HP COLOR LASERJET ENTERPRISE CP4520 PRINTER SERIES
CP4525n • CP4525dn • CP4525xh
This network color laser printer is ideal for large workgroups
that need to print high-impact color documents and protect their
confidential print jobs.
• Experience powerful color printing with HP’s high-performance
leader. Fast print speeds, robust paper handling, and simplified
controls keep your business productive.
• Produce superior documents with consistent color print quality and
crisp detail every time you print.
• Protect your sensitive data with advanced on-board security and
support for optional authentication solutions.
Top-of-the-line performance
Boost your printing productivity with high-performance
speeds up to 42 pages per minute (ppm) letter—ideal for
large workgroups. Get a first page out in as fast as 9.5
seconds. Instant-on Technology enables print jobs to
begin quickly from low-power mode and provides up to
50 percent energy savings over competitive laser
products.
1
Advanced on-board security
Secure your business-critical data with the HP Secure
Hard Disk,
network with IPv6, and implement sophisticated network
access control with 802.1x authentication and IPsec
encryption. Keep sensitive material private when you
retrieve stored confidential print jobs using the control
panel.
4
expand the number of IP addresses on your
Improve efficiency and simplify printing for multiple users
and print jobs. HP Advanced Auto Media Sensing
automatically adjusts settings according to paper type.
Conveniently connect an optional security card reader or
other authentication device with the Hi-Speed USB 2.0
port.
An intuitive, 4-line color control panel with autonavigational help makes printer operation easy and
straightforward.
With twenty-five years of continuous innovation and
reliable, professional-quality printing, HP LaserJet
HP Color LaserJet Enterprise CP4520 Printer series
remains the brand businesses count on.
Exceptional color output
Make a statement with high-impact color documents.
With HP ImageREt 3600 and up to 1200 x 1200 dpi,
you’ll get superior results: smooth color transitions, crisp
Reduce energy use up to 50 percent with Instant-on
Technology
• Reduce paper use by up to 50 percent using automatic
two-sided printing (CP4525dn and CP4525xh)
• Free, convenient cartridge recycling in over 49 countries
1
text, and sharp images for all of your office documents
and professional marketing materials.
The improved HP Universal Print Driver with
HP EasyColor simplifies color printing and improves the
rendering of images for consistent print quality.
Manage your color printing costs using HP color access
controls.
3
Assign color access by user, time of day, or
2
www.hp.com/ecosolutions
(CP4525dn and CP4525xh models)
application, or shut color capability down completely
until it’s needed for special projects. This ensures that the
people who truly need to leverage the power of color—
such as your marketing department—can, while others
automatically default to black-and-white printing.
1
Energy savings based on HP testing using the ENERGY STAR program’s Typical Energy Consumption (TEC) method on HP LaserJet products with Instant-on Technology
vs. top competitive models as of March 2009.
2
HP EasyColor is available on HP Universal Print Drivers—available for free download at www.hp.com/go/upd.
3
Color access control capabilities vary from device to device.
4
The HP Secure Hard Disk is standard on the CP4525xh model and optional for the CP4525n and CP4525dn models.
HP COLOR LASERJET ENTERPRISE CP4520 PRINTER SERIES
w
1 Control panel with four-line
color display
2 500-sheet output bin
3 Front door allows convenient
access to four, all-in-one
HP print cartridges
4 Built-in automatic two-sided
printing
5 Four 500-sheet input trays for a
2,100-sheet total input capacity
6 100-sheet multipurpose tray 1
handles heavy custom media
up to 58 lb bond
7 Hi-Speed USB 2.0 port
8 HP Jetdirect Gigabit Ethernet
embedded print server
9 HP Secure High Performance
embedded hard disk
10 1 GB (1024 MB) total memory
and an 800 MHz processor
quickly handle complex print
jobs
11 One open EIO slot
12 Access port for optional
Kensington-style lock
2
3
4
5
Front vie
HP Color LaserJet Enterprise CP4525xh Printer shown
1
6
7
8
9
10
11
12
I/O panel close-up
Series at a glance
CP4525n Printer CP4525dn Printer CP4525xh Printer
Part number CC493A CC494A CC495A
100-sheet multipurpose tray 1 √ √ √
500-sheet tray 2 √ √ √
3 x 500-sheet Paper Feeder and Stand Optional Optional √
500-sheet Paper Feeder and Cabinet Optional Optional
Postcard Media Insert Tray Optional Optional Optional
Two-sided printing Manual Automatic Automatic
HP Jetdirect Gigabit Ethernet embedded print server √ √ √
Memory
HP Secure High Performance Hard Disk Optional Optional √
ENERGY STAR qualified √ √
512 MB, expandable to
1 GB (1024 MB)
512 MB, expandable to
1 GB (1024 MB)
1 GB (1024 MB)
High-volume color for the enterprise
Not only does this printer offer ultra-fast print speeds and a
design that is easy for multiple users to operate and
maintain, your workgroup will gain efficiencies with a host
of features designed specifically for high-volume enterprise
environments:
• Cost-effective office printing with the optional
high-capacity black toner cartridge
5
and HP color
access controls
• An optional HP 500-sheet Paper Feeder and Cabinet
for an input capacity of up to 1,100 sheets and
convenient paper storage, or an optional HP
3 x 500-sheet Paper Feeder for an input capacity of up
to 2,100 sheets (standard on the CP4525xh model)
Get the most out of your printer with HP accessories, supplies, and services.
• Secure storage for sensitive materials with the
HP Secure High Performance Hard Disk
• An optional HP Postcard Media Insert Tray for
efficiently printing stacks of postcards for office mailings
or marketing campaigns
• Streamlined fleet management with HP Web Jetadmin:
configure optimal settings across your entire printer
fleet, access device information from anywhere on the
network, receive instant e-mail notifications detailing
device or supply issues, and fix problems before they
impact users
6
HP 500-sheet Paper Feeder and Cabinet
Spend less time loading paper with a
total input capacity of up to 1,100 sheets.
The 500-sheet feeder supports a range of
paper types and sizes, and you can use
the cabinet for convenient paper storage.
HP 3 x 500-sheet Paper Feeder and Stand
CC422A
Increase office productivity with a total
input capacity of up to 2,100 sheets.
With support for a range of paper types
and sizes, you can use each tray for a
different paper type to minimize
interruptions.
CC423A
HP Services
Because downtime can have serious business consequences,
HP provides high-quality services that extend beyond the standard
warranty and help you avoid unbudgeted repair costs. Benefits include
reduced printing and infrastructure costs, maximized uptime, expert
technical phone support, and predictable, consistent service delivery—
even across multiple locations.
Recommended services:
• Installation Service with Network Configuration: expert assembly of
HP accessories, hardware verification, network configuration, and
basic administrator familiarization
• Same Day Onsite Service: an HP technician or authorized service
provider arrives at your site within four hours after the service call is
received, if this time falls within the coverage window
• Next Day Onsite Service: a technician delivers onsite service the next
business day after the service call is received
These services and additional coverage options can be purchased as:
• HP Care Pack Services: easy-to-buy, easy-to-use support packages
• HP Contractual Services: a comprehensive portfolio for maintaining
maximum IT availability
HP also offers HP Managed Print Services: scalable assessment,
procurement, implementation, management, maintenance, support, and
workflow services.
For more information, visit www.hp.com/go/printservices.
HP Color LaserJet Print Cartridges with HP ColorSphere Toner7
Black Print Cartridge (8,500 pages)
Black Print Cartridge, high capacity (17,000 pages)
Cyan Print Cartridge (11,000 pages)
Yellow Print Cartridge (11,000 pages)
Magenta Print Cartridge (11,000 pages)
Supplies
Toner Collection Unit (36,000 pages)8
110 Volt Fuser Kit
220 Volt Fuser Kit
Transfer Kit
Accessories
HP 500-sheet Paper Feeder and Cabinet
HP 3 x 500-sheet Paper Feeder and Stand
HP Postcard Media Insert Tray
Memory/storage
HP 256 MB DDR2 200-pin x32 DIMM
HP 512 MB DDR2 200-pin x32 DIMM
HP Secure High Performance EIO Hard Disk
Connectivity
HP Jetdirect 620n Fast Ethernet Print Server
HP Jetdirect 635n IPv6/IPsec Print Server
HP Jetdirect 690n IPv6/IPsec 802.11g Wireless Print Server
HP Jetdirect ew2500 802.11b/g Wireless Print Server
HP 1284B Parallel Card
HP Care Pack Services
HP 3-year Next Business Day Onsite Service
HP Network Installation Service with Network Setup
HP 3-year Same Day Onsite Service (9x5)
HP 3-year Same Day Onsite Service (13x5)
HP 4-year Next Business Day Onsite Service
HP 5-year Same Day Onsite Service
Paper
www.hp.com/go/paper
Software
HP Web Jetadmin: www.hp.com/go/webjetadmin
HP Easy Printer Care: www.hp.com/go/easyprintercare
HP Universal Print Driver: www.hp.com/go/upd
HP Install Network Printer Wizard: www.hp.com/go/inpw_sw
Solutions
HP BarCodes and More USB Solution
HP Scalable BarCode Set USB Solution
HP BarCode Printing USB Solution
HP MICR USB Solution
HP LaserJet Fonts and IPDS Emulation available at
www.hp.com/go/laserjetfonts
For more solutions information, please visit www.hp.com/go/gsc
, 1-800-477-5010
CE260A
CE260X
CE261A
CE262A
CE263A
CE265A
CE246A
CE247A
CE249A
CC422A
CC423A
CC497A
CE466A
CE467A
J8019A
J7934G
J7961G
J8007G
J8021A
J7972G
US186E
H2872E
UT443E
UT442E
US188E
US189E
HG281US
HG282UT
HG271US
HG283US
5
Not included. Please purchase separately.
6
The HP Secure Hard Disk is standard on the CP4525xh model and optional for the CP4525n and CP4525dn models.
7
Average continuous composite cyan/yellow/magenta cartridge yield 11,000 standard pages and average continuous black cartridge yield 8,500 standard pages (CE260A) and average continuous black cartridge high-capacity yield 17,000 standard
pages (CE260X). Declared yield value in accordance with ISO/IEC 19798. Actual yields vary considerably based on images printed and other factors. For details see www.hp.com/go/learnaboutsupplies
8
Toner Collection Unit capacity approximately 36,000 pages (individual experience may vary considerably based on images printed, media used, environmental conditions and other factors).
.
HP COLOR LASERJET ENTERPRISE CP4520 PRINTER SERIES
Technical specifications
Print speed (color and black-only)9
First page out
Print resolution
Control panel
Processor
Memory
Hard disk
Durability ratings
Paper
Input 100-sheet multipurpose tray, 500-sheet tray
Output 500-sheet output bin
Two-sided printing Manual (driver support provided) Automatic
Sizes Multipurpose tray: 3 x 5 in to 8.5 x 14 in; letter, legal, 5 x 8 in, 8.5 x 13 in, statement, executive, postcard, dpostcard, 3 x 5 in, 4 x 6 in;
Weights Multipurpose tray: 16 to 58 lb
Types Paper (plain, light, bond, recycled, mid-weight, heavy, mid-weight glossy, heavy glossy, extra heavy, extra heavy glossy, cardstock, card glossy, preprinted, prepunched,
Interfaces
Network capabilities
Languages
Fonts
Operating systems
Network protocols
Security
Dimensions (width x depth x height)
Weight (without print cartridge)
What’s in the box
Also includes Automatic two-sided printing Automatic two-sided printing, 3 x 500-sheet feeder with
Warranty
Environmental ranges
Recommended temperature 59 to 80.6º F ENERGY STAR qualified models, see www.hp.com/go/energystar.
Storage temperature 32 to 95º F
Recommended relative humidity 30 to 70%
Storage relative humidity 10 to 90%
Altitude 0 to 9842 ft
Acoustics
Sound power emissions13 Active: 6.9 B(A); Ready: 5.0 B(A)
Sound pressure (bystander position) Idle: 35 dB; Operating: 54 dB
Power specifications
Power supply required Input voltage 110 to 127 VAC (±10%), 50/60 Hz
Power consumption
9
Exact speed varies depending on the system configuration, software application, driver, and document complexity.
10
HP recommends that the number of printed pages per month be within the stated range for optimum device performance, based on factors including supplies replacement intervals and device life over an extended warranty period.
11
Duty cycle is defined as the maximum number of pages per month of imaged output. This value provides a comparison of product robustness in relation to other HP LaserJet or HP Color LaserJet devices, and enables appropriate deployment of printers
and MFPs to satisfy the demands of connected individuals or groups.
12
Average continuous composite cyan/yellow/magenta cartridge yield 11,000 standard pages and average continuous black cartridge yield 8,500 standard pages. Declared yield value in accordance with ISO/IEC 19798. Actual yields vary
considerably based on images printed and other factors. For details see www.hp.com/go/learnaboutsupplies
13
Declared per ISO 9296 and 7729; values are subject to change. Configuration tested: HP Color LaserJet CP4525dn, printing at 40 ppm on A4 paper.
14
Values subject to change. Power numbers are the highest values measured using all standard voltages.
15
HP SureSupply alerts you when your print cartridge is running low and helps you purchase online or locally through HP or a participating retailer. Only available with Original HP supplies; Internet access required.
14
Active: 740 watts; Standby: 72 watts;
HP Color LaserJet Enterprise CP4525n Printer
(CC493A)
HP Color LaserJet Enterprise CP4525dn Printer
(CC494A)
HP Color LaserJet Enterprise CP4525xh Printer
(CC495A)
Up to 42 ppm (letter)
As fast as 9.5 seconds from Ready (letter)
HP ImageREt 3600 technology; 1200 x 1200 dpi for fine details and line art
2.03-in LCD, 64 x 160 pixels, 4-line, color control panel display; 7 front-panel buttons (Menu, Select, Stop, Back/Exit, Help, Up arrow, Down arrow);
3 LED status lights (Attention, Data, Ready); enhanced help with animated graphics
800 MHz
512 MB, expandable to 1 GB (1024 MB) via one available 200-pin-x32 SODIMM slot 1 GB (1024 MB)
Optional via EIO slot HP Secure High Performance embedded hard disk
Recommended monthly volume: 2,500 to 10,000 pages;10 Duty cycle: up to 120,000 pages (letter)11
HP 3 x 500 sheet Paper Feeder and Stand, optional HP Postcard Media Insert Tray)
(optional HP 500-sheet Paper Feeder and Cabinet or
500-sheet input trays: 5.83 x 8.27 in to 8.5 x 14 in; letter, legal, 5 x 8 in, 8.5 x 13 in, statement, executive;
optional HP Postcard Media Insert Tray must be installed in Tray 2 for 4 x 6 in
envelopes (No. 9, No. 10, Monarch 7¾)
Automatic two-sided printing: letter, legal, executive
100-sheet multipurpose tray, 500-sheet tray,
3 x 500-sheet Paper Feeder and Stand
(optional HP Postcard Media Insert Tray)
500-sheet input trays, automatic two-sided printing: 16 to 32 lb plain paper; 28 to 58 lb glossy paper
colored, rough), color transparency, labels, letterhead, envelope, opaque film, user-defined
Hi-Speed USB 2.0 port, RJ-45 port (10/100/1000 Base-TX), EIO slot
Via HP Jetdirect 10/100/1000 Base-TX Ethernet embedded print server (standard), IPsec (standard), SNMP3, 802.1x wireless (optional), TC/IP support (optional)
HP PCL 6, HP PCL 5c, HP postscript level 3 emulation, direct PDF printing v 1.4
93 internal TrueType fonts scalable in HP PCL and HP postscript level 3 emulation
Works with Windows® 7 Home Basic, Windows 7 Home Premium, Windows 7 Professional, Windows 7 Enterprise, Windows 7 Ultimate, Windows 7 x64, Windows
Vista®, Windows Vista Premium, Windows XP® Professional, Windows XP Home, Windows Server 2003, Windows Server 2003 (32/64 bit), Windows Server 2008,
Windows XP Professional x64 (IPv6 only supported on Windows 2003, Windows XP Professional, and Windows XP Home; IPsec on IPv4 only on Windows 2003,
Windows XP Professional, and Windows XP Home), Novell NetWare 5.1 or higher, Mac OS X v 10.3 or higher, SAP, Linux (see www.hplip.net), Red Hat Linux 7.x or
higher, SuSE Linux 8.x or higher, HP-UX 10.20, 11.x, 11.i, Solaris 2.5 or higher (SPARC) (SPARC-based systems only), AIX 3.2.5 or higher, MPE-iX, Citrix Presentation
IPv4/IPv6: Apple Bonjour compatible (Mac OS 10.2.4 and higher), SNMPv1/v2c/v3, HTTP, HTTPS, FTP, TFTP, Port 9100, LPD, WS Discovery, IPP, Secure-IPP,
IPsec/Firewall; IPv6: DHCPv6, MLDv1, ICMPv6; IPv4: Auto-IP, SLP, Telnet, IGMPv2, BOOTP/DHCP, WINS, IP Direct Mode, WS Print;
SNMPv3; SSL/TLS; 802.1x authentication (EAP- PEAP, EAP-TLS); IPsec/Firewall with certificate authentication, Pre-Shared Key authentication, Kerberos authentication;
Server 4.0 and 4.5, Citrix XenApp Server 5.0, Windows 2003 and 2008 Terminal Services
Other: IPX/SPX, AppleTalk, NetWare NDS, Bindery, NDPS, iPrint
support for HP Web Jetadmin with IPsec configuration; access port for optional Kensington-style lock
21.3 x 20.6 x 16.5 in 26.1 x 25.7 x 38.0 in
84.6 lb 141.1 lb
HP LaserJet Black Print Cartridge (8,500 pages12); HP Color LaserJet Cyan, Yellow, and Magenta Print Cartridges with HP ColorSphere Toner (11,000 pages12);
Printer; power cable; 100-sheet multipurpose tray; 500-sheet input tray; HP Jetdirect Gigabit Ethernet embedded print server;
Hardware and Software Installation Guide; CD-ROM with software drivers and documentation
stand, HP Secure High Performance embedded hard
disk
One-year, next-day, onsite warranty
Typical Electricity Consumption (TEC) 6.485 kWh/Week
IEC 60950-1 (International); EN 60950-1+A11 (EU); IEC 608251+A1+A2; NRTL Listed (US/Canada); GS License (Europe); EN 608251+A1+A2 (Class 1 Laser/LED Device) GB4943-2001; Low Voltage
Directive 2006/95/EC with CE Marking (Europe); other safety
approvals as required by individual countries
CISPR 22: 2005/EN 55022: 2006 Class A, EN 61000-3-2: 2006, EN
61000-3-3: 1995+A1+A2, EN 55024: 1998+A1+A2, FCC Title 47
CFR, Part 15 Class A (USA), ICES-003, Issue 4, (Canada), GB92541998, EMC Directive 2004/108/EC with CE Marking (Europe), other
EMC approvals as required by individual countries
(±2 Hz); 220 to 240 VAC (±10%), 50/60 Hz (±2 Hz)
PowerSave: 19.0 watts; Off: 0.3 watts
.
Safety approvals and requirements
Electromagnetic emission standard
Supports HP SureSupply.15 For more information, visit www.hp.com/go/SureSupply.
ENERGY STAR and the ENERGY STAR mark are registered U.S. marks. Linux is a U.S. registered trademark of Linus Torvalds. Windows and Windows XP are registered trademarks of Microsoft
Corporation. Windows Vista is either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.
© Copyright 2009 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements
accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors
or omissions contained herein.
To learn more, visit www.hp.com 4AA2-8522ENUC, Rev. 1.1, September 2009
Loading...
