Technical white paper
HP ConvergedSystem 300 for
Vertica Software/Firmware
Releases v1.0
(H6X73A, H6X75A, H6X78A, H6X79A)
May 2014 Release (v1.0)
Table of Contents
Managing Software and Firmware updates for the ConvergedSystem 300 for Vertica ............................................... 2
Firmware Requirements .............................................................................................................................................................. 2
HP Firmware, Driver, and Software Support Recipe – CS300 for Vertica v1.0 ............................................................ 2
HP Integrated Lights-Out 4 ................................................................................................................................................. 2
HP Network Switches ........................................................................................................................................................... 2
HP Intelligent Power Distribution Unit .............................................................................................................................. 2
Software .......................................................................................................................................................................................... 3
System Level Firmware and Drivers ......................................................................................................................................... 3
Summary Table.............................................................................................................................................................................. 4
Page 2
Technical white paper | HP ConvergedSystem 300 for Vertica Software/Firmware Releases v1.0
Managing Software and Firmware updates for the ConvergedSystem 300
for Vertica
The HP ConvergedSystem 300 for Vertica is an integrated solution with specific software and firmware versions, qualified at
time of delivery. The HP ConvergedSystem 300 for Vertica is designed for solution level support across all components
within the Appliance. Unless in response to a support case as instructed to by the HP Customer Response Center, you will
not need to update the software and firmware versions within the solution until the support window expires. The software
firmware compatibility matrix was created based on the software versions defined at the time of manufacture.
The HP Customer Response Center may instruct you to apply specific hot fixes to address potential issues. Hot fixes are
supported as part of the solution level support criteria for the HP ConvergedSystem 300 for Vertica solution.
Before updating any software or firmware versions, contact the HP Customer Response Center at 1-800-325-5372 to verify
the compatibility of the updates. Any firmware or software updates applied, which are later than the compatibility listing,
will change the solution level support experience and must be accepted by the HP Customer Response Center.
Firmware Requirements
Unless otherwise specified, the components below apply to HP ConvergedSystem 300 for Vertica Appliance.
This section outlines specific firmware and software requirements for the Appliance.
HP Firmware, Driver, and Software Support Recipe – CS300 for Vertica v1.0
HP Integrated Lights-Out 4
At the time of release HP ConvergedSystem 300 for Vertica was tested and configured with HP Integrated Lights-Out 4
(iLO4) firmware v1.32. Systems being built for delivery should be in compliance with this version.
HP Network Switches
At the time of release HP ConvergedSystem 300 for Vertica was tested and configured with the latest firmware version
available at that time. Systems being built for delivery should be in compliance with the following firmware release.
• HP Network Switch – Model 5900AF-48XGT-4QSFP – Version R2307
Download firmware updates from the following URL:
HP Network Switch HP 5900AF-48XGT-4QSFP + Switch
https://h10145.www1.hp.com/downloads/SoftwareReleases.aspx?ProductNumber=JC772A
Refer to the firmware release notes for instructions on upgrading the firmware. Downloading firmware updates to the
network switches via serial port can take a long time. Utilizing the network is a much faster option but requires a TFTP or
FTP server to retrieve the updated firmware file.
HP Intelligent Power Distribution Unit
At the time of release, HP ConvergedSystem 300 for Vertica solutions were tested and configured with the HP Intelligent
Power Distribution Unit firmware version 1.5. Systems being built for delivery should be in compliance with the following
firmware release:
• HP Intelligent PDU Firmware Update 1.6.6.12
Download firmware updates from the following URL:
https://h20392.www2.hp.com/portal/swdepot/displayProductInfo.do?productNumber=Z7550-00906
2
Page 3
Technical white paper | HP ConvergedSystem 300 for Vertica Software/Firmware Releases v1.0
BIOS
12/20/2013
HP SmartArray Firmware
4.68
HP SmartArray Driver
3.2.0-RH1
NIC Firmware
0x8000049c
NIC Driver
3.9.15-k
Power Regulator Firmware
3.2
Software
ConvergedSystem 300 for Vertica requires the following software distributions:
• CS300 for Vertica Management Node 1 – DL360p
– Red Hat Release 6.4
– HP CMU version 7.2
– Vertica Management Console version 7.0.1
• Vertica Server Nodes – DL380p
– Red Hat Release 6.4
– Vertica Release version 7.0.1
• CS300 for Vertica Management Node 2 – DL360p
– Windows Server 2012 Enterprise (x64)
– Insight Management version 7.3.0
https://h20392.www2.hp.com/portal/swdepot/displayProductInfo.do?productNumber=IMDVD
– Insight Control version 7.3.0
https://h20392.www2.hp.com/portal/swdepot/displayProductInfo.do?productNumber=HPICE
– Insight Remote Support version 7.0.8
https://h20392.www2.hp.com/portal/swdepot/displayProductInfo.do?productNumber=REMOTESUPPORT
System Level Firmware and Drivers
Each Sever Node in the CS300 for Vertica shares the following parameters:
3
Page 4
Sign up for updates
hp.com/go/getupdated
Share with colleagues
© Copyright 2014 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for
HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as
constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
5900-3883, July 2014
Component
Version
Vertica Management Console
7.0.1
Vertica Release
7.0.1
Red Hat Server Release
6.4
DL380/360 BIOS
12/20/2013
HPN 5900 Network Switch
R2307
Intelligent Power (IPDU)
1.6.16.12
Power Regulator Firmware
3.2
Windows OS
Windows Server 2012 Standard (x64)
Insight Management
7.3.0
Insight Control
7.3.0
Insight Remote Support
7.0.8
Insight Cluster Management
7.2
iLO4
1.32
HP Smart Array Firmware
4.68
HP Smart Array Driver
3.2.0-RH1
NIC Firmware
0x8000049c
NIC Driver
3.9.15-k
Summary Table
