HP Designjet Z2100 Photo Printer series
(1 With i1 color technology.
(2 HP's preliminary, internal results have shown that the HP Designjet Z Photo Printer series is capable of successfully simulating over 80% of the PANTONE colors. HP Designjet
Z2100 and Z3100 Photo Printers are pending PANTONE-licensing
(3 Display permanence rating by Wilhelm Imaging Research, Inc. on a range of HP creative and specialty media. For details:
http://www.hp.com/go/supplies/printpermanence
BREAKTHROUGH COLOR: Achieve consistent & accurate color with the first ever embedded spectrophotometer
(1
• Automatic and simple creation of ICC profiles. HP's embedded spectrophotometer and an automated workflow bring
simplicity and reliability to accurate profiling and precise printer calibration. HP's Advanced Profiling Solution offers
additional options for profiling and calibrating your color system.
• Expect consistent color from print to print. Calibrate the printer and begin delivering print-to-print and printer-toprinter
color repeatability.
• Fast color stability covering a broad gamut: Stable proofs in less than 5 minutes, and with over 80% PANTONE
®
coverage(2, and full compliance with prepress standards: SWOP, ISO, GRACOL, EUROSCALE, TOYO, FOGRA, and 3DAP.
TRUE CREATIVE EXPRESSION: Get vivid, long-lasting quality with an 8-ink printing system with HP Vivera pigment inks
• Water resistant prints resist fading for over 200 years(3: HP 70 Vivera pigment inks with an 8-ink printing system achieve
a unique combination of consistently outstanding image quality. Your photos, posters, presentations and maps will be
water-resistant and will resist fading for over 200 years
(3
on a range of HP creative and specialty media.
• Rich, dark blacks on matte and glossy papers without swapping cartridges. The HP Three-Black Ink set consists of matte
black, photo black, and light gray HP Vivera pigment ink cartridges that reside in the printer at all times.
• Achieve consistent results on a wide range of papers. Choose from a variety of HP papers from plain to glossy, including
backlit, indoor banner, and other specialty papers.
TRUE PRINT CONFIDENCE: Print with greater confidence thanks to dependable HP technologies
• Eliminate trial and error with real-time layout and orientation preview. Take the guess work out of margins. Save time
and materials.
• Glide effortlessly through color management and printing with the HP Color Center tool.
• Save time with HP Easy Printer Care/HP Printer Utility software. Monitor the status of printers & supplies and get the latest updates.
• Expect always-on quality with automatic servicing routines that are economical and convenient thanks to proactive
printhead maintenance.
• Have your questions answered. Application settings and color management consultation at your finger tips with the HP
Knowledge Center.
Services
A number of standard services come in the printer box to enable you to print with confidence right from the start:
- HP Start-up Kit enables you to easily install the printer on your own. Includes: drivers for both Mac® and Windows®, multimedia training in how to operate the
printer, and PDF user manuals for easier consultation.
- Online HP Knowledge Centre helps you to fit your printer into your workflow. Benefit from: multimedia training sessions, step-by-step guides, access to relevant forums
and blogs, contact details for HP support, and information on the latest drivers and firmware.
- HP Easy Printer Care (Windows®) or Printer Utility (Mac®) ensure that you always know how your printer is doing by sending you alerts on everything from job
accounting to color control.
See www.hp.com/go/graphic-arts for full details on all services.
For enhanced services purchase from the HP Professional Graphic Services portfolio, which includes:
- HP Installation Care Pack Services: Easier to get your printer up and running in minimum time. Stand alone and network options available.
- HP Color Expert Service powered by X-Rite Color Services: Problems getting the right color from your printer? Call one phone-number for immediate, reliable answers
to all of your questions on color, color management software and hardware, RIPs, design applications, output devices, drivers and operating systems.
- HP Care Pack and Post Warranty Services: Reduce downtime and mitigate the risk of unbudgeted repair costs. 3-5 year warranty extensions available.
See back page for ordering information and visit www.hp.com/go/pgs for more details on all options.
1. LCD front panel and direct access keys for ink supply
maintenance and print message alerts.
2. Front bypass slot accommodates media up to 24 in/609 mm
wide (24” printer) or up to 44 in/1117 mm (44” printer)
3. Mounted on the carriage, the embedded spectrophotometer
(1
brings accurate profiling and precision color calibration
4. Rear USB 2.0 High Speed and 10/100 BT Ethernet connection
for TCP/IP. Free slot for additional network connectivity with 1 EIO
HP Jetdirect card
5. Rear bypass slot handles heavy and rigid media of weights up to
500 g/m2and thickness up to 0.8 mm.
6. Roll feed (located at the back of the printer) feeds rolls up to 24
in/609 mm wide (for 24” printer) or up to 44 in/1117 mm (for
44” printer) and 300 ft/91 m long
7. Media bin
8. 8 HP Vivera pigment ink set with 4 pl & 6 pl drop size for prints
that resist fading for over 200 years
(3
1
2
3
4
5
6
7
8
HP Designjet Z2100 Photo Printer series
HP-GL/2 Upgrade Kit. For CAD customers that need
improved line quality and network availability with the HPGL/2 software key. The printer --rather than the computer-processes files for improved operating efficiency. Store and
reprint files from the printer queue and print legacy HP-GL/2
files.
The Efi Designer Edition 5.1 XL for HP is the recommended
RIP and proofing application for your HP Designjet printer.
Integrating this enables CMYK workflow support,
PostScript® & PDF printing, and accurate spot color
management for designers, photographers, and other
creative professionals. A powerful, yet cost effective digital
proofing system that allows full control over digital proofing
needs to speed up workflows, saving both time and money.
The HP Advanced Profiling Solution, powered by
GretagMacbeth™ technology, offers a color management system
that works in combination with the spectrophotometer
embedded in the printer. This automated solution enables
you to perform: monitor profiling and calibration, ambient
light and monitor-profile validation, RGB and CMYK
profiling with optimized inkjet separations for HP Media in
addition to the most common separations (Inkjet 260 and
400), and rigorous fine-tuning of printer color profiles. A
very intuitive profile-editing wizard lets you match colors to,
for example, output viewing conditions that use nonstandard illuminants.
Additional 24" and 44" spindles make life easier for
professional photographers and graphic designers, spare
spindles mean that they can have different media types
ready to load. Also available, for design professionals such
as architects, engineers, and GIS specialists, is an
additional 44" spindle for easy switching between
technical media rolls. This technical media spindle is
recommended for use with Plain, Bright White Bond,
Coated, Natural Tracing and Translucent Bond papers,
and Vellum.
Optional accessories
• Make an impact by presenting concepts and designs in large format and with accurate colors right from the start of
your project. The printer accepts paper up to 44 inches wide (24 inches on the smaller model) and covers over 80%
of PANTONE colors.
(2
• Get consistent colors, print after print and from one printer to another, thanks to automated printer calibration.
Design
Proofing
• Have proofs approved in record time: Colors stabilize in less than 5 minutes.
• Print consistent and accurate colors across a wide range of media thanks to automated printer calibration and ICC
profiling.
• Produce high-quality black-and-white proofs: The 8 HP Vivera pigment inks include three blacks that give excellent
gray neutrality.
Commercial photography
• Create neutral black-and-white prints with the printer’s 3 black inks. No need to waste ink when changing between
matte and glossy papers: All three blacks are always on board.
• Produce consistent and accurate color photo proofs thanks to the printer’s unique, built-in calibration technology and
broad color gamut.
• Print on almost any media: The printer creates the new media profiles for you, and you can use thick stock of up to 500 g/m
2
.
• Print full-color, long-lasting posters,
banners, and displays on a wide range
of media.
• Create persuasive marketing collateral,
point-of-sales material, and tradeshow
displays with photo quality images and
consistent, accurate colors.
Display graphics
Technical imaging
Key technologies
Electrosteric Encapsulation
Technology
HP Vivera pigment inks offer outstanding image quality and fade
resistance on a wide variety of photo and fine art media, along with
water resistance on a range of HP creative and specialty media.
HP’s proprietary Electrosteric Encapsulation Technology optimizes
the pigment chemistry and ink properties for stability and
performance to ensure a broad color gamut, print permanence,
excellent gloss uniformity, and reliable, accurate, and consistent
printing.
HP's 8-ink printing system is made up of the exclusive
HP Vivera pigment ink formulation technology with HP 70
Printheads, each printing two colors of ink with 1,056
nozzles per color, and the HP Three-Black Ink set. Ensures
exceptional color accuracy and consistency: a valuable
tool for graphic designers and prepress professionals
who need repeatable results. The HP Designjet Z series
are also the first large-format printers to employ HP
Scalable Printing Technology, providing superior
reliability and optimized ink consumption.
The HP embedded spectrophotometer with i1 Color
Technology from GretagMacbeth is mounted on the printer
carriage and revolutionizes professional color workflows by
automating media profiling. It allows users to automatically
generate custom RGB ICC profiles for their preferred media and
provides accurate measurements for printer calibration that
delivers print-to-print and printer-to-printer color consistency.
Also, with the optional HP Advanced Profiling Solution, you can
edit and modify existing profiles and create CMYK profiles.
An extensive media portfolio: HP offers a portfolio of 9
photo papers, 10 digital fine art papers, 3 proofing
papers, 9 bond and coated papers, and over 30 other
HP media. All have been tested with HP 70 Vivera
pigment inks to deliver consistent, museum-quality prints
that withstand the demands of handling, display and
storage expected of professional prints.
• Produce impressive renderings, photorealistic prints, maps, satellite images,
and presentations panels with superior
quality, consistency, and durability.
• Architects, engineers, industrial designers, and GIS specialists all benefit from
easy, predictable, and reliable printing.
High-quality creative prints, prepress proofs, and technical images
HP Designjet Z2100 Photo Printer series
Technical specifications
Ordering information
Product
Q6675A HP Designjet Z2100 24" Photo Printer
Q6677A HP Designjet Z2100 44" Photo Printer
Accessories
Q6643D EFI Designer 5.1 for HP XL International
Q6692A HP GL/2 Upgrade Kit for the HP Designjet Z2100/Z3100 Photo series
Q6695A HP Advanced Profiling Solution International
Q6698A HP Designjet ZX100 44 inch Spindle for printing on technical media
Q6699A HP Designjet ZX100 44 inch Spindle for graphics (spare spindle for easy media switching)
Q6700A HP Designjet ZX100 24 inch Spindle for graphics (spare, for easy media switching)
Printing supplies
Printheads
C9404A HP 70 Matte Black & Cyan Printhead
C9405A HP 70 Light Magenta & Light Cyan Printhead
C9406A HP 70 Magenta & Yellow Printhead
C9407A HP 70 Photo Black & Light Gray Printhead
130 ml ink cartridges
C9448A HP 70 Matte Black 130 ml Ink Cartridge
C9449A HP 70 Photo Black 130 ml Ink Cartridge
C9451A HP 70 Light Gray 130 ml Ink Cartridge
C9452A HP 70 Cyan 130 ml Ink Cartridge
C9453A HP 70 Magenta 130 ml Ink Cartridge
C9454A HP 70 Yellow 130 ml Ink Cartridge
C9455A HP 70 Light Magenta 130 ml Ink Cartridge
C9390A HP 70 Light Cyan 130 ml Ink Cartridge
Ink cartridge twin packs
CB339A HP 70 Matte Black 130 ml Ink Cartridge Twin Pack
CB340A HP 70 Photo Black 130 ml Ink Cartridge Twin Pack
CB342A HP 70 Light Gray 130 ml Ink Cartridge Twin Pack
CB343A HP 70 Cyan 130 ml Ink Cartridge Twin Pack
CB344A HP 70 Magenta 130 ml Ink Cartridge Twin Pack
CB345A HP 70 Yellow 130 ml Ink Cartridge Twin Pack
CB346A HP 70 Light Magenta 130 ml Ink Cartridge Twin Pack
CB351A HP 70 Light Cyan 130 ml Ink Cartridge Twin Pack
Media supplies
Q7991A HP Premium Instant-Dry Gloss Photo Paper 24 in x 75 ft/610 mm x 22.9 m
Q7992A HP Premium Instant-Dr y Satin Photo Paper 24 in x 75 ft/610 mm x 22.9 m
Q6626A HP Super Heavyweight Plus Matte Paper 24 in x 100 ft/610 mm x 30.5 m
C6029C HP Heavyweight Coated Paper 24 in x 100 ft/610 mm x 30.5 m
C6775A HP Colorfast Adhesive Vinyl 36 in x 40 ft/914 mm x 12.2 m
Q1898B HP Opaque Scrim 36 in x 50 ft/914 mm x 15 m
C6787A HP Banners with Tyvek
®
36 in x 50 ft/914 mm x 15 m
Q7973A HP Matte Litho-realistic Paper 36 in x 100 ft/914 mm x 30.5 m
Q8663A HP Professional High-gloss Contract Proofing Paper 24 in x 100 ft/610 mm x 30.5 m
Q7991A HP Professional Semi-gloss Contract Proofing Paper 24 in x 100 ft/610 mm x 30.5 m
Q1968A HP Proofing Matte 24 in x 100 ft/610 mm x 30.5 m
Q8732A HP Hahnemühle Smooth Fine Art Paper 265 g/m
2
24 in x 35 ft/610 mm x 10.7 m
Q8636A HP Hahnemühle Textured Fine Art Paper 265 g/m
2
24 in x 35 ft/610 mm x 10.7 m
Q1984A HP Hahnemühle Watercolor Paper 36 in x 38 ft/914 mm x 11.58 m
Q8741A HP Aquarella Art Paper 24 in x 35 ft/610 mm x 10.7 m
More HP media sizes and weights available at www.hp.com/go/designjet/supplies
Environmental ranges
Operating temperature
Recommended operating temperature
Storage temperature
Recommended operating humidity
Recommended storage humidity
Acoustic
Sound pressure, active
Sound pressure, standby
Sound power, active
Sound power, standby
Power consumption
Active
Maximum
Powe rsav e
Standby
Power requirements
Certification
Safety
Electromagnetic
Energy Star
®
compliant
Press standard
Warranty
Warranty extensions
Care Packs
Color Services
41 to 104ºF/5 to 40ºC
59 to 95ºF/15 to 35ºC
-13 to 131ºF/-25 to 55ºC
20 to 80% RH
0 to 95% RH
44 dB(A)
29 dB(A)
6.5 B(A)
4.4 B(A)
200 watts
200 watts
27 watts
43 watt s
Input voltage auto-ranging 100 to 240 VAC (+/- 10%) , 50/60Hz (+/- 3 Hz), 2 Amp max
IEC 60950-1 compliant, EU LVD and EN 60950-1 compliant, certified by CSA for Canada
and US, Argentina IRAM, Singapore PSB, Russia GOST, China CCIB, Taiwan BSMI
Compliance for Class B products: EU (EMC Directive), USA (FCC rules), Canada (DoC),
Australia (ACA), New Zealand (MoC), China (CCC), Japan (VCCI), Korea (MIC) and
Taiwan (BSMI)
Yes
100% coverage of SWOP, ISO and GRACOL, and 3DAP
1 year warranty with on-site, next business-day service
UF028PE HP 1yr Post Warranty Next-Business-Day Service
HC132PE HP 1yr Post Warranty Phone Only Hardware Service
UF017E HP 3yr Next-Business-Day Service
UF018E HP 4 yr Next-Business-Day Service
UF019E HP 5 yr Next-Business-Day Service
H7604E HP Installation mid-high Designjet Service
H4518E HP Network Installation Designjet Windows
®
/Mac®Service
UF050E 1yr/5 cases HP Color Expert Service
UF315E 1 case HP Color Expert Service
4AA0-6246ENW
(4 ICC absolute colorimetric accuracy on HP Proofing Matte paper
(5 With HP Premium Instant Dry Photo Satin media, right after calibration
(6 With HP Premium Instant Dry Photo Gloss media
(7 Replacement ink cartridges available are HP 70 130 ml Ink Cartridges and HP 70 130 ml Ink Cartridge Twin Packs. For more information, visit
www.hp.com/go/pageyield
More information on products, technologies and services available at www.hp.com/go/graphic--arts
15 min/page on D/A1 or up to 17 ft2/h (color image on glossy paper)
9.8 min/page on D/A1 or up to 31 ft
2
/h (color image on coated paper)
7.9 min/page on D/A1 or up to 38 ft
2
/h (color image on glossy paper)
4.2 min/page on D/A1 or up to 72 ft
2
/h (color image on coated paper)
5.8 min/page on D/A1 or up to 52 ft
2
/h (color image on glossy paper)
2.0 min/page on D/A1 or up to 150 ft
2
/h (color image on coated paper)
2400 x 1200 optimized dpi
600 x 600 dpi
600 x 600 dpi
128 MB Standard memory, 40 GB hard disk
Sheet feed, roll feed, automatic cutter (cuts all media except canvas)
Photographic paper (satin, gloss, semi-gloss, matte), proofing paper
(high-gloss, semi-gloss, matte), fine art printing material (canvas,
smooth, textured, watercolor), self-adhesive and vinyl (polypropylene,
vinyl), sign and banner (display film, banner, scrim, polypropylene,
Tyvek
®
, outdoor paper), backlit, bond and coated (bond, coated,
heavyweight coated, super heavyweight coated)
500 g/m
2
HP Designjet Z2100 24” Photo Printer: All standard sizes larger than Letter/A4
up to 24 in/609 mm wide
HP Designjet Z2100 44” Photo Printer: All standard sizes larger than Letter/A4
up to 44 in/1117 mm wide
5.11 in/140 mm
300 ft/91 m
Roll: 0.2 x 0.2 x 0.2 x 0.2 in/5 x 5 x 5 x 5 mm
(full bleed available on glossy roll media)
Sheet: 0.2 x 0.2 x 0.2 x 0.55 in/5 x 5 x 5 x 14 mm
HP Vivera pigment inks, HP Three-Black ink set, HP Embedded Spectrophotometer
Light cyan, light magenta, light gray, photo black, cyan, magenta, yellow, matte black
HP Vivera pigment inks
4 pl
(light cyan, light magenta, light gray, photo black), 6 pl (cyan, magenta, yellow, matte black)
130 ml ink cartridges (69 ml introductory ink cartridges included in 24" printer box, not available
as replacement cartridges); 130 ml Ink Cartridge Twin Packs also available
2 colors per printhead, 1056 nozzles per color
300 ft/91 m (OS and application dependent)
+/- 0.2 %
Over 200 years
(3
fade resistance
Water-resistant on a range of HP creative and specialty media
Standard: One 10/100 BT Ethernet, One USB 2.0 high-speed certified port,
One EIO Jetdirect accessory slot
Optional: HP Jetdirect EIO print servers
Standard: HP PCL3GUI
Optional: PS via optional software RIP, HP-GL2/TRL/RTL optional software solution
Median <1.6 dE2000, 95% of colors <2.8 dE2000
(4
<1 dE2000 in less than 5 minutes
(5
Average <0.5 dE2000, 95% of colors <1.4 dE2000
(5
4 L* / 2.4 D
(6
Print speed
Best
Normal
Draft
Resolution
Best (Color and B&W)
Normal (Color and B&W)
Draft (Color and B&W)
Memory
Media
Handling
Types
Maximum weight
Size
Maximum external roll diameter
Maximum roll length
Printing
Margins
Technology
Ink cartridge colors
Ink types
Ink drop
Ink cartridge size
Nozzles
Maximum print length
Line accuracy
Lightfastness
Water resistance
Connectivity
Print Languages
Image quality
Color accuracy
Short term color stability
Long term print-to-print repeatability
Maximum optical density
Recommended system requirements
Macintosh
Windows
Dimensions (w x d x h)
Printer with stand
Shipping Dimensions
Weight
Printer with stand
Shipping weight
What’s in the box
Mac OS X v10.2, v10.3, v10.4 and
later, PowerPC G4, G5, or Intel Core
Processor, 1 GB Ram, 2 GB available
hardware disk
Microsoft Windows XP or 2000: Pentium
IV, 3 GHz, 1GB RAM, 2 GB available
hard disk
HP Designjet Z2100 24” Photo Printer:
49.7 x 28.8 x 41.2 in
1262 x 732 x 1047 mm
HP Designjet Z2100 44” Photo Printer:
69.7 x 28.8 x 41.2 in
1770 x 732 x 1047 mm
HP Designjet Z2100 24” Photo Printer:
57.8 x 30.7 x 29.1 in
1470 x 780 x 740 mm
HP Designjet Z2100 44” Photo Printer:
77.2 x 30.5 x 23.6 in
1960 x 775 x 600 mm
HP Designjet Z2100 24” Photo Printer:
143 lb/65 kg
HP Designjet Z2100 44” Photo Printer:
189 lb/86 kg
HP Designjet Z2100 24” Photo Printer:
225 lb/102 kg
HP Designjet Z2100 44” Photo Printer:
271 lb/123 kg
HP Designjet Z2100 24” Photo Printer: spindle, printheads (4 x 2 colors), ink
cartridges (8 x 69 ml)
(7
, media high gloss photo sample roll (24 in x 15 ft), stand
(24"), rear tray (24"), adaptor 3" KIT for spindle (2), quick reference guide, set-up
poster, USB cable, power cord, HP Start-up kit including printer software and
training
HP Designjet Z2100 44” Photo Printer: spindle, technical spindle, printheads
(4 x 2 colors), ink cartridges (8 x 130 ml), media high gloss photo sample roll
(36" x 15 ft), stand (44"), rear tray (44"), 3" KIT for spindle (2), quick reference
guide, set-up poster, USB cable, power cord, HP Start-up kit including printer
software and training
Loading...
