QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Overview
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 1
HP EliteDesk 800 G5 Desktop Mini Business PC
1.
USB Type-C™ 3.1 Gen 2 port (charge support up to 5V/3A)
5.
Universal Audio Jack with CTIA headset support
2.
USB 3.1 Gen 2 Type A
6.
Hard Drive activity light
3.
USB 3.1 Gen 1 Type A (charging port)
7.
Dual-state power button
4.
Headphone Jack
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Overview
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 2
HP EliteDesk 800 G5 Desktop Mini Business PC
1.
DisplayPort™ 1.2
5.
RJ-45 Network connector
2.
USB 3.1 Gen 2 Type A
6.
Power connector
3.
Configurable Option card slot (Choice of DisplayPort™ 1.2,
HDMI™ 2.0, VGA, USB Type-C™ with alt mode display, USB
Type-C™ with Power Delivery, Discrete Graphics Option Card
with DisplayPort™ 1.4, Thunderbolt 3.0, Serial Port, Fiber NIC)
(not all options are available on 65W and 95W processors)
7.
WLAN External Antenna Punchout
8.
Standard lock slot (10mm)
9.
Cover Release Thumbscrew
4.
USB 3.1 Gen 1 Type A
allows for wake from S4/S5 with keyboard/mouse when
connected and enabled in BIOS
10.
WLAN Internal Antenna
11
Padlock Loop
Not Shown
Slots
(1) Internal M.2 2230 connector for WLAN
(2) Internal M.2 SSD storage (2230 or 2280 connector)
Bays
(1) 2.5- inch SATA drive Bay (not available on 95W processor)
Mounting
Support for
- VESA Sleeve Standalone
- Quick Release Bracket
- B300/B500 Mounting bracket
- Integrated Work Center
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Overview
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 3
HP EliteDesk 800 G5 Small Form Factor Business PC
1.
Slim optical drive (optional)
6.
USB 2.0 (charge support up to 5V/1.5A)
2.
SD 4 Card Reader (optional)
7.
Headphone connector
3.
USB Type-C™ port (charge support up to 5V/3A)
8.
Universal Audio Jack with CTIA headset support
4.
USB 3.1 Gen2 ports (2)
9.
Hard drive activity light
5.
USB 2.0 port
10.
Dual-state power button
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Overview
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 4
HP EliteDesk 800 G5 Small Form Factor Business PC
(Rear Image)
1.
Audio-in connector
7.
RJ-45 (network) jack
2.
Audio-out connector for powered audio devices
8.
USB 2.0 ports with wake from S4/S5 (2)
3.
Standard lock slot
9.
USB 3.1 Gen2 ports (2)
4.
Dual-Mode DisplayPort™ 1.2 (2)
10.
USB 3.1 Gen1 ports (2)
5.
Optional serial port - shown here not installed
11.
Optional Thunderbolt PCIe card - shown here installed
6.
Optional port (DisplayPort™ 1.2, HDMI 2.0a, VGA or USB-C™)
(USB-C™ option has alt mode DisplayPort™ 1.2 or 15W
output) - shown here not installed
Not shown
Slots
Bays
(2) PCI Express x16 graphics connectors; one wired as an x4
(1) 2.5" internal storage drive bay
(2) PCI Express x1
(2) 3.5” internal storage drive bay (convertible to 2.5”)
(2) internal M.2 SSD storage (2230 or 2280 connector)
(1) internal M.2 WLAN (2230 connector)
(1) 9.5 mm slim optical drive bay
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Overview
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 5
HP EliteDesk 800 G5 Tower Business PC
1.
5.25-inch Half-Height Drive Bay (behind bezel)
1.
Audio-out jack for powered audio devices
2.
Slim optical drive (optional)
2.
Dual-Mode DisplayPort™ 1.2 (DP++) (2)
3.
SD 4 Card Reader (optional)
3.
Optional port (DisplayPort™ 1.2, HDMI 2.0a, VGA or USB-C™)
(USB-C™ option has alt mode DisplayPort™ 1.2 or 15W
output) – Shown here HDMI installed
4.
Dual-state power button
5.
Universal Audio Jack with CTIA headset support
4.
USB 2.0 ports with wake from S4/S5 (2)
6.
Headphone connector
5.
USB 3.1 Gen2 ports (2)
7.
USB 2.0 port (charge support up to 5V/1.5A)
6.
USB 3.1 Gen1 ports (2)
8.
USB 2.0 port
7.
Standard lock slot
9.
USB 3.1 Gen2 ports (2)
8.
RJ-45 (network) jack
10.
USB Type-C™ port (charge support up to 5V/3A)
9.
Optional serial port – shown here installed
10.
Power cord connector
11.
Audio-in jack
Not shown
Slots
Bays
(2) PCI Express x16 graphics connectors; one wired as an x4
(1) 2.5" internal storage drive bay
(2) PCI Express x1
(2) 3.5” internal storage drive bay (convertible to 2.5”)
(2) internal M.2 SSD storage (2230 or 2280 connector)
(1) internal M.2 WLAN (2230 connector)
(1) 5.25” half-height drive bay
(1) 9.5mm slim optical drive bay
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Overview
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 6
HP EliteOne 800 G5 23.8-in All-in-One*
1.
Camera (optional)
2.
Speakers (optional)
Infrared (IR) and dual facing camera (optional)
1.
Camera light
3.
Full High Definition
(FHD) camera
5.
Rear camera adjustment
wheel
7.
Camera light
2.
IR camera light
4.
IR camera
6.
Digital microphones
8.
FHD camera
Full High Definition (FHD) camera (optional)
1.
Camera light
2.
FHD camera
3.
Digital microphones
*Available Options: Touch, Non-Touch, HP Sure View, and Discrete Graphics
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Overview
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 7
HP EliteOne 800 G5 23.8-in All-in One
1.
Optical disc drive (optional)
4.
Universal Audio Jack with CTIA headset support
2.
Optical disc drive eject button (optional)
4.
Headphone connector
3.
Standard lock slot (10 mm)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Overview
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 8
HP EliteOne 800 G5 23.8-in All-in-One
Bottom components and rear ports (behind security cover)
1.
USB 3.1 Gen 2 Type-A port
7.
USB 3.1 Gen 2 Type-A ports (2) wake capable
2.
USB 3.1 Gen 2 Type-A port (charge support up to 5V/1.5A)
8.
Dual-Mode DisplayPort™1.2 (DP++)
3.
Audio line-out connector
9.
HDMI 2.0a connector
4.
USB 3.1 Gen 1 Type-A ports (2)
10.
SD card reader 4.0 (optional)
5.
RJ-45 (network) jack
11.
USB 3.1 Type-C™ Gen 2 port (charge support up to 5V/3A)
6.
Power connector
12.
Dual-state power button
13.
Sure View Button (optional)
Not shown
Slots
Bays
(1) internal M.2 PCIe x1 connector for optional wireless NIC
(1) 2.5" internal storage drive bay
(2) internal M.2 PCIe x4 connector for optional m.2 SSD
VESA
Support for VESA 100 mounting system on back of PC
chassis (mounting hardware sold separately)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Overview
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 9
HP EliteOne 800 G5 23.8-in All-in-One
Rear and side components
1.
Fingerprint sensor (optional)
3.
Standard lock slot (10 mm)
2.
Rear port cover
4.
Adjustable height stand (optional)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 10
AT A GLANCE
• Choice of four form factors: Tower, Small Form Factor, Desktop Mini and All-In-One (touch/non-touch)
• HP developed and engineered UEFI V2.6 BIOS supporting security, manageability and software image stability
• Intel® Q370 chipset supporting Intel® 9
th
and select 8
th
generation Core™ processors, featuring integrated Intel® UHD
Graphics and Intel® vPro™ Technology (available with Core i5, Core i7 and Core i9 processors)
1,4
• Processors up to 95W on TWR, SFF and DM
• Intel® Optane™ Memory H10 with Solid State Storage
• Intel® UHD graphics as well as optional discrete graphics configure systems to up to 7 displays (TWR, SFF and DM 35W)
2
• Intel® Ethernet Connection I219LM GbE LOM integrated network connection
• Intel® Wi-Fi 6 + BT5 (802.11AX 2x2)
• DDR4 Synchronous Dynamic Random Access Memory (SDRAM) (Transfer rates up to 2666 MT/s)
• Support for up to three monitors via two standard DisplayPort™ 1.2 connectors and an optional third video port connector
which provides the following choices: HDMI 2.0, VGA, DisplayPort™ 1.2, or USB Type-C™ with DisplayPort™ 1.2 for all
platforms; USB Type-C™ with DisplayPort™ 1.2 and Power Delivery (PD) from Display for 800 G5 DM 35W (see Ports
section for port availability by platform). AiO supports up to two additional monitors via DisplayPort™ or HDMI
connectors.2
• Configurable 3rd rear I/O with video port (HDMI 2.0, DisplayPort™ 1.2, VGA, Type-C™ with DisplayPort™ 1.2) or
Thunderbolt 3.0 (port on DM, PCIe card on TWR, SFF)
• Configurable AMD® Radeon and NVIDA® GeForce® VR ready discrete graphics on TWR
5
• Compatibility with HP Mini-In-One 24 Display (800 G5 DM with 100W USB-C +PD option card)
• Models can be configured with multiple data drives in a RAID array
• Skype for Business certified (AiO)
• Audio by Bang & Olufsen (AiO)
• Intel® Unite™ available (AiO, Desktop Mini)
• Intel® Unite™ must be configured at the factory
• EN 60601-1-2: 2015 compliant (AiO)
• Enhanced Security With:
HP Sure Click
HP Sure Start Gen5
HP Sure Run
HP Sure Recover
HP Sure View Gen3 (AiO)
HP Manageability Integration Kit Gen3
HP BIOSphere Gen5
HP Sure Sense
HP Client Security Manager Gen5
Notification with HP Image Assistant Gen3
HP Multi-Factor Authenticate Gen3, features include fingerprint sensor (optional) and IR webcam (optional) both Windows
Hello certified (AiO)
• High efficiency energy saving power supply options
• ENERGY STAR® certified. EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See
http://www.epeat.net for registration status by country6. Search keyword generator on HP’s 3rd party option store for
solar generator accessories at http://www.hp.com/go/options.
• CCC, CECP and SEPA Certified (TWR/SFF/DM/AiO)
• CECP Certified (AiO)
• TCO Edge for AiO
• PC chassis and all internal components and modules are manufactured with low halogen content
3
• Dust filter available for all platforms (except 65W and 95W Desktop Mini, 35W Desktop Mini with Discrete Graphics)
• Protected by HP Services, including limited warranties up to 3-3-3 (terms and conditions vary by country; certain
restrictions and exclusions apply); Care Packs available with up to 5 years Next Business Day Onsite Hardware Support
• Compliance with CE (Class B) / FCC (Class B) / UL (UL609501) / CSA (CSA C22.2 No.60950-1-07) / ICES-003 / CCC / VCCI
(Class B) / KCC (Class B)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 11
1. Multi core is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit
from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software
configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance
2. DisplayPort™ multi-stream monitors ‘daisy-chained’ together.
3. External power supplies, power cords, cables and peripherals are not low halogen. Service parts obtained after purchase may not be low
halogen.
4. Some functionality of vPro technology, such as Intel Active management technology and Intel Virtualization technology, requires additional
3rd party software in order to run. Availability of future "virtual appliances" applications for Intel vPro technology is dependant on 3rd party
software providers. Compatibility of this generation of Intel vPro technology-based hardware with with future "virtual appliances" is yet to be
determined.”
5. VR-ready as optional feature, requires specific configuration to support.
6. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit http://www.epeat.net for more
information.
NOTE: See important legal disclosures for all listed specs in their respective features sections
PRODUCT NAME
HP EliteDesk 800 G5 Tower Business PC
HP EliteDesk 800 G5 Small Form Factor Business PC
HP EliteDesk 800 G5 Desktop Mini Business PC
HP EliteOne 800 G5 23.8-inch All-in-One
OPERATING SYSTEM
Preinstalled
Windows® 10 Pro 641
Windows® 10 Pro 64 (National Academic License)2
Windows® 10 Home 641
Windows® 10 Home Single Language 641
FreeDos
Web-supported only
Windows® 10 Enterprise 64
1
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware,
drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always
enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com/.
2. Some devices for academic use will automatically be updated to Windows 10 Pro Education with the Windows 10 Anniversary Update.
Features vary; see https://aka.ms/ProEducation for Windows 10 Pro Education feature information.
NOTE: Your product does not support Windows 8 or Windows 7. In accordance with Microsoft’s support policy, HP does not support the
Windows® 8 or Windows 7 operating system on products configured with Intel and AMD® 7th generation and forward processors or provide
any Windows® 8 or Windows 7 drivers on http://www.support.hp.com
CHIPSET
DM
SFF
TWR
AiO
Intel® Q370 PCH-H– vPro™
X X X
X
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 12
PROCESSORS
Intel® 9th Generation Core™ Processors
DM
SFF
TWR
AiO
Intel® Core™ i9 9900 Processor with Intel® UHD Graphics 630 (3.1GHz, up to
4.9 GHz with Intel® Turbo Boost,16MB cache, 8 cores) 65W
1,2
Supports Intel® vPro™Technology3
X X X
X
Intel® Core™ i9 9900K Processor with Intel® UHD Graphics 630 (3.6GHz, up
to 5.0 GHz with Intel® Turbo Boost,16MB cache, 8 cores) 95W
1,2
Supports Intel® vPro™Technology3
X X X
Intel® Core™ i9 9900T Processor with Intel® UHD Graphics 630 (2.1GHz, up
to 4.4 GHz with Intel® Turbo Boost,16MB cache, 8 cores) 35W
1,2
Supports Intel® vPro™Technology3
X
Intel® Core™ i7 9700 processor with Intel® UHD Graphics 630 (3.0 GHz, up to
4.7 GHz with Intel® Turbo Boost, 12 MB cache, 8 cores) 65W
1,2
Supports Intel® vPro™Technology3
X X X
X
Intel® Core™ i7 9700K Processor with Intel® UHD Graphics 630 (3.6 GHz, up
to 4.9 GHz with Intel® Turbo Boost,12MB cache, 8 cores) 95W
1,2
Supports Intel® vPro™Technology
3
X X X
Intel® Core™ i7 9700T Processor with Intel® UHD Graphics 630 (2.0Hz, up to
4.3 GHz with Intel® Turbo Boost,12MB cache, 8 cores) 35W
1,2
Supports Intel® vPro™Technology3
X
Intel® Core™ i5 9600 processor with Intel® UHD Graphics 630 (3.1 GHz, up to
4.8 GHz with Intel® Turbo Boost, 9 MB cache, 6 cores)
1, 2
Supports Intel® vPro™Technology3
X X X
X
Intel® Core™ i5 9600K processor with Intel® UHD Graphics 630 630 (3.7 GHz,
up to 4.6 GHz with Intel® Turbo Boost, 9 MB cache, 6 cores) 95W
1, 2
Supports Intel® vPro™Technology3
X X X
Intel® Core™ i5 9600T processor with Intel® UHD Graphics 630 (2.3 GHz, up
to 3.9 GHz with Intel® Turbo Boost, 9 MB cache, 6 cores)
1, 2
Supports Intel® vPro™Technology3
X
Intel® Core™ i5 9500 processor with Intel® UHD Graphics 630 (3.0 GHz, up to
4.1 GHz with Intel® Turbo Boost, 9 MB cache, 6 cores)
1, 2
Supports Intel® vPro™Technology3
X X X
X
Intel® Core™ i5 9500T processor with Intel® UHD Graphics 630 (2.2 GHz, up
to 3.7 GHz with Intel® Turbo Boost, 9 MB cache, 6 cores)
1, 2
Supports Intel® vPro™Technology3
X
Intel® Core™ i5 9400 processor with Intel® UHD Graphics 630 (2.9 GHz, up to
4.1 GHz with Intel® Turbo Boost, 9 MB cache, 6 cores)
X X X
X
Intel® Core™ i5 9400T processor with Intel® UHD Graphics 630 (1.8 GHz, up
to 3.4 GHz with Intel® Turbo Boost, 9 MB cache, 6 cores)
X
Intel® Core™ i5 8400 processor with Intel® UHD Graphics 630 (2.8 GHz, up to
4.0 GHz with Intel® Turbo Boost, 9 MB cache, 6 cores)
X X X
X
Intel® Core™ i5 8400T processor with Intel® UHD Graphics 630 (1.7 GHz, up
to 3.3 GHz with Intel® Turbo Boost, 9 MB cache, 6 cores)
X
Intel® Core™ i3 9300 processor with Intel® UHD Graphics 630 (3.7 GHz, 8 MB
cache, 4 cores)1
X X X
X
Intel® Core™ i3 9300T processor with Intel® UHD Graphics 630 (3.2 GHz, 8
MB cache, 4 cores)1
X
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 13
Intel® Core™ i3 9100 processor with Intel® UHD Graphics 630 (3.6 GHz, 6 MB
cache, 4 cores)1
X X X
X
Intel® Core™ i3 9100T processor with Intel® UHD Graphics 630 (3.1 GHz, 6
MB cache, 4 cores)1
X
Intel® 8th Generation Core™ Processors
DM
SFF
TWR
AiO
Intel® Core™ i7 8700 processor with Intel® UHD Graphics 630 (3.2 GHz, up to
4.6 GHz with Intel® Turbo Boost, 12 MB cache, 6 cores)
1, 2
Supports Intel® vPro™Technology3
X X X
X
Intel® Core™ i7 8700T processor with Intel® UHD Graphics 630 (2.4 GHz, up
to 4.0 GHz with Intel® Turbo Boost, 12 MB cache, 6 cores)
1, 2
Supports Intel® vPro™Technology3
X
Intel® Core™ i5 8500 processor with Intel® UHD Graphics 630 (3.0 GHz, up to
4.1 GHz with Intel® Turbo Boost, 9 MB cache, 6 cores)
1,2
Supports Intel® vPro™Technology3
X X X
X
Intel® Core™ i5 8500T processor with Intel® UHD Graphics 630 (2.1 GHz, up
to 3.5 GHz with Intel® Turbo Boost, 9 MB cache, 6 cores)
1,2
Supports Intel® vPro™Technology3
X
Intel® Core™ i3 8100 processor with Intel® UHD Graphics 630 (3.6 GHz, 6 MB
cache, 4 cores)1
X X X
X
Intel® Core™ i3 8100T processor with Intel® UHD Graphics 630 (3.61GHz, 6
MB cache, 4 cores)1
X
Intel® Pentium® Processors
DM
SFF
TWR
AiO
Intel® Pentium® Gold G5420 processor with Intel® UHD Graphics 610 (3.8
GHz, 4 MB cache, 2 cores)1
X X X
X
Intel® Pentium® Gold G5420T processor with Intel® UHD Graphics 610 (3.2
GHz, 4 MB cache, 2 cores)1
X
Intel® Pentium® Gold G5600 processor with Intel® UHD Graphics 630 (3.9
GHz, 4 MB cache, 2 cores)1
X X X
X
Intel® Pentium® Gold G5600T processor with Intel® UHD Graphics 630
(3.3GHz, 4 MB cache, 2 cores)1
X
Intel® Pentium® Gold G5620 processor with Intel® UHD Graphics 630 (4.0
GHz, 4 MB cache, 2 cores)1
X X X
X
Intel® Celeron™ Processors
DM
SFF
TWR
AiO
Intel® Celeron® G4930 processor with Intel® UHD Graphics 610 (3.2 GHz, 2
MB cache, 2 cores)1
X X X
X
Intel® Celeron® G4930T processor with Intel® UHD Graphics 610 (3.0 GHz, 2
MB cache, 2 cores)1
X
1: Multi-core is designed to improve performance of certain software products. Not all customers or software applications will necessarily
benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and
software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
2. Intel® Turbo Boost technology requires a PC with a processor with Intel Turbo Boost capability. Intel Turbo Boost performance varies
depending on hardware, software and overall system configuration. See http://www.intel.com/technology/turboboost for more
information.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 14
3. Some functionality of vPro technology, such as Intel Active management technology and Intel Virtualization technology, requires additional
3rd party software in order to run. Availability of future "virtual appliances" applications for Intel vPro technology is dependant on 3rd party
software providers. Compatibility of this generation of Intel vPro technology-based hardware with with future "virtual appliances" is yet to be
determined.
GRAPHICS
Integrated Intel® Graphics
DM
SFF
TWR
AiO
Intel® UHD Graphics 630 (integrated on 9th gen Core i9/i7/i5/i3,
Pentium® Gold G5600, G5500)
X X X
X
Intel® UHD Graphics 610 (integrated on 9th gen Pentium® Gold G5400,
Celeron® G4900)
X X X
X
Optional Discrete Graphics Solutions
DM
SFF
TWR
AiO
NVIDIA® GeForce® RTX 2080 8GB FH 3DP HDMI Graphics Card*
X
NVIDIA® GeForce® RTX 2070 8GB FH 3DP HDMI Graphics Card*
X
NVIDIA® GeForce® RTX 2070 Super 8GB Graphics Card
X
NVIDIA® GeForce® RTX 2060 6GB FH Graphics Card*
X
NVIDIA Quadro P1000 4GB Graphics Card
X
NVIDIA® Quadro P620 2GB Graphics Card
X X
NVIDIA® Quadro P400 2GB Graphics Card
X X
NVIDIA® GeForce® GT 730 2GB DP DVI Graphics Card
X X
AMD® Radeon™ RX 580 8GB FH 3DP 1HDMI Graphics Card*
X
AMD® Radeon™ RX 560X 4GB GDDR5**
X
X
AMD® Radeon™ RX 550 4GB 1DP 1HDMI Graphics Card
X X
AMD® Radeon™ R7 430 2GB GDDR5 64bit DP+VGA***
X X
AMD® Radeon™ R7 430 2GB GDDR5 64bit 2DP
X X
AMD® Radeon™ 520 1GB VGA +DP
X
*Requires 500W chassis
**Only available on the Touch Version All-in-One
***Not available in all regions
NOTE: As of 2019, AMD Radeon™ RX 560 is renamed to AMD Radeon™ RX 560X
Adapters and Cables
DM
SFF
TWR
AiO
HP DisplayPort™ Cable
X X X
X
HP DisplayPort™ to DVI-D Adapter
X X X
X
HP DisplayPort™ to HDMI 4K Adapter
X X X
X
HP DisplayPort™ to VGA Adapter
X X X
X
HP USB-C™ to USB 3.0
X X X
X
HP USB to Serial Port Adapter
X X X
X
HP USB-C™ to HDMI 4K Adapter
X
HP DisplayPort to HDMI True 4K Adapter
X
HP DVI Cable
X
HP HDMI Standard Cable Kit (HDMI)
X
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 15
HP DVI Cable Kit
X
HP HDMI to VGA Adapter
X
HP UHD USB Graphics Adapter
X
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 16
STORAGE
3.5 inch SATA Hard Disk Drives (HDD)
DM
SFF
TWR
AiO
500GB 7200RPM 3.5in SATA HDD
X X
1TB 7200RPM 3.5in SATA HDD
X X
2TB 7200RPM 3.5in SATA HDD
X X
2.5 inch SATA Hard Disk Drives (HDD)
DM
SFF
TWR
AiO
500GB 7200RPM 2.5in SATA HDD
X X X
X
1TB 7200RPM 2.5in SATA HDD
X X X
X
2TB 5400RPM 2.5in SATA HDD
X X X
X
500GB 7200RPM 2.5in Self Encrypted OPAL2 SATA HDD*
X X X
X
500GB 7200RPM 2.5in Self Encrypted Federal Information Processing
Standard SATA HDD*
X X X
X
NOTE*: Storage Drivelock does not work with Self Encrypting or Optane based storage.
2.5 inch Solid State Drives (SSD)
DM
SFF
TWR
AiO
256GB 2.5in SATA Three Layer Cell SSD
X X X
X
512GB 2.5in SATA Three Layer Cell SSD
X X X
X
256GB 2.5in SATA Self Encrypted OPAL2 Three Layer Cell SSD*
X X X
X
512GB 2.5in SATA Self Encrypted OPAL2 Three Layer Cell SSD*
X X X
X
256GB 2.5in SATA Self Encrypted Federal Information Processing
Standard SSD*
X X X
X
512GB 2.5in SATA Self Encrypted Federal Information Processing
Standard SSD*
X X X
X
NOTE*: Storage Drivelock does not work with Self Encrypting or Optane based storage.
M.2 PCIe NMVe Solid State Drives (SSD)
DM
SFF
TWR
AiO
256GB M.2 2280 PCIe NVMe SSD
X X X
X
512GB M.2 2280 PCIe NVMe SSD
X X X
X
1TB M.2 2280 PCIe NVMe SSD
X X
128GB M.2 2280 PCIe NVMe Three Layer Cell SSD
X X X
X
256GB M.2 2280 PCIe NVMe Three Layer Cell SSD
X X X
X
512GB M.2 2280 PCIe NVMe Three Layer Cell SSD
X X X
X
1TB M.2 2280 PCIe NVMe Three Layer Cell SSD
X X X
X
2TB M.2 2280 PCIe NVMe Three Layer Cell SSD
X X X
X
256GB M.2 2280 PCIe NVMe Self Encrypted OPAL2 Three Layer Cell SSD*
X X X
X
512GB M.2 2280 PCIe NVMe Self Encrypted OPAL2 Three Layer Cell SSD*
X X X
X
256GB Intel® Optane™ Memory H10 with Solid State Storage*
X X X
X
512GB Intel® Optane™ Memory H10 with Solid State Storage*
X X X
X
NOTE*: Storage Drivelock does not work with Self Encrypting or Optane based storage.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 17
Optical Disc Drives
DM
SFF
TWR
AiO
HP 9.5mm Slim DVD-ROM Drive
X X
X
HP 9.5mm Slim DVD Writer Drive
X X
X
HP 9.5mm Slim Blu-Ray Writer Drive
X X
X
Removable
DM
SFF
TWR
AiO
SSD 256GB M.2 PCIe NVMe TLC Removable
X
SSD 512GB M.2 PCIe NVMe TLC Removable
X
SSD 1TB M.2 PCIe NVMe TLC Removable
X
Media Card Reader
DM
SFF
TWR
AiO
SD 4.0 with 5-in-1 Interface (Supports SD, SDXC, SDHC, UHS-I, UHS-II)
X X
X
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
MEMORY
Memory Type
DM
SFF
TWR
AiO
DDR4-2666 (Transfer rates up to 2666 MT/s), 64 GB, 2 SODIMM
X
X
DDR4-2666 (Transfer rates up to 2666 MT/s), 128 GB, 4 DIMM
X X
Memory Configuration
DM
SFF
TWR
AiO
4 GB (1 x 4 GB)
X X X
X
8 GB (2 x 4 GB)
X X X
X
8 GB (1 x 8 GB)
X X X
X
16 GB (2 x 8 GB)
X X X
X
16 GB (1 x 16 GB)
X X X
X
32 GB (2 x 16 GB)
X X X
X
32 GB (4 x 8 GB)
X X
32 GB (1 x 32 GB)
X X X
X
64 GB (4 x 16 GB)
X X
64 GB (2 x 32 GB)
X X X
X
128 GB (4 x 32 GB)
X X
NOTE: For systems configured with more than 3 GB of memory and a 32-bit operating system, all memory may not be available due to system
resource requirements. Addressing memory above 4 GB requires a 64-bit operating system.
Memory modules support data transfer rates up to 2666 MT/s; actual data rate is determined by the system's configured processor. See processor
specifications for supported memory data rate.
NOTE: All memory slots are customer accessible / upgradeable.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 18
NETWORKING/COMMUNICATIONS
Ethernet (RJ-45)
DM
SFF
TWR
AiO
Intel® I219-LM Gigabit Network Connection LOM (standard)
X X X
X
Intel® Ethernet I210-T1 PCIe x1 Gb Network Interface Card (optional)
X X
Wireless1
DM
SFF
TWR
AiO
Intel® Wi-Fi 6 AX200 + BT5 (802.11AX 2x2 vPro, supporting gigabit file
transfer speed )
X X X
X
Intel® Wi-Fi 6 AX200 + BT5 (802.11AX 2x2 non-vPro, supporting gigabit
file transfer speed )
X X X
X
Intel Wireless-AC 9560 802.11ac 2x2 Wi-Fi + BT5 (vPro, supporting
gigabit file transfer speeds)
X X X
X
Intel Wireless-AC 9560 802.11ac 2x2 Wi-Fi + BT5 (non-vPro, supporting
gigabit file transfer speeds)
X X X
X
Realtek RTL8822BE 802.11ac 2x2 Wi-Fi + BT4.2
X X
X
Realtek RTL8821CE 802.11ac 1x1 Wi-Fi + BT4.2
X
1. Wireless access point and Internet service required and not included. Availability of public wireless access points limited. The
specifications for the 802.11ax WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications,
it may affect the ability of the PC to communicate with 802.11ax WLAN devices. Wi-Fi 6 requires a wireless router, sold separately, that
supports 802.11ax (Wi-Fi 6). Only available in countries where 802.11ax is supported.
KEYBOARDS AND POINTING DEVICES
Keyboards
DM
SFF
TWR
AiO
HP USB Premium Keyboard
X X X
X
HP USB Conferencing Keyboard
X X X
X
HP Wireless Collaboration Keyboard
X X X
X
HP USB Collaboration Keyboard
X X X
X
HP USB and PS/2 Washable Keyboard1
X X X
X
HP USB Smart Card (CCID) Keyboard
X X X
X
HP USB Business Slim Keyboard
X X X
X
HP USB Keyboard
X X X
X
HP PS/2 Business Slim Keyboard1
X X
HP Wireless Business Slim Keyboard and Mouse
X X X
X
HP USB Business Slim Antimicrobial Keyboard2
X X X
X
Mouse
DM
SFF
TWR
AiO
HP PS/2 Mouse1
X X
HP USB Optical Mouse
X X X
X
HP USB Premium Mouse
X X X
X
HP USB 1000dpi Laser Mouse
X X X
X
HP USB and PS/2 Washable Mouse1
X X X
X
Antimicrobial USB Mouse2
X X X
X
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 19
HP USB Hardened Mouse2
X X X
X
HP USB Fingerprint Reader Mouse
X X
X
HP USB Grey Mouse2
X X X
X
1. PS/2 port not available on EliteOne 800 G5 AiOs and not available on any EliteDesk 800 G5 DMs
2. Not available in all regions
SECURITY
DM
SFF
TWR
AiO
TPM 2.0 (FW: 7.85) endpoint security controller (Infineon SLB9670)
Common Criteria EAL4+ Certified. FIPS 140-2 Level 2 Certified.
X X X
X
Solenoid Lock & Intrusion Sensor
X X
Intrusion Sensor for DM/AiO (integrated in the PCA, can be
enabled/disabled through BIOS)
X
X
Support for chassis cable lock devices
X
(10 mm or
smaller)
X X X
Support for chassis padlocks devices
X X X
HP Fingerprint Sensor (standard on 800 G5 AiO touch models and
optional on non-touch models)
X
SATA port disablement (via BIOS)
X X X
X
Serial, USB enable/disable (via BIOS)
X X X
X
Intel® Identify Protection Technology (IPT)1
X X X
X
Serial, parallel, USB enable/disable (via BIOS)
X X X
X
Optional USB Port Disable at factory (user configurable via BIOS)
X X X
X
Removable media write/boot control
X X X
X
Power-on password (via BIOS)
X X X
X
Setup password (via BIOS)
X X X
X
1. Models configured with Intel® Core™ processors have the ability to utilize advanced security protection for online transactions. IPT, used in
conjunction with participating web sites, provides double identity authentication by adding a hardware component in addition to the usual user
name and password. IPT is initialized through an HP Client Security module.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 20
PORTS
I/O Ports – Standard
DM
SFF
TWR
AiO
USB 2.0
N/A
2 including 1 fast
charging (front);
2 including wake
from S4/S5 (rear)
2 including 1 fast
charging (front);
2 including wake
from S4/S5 (rear)
N/A
USB 3.1 Gen 1
1 front, 2 rear
2 rear
2 rear
2 rear
USB 3.1 Gen 2
1 front, 2 rear
2 front; 2 rear
2 front; 2 rear
4 rear
USB Type-C™ 3.1 Gen 2 (15W)
1 front; 1 rear
(option)
1 front; 1 rear
(option)
1 front; 1 rear
(option)
1 rear
Video
2 DisplayPort™ 1.2
(rear)
1 Configurable
video port (rear)
(Choice of
DisplayPort™ 1.2,
HDMI™ 2.0a, VGA,
or USB Type-C™
with alt mode
display port and
power delivery)
For models with
discrete graphics:
1 DisplayPort™ 1.4
(rear)
2 DisplayPort™ 1.2
(rear)
1 Configurable
video port (rear)
(Choice of
DisplayPort™ 1.2,
HDMI™ 2.0a, VGA,
or USB Type-C™
with alt mode
display or 15W
output)
2 DisplayPort™ 1.2
(rear)
1 Configurable
video port (rear)
(Choice of
DisplayPort™ 1.2,
HDMI™ 2.0a, VGA,
or USB Type-C™
with alt mode
display port or 15W
output)
For models with
integrated
graphics:
1 DisplayPort™
1.2 (rear)
1 HDMI™ 2.0a
(rear)
For models with
discrete graphics:
1 DisplayPort™
1.4 (rear)
1 HDMI™ 2.0a
(rear)
Audio
1 Headphone
(front),
1 Universal Audio
Jack with CTIA
headset support
(front))
1 Headphone
(front),
1 Universal Audio
Jack with CTIA
headset support
(front));
1 Audio-out (rear),
1 Audio-in (rear)
1 Headphone
(front),
1 Universal Audio
Jack with CTIA
headset support
(front));
1 Audio-out (rear),
1 Audio-in (rear)
1 Line out (rear)
1 CTIA UAJ (side)
1Audio out (side)
Network Interface
RJ45
RJ45
RJ45
RJ45
I/O Ports – Optional
DM
SFF
TWR
AiO
Serial (RS-232)
1 (rear)(option)
1 (rear) (option)
1 (rear) (option)
N/A
Serial (RS-232) and PS/2 combination
N/A
1 (rear) (option)
1 (rear) (option)
N/A
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 21
I/O Ports – Internal Ports
DM
SFF
TWR
AiO
Internal SATA storage connector(s)
N/A 3 4
2
Internal SATA storage connector (Data and
Power)
1
N/A
N/A
N/A
NOTE: For Desktop Mini with M.2 Storage config, there will be no SATA drive bracket. If you plan to use or upgrade the storage with any 2.5" SATA
drive, please select a DM SATA Drive Bracket (available as both factory configured and after market option).
Slots
DM
SFF
TWR
AiO
M.2 PCIe
(1) M.2 PCIe x1
2230 (for WLAN)
(2) M.2 PCIe x4
2280/2230 Combo
(for storage)
(1) M.2 PCIe x1
2230 (for WLAN)
(2) M.2 PCIe x4
2280/2230 Combo
(for storage)
(1) M.2 PCIe x1
2230 (for WLAN)
(2) M.2 PCIe x4
2280/2230 Combo
(for storage)
(1) M.2 PCIe x1
2230 (for WLAN)
(2) M.2 PCIe x4
2280/2230
Combo (for
storage)
PCI Express v3.0 x1
N/A 2 2
N/A
PCI Express v3.0 x16 (wired as x4)
N/A 1 1
N/A
PCI Express v3.0 x16
N/A 1 1
N/A
NOTE: The TWR can support a single graphics card up to 75W. When configured with dual graphics cards support is limited to 35W for each.
Bays
DM
SFF
TWR
AiO
5.25" Half Height (External)
N/A
N/A
1
N/A
9mm Slim Optical Disc Drive (ODD)
N/A 1 1
1
SD Card Reader
N/A 1 1
1
2.5" Internal Storage Drive
1 1 1
1
3.5" Internal Storage Drive
N/A 2 2
N/A
SATA 2.5” internal storage drive cannot be selected if 2nd M.2, discrete graphic card, or 95W processor is selected.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 22
SOFTWARE COMPONENTS AND APPLICATIONS WITH WINDOWS
BIOS
HP BIOSphere Gen5 17
HP DriveLock & Automatic DriveLock20
BIOS Update via Network
Master Boot Record Security
Power On Authentication
HP Secure Erase 18
Absolute Persistence Module
19
RAID Configurations33
Pre-boot Authentication
HP Wireless Wakeup
Software
HP Native Miracast Support 15
HP Hotkey Support - CMIT
HP Recovery Manager
HP JumpStarts
HP Privacy Settings
HP Setup Integrated OOBE
HP Support Assistant 21
HP Noise Cancellation Software
HP PC Hardware Diagnostics Windows
Buy Office (sold separately)
Intel® Unite (optional for AiOs and DMs)
HP Sure View Gen3 (AiO)
Manageability Features
HP Driver Packs 22
HP System Software Manager (SSM)
HP BIOS Config Utility (BCU)
HP Client Catalog
HP Image Assistant Gen4
HP Manageability Integration Kit Gen3 23
Ivanti Management Suite
24
HP Cloud Recovery39
Client Security Software
HP Client Security Suite Gen5 25 including:
HP Security Manager 26 (including Credential Manager, HP Password Manager, HP Spare Key)
HP Fingerprint Sensor 31
HP Device Access Manager
HP Power On Authentication
HP Sure Sense
Windows Defender 27
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 23
Security Management
HP Secure Erase
18
TPM 2.0 (FW: 7.85) endpoint security controller (Infineon SLB9670) Common Criteria EAL4+ Certified. FIPS 140-2 Level 2
Certified.
SATA 0,1 port disablement (viaBIOS)
RAID configurations
33
Serial, USB enable/disable (viaBIOS)
Power-on password (viaBIOS)
Setup password (viaBIOS)
Support for chassis padlocks and cable lock devices
Integrated hood sensor
HP Sure Click Gen2
38
HP Sure Start Gen5
30
HP Sure Run
35
HP Sure Recover
36
15. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming
17. HP BIOSphere Gen5 requires Intel® or AMD® 9th Gen processors. Features may vary depending on the platform and configurations.
18. For the methods outlined in the National Institute of Standards and Technology Special Publication 800-88. Supported on Elite platforms with
BIOS version F.03 or higher.
19. Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription. Subscriptions can be purchased
for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery Guarantee is a
limited warranty. Certain conditions apply. For full details visit: http://www.absolute.com/company/legal/agreements/computrace-
agreement. Data Delete is an optional service provided by Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use
the Data Delete service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID
tokens from Absolute Software.
20. Storage Drivelock does not work with Self Encrypting or Optane based storage.
21. HP Support Assistant requires Windows and Internet access.
22. HP Driver Packs not preinstalled, however available for download at http://www.hp.com/go/clientmanagement.
23. HP Manageability Integration Kit can be downloaded from http://www.hp.com/go/clientmanagement.
24. Ivanti Management Suite subscription required.
25. HP Client Security Manager Gen5 requires Windows and is available on select HP Pro and Elite PCs. See product specifications for details.
26. HP Password Manager requires Internet Explorer or Chrome or FireFox. Some websites and applications may not be supported. User may need
to enable or allow the add-on / extension in the internet browser.
27. Windows Defender Opt in Windows 10 and internet connection required for updates.
30. HP Sure Start Gen5 is available on select HP PCs with Intel processors. See product specifications for availability.
31. HP Fingerprint Sensor available on 800 G5 AiO touch models and optional on 800 G5 AiO non-touch models
33. RAID configuration is optional and requires two equivalent hard drives.
34. RAID 1 is pre-installed and functionality will require a second hard drive.
35. HP Sure Run is available on HP Elite products equipped with 8th and 9th generation Intel® or AMD® processors.
36. HP Sure Recover is available on HP Elite PCs with 8th generation Intel® or AMD® processors and requires an open, wired network connection.
Not available on platforms with multiple internal storage drives, Intel® Optane™. You must back up important files, data, photos, videos, etc.
before use to avoid loss of data.
38. HP Sure Click is available on most HP PCs and supports Microsoft® Internet Explorer, Google Chrome, and Chromium™. Supported
attachments include Microsoft Office (Word, Excel, PowerPoint) and PDF files in read only mode, when Microsoft Office or Adobe Acrobat are
installed.
39. HP Cloud Recovery is available for HP Elite and Pro desktops and laptops PCs with Intel® or AMD processors and requires an open, wired
network connection. Note: You must back up important files, data, photos, videos, etc. before use to avoid loss of data. Detail please refer to:
https://support.hp.com/us-en/document/c05115630.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 24
ENVIRONMENTAL & INDUSTRY
ENERGY STAR® certified models available
EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See http://www.epeat.net for registration status
by country1. Search keyword generator on HP’s 3rd party option store for solar generator accessories at
http://www.hp.com/go/options.
Low halogen (chassis, all internal components and modules)2
TAA compliant models available
1. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit http://www.epeat.net for more
information
2. External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be Low
Halogen.
UNIT ENVIRONMENT AND OPERATING CONDITIONS
General Unit Operating Guidelines
• Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit
is operated within the specified operating range.
• Leave a 10.2 cm (4 in) clearance on all vented sides of the computer to permit the required airflow.
• Never restrict airflow into the computer by blocking any vents or air intakes.
• Do not stack computers on top of each other or place computers so near each other that they are subject to each other's
re-circulated or preheated air.
• Occasionally clean the air vents on the front, back, and any other vented side of the computer. Lint, dust and other foreign
matter can block the vents and limit the airflow.
• If the computer is to be operated within a separate enclosure, intake and exhaust ventilation must be provided on the
enclosure, and the same operating guidelines listed above will still apply.
Temperature Range
Operating: 50° to 95° F (10° to 35° C)1
Non-operating: -22° to 140° F (-30° to 60° C)
Relative Humidity
Operating: 10% to 90% (non-condensing at ambient)
Non-operating: 5% to 95% (non-condensing at ambient)
Maximum Altitude
(unpressurized)
Operating: 5000m
Non-operating: 50000ft (15240 m)
1. Operating temperature is de-rated 1.0 deg C per 300 m (1000 ft) to 3000 m (10,000 ft) above sea level, no direct sustained sunlight. Maximum
rate of change is 10 deg C/Hr. The upper limit may be limited by the type and number of options installed.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 25
HP EliteDesk 800 Desktop Mini G5 series
Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals and may
be labeled with one or more of these marks:
• IT ECO declaration
• US ENERGY STAR®
• EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See
http://www.epeat.net for registration status by country. Search keyword generator on HP’s 3rd
party option store for solar generator accessories at http://www.hp.com/go/options.
*Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit
http://www.epeat.net for more information.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Desktop model is based on a “Typically Configured Desktop.
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation (Short
idle)
13.27 W
13.51 W
13.11 W
Normal Operation (Long
idle)
13.11 W
13.27 W
12.88 W
Sleep
0.75 W
0.81 W
0.75 W
Off
0.69 W
0.74 W
0.68 W
NOTE: Energy efficiency data listed is for an ENERGY STAR® certified product if offered within the
model family. HP computers marked with the ENERGY STAR® Logo are compliant with the
applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for
computers. If a model family does not offer ENERGY STAR® certified configurations, then energy
efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency
power supply, and a Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation
(Short idle)
45 BTU/hr
46 BTU/hr
45 BTU/hr
Normal Operation
(Long idle)
45 BTU/hr
45 BTU/hr
44 BTU/hr
Sleep
3 BTU/hr
3 BTU/hr
3 BTU/hr
Off
2 BTU/hr
3 BTU/hr
2 BTU/hr
NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured – Idle
3
20
Fixed Disk – Random writes
3.9
22
Longevity and Upgrading
This product can be upgraded, possibly extending its useful life by several years. Upgradeable
features and/or components contained in the product may include:
Spare parts are available throughout the warranty period and or for up to “5” years after the end of
production.
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 26
Battery size: CR2032 (coin cell)
Battery type: Lithium
Additional Information
• This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive 2011/65/EC.
• This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.
• This product is in compliance with California Proposition 65 (State of California; Safe Drinking
Water and Toxic Enforcement Act of 1986).
• This product is in compliance with the IEEE 1680 (EPEAT) standard, see http://www.epeat.net for
registration status by country. Search keyword generator on HP’s 3rd party option store for solar
generator accessories at http://www.hp.com/go/options
• Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043.
• This product contains 0% post-consumer recycled plastic (by wt.)
• This product is 95.1% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Corrugated
322 g
Internal:
PLASTIC/EPE (Expanded Polyethylene)
33 g
PLASTIC/Polyethylene low density
5 g
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer
to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
• Asbestos
• Certain Azo Colorants
• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Formaldehyde
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 27
Packaging Usage
This product does not contain any of the following substances in excess of regulatory limits (refer
to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
• Asbestos
• Certain Azo Colorants
• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Formaldehyde
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
End-of-life Management
and Recycling
HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest
HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for
each product type for use by treatment facilities. This information (product disassembly
instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These
instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K
_Certificate.pdf
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
HP EliteDesk 800 Small Form Factor G5 series
Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals and may
be labeled with one or more of these marks:
• IT ECO declaration
• US ENERGY STAR®
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 28
• EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See
http://www.epeat.net for registration status by country. Search keyword generator on HP’s 3rd
party option store for solar generator accessories at http://www.hp.com/go/options.
*Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit
http://www.epeat.net for more information.
.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Desktop model is based on a “Typically Configured Desktop.
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation
(Short idle)
10.78 W
10.98 W
10.905 W
Normal Operation
(Long idle)
9.863 W
10.063 W
9.988 W
Sleep
1.088 W
1.388 W
1.173 W
Off
0.602 W
0.599 W
0.601 W
NOTE: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the
model family. HP computers marked with the ENERGY STAR® Logo are compliant with the
applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for
computers. If a model family does not offer ENERGY STAR® compliant configurations, then energy
efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency
power supply, and a Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation (Short
idle)
15.4926 BTU/hr
15.6294 BTU/hr
15.0138 BTU/hr
Normal Operation (Long
idle)
13.8168 BTU/hr
14.364 BTU/hr
13.5432 BTU/hr
Sleep
1.2996 BTU/hr
1.4364 BTU/hr
1.2996 BTU/hr
Off
1.197 BTU/hr
1.2996 BTU/hr
1.1628 BTU/hr
NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured – Idle
3.2
23
Fixed Disk–Random writes
3.6
25
Longevity and Upgrading
This product can be upgraded, possibly extending its useful life by several years. Upgradeable
features and/or components contained in the product may include:
Spare parts are available throughout the warranty period and or for up to “5” years after the end of
production.
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
Battery size: CR2032 (coin cell)
Battery type: Lithium
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 29
Additional Information
• This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive 2011/65/EC.
• This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.
• This product is in compliance with California Proposition 65 (State of California; Safe Drinking
Water and Toxic Enforcement Act of 1986).
• This product is in compliance with the IEEE 1680 (EPEAT) standard, see http://www.epeat.net for
registration status by country. Search keyword generator on HP’s 3rd party option store for solar
generator accessories at http://www.hp.com/go/options
• Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043.
• This product contains 0% post-consumer recycled plastic (by wt.)
• This product is 95.1% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Corrugated
1158 g
Internal:
PLASTIC/EPE (Expanded Polyethylene)
320 g
PLASTIC/Polyethylene low density
28 g
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer
to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
• Asbestos
• Certain Azo Colorants
• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Formaldehyde
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product packaging:
• Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.
• Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
• Design packaging materials for ease of disassembly.
• Maximize the use of post-consumer recycled content materials in packaging materials.
• Use readily recyclable packaging materials such as paper and corrugated materials.
• Reduce size and weight of packages to improve transportation fuel efficiency.
• Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 30
End-of-life Management
and Recycling
HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest
HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for
each product type for use by treatment facilities. This information (product disassembly
instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These
instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K
_Certificate.pdf
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 31
HP EliteDesk 800 Tower G5 series
Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals and may
be labeled with one or more of these marks:
• IT ECO declaration
• US ENERGY STAR®
• EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See
http://www.epeat.net for registration status by country. Search keyword generator on HP’s 3rd
party option store for solar generator accessories at http://www.hp.com/go/options.
*Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit
http://www.epeat.net for more information.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Desktop model is based on a Typically Configured Desktop.
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
(Short idle)
15.02 W
14.68 W
14.94 W
Normal Operation
(Long idle)
14.34 W
13.38 W
14.12 W
Sleep
1.20 W
1.11 W
1.25 W
Off
0.70 W
0.72 W
0.69 W
NOTE: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the
model family. HP computers marked with the ENERGY STAR® Logo are compliant with the
applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for
computers. If a model family does not offer ENERGY STAR® compliant configurations, then energy
efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency
power supply, and a Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation (Short
idle)
51.3684 BTU/hr
50.2056 BTU/hr
51.0948 BTU/hr
Normal Operation (Long
idle)
49.0428 BTU/hr
45.7596 BTU/hr
48.2904 BTU/hr
Sleep
4.104 BTU/hr
3.7962 BTU/hr
4.275 BTU/hr
Off
2.394 BTU/hr
2.4624 BTU/hr
2.3598 BTU/hr
NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured – Idle
3.2
23
Fixed Disk–Random writes
3.6
26
Longevity and Upgrading
This product can be upgraded, possibly extending its useful life by several years. Upgradeable
features and/or components contained in the product may include:
Spare parts are available throughout the warranty period and or for up to “5” years after the end of
production.
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 32
Battery size: CR2032 (coin cell)
Battery type: Lithium
Additional Information
• This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive 2011/65/EC.
• This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.
• This product is in compliance with California Proposition 65 (State of California; Safe Drinking
Water and Toxic Enforcement Act of 1986).
• This product EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country.
See http://www.epeat.net for registration status by country. Search keyword generator on HP’s 3rd
party option store for solar generator accessories at http://www.hp.com/go/options.
• Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043.
• This product contains 0% post-consumer recycled plastic (by wt.)
• This product is 95.1% recycle-able when properly disposed of at end of life.
*Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit
http://www.epeat.net for more information.
Packaging Materials
External:
PAPER/Corrugated
1170 g
Internal:
PLASTIC/EPE (Expanded Polyethylene)
378 g
PLASTIC/Polyethylene low density
17 g
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer
to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
• Asbestos
• Certain Azo Colorants
• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Formaldehyde
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 33
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product packaging:
• Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.
• Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
• Design packaging materials for ease of disassembly.
• Maximize the use of post-consumer recycled content materials in packaging materials.
• Use readily recyclable packaging materials such as paper and corrugated materials.
• Reduce size and weight of packages to improve transportation fuel efficiency.
• Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
End-of-life Management
and Recycling
HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest
HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for
each product type for use by treatment facilities. This information (product disassembly
instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These
instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K
_Certificate.pdf
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
HP EliteOne 800 G5 23.8-in All-in-One
Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals and may
be labeled with one or more of these marks:
• IT ECO declaration
• US ENERGY STAR®
• EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See
http://www.epeat.net for registration status by country. Search keyword generator on HP’s 3rd
party option store for solar generator accessories at http://www.hp.com/go/options.
*Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit
http://www.epeat.net for more information.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Desktop model is based on a Typically Configured Desktop.
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation
(Short idle)
31.86
31.868
31.626
Normal Operation
(Long idle)
14.466
14.483
14.389
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 34
Sleep
4.049
4.082
3.971
Off
0.644
0.649
0.623
NOTE: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the
model family. HP computers marked with the ENERGY STAR® Logo are compliant with the
applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for
computers. If a model family does not offer ENERGY STAR® compliant configurations, then energy
efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency
power supply, and a Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 50Hz
Normal Operation
(Short idle)
108.6426
108.6699
107.8447
Normal Operation
(Long idle)
49.3291
49.387
49.0665
Sleep
13.8071
13.9196
13.5411
Off
2.196
2.2131
2.1244
NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured – Idle
2.9
21.0
Fixed Disk – Random writes
3.7
22.8
Longevity and Upgrading
This product can be upgraded, possibly extending its useful life by several years. Upgradeable
features and/or components contained in the product may include: storage, Memory and
processor.
Spare parts are available throughout the warranty period and or for up to “5” years after the end of
production.
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
Battery size: CR2032 (coin cell)
Battery type: Lithium
Additional Information
• This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive 2011/65/EC.
• This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.
• This product is in compliance with California Proposition 65 (State of California; Safe Drinking
Water and Toxic Enforcement Act of 1986).
• This product is in compliance with the IEEE 1680 (EPEAT) standard, see http://www.epeat.net for
registration status by country. Search keyword generator on HP’s 3rd party option store for solar
generator accessories at http://www.hp.com/go/options
• Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043.
• This product contains 0% post-consumer recycled plastic (by wt.)
• This product is 95.1% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Corrugated
Internal:
PLASTIC/EPE (Expanded Polyethylene)
PLASTIC/Polyethylene low density
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer
to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
• Asbestos
• Certain Azo Colorants
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 35
• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Formaldehyde
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product packaging:
• Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.
• Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
• Design packaging materials for ease of disassembly.
• Maximize the use of post-consumer recycled content materials in packaging materials.
• Use readily recyclable packaging materials such as paper and corrugated materials.
• Reduce size and weight of packages to improve transportation fuel efficiency.
• Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
End-of-life Management
and Recycling
HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest
HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for
each product type for use by treatment facilities. This information (product disassembly
instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These
instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K
_Certificate.pdf
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 36
HP EliteDesk 800 G5 Desktop Mini Business PC
Eco-Label Certifications &
declarations
This product has received or is in the process of being certified to the following approvals and may
be labeled with one or more of these marks:
• IT ECO declaration
• US ENERGY STAR®
• EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country. See
http://www.epeat.net for registration status by country. Search keyword generator on HP’s 3rd
party option store for solar generator accessories at http://www.hp.com/go/options.
*Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit
http://www.epeat.net for more information.
System Configuration
The configuration used for the Energy Consumption and Declared Noise Emissions data for the
Notebook model is based on a Typically Configured Notebook.
Energy Consumption
(in accordance with US
ENERGY STAR® test
method)
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
(Short idle)
13.279
13.514
13.115
Normal Operation
(Long idle)
13.116
13.275
12.889
Sleep
0.753
0.817
0.751
Off
0.69
0.746
0.689
NOTE: Energy efficiency data listed is for an ENERGY STAR® compliant product if offered within the
model family. HP computers marked with the ENERGY STAR® Logo are compliant with the
applicable U.S. Environmental Protection Agency (EPA) ENERGY STAR® specifications for
computers. If a model family does not offer ENERGY STAR® compliant configurations, then energy
efficiency data listed is for a typically configured PC featuring a hard disk drive, a high efficiency
power supply, and a Microsoft Windows® operating system.
Heat Dissipation*
115VAC, 60Hz
230VAC, 50Hz
100VAC, 60Hz
Normal Operation
(Short idle)
45.2814
46.0827
44.7222
Normal Operation
(Long idle)
44.7256
45.2678
43.9515
Sleep
2.5677
2.7860
2.5609
Off
2.3529
2.5439
2.3495
NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is
attained for one hour.
Declared Noise Emissions
(in accordance with
ISO 7779 and ISO 9296)
Sound Power
(L
WAd
, bels)
Sound Pressure
(L
pAm
, decibels)
Typically Configured – Idle
Fixed Disk – Random writes
Longevity and Upgrading
This product can be upgraded, possibly extending its useful life by several years. Upgradeable
features and/or components contained in the product may include:
Spare parts are available throughout the warranty period and or for up to “5” years after the end of
production.
Batteries
This battery(s) in this product comply with EU Directive 2006/66/EC
Batteries used in the product do not contain:
Mercury greater the1ppm by weight
Cadmium greater than 20ppm by weight
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 37
Battery size: CR2032 (coin cell)
Battery type: Lithium
Additional Information
• This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive 2011/65/EC.
• This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE)
Directive – 2002/96/EC.
• This product is in compliance with California Proposition 65 (State of California; Safe Drinking
Water and Toxic Enforcement Act of 1986).
• This product is in compliance with the IEEE 1680 (EPEAT) standard, see http://www.epeat.net for
registration status by country. Search keyword generator on HP’s 3rd party option store for solar
generator accessories at http://www.hp.com/go/options
• Plastics parts weighing over 25 grams used in the product are marked per ISO11469 and ISO1043.
• This product contains 0% post-consumer recycled plastic (by wt.)
• This product is 95.1% recycle-able when properly disposed of at end of life.
Packaging Materials
External:
PAPER/Corrugated
322 g
Internal:
PLASTIC/EPE (Expanded Polyethylene)
32 g
PLASTIC/Polyethylene low density
5 g
Material Usage
This product does not contain any of the following substances in excess of regulatory limits (refer
to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/gse.pdf):
• Asbestos
• Certain Azo Colorants
• Certain Brominated Flame Retardants – may not be used as flame retardants in plastics
• Cadmium
• Chlorinated Hydrocarbons
• Chlorinated Paraffins
• Formaldehyde
• Halogenated Diphenyl Methanes
• Lead carbonates and sulfates
• Lead and Lead compounds
• Mercuric Oxide Batteries
• Nickel – finishes must not be used on the external surface designed to be frequently handled or
carried by the user.
• Ozone Depleting Substances
• Polybrominated Biphenyls (PBBs)
• Polybrominated Biphenyl Ethers (PBBEs)
• Polybrominated Biphenyl Oxides (PBBOs)
• Polychlorinated Biphenyl (PCB)
• Polychlorinated Terphenyls (PCT)
• Polyvinyl Chloride (PVC) – except for wires and cables, and certain retail packaging has been
voluntarily removed from most applications.
• Radioactive Substances
• Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging Usage
HP follows these guidelines to decrease the environmental impact of product packaging:
• Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging
materials.
• Eliminate the use of ozone-depleting substances (ODS) in packaging materials.
• Design packaging materials for ease of disassembly.
• Maximize the use of post-consumer recycled content materials in packaging materials.
• Use readily recyclable packaging materials such as paper and corrugated materials.
• Reduce size and weight of packages to improve transportation fuel efficiency.
• Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 38
End-of-life Management
and Recycling
HP Inc. offers end-of-life HP product return and recycling programs in many geographic areas. To
recycle your product, please go to: http://www.hp.com/go/reuse-recycle or contact your nearest
HP sales office. Products returned to HP will be recycled, recovered or disposed of in a responsible
manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for
each product type for use by treatment facilities. This information (product disassembly
instructions) is posted on the Hewlett Packard web site at: http://www.hp.com/go/recyclers. These
instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www8.hp.com/us/en/hp-information/environment/ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/PC_GBU_Product_Design_ISO_14K
_Certificate.pdf
and
http://www.hp.com/hpinfo/globalcitizenship/environment/pdf/cert.pdf
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 39
SERVICE AND SUPPORT
HP EliteDesk 800 G5 Tower Business PC
On-site Warranty15: Three-year (3-3-3) limited warranty delivers three years of on-site, next business day16 service for parts
and labor and includes free support 24 x 717. Three-year onsite and labor are not available in all countries. Service offers
terms up to 5 years by choosing an optional HP Care Pack. To choose the right level of service for your HP product, visit HP
Care Pack Central: http://www.hp.com/go/cpc.18
15. Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other warranty variations may be offered in your
region.
16. On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and is not
available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.
17. Technical telephone support applies only to HP-configured and third-party HP qualified hardware and software. Toll-free calling and 24
x 7 support may not be available in some countries.
18. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of
hardware purchase. Restrictions and limitations apply. For details, visit www.hp.com/go/cpc. HP services are governed by the applicable HP
terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory rights
according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited
Warranty provided with your HP Product.
HP EliteDesk 800 G5 Small Form Factor Business PC
On-site Warranty15: Three-year (3-3-3) limited warranty delivers three years of on-site, next business day16 service for parts
and labor and includes free support 24 x 717. Three-year onsite and labor are not available in all countries. Service offers
terms up to 5 years by choosing an optional HP Care Pack. To choose the right level of service for your HP product, visit HP
Care Pack Central: http://www.hp.com/go/cpc.18
15. Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other warranty variations may be offered in your
region.
16. On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and is not
available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.
17. Technical telephone support applies only to HP-configured and third-party HP qualified hardware and software. Toll-free calling and 24
x 7 support may not be available in some countries.
18. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of
hardware purchase. Restrictions and limitations apply. For details, visit www.hp.com/go/cpc. HP services are governed by the applicable HP
terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory rights
according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited
Warranty provided with your HP Product.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 40
HP EliteDesk 800 G5 Desktop Mini Business PC
On-site Warranty15: Three-year (3-3-3) limited warranty delivers three years of on-site, next business day16 service for parts
and labor and includes free support 24 x 717. Three-year onsite and labor are not available in all countries. Service offers
terms up to 5 years by choosing an optional HP Care Pack. To choose the right level of service for your HP product, visit HP
Care Pack Central: http://www.hp.com/go/cpc.18
15. Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other warranty variations may be offered in your
region.
16. On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and is not
available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.
17. Technical telephone support applies only to HP-configured and third-party HP qualified hardware and software. Toll-free calling and 24
x 7 support may not be available in some countries.
18. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of
hardware purchase. Restrictions and limitations apply. For details, visit www.hp.com/go/cpc. HP services are governed by the applicable HP
terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory rights
according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited
Warranty provided with your HP Product.
HP EliteOne 800 G5 All-in-One Business PC
On-site Warranty15: Three-year (3-3-3) limited warranty delivers three years of on-site, next business day16 service for parts
and labor and includes free support 24 x 717. Three-year onsite and labor are not available in all countries. Service offers
terms up to 5 years by choosing an optional HP Care Pack. To choose the right level of service for your HP product, visit HP
Care Pack Central: http://www.hp.com/go/cpc.18
15. Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other warranty variations may be offered in your
region.
16. On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and is not
available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.
17. Technical telephone support applies only to HP-configured and third-party HP qualified hardware and software. Toll-free calling and 24
x 7 support may not be available in some countries.
18. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of
hardware purchase. Restrictions and limitations apply. For details, visit www.hp.com/go/cpc. HP services are governed by the applicable HP
terms and conditions of service provided or indicated to Customer at the time of purchase. Customer may have additional statutory rights
according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited
Warranty provided with your HP Product.
CERTIFICATION AND COMPLIANCE
Energy Efficiency Compliance
ENERGY STAR® certified; EPEAT® 2019 registered where applicable. EPEAT ® registration varies by country.See
http://www.epeat.net for registration status by country
19
19. *Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit http://www.epeat.net for more
information.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Processors
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 41
PROCESSORS
Intel® 8th and 9th Generation Core™ Processors
All HP EliteDesk 800 G5 Business PC models featuring this technology include processors that are part of the Intel® Stable
Image Platform Program (SIPP) designed to ensure the stability promise inherent in the value proposition of the HP EliteDesk
and EliteOne 800 G5 Business PC.
Intel® Advanced Management Technology (AMT) v12 – An advanced set of remote management features and functionality
which provides network administrators the latest and most effective tools to remotely discover, heal, and protect networked
client systems regardless of the system's health or power state. AMT 12 includes the following advanced management
functions:
• Support for configuration of Intel AMT 12.0 new capabilities
• No reset after provisioning
• Support changes to BIOS table 130
• Support for Microsoft Windows Server 2012 R2
• Support for New Microsoft SQL Server Versions including Standard and Enterprise editions
• Support for Intel SSD Prop 2500 Series
• Support for Intel Enterprise Digital Fence
• The Platform Discovery Utility can now discover these additional Intel products:
• Intel SSD Pro 2500 Series; Enterprise Digital Fence
• Intel Identity Protection Technology with One Time Password; Public Key Infrastructure; Multi Factor Authentication
• Intel Identity Protection Technology with Intel WiGig
• New Profile Editor and Profile Editor Plugin Interface
• New Required Permissions for Solutions Framework
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Display Panel Specifications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 42
DISPLAY PANEL SPECIFICATIONS
23.8" diagonal IPS widescreen WLED backlit anti-glare LCD (1920 x 1080) non-touch or optional touch
Projected Capacitive Touch supports up to 10 touch-points
Type
IPS WLED Backlit LCD
Active area (mm)
527.04 x 296.46
Native Resolution (HxV)
1920 x 1080
Refresh Rate
60 Hz @ 1920 x 1080
Aspect ratio
16:9
Pixel pitch (HxV)(mm)
0.2745 x 0.2745
Contrast ratio (typical)
1000:1
Brightness (typical)
250nits
Viewing angle (typical) (HxV)
178 ° x 178 °
Backlight lamp life (to half brightness)
30,000 hours minimum
Color support
Up to 16.7 million colors with the use of FRC technology
Color gamut (typical)
NTSC 72%
Anti-glare
Yes*
Response Time
14ms (Typical)
Default color temperature
Warm (6500K)
23.8" diagonal IPS widescreen WLED backlit anti-glare LCD (1920 x 1080) with HP Sure View (optional)
Type
IPS WLED Backlit LCD
Active area (mm)
527.04 x 296.46
Native Resolution (HxV)
1920 x 1080
Refresh Rate
60 Hz @ 1920 x 1080
Aspect ratio
16:9
Pixel pitch (HxV)(mm)
0.2745 x 0.2745
Contrast ratio (typical)
1000:1
Brightness (typical)
285 nits (non-Privacy); 400 nits (Privacy)
Viewing angle (typical) (HxV)
178° x 178° (non-Privacy); 80° x 178° (Privacy)
Backlight lamp life (to half brightness)
30,000 hours minimum
Color support
Up to 16.7 million colors with the use of FRC technology
Color gamut (typical)
NTSC 72%
Anti-glare
Yes*
Response Time
14ms (Typical)
Default color temperature
Warm (6500K)
1. All performance specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either higher or
lower.
2. For All in One only
Intel® HD Graphics (integrated)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Display Panel Specifications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 43
Adjustable Height Stand:
Height - Vertical/Landscape Adjustment
101mm (±2 mm)
Portrait Adjustment
54mm (±2 mm)
Tilt Angle
-5° to +20° (±3°) in landscape and portrait
Rotation (Swivel)
90° (±1°)
Pivot
Clockwise 90°
Recline Stand:
Height - Vertical Adjustment
178 mm (±2 mm)
Tilt Angle
-5° to +65° (+/-3°)
Rotation (swivel)
360° swivel
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Graphics
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 44
GRAPHICS
HP EliteDesk 800 G5 Desktop Mini Business PC
Intel® HD Graphics (integrated)
VGA Controller
Integrated
DisplayPort™ 1.2
Multimode capable; supports HDCP, Display Port Audio (2 streams), HBR2 link rates and MultiStream Technology for a maximum of 3 displays connected to any output controlled by Intel®
Graphics
HDMI (optional)
Supports HDMI 2.0a features
Supports HDCP 2.2
Supports audio over HDMI
VGA (optional)
VGA output
USB-C™ DP Alt Mode (optional)
DisplayPort over the optional USB-C™ module
Memory
The actual amount of maximum graphics memory can be >4GB. System memory is allocated
for graphics as needed using Intel's Dynamic Video Memory Technology (DVMT), to provide an
optimal balance between graphics and system memory use.
Maximum Color Depth
up to 10 bits/color
Graphics/Video API Support
HEVC 10b Enc/Dec HW
VP9 10b Dec HW
HDR
Rec. 2020
DX12
Max. Resolution (VGA)
2048 x 1536@60Hz
Max. Resolution (HDMI)
4096 x 2160@60Hz
Max. Resolution (DP)
4096 x 2160@60Hz
AMD® Radeon™ RX 560X
Architecture
Discrete GPU
AMD® GPU drives the integrated panel and all of the graphics output ports
DisplayPort
Multimode capable; supports HDCP, HDR, Display Port Audio (6 streams max), DisplayPort HBR3
link rates and Multi-Stream Technology for a maximum of 5 displays (including the integrated
panel and all attached displays)
HDMI
Supports HDMI 2.0b features
Supports HDCP 2.2, HDR
Memory
4GByte, 128bit wide GDDR5
Maximum Color Depth
up to 12 bits/color
Graphics/Video API Support
DirectX 12
OpenCL 2.0
OpenGL 4.5
AMD® Unified Video Decoder (UVD)
Rear I/O connector
1 DP
Max. Resolution (VGA)
2048 x 1536@60Hz
Max. Resolution (HDMI)
4096 x 2160@60Hz
Max. Resolution (DP)
5120 x 2880@60Hz
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Graphics
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 45
HP EliteDesk 800 G5 Tower Business PC
Intel® UHD Graphics (integrated)
VGA Controller
Integrated
DisplayPort™ 1.2
Multimode capable; supports HDCP, Display Port Audio (2 streams), HBR2 link rates and MultiStream Technology for a maximum of 3 displays connected to any output controlled by Intel®
Graphics
HDMI (optional)
Supports HDMI 2.0a features
Supports HDCP 2.2
Supports BT2020 and HDR playback (7th Gen processors only)
VGA (optional)
VGA ouput
USB-C™ DP Alt Mode
(optional)
DisplayPort over the optional USB-C™ module
Memory
The actual amount of maximum graphics memory can be >4GB. System memory is allocated
for graphics as needed using Intel's Dynamic Video Memory Technology (DVMT), to provide an
optimal balance between graphics and system memory use.
Maximum Color Depth
up to 10 bits/color
Graphics/Video API Support
HEVC 10b Enc/Dec HW
VP9 10b Dec HW
HDR
Rec. 2020
DX12
34" UHD Supported
Resolutions and Refresh
Rates. Other resolutions may
also work.
640x480 60 Hz640x480 67Hz
640x480 72Hz
640x480 75Hz
720x400 70Hz
800x600 60Hz
800x600 75Hz
1024x768 60Hz
1024x768 75Hz
1280x960 60Hz
1280x720 60Hz
1280x1024 60Hz
1280x1024 75Hz
1440x900 60Hz
1440x900 75Hz
1680x1050 60Hz
1920x1080 60Hz
3440x1440 60Hz (Native Resolution)
3440x1440 30Hz
Max. Resolution (VGA)
2048 x 1536@60Hz
Max. Resolution (HDMI)
4096 x 2160@60Hz
Max. Resolution (DP)
4096 x 2160@60Hz
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Graphics
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 46
NVIDIA® GeForce® GT730 2GB DP DVI PCIe x8 GFX
Engine Clock
902 MHz
Memory Clock
1250 MHz
Memory Size(width)
2 GB (64-bit)
Memory Type
256Mx32 GDDR5
Max. Resolution(DVI)
2560 x 1600 x 30 bpp @ 60Hz (Dual Link)
Max. Resolution(DP)
4096 x 2160 x 24 bpp @ 60 Hz (DP1.2)
Multi Display Support
Up to 2 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
DL DVI-I + DP
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
35 W
PCB form-factor with bracket
2-pin fan connector for fan sink power/speed control
NVIDIA® GeForce® RTX 2060 6 GB Graphics Card
Engine Clock
1680 MHz
Memory Clock
7000 MHz
Memory Size(width)
6 GB(192-bit)
Memory Type
256M x 32 GDDR6
Max. Resolution(DVI)
2560x1600@60Hz
Max. Resolution(HDMI)
4096x2160@60Hz
Max. Resolution(DP)
7680x4320@60Hz
Multi Display Support
3 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
DVI+HDMI+DP
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<170W
PCB form-factor with bracket
ATX (Full height) PCB with ATX dual slot bracket
AMD® Radeon™ RX 550X 4 GB FH PCIe x16
Engine Clock
1183MHz
Memory Clock
6 Gbps
Memory Size(width)
4 GB(128-bit)
Memory Type
GDDR5
Max. Resolution(HDMI)
4096x2160 @ 60Hz
Max. Resolution(DP)
5120x2880 @ 60Hz
Multi Display Support
2 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
HDMI, DPx2
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<50W
PCB form-factor with bracket
LP (low profile) PCB with FH/LP bracket
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Graphics
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 47
AMD® Radeon™ RX 580 8GB GDDR5 Graphics Card
Engine Clock
1266 MHz
Memory Clock
4000 MHz
Memory Size(width)
8 GB (256-bit)
Memory Type
256M x 32 GDDR5
Max. Resolution(HDMI)
4096x2160@60Hz
Max. Resolution(DP)
5120x3200@60Hz
Multi Display Support
4 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
HDMI + DPx3
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<150W
PCB form-factor with bracket
ATX (Full height) PCB with ATX dual slot bracket
NVIDIA® GeForce® RTX 2080 8GB GDDR6
Engine Clock
1710 MHz
Memory Clock
7000 MHz
Memory Size(width)
8GB (256-bit)
Memory Type
256M x 32 GDDR6
Max. Resolution(Virtual Link)
3840 x 2160@60Hz
Max. Resolution(HDMI)
4096 x 2160@60Hz
Max. Resolution(DP)
7680 x 4320@60Hz
Multi Display Support
4 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
DPx3 + HDMI + Virtual Link
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<250W
PCB form-factor with bracket
ATX (Full height) PCB with ATX dual slot bracket
NVIDIA® GeForce® RTX 2070 8GB GDDR6
Engine Clock
1620 MHz
Memory Clock
7000 MHz
Memory Size(width)
8GB (256-bit)
Memory Type
256M x 32 GDDR6
Max. Resolution(Virtual Link)
3840 x 2160@60Hz
Max. Resolution(HDMI)
4096 x 2160@60Hz
Max. Resolution(DP)
7680 x 4320@60Hz
Multi Display Support
4 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
DPx2 + HDMI + DVI+Virtual Link
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<210W
PCB form-factor with bracket
ATX (Full height) PCB with ATX dual slot bracket
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Graphics
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 48
NVIDIA® GeForce® RTX 2070 Super 8GB Graphics Card
Engine Clock
1770 MHz
Memory Clock
7000 MHz
Memory Size(width)
8 GB(256-bit)
Memory Type
256M x 32 GDDR6
Max. Resolution(Virtual Link)
3840*2160@60Hz
Max. Resolution(HDMI)
7680x4320@60Hz
Max. Resolution(DP)
4 displays
Multi Display Support
Yes
HDCP Compliance
DPx3 + HDMI + Virtual Link(USB-C)
Rear I/O connectors(bracket)
Active fan-sink (Active cooling with dynamic speed)
Cooling(active/passive)
Total 250W (with USB-C)/215 W (GFX)
Total power consumption(W)
ATX (Full height) PCB with ATX dual slot bracket
PCB form-factor with bracket
1770 MHz
NVIDIA® Quadro P620 2GB Graphics Card
Engine Clock
1354 MHz
Memory Clock
2500 MHz
Memory Size(width)
2GB (128-bit)
Memory Type
128M x 32 GDDR5
Max. Resolution(DP)
5120x2880@60Hz
Multi Display Support
4 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
mDPx4
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<40W
PCB form-factor with bracket
LP PCB with LP bracket
NVIDIA® Quadro® P1000 4GB Graphics Card
Engine Clock
1455 MHz
Memory Clock
2500 MHz
Memory Size(width)
4 GB (128-bit)
Memory Type
256M x 32 GDDR5
Max. Resolution(HDMI)
Not Available
Max. Resolution(DP)
5120x2880@60Hz
Multi Display Support
4 independent displays
HDCP Compliance
Yes, HDCP 2.2
Rear I/O connectors(bracket)
4x mDP 1.4
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
47W
PCB form-factor with bracket
Single Slot, Low Profile
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Graphics
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 49
NVIDIA® Quadro P400 2GB Graphics Card
Engine Clock
1252 MHz
Memory Clock
2000 MHz
Memory Size(width)
2GB (64-bit)
Memory Type
256M x 32 GDDR5
Max. Resolution(DP)
5120x2880@60Hz
Multi Display Support
3 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
mDPx3
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<30W
PCB form-factor with bracket
LP PCB with LP bracket
AMD® Radeon™ R7 430 2GB VGA+DP 64bit Graphics Card
Engine Clock
780 MHz
Memory Clock
1100 MHz
Memory Size(width)
2 GB(64-bit)
Memory Type
256M x 32 GDDR5
Max. Resolution(HDMI)
2048x1536
Max. Resolution(DP)
4096x2160@60Hz
Multi Display Support
2 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
VGA+DP
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<50W
PCB form-factor with bracket
LP PCB with FH/LP bracket
AMD® Radeon™ R7 430 2GB GDDR5 2DP 64 bit Graphics Card
Engine Clock
780 MHz
Memory Clock
1100 MHz
Memory Size(width)
2 GB(64-bit)
Memory Type
256M x 32 GDDR5
Max. Resolution(DP)
4096x2160@60Hz
Multi Display Support
2 displays
HDCP Compliance
yes
Rear I/O connectors(bracket)
DPx2
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<50W
PCB form-factor with bracket
LP PCB with FH/LP bracket
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Graphics
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 50
HP EliteDesk 800 G5 Small Form Factor Business PC
Intel® HD Graphics (integrated)
VGA Controller
Integrated
DisplayPort™ 1.2
Multimode capable; supports HDCP, Display Port Audio (2 streams), HBR2 link rates and
Multi-Stream Technology for a maximum of 3 displays connected to any output controlled by
Intel® Graphics
HDMI (optional)
Supports HDMI 2.0a features
Supports HDCP 2.2
Supports audio over HDMI
VGA (optional)
VGA Output
USB-C™ DP Alt Mode (optional)
DisplayPort over the optional USB-C™ module
Memory
The actual amount of maximum graphics memory can be >4GB. System memory is allocated
for graphics as needed using Intel's Dynamic Video Memory Technology (DVMT), to provide
an optimal balance between graphics and system memory use.
Maximum Color Depth
up to 10 bits/color
Graphics/Video API Support
HEVC 10b Enc/Dec HW
VP9 10b Dec HW
HDR
Rec. 2020
DX12
Max. Resolution (VGA)
2048 x 1536@60Hz
Max. Resolution (HDMI)
4096 x 2160@60Hz
Max. Resolution (DP)
4096 x 2160@60Hz
AMD® Radeon™ R7 430 2GB VGA+DP 64bit Graphics Card
Engine Clock
780 MHz
Memory Clock
1100 MHz
Memory Size(width)
1 GB(64-bit)
Memory Type
256M x 32 GDDR5
Max. Resolution(HDMI)
2048x1536
Max. Resolution(DP)
4096x2160@60Hz
Multi Display Support
2 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
VGA+DP
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<50W
PCB form-factor with bracket
LP PCB with FH/LP bracket
AMD® Radeon™ R7 430 2GB GDDR5 2DP 64 bit Graphics Card
Engine Clock
780 MHz
Memory Clock
1100 MHz
Memory Size(width)
1 GB(64-bit)
Memory Type
256M x 32 GDDR5
Max. Resolution(DP)
4096x2160@60Hz
Multi Display Support
2 displays
HDCP Compliance
yes
Rear I/O connectors(bracket)
DPx2
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Graphics
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 51
Total power consumption(W)
<50W
PCB form-factor with bracket
LP PCB with FH/LP bracket
NVIDIA® GeForce® GT730 2GB DP DVI PCIe x8 GFX
Engine Clock
902 MHz
Memory Clock
1250 MHz
Memory Size(width)
2 GB (64-bit)
Memory Type
256Mx32 GDDR5
Max. Resolution(DVI)
2560 x 1600 x 30 bpp @ 60Hz (Dual Link)
Max. Resolution(DP)
4096 x 2160 x 24 bpp @ 60 Hz (DP1.2)
Multi Display Support
Up to 2 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
DL DVI-I + DP
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
35 W
PCB form-factor with bracket
2-pin fan connector for fan sink power/speed control
AMD® Radeon™ RX550 4 GB PCIe x16
Engine Clock
1183MHz
Memory Clock
6 Gbps
Memory Size(width)
4 GB(128-bit)
Memory Type
GDDR5
Max. Resolution(HDMI)
4096x2160 @ 60Hz
Max. Resolution(DP)
5120x2880 @ 60Hz
Multi Display Support
2 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
HDMI, DP
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<50W
PCB form-factor with bracket
LP (low profile) PCB with FH/LP bracket
AMD Radeon™ 520 1GB Graphics Card
Engine Clock
780 MHz
Memory Clock
1100 MHz
Memory Size(width)
1 GB (32-bit)
Memory Type
256M x 32 GDDR5
Max. Resolution(DP)
2048x1536@60Hz
Multi Display Support
2 displays
HDCP Compliance
Yes
Rear I/O connectors(bracket)
VGA+DP
Cooling(active/passive)
Active fan-sink (Active cooling with dynamic speed)
Total power consumption(W)
<50W
PCB form-factor with bracket
LP PCB with FH/LP bracket
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Graphics
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 52
HP EliteOne 800 G5 23.8-in All-in-One
Intel® UHD Graphics (integrated)
VGA Controller
Integrated
DisplayPort™ 1.2
Multimode capable; supports HDCP, Display Port Audio (2 streams), HBR2 link rates and MultiStream Technology for a maximum of 3 displays (including the integrated panel and all
attached displays)
HDMI
Supports HDMI 2.0a features
Supports HDCP 2.2
Supports audio over HDMI
Memory
The actual amount of maximum graphics memory can be >4GB. System memory is allocated
for graphics as needed using Intel's Dynamic Video Memory Technology (DVMT), to provide an
optimal balance between graphics and system memory use.
Maximum Color Depth
up to 10 bits/color
Graphics/Video API Support
HEVC 10b Enc/Dec HW
VP9 10b Dec HW
HDR
Rec. 2020
DX12
Max. Resolution (VGA)
2048 x 1536@60Hz
Max. Resolution (HDMI)
4096 x 2160@60Hz
Max. Resolution (DP)
4096 x 2160@60Hz
AMD® Radeon™ RX 560X
Architecture
Discrete GPU
AMD® GPU drives the integrated panel and all of the graphics output ports
DisplayPort
Multimode capable; supports HDCP, HDR, Display Port Audio (6 streams max), DisplayPort HBR3
link rates and Multi-Stream Technology for a maximum of 5 displays (including the integrated
panel and all attached displays)
HDMI
Supports HDMI 2.0b features
Supports HDCP 2.2, HDR
Memory
4GByte, 128bit wide GDDR5
Maximum Color Depth
up to 12 bits/color
Graphics/Video API Support
DirectX 12
OpenCL 2.0
OpenGL 4.5
AMD® Unified Video Decoder (UVD)
Rear I/O connector
1 DP
Max. Resolution (VGA)
2048 x 1536@60Hz
Max. Resolution (HDMI)
4096 x 2160@60Hz
Max. Resolution (DP)
5120 x 2880@60Hz
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 53
STORAGE
500 GB 7200RPM 3.5in SATA HDD
Capacity
500 GB
Rotational Speed
7,200 rpm
Interface
SATA 6.0 Gb/s
Buffer Size
32 MB
Logical Blocks
976,773,168
Seek Time
11 ms (Average)
Height
1 in/2.54 cm
Width
Media diameter: 3.5 in/8.89 cm
Physical size: 4 in/10.2 cm
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
1 TB 7200RPM 3.5in SATA HDD
Capacity
1 TB
Rotational Speed
7,200 rpm
Interface
SATA 6 Gb/s
Buffer Size
64 MB
Logical Blocks
1,953,525,168
Seek Time
11 ms (Average)
Height
1 in/2.54 cm
Width (nominal)
Media diameter: 3.5 in/8.89 cm
Physical size: 4 in/10.2 cm
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
2 TB 7200RPM 3.5in SATA HDD
Capacity
2 TB
Rotational Speed
7,200 rpm
Interface
SATA 6 Gb/s
Buffer Size
64 MB
Logical Blocks
1,953,525,168
Seek Time
11 ms (Average)
Height
1.028 in/26.11 mm
Width (nominal)
4.0 in/101.6 mm
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 54
500 GB 7200RPM 2.5in SATA HDD
Capacity
500 GB
Rotational Speed
7,200 rpm
Interface
SATA 6 Gb/s
Buffer Size
32 MB
Logical Blocks
976,773,168
Seek Time
12 ms (Average)
Height
0.267 in/6.8 mm (nominal)
Width (nominal)
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
1 TB 7200RPM 2.5in SATA HDD
Capacity
1 TB
Rotational Speed
7,200 rpm
Interface
SATA 6 Gb/s
Buffer Size
32 MB
Logical Blocks
1,953,525,168
Seek Time
12 ms (Average)
Height
0.374 in/9.5 mm (nominal)
Width (nominal)
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
2 TB 5400RPM 2.5in SATA HDD
Capacity
2 TB
Rotational Speed
5,400 rpm
Interface
SATA 6 Gb/s
Buffer Size
128 MB
Logical Blocks
3,907,050,336
Seek Time
12 ms (Average)
Height
0.374 in/9.5 mm (nominal)
Width (nominal)
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 55
500 GB 7200RPM 2.5in Self Encrypted OPAL2 SATA HDD
Capacity
500 GB
Architecture
Self-Encrypting (SED) Solid State Drive with SATA interface
Interface
SATA 6 Gb/s
Buffer Size
32 MB
Logical Blocks
976,773,168
Seek Time
12 ms (Average)
Height
0.267 in/6.8 mm (nominal)
Width
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
500 GB 7200RPM 2.5in Self Encrypted Federal Information Processing Standard SATA HDD
Capacity
500 GB
Architecture
Self-Encrypting (SED) Solid State Drive with SATA interface
Interface
SATA 6 Gb/s
Buffer Size
32 MB
Logical Blocks
976,773,168
Seek Time
12 ms (Average)
Height
0.267 in/6.8 mm (nominal)
Width
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
500 GB 5400RPM 2.5in SATA SSHD
Capacity
500 GB
Rotational Speed
5,400 rpm
Drive Type
Solid State Hybrid Drive (SSHD) technology with NAND Flash
Interface
SATA 6 Gb/s
Buffer Size
64 MB
NAND Flash
8 GB
Seek Time
12 ms (Average)
Height
0.267 in/6.8 mm (nominal)
Width
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 56
1 TB 5400RPM 2.5in SATA SSHD
Capacity
1 TB
Rotational Speed
5,400 rpm
Drive Type
Solid State Hybrid Drive (SSHD) technology with NAND Flash
Interface
SATA 6 Gb/s
Buffer Size
64 MB
NAND Flash
8 GB
Seek Time
12 ms (Average)
Height
0.374 in/9.5 mm (nominal)
Width
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
2 TB 5400RPM 2.5in SATA SSHD
Capacity
2 TB
Rotational Speed
5,400 rpm
Drive Type
Solid State Hybrid Drive (SSHD) technology with NAND Flash
Interface
SATA 6 Gb/s
Buffer Size
128 MB
NAND Flash
8 GB
Seek Time
12 ms (Average)
Height
0.374 in/9.5 mm (nominal)
Width
2.75 in/70 mm (nominal)
Operating Temperature
41° to 131° F (5° to 55° C)
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
128 GB 2.5in SATA Three Layer Cell SSD
Drive Weight
<50g
Capacity
128 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 380MB/s
Logical Blocks
250,069,680
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 57
256 GB 2.5in SATA Three Layer Cell SSD
Drive Weight
<62g
Capacity
256 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 450MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
512 GB 2.5in SATA Three Layer Cell SSD
Drive Weight
<50g
Capacity
512 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 500MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
256 GB 2.5in SATA Self Encrypted OPAL2 Three Layer Cell SSD
Drive Weight
<50g
Capacity
256 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 500MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM; TCG-OPAL2.0 security
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 58
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
512 GB 2.5in SATA Self Encrypted OPAL2 Three Layer Cell SSD
Drive Weight
<50g
Capacity
512 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 500MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM; TCG-OPAL2.0 security
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
256 GB 2.5in SATA Self Encrypted Federal Information Processing Standard SSD
Drive Weight
<40g
Capacity
256 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 500MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM; FIPS 140-2 security
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 59
512 GB 2.5in SATA Self Encrypted Federal Information Processing Standard SSD
Drive Weight
<45g
Capacity
512 GB
Height
7mm
Length
100.45mm
Width
69.85mm
Interface
SATA 3.0 (6Gb/s)
Maximum Sequential Read
Up to 530MB/s
Maximum Sequential Write
Up to 500MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
DIPM; TRIM; FIPS 140-2 security
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
128 GB M.2 2280 PCIe NVMe SSD
Drive Weight
< 10g
Capacity
128GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Maximum Sequential Read
Up to 1400MB/s
Maximum Sequential Write
Up to 395MB/s
Logical Blocks
250,069,680
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
256 GB M.2 2280 PCIe NVMe SSD
Drive Weight
< 10g
Capacity
256 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Maximum Sequential Read
Up to 1600MB/s
Maximum Sequential Write
Up to 780MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 60
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
512 GB M.2 2280 PCIe NVMe SSD
Drive Weight
< 10g
Capacity
512 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Maximum Sequential Read
Up to 1600MB/s
Maximum Sequential Write
Up to 860MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
1 TB M.2 2280 PCIe NVMe SSD
Drive Weight
< 10g
Capacity
1 TB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Maximum Sequential Read
Up to 1800MB/s
Maximum Sequential Write
Up to 1800MB/s
Logical Blocks
2,000,409,264
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
TRIM; ASPM L1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
128 GB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
128 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2800MB/s
Maximum Sequential Write
Up to 600MB/s
Logical Blocks
250,069,680
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 61
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
256 GB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
256GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2700MB/s
Maximum Sequential Write
Up to 1000MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
512 GB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
512 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2900MB/s
Maximum Sequential Write
Up to 1100MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
1 TB M.2 2280 PCIe NVMe Three Layer Cell SSD
Drive Weight
< 10g
Capacity
1 TB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 62
Maximum Sequential Read
Up to 3480MB/s
Maximum Sequential Write
Up to 3037MB/s
Logical Blocks
2,000,409,264
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
TRIM; ASPM L1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
256 GB M.2 2280 PCIe NVMe Self Encrypted OPAL2 Three Layer Cell SSD
Drive Weight
< 10g
Capacity
256 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2700MB/s
Maximum Sequential Write
Up to 1000MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2; TCG-OPAL2 security
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
512 GB M.2 2280 PCIe NVMe Self Encrypted OPAL2 Three Layer Cell SSD
Drive Weight
< 10g
Capacity
512 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2900MB/s
Maximum Sequential Write
Up to 1100MB/s
Logical Blocks
1,000,215,216
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2; TCG-OPAL2 security
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 63
256GB Intel® Optane™ Memory H10 with Solid State Storage
Drive Weight
< 10g
Capacity
256 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Maximum Sequential Read
Up to 1450MB/s
Maximum Sequential Write
Up to 500MB/s
Logical Blocks
500,118,192
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
TRIM; ASPM L1.2
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
512 GB Intel® PCIe® NVMe™ QLC + 32 GB Intel® Optane™
Drive Weight
< 10g
Capacity
512 GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3x4
Maximum Sequential Read
Up to 2400MB/s
Maximum Sequential Write
Up to 1300MB/s
Logical Blocks
1,000,215,215
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
TRIM; ASPM L1.2
NOTE: For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10) is
reserved for system recovery software. Not available with eMMC Base Units. Intel® Optane™ SSD is sold separately. Intel® Optane™ SSD system
acceleration does not replace or increase the DRAM in your system. Available for HP commercial desktops and notebooks and for select HP
workstations and requires a SATA HDD, 7th Gen or higher Intel® Core™ processor or Intel ® Xeon® processor E3-1200 V6 product family or higher,
BIOS version with Intel® Optane™ supported, Windows 10 version 1703 or higher, M.2 type 2280-S1-B-M connector on a PCH Remapped PCIe
Controller and Lanes in x2 or x4 configuration with B-M keys that meet NVMeTM Spec 1.1, and an Intel® Rapid Storage Technology (Intel® RST)
15.5 driver.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 64
HP 9.5mm Slim DVD-ROM Drive
Height
9.5 mm height
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Dimensions (W x H x D)
5.04 x 0.37 x 5.0 in (128 x 9.5 x 127 mm) without bezel
Weight (max)
Up to 0.31 lb (140g) without bezel
Read Speeds
DVD+R/-R/+RW/
-RW/+R DL /-R DL Up to 8X
DVD-ROM Up to 8X
CD-ROM, CD-R Up to 24X
CD-RW Up to 24X
Access time
(typical reads, including
settling)
Random: DVD-ROM: 170 ms (typical), CD-ROM: 170 ms (typical)
Full stroke: DVD-ROM: 320 ms (typical), CD-ROM: 320 ms (typical)
Power
Source Slimline SATA DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC (< 1000 mA typical, 1600 mA maximum)
Environmental conditions
(operating - non-condensing)
Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 80%
Maximum Wet Bulb Temperature 84° F (29° C)
HP 9.5mm Slim DVD Writer Drive
Height
9.5 mm height
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc recording capacity
Up to 8.5 GB DL or 4.7 GB standard
Dimensions (W x H x D)
5.04 x 0.37 x 5.0 in (128 x 9.5 x 127 mm) without bezel
Weight (max)
0.31 lb (140 g)
Write Speeds
DVD-R DL - Up to 6X
DVD+R - Up to 8X
DVD+RW - Up to 8X
DVD+R DL - Up to 6X
DVD-R - Up to 8X
DVD-RW - Up to 6X
CD-R - Up to 24X
CD-RW - Up to 10X
DVD-RW, DVD+RW - Up to 8X
Read Speeds
DVD-R DL, DVD+R DL - Up to 8X
DVD+R, DVD-R - Up to 8X
DVD-ROM DL, DVD-ROM - Up to 8X
CD-ROM, CD-R - Up to 24X
CD-RW - Up to 24X
Access time
(typical reads, including
settling)
Random DVD-ROM: 170 ms (typical), CD-ROM: 170 ms (typical)
Full Stroke DVD-ROM: 320 ms (typical), CD-ROM: 320 ms (typical)
Stop Time 6 seconds (typical)
Power
Source Slimline SATA DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC (< 1000 mA typical, 1600 mA maximum)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Storage
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 65
Environmental conditions
(operating - non-condensing)
Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 80%
Maximum Wet Bulb Temperature 84° F (29° C)
HP 9.5mm Slim Blu-Ray Writer Drive
Height
9.5 mm height
Orientation
Either horizontal or vertical
Interface type
SATA/ATAPI
Disc recording capacity
Up to 128 GB QL, 100 GB TL, 50 GB DL or 25 GB standard SL
Dimensions (W x H x D)
5.04 x 0.37 x 5.0 in (128 x 9.5 x 127 mm) without bezel
Weight (max)
0.29 lb (132 g)
Write Speeds
BD-R SL/DL Up to 6X
BD-R TL/QL Up to 4X
BD-R Up to 6X
BD-RE Up to 2X
DVD-R Up to 8X
DVD-R DL - Up to 6X
DVD-RW Up to 6X
DVD+R Up to 8X
DVD+R DL - Up to 6X
DVD+RW Up to 8X
DVD-RAM Up to 5X
CD-R Up to 24X
CD-RW Up to 10X
Read Speeds
BD-ROM Up to 6X
BD-R Up to 6X
BD-RE SL/DL Up to 6X
BD-RE TL Up to 4X
DVD-ROM Up to 8X
DVD-R SL/DL Up to 8X
DVD-R Up to 8X
DVD-RW Up to 8X
DVD+R SL/DL Up to 8X
DVD+R Up to 8X
DVD+RW Up to 8X
BDMV (AACS Compliant Disc)
Up to 6x/2x (Read/Play)
DVD-RAM Up to 5x
DVD-Video (CSS Compliant Disc)
Up to 8x/4x (Read/Play)
CD-R/RW/ROM Up to 24x
CD-DA (DAE) Up to 24X/10X (Read/Play)
Access time
(typical reads, including
settling)
Random BD-ROM: 205 ms (typical), DVD-ROM: 185 ms (typical),
CD-ROM: 165 ms (typical)
Full Stroke BD-ROM: 350 ms (typical), DVD-ROM: 345 ms (typical),
CD-ROM: 340 ms (typical)
Power
Source Slimline SATA DC power receptacle
DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p
DC Current 5 VDC -1200 mA typical, 2000 mA maximum
Environmental conditions
(operating - non-condensing)
Temperature 41° to 122° F (5° to 50° C)
Relative Humidity 10% to 80%
Maximum Wet Bulb Temperature 84° F (29° C)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 66
NETWORKING AND COMMUNICATIONS
Intel® i219LM 10/100/1000 Integrated NIC
Connector
RJ-45
System Interface
PCI (Intel proprietary) + SMBus
Data rates supported
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s
IEEE Compliance
IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
IEEE 802.3az EEE (Energy Efficient Ethernet)
Performance
TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Jumbo Frame 9K
Power consumption
Cable Disconnetion: 25mW
100Mbps Full Run: 450mW
1000bp Full Run: 1000mW
WoL Enable(S3/S4/S5): 50mW
WoL Disable(S3/S4/S5): 25mW
Power
Management
ACPI compliant – multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power consumption
Management Interface
Auto MDI/MDIX Crossover cable detection
IT Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame);
Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 67
Security & Manageability
Intel® vPro™ support with appropriate Intel® chipset components
Intel® i210 10/100/1000 NIC
Connector
RJ-45
System Interface
PCI (Intel proprietary) + SMBus
Data rates supported
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14)
100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30)
1000 Mbit/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023 clauses 40)
Auto-Negotiation (Automatic Speed Selection)
Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s
IEEE Compliance
IEEE 802.1p QoS (Quality of Service) Support
IEEE 802.1q VLAN support
IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)
IEEE 802.3az EEE (Energy Efficient Ethernet)
Performance
TCP/IP/UDP Checksum Offload (configurable)
Protocol Offload (ARP & NS)
Large send offload and Giant send offload
Receiving Side Scaling
Jumbo Frame 9K
Power consumption
Cable Disconnetion: 25mW
100Mbps Full Run: 450mW
1000bp Full Run: 1000mW
WoL Enable(S3/S4/S5): 50mW
WoL Disable(S3/S4/S5): 25mW
Power
Management
ACPI compliant – multiple power modes
Situation-sensitive features reduce power consumption
Advanced link down power saving for reducing link down power consumption
Management Interface
Auto MDI/MDIX Crossover cable detection
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 68
IT Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame);
Wake-on-LAN from off (Magic Packet only)
PXE 2.1 Remote Boot
Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30))
Comprehensive diagnostic and configuration software suite
Virtual Cable Doctor for Ethernet cable status
Security & Manageability
Intel® vPro™ support with appropriate Intel® chipset components
Intel Wi-Fi 6 AX200 + BT5 (802.11ax 2x2, vPro, supporting gigabit file transfer speeds) vPro
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11ax
IEEE 802.11d
IEEE 802.11e
IEEE 802.11h
IEEE 802.11i
IEEE 802.11k
IEEE 802.11r
IEEE 802.11v
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n/ax
• 2.402 – 2.482 GHz
802.11a/n/ac/ax
• 4.9 – 4.95 GHz (Japan)
• 5.15 – 5.25 GHz
• 5.25 – 5.35 GHz
• 5.47 – 5.725 GHz
• 5.825 – 5.850 GHz
Data Rates
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
• 802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, ,80MHz & 160MHz)
• 802.11ax : MCS0 ~ MCS11, (1SS and 2SS) (20MHz, 40MHz, ,80MHz & 160MHz)
Modulation
Direct Sequence Spread Spectrum
OFDMA, BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security1
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b: +18.5dBm minimum
• 802.11g: +17.5dBm minimum
• IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• IEEE 802.11i
• WAPI
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 69
• 802.11a: +18.5dBm minimum
• 802.11n HT20(2.4GHz): +15.5dBm minimum
• 802.11n HT40(2.4GHz): +14.5dBm minimum
• 802.11n HT20(5GHz): +15.5dBm minimum
• 802.11n HT40(5GHz): +14.5dBm minimum
• 802.11ac VHT80(5GHz): +11.5dBm minimum
• 802.11ac VHT160(5GHz): +11.5dBm minimum
• 802.11ax VHT160(5GHz) : +10dBm minimum
Power Consumption
• Transmit mode2.0 W
• Receive mode 1.6 W
• Idle mode (PSP) 180 mW (WLAN Associated)
• Idle mode 50 mW (WLAN unassociated)
• Connected Standby 10mW
• Radio disabled 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -93.5dBm maximum
802.11b, 11Mbps : -84dBm maximum
802.11a/g, 6Mbps : -86dBm maximum
802.11a/g, 54Mbps : -72dBm maximum
802.11n, MCS07 : -67dBm maximum
802.11n, MCS15 : -64dBm maximum
802.11ac, MCS0 : -84dBm maximum
802.11ac, MCS9 : -59dBm maximum
802.11ax, MCS11(HT40): -59dBm maximum
802.11ax, MCS11(VHT160): -58.5dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230: 2.3 x 22.0 x 30.0 mm
Weight
Type 2230: 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2/5.0 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels.
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 70
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Range
Legacy Up to 33 ft (10 m)
BLE Up to 99 ft (30 m)
Bluetooth Software Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
Security & Manageability
Intel® vPro™ support with appropriate Intel® chipset components
Intel Wi-Fi 6 AX200 + BT5 (802.11ax 2x2, non-vPro, supporting gigabit file transfer speeds) non-vPro
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11ax
IEEE 802.11d
IEEE 802.11e
IEEE 802.11h
IEEE 802.11i
IEEE 802.11k
IEEE 802.11r
IEEE 802.11v
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n/ax
• 2.402 – 2.482 GHz
802.11a/ac/ax
• 4.9 – 4.95 GHz (Japan)
• 5.15 – 5.25 GHz
• 5.25 – 5.35 GHz
• 5.47 – 5.725 GHz
• 5.825 – 5.850 GHz
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 71
Data Rates
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, ,80MHz & 160MHz)
Modulation
Direct Sequence Spread Spectrum
OFDM, BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security1
• IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• IEEE 802.11i
• WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b : +18.5dBm minimum
• 802.11g : +17.5dBm minimum
• 802.11a : +18.5dBm minimum
• 802.11n HT20(2.4GHz) : +15.5dBm minimum
• 802.11n HT40(2.4GHz) : +14.5dBm minimum
• 802.11n HT20(5GHz) : +15.5dBm minimum
• 802.11n HT40(5GHz) : +14.5dBm minimum
• 802.11ac VHT80(5GHz) : +11.5dBm minimum
• 802.11ac VHT160(5GHz) : +11.5dBm minimum
Power Consumption
• Transmit mode2.0 W
• Receive mode 1.6 W
• Idle mode (PSP) 180 mW (WLAN Associated)
• Idle mode 50 mW (WLAN unassociated)
• Connected Standby 10mW
• Radio disabled 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -93.5dBm maximum
802.11b, 11Mbps : -84dBm maximum
802.11a/g, 6Mbps : -86dBm maximum
802.11a/g, 54Mbps : -72dBm maximum
802.11n, MCS07 : -67dBm maximum
802.11n, MCS15 : -64dBm maximum
802.11ac, MCS0 : -84dBm maximum
802.11ac, MCS9 : -59dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230: 2.3 x 22.0 x 30.0 mm
Weight
Type 2230: 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 72
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2/5.0 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels.
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5)
or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Range
Legacy Up to 33 ft (10 m)
BLE Up to 99 ft (30 m)
Bluetooth Software Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 73
Intel Thunder Peak 9260 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 5.0 Combo vPro
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11bsd
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11d
IEEE 802.11e
IEEE 802.11h
IEEE 802.11i
IEEE 802.11k
IEEE 802.11r
IEEE 802.11v
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
• 2.402 – 2.482 GHz
802.11a/n/ac
• 4.9 – 4.95 GHz (Japan)
• 5.15 – 5.25 GHz
• 5.25 – 5.35 GHz
• 5.47 – 5.725 GHz
• 5.825 – 5.850 GHz
Data Rates
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
• 802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, ,80MHz & 160MHz)
Modulation
Direct Sequence Spread Spectrum
OFDMA, BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security1
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b: +18.5dBm minimum
• 802.11g: +17.5dBm minimum
• 802.11a: +18.5dBm minimum
• 802.11n HT20(2.4GHz): +15.5dBm minimum
• 802.11n HT40(2.4GHz): +14.5dBm minimum
• 802.11n HT20(5GHz): +15.5dBm minimum
• 802.11n HT40(5GHz): +14.5dBm minimum
• 802.11ac VHT80(5GHz): +11.5dBm minimum
• 802.11ac VHT160(5GHz): +11.5dBm minimum
Power Consumption
• Transmit mode2.0 W
• Receive mode 1.6 W
• Idle mode (PSP) 180 mW (WLAN Associated)
• Idle mode 50 mW (WLAN unassociated)
• Connected Standby 10mW
• Radio disabled 8 mW
• IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• IEEE 802.11i
• WAPI
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 74
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -93.5dBm maximum
802.11b, 11Mbps : -84dBm maximum
802.11a/g, 6Mbps : -86dBm maximum
802.11a/g, 54Mbps : -72dBm maximum
802.11n, MCS07 : -67dBm maximum
802.11n, MCS15 : -64dBm maximum
802.11ac, MCS0 : -84dBm maximum
802.11ac, MCS9 : -59dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230: 2.3 x 22.0 x 30.0 mm
Weight
Type 2230: 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Nonoperating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Nonoperating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Nonoperating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2/5.0 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels.
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Range
Legacy Up to 33 ft (10 m)
BLE Up to 99 ft (30 m)
Bluetooth Software Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 75
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
Security & Manageability
Intel® vPro™ support with appropriate Intel® chipset components
Intel Thunder Peak 9260 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 5.0 Combo Non vPro
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11d
IEEE 802.11e
IEEE 802.11h
IEEE 802.11i
IEEE 802.11k
IEEE 802.11r
IEEE 802.11v
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
• 2.402 – 2.482 GHz
802.11a/ac
• 4.9 – 4.95 GHz (Japan)
• 5.15 – 5.25 GHz
• 5.25 – 5.35 GHz
• 5.47 – 5.725 GHz
• 5.825 – 5.850 GHz
Data Rates
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, ,80MHz & 160MHz)
Modulation
Direct Sequence Spread Spectrum
OFDM, BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security1
• IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• IEEE 802.11i
• WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 76
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b : +18.5dBm minimum
• 802.11g : +17.5dBm minimum
• 802.11a : +18.5dBm minimum
• 802.11n HT20(2.4GHz) : +15.5dBm minimum
• 802.11n HT40(2.4GHz) : +14.5dBm minimum
• 802.11n HT20(5GHz) : +15.5dBm minimum
• 802.11n HT40(5GHz) : +14.5dBm minimum
• 802.11ac VHT80(5GHz) : +11.5dBm minimum
• 802.11ac VHT160(5GHz) : +11.5dBm minimum
Power Consumption
• Transmit mode2.0 W
• Receive mode 1.6 W
• Idle mode (PSP) 180 mW (WLAN Associated)
• Idle mode 50 mW (WLAN unassociated)
• Connected Standby 10mW
• Radio disabled 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -93.5dBm maximum
802.11b, 11Mbps : -84dBm maximum
802.11a/g, 6Mbps : -86dBm maximum
802.11a/g, 54Mbps : -72dBm maximum
802.11n, MCS07 : -67dBm maximum
802.11n, MCS15 : -64dBm maximum
802.11ac, MCS0 : -84dBm maximum
802.11ac, MCS9 : -59dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230: 2.3 x 22.0 x 30.0 mm
Weight
Type 2230: 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2/5.0 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels.
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5)
or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 77
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Range
Legacy Up to 33 ft (10 m)
BLE Up to 99 ft (30 m)
Bluetooth Software Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
Realtek RTL8822BE 802.11ac 2x2 Wi-Fi + BT4.2
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11d
IEEE 802.11e
IEEE 802.11h
IEEE 802.11i
IEEE 802.11k
IEEE 802.11r
IEEE 802.11v
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
• 2.402 – 2.482 GHz
802.11a/n/ac
• 4.9 – 4.95 GHz (Japan)
• 5.15 – 5.25 GHz
• 5.25 – 5.35 GHz
• 5.47 – 5.725 GHz
• 5.825 – 5.850 GHz
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 78
Data Rates
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, ,80MHz & 160MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security1
• IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• IEEE 802.11i
• WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b: +14dBm minimum
• 802.11g: +12dBm minimum
• 802.11a: +12dBm minimum
• 802.11n HT20(2.4GHz): +12dBm minimum
• 802.11n HT40(2.4GHz): +12dBm minimum
• 802.11n HT20(5GHz): +10dBm minimum
• 802.11n HT40(5GHz): +10dBm minimum
• 802.11ac VHT80(5GHz): +10dBm minimum
Power Consumption
• Transmit mode2.0 W
• Receive mode 1.6 W
• Idle mode (PSP) 180 mW (WLAN Associated)
• Idle mode 50 mW (WLAN unassociated)
• Connected Standby 10mW
• Radio disabled 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps: -93.5dBm maximum
802.11b, 11Mbps: -84dBm maximum
802.11a/g, 6Mbps: -86dBm maximum
802.11a/g, 54Mbps: -72dBm maximum
802.11n, MCS07: -67dBm maximum
802.11n, MCS15: -64dBm maximum
802.11ac, MCS0: -84dBm maximum
802.11ac, MCS9: -59dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure
Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN
MIMO communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 79
HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Electrical Interface
USB 2.0 compliant
Bluetooth Software Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management Certifications
Microsoft Windows ACPI, and USB Bus Support
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
Realtek 802.11a/b/g/n/ac (1x1) WiFi and Bluetooth® 4.2 Combo
Wireless LAN Standards
IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.11ac
IEEE 802.11d
IEEE 802.11e
IEEE 802.11h
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 80
IEEE 802.11i
IEEE 802.11k
IEEE 802.11r
IEEE 802.11v
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
• 2.402 – 2.482 GHz
802.11a/n/ac
• 4.9 – 4.95 GHz (Japan)
• 5.15 – 5.25 GHz
• 5.25 – 5.35 GHz
• 5.47 – 5.725 GHz
• 5.825 – 5.850 GHz
Data Rates
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and 80MHz)
Modulation
Direct Sequence Spread Spectrum
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security1
• IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• IEEE 802.11i
• WAPI
Network Architecture
Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 802.11b : +14dBm minimum
• 802.11g : +12dBm minimum
• 802.11a : +12dBm minimum
• 802.11n HT20(2.4GHz) : +12dBm minimum
• 802.11n HT40(2.4GHz) : +12dBm minimum
• 802.11n HT20(5GHz) : +10dBm minimum
• 802.11n HT40(5GHz) : +10dBm minimum
• 802.11ac VHT80(5GHz) : +10dBm minimum
Power Consumption
• Transmit mode2.0 W
• Receive mode 1.6 W
• Idle mode (PSP) 180 mW (WLAN Associated)
• Idle mode 50 mW (WLAN unassociated)
• Connected Standby 10mW
• Radio disabled 8 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -93.5dBm maximum
802.11b, 11Mbps : -84dBm maximum
802.11a/g, 6Mbps : -86dBm maximum
802.11a/g, 54Mbps : -72dBm maximum
802.11n, MCS07 : -67dBm maximum
802.11n, MCS15 : -64dBm maximum
802.11ac, MCS0 : -84dBm maximum
802.11ac, MCS9 : -59dBm maximum
Antenna type
High efficiency antenna.
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Networking and Communications
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 81
One embedded dual band 2.4/5 GHz antenna is provided to the card to support WLAN
communications and Bluetooth communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating
Non-operating
14° to 158° F (–10° to 70° C)
–40° to 176° F (–40° to 80° C)
Humidity
Operating
Non-operating
10% to 90% (non-condensing)
5% to 95% (non-condensing)
Altitude
Operating
Non-operating
0 to 10,000 ft (3,048 m)
0 to 50,000 ft (15,240 m)
HP Integrated Module with Bluetooth 4.0/4.1/4.2 Wireless Technology
Bluetooth Specification
4.0/4.1/4.2 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH)
BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps
BLE : 1 Mbps data rate; throughput up to 0.2 Mbps
Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or
864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum
transmit power of +4 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW
Peak (Rx) 230 mW
Selective Suspend 17 mW
Electrical Interface
USB 2.0 compliant
Bluetooth Software Supported
Link Topology
Microsoft Windows Bluetooth Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles Supported
BT4.1-ESR 5/6/7 Compliance
LE Link Layer Ping
LE Dual Mode
LE Link Layer
LE Low Duty Cycle Directed Advertising
LE L2CAP Connection Oriented Channels
Train Nudging & Interlaced Scan
BT4.2 ESR08 Compliance
LE Secure Connection- Basic/Full
LE Privacy 1.2 –Link Layer Privacy
LE Privacy 1.2 –Extended Scanner Filter Policies
LE Data Packet Length Extension
FAX Profile (FAX)
Basic Imaging Profile (BIP)2
Headset Profile (HSP)
Hands Free Profile (HFP)
Advanced Audio Distribution Profile (A2DP)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Input/Output Devices
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 82
I/O DEVICES
HP Conferencing Keyboard
1.
Function Keys
6.
End/Decline a Call
2.
F11 Lync or Skype for Business Contact list[1]
7.
Answer a Call
3.
F12 Lync or Skype for Business Calendar[2]
8.
Microphone Mute
4.
Share Screen
9.
Volume Up/Down
5.
Stop Webcam
10.
Audio Mute
1. Microsoft Lync 2013, or Skype for Business, or Microsoft Outlook 2013 Contact list
2. Microsoft Lync 2013, or Skype for Business, or Microsoft Outlook 2013 Calendar
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Input/Output Devices
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 83
HP USB Premium Keyboard
Physical Characteristics
Keys
104, 105 layout (depending upon country)
Dimensions
(L x W x H)
17.04 x 5.55 x 0.52 in (433 x 141 x13.2 mm)
Weight
1.54 lb. (698g)
Electrical
Operating voltage
5 VDC, +/-5%
Power consumption
35mA (All LED on)
System interface
USB Type A plug connector
ESD
Contact Discharge: 8 KV Air Discharge: 15 KV
EMI - RFI
Conforms to FCC rules for a Class B computing device
Microsoft® PC 99 - 2001
Functionally compliant
Mechanical
Keycaps
Low-profile design
Switch actuation
60±10g nominal peak force with tactile feedback
Switch life
10 million keystrokes (Life tester)
Switch type
Contamination-resistant switch membrane
Key-leveling mechanisms
For all double-wide and greater-length keys
Cable length
6 ft. (1.8 m)
Microsoft PC 99 - 2001
Mechanically compliant
Environmental
Acoustics
43-dBA maximum sound pressure level
Operating temperature
50° to 122° F (10° to 50° C)
Non-operating temperature
-22° to 140° F (-30° to 60° C)
Operating humidity
10% to 90% (non-condensing at ambient)
Non-operating humidity
20% to 80% (non-condensing at ambient)
Operating shock
40 g, six surfaces
Non-operating shock
80 g, six surfaces
Operating vibration
2-g peak acceleration
Non-operating vibration
4-g peak acceleration
Drop (out of box)
26 in (66 cm) on carpet, six-drop sequence
Drop (in box)
30 in (76.2 cm) on concrete, 16-drop sequence
Approvals
UL, FCC, CE Mark, TUV GS, VCCI, BSMI, C-Tick, KC
Ergonomic compliance
TUVGS
Kit contents
Keyboard, QSP
Warranty Card
Product Notice
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Input/Output Devices
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 84
Skylab USB Wired Keyboard
Physical Characteristics
Keys
104, 105, 106, 107, 109 layout (depending upon country)
Dimensions
(L x W x H)
171.97 x 68.35 x 8.27 in (436.8± 1.5 x 137.6± 1.0 x 21.0±
1.0 cm)
Weight
1.32 lb. (0.6± 0.08 kg)
Electrical
Operating voltage
4.4-5.25VDC
Power consumption
50-mA maximum (with 5 VDC power supplied and three
LEDs ON)
System interface
USB
ESD
Contact Discharge: 2, 4,6,8KV
Air Discharge: 2, 4, 8,10,12.5KV
EMI - RFI
Conforms to FCC rules for a Class B computing device
Mechanical
Keycaps
Low-profile design
Switch actuation
60±10g nominal peak force with tactile feedback
Switch life
10 million keystrokes (Life tester)
Switch type
Contamination-resistant switch membrane
Key-leveling mechanisms
For all double-wide and greater-length keys
Cable length
6 ft. (1.8 m)
Microsoft PC 99 - 2001
Mechanically compliant
Environmental
Acoustics
43-dBA maximum sound pressure level
Operating temperature
50° to 122° F (10° to 50° C)
Non-operating temperature
Minus 30 degrees to 60 degrees Celsius
Operating humidity
10% to 90% (non-condensing at ambient)
Non-operating humidity
20% to 80% (non-condensing at ambient)
Operating shock
40 g, six surfaces
Non-operating shock
80 g, six surfaces
Operating vibration
2-g peak acceleration
Non-operating vibration
4-g peak acceleration
Drop (out of box)
26 in (66 cm) on carpet, six-drop sequence
Drop (in box)
30 in (76.2 cm) on concrete, 16-drop sequence
Approvals
UL, FCC, CE Mark, TUV GS, VCCI, BSMI, C-Tick, KC
Ergonomic compliance
ANSI HFS 100, ISO 9241-4, and TUVGS
Kit contents
Keyboard, Installation Guide, Warranty card, Safety and Comfort Guide
HP USB Premium Mouse
Dimensions (H x L x W)
4.21 x 2.64 x 1.52 in (107 x 67 x 38.7 mmm)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Input/Output Devices
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 85
Weight
0.19lb (90g)
Environmental
Operating temperature
50° to 122°F (10° to 50° C)
Non-operating temperature
-22° to 140°F (-30° to 60° C)
Operating humidity
10% to 90% (non-condensing at ambient)
Non-operating humidity
20% to 80% (non-condensing at ambient)
Operating shock
50 g, 6 surfaces
Non-operating shock
80 g, 6 surfaces
Operating vibration
2 g peak acceleration
Non-operating vibration
4 g peak acceleration
Electrical
Operating voltage
5 VDC, +/-5%
Power consumption
12mA
Mechanical
Connector
USB 2.0
Type
3D mouse (3 keys and wheel)
Resolution
800, 1200, 1600 DPI
Sensor
Pixart PAN3606DL
Tracking speed
Tracking acceleration
8G(max), 1G=9.8m/s2
Cable length
6 ft. (1.8 m)
Color
Jack Black
Regulatory approvals
Compliant
UL, FCC, CE Mark, TUV GS, VCCI, BSMI, C-Tick, KC
HP USB Mouse
Dimensions
(H x L x W)
37mm x 115mm x ccccccccc62.9mm
Weight
90 +10g/- 5 g
Color
Black
Connector
USB
Mechanical
Resolution
800 DPI sensitivity
Buttons
Two primary buttons and clickable scroll wheel
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Audio/Multimeda
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 86
AUDIO/MULTIMEDIA
HP EliteDesk 800 G5 Tower Business PC
Type
Integrated
HD Stereo Codec
Conexant CX20632
Audio I/O Ports
Front: 1 - Headset connector supports a CTIA style headset and is re-taskable as a Line-in, Lineout, Microphone-in or Headphone-out port
1 - Headphone port
Rear: 1 - Line-out
1 - Line-in which is retaskable as a Microphone Input
All ports are 3.5mm and support stereo
Internal Speaker Amplifier
2W class D mono amplifier for the internal speaker only. External speakers must be powered
Multi-streaming Capable
Playback multi-streaming can be enabled in the audio control panel to allow independent audio
streams to be sent to/from the front and rear jacks or integrated speaker.
Sampling
Independent sampling rates for DAC’s and ADC’s; supports resolutions from 16 to 24-bit; 44.1 kHz
to 192 kHz for DAC and 44.1 kHz to 96 kHz for ADC
Wavetable Syntheses
Yes - Uses OS soft wavetable
Analog Audio
Yes
# of Channels on Line-Out
Stereo (Left & Right channels)
Internal Speaker
Yes
HP EliteDesk 800 G5 Small Form Factor Business PC
Type
Integrated
HD Stereo Codec
Conexant CX20632
Audio I/O Ports
Front: 1 - Headset connector supports a CTIA style headset and is re-taskable as a Line-in, Lineout, Microphone-in or Headphone-out port
1 - Headphone port
Rear: 1 - Line-out
1 - Line-in which is retaskable as a Microphone Input
All ports are 3.5mm and support stereo
Internal Speaker Amplifier
2W class D mono amplifier for the internal speaker only. External speakers must be powered
Multi-streaming Capable
Playback multi-streaming can be enabled in the audio control panel to allow independent audio
streams to be sent to/from the front and rear jacks or integrated speaker.
Sampling
Independent sampling rates for DAC’s and ADC’s; supports resolutions from 16 to 24-bit; 44.1 kHz
to 192 kHz for DAC and 44.1 kHz to 96 kHz for ADC
Wavetable Syntheses
Yes - Uses OS soft wavetable
Analog Audio
Yes
# of Channels on Line-Out
Stereo (Left & Right channels)
Internal Speaker
Yes
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Audio/Multimeda
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 87
HP EliteDesk 800 G5 Desktop Mini Business PC
Type
Integrated
HD Stereo Codec
Conexant CX20632
Audio I/O Ports
Front: 1 - Headset connector supports a CTIA style headset and is re-taskable as a Line-in, Lineout, Microphone-in or Headphone-out port
1 - Headphone port
Internal Speaker Amplifier
2W class D mono amplifier for the internal speaker only. External speakers must be powered
Multi-streaming Capable
Playback multi-streaming can be enabled in the audio control panel to allow independent audio
streams to be sent to/from the front and rear jacks or integrated speaker.
Sampling
Independent sampling rates for DAC’s and ADC’s; supports resolutions from 16 to 24-bit; 44.1 kHz
to 192 kHz for DAC and 44.1 kHz to 96 kHz for ADC
Wavetable Syntheses
Yes - Uses OS soft wavetable
Analog Audio
Yes
# of Channels on Line-Out
Stereo (Left & Right channels)
Internal Speaker
Yes
HP EliteOne 800 G5 23.8-in All-in-One
Bang & Olufsen Audio
Type
Integrated
HD Stereo Codec
Conexant CX5001
Audio I/O Ports
Side headset connector supports a CTIA style headset and is re-taskable as a Line-in, Line-out,
Microphone-in or Headphone-out port
Side headphone connector supports a headphone connections
Rear line out connector
All ports are 3.5mm and support stereo
Internal Speaker Amplifier
2W per channel class D stereo amplifier for the internal speakers only
Multi-streaming Capable
Playback multi-streaming can be enabled in the audio control panel to allow independent audio
streams to be sent to/from the front and rear jacks or integrated speakers.
Sampling
Independent sampling rates for DAC’s and ADC’s; supports resolutions from 16 to 24-bit; 44.1 kHz
to 192 kHz for DAC and 44.1 kHz to 96 kHz for ADC
Wavetable Syntheses
Yes - Uses OS soft wavetable
Analog Audio
Yes
# of Channels on Line-Out
Stereo (Left & Right channels)
Internal Speaker
Yes - Stereo
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Integrated Webcam and Microphone
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 88
INTEGRATED WEBCAM AND MICROPHONE
Integrated Webcam and Microphone
Optional integrated 2 MP Full HD RGB webcam & microphone; maximum resolution of 1920 x 1080
Optional integrated 2 MP Full HD RGB dual-facing webcam with IR sensor (user-facing) & microphone; maximum resolution of
1920 x 1080
NOTE: All HP devices which carry the Bang & Olufsen brand are custom-tuned with Bang & Olufsen’s acoustical engineers for precise sound experience in business
use.
INTEGRATED FINGERPRINT SENSOR
Sensor type: Touch
Fingerprint matching: Performed on device
Anti-Spoofing: Yes
Windows Hello Support: Yes
Encryption: On sensor
FIPS Compliant: No
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Power
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 89
POWER
HP EliteDesk 800 G5 Tower Business PC
Unit Environment and Operating Conditions
Temperature Range
Operating: 5°C ~45°C
Non-Operating: -40°C ~66°C
Relative Humidity
Operating 5% to 90% relative humidity at max inlet temperature
Non-Operating 5% to 90% relative humidity at max inlet temperature
Maximum Altitude
(unpressurized)
Operating: 5000m
Non-operating: 50,000 ft. (15240 m)
HP EliteDesk 800 G5 SFF Business PC
Unit Environment and Operating Conditions
Temperature Range
Operating: 5°C ~45°C
Non-Operating: -40°C ~66°C
Relative Humidity
Operating 5% to 90% relative humidity at max inlet temperature
Non-Operating 5% to 90% relative humidity at max inlet temperature
Maximum Altitude
(unpressurized)
Operating: 5000m
Non-operating: 50,000 ft. (15240 m)
HP EliteDesk 800 G5 Desktop Mini Business PC (35W)
Unit Environment and Operating Conditions
Temperature Range
Operating: 5°C ~35°C
Non-Operating: -40°C ~66°C
Relative Humidity
Operating 5% to 90% relative humidity at max inlet temperature
Non-Operating 5% to 90% relative humidity at max inlet temperature
Maximum Altitude
(unpressurized)
Operating: 5000m
Non-operating: 50,000 ft. (15240 m)
HP EliteDesk 800 G5 Desktop Mini Business PC (65W)
Unit Environment and Operating Conditions
Temperature Range
Operating: 5°C ~35°C
Non-Operating: -40°C ~66°C
Relative Humidity
Operating 5% to 90% relative humidity at max inlet temperature
Non-Operating 5% to 90% relative humidity at max inlet temperature
Maximum Altitude
(unpressurized)
Operating: 5000m
Non-operating: 50,000 ft. (15240 m)
HP EliteDesk 800 G5 Desktop Mini Business PC (95W)
Unit Environment and Operating Conditions
Temperature Range
Operating: 5°C ~35°C
Non-Operating: -40°C ~66°C
Relative Humidity
Operating 5% to 90% relative humidity at max inlet temperature
Non-Operating 5% to 90% relative humidity at max inlet temperature
Maximum Altitude
(unpressurized)
Operating: 5000m
Non-operating: 50,000 ft. (15240 m)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Power
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 90
HP EliteOne 800 G5 23.8-in All-in-One
Unit Environment and Operating Conditions
Temperature Range
Operating: 5°C ~45°C
Non-Operating: -40°C ~66°C
Relative Humidity
Operating 5% to 90% relative humidity at max inlet temperature
Non-Operating 5% to 90% relative humidity at max inlet temperature
Maximum Altitude
(unpressurized)
Operating: 5000m
Non-operating: 50,000 ft. (15240 m)
DM
SFF
TWR
AiO
External Power Supplies
65W EPS, 88% average
efficiency at 115V &
89% at 230Vac
90W EPS, 88% average
efficiency at 115V &
89% at 230Vac
150W EPS, 88% average
efficiency at 115V &
89% at 230Vac
N/A
N/A
N/A
80 PLUS Gold
N/A
N/A
500W active PFC / 80
PLUS Gold
87/90/87% efficient at
20/50/100% load
(115V)
180W active PFC / 80
PLUS Gold*
87/90/87% efficient at
20/50/100% load
(115V)
*Available on models with
integrated graphics
80 PLUS Platinum
N/A
250W active PFC / 80
PLUS Platinum
90/92/89% efficient at
20/50/100% load
(115V)
91/93/90% efficient at
20/50/100% load
(230V)
250W active PFC / 80
PLUS Platinum
90/92/89% efficient at
20/50/100% load
(115V)
91/93/90% efficient at
20/50/100% load
(230V)
210W active PFC / 80
PLUS Platinum*
90/92/89% efficient at
20/50/100% load
(115V)
91/93/90% efficient at
20/50/100% load
(230V)
*Available on models with
discrete graphics
Operating Voltage Range
90Vac~264Vac
90Vac~264Vac
90Vac~264Vac
90Vac~264Vac
Rated Voltage Range
100Vac~240Vac
100Vac~240Vac
100Vac~240Vac
100Vac~240Vac
Rated Line Frequency
50HZ~60HZ
50HZ~60HZ
50HZ~60HZ
50HZ~60HZ
Operating Line Frequency
47HZ~63HZ
47HZ~63HZ
47HZ~63HZ
47HZ~63HZ
Rated Input Current
65W≦1.6A
90W≦1.2A
150W≦2.2A
250W≦3A
500W≦6A
250W≦3A
210W≦3A
180W≦2.5A
Rated Input Current with
Energy Efficient* Power
Supply
65W≦1.6A
90W≦1.2A
150W≦2.2A
250W≦3A
500W≦6A
250W≦3A
210W≦3A
180W≦2.5A
DC Output
+19.5VV
+12V
+12V
+12V
DM
SFF
TWR
AiO
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Power
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 91
Current Leakage (NFPA 99:
2102)
Less than 500
microamps of leakage
current at 120 Vac with
the ground wire
disconnected, as
required for Non-patient
Electrical Appliances
and Equipment used in a
patient care facility or
that contact patients in
normal use. Per section
10.3.5.1.
Less than 100
microamps of leakage
current at 120 Vac with
the ground wire intact
with normal polarity, as
required for Non-patient
Electrical Appliances
and Equipment used in a
patient care facility or
that contact patients in
normal use. Per section
10.3.5.1.
Less than 500
microamps of leakage
current at 120 Vac with
the ground wire
disconnected, as
required for Non-patient
Electrical Appliances
and Equipment used in a
patient care facility or
that contact patients in
normal use. Per section
10.3.5.1.
Less than 100
microamps of leakage
current at 120 Vac with
the ground wire intact
with normal polarity, as
required for Non-patient
Electrical Appliances
and Equipment used in a
patient care facility or
that contact patients in
normal use. Per section
10.3.5.1.
Less than 500
microamps of leakage
current at 120 Vac with
the ground wire
disconnected, as
required for Non-patient
Electrical Appliances
and Equipment used in a
patient care facility or
that contact patients in
normal use. Per section
10.3.5.1.
Less than 100
microamps of leakage
current at 120 Vac with
the ground wire intact
with normal polarity, as
required for Non-patient
Electrical Appliances
and Equipment used in a
patient care facility or
that contact patients in
normal use. Per section
10.3.5.1.
Less than 500
microamps of leakage
current at 120 Vac with
the ground wire
disconnected, as
required for Nonpatient Electrical
Appliances and
Equipment used in a
patient care facility or
that contact patients in
normal use. Per section
10.3.5.1.
Less than 100
microamps of leakage
current at 120 Vac with
the ground wire intact
with normal polarity, as
required for Nonpatient Electrical
Appliances and
Equipment used in a
patient care facility or
that contact patients in
normal use. Per section
10.3.5.1.
Power Supply Fan
N/A
70mm variable speed
70mm variable speed
N/A
Power cord length
6.0 ft. (1.83 m)
6.0 ft. (1.83 m)
6.0 ft. (1.83 m)
6.0 ft. (1.83 m)
External Power Adapter
External power supply
Internal power supply
Internal power supply
Internal power supply
Dimensions
65W: 113.5mm x 55mm
x 30mm
90W: 132mm x 57mm x
30mm
150W: 160mm x 80mm
x 40mm
165mm x 95mm x
73mm
500W : 165mm x
140mm x 73mm
250W : 165mm x 95mm
x 73mm
135mm x 100mm x
19.52mm
Total Cord Length
6.0 ft. (1.83 m)
6.0 ft. (1.83 m)
6.0 ft. (1.83 m)
6.0 ft. (1.83 m)
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Power
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 92
The harmonic input current requirements must be met under the following operating conditions:
Load Requirements: 50% and 100%
Input Voltage: 230Vac/50Hz.
For active power factor correction the power factor at 50% &100% loads shall be greater than 0.9 over the entire nominal input
voltage range (100-127VAC and 200-240VAC).
Condition
Standard Efficiency
82/85/82%
85/88/85%
87/90/87%
90/92/89%
Input Voltage
10% of Rated
Load
-
75%
81%
84%
84%
115Vac/60HZ
20% of Rated
Load
-
82%
85%
87%
90%
115Vac/60HZ
50% of Rated
Load
-
85%
88%
90%
92%
115Vac/60HZ
PF>0.9
PF>0.9
PF>0.9
PF>0.9
PF>0.95
100% of Rated
Load
70%
82%
85%
87%
89%
115Vac/60HZ
PF>0.9
PF>0.9
PF>0.9
PF>0.9
PF>0.9
230Vac/50HZ
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Weights and Dimensions
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 93
WEIGHTS & DIMENSIONS
DM
SFF
TWR
AiO
Chassis (W x D x H)
6.97 x 6.89 x 1.35 in
177x175x34mm
13.3 x 12.13 x 3.94 in
338 x 308 x 100 mm
6.1 x 14.6 x 14.4 in
154 x 370 x 365 mm
See table below.
System Volume
63.4 cu in
1.05L
63.4 cu in
10.4 L
1269 cu in
20.8 L
See table below.
System Weight
2.31 lb
1.05 kg
13.5 lb
6.13 kg
21.74 lb
9.86 kg
See table below.
Max Supported Weight
(desktop orientation)
0
77 lb
35 kg
77 lb
35 kg
See table below.
Stand Dimensions
160x117x18.5mm
151.8x200x37.2mm
N/A
See table below.
Packaging (W x D x H)
19.57 x 5.04 x 8.78 in
497 x128 x223mm
15.71 x 19.65 x 9.06 in
399 x 499 x 230 mm
11.77 x 18.82 x 20.35 in
299 x 478 x 517 mm
See table below.
Shipping Weight
2.95 kg
6.49 lb
9 kg
19.82 lb
11.34 kg
24.98 lb
See table below.
Multipack
Packaging
(10 units)
20.28x16.54x25 in
515x420x636 mm
Palletization Profile
18-units per layer
5 or 6 layers max
depending on details of
air freight
90 or 108 units per
pallet
depending on details of
air freight
45.354 x 39.13 x 57.80
in, 1152 x 994 x 1468
mm
(include pallet)
6 units per layer
10 layers max
60 units per pallet
1200*1000*2438 mm
(include the pallet)
8 units per layer
4 layers ax
32 units per pallet
1200*1000*2203 mm
(include the pallet)
10-units per layer
4-layers max
40-units per pallet (sea)
1200 x 1000 x 2470 mm
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Weights and Dimensions
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 94
STANDS AND DIMENSIONS
HP EliteOne G5 AIO Adjustable Height Stand
HP EliteOne G5 AIO Recline Stand
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Weights and Dimensions
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 95
ALL-IN-ONE WEIGHTS AND DIMENSIONS
Weight with Touch Panel
Product Weight
Unboxed
Without Stand
13.29 lbs.
6.03kg
Adjustable Height
Stand
19.24 lbs.
8.73kg
Recline Stand
21.12lbs
9.58kg
Shipping Weight
Boxed
Without Stand
20.64-21.15lbs
9.4-9.45kg
Adjustable Height
Stand
26.68 lbs.
12.1kg
Recline Stand
28.66-28.88 lbs.
13-13.1kg
Shipping Weight
Pallet
Without Stand
(10units)
233.73lbs
106kg
Adjustable Height
Stand (10units)
293.21lbs
133 kg
Recline Stand
(10units)
313.06lbs
142kg
Weight without Touch Panel
Product Weight
Unboxed
Without Stand
13.51-13.62 lbs.
6.13-6.18kg
Adjustable Height
Stand
19.46-19.68lbs
8.93 kg
Recline Stand
21.34-21.44 lbs.
9.68-9.73kg
Shipping Weight
Boxed
Without Stand
20.86-21.06lbs
9.5-9.55kg
Adjustable Height
Stand
26.89-27.12 lbs.
12.2-12.3 kg
Recline Stand
28.88lbs
13.1kg
Shipping Weight
Pallet
Without Stand
21.2 x 2.12 x 13.46 in
539.6 x 53.8 x 341.79
mm
Adjustable Height
Stand 0 degrees
21.2 x 7.1 x 18.4 in
539.6 x 180.28 x 467.7
mm
Recline Stand
0 degrees
21.2 x 10.3 x 10.63 in
539.6 x 261.8 x
269.98 mm
Dimensions (W x D x H)
Product
Dimensions
Without Stand
21.2 x 2.12 x 13.46 in
539.6 x 53.8 x 341.79
mm
Adjustable Height
Stand 0 degrees
21.2 x 7.1 x 18.4 in
539.6 x 180.28 x 467.7
mm
Recline Stand
0 degrees
21.2 x 10.3 x 10.63 in
539.6 x 261.8 x
269.98 mm
Shipping Dimensions
Shipping
Dimensions
Boxed
Without Stand
27.17 x 10.08 x
21.46(H) in
690 x 256 x 545(H)
mm
Adjustable Height
Stand
27.17 x 10.08 x
26.22(H) in
690 x 256 x 666(H)
mm
Recline Stand
27.17 x 10.08 x
26.22(H) in
690 x 256 x 666(H)
mm
Shipping
Dimensions
Pallet
Without Stand
(10 units)
47.24 x 39.37 x
24.02(H) in
1200 x 1000 x 610(H)
mm
Adjustable Height
Stand (10 units)
47.24 x 39.37 x
28.94(H) in
1200 x 1000 x 735(H)
mm
Recline Stand
(10 units)
47.24 x 39.37 x
28.94(H) in
1200 x 1000 x 735(H)
mm
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Miscellaneous Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 96
MISCELLANEOUS FEATURES
Management Features
• Advanced Configuration and Power Management Interface (ACPI). Allows the system to wake from a low power mode.
Controls system power consumption, making it possible to place individual cards and peripherals in a low-power or
powered-off state without affecting other elements of the system.
• Intel® Wired for Management support; industry wide initiative to make Intel® architecture based PCs, servers and mobile
computers more inherently manageable out-of-the-box and over the network
• Dual State Power Button; acts as both an on/off button and a suspend-to-sleep button
Serviceability Features
• Dual colored power LED on front of computer to indicate either normal or fault condition
• Diagnostic LED Explanation Table:
o Power LED will blink red 2 to 5 times, then blink white 2 or more times, then repeat (with beep tones for each blink
initially):
▪ 2 red + 2 white User must provide file for BIOS recovery (USB storage typically)
▪ 2 red + 3 white User must enter a key sequence to proceed with recovery by policy
▪ 2 red + 4 white BIOS recovery is in progress
▪ 3 red + 2 white Memory could not be initialized
▪ 3 red + 3 white Graphics adaptor could not be found
▪ 3 red + 4 white Power supply failure / not connected
▪ 3 red + 5 white Processor not installed
▪ 3 red + 6 white Current processor does not support an enabled feature
▪ 4 red + 2 white Processor has exceeded its temperature threshold / system thermal shutdown
▪ 4 red + 3 white System internal temperature has exceeded its threshold
▪ 5 red + 2 white System controller firmware is not valid
▪ 5 red + 3 white System controller detected BIOS is not executing
▪ 5 red + 4 white BIOS could not complete initialization / PCA failure
▪ 5 red + 5 white System controller rebooted the system after a health or recovery timer triggered
• HP PC Hardware Diagnostics UEFI:
o This utility enables hardware level testing outside the operating system on many components. The diagnostics
can be invoked by pressing F2 at POST, and is available as a download from HP Support
• System/Emergency ROM
• Flash ROM
• CMOS Battery Holder for easy replacement
• Flash Recovery with Video Configuration Record Software5 Aux Power LED on System PCA
• Processor ZIF Socket for easy Upgrade
• Over-Temp Warning on Screen (Requires IM Agents)
• Clear Password Jumper
• DIMM Connectors for easy Upgrade
• Clear CMOS Button
• NIC LEDs (integrated) (Green & Amber)
• Dual Color Power and HD LED - To Indicate Normal Operations and Fault Conditions
• Color coordinated cables and connectors
• Tool-less Hood Removal
• Front power switch
• System memory can be upgraded without removing the system board or any internal components
• Tool-less Hard Drive, CD & Diskette Removal (For MT, SFF, and DM only)
• Green Pull Tabs, and Quick Release Latches for easy Identification
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – Miscellaneous Features
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 97
Additional Features
Description
Tower Orientation
Product can be oriented as either a desktop (horizontal) or a tower (vertical) for MT,
SFF, and DM only
Drive Lock
Implementation of the industry standard ATA Security feature set. When enabled, it
prevents software access to user data on the drive until one or two user-defined
passwords are provided.
Boot Sectors Protection
MBR and GPT sectors of the hard drive are critical to booting the operating system. By
saving the MBR or GPT data (depending on the how the OS was installed), the BIOS will
be able to monitor for changes and allow the user to override them with the backup
copy at boot-up.
Drive Protection System
DPS Access through F10 Setup during Boot
A diagnostic hard drive self- test. It scans critical physical components and every
sector of the hard drive for physical faults and then reports any faults to the user
Running independently of the operating system, it can be accessed through a
Windows-based diagnostics utility or through the computer's setup procedure. It
produces an evaluation on whether the hard drive is the source of the problem and
needs to be replaced
The system expands on the Self-Monitoring, Analysis, and Reporting Technology
(SMART), a continuously running systems diagnostic that alerts the user to certain
types of failures
SMART Technology (Self-Monitoring,
Analysis and Reporting Technology)
Allows hard drives to monitor their own health and to raise flags if imminent failures
were predicted
SMART I - Drive Failure Prediction
Predicts failures before they occur. Tracks fault prediction and failure indication
parameters such as re-allocated sector count, spin retry count, calibration retry count
SMART II - Off-Line Data Collection
By avoiding actual hard drive failures, SMART hard drives act as "insurance" against
unplanned user downtime and potential data loss from hard drive failure
SMART III - Off-Line Read Scanning with
Defect Reallocation
IOEDC: I/O Error Detection Circuitry
SMART IV - End-to-End CRC for hard drives
Detects errors in Read/Write buffers on HDD cache RAM
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – After Market Options
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 98
AFTER MARKET OPTIONS
Graphics Solutions
DM
SFF
TWR
AiO
Part Number
AMD® Radeon™ RX 550X 4GB LP Display Port Card
X 5LH79AA
AMD® Radeon™ R7 430 2GB 2 Display Port Card
X X 5JW82AA
AMD® Radeon™ R7 430 2GB Display Port VGA 64bit Card
(China Only)
X X
5JW81AA
NVIDIA GeForce GT730 DP 2GB PCIe x8 GFX
X X Z9H51AA
HP DisplayPort To HDMI True 4k Adapter
X X X X 2JA63AA
HP DVI Cable Kit
X X X X DC198A
HP HDMI Standard Cable Kit
X X X X T6F94AA
HP DisplayPort Cable Kit
X X X X VN567AA
HP DisplayPort To VGA Adapter
X X X X AS615AA
HP DisplayPort To DVI-D Adapter
X X X X FH973AA
Desktop Mini Accessories
DM
SFF
MT
AiO
Part Number
HP Desktop Mini G3 Port Cover Kit
X
1ZE52AA
HP G4 Mini 2.5-inch SATA Drive Bay Kit
X
3TK91AA
HP Desktop Mini LockBox V2
X
(95W and discrete GPU
skus not supported)
3EJ57AA
HP Desktop Mini DVD-Writer ODD Expansion Module
X (Either one)
K9Q83AA
HP Desktop Mini I/O Expansion Module
K9Q84AA
HP Desktop Mini Security/Dual VESA Sleeve v2
X
(95W and discrete GPU
skus not supported)
2JA32AA
HP Desktop Mini Security/Dual VESA Sleeve v2 with
Power Supply Holder
X
(95W and discrete GPU
skus not supported)
7DB36AA
HP B300 PC Mounting Bracket
X
2DW53AA
HP B300 PC Mounting Bracket with Power Supply
Holder
X
7DB37AA
HP B500 PC Mounting Bracket
X
2DW52AA
HP Desktop Mini Vertical Chassis Stand
X
G1K23AA
HP DM VESA Power Supply Holder Kit v2
X
7DB38AA
HP Quick Release Bracket 2
X
X
6KD15AA
HP Single Monitor Arm
X
X
BT861AA
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – After Market Options
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 99
Data Storage Drives
DM
SFF
TWR
AiO
Part
Number
HP 256GB SATA TLC Non-SED Solid State
Drive
X (95W and discrete GPU skus
not supported, cannot use in
conjunction with Thunderbolt 3
and Fiber NIC and any Fiber NIC
option card)
X X X
P1N68AA
HP PCIe NVME TLC 256GB SSD M.2 Drive
X
X X X
1CA51AA
HP PCIe NVME TLC 512GB SSD M.2 Drive
X
X X X
X8U75AA
HP PCIe NVME TLC 512GB SSD PCIe Drive
X X
Z4L70AA
HP 500GB 7200PRM SATA 6.0Gb/s 3.5”
Hard Drive
X X
QK554AA
HP 1TB 7200rpm SATA 6Gb/s 3.5” Hard
Drive
X X
QK555AA
HP 500GB SATA 6Gb/s 7200 HDD
X X
LQ036AA
HP 1TB SATA 6Gb/s 7200 HDD
X X
LQ037AA
HP 3.5" Removable SATA HDD
Frame/Carrier
X
RY102AA
HP 9.5mm G3 800/600 Tower DVD-Writer
(need to be confirmed)
X
1CA52AA
Input Devices
DM
SFF
TWR
AiO
Part
Number
HP USB (Grey) SmartCard CCID Keyboard
X X
J7H70AA
HP USB Antimicrobial Business Slim Keyboard and Mouse
(China Only)
X X
X
Z9H50AA
HP USB Business Slim CCID SmartCard Keyboard
X X X
X
Z9H48AA
HP USB Business Slim (Grey) Keyboard (EMEA Only)
X X X
X
Z9H49AA
HP USB Business Slim Keyboard
X X X
X
N3R87AA
HP USB Business Slim Keyboard and Mouse and Mousepad
X X
X
T4E63AA
HP USB Collaboration Keyboard
X X X
Z9N38AA
HP USB Conferencing Keyboard
X
K8P74AA
HP USB Keyboard
X X X
X
QY776AA
HP USB Keyboard and Mouse Healthcare Edition
X X X
X
1VD81AA
HP USB Premium Keyboard
X X X
X
Z9N40AA
HP USB PS/2 Washable Keyboard & Mouse
X X X
X
BU207AA
HP Wireless Business Slim Keyboard and Mouse
X X X
X
N3R88AA
HP Wireless Collaboration Keyboard
X X X
Z9N39AA
HP Wireless Premium Keyboard
X X
X
Z9N41AA
HP PS/2 Business Slim Keyboard
X X
N3R86AA
HP USB Grey v2 Mouse (EMEA only)
X X X
X
Z9H74AA
HP USB Premium Mouse
X X X
X
1JR32AA
HP PS/2 Mouse
X X
QY775AA
HP USB 1000dpi Laser Mouse
X X X
X
QY778AA
QuickSpecs
HP EliteDesk 800 G5 and HP EliteOne 800 G5 Business Desktops PCs
Technical Specifications – After Market Options
Not all configuration components are available in all regions/countries.
c06320288 – DA-16479 – Worldwide – Version 25 – September 9, 2020
Page 100
HP USB Hardened Mouse
X X X
X
P1N77AA
HP USB Mouse
X X X
X
QY777AA
System Memory
DM
SFF
TWR
AiO
Part
Number
HP 4GB DDR4-2666 DIMM
X X
3TK85AA
HP 8GB DDR4-2666 DIMM
X X
3TK87AA
HP 16GB DDR4-2666 DIMM
X X
3TK83AA
HP 4GB DDR4-2666 SODIMM
X
X
3TK86AA
HP 8GB DDR4-2666 SODIMM
X
X
3TK88AA
HP 16GB DDR4-2666 SODIMM
X
X
3TK84AA
Multimedia Devices
DM
SFF
TWR
AiO
Part
Number
HP Business Headset v2
X
X X X
T4E61AA
HP S101 Speaker Bar
X
X X
5KC42AA
Security Devices
DM
SFF
TWR
AiO
Part
Number
HP Business PC Security Lock v3 Kit
X X
3XJ17AA
HP 800 G3 (SFF) Solenoid Lock and
Intrusion Sensor
X
1CA50AA
HP Dual Head Keyed Cable Lock
X X
T1A64AA
HP Keyed Cable Lock 10mm
X
X X X
T1A62AA
HP Master Keyed Cable Lock 10mm
X X X
T1A63AA
Stands and Accessories
DM
SFF
TWR
AiO
Part Number
HP ProOne G4 Height Adjustable Stand
X 4CX34AA
Loading...
