QuickSpecs
HP E24q G4 QHD Monitor
Technical Specifications
c06922713 — DA16764— Worldwide — Version 3 — February 28, 2021
Page 1
HP E24q G4 QHD Monitor
Front
1.
OSD Buttons
2.
Power Button
QuickSpecs
HP E24q G4 QHD Monitor
Technical Specifications
c06922713 — DA16764— Worldwide — Version 3 — February 28, 2021
Page 2
HP E24q G4 QHD Monitor
Back
1.
Power Connector
5.
USB-B Port
2.
DisplayPort™
6.
USB-A Ports (2)
3.
HDMI Port
7.
USB-A Ports (2)
4.
VGA Port
QuickSpecs
HP E24q G4 QHD Monitor
Technical Specifications
c06922713 — DA16764— Worldwide — Version 3 — February 28, 2021
Page 3
Models: 9VG12AA
Panel Specifications
Display Size (Diagonal)
23.8-in
Display Panel Type
IPS Micro-Edge Bezel
Yes, 3-sided
Native Resolution/Timing
2560x1440 @60Hz
Panel Bit Depth
8bit (6bit + FRC)
Aspect Ratio
16:9
Brightness - Typical
250 cd/m²
Static Contrast Ratio - Typical
1000:1
Static Contrast Ratio - Minimum
700:1
Dynamic Contrast Ratio (DCR)
5M:1
Flicker Free
Yes Pixel Pitch
0.2058 (H) × 0.2058(V) mm
Pixels Per Inch (PPI)
123
Backlight Lamp Life (to half brightness
- in hours)
30k minimum
Anti-Glare Panel
Yes Response Time - Typical
4 ms
Horizontal Viewing Angle (typical
CR>10)
178°
Vertical Viewing Angle (typical CR>10)
178°
Panel Active Area (w x h)
526.85(H) × 296.35(V) mm
Preset Graphic Modes/Supported
Resolutions
640 × 480 @60Hz
720 × 400 @70Hz
800 × 600 @60Hz
1024 × 768 @60Hz
1280 × 720 @60Hz
1280 x 800 @60 HZ
1280 × 1024@60Hz
1440 × 900 @60Hz
1600 × 900 @60Hz
1680 × 1050 @60Hz
1920 × 1080 @60Hz
1920 x 1200 @ 60Hz
2560 x 1440 @ 60Hz
Maximum Resolution
2560 x 1440 @ 60Hz
Recommended Resolution
2560 x 1440 @ 60Hz
Vertical Scan Range
50-60Hz
Horizontal Scan Range
30-90kHz
Default Color Temperature
Neutral (6500K)
NOTE: Performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
Color Gamut Coverage
NTSC
72%
Color Management
Color Space / Subsampling Support
RGB 4:4:4, YCBCR 4:4:4, YCBCR 4:2:2
Default Color Temperature
Neutral (6500 K)
Low Blue Light Modes
Yes, HP Eye Ease (TÜV Low Blue Light Hardware Solution
certified)
RGB Channel Adjust
Yes, Gain
QuickSpecs
HP E24q G4 QHD Monitor
Technical Specifications
c06922713 — DA16764— Worldwide — Version 3 — February 28, 2021
Page 4
Monitor Specifications
Exterior Color of Monitor Bezel and
Stand
Black head, Silver stand
Plug & Play
Yes Tilt
–5° to +23°
Swivel
+/-45°
Pivot
+/-90°
Height Adjustment Range
150mm
VESA Mounting
Yes, 100 mm
Security Lock Ready
Yes Detachable Base
Yes, ships detached
Warranty
Based on region
On Screen Display
(OSD)
On Screen Display User Controls
Brightness+, Color, Image, Input, Power, Menu,
Management, Information
Monitor Control Buttons or Switches
Menu, Minus ("-")/Information, Plus ("+") /Viewing Mode,
OK/Next Active Input, Power
User-Assignable Function Buttons
Yes, 4
Languages
10 (German, Dutch, T-Chinese and S-Chinese, English,
Spanish, French, Italian, Japanese, Portuguese)
Connector Types
DisplayPort™
1 DisplayPort™ 1.2 in
HDMI
1 HDMI1.4
VGA 1
HDCP support
Yes, (DisplayPort™ and HDMI)
USB Port
Specifications
USB Version
3.2
USB Hub
Yes
Downstream Ports
4 Ports
Upstream Ports
1 USB-B port
Fast Charging USB Ports
1 Ports (Side) (USB-A)
Power Output Maximum
Fast Charging: 7.5 W
Special Features
User Presets
Yes User Updateable Firmware
Yes
Power & Operating
Specs
Power Supply
Internal
Power Source
100 – 240 VAC 50/60 Hz
Power Consumption - Maximum
175 W
Energy Saving/Standby Mode
0.5 W
Power Consumption - Typical
70 W
Power cable length
1.9 m
EU Energy Efficiency
Class (ERP lot-5)
On-mode Power Consumption
15 W
Annual Power Consumption
22 kWh
Energy Efficiency Class
E Visible Screen Size
23.8" / 60,5 cm Diagonal
Operating Conditions
Operating Temperature - Celsius
5o – 35oC
Operating Temperature - Fahrenheit
41o – 95oF
Non-operating Temperature - Celsius
–34° – 60°C
Non-operating Temperature Fahrenheit
–29° – 140°F
Operating Humidity
20 – 80% Relative Humidity (non-condensing)
QuickSpecs
HP E24q G4 QHD Monitor
Technical Specifications
c06922713 — DA16764— Worldwide — Version 3 — February 28, 2021
Page 5
Non-operating Humidity
5 – 95%
Operating Altitude
0 – 5,000 m (16,400 ft.)
Non-operating Altitude
0 – 12,192 m (40,000 ft.)
Environmental
Features and
Certifications
Mercury-free LED display backlighting
Yes, Mercury-free LED backlighting
Arsenic-Free Display Glass
Yes
Low Halogen*
Yes
GSE HP-00011-01B, table 2 defines low-halogen (BFR, CFR,
PVC)
NOTE: External power supplies, power cords, cables and
peripherals are not Low Halogen. Service parts obtained
after purchase may not be Low Halogen.
Agency Approvals and Certifications
WW certificate
CE, CB, KC/KCC/NOM/ISO 9241-307/ EAC/TUVGS/cTUVus/PSB/CCC/CEL/ISC/VCCI/FCC/BSMI/Vietnam
MEPS/Australian-New Zealand MEPS/WEEE/BIS/CEC/EStandby/Low Blue Light/CECP/TUV-S/CECP
Microsoft WHQL Certification
Win 10, Win 8, Win 7
ENERGY STAR®
Yes, ENERGY STAR® 8
EPEAT® Registered*
Yes TCO Certified
Yes China Energy Label
CEL Grade 1
SmartWay Transport Partnership - NA
only
Yes (NA SKU)
*External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after
purchase may not be Low Halogen.
NOTE: DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards
Association (VESA®) in the United States and other countries.
Contains Recycled Plastics
85% recycled content by total weight
Metric
Imperial
Unit Product/Package
Specifications
Product Dimensions
(Unpacked with stand) (W x D x H)
53.94 x 20.7 x 49.49 cm
21.24 x 8.15 x 19.48 in
Product Dimensions
(Packed) (W x D x H)
61 x 22.5 x 39.5 cm
24.02 x 8.86x 15.55 in
Display Head Dimensions
(Unpacked without stand) (W x D x H)
53.94 x 4.7 x 32.33 cm
21.24 x 1.85 x 12.73 in
Base Area Footprint
(w x d mm)
260 x 207 mm
10.24 x 8.15 in
Bezel Measurements
Bottom 19.66mm (display
chin)
Bottom 0.77 in (display chin)
Product Weight
(Unpacked with stand)
5.9 kg
13 lb
Product Weight
(Packed)
8.8 kg
19.4 lb
Product Weight
(Head Only)
3.4 kg
7.5 lb
Container Load, 40-Foot HighQ
1152
Display Management
Software
HP Display Center
QuickSpecs
HP E24q G4 QHD Monitor
Technical Specifications
c06922713 — DA16764— Worldwide — Version 3 — February 28, 2021
Page 6
What's in the box?
1 HDMI 2.0
1 DisplayPort™ (DisplayPort™ 1.2)
1 USB-B to A cable
1 Power Cord
1 QSP
1 Doc-Kit
(1.8 m) 5.9 ft
(1.8 m) 5.9 ft
(1.8 m) 5.9 ft
(1.9 m) 6.2 ft
User Guide and
Warranty Languages
User Guide Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish,
Dutch, Finnish, French, German, Greek, Hungarian, Italian,
Japanese, Kazakh, Korean, Norwegian, Polish, Brazilian
Portuguese, Russian, Slovenian, Spanish, Swedish and
Turkish.
Warranty Languages
English, Arabic, S. Chinese, T. Chinese, Czech, Danish,
Dutch, Finnish, French, German, Greek, Hungarian, Italian,
Japanese, Kazakh, Korean, Norwegian, Polish, Brazilian
Portuguese, Russian, Slovenian, Spanish, Swedish and
Turkish.
QuickSpecs
HP E24q G4 QHD Monitor
Technical Specifications
c06922713 — DA16764— Worldwide — Version 3 — February 28, 2021
Page 7
Copyright © 2021 HP Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products are set forth in the
express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an
additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries.
ENERGY STAR is a registered trademark owned by the U.S. Environmental Protection Agency.
QuickSpecs
HP E24q G4 QHD Monitor
Summary
c06922713 — DA16764— Worldwide — Version 3 — February 28, 2021
Page 8
Change Log
January 3, 2021
V1 to V2
Techspecs Updated
February 28,2021
V2 to V3
Energy Efficiency Class
