Table of Contents
Finding HP TouchSmart PC Information ........................................................................................... vi
Index .........................................................................................................................59
Table of Contentsv
Finding HP TouchSmart PC Information
Type of informationWhere to find
Set up your HP TouchSmart PC.Setup poster
How-to videos about using HP TouchSmart
features.
Hardware features.
Connect to the Internet.
HP TouchSmart and other software.
Connect a television signal.
Recover factory settings.
Learn how to use the Microsoft
®
Windows®7
operating system.
Troubleshoot the most common computer
hardware and software issues.
Find electronic user guides and specifications
for your computer model.
Order parts and find additional
troubleshooting help.
Upgrade or replace components of your
computer.
On the HP TouchSmart home page, tap the
Tutor ials tile to open it, and then tap a tutorial
to view it. Or, visit
www.hp.com/supportvideos (English only)
User Guide (this guide)
Help and Support
Tap the W i n dows Start button
®
, and then tap
Help and Support.
HP Support Web site:
www.hp.com/support
Tap the Start button, tap Help and Support,
and then tap the Online Help icon.
Upgrading and Servicing Guide
Tap the Start button, tap Help and Support,
and then tap the User Guides icon.
Find computer warranty information.
Get technical support.
Get up-to-date information and help from the
Windows community.
Learn how to make your computer adaptable to
wall mounting.
If the guide is not there, visit
www.hp.com/support
Limited Warranty and Support Guide
www.hp.com/support/consumer-forum
Preparing Your Computer for
Wall-Mounting guide
If the guide is not there, visit
www.hp.com/support
viUser Guide (Features may vary by model)
Features
The HP TouchSmart PC is a touch-enabled high-performance computer built into a high-definition*
50.8-cm (20-in) diagonal widescreen display.
webcam, a CD/DVD and Blu-ray player and burner, Bluetooth capability, ambient lighting, USB ports, a
media card reader, a BrightView display, Wireless 802.11n networking, and high-quality speakers.
The interactive screen makes wall mounting a good choice for the HP TouchSmart PC. The hardware to
adapt the computer for wall mounting (not the actual wall mount) is included with select models and can be
purchased.
Using your fingertips, you can listen to music, edit digital photos, or watch home videos.
***
Welcome
**
The slim computer offers features such as an adjustable
* High-definition (HD) content is required to view HD images.
** Features vary by model. Your computer may not exactly match the illustrations and descriptions in this guide.
*** VESA mount adapter availability varies by country/region. Separate wall-mounting hardware is required that attaches to
the VESA mount adapter.
Welcom e1
Cables and accessories
What’s in the box
Power cordUse to connect computer to
power source.
Keyboard and mouse (wireless
option shown with receiver)
Cleaning clothUse to clean the touch screen.
Setup poster and
documentation
Computers with TV tuners
Infrared (IR) emitter cableUse to control a set-top box
Use to control some functions
and software, instead of using
touch. Batteries installed (select
models).
Use to set up your computer
and navigate its features.
(cable or satellite TV) with a
remote control.
Remote controlUse with Windows Media
Computers with wall-mounting option
VESA plate adapter assemblyMount on the back of the
2User Guide (Features may vary by model)
Center and some features of the
touch screen.
Also included in select models
without TV tuners.
computer to adapt the computer
for separate wall-mounting
hardware (not included).
Cables not included but that may be required
Ethernet (LAN) cableUse to connect to a wired network.
Coaxial cableUse to connect to an Internet
connection with a cable modem, or to
connect the TV signal source to the
computer.
Connector type may vary.
S-Video cableUse to connect the TV signal source to
the computer from a set-top box.
Audio/video composite cableUse to connect the TV signal from a
set-top box.
TV tuner (composite video to
S-Video) adapter
Use to connect the TV signal source to
the computer from a set-top box.
Welcom e3
Front and right side of the HP TouchSmart PC
Features and configurations vary by model
E
B
A
L
ItemDescription
K
EDDC
F
G
H
J
I
ALCD display
optimized for touch
BBluetooth
(select models only)
CWebcamCreate videos and snapshots that you can view, send by e-mail, and
State-of-the-art 50.8-cm (20-in) diagonal widescreen high-definition
display with HP BrightView technology.* HP BrightView technology
improves the contrast and clarity of your display. In addition, it boasts a
high resolution of 1600 x 900 and a fast response time of 5 ms.**
The display is optimized for an elegant touch experience. Your
fingertip is all you need to interact with the HP TouchSmart. The
durable glass panel is sturdy and delightfully responsive.
Experience the ease of managing your digital life by touch with the
HP TouchSmart software.
* High definition (HD) content is required to view HD images. Most current DVDs do
not provide HD images.
**All specifications represent the typical specifications provided by Hewlett-Packard’s
component manufacturers; actual performance may vary either higher or lower.
Use Bluetooth to connect to Bluetooth-enabled devices. The diagram
shows the internal location of Bluetooth (not visible externally).
upload to video sharing sites. Use the built-in webcam and microphone
array to have video chats with friends and family.*
To adjust the viewing angle of the webcam shot, tilt the screen, or use the
adjust lever immediately behind the webcam. You can also choose how
tightly you want to crop the view of the camera, creating a close-up view
of your face or including more of the background.
4User Guide (Features may vary by model)
* Internet access required.
ItemDescription (continued)
DMicrophone arrayUse the built-in digital microphone array to record sound for your
webcam videos, and to use instant messenger or chat software to have
video chats online. The microphone is designed to provide a clean sound
by filtering out ambient noise in your environment. It is designed to
record from a distance of up to one-half meter (2 feet) away from the
computer.
EBuilt-in wireless LAN
(select models only)
Use the built-in wireless LAN to connect to the Internet through your
existing wireless network. The diagram shows the internal location of the
wireless LAN (top left and right, not visible externally).
The wireless LAN supports IEEE 802.11 b/g/n.
FPower/Sleep buttonPress the Power/Sleep button to turn on your HP TouchSmart PC, or to
put it into Sleep mode.
To turn off your computer, tap the Start button, and then select Shut Down. Or tap the arrow next to the Shut Down button to switch users,
log off, lock, restart, or sleep.
GSlot-loading
CD/DVD drive
(located on back
side panel)
Watch your favorite DVD or Blu-ray disc (select models only), or listen to
your CD collection. Burn CDs, DVDs, and Blu-ray discs (select models
only).*
Read and write DVD-RAM, CD-R/RW, DVD+/-R/RW and DVD+/-R dual
layer (DL).
Read and play CD-ROM, DVD-ROM, CD Audio, DVD+/-R DL,
DVD-Video, Video CD, and Blue-ray disc (with BD drive only).
* HP supports the lawful use of technology and does not endorse or encourage the
use of our products for purposes other than those permitted by copyright law.
HCD/DVD Eject buttonPress the Eject button to remove the CD/DVD from the disc drive.
IUSB portsConnect USB devices (USB 2.0) such as printers, external hard drive
disks, digital cameras, and MP3 players.
JIR receiver window
(select models only)
Infrared (IR) receiver window, located on the lower-right side of the
computer. Allows for use with a remote control.
KHP TouchSmart buttonTurn your HP TouchSmart PC on and open your HP TouchSmart software.
Or, if the computer is already turned on, press the button to open the
HP TouchSmart software for quick access to your music, photos, videos,
or the Web. The HP TouchSmart button cannot turn the computer off.
LInternal SpeakersUse the built-in, high-quality stereo speakers for a powerful media
experience when listening to music, or when watching your home videos
and DVDs.
Welcome5
Left side of the HP TouchSmart PC
Features and configurations vary by model
A
B
C
D
E
ItemFunction
AVolume an d mute
controls
BAmbient Light
button (select
models only)
CMemory card
reader
DAudio Line InConnect MP3 players or other audio players.
EHeadphonesConnect headphones to the port to listen to music without disturbing
Adjust the sound level up or down, or mute the sound.
The HP TouchSmart Ambient Light casts a glow from the computer base.
Ambient Light is turned off by default. Turn the Ambient Light on or off by
pressing the Ambient Light button.
Use the built-in memory card reader to easily access photos and other files
directly from a memory card.
Supported formats include Extreme Digital (xD), Secure Digital (SD),
Secure Digital High-Capacity (SDHC), MultiMediaCard (MMC),
Memory Stick (MS), and Memory Stick Pro (MS-Pro) memory cards.
Your memory card reader also supports adapters for the following memory
cards: Mini SD, RS-MMC, Micro SD, MS-Duo, and MS Pro Duo.
anyone.
6User Guide (Features may vary by model)
Back of the HP TouchSmart PC
Features and configurations vary by model
C
D
E
B
A
F
G
K
ItemFunction
ASecurity lock slotInsert a security lock (sold separately), which enables you to secure your
I
J
computer from theft and unwanted changes.
H
BGigabit
Ethernet LAN
(10/100/1G)
CUSB 2.0 ports (3)Connect USB devices (USB 2.0) such as printers, external hard disk drives,
DDigital audio port
(SPDIF Out)
EAudio Line OutConnect external 2.0 and 2.1 powered speakers.
FTV In (TV tuner
models only)
GWireless keyboard
and mouse receiver
(select models only)
HIR emitter (blaster)
(select models only)
IPower connectorPlug the power cord into the computer.
JStereo Audio In (TV
tuner models only)
Connect to the Internet through your wired network.
digital cameras, and MP3 players.
Connect to your home theater system or your surround sound digital
speakers. Supports 3.1, 4.1, and 5.1 speakers.
Connect your TV signal source to watch, record, and pause live TV. This is
a coaxial TV input signal connector.
Use wireless keyboard and mouse with the preinstalled receiver to control
some functions and software.
Adhere to your TV set-top box IR receiver area to receive the remote
control signal while watching and recording TV programs. This is not
required if you do not use a set-top box. A remote control is included with
select models only.
Connect stereo audio input cables (left and right) from a set-top box,
digital video camera, or other video device.
Welcom e7
ItemFunction (continued)
KS-Video In (TV tuner
models only)
Capture analog video from a video camera, or connect to a set-top box
for TV input.
Activity LED indicator lights
A
G
F
B
C
D
E
The following are the activity indicator light-emitting diodes (LEDs) on your HP TouchSmart PC:
LEDWhat it does
AWebcamIndicates webcam activity.
BPowerIndicates the power state: blue indicates power on, and amber
indicates Sleep mode.
COptical disc drive Indicates optical disc drive is in use.
DHard disk driveIndicates hard disk drive activity.
ERemote control IR receiver
(select models only)
FWireless keyboard and
mouse receiver
(select models only)
GMemory card readerIndicates memory card reader activity. When the LED is flashing, do
Indicates that your computer is working with your remote control to
navigate windows, record TV shows, and perform other activities in
Windows Media Center.
Indicates wireless signals received from the wireless keyboard and
mouse. The LED is visible from the back of the computer.
not remove your memory card.
When the LED is off, no card is inserted. A solid LED indicates that a
card is inserted with no read or write capacity. A flashing LED
indicates that there is memory card activity, and that a card has
read/write capacity.
8User Guide (Features may vary by model)
Connecting the Power Source
Route the power cord through the opening in the computer stand and plug the power cord directly into the
back of the computer. Plug the power cord into an AC power source through a surge
protector/uninterruptible power supply (UPS).
Cable Management
The HP TouchSmart PC includes an easy-to-use cable-management feature; all cables connected at the back
of the computer are routed through the opening in the computer stand.
Welcom e9
Computer Stand
The HP TouchSmart PC is shipped with the computer stand secured against the back of the computer. To
assure that the computer is in a stable position on your desktop, pull the computer stand open. Then, if you
want to change the angle of the HP TouchSmart PC, hold each side of the computer and tilt it back to an
angle of between 5 degrees and 40 degrees from the vertical.
CAUTION: Make sure the angle of the computer is at least 5 degrees from the vertical;
otherwise the computer will be unstable and could fall over.
5° min.
40°
max
CAUTION: The computer stand stays in place as you increase the angle; the computer moves
forward. Take care that the computer screen does not move off the table.
Computer Orientation
Your HP TouchSmart PC is designed to be operated in a landscape orientation (A). When wall-mounted,
the PC should remain with the display in landscape orientation, not portrait (B), or laid horizontal (C).
CAUTION: Placing your PC in portrait orientation (B) or horizontal orientation (C) may result in
damage to the hardware components.
AB BC
10User Guide (Features may vary by model)
Computer Swivel
The computer allows a usable range of motion with the swivel feature.
Wireless Keyboard and Mouse
Select models only
Your wireless keyboard and mouse are easy to set up. Just remove the battery tabs from both the keyboard
and the mouse. Also, make sure the Power switch on the bottom of the mouse is in the On position (the
keyboard does not have a Power switch). Then, turn on the computer. If you have trouble using the
keyboard and mouse, manually synchronize them as explained in the next procedure.
NOTE: Select models may have a wired keyboard and mouse.
The keyboard is designed to fit under your computer when not in use. Your product may vary from the one
shown here.
IMPORTANT: For better mouse battery life and performance, avoid using your mouse on a dark or
high-gloss surface, and turn mouse off when not in use.
Welcom e11
Synchronizing the wireless keyboard or mouse
The wireless keyboard and mouse are pre-synchronized, for your convenience, to work with your
HP TouchSmart PC. The keyboard and mouse should work immediately after you pull the battery tabs to
activate the preinstalled batteries, and then turn on the mouse (A).
You may need to manually synchronize the wireless keyboard or mouse if they are not functioning.
To synchronize them:
Make sure the keyboard and mouse are next to the HP TouchSmart PC, within 30 cm (1 foot) and
away from interference from other devices.
Keyboard: Press the Connect button on the bottom of the keyboard (B) for five seconds. The blue
activity LED on the wireless receiver illuminates when the synchronization command has been received
and turns off when synchronization is complete.
Mouse: Press the Connect button on the bottom of the mouse (C) for five seconds. The blue activity
LED on the wireless receiver illuminates when the synchronization command has been received and
turns off when synchronization is complete.
BAC
If this does not work, remove and then re-insert the wireless keyboard and mouse receiver from the back of
the computer and then synchronize the keyboard and mouse again.
USB Keyboard and Mouse
Select models only
Connect the keyboard and mouse to the USB ports on your computer.
12User Guide (Features may vary by model)
Ambient Light
Select models only
The HP TouchSmart Ambient Light casts a cool white glow from the base of the computer. By default, the
Ambient Light is turned off when you turn on the computer.
Press the Ambient Light button on the left side of the computer to turn the Ambient Light on.
Adding Hardware and Software
HP TouchSmart PCs may not be compatible with all of the software you install or all of the hardware you
add. Make sure your hardware and software are compatible with the operating system.
Determining whether your system is 64-bit or 32-bit
1 Tap the Start button, and then tap Help and Support.
2 Tap Troubleshooting Tools, and then tap System Information.
3 Tap Touch here to open System Information.
4 After the System Information displays, view Operating System, Name. It will appear as either
(64-bit) or (32-bit).
Optical Disc Drive
Use your CD/DVD drive to play and record CDs and DVDs, and Blu-ray discs (select models only). The
slim-slot CD/DVD drive does not have a disc tray. To insert a disc, turn the data side toward the back of the
computer (label side forward) and slide the disc into the drive slot.
A
To eject a disc, make sure the power is turned on and then press the Eject button (A) on the side of the disc
drive. You can also tap the Start button, tap Computer, press and hold (or with the mouse, right-click) the
CD drive, and then tap Eject.
If the disc gets stuck, refer to the Limited Warranty and Support Guide for the telephone number to contact
HP Support.
Welcom e13
Connecting to the Internet
Your HP TouchSmart PC is designed to support a wireless (select models only) or wired LAN that connects
your computer to other devices, such as printers and other PCs. The network connection to the Internet is
usually through a broadband modem (digital subscriber line [DSL] or cable), which requires a separate
subscription.
For a wireless LAN, the HP TouchSmart PC includes a built-in wireless LAN antenna, which you
can use to access your wireless home network.
For a wired LAN, connect an Ethernet cable (sold separately) to the Ethernet connector on the back
of the computer, and then connect the other end to the network router or broadband modem.
Wireless home network
Wireless access point and Internet service are required and not included. Availability of public wireless
access points may be limited.
First-time wireless network installation requires that you:
1 Purchase high-speed Internet service from an Internet service provider (ISP).
2 Purchase a broadband modem (DSL or cable). This may be provided by the ISP.
3 Purchase and install a wireless router (sold separately), if one is required.
NOTE: Broadband modem and router installation procedures vary, depending on the manufacturer.
Follow the manufacturer’s instructions.
4 Connect your computer to the network.
NOTE: A DSL wall connection is shown here. If you have a cable modem, the modem will be
connected to the wall using a coaxial cable.
5 Configure the HP TouchSmart PC to connect to the wireless network.
a Turn on your HP TouchSmart PC.
b Connect your HP TouchSmart PC to the wireless network:
Right-click the Network icon on the taskbar, and then select Open Network and
Sharing Center. Click Connect to a network. When the window opens, select the network, and then click Connect.
Or
Right-click the Network icon on the taskbar, and then select Network and Sharing
Center. When the window opens, select Set up a new connection or network,
and then follow the onscreen instructions.
cTest the wireless network by opening your Web browser and accessing any Web site.
6 Add wireless devices to the network (optional).
14User Guide (Features may vary by model)
Wired home network
First-time wired network installation requires that you:
1 Purchase high-speed Internet service from an Internet service provider (ISP).
2 Purchase a broadband modem (DSL or cable). This may be provided by the ISP.
3 Purchase and install a wired router (sold separately), if one is required.
NOTE: Broadband modem and router installation procedures vary, depending on the manufacturer.
Follow the manufacturer’s instructions.
4 Connect the DSL cable (shown) or coaxial cable (not shown) from the wall to the modem.
5 Connect the modem to the computer Ethernet port with an Ethernet cable. If you want to connect
multiple devices to the network, connect a router or hub (not shown) to the modem with an Ethernet
cable, and then connect the computer to the router with an Ethernet cable.
If you have a wired network in your home with Ethernet connectors in the wall, connect directly from
your computer Ethernet port to the Ethernet wall connector with an Ethernet cable.
The Ethernet port on the HP TouchSmart PC is located on the back of the computer, behind the
connector cover.
6 Add other computers or devices to your wired network:
a Disconnect power from the broadband modem and the router, and then shut down your
HP TouchSmart PC and the computers you want to add to your network.
b For each wired computer, connect one end of an Ethernet cable to the LAN connector on the
computer, and then connect the other end of the cable to any available Ethernet connector on
the router.
cReconnect power to the modem, and wait until the modem has completed its startup cycle.
Reconnect power to the router. Then, turn on the wired computers and your HP TouchSmart PC.
d Test the network connection for each wired computer by opening your Web browser and
accessing any Web site.
Welcom e15
Loading...
+ 47 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
