Page 1
1.
Mics
Dual microphones
5.
Plus"+"/ Input
If the OSD menu is on, press to navigate
forward through the OSD menu and increase
adjustment levels.
If the OSD menu is inactive, press to activate
the source button that chooses the video
signal input (VGA, DVI, or DisplayPort).
2.
Webcam
Integrated 720p webcam
6.
Minus ""/Volume
If the OSD menu is on, press to navigate
backward through the OSD menu and
decrease adjustment levels.
Adjust volume levels.
3.
Power/
Power LED
Turns the monitor on or off.
LED:
fully powered = white;
sleep mode = amber;
sleep timer mode = flashing amber.
7.
Menu
Opens, selects or exits the OSD menu.
4.
OK/Auto
If the OSD menu is on, press to select the
highlighted menu item. If the OSD menu is
inactive, press to activate the auto
adjustment feature to optimize the screen
image.
QuickSpecs
HP EliteDisplay E221c 21.5-inch Webcam LED Backlit
Monitor
Overview
DA - 14664 North America — Version 2 — September 4, 2013
Page 1
Page 2
Boost Productivity with Dual Monitor Work Solution
Use two E221c monitors with an HP Adjustable Dual
Display Stand (AW664AA) for a small footprint, high
productivity work solution.
(Multi-monitor support depends on your PC capability. Monitors and stands are sold separately.)
Model
: D9E49AA
QuickSpecs
HP EliteDisplay E221c 21.5-inch Webcam LED Backlit
Monitor
Overview
DA - 14664 North America — Version 2 — September 4, 2013
Page 2
Page 3
Panel
Type
IPS w/LED backlight
Viewable Image Area
(diagonal)
54,6 cm
(21.5 in) widescreen, diagonally measured
Active Area
(W x H)
47,66 x 26,81 cm
(18.76 x 10.56 in)
Aspect Ratio
16:9
Viewing Angle
(typical)
Up to 178° horizontal/178° vertical (10:1 minimum contrast ratio)
Brightness
(typical)
*
250 nits (cd/m2)
Static Contrast Ratio
(typical)
*
1000:1
Dynamic Contrast Ratio
(typical)
*
5,000,000:1
Response Time
(typical)*7 ms w/overdrive (gray-to-gray)
Pixel Pitch
0.248 mm
Backlight Lamp Life
(to half brightness)
30,000 hours minimum
Color Gamut
(typical)*
72%
Color Support**
Can display up to 16.7 million colors
*All performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
** With the use of FRC technology.
On Screen Display
(OSD)
Controls
Buttons or Switches
Menu, Minus ("-")/Volume, Plus ("+") /Input Control, OK/Auto, Power
Languages
10 (English, Spanish, German, French, Italian, Netherlands, Portuguese,
Japanese, T-Chinese and S-Chinese)
User Controls
Brightness, Contrast, Color, Image Control, OSD control, Management,
Language, Information, Factory Reset, Input Control
Signal Interface/
Performance
Horizontal Frequency
24 to 94 kHz
Vertical Frequency
50 to 76 Hz
Native Resolution
1920 x 1080 @ 60 Hz
Preset VESA Graphic
Modes
(non-interlaced)
1920 x 1080 @ 60 Hz
1600 x 900 @ 60 Hz
1440 x 900 @ 60 Hz
1280 x 1024 @ 60 Hz
1024 x 768 @ 60 Hz
800 x 600 @ 60 Hz
720 x 400 @ 60 Hz
640 x 480 @ 60 Hz
Maximum Pixel Clock
Speed
200 MHz
User Programmable
Modes
Yes (10)
Anti-Glare
Yes
QuickSpecs
HP EliteDisplay E221c 21.5-inch Webcam LED Backlit
Monitor
Technical Specifications
DA - 14664 North America — Version 2 — September 4, 2013
Page 3
Page 4
Default Color
Temperature
6500 K
Video/Other Inputs
Plug and Play
Yes
Input Connectors
VGA (analog), DVI-D, DisplayPort (HDCP support on DVI-D and DisplayPort)
USB
Integrated USB 2.0 hub with (2) Downstream and (1) Upstream ports
USB Cable
(1)USB cable,
1,8 m
(5.9 ft)
Video Cables
(1)VGA, (1)DisplayPort
APJ Specific:
(1)VGA and (1)DVI-D cables are included. DisplayPort cable is only available in
Australia and New Zealand).
Video Cable Lengths
VGA, DVI-D, & DisplayPort
1,8 m
(5.9 ft)
Audio
(2) 1W/channel built-in speakers (rear firing);
(1) Audio in, (1) Headphone/Speaker audio out
Audio Cable Length
N/A
Webcam
Integrated 720p webcam with dual microphones
Power
Power Supply
Internal
Input Power
90 - 265 VAC at 45 - 63 Hz
Typical Power
Consumption
27 W
Maximum
42 W
Power Saving
0.4 W
Power Cable Length
1,9 m
(6.2 ft)
Mechanical
Dimensions
(W x D x H)
Unpacked w/stand
50,9 x 23,7 x 46 cm
(20.05 x 9.34 x 18.12 in)
Unpacked w/o stand
(head
only)
50,9 x 5,1 x 30,9 cm
(20.05 x 2.01 x 12.17 in)
Packaged
57,5 x 18,3 x 50 cm
(22.66 x 7.21 x 19.7 in)
Base area
(footprint)
16,85 x 23,65 cm
(6.63 x 9.31 in)
Weight
Head Only
3,3 kg
(7.27 lb)
Unpacked
5,4 kg
(11.9 lb)
Packaged
7,1 kg
(15.62 lb)
Tilt Range
-5° to +30°
Swivel Range
Yes, 360°
Height Adjustable
Yes, 150 mm
Pivot Rotation
Yes, 90°
Base
Attached
Environmental
Temperature - Operating
5° to 35° C
(41° to 95° F)
Temperature - Nonoperating
-20° to 60° C
(-4° to 140° F)
QuickSpecs
HP EliteDisplay E221c 21.5-inch Webcam LED Backlit
Monitor
Technical Specifications
DA - 14664 North America — Version 2 — September 4, 2013
Page 4
Page 5
Humidity - Operating
20% to 80% non-condensing
Humidity - Non-operating
5% to 95%, 38.7° C max wet-bulb
Altitude - Operating
0 to 5,000 m
(16,404 ft)
Altitude - Non-operating
0 to 12,192 m
(0 to 40,000 ft)
White LED Backlights
Yes
CCFL Panel
No
Arsenic-Free Display
Glass
Yes
Low Halogen
4
Yes
Mercury- Free Display
Backlighting
Yes
Environmental Data
Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
IT ECO declaratio
US ENERGY STAR®
TCO 6.0 and TCO Edge Certification
EPEAT® Gold where HP registers commercial display products. See
http://www.epeat.net
for registration status in your country US Federal
Energy Management Program (FEMP)
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation
20.6 W 20.4 W 20.8 W
Sleep
0.4 W 0.4 W 0.4 W
Off
0.2 W 0.2 W 0.2 W
Heat Dissipation
*
115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation
70 BTU/hr 70 BTU/hr 71 BTU/hr
Sleep
1 BTU/hr 1 BTU/hr 1 BTU/hr
Off
1 BTU/hr 1 BTU/hr 1 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Additional Information
This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the
Gold level, see www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per
ISO 11469 and ISO1043.
This product contains 12.9 % post-consumer recycled plastic (by wt.)
QuickSpecs
HP EliteDisplay E221c 21.5-inch Webcam LED Backlit
Monitor
Technical Specifications
DA - 14664 North America — Version 2 — September 4, 2013
Page 5
Page 6
This product is 98.2 % recycle-able when properly disposed of at end of
life.
Packaging Materials
External:
PAPER/Corrugated
808 g
Internal:
PLASTIC/EPS (Expanded
Polystyrene)
328 g
PLASTIC/EPE-Expanded
Polyethylene
48 g
RoHS Compliance
Hewlett-Packard is committed to compliance with all applicable environmental
laws and regulations, including the European Union Restriction of Hazardous
Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by
meeting the requirements of the RoHS Directive on a worldwide basis. By July 1,
2006, RoHS substances will be virtually eliminated (virtually = to levels below
legal limits) for all HP electronic products subject to the RoHS Directive, except
where it is widely recognized that there is no technically feasible alternative (as
indicated by an exemption under the EU RoHS Directive).
Material Usage
This product does not contain any of the following substances in excess of
regulatory limits (refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/
supplychain/gen_specifications.html
):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as flame
retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel - finishes must not be used on the external surface designed to be
frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) - except for wires and cables, and certain retail
packaging has been voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging
HP follows these guidelines to decrease the environmental impact of product
packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and
cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging
QuickSpecs
HP EliteDisplay E221c 21.5-inch Webcam LED Backlit
Monitor
Technical Specifications
DA - 14664 North America — Version 2 — September 4, 2013
Page 6
Page 7
materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and corrugated
materials.
Reduce size and weight of packages to improve transportation fuel
efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN
6120 standards.
End-of-life Management
and Recycling
Hewlett-Packard offers end-of-life HP product return and recycling programs in
many geographic areas. To recycle your product, please go to:
http://www.hp.com/go/reuse-recycle
or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities. This
information (product disassembly instructions) is posted on the Hewlett
Packard web site at:
http://www.hp.com/go/recyclers
. These instructions may
be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
Hewlett-Packard
Corporate
Environmental
Information
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/
productdesign/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/operations/
envmanagement.html
Options
(sold separately)
HP LCD Monitor Quick
Release – Part number
EM870AA
1
An easy-to-use, VESA-compliant, LCD monitor mounting solution that allows
you to quickly and securely attach an LCD monitor to a variety of stands,
brackets, arms or wall mounts. For more information, refer to this product's
QuickSpecs document.
HP USB Graphics Adapter
– Part number NL571AA
Enables connection of up to six simultaneous displays to help you boost
productivity and multi-task across several open applications. Use one Adapter
to bridge between a notebook or desktop PC and second monitor or use
multiple Adapters to connect several displays to each other.
HP Dual Output USB
Graphics Adapter – Part
Number C5U89AA
You can boost your productivity by creating a dual-monitor setup with the HP
Dual Output USB Graphics Adapter – featuring both DVI-I and DisplayPort
inputs to drive displays at high resolutions through a single USB 3.0
connection to your PC.
HP Business PC Security
Lock Kit – Part number
PV606AA
Attaches to the rear of the PC with a six-foot steel cable that can be used to
secure a PC or peripherals such as mice, keyboards, monitors or USB security
devices to protect them against unauthorized removal by physically
connecting the system to an anchor point.
QuickSpecs
HP EliteDisplay E221c 21.5-inch Webcam LED Backlit
Monitor
Technical Specifications
DA - 14664 North America — Version 2 — September 4, 2013
Page 7
Page 8
HP Integrated Work
Center Stand - USDT and
Thin Clients)—Part
number LH526AA
Allows mounting of a 17 - 24 inch diagonal HP LCD monitor and an HP Compaq
8000 series Ultra-slim Desktop PC as well as select HP Thin Clients on a single
stand for the convenience of an "all-in-one" form factor. For more
information, refer to this product's QuickSpecs document.
HP Adjustable Dual
Display Stand – Part
Number AW664AA
Premium space-saving dual screen solution provides access to more monitor
real estate and makes it possible to manage multiple applications
simultaneously. Weight adjustable for dual monitors from 17-24". Rotate
displays into portrait/landscape positions.
HP LCD Speaker Bar–Part
number NQ576AA
Powered directly by the connected PC, the Speaker Bar seamlessly attaches to
the monitor's lower bezel to bring full audio support to select HP flat panel
monitors. Features include dual speakers with full sound range and dual
external headphone jacks. Sold separately. For more information, refer to the
product's QuickSpecs.
HP Business Headset–Part
number QK550AA
A headset that is perfect for call centers, telephone-intensive jobs, or casual
use while working at your desk. The over-the-head flexible design includes
light padding, full size leather ear phones and a mounted microphone boom.
HP DVI to DVI cable –
Part number DC198A
Connect to external monitors with a DVI connector from an HP Compaq
Business Desktop computer with a DVI connector. The cable is a single link
cable with DVI-D support on both connectors. The cable will connect to either
a DVI-D or DVI-I connector on the monitor and the graphics card.
What's in the box?
Monitor and Accessories
HP EliteDisplay E221c 21.5-inch Webcam LED Backlit Monitor; VGA cable;
DisplayPort cable; USB cable; AC Power cable
APJ Specific:
(1)VGA and (1)DVI-D cables are included. DisplayPort cable is only available in
Australia and New Zealand).
Documentation
Printed documentation and CD
Featured Software
Yes, HP Display Assistant, Cyberlink You Cam and HP MyRoom
Other
User Guide Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish, Dutch, Finnish, French,
German, Greek, Hungarian, Italian, Japanese, Kazakh, Korean, Norwegian,
Polish, Brazilian Portuguese, Russian, Slovenian, Spanish, Swedish and
Turkish.
Warranty Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish, Dutch, Finnish, French,
German, Greek, Hungarian, Italian, Japanese, Kazakh, Korean, Norwegian,
Polish, Brazilian Portuguese, Russian, Slovenian, Spanish, Swedish and
Turkish.
Color
Black
VESA External Mounting
Yes (one set of standard 4-hole pattern, 100 mm)
Security Lock-Ready
Yes
Country of Origin
China
Certification and
Compliance
CE, CB ,KC, KCC, NOM, PSB, ICE, TUV-S, CCC, CEL Grade 1, CECP, SEPA, TCO Certified Edge, VCCI ,FCC, Taiwan
BSMI , ENERGY STAR®, EPEAT® Gold
3
Compatibility
Compatible with platforms using the VESA standard video modes. Recommended for use with HP
products.
Service and Warranty
Protected by HP, including a 3 year standard limited warranty. Optional Care Pack Services are extended
service contracts which go beyond your standard warranties.
2
QuickSpecs
HP EliteDisplay E221c 21.5-inch Webcam LED Backlit
Monitor
Technical Specifications
DA - 14664 North America — Version 2 — September 4, 2013
Page 8
Page 9
© Copyright 2013 Hewlett-Packard Development Company, L.P.
ENERGY STAR® is a US registered mark of the United States Environmental Protection Agency.
1
The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg) for all devices mounted. Because mounting
surfaces vary widely and the final mounting method and configuration may vary, mounting fasteners are not supplied (other than the
VESA-compliant screws). HP recommends that you consult with a qualified engineering, architectural or construction professional to
determine the appropriate type and quantity of mounting fasteners required for your application and to ensure that your mounting
solution is properly installed to support applied loads.
2
HP Care Pack Services extend service contracts beyond the standard warranties. Service levels and response times for HP Care Packs
may vary depending on your geographic location. Service starts from date of hardware purchase. To choose the right level of service
for your HP product, use the HP Care Pack Services Lookup Tool at http://www.hp.com/go/lookuptool. Additional HP Care Pack
Services information by product is available at http://www.hp.com/hps/carepack.
3
EPEAT® Gold registered models of this product are available where HP registers commercial display products. See
www.epeat.net
for
registration status in your country.
5
External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be
Low Halogen.
All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either
higher or lower. The only warranties for HP products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or
editorial errors or omissions contained herein.
QuickSpecs
HP EliteDisplay E221c 21.5-inch Webcam LED Backlit
Monitor
Technical Specifications
DA - 14664 North America — Version 2 — September 4, 2013
Page 9
Loading...
