HP D2827A

HP 51

15-inch Color Monitor

13.9-inch Viewable Image

User’s Guide

15-Zoll-Farbbildschirme

13.9 Zoll Bildanzeige

Benutzerhandbuch

Moniteurs couleur 15 pouces

Affichage 13,9 pouces

Guide de l’utilisateur

Pantallas de color de 15 pulgadas

13.9 pulgadas de imagen visualizada

Manual del Usuario Léase esto primero

Video a colori da 15 pollici

13.9 effetivi per l’immagine

Manuale utente

Monitor Colorido de 15 polegadas

Imagem Visível de 13,9 polegadas

Guia do Usuário

Notice

The information contained in this document is subject to change without notice. Hewlett-Packard makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material. Hewlett-Packard assumes no responsibility for the use or reliability of its software on equipment that is not furnished by HewlettPackard. This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of Hewlett-Packard Company.

Hinweis

Inhaltliche Änderungen vorbehalten. Hewlett-Packard übernimmt keine Garantie welcher Art auch immer für diese Ausrüstung, einschließlich der (doch nicht begrenzt auf die) Qualitätsgarantie und die Garantie bezüglich Eignung für einen bestimmten Zweck. Hewlett-Packard haftet nicht für in dieser Dokumentation enthaltene Fehler oder für unbeabsichtigte oder indirekte Schäden in Verbindung mit der Lieferung, der Leistung oder der Benutzung der Ausrüstung. Hewlett-Packard übernimmt keine Haftung fur den Betrieb oder die Zuverlässigkeit seiner Software, wenn diese auf Hardware benutzt wird, die nicht von Hewlett-Packard geliefert wurde. Dieses Dokument enthalt proprietäre Informationen, die durch das Copyright geschützt sind. Alle Rechte vorbehalten. Dieses Dokument darf ohne vorherige schriftliche Genehmigung der Hewlett-Packard Company weder ganz noch teilweise fotokopiert, reproduziert oder übersetzt werden.

Avertissement

Les informations contenues dans ce document peuvent être modifiées sans préavis. Hewlett-Packard ne donne aucune garantie de quelque sorte que ce soit concernant, sans que ce soit limitatif, les garanties implicites de qualité commerciale de ce matériel, ou la bonne adaptation de celui-ci à un usage particulier. Hewlett-Packard n’est pas responsable des erreurs pouvant apparaître dans ce manuel et n’est pas non plus responsable des dommages directs ou indirects résultant de l’équipement, des performances et de l’utilisation de ce matériel. Hewlett-Packard ne saurait être tenu pour responsable de l’utilisation et de la fiabilité de son logiciel sur des matériels non fournis par Hewlett-Packard. Les informations contenues dans ce document sont originales et protégées par copyright. Tous droits réservés. L’acheteur s’interdit en conséquence de les photocopier, de les reproduire ou de les traduire dans toute autre langue, sauf accord préalable et écrit de Hewlett-Packard.

Aviso

La información contenida en este documento está sujeta a cambios sin previo aviso. Hewlett-Packard no ofrece ningún tipo de garantía con respecto a este material, incluyendo, pero sin limitarse a, las garantías implícitas de comerciabilidad e idoneidad para un fin determinado. Hewlett-Packard no asume responsabilidad alguna por los posibles errores contenidos o por los daños casuales o emergentes relacionados con el suministro, funcionamiento o uso de este material. Hewlett-Packard no asume responsabilidad alguna por el uso o fiabilidad de su software en equipos que no hayan sido fabricados por Hewlett-Packard. Este documento contiene información patentada, protegida por las leyes del copyright. Reservados todos los derechos. Ninguna parte de este documento puede ser fotocopiada, reproducida o traducida a otro idioma sin la autorización previa y por escrito de Hewlett-Packard Company.

Avviso

Le informazioni contenute in questo documento sono soggette a cambiamento senza preavviso. Hewlett-Packard non rilascia garanzie di alcun tipo riguardo a questo materiale, comprese le garanzie implicite di commerciabilità e di idoneità per uno scopo particolare. Hewlett-Packard non sarà ritenuta responsabile per errori contenuti in questo documento, né per danni accidentali o conseguenti alla fornitura, alle prestazioni o all’uso di questo materiale. Hewlett-Packard non si assume alcuna responsabilità riguardo all’uso o all’affidabilità del proprio software su apparecchiature di altri produttori. Questo documento contiene informazioni di proprietà protette da copyright. Tutti i diritti sono riservati. Nessuna parte di questo documento può essere fotocopiata, riprodotta o tradotta in un’altra lingua senza un precedente consenso scritto di Hewlett-Packard Company.

Nota

As informações contidas neste documento estão sujeitas a alteração sem notificação prévia. A Hewlett-Packard não oferece nenhum tipo de garantia com relação a este material, incluindo, mas não limitada às, garantias implícitas de comercialização e conveniência para um propósito específico. A Hewlett-Packard não será responsável por erros aqui contidos ou por danos incidentais ou conseqüenciais relacionados ao fornecimento, desempenho ou utilização deste material. A Hewlett-Packard não se responsabiliza pelo uso ou confiabilidade se seu software em equipamentos que não sejam fornecidos pela Hewlett-Packard. Este documento contém informações proprietárias protegidas por direitos autorais. Todos os direitos são reservados. Nenhuma parte deste documento pode ser fotocopiada, reproduzida ou traduzida para outro idioma sem o consentimento prévio por escrito da Hewlett-Packard Company.

Francais

English.................................................... Chapter 1

Deutsch .................................................. Kapitel 2

Français.................................................. Chapitre 3

Español................................................... Capítulo 4

Italiano................................................... Capitolo 5

Português ............................................... Capítulo 6

Full scan screen that gives an edge to edge image

0.28 mm dot pitch for excellent graphics

Non-glare, anti-static, screen coating

Image adjustment controls to operate on-screen display menus

Status indicator

HP D2827A 15-inch Color Monitor

13.9-inch Viewable Image

User’s Guide

On/Off switch

HP 15” Color Monitor User’s Guide

Important Safety Instructions

Before you plug in your new monitor, read these important safety instructions.

WARNING To reduce the risk of electric shock, do not remove cover(or back).

There are no user servicable parts inside. Refer servicing to qualified service personnel.

Connect the monitor only to a grounded power outlet. Use the power cord supplied with the monitor or one with a properly grounded plug. Ensure the cable meets your country’s standards for safety.

This monitor operates on all power systems, including “IT” power systems. To completely disconnect power at the monitor, remove the power cord from the power outlet. Ensure that the power outlet is easily accessible.

Make sure the power to your computer is “off” before connecting or disconnecting any monitor peripheral.

The monitor is quite heavy(the weight is shown in the technical specifications). We recommend you ask the assistance of a second person when lifting or moving it.

USA and Canada

If the power cord is not supplied with your monitor, select the proper power cord according to your national electric safety codes.

USA: use a UL Listed detachable power cord.

•

Canada: use a CSA certified detachable power cord.

•

Si le cordon secteur n’est pas livré avec votre moniteur, utiliser un cordon secteur en accord avec votre code électrique national.

USA: utiliser un cordon secteur UL Listé.

•

Canada: utiliser un cordon secteur certifié CSA.

•

2 English

HP 15” Color Monitor User’s Guide

What Your New Monitor Offers

Your HP monitor is a 15-inch (13.9-inch viewable image), high resolution, multi-synchronous color monitor. Multi-synchronous means that the monitor supports a range of video modes. It is optimized to be used with all Hewlett-Packard PCs.

Your HP color monitor has the following features:

•

A 15-inch flat square tube, with a 13.9-inch viewable image, and

0.28 mm dot pitch for excellent graphics.

•

Anti-static, non-glare screen coating to minimize reflection.

•

Support for video modes up to SVGA 800x600 at 85Hz refresh rate, giving a flicker free image and reduced eye-strain.

Support for Ultra VGA 1024x768 at 60Hz refresh rate.

•

Image adjustment using on-screen display menus. Includes color adjustment to optimize the quality of the image.

•

Monitor power management system (VESA1 standard) controlled from suitably equipped HP PCs to automatically reduce the power consumption of the monitor. Complies with the Energy Star Computers Program initiated by the US EPA

Packard has determined that this product meets the Energy Star guidelines for energy efficiency

•

Monitor Plug and Play capability (VESA DDC1/2B standard) that enables the monitor to identify itself to suitably equipped HP PCs.

•

Compliance with ISO 9241-3, ISO 9241-8 and ZH-1/618 ergonomic standards.

•

Complies with MPRII guidelines for upper limits of electrical and electrostatic emissions, from the Swedish National Board for Measurement and Testing. Your monitor also complies with the Swedish standard MPR III, level B, for electric and magnetic field emission.

As an Energy Star Partner, Hewlett

1. VESA is the Video Electronics Standards Association

2. The US EPA is the United States Environmental Protection Agency

3. ENERGY STAR is a US registered service mark of the US EPA.

English 3

HP 15” Color Monitor User’s Guide

Setting Up Your Monitor

Attaching the Tilt and Swivel Base

Your display has a tilt and swivel base. To fit and tilt the swivel base:

1 Turn the monitor on its side (never on the screen). Identify the front

of the base.

2 Locate the slots in the underside of the monitor. 3 Slide the base towards the front of the monitor until the locking tab

on the base clicks into place.

Where to Place the Monitor

Place your monitor on a flat sturdy surface.

Ensure the operating site is free from excessive heat, moisture, dust and sources of electromagnetic fields. Sources of electromagnetic fields include transformers, motors, and other monitors.

Avoid exposing the monitor to direct sunlight.

4 English

HP 15” Color Monitor User’s Guide

Setting Up Your Monitor

Connecting the Cables

CAUTION Before you connect any cables, or install your HP monitor, refer to the

safety instructions at the beginning of this manual. Refer also to the user manual which accompanies your PC and video adapter to ensure this equipment is correctly installed.

1 Make sure that your PC and monitor are switched off. 2 Connect the video cable (it has a 15-pin plug) to the video outlet on

your PC. Tighten the thumbscrews on the plug.

3 Connect the power cord to the monitor. 4 Plug the power cord into a grounded power outlet.

1 PC and Monitor OFF

Video cable

Power cords

NOTE The location of your PC’s video outlet may be different to the one shown

in the diagram. Refer to the manual that came with your PC, if necessary.

English 5

HP 15” Color Monitor User’s Guide

Using Your Monitor

The on/off switch is on the front of the monitor.

You can adjust the quality, position, size and shape of the displayed image using the controls on the front of the monitor to operate on screen menus.

Brightness

Contrast

Select Button

Status Indicator

On/Off Switch

Adjustment Controls

Menu Button

Menu 2Menu 1

Operating On Screen Menus

Pressing the MENU button activates the monitor’s on screen menus. These menus contain the monitor’s various adjustment features. You can select a feature using the adjustment feature you require.

There are two on screen menus:

SELECT

button to scroll to the

MENU 1

Pressing the menu allows you to adjust basic parameters such as quality, size and position of the displayed image.

button once activates the first on screen menu. This

MENU 2

Pressing the MENU button twice activates menu 2. This menu allows you to adjust advanced parameters such as shape and color of the displayed image.

6 English

HP 15” Color Monitor User’s Guide

Using Your Monitor

Adjusting the Quality, Size and Position of the Displayed Image

Adjustments to the quality, size and position of the displayed image can be made from menu 1. (Refer to“Operating On Screen Menus“ on page 6)

CONTRAST

To adjust the contrast, select , then use the and adjustment controls. (Contrast is the difference in brightness between the dark and light parts of the displayed image.)

BRIGHTNESS

To adjust the overall picture brightness, select then use the and

adjustment controls. (The brightness should be set so that the dark

areas of the displayed image remain black.)

NOTE You can also change the contrast and brightness of your monitor by

using the and controls respectively. Adjust the quality using the

and adjustment controls as required.

H. POSITION

To adjust the horizontal position of the displayed image, select , then use the and adjustment controls to move the image.

H. SIZE

To adjust the horizontal size of the displayed image, select , then use the and adjustment controls to resize.

V. POSITION

To adjust the vertical position of the displayed image, select , then use the and adjustment controls to move the image.

V. SIZE

To adjust the vertical size of the displayed image, select , then use the and adjustment controls to resize.

PINCUSHION

TRAPEZOID

Adjusting the Shape of the Displayed Image

Adjustments to the shape of the displayed image are performed using menu 2. (Refer to“Operating On Screen Menus“ on page 6)

To adjust the displayed image if its vertical edges appear to bow in or out, select then reshape using the and adjustment controls.

To adjust the displayed image if its vertical edges do not appear parallel, select , then use the and adjustment controls to correct the distortion.

English 7

HP 15” Color Monitor User’s Guide

Using Your Monitor

Adjusting the Color of the Displayed Image

Adjustments to the color of the displayed image can be made from menu 2 (Refer to“Operating On Screen Menus“ on page 6).

Your monitor displays a combination of red, blue, and green to show a full color image. If you want to change the proportions of red, blue and green used by your monitor you will need to change the color temperature.

To Select a Preset Color Temperature

Your monitor is shipped with two preset color temperatures: 9300K and 6550K.

COLOR TEMP.

R.GAIN

B.GAIN

DEGAUSSING

RECALL

To adjust the color temperature select COLOR TEMP then select the required setting using the and adjustment controls.

Adjusting the Color Temperature Setting

You can adjust the red and blue color temperature levels of your monitor.

To adjust the level of red in the displayed image select the and adjustment controls to adjust the color level.

To adjust the level of blue in the displayed image select B.GA I N , then use the and adjustment controls to adjust the color level.

Degaussing keeps the monitor free from unwanted magnetism that can result in color impurity. To degauss the monitor, select from menu 2, then using the adjustment control select

YES. Degaussing is

accompanied by brief instability of the displayed image and a slight humming sound. It is recommended that you degauss at least every week.

To revert to preset factory settings, select RECALL from menu 2, then using the adjustment control select

YES.

R.GAIN

, then use

8 English

HP 15” Color Monitor User’s Guide

Using Your Monitor

Setting the Amount of Displayed Information

To set the amount of displayed information, change the screen resolution of your PC. The higher the screen resolution, the more

information you can see on the screen. It is recommended that you use a resolution of 800 large amount of displayed information, and a flicker-free image.

You can make adjustments to the displayed image and they are automatically saved for the resolution you are using. For example, if you adjust your monitor when working in SVGA those settings are saved for SVGA. If you then work in VGA and change the image settings, they are saved for VGA. The next time you switch back to SVGA, your previous settings are used automatically.

To find out which resolutions are supported by your monitor, refer to “What Video Modes are Supported” on page 11. To change the screen resolution, please refer to the manual that came with your PC or your operating system documentation, if necessary.

600 at 85Hz. This gives easy-to-read characters, a

Your monitor has a Plug and Play capability (VESA DDC1/2B standard) that enables it to identify itself to suitably equipped HP PCs. This will automatically give you the best refresh rate for the resolution that you have set. Also, by using the appropriate software (when available), you can adjust the monitor settings directly from your PC.

Minimizing Eye Strain

To avoid screen flicker and minimize eye strain, use the highest supported image refresh rate for the chosen resolution. It is recommended that you use a resolution of 800 refresh rate. The image refresh rate is the number of times per second that the image is refreshed.

To find out which image refresh rates are supported by your monitor, refer to “What Video Modes are Supported” on page 11. To set the image refresh rate (also known as the vertical frequency), refer to the manual that came with your PC or your operating system documentation, if necessary. If your PC supports Plug and Play, it will automatically select the best refresh rate for the screen resolution you have set.

English 9

600 with an 85Hz

HP 15” Color Monitor User’s Guide

Using Your Monitor

Minimizing Energy Consumption

If your PC supports VESA monitor power management (available on many HP PCs), you can minimize the power consumed by the monitor. There are two power saving modes:

Suspend mode1 (uses less than 15 W). In this mode, the monitor’s

•

front panel indicator light is blinking green and amber.

Sleep mode2 (uses less than 5W). In this mode, the monitor’s front

•

panel indicator light is amber.

To set these power saving modes, refer to the manual that came with your PC. If your screen is not displaying an image, check the front panel indicator light first — your monitor may be in a power saving mode.

1. Suspend mode is activated when horizontal sync is cut by the video controller.

2. Sleep mode is activated when both vertical and horizontal sync are cut by the video controller, this may also be referred to as Off MODE.

10 English

HP 15” Color Monitor User’s Guide

What Video Modes are Supported

Your monitor supports the video modes shown in the table below.

Screen Resolution Image Refresh Rate Video Solution

640×400 70 Hz VGA 640×480 60 Hz VGA 640×480 75 Hz Ergonomic VGA 640×480 85 Hz Ergonomic VGA 800×600 60 Hz Super VGA 800×600 75 Hz Ergonomic Super VGA 800×600 85 Hz Ergonomic Super VGA

1024×768 60 Hz Ultra VGA 1024

CAUTION Selecting a video mode on your PC with a screen resolution/image

refresh rate combination higher than 1024

768 at 60Hz can damage

your monitor.

Selecting a video mode not supported by your monitor will cause your monitor screen to blank.

English 11

PICTURE TUBE

INPUT SIGNAL

INTERFACE

HP 15” Color Monitor User’s Guide

Technical Specifications

Size 15-inch flat screen/ 13.9-inch viewable image Phosphorous Red, Green, Blue P22 (medium short persistence) Dot pitch 0.28 mm Face Plate Anti-glare, anti-static, screen coating Video 0.7 Vp p analog RGB Synchronization TTL level separate synchronisation (negative/positive) Input Connector 15-pin mini D-SUB

SCANNING FREQUENCY

WARM-UP TIME

PIXEL CLOCK

DISPLAY SIZE

POWER SOURCE

OPERATING ENVIRONMENT

CABINET DIMENSIONS

WEIGHT

TILT/SWIVEL STAND

Horizontal 31 to 54kHz Vertical 50 to 120 Hz 30 minutes to reach optimum performance level

65 MHz

283

211mm±3mm

AC 90 to 264 V, 47 to 63 Hz, 70W (Nominal), less than 15 W in Suspend mode, less than 5Win Sleep mode,

Temperature 0 °C to 40 °C (operating)

- 25°C to +70 °C (storage) Humidity 10% RH through 80% RH (without condensation) 398(H) × 368(W) × 382(D) mm (including pedestal)

12,5 kg (27lbs)

Tilt Angle - 5° to +10 Swivel Angle

±60°

12 English

HP 15” Color Monitor User’s Guide

Care and Cleaning

Do not place anything on top of the monitor. Doing so may block the monitor vents and cause damage to the monitor due to overheating.

Do not let liquid get on or into the monitor.

To maximize screen life and prevent damage to the picture tube (such as burned phosphor due to leaving the same image on the screen for a long time), it is recommended that you:

Use the monitor power management system (on HP PCs) or a screen

•

saver program.

Avoid setting contrast and brightness to their maximum levels for

•

prolonged periods.

If you do not have a power management system or a screen saver

•

program, switch the monitor off or reduce the brightness and contrast to minimum levels when the monitor is not in use.

Your monitor has an anti-glare, anti-static screen coating. To prevent damage to the monitor screen’s coating, use a regular household glass cleaner when cleaning the screen. To clean the screen:

1 Switch the monitor off and remove the power plug (pull the plug, not

the cable).

2 Wet a soft cotton cloth with the cleaning solution and gently wipe the

screen. Do not spray cleaner onto the screen because the cleaner may drip inside the monitor.

3 Dry with a clean, soft cotton cloth.

Do not use cleaning solutions containing fluoride, acids, or alkalis.

English 13

HP 15” Color Monitor User’s Guide

Environmental Information

HP has a strong commitment toward the environment. Your HP monitor has been designed to respect the environment as much as possible.

HP can also take back your old monitor for recycling when it reaches the end of its useful life.

HP has a product take-back program in several countries. The collected equipment is sent to of HP’s recycling facilities in Europe or the USA. As many parts as possible are reused. The remainder is recycled. Special care is taken for batteries and other potentially toxic substances, which are reduced to non-harmful components through a special chemical process. If you require more details about HP’s product take-back program, contact your dealer or your nearest HP Sales Office.

The cathode ray tube used in this monitor does not contain cadmium.

14 English

HP 15” Color Monitor User’s Guide

Hardware Warranty

This is your HP Monitor Hardware Warranty Statement. Warranty terms may be different in your country. If so, your Authorized HP Dealer or Hewlett-Packard Sales and Service Office can give you details.

For Consumer Transactions in Australia and New Zealand: The warranty terms contained in this statement, except to the extent lawfully permitted, do not exclude, restrict or modify and are in addition to the mandatory statutory rights applicable to the sale of this product to you.

Limited Monitor Hardware Warranty

Model Warranty Period Service provided

Model D2827A 1 year On-site service

Hewlett-Packard (HP) warrants this monitor hardware product against defects in materials and workmanship for the applicable warranty period stated above, commencing from the date of purchase by you, the original end-user customer. If you return this monitor hardware product with a defect as defined above, during the warranty period, to an HP-authorized reseller or service center, HP will either, at its option, repair or replace the defective product with a new or equivalent-to-new unit of the same or equivalent model. Should HP be unable to repair or replace the product within a reasonable amount of time, your alternate exclusive remedy shall be a refund of the purchase price upon return of the product.

If you purchased this monitor hardware product for use with an HP personal computer (Vectra, Brio or Kayak), please refer to the terms and conditions of the HP Hardware Warranty statement provided with your HP personal computer (Vectra, Brio or Kayak), including limitations, your responsibilities and method for obtaining warranty service.

English 15

HP 15” Color Monitor User’s Guide

Hardware Warranty

Limitation of Warranty The above warranty shall not apply to defects resulting from: misuse

(including “burned” screens); unauthorized modification; operation or storage outside the environmental specifications for this monitor product; in-transit damage; improper maintenance; or defects resulting from use of non-HP software, accessories, media, supplies, consumables, or such items not designed for use with this product.

HP MAKES NO OTHER EXPRESS WARRANTY, WHETHER WRITTEN OR ORAL, WITH RESPECT TO THIS PRODUCT. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS LIMITED TO THE DURATION OF THE EXPRESS WARRANTY SET FORTH ABOVE.

Some states or provinces do not allow limitations on warranty, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may also have other rights which vary from state to state, or province to province.

Limitation of Liability and Remedies

THE REMEDIES PROVIDED ABOVE ARE YOUR SOLE AND EXCLUSIVE REMEDIES. IN NO EVENT SHALL HP BE LIABLE FOR ANY OTHER DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER BASED ON WARRANTY, CONTRACT, TORT, OR ANY OTHER LEGAL THEORY.

The foregoing limitation of liability shall not apply in the event that any HP product sold hereunder is determined by a court of competent jurisdiction to be defective and to have directly caused bodily injury, death, or property damage; provided, that in no event shall HP's liability for property damage exceed the greater of $50,000 or the purchase price of the specific product that caused such damage.

Some states or provinces do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

16 English

Regulatory Information

DECLARATION OF CONFORMITY

according to ISO/IEC Guide 22 and EN 45014

Manufacturer’s Name: HEWLETT-PACKARD

HP 15” Color Monitor User’s Guide

Regulatory Information

Manufacturer’s Address:

declares, that the product:

Product Name:

Model Number:

conforms to the following product specifications:

SAF ET Y

EMC

Supplementary information: Voltage Directive 73/23/EEC, both amended by the Directive 93/68/EEC, and carries the CE marking accordingly.

the product herewith complies with the requirements of the EMC Directive 89/336/EEC and the Low

5, Avenue Raymond Chanas 38320 EYBENS FRANCE

HP 51 15-inch Color Monitor D2827A

International: IEC 60950:1991 + A1 + A2 +A3 +A4 Europe: EN 60950:1992 + A1 + A2+A3+A4

CISPR 22:1993+A1 / EN 55022:1994 - Class B EN 50082-1:1992

IEC 801-2:1992 / prEN 55024-2:1992 - 4kV CD, 8 kV AD IEC 801-3:1984/prEN55024-3:1991 - 3V/m IEC 801-4:1988 / prEN 55024-4:1992 - 0.5 kV Signal Lines 1 kV Power Lines

IEC 555-2:1982 + A1:1985 / EN 60555-2:1987 IEC 1000-3-3:1994 / EN 61000-3-3:1995

Grenoble, September1998 Quality Manager

Jean Marc JULIA

English 17

HP 15” Color Monitor User’s Guide

Regulatory Information

Notice for the USA: FCC Statement

Federal Communications Commission (FCC) Radio

Frequency Interference Statement (USA Only)

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protections against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try one of more of the following measures:

Relocate the radio or television antenna.

•

Move the computer away from the radio or television.

•

Plug the computer into a different electrical outlet, so that the computer and the radio or television are on

•

separate electrical circuits.

Make sure that all your peripheral devices are also FCC Class B certified.

•

Make sure you use only shielded cables to connect peripheral devices to your computer.

•

Consult your computer dealer, Hewlett-Packard, or an experienced radio/television technician for help.

•

WARNING Hewlett-Packard’s system certification tests were conducted with HP-supported peripheral devices and HP

shielded cables, such as those you received with your system. Cables used with this computer must be properly shielded to comply with the requirements of the FCC.

Changes or modifications not expressly approved by Hewlett-Packard could void the user’s authority to operate the equipment.

X-Ray Radiation Notice

When operating, this product emits x-rays; however, it is well shielded and meets the safety and health requirements of various countries, such as the Radiation Act of Germany and the Radiation Control for Health and Safety Act of the United States.

Radiation emitted by this product is less than 0.1 mR/hr (1uSv/hr) at a distance of 10 centimeters from the surface of the cathode ray tube. The x-ray radiation primarily depends on the characteristics of the cathode ray tube and its associated low voltage and high voltage circuitry. Internal controls have been adjusted to ensure safe operation. Only qualified personnel should perform any internal adjustments as specified in the service manual for this product.

Replace the cathode ray tube with an identical CRT only.

General Notice

The HP D2827A 15-inch Color Monitors have been tested according to MPR 1990:8 for Emission properties and meets the guidelines as given by MPR 1990:10 (2.01 - 2.04)

18 English
