d510/d530 Software Image Comparison Overview
2003 HP Compaq Business Desktop Products
Table of Contents ...................................................................................................... 1
Abstract.................................................................................................................... 2
Definition of Terms .................................................................................................... 2
Highlights ................................................................................................................. 2
d530 Pre-installed Operating Systems ...................................................................... 2
d530 Supported Operating Systems .......................................................................... 3
3rd Party Certified Operating Systems ........................................................................ 3
General Pre-installed Image Contents ........................................................................ 4
Microsoft Windows 2000 .......................................................................................... 5
Microsoft Windows XP .............................................................................................. 7
Microsoft Windows NT Workstation 4.0..................................................................... 9
Microsoft Windows 98 ............................................................................................ 10
Hardware Functionality and Software Enhancements....................................................... 10
OS/2...................................................................................................................... 11
Hardware Functionality and Software Enhancements....................................................... 11
Software Delivery ................................................................................................... 11
HP Support Software CD ................................................................................................ 11
HP Worldwide Web Site and Download Facility .............................................................. 11
Restore Plus!.................................................................................................................. 11
Copyright and Trademarks...................................................................................... 12
1
D510/D530 Software Image Comparison Overview
Abstract
Definition of
Terms
The purpose of this white paper is to present both an overview of the preinstalled software
with operating system support and a brief description of major software components and
features. This white paper covers the HP Compaq Business Desktop d530 models along with a
software comparison to Compaq Evo D510 models.
This document is intended for HP personnel and customers who need information about the
software provided on the HP Compaq Business Desktop d530 preinstall images.
Application Installer – This is an application provided by HP can be used to install
software that is pre-loaded (not preinstalled) on the hard drive.
Preinstalled applications – Preinstalled applications are installed during the initial
software unbundling, and are ready to use immediately.
Preloaded applications – Some applications from HP are loaded on the hard drive in an
uninstalled state; you must install the application manually before you can use it. Application
Installer provides a simple interface to the uninstalled applications. Note that some pre-loaded
applications have their own install program. For example, Norton AntiVirus and HP
ProtectTools are installed by selecting their shortcut icons from the START->PROGRAM menu.
Product family – A product family is defined as a set of form-factor types within a
numerically-defined series. For example, the HP Compaq Business Desktop d530 Series
consists of the d530 convertible minitower, d530 small form factor, and d530 ultra-slim
desktop.
Highlights
d530
Pre-installed
Operating
Systems
Quick fixes – Sometimes called QFE’s, are important software updates provided by
Microsoft. These are usually included in operating system images provided by HP.
Restore Plus! – This is the hard drive recovery media provided by HP on CD-ROM and used
to allow a user to re-image the system back to its factory state.
Standalone service packs – Service packs are a large collection of QFE’s grouped
together that provides a significant update, or service pack, to an existing Microsoft operating
system.
Benefits of the new HP Compaq Business Desktop d530 preinstall image include:
Support for all HP Compaq Business Desktop d530 models
Microsoft WHQL certified
Pre-installed operating systems include:
Microsoft Windows 2000 Professional with Service Pack 3
Microsoft Windows XP Professional with Service Pack 1
Microsoft Windows XP Home with Service Pack 1
2
D510/D530 Software Image Comparison Overview
d530
The following operating systems are supported:
Supported
Operating
Systems
Windows XP Home/Pro (Gold)
Windows 2000 SP1
Windows 2000 SP2
Windows NT 4 SP6a
Supported definition:
Full HP testing
All HP software value add applications and drivers available (OS Dependant)
All drivers available (HP Web site/CD) within 30 days
New technologies may not be supported on older operating systems.
✎
Limited support is provided for the following operating systems:
Windows 98SE
OS/2 Warp 4.0
Limited support definition:
All drivers available for major subsystems, if not provided by OS, within 30 days (NIC,
audio, video, cold dock MultiBay devices)
ROMPaq updates as needed
Functional test on representative configurations
Does not include delivery and support of HP/Compaq branded applications or utilities
and 3rd party user applications (i.e., DVD player)
No support for USB devices other than basic keyboard and mouse (no Easy Access
Keyboard hot button support)
3rd Party
Certified
Operating
Systems
New technologies may not be supported on older operating systems.
✎
OS/2 is not supported on legacy-free HP Compaq Business Desktop d530 ultra-
3rd Party certified operating systems include:
Novell
Mandrake Linux
Turbolinux
Red Hat Linux
SuSE Linux
3rd Party Vendor Certification: Linux
Hardware submitted to vendor for testing and certification
All drivers are OS dependent, not supplied by HP
Certification posted to Linux vendor site
slim desktop models.
3
D510/D530 Software Image Comparison Overview
3rd Party Vendor Certification: Novell
Hardware submitted HP Research Park for testing and certification
Novel Certified and posted to their Web
General
Pre-installed
Contents
HP Compaq Business Desktops come standard with a factory-installed software image. The
image consists of a number of separate software components including the operating system
and its associated components, drivers for the specific hardware devices included with the
system (such as graphics, network interface cards, modems, etc.) and a small number of
additional applications.
Quick fixes (QFEs) are also included with the image for any Microsoft operating system issues
that HP identified as problems that might affect its customers. These QFEs will show up under
the Add/Remove Programs applet in the Control Panel. Since most of these fixes are critical in
nature, they will appear grayed out by design so they cannot be removed.
Standalone service packs may also be preloaded on some systems depending on the version
of the integrated operating system and the timing and nature of the HP Compaq Business
Desktop product introduction. Other software applications that are preloaded include optional
business software. Examples of these types of applications include: Norton Anti-Virus, Altiris
Deployment Solution Agents, Insight Management Agents, and HP Diagnostics for Windows.
In addition, an HP internally-supported application called Application Installer provides a user
interface to allow installation of these optional preloaded programs. (See page 2 for definition
of preloaded applications.)
Following is a more detailed list of general software provided:
Microsoft Windows Operating System Software:
Windows XP Professional or Windows XP Home Edition or Windows 2000
Step By Step Interactive for Windows XP Home and Pro (For locales supported by
Microsoft)
Direct X
Dot Net Framework for Windows XP
Microsoft-provided QFE’s
Quad Byte Supplement (for Simplified Chinese language only)
Windows XP Professional Multi User Interface Pack (for Eastern European and Thai
regions)
Standalone Service Packs
USB 2.0 Supplement for Windows 2000
Hardware/OEM specific drivers and files:
Graphics
Network Interface Card
Audio
Modem
Wireless LAN
HP Monitor INF
Chipset INF
HP SLP Driver files for Windows XP
HP Online Crash Analysis File
HP Security Guest account fix
4
D510/D530 Software Image Comparison Overview
ppy
HP Specific Applications
Help and Support Center for Windows XP
Application Installer (for preloaded components)
Insight Management Agents
Online EULA for Windows XP
Safety and Comfort Guide
Technical Support Phonebook
Optional applications that are typically preinstalled
Altiris Deployment Solution Agents (preloaded)
Adobe Acrobat Reader
Microsoft Word
Microsoft Works
Microsoft Office XP
Norton AntiVirus
Microsoft
Microsoft Windows 2000 Professional with Service Pack 3 is the preinstalled operating system
for select HP Compaq Business Desktops d530 models. HP also supports customers who install
Windows
2000
Windows 2000 on their own. The following table compares the delivered operating systems
components and drivers for the Compaq Evo D510 to the HP Compaq Business Desktop
d530.
Many of the drivers and components denoted with “*” are available on the HP driver
download Web site. Instructions for where to obtain and how to install these drivers are
provided in the “Software Delivery” section of this white paper.
Table 1. Windows 2000 Software Component Version Comparison
Software
INTEL 845G GRAPHICS DRIVER *
nVidia Graphics Driver *
Intel Intel 865 Graphics Driver *
ADI Integrated Digital Audio driver *
3com 3C905C Drivers *
Intel(R) PRO/100/1000 Drivers *
Broadcom 10/100/1000 Drivers *
HP WLAN 802.11b WL220 *
Lucent 56K v.90 Win Modem Driver *
Compaq 3 mode flo
PSeries Drivers for HP PCMCIA Reader
Via PCI Card
Easy Access Keyboard support software*
HP Wireless Keyboard and Wireless
Mouse Applet
HP Wireless Mouse Applet *
*
*
driver *
Input Device Software
D510 d530
Drivers
6.13.01.3095 B -
31.00 G 43.03 B
- 6.13.01.3485 A
5.12.1.3501 J 5.12.01.3570 B
5.40 A -
6.1.30 A 6.4.16.1 A
2.67 A 6.34 A
- 1.1.5.0 A
5.98 B 8.22 E
1.00 D 1.00 B
- 5.07.04 A (SFF/CMT only)
8.0.0.571 C 8.0.0.678C E
- 1.14 B
- 1.09 B
5
D510/D530 Software Image Comparison Overview
y
)
Table 1. Windows 2000 Software Component Version Comparison
Software
Component
Preinstalled Applications
InterVideo WinDvD Software *
Roxio Easy CD Creator (upgrade
package)
HP ProtectTools Embedded Securit
Adobe Acrobat Reader - 5.10 A
Safety and Comfort Guide - Desktop - 1.00 B
Application Installer 1.20 A 2.00 B
Norton AntiVirus 2002 E 2003 A
Remote Diags Enabling Agent *
Diagnostics for Windows *
Altiris eXpress agent (available at:
http://h18000.www1.hp.com/im/swdeploy/
prodinfo.html#deployment_solution) *
Insight Management Agent *
Intel Chipset Support for Windows 2000 *
Win2K USB Standby QFE *
USB 2.0 for Windows 2K *
Win2K ICH4IDE Fix *
Win2K ICH5IDE Fix *
NTFS Security Update *
Win2K fix adds 802.11 support *
Windows 2000 SATA Fix Q812415 *
Q810090 Win2K USB 2.0 updated driver
stack
Win2K Atapi.sys Update Q817472 *
ADAPTEC SCSI CONTROLLER W2K *
Microsoft DirectX 8.1 J (DX 8.1) 1.00 A (DX 9.0)
Set Video Refresh rate - 1.1.0.20 F
Chinese Quad Byte Support *
ROM for Intel 845 (686O2) *
ROM for Intel 865 (CMT/SFF) (786B2
ROM for Intel 865 (ultra-slim desktop)
(786B1)
*
*
Preloaded Applications
OS Support/QFE’s
4.00.1009 A (Intel 845) 5.00 A (Intel 865)
*
*
*
D510 d530
3.2.41.136 F 4.0.11.268 K
5.3.4.21 SP12 B2D 5.3.4.21 SP19a B2F
- 1.50.61.3 A
2.14 H 3.02 N
3.15 J 4.06A W
5.50 A2 5.50 A4
5.00 D 5.00 J
1.00 A -
2.00 A 2.10 B
1.00 B -
- 1.00 A
- 1.02 B
- 1.00 A
- 1.00 A
- 1.00 A
- 1.00 A
4.10 B -
1.00 A 2.00 A
BIOS
2.14 A
- 1.10 A
- 1.12 A
(continued)
6
D510/D530 Software Image Comparison Overview
y
Microsoft
Microsoft Windows XP Professional is preinstalled on select HP Compaq Business Desktops d530
models. HP also supports customers who install Windows XP on their own.
Windows
XP
Table 2. Windows XP Software Component Version Comparison
Software
Component
INTEL 845G GRAPHICS DRIVER *
Intel Intel 865 Graphics Driver *
nVidia Graphics Drivers *
nVidia Graphics Drivers *
ADI Integrated Digital Audio *
3COM 3C905C Drivers for Microsoft Windows
XP
*
Intel(R) PRO/100/1000 Drivers for Windows
*
XP
Broadcom 10/100/1000 Drivers for Microsoft
Windows XP
HP WLAN 802.11b WL220 *
Lucent 56K v.90 Win Modem Driver *
PSeries Drivers for HP PCMCIA Reader *
Easy Access Keyboard support software *
O2 Micro Basic Smartcard Keyboard Drivers *
HP Wireless Keyboard and Wireless Mouse
Applet
HP Wireless Mouse Applet *
Application Installer 2.00 A 2.00 B
Compaq branded Help and Support Center 2.21 E -
HP branded Help Support Center - 2.0.9.3 C
InterVideo WinDvD Software *
Adobe Acrobat Reader - 5.10 A
Safety and Comfort Guide - Desktop - 1.00 B
HP ProtectTools Embedded Securit
Roxio Easy CD Creator (upgrade package) *
OEM START PAGE for Windows-XP *
Norton AntiVirus 2002 2002 E N/A
Norton AntiVirus 2003 N/A 2003 A
Remote Diags Enabling Agent *
Diagnostics for Windows *
Altiris eXpress agent (available at:
http://h18000.www1.hp.com/im/swdeploy/prod
info.html#deployment_solution) *
Insight Management Agent *
*
*
Drivers
6.13.01.3095 B -
31.00 F -
5.12.1.3501 J 5.12.01.3570 B
5.40 A -
6.1.30 A 6.4.16.1 A
2.67 A 6.34 A
Input Device Software
8.0.0.571 C 8.0.0.678C E
Preinstalled Applications
3.2.41.136 F 4.0.11.268 K
*
5.3.4.21 SP12 B2D 5.3.4.21 SP19a B2F
2.00 A -
Preloaded Applications
2.14 H 3.02 N
3.15 J 4.06A W
5.50 A2 5.50 A4
5.00 D 5.00 J
D510 d530
- 6.13.01.3485 A
- 43.03 B
- 1.1.5.0 A
- 8.22 E
- 5.07.04 A (CMT/SFF only)
- 1.3.5.3 D
- 1.14 B
- 1.09 B
- 1.50.61.3 A (XP Pro Only)
7
D510/D530 Software Image Comparison Overview
)
)
(
)
Table 2. Windows XP Software Component Version Comparison
Software
Component
OS Support/QFE’s
Intel Chipset Support for Windows XP *
Monitor INF and ICM Files - 1.10 A
Microsoft DirectX 9.0 - 1.00 A
USB 2.0 for Windows XP *
USB 2.0 Upgrade for Windows XP
(Q810090)
WinXP OOBE DLL Fix Q308678 1.00 D - (integrated into SP1)
WinXP Recovery Console Fix 1.00 A - (integrated into SP1)
WinXP Hibernation Fix (q312372) 1.00 A - (integrated into SP1)
WinXP Remote Assistance SLP Fix
Q311889
WinXP UPNP Buffer Update Q315000 1.00 C - (integrated into SP1)
WinXP Home User Account QFE Q314412 1.00 B (XP Home only) - (integrated into SP1)
Enable 48 Bit LBA QFE Q306583 1.00 A - (integrated into SP1)
WinXP Unmountable Boot Volume Q315403 1.00 B - (integrated into SP1)
WinXP Home and Pro ICH4IDE Fix 1.00 A -
WinXP ICH5 Intelide.sys Fix *
.Net for WinXP *
NTFS Security Update *
Windows XP Unchecked Buffer in Windows - 1.00 A
Windows XP SATA Fix Q812415 *
Microsoft Windows DMA Downshift Fix *
Set Video Refresh rate - 1.1.0.20 F
Chinese Quad Byte Support *
ROM Firmware for Intel 854 G (686O2
ROM for Intel 865 (CMT/SFF
ROM for Intel 865 (ultra-slim desktop)
(786B1)
*
786B2
*
*
4.00.1009 A (Intel 845) 5.00 A (Intel 865)
BIOS
D510 d530
4.08 B -
- 1.00 A
1.00 E - (integrated into SP1)
- 1.00 A
- 1.00 A
- 1.02 2
- 1.00 B
- 1.00 A
1.00 A 2.00 A
2.14 A -
- 1.10 A
- 1.12 A
(continued)
8
D510/D530 Software Image Comparison Overview
Microsoft
Support is provided for Microsoft Windows NT Workstation 4.0 with Service Pack 6 on HP Compaq
Business Desktop d530 models for customers who require basic hardware-enabling support under this
Windows
NT
Workstation
operating system.
Hardware Functionality and Software Enhancements
Software drivers and utilities for Windows NT 4.0 include audio, video, and network drivers
4.0
IMPORTANT: Some features are not supported by Windows NT. With
✎
Windows NT, support for device swapping and USB are not built into the OS.
Proper shutdown of Windows NT prior to docking, undocking, or switching
Table 3 provides a list of tested Windows NT software drivers and utilities, which are available on the
HP software support Web site.
Table 3. Windows NT Software Components for HP Compaq Business Desktop d530
MultiBay devices is required.
Software
Component
Nvidia Graphics driver 42.49
WinNT Intel Extreme Graphics Driver 4.02.1381.3551
ADI SoundMax Audio Driver for Windows NT 4.0 4.02.00.0069
Broadcom NetExtreme 10/100/1000 Drivers 6.6.11 B
Intel Pro 10/100/1000 NIC Drivers 6.4.16.1 A
Insight Management Agent for Clients 5.00 K
Diagnostics for Windows 4.07 A
ROM Firmware for Intel 865 (CMT/SFF) (786B2) 1.10 A
ROM Firmware for Intel 865 (ultra-slim desktop) (786B1) 1.12 A
Driver Version
9
D510/D530 Software Image Comparison Overview
Microsoft
Limited Support is provided for Microsoft Windows 98 Second Edition for customers who require basic
hardware-enabling support under this operating system.
Windows
98
Hardware Functionality and Software Enhancements
Software drivers and utilities for Windows 98 include audio, video, and network drivers.
IMPORTANT: You must shut down Windows 98 prior to docking, undocking,
✎
or switching MultiBay devices.
Table 4 provides a list of tested Windows 98 software drivers and utilities.
Table 4. Windows 98 Software Components for HP Compaq Business Desktop d530
Software
Component
Win98 Intel Extreme Graphics Driver 4.13.01.3551
Nvidia Graphics driver 42.49
ADI SoundMax Audio Driver for Windows 98SE/2000/ME/XP 5.12.01.3570
Broadcom NetExtreme 10/100/1000 Drivers 6.6.11 B
Intel Pro 10/100/1000 NIC Drivers 6.4.16.1 A
HP WLAN 802.11b WL220 Configuration Utility 1.04.1
HP WLAN 802.11b WL220 Wireless Controller Driver 1.1.5.0
Insight Management Agent for Clients 5.00 K
Intel Chipset Support for Windows 98/ME/2000/XP 5.00.1012 A
Business Desktops BIOS Utility for Replicated Setup 1.00 A
Diagnostics for Windows 4.07 A
Remote Diagnostics Enabling Agent 3.02 A
HP business desktop d330 and d530 System BIOS (786B2 BIOS) 1.10 A
HP business desktop d530 ultra-slim desktop System BIOS (786B1
BIOS)
Driver Version
1.12 A
10
D510/D530 Software Image Comparison Overview
OS/2
Limited Support is provided for OS/2 for customers who require basic hardware-enabling support
under this operating system.
Hardware Functionality and Software Enhancements
Software drivers and utilities for OS/2 include audio, video, and network drivers.
IMPORTANT: OS/2 is not supported on legacy-free HP Compaq Business
✎
Desktops d530 ultra-slim desktop models.
Table 5. OS/2 Software Components for HP Compaq Business Desktop d530
Software
Delivery
Software
Component
Scitech OS/2 Graphics Driver (Available as a CD purchased option.
Not available for HP Compaq d530 ultra-slim desktop models)
ADI SoundMax Integrated Digital Audio Driver for IBM OS/2 3.1.7
Nvidia OS/2 Graphics Driver 1.3
Broadcom NetExtreme 10/100/1000 Drivers 6.6.11 B
Intel Pro 10/100/1000 NIC Drivers 6.4.16.1 A
HP business desktop d330 and d530 System BIOS (786B2 BIOS) 1.10 A
HP business desktop d530 ultra-slim desktop System BIOS (786B1
HP Support Software CD
BIOS)
Driver Version
2.1.5
1.12 A
The Support Software CD (SSCD) includes updated drivers and utilities for HP commercial notebook,
desktop, and workstation computers. Key drivers and utilities for HP computers are included on the
SSCD. The user interface is in English, French, Italian, German, Spanish, and Japanese. The SSCD is
updated regularly and is available either through an annual subscription or as a one-time purchase.
Subscriptions can be purchased through customer support or from an authorized dealer.
HP Worldwide Web Site and Download Facility
Individual drivers and utilities can be downloaded, in the form of SoftPaqs, from the HP Download
Facility or from the Web site at http://h18000.www1.hp.com/support/files/
ftp://ftp.compaq.com/pub/softpaq/
(if you already know the SoftPaq number you need). SoftPaqs
provide a distribution method for driver and ROM updates and product software enhancements. For
regional Web sites or additional support, visit http://www.hp.com/support
bootable diskettes can be distributed conveniently and electronically through diskettes or the Web.
or
. Multiple files and
Restore Plus!
The Restore Plus! CD Kit is shipped with each HP Compaq Business Desktop d530 model. This CD
provides a complete, easy-to-use restore solution for preinstalled operating systems. The preinstalled
operating system and HP software enhancements are provided in the kit. This complete restore solution
allows customers to reinstall or refresh the operating system and preinstalled software. The kit consists
of two components. The OS CD contains the preinstalled operating system. The Restore Plus! CD
provides drivers, utilities, and applications that are preinstalled on the computer.
11
D510/D530 Software Image Comparison Overview
Microsoft, Windows, and Windows NT are US registered trademarks of Microsoft Corporation. Intel is a US registered
Copyright
and
Trademarks
trademark of Intel Corporation. Adobe and Acrobat are trademarks of Adobe Systems Incorporated.
The information in this document is subject to change without notice.
© 2003 Hewlett-Packard Development Company, L.P.
07/2003
Publication Number 347248-001
12
Loading...
