HP E5412 ZL, E5412-92G-PoE, E5406 zl, E5406-44G-PoE+/2XG-SFP+ v2 zl Datasheet

HP E5400 zl Switch Series

Data sheet

Product overview

The HP E5400 zl Switch Series consists of advanced intelligent switches in the HP E-Series product-line. The E5400 zl series includes 6-slot and 12-slot chassis and associated zl modules and bundles. The foundation for all of these switches is a purpose-built, programmable ProVision ASIC that allows the most demanding networking features, such as quality of service (QoS) and security, to be implemented in a scalable yet granular fashion. With 10/100, Gigabit Ethernet and 10 Gigabit Ethernet interfaces, choice of PoE+ & Non-PoE, integrated layer 3 features and HP allianceONE Solutions, the E5400 zl switches offer excellent investment protection, flexibility, and scalability, as well as ease of deployment, operation, and maintenance.

Key features

b

Advanced access layer, distribution & Core

b

Integrated L2 to L4 intelligent edge feature set

b

Enterprise-class performance and security

b

HP Alliance ONE integrated

b

Scalable 10/100/1000 and 10 GbE connectivity

Features and benefits

Quality of Service (QoS)

•

Advanced classifier-based QoS: classifies traffic using multiple match criteria based on Layer 2, 3, and 4 information; applies QoS policies such as setting priority level and rate limit to selected traffic on a per-port or per-VLAN basis

•

Layer 4 prioritization: enables prioritization based on TCP/UDP port numbers

•

Traffic prioritization: allows real-time traffic classification into eight priority levels mapped to eight queues

•

Bandwidth shaping:

– Port-based rate limiting: provides per-port

ingress/egress enforced maximum bandwidth

– Classifier-based rate limiting: uses access

control list (ACL) to enforce maximum bandwidth for ingress traffic on each port

– Guaranteed minimum: provides per-port,

per-queue egress-based guaranteed minimum bandwidth

•

Class of Service (CoS): sets the IEEE 802.1p priority tag based on IP address, IP Type of Service (ToS), Layer 3 protocol, TCP/UDP port number, source port, and DiffServ

Management

•

Remote Intelligent Mirroring: mirrors selected ingress/egress traffic based on ACL, port, MAC address, or VLAN to a local or remote E8200, E6200, E5400, or E3500 switch anywhere on the network

•

RMON, XRMON, and sFlow v5: provide advanced monitoring and reporting capabilities for statistics, history, alarms, and events

•

IEEE 802.1AB Link Layer Discovery Protocol (LLDP): automated device discovery protocol

provides easy mapping by network management applications

•

Uni-Directional Link Detection (UDLD):

monitors cable between two switches and shuts down the ports on both ends if the cable is broken, turning the bi-directional link into uni-directional; this prevents network problems such as loops

•

Management simplicity: includes HP E-Series common networking features and CLI implementation (common across HP E5400/E8200/E6200/E6600/E3500 switches)

•

Command authorization: leverages RADIUS to link a custom list of CLI commands to an individual network administrator's login; also provides an audit trail

•

Friendly port names: allow assignment of descriptive names to ports

•

Dual flash images: provide independent primary and secondary operating system files for backup while upgrading

•

Multiple configuration files: can be stored to the flash image

Connectivity

•

NEW IEEE 802.3az Energy Efficient Ethernet:

Lowers power consumption in periods of low link usage. (Supported on v2 zl 10/100/1000 & 10/100 modules)

•

IEEE 802.3af Power over Ethernet (PoE):

provides up to 15.4 W per port to IEEE

802.3af-compliant PoE-powered devices such as IP phones, wireless access points, and security cameras

•

IEEE 802.3at Power Over Ethernet Plus:

provides up to 30 W per port to IEEE 802.3 for PoE-/PoE+-powered devices such as video IP phones, IEEE 802.11n wireless access points, and advanced pan/zoom/tilt security cameras

•

Prestandard PoE support: detects and provides power to prestandard PoE devices; see list of supported devices in the product FAQ at www.hp.com/networking

•

High-density port connectivity: up to 12 interface module slots and up to 288 wire-speed 10/100/1000 PoE-enabled ports or 48 10-GbE ports per system

•

Jumbo frames: on Gigabit and 10-Gigabit ports, allow high-performance remote backup and disaster-recovery services

•

Auto-MDIX: automatically adjusts for straight-through or crossover cables on all 10/100 and 10/100/1000 ports

•

ipv6: IPv6 host: enables switches to be managed and deployed at the IPv6 network's edge - Dual stack (IPv4 and IPv6): transitions from IPv4 to IPv6, supporting connectivity for both protocols - MLD snooping: forwards IPv6 multicast traffic to the appropriate interface - IPv6 ACL/QoS: supports ACL and QoS for IPv6 network traffic, preventing traffic flooding - IPv6 routing: supports static and OSPFv3 routing protocols

2

Performance

•

High-speed/capacity architecture: 1 Tbps crossbar switching fabric provides intra-module and inter-module switching with 585.6 million pps throughput on the purpose-built ProVision ASICs

•

Selectable queue configurations: increase performance by selecting the number of queues and associated memory buffering that best meet the requirements of your network applications

Resiliency and high availability

•

Virtual Router Redundancy Protocol: allows groups of two routers to dynamically back each other up to create highly available routed environments

•

IEEE 802.1s Multiple Spanning Tree Protocol: provides high link availability in multiple

VLAN environments by allowing multiple spanning trees; encompasses IEEE 802.1D Spanning Tree Protocol and IEEE 802.1w Rapid Spanning Tree Protocol

•

Server-to-switch distributed trunking: allows a server to connect to two switches with one logical trunk that consists of multiple physical connections; enables load-balancing and increases resiliency

•

IEEE 802.3ad Link Aggregation Control Protocol (LACP) and HP port trunking:

support up to 60 trunks, each with up to 8 links (ports) per trunk

•

Optional redundant power supply (HP E5400 series): provides uninterrupted power and

allows hot-swapping of the redundant power supplies when installed

•

Hot-swappable modules (E5400 zl series):

permits modules, mini-GBICs, and power supplies in a redundant power supply configuration to be added or swapped without interrupting the network

•

Sparing simplicity: HP zl-common accessories (interface modules, power supplies)

Layer 2 switching

•

HP's switch meshing: dynamically load-balances across multiple active redundant links to increase available aggregate bandwidth

•

VLAN support and tagging: supports the IEEE

802.1Q standard and 2,048 VLANs simultaneously

•

IEEE 802.1v protocol VLANs: isolate select non-IPv4 protocols automatically into their own VLANs

•

GARP VLAN Registration Protocol (GVRP):

allows automatic learning and dynamic assignment of VLANs

•

802.1ad QinQ: increases the scalability of an Ethernet network by providing a hierarchical structure; connects multiple LANs on high-speed campus or metro network

Layer 3 services

•

User Datagram Protocol (UDP) helper function: allows UDP broadcasts to be directed

across router interfaces to specific IP unicast or subnet broadcast addresses and prevents server spoofing for UDP services such as DHCP

•

Loopback interface address: defines an address in Routing Information Protocol (RIP) and OSPF that can always be reachable, improving diagnostic capability

•

NEW Route maps: provide more control during

route redistribution; allow filtering and altering of route metrics

Layer 3 routing

•

NEW Static IP routing: provides manually

configured routing for both IPv4 and IPv6 networks

•

Routing Information Protocol (RIP): provides RIPv1 and RIPv2 routing

•

OSPF: provides OSPFv2 for IPv4 routing and OSPFv3 for IPv6 routing

Security

•

Access control lists (ACLs): provide filtering based on the IP field, source/destination IP address/subnet, and source/destination TCP/UDP port number on a per-VLAN or per-port basis

•

Multiple user authentication methods:

– IEEE 802.1X users per port: provides

authentication of multiple IEEE 802.1X users per port; prevents user "piggybacking" on another user's IEEE 802.1X authentication

– Web-based authentication: authenticates

from Web browser for clients that do not support IEEE 802.1X supplicant; customized remediation can be processed on an external Web server

– MAC-based authentication: client is

authenticated with the RADIUS server based on client's MAC address

– Concurrent IEEE 802.1X, Web, and MAC

authentication schemes per port: switch port will accept up to 32 sessions of IEEE 802.1X, Web, and MAC authentications

3

•

Virus throttling: detects traffic patterns typical of WORM-type viruses and either throttles or entirely prevents the virus from spreading across the routed VLANs or bridged interfaces, without requiring external appliances

•

DHCP protection: blocks DHCP packets from unauthorized DHCP servers, preventing denial-of-service attacks

•

Secure management access: securely encrypts all access methods (CLI, GUI, or MIB) through SSHv2, SSL, and/or SNMPv3

•

USB Secure Autorun (requires HP PCM+):

deploys, diagnoses, and updates switch using a USB flash drive; works with a secure credential to prevent tampering

•

Switch CPU protection: provides automatic protection against malicious network traffic trying to shut down the switch

•

ICMP throttling: defeats ICMP denial-of-service attacks by enabling any switch port to automatically throttle ICMP traffic

•

Identity-driven ACL: enables implementation of a highly granular and flexible access security policy and VLAN assignment specific to each authenticated network user

•

STP BPDU port protection: blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged BPDU attacks

•

Dynamic IP lockdown: works with DHCP protection to block traffic from unauthorized hosts, preventing IP source address spoofing

•

Dynamic ARP protection: blocks ARP broadcasts from unauthorized hosts, preventing eavesdropping or theft of network data

•

STP Root Guard: protects root bridge from malicious attack or configuration mistakes

•

Detection of malicious attacks: monitors 10 types of network traffic and sends a warning when an anomaly that potentially can be caused by malicious attacks is detected

•

Port security: allows access only to specified MAC addresses, which can be learned or specified by the administrator

•

MAC address lockout: prevents particular configured MAC addresses from connecting to the network

•

Source-port filtering: allows only specified ports to communicate with each other

•

RADIUS/TACACS+: eases switch management security administration by using a password authentication server

•

Secure Shell (SSHv2): encrypts all transmitted data for secure, remote command-line interface (CLI) access over IP networks

•

Secure Sockets Layer (SSL): encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in the switch

•

Secure File Transfer Protocol (FTP): allows secure file transfer to and from the switch; protects against unwanted file downloads or unauthorized copying of switch configuration file

•

Management Interface Wizard: helps ensure that management interfaces such as SNMP, telnet, SSH, SSL, Web, and USB are secured to the desired level

•

Switch management logon security: can require either RADIUS or TACACS+ authentication for secure switch CLI logon

•

Security banner: displays a customized security policy when users log in to the switch

Convergence

•

IP multicast routing : includes PIM Sparse and Dense modes to route IP multicast traffic

•

IP multicast snooping (data-driven IGMP):

automatically prevents flooding of IP multicast traffic

•

LLDP-MED (Media Endpoint Discovery): is a standard extension of LLDP that stores values for parameters such as QoS and VLAN to automatically configure network devices such as IP phones

•

RADIUS VLAN for voice: uses standard RADIUS attribute and LLDP-MED to automatically configure VLAN for IP phones

•

PoE allocations: support multiple methods (automatic, IEEE 802.3af class, LLDP-MED, or user specified) to allocate PoE power for more efficient energy savings

Warranty and support

•

Lifetime warranty: for as long as you own the product with advance replacement and next-business-day delivery (available in most countries)*

•

Electronic and telephone support: limited electronic and telephone support is available from HP; refer to www.hp.com/networking/warranty for details on the support provided and the period during which support is available

*Hardware warranty replacement for as long as you own the product, with next business day advance replacement (available in most countries) with a five-year hardware warranty replacement for the disk drive included with HP AllianceONE Services zl Module, HP Threat Management Services zl Module, HP PCM+ Agent with AllianceONE Services zl Module, and HP E-MSM765 zl Mobility Controller. For details, refer to the HP Software License, Warranty, and Support booklet at www.hp.com/networking/warranty.

4

•

Software releases: refer to

www.hp.com/networking/warranty for details on

the software releases provided and the period during which software releases are available for your product(s)

5

HP E5400 zl Switch Series

Specifications

Included accessories

Ports

Power supplies

Physical characteristics

Dimensions

Weight

Memory and processor

Gigabit Module

10G Module

Management Module

Mounting

Performance

1000 Mb Latency 10 Gbps Latency Throughput Routing/Switching capacity Switch fabric speed Routing table size MAC address table size

Environment

Operating temperature

Operating relative humidity Nonoperating/Storage temperature Nonoperating/Storage relative humidity Altitude Acoustic

Electrical characteristics

Description

Maximum heat dissipation

Voltage Idle power Frequency

HP E5406 zl Switch with Premium Software (J9642A)

1 HP E5400 zl Switch Premium License (J8994A) 1 HP E5400 zl Switch Premium License (J8994A) 1 HP 20-port Gig-T PoE+ / 2-port 10-GbE SFP+ v2

6 open module slots

Supports a maximum of 48 10-GbE ports or 144 autosensing 10/100/1000 ports or 144 mini-GBICs, or a combination

2 power-supply slots 4 power-supply slots 1 power-supply slots

17.75(d) x 17.5(w) x 6.9(h) in. (45.09 x 44.45 x

17.53 cm) (4U height)

23.55 lb. (10.68 kg) 34.94 lb. (15.85 kg) 46.08 lb. (20.9 kg)

ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR SDRAM

ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR SDRAM

Freescale PowerPC 8540 @ 666 MHz, 4 MB flash, 128 MB compact flash, 256 MB DDR SDRAM

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface mounting only

< 3.7 µs (FIFO 64-byte packets) < 3.7 µs (FIFO 64-byte packets) < 3.7 µs (FIFO 64-byte packets) < 2.1 µs (FIFO 64-byte packets) < 2.1 µs (FIFO 64-byte packets) < 2.1 µs (FIFO 64-byte packets) up to 282.1 million pps up to 564.2 million pps up to 282.1 million pps

379.2 Gbps 758.4 Gbps 379.2 Gbps

379.2 Gbps 758.4 Gbps 379.2 Gbps 10,000 entries 10,000 entries 10,000 entries 64,000 entries 64,000 entries 64,000 entries

32°F to 131°F (0°C to 55°C); 0°C to 40°C with J8706A or J8707A modules installed

15% to 95% @ 131°F (55°C), noncondensing 15% to 95% @ 131°F (55°C), noncondensing 15% to 95% @ 131°F (55°C), noncondensing

-40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C) 15% to 95% @ 149°F (65°C), noncondensing 15% to 95% @ 149°F (65°C), noncondensing 15% to 95% @ 149°F (65°C), noncondensing up to 10,000 ft. (3 km) up to 10,000 ft. (3 km) up to 10,000 ft. (3 km) Power: 57 dB, Pressure: 40.2 dB ISO 7779, ISO

9296

Achieved Miercom Certified Green Award

Chassis ships without power supplies. Two power supply slots are available; three different power supplies are available. See power supply products for additional specifications.

2450 BTU/hr (2584 kJ/hr), (max. non-PoE); 3700 BTU/hr (3903 kJ/hr) (max. using PoE)

100-127 / 200-240 VAC 100-127 / 200-240 VAC 110-127 / 200-240 VAC

50 / 60 Hz 50 / 60 Hz 50 / 60 Hz

HP E5412 zl Switch with Premium Software (J9643A)

12 open module slots

Supports a maximum of 96 10-GbE ports or 288 autosensing 10/100/1000 ports or 288 mini-GBICs, or a combination

17.75(d) x 17.5(w) x 12.1(h) in. (45.09 x 44.45 x

30.73 cm) (7U height)

ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR SDRAM

ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR SDRAM

Freescale PowerPC 8540 @ 666 MHz, 4 MB flash Mb, 128 MB compact flash, 256 MB DDR SDRAM

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface mounting only

32°F to 131°F (0°C to 55°C); 0°C to 40°C with J8706A or J8707A modules installed

Power: 64 dB, Pressure: 57.5 dB ISO 7779, ISO 9296

Chassis ships without power supplies. Four power supply slots are available; three different power supplies are available. See power supply products for additional specifications.

4900 BTU/hr (5169 kJ/hr), (max. non-PoE); 7400 BTU/hr (7,807 kJ/hr) (max. using PoE)

HP E5406-44G-PoE+/2XG-SFP+ v2 zl Switch with Premium Software (J9533A)

zl Module (J9536A) 1 HP 1500 W PoE+ zl Power Supply (J9306A) 1 HP 24-port Gig-T PoE+ v2 zl Module (J9534A) 1 HP E5400 zl Switch Premium License (J8994A)

44 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T, IEEE

802.3at PoE+); Media Type: Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full; 1000Base-T: full only

2 open 10-GbE SFP+ transceiver slots

4 open module slots

Supports a maximum of 16 10-GbE ports or 140 autosensing 10/100/1000 ports or 100 mini-GBICs, or a combination

includes: 1 x J9306AHP 1500 W PoE+ zl Power Supply

17.75(d) x 17.5(w) x 6.9(h) in. (45.09 x 44.45 x

17.53 cm) (4U height)

ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR SDRAM

ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR SDRAM

Freescale PowerPC 8540 @ 666 MHz, 4 MB flash, 128 MB compact flash, 256 MB DDR SDRAM

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface mounting only

32°F to 131°F (0°C to 55°C); 0°C to 40°C with J8706A or J8707A modules installed

Power: 57 dB, Pressure: 40.2 dB ISO 7779, ISO 9296

One J9306A installed. One open power supply slot is available; three different power supplies are available. See power supply products for additional specifications.

2450 BTU/hr (2584.75 kJ/hr), (max. non-PoE); 3700 BTU/hr (3903 kJ/hr) (max. using PoE)

215 W

6

HP E5400 zl Switch Series

Specifications (continued)

Notes

Safety

Emissions

Immunity

EN ESD Radiated EFT/Burst

Surge Conducted Power frequency magnetic field Voltage dips and interruptions

Harmonics Flicker

Management

Notes

HP E5406 zl Switch with Premium Software (J9642A)

Power supplies must be ordered separately. Heat dissipation does not include heat dissipated by the PoE-powered devices themselves.

CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A

EN 55024, CISPR 24 EN 55024, CISPR 24 EN 55024, CISPR 24 IEC 61000-4-2; 4 kV CD, 8 kV AD IEC 61000-4-2; 4 kV CD, 8 kV AD IEC 61000-4-2; 4 kV CD, 8 kV AD IEC 61000-4-3; 3 V/m IEC 61000-4-3; 3 V/m IEC 61000-4-3; 3 V/m IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal

line) IEC 61000-4-5; 1 kV/2 kV AC IEC 61000-4-5; 1 kV/2 kV AC IEC 61000-4-5; 1 kV/2 kV AC IEC 61000-4-6; 3 V IEC 61000-4-6; 3 V IEC 61000-4-6; 3 V IEC 61000-4-8; 1 A/m, 50 or 60 Hz IEC 61000-4-8; 1 A/m, 50 or 60 Hz IEC 61000-4-8; 1 A/m, 50 or 60 Hz IEC 61000-4-11; >95% reduction, 0.5 period; 30%

reduction, 25 periods EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2 EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3

HP PCM+; HP PCM (included); command-line interface; Web browser; configuration menu; out-of-band management (serial RS-232C)

When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with the letter "B" or later, e.g. J4858B, J4859C) are required. J8177B Gigabit 1000Base-T mini-GBIC is not supported on the 3500yl series switches. When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with the letter "B" or later, e.g., J4858B, J4859C) are required.

HP E5412 zl Switch with Premium Software (J9643A)

Power supplies must be ordered separately. Two power supplies are required to power the J8698A chassis. Heat dissipation does not include heat dissipated by the PoE-powered devices themselves.

CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

IEC 61000-4-11; >95% reduction, 0.5 period; 30% reduction, 25 periods

HP PCM+; HP PCM (included); command-line interface; Web browser; configuration menu; out-of-band management (serial RS-232C)

When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with the letter "B" or later, e.g. J4858B, J4859C) are required. J8177B Gigabit 1000Base-T mini-GBIC is not supported on the 3500yl series switches. When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with the letter "B" or later, e.g., J4858B, J4859C) are required.

HP E5406-44G-PoE+/2XG-SFP+ v2 zl Switch with Premium Software (J9533A)

Idle power is the actual power consumption of the device with no ports connected. Heat dissipation does not include heat dissipated by the PoE-powered devices themselves.

CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

IEC 61000-4-11; >95% reduction, 0.5 period; 30% reduction, 25 periods

HP PCM+; HP PCM (included); command-line interface; Web browser; configuration menu; out-of-band management (serial RS-232C)

When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with the letter "B" or later, e.g. J4858B, J4859C) are required. J8177B Gigabit 1000Base-T mini-GBIC is not supported on the 3500yl series switches. When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with the letter "B" or later, e.g., J4858B, J4859C) are required.

7

HP E5400 zl Switch Series

Specifications (continued)

Services

HP E5406 zl Switch with Premium Software (J9642A)

3-year, 4-hour onsite, 13x5 coverage for hardware (UE250E) 3-year, 4-hour onsite, 24x7 coverage for hardware (UE251E) 3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (UE252E) 3-year, 24x7 SW phone support, software updates (UF786E) Installation with minimum configuration, system-based pricing (U4828E) Installation with HP-provided configuration, system-based pricing (U4832E) 4-year, 4-hour onsite, 13x5 coverage for hardware (UR900E) 4-year, 4-hour onsite, 24x7 coverage for hardware (UR901E) 4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR902E) 4-year, 24x7 SW phone support, software updates (UR903E) 5-year, 4-hour onsite, 13x5 coverage for hardware (UR904E) 5-year, 4-hour onsite, 24x7 coverage for hardware (UR905E) 5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR906E) 5-year, 24x7 SW phone support, software updates (UR907E) 3 Yr 6 hr Call-to-Repair Onsite (UW377E) 4 Yr 6 hr Call-to-Repair Onsite (UW378E) 5 Yr 6 hr Call-to-Repair Onsite (UW379E)

Refer to the HP website at

www.hp.com/networking/services for details on the

service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

HP E5412 zl Switch with Premium Software (J9643A)

3-year, 4-hour onsite, 13x5 coverage for hardware (UE253E) 3-year, 4-hour onsite, 24x7 coverage for hardware (UE254E) 3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (UE255E) 3-year, 24x7 SW phone support, software updates (UF788E) Installation with minimum configuration, system-based pricing (U4828E) Installation with HP-provided configuration, system-based pricing (U4832E) 4-year, 4-hour onsite, 13x5 coverage for hardware (UR916E) 4-year, 4-hour onsite, 24x7 coverage for hardware (UR917E) 4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR918E) 4-year, 24x7 SW phone support, software updates (UR919E) 5-year, 4-hour onsite, 13x5 coverage for hardware (UR920E) 5-year, 4-hour onsite, 24x7 coverage for hardware (UR921E) 5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR922E) 5-year, 24x7 SW phone support, software updates (UR923E) 3 Yr 6 hr Call-to-Repair Onsite (UW380E) 4 Yr 6 hr Call-to-Repair Onsite (UW381E) 5 Yr 6 hr Call-to-Repair Onsite (UW382E)

Refer to the HP website at

www.hp.com/networking/services for details on the

service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

HP E5406-44G-PoE+/2XG-SFP+ v2 zl Switch with Premium Software (J9533A)

3-year, 4-hour onsite, 13x5 coverage for hardware (UE250E) 3-year, 4-hour onsite, 24x7 coverage for hardware (UE251E) 3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (UE252E) 3-year, 24x7 SW phone support, software updates (UF786E) Installation with minimum configuration, system-based pricing (U4828E) Installation with HP-provided configuration, system-based pricing (U4832E) 4-year, 4-hour onsite, 13x5 coverage for hardware (UR900E) 4-year, 4-hour onsite, 24x7 coverage for hardware (UR901E) 4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR902E) 4-year, 24x7 SW phone support, software updates (UR903E) 5-year, 4-hour onsite, 13x5 coverage for hardware (UR904E) 5-year, 4-hour onsite, 24x7 coverage for hardware (UR905E) 5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR906E) 5-year, 24x7 SW phone support, software updates (UR907E) 3 Yr 6 hr Call-to-Repair Onsite (UW377E) 4 Yr 6 hr Call-to-Repair Onsite (UW378E) 5 Yr 6 hr Call-to-Repair Onsite (UW379E)

Refer to the HP website at

www.hp.com/networking/services for details on the

service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

8

HP E5400 zl Switch Series

Specifications (continued)

Standards and protocols

(applies to all products in series)

HP E5406 zl Switch with Premium Software (J9642A)

Device management

RFC 1591 DNS (client) HTML and telnet management

General protocols

IEEE 802.1ad Q-in-Q IEEE 802.1AX-2008 Link Aggregation IEEE 802.1D MAC Bridges IEEE 802.1p Priority IEEE 802.1Q VLANs IEEE 802.1s Multiple Spanning Trees IEEE 802.1v VLAN classification by Protocol and Port IEEE 802.1w Rapid Reconfiguration of Spanning Tree IEEE 802.3ad Link Aggregation Control Protocol (LACP) IEEE 802.3af Power over Ethernet IEEE 802.3x Flow Control RFC 768 UDP RFC 783 TFTP Protocol (revision 2) RFC 792 ICMP RFC 793 TCP RFC 826 ARP RFC 854 TELNET RFC 868 Time Protocol RFC 951 BOOTP RFC 1058 RIPv1 RFC 1350 TFTP Protocol (revision 2) RFC 1519 CIDR RFC 1542 BOOTP Extensions RFC 2030 Simple Network Time Protocol (SNTP) v4 RFC 2131 DHCP RFC 2453 RIPv2 RFC 2548 (MS-RAS-Vendor only) RFC 3046 DHCP Relay Agent Information Option RFC 3576 Ext to RADIUS (CoA only) RFC 3768 VRRP RFC 4675 RADIUS VLAN & Priority UDLD (Uni-directional Link Detection)

IP multicast

RFC 3376 IGMPv3 (host joins only) RFC 3973 Draft 2 PIM Dense Mode RFC 4601 Draft 10 PIM Sparse Mode

HP E5412 zl Switch with Premium Software (J9643A)

IPv6

RFC 1981 IPv6 Path MTU Discovery RFC 2375 IPv6 Multicast Address Assignments RFC 2460 IPv6 Specification RFC 2464 Transmission of IPv6 over Ethernet Networks RFC 2710 Multicast Listener Discovery (MLD) for IPv6 RFC 2925 Definitions of Managed Objects for Remote Ping, Traceroute, and Lookup Operations (Ping only) RFC 3019 MLDv1 MIB RFC 3315 DHCPv6 (client and relay) RFC 3484 Default Address Selection for IPv6 RFC 3587 IPv6 Global Unicast Address Format RFC 3596 DNS Extension for IPv6 RFC 3810 MLDv2 (host joins only) RFC 4022 MIB for TCP RFC 4113 MIB for UDP RFC 4251 SSHv6 Architecture RFC 4252 SSHv6 Authentication RFC 4253 SSHv6 Transport Layer RFC 4254 SSHv6 Connection RFC 4291 IP Version 6 Addressing Architecture RFC 4293 MIB for IP RFC 4294 IPv6 Node Requirements RFC 4419 Key Exchange for SSH RFC 4443 ICMPv6 RFC 4541 IGMP & MLD Snooping Switch RFC 4861 IPv6 Neighbor Discovery RFC 4862 IPv6 Stateless Address Auto-configuration RFC 5095 Deprecation of Type 0 Routing Headers in IPv6 RFC 5340 OSPFv3 for IPv6 RFC 5453 Reserved IPv6 Interface Identifiers RFC 5722 Handling of Overlapping IPv6 Fragments

MIBs

RFC 1213 MIB II RFC 1493 Bridge MIB RFC 1724 RIPv2 MIB

HP E5406-44G-PoE+/2XG-SFP+ v2 zl Switch with Premium Software (J9533A)

RFC 1850 OSPFv2 MIB RFC 2021 RMONv2 MIB RFC 2096 IP Forwarding Table MIB RFC 2613 SMON MIB RFC 2618 RADIUS Client MIB RFC 2620 RADIUS Accounting MIB RFC 2665 Ethernet-Like-MIB RFC 2668 802.3 MAU MIB RFC 2674 802.1p and IEEE 802.1Q Bridge MIB RFC 2737 Entity MIB (Version 2) RFC 2787 VRRP MIB RFC 2863 The Interfaces Group MIB RFC 2925 Ping MIB

Network management

IEEE 802.1AB Link Layer Discovery Protocol (LLDP) RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events) RFC 3176 sFlow ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED) SNMPv1/v2c/v3 XRMON

OSPF

RFC 2328 OSPFv2 RFC 3101 OSPF NSSA RFC 5340 OSPFv3 for IPv6

QoS/CoS

RFC 2474 DiffServ Precedence, including 8 queues/port RFC 2597 DiffServ Assured Forwarding (AF) RFC 2598 DiffServ Expedited Forwarding (EF)

Security

IEEE 802.1X Port Based Network Access Control RFC 1492 TACACS+ RFC 2865 RADIUS (client only) RFC 2866 RADIUS Accounting Secure Sockets Layer (SSL) SSHv1/SSHv2 Secure Shell

9

HP E5400 zl Switch Series

Specifications (continued)

Included accessories

Ports

Power supplies

Physical characteristics

Dimensions

Weight

Memory and processor

Gigabit Module

10G Module

Management Module

Mounting

Performance

1000 Mb Latency 10 Gbps Latency Throughput Routing/Switching capacity Switch fabric speed Routing table size MAC address table size

Environment

Operating temperature

Operating relative humidity Nonoperating/Storage temperature Nonoperating/Storage relative humidity Altitude Acoustic

Electrical characteristics

Description

Maximum heat dissipation

Voltage Idle power Frequency

HP E5412-92G-PoE+/2XG-SFP+ v2 zl Switch with Premium Software (J9532A)

3 HP 24-port Gig-T PoE+ v2 zl Module (J9534A) 1 HP 20-port Gig-T PoE+ / 2-port 10-GbE SFP+ v2 zl Module (J9536A) 2 HP 1500 W PoE+ zl Power Supply (J9306A) 1 HP E5400 zl Switch Premium License (J8994A)

92 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T, IEEE

802.3at PoE+); Media Type: Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full; 1000Base-T: full only

2 open 10-GbE SFP+ transceiver slots

8 open module slots

Supports a maximum of 32 10-GbE ports or 284 autosensing 10/100/1000 ports or 196 mini-GBICs, or a combination

2 power-supply slots includes: 2 x J9306AHP 1500 W PoE+ zl Power Supply

17.75(d) x 17.5(w) x 12.1(h) in. (45.09 x 44.45 x

30.73 cm) (7U height)

75.36 lb. (34.18 kg) 45.58 lb. (20.68 kg) 74.86 lb. (33.96 kg)

ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR SDRAM

ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR SDRAM

Freescale PowerPC 8540 @ 666 MHz, 4 MB flash Mb, 128 MB compact flash, 256 MB DDR SDRAM

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface mounting only

< 3.7 µs (FIFO 64-byte packets) < 3.7 µs (FIFO 64-byte packets) < 3.7 µs (FIFO 64-byte packets) < 2.1 µs (FIFO 64-byte packets) < 2.1 µs (FIFO 64-byte packets) < 2.1 µs (FIFO 64-byte packets) up to 564.2 million pps up to 282.1 million pps up to 564.2 million pps

758.4 Gbps 379.2 Gbps 758.4 Gbps

758.4 Gbps 379.2 Gbps 758.4 Gbps 10,000 entries 10,000 entries 10,000 entries 64,000 entries 64,000 entries 64,000 entries

32°F to 131°F (0°C to 55°C); 0°C to 40°C with J8706A or J8707A modules installed

15% to 95% @ 131°F (55°C), noncondensing 15% to 95% @ 131°F (55°C), noncondensing 15% to 95% @ 131°F (55°C), noncondensing

-40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C) 15% to 95% @ 149°F (65°C), noncondensing 15% to 95% @ 149°F (65°C), noncondensing 15% to 95% @ 149°F (65°C), noncondensing up to 10,000 ft. (3 km) up to 10,000 ft. (3 km) up to 10,000 ft. (3 km) Power: 64 dB, Pressure: 57.5 dB ISO 7779, ISO

9296

Two J9306A installed. Two open power supply slots are available; three different power supplies are available. See power supply products for additional specifications.

4900 BTU/hr (5169.5 kJ/hr), (max. non-PoE); 7400 BTU/hr (7807 kJ/hr) (max. using PoE)

110-127 / 200-240 VAC 110-127 / 200-240 VAC 110-127 / 200-240 VAC 312 W 215 W 312 W 50 / 60 Hz 50 / 60 Hz 50 / 60 Hz

HP E5406-44G-PoE+/4G-SFP v2 zl Switch with Premium Software (J9539A)

1 HP 24-port Gig-T PoE+ v2 zl Module (J9534A) 1 HP 20-port Gig-T PoE+ / 4-port SFP v2 zl Module (J9535A) 1 HP 1500 W PoE+ zl Power Supply (J9306A) 1 HP E5400 zl Switch Premium License (J8994A)

44 RJ-45 autosensing 10/100/1000 ports (IEEE

802.3 Type 10Base-T, IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); Media Type: Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full; 1000Base-T: full only

4 open mini-GBIC slots

4 open module slots

Supports a maximum of 16 10-GbE ports or 140 autosensing 10/100/1000 ports or 100 mini-GBICs, or a combination

1 power-supply slots includes: 1 x J9306AHP 1500 W PoE+ zl Power Supply

17.75(d) x 17.5(w) x 6.9(h) in. (45.09 x 44.45 x

17.53 cm) (4U height)

ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR SDRAM

ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR SDRAM

Freescale PowerPC 8540 @ 666 MHz, 4 MB flash, 128 MB compact flash, 256 MB DDR SDRAM

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface mounting only

32°F to 131°F (0°C to 55°C); 0°C to 40°C with J8706A or J8707A modules installed

Power: 57 dB, Pressure: 40.2 dB ISO 7779, ISO 9296

One J9306A installed. One open power supply slot is available; three different power supplies are available. See power supply products for additional specifications.

2450 BTU/hr (2584.75 kJ/hr), (max. non-PoE); 3700 BTU/hr (3903 kJ/hr) (max. using PoE)

HP E5412-92G-PoE+/4G-SFP v2 zl Switch with Premium Software (J9540A)

3 HP 24-port Gig-T PoE+ v2 zl Module (J9534A) 1 HP 20-port Gig-T PoE+ / 4-port SFP v2 zl Module (J9535A) 2 HP 1500 W PoE+ zl Power Supply (J9306A) 1 HP E5400 zl Switch Premium License (J8994A)

92 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T, IEEE

802.3at PoE+); Media Type: Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full; 1000Base-T: full only

4 open mini-GBIC slots

8 open module slots

Supports a maximum of 32 10-GbE ports or 284 autosensing 10/100/1000 ports or 196 mini-GBICs, or a combination

2 power-supply slots includes: 2 x J9306AHP 1500 W PoE+ zl Power Supply

17.75(d) x 17.5(w) x 12.1(h) in. (45.09 x 44.45 x

30.73 cm) (7U height)

ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR SDRAM

ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR SDRAM

Freescale PowerPC 8540 @ 666 MHz, 4 MB flash Mb, 128 MB compact flash, 256 MB DDR SDRAM

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface mounting only

32°F to 131°F (0°C to 55°C); 0°C to 40°C with J8706A or J8707A modules installed

Power: 64 dB, Pressure: 57.5 dB ISO 7779, ISO 9296

Two J9306A installed. Two open power supply slots are available; three different power supplies are available. See power supply products for additional specifications.

4900 BTU/hr (5169.5 kJ/hr), (max. non-PoE); 7400 BTU/hr (7807 kJ/hr) (max. using PoE)

10

HP E5400 zl Switch Series

Specifications (continued)

Notes

Safety

Emissions

Immunity

EN ESD Radiated EFT/Burst

Surge Conducted Power frequency magnetic field Voltage dips and interruptions

Harmonics Flicker

Management

Notes

HP E5412-92G-PoE+/2XG-SFP+ v2 zl Switch with Premium Software (J9532A)

Idle power is the actual power consumption of the device with no ports connected. Heat dissipation does not include heat dissipated by the PoE-powered devices themselves.

CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A

EN 55024, CISPR 24 EN 55024, CISPR 24 EN 55024, CISPR 24 IEC 61000-4-2; 4 kV CD, 8 kV AD IEC 61000-4-2; 4 kV CD, 8 kV AD IEC 61000-4-2; 4 kV CD, 8 kV AD IEC 61000-4-3; 3 V/m IEC 61000-4-3; 3 V/m IEC 61000-4-3; 3 V/m IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal

line) IEC 61000-4-5; 1 kV/2 kV AC IEC 61000-4-5; 1 kV/2 kV AC IEC 61000-4-5; 1 kV/2 kV AC IEC 61000-4-6; 3 V IEC 61000-4-6; 3 V IEC 61000-4-6; 3 V IEC 61000-4-8; 1 A/m, 50 or 60 Hz IEC 61000-4-8; 1 A/m, 50 or 60 Hz IEC 61000-4-8; 1 A/m, 50 or 60 Hz IEC 61000-4-11; >95% reduction, 0.5 period; 30%

reduction, 25 periods EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2 EN 61000-3-2, IEC 61000-3-2 EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3 EN 61000-3-3, IEC 61000-3-3

HP PCM+; HP PCM (included); command-line interface; Web browser; configuration menu; out-of-band management (serial RS-232C)

When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with the letter "B" or later, e.g. J4858B, J4859C) are required. J8177B Gigabit 1000Base-T mini-GBIC is not supported on the 3500yl series switches. When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with the letter "B" or later, e.g., J4858B, J4859C) are required.

HP E5406-44G-PoE+/4G-SFP v2 zl Switch with Premium Software (J9539A)

Idle power is the actual power consumption of the device with no ports connected. Heat dissipation does not include heat dissipated by the PoE-powered devices themselves.

CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

IEC 61000-4-11; >95% reduction, 0.5 period; 30% reduction, 25 periods

HP PCM+; HP PCM (included); command-line interface; Web browser; configuration menu; out-of-band management (serial RS-232C)

When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with the letter "B" or later, e.g. J4858B, J4859C) are required. J8177B Gigabit 1000Base-T mini-GBIC is not supported on the 3500yl series switches. When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with the letter "B" or later, e.g., J4858B, J4859C) are required.

HP E5412-92G-PoE+/4G-SFP v2 zl Switch with Premium Software (J9540A)

Idle power is the actual power consumption of the device with no ports connected. Heat dissipation does not include heat dissipated by the PoE-powered devices themselves.

CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

IEC 61000-4-11; >95% reduction, 0.5 period; 30% reduction, 25 periods

HP PCM+; HP PCM (included); command-line interface; Web browser; configuration menu; out-of-band management (serial RS-232C)

When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with the letter "B" or later, e.g. J4858B, J4859C) are required. J8177B Gigabit 1000Base-T mini-GBIC is not supported on the 3500yl series switches. When using mini-GBICs with this product, mini-GBICs with revision "B" or later (product number ends with the letter "B" or later, e.g., J4858B, J4859C) are required.

11

HP E5400 zl Switch Series

Specifications (continued)

Services

HP E5412-92G-PoE+/2XG-SFP+ v2 zl Switch with Premium Software (J9532A)

3-year, 4-hour onsite, 13x5 coverage for hardware (UE253E) 3-year, 4-hour onsite, 24x7 coverage for hardware (UE254E) 3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (UE255E) 3-year, 24x7 SW phone support, software updates (UF788E) Installation with minimum configuration, system-based pricing (U4828E) Installation with HP-provided configuration, system-based pricing (U4832E) 4-year, 4-hour onsite, 13x5 coverage for hardware (UR916E) 4-year, 4-hour onsite, 24x7 coverage for hardware (UR917E) 4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR918E) 4-year, 24x7 SW phone support, software updates (UR919E) 5-year, 4-hour onsite, 13x5 coverage for hardware (UR920E) 5-year, 4-hour onsite, 24x7 coverage for hardware (UR921E) 5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR922E) 5-year, 24x7 SW phone support, software updates (UR923E) 3 Yr 6 hr Call-to-Repair Onsite (UW380E) 4 Yr 6 hr Call-to-Repair Onsite (UW381E) 5 Yr 6 hr Call-to-Repair Onsite (UW382E)

Refer to the HP website at

www.hp.com/networking/services for details on the

service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

HP E5406-44G-PoE+/4G-SFP v2 zl Switch with Premium Software (J9539A)

3-year, 4-hour onsite, 13x5 coverage for hardware (UE250E) 3-year, 4-hour onsite, 24x7 coverage for hardware (UE251E) 3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (UE252E) 3-year, 24x7 SW phone support, software updates (UF786E) Installation with minimum configuration, system-based pricing (U4828E) Installation with HP-provided configuration, system-based pricing (U4832E) 4-year, 4-hour onsite, 13x5 coverage for hardware (UR900E) 4-year, 4-hour onsite, 24x7 coverage for hardware (UR901E) 4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR902E) 4-year, 24x7 SW phone support, software updates (UR903E) 5-year, 4-hour onsite, 13x5 coverage for hardware (UR904E) 5-year, 4-hour onsite, 24x7 coverage for hardware (UR905E) 5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR906E) 5-year, 24x7 SW phone support, software updates (UR907E) 3 Yr 6 hr Call-to-Repair Onsite (UW377E) 4 Yr 6 hr Call-to-Repair Onsite (UW378E) 5 Yr 6 hr Call-to-Repair Onsite (UW379E)

Refer to the HP website at

www.hp.com/networking/services for details on the

service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

HP E5412-92G-PoE+/4G-SFP v2 zl Switch with Premium Software (J9540A)

3-year, 4-hour onsite, 13x5 coverage for hardware (UE253E) 3-year, 4-hour onsite, 24x7 coverage for hardware (UE254E) 3-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone support (UE255E) 3-year, 24x7 SW phone support, software updates (UF788E) Installation with minimum configuration, system-based pricing (U4828E) Installation with HP-provided configuration, system-based pricing (U4832E) 4-year, 4-hour onsite, 13x5 coverage for hardware (UR916E) 4-year, 4-hour onsite, 24x7 coverage for hardware (UR917E) 4-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR918E) 4-year, 24x7 SW phone support, software updates (UR919E) 5-year, 4-hour onsite, 13x5 coverage for hardware (UR920E) 5-year, 4-hour onsite, 24x7 coverage for hardware (UR921E) 5-year, 4-hour onsite, 24x7 coverage for hardware, 24x7 software phone (UR922E) 5-year, 24x7 SW phone support, software updates (UR923E) 3 Yr 6 hr Call-to-Repair Onsite (UW380E) 4 Yr 6 hr Call-to-Repair Onsite (UW381E) 5 Yr 6 hr Call-to-Repair Onsite (UW382E)

Refer to the HP website at

www.hp.com/networking/services for details on the

service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

12

HP E5400 zl Switch Series

Specifications (continued)

Standards and protocols

(applies to all products in series)

HP E5412-92G-PoE+/2XG-SFP+ v2 zl Switch with Premium Software (J9532A)

Device management

RFC 1591 DNS (client) HTML and telnet management

General protocols

IEEE 802.1ad Q-in-Q IEEE 802.1AX-2008 Link Aggregation IEEE 802.1D MAC Bridges IEEE 802.1p Priority IEEE 802.1Q VLANs IEEE 802.1s Multiple Spanning Trees IEEE 802.1v VLAN classification by Protocol and Port IEEE 802.1w Rapid Reconfiguration of Spanning Tree IEEE 802.3ad Link Aggregation Control Protocol (LACP) IEEE 802.3af Power over Ethernet IEEE 802.3x Flow Control RFC 768 UDP RFC 783 TFTP Protocol (revision 2) RFC 792 ICMP RFC 793 TCP RFC 826 ARP RFC 854 TELNET RFC 868 Time Protocol RFC 951 BOOTP RFC 1058 RIPv1 RFC 1350 TFTP Protocol (revision 2) RFC 1519 CIDR RFC 1542 BOOTP Extensions RFC 2030 Simple Network Time Protocol (SNTP) v4 RFC 2131 DHCP RFC 2453 RIPv2 RFC 2548 (MS-RAS-Vendor only) RFC 3046 DHCP Relay Agent Information Option RFC 3576 Ext to RADIUS (CoA only) RFC 3768 VRRP RFC 4675 RADIUS VLAN & Priority UDLD (Uni-directional Link Detection)

IP multicast

RFC 3376 IGMPv3 (host joins only) RFC 3973 Draft 2 PIM Dense Mode RFC 4601 Draft 10 PIM Sparse Mode

HP E5406-44G-PoE+/4G-SFP v2 zl Switch with Premium Software (J9539A)

IPv6

RFC 1981 IPv6 Path MTU Discovery RFC 2375 IPv6 Multicast Address Assignments RFC 2460 IPv6 Specification RFC 2464 Transmission of IPv6 over Ethernet Networks RFC 2710 Multicast Listener Discovery (MLD) for IPv6 RFC 2925 Definitions of Managed Objects for Remote Ping, Traceroute, and Lookup Operations (Ping only) RFC 3019 MLDv1 MIB RFC 3315 DHCPv6 (client and relay) RFC 3484 Default Address Selection for IPv6 RFC 3587 IPv6 Global Unicast Address Format RFC 3596 DNS Extension for IPv6 RFC 3810 MLDv2 (host joins only) RFC 4022 MIB for TCP RFC 4113 MIB for UDP RFC 4251 SSHv6 Architecture RFC 4252 SSHv6 Authentication RFC 4253 SSHv6 Transport Layer RFC 4254 SSHv6 Connection RFC 4291 IP Version 6 Addressing Architecture RFC 4293 MIB for IP RFC 4294 IPv6 Node Requirements RFC 4419 Key Exchange for SSH RFC 4443 ICMPv6 RFC 4541 IGMP & MLD Snooping Switch RFC 4861 IPv6 Neighbor Discovery RFC 4862 IPv6 Stateless Address Auto-configuration RFC 5095 Deprecation of Type 0 Routing Headers in IPv6 RFC 5340 OSPFv3 for IPv6 RFC 5453 Reserved IPv6 Interface Identifiers RFC 5722 Handling of Overlapping IPv6 Fragments

MIBs

RFC 1213 MIB II RFC 1493 Bridge MIB RFC 1724 RIPv2 MIB

HP E5412-92G-PoE+/4G-SFP v2 zl Switch with Premium Software (J9540A)

RFC 1850 OSPFv2 MIB RFC 2021 RMONv2 MIB RFC 2096 IP Forwarding Table MIB RFC 2613 SMON MIB RFC 2618 RADIUS Client MIB RFC 2620 RADIUS Accounting MIB RFC 2665 Ethernet-Like-MIB RFC 2668 802.3 MAU MIB RFC 2674 802.1p and IEEE 802.1Q Bridge MIB RFC 2737 Entity MIB (Version 2) RFC 2787 VRRP MIB RFC 2863 The Interfaces Group MIB RFC 2925 Ping MIB

Network management

IEEE 802.1AB Link Layer Discovery Protocol (LLDP) RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events) RFC 3176 sFlow ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED) SNMPv1/v2c/v3 XRMON

OSPF

RFC 2328 OSPFv2 RFC 3101 OSPF NSSA RFC 5340 OSPFv3 for IPv6

QoS/CoS

RFC 2474 DiffServ Precedence, including 8 queues/port RFC 2597 DiffServ Assured Forwarding (AF) RFC 2598 DiffServ Expedited Forwarding (EF)

Security

IEEE 802.1X Port Based Network Access Control RFC 1492 TACACS+ RFC 2865 RADIUS (client only) RFC 2866 RADIUS Accounting Secure Sockets Layer (SSL) SSHv1/SSHv2 Secure Shell

13

HP E5400 zl Switch Series

Specifications (continued)

HP E5406-44G-PoE+/4SFP zl Switch (J9447A) HP E5412-92G-PoE+/4SFP zl Switch (J9448A)

Included accessories

Ports

Power supplies

Physical characteristics

Dimensions Weight

Memory and processor

Gigabit Module 10G Module Management Module

Mounting

Performance

1000 Mb Latency 10 Gbps Latency Throughput Routing/Switching capacity Switch fabric speed Routing table size MAC address table size

Environment

Operating temperature

Operating relative humidity Nonoperating/Storage temperature Nonoperating/Storage relative humidity Altitude Acoustic

Electrical characteristics

Description

Maximum heat dissipation

Voltage Idle power Frequency Notes

Safety

Emissions

Immunity

EN ESD Radiated EFT/Burst

1 HP ProCurve 24-Port 10/100/1000 PoE+ zl Module (J9307A) 1 HP ProCurve 20-Port 10/100/1000 PoE+ and 4-Port Mini-GBIC zl Module (J9308A) 1 HP ProCurve 1500W PoE+ zl Power Supply (J9306A)

44 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T, IEEE

802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); Media Type: Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full; 1000Base-T: full only

4 open mini-GBIC slots

4 open module slots

Supports a maximum of 16 10-GbE ports or 140 autosensing 10/100/1000 ports or 100 mini-GBICs, or a combination

1 power-supply slots includes: 1 x J9306AHP 1500 W PoE+ zl Power Supply

17.75(d) x 17.5(w) x 6.9(h) in. (45.09 x 44.45 x 17.53 cm) (4U height) 17.75(d) x 17.5(w) x 12.1(h) in. (45.09 x 44.45 x 30.73 cm) (7U height)

34.9 lb. (15.83 kg) 58.18 lb. (26.39 kg)

ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR SDRAM ARM9 @ 200 MHz; packet buffer size: 144 Mb QDR SDRAM ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR SDRAM ARM9 @ 200 MHz; packet buffer size: 36 Mb QDR SDRAM Freescale PowerPC 8540 @ 666 MHz, 4 MB flash, 128 MB compact flash,

256 MB DDR SDRAM

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); horizontal surface mounting only

< 3.7 µs (FIFO 64-byte packets) < 3.7 µs (FIFO 64-byte packets) < 2.1 µs (FIFO 64-byte packets) < 2.1 µs (FIFO 64-byte packets) up to 282.1 million pps up to 564.2 million pps

379.2 Gbps 758.4 Gbps

379.2 Gbps 758.4 Gbps 10,000 entries 10,000 entries 64,000 entries 64,000 entries

32°F to 131°F (0°C to 55°C); 0°C to 40°C with J8706A or J8707A modules installed

15% to 95% @ 131°F (55°C), noncondensing 15% to 95% @ 131°F (55°C), noncondensing

-40°F to 158°F (-40°C to 70°C) -40°F to 158°F (-40°C to 70°C) 15% to 95% @ 149°F (65°C), noncondensing 15% to 95% @ 149°F (65°C), noncondensing up to 10,000 ft. (3 km) up to 10,000 ft. (3 km) Power: 57 dB, Pressure: 40.2 dB ISO 7779, ISO 9296 Power: 64 dB, Pressure: 57.5 dB ISO 7779, ISO 9296

One J9306A installed. One open power supply slot is available; three different power supplies are available. See power supply products for additional specifications.

2450 BTU/hr (2584.75 kJ/hr), (max. non-PoE); 3700 BTU/hr (3903 kJ/hr) (max. using PoE)

110-127 / 200-240 VAC 110-127 / 200-240 VAC 215 W 312 W 50 / 60 Hz 50 / 60 Hz Idle power is the actual power consumption of the device with no ports

connected. Heat dissipation does not include heat dissipated by the PoE-powered devices themselves.

CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950 CSA 22.2 No. 60950; UL 60950; IEC 60950; EN 60950

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A

EN 55024, CISPR 24 EN 55024, CISPR 24 IEC 61000-4-2; 4 kV CD, 8 kV AD IEC 61000-4-2; 4 kV CD, 8 kV AD IEC 61000-4-3; 3 V/m IEC 61000-4-3; 3 V/m IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line) IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

3 HP ProCurve 24-Port 10/100/1000 PoE+ zl Module (J9307A) 1 HP ProCurve 20-Port 10/100/1000 PoE+ and 4-Port Mini-GBIC zl Module (J9308A) 2 HP ProCurve 1500W PoE+ zl Power Supply (J9306A)

92 autosensing 10/100/1000 ports (IEEE 802.3 Type 10Base-T, IEEE 802.3u Type 100Base-TX, IEEE 802.3ab Type 1000Base-T); Media Type: Auto-MDIX; Duplex: 10Base-T/100Base-TX: half or full; 1000Base-T: full only
