1. Menu
Opens, selects or exits the OSD menu.
4. OK/auto
If the OSD menu is on, press to select the
highlighted menu item.
If the OSD menu is inactive, press to activate the
auto adjustment feature to optimize the screen
image.
2. Minus
If the OSD menu is on, press to navigate
backward through the OSD menu and decrease
adjustment levels.
5. Power
Turns the monitor on or off.
3. Plus/source
If the OSD menu is on, press to navigate
forward through the OSD menu and increase
adjustment levels.
If the OSD menu is inactive, press to activate the
source button that chooses the video signal
input (VGA, DVI, or
DisplayPort).
6. Power LED
Blue = Fully powered.
Amber = Sleep mode.
Flashing Amber = Sleep Timer mode.
Model
XN375A
*
C0H31AA/A8#ABA (Head only)
QuickSpecs
HP Compaq LA2306x 23-inch LED Backlit LCD Monitor
Overview
DA - 13909 North America — Version 8 — April 17, 2013
Page 1
Panel
Type
TN (Twisted Nematic) LED Backlit LCD
Viewable Image Area
(diagonal)
58,42 cm.
(23 in.) widescreen; diagonally measured
Screen Opening
(W x H)
50,92 x 28,64 cm.
(20.05 x 11.28 in.)
Aspect Ratio
16:9
Viewing Angle
(typical)
Up to 170° horizontal/160° vertical (10:1 minimum contrast ratio)
Brightness
(typical)
*
250 nits (cd/m2)
Contrast Ratio
(typical)*1000:1
Dynamic Contrast Ratio
(typical)
*
1,000,000:1
Response Time
(typical)*5 ms (on/off)
Pixel Pitch
0.265 mm
Backlight Lamp Life
(to half brightness)
30,000 hours minimum
Color Support
Over 16 million colors (through FRM)
Color Gamut
(typical)
68%
*All performance specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
On Screen Display
(OSD)
Controls
Buttons or Switches
"Menu" "-" "+" "OK" "Power"
Languages
English, French, German, Italian, Dutch, Spanish, Japanese, Portuguese,
Traditional Chinese, and Simplified Chinese
User Controls
Brightness, contrast, positioning, color temperature (warm, standard, cool,
custom), image control (clock, clock phase, scaling, sharpness, DCR), monitor
management, source control, information and factory reset
Signal Interface/
Performance
Horizontal Frequency
24 to 94 kHz
Vertical Frequency
50 to 76 Hz
Native Resolution
1920 x 1080 @ 60 Hz
Preset VESA Graphic
Modes
(non-interlaced)
1920 x 1080 @ 60 Hz
1680 x 1050 @ 60 Hz
1440 x 900 @ 60 Hz
1280 x 1024 @ 60 Hz
1280 x 720 @ 60 Hz
1024 x 768 @ 60 Hz
800 x 600 @ 60 Hz
720 x 400 @ 70 Hz
640 x 480 @ 60 Hz
Text Mode
720 x 400 @ 70 Hz
Maximum Pixel Clock
Speed
200 MHz (VGA); 165MHz (DVI and DisplayPort)
QuickSpecs
HP Compaq LA2306x 23-inch LED Backlit LCD Monitor
Technical Specifications
DA - 13909 North America — Version 8 — April 17, 2013
Page 2
User Programmable
Modes
Yes (10)
Anti-Glare
Yes
Default Color
Temperature
Warm (6500K)
Video/Other Inputs
Plug and Play
Yes
Input Connectors
VGA (analog), DVI-D and DisplayPort w/ HDCP, USB 2-port hub
Input Impedance
75 Ohms (VGA)
Sync Input
TTL separate synch
Video/Other Cables
(1) (1) DVI-D cable, (1) VGA cable, (1) USB cable
Cable Lengths
1,8 m.
(5.9 ft.)
Power
Input Power
100 - 240 VAC, 50/60 Hz
Typical Power
Consumption
33 W
Maximum
41.5 W
Power Saving
< 0.5 W standby; < 0.5 W off
Power Cable Length
1,9 m.
(6.2 ft.)
Mechanical
Dimensions
(W x D x H)
Unpacked w/stand
55,15 x 24,94 x 35,1 to 46,7 cm.
(21.71 x 9.82 x 13.82 to 18.39 in.)
Unpacked w/o stand
(head only)
55,51 x 4,95 x 33,42 cm.
(21.69 x 1.95 x 13.16 in.)
Packaged
62,4 x 50,2 x 16,9 cm.
(24.57 x 19.76 x 6.65 in.)
Weight
Head Only
4,4kg.
(9.68 lb.)
Head Only
(Packaged)
7,0 kg.
(15.4 lb.)
Unpacked
6,8 kg.
(15.0 lb.)
Packaged
9,2 kg.
(20.3 lb.)
Tilt Range
-5° to +30°
Swivel Range
Yes 360°
Height Adjustable
Yes - from
0 to 13,0 cm.
(0 to 5.1 in.)
Pivot Rotation
Yes
Base
Detachable, ships attached
Environmental
Temperature - Operating
5° to 35° C
(41° to 95° F)
Temperature - Nonoperating
-20° to 60° C
(-4° to 140° F)
Humidity - Operating
20% to 80% non-condensing
Humidity - Non-operating
5% to 95%, 38.7° C max wet-bulb
Altitude - Operating
0 to 5000 m.
(16,400 ft.)
Altitude - Non-operating
0 to 12192 m.
(40,000 ft.)
White LED Backlights
Yes
QuickSpecs
HP Compaq LA2306x 23-inch LED Backlit LCD Monitor
Technical Specifications
DA - 13909 North America — Version 8 — April 17, 2013
Page 3
CCFL Panel
No
Arsenic-Free Display
Glass
Yes
Low Halogen4
Plastics and Finishes or Paint
Mercury-Free Display
Backlighting
Yes
Environmental Data
Eco-Label Certifications
& Declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
US Energy Star®
IT ECO declaration
EPEAT® Gold where HP registers commercial display products. See
http://www.epeat.net
for registration status in your country.
Energy Consumption
(in accordance with US
Energy Star® test
method)
115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation
22.61 W 22.55 W 22.67 W
Sleep
0.25 W 0.25 W 0.31 W
Off
0.22 W 0.21 W 0.28 W
Heat Dissipation
*
115VAC, 60 Hz 230VAC, 50 Hz 100VAC, 60 Hz
Normal Operation
77 BTU/hr 77 BTU/hr 77 BTU/hr
Sleep
0.8 BTU/hr 0.8 BTU/hr
1 BTU/hr
Off
0.7 BTU/hr 0.7 BTU/hr 0.9 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one
hour.
Additional Information
This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT®) standard at
the Gold level, see
www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked
per ISO 11469 and ISO1043.
This product contains 0.14% post-consumer recycled plastic (by wt.)
This product is 98.0% recycle-able when properly disposed of at end of
life.
Packaging Materials
External:
Corrugated carton
1500g
Internal:
Polyethylene low density
36g
RoHS Compliance
Hewlett-Packard is committed to compliance with all applicable environmental
laws and regulations, including the European Union Restriction of Hazardous
Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by
meeting the requirements of the RoHS Directive on a worldwide basis. By July
QuickSpecs
HP Compaq LA2306x 23-inch LED Backlit LCD Monitor
Technical Specifications
DA - 13909 North America — Version 8 — April 17, 2013
Page 4
1, 2006, RoHS substances will be virtually eliminated (virtually = to levels
below legal limits) for all HP electronic products subject to the RoHS Directive,
except where it is widely recognized that there is no technically feasible
alternative (as indicated by an exemption under the EU RoHS Directive).
Material Usage
This product does not contain any of the following substances in excess of
regulatory limits (refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/
gen_specifications.html
):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants - may not be used as flame
retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel - finishes must not be used on the external surface designed to be
frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) - except for wires and cables, and certain retail
packaging has been voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging
HP follows these guidelines to decrease the environmental impact of product
packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and
cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging
materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
packaging materials.
Use readily recyclable packaging materials such as paper and corrugated
materials.
Reduce size and weight of packages to improve transportation fuel
efficiency.
Plastic packaging materials are marked according to ISO 11469 and DIN
6120 standards.
End-of-life Management
Hewlett-Packard offers end-of-life HP product return and recycling programs
QuickSpecs
HP Compaq LA2306x 23-inch LED Backlit LCD Monitor
Technical Specifications
DA - 13909 North America — Version 8 — April 17, 2013
Page 5
and Recycling
in many geographic areas. To recycle your product, please go to:
http://www.hp.com/go/reuse-recycle
or contact your nearest HP sales office.
Products returned to HP will be recycled, recovered or disposed of in a
responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities.
This information (product disassembly instructions) is posted on the Hewlett
Packard web site at:
http://www.hp.com/go/recyclers
. These instructions may
be used by recyclers and other WEEE treatment facilities as well as HP OEM
customers who integrate and re-sell HP equipment.
Hewlett-Packard
Corporate Environmental
Information
For more information about HP's commitment to the environment:
Global Citizenship Report
http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html
Eco-label certifications
http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/
ecolabels.html
ISO 14001 certificates:
http://www.hp.com/hpinfo/globalcitizenship/environment/operations/
envmanagement.html
Options
HP Single Monitor Arm
Part number BT861AA
The flexible design of the HP Single Monitor Arm provides a seemingly endless
range of display adjustments with an amazing 13 inches of lift, 50 degrees of
tilt, and 360 degrees of pan and rotation - all at your fingertips -- helping you
stay comfortable and productive throughout the day.
HP Adjustable Dual
Display Stand
Part Number AW664AA
Premium space-saving dual screen solution provides access to more monitor
real estate and makes it possible to manage multiple applications
simultaneously. Weight adjustable for dual monitors from 17-24". Rotate
displays into portrait/landscape positions.
HP LCD Speaker Bar
Part number NQ576AA
Powered directly by the connected PC, the Speaker Bar seamlessly attaches to
the monitor's lower bezel to bring full audio support to select HP flat panel
monitors. Features include dual speakers with full sound range and dual
external headphone jacks.
HP LCD Monitor Quick
Release
Part number EM870AA
1
An easy-to-use, VESA-compliant, LCD monitor mounting solution that allows
you to quickly and securely attach an LCD monitor to a variety of stands,
brackets, arms or wall mounts.
HP Integrated Work
Center Stand—Part
number LH526AA
Allows mounting of a 17 - 24 inch (43.18- to 60.96 cm) diagonal HP LCD
monitor and an HP Compaq 8000 series Ultra-slim Desktop PC as well as select
HP Thin Clients on a single stand for the convenience of an "all-in-one" form
factor. For more information, refer to this product's QuickSpecs document.
HP Integrated Work
Center 2 - Small Form
Factor (SFF) - Part
number QP897AA
Designed specifically for use with the HP Compaq Small Form Factor (SFF)
Desktop PC and a 17 to 24-inch (43.18 to 60.96 cm) diagonal monitor, the HP
Integrated Work Center 2 (IWC) - Small Form Factor (SFF) provides a portable,
compact workspace to help maximize space-constrained work environments.
(17 to 24-inch diagonal monitors need to meet supported weight limits of 7.5
to 12.1 lbs. (3.38 to 5.5 kg). For more information, refer to the product's
QuickSpecs.
QuickSpecs
HP Compaq LA2306x 23-inch LED Backlit LCD Monitor
Technical Specifications
DA - 13909 North America — Version 8 — April 17, 2013
Page 6
HP USB Graphics Adapter
Part number NL571AA
Enables connection of up to six simultaneous displays to help you boost
productivity and multi-task across several open applications. Use one Adapter
to bridge between a notebook or desktop PC and second monitor or use
multiple Adapters to connect several displays to each other.
HP Business PC Security
Lock Kit
Part number PV606AA
Attaches to the rear of the PC with a six-foot steel cable that can be used to
secure a PC or peripherals such as mice, keyboards, monitors or USB security
devices to protect them against unauthorized removal by physically connecting
the system to an anchor point.
HP DisplayPort Cable Kit
Part number VN567AA
Connects a DisplayPort connector on an HP Business Desktop computer to a
DisplayPort connector on a monitor.
HP USB HD 720P Business
Webcam
Part Number QP896AA
Enjoy live video conferencing in 720p high-definition1 with this small and
stylish webcam that captures images and video. Attach it to your monitor with
a clip or sit it on your desk, and then connect to your desktop through a USB
port. Meet face to face over the Internet (Internet service required and sold
separately) with co-workers and clients.
Other
Accessories Included
AC Power cable, VGA cable, DVI-D cable, USB cable
Software
Yes - HP Display Asst, Auto Adjustment Pattern Utility, Monitor Driver, PDF
Complete (v35109 rc4)
User Guide Languages
English, Danish, Dutch, Finnish, French, German, Italian, Norwegian, Spanish
(International), Swedish, Czech, Greek, Hungarian, Polish, Russian, Slovenian,
Turkish, Arabic, Portuguese (Brazilian), Bahasa Indonesia, T. Chinese, S.
Chinese, Japanese
Warranty Languages
English, German, French, Italian, Turkish, Greek, Arabic, Hungarian, Czech,
Russian, Polish, Japanese, Dutch, Danish, Finnish, Portuguese, Norwegian,
Swedish, T. Chinese, Korean, Slovenian, Bahasa, Spanish
Color
Black
VESA External Mounting
Yes (one set of standard 4-hole pattern, 100 mm).
Security Lock-Ready
Yes
Certification and
Compliance
TCO 5.0, VCCI, KC, CECP, FCC, CE, BSMI, ISC, C-Tick, Gost, E-Standy, RoHS, WEEE, ETL, CCC, Energy Star® 5.0,
NOM, KCC, BSMI, TUV, Microsoft WHQL, China Energy Label Grade 1, EPEAT® Gold
3
Compatibility
Recommended for use with HP products.
Service and Warranty
Protected by HP, including a 3 year standard limited warranty. Optional Care Pack Services are extended
service contracts which go beyond your standard warranties.2
QuickSpecs
HP Compaq LA2306x 23-inch LED Backlit LCD Monitor
Technical Specifications
DA - 13909 North America — Version 8 — April 17, 2013
Page 7
© Copyright 2013 Hewlett-Packard Development Company, L.P.
ENERGY STAR® is a US registered mark of the United States Environmental Protection Agency.
1 The HP Quick Release has been designed to support a maximum of up to 24 lbs (10.9 kg) for all devices mounted. Because mounting
surfaces vary widely and the final mounting method and configuration may vary, mounting fasteners are not supplied (other than the
VESA-compliant screws). HP recommends that you consult with a qualified engineering, architectural or construction professional to
determine the appropriate type and quantity of mounting fasteners required for your application and to ensure that your mounting
solution is properly installed to support applied loads.
2 HP Care Pack Services extend service contracts beyond the standard warranties. Service levels and response times for HP Care Packs
may vary depending on your geographic location. Service starts from date of hardware purchase. To choose the right level of service
for your HP product, use the HP Care Pack Services Lookup Tool at http://www.hp.com/go/lookuptool. Additional HP Care Pack
Services information by product is available at http://www.hp.com/hps/carepack.
3 EPEAT Gold where HP registers commercial display products. See www.epeat.net for registration status in your country.
4 External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be
Low Halogen.
All specifications represent the typical specifications provided by HP's component manufacturers; actual performance may vary either
higher or lower. The only warranties for HP products and services are set forth in the express warranty statements accompanying such
products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or
editorial errors or omissions contained herein.
QuickSpecs
HP Compaq LA2306x 23-inch LED Backlit LCD Monitor
Technical Specifications
DA - 13909 North America — Version 8 — April 17, 2013
Page 8
Loading...
