hp L1510 D5062 15-inch LCD Monitor

(15-inch Viewable Image)

User's Guide

Notice

The information contained in the documents accompanying this product is subject to change without notice.

Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

Hewlett-Packard assumes no responsibility for the use or reliability of its software on equipment that is not furnished by Hewlett-Packard.

These documents contain proprietary information that is protected by copyright. All rights are reserved. No part of these documents may be photocopied, reproduced, or translated to another language without the prior written consent of Hewlett-Packard Company.

English

HP L1510 15” LCD Monitor

Important Safety Instructions

WARNING

Working in Comfort

CAUTION The lightning flash with arrowhead symbol, situated within an

For your safety always connect equipment to a grounded wall outlet. Always use a power cord with a properly grounded plug, such as the one provided with the equipment, or one in compliance with your national safety standards. This equipment can be disconnected from the power by removing the power cord from the power outlet. This means the equipment must be located close to an easily accessible power outlet.

To avoid electrical shock, do not open the monitor's cover. There are no user-serviceable parts inside. Only qualified service personnel should service these parts.

Make sure your PC is powered off before connecting or disconnecting a display peripheral.

Thank you for selecting HP monitor equipment. To optimize your comfort and productivity, it's important that you set up

your work area correctly and use your HP equipment properly. With that in mind, wehave developed some setup and use recommendations for you to follow based on established ergonomic principles.

You can consult the online version of Working in Comfort preloaded on the hard disk of HP computers, or visit HP's Working in Comfort web site at: http://www.hp.com/ergo/

equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" which may be of sufficient magnitude to constitute a risk of electric shock.

WARNING

The exclamation mark within an equilateral triangle is intended to alert the user to the presence of important operating and servicing instructions in the literature accompanying the appliance.

Before you connect any cables or install your HP monitor, refer to the above safety instructions. Refer also to the user’s manual that accompanies your PC and the video adapter to ensure this equipment is correctly installed.

2 EnglishEnglish

HP L1510 15” LCD Monitor

What Your New Monitor Offers

Your HP monitor is an LCD 15-inch, high resolution, multi-synchronous color monitor. Multi-synchronous means that the monitor supports a range of video modes. It is optimized for use with all Hewlett-Packard computers.

Your HP color monitor has the following features:

•

A 15-inch Thin Film Transistor (TFT) liquid crystal display.

• Support of video modes up to 1024 x 768 at a 75 Hz refresh rate.

Auto-configuration of display position, clock and phase.

•

Integrated 2 x 8W PMPO speaker plus microphone.

•

2 upstream (PC to monitor), 2 downstream (microphone and headphone connector)

• An On-Screen Display (OSD) allows you to adjust all settings with

on-screen menus.

• A power management system (VESA

suitably equipped HP computers to automatically reduce the power consumption of the monitor. This system complies with the Energy Star Computers Program initiated by the US EPA2 specification for energy efficient monitors. As an Energy Star Partner, Hewlett-Packard has determined that this product meets the Energy Star guidelines for energy efficiency.

• Plug and Play capability (compliant with VESA DDC1, DDC2B

standards) that enables the monitor to identify itself to suitably equipped HP computers.

• Your HP monitor complies with TCO 99 requirements.

• Your monitor complies with MPRII guidelines for upper limits of

electrical and electrostatic emissions, from the Swedish National Board of Measurement and Testing.

Slot for security lock.

•

standard) controlled from

1.VESA is the Video Electronics Standards Association.

2.The US EPA is the United States Environmental Protection Agency.

3.ENERGY STAR is a US registered service mark of the US EPA.

EnglishEnglish 3

HP L1510 15” LCD Monitor

Unpacking Your Monitor

Check for the following items. If they are missing or damaged, consult your place of purchase immediately.

•

1 LCD

1 power cord and adapter

•

• 2 audio cables

• 1 video cable

• 1 quick set-up card

• 1 warranty booklet

• 1 CD-ROM

Setting Up Your Monitor

Where to Place the Monitor

Place your monitor on a flat sturdy surface. Ensure the operating site is free from excessive heat and moisture.

WARNING

Before you connect any cables, or install your HP monitor, refer to the safety instructions at the beginning of this manual. Refer also to the user’s manual that accompanies your PC and video adapter to ensure this equipment is correctly installed.

4 EnglishEnglish

e-pc dock

HP L1510 15” LCD Monitor

Setting Up Your Monitor

Using an e-pc with your monitor

If you are using an e-pc with your monitor, follow these instructions for setting it up:

1 Clip the e-pc dock to the rear of the monitor stand. 2 Lower the e-pc into position on the e-pc dock.

Ensure that the catches on the back of the e-pc fit properly into the grooves on the e-pc dock.

3 Connect all the cables you require to the rear of the e-pc, taking

care to route them properly under the e-pc dock.

4 Attach the port control system by fitting its tabs into the slots

provided at the rear of the e-pc.

EnglishEnglish 5

HP L1510 15” LCD Monitor

Setting Up Your Monitor

Connecting the Cables

This monitor is equipped with an auto-sensing power supply for voltage ranges 100 ~ 240V AC, 50 ~ 60 Hz. Only use with the supplied adapter.

audio connectors

video connector

adapter output

video cable

power source

power cord

1 Make sure the system power is turned off. 2 Plug the signal cable into the signal connector at the rear of the

PC.

3 Plug the adapter output cable into the jack at the rear of the

monitor and the power cord to the adapter.

4 Plug the video cable into the video connector at the rear of the

monitor. Secure the cable by tightening the thumb screws on the video connector.

5 Connect the audio cables to the connectors according to the

following color definitions:

Red + Green end Red + Blue end

➔ PC

➔ rear of LCD monitor

6 Connect the power cord to the power source. 7 Turn on the computer and the monitor.

6 EnglishEnglish

HP L1510 15” LCD Monitor

Setting Up Your Monitor

Changing the Monitor Viewing Position

Your monitor can be rotated to either a landscape or portrait position.

1 Tilt the lower part of the monitor upwards. 2 Rotate the monitor clockwise until the monitor controls are on the

left side.

3 Firmly push the lower part of the monitor downwards to secure it

in the new position.

To rotate your display, you need to install specific software.

EnglishEnglish 7

HP L1510 15” LCD Monitor

How To Install The Drivers

In order to take advantage of the Plug & Play functionality of your Windows 95/98/2000 operating system, HP Monitors come with a driver.

To install this driver:

Windows 95 and 98 Users

Windows 2000 Users only

1 Click on Start, select Settings, then click Control Panel. 2 Double click on Display.

Click on the Settings tab.

Click on Advanced Properties or Advanced... and select the Monitor tab.

4 5 Click on Change... to select the model of the HP Monitor you are

using.

6 Click on Have Disk... 7 Click on Browse... to find the D5062A.INF file on your CD-ROM

under the

8 Select your monitor type from the Models box and click on OK to

install the selected monitor.

1 Click on Start, select Settings, then click Control Panel. 2 Double click on Display. 3 Click on the Settings tab. 4 Click on Advanced Properties or Advanced... and select the Monitor tab. 5 Click on Properties. 6 Click on the Driver tab. 7 Click on Update Driver... and click on Next. 8 Select the Recommended option and click on Next.

Check the Specify a Location box.

Find and open the

\Drivers directory and click on OK.

11 Click on Next to install the selected monitor.

\Drivers directory and click on OK.

D5062A.INF

file on your CD-ROM under the

8 EnglishEnglish

HP L1510 15” LCD Monitor

How To Install The Drivers

Your operating system and your HP Monitor are now set up to work in optimum conditions.

If the installation procedure of your monitor driver on your Windows 95/98/2000 version is different or you need more detailed installation information, please refer to Windows 95/98/2000 user's manual.

To download the latest version, visit our HP Monitors Support web site at:

http://www.hp.com/go/monitorsupport

EnglishEnglish 9

HP L1510 15” LCD Monitor

Adjusting Your Monitor

A Look at the Control Panel

➄

There are 5 buttons which perform the following operations:

➀

Auto Adjustment button: automatically adjusts the main settings.

➁

Validation (Enter Sub-Menu) button: acts as an enter button, selects sub-menus.

Volume Control/Select and Adjustment buttons:

➂ ➃

mute and unmute the speaker when pressed simultaneously.

Menu button.

➄

➀

➁

➂

➃

When to Adjust the Monitor

When the monitor is installed for the first time

•

If the resolution or frequency has been changed

•

• If the graphic card has been changed

• If the monitor is connected to a different computer

• After using the Recall function, (refer to “Miscellaneous” on page

20).

NOTE It is recommended that you select a video mode of 1024 x 768 at 60Hz

on your computer for optimum performance.

10 EnglishEnglish
