HP DL145 User Manual

HP ProLiant DL145 Server
User Guide
June 2004 (Third Edition) Part Number 361542-003
© Copyright 2004 Hewlett-Packard Development Company, L.P.
Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is provided “as is” without warranty of any kind and is subject to change without notice. The warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty.
HP ProLiant DL145 Server User Guide
June 2004 (Third Edition) Part Number 361542-003 Product Version

Contents

About This Guide
Audience Assumptions............................................................................................................................... vii
Important Safety Information..................................................................................................................... vii
Symbols on Equipment .............................................................................................................................. vii
Rack Stability ............................................................................................................................................ viii
Symbols in Text......................................................................................................................................... viii
Related Documents.......................................................................................................................................ix
Getting Help .................................................................................................................................................ix
Technical Support..................................................................................................................................ix
HP Website ............................................................................................................................................ix
Authorized Reseller ...............................................................................................................................ix
Reader’s Comments ......................................................................................................................................x
Chapter 1
Server Component Identification
Front Panel Components ........................................................................................................................... 1-1
Rear Panel Connectors .............................................................................................................................. 1-2
Rear Panel LEDs ....................................................................................................................................... 1-3
System Board Components ....................................................................................................................... 1-4
J9 CMOS Jumper................................................................................................................................ 1-5
Chapter 2
Server Operations
Powering Up the Server............................................................................................................................. 2-1
Powering Down the Server........................................................................................................................ 2-1
Extending the Server from the Rack ......................................................................................................... 2-2
Removing the Server from the Rack ......................................................................................................... 2-2
Removing the Access Panel ...................................................................................................................... 2-3
Chapter 3
Server Setup
Optional Installation Services.................................................................................................................... 3-1
Rack Planning Resources .......................................................................................................................... 3-1
Optimum Environment.............................................................................................................................. 3-2
Space and Airflow Requirements ....................................................................................................... 3-2
Temperature Requirements................................................................................................................. 3-3
Power Requirements ........................................................................................................................... 3-4
Grounding Requirements.................................................................................................................... 3-4
Rack Warnings and Cautions .................................................................................................................... 3-5
HP ProLiant DL145 Server User Guide iii
Contents
Installing Hardware Options......................................................................................................................3-5
Server Shipping Contents ..........................................................................................................................3-5
Installing the Server into the Rack.............................................................................................................3-6
Operating System Installation..................................................................................................................3-10
Registering the Server..............................................................................................................................3-10
Routine Maintenance ...............................................................................................................................3-11
Chapter 4
Hardware Options Installation
Processors ..................................................................................................................................................4-1
Memory Options ........................................................................................................................................4-4
Memory Guidelines.............................................................................................................................4-4
Installing a DVD Drive..............................................................................................................................4-6
Hard Drive Installation ..............................................................................................................................4-9
PCI-X Expansion Board ..........................................................................................................................4-12
Chapter 5
Operating System Installation and Software
Overview....................................................................................................................................................5-1
Operating System Installation....................................................................................................................5-2
ProLiant DL145 Support CD.....................................................................................................................5-2
PXE Deployment .......................................................................................................................................5-3
Rapid Deployment Pack (RDP) .................................................................................................................5-3
Software and Utilities ................................................................................................................................5-3
ROMPaq Utility ..................................................................................................................................5-3
Management Processor Flash Utility...................................................................................................5-4
Diagnostics Utility...............................................................................................................................5-4
BIOS Setup Utility ..............................................................................................................................5-5
Server Management .................................................................................................................................5-13
Configuring the Serial Port................................................................................................................5-13
Configuring Access Through the Serial Port.....................................................................................5-14
Configuring Access Through the Network........................................................................................5-17
User Accounts ...................................................................................................................................5-17
Accessing the Management Processor CLI.......................................................................................5-18
Using CLI Commands.......................................................................................................................5-20
BIOS Console Text Redirection........................................................................................................5-23
Linux Operating System Redirection ................................................................................................5-24
Windows EMS Management.............................................................................................................5-24
Using the Watch Dog Timer..............................................................................................................5-25
System Event Log .............................................................................................................................5-26
Systems Insight Manager ..................................................................................................................5-27
IPMI System Management................................................................................................................5-27
Appendix A
Regulatory Compliance Notices
Regulatory Compliance Model Number................................................................................................... A-1
Federal Communications Commission Notice .........................................................................................A-1
Class A Equipment.............................................................................................................................A-1
Class B Equipment .............................................................................................................................A-2
Declaration of Conformity for Products Marked with the FCC Logo, United States Only ...............A-2
iv HP ProLiant DL145 Server User Guide
Modifications..................................................................................................................................... A-2
Cables................................................................................................................................................. A-3
Canadian Notice (Avis Canadien)............................................................................................................ A-3
Class A Equipment ............................................................................................................................ A-3
Class B Equipment............................................................................................................................. A-3
Mouse Compliance Statement.................................................................................................................. A-3
European Union Notice............................................................................................................................ A-4
Japanese Notice ........................................................................................................................................ A-4
BSMI Notice............................................................................................................................................. A-4
Laser Compliance..................................................................................................................................... A-5
Battery Replacement Notice..................................................................................................................... A-5
Appendix B
Electrostatic Discharge
Preventing Electrostatic Damage ..............................................................................................................B-1
Grounding Methods...................................................................................................................................B-1
Appendix C
System Battery
Battery Replacement .................................................................................................................................C-1
Contents
Appendix D
Server Error Messages
Appendix E
Server Specifications
Server Specifications.................................................................................................................................E-1
Appendix F
Troubleshooting
If the Server Does Not Start ......................................................................................................................F-1
Diagnosis Steps .........................................................................................................................................F-2
Problems After Initial Startup ...................................................................................................................F-4
Other Troubleshooting Resources .............................................................................................................F-6
Index
HP ProLiant DL145 Server User Guide v
This guide provides step-by-step instructions for installation, and reference information for operation, troubleshooting, and future upgrades for the HP ProLiant DL145 server.

Audience Assumptions

This guide is for the person who installs, administers, and troubleshoots servers. HP assumes you are qualified in the servicing of computer equipment and trained in recognizing hazards in products with hazardous energy levels.

Important Safety Information

Before installing this product, read the Important Safety Information document included with the server.

About This Guide

Symbols on Equipment

The following symbols may be placed on equipment to indicate the presence of potentially hazardous conditions:
WARNING: This symbol, in conjunction with any of the following symbols, indicates the presence of a potential hazard. The potential for injury exists if warnings are not observed. Consult your documentation for specific details.
This symbol indicates the presence of hazardous energy circuits or electric shock hazards. Refer all servicing to qualified personnel.
WARNING: To reduce the risk of injury from electric shock hazards, do not open this enclosure. Refer all maintenance, upgrades, and servicing to qualified personnel.
This symbol indicates the presence of electric shock hazards. The area contains no user or field serviceable parts. Do not open for any reason.
WARNING: To reduce the risk of injury from electric shock hazards, do not open this enclosure.
This symbol on an RJ-45 receptacle indicates a network interface connection. WARNING: To reduce the risk of electric shock, fire, or damage to the equipment, do
not plug telephone or telecommunications connectors into this receptacle.
HP ProLiant DL145 Server User Guide vii
About This Guide
Weight in kg
Weight in lb

Rack Stability

This symbol indicates the presence of a hot surface or hot component. If this surface is contacted, the potential for injury exists.
WARNING: To reduce the risk of injury from a hot component, allow the surface to cool before touching.
These symbols, on power supplies or systems, indicate that the equipment is supplied by multiple sources of power.
WARNING: To reduce the risk of injury from electric shock, remove all power cords to completely disconnect power from the system.
This symbol indicates that the component exceeds the recommended weight for one individual to handle safely.
WARNING: To reduce the risk of personal injury or damage to the equipment, observe local occupational health and safety requirements and guidelines for manual material handling.
WARNING: To reduce the risk of personal injury or damage to the equipment, be sure that:
• The leveling jacks are extended to the floor.
• The full weight of the rack rests on the leveling jacks.
• The stabilizing feet are attached to the rack if it is a single-rack installation.
• The racks are coupled together in multiple-rack installations.
• Only one component is extended at a time. A rack may become unstable if more

Symbols in Text

These symbols may be found in the text of this guide. They have the following meanings.
WARNING: Text set off in this manner indicates that failure to follow directions in the warning could result in bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions could result in
damage to equipment or loss of information.
IMPORTANT: Text set off in this manner presents essential information to explain a concept or complete a task.
NOTE: Text set off in this manner presents additional information to emphasize or supplement important points of the main text.
than one component is extended for any reason.
viii HP ProLiant DL145 Server User Guide

Related Documents

For additional information on the topics covered in this guide, refer to the HP Website at
www.docs.hp.com or www.hp.com/support.
• HP Servers Troubleshooting Guide
• HP ProLiant DL145 Maintenance and Service Guide

Getting Help

If you have a problem and have exhausted the information in this guide, you can get further information and other help in the following locations.

Technical Support

In North America, call the HP Technical Support Phone Center at 1-800-633-3600. This service is available 24 hours a day, 7 days a week. For continuous quality improvement, calls may be recorded or monitored. Outside North America, call the nearest HP Technical Support Phone Center. Telephone numbers for worldwide Technical Support Centers are listed on the HP website, www.hp.com.
About This Guide
Be sure to have the following information available before you call HP:
• Technical support registration number (if applicable)
• Product serial number
• Product model name and number
• Applicable error messages
• Add-on boards or hardware
• Third-party hardware or software
• Operating system type and revision level

HP Website

The HP website has information on this product as well as the latest drivers and flash ROM images. You can access the HP website at www.hp.com/products/servers/platforms

Authorized Reseller

For the name of your nearest authorized reseller:
• In the United States, call 1-800-345-1518.
• In Canada, call 1-800-263-5868.
• Elsewhere, see the HP website for locations and telephone numbers.
HP ProLiant DL145 Server User Guide ix
About This Guide

Reader’s Comments

HP welcomes your comments on this guide. Please send your comments and suggestions by e-mail to ServerDocumentation@hp.com.
x HP ProLiant DL145 Server User Guide

Front Panel Components

1
Server Component Identification
Figure 1-1: Front panel components
Table 1-1: Front Panel Components
Item Description Status
1 LAN activity LED On = Network link
Flashing = Network link and activity Off = No link to network
2 System health LED Off = Normal
On = System degraded
3 Disk drive activity LED On = Drive activity
Flashing = High drive activity Off = No drive activity
4 Power LED On = Power on
Off = Power off
continued
HP ProLiant DL145 Server User Guide 1-1
Server Component Identification
Table 1-1: Front Panel Components continued
Item Description Status
5 USB port
6 Media bay
7 Hard drive bay 2
8 Hard drive bay 1
9 Power button

Rear Panel Connectors

Figure 1-2: Rear panel connectors
Table 1-2: Rear Panel Connectors
Item Description Item Description
1 Mouse 5 Dedicated Management NIC
2 Keyboard 6 NIC 2
3 Video 7 NIC 1
4 USB 8 COM1/Management Processor
1-2 HP ProLiant DL145 Server User Guide

Rear Panel LEDs

Figure 1-3: Rear Panel LEDs
Table 1-3: Rear Panel LEDs
Server Component Identification
Item Description LED Color Status
1 Aux Power LED Amber On = Aux power present
Off = No Aux power
2 LAN Link LED
3 LAN Activity LED Amber On or flashing = network activity
Green Green = 1 GB connection
Off = no link to network
Red Red = 10/100 MB connection
Off = no link to network
Off = no network activity
HP ProLiant DL145 Server User Guide 1-3
Server Component Identification

System Board Components

Figure 1-4: System board components
Table 1-4: System Board Components
Item Description
1
2
3
4
5
6
7
8
9
10
11
PCI-X riser board slot
NVRAM Battery
Management Processor
Video board
J9 CMOS jumper
Processor socket 2
Memory banks 2A and 2B
Processor power module slot 2
Processor power module slot 1
Memory banks 1A and 1B
Processor 1 (boot processor)
1-4 HP ProLiant DL145 Server User Guide

J9 CMOS Jumper

Server Component Identification
Figure 1-5: J9 CMOS Jumper
Table 1-5: J9 CMOS Jumper Settings
Item Setting
1 Set
2 Clear
To clear CMOS:
1. Back up the server data.
2. Shut down the operating system as directed by the operating system documentation.
3. Press the Power button to power down the server. When the server powers down, the system power LED turns off.
4. Disconnect the power cord.
5. Set the J9 CMOS jumper to Clear and hold in position for 3 seconds.
6. Reset the J9 CMOS jumper to Set.
7. Connect the power cord.
8. Power up the system.
9. Reconfigure the server using the BIOS Setup Utility. Refer to Chapter 5, “Operating System Installation and Software” for more information on the BIOS Setup Utility.
HP ProLiant DL145 Server User Guide 1-5

Powering Up the Server

To power up the server, press the Power button.

Powering Down the Server

WARNING: To reduce the risk of personal injury, electric shock, or damage to the equipment, remove the power cord to remove power from the server. The front panel Power button does not completely shut off system power. Portions of the power supply and some internal circuitry remain active until AC power is removed.
1. Back up the server data.
2. Shut down the operating system as directed by the operating system documentation.
3. Press the Power button to power down the server. When the server powers down, the system power LED turns off.
2
Server Operations
4. Disconnect the power cord.
The system is now without power.
HP ProLiant DL145 Server User Guide 2-1
Server Operations

Extending the Server from the Rack

1. Extend the server on the rack rails until the server rail-release latches engage.
Figure 2-1: Extending the server from the rack
2. Reverse the steps to restore the server to operating position.

Removing the Server from the Rack

Press the side rail tabs to release the server from the rack rails.
Figure 2-2: Removing the server from the rack
2-2 HP ProLiant DL145 Server User Guide

Removing the Access Panel

WARNING: Pressing the Power button does not remove power from all areas of the server. Portions of the power supply and some internal circuitry remain active until the AC power cord is disconnected.
WARNING: To reduce the risk of personal injury from hot surfaces, allow the internal system components to cool before touching.
CAUTION: Electrostatic discharge can damage electronic components. Properly ground
yourself before beginning any installation procedure.
1. Power down the server. Refer to the “Powering Down the Server” section earlier in this chapter.
2. Extend the server from the rack. Refer to the “Extending the Server from the Rack” section earlier in this chapter.
3. Remove the access panel.
Server Operations
Figure 2-3: Removing the access panel
4. Reverse the steps to install the access panel.
HP ProLiant DL145 Server User Guide 2-3

Optional Installation Services

You may choose to have HP install the system. The installation service can be purchased as a Care Pack packaged service or as a customized service agreement to meet your specific requirements. Some of the Care Pack services are as follows:
•
Hardware installation services
•
Hardware and operating system installation for ProLiant servers
•
Installation and start-up services for some operating systems
•
Installation and start-up services for Insight Manager
This optional hardware installation service is available in all countries where HP has a direct or indirect service presence. Service may be ordered from and directly provided by an authorized service reseller or, in the United States only, service may be ordered by calling 1-800-633-3600. In the United States, HP makes all the arrangements to have the system installed by qualified guaranteed service providers. For more information, refer to the HP website
3
Server Setup
http://www.hp.com/hps

Rack Planning Resources

The following resource information is available on rack designs and products.
The Rack Builder Pro Configuration Tool and Rack Products documentation information can be found on the HP website by following the storage link on the product website.
HP ProLiant DL145 Server User Guide 3-1
Server Setup
The entire Rack Resource CD Kit ships with all HP racks. A summary of the content of each CD follows:
•
Rack Builder Pro Configuration Tool This information helps you to simulate potential rack configurations based on your input.
Rack Builder Pro provides the following information: — Graphical preview of properly configured racks — Site planning data, including power requirements, cooling mandates, and physical
specifications
— Ordering information, including required components, part numbers, and appropriate
quantities
•
The Installing Rack Products video provides a visual overview of operations required for configuring a rack with rack-mountable components. It also provides the following important configuration steps:
— Planning the site — Installing rack servers and rack options — Cabling servers in a rack — Coupling multiple racks
The Rack Products Documentation CD enables you to view, search, and print documentation for HP racks and rack options. It also helps you set up and optimize a rack in a manner that best fits your environment.

Optimum Environment

When installing the server in a rack, select a location that meets the environmental standards described in the following sections.

Space and Airflow Requirements

To enable servicing and adequate airflow, observe the following spatial requirements when deciding where to install the rack:
•
Leave a minimum clearance of 63.5 cm (25 in) in front of the rack.
•
Leave a minimum clearance of 76.2 cm (30 in) in the back of the rack.
•
Leave a minimum clearance of 121.9 cm (48 in) from the back of the rack to the rear of another rack or row of racks.
3-2 HP ProLiant DL145 Server User Guide
Server Setup
HP servers draw in cool air through the front door and expel warm air through the rear door. Therefore, the front and rear rack doors must be adequately ventilated to allow ambient room air to enter the cabinet, and the rear door must be adequately ventilated to enable the warm air to escape from the cabinet.
CAUTION: To prevent improper cooling and damage to the equipment, do not block the ventilation openings.
The 9000 and 10000 Series racks provide proper server cooling from flow-through perforations in the front and rear doors that provide 64 percent open area for ventilation.
CAUTION: When using a Compaq branded 7000 Series rack, you must install the high airflow rack door insert [P/N 327281-B21 (42U) and P/N 157847-B21 (22U)] to provide proper front-to-back airflow and cooling.
CAUTION: If a third-party rack is used, observe the following additional requirements to ensure adequate airflow and to prevent damage to the equipment:
• Front and rear doors: If the 42U server rack includes closing front and rear doors, you
must allow 5,350 sq cm (830 sq in) of holes evenly distributed from top to bottom to permit adequate airflow (equivalent to the required 64 percent open area for ventilation).
• Side: The clearance between the installed rack component and the side panels of the
rack must be a minimum of 7 cm (2.75 in).

Temperature Requirements

To ensure continued safe and reliable equipment operation, install or locate the system in a well-ventilated, climate-controlled environment.
The maximum recommended ambient operating temperature (TMRA) for most server products is 35°C (95°F). The temperature in the room where the rack is located must not exceed 35°C
(95°F).
CAUTION: To reduce the risk of damage to the equipment when installing third-party options:
• Do not permit optional equipment to impede airflow around the server or to increase the
internal rack temperature beyond the server or to increase the internal rack temperature beyond the maximum allowable limits.
• Do not exceed the manufacturer’s recommended ambient operating temperature
(TMRA).
HP ProLiant DL145 Server User Guide 3-3
Server Setup

Power Requirements

The installation of this equipment shall be in accordance with local/regional electrical regulations governing the installation of information technology equipment by licensed electricians. This equipment is designed to operate in installations covered by NFPA 70, 1999 Edition (National Electric Code) and NFPA 75, 1992 Edition (code for Protection of Electronic Computer/Data Processing Equipment). For electrical power ratings on options, refer to the product rating label or the user documentation supplied with that option.
WARNING: To reduce the risk of personal injury, fire, or damage to the equipment, do not overload the AC supply branch circuit that provides power to the rack. Consult the electrical authority having jurisdiction over the wiring and installation requirements of your facility.
CAUTION: Protect the server from power fluctuations and temporary interruptions with a
regulating uninterruptible power supply (UPS). This device protects the hardware from damage caused by power surges and voltage spikes and keeps the system in operation during a power failure.
When installing more than one server, you may need to use additional power distribution devices to safely provide power to all devices. Observe the following guidelines:
•
The power load must be balanced between available AC supply branch circuits.
•
The overall system AC current load must not exceed 80 percent of the branch circuit AC current rating.
•
Do not use common outlet strips for this equipment.
•
Provide a separate electrical circuit for the server.

Grounding Requirements

For proper operation and safety, the server must be properly grounded. In the United States, you must install the equipment in accordance with NFPA 70, 1999 Edition (National Electric Code) Article 250 as well as any local and regional building codes. In Canada, the equipment must be installed in accordance with Canadian Standards Association, CSA C22.1, Canadian Electrical Code. In all other countries, the installation must follow any regional or national electrical wiring codes, such as the International Electrotechnical Commission (IEC) 364, parts 1 through 7. Furthermore, you must ensure that all power distribution devices used in the installation—such as branch wiring and receptacles—are listed or certified grounding­type devices.
Because of the high ground leakage currents associated with multiple servers connected to the same power source, HP recommends the use of a power distribution unit (PDU) that is either permanently wired to the branch circuit of the building or includes a nondetachable cord that is wired to an industrial-style plug. NEMA locking-style plugs or those complying with IEC 60309 are considered suitable for this purpose. HP does not recommend using common power outlet strips for this equipment.
3-4 HP ProLiant DL145 Server User Guide

Rack Warnings and Cautions

WARNING: To reduce the risk of personal injury or equipment damage, be sure that:
• The leveling jacks are extended to the floor.
• The full weight of the rack rests on the leveling jacks.
• The stabilizers are attached to the rack for single-rack installation.
• The racks are coupled together in multiple-rack installations.
• Only one component is extended at a time. A rack may become unstable if more
than one component is extended for any reason.
WARNING: Always mount the heaviest item on the bottom of the rack and work from the bottom to the top.

Installing Hardware Options

Install any hardware options before initializing the server. For options installation information, refer to the option documentation. For server-specific information, refer to Chapter 4, “Hardware Options Installation.”
Server Setup

Server Shipping Contents

Unpack the server-shipping carton and locate the materials and documentation necessary for installing the server. All the rack-mounting hardware necessary for installing the server into the rack is included with the rack or the server.
The contents of the server-shipping carton include:
•
Server
•
HP ProLiant DL145 Server Support CD
•
Setup documentation
•
Power cord
•
Rack-mounting hardware
HP ProLiant DL145 Server User Guide 3-5
Server Setup
In addition to these supplied items, you may need any options to be installed.
Figure 3-1: Rack-mounting hardware
Table 3-1: Rack Mounting Hardware
Item Description
1 Rack rail assemblies (2)
2
Bag of screws

Installing the Server into the Rack

If you are installing the server into a telco rack, order the appropriate option kit at the RackSolutions.com website. Follow the server specific instructions on the website to install the rack brackets. After installing the brackets, follow the steps in this section.
WARNING: When installing the server in a telco rack, be sure that the rack frame is adequately secured to the top and bottom of the building structure.
WARNING: Always plan the rack installation so that the heaviest item is on the bottom of the rack. Install the heaviest item first, and continue to populate the rack from the bottom to the top.
3-6 HP ProLiant DL145 Server User Guide
1. Remove server rails from rack rails.
Figure 3-2: Removing server rails from rack rails
2. Attach and secure the server rails to the server.
Server Setup
Figure 3-3: Attaching server rails
HP ProLiant DL145 Server User Guide 3-7
Server Setup
3. Install the rack rails.
Figure 3-4: Installing rack rails
4. Pull the inner slide rail forward from each rack rail assembly until it locks into place.
5. Align the server and carefully insert the server rail into the inner slide rail until the rail­release levers engage.
Figure 3-5: Loading the server onto the rack rails
3-8 HP ProLiant DL145 Server User Guide
Server Setup
6. Slide the server into the rack and tighten the thumbscrews to secure the server.
Figure 3-6: Securing the server to the rack
7. Connect peripheral devices to the server.
WARNING: To reduce the risk of electric shock or fire, do not plug telecommunications/telephone connectors into the NIC connectors.
IMPORTANT: To enable the embedded NIC functionality on servers running Microsoft Windows
Server based operating systems, it is necessary to load the NIC drivers provided on the HP ProLiant DL145 Server Support CD.
Figure 3-7: Rear panel connectors
HP ProLiant DL145 Server User Guide 3-9
Server Setup
Table 3-2: Rear Panel Connectors
Item Description Item Description
1 Mouse 5 Dedicated Management NIC
2 Keyboard 6 NIC 2
3 Video 7 NIC 1
4 USB 8 COM1/Management Processor
8. Connect the power cord.
9. Power up the server and load the operating system.

Operating System Installation

To operate properly, the server must have a supported operating system. For the latest information on supported operating systems, refer to the HP website
http://hp.com/go/supportos
Install the operating system using the following instructions.
1. Use the optional DVD drive or connect a USB CD-ROM drive to a USB connector.
2. Connect a monitor to the video connector.
3. Connect a mouse to the mouse connector.
4. Connect a keyboard to the keyboard connector.
5. Place the operating system CD in the CD-ROM drive and follow the instructions to complete the server initialization process.
IMPORTANT: To enable the embedded NIC functionality on servers running Microsoft Windows Server based operating systems, it is necessary to load the NIC drivers provided on the HP ProLiant DL145 Server Support CD.
6. Check the HP ProLiant DL145 Server Support CD for device drivers. The most current drivers, INF files, ROM images, and diagnostics can be downloaded from the web at
www.hp.com/support

Registering the Server

Register the server at the HP website:
http://register.hp.com
3-10 HP ProLiant DL145 Server User Guide
Loading...
+ 65 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
