HP Compaq AlphaStation DS10 Overview

1.

Diskette drive

2.

Fan

3.

PCI riser card

4.

Memory boards

5.

Dual Ethernet ports

6.

Keyboard and mouse ports

7.

CPU and fan

8.

Power supply

9.

Disks

10.

CD-ROM drive

11.

Front Access Storage Cage

12.

Internal Storage Cage

MR0050

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Overview

DA - 10908 North America — Version 29 — April 27, 2004

Page 1

MR0049

At A Glance

AlphaServer/AlphaStation DS10 3U Systems include:

Alpha 600-MHz CPU with 2-MB onboard ECC cache
512-MB or 1-GB SDRAM memory - expandable to 2-GB maximum memory capacity
Onboard dual 10/100 BaseT Ethernet ports
Four PCI expansion slots - three 64-bit PCI slots and one 32-bit PCI slot
Onboard dual IDE controller

1.44-MB diskette drive
600-MB CD-ROM drive
Two storage cage subsystems: Internal Storage Cage for IDE/SCSI tapes/drives; Front Access Storage Cage for SCSI drives
DS10 Internal Storage Cage Systems can be configured with: three internal 3.5-inch x 1-inch hard disk drives or two internal 3.5-inch x 1­inch hard disk drives and one 5.25-inch x 1.6-inch removable media device
DS10 Front Access Storage Cage Systems can be configured with: two front access 3.5-inch x 1-inch hard disk drives and two internal 3.5­inch x 1-inch hard disk drives) or one Front Access Universal tape drive (DAT) and two internal disk drives
Maximum Internal storage capacity: Internal Storage Cage 218-GB SCSI or 120-GB IDE; Front Access Storage Cage-437-GB SCSI
Two serial ports: COM1 port is both an RMC port with modem control and a full-duplex asynchronous communications port; COM2 port is a
full-duplex asynchronous communications port
Bi-directional enhanced parallel port
PS/2-style keyboard port and mouse port
300W (88-260V, 47-63Hz) power supply
U.S. English documentation
Tru64 UNIX or OpenVMS Factory Installed Software
90-day software product warranty
Protected by HP Services, including three-year, on-site hardware with next business day response

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Overview

DA - 10908 North America — Version 29 — April 27, 2004

Page 2

Processor

Alpha 21264A 600-MHz processor

Cache Memory

2-MB onboard cache

Upgradability

Supports upgrades of memory and hard drives
Standard

One CPU

Memory

Standard

512 MB or 1 GB (one memory kit)

Maximum

2 GB (two memory kits, kits include two industry-standard DIMMs with
ECC support)

Network Controller

Onboard dual 10/100 BaseT Ethernet ports

Expansion

Storage bays

Internal Storage Cage Systems: Five total - CD-ROM, FDD, and three storage bays: Three internal

3.5-inch x 1-inch hard disk drives or two internal 3.5-inch x 1-inch hard disk drives and one

5.25-inch x 1.6-inch removable media device
Front Access Storage Cage Systems: Six Total - CD-ROM, FDD, and Four Storage bays (two

front access 3.5-inch x 1-inch hard disk drives and two internal 3.5-inch x 1-inch hard disk
drives)

PCI slots

Four full-length slots (three 64-bit, one 32-bit)

Storage

Diskette Drive

1.44-MB diskette drive

CD-ROM

Internal Storage Cage Systems: 5.25-inch half height 48X CD-ROM drive
Front Access Storage Cage Systems 24X slim-line CD-ROM drive

Hard Drives

40-GB and 80-GB IDE disk drives or 36.4-GB and 72.8-GB Wide Ultra3 available with the Internal
Storage Cage, and 18.2-GB, 36.4-GB, 72.8-GB, or 146-GB Universal SCSI drives available with
Front Access Storage Cage. SCSI disk drives require optional SCSI adapter. IDE drives not
supported in Front Access Cage systems.

Storage Adapter/
Controller

Onboard IDE controller for internal storage, choice of optional storage adapters/controllers

Expansion Ports

Parallel

One bi-directional enhanced port

Serial

Two ports, one serial port with full-duplex asynchronous modem control and one RMS dedicated
serial port with full-duplex asynchronous modem control

Keyboard

One PS/2-style port

Mouse

One port

Power Supply

300W (88-260V, 47-63 Hz)

Manageability

Insight Manager

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Standard Features

DA - 10908 North America — Version 29 — April 27, 2004

Page 3

Supported Options

A detailed summary of options supported on the AlphaServer/AlphaStation DS10 is available at

http://www.compaq.com/alphaserver/options/asds10/asds10_options.html

OS Support

AlphaServer DS10 Tru64 UNIX systems include pre-installed software (V5.1B PK3/NHD7), Base license, Unlimited
User license, Server Extension license, Internet Express and Secure Web Server

AlphaStation DS10 Tru64 UNIX systems include pre-installed software (V5.1B PK3/NHD7), 2-user Base license
AlphaServer DS10 OpenVMS systems include pre-installed software (V7.3-2), Base license with System Manager

license and Enterprise Integration Server License Package for OpenVMS V3.0A.
AlphaStation DS10 OpenVMS systems include pre-installed software (V7.3-2), Base license, Concurrent Use 1-user

license, and NAS 150 Client license
Minimum OS support: Tru64 UNIX V4.0F or OpenVMS V7.1 -2

Service and Support

Protected by HP Services, including a three-year, on-site hardware warranty with next business day response.
Software warranty is a 90-day telephone advisory. Training, consulting, network integration, software support,
comprehensive system maintenance and guaranteed uptime services are also available for customers requiring
higher levels of service and support.

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Standard Features

DA - 10908 North America — Version 29 — April 27, 2004

Page 4

Step 1 – Select system

AlphaServer/AlphaStation DS10 600-MHz systems require the

mandatory

selection of the following items:

One Storage Cage

(either Internal Storage Cage or Front Access Storage Cage)

and one system disk

If Internal Storage Cage is selected:

Mandatory selection of one IDE or one internal SCSI system disk drive
Mandatory selection of SCSI adapter and SCSI cable kit required for internal SCSI disks and tape

If Front Access Storage Cage is selected:

Mandatory selection of one Universal SCSI system disk drive
Mandatory selection of SCSI adapter is required for Front Access Storage Cage (cable is included)
Front Access Storage Cage based system is SCSI only. (IDE drives cannot be used.)
Country-specific power cord
Software media and documentation for first system on site
Rackmount kit for rackmount systems (See Step 5 – M-Series Cabinet Enclosures)
Minimum OS support: Tru64 UNIX V4.0F or OpenVMS V7.1-2

NOTE:

Country-specific keyboard and mouse are recommended. See Step 11.

AlphaServer DS10 600-MHz Base Systems

OS

CPU

Memory

PCI

2-10/100t Ports

Hard Drive

Storage Cage

Order Number

Tru64 UNIX

600 MHz

512 MB

4

Onboard

Mandatory Mandatory

DA-74BAA-EA

Tru64 UNIX

600 MHz

1 GB

4

Onboard

Mandatory Mandatory

DA-74BAA-FA

OpenVMS

600 MHz

512 MB

4

Onboard

Mandatory Mandatory

DY-74BAA-EA

OpenVMS

600 MHz

1 GB

4

Onboard

Mandatory Mandatory

DY-74BAA-FA

Linux-Ready

600 MHz

512 MB

4

Onboard

Mandatory Mandatory

DJ-74BAA-EA

Linux-Ready

600 MHz

1 GB

4

Onboard

Mandatory Mandatory

DJ-74BAA-FA

AlphaStation DS10 600-MHz Base Systems

OS

CPU

Memory

PCI

2-10/100t Ports

Hard Drive

Storage Cage

Order Number

Tru64 UNIX

600 MHz

512 MB

4

Onboard

Mandatory Mandatory

DA-74BAA-EW

Tru64 UNIX

600 MHz

1 GB

4

Onboard

Mandatory Mandatory

DA-74BAA-FW

OpenVMS

600 MHz

512 MB

4

Onboard

Mandatory Mandatory

DY-74BAA-EW

OpenVMS

600 MHz

1 GB

4

Onboard

Mandatory Mandatory

DY-74BAA-FW

Linux-Ready

600 MHz

512 MB

4

Onboard

Mandatory Mandatory

DJ-74BAA-EW

Linux-Ready

600 MHz

1 GB

4

Onboard

Mandatory Mandatory

DJ-74BAA-FW

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Systems

DA - 10908 North America — Version 29 — April 27, 2004

Page 5

Step 2 – Select Mandatory Options (Storage Cage, System Disk, SCSI Controller, Power Cord)

MR0051

Step 2a – Mandatory Selection of Storage Cage

DS10 Systems support

one

Storage Cage

Selection of one Storage Cage is

mandatory (no exceptions)

DS10 Internal Storage Cage: DS10 System with Internal Cage supports three storage devices:

- Either three internal hard disk drives or one 5.25-inch half height backup tape and two internal hard disk drives
DS10 Front Access Storage Cage: DS10 System with Front Access Cage supports up to four storage devices:

- Two Universal disk drives plus two internal disk drives, or

- One Front Access Universal Tape Drive (DAT) and two internal disk drives

3X-BA10A-AA

3X-BA10B-AA

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Systems

DA - 10908 North America — Version 29 — April 27, 2004

Page 6

Step 2b – Internal Storage Cage - System Disk Drive -

Mandatory

Selection of one system disk drive is mandatory for the Internal Storage Cage (3X-BA10A-AA)

- Mandatory selection of one IDE or one internal SCSI system disk drive

- Mandatory selection of SCSI adapter and SCSI cable kit required for internal SCSI disks and tape

1.

Floppy Disk Drive

2.

Internal Drive Bay

3.

CD-ROM

4.

Internal Drive/Tape Bay

5.

Internal Drive Bay

MR0052

DS10 Storage Configuration Rules with Selection of Internal Storage Cage:

DS10 Systems configured with the Internal Storage Cage include a 600-MB 48X half height CD-ROM and 1.44-MB diskette in
dedicated drive slots
DS10 Systems configured with the Internal Storage Cage include three internal storage bays (two in the Storage cage plus
one in the system box) that can be configured as follows:

Maximum of three internal disk drives (3.5-inch x 1-inch drives) or two internal disk drives

(3.5-inch x 1-inch) and one 5.25-inch half height removable media device
Mandatory selection of SCSI adapter and SCSI cable kit is required for internal SCSI disks or tapes
IDE Disk drive cable kits are included with the system

NOTE:

When a tape drive is ordered, it will be installed in the top slot (Slot 3) and the CD will be installed in

Slot 4.

Internal IDE Disk Drives

20 GB 7,200 rpm IDE (UDMA) drive

3X-RE58A-AA

40-GB 7,200 rpm IDE (UDMA) disk drive

3X-RE58A-BA

NOTE:

Requires minimum console firmware V5.9-6 or higher. Updates available at

http://ftp.digital.com/pub/Digital/Alpha/firmware

80-GB 7,200 rpm IDE (UDMA) disk drive

3X-RE58A-CA

NOTE:

Requires minimum console firmware V6.0 or higher. Updates available at

http://ftp.digital.com/pub/Digital/Alpha/firmware

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Systems

DA - 10908 North America — Version 29 — April 27, 2004

Page 7

Internal SCSI Disk Drives

36.4-GB Ultra3 SCSI 10,000 rpm drive

DS-RZ3FD-WA

72.8-GB Ultra3 SCSI 10,000 rpm drive

DS-RZ3GA-WA

Internal Tape Drives

DAT 12/24-GB 4-mm 5.25-inch half-height SCSI tape drive, top gun blue; requires single-ended
UltraSCSI or Ultra2/Ultra3 adapter (3X-DEPVZ-AA, 3X-KZPCA-AA, 3X-KZPEA-DB, or KZPCM­DA) and SCSI cable (SCSI adapter, SN-PBXKP-BA required)

TLZ10-LB

DAT 20/40-GB tape drive, LVD, carbon black (C5686B)
See Supported Options List --

http://www.compaq.com/alphaserver/options/asds10/asds10_options.html

-- for complete listing
of supported options and configuration details. See option specific QuickSpecs for complete list
of country specific SKUs.

3R-A4752-AA

DAT 36/72-GB 4-mm 5.25-inch half-height LVD SCSI tape drive, carbon black (Q1522A)

3R-A4544-AA

DS10 SCSI cable kit (with connections for three internal drives)

3X-BN51A-SE

NOTE:

The DS10 SCSI cable kit is included with the Front Access Storage Cage. The DS10 SCSI

cable kit is required for Internal Storage Cage systems with SCSI disks or tapes

.

DLT 40/80-GB VS 80 half-height tape drive (337699-B21)

3R-A5071-AA

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Systems

DA - 10908 North America — Version 29 — April 27, 2004

Page 8

Step 2c – Front Access Storage Cage - System Disk or Tape Drive -

Mandatory

1.

Floppy Disk Drive

2.

Internal Drive Bay

3.

CD-ROM

4.

Compaq Universal Drive Bay

5.

Compaq Universal Drive Bay

6.

Internal Drive Bay

MR0053

Front Access Storage Cage System Disk Drive Selection

- Mandatory

Selection of one system disk drive is mandatory for each Front Access Storage Cage
Mandatory selection of SCSI adapter is required for Front Access Storage Cage
SCSI cable with connections to the four disk drives is included with the Front Access Storage Cage

DS10 Storage Configuration Rules with Selection of Front Access Storage Cage:

DS10 Systems configured with Front Access Storage Cage include a 600-MB 24X slim-line CD-ROM and 1.44-MB drive in
dedicated drive slots
DS10 Systems configured with the Front Access Storage Cage include four storage bays (two Universal SCSI disk drives
and two internal SCSI drives) which can be configured as follows:

- Maximum of two internal disk drives (3.5-inch x 1-inch drives) and two Universal disk drives
(3.5-inch x 1-inch) or one Front Access Universal tape drive (DAT) and two internal disk drives.
Mandatory selection of SCSI adapter for Front Access Cage Systems
SCSI cable included with Front Access Cage

NOTE:

IDE drives may not be used in Front Access Cage systems

Internal SCSI Disk Drives

(For Drives
Internal to System Enclosure)

36.4-GB Ultra3 SCSI 10,000 rpm drive

DS-RZ3FD-WA

72.8-GB Ultra3 SCSI 10,000 rpm drive

DS-RZ3GA-WA

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Systems

DA - 10908 North America — Version 29 — April 27, 2004

Page 9

Universal Disk Drives

(For Front Access Storage
Cage)

18.2-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive

3R-A3848-AA

36.4-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive

3R-A3838-AA

36.4-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive

3R-A3849-AA

72.8-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive

3R-A3839-AA

72.8-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive

3R-A3851-AA

146-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive

3R-A3841-AA

Optional Universal Tape
Drives

(For Front Access Storage
Cage)

DAT 20/40-GB Universal tape drive, LVD, uses two slots. (Q1546A)
See Supported Options List -

http://www.compaq.com/alphaserver/options/asds10/asds10_options.html

-- for complete listing
of supported options and configuration details. See option specific QuickSpecs for complete list
of country specific SKUs.

3R-A4745-AA

DAT 36/72-GB LVD Universal tape drive, carbon black; uses two slots in
3X-BA10B-AA or DS-SL13R-xx storage shelves (Q1529A)

3R-A4547-AA

Step 2d – Internal SCSI Adapters and Cable Kits

Front Access Storage Cage

:

- Mandatory selection of SCSI adapter is required for Front Access Storage Cage

- Front Access Storage Cage includes SCSI cable kit for connection to four disks

Internal Storage Cage

:

- Mandatory selection of SCSI adapter and SCSI cable kit are required for Standard Storage Cage systems with SCSI
disk or tapes

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Systems

DA - 10908 North America — Version 29 — April 27, 2004

Page 10

SCSI Adapters

(For Internal and Front
Access Drives)

PCI 1-channel Ultra2 SCSI adapter (LVD)

3X-KZPCA-AA

PCI 2-channel multi-mode Ultra3 LVD SCSI adapter, VHDCI (Tru64 UNIX V5.1 or higher and
OpenVMS V7.2-2 or higher) No shared bus support with OpenVMS. No shared tape/library
support with OpenVMS or Tru64 UNIX. 3X-KZPEA-DB adapter supports shared bus using hard
disk drives under Tru64 UNIX V5.1A with PK4 and NHD5 or V5.1B and TruCluster V5.1B with
Initial Patch Kit installed; supports maximum of two nodes per shared bus; requires 3X-BN55A­01 Y-cable and connector plug assembly, and 3X-H32CT-AA external LVD terminator per
shared bus.

3X-KZPEA-DB

NOTE:

Tru64 UNIX Initial Patch Kit for V5.1B located at:

http://ftp1.support.compaq.com/public/unix/5.1b

NOTE:

Patch kit required, kit available at:

http://ftp1.support.compaq.com/public/Digital_UNIX/v5.1/

PCI combo card - PCI 2-channel UltraSCSI single-ended adapter and 10/100 Mbit

KZPCM-DA

PCI combo card - 1-channel Ultra2 SCSI (LVD) Graphics, 10/100 Ethernet
(Tru64 UNIX and OpenVMS only)

3X-DEPVZ-AA

PCI 1-channel UltraSCSI RAID controller (Tru64 UNIX and OpenVMS only)

KZPAC-AA

NOTE:

Internal or Front Access Disk Drives connected to a KZPAC controller are not capable of
implementing the fault management features of this controller, such as 'hot spare' and 'automatic
rebuilds'- manual rebuilds are supported.

PCI 3-port UltraSCSI RAID controller (4-MB/8-MB cache) (Tru64 UNIX V4.0F, OpenVMS V7.2-1)

KZPAC-CA/CB

NOTE:

Internal or Front Access Disk Drives connected to a KZPAC controller are not capable of
implementing the fault management features of this controller, such as 'hot spare' and 'automatic
rebuilds' - manual rebuilds are supported.

PCI 1-channel Ultra2 SCSI RAID controller, 4-MB cache (Linux-Ready Systems only)

SN-KZPBC-AA

PCI 3-channel Ultra2 SCSI RAID controller, 32-MB cache (Linux-Ready Systems only)

FR-PCTAR-IB

PCI 3-channel Ultra2 SCSI RAID controller, 64-MB cache (Linux-Ready Systems only)

FR-PCTAR-IC

DS10 SCSI cable kit (with connections for three internal drives)

3X-BN51A-SE

NOTE:

The DS10 SCSI cable kit is included with the Front Access Storage Cage. The DS10 SCSI
cable kit is required for Internal Storage Cage systems with SCSI disks or tapes.

Desktop Power Cords

North America, 2.5-meter

3X-BN46K-2E

North America, 200 to 240V, 75-inch

BN18J-1K

Australia, New Zealand, 2.5-meter (103541-011)

BN19H-2E

Central Europe, 2.5-meter

BN19C-2E

Denmark, 2.5-meter (103541-481)

BN19K-2E

Egypt, India, South Africa, 2.5-meter (103541-AR1)

BN19S-2E

Israel, 2.5-meter

BN18L-2E

Italy, 2.5-meter

BN19M-2E

Japan, 2.5-meter, Dentori approved

3X-BN46G-02

Switzerland, 2.5-meter (103541-511)

BN19E-2E

UK, Ireland, 2.5-meter

BN19A-2E

Rackmount

(M-Series

Cabinet)

Power Cords

U.S./Canada

BN20Z-4E

Non-U.S.

3X-BN46L-4E

Japan, 4.5-meter (right-angle connector)

3X-BN46D-4E

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Systems

DA - 10908 North America — Version 29 — April 27, 2004

Page 11

Step 3 – Memory

– Optional

Maximum 2 GB memory
Systems include one memory kit; maximum two memory kits per system - each kit includes two industry-standard DIMMs
with ECC support

512-MB memory kit, two 200-pin, 100-MHz, 256-MB DIMMs

3X-MS310-DA

1-GB memory kit, two 200-pin, 100-MHz, 512-MB DIMMs

3X-MS310-EA

Step 4 – DVD-ROM Drive

– Optional

Optional 16X DVD-ROM Drive - Supported in Internal Storage Cage only - not supported in Front
Access Storage Cage - supported in slot 3 of the Internal Storage Cage and replaces standard
CD-ROM (see diagram on page 6, Step 2b). Ships as spare, not integrated in manufacturing.

3X-PBXRV-BA

Optional 48X half-height DVD/CD-RW combo, carbon black, for DS10 Internal Storage Cage,
supported in 3X-BA10A-AA only

3X-A4412-BA

Step 5 – M-Series Cabinets or Series 10000 Rack

– Optional

Step 5a - M-Series Cabinets (Optional)

M-Series cabinet enclosures support up to 12 DS10 systems (H9A15).
M-Series enclosures require selection of the following items:

H9A10, or H9A15 Cabinet, 120V or 240V
Cabinet front door based on cabinet height
Factory integration

Cabinet Configuration Chart for AlphaServer DS10 Rackmount Systems

A minimum of two AlphaServer DS10 systems is required in the H9A15 M-Series cabinet.
Each system requires a DS10 M-Series Rackmount kit (3X-PBX01-AB).
Each system requires a rackmount power cord.

NOTE:

The number of ballast kits required is determined only by the number of system boxes. Ballast kits are required according
to the following chart. For more information on M-Series Cabinet Enclosures, see

http://www.compaq.com/alphaserver/products/m-series/index.html

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 12

Cabinet Configuration Chart for AlphaServer DS10 (3U) Rackmount Systems with Disk Shelves (12U)

M-Series Cabinet

System Rack Kit per

DS10 system

M-Series Cabinet

Height/Space

DS10 Systems

StorageWorks

DS-SL13R/

3R-A4075-AA/

3R-A4076-AA

*

Disk Shelf

Ballast Kits Required

H9A10-MC/MD

3X-PBX01-AB

67-inch/32U

1 or 2

6 2

3 or 4

6 1
5 6 1
6 4 0
7 2 0

8, 9, or 10

0 0

H9A15-MC/MD

3X-PBX01-AB

79-inch/39U

2 or 3

6 2
4 6 1
5 6 1
6 4 1
7 2 0

8 to 12 0 0

*

3R-A4075-AA and 3R-A4076-AA are not supported in a shared-SCSI cluster using the 3X-KZPEA-DB.

M-Series Rackmount Kit
for AlphaServer DS10

Rackmount kit must be ordered separately
DS10 M-Series rackmount kit

3X-PBX01-AB

NOTE:

Factory integration of a DS10 system drawer in a 9000 Series Rackmount Cabinet using rack kit,

3X-PBX01-AA, is not supported. Contact Custom Systems.

M-Series Cabinets

67-inch cabinet enclosure with 59.5-inch or 34U of usable vertical space; 120V
dual-24A controller, each with 10 NEMA 5-15R outlets, input power plug NEMA L5-30P,
Americas, Asia Pacific; includes rear door, top fan tray, and two H7600-AA power distribution
units

H9A10-MC

67-inch cabinet enclosure with 59.5-inch or 34U of usable vertical space; 240V
dual-16A controller, each with 12 IEC C13 outlets, input power plug IEC 309, 16A, Europe;
includes rear door, top fan tray, and two H7600-DB power distribution units

H9A10-MD

79-inch cabinet enclosure with 71.7-inch or 41U of usable vertical space; 120V
dual-24A controller, each with 10 NEMA 5-15R outlets, input power plug NEMA L5-30P,
Americas, Asia Pacific; includes rear door, top fan tray, and two H7600-AA power distribution
units

H9A15-MC

79-inch cabinet enclosure with 71.7-inch or 41U of usable vertical space; 240V
dual-16A controller, each with 12 IEC C13 outlets, input power plug IEC 309, 16A, Europe;
includes rear door, top fan tray, and two H7600-DB power distribution units

H9A15-MD

M-Series Cabinet Front
Door

Requires selection of door based on cabinet height

Front door, top gun blue, for H9A10-MC/MD cabinet enclosure

H9C10-TF

Front door, top gun blue, for H9A15-MC/MD cabinet enclosure

H9C15-TF

M-Series Cabinet Factory
Integration

Mandatory selection

Factory Integration of systems and storage devices assembled and configured in cabinet
enclosure for H9A10 or H9A15 cabinet enclosures

YS-ASCAA-AA

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 13

M-Series Cabinet Ballast
Kits

Add ballast kits as required
Ballast is added to a cabinet at particular locations for specific configurations to meet
safety regulations for installation, operation, and service; see Cabinet Configuration
Charts

Two 35 to 40 lb steel plates

H9C10-MC

M-Series Cabinet
Rackmount Power Cords

U.S./Canada

BN20Z-4E

Non-U.S.

BN35S-4E

Japan, 2.5-meter

3X-BN46D-4E

CustomSystems Support

Cabinets that contain systems and storage must be assembled by qualified assemblers: HP Manufacturing,
CustomSystems, or an authorized HP Certified Integration Partner.
For custom integration of systems, options, cabinet expansion offerings, and additional HP and third-party devices, or
for other cabinets, doors, and trim kits of a different color, contact CustomSystems at
1-800-AT COMPAQ, or your local authorized HP Certified Integration Partner.

Step 5b Rack 10000 Series

- Optional

10000 Series rack enclosure supports up to 12 DS10 systems (10642)
10000 Series rack enclosure requires selection of the following items:
10642 rack

Rack sidewall kit or baying kit
Deployable stabilizer
Power Distribution Unit (PDU)
Ballast kits (if required)
Factory integration

Cabinet Configuration Chart for AlphaServer DS10 Rackmount Systems

10000 Series rack requires selection of a power distribution unit
Each system requires a DS10 Rack-mount kit (3X-PBX01-AA).

Each system requires a rackmount power cord.

NOTE:

The number of ballast kits required is determined by the number of system boxes. Ballast kits are required according to

the following chart. For more information on Rack 10000 Series Enclosures, see

http://h18004.www1.hp.com/products/quickspecs/10995_div/10995_div.html

Rack Configuration Chart for AlphaServer DS10 (3U) Rackmount Systems with Disk Shelves (12U)

10000 Series Rack

System Rack Kit per

DS10 system

Series 10000

Height/Space

DS10 Systems

StorageWorks

DS-SL13R/

3R-A4075-AA/

3R-A4076-AA

*

Disk Shelves

Ballast Kits Required

3R-A3894-AA

(10642 42U)

3X-PBX01-AA

79-inch/41U

2-3

6 2
4 6 1
5 6 1
6 4 1
7 2 0

8 to 12 0 0

*

3R-A4075-AA and 3R-A4076-AA are not supported in a shared-SCSI cluster using the 3X-KZPEA-DB.

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 14

10000 Series Rackmount
Kit for AlphaServer DS10
Rack 10000 Series
(10642)

Rackmount kit must be ordered separately

DS10 Series 10000 rackmount kit

3X-PBX01-AA

79-inch cabinet enclosure with 73.5-inch or 42U of usable vertical space; includes front and
rear doors, no side panels, shock pallet

3R-A3894-AA

Side Panel Kit

42U graphite metallic

3R-A3895-AA

Baying Kit

(Carbon) - Used to join two or more 10000 Series racks

3R-A4125-AA

Deployable Stabilizer Kit

Mandatory selection

2T-H9C30-MK

Power Distribution Unit
(PDU)

Mandatory selection

Single Phase, Double Power Controller, 16 outlet North America/Japan 240V

3X-H7609-EB

Single Phase, Double Power Controller, 16 outlet, Europe 240V

3X-H7609-DB

Rack 10000 Series Factory
Integration

Mandatory selection

Factory Integration of systems and storage devices assembled and configured in 10642 rack
enclosure

YS-ASCAA-AA

10000 Series Rack Ballast
Kit

Add ballast kits as required

Ballast is added to the rack at particular locations for specific configurations to meet safety
regulations for installation, operation and service. See Rack Configuration Charts.

2T-H9C30-MA

Series 10000 Rackmount
Power Cord

Series 10000 Rackmount Power Cord

BN35S-4E

Step 6 – External Storage

– Optional

Tape drives require an LVD adapter (3X-KZPCA-AA or 3X-KZPEA-DB) or single-ended UltraSCSI adapter (KZPCM-DA)
and country-specific power cord.

NOTE:

3X-KZPEA-DB does not support shared tape/libraries.

Tape Devices

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 15

DAT Tabletop Tape Drives

DAT 20/40-GB 4-mm Wide Ultra2 (LVD) tabletop SCSI tape drive with 120V
North America power cord, carbon black; requires Ultra2 (LVD) adapter

157770-002

Same as above, International

157770-B32

Same as above, Japan

157770-292

DAT 36/72-GB LVD tabletop SSI tape drive, carbon black
See Supported Options List --

http://www.compaq.com/alphaserver/options/asds10/asds10_options.html

-- for complete listing
of supported options and configuration details. See option specific QuickSpecs for complete list
of country specific SKUs.

Q1523A

DAT 40-GB LVD tabletop tape drive, carbon black
See Supported Options List --

http://www.compaq.com/alphaserver/options/asds10/asds10_options.html

-- for complete listing
of supported options and configuration details. See option specific QuickSpecs for complete list
of country specific SKUs.

C5687C

DAT Hot-plug Tape Drives

DAT 36/72-GB hot-plug LVD Universal tape drive, carbon black; uses two slots in 43xxx storage
shelves (Q1529A)

3R-A4547-AA

DAT 20/40-GB hot-plug LVD Universal tape drive; carbon black; uses two slots in 43xxx storage
shelves (Q1546A)

3R-A4745-AA

DAT Autoloaders

DAT 20/40-GB auto loader external; requires BN31W-xx SCSI cable and
3X-KZPCA-AA, or 3X-DEPVZ-AA adapter, North America

166505-001

Same as above, International

166505-B31

Same as above, Japan

166505-291

SureStore DAT 40x6e external auto loader
See Supported Options List --

http://www.compaq.com/alphaserver/options/asds10/asds10_options.html

-- for complete listing
of supported options and configuration details. See option specific QuickSpecs for complete list
of country specific SKUs.

C5717C

DLT/SDLT Tabletop Tape
Drives

DLT8000 tabletop 40/80-GB DLT external tape drive, carbon black - requires
3X-KZPCA-AA LVD adapter - U.S.

146197-B23

Same as above – Japan

146197-293

SDLT tabletop 110/220-GB external tape drive, carbon black- requires 3X-KZPCA-AA or 3X­KZPEA-DB LVD adapter - U.S.

192103-002

Same as above – International

192103-B32

Same as above – Japan

192103-292

SDLT tabletop 160/320-GB external tape drive, carbon black - requires 3X-KZPCA-AA or 3X­KZPEA-DB LVD adapter - U.S.

257319-001

Same as above - International

257319-B31

Same as above - Japan

257319-291

DLT 40/80-GB VS 80 half-height external tape drive (337699-B22)

3R-A4982-AA

DLT 40/80-GB VS 80 half-height external tape drive, International (337699-B31)

3R-A4984-AA

DLT 40/80-GB VS 80 half-height external tape drive, Japan (337699-291)

3R-A4983-AA

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 16

Ultrium Tabletop Tape
Drives

Ultrium 460 tabletop tape drive, four per system, two per SCSI bus, U.S.
Supported with 3X-KZPEA-xx, KZPCA-xx, and DEPVZ SCSI adapters only.
Ultrium 460 tape drives are cluster friendly devices, but cannot be shared by cluster members.
Tru64 UNIX V5.1A requires Patch Kit 4: T64V51AB21AS0004-20030206.tar
Tru64 UNIX V5.1B requires Patch Kit 1: T64v51bb03as0001-20021229.tar

Q1519A

Ultrium 460 tabletop tape drive, same as above, International

Q1520A

DLT/SDLT Tape Libraries

Rackmount kit for H9Axx M-Series cabinets - required for mounting MSL5000 series in M-Series
cabinets

254795-001

MSL5026DLX, DLT tabletop library with one 40/80-GB DLT tape drive, LVD

231821-B21

MSL5026DLX, DLT tabletop library with two 40/80-GB DLT tape drives, LVD

231821-B22

MSL5026DLX or MSL5026SL, DLT/SDLT rackmount library, 0 drives - requires rackmount kit
(254795-001)

231979-B21

MSL5026DLX, DLT rackmount library with one 40/80-GB DLT tape drive, LVD - requires rackmount
kit (254795-001)

231891-B21

MSL5026DLX, DLT rackmount library with two 40/80-GB DLT tape drives, LVD - requires
rackmount kit (254795-001)

231891-B22

MSL5026S2, SDLT2 tabletop library with one 160/320-GB SDLT tape drive, LVD

293473-B21

MSL5026S2, SDLT2 tabletop library with two 160/320-GB SDLT tape drives, LVD

293473-B22

MSL5026S2 SDLT rackmount library, 0 drives, LVD - requires rackmount kit
(254795-001)

293472-B21

MSL5026S2, SDLT2 rackmount library with one 160/320-GB SDLT tape drive, LVD

293472-B22

MSL5026S2, SDLT2 rackmount library with two 160/320-GB SDLT tape drive, LVD

293472-B23

MSL5026S2, SDLT2 rackmount library with one 160/320-GB SDLT tape drive with Fibre Channel,
LVD

293472-B24

MSL5026S2, SDLT2 rackmount library with two 160/320-GB SDLT tape drive with Fibre Channel,
LVD

293472-B25

MSL5026SL, SDLT tabletop library with one 110/220-GB SDLT tape drive, LVD

302511-B21

MSL5026SL, SDLT tabletop library with two 110/220-GB SDLT tape drives, LVD

302511-B22

MSL5026SL, SDLT rackmount library with one 110/220-GB SDLT tape drive, LVD

302512-B21

MSL5026SL, SDLT rackmount library with two 110/220-GB SDLT tape drives, LVD

302512-B22

MSL5052, 0 drives, LVD, rackmount

255102-B21

MSL5052SL SDLT tabletop library with two 110/220-GB drives, LVD

249490-B21

MSL5052SL SDLT rackmount library with two 110/220-GB drives, LVD - requires rackmount kit
(254795-001)

249491-B21

MSL5052SL SDLT 110/220-GB drive field upgrade, LVD

231823-B22

MSL5052S2, SDLT2 tabletop library with two 160/320-GB SDLT tape drives, LVD, graphite

293476-B21

MSL5052S2, SDLT2 rackmount library with two 160/320-GB SDLT tape drive, LVD

293474-B21

MSL5052S2, SDLT2 rackmount library with two 160/320-GB SDLT tape drive with Fibre Channel,
LVD

293474-B24

MSL6030 LTO Ultrium 460, 30 cartridge 5U, with 0 drives, rackmount LVD

330731-B21

MSL6030 LTO Ultrium 460, 30 cartridge 5U, with one drive, rackmount LVD

330731-B22

MSL6030 LTO Ultrium 460, 30 cartridge 5U, with two drives, rackmount LVD

330731-B23

MSL6030 LTO Ultrium 460, 30 cartridge 5U, with one drive, rackmount Fibre

330731-B24

MSL6030 LTO Ultrium 460, 30 cartridge 5U, with two drives, rackmount Fibre

330731-B25

MSL6030 LTO Ultrium 460, 30 cartridge 5U, with one drive, tabletop LVD

330788-B21

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 17

MSL6030 LTO Ultrium 460, 30 cartridge 5U, with two drives, tabletop LVD

330788-B22

MSL6060 LTO Ultrium 460, 60 cartridge 10U, with 0 drives, rackmount LVD

331196-B23

MSL6060 LTO Ultrium 460, 60 cartridge 10U, with two drives, tabletop LVD

331195-B21

MSL6060 LTO Ultrium 460, 60 cartridge 10U, with two drives, rackmount LVD

331196-B21

MSL6060 LTO Ultrium 460, 60 cartridge 10U, with two drives, rackmount Fibre

331196-B22

ESL9326SL SDLT tape library with six 110/220-GB SDLT tape drives, LVD

234615-B21

ESL9326SL SDLT tape library with eight 110/220-GB SDLT tape drives, LVD

234615-B22

ESL9326SL SDLT tape library with 16 110/220-GB SDLT tape drives, LVD

234615-B26

3U Rackmount Tape Drive
Enclosure

3U LVD Rackmount Tape Drive Enclosure for use in H9Axx M-Series Cabinets, 0 drives, carbon
black

274338-B21

Rackmount Kit for H9Axx Series Cabinets, carbon black - required for mounting 3U Rackmount
Tape Drive Enclosure in M-Series cabinet

3R-A3804-AA

NOTE:

The 3U Tape Drive Enclosure supports up to four internal half-height removable devices,
or up to two full height devices. Select up to four DAT devices, or two DLT/SDLT devices with
3U Rackmount Tape Drive Enclosure (274338-B21), or select preconfigured configurations listed
below

DAT 20/40-GB 3U tape drive, requires 3X-KZPCA-AA LVD adapter, carbon black (157769-B22)

3R-A3752-AA

DLT8000 40/80-GB tape drive, requires 3X-KZPCA-AA LVD adapter

146196-B22

SDLT 110/220-GB tape drive, requires 3X-KZPCA-AA or 3X-KZPEA-DB LVD adapter

192106-B25

SDLT 160/320-GB tape drive, requires 3X-KZPCA-AA or 3X-KZPEA-DB LVD adapter, carbon
black

257319-B21

Ultrium 460 tape drive, requires 3X-KZPEA-xx, KZPCA-xx, or DEPVZ SCSI adapter, carbon
black; Tru64 UNIX V5.1A requires Patch Kit 4: T64V51AB21AS0004-20030206.tar; Tru64 UNIX
V.1B requires Patch Kit 1: T64v51bb03as0001-20021229.tar; OpenVMS support: minimum V7.2­2

Q1518A

SureStore DAT 40x6i internal auto loader (supported in 274338-B21). See Supported Options
List --

http://www.compaq.com/alphaserver/options/asds10/asds10_options.html

-- for complete listing
of supported options and configuration details. See option specific QuickSpecs for complete list
of country specific SKUs.

C5716A

Preconfigured Configurations

DLT 40/80-GB, 3U rackmount kit, carbon black

274332-B21

DLT 40/80-GB, dual-drive, 3U rackmount kit, carbon black

274335-B21

SDLT 110/220-GB, 3U rackmount kit, carbon black

274331-B21

SDLT 110/220-GB, dual-drive, 3U rackmount kit, carbon black

274334-B21

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 18

5U Rackmount Tape Drive
Enclosure

5U LVD Rackmount Tape Drive Enclosure, carbon black, for use in H9Axx M-Series Cabinets, 0
drives

274339-B21

Rackmount Kit for H9Axx Series Cabinets, carbon black - required for mounting 5U Rackmount
Tape Drive Enclosure in M-Series cabinet

254795-001

NOTE:

The 5U Rackmount Tape Drive Enclosure supports four full-height devices; select up to
four DLT or SDLT devices with 274339-B21, or select preconfigured configurations listed
below.

DLT8000 40/80-GB tape drive, requires 3X-KZPCA-AA LVD adapter, carbon black

146196-B22

SDLT 110/220-GB tape drive, requires 3X-KZPCA-AA or 3X-KZPEA-DB LVD adapter, carbon
black

192106-B25

SDLT 160/320-GB tape drive, requires 3X-KZPCA-AA or 3X-KZPEA-DB LVD adapter, carbon
black

257319-B21

Preconfigured configurations

SDLT 110/220-GB Tape Array III, 5U rackmount kit, carbon black

274336-B21

DLT 40/80-GB Tape Array III, 5U rackmount kit, carbon black

274337-B21

DLT Tape Array III Model 0 enclosure, U.S.

168047-001

Same as above, International

168047-B31

Same as above, Japan

168047-291

Network Storage Routers

NOTE:

The following Network Storage Routers are supported with MSL5000 or ELS9000 tape libraries:

NSR e1200 one Fibre Channel x two LVD FC to SCSI Data Router, Tru64 UNIX and OpenVMS,
carbon black (262672-B21)

3R-A3746-AA

NSR e2400 two Fibre Channel x four LVD FC to SCSI Data Router with card cage, Tru64 UNIX
and OpenVMS, carbon black (262665-B21)

3R-A3935-AA

NSR e2400 two Fibre Channel x four LVD FC to SCSI Data Router with no card cage, Tru64
UNIX and OpenVMS, carbon black (262664-B21)

3R-A3745-AA

NSR N1200 one Fibre Channel x two LVD FC to SCSI Data Router, Tru64 UNIX and OpenVMS,
supports tape drives and tape libraries (280823-B21)

3R-A3747-AA

NSR m2402 two Fibre Channel x four LVD FC to SCSI Data Router, Tru64 UNIX and OpenVMS
262653-B21)

3R-A3740-AA

NSR m2402 two Fibre Channel x four HVD FC to SCSI Data Router, Tru64 UNIX and OpenVMS
(262654-B21)

3R-A3741-AA

NSR ESL e2400-160 two Fibre Channel x four LVD Data Router, Interface Card
(330839-B21)

3R-A4743-AA

NSR MSL e1200-160 one Fibre Channel x two LVD Data Router, CD, graphite

330728-B21

NSR MSL e1200-160 one Fibre Channel x two LVD Data Router, CD, opal

330728-B22

Storage Controllers/Host Bus Adapters for StorageWorks Pedestals and Shelves

Storage controllers require a minimum operating system revision of Tru64 UNIX V4.0F or OpenVMS V7.1-2
unless noted otherwise.

Each storage controller/adapter uses one PCI slot

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 19

Maximum # Supported

Tru64 UNIX

OpenVMS

Linux

PCI-to-Fibre Channel host bus adapter (168794-B21)

2 2

-

DS-KGPSA-CA

PCI to 2–Gb Fibre Channel adapter, 64-bit/33 MHz, single-channel
(261329-B21)

2 2

-

DS-KGPSA-DA

PCI-X to 2-Gb Fibre Channel adapter, 64-bit/66-MHz, single-channel
(302784-B21)
OpenVMS V7.2-2 requires TIMA Kit:
VMS722_FIBRE_SCSI-V0400
OpenVMS V7.3-1 requires TIMA Kit: VMS73_1_SCSI_FIBRE_V0300
OpenVMS V7.3-1 clusters requires TIMA Kit:
VMS73_1_CLUSTER_V0100
Tru64 UNIX V5.1A requires NHD 6 and T64V51AB21AS0004-

20030206.tar
Tru64 UNIX V5.1B requires Patch Kit 1: T64V51BB03AS0001-

20021229.tar
DS-KGPSA-EA does not support MSA 1000

2 2

-

DS-KGPSA-EA

Fibre Channel cable
BNGBX-xx=02, 05, 15, 30, 50 meters (234457-B2x)
234457-B2x=1 (02m), 2 (05m), 3 (15m), 4 (30m), 5 (50m)

BNGBX-xx

PCI-to-Fibre Channel 64-bit adapter, HBA

- -

2

DS-SWLA4-PD

PCI 2-port UltraSCSI single-ended adapter and 10/100 Mb Ethernet
combo adapter

2 2

-

KZPCM-DA

VHDCI male-to-VHDCI male UltraSCSI cable,
xx=02, 2E(2.5), 03, 05, 10, 20 meters)

BN37A-xx

PCI 1-port Ultra2 SCSI (LVD) single-ended adapter, 68-pin HD
connector, requires BN38C cable (2 to 20 meters) to connect to single­ended UltraSCSI shelf

2 2 3

3X-KZPCA-AA

68-pin HD male-to-VHDCI male UltraSCSI cable; required for each
external UltraSCSI shelf attached to KZPCA-AA adapter

BN38C-xx

PCI 2-channel LVD multi-mode Ultra3 SCSI adapter, VHDCI (supported
in dual-bus and single-bus shelves) -- requires use of Ultra160 SCSI
cables.

NOTES

:
Patch kit required, kit is available at:

http://ftp1.support.compaq.com/public/Digital_UNIX/v5.1/

No shared bus support with OpenVMS. No shared tape/library support
with OpenVMS or Tru64 UNIX. 3X-KZPEA-DB adapter supports shared
bus using hard disk drives under Tru64 UNIX V5.1A with PK4 and
NHD5 or V5.1B and TruCluster V5.1B with Initial Patch Kit installed;
supports maximum of two nodes per shared bus; requires 3X-BN55A­01 Y-cable and connector plug assembly, and 3X-H32CT-AA external
LVD terminator per shared bus.
Tru64 UNIX Initial Patch Kit for V5.1B located at:

http://ftp1.support.compaq.com/public/unix/5.1b

Refer to 3X-KZPEA-DB QuickSpecs for complete list of restrictions.

1

(V5.1 or higher)

1

-

3X-KZPEA-DB

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 20

Ultra160 SCSI cables xx=02 for 6 feet, 03 for 12 feet, 04 for 24 feet

3X-BC56J-xx

PCI 1-port UltraSCSI differential adapter; includes external 68-pin HD
connector; requires BN38C-xx cable (2-25 meters) to connect adapter
to Differential UltraSCSI shelf or RAID controller

NOTE:

Internal Connection is not supported.

2 2 2

3X-KZPBA-CC

68-pin HD male-to-VHDCI male UltraSCSI cable; required for each
external UltraSCSI shelf attached to KZPBA-CB adapter

BN38C-xx

PCI 3-channel Ultra2 LVD RAID controller, 64-bit, 64-MB cache

NOTES

:

Connection of RAID controllers directly to DS10 Internal Storage

Cage or Front Access Storage Cage is not supported.

Supported with BA356, DS-SL13R-xx, DS-SSL14-Rx, or 3R-

A4075-AA/3R-A4076-AA shelves only.

" When installed in BA356 shelves, part number DS-BA35X-FC

is required for non-factory installations.

Graphics card is required to run the DS-KZPCC-CE console

utilities (SMOR) with SRM console versions lower than V6.0 or,

alternatively can be run via serial line and terminal emulation

software for SRM V6.0 or higher.

PB2GA-JC/JD graphics cards are not supported.

EV6 systems not supported.

Tru64 UNIX V4.0F requires NHD3 and Patch Kit 4 (BL15) or

later.

Tru64 UNIX V5.1 requires Patch Kit 3 (BL17) and Early Release

Patch C462.

Patch Kit 3 (BL17) is located at: T64V5117-C0046202-11060-

Manual-ER-20010615.tar

Patch C462.02 is located at:

http://ftp1.support.compaq.com/public/unix/v5.1/

TruCluster V5.1 (restricted to non-shared buses only)

2

(V4.0F/

4.0G/

5.1/V5.1A)

- -

DS-KZPCC-CE

PCI 1-channel Ultra2 LVD backplane RAID controller, 64-bit, 16-MB
cache

NOTES

:

Connection of RAID controllers directly to DS10 Internal Storage

Cage or Front Access Storage Cage is not supported.

Supported with BA356, and DS-SL13R-xx or 3R-A4075-AA/3R-

A4076-AA shelves only.

When installed in BA356 shelves, part number DS-BA35X-FC is

required for non-factory installations.

Graphics card is required to run the DS-KZPCC-AC console

utilities (SMOR) with SRM console versions lower than V6.0 or,

alternatively can be run via serial line and terminal emulation

software for SRM V6.0 or higher. PB2GA-JC/JD graphics cards

are not supported.

EV6 systems not supported. Tru64 UNIX V4.0F requires NHD3

and Patch Kit 4 (BL15) or later.

Tru64 UNIX V5.1 requires Patch Kit 3 (BL17) and Early Release

Patch C462.

Patch Kit 3 (BL17) is located at: T64V5117-C0046202-11060-

Manual-ER-20010615.tar

Patch C462.02 is located at:

http://ftp1.support.compaq.com/public/unix/v5.1/

TruCluster V5.1 (restricted to non-shared buses only)

2

(V4.0F/

4.0G/5.1/ V5.1A)

- -

DS-KZPCC-AC

PCI 2-port PCI to Ultra3, 64-bit, 66-MHz, LVD backplane RAID controller

1 1

-

3X-KZPDC-BE

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 21

with 128-MB cache (uses one PCI slot); requires connection to DS­SL13R-xx or 3R-A4075-AA/3R-A4076-AA shelves. Requires use of
Ultra160 SCSI cables.

NOTES:

Connection of RAID controllers directly to DS10 Internal Storage

Cage or Front Access Storage Cage is not supported.

Host-based volume shadowing or shared bus support not

supported under OpenVMS.

Tru64 UNIX support: TruCluster support is restricted to non-

shared buses only. Requires V5.1B with Initial Patch Kit located

at:

http://ftp1.support.compaq.com/public/unix/51b

.

Tru64 UNIX V5.1A support requires patch kit located at

:

http://ftp1.support.compaq.com/public/unix/V5.1a

PCI 4-port PCI to Ultra3, 64-bit, 66-MHz, LVD backplane RAID controller
with 256-MB cache (uses one PCI slot); requires connection to DS­SL13R-xx or 3R-A4075-AA/3R-A4076-AA shelves. Requires use of
Ultra160 SCSI cables.

NOTES:

Connection of RAID controllers directly to DS10 Internal Storage

Cage or Front Access Storage Cage is not supported.

Host-based volume shadowing or shared bus support not

supported under OpenVMS.

Tru64 UNIX support: TruCluster support is restricted to non-

shared buses only. Requires V5.1B with Initial Patch Kit located

at:

http://ftp1.support.compaq.com/public/unix/51b

.
Tru64 UNIX V5.1A support requires patch kit located at:

http://ftp1.support.compaq.com/public/unix/V5.1a

1 1

-

3X-KZPDC-DF

Ultra160 SCSI cables, xx=02 for 6 feet, 03 for 12 feet, 04 for 24 feet

3X-BC56J-xx

PCI 1-port UltraSCSI RAID controller with 4-MB cache memory, includes
RAID Array 230/Plus Subsystem software and documentation kit and
VHDCI female connector; tape drives not supported - 18.2-GB or higher
disk drives not supported on KZPAC-xx RAID controllers. Connection of
RAID controllers directly to DS10 Internal Storage Cage or Front Access
Storage Cage is not supported.

2 2

-

KZPAC-AA

PCI 3-port UltraSCSI RAID controller with 4-MB cache memory, includes
RAID Array 230/Plus Subsystem Software and documentation kit; tape
drives not supported; SCSI cable required for each active port; requires
BN31K-0E for external third-port connection - 18.2-GB or higher disk
drives not supported on KZPAC-xx RAID controllers. Connection of RAID
controllers directly to DS10 Internal Storage Cage or Front Access
Storage Cage is not supported.

2 2

-

KZPAC-CA

PCI 3-port UltraSCSI RAID controller with 8-MB cache memory, includes
RAID Array 230/Plus Subsystem Software and documentation kit; tape
drives not supported; SCSI cable required for each active port; requires
BN31K-0E for external third-port connection - 18.2-GB or higher disk
drives not supported on KZPAC-xx RAID controllers Connection of RAID
controllers directly to DS10 Internal Storage Cage or Front Access
Storage Cage is not supported.

2 2

-

KZPAC-CB

Cache battery backup for KZPAC controller

KZPSC-UB

VHDCI male-to-VHDCI male UltraSCSI cable,
xx=02, 2E(2.5), 03, 05, 10, 20 m)

NOTE:

Manufacturing may substitute BN37A-02 cable for specific

cabinet configurations

BN37A-xx

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 22

SCSI cable/bulkhead assembly kit with KZPAC-CA/CB, allows external
connection of one third port

BN31K-0E

SCSI cable/bulkhead assembly kit, supports two third-port connections
from KZPAC-CA/CB, allows external connection of two third ports

KZPAC-SB

PCI 1-channel Ultra2 SCSI RAID controller, 4-MB cache (Linux-Ready
systems only)

- -

3

SN-KZPBC-AA

PCI 3-channel Ultra2 SCSI RAID controller, 32-MB cache (Linux-Ready
systems only)

- -

3

FR-PCTAR-IB

HVD to LVD Converters

HVD (High Voltage Differential) adapters and LVD (Low Voltage
Differential) devices are normally incompatible due to their different
signaling voltage levels. This incompatibility does not allow direct
communication between the different technologies. The HVD to LVD
converter allows connectivity between legacy HVD Host Bust
Adapters and today's LVD devices. The converter provides:

Connectivity in direct attach or shared configurations of all
currently available LVD devices, including disks, tapes, libraries,
and shelves (4314 or 4354) when used with the KZPBA-CB
and 3X-KZPBA-CC HVD adapters. With the retirement of
StorageWorks 1 disks and HVD shelves (BA36R), converters
are desirable where upgrades to LVD HBAs or upgrades to
current operating system versions are not possible.

Shared and direct attach configurations are interconnected much the
same as those previously configured with homogeneous HVD
solutions, except that the HVD output is now passed through the
converter before proceeding to the LVD device

HVD to LVD one-port rackmount converter (see QuickSpecs for
configuration details)

3X-DWZCV-BA

HVD to LVD two-port rackmount converter (see QuickSpecs for
configuration details)

3X-DWZCV-CA

External Storage Solutions/Controllers
Enterprise Virtual Array

5000

The Enterprise Virtual Array 5000 (EVA5000) is the mid to high-range member of the HP
StorageWorks virtual disk array enabled by VersaStor technology. The EVA5000 is designed for
the data center where there is a critical need for ever-increasing capacity/replication
requirements, performance demands and business continuance needs. Support is provided for
HP StorageWorks Continuous Access, HP StorageWorks Business Copy, and HP OpenView
Storage Operations Management Software. The EVA5000 is a full 2-Gb end-to-end Fibre
Channel Array that operates in 1-Gb, 2-Gb or mixed 1-Gb/2-Gb SAN fabrics.
The EVA5000 is available in pre-defined configurations with controllers and expansion
configurations without controllers. There is also a pre-defined configuration that is optimized for
the High Performance Technical Computing (HPTC) environments. For ordering information and
configuration rules, refer to the EVA5000 QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/11006_div/11006_div.HTML

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 23

Enterprise Virtual Array
3000

The Enterprise Virtual Array 3000 (EVA3000) is the mid-range member of the HP StorageWorks
virtual disk array enabled by VersaStor technology. The EVA3000 is designed for the data
center where there is a critical need for ever-increasing capacity/replication requirements,
performance demands and business continuance needs. Support is provided for HP
StorageWorks Continuous Access, HP StorageWorks Business Copy, and HP OpenView
Storage Operations Management Software. The EVA3000 is a full 2-Gb end-to-end Fibre
Channel Array that operates in 1-Gb, 2-Gb or mixed 1-Gb/2-Gb SAN fabrics.
The EVA3000 is available in one of four integrated "independent bundle" configurations, which
includes one pair of HSV100 controllers, two FC drive enclosures, and 8 to 16 FC hard drives
(bundle dependent). For ordering information and configuration rules, refer to the EVA3000
QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/11619_div/11619_div.HTML

MSA1000 SAN Storage
Array

MSA1000 StorageWorks Modular SAN Array, supported with DS-KGPSA-CA and DS-KGPSA­DA adapters; requires connection via a switch - no direct connect; no support for FC arbitrated
loop. (201723-B22)
Tru64 UNIX V5.1A requires Patch Kit 4: T64V51AB21AS0004-20030206.tar
Tru64 UNIX V5.1B requires Patch Kit 1: T64V51BB03AS0001-20021229.tar
OpenVMS V7.3-1 requires TIMA Kit: VMS731_MSA1000-V0100
OpenVMS V7.3 requires TIMA Kit: VMS73_FIBRE_SCSI-V0500
OpenVMS V7.2-2 requires TIMA Kit: VMS722_FIBRE_SCSI-V0400
See Systems and Options Listing --

http://www.compaq.com/alphaserver/options/asds10/asds10_options.html

-- for configuration

details.

3R-A4328-AA

Fibre Channel Switches

HP supports three product lines of Fibre Channel switch products that may be used to build SAN fabrics. Each
product line provides certain advantages that apply to specific applications. For more information on specific switch
models and selection, please refer to Chapter 2 in the SAN Design Guidelines:

http://www.hp.com/go/SANDesignGuide

The B-Series product line includes a wide range of Fibre Channel switches, described as "SAN switches" and "Core
switches." Products in this family include switches from the HP StorageWorks SAN Switch 2/16 to the HP
StorageWorks Core Switch 2/64. This product line includes switches with 8, 16, 32, and 64 ports, including both full­function and entry-level models. The HP StorageWorks Core Switch 2/64 includes a pair of independent 64-port
switches in a single chassis with a high level internal redundancy.

The C-Series product line includes the Cisco MDS 9506 and 9509 Multilayer Directors and the Cisco MDS 9216, 9120,
and 9140 Multilayer Fabric Switches. The MDS 9506 is supported with 224 ports, over seven modular chassis
consisting of both 16-port and 32-port modules. The MDS 9506 is supported with 128 ports, over four modular
chassis consisting of both 16 port and 32 port modules. The MDS 9216 has a basic configuration with 16 ports. It
has an expansion slot that supports either a 16- or a 32-port card, for 32 or 48 ports in total.

The M-Series Fabric product line includes a wide range of Fibre Channel switches described as "Directors" and
"Edge switches." A partial list of products in this family includes the HP StorageWorks Director 2/140 and the HP
StorageWorks Edge Switch 2/32. This product line includes switches with 16, 24, 32, 64, and 140 ports internal
microcode. The HP StorageWorks Director 2/64 and 2/140 switches have a high level of internal redundancy.

For part number and configuration information, see the SAN infrastructure switch information at

http://www.hp.com/go/san

Also, See Supported Options List at --

http://www.compaq.com/alphaserver/options/asds10/asds10_options.html

--

for complete listing of supported options and configuration details.

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 24

Fibre Channel Disk Drives

36-GB 10K rpm dual-port 2-Gb/sec FC-AL 1-inch (25.4mm) drive (238590-B21)

3R-A3239-AA

72-GB 10K rpm dual-port 2-Gb/sec FC-AL 1-inch (25.4mm) drive (238921-B21)

3R-A3260-AA

146-GB 10K rpm dual-port 2-Gb/sec FC-AL 1-inch (25.4mm) drive (293556-B21)

3R-A3975-AA

36-GB 15K rpm dual-port 2-Gb/sec FC-AL 1-inch (25.4mm) drive (236205B21)

3R-A3210-AA

72-GB 15K rpm dual-port 2-Gb/sec FC-AL 1-inch (25.4mm) drive (293568-B21)

3R-A3971-AA

StorageWorks Universal
Drive Shelves – Model
4314R (Ultra3)

StorageWorks Model 4314R Ultra3 SCSI (LVD) single bus, Universal drive rackmount shelf, North
America and International, except Japan

DS-SL13R-AA

Same as above, Japan

DS-SL13R-AJ

StorageWorks Universal
Drive Shelves – Model
4354R (Ultra3)

StorageWorks Model 4354R Ultra3 SCSI (LVD), dual bus, Universal drive rackmount shelf, North
America and International, except Japan

DS-SL13R-BA

Same as above, Japan

DS-SL13R-BJ

StorageWorks Modular
Smart Array 3000

(Ultra320)

StorageWorks Modular Smart Array SW4414R Single Bus Ultra320 Rackmountable SCSI Disk
Drive 4-node Storage Enclosure (302969-B21). See Systems and Options Listing for
configuration details.

3R-A4075-AA

StorageWorks Modular Smart Array SW4454R Dual Bus Ultra320 Rackmountable SCSI Disk Drive
4-node Storage Enclosure (302970-B21).
See Supported Options List at --

http://www.compaq.com/alphaserver/options/asds10/asds10_options.html

-- for configuration

details.

3R-A4076-AA

NOTE:

* 3R-A4075-AA and 3R-A4076-AA are not supported in a shared-SCSI cluster using the

3X-KZPEA-DB.

StorageWorks Universal
Drive Shelves – Model
4314T (Ultra3)

StorageWorks Model 4314T, Ultra3, Universal Drive Shelves Single Bus, Tower, U.S. (190210-

001)

DS-SL13T-AA

StorageWorks Model 4314T, Ultra3, Universal Drive Shelves Single Bus, Tower, International
(190210-B31)

DS-SL13T-AB

StorageWorks Model 4314T, Ultra3, Universal Drive Shelves Single Bus, Tower, Japan (190210-

291)

DS-SL13T-AJ

StorageWorks Universal
Drive Shelves – Model
4200 to Model 4300
Upgrade I/O Modules

StorageWorks Model 4300 Ultra 160 single-port LVD I/O Module (190212-B21)

DS-SE3ZJ-DA

StorageWorks Model 4300 Ultra 160 dual-port LVD I/O Module (190213-B21)

DS-SE3ZJ-SA

System Disk Drives

(Supported in Model 4314R,
4314T, or 4354R Universal
Drive Shelves)

18.2-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive

3R-A3848-AA

36.4-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive

3R-A3838-AA

36.4-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive

3R-A3849-AA

72.8-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive

3R-A3839-AA

72.8-GB Ultra320 SCSI 15,000 rpm 1-inch Universal disk drive

3R-A3851-AA

146-GB Ultra320 SCSI 10,000 rpm 1-inch Universal disk drive

3R-A3841-AA

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 25

Enterprise Virtual Array
Model 8C8D

Enterprise Virtual Array Model 8C8D 60-Hz, includes 42U opal storage cabinet, four M3220
controller assembly with eight HSV110 controllers, eight M5214 dual FC loop 14-bay drive
enclosures

239782-001

Enterprise Virtual Array Model 8C8D 50-Hz, includes 42U opal storage cabinet, four M3220
controller assembly with eight HSV110 controllers, eight M5214 dual FC loop 14-bay drive
enclosures

249977-B21

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 26

Step 7 - UltraSCSI RAID Array Controllers -

Optional

StorageWorks Disk Array
Family

NOTE:

The HP StorageWorks Disk Array Family, specifically the XP128 and XP1024, are now supported on
AlphaServer DS10 systems. For product and ordering information, refer to the following Web pages:

http://www.hp.com/products1/storage/products/disk_arrays/highend/xp1024/index.html
http://www.hp.com/products1/storage/products/disk_arrays/highend/xp128/index.html

The following part numbers have been assigned for reference purposes only:

3R-A4417-AA

A7876A

XP128 Disk Array Control Frame

3R-A4418-AA

A7906A

XP1024 Disk Array Control Frame

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 27

Step 8 - Networks and Communications

- Optional

Reference individual product information for operating system support.
Systems include dual embedded 10/100 BaseT Ethernet ports (BN25G-xx cable

must be ordered separately)
Additional Ethernet ports can be added using available PCI slots

Maximum # Supported

Tru64 UNIX

OpenVMS

Linux

Ethernet 10/100/1000

Single-port 100Mbps (MMF/duplex-SC) add-on daughter card for use
with 3X-DE602-BB. The combined 3X-DE602-BB 3X-DE602-FA
provides two 10/100 (UTP/RJ45s) and one 100Mbps (MMF/SC) ports in
a single PCI slot option. Maximum two per system, maximum ten 10/100
Ethernet ports supported per system. Use BN34A or BN34B cables.

NOTE:

The 3X-DE602-FA cannot be used standalone.
Two 10/100 Ethernet ports included with DS10 system.

2 1

-

3X-DE602-FA

PCI (32-/64-bit, 33-/66-MHz) dual-port 10/100 Ethernet (UTP/RJ45s) NIC
and Base Module. (One 3X-DE602-TA or 3X-DE602-FA optional add-on
daughter card can be combined with this module.) Maximum two per
system, maximum ten 10/100 Ethernet ports per system.
Use BN25G, BN26M, BN24Q, or BN28Q twisted pair RJ45 cables.

NOTE:

Two 10/100 Ethernet ports included with DS10 system.

2 2

-

3X-DE602-BB

Dual-port 10/100 Ethernet (UTP/RJ45) add-on daughter card for use
with the 3X-DE602-BB only. The combined 3X-DE602-BB and 3X­DE602-TA modules provide four 10/100 (UTP/RJ45s) ports in a single
PCI slot option; allows for a maximum of 16 ports per system. Maximum
two per system, maximum ten 10/100 Ethernet ports per system.
Use BN25G, BN26M, BN24Q, or BN28Q twisted pair RJ45 cables.

NOTES

:

The 3X-DE602-TA cannot be used standalone.
OpenVMS V7.3 requires Tima Kit:
DEC-AXPVMS-VMS73_LAN-V0100-4.PCSI
OpenVMS V7.2-2H1 requires OpenVMS Tima Kit located at:

http://ftp.support.compaq.com/patches/.new/openvms.shtml

Two 10/100 Ethernet ports included with DS10 system.

2 2

-

3X-DE602-TA

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 28

Cable for 10BaseT twisted pair connection

BN25G-xx

PCI (32-/64-bit, 33-/66-MHz) single-port 1000 Mbps (MMF/SC) NIC; no
on-board boot-ROM support. Use BN34A or BN34B cables.

1 1 1

DEGPA-SA

PCI single-port 1000 Mbps (MMF with duplex-SC) Gigabit Ethernet

NOTES

:

Requires OpenVMS V7.3-1 plus TIMA kits located at DEC­AXPVMS-VMS731_ PCSI_V0100-4.PCSI then DEC-AXPVMS­VMS731_LAN_V06004.PCSI
Tru64 UNIX V5.1A requires Patch Kit 004 ­T64V51AB21AS0004-20030206.tar and Early Release Patch Kit

- T64V51AB21-C0127901-19213-E-20030710.tar
Tru64 UNIX V5.1B requires Patch Kit 2 - T64V51BB22AS0002-

20030415.tar and Early Release Patch Kit to update driver to
v1.0.21 - Early Release Patch Kit - T64V51BB22-C0019200­1912-E-20030710.tar

Use BN34A, BN34B, or equivalent cables with SC connectors.

2 2

-

3X-DEGXA-SA

PCI single-port 10/100/1000Mbps (Twisted-Pair Copper with RJ45)
Gigabit Ethernet

NOTES

:

Requires OpenVMS V7.3-1 plus TIMA kits located at DEC­AXPVMS-VMS731_ PCSI_V0100-4.PCSI then DEC-AXPVMS­VMS731_LAN_V06004.PCSI
Tru64 UNIX V5.1A requires Patch Kit 004 ­T64V51AB21AS0004-20030206.tar and Early Release Patch Kit

- T64V51AB21-C0127901-19213-E-20030710.tar
Tru64 UNIX V5.1B requires Patch Kit 2 - T64V51BB22AS0002-

20030415.tar and Early Release Patch Kit to update driver to
v1.0.21 - Early Release Patch Kit - T64V51BB22-C0019200­1912-E-20030710.tar

Use BN25G, BN26M, BN24Q, BN28Q twisted pair RJ45 cables.

2 2

-

3X-DEGXA-TA

Multi-function Ethernet 10/100

PCI combo adapter, Permedia P2 graphics, 10/100 NIC, 1-port SCSI

1 1

-

3X-DEPVZ-AA

3X-DEPVZ-AA specific-use 3-meter LVD2 SCSI cable

BN37A-03

PCI-to-Gigabit Ethernet adapter – UTP, with RJ45 (no boot support)

1 1 1

DEGPA-TA

FDDI

PCI FDDI adapter, single attachment station (SAS), multi-mode fiber
(MMF), SC connector

1 1

-

3X-DEFPA-AC

PCI (32-bit, 33-MHz) to FDDI DAS (MMF/duplex-SC) NIC.
Use BN34A, BN34B, or BN34D cables.

1 1

-

3X-DEFPA-DC

FDDI-specific cable - Multimode fiber optic (MMF) 62.5/125um duplex
cable with SC-to-MIC connectors.

-xx = available lengths: (01, 03, 10) for 1, 3, 10 meters

BN34D-xx

SC-to-SC dual fiber optic cable mm, pp xx = length in meters

BN34B-xx

PCI (32-bit, 33-MHz) to FDDI SAS (UTP/RJ45) NIC.
Use BN25G, BN26M, BN24Q, or BN28Q twisted pair RJ45 cables.

1 1

-

3X-DEFPA-UC

PCI (32-bit, 33-MHz) to FDDI DAS (UTP/RJ45s) NIC.
Use BN25G, BN26M, BN24Q, or BN28Q twisted pair RJ45 cables.

1 1

-

3X-DEFPA-MC

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 29

ATM

PCI (32-bit, 33-MHz) to 155 Mbps ATM, copper NIC with RJ45
connector.
Use BN25G-xx, or BN26M-xx cables.

2

(V4.0F)

2

(V7.2-1)

-

3X-DAPBA-UA

PCI (32-bit, 33-MHz) to 155 Mbps ATM fiber NIC with SC connector.
Use BN34B-xx cable.

2

(V4.0F)

2

(V7.2-1)

-

3X-DAPBA-FA

Asynchronous Communications (ASYNC)

PCI (32-bit, 33-MHz) to quad-port Async Communications NIC with DB­25 octopus cable

PBXDA-BA

PCI (32-bit, 33-MHz) to 8-port Async Communications NIC with DB-25
octopus cables

PBXDA-BB

PCI 16-port asynchronous controller, cable included; maximum three
PBXDA-Ax per system

3

(V4.0F)

3

-

PBXDA-AC

PBXDA-AC Asynchronous Connector Adapters

RJ45 to DB-25 converter cable

CXI01-AC

RJ45 to DEC MJ11 converter cable (8 pack)

CXI01-AF

Synchronous Communications

(SYNC)

PCI (32-bit, 33-MHz) to dual-port intelligent synchronous
communications NIC. Requires at least one (maximum two) BN34x
synchronous cable listed below.

2 2

-

3X-PBXDD-AA

PCI (32-bit, 33-MHz) to quad-port intelligent synchronous
communications NIC. Requires at least one (maximum four) BN34x
synchronous cable listed below.

2 2

-

3X-PBXDD-AB

Synchronous-Specific Cables

EIA-530 single-port cable

3X-BC34G-06

V.24/EIA-232 single-port cable

3X-BC34L-06

V.11/x.21 single-port cable

3X-BC33S-06

V.35 single-port cable

3X-BC34T-06

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 30

Ethernet, FDDI, ATM Multi-use Cables

Multimode fiber optic (MMF) 62.5/125um duplex cable, with SC-to-ST
connectors.
–xx = available lengths: (2E, 4E, 01, 03, 10, 20, 30) for 2.4, 4.5, 1, 3,
10, 20, 30 meters

BN34A-xx

Multimode fiber optic (MMF) 62.5/125um duplex cable, with SC-to-SC
connectors.

-xx = available lengths: (2E, 4E, 01, 03, 10, 20, 30) for 2.4, 4.5, 1, 3, 10,
20, 30 meters

BN34B-xx

Category 5e (4-Unshielded Twisted Pairs / UTP) straight-through cable
with RJ45-to-RJ45 connectors for system to switch, repeater, or hub
connectivity.

-xx = available lengths: (0B, 0E, 01, 03, 04, 07) for 0.2, 0.5, 1, 3, 4, 7
meters

BN25G-xx

Category 5e (4-Twisted Pairs, Screened/ ScTP) straight-through cable
with RJ45-to-RJ45 connectors for system to switch, repeater, or hub
connectivity.

-xx = available lengths: (0E, 01, 03, 04, 07) for 0.5, 1, 3, 4, 7 meters

BN26M-xx

Category 5e (4-Unshielded Twisted Pairs / UTP) Xover cable with
RJ45-to-RJ45 connectors for system to switch, repeater, or hub
connectivity.

-xx = available lengths: (0E, 01, 03, 04, 07) for 0.5, 1, 3, 4, 7 meters

BN24Q-xx

Category 5e (4-Twisted Pairs, Screened / ScTP) Xover cable with
RJ45-to-RJ45 connectors for system to switch, repeater, or hub
connectivity.

-xx = available lengths: (0E, 01, 03, 04, 07) for 0.5, 1, 3, 4, 7 meters

BN28Q-xx

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 31

Step 9 - Graphics Adapters

- Optional

RAID Configuration Utility is accessible via console port for Tru64 UNIX and OpenVMS
systems; optional graphics capability available

Select graphics adapter, monitor, and country-specific keyboard if required
Open3D license ships with PowerStorm 300/350 graphics accelerators - Open3D drivers

and libraries ship with either the operating system or graphics accelerator.

Maximum # Supported

Tru64 UNIX

OpenVMS

Linux

ATI RADEON 7500 64-MB PC I 2D/3D Graphics Accelerator

NOTE:

Only RADEON 7500 PCI cards can be used in a multi-card
environment. For multi-head support, refer to Read Me First
document/Release Notes.

Tru64 UNIX requires V5.1B with Patch Kit 1: Tru64V51BB03AS0001-

20021229.tar
OpenVMS requires V7.3-1 with TIMA Kit: DEC-AXPVMS­VMS731_GRAPHICS-V0200--4.PCSI

4 - (2D only)

1 - 3D

Dual head on first

card only (unique

video using DVI

port for 2D or 3D)

V5.1B

4 - 2D/3D

Dual head on first

card only (cloned

video using DVI

port for 2D or 3D)

V7.3-1

-

3X-PBXGG-AA

Tru64 UNIX Open 3D license for RADEON 7500 (required for 3D
functionality)

QL-6ZRA9-AA

OpenVMS Open3D license for RADEON 7500 (required for 3D
functionality)

QL-0ADA9-AA

Additional Tru64 UNIX media kit for RADEON 7500 (initial kit ships with
RADEON 7500 card)

QA-6ZRAA-H8

Additional OpenVMS media kit for RADEON 7500 (initial kit ships with
RADEON 7500 card)

QA-6ZPAA-H8

PowerStorm 300 3D multi-head graphics accelerator with 15-MB frame
buffer memory and 16-MB texture memory

3 3

-

SN-PBXGD-AD

PowerStorm 350 3D multi-head graphics accelerator with 30-MB frame
buffer memory and 32-MB texture memory

3 3

-

SN-PBXGD-AE

PCI combo adapter, Permedia P2 graphics, 10/100 NIC, 1-port SCSI

1 1

-

3X-DEPVZ-AA

Step 10 - Monitors

- Optional

Graphics monitors other than those listed below can be used if compatible with SVGA
graphics ordered with system.

A video cable, 6-foot/1.8-meter length, is included with all variants of monitors.
Video extension cable required if monitor is located more than 1.5-meters from system.
Monitors ship with, but are not integrated with the system.

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 32

Carbon/Silver Monitors

V7550 17-inch (16-inch viewable image size) flat-faced shadow mask color monitor, two-tone
(carbon/silver), 0.25mm dot pitch, VGA to 1024 x 768 @85 Hz, MPRII/TCO99/Energy Star
compliant, Northern Hemisphere with North America power cord, VGA cable

3R-A4002-AA

Same as above, with Euro power cord

3R-A4201-AA

Same as above, APD, no power cord

3R-A4202-AA

Same as above, Southern Hemisphere, with Australia/New Zealand power cord

3R-A4203-AA

S7500 17-inch (16-inch viewable image size) FST multi-frequency color monitor, 2-tone
(carbon/silver), 0.24-mm dot pitch, VGA to 1024 x 768 @85 Hz, MPRII/TCO 99/Energy Star
Compliant, Northern Hemisphere with PRC power cord CCIB, VGA cable

3R-A4800-AA

P930 19-inch (18-inch viewable image size) auto-scanning color monitor, Diamondtron NF, 0.24­mm aperture grille pitch, VGA to 1600 x 1200 @85 Hz, MPRII/TCO 99/Energy Star Compliant,
Northern Hemisphere with North America power cord, VGA cable

3R-A4215-AA

Same as above, with Euro power cord

3R-A4391-AA

Same as above, Taiwan, with North America power cord

3R-A4392-AA

Same as above, Southern Hemisphere, 0.25 to 0.27 mm aperture grille pitch, with Australia/New
Zealand power cord

3R-A4393-AA

S9500 19-inch (18-inch viewable image size) FST multi-frequency color monitor, 2-tone
(carbon/silver), 0.24-mm dot pitch, VGA to 1280 x 1024 @85 Hz, MPRII/TCO 99/Energy Star
Compliant, Northern Hemisphere with PRC power cord CCIB, VGA cable

3R-A4801-AA

P1130 21-inch (19.8-inch viewable image size) FD Trinitron auto-scanning color monitor, 0.24­mm aperture grille pitch, VGA to 1792 x 1344 @85Hz, dual video input, USB Hub, MPRII/TCO
99/Energy Star Compliant, Northern Hemisphere with North America power cord, VGA cable

3R-A4216-AA

Same as above, with Euro power cord

3R-A4396-AA

Same as above, Taiwan, no power cord

3R-A4397-AA

Same as above, with PRC power cord, CCIB

3R-A4400-AA

Same as above, Southern Hemisphere, with Australia/New Zealand power cord

3R-A4398-AA

Carbon/Silver Flat Panel
Monitors

TFT1825, 18-inch (18-inchviewable image size) TFT flat panel monitor, 0.28mm pixel pitch, 1600
x 1200 @60Hz, multi-mode support, MPRII/TCO99/Energy Star compliant, one VGA, one DVI-I
input connector, North America power cord, VGA and DVI-I cables

3R-A4292-AA

L1530, 15-inch (15-inch viewable image size) TFT flat panel monitor, 0.297 mm pixel pitch, 1024
x 768 @60 Hz, multi-mode support, MPRII/TCO99/Energy Star compliant, two video input
connectors (one VGA and one DVI-I), North America power cord, VGA and DVI-I cables

3R-A4857-AA

L1530, 15-inch (15-inch viewable image size) TFT flat panel monitor, 0.297 mm pixel pitch, 1024
x 768 @60 Hz, multi-mode support, MPRII/TCO99/Energy Star compliant, two video input
connectors (one VGA and one DVI-I), Euro power cord, VGA and DVI-I cables

3R-A4858-AA

Video Extension Cable

6-foot/1.8-meter video extension cable

BN39C-02

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 33

Monitor Power Cords

North America

BN26J-1K

Australia, New Zealand, 2.5-meter (103541-011)

BN19H-2E

Central Europe, 2.5-meter

BN19C-2E

Denmark, 2.5-meter (103541-481)

BN19K-2E

Egypt, India, South Africa, 2.5-meter (103541-AR1)

BN19S-2E

Israel, 2.5-meter

BN18L-2E

Italy, 2.5-meter (103541-461)

BN19M-2E

Japan, 2.5-meter, Dentori approved

3X-BN46F-02

Switzerland, 2.5-meter (103541-511)

BN19E-2E

UK, Ireland, 2.5-meter

BN19A-2E

Step 11 - Keyboards, Mouse

Keyboards are not included with the system and must be ordered separately
Selection of country-specific keyboard is recommended
Select an opal OpenVMS keyboard for use with VT5xx text terminals.

NOTE:

The 3X-LK463-xx is a dual-personality keyboard that can be used with a USB or PS/2

port.

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 34

Opal

Carbon

Keyboard/Language

OpenVMS

Tru64 UNIX

OpenVMS

U.S. keyboard

LK461-A2

3R-A4362-AA

3X-LK463-A2

Arabic keyboard

-

3R-A4348-AA

-

Belgian keyboard

LK461-AB

3R-A4349-AA

3X-LK463-AB

BHCSY keyboard

-

3R-A4350-AA

-

Canadian/English keyboard

LK461-AQ

-

3X-LK463-AQ

Canadian/French keyboard

LK461-AC

3R-A4351-AA

3X-LK463-AC

Cyrillic keyboard (Russian)

LK461-BT

3R-A4352-AA

3X-LK463-BT

Czech keyboard

LK461-BV

3R-A4353-AA

3X-LK463-BV

Danish keyboard

LK461-AD

3R-A4354-AA

3X-LK463-AD

Dutch keyboard

LK461-AH

3R-A4355-AA

3X-LK463-AH

Finnish keyboard

LK461-AF

3R-A4356-AA

3X-LK463-AF

French keyboard

LK461-AP

3R-A4357-AA

3X-LK463-AP

German keyboard

LK461-AG

3R-A4358-AA

3X-LK463-AG

Greek keyboard

LK461-BH

3R-A4359-AA

3X-LK463-BH

Hebrew keyboard

LK461-AT

3R-A4360-AA

3X-LK463-AT

Hungarian keyboard

LK461-BQ

3R-A4361-AA

3X-LK463-BQ

International keyboard

-

3R-A4362-AA

-

Italian keyboard

LK461-AI

3R-A4363-AA

3X-LK463-AI

Japanese keyboard

-

3R-A4364-AA

-

Korean keyboard

-

3R-A4365-AA

-

Latin-American keyboard

-

3R-A4366-AA

-

Norwegian keyboard

LK461-AN

3R-A4367-AA

3X-LK463-AN

Polish keyboard

LK461-BP

3R-A4368-AA

3X-LK463-BP

Portuguese keyboard

LK461-AV

3R-A4369-AA

3X-LK463-AV

Romanian keyboard

LK461-BL

-

3X-LK463-BL

Simplified Chinese keyboard

-

3R-A4370-AA

-

Slovak keyboard

LK461-CZ

3R-A4371-AA

3X-LK463-CZ

Spanish keyboard

LK461-AS

3R-A4372-AA

3X-LK463-AS

Swedish keyboard

LK461-AM

3R-A4373-AA

3X-LK463-AM

Swiss/French keyboard

LK461-AK

3R-A4374-AA

3X-LK463-AK

Swiss/German keyboard

LK461-AL

-

3X-LK463-AL

Traditional Chinese keyboard

-

3R-A4375-AA

-

Thai keyboard

-

3R-A4376-AA

-

Turkish Q keyboard

LK461-BU

3R-A4377-AA

3X-LK463-BU

Turkish/F keyboard

LK461-BW

-

3X-LK463-BW

UK keyboard

-

3R-A4378-AA

-

Yugoslavian keyboard

LK461-BY

-

3X-LK463-BY

Mouse - Recommended

3-button mouse - carbon

3R-A4565-AA

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 35

Step 12 - Console Terminal

- Optional

Any terminal can be used as a console device.
Third-party console devices require an EIA-232 25-pin DSUB connector.

VT510 video terminal; requires H8575-x cable, either male or female

VT510-xx

Console cable, female connector

H8575-A

Console cable, male connector

H8575-D

Console cable, male connector (IBM compatible)

H8575-E

Step 13 - MEMORY CHANNEL

- Optional

Tru64 UNIX Systems

Requires Tru64 UNIX V5.0A or later and either TruCluster Server license
(QL-6BRAC-AA) or TruCluster Plus Software Package (QP-6R9AC-AA)

OpenVMS Systems

Requires OpenVMS V7.1-2 or later and OpenVMS Cluster license
(QL-MUZAC-AA)

Configuring Information

Up to two PCI-to-System Area Network adapters (CCMAB-BA) are supported in a single
system.
Two-node clusters can be configured by ordering a CCMAB-BA for each node and one
BN39B-04 or BN39B-10 cable; cable connects directly to CCMAB-BA in each node.
For a two-node cluster that will not need to be rebooted when adding additional
members, order one CCMAB-BA adapter and one BN39B-04 or BN39B-10 cable for each
node, and one CCMHB-AA hub for the cluster.
For three- or four- node clusters, order one CCMAB-BA adapter and one BN39B-04 or
BN39B-10 cable for each node, and one CCMHB-AA hub for the cluster
CCMHB-AA includes four CCMLB-AA line cards and supports up to four nodes;
expansion up to eight system nodes can be achieved by adding up to four CCMLB-AA
line cards.
If two CCMAB-AAs are configured in each system, a second CCMHB-AA is required for
greater than 2 node configurations.
If nodes must be separated by a distance longer than standard copper cables allow the
CCMFB option converts the output of the standard CCMAB controller or CCMLB line card
to single-mode fiber optic cable. The fiber optic connection may be up to 2,000 meters
long between two CCMAB controllers connected in virtual hub mode, or 3,000 meters
between a CCMAB controller and a CCMHB hub. (The connection from the CCMHB hub to
a second system may also be 3,000 meters.) The CCMFB option requires a second PCI
slot in the system from which it draws power only. It is normally connected to the
prerequisite CCMAB controller with the short BN39B-01 cable provided with the CCMFB.
The CCMFB is also used in the CCMHB hub where it occupies a slot normally used by the
CCMLB line card, limiting expansion to four radial fiber optic connections.
CCMHB-BA hub does not contain any line cards and can be used to plug in up to eight
CCMFB fiber optic converters. Two standard length single-mode fiber optic cables are
available (BN34R-10 and BN34R-31); however, users normally provide this fiber optic
connection. Fiber optic connectivity is completely transparent to the systems using it and
has no performance impact.
For integration of MEMORY CHANNEL hubs into cabinet configurations, a rackmount kit
(2T-MAVRK-AA) and power cord (BN35S-02) are required
Please refer to Systems and Options Listing at -

http://www.compaq.com/alphaserver/options/asds10/asds10_options.html

for additional

configuration information and restrictions.

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 36

MEMORY CHANNEL
Controller

PCI System Area Network Controller, maximum two

CCMAB-BA

System Area Network Hub with four line cards; includes BN19P-2E power cord for Canada,
Japan, and U.S. operations- for other regions, order appropriate power cord from list below

CCMHB-AA

Hub expansion box with no line cards

CCMHB-BA

Expansion line card for CCMHB hub

CCMLB-AA

1-meter cable for CCMAB and CCMHB

BN39B-01

4-meter cable for CCMAB and CCMHB

BN39B-04

10-meter cable for CCMAB and CCMHB

BN39B-10

Copper-to-single mode fiber optic converter - requires BN34R-xx fiber optic connection

CCMFB-BA

Rackmount kit for CCMHB hub

2T-MAVRK-AA

Power cord for rackmount CCMHB hub

BN35S-02

MEMORY CHANNEL Power
Cords

Australia, New Zealand and China (103541-011)

BN19H-2E

Central Europe

BN19C-2E

Denmark (103541-481)

BN19K-2E

Egypt, India (103541-AR1)

BN19S-2E

Ireland, United Kingdom

BN19A-2E

Israel

BN18L-2E

Italy (103541-461)

BN19M-2E

Switzerland (103541-511)

BN19E-2E

Step 14 - Floor Stand

Floor Stand

Floor Stand for AlphaServer/AlphaStation DS10

3X-BA73P-AA

Step 15 - Software

- Required selection of media and documentation for first system on site

Tru64 UNIX

Software processor code = E
AlphaServer DS10 Tru64 UNIX systems include Base license, Unlimited User

license, Server Extension license, Internet Express, and Secure Web Server
AlphaStation DS10 Tru64 UNIX systems include 2-user Base license

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 37

When using Tru64 UNIX
V5.0A or later

Tru64 UNIX media and online documentation on CD-ROM

QA-6ADAA-H8

Tru64 UNIX full hard copy documentation

QA-6ADAA-GZ

TruCluster Plus Software Package with licenses for TruCluster Server, Logical Storage
Manager, and AdvFS Utilities

QP-6R9AC-AA

TruCluster Server License

QL-6BRAC-AA

AdvFS Utilities License

QL-0EGAE-AA

Logical Storage Manager License

QL-2GVAE-AA

Advanced Server for Tru64 UNIX, 25 client concurrent use license

QL-5U29M-3D

Advanced Server for Tru64 UNIX, 50 client concurrent use license

QL-5U29M-3E

Advanced Server for Tru64 UNIX, 100 client concurrent use license

QL-5U29M-3F

Advanced Server for Tru64 UNIX, 250 client concurrent use license

QL-5U29M-3G

Advanced Server for Tru64 UNIX, 500 client concurrent use license

QL-5U29M-3H

Layered products media and documentation for Tru64 UNIX on CD-ROM

QA-054AA-H8

DECnet/OSI end-system license for Tru64 UNIX

QL-MTJAE-AA

DECnet/OSI extended function license for Tru64 UNIX

QL-MTKAE-AA

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 38

OpenVMS

AlphaServer DS10 OpenVMS systems include Base license with System Manager
license and Enterprise Integration Server License Package for OpenVMS Revision
V3.0A.

AlphaStation DS10 OpenVMS systems include Base license, Concurrent
Use1-user license, and NAS 150 Client license.

Enterprise Integration Package includes licenses for TCP/IP Services for OpenVMS,
DECwindows Motif for OpenVMS Alpha, DECprint Supervisor for OpenVMS Alpha Plus,
DECprint Supervisor for OpenVMS Open, DECnet-Plus for OpenVMS Alpha End System,
Archive/Backup System for OpenVMS Management Tools, Archive/Backup Agent for
Windows NT, OpenVMS Disk Services for Windows NT, Office Server for OpenVMS,
PATHWORKS 32, PATHWORKS V6 for OpenVMS – Advanced Server, and DIGITAL
Office Server Client Access License

OpenVMS V7.1-2 media and online documentation on CD-ROM

QA-MT1AR-H8

OpenVMS V7.2-1 media and online documentation on CD-ROM

QA-MT1AT-H8

OpenVMS media and online documentation on CD-ROM

QA-MT1AA-H8

OpenVMS hard copy documentation

QA-001AA-GZ

Layered products media and documentation for OpenVMS on CD-ROM

QA-03XAA-H8

OpenVMS Concurrent Use licenses provide the right to interactively use the operating
system by the specified number of concurrent users on a designated OpenVMS system.
OpenVMS Concurrent Use licenses can be moved from one system to another at user
discretion and can be shared in a mixed OpenVMS VAX and OpenVMS Alpha cluster.

OpenVMS Traditional Unlimited Use license is system specific and can only be used on
one single system at a time. It cannot be shared between systems or in an OpenVMS
VAX or OpenVMS Alpha Cluster.

Concurrent Use 1-user license

QL-MT3AA-3B

Concurrent Use 2-user license

QL-MT3AA-3C

Concurrent Use 4-user license

QL-MT3AA-3D

Concurrent Use 8-user license

QL-MT3AA-3E

Concurrent Use 16-user license

QL-MT3AA-3F

Concurrent Use 32-user license

QL-MT3AA-3G

Concurrent Use 64-user license

QL-MT3AA-3H

Concurrent Use 128-user license

QL-MT3AA-3J

Concurrent Use 256-user license

QL-MT3AA-3K

Traditional Unlimited User license

QL-MT2AE-AA

OpenVMS Cluster license for Alpha systems

QL-MUZAC-AA

OpenVMS Cluster Client license for Alpha systems

QL-3MRAC-AA

OpenVMS Cluster Client-to-Full OpenVMS Cluster Migration license

QL-6J7AC-AA

Linux Kit

- Optional

Linux Red Hat CD-ROM Kit

QA-6M1AA-H8

Step 16 - Hardware and Software Support Services

Hardware and Software
Support Services

Select one of the optional HP Care Pack Service Packages described below that best
supports the customer's operational requirements for system availability.

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 39

HP Care Pack Services

HP Care Pack Services are available for AlphaServer/AlphaStation systems running
Tru64 UNIX or OpenVMS operating systems. HP Care Pack Services are designed for
customers who require support beyond that provided by the hardware warranty with
coverage for both Principal servers/stations and SSPs (Subsequent System Packages) ­that meet a full range of customer support requirements.

Program Features – Principal Server/Station
HP Support Plus

13 x 5 HW/SW support
4-hour response on-site hardware support
2-hour response for software support
License Subscription for HP O/S software and embedded L/P (i.e., EIS for OpenVMS,
unlimited users, and server extensions for Tru64 UNIX)
Consolidated Software Media Update Distribution for OpenVMS or Tru64 UNIX and their
layered products. (Layered products not included on Consolidated Media Update
Distribution can be ordered separately.)

HP Support Plus 24

24 x 7 HW/SW support
Named HW engineer
4-hour response on-site hardware support
2-hour response for software support
License Subscription for HP O/S software and embedded L/P (i.e., EIS for OpenVMS,
unlimited users, and server extensions for Tru64 UNIX)
Consolidated Software Media Update Distribution for OpenVMS or Tru64 UNIX and their
layered products. (Layered products not included on Consolidated Media Update
Distribution can be ordered separately.)

Program Features – Additional Services
SSPs

(Subsequent System

Packages)

For HP Care Pack Support Plus and Support Plus 24
HW Support at same level as corresponding package for Principal server/station
License Subscription: HP O/S (where applicable)
Telephone support through Principal server/station covered by full support package

Installation

Pre-installation review
Unpacking of equipment
Assemble and test
Basic product usage info
No software installation added

Installation & Startup HP
O/S

Pre-installation review
Unpacking of equipment
Assemble and test
Basic product usage info
Install operating systems
Product configuration
Print and network access
Orientation

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 40

Model/HP Care Pack
Services

Principal Server/
Station 1 year

Principal Server/
Station 3 years

Subsequent
Systems 1 year

Subsequent
Systems 3 years

AlphaServer/AlphaStation DS10
HP Support Plus

FP-A01BA-12 FP-A01BA-36 FP-A21BA-12 FP-A21BA-36

HP Support Plus 24

FP-A02BA-12 FP-A02BA-36 FP-A22BA-12 FP-A22BA-36

Installation

FP-AINST-BA FP-AINST-BA FP-AINST-BA FP-AINST-BA

Installation & Startup

FP-ASTAR-BA FP-ASTAR-BA FP-ASTAR-BA FP-ASTAR-BA

NOTES

:

AlphaServer/AlphaStation DS10 systems include three years hardware warranty with 5x9, on-site Next Business Day
response.
HP Care Pack Services include support for new HP branded hardware options internal to the AlphaServer/AlphaStation
enclosure plus a monitor (17-inch or less excluding flat panel models).
External storage devices/cabinets carry their own level of warranty and should be quoted separately for uplifted
warranty services.
In addition to the HP Care Pack Services shown above, other service packages are available for separate hardware
and software support. For more information on Hardware and Software Upfront Services and other HP service options
available for AlphaServers and AlphaStations, consult your Sales Account Manager, HP Services Principal, or visit

http://www.hp.com/hps/

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

Options

DA - 10908 North America — Version 29 — April 27, 2004

Page 41

Physical Characteristics

Dimensions

(H x W x D)

5.1 x 17.6 x 19 in (13 x 45 x 48 cm)

Weight

(maximum)

36 lb (16.3 kg)

Cabinets

H9A10 M-Series H9A15 M-Series

Series 10000 Rack

(10642)

Dimensions

(H x W x D)

67 x 23.6 x 36.1 in
(170 x 60 x 91.6 cm)

79 x 23.6 x 36.1 in
(200 x 60 x 91.6 cm)

78.7 x 24 x 39.69 in
(199.9 x 60.96 x 100.82
cm)

Shipping Dimensions

73 x 36 x 48 in
(185.5 x 91.5 x 122 cm)

85 x 36 x 48 in
(216 x 91.5 x 122 cm)

86.22 x 32 x 48 in
(219 x 81.28 x 121.92 cm)

Weight

280 lb (126 kg) 313 lb (142 kg)

253 lb (114.84 kg)

Shipping Weight

354 lb (159.3 kg) 369 lb (167.4 kg)

284 lb (129 kg)

Loading Capacity

1,408 lb (640 kg) maximum

1,408 lb (640 kg)
maximum

2,000 lb 909.1 kg)
maximum

System Unit

Environmental
Temperature

Operating (Tower,
Rackmount)

50° to 104° F (10° to 40° C)

NOTE:

Maximum operating temperature at sea level. Reduce by 1.8° F (1° C) for each

2,000 ft (660 m) above sea level.

Non-operating

–40° to 151° F (–40° to 66° C)

Humidity

Operating

10% to 95%

Non-operating

20% to 80%

Heat Dissipation

Single unit = 176 Watts = 601 BTU/Hr
Rack of 12 systems = 2112 Watts = ~7,212 BTU/Hr

Typical System

AlphaServer DS10 600 MHz
Power Supply, 300W
Main logic board containing Alpha CPU, EV6, 600 MHz
Main memory = 1 GB
(3) Hard disk drive
(1) Floppy disk drive
(1) CD-ROM disk drive
(1) PCI Graphics Card
(1) PCI Graphics Card
Running system exerciser during the power measurement.
Measured Input Voltage = 116 VAC RMS @ 60Hz
Measured Input Current = 2.27 Amps RMS
Measured Input Power = 176 Watts

Altitude

(unpressurized)

Operating

40,000 ft (12,192 m)

Non-operating

10,000 ft (3,048 m)

NOTE:

Higher altitudes are possible if maximum operating temperature is reduced.

Electrical

(Power supplies are universal, PFC, auto ranging, 100/240 VAC)

Nominal Voltage

(VAC)

100 to 120 VAC/220 VAC

Operating Voltage Range

(VAC) (temporary condition)

90 to 128 VAC/180 to 265
VAC

Power Source Phase

Single/Single/Single

Nominal Frequency

(Hz)

60 Hz/50 Hz

Frequency Range

(Hz)

59 to 61 Hz /49-51 Hz

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

TechSpecs

DA - 10908 North America — Version 29 — April 27, 2004

Page 42

Maximum Inrush Current

11 amps/22 amps

Power Supply

(single

cordset)

12 amps/5 amps

Acoustics

(Declared values per ISO 9296 and ISO 7779)

AlphaServer DS10 with
one HDD

LWAdB

LpAm

, dBA

(Operator position)

LpAm

, dBA

(Bystander Position)

Idle

5.7 48 41

Operating

6.0 52 45

Regulatory

Agency Approvals

UL: Listed to UL1950 (3rd edition)
CUL Listed: CAN/CSA-C22.2 No. 950-M95
TUV: EN 60950/A11: 1997 GS marked
FCC: Part 15 Class B
CE: EN55022, EN50082
VCCI Class II ITE
BMSI: CISPR22, CNS13438
C-Tick: CISPR22, AS/NZS 3548

Reviewed to

AS/NZ 3260:1993 Australian/New Zealand Standard
EN 60950/A11: 1997 European Norm
IEC950 (2nd edition, 4th amend)

© Copyright 2001-2004 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
UNIX is a registered trademark or trademark of The Open Group in the U.S. and/or other countries. The only warranties for HP products and
services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as
constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

QuickSpecs

Compaq AlphaServer DS10

Compaq AlphaStation DS10

TechSpecs

DA - 10908 North America — Version 29 — April 27, 2004

Page 43
