to 13.1 million pps throughput

Gigabit Ethernet interface

provides a connection to the network that eliminates the network as a bottleneck

Hardware-based wirespeed access control lists

feature-rich ACL implementation helps ensure high levels of security and ease of administration without impacting network performance

Resiliency and high availability

Separate data and control paths

separates control from services and keeps service processing isolated; increases security and performance

External redundant power supply

provides high reliability

Smart link

allows 50 ms failover between links

Spanning Tree/MSTP, RSTP

provides redundant links while preventing network loops

Intelligent Resilient Framework (IRF)

creates virtual resilient switching fabrics, where two or more switches perform as a single L2 switch and L3 router; switches do not have to be co-located and can be part of a disaster-recovery system; servers or switches can be attached using standard LACP for automatic load balancing and high availability; can eliminate the need for complex protocols like Spanning Tree Protocol, Equal-Cost Multipath (ECMP), or VRRP, thereby simplifying network operation

IEEE 802.3ad Link Aggregation Control Protocol (LACP)

supports up to 26 trunks, each with 8 links per trunk; supports static or dynamic groups

Virtual Router Redundancy Protocol (VRRP)

allows groups of two routers to dynamically back each other up to create highly available routed environments in IPv4 and IPv6 networks

IRF capability

provides single IP address management for a resilient virtual switching fabric of up to nine switches

Ring Resiliency Protection Protocol (RRPP)

provides standard sub 50 ms recovery for ring Ethernet-based topology

Manageability

RMON (remote monitoring)

provides advanced monitoring and reporting capabilities for statistics, history, alarms, and events

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 3

QuickSpecs

HP 3600 SI Switch Series

Overview

Layer 2 switching

16/32K MAC address table

provides access to many Layer 2 devices

VLAN support and tagging

supports IEEE 802.1Q with 4,094 simultaneous VLAN IDs

GARP VLAN Registration Protocol

allows automatic learning and dynamic assignment of VLANs

IEEE 802.1ad QinQ and selective QinQ

increase the scalability of an Ethernet network by providing a hierarchical structure; connect multiple LANs on a high-speed campus or metro network

Gigabit Ethernet port aggregation

allows grouping of ports to increase overall data throughput to a remote device

Internet Group Management Protocol (IGMP) and Multicast

Listener Discovery (MLD) protocol snooping controls and manages the flooding of multicast packets in a Layer 2 network

Layer 3 services

Address Resolution Protocol (ARP)

determines the MAC address of another IP host in the same subnet

Dynamic Host Configuration Protocol (DHCP)

simplifies the management of large IP networks and supports client and server; DHCP Relay enables DHCP operation across subnets

Loopback interface address

defines an address in Routing Information Protocol (RIP) and Open Standard Path First (OSPF), improving diagnostic capability

User Datagram Protocol (UDP) helper function

allows UDP broadcasts to be directed across router interfaces to specific IP unicast or subnet broadcast addresses and prevents server spoofing for UDP services such as DHCP

Route maps

provide more control during route redistribution; allow filtering and altering of route metrics

Layer 3 routing

IPv4 routing protocols

support static routes and RIP

IPv6 routing protocols

provide routing of IPv6 at wire speed; support static routes and RIPng

IPv6 tunneling

allows a smooth transition from IPv4 to IPv6 by encapsulating IPv6 traffic over an existing IPv4 infrastructure

Equal-Cost Multipath (ECMP)

enables multiple equal-cost links in a routing environment to increase link redundancy and scale bandwidth

Bidirectional Forwarding Detection (BFD)

enables link connectivity monitoring and reduces network convergence time for VRRP, static routing, and IRF

Security

Access control lists (ACLs)

provides IP Layer 2 to Layer 4 traffic filtering; supports VLAN ACL and port ACL

Multiple user authentication methods

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 4

QuickSpecs

HP 3600 SI Switch Series

Overview

IEEE 802.1X

uses an IEEE 802.1X supplicant on the client in conjunction with a RADIUS server to authenticate in accordance with industry standards

Web-based authentication

provides a browser-based environment, similar to IEEE 802.1X, to authenticate clients that do not support the IEEE

802.1X supplicant

MAC-based authentication

authenticates the client with the RADIUS server based on the client's MAC address

Identity-driven security and access control

Per-user ACLs

permits or denies user access to specific network resources based on user identity and time of day, allowing multiple types of users on the same network to access specific network services without risking network security or allowing unauthorized access to sensitive data

Automatic VLAN assignment

automatically assigns users to the appropriate VLAN based on their identities

Secure management access

delivers secure encryption of all access methods (CLI, GUI, or MIB) through SSHv2, SSL, and/or SNMPv3

Secure FTP

allows secure file transfer to and from the switch; protects against unwanted file downloads or unauthorized copying of a switch configuration file

Guest VLAN

provides a browser-based environment to authenticated clients that is similar to IEEE 802.1X

Endpoint Admission Defense (EAD)

provides security policies to users accessing a network

Port security

allows access only to specified MAC addresses, which can be learned or specified by the administrator

Port isolation

secures and adds privacy, and prevents malicious attackers from obtaining user information

STP BPDU port protection

blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged BPDU attacks

STP root guard

protects the root bridge from malicious attacks or configuration mistakes

DHCP protection

blocks DHCP packets from unauthorized DHCP servers, preventing denial-of-service attacks

Dynamic ARP protection

blocks ARP broadcasts from unauthorized hosts, preventing eavesdropping or theft of network data

IP Source Guard

filters packets on a per-port basis, which prevents illegal packets from being forwarded

RADIUS/HWTACACS

eases switch management security administration by using a password authentication server

Multiple Customer Edge (MCE)

facilitates MPLS VPN network integration with support for up to 63 VPNs

Convergence

IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

facilitates easy mapping using network management applications with LLDP automated device discovery protocol

LLDP-MED

is a standard extension that automatically configures network devices, including LLDP-capable IP phones

LLDP-CDP compatibility

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 5

QuickSpecs

HP 3600 SI Switch Series

Overview

receives and recognizes CDP packets from Cisco's IP phones for seamless interoperation

PoE allocations

supports multiple methods (automatic, IEEE 802.3af class, LLDP-MED, or user-specified) to allocate PoE power for more efficient energy savings

Voice VLAN

automatically assigns VLAN and priority for IP phones, simplifying network configuration and maintenance

IP multicast snooping and data-driven IGMP

automatically prevent flooding of IP multicast traffic

Multicast VLAN

allows multiple VLANs to receive the same multicast traffic, reducing network bandwidth demand by eliminating multiple streams to each VLAN

Device support

Cisco prestandard PoE support

detects and provides power to Cisco's prestandard PoE devices such as wireless LAN access points and IP phones

Additional information

Green initiative support

provides support for RoHS and WEEE regulations

Green IT and power

uses the latest advances in silicon development and shuts off unused ports to improve power efficiency

Warranty and support

NEW Lifetime Warranty 2.0

advance hardware replacement for as long as you own the product with next-business-day delivery (available in most countries)†

NEW Electronic and telephone support

limited 24x7 telephone support is available from HP for the first 3 years; limited electronic and business hours telephone support is available from HP for the entire warranty period; to reach our support centers, refer to

www.hp.com/networking/contact-support

www.hp.com/networking/warrantysummary

Software releases

to find software for your product, refer to with your product purchase, refer to

* HP warranty includes repair or replacement of hardware for as long as you own the product, with next business day advance replacement (available in most countries). The disk drive included with HP AllianceOne Advanced Services and Services zl Modules, HP Threat Management Services zl Module, HP AllianceOne Extended zl Module with Riverbed Steelhead, HP MSM765zl Mobility Controller and HP Survivable Branch Communication zl Module powered by Microsoft Lync has a five-year hardware warranty. For details, refer to the Software license and hardware warranty statements at www.hp.com/networking/warranty.

(for Lifetime Warranty 2.0)

; for details on the duration of support provided with your product purchase, refer

www.hp.com/networking/support

www.hp.com/networking/warrantysummary

; for details on the software releases available

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 6

QuickSpecs

HP 3600 SI Switch Series

Configuration

Build To Order:

BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.

HP 3600-24-PoE+ v2 SI Switch

24 RJ-45 autosensing 10/100 PoE ports 4 SFP 1000 Mbps ports min=0 \ max=4 SFP Transceivers 1U - Height

HP 3600-24-PoE+ v2 SI Switch

24 RJ-45 autosensing 10/100 PoE ports 4 SFP 1000 Mbps ports min=0 \ max=4 SFP Transceivers 1U - Height

PDU Cable NA/MEX/TW/JP

C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

C15 PDU Jumper Cord (ROW)

High Volt Switch/Router to Wall Power Cord

NEMA L6-20P Cord (NA/MEX/JP/TW)

HP 3600-24 v2 SI Switch

24 RJ-45 autosensing 10/100 ports 2 dual-personality 10/100/1000 ports/ SFP 1000 Mbps ports 4 SFP 1000 Mbps ports min=0 \ max=6 SFP Transceivers 1U - Height

HP 3600-48 v2 SI Switch

48 RJ-45 autosensing 10/100 ports 2 dual-personality 10/100/1000 ports/ SFP 1000 Mbps ports 4 SFP 1000 Mbps ports min=0 \ max=6 SFP Transceivers 1U - Height

HP 3600-48-PoE+ v2 SI Switch

48 RJ-45 autosensing 10/100 ports 2 dual-personality 10/100/1000 ports/ SFP 1000 Mbps ports 4 SFP 1000 Mbps ports min=0 \ max=6 SFP Transceivers 1U - Height

HP 3600-48-PoE+ v2 SI Switch

JG306A

See

Configuration

Note:1, 2

JG306A

See Configuration Note:1, 4, 5, 6

JG306B#B2B

JG306B#B2C

JG306B#B2E

JG304A

See Configuration

Note:1, 2

JG305A

See Configuration

Note:1, 2

JG307A

See Configuration

Note:1, 2

JG307B

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 7

QuickSpecs

Configuration

HP 3600 SI Switch Series

48 RJ-45 autosensing 10/100 ports 2 dual-personality 10/100/1000 ports/ SFP 1000 Mbps ports 4 SFP 1000 Mbps ports min=0 \ max=6 SFP Transceivers 1U - Height

PDU Cable NA/MEX/TW/JP

C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

C15 PDU Jumper Cord (ROW)

High Volt Switch/Router to Wall Power Cord

NEMA L6-20P Cord (NA/MEX/JP/TW)

Configuration Rules:

Note 1

Note 2

Note 4

Note 5

Note 6

The following Transceivers install into this switch: (SFP 1000 Mbps ports only) HP X125 1G SFP LC SX Transceiver HP X120 1G SFP LC LX Transceiver HP X125 1G SFP LC LH70 Transceiver HP X125 1G SFP RJ45 T Transceiver HP X120 1G SFP LC BX 10-D Transceiver HP X120 1G SFP LC BX 10-D Transceiver HP X124 1G SFP LC LH40 1310nm Transceiver HP X120 1G SFP LC LH40 1550nm Transceiver HP X170 1G SFP LC LH70 1550 Transceiver HP X170 1G SFP LC LH70 1570 Transceiver HP X170 1G SFP LC LH70 1590 Transceiver HP X170 1G SFP LC LH70 1610 Transceiver HP X170 1G SFP LC LH70 1470 Transceiver HP X170 1G SFP LC LH70 1490 Transceiver HP X170 1G SFP LC LH70 1510 Transceiver HP X170 1G SFP LC LH70 1530 Transceiver

Localization required. (See Localization Menu for list.)

When Switches are Not Factory Racked, Then Switch to Wall Power Cord should be the Defaulted Power Cable option on the Switches.

Localization (Wall Power Cord) required on orders without #B2B, #B2C (PDU Power Cord) or #B2E. (See Localization Menu)

#B2E is Offered only in NA, Mexico, Taiwan and Japan.

See Configuration Note:1, 4, 5, 6

JG307B#B2B

JG307B#B2C

JG307B#B2E

JD118B JD119B JD063B JD089B JD098B JD099B JD061A JD062A JD109A JD110A JD111A JD112A JD113A JD114A JD115A JD116A

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 8

QuickSpecs

Configuration

HP 3600 SI Switch Series

Remarks

Drop down under power supply should offer the following options and results: Switch/Router/Power Supply to PDU Power Cord - #B2B in North America, Mexico, Taiwan, and Japan or #B2C ROW. (Watson Default B2B or B2C for Rack Level CTO) Switch/Router/Power Supply to Wall Power Cord - Localized Option (Watson Default for BTO and Box Level CTO) High Volt Switch/Router/Power Supply to Wall Power Cord - #B2E Option. (Offered only in North America, Mexico, Taiwan, and Japan)

Rack Level Integration CTO Models

Switch Chassis

HP 3600-24-PoE+ v2 SI Switch

24 RJ-45 autosensing 10/100 PoE ports 4 SFP 1000 Mbps ports min=0 \ max=4 SFP Transceivers 1U - Height

PDU Cable NA/MEX/TW/JP

C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

C15 PDU Jumper Cord (ROW)

HP 3600-48-PoE+ v2 SI Switch

48 RJ-45 autosensing 10/100 ports 2 dual-personality 10/100/1000 ports/ SFP 1000 Mbps ports 4 SFP 1000 Mbps ports min=0 \ max=4 SFP Transceivers 1U - Height

PDU Cable NA/MEX/TW/JP

C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

C15 PDU Jumper Cord (ROW)

Configuration Rules:

Note 1

JG306B

See Configuration Note:1, 3, 4, 5

JG306B#B2B

JG306B#B2C

JG307B

See Configuration Note:1, 3, 4, 5

JG307B#B2B

JG307B#B2C

JD118B JD119B JD063B JD089B JD098B JD099B JD061A

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 9

QuickSpecs

Configuration

HP 3600 SI Switch Series

HP X120 1G SFP LC LH40 1550nm Transceiver HP X170 1G SFP LC LH70 1550 Transceiver HP X170 1G SFP LC LH70 1570 Transceiver HP X170 1G SFP LC LH70 1590 Transceiver HP X170 1G SFP LC LH70 1610 Transceiver HP X170 1G SFP LC LH70 1470 Transceiver HP X170 1G SFP LC LH70 1490 Transceiver HP X170 1G SFP LC LH70 1510 Transceiver HP X170 1G SFP LC LH70 1530 Transceiver

Note 3

Note 4

Note 5

Remarks

When Switches are Factory Racked, Then #B2B, or #B2C should be the Defaulted Power Cable option on the Switches.

Localization (Wall Power Cord) required on orders without #B2B, #B2C (PDU Power Cord). (See Localization Menu)

If the CTO Switch Chassis needs to be racked, Then the CTO Base Model needs to integrate (with #0D1) to the HP Network Rack.

Transceivers

SFP Transceivers

HP X120 1G SFP LC BX 10-U Transceiver HP X120 1G SFP LC BX 10-D Transceiver HP X120 1G SFP LC SX Transceiver HP X120 1G SFP LC LX Transceiver HP X125 1G SFP LC LH40 1310nm XCVR HP X120 1G SFP LC LH40 1550nm XCVR HP X125 1G SFP LC LH70 Transceiver HP X120 1G SFP RJ45 T Transceiver HP X170 1G SFP LC LH70 1550 Transceiver HP X170 1G SFP LC LH70 1570 Transceiver HP X170 1G SFP LC LH70 1590 Transceiver HP X170 1G SFP LC LH70 1610 Transceiver HP X170 1G SFP LC LH70 1470 Transceiver HP X170 1G SFP LC LH70 1490 Transceiver HP X170 1G SFP LC LH70 1510 Transceiver HP X170 1G SFP LC LH70 1530 Transceiver

Internal Power Supplies

JD062A JD109A JD110A JD111A JD112A JD113A JD114A JD115A JD116A

JD098B JD099B JD118B JD119B

JD061A

JD062A JD063B JD089B

JD109A

JD110A

JD111A

JD112A

JD113A

JD114A

JD115A

JD116A

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 10

QuickSpecs

HP 3600 SI Switch Series

Configuration

Power Supplies included

Switch Enclosure Options

Stacking Cable kit

HP 3600 Switch SFP Stacking Kit

External Redundant Power Supplies

HP RPS 800 Redundant Power Supply

Height = 1U includes 1 x c13, 800w

HP RPS1600 Redundant Power System

Height = 1U includes 1 x c13, 1600w and Power Supply port

HP RPS1600 1600W AC Power Supply

Installs into JG136A only

Configuration Rules:

Note 1

Note 2

External Redundant Power Cables

HP X290 1000 A JD5 2m RPS Cable

If this power supply is selected, The JG136A - HP A-RPS1600 Redundant Power System must be on order or onsite.

Localization required.

JD324B

JD183A

Configuration

Note:2

JG136A

Configuration

Note:2

JG137A

Configuration

Note:1

JD187A

See

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 11

QuickSpecs

Technical Specifications

HP 3600 SI Switch Series

HP 3600-24 v2 SI Switch

Ports

Physical characteristics

Memory and processor

Mounting

Performance

Environment

Electrical characteristics

Safety

Emissions

Management

Services

(JG304A)

24 RJ-45 autosensing 10/100 ports; Media Type: Auto-MDIX; Duplex: half or full (IEEE

802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX) 4 SFP 1000 Mbps ports 2 dual-personality 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

100BASE-TX, IEEE 802.3ab Type 1000BASE-T) 1 RJ-45 serial console port

Dimensions

Weight

256 MB SDRAM, 128 MB flash; packet buffer size: 2 MB Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)

100 Mb Latency

1000 Mb Latency

Throughput

Routing/Switching capacity

Routing table size

Operating temperature

Operating relative humidity

Nonoperating/Storage temperature

Nonoperating/Storage relative humidity

Acoustic

Frequency

Maximum heat dissipation

AC Voltage

Maximum power rating

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60950-1/A11; FDA 21 CFR Subchapter J; ROHS Compliance

FCC part 15 Class A; VCCI Class A; EN 55022 Class A; CISPR 22 Class A; ICES-003 Class A; ANSI C63.4 2003; ETSI EN 300 386 V1.3.3; AS/NZS CISPR22 Class A; EN 61000-3-2; EN 61000-3-3; EN 61000-4-2; EN 610004-3; EN 61000-4-4; EN 61000-4-5; EN 61000-4-6; EN 61000-4-11; EN 61000-3-2:2006; EN 61000-33:1995 +A1:2001+A2:2005; EMC Directive 2004/108/EC; FCC (CFR 47, Part 15) Class A

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager 3-year, 4-hour onsite, 13x5 coverage for hardware (UV822E)

17.32(w) x 10.24(d) x 1.72(h) in (43.99 x 26.01 x 4.37 cm) (1U height)

11.02 lb (5 kg)

< 6 µs < 5 µs

9.5 million pps

12.8 Gb/s

2048 entries (IPv4) 32°F to 122°F (0°C to 50°C) 5% to 95%, noncondensing

-40°F to 158°F (-40°C to 70°C)

5% to 95%, noncondensing

Low-speed fan: 39.5 dB, High-speed fan: 48.4 dB 50/60 Hz 89 BTU/hr (93.9 kJ/hr)

100-240 VAC 26 W

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 12

QuickSpecs

Technical Specifications

1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR590E) 1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (HR591E) 4-year, 4-hour onsite, 13x5 coverage for hardware (UV823E) 4-year, 4-hour onsite, 24x7 coverage for hardware UV826E) 4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UV829E) 4-year, 24x7 SW phone support, software updates (UV832E) 5-year, 4-hour onsite, 13x5 coverage for hardware (UV824E) 5-year, 4-hour onsite, 24x7 coverage for hardware (UV827E) 5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UV830E) 5-year, 24x7 SW phone support, software updates (UV833E) 3 Yr 6 hr Call-to-Repair Onsite (UW431E) 4 Yr 6 hr Call-to-Repair Onsite (UW432E) 5 Yr 6 hr Call-to-Repair Onsite (UW433E) 1-year, 6 hour Call-To-Repair Onsite for hardware (HR593E) 1-year, 24x7 software phone support, software updates (HR592E) 1-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange (HS690E) 1-year, 24x7 software phone support, software updates + 4 hour hardware exchange (HS691E) 3-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange (HS692E) 3-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS693E) 4-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange (HS694E) 4-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS695E) 5-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange (HS696E) 5-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS697E)

HP 3600 SI Switch Series

HP 3600-48 v2 SI Switch

Ports

Physical characteristics

Memory and processor

Mounting

Performance

Refer to the HP website at: descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

(JG305A)

48 RJ-45 autosensing 10/100 ports; Media Type: Auto-MDIX; Duplex: half or full (IEEE

802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX) 4 SFP 1000 Mbps ports 2 dual-personality 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

100BASE-TX, IEEE 802.3ab Type 1000BASE-T) 1 RJ-45 serial console port

Dimensions

Weight

256 MB SDRAM, 128 MB flash; packet buffer size: 4 MB Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)

100 Mb Latency

1000 Mb Latency

Throughput

www.hp.com/networking/services

17.32(w) x 10.24(d) x 1.72(h) in (43.99 x 26.01 x 4.37 cm) (1U height)

8.82 lb (4 kg)

< 6 µs < 5 µs

13.1 million pps (64-byte packets)

for details on the service-level

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 13

QuickSpecs

Technical Specifications

HP 3600 SI Switch Series

Environment

Electrical characteristics

Safety

Emissions

Management

Services

Routing/Switching capacity

Routing table size

Operating temperature

Operating relative humidity

Nonoperating/Storage temperature

Nonoperating/Storage relative humidity

Acoustic

Frequency

Maximum heat dissipation

AC Voltage

Maximum power rating

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60950-1/A11; FDA 21 CFR Subchapter J; ROHS Compliance

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager 3-year, 4-hour onsite, 13x5 coverage for hardware (UV822E)

3-year, 4-hour onsite, 24x7 coverage for hardware (UV825E) 3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 SW phone support and SW updates (UV828E) 3-year, 24x7 SW phone support, software updates (UV831E) 1-year, post-warranty, 4-hour onsite, 13x5 coverage for hardware (HR589E) 1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware (HR590E) 1-year, post-warranty, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (HR591E) 4-year, 4-hour onsite, 13x5 coverage for hardware (UV823E) 4-year, 4-hour onsite, 24x7 coverage for hardware UV826E) 4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UV829E) 4-year, 24x7 SW phone support, software updates (UV832E) 5-year, 4-hour onsite, 13x5 coverage for hardware (UV824E) 5-year, 4-hour onsite, 24x7 coverage for hardware (UV827E) 5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UV830E) 5-year, 24x7 SW phone support, software updates (UV833E) 3 Yr 6 hr Call-to-Repair Onsite (UW431E) 4 Yr 6 hr Call-to-Repair Onsite (UW432E) 5 Yr 6 hr Call-to-Repair Onsite (UW433E) 1-year, 6 hour Call-To-Repair Onsite for hardware (HR593E) 1-year, 24x7 software phone support, software updates (HR592E) 1-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange (HS690E)

17.6 Gb/s

2048 entries (IPv4) 32°F to 122°F (0°C to 50°C) 5% to 95%, noncondensing

-40°F to 158°F (-40°C to 70°C)

5% to 95%, noncondensing

Low-speed fan: 43.2 dB, High-speed fan: 50 dB 50/60 Hz 140 BTU/hr (147.7 kJ/hr)

100-240 VAC 41 W

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 14

QuickSpecs

Technical Specifications

1-year, 24x7 software phone support, software updates + 4 hour hardware exchange (HS691E) 3-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange (HS692E) 3-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS693E) 4-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange (HS694E) 4-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS695E) 5-year, 24x7 software phone support, software updates + Next Business Day Hardware Exchange (HS696E) 5-year, 24x7 software phone support, software updates + 4 hour Hardware Exchange (HS697E)

HP 3600 SI Switch Series

Refer to the HP website at: descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

HP 3600-24-PoE+ v2 SI Switch (JG306B)

Ports

Physical characteristics

Memory and processor

Mounting

Performance

Environment

Electrical characteristics

24 RJ-45 autosensing 10/100 PoE+ ports; Media Type: Auto-MDIX; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3at PoE+)

4 SFP 1000 Mbps ports 2 dual-personality 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

100BASE-TX, IEEE 802.3ab Type 1000BASE-T) 1 RJ-45 serial console port

Dimensions

Weight

256 MB SDRAM, 128 MB flash; packet buffer size: 2 MB Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)

100 Mb Latency

1000 Mb Latency

Throughput

Routing/Switching capacity

Routing table size

Operating temperature

Operating relative humidity

Nonoperating/Storage temperature

Nonoperating/Storage relative humidity

Acoustic

Frequency

Maximum heat dissipation

www.hp.com/networking/services

17.32(w) x 16.54(d) x 1.72(h) in (44.0 x 42.0 x 4.36 cm) (1U height)

22.05 lb (10 kg)

< 6 µs < 5 µs

9.5 million pps (64-byte packets)

12.8 Gb/s

2048 entries (IPv4) 32°F to 122°F (0°C to 50°C) 5% to 95%, noncondensing

-40°F to 158°F (-40°C to 70°C)

5% to 95%, noncondensing

Low-speed fan: 44.7 dB, High-speed fan: 53.8 dB 50/60 Hz 143 BTU/hr (150.86 kJ/hr)

for details on the service-level

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 15

QuickSpecs

Technical Specifications

HP 3600 SI Switch Series

AC Voltage

Maximum power rating

PoE power

Safety

Emissions

Management

Services

HP 3600-48-PoE+ v2 SI Switch (JG307B)

Ports

Physical characteristics

Memory and processor

Mounting

Performance

Environment

Electrical characteristics

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60950-1/A11; FDA 21 CFR Subchapter J; ROHS Compliance

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager Refer to the HP website at

descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

48 RJ-45 autosensing 10/100 PoE+ ports; Duplex: half or full (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3at PoE+)

4 SFP 1000 Mbps ports 2 dual-personality 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

100BASE-TX, IEEE 802.3ab Type 1000BASE-T) 1 RJ-45 serial console port

Dimensions

Weight

256 MB SDRAM, 128 MB flash; packet buffer size: 4 MB Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included)

100 Mb Latency

1000 Mb Latency

Throughput

Routing/Switching capacity

Routing table size

Operating temperature

Operating relative humidity

Nonoperating/Storage temperature

Nonoperating/Storage relative humidity

Acoustic

Frequency

Maximum heat dissipation

100-240 VAC 795 W 720 W

www.hp.com/networking/services

17.32(w) x 16.54(d) x 1.72(h) in (43.99 x 42.01 x 4.37 cm) (1U height)

22.05 lb (10 kg)

< 6 µs < 5 µs

13.1 million pps (64-byte packets)

17.6 Gb/s

2048 entries (IPv4) 32°F to 122°F (0°C to 50°C) 5% to 95%, noncondensing

-40°F to 158°F (-40°C to 70°C)

5% to 95%, noncondensing

Low-speed fan: 43.5 dB, High-speed fan: 55 dB 50/60 Hz 198 BTU/hr (208.89 kJ/hr)

for details on the service-level

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 16

QuickSpecs

Technical Specifications

HP 3600 SI Switch Series

Voltage

Maximum power rating

PoE power

Safety

Emissions

Management

Services

Standards and Protocols

(applies to all products in series)

Device management

General protocols

UL 60950-1; EN 60825-1 Safety of Laser Products-Part 1; EN 60825-2 Safety of Laser Products-Part 2; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60950-1/A11; FDA 21 CFR Subchapter J; ROHS Compliance

IMC - Intelligent Management Center; command-line interface; Web browser; SNMP Manager Refer to the HP website at:

descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

RFC 1157 SNMPv1/v2c RFC 1901-1907 SNMPv2c, SMIv2 and Revised MIB-II RFC 2573 (SNMPv3 Applications) RFC 2578-2580 SMIv2 RFC 2819 (RMON groups Alarm, Event, History and Statistics only) RFC 3410 (Management Framework) RFC 3416 (SNMP Protocol Operations v2) RFC 3417 (SNMP Transport Mappings) HTML and telnet management Multiple Configuration Files SNMP v3 and RMON RFC support SSHv1/SSHv2 Secure Shell

IEEE 802.1ad Q-in-Q IEEE 802.1D MAC Bridges IEEE 802.1p Priority IEEE 802.1Q VLANs IEEE 802.1s (MSTP) IEEE 802.1v VLAN classification by Protocol and Port IEEE 802.1w Rapid Reconfiguration of Spanning Tree IEEE 802.1X PAE IEEE 802.3 Type 10BASE-T IEEE 802.3ab 1000BASE-T IEEE 802.3ac (VLAN Tagging Extension) IEEE 802.3ad Link Aggregation Control Protocol (LACP) IEEE 802.3af Power over Ethernet IEEE 802.3at Power over Ethernet Plus IEEE 802.3i 10BASE-T IEEE 802.3u 100BASE-X IEEE 802.3x Flow Control IEEE 802.3z 1000BASE-X RFC 768 UDP RFC 783 TFTP Protocol (revision 2)

100-240 VAC 820 W 720 W

www.hp.com/networking/services

for details on the service-level

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 17

QuickSpecs

Technical Specifications

RFC 791 IP RFC 792 ICMP RFC 793 TCP RFC 826 ARP RFC 1058 RIPv1 RFC 1213 Management Information Base for Network Management of TCP/IP-based internets RFC 1812 IPv4 Routing RFC 2131 DHCP RFC 2236 IGMP Snooping RFC 2338 VRRP RFC 2453 RIPv2 RFC 2644 Directed Broadcast Control RFC 2665 Definitions of Managed Objects for the Ethernet-like Interface Types RFC 2711 IPv6 Router Alert Option RFC 3410 Applicability Statements for SNMP RFC 3414 User-based Security Model (USM) for version 3 of the Simple Network Management Protocol (SNMPv3) RFC 3415 View-based Access Control Model (VACM) for the Simple Network Management Protocol (SNMP) RFC 3416 Protocol Operations for SNMP RFC 3417 Transport Mappings for the Simple Network Management Protocol (SNMP) RFC 4594 Configuration Guidelines for DiffServ Service Classes

IPv6

MIBs

RFC 1881 IPv6 Address Allocation Management RFC 1887 IPv6 Unicast Address Allocation Architecture RFC 1981 IPv6 Path MTU Discovery RFC 2080 RIPng for IPv6 RFC 2373 IPv6 Addressing Architecture RFC 2375 IPv6 Multicast Address Assignments RFC 2460 IPv6 Specification RFC 2461 IPv6 Neighbor Discovery RFC 2462 IPv6 Stateless Address Auto-configuration RFC 2463 ICMPv6 RFC 2464 Transmission of IPv6 over Ethernet Networks RFC 2475 IPv6 DiffServ Architecture RFC 2711 IPv6 Router Alert Option RFC 2893 Transition Mechanisms for IPv6 Hosts and Routers RFC 2925 Definitions of Managed Objects for Remote Ping, Traceroute, and Lookup Operations (Ping only) RFC 2925 Remote Operations MIB (Ping only) RFC 3056 Connection of IPv6 Domains via IPv4 Clouds RFC 3162 RADIUS and IPv6 RFC 3306 Unicast-Prefix-based IPv6 Multicast Addresses RFC 3307 IPv6 Multicast Address Allocation RFC 3315 DHCPv6 (client and relay) RFC 3484 Default Address Selection for IPv6 RFC 3493 Basic Socket Interface Extensions for IPv6 RFC 3513 IPv6 Addressing Architecture RFC 3542 Advanced Sockets API for IPv6 RFC 3587 IPv6 Global Unicast Address Format RFC 3596 DNS Extension for IPv6 RFC 4113 MIB for UDP RFC 4443 ICMPv6

RFC 1213 MIB II

HP 3600 SI Switch Series

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 18

QuickSpecs

Technical Specifications

RFC 1493 Bridge MIB RFC 1724 RIPv2 MIB RFC 1757 Remote Network Monitoring MIB RFC 1907 SNMPv2 MIB RFC 2233 Interface MIB RFC 2571 SNMP Framework MIB RFC 2572 SNMP-MPD MIB RFC 2573 SNMP-Notification MIB RFC 2573 SNMP-Target MIB RFC 2574 SNMP USM MIB RFC 2618 RADIUS Authentication Client MIB RFC 2620 RADIUS Accounting Client MIB RFC 2665 Ethernet-Like-MIB RFC 2674 802.1p and IEEE 802.1Q Bridge MIB RFC 2819 RMON MIB RFC 3414 SNMP-User based-SM MIB RFC 3415 SNMP-View based-ACM MIB

Network management

QoS/CoS

IEEE 802.1AB Link Layer Discovery Protocol (LLDP) RFC 1157 SNMPv1 RFC 1757 RMON 4 groups: Stats, History, Alarms and Events RFC 1901 SNMPv2 Introduction RFC 1902 Structure of Management Information for Version 2 of the Simple Network Management Protocol (SNMPv2) RFC 1903 SNMPv2 Textual Conventions RFC 1904 SNMPv2 Conformance RFC 1905 SNMPv2 Protocol Operations RFC 1906 SNMPv2 Transport Mappings RFC 2570 SNMPv3 Overview RFC 2571 An Architecture for Describing SNMP Management Frameworks RFC 2572 Message Processing and Dispatching for the Simple Network Management Protocol (SNMP) RFC 2573 SNMP Applications RFC 2574 SNMPv3 User-based Security Model (USM) RFC 2575 SNMPv3 View-based Access Control Model (VACM) RFC 2578 Structure of Management Information Version 2 (SMIv2) RFC 2579 Textual Conventions for SMIv2 RFC 2580 Conformance Statements for SMIv2 RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events) RFC 3410 Introduction to Version 3 of the Internet-standard Network Management Framework RFC 3414 SNMPv3 User-based Security Model (USM) RFC 3415 SNMPv3 View-based Access Control Model VACM) ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED) SNMPv1/v2c/v3

RFC 4594 Configuration Guidelines for DiffServ Service Classes

HP 3600 SI Switch Series

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 19

QuickSpecs

Accessories

HP 3600 SI Switch Series

HP 3600 SI Switch Series accessories

Transceivers

HP X125 1G SFP LC LH40 1310nm Transceiver HP X120 1G SFP LC LH40 1550nm Transceiver HP X125 1G SFP LC LH70 Transceiver HP X125 1G SFP RJ45 T Transceiver HP X120 1G SFP LC BX 10-U Transceiver HP X120 1G SFP LC BX 10-D Transceiver

HP X170 1G SFP LC LH70 1550 Transceiver HP X170 1G SFP LC LH70 1570 Transceiver HP X170 1G SFP LC LH70 1590 Transceiver HP X170 1G SFP LC LH70 1610 Transceiver HP X170 1G SFP LC LH70 1470 Transceiver HP X170 1G SFP LC LH70 1490 Transceiver HP X170 1G SFP LC LH70 1510 Transceiver HP X170 1G SFP LC LH70 1530 Transceiver

HP X120 1G SFP LC SX Transceiver HP X120 1G SFP LC LX Transceiver

Cables

HP A3600 Switch SFP Stacking Kit

HP 0.5 m Multimode OM3 LC/LC Optical Cable HP 1 m Multimode OM3 LC/LC Optical Cable HP 2 m Multimode OM3 LC/LC Optical Cable HP 5 m Multimode OM3 LC/LC Optical Cable HP 15 m Multimode OM3 LC/LC Optical Cable HP 30 m Multimode OM3 LC/LC Optical Cable HP 50 m Multimode OM3 LC/LC Optical Cable HP Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable HP Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable HP Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable HP Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable HP Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable HP Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable

Power Supply

HP RPS1600 Redundant Power System HP RPS1600 1600W AC Power Supply

Power cords

HP X290 JD5 JD5 2m RPS1600 Cable

JD061A

JD062A JD063B JD089B JD098B JD099B

JD109A

JD110A

JD111A

JD112A

JD113A

JD114A

JD115A

JD116A JD118B JD119B

JD324B

AJ833A

AJ834A

AJ835A

AJ836A

AJ837A

AJ838A

AJ839A

QK732A QK733A QK734A QK735A QK736A QK737A

JG136A

JG137A

JD187A

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 20

QuickSpecs

Accessory Product Details

NOTE:

Details are not available for all accessories. The following specifications were available at the time of publication.

HP 3600 SI Switch Series

HP X124 1G SFP LC LH40 1310nm Transceiver

(JD061A)

A small form-factor pluggable SFP Gigabit LH40 transceiver that provides a full duplex Gigabit solution up to 40km on a singlemode fiber.

HP X120 1G SFP LC LH40 1550nm Transceiver

(JD062A)

A small form-factor pluggable (SFP) Gigabit LH40 transceiver that provides a full-duplex Gigabit solution up to 40 km on a single mode fiber.

Ports Connectivity

Physical characteristics

Electrical characteristics

Cabling

Services

Ports Connectivity

Physical characteristics

Electrical characteristics

Cabling

1 LC 1000Base-LH port (no IEEE standard exists for 1550 nm optics) Connector type Wavelength Dimensions

Full configuration weight Power consumption typical Power consumption

maximum Cable type:

Single-mode fiber optic, complying with ITU-T G.652;

Maximum distance:

40km distance Fiber type Refer to the HP website at

the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

1 LC 1000BASE-LH port (no IEEE standard exists for 1550 nm optics) Connector type Wavelength Dimensions

Full configuration weight Power consumption typical Power consumption

maximum Cable type:

Single-mode fiber optic, complying with ITU-T G.652;

LC 1310 nm

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

0.04 lb. (0.02 kg)

0.8 W

1.0 W

Single Mode

www.hp.com/networking/services

LC 1550 nm

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

0.04 lb. (0.02 kg)

0.8 W

1.0 W

for details on

Services

Maximum distance:

40km distance Fiber type Refer to the HP website at

the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

DA - 13788 Worldwide — Version 11 — December 9, 2013

Single Mode

www.hp.com/networking/services

for details on

Page 21

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP X125 1G SFP LC LH70 Transceiver

A small form-factor pluggable (SFP) Gigabit LH70 transceiver that provides a full-duplex Gigabit solution up to 70km on a single-mode fiber.

HP X125 1G SFP RJ45 T Transceiver (JD089B)

A small form factor pluggable (SFP) Gigabit 1000Base-T transceiver that provides a full duplex Gigabit solution up to 100m on a Cat-5+ cable.

(JD063B)

Ports

Connectivity

Physical characteristics

Electrical characteristics

Cabling

Services

Ports

Connectivity

Physical characteristics

Electrical characteristics

Cabling

1 LC 1000BASE-LH port (no IEEE standard exists for 1550 nm optics)

Connector type

Wavelength

Dimensions

Full configuration weight

Power consumption typical

Power consumption maximum

Cable type: Single-mode fiber optic, complying with ITU-T G.652;

Maximum distance:

• 70km Fiber type Refer to the HP website at

the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

1 RJ-45 1000BASE-T port (IEEE 802.3ab Type 1000BASE-T)

Connector type

Dimensions

Full configuration weight

Power consumption typical

Power consumption maximum

Cable type: 1000BASE-T: Category 5 (5E or better recommended), 100 Ù differential 4pair unshielded twisted pair (UTP) or shielded twisted pair (STP) balanced, complying with IEEE 802.3ab 1000BASE-T;

LC 1550 nm

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

0.04 lb. (0.02 kg)

0.8 W

1.0 W

Single Mode

www.hp.com/networking/services

RJ-45

2.71(d) x 0.54(w) x 0.55(h) in. (6.88 x 1.37 x 1.4 cm)

0.07 lb. (0.03 kg)

0.8 W

1.0 W

for details on

Services

Maximum distance:

• 100m Refer to the HP website at

the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

DA - 13788 Worldwide — Version 11 — December 9, 2013

www.hp.com/networking/services

for details on

Page 22

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP X120 1G SFP LC BX 10U Transceiver

A small form-factor pluggable (SFP) Gigabit LXBX10-U transceiver that provides a full duplex Gigabit solution up to 10km on a single mode cable.

HP X120 1G SFP LC BX 10D Transceiver (JD099B)

A small form-factor pluggable (SFP) Gigabit LXBX10-D transceiver that provides a full duplex Gigabit solution up to 10km on a single mode cable.

(JD098B)

Ports

Connectivity

Physical characteristics

Electrical characteristics

Cabling

Notes

Services

Ports

Connectivity

Physical characteristics

Electrical characteristics

Cabling

Notes

Services

1 LC 1000BASE-BX10 port (IEEE 802.3ah Type 1000BASE-BX10-U); Duplex: full only

Connector type

Dimensions

Full configuration weight

Power consumption typical

Power consumption maximum

Maximum distance:

• 10km Fiber type TX 1310nm RX 1490nm Refer to the HP website at:

the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

1 LC 1000BASE-BX10 port (IEEE 802.3ah Type 1000BASE-BX10-D); Duplex: full only

Connector type

Dimensions

Full configuration weight

Power consumption typical

Power consumption maximum

Maximum distance:

• Up to 10km Fiber type TX 1490nm RX 1310nm Refer to the HP website at

the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

0.04 lb. (0.02 kg)

0.8 W

1.0 W

Single Mode

www.hp.com/networking/services

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

0.04 lb. (0.02 kg)

0.8 W

1.0 W

Single Mode

www.hp.com/networking/services

for details on

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 23

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP X120 1G SFP LC SX Transceiver

A small form-factor pluggable (SFP) Gigabit SX transceiver that provides a full-duplex Gigabit solution up to 550m on a Multimode fiber.

(JD118B)

Ports

Connectivity

Physical characteristics

Electrical characteristics

Cabling

Services

1 LC 1000BASE-SX port

Connector type

Wavelength

Dimensions

Full configuration weight

Power consumption typical

Power consumption maximum

Maximum distance:

• FDDI Grade distance = 220m

• OM1 = 275m

• OM2 = 500m

• OM3 = Not Specified by standard Cable length Fiber type Refer to the HP website at

the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

LC 850 nm

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

0.04 lb. (0.02 kg)

0.8 W

1.0 W

up to 550m Multi Mode

www.hp.com/networking/services

for details on

HP X120 1G SFP LC LX Transceiver

A small form-factor pluggable (SFP) Gigabig LX transceiver that provides a full duplex Gigabit solution up to 550m on MMF or 10Km on SMF

(JD119B)

Ports

Connectivity

Physical characteristics

Electrical characteristics

Cabling

Services

1 SFP 1000BASE-LX port (IEEE 802.3z Type 1000BASE-LX)

Connector type

Wavelength

Dimensions

Full configuration weight

Power consumption typical

Power consumption maximum

Cable type: Either single mode or multimode;

Maximum distance:

• 550m for Multimode

• 10km for Singlemode Fiber type Refer to the HP website at

the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

LC 1300 nm

2.17(d) x 0.6(w) x 0.46(h) in. (5.51 x 1.52 x 1.17 cm)

0.04 lb. (0.02 kg)

0.8 W

1.0 W

Both

www.hp.com/networking/services

for details on

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 24

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP 0.5 m Multimode OM3 LC/LC Optical Cable

(AJ833A)

Cabling

Notes

Services

Cable type

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of up to 300 m

Maximum distance

10Gbps Transfer Rate (Ethernet): 300m Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um

fiber optic cable and Ethernet assembly with LC duplex connectors on one end and LC duplex connectors on other end.

Refer to the HP website at the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical glass: Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical glass: Bandwidth: For Laser sources: 2000/500 MHz-km

@850/1300nm. VCSEL Laser sources: 600 / 600 meters @850/1300nm

for Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber and designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

www.hp.com/networking/services

for details on

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 25

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP 1 m Multimode OM3 LC/LC Optical Cable

(AJ834A)

Cabling

Notes

Services

Cable type

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of up to 300 m

Maximum distance

10Gbps Transfer Rate (Ethernet): 300m Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um

fiber optic cable and Ethernet assembly with LC duplex connectors on one end and LC duplex connectors on other end.

Refer to the HP website at the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.

VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for

Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber. The cable is designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

www.hp.com/networking/services

for details on

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 26

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP 2 m Multimode OM3 LC/LC Optical Cable

(AJ835A)

Cabling

Notes

Services

Cable type

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of up to 300 m;

Maximum distance

10Gbps Transfer Rate (Ethernet): 300m Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um

fiber optic cable and Ethernet assembly with LC duplex connectors on one end and LC duplex connectors on other end.

Refer to the HP website at the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.

VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for

Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber. The cable is designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

www.hp.com/networking/services

for details on

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 27

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP 5 m Multimode OM3 LC/LC Optical Cable

(AJ836A)

Cabling

Notes

Services

Cable type

50/125 µm core/cladding) diameter, mulitimode fiber optic, with effective modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of up to 300 m;

Maximum distance

10Gbps Transfer Rate (Ethernet): 300m Cable Specs: This specification defines the detail requirements for a tight

buffered duplex fiber optic multimode OM3 50/125 um fiber optic cable and Ethernet assembly with LC duplex connectors on one end and LC duplex connectors on other end.

Refer to the HP website at the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.

VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for

Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber. The cable is designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

www.hp.com/networking/services

for details on

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 28

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP 15 m Multimode OM3 LC/LC Optical Cable

(AJ837A)

Cabling

Notes

Services

Cable type

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of up to 300 m;

Maximum distance

10Gbps Transfer Rate (Ethernet): 300m Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um

fiber optic cable and Ethernet assembly with LC duplex connectors on one end and LC duplex connectors on other end.

Refer to the HP website at the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.

VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for

Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber. The cable is designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

www.hp.com/networking/services

for details on

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 29

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP 30 m Multimode OM3 LC/LC Optical Cable

(AJ838A)

Cabling

Notes

Services

Cable type

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of up to 300 m;

Maximum distance

10Gbps Transfer Rate (Ethernet): 300m Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um

fiber optic cable and Ethernet assembly with LC duplex connectors on one end and LC duplex connectors on other end.

Refer to the HP website at the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.

VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for

Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber. The cable is designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

www.hp.com/networking/services

for details on

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 30

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP 50 m Multimode OM3 LC/LC Optical Cable

(AJ839A)

Cabling

Notes

Services

Cable type

50/125 µm (core/cladding) diameter, mulitimode fiber optic, with effective modal bandwidth of 2000 MHz/km as detailed in TIA-492AAAC for distances of up to 300 m;

Maximum distance

10Gbps Transfer Rate (Ethernet): 300m Cable Specs: Tight buffered duplex fiber optic multimode OM3 50/125 um

fiber optic cable and Ethernet assembly with LC duplex connectors on one end and LC duplex connectors on other end.

Refer to the HP website at the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

Dimensions: Core diameter: 50 ± 3.0um Cladding diameter: 125 ± 2.0um

Coating diameter: 245 ± 10um

Optical Glass Bandwidth: For LED sources: 1500/500 MHz-km

@850/1300nm.

Optical Glass: For Laser sources: 2000/500 MHz-km @850/1300nm.

VCSEL Laser sources: Shall achieve 600 / 600 meters @850/1300nm for

Gigabit Ethernet compliant links.

CABLE: The cable is duplex zipcord graded index 50/125um multimode

optical fiber. The cable is designed to work in both the 850 and 1300 nm

wavelength windows.

BULK CABLE & CABLE ASSEMBLY CONFIGURATION:

Jacket Material: Riser Grade - Low Smoke Zero Halogen thermoplastic.

Jacket Color: Aqua for OM3 multimode per TIA 598

Boot Color: White

Insertion Loss: less than 0.5 dB @ 850 with LED source, 0.003 dB/M

added for lengths > 30 meters.

Maximum Cable attenuation: 3.0 dB/km @ 850 nm, 1.0 dB/Km @ 1310

nm @ 23°C as tested in accordance with EIA 455-46.

Weight: Air Packed Weight: 1 LB Net Weight: 0.454Kg

www.hp.com/networking/services

for details on

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 31

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable (QK732A)

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable (QK733A)

Notes

Services

Notes

Services

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um duplex cable and Ethernet assembly with LC duplex connectors on each end.

• Core Diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @ 23°C as tested in accordance with EIA 455-45

Refer to the HP website at the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um duplex cable and Ethernet assembly with LC duplex connectors on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @ 23°C as tested in accordance with EIA 455-45

Refer to the HP website at the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

www.hp.com/networking/services

for details on

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 32

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable (QK734A)

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable

(QK735A)

Notes

Services

Notes

Services

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um duplex cable and Ethernet assembly with LC duplex connectors on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @ 23°C as tested in accordance with EIA 455-45

Refer to the HP website at the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um duplex cable and Ethernet assembly with LC duplex connectors on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @ 23°C as tested in accordance with EIA 455-45

Refer to the HP website at the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

www.hp.com/networking/services

for details on

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 33

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable

(QK736A)

(QK737A)

Notes

Services

Notes

Services

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um duplex cable and Ethernet assembly with LC duplex connectors on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @ 23°C as tested in accordance with EIA 455-45

Refer to the HP website at the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

Cable Specs: Graded-index, "bendable" fiber optic multimode OM3+ 50/125um duplex cable and Ethernet assembly with LC duplex connectors on each end.

• Core diameter: 50um ±3um, Cladding diameter: 125um ±2um; Coating diameter: 245 ± 10um

• Bandwidth: 3000 MHz-km @ 850nm (Laser)

• Jacket Color: Blue

• Jacket Material: Riser Grade – Low Smoke Zero Halogen (LSZH) thermoplastic

• Boot Color: White

• Outer Jacket Print: HP PremierFlex OM3+ Fiber Optic Cable, 50/125um, Type OFNR (UL), LSZH, cUL, OFN FT4, ROHS. Cable also has a longitudinal white stripe that runs the entire length of the cable.

• Insertion Loss: Less than 0.5dB @ 850nm with LED source, 0.003dB/m added for lengths >30m

• Maximum Cable Attenuation: 3.0 dB/km @ 850nm, 1.0 dB/km @ 1310nm @ 23°C as tested in accordance with EIA 455-45

Refer to the HP website at the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

www.hp.com/networking/services

for details on

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 34

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP RPS1600 Redundant Power System

(JG136A)

Ports

Physical characteristics

Environment

Electrical characteristics

Safety

Services

8 redundant power supply ports Restrictions: two -56V/25A DC(PoE); six -56V/8A DC(non-PoE)

Dimensions

Weight

Full configuration weight

Operating temperature

Operating relative humidity

Nonoperating/Storage temperature

Nonoperating/Storage relative humidity

Altitude

Acoustic

Voltage

Current

Idle power

Maximum power rating

RPS power

PoE power

RPS

PoE

Frequency

Notes

CE Labeled; UL 60950-1; IEC 60950-1; ICES-003; FCC Part 15, Subpart B; EU RoHS Compliant; EN 60950-1/A11; C-Tick; VCCI Class A; ROHS Compliance; EN 300386

Refer to the HP website at: the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

15.63(d) x 17.32(w) x 1.74(h) in. (39.7 x 44 x 4.42 cm)

14.11 lb. (6.4 kg)

16.75 lb. (7.6 kg) 14°F to 122°F (-10°C to 50°C) 5% to 95%

-40°F to 158°F (-40°C to 70°C)

5% to 95%

up to 13,123 ft. (4 km) Pressure: 53 dB; ISO 7779, ISO 9296 100-120/200-240 VAC 30/60 A 38 W 3550 W 3200 W 2800 W

-55 V

-55 V 50/60 Hz Idle power is the actual power consumption of the

device with no ports connected. Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated. With one RPS1600 Power Supply, the PRS1600 Redundant Power System can provide 1600W power output; With two PRS1600 Power Supplies, the output power is 3200W.

www.hp.com/networking/services

for details on

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 35

QuickSpecs

Accessory Product Details

HP 3600 SI Switch Series

HP RPS1600 1600W AC Power Supply

(JG137A)

Physical characteristics

Environment

Electrical characteristics

Services

Dimensions

Weight

Operating temperature

Operating relative humidity

Nonoperating/Storage temperature

Nonoperating/Storage relative humidity

Voltage

Current

Maximum power rating

Frequency

Notes

Refer to the HP website at: the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

8.19(d) x 4.96(w) x 1.63(h) in. (20.8 x 12.6 x 4.15 cm)

3.02 lb. (1.37 kg) 14°F to 122°F (-10°C to 50°C) 5% to 95%

-40°F to 158°F (-40°C to 70°C)

5% to 95%

100-120/200-240 VAC 15/30 A 1600 W 50/60 Hz Maximum power rating and maximum heat

dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated.

www.hp.com/networking/services

for details on

To learn more, visit:

© Copyright 2010-2013 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

www.hp.com/networking

DA - 13788 Worldwide — Version 11 — December 9, 2013

Page 36

HP FlexNetwork 3100 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Configuration

Technical Specifications

Accessories

Accessory Product Details
