:: Seite 1 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Hot Plug SAS/SATA Models
Front View:
1.
Access panel
2.
Two Non-Hot Plug SATA 3.5" Hard Drive Bays or Two
Hot Plug SAS/SATA 3.5" Hard Drive
3.
Optional CD- or DVD-ROM drive
4.
System LEDs
5.
USB Port
6.
Power on/off
7.
System Fans
8.
Quad-Core and Dual-Core Intel® Xeon™ Processors
(Supports up to Two)
9.
PC2-5300 Fully Buffered DIMMs (DDR2-667) memory
slots
10.
Expansion Slots:
Non-Hot Plug Models - Two available PCI-Express slots
Hot-Plug Models - One available PCI-Express slot
11.
Power Supply (650 Watts)
12.
SAS/SATA Hot Plug Backplane (Hot Plug SAS/SATA
Model)
Rear View:
1.
Two GbE LAN ports for NIC 1 and NIC 2 (RJ-45)
2.
Low-Profile PCI Express x8/PCI-X riser board slot cover
3.
Rear USB ports
4.
Video Port
5.
Serial Port
6.
PS/2 Keyboard Port
7.
PS/2 Mouse Port
8.
LO100i 10/100 Mbps LAN port for IPMI management (RJ-
45)
9.
Standard height/full-height PCI Express x16/PCI-X riser
board
10.
Power Supply Cable Socket
What's New
One year of 24 x 7 HP Software Technical Support and Update Service included with Insight Control management
suites and select ProLiant Essentials Licenses.
At A Glance
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Overview
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 1
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 2
:: Seite 2 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Processors:
Supports up to two Quad-Core and Dual-Core Intel Xeon processors: 5300 and 5100 sequence
Quad-Core Intel Xeon processors 5300 sequence with 8MB Level 2 cache
Dual-core Intel Xeon processor 5100 sequence with 4MB Level 2 cache
Intel 5000X Chipset
Memory:
Supports up to 32 GB PC2-5300 Fully Buffered DIMMs (DDR2-667) with Advanced ECC
Internal Drive Support:
Supports up to two:
Non-Hot Plug Serial ATA (SATA) 3.5"hard drives; or
Hot Plug Serial Attached SCSI (SAS/Serial ATA (SATA) 3.5"hard drives
Internal storage capacity of up to 1.5TB (2 x 750GB Hot Plug 3.5" SATA hard drives), 1 TB (2 x 500 Non-Hot
Plug SATA hard drives) or 600GB (2 x 300GB Hot Plug 3.5" SAS hard drives)
Network Controller:
Two embedded NC320i PCIe Gigabit Server Adapters
Storage Controllers:
HP Embedded SATA RAID Controller on Non-Hot Plug SATA Models
HP 8 Internal Port SAS HBA with RAID 0,1 on Hot Plug SAS/SATA Models
HP Smart Array E500 Controller
HP Smart Array E200 Controller
HP SC11Xe Host Bus Adapter
HP SC44Ge Host Bus Adapter
Expansion Slots:
Non-Hot Plug Models:
Two available PCI Express slots:
Slot 1: full-length/full-height PCI-Express x16
Slot 2: low-profile/half-height PCI-Express x8
Hot Plug Models:
One available PCI-Express slot:
Slot 1: full-length/full-height PCI-Express x16
Slot 2: low-profile/half-height PCI-X slot populated by the SAS/SATA storage controller
Management:
IPMI 2.0 support
HP Lights Out 100i Remote Management with new licensed key activated upgrades for Virtual KVM and virtual
media support
ROM Setup Utility
USB Ports:
Four USB ports (two front, two rear)
Optical Drive:
Support for one (optional): CD-ROM, DVD-ROM, DVD RW, DVD/CD RW
Power Supply:
650W Power Supply (Non-Hot Plug, Autoswitching)
Additional Features:
Support for:
NVIDIA Quadro FX3500 256MB PCIe graphics card
NVIDIA Quadro FX1500 256MB PCIe graphics card
Form Factor:
1U rack models
Deployment/Serviceability:
Tool-less access to all system components for easy in rack serviceability
Warranty:
Protected by HP Services, including a one-year, limited warranty, Next Business Day 1, year on-site limited
Global warranty - Certain restrictions and exclusions apply
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Overview
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 2
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 3
:: Seite 3 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
NOTE:
For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and
specifications, please visit:
http://h71028.www7.hp.com/ERC/downloads/4AA0-6065ENW.pdf
NOTE:
For the Standard Features shipped in the Factory Integrated Models, please see the "Configuration Information -
Factory Integrated Models" section.
Processor
One of the following
depending on Model
Quad-Core Intel Xeon processor X5355 (2.66 GHz, 120 W, 1333 MHz Front Side Bus FSB)
*
Quad-Core Intel Xeon processor E5345 (2.33 GHz, 80 W, 1333 MHz FSB)
Quad-Core Intel Xeon processor E5335 (2.00 GHz, 80 W, 1333 MHz FSB)
*
Quad-Core Intel Xeon processor L5320(1.86GHz, 50W, 1066 MHz FSB, Low Voltage)
*
Quad-Core Intel Xeon processor E5320 (1.86 GHz, 80 W, 1066 MHz FSB)
*
Quad-Core Intel Xeon processor E5310 (1.60 GHz, 80 W, 1066 MHz FSB)
Dual-Core Intel® Xeon™ processor 5160 (3.00 GHz, 80 W, 1333 MHz FSB)
Dual-Core Intel® Xeon processor 5150 (2.66 GHz, 65 W, 1333 MHz FSB)
*
Dual-Core Intel® Xeon processor 5148 (2.33 GHz, 40 W, 1333 MHz FSB, Low Voltage)
*
Dual-Core Intel® Xeon processor 5140 (2.33 GHz, 65 W, 1333 MHz FSB)
Dual-Core Intel® Xeon processor 5130 (2.0 GHz, 65 W, 1333 MHz FSB)
*
Dual-Core Intel® Xeon processor 5110 (1.60 GHz, 65 W, 1066 MHz FSB)
*Available through Configure To Order only. See Factory Integration Models section for more
details.
Upgradeability
Upgradeable to two processors
Future upgradeable to Xeon Series 5300 Quad-Core, or 5100 Dual-Core processors (Please
contact your regional sales support to determine quad core upgradeability. Some of the earlier
shipping models may not support this upgrade)
Chipset
Intel 5000X Chipset
Cache Memory
8MB (2 x 4MB) Level 2 cache (5300 sequence)
4MB (1 x 4MB) Level 2 cache (5100 sequence)
Memory Protection
Memory mirroring with Advanced ECC capabilities
Memory
Type
PC2-5300 Fully Buffered DIMMs (DDR2-667)
Standard
1 GB
(2 x 512 MB)
Maximum
32 GB
(8 x 4 GB)
Network Controller
Two embedded NC320i PCIe Gigabit Server Adapters
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Standard Features
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 3
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 4
:: Seite 4 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Expansion Slots
Slot
Number
Bus Speed
Bus
Number
*
Device
Number
**
Hot Plug
(Y/N)
PCI
Voltage
Notes
1
x16 PCI-Express
1 0
N
3.3 volts
Full
length, full
height
1
PCI-X
***
5 1
N
3.3 volts
Full
length, full
height
2
x8 PCI-Express
6 3
N
3.3 volts
Low-
profile
2
PCI-X
***
5 1
N
3.3 volts
Low-
profile
NOTE:
All slots can accept universal keyed PCI cards
* Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number.
** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID by bus (starting with
the lowest bus).
*** PCI-X bus speed will be 133MHz when only one PCI-X card is installed. It will be 100MHz when both slots have PCI-X
cards installed.
Storage Controller
Non-Hot Plug SATA
Models
HP Embedded SATA RAID Controller (integrated into the south-bridge)
supporting SW RAID 0,1
Hot Plug SAS/SATA
Models
HP 8 Internal Port SAS HBA with RAID 0,1
NOTE:
A diskette drive is needed to install storage controller drivers during a Windows operating
system installation from a CD.
Storage
Optical Drives:
DVD-ROM
8x IDE (ATAPI) DVD-ROM drive, slim (optional)
CD-ROM
24x IDE (ATAPI) CD-ROM drive (optional)
DVD RW
8x IDE (ATAPI) DVD-ROM drive, slim (optional)
DVD/CD RW
24x IDE (ATAPI) CD-ROM drive (optional)
Diskette Drives
Via USB only
Drive Bays:
Non-Hot Plug SATA
Up to 2 non-hot plug SATA 3.5" drives
Hot-Plug SAS/SATA
Up to 2 hot plug SAS/SATA 3.5" drives
Maximum Internal
Storage
Non-Hot Plug SATA
1TB
2 x 500GB
Hot Plug SATA
1.5TB
2 x 750GB
Non-Hot Plug SAS
600GB
2 x 300GB
Hot Plug SAS
600GB
2 x 300GB
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Standard Features
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 4
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
Den aktuellen Preis und Lagerstand finden Sie online auf
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Page 5
:: Seite 5 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Interfaces
Parallel
None
Network RJ-45
(Ethernet)
2 10/100/1000 NIC ports (plus 1 dedicated for the HP ProLiant Lights
Out 100i Remote Management)
Serial
1
Pointing Device (Mouse)
1
Graphics
1
Keyboard
1
USB
4 (two front, two rear)
NOTE:
Please see the following URL for additional information
regarding USB support:
http://h18004.www1.hp.com/products/servers/platforms/usbsupport.html
.
Graphics
Integrated on the system board:
1280 x 1024 at 8bpp (bits per pixel) or 2^8 = 256 colors
or
1024 x 768 at 16bpp (bits per pixel) or 2^16 = 65536 or 64k colors
Form Factor
Rack Mount (1U), (1.75 in/4.45 cm)
ProLiant Essentials
Foundation Pack
Software
Optional ProLiant
Essentials Value Packs
Optional software offerings that selectively extend the functionality of an
Adaptive Infrastructure to address specific business problems and
needs:
Rapid Deployment Pack (RDP) is an automated deployment and
provisioning solution for all ProLiant servers. RDP includes the
ProLiant Integration Module featuring ProLiant server preconfigured events for OS installation, and optimized software
drivers, firmware and management agents. Every RDP disc
includes 10-node trial licenses for evaluation purposes. RDP
requires a license for each server deployed and is available for
purchase with HP servers. For more information, visit:
http://www.hp.com/servers/rdp
.
Server Migration Pack - The Server Migration Pack automates the
manual processes required for migrating servers between
physical or virtual platforms (P2V, V2P, and V2V).
Virtualization Management Software - Get the most out of server
virtualization by unifying the management of physical and virtual
servers in HP Systems Insight Manager. The Virtual Machine
Management Pack plug-in provides central management and
control of VMware and Microsoft virtual machines and provides
physical host to virtual machine association. The Server Migration
Pack plug-in automates the manual task of migrating servers
between physical or virtual platforms.
Vulnerability and Patch Management Pack (offered exclusively
through the Insight Control suites) - identifies and remediates
software security vulnerabilities due to missing patches as well
operating system configurations that can be exploited by viruses,
worms, and other blended threats.
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Standard Features
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 5
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
Den aktuellen Preis und Lagerstand finden Sie online auf
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Page 6
:: Seite 6 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
NOTE:
Flexible and volume quantity license kits are available for
ProLiant Essentials Value Packs. Refer to
http://www.hp.com/servers/proliantessentials
or the various ProLiant
Essentials Value Pack product QuickSpecs for more information.
NOTE:
For more information regarding ProLiant Essentials Software,
please see the following URL:
http://www.hp.com/servers/proliantessentials
.
Industry Standard
Compliance
ACPI V2.0 Compliant
PCI 2.2 Compliant
PXE Support
WOL Support
Microsoft® Logo certifications
IPMI 2.0 Compliant
Manageability
HP Lights-Out 100i Standard providing the following OS-independent remote control capabilities:
Virtual power
System event log access
System health
Remote Serial console (serial redirection)
Browser, Telnet access
SM-CLP compliant
IPMI 2.0 compliant
HP Lights-Out 100i Select Pack providing license key activated upgrades to the following:
Virtual media (Floppy and CD)
Secure Socket Layer Encryption
Secure Shell Encryption
HP Lights-Out 100i Advanced Pack providing license key activated upgrades to the following:
Virtual KVM (KVM over IP functionality embedded on the system board) plus all of the
LO100i Select Pack features above.
Security
Power-on password
Setup password
Server Power Cords
One Highline IEC Power cord ships standard (for connection to a Power Distribution Unit)
NOTE:
Rack models ship standard with an IEC cable.
Localized cables included with geographic specific models in other world regions.
UPS and PDU Power
Cord Matrix
Please see the UPS and PDU cable matrix that lists cable descriptions, requirements, and
specifications for UPS and PDU units:
ftp://ftp.compaq.com/pub/products/servers/ProLiantstorage/power-protection/powercordmatrix.pdf
.
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Standard Features
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 6
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 7
:: Seite 7 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Power Supply
650 Watts, auto-switching, PFC (Power Factor Correcting)
System Fans
6 system fans ship standard; Non-hot plug, Non-redundant
OS Support
Microsoft Windows® 2000 Server (32-bit)
Microsoft Windows 2000 Advanced Server (32-bit)
Microsoft Windows 2003 and Microsoft Windows 2003/R2 Standard Edition (32-bit)
Microsoft Windows 2003 and Microsoft Windows 2003/R2 Enterprise Edition (32-bit)
Microsoft Windows 2003 and Microsoft Windows 2003/R2 Web Edition (32-bit)
Microsoft Windows 2003 and Microsoft Windows 2003/R2 for Extended Systems Standard Edition
(64-bit)
Microsoft Windows 2003 and Microsoft Windows 2003/R2 for Extended Systems Enterprise
Edition (64-bit)
Red Hat Enterprise Linux
SUSE Linux Enterprise Server
NOTE:
For an up-to-date listing of the latest OS support matrix, please see:
http://www.hp.com/go/supportos
NOTE:
For an up-to-date listing of the latest drivers available for the HP ProLiant DL140 G3,
please see:
http://h18023.www1.hp.com/support/files/server/us/index.html
NOTE:
For more complete and up-to-date information on how to buy server operating systems
from HP please visit the OS product site at:
http://h18004.www1.hp.com/products/servers/software/OEM.html
NOTE:
Drivers may also found on the base media for some Linux OS's. When configuring your
server, please consult your base media driver base, or visit HP.com at:
http://h18023.www1.hp.com/support/files/server/us/index.html
NOTE:
For more Linux OS support & certification information, please visit our the ProLiant &
Bladesystem Server Linux matrix
http://h18004.www1.hp.com/products/servers/linux/hpLinuxcert.html
Rack Airflow
Requirements
Rack 10000 series Cabinets
The increasing power of new high-performance processor technology requires increased cooling
efficiency for rack-mounted servers. The 10000 Series Racks provide enhanced airflow for
maximum cooling, allowing these racks to be fully loaded with servers using the latest processors.
CAUTION:
If a third-party rack is used, observe the following additional requirements to ensure
adequate airflow and to prevent damage to the equipment:
Front and rear doors: If your 42U server rack includes closing front and rear doors, you must allow
5,350 sq cm (830 square inches) of hole evenly distributed from top to bottom to permit adequate
airflow (equivalent to the required 64 percent open area for ventilation).
Side: The clearance between the installed rack component and the side panels of the rack must
be a minimum of 7 cm (2.75 inches)
CAUTION:
Always use blanking panels to fill all remaining empty front panel U-spaces in the rack.
This arrangement ensures proper airflow. Using a rack without blanking panels results in improper
cooling that can lead to thermal damage.
NOTE:
For additional information, refer to the Setup and Installation Guide or the Documentation
CD provided with the server, or to the server documentation located in the Support section at the
following URL:
http://h18000.www1.hp.com/products/servers/proliantdl140/index.html
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Standard Features
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 7
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 8
:: Seite 8 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Telco Rack Support
Telco Rack Kit:
Support for all 2-post Telco racks requires the use of the standard rack kit and an additional
option kit from Rack Solutions.
http://www.racksolutions.com/hp
Factory Express
Portfolio for Servers
and Storage
HP Factory Express offers configuration, customization, integration and deployment services for
HP servers and storage products. Customers can choose how their factory solutions are built,
tested, integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex
configuration and design services as well as individual factory services, such as image loading,
asset tagging, and custom packaging. HP products supported through Factory Express include a
wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP
BladeSystem, HP 9000 servers as well as the MSA1000, VA7xxx, EVA, XP, rackable tape
libraries and configurable network switches.
For more information on Factory Express services for your specific server model please contact
your sales representative or go to
http://www.hp.com/go/factory-express
.
HP Enterprise
Configurator
The HP eCo-Enterprise Configurator now provides factory default racking for our HP hardware
portfolio. This approach is aligned with our strategic direction to meet the needs and expectations
of our valued customers. If you require "custom" rack configuration, please contact HP's
Customer Business Center or an Authorized Partner for assistance.
Service and Support
This product is covered by a global limited warranty and supported by HP Services and a
worldwide network of resellers and service providers. Hardware diagnostic support and repair is
available for one year from date of purchase. Support for software and initial setup is available for
90 days from date of purchase. Additional support may be covered under the warranty or available
for an additional fee. Enhancements to warranty services are available through HP Care Pack
services or customized service agreements.
NOTE:
Server Warranty includes 1 year Parts, 1 year Labor, 1-year on-site support. Additional
information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
HP Care Pack services include coverage for the HP branded hardware options qualified for the
server, purchased at the same time or afterward, internal to the enclosure, as well as 22" and
smaller external monitors and tower UPS options up to 3kVA; these items will be covered at the
same service level and for the same coverage period as the server. Coverage of UPS Battery is
not included, standard warranty terms & conditions apply. For servers or storage systems installed
within a rack, service also covers all HP qualified rack options installed within the same rack.
HP services provide continuous care and support expertise with committed response designed to
meet your IT and business needs.
To fully capitalizing on your HP ProLiant servers' capabilities requires a service partner who
thoroughly understands your server technology and systems environment. HP Services, an
industry leader in provision of multi vender support solutions provides a range of support services
designed to meet the varying needs of business. Whether an SMB or large global corporation HP
has a ProLiant server support offer to help you speedily deploy and maximize system uptime.
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Standard Features
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 8
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 9
:: Seite 9 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Enhanced Care - Minimum recommended service support offer designed to ensure customers
have access to expert assistance, whenever they need it.
Next Business Day on site coverage, 3 Years
Continuous Care - Recommended service, delivering cost-effective support options designed to
extend HP Services committed response and guaranteed fix times, designed to speed problem
identification and resolution.
4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years
Total Care - Highest HP Support service level recommend to help increase IT performance and
availability with comprehensive, integrated hardware and software services
4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years
Deployment Services - HP Installation and Start Up services designed to take time, risk, and worry
out of the deployment of ProLiant servers - and free customers IT support staff to focus on what
they do best, their business.
Installation of a ProLiant server as per Data Sheet. To be delivered on a scheduled basis
8am-5pm, M-F, excl. HP holidays
For a complete listing of service offerings and information visit:
http://www.hp.com/services/proliantservices
http://www.hp.com/go/proliant/carepack
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Standard Features
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 9
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 10
:: Seite 10 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
NOTE:
High Performance Computing (HPC) interconnect technologies are available for the DL140 under the Cluster
Platform product portfolio. These high-speed interconnects are fully supported by HP when they are part of these configure
to order clusters. Solutions can be defined with a lot of flexibility with the help of configuration tools. Please visit the following
URL to configure HPC Clusters with InfiniBand, Gigabit Ethernet or Myrinet Interconnects:
http://www.hp.com/techservers/clusters/ucp/index.html
HPC Interconnect
InfiniBand
PCI-X and PCI-Express adapters
Gigabit Ethernet
Use embedded ports
Myrinet XP
PCI-X Rev D, Rev E and Rev F adapters
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
HPC Interconnects
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 10
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 11
:: Seite 11 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Non Hot Plug Serial ATA (SATA) Models
HP DL140G3 E5345
417748-xx1
HP DL140G3 E5310
417746-xx1
HP DL140G3 5160
417759-xx1
HP DL140G3 5140
417757-xx1
HP DL140G3 5110
417756-xx1
Processor(s)
One of the following
depending on model
(1) Quad-Core Intel Xeon processor E5345 (2.33 GHz, 80 W, 1333 MHz
FSB)
(1) Quad-Core Intel Xeon processor E5310 (1.60 GHz, 80 W, 1066 MHz
FSB)
(1) Dual-Core Intel Xeon processor 5160 (3.00 GHz, 80 W, 1333 MHz
FSB)
(1) Dual-Core Intel Xeon processor 5140 (2.33 GHz, 65 W, 1333 MHz
FSB)
(1) Dual-Core Intel Xeon processor 5110 (1.60 GHz, 65 W, 1066 MHz
FSB)
Cache Memory
8MB (2 x 4MB) Level 2 cache (5300 sequence)
4MB (1 x 4MB) Level 2 cache (5100 sequence)
Memory
1 GB (2 x 512 MB) PC2-5300 DDR2 Fully Buffered DIMMs (667MHz)
with Advanced ECC capabilities
Network Controller
Two embedded NC320i PCIe Gigabit Server Adapters
Storage Controller
HP Embedded SATA RAID Controller
Hard Drive
80GB NHP SATA HDD
Internal Storage
1TB maximum (2 x 500GB Non-Hot plug 3.5" SATA hard drives)
Optical Drive
Optional CD-ROM, DVD-ROM, DVD RW, DVD/CD RW
Form Factor
Rack Mount (1U)
Hot Plug Serial ATA (SATA)/Serial Attached SCSI (SAS) Models
HP DL140G3 E5345
417749-xx1
HP DL140G3 E5310
417747-xx1
HP DL140G3 5160
417755-xx1
HP DL140G3 5140
417754-xx1
HP DL140G3 5110
417753-xx1
Processor(s)
One of the following
depending on model
(1) Quad-Core Intel Xeon processor E5345 (2.33 GHz, 80 W, 1333 MHz
FSB)
(1) Quad-Core Intel Xeon processor E5310 (1.60 GHz, 80 W, 1066 MHz
FSB)
(1) Dual-Core Intel Xeon processor 5160 (3.00 GHz, 80 W, 1333 MHz
FSB)
(1) Dual-Core Intel Xeon processor 5140 (2.33 GHz, 65 W, 1333 MHz
FSB)
(1) Dual-Core Intel Xeon processor 5110 (1.60 GHz, 65 W, 1066 MHz
FSB)
Cache Memory
8MB (2 x 4MB) Level 2 cache (5300 sequence)
4MB (1 x 4MB) Level 2 cache (5100 sequence)
Memory
1 GB (2 x 512 MB) PC2-5300 DDR2 Fully Buffered DIMMs (667MHz)
with Advanced ECC capabilities
Network Controller
Two embedded NC320i PCIe Gigabit Server Adapters
Storage Controller
HP 8 Internal Port SAS HBA with RAID
Hard Drive
None ship standard (up to 2 Hot Plug SATA or SAS drives supported)
Internal Storage
1.5TB max. (2 x 750GB Hot Plug 3.5" SATA hard drives) or 600GB (2 x
300GB Hot Plug 3.5" SAS hard drives)
Optical Drive
Optional CD-ROM, DVD-ROM, DVD RW, DVD/CD RW
Form Factor
Rack Mount (1U)
Availability
Hot Plug Hard Drives
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Models
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 11
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
Den aktuellen Preis und Lagerstand finden Sie online auf
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Page 12
:: Seite 12 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Country Code Key
XX=00
U.S.
XX=29
Japan
XX=37
APD
XX=42
Euro
XX=AA
CN
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Models
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 12
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 13
:: Seite 13 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
NOTE:
For Configure to Order requirements within EMEA region, please consult local Sales Contact.
NOTE:
HP does not allow factory integration of options into standard models listed above.
Configure-to-order servers must start with a CTO Chassis.
NOTE:
This product offering does not support HP Factory Express Server Configuration Level 1.
NOTE:
FIO indicates that this option is a Factory Installable Option.
NOTE:
This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid
configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales
representative for additional information.
Step 1: Base Configuration (choose one of the following configurable models)
Non-Hot Plug Model
HP ProLiant DL140 G3 Non- Hot Plug SATA Rack CTO Chassis (North America)
409023-B21
Factory Integrated Model ships with:
Two integrated Broadcom 10/100/1000 NICs (Wake on LAN and PXE capable)
Two available PCI-Express slots:
Slot 1: full-length/full-height PCI-Express x16
Slot 2: low-profile/half-height PCI-Express x8
(
NOTE:
Optional PCI-X option kit includes: Slot 1: full-length/full-height PCI-X
100; Slot 2: low-profile/half-height PCI-X 100. PCI-X slots are 64 bits; 133 MHz
capable if only one PCI-X card is installed in the server
)
HP Embedded SATA RAID Controller
650 Watt Power Supply
One Highline IEC Power Cord
6 Non-Hot Plug Fans
Rack (1U), (1.75 in / 4.45 cm)
HP ProLiant DL140 G3 Hot Plug SAS/SATA Rack CTO Chassis (North America)
409024-B21
Factory Integrated Model ships with:
Two integrated Broadcom 10/100/1000 NICs (Wake on LAN and PXE capable)
One available PCI-Express slot:
Slot 1: full-length/full-height PCI-Express x16
Slot 2: low-profile/half-height PCI-X slot populated by the SAS/SATA
storage controller
(
NOTE:
Optional PCI-X option kit includes: Slot 1: full-length/full-height PCI-X
100; and Slot 2: low-profile/half-height PCI-X 100. PCI-X slots are 64 bits; 133
MHz capable if only one PCI-X card is installed in the server
)
One HP SAS/SATA Host Cable Kit
One Hot Plug Backplane Option Kit
650 Watt Power Supply
One Highline IEC Power Cord
6 Non-Hot Plug Fans
Rack (1U), (1.75 in / 4.45 cm)
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Configuration Information - Factory Integrated Models (North America only)
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 13
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
Den aktuellen Preis und Lagerstand finden Sie online auf
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Page 14
:: Seite 14 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Step 2: Choose Required Options (only one of the following from each list unless
otherwise noted)
Processors
Quad-Core Intel Xeon processor X5355 (2.66 GHz, 120 W, 1333 MHz FSB) FIO
BASE
409279-L21
Quad-Core Intel Xeon processor E5345 (2.33 GHz, 80 W, 1333 MHz FSB) FIO
BASE
409159-L21
Quad-Core Intel Xeon processor E5335 (2.00 GHz, 80 W, 1333 MHz FSB) FIO
BASE
442992-L21
Quad-Core Intel Xeon processor L5320 (1.86GHz, 50W, 1066 MHz FSB), FIO
BASE
442995-L21
Quad-Core Intel Xeon processor E5320 (1.86 GHz, 80 W, 1066 MHz FSB) FIO
BASE
409157-L21
Quad-Core Intel Xeon processor E5310 (1.60 GHz, 80 W, 1066 MHz FSB) FIO
BASE
409278-L21
Dual-Core Intel Xeon processor 5160 (3.00 GHz, 80 W, 1333 MHz FSB) FIO
BASE
417786-L21
Dual-Core Intel Xeon processor 5150 (2.66 GHz, 65 W, 1333 MHz FSB) FIO
BASE
417784-L21
Dual-Core Intel Xeon processor 5148 (2.33 GHz, 40 W, 1333 MHz FSB) FIO
BASE
433253-L21
Dual-Core Intel Xeon processor 5140 (2.33 GHz, 65 W, 1333 MHz FSB) FIO
BASE
417774-L21
Dual-Core Intel Xeon processor 5130 (2.0 GHz, 65 W, 1333 MHz FSB) FIO
BASE
417772-L21
Dual-Core Intel Xeon processor 5110 (1.60 GHz, 65 W, 1066 MHz FSB) FIO
BASE
417770-L21
Memory
1 GB FBD PC2-5300 2X512 Kit
397409-B21
2 GB FBD PC2-5300 2X1GB Kit
397411-B21
4 GB FBD PC2-5300 2X2GB Kit
397413-B21
8 GB FBD PC2-5300 2X4GB Kit
397415-B21
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Configuration Information - Factory Integrated Models (North America only)
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 14
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
Den aktuellen Preis und Lagerstand finden Sie online auf
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Page 15
:: Seite 15 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Hard Drive
Serial-ATA (SATA) Non-Hot Plug Hard Drives
(To be used with Non-Hot Plug
CTO Chassis Models Only)
HP 80GB 1.5G SATA 7.2K NHP 3.5" HDD
383410-B21
HP 160GB 1.5G SATA 7.2K NHP 3.5" HDD
411275-B21
HP 250GB 1.5G SATA 7.2K NHP 3.5" HDD
411276-B21
HP 500GB 1.5G SATA 7.2K NHP 3.5" HDD, FIO
*
404469-B21
*Factory Integrated Only
Serial-ATA (SATA) Hot Plug Hard Drives
(To be used with SAS/SATA Hot Plug
CTO Chassis Models Only)
HP 80GB SATA 7.2K Hot Plug 3.5" HDD
349237-B21
HP 160GB SATA 7.2K Hot Plug 3.5" HDD
349238-B21
HP 250GB SATA 7.2K Hot Plug 3.5" HDD
349239-B21
HP 500GB SATA 7.2K Hot Plug 3.5" HDD
395473-B21
HP 750GB SATA 7.2K Hot Plug 3.5" HDD
432341-B21
Serial-Attached SCSI (SAS) Hot Plug Hard Drives
(To be used with
SAS/SATA Hot Plug CTO Chassis Models Only)
NOTE:
A SAS HBA or Array Controller is required.
HP 36GB 3G SAS 15K 3.5" SP HDD
375868-B21
HP 72GB 3G SAS 15K 3.5" SP HDD
375870-B21
HP 146GB 3G SAS 15K 3.5" SP HDD
375872-B21
HP 300GB 3G SAS 15K 3.5" SP HDD
431944-B21
Storage Controllers
HP 8 Internal Port SAS HBA with RAID
NOTE:
For use with Hot Plug SAS/SATA CTO Chassis models. Required only
when upgrading from a non-hot plug to a hot-plug model.
NOTE:
The selection HP 8 Internal Port SAS HBA with RAID requires the
purchase of the PCI-X Riser Option kit (P/N 409347-B21)
347786-B21
HP Smart Array E500/256MB Controller (Standard RAID 0,1, 1+0)
435129-B21
256MB Battery-backed write cache upgrade for RAID 5 support
Note: when installing a battery-backed write cache module, the HP Smart Array
E500 must be installed in the full-length PCI slot
383280-B21
HP Smart Array E200/128 BBWC Controller
411508-B21
128-MB BBWC (Battery-Backed Write Cache) Enabler
351580-B21
HP Single Channel U320 SCSI Controller
374654-B21
HP SC11Xe Host Bus Adapter
NOTE:
U20 HBA with tape support only.
412911-B21
HP SC44Ge Host Bus Adapter
NOTE:
SAS HBA
416096-B21
Step 3: Choose Additional Options for Factory Integration
NOTE:
For additional options, please refer to the "Options" section below. Some options may not be available for factory
integration. Please contact an HP sales representative for additional information.
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Configuration Information - Factory Integrated Models (North America only)
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 15
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 16
:: Seite 16 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
ProLiant Essentials
Licensing and
Packaging
HP Insight Control Environment
HP Insight Control Environment, No Media 1-Server License including 1 year of
24x7 Technical Support and Updates
NOTE:
Contains 1 license for each of RDP, PMP, VPM, IPM and iLO Advanced.
Includes one year of 24 x 7 HP Software Technical Support and Update Service.
452148-B21
NOTE:
For additional Insight Control Environment License Kits please see the
QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12631_div/12631_div.HTML
ProLiant Essentials Rapid Deployment Pack
ProLiant Essentials Rapid Deployment Pack No Media 1-Server License
including 1 year of 24x7 Technical Support and Updates
NOTE:
This license allows 1 server to be deployed and managed via RDP
452151-B21
NOTE:
For additional ProLiant Essentials Rapid Deployment Pack License Kits
please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/11053_div/11053_div.HTML
ProLiant Essentials Server Migration Pack
ProLiant Essentials Server Migration Pack, No Media, 1-Migration License
NOTE:
This license allows 1 P2V, V2P, or V2V migration. Contains one license
with a unique license activation key and documentation
435663-B21
NOTE:
For additional ProLiant Server Migration Pack License Kits please see
the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12328_div/12238_div.HTML
ProLiant Essentials Virtual Machine Management Pack
ProLiant Essentials Virtual Machine Management Pack, No Media, 1-Server
License, including 1 year of 24x7 Technical Support and Updates
NOTE:
For use with a single server. Contains one license with a unique license
activation key and documentation
452153-B21
NOTE:
For additional ProLiant Virtual Machine Management Pack License Kits
please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12328_div/12238_div.HTML
NOTE:
Flexible and volume quantity license kits are available for ProLiant
Essentials Value Packs. Refer to http://www.hp.com/servers/proliantessentials or
the various ProLiant Essentials Value Pack product QuickSpecs for more
information.
NOTE:
For more information regarding ProLiant Essentials Software, please see
the following URL:
http://www.hp.com/servers/proliantessentials
.
Remote Management
ProLiant Essentials Integrated Lights-Out Select Pack and Advanced Pack
HP Lights Out 100i Select Pack 1-Server License
413111-B21
HP Lights Out 100i Advanced Pack 1-Server License
413115-B21
NOTE:
For additional ProLiant Integrated Light-Out Select Pack and Advanced
Pack License Kits please see the QuickSpecs at:
http://h18000.www1.hp.com/products/quickspecs/12087_div/12087_div.HTML
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Options
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 16
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 17
:: Seite 17 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Processor
Quad-Core Intel Xeon processor X5355 (2.66 GHz, 120 W, 1333 MHz FSB)
Option Kit
*
409279-B21
Quad-Core Intel Xeon processor E5345 (2.33 GHz, 80 W, 1333 MHz FSB)
Option Kit
409159-B21
Quad-Core Intel Xeon processor E5335 (2.00 GHz, 80 W, 1333 MHz FSB)
Option Kit
*
442992-B21
Quad-Core Intel Xeon processor L5320 (1.86 GHz, 50W, 1066 FSB) Option Kit*442995-B21
Quad-Core Intel Xeon processor E5320 (1.86 GHz, 80 W, 1066 MHz FSB)
Option Kit
*
409157-B21
Quad-Core Intel Xeon processor E5310 (1.60 GHz, 80 W, 1066 MHz FSB)
Option Kit
409278-B21
Dual-Core Intel Xeon processor 5160 (3.00 GHz, 80 W, 1333 MHz FSB) Option
Kit
417786-B21
Dual-Core Intel Xeon processor 5150 (2.66 GHz, 65 W, 1333 MHz FSB) Option
Kit*
417784-B21
Dual-Core Intel Xeon processor 5148 (2.33 GHz, 40 W, 1333 MHz FSB, Low
Voltage) Option Kit
*
433253-B21
Dual-Core Intel Xeon processor 5140 (2.33 GHz, 65 W, 1333 MHz FSB) Option
Kit
417774-B21
Dual-Core Intel Xeon processor 5130 (2.00 GHz, 65 W, 1333 MHz FSB) Option
Kit*
417772-B21
Dual-Core Intel Xeon processor 5110 (1.60 GHz, 65 W, 1066 MHz FSB) Option
Kit
417770-B21
*Available through Configure To Order only. See Factory Integration Models
section for more details.
Memory (FBDIMMs)
1 GB FBD PC2-5300 2X512 Kit
397409-B21
2 GB FBD PC2-5300 2X1GB Kit
397411-B21
4 GB FBD PC2-5300 2X2GB Kit
397413-B21
8 GB FBD PC2-5300 2X4GB Kit
397415-B21
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Options
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 17
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
Den aktuellen Preis und Lagerstand finden Sie online auf
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Page 18
:: Seite 18 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Hard Drives
Serial-ATA (SATA) Non-Hot Plug Hard Drives
(Non-Hot Plug Models Only)
HP 80GB 1.5G SATA 7.2K NHP 3.5" HDD
383410-B21
HP 160GB 1.5G SATA 7.2K NHP 3.5" HDD
411275-B21
HP 250GB 1.5G SATA 7.2K NHP 3.5" HDD
411276-B21
NOTE:
When purchasing systems with the 500GB Non-Hot Plug SATA drives,
please reference the Configuration Information Section of this QuickSpecs to
order via Configuration to Order.
Serial-ATA (SATA) Hot Plug Hard Drives
(SAS/SATA Hot Plug Models Only)
NOTE:
A SAS HBA or Array Controller is required.
HP 80GB SATA 7.2K Hot Plug 3.5" HDD
349237-B21
HP 160GB SATA 7.2K Hot Plug 3.5" HDD
349238-B21
HP 250GB SATA 7.2K Hot Plug 3.5" HDD
349239-B21
HP 500GB SATA 7.2K Hot Plug 3.5" HDD
395473-B21
HP 750GB SATA 7.2K Hot Plug 3.5" HDD
432341-B21
Serial-Attached SCSI (SAS) Hot Plug Hard Drives
(SAS/SATA Hot Plug
Models Only)
HP 36GB 3G SAS 15K 3.5" SP HDD
375868-B21
HP 72GB 3G SAS 15K 3.5" SP HDD
375870-B21
HP 146GB 3G SAS 15K 3.5" SP HDD
375872-B21
HP 300GB 3G SAS 15K 3.5" SP HDD
431944-B21
NOTE:
The purchase of SAS HBA or array controller is required.
Graphic Cards
NVIDIA Quadro FX3500 256MB PCIe
435681-B21
NVIDIA Quadro FX1500 256MB PCIe
435703-B21
NOTE:
Graphic cards are supported on Windows 2003 and Linux Operating
Systems.
Optical Drives
DVD-ROM Drive (optional)
361040-B21
24x CD-ROM Drive (optional)
349046-B21
DVD-RW Drive (optional)
395498-B21
DVD/CD RW Drive (optional)
377402-B21
Multibay II DVD/CD-RW Combo Drive
NOTE:
When purchasing the Multibay II DVD/CD-RW Combo Drive, (P/N
PA850A), the USB 2.0 Multibay II Cradle (P/N PA509A) is required.
PA850A
USB 2.0 MultiBay II Cradle, External
NOTE:
When purchasing the Multibay II DVD/CD-RW Combo Drive, (P/N 850A),
the USB 2.0 Multibay II Cradle, (P/N PA509A) is required.
PA509A
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Options
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 18
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 19
:: Seite 19 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Storage Controllers
HP 8 Internal Port SAS HBA with RAID
NOTE
: For use with Hot Plug SAS/SATA models. Required only when upgrading
from a non-hot plug to a hot plug model.
NOTE:
The selection HP 8 Internal Port SAS HBA with RAID requires the
purchase of the PCI-X Riser Option kit (P/N 409347-B21)
347786-B21
HP SAS/SATA Host Cable Kit
NOTE: For use with Hot Plug SAS/SATA models. Required only when upgrading
from a non-hot plug to a hot plug model.
389650-B21
HP Smart Array E500/256MB Controller (Standard RAID 0,1, 1+0)
435129-B21
256MB Battery-backed write cache upgrade for RAID 5 support
NOTE:
when installing a battery-backed write cache module, the HP Smart Array
E500 must be installed in the full-length PCI slot
383280-B21
HP Smart Array E200/128 BBWC Controller
411508-B21
128-MB BBWC (Battery-Backed Write Cache) Enabler
351580-B21
HP PCI-X Riser Board Kit
409347-B21
Hot Plug Backplane Option Kit
NOTE:
Required when upgrading from a non-hot plug to a hot plug model
409348-B21
64-Bit/133-MHz Single Channel Ultra320 SCSI HBA G2
374654-B21
HP SC11Xe Host Bus Adapter
NOTE:
U320 HBA with tape support only.
412911-B21
HP SC44Ge Host Bus Adapter
NOTE:
SAS HBA.
416096-B21
Communications
HP NC110T PCI Express 1 Port Gigabit Server Adapter
NOTE:
Does not support Windows 2000.
434905-B21
HP NC150T PCI 4-Port Gigabit Combo Switch Adapter
367132-B21
HP NC310F PCI-X Gigabit Server Adapter
368169-B21
HP NC360T PCI Express Dual Port Gigabit Server Adapter
412648-B21
HP NC364T PCI Express Quad Port Gigabit Server Adapter
NOTE:
Does not support Windows 2000.
435508-B21
HP NC373F PCI Express Multifunction Gigabit Server Adapter
394793-B21
HP NC373T PCI Express Multifunction Gigabit Server Adapter
394791-B21
HP NC380T PCI Express Dual Port Multifunction Gigabit Server Adapter
394795-B21
HP NC510C PCIe 10 Gigabit Server Adapter
NOTE:
A minimum of 1 gigabyte (1 GB) of server memory is required per each
NC510C adapter.
414129-B21
HP NC510F PCIe 10 Gigabit Server Adapter
NOTE:
A minimum of 1 gigabyte (1 GB) of server memory is required per each
NC510F adapter.
414126-B21
HP NC7771 PCI-X Single Port Gigabit Server Adapter
290563-B21
InfiniBand 4X PCI-E Dual Port Host Adapter
380298-B21
InfiniBand 4X PCI-X Dual Port Host Adapter
380299-B21
HP IB 4X DDR PCI-e DUAL PORT HCA
448397-B21
HP IB 4X DDR PCI-e Dual Port HCA
409376-B21
Myrinet PCI 2XP Rev-E 4MB Network Interface Card
373983-B21
Myrinet 2XP PCI-X, Fiber F-Series, 2MB NIC
390456-B21
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Options
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 19
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 20
:: Seite 20 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Myrinet-Fiber/PCI-X Interface (Dual channel Rev. D card)
360040-B21
Quadrics QsNet-II Rev BB PCI-X NIC
AC071A
NOTE:
For HPC interconnect adapters please see the HPC Interconnect section
of this QuickSpecs.
Rack Kits
1U Cable Management Arm
NOTE:
Package contains two cable management arms
365403-B21
Tape Drives
USB Tape Drives
HP StorageWorks DAT 40 USB Internal Tape Drive (Carbonite)
NOTE:
HP recommends combining this tape drive with the 1U USB Rack-Mount
kit (A8007A) for a complete rack-mount solution.
DW022A
HP StorageWorks DAT 72 USB Internal Tape Drive (Carbonite)
NOTE:
HP recommends combining this tape drive with the 1U USB Rack-Mount
kit (A8007A) for a complete rack-mount solution.
DW026A
DAT External Tape Drive
HP StorageWorks DAT 40 SCSI Internal Tape Drive (Carbon)
NOTE:
HP recommends combining this tape drive with the 1U SCSI Rack-Mount
kit (A7445B) for a complete rack-mount solution.
C5686C
HP StorageWorks DAT 72 SCSI Internal Tape Drive (Carbon)
NOTE:
HP recommends combining this tape drive with the 1U SCSI Rack-Mount
kit (A7445B) for a complete rack-mount solution.
Q1522B
Ultrium External Tape Drive
HP StorageWorks Ultrium 232 Internal Tape Drive, (Carbonite)
NOTE:
HP recommends combining this tape drive with the 1U SCSI Rack-Mount
kit (A7445B) for a complete rack-mount solution.
DW064A
Rack-Mount Tape Drive
HP StorageWorks 1U SCSI Rack-Mount kit
NOTE:
The 1U Rack-Mount Kit can support up to (2) half-height tape drives and
is compatible with multiple Single-Ended and LVD SCSI tape drives including the
DAT 24, DAT 40, DAT 72, DLT VS80, DLT VS160, Ultrium 215, Ultrium 232,
Ultrium 448 and Ultrium 920 tape drives.
A7445B
HP StorageWorks 1U USB Rack-Mount Kit
NOTE:
The 1U USB Rack-Mount Kit can support up to (2) half-height tape drives
and is compatible with the DAT 24 USB, DAT 40 USB and DAT 72 USB tape
drives.
A8007A
NOTE:
When attaching to an external tape drive, autoloader or library, you must
also purchase a HBA
NOTE:
For a complete listing of HP tape drive offerings supported with the
DL140 G3, visit
http://www.hp.com/products1/storage/compatibility/tapebackup/ISS/index.html
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Options
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 20
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 21
:: Seite 21 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
StorageWorks Options
StorageWorks Fibre Channel HBA
NOTE:
The following is a list of all Fibre Channel Host Bus Adapters for
Windows and Linux. For detailed compatibility information please see:
http://h18006.www1.hp.com/storage/saninfrastructure/hba.html
HP StorageWorks 4 Gb PCI-X 2.0-to-Fibre Channel HBA
AB429A
HP StorageWorks 4 Gb PCI-X 2.0 DC-to-Fibre Channel HBA
AE369A
HP StorageWorks FC2142SR 4Gb PCI-E HBA
A8002A
HP StorageWorks FC2242SR Dual Channel 4 Gb PCI-E HBA
A8003A
HP StorageWorks FC1142SR 4Gb PCI-E HBA
AE311A
HP StorageWorks FC1242SR Dual Channel 4 Gb PCI-E HBA
AE312A
HP StorageWorks FC2143 4Gb PCI-X 2.0 HBA
AD167A
StorageWorks SCSI HBA
HP U320e SCSI Host Bus Adapter
NOTE:
Recommended Dual Channel Ultra320 SCSI Controller for connecting
multi-drive MSL tape libraries to ProLiant servers
AH627A
HP StorageWorks FC2243 4Gb PCI-X 2.0 DC HBA
AD168A
USB Options
HP 1GB USB 2.0 Floppy Drive Key
442085-B21
HP 256MB USB 2.0 Floppy Drive Key
442084-B21
USB 1.44-MB External Diskette Drive
DC141B
USB Floppy Drive
DC361B
HP USB-P/S2 Mouse
DC369A
HP Keyboard (USB) standard 2004
DT528A#xxx
USB 2.0 4-port HUB
DG954A
HP KVM Switch
Options
2x1x16 IP Console Switch with Virtual Media
AF601A
4x1x16 IP Console Switch with Virtual Media
AF602A
2x16 Server Console Switch with Virtual Media
AF600A
PS/2 Virtual Media Interface Adapter, 1 pack
NOTE:
Requires PS/2 and one USB port on server.
AF604A
HP Server Console Switch (KVM), 0 x 1 x 8 port
336044-B21
HP Server Console Switch (KVM), 0 x 2 x 16 port
336045-B21
PS/2 Interface Adapter, 1 pack
262588-B21
PS/2 Interface Adapter, 8 pack
262587-B21
USB Interface Adapter, 1 pack
336047-B21
Serial Interface Adapter - 1 pack with power supply
373035-B21
CAT5 KVM Expansion Module
262589-B21
HP 1x4 Console Switch
AF611A
HP PS2 Server Console Cable, 6 foot, 2-Pack
AF612A
HP USB Server Console Cable, 6 foot, 2-Pack
NOTE:
required for supporting USB peripherals.
AF613A
NOTE
: Cat5e cables are required to connect Interface Adapters to Console
Switches. Cat5e cables can be found at the following URL:
http://www.hp.com/go/kvm
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Options
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 21
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 22
:: Seite 22 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
HP Serial Console
Server Options
HP 16 Port Serial Console Server (worldwide)
AF101A
HP 48 Port Serial Console Server (worldwide)
AF102A
Serial Adapter, RJ45-D89 DCE Female, 1-pack
AF103A
Serial Adapter, RJ45-D89 DCE Female, 8-pack
AF110A
NOTE: For additional information regarding KVM switches, Serial Console
servers, rack mount monitors, keyboards and all related options please see the
following URL:
http://www.hp.com/go/kvm
Service and Support
Offerings (HP Care
Pack Services)
Hardware Services 4-Hour On-site Service
13-Hour x 5-Day Coverage, 3 Years, Electronic
U9509E
24-Hour x 7-Day Coverage, 3 Years, Electronic
U9510E
Hardware Services Next Business Day On-Site Service
9-Hour x 5-Day Coverage, 3 Years, Electronic
U9508E
Hardware Services 6-Hour Call to Repair On-Site Service
6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years,
Electronic
U9511E
Hardware Installation, Electronic
U9520E
NOTE:
For more information, customer/resellers can contact
http://www.hp.com/services/carepack
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Options
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 22
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 23
:: Seite 23 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
HP ProLiant DL140 G3 (all models)
NOTE:
Memory configurations listed do not apply to "Factory Integrated Models".
Standard Memory
1 GB (2 x 512 MB) PC2-5300 Fully Buffered DIMM memory, with Advanced ECC Capabilities Memory installed.
Maximum Memory
Up to 32GB memory is available with the optional installation of PC2-5300 Fully Buffered DIMM memory kits.
NOTE:
Memory should be installed in pairs and matched for optimum performance.
NOTE:
Chart does not represent all possible memory configurations.
Memory
Slot
1 2 3 4 5 6 7 8
Standard (1 GB)
512 MB
Empty
512 MB
Empty Empty Empty Empty Empty
Maximum (32 GB)
4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB
Following are memory options available from HP:
1 GB FBD PC2-5300 2X512 Kit
397409-B21
2 GB FBD PC2-5300 2X1GB Kit
397411-B21
4 GB FBD PC2-5300 2X2GB Kit
397413-B21
8 GB FBD PC2-5300 2X4GB Kit
397415-B21
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Memory
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 23
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 24
:: Seite 24 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
1,2
Two Non-hot plug SATA or Two 3.5" Hot Plug
SAS/SATA Hard Drive Bays
3
Optional CD-ROM, DVD-ROM, DVD RW,
DVD/CD RW
4
Power On/Off
Drive Support
Removable Media
Quantity
Supported
Position
Supported
Controller
IDE (ATAPI) CD-ROM
Drive
Up to 1
3
Integrated IDE (ATAPI) (optional)
DVD-ROM
Up to 1
3
Integrated IDE (ATAPI) (optional)
DVD RW
Up to 1
3
Integrated IDE (ATAPI) (optional)
DVD/CD RW
Up to 1
3
Integrated IDE (ATAPI) (optional)
Hard Drives
SATA - Non-Hot Plug
Quantity
Supported
Position
Supported
Controller
3.5-inch
80GB 7,200 rpm
Up to 2
1;2
HP Embedded SATA RAID Controller
160GB 7,200 rpm
Up to 2
1;2
HP Embedded SATA RAID Controller
250GB 7,200 rpm
Up to 2
1;2
HP Embedded SATA RAID Controller
500GB 7,200 rpm
Up to 2
1;2
HP Embedded SATA RAID Controller
SAS/SATA Hot Plug
Quantity
Supported
Position
Supported
Controller
3.5-inch
80GB SATA 7,200 rpm
Up to 2
1;2
See Storage Controller Section
160GB SATA 7,200 rpm
Up to 2
1;2
See Storage Controller Section
250GB SATA 7,200 rpm
Up to 2
1;2
See Storage Controller Section
500GB SATA 7,200 rpm
Up to 2
1;2
See Storage Controller Section
750GB SATA 7,200 rpm
Up to 2
1;2
See Storage Controller Section
36GB SAS 15,000 rpm
Up to 2
1;2
See Storage Controller Section
72GB SAS 15,000 rpm
Up to 2
1;2
See Storage Controller Section
146GB SAS 15,000 rpm
Up to 2
1;2
See Storage Controller Section
300GB SAS 15,000 rpm
Up to 2
1;2
See Storage Controller Section
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Storage
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 24
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 25
:: Seite 25 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Tape Drives
NOTE:
For an up-to-date listing of the latest O/S Support details for each of the Tape Drives listed below, please see the
following:
http://h18000.www1.hp.com/products/quickspecs/Division/10233.html
(Worldwide)
NOTE:
For complete listing of tape drive offerings see
http://www.hp.com/products1/storage/compatibility/tapebackup/ISS/index.html
For recommended tape drive offerings for this ProLiant server see the following:
Position
Supported
Controller
Controller/HBA
Option Kit Part
Number
HP StorageWorks USB
Tape Drives, External
DAT 40 USB
DAT 72 USB
External
USB 2.0 Port
N/A
HP StorageWorks
SCSI Tape Drives,
External
Ultrium 232
DAT 40
DAT 72
External
HP SC11Xe Host Bus Adapter
412911-B21
HP StorageWorks
SCSI Rack-mount
Tape Drive Enclosures
1U Rack-Mount Kit
External
HP SC11Xe Host Bus Adapter
412911-B21
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Storage
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 25
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 26
:: Seite 26 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
650W Power Supply
Spare Kit
416349-001
Operational Input
Voltage Range
(Vrms)
90Vac to 264Vac full range
Frequency Range
(Nominal) (Hz)
47 Hz to 63 Hz
Nominal Input Voltage
(Vrms)
100 115 200 220 230 240
Max Rated Output
Wattage Rating
653.10 653.19 653.08 652.96 653.08 652.96
Nominal Input Current
(A rms)
8.55 7.31 4.12 3.77
3.6
3.46
Max Rated Input
Wattage Rating
(Watts)
855
840.72 824.12
827.5 806.3
805.71
Max. Rated VA
(Volt-Amp)
990 990 990 990 990 990
Efficiency
(%)
76.39 77.69 79.25 78.91
81
81.04
Power Factor
0.998 0.997 0.983 0.976 0.973 0.969
Leakage Current
(mA)
<3.5mA <3.5mA <3.5mA <3.5mA <3.5mA <3.5mA
Maximum Inrush
Current
(A peak)
60A 60A 60A 60A 60A 60A
Maximum Inrush
Current Duration
(mS)
1mS 1mS 1mS 1mS 1mS 1mS
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Power Specifications
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 26
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 27
:: Seite 27 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Power
ProLiant DL140 G3 Fully Configured
115V/60Hz 220V/50Hz
Fully Loaded System Input Wattage
(W)
651 638
Fully Loaded System Input Current
(A rms)
5.7 3.0
Fully Loaded System Thermal
(BTU- Hr)
2218 2174
Fully Loaded System VA
(Volt-Amp)
657 657
System Leakage with all power supplies loaded
(mA)
1.58 3.03
System Inrush Current with all power supplies loaded
(A)
19 37
Power cord requirements
Nema 5-15P to IEC320-C13
IEC320-C13 to IEC320-C14
NOTE:
Power shown is for a fully configured system consisting of (2) CPU, (8) double-sided DIMMs, (2) HDDs, (1) CD-
ROM, and (2) PCI cards.
Power Cord
AF556A
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
System Specifications
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 27
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Page 28
:: Seite 28 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
System Unit
Dimensions
(HxWxD)
(with feet)
1.70 x 16.78 x 26.62 in (4.32 x 42.62 x 67.62 cm)
Weight
(approximate)
35 lb
(15.87 kg)
Fully configured
Input Requirements
(per power supply)
Range Input Voltage
90 to 140 VAC/180 to 264 VAC
Normal Line Voltage
115 or 230 VAC
Line Frequency
47 to 63 Hz
Rated Input Current
load
7.31A at 115VAC, 3.6A at 230VAC
BTU Rating
BTU-Hr
2228
Power Supply Output
Power
(per power
supply)
Rated Steady-State
Power
653W
Maximum Peak Power
Temperature Range
Operating
50° to 95° F (10° to 35° C)
Shipping
-40° to 140° F (-40° to 60° C)
NOTE:
All temperature ratings shown are for sea level. An altitude derating of 1° C per 304.8 m
(1.8°F per 1,000 ft) to 3048 m (10,000 ft) is applicable. No direct sunlight allowed. Upper operating
limit is 3,048m (10,000 ft) or 70 Kpa/10.1 psia. Upper non-operating limit is 9,144 m (30,000 ft) or
30.3KPa/4.4 psia. System performance may be reduced if operating above 30° C.
Relative Humidity
(non-condensing)
Operating
10% to 85%
Non-operating
10% to 95%
Acoustic Noise
Idle
(Fixed Disk Drives
Spinning)
L WAd
(BELS)
6.21
Operating
(Random Seeks to Fixed
Disks)
L WAd
(BELS)
6.29
Non-Hot Plug SATA
Hard Drives
80 GB 7.2K
383410-B21
Capacity
80027 MB
Height
1.028 in (2.61 cm)
Width
4.0 in (10.16 cm)
Interface
SATA 150
Transfer Rate
Synchronous
(Maximum)
150 MB/s
Seek Time
(typical reads, including
settling)
Single Track
0.8 ms
Average
9.0 ms
Full-Stroke
17.0 ms
Rotational Speed
7,200 rpm
Physical Configuration
Bytes/Sector
512
Logical Blocks
160,086,528
Operating Temperature
41° to 131° F (5° to 55° C)
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Technical Specifications
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 28
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
Den aktuellen Preis und Lagerstand finden Sie online auf
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Page 29
:: Seite 29 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
Two embedded NC320i
PCIe Gigabit Server
Adapters
Network Interface
Compatibility
10Base-T/100Base-TX/1000Base-TX
IEEE 802.3 10Base-T
IEEE 802.3 1000Base-T
IEEE 802.3 100Base-TX
Data Transfer Method
64-bit, 133MHz PCI(X)1.0
Network Transfer Rate
10Base-T
(Half-Duplex)
10 Mb/s
10Base-T
(Full-Duplex)
20 Mb/s
100Base-TX
(Half-
Duplex)
100 Mb/s
100Base-TX
(Full-
Duplex)
200 Mb/s
1000Base-TX
(Half and
Full-Duplex)
2000 Mb/s
Connector
RJ-45
Cable Support
10Base-T
Categories 3, 4 or 5 UTP; up to 328 ft (100 m)
10/100/1000Base-TX
Category 5 UTP (2 Pair); up to 328 ft (100 m)
© Copyright 2007 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft and Windows NT are US registered trademarks of Microsoft Corporation. Intel is a US registered trademark of
Intel Corporation.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for
technical or editorial errors or omissions contained herein.
For hard drives, 1 GB = 1 billion bytes. Actual formatted capacity is less.
QuickSpecs
HP ProLiant DL140 Generation 3 (G3)
Technical Specifications
DA - 12509 Worldwide — Version 14 — July 9, 2007
Page 29
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Den aktuellen Preis und Lagerstand finden Sie online auf
Loading...
