HP Aruba 3810M Switch Specsheet

QuickSpecs

Aruba 3810M Switch Series

Overview

1

Aruba 3810M Switch Series

The Aruba 3810 Switch Series provides performance and resiliency for enterprises, SMBs, and branch office networks. With HPE
Smart Rate multi
better application experience with low latency, virtualization with resilient stacking technology, and line rate 40GbE for pl
back haul capacity.

A powerf
latest applications. The 3810 delivers resiliency and scalability via innovative backplane stacking technology and redundant
swappab
IPv4 BGP, Dynamic Segmentation, robust QoS, and policy

The 3810M is easy to de
and external captive portal support. The switches offer a limited lifetime warranty.

Aruba 3810M Switch Series

Models

Aruba 3810M 24G 1-slot Switch

JL071A

Aruba 3810M 48G 1-slot Switch

JL072A

Aruba 3810M 24G PoE+ 1-slot Switch

JL073A

Aruba 3810M 48G PoE+ 1-slot Switch

JL074A

Aruba 3810M 16SFP+ 2-slot Switch

JL075A

Aruba 3810M 40G 8 HPE Smart Rate PoE+ 1-slot Switch

JL076A

Aruba 3810M 48G PoE+ 4SFP+ 680W Switch

JL428A

Aruba 3810M 48G PoE+ 4SFP+ 1050W Switch

JL429A

Aruba 3810M 24SFP+ 250W Switch

JL430A

-gigabit ports for high speed access points and IoT devices, this advanced Layer 3 network switch delivers a
enty of

ul Aruba ProVision ASIC delivers performance, robust feature support, and value with flexible programmability for the

, hot-

le power supplies all in a convenient 1U form factor. It supports an advanced Layer 2 and 3 feature set with OSPF, IPv6,

-based routing are included with no software licensing.

ploy, use and manage using Aruba AirWave or Aruba Central. Aruba ClearPass offers centralized security

Page

QuickSpecs

Aruba 3810M Switch Series

Overview

2

Key features

• Software-defined ready with REST APIs and OpenFlow support

• Advanced Layer 3 switch series with backplane stacking, dynamic segmentation, low latency and resiliency

• Advanced security and network management via Aruba ClearPass Policy Manager, Aruba AirWave and Aruba Central

• Modular 10GbE and 40GbE uplinks for wireless aggregation

• HPE Smart Rate for high-speed multi-gigabit capacity and PoE+ power

Page

QuickSpecs

Aruba 3810M Switch Series

Standard Features

3

Enhanced Capabilities and benefits

Software-defined networks

Unified Wired and Wireless

uba

Quality of Service

sets the IEEE 802.1p priority tag based on IP address, IP Type of Service (ToS), Layer 3 protocol, TCP/UDP port number,

throttles unicast packets with unknown destination addresses and limits flooding on the VLAN

• Supports multiple programmatic interfaces

Including REST APIs and Openflow 1.0 and 1.3, to enable automation of network operations, monitoring, and
troubleshooting.

• ClearPass Policy Manager support

unified wired and wireless policies using Aruba ClearPass Policy Manager

• Switch auto-configuration

Automatically configures switch for different settings such as VLAN, CoS, PoE max power, and PoE priority when an Ar
access point is detected.

• User role

Defines a set of switch-based policies in areas such as security, authentication, and QoS. A user role can be assigned to a
group of users or devices, using switch-based local user role or download from ClearPass

• Improved network simplicity and security

Aruba Dynamic Segmentation automatically enforces user, device and application-aware policies on Aruba wired and
wireless networks. Automated device profiling, role-based access control, and Layer 7 firewall features deliver enhanced
visibility and performance for a better overall experience for both IT and end-users alike.

• Dynamic segmentation

Provides a secured tunnel to transport network traffic on a per-port or per-user-role basis to an Aruba Controller. In per­user-role Tunneled Node, users are authenticated with ClearPass Policy Manager which can direct the traffic to be
tunneled to Aruba controller or switch locally.

• Static IP visibility

provides a way for ClearPass to do accounting for clients with static IP addresses

(QoS)

• Advanced classifier-based QoS

classifies traffic using multiple match criteria based on Layer 2, 3, and 4 information; applies QoS policies such as setting
priority level and rate limit to selected traffic on a per-port or per-VLAN basis

• Layer 4 prioritization

based on TCP/UDP port numbers

• Class of Service (CoS)

Support

• Bandwidth shaping:

– Port-based rate limiting: provides per-port ingress-/egress-enforced increased bandwidth
– Classifier-based rate limiting: uses an access control list (ACL) to enforce increased bandwidth for ingress traffic

on each port

source port, and DiffServ

– Reduced bandwidth: provides per-port, per-queue egress-based reduced bandwidth

• Remote intelligent mirroring

mirrors selected ingress/egress traffic based on an ACL, port, MAC address, or VLAN to a local or remote HPE 8200 zl,
6600, 6200 yl, 5400 zl, or 3500 switch anywhere on the network

• Remote monitoring (RMON), Extended RMON (XRMON), and sFlow v5

provide advanced monitoring and reporting capabilities for statistics, history, alarms, and events

• Traffic prioritization

allows real-time traffic classification into eight priority levels that are mapped to eight queues

• Unknown Unicast Rate Limiting

Page

QuickSpecs

Aruba 3810M Switch Series

Standard Features

4

Simplified management and configuration

monitor quality of voice traffic using the UDP jitter and UDP jitter for VoIP tests

Connectivity

– 6in4 tunneling

• Flexible management

supports both cloud-based Central and on-premise AirWave without ripping and replacing switching infrastructure

• Aruba Central cloud-based management platform

offers simple, secure, and cost effective way to manage switches

• Built-in programmable and easy to use REST API interface

provides configuration automation for campus networks

• Friendly port names

allows assignment of descriptive names to ports

• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

advertises and receives management information from adjacent devices on a network, facilitating easy mapping by
network management applications

• Command authorization

leverages RADIUS to link a custom list of CLI commands to an individual network administrator's login; an audit trail
documents activity

• Multiple configuration files

stores easily to the flash image

• Dual flash images

provides independent primary and secondary operating system files for backup while upgrading

• Out-of-band Ethernet management port

enables management over a separate physical management network; and keeps management traffic segmented from
network data traffic

• Zero Touch ProVisioning (ZTP)

simplifies installation of the switch infrastructure using the Aruba Activate-based or a DHCP-based process with AirWave
and Central Network Management

• Unidirectional Link Detection (UDLD)

monitors the link between two switches and blocks the ports on both ends of the link if the link goes down at any point
between the two devices

• IP service level agreements (SLA) for voice

• Jumbo frames on Gigabit Ethernet and 10-Gigabit Ethernet ports

allow high-performance remote backup and disaster-recovery services

• IEEE 802.3at Power over Ethernet (PoE+)

provides up to 30 W per port that allows support of the latest PoE+ capable devices such as IP phones, wireless access
points, and security cameras, as well as any IEEE 802.3af compliant end device; eliminates the cost of additional electrical
cabling and circuits that would otherwise be necessary in IP phone and WLAN deployments

• Support for pre-standard PoE

detects and provides power to pre-standard PoE devices

• Choice of uplinks:

– SFP+ uplink models: provide fiber-optic (up to 70 km) or direct-attach-cable (DAC) connectivity
– 10GBASE-T uplink models: offer 10GbE speeds, using standard RJ-45 connectors and standard twisted-pair

• Auto-MDIX

provides automatic adjustments for straight-through or crossover cables on all RJ-45 ports

• IPv6:

– IPv6 host: enables switch management in an IPv6 network
– Dual stack (IPv4 and IPv6): transitions IPv4 to IPv6, supporting connectivity for both protocols
– MLD snooping: forwards IPv6 multicast traffic to the appropriate interface
– IPv6 ACL/QoS: supports ACL and QoS for IPv6 traffic
– IPv6 routing: supports static, RIPng, OSPFv3 routing protocols

cabling up to 100 m

: supports encapsulation of IPv6 traffic in IPv4 packets

Page

QuickSpecs

Aruba 3810M Switch Series

Standard Features

5

– Security: provides RA guard, DHCPv6 protection, dynamic IPv6 lockdown, and ND snooping

Resiliency and high availability

allows groups of two routers to dynamically back each other up to create highly available routed environments in IPv4 and

h as unified communication and mobility; traffic will

provides high link availability in multiple VLAN environments by allowing multiple spanning trees; provides legacy support

Increased resiliency: with secondary power supply to enable complete switch power redundancy in case of power

provides easy-to-configure link redundancy of active and standby links

Layer 2 switching

allows automatic learning and dynamic assignment of VLANs

Layer 3 routing

provides RIPv1, RIPv2, and RIPng routing

• Virtual Router Redundancy Protocol (VRRP)

IPv6 networks

• Nonstop switching and routing

improves network availability to better support critical applications, suc
continue to be forwarded during failovers, when the backup member of the stack becomes the commander

• IEEE 802.3ad Link Aggregation Protocol (LACP) and Hewlett Packard Enterprise port trunking

support up to 144 trunks, each with up to 8 links (ports) per trunk

• IEEE 802.1s Multiple Spanning Tree

for IEEE 802.1d and IEEE 802.1w

• Dual hot-swappable power supplies

–

line or supply failure

– Secondary power supply increases available PoE+ power

• Distributed trunking

enables loop-free and redundant network topology without using Spanning Tree Protocol; allows a server or switch to
connect to two switches using one logical trunk for redundancy and load sharing

• SmartLink

• IEEE 802.1ad QinQ

increases the scalability of an Ethernet network by providing a hierarchical structure; connects multiple LANs on a high­speed campus or metro network

• VLAN support and tagging

supports the IEEE 802.1Q standard and 4096 VLANs simultaneously

• IEEE 802.1v protocol VLANs

isolate select non-IPv4 protocols automatically into their own VLANs

• MAC-based VLAN

provides granular control and security; uses RADIUS to map a MAC address/user to specific VLANs

• Rapid Per-VLAN Spanning Tree (RPVST+)

allows each VLAN to build a separate spanning tree to improve link bandwidth usage; is compatible with PVST+

• Aruba 3810M switch meshing

dynamically load balances across multiple active redundant links to increase available aggregate bandwidth; allows
concurrent Layer 3 routing

• GVRP and MVRP

• Static IP routing

provides manually configured routing for both IPv4 and IPv6 networks

• OSPF

provides OSPFv2 for IPv4 routing and OSPFv3 for IPv6 routing

• Policy-based routing

makes routing decisions based on policies set by the network administrator

• Border Gateway Protocol (BGP)

provides IPv4 Border Gateway Protocol routing, which is scalable, robust, and flexible

• Routing Information Protocol (RIP)

Page

QuickSpecs

Aruba 3810M Switch Series

Standard Features

6

Layer 3 services

enables link connectivity monitoring and reduces network convergence time for static routing, OSPFv2, and VRRP

Convergence

configure automatically

assigns attributes such as VLAN and QoS using locally configured profile that can be a list of MAC prefixes

Warranty, Services and Support

For support and services information, visit https://www.arubanetworks.com/support-services/arubacare/

• Loopback interface address

defines an address in Routing Information Protocol (RIP) and Open Standard Path First (OSPF), improving diagnostic
capability

• Route maps

provide more control during route redistribution; allow filtering and altering of route metrics

• User datagram protocol (UDP) helper function

allows UDP broadcasts to be directed across router interfaces to specific IP unicast or subnet broadcast addresses; and
helps prevent server spoofing for UDP services such as DHCP

• DHCP server

centralizes and reduces the cost of IPv4 address management

• Bidirectional Forwarding Detection (BFD)

• IP multicast snooping (data-driven IGMP)

prevents flooding of IP multicast traffic

• LLDP-MED (Media Endpoint Discovery)

defines a standard extension of LLDP that stores values for parameters such as QoS and VLAN to
network devices such as IP phones

• PoE allocations

supports multiple methods (automatic, IEEE 802.3af class, LLDP-MED, or user-specified) to allocate PoE power for more
efficient energy savings

• Protocol Independent Multicast for IPv6

supports one-to-many and many-to-many media casting use cases such as IPTV over IPv6 networks

• IP multicast routing

includes PIM sparse and dense modes to route IP multicast traffic

• Auto VLAN configuration for voice

– RADIUS VLAN

uses a standard RADIUS attribute and LLDP-MED to automatically configure a VLAN for IP phones

– CDPv2

uses CDPv2 to configure legacy IP phones

• Local MAC Authentication

• Limited Lifetime Warranty

See https://www.arubanetworks.com/support-services/ product-warranties/
information included with your product purchase

• For Software Releases and Documentation, refer to https://asp.arubanetworks.com/downloads

for warranty and support

Page

QuickSpecs

Aruba 3810M Switch Series

Standard Features

7

Security

allows users to use a more secure and reliable mode of communications between switch and radius servers over unsecure

number on a per-VLAN or per-port basis

• Control plane policing

sets rate limit on control protocols to protect CPU overload from DOS attacks

• Source-port filtering

allows only specified ports to communicate with each other

• RADIUS/TACACS+

eases switch management security administration by using a password authentication server

• Secure shell

encrypts all transmitted data for secure remote CLI access over IP networks

• Secure Sockets Layer (SSL)

encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in the switch

• Radius over TLS (RadSec)

•

networks

• Port security

allows access only to specified MAC addresses, which can be learned or specified by the administrator

• MAC address lockout

prevents particular configured MAC addresses from connecting to the network

• Detection of malicious attacks

monitors 10 types of network traffic and sends a warning when an anomaly that potentially can be caused by malicious
attacks is detected

• Secure FTP

allows secure file transfer to and from the switch; protects against unwanted file downloads or unauthorized copying of a
switch configuration file

• Switch management logon security

helps secure switch CLI logon by optionally requiring either RADIUS or TACACS+ authentication

• Secure management access

delivers secure encryption of all access methods (CLI, GUI, or MIB) through SSHv2, SSL, and/or SNMPv3

• ICMP throttling

defeats ICMP denial-of-service attacks by enabling any switch port to automatically throttle ICMP traffic

• Identity-driven ACL

enables implementation of a highly granular and flexible access security policy and VLAN assignment specific to each
authenticated network user

• STP BPDU port protection

blocks Bridge Protocol Data Units (BPDUs) on ports that do not require BPDUs, preventing forged BPDU attacks

• Dynamic IP lockdown

works with DHCP protection to block traffic from unauthorized hosts, preventing IP source address spoofing

• DHCP protection

blocks DHCP packets from unauthorized DHCP servers, preventing denial-of-service attacks

• Dynamic ARP protection

blocks ARP broadcasts from unauthorized hosts, preventing eavesdropping or theft of network data

• STP root guard

protects the root bridge from malicious attacks or configuration mistakes

• Management Interface Wizard

helps secure management interfaces such as SNMP, Telnet, SSH, SSL, Web, and USB at the desired level

• Security banner

displays a customized security policy when users log in to the switch

• Switch CPU protection

provides automatic protection against malicious network traffic trying to shut down the switch

• ACLs

provide filtering based on the IP field, source/destination IP address/subnet and source/destination TCP/UDP port

Page

QuickSpecs

Aruba 3810M Switch Series

Standard Features

8

• Multiple authentication methods

chatty legacy devices to stay authenticated by pinning client MAC addresses to the port until the clients logoff

– IEEE 802.1X

authenticates multiple IEEE 802.1X users per port; prevents a user from "piggybacking" on another user's
authentication

– Supports web-based authentication
– MAC-based client authentication
– Concurrent authentication modes

enables a switch port to accept up to 32 sessions of 802.1X, Web, and MAC authentication

• Private VLAN

provides network security by restricting peer-to-peer communication to prevent a variety of malicious attacks; typically a
switch port can only communicate with other ports in the same community and/or an uplink port, regardless of VLAN ID
or destination MAC address

• IEEE 802.1AE MACsec

provides security on a link between two switch ports (1Gbps or 10Gbps) using standard encryption and authentication

• Open authentication role

simplifies first-time deployment of AAA in brownfield deployments by allowing full network access for failed clients and
provides instant connectivity as soon as a client is plugged-in

• Critical authentication role

ensures that important infrastructure devices such as IP phones are allowed network access even in the absence of a
RADIUS server

• MAC pinning

allows non­or get disconnected

• Enrollment over Secure Transport (EST)

enhances the switch PKI infrastructure with a simpler, scalable and more secure method of certificate provisioning, re­enrollment and renewal

Page

QuickSpecs

Aruba 3810M Switch Series

Configuration

Information

9

Build To Order:

BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-Shippable solution.

BTO Models

Rule #

Description

SKU

Aruba 3810M 24G 1-slot Switch

JL071A

•

• 1U - Height

Aruba 3810M 48G 1-slot Switch

JL072A

•

• 1U - Height

Aruba 3810M 24G PoE+ 1-slot Switch

JL073A

•

• 1U - Height

Aruba 3810M 48G PoE+ 1-slot Switch

JL074A

•

• 1U - Height

1, 3

Aruba 3810M 16SFP+ 2-slot Switch

JL075A

•

•

Aruba 3810M 40G 8 HPE Smart Rate PoE+ 1-slot Switch

JL076A

•

• 1U - Height

24 RJ-45 autosensing 10/100/1000 ports

• 1 open stacking module slot

• 1 open uplink module slot

• 1 Power Supply required (Max 2)

48 RJ-45 autosensing 10/100/1000 ports

• 1 open stacking module slot

• 1 open uplink module slot

• 1 Power Supply required (Max 2)

24 RJ-45 autosensing 10/100/1000 PoE+ ports

• 1 open stacking module slot

• 1 open uplink module slot

• 1 Power Supply required (Max 2)

48 RJ-45 autosensing 10/100/1000 PoE+ ports

• 1 open stacking module slot

• 1 open uplink module slot

• 1 Power Supply required (Max 2)

16 fixed 1000/10000 SFP/SFP+ ports

• min=0 \ max=16 SFP/SFP+ Transceivers

• 1 open stacking module slot

• 2 open uplink module slot

• 1 Power Supply required (Max 2)

1U - Height

40 RJ-45 autosensing 10/100/1000 PoE+ ports

• 8 RJ-45 1/2.5/5/XGT PoE+ ports

• 1 open stacking module slot

• 1 open uplink module slot

• 1 Power Supply required (Max 2)

Page

QuickSpecs

Aruba 3810M Switch Series

Configuration

Information

10

1 ,2, 3

Aruba 3810M 48G PoE+ 4SFP+ 680W Switch

JL428A

•

• 1U - Height

Aruba 3810M 48G PoE+ 4SFP+ 680W Switch PDU NA, JP or TW

JL428A#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

Aruba 3810M 48G PoE+ 4SFP+ 680W Switch PDU ROW

JL428A#B2C

• C15 PDU Jumper Cord (ROW)

Aruba 3810M 48G PoE+ 4SFP+ 680W Switch United States 220 volt

JL428A#B2E

• NEMA L6-20P Cord (NA/MEX/JP/TW)

Aruba 3810M 48G PoE+ 4SFP+ 680W Switch

JL428A#AC3

• No Localized Power Cord Selected

1 ,2, 3

Aruba 3810M 48G PoE+ 4SFP+ 1050W Switch

JL429A

•

• 1U - Height

Aruba 3810M 48G PoE+ 4SFP+ 1050W Switch PDU NA, JP or TW

JL429A#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

Aruba 3810M 48G PoE+ 4SFP+ 1050W Switch PDU ROW

JL429A#B2C

• C15 PDU Jumper Cord (ROW)

Aruba 3810M 48G PoE+ 4SFP+ 1050W Switch United States 220 volt

JL429A#B2E

• NEMA L6-20P Cord (NA/MEX/JP/TW)

Aruba 3810M 48G PoE+ 4SFP+ 1050W Switch

JL429A#AC3

• No Localized Power Cord Selected

1 ,2, 3

Aruba 3810M 24SFP+ 250W Switch

JL430A

•

• 1U - Height

Aruba 3810M 24SFP+ 250W Switch PDU NA, JP or TW

JL430A#B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

Aruba 3810M 24SFP+ 250W Switch PDU ROW

JL430A#B2C

• C15 PDU Jumper Cord (ROW)

Aruba 3810M 24SFP+ 250W Switch United States 220 volt

JL430A#B2E

Includes 1 3810M 48 Port PoE+ Switch (JL074A)

• 48 RJ-45 autosensing 10/100/1000 PoE+ ports

• 4 fixed 1000/10000 SFP/SFP+ ports

• min=0 \ max=4 SFP/SFP+ Transceivers

• 1 open stacking module slot

• Includes 1 uplink module (JL083A)

• Includes 1 680W Power Supply (JL086A, Max 2)

Includes 1 3810M 48 Port PoE+ Switch (JL074A)

• 48 RJ-45 autosensing 10/100/1000 PoE+ ports

• 4 fixed 1000/10000 SFP/SFP+ ports

• min=0 \ max=4 SFP/SFP+ Transceivers

• 1 open stacking module slot

• Includes 1 uplink module (JL083A)

• Includes 1 1050W Power Supply (JL087A, Max 2)

Includes 1 3810M 16 Port SFP+ Switch (JL075A)

• 16 fixed 1000/10000 SFP/SFP+ ports

• 8 port SFP+ ports on the included modules

• min=0 \ max=24 SFP/SFP+ Transceivers

• 1 open stacking module slot

• Includes 2 uplink modules (JL083A)

• Includes 1 250W Power Supply (JL085A, Max 2)

Page

QuickSpecs

Aruba 3810M Switch Series

Configuration

Information

11

• NEMA L6-20P Cord (NA/MEX/JP/TW)

Aruba 3810M 24SFP+ 250W Switch

JL430A#AC3

• No Localized Power Cord Selected

Configuration Rules

Rule #

Description

SKU

1

The following Transceivers install into this Switch (For the 1000/10000 SFP+ Ports):

Aruba 1G SFP LC SX 500m OM2 MMF Transceiver

J4858D

Aruba 1G SFP LC LX 10km SMF Transceiver

J4859D

Aruba 1G SFP LC LH 70km SMF Transceiver

J4860D

Aruba 1G SFP RJ45 T 100m Cat5e Transceiver

J8177D

Aruba 100M SFP LC FX 2km MMF Transceiver

J9054D

Aruba 10G SFP+ LC SR 300m OM3 MMF Transceiver

J9150D

Aruba 10G SFP+ LC LR 10km SMF Transceiver

J9151E

Aruba 10G SFP+ LC LRM 220m OM2 MMF Transceiver

J9152D

Aruba 10G SFP+ LC ER 40km SMF Transceiver

J9153D

Aruba 10G SFP+ to SFP+ 1m Direct Attach Copper Cable

J9281D

Aruba 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

J9283D

Aruba 10G SFP+ to SFP+ 7m Direct Attach Copper Cable

J9285D

2

Localization required on orders without #B2B, #B2C, #B2E options.

3

The following Transceivers install into this Switch : (For the 1000/10000 SFP+ Ports)

Aruba 1G SFP LC SX 500m MMF TAA Transceiver

JL745A

Aruba 1G SFP LC LX 10km SMF TAA Transceiver

JL746A

Aruba 1G SFP RJ45 T 100m Cat5e TAA Transceiver

JL747A

Aruba 10G SFP+ LC SR 300m MMF TAA Transceiver

JL748A

Aruba 10G SFP+ LC LR 10km SMF TAA Transceiver

JL749A

Page

QuickSpecs

Aruba 3810M Switch Series

Configuration

Information

12

Rack Level Integration CTO Models

Rule #

Description

SKU

10, 11

Aruba 3810M 24G 1-slot Switch

JL071A

•

• 1U - Height

10, 11

Aruba 3810M 48G 1-slot Switch

JL072A

•

• 1U - Height

10, 11

Aruba 3810M 24G PoE+ 1-slot Switch

JL073A

•

• 1U - Height

10, 11

Aruba 3810M 48G PoE+ 1-slot Switch

JL074A

•

• 1U - Height

1, 2, 10, 11

Aruba 3810M 16SFP+ 2-slot Switch

JL075A

•

•

10, 11

Aruba 3810M 40G 8 HPE Smart Rate PoE+ 1-slot Switch

JL076A

•

• 1U - Height

24 RJ-45 autosensing 10/100/1000 ports

• 1 open stacking module slot

• 1 open uplink module slot

• 1 Power Supply required (Max 2)

48 RJ-45 autosensing 10/100/1000 ports

• 1 open stacking module slot

• 1 open uplink module slot

• 1 Power Supply required (Max 2)

24 RJ-45 autosensing 10/100/1000 PoE+ ports

• 1 open stacking module slot

• 1 open uplink module slot

• 1 Power Supply required (Max 2)

48 RJ-45 autosensing 10/100/1000 PoE+ ports

• 1 open stacking module slot

• 1 open uplink module slot

• 1 Power Supply required (Max 2)

16 fixed 1000/10000 SFP/SFP+ ports

• min=0 \ max=16 SFP/SFP+ Transceivers

• 1 open stacking module slot

• 2 open uplink module slot

• 1 Power Supply required (Max 2)

1U - Height

40 RJ-45 autosensing 10/100/1000 PoE+ ports

• 8 RJ-45 1/2.5/5/XGT PoE+ ports

• 1 open stacking module slot

• 1 open uplink module slot

• 1 Power Supply required (Max 2)

Page

QuickSpecs

Aruba 3810M Switch Series

Configuration

Information

13

Rule #

Description

SKU

1, 2, 3, 4, 10,
11

Aruba 3810M 48G PoE+ 4SFP+ 680W Switch

JL428A

•

• 1U - Height

PDU Cable NA/MEX/TW/JP

JL428A #B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JL428A #B2C

• C15 PDU Jumper Cord (ROW)

High Volt Power Supply to Wall Power Cord

JL428A #B2E

• NEMA L6-20P Cord (NA/MEX/JP/TW)

Aruba 3810M 48G PoE+ 4SFP+ 680W Switch

JL428A#AC3

• No Localized Power Cord Selected

1, 3, 4, 10,
11

Aruba 3810M 48G PoE+ 4SFP+ 1050W Switch

JL429A

•

• 1U - Height

PDU Cable NA/MEX/TW/JP

JL429A #B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JL429A #B2C

• C15 PDU Jumper Cord (ROW)

High Volt Power Supply to Wall Power Cord

JL429A #B2E

• NEMA L6-20P Cord (NA/MEX/JP/TW)

No Power Cord

JL429A #AC3

•

1, 3, 4, 10,
11

Aruba 3810M 24SFP+ 250W Switch

JL430A

•

• 1U - Height

Includes 1 3810M 48 Port PoE+ Switch (JL074A)

• 48 RJ-45 autosensing 10/100/1000 PoE+ ports

• 4 fixed 1000/10000 SFP/SFP+ ports

• min=0 \ max=4 SFP/SFP+ Transceivers

• 1 open stacking module slot

• Includes 1 uplink module (JL083A)

• Includes 1 680W Power Supply (JL086A, Max 2)

Includes 1 3810M 48 Port PoE+ Switch (JL074A)

• 48 RJ-45 autosensing 10/100/1000 PoE+ ports

• 4 fixed 1000/10000 SFP/SFP+ ports

• min=0 \ max=4 SFP/SFP+ Transceivers

• 1 open stacking module slot

• Includes 1 uplink module (JL083A)

• Includes 1 1050W Power Supply (JL087A, Max 2)

No Localized Power Cord Selected

Includes 1 3810M 16 Port SFP+ Switch (JL075A)

• 16 fixed 1000/10000 SFP/SFP+ ports

• 8 port SFP+ ports on the included modules

• min=0 \ max=24 SFP/SFP+ Transceivers

• 1 open stacking module slot

• Includes 2 uplink modules (JL083A)

• Includes 1 250W Power Supply (JL085A, Max 2)

Page

QuickSpecs

Aruba 3810M Switch Series

Configuration

Information

14

PDU Cable NA/MEX/TW/JP

JL430A #B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JL430A #B2C

• C15 PDU Jumper Cord (ROW)

High Volt Power Supply to Wall Power Cord

JL430A #B2E

•

No Power Cord

JL430A #AC3

• No Localized Power Cord Selected

Configuration Rules

Rule #

Description

SKU

1

The following Transceivers install into this Switch (For the 1000/10000 SFP+ Ports):

Aruba 1G SFP LC SX 500m OM2 MMF Transceiver

J4858D

Aruba 1G SFP LC LX 10km SMF Transceiver

J4859D

Aruba 1G SFP LC LH 70km SMF Transceiver

J4860D

Aruba 1G SFP RJ45 T 100m Cat5e Transceiver

J8177D

Aruba 100M SFP LC FX 2km MMF Transceiver

J9054D

Aruba 10G SFP+ LC SR 300m OM3 MMF Transceiver

J9150D

Aruba 10G SFP+ LC LR 10km SMF Transceiver

J9151E

Aruba 10G SFP+ LC LRM 220m OM2 MMF Transceiver

J9152D

Aruba 10G SFP+ LC ER 40km SMF Transceiver

J9153D

Aruba 10G SFP+ to SFP+ 1m Direct Attach Copper Cable

J9281D

Aruba 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

J9283D

Aruba 10G SFP+ to SFP+ 7m Direct Attach Copper Cable

J9285D

2

The following Transceivers install into this Switch : (For the 1000/10000 SFP+ Ports)

Aruba 1G SFP LC SX 500m MMF TAA Transceiver

JL745A

Aruba 1G SFP LC LX 10km SMF TAA Transceiver

JL746A

Aruba 1G SFP RJ45 T 100m Cat5e TAA Transceiver

JL747A

Aruba 10G SFP+ LC SR 300m MMF TAA Transceiver

JL748A

Aruba 10G SFP+ LC LR 10km SMF TAA Transceiver

JL749A

3

Localization required on orders without #B2B, #B2C, #B2E options.

4

When Switches are Factory Racked with this power supply, Then #B2B, or #B2C should be
the
Power Supplies” section.)

10

If switch is 0D1 to Racks, then the J9583A#0D1 is also required.

11

If the CTO Switch Chassis needs to be racked, Then the CTO Base Model needs to integrate
(with #0D1) to the HPE Network Rack.

NOTE:

Drop down under power supply should offer the following options and results:
Switch/Router/Power Supply to PDU Power Cord
and Japan or #B2C ROW.
Switch/Router/Power Supply to Wall Power Cord - Localized Option (Watson Default for BTO
and Box Level CTO)
High Volt Switch/Router/Power Supply to Wall Power Cord
North Ameri
Watson Blue

It is recommended that both power supplies match for full redundancy in
the case of a fully populated switch, but not required.
Clic UNB - If an option is ordered with #0D1/#B01, then the switch must have #0D1 option.

NEMA L6-20P Cord (NA/MEX/JP/TW)

Defaulted Power Cable option on the Power Supplies. (See Drop down remark in “Internal

- #B2B in North America, Mexico, Taiwan,

(Watson Default B2B or B2C for Rack Level CTO)

- #B2E Option. (Offered only in

ca, Mexico, Taiwan, and Japan)

NOTE:

Page

QuickSpecs

Aruba 3810M Switch Series

Configuration

Information

15

Enter the following menu selections as integrated to the CTO Model X switch above if order is factory built.

Modules

Stacking Modules

Rule #

Description

SKU

System (std 0 // max=1) User Selection (min 0 / max=1) per Chassis

1

Aruba 3810M 4-port Stacking Module

JL084A

• min=1 \ max=4 Stacking cables

Configuration Rules

1

One of the following Stacking Cables must be selected:

Aruba 3800/3810M 0.5m Stacking Cable

J9578A

Aruba 3800/3810M 1m Stacking Cable

J9665A

Aruba 3800/3810M 3m Stacking Cable

J9579A

Uplink Modules

•

• JL430A Only System (std 2 // max 2) User Selection (min 0 / max 0) per Chassis

Rule #

Description

SKU

1

Aruba 3810M/2930M 1-port QSFP+ 40GbE Module

JL078A

• min=0 \ max=1 QSFP+ Transceiver

1, 3

Aruba 3810M 2QSFP+ 40GbE Module

JL079A

• min=0 \ max=2 QSFP+ Transceiver

Aruba 3810M 4 HPE Smart Rate PoE+ Module

JL081A

• 4 x HPE Smart Rate Ports

2, 4, 5

Aruba 3810M/2930M 4-port 100M/1G/10G SFP+ MACsec Module JL075A

JL083A

• min=0 \ max=4 SFP/SFP+ Transceivers

Configuration Rules

1

The following Transceivers install into this Module: (Use #0D1 or #B01 if switch is CTO) - if
applicable

HPE X142 40G QSFP+ MPO SR4 Transceiver

JH231A

HPE X142 40G QSFP+ LC LR4 SM Transceiver

JH232A

HPE X142 40G QSFP+ MPO eSR4 300M Transceiver

JH233A

HPE X242 40G QSFP+ to QSFP+ 1m Direct Attach Copper Cable

JH234A

HPE X242 40G QSFP+ to QSFP+ 3m Direct Attach Copper Cable

JH235A

HPE X242 40G QSFP+ to QSFP+ 5m Direct Attach Copper Cable

JH236A

Aruba 40G QSFP+ LC Bidirectional 150m MMF 2-strand Transceiver

JL308A

2

The following Transceivers install into this Switch (For the 1000/10000 SFP+ Ports):

Aruba 1G SFP LC SX 500m OM2 MMF Transceiver

J4858D

Aruba 1G SFP LC LX 10km SMF Transceiver

J4859D

Aruba 1G SFP LC LH 70km SMF Transceiver

J4860D

Aruba 1G SFP RJ45 T 100m Cat5e Transceiver

J8177D

Aruba 100M SFP LC FX 2km MMF Transceiver

J9054D

Aruba 10G SFP+ LC SR 300m OM3 MMF Transceiver

J9150D

Aruba 10G SFP+ LC LR 10km SMF Transceiver

J9151E

Aruba 10G SFP+ LC LRM 220m OM2 MMF Transceiver

J9152D

Aruba 10G SFP+ LC ER 40km SMF Transceiver

J9153D

JL071A, JL072A, JL073A, JL074A, JL076A Only System (std 0 // max 1) User
Selection (min 0 / max 1) per Chassis

• JL075A Only System (std 0 // max 2) User Selection (min 0 / max 2) per Chassis

• JL428A, JL429A Only System (std 1 // max 1) User Selection (min 0 / max 0) per

Chassis

Page

QuickSpecs

Aruba 3810M Switch Series

Configuration

Information

16

Aruba 10G SFP+ to SFP+ 1m Direct Attach Copper Cable

J9281D

Aruba 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

J9283D

Aruba 10G SFP+ to SFP+ 7m Direct Attach Copper Cable

J9285D

3

This module is only available for the following switches:

Aruba 3810M 48G 1-slot Switch

JL072A

Aruba 3810M 48G PoE+ 1-slot Switch

JL074A

Aruba 3810M 40G 8 HPE Smart Rate PoE+ 1-slot Switch

JL076A

4

The following Transceivers install into this Switch (Use #0D1 qutoed to switch if switch is
CTO) - if applicable :

Aruba 1G SFP LC SX 500m MMF TAA Transceiver

JL745A

Aruba 1G SFP LC LX 10km SMF TAA Transceiver

JL746A

Aruba 1G SFP RJ45 T 100m Cat5e TAA Transceiver

JL747A

5

The following Transceivers install into this Switch (Use #0D1 qutoed to switch if switch is
CTO) - if applicable :

Aruba 10G SFP+ LC SR 300m MMF TAA Transceiver

JL748A

Aruba 10G SFP+ LC LR 10km SMF TAA Transceiver

JL749A

NOTE:

Although all 3810M/2930M Switches are compatible with the 4 Port HPE Smart Rate
module, non PoE switches do not provide PoE power to the HPE Smart Rate Module.

Transceivers

Rule #

Description

SKU

SFP Transceivers

Aruba 100M SFP LC FX 2km MMF Transceiver

J9054D

Aruba 1G SFP LC SX 500m OM2 MMF Transceiver

J4858D

Aruba 1G SFP LC LX 10km SMF Transceiver

J4859D

Aruba 1G SFP LC LH 70km SMF Transceiver

J4860D

Aruba 1G SFP RJ45 T 100m Cat5e Transceiver

J8177D

Aruba 1G SFP LC SX 500m MMF TAA Transceiver

JL745A

Aruba 1G SFP LC LX 10km SMF TAA Transceiver

JL746A

Aruba 1G SFP RJ45 T 100m Cat5e TAA Transceiver

JL747A

SFP+ Transceivers

Aruba 10G SFP+ LC SR 300m OM3 MMF Transceiver

J9150D

Aruba 10G SFP+ LC LR 10km SMF Transceiver

J9151E

Aruba 10G SFP+ LC LRM 220m OM2 MMF Transceiver

J9152D

Aruba 10G SFP+ LC ER 40km SMF Transceiver

J9153D

Aruba 10G SFP+ LC SR 300m MMF TAA Transceiver

JL748A

Aruba 10G SFP+ LC LR 10km SMF TAA Transceiver

JL749A

Aruba 10G SFP+ to SFP+ 1m Direct Attach Copper Cable

J9281D

Aruba 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

J9283D

Aruba 10G SFP+ to SFP+ 7m Direct Attach Copper Cable

J9285D

QSFP+ Transceivers

HPE X142 40G QSFP+ MPO SR4 Transceiver

JH231A

HPE X142 40G QSFP+ LC LR4 SM Transceiver

JH232A

HPE X142 40G QSFP+ MPO eSR4 300M Transceiver

JH233A

Aruba 40G QSFP+ LC Bidirectional 150m MMF 2

JL308A

HPE X242 40G QSFP+ to QSFP+ 1m Direct Attach Copper Cable

JH234A

HPE X242 40G QSFP+ to QSFP+ 3m Direct Attach Copper Cable

JH235A

HPE X242 40G QSFP+ to QSFP+ 5m Direct Attach Copper Cable

JH236A

-strand Transceiver

Page

QuickSpecs

Aruba 3810M Switch Series

Configuration

Information

17

Internal Power Supplies

System (std 0 // max=2) User Selection (min 1 / max=2) per Switch
For JL428A, JL429A, JL430A System (std 1 // max=2)
Switch

Rule #

Description

SKU

1, 3, 4

Aruba X371 12VDC 250W 100-240VAC Power Supply

JL085A

• PDU Cable NA/MEX/TW/JP

JL085A #B2B

C15 PDU Jumper Cord (NA/MEX/TW/JP)

• PDU Cable ROW

JL085A #B2C

C15 PDU Jumper Cord (ROW)

• High Volt Power Supply to Wall Power Cord

JL085A #B2E

NEMA L6-20P Cord (NA/MEX/JP/TW)

• No Power Cord

JL085A #AC3

No Localized Power Cord Selected

2, 3, 4

Aruba X372 54VDC 680W 100-240VAC Power Supply

JL086A

PDU Cable NA/MEX/TW/JP

JL086A #B2B

• C15 PDU Jumper Cord (NA/MEX/TW/JP)

PDU Cable ROW

JL086A #B2C

• C15 PDU Jumper Cord (ROW)

High Volt Power Supply to Wall Power Cord

JL086A #B2E

•

Rule #

Description

SKU

No Power Cord

JL086A #AC3

•

2, 3, 4

Aruba X372 54VDC 1050W 110-240VAC Power Supply

JL087A

PDU Cable NA/MEX/TW/JP

JL087A #B2B

C15 PDU Jumper Cord (NA/MEX/TW/JP)

• PDU Cable ROW

JL087A #B2C

C15 PDU Jumper Cord (ROW)

High Volt Power Supply to Wall Power Cord

JL087A #B2E

• NEMA L6-20P Cord (NA/MEX/JP/TW)

No Power Cord

JL087A #AC3

• No Localized Power Cord Selected

Configuration Rules

Rule #

Description

1

If this Power supply is selected, Then JL071A, JL072A, JL075A, JL430A must be the switch
its installed into.

2

If this Power supply is selected, Then JL073A, JL074A, JL076A, JL428A, JL429A must be
the switch its installed into.

3

Localization required on orders without #B2B or #B2C options.

4

When Switches are Factory Racked with this power supply, Then #B2B, or #B2C should be
the Defaulted Power Cable option on the Power Supplies. (See Drop down remark in “Internal
Power Supplies” section.)

User Selection (min 0 / max=1) per

NEMA L6-20P Cord (NA/MEX/JP/TW)

No Localized Power Cord Selected

Page

QuickSpecs

Aruba 3810M Switch Series

Configuration

Information

18

NOTE:

Drop down under power supply should offer the following options and results:
S
and Japan or #B2C ROW. (Watson Default B2B or B2C for Rack Level CTO)
Switch/Router/Power Supply to Wall Power Cord - Localized Option (Watson Default for BTO
and Box Lev
High Volt Switch/Router/Power Supply to Wall Power Cord
North America, Mexico, Taiwan, and Japan)
No Localized Power Cord Selected
Watson Blue

It is recommended that both power supplies match for full redundancy in
the case of a fully populated switch, but not required.

Cables

Rule #

Description

SKU

Stacking Cables

(std 0 // max 99) User Selection (min 0 // max 99) per switch

Aruba 3800/3810M 0.5m Stacking Cable

J9578A

Aruba 3800/3810M 1m Stacking Cable

J9665A

Aruba 3800/3810M 3m Stacking Cable

J9579A

Console Cables

(std 0 // max 99) User Selection (min 0 // max 99) per switch

Aruba X2C2 RJ45 to DB9 Console Cable

JL448A

Multi-Mode Cables

(std 0 // max 99) User Selection (min 0 // max 99) per switch

HPE LC to LC Multi

AJ833A

HPE LC to LC Multi

AJ834A

HPE LC to LC Multi-mode OM3 2-Fiber 2.0m 1-Pack Fiber Optic Cable

AJ835A

HPE LC to LC Multi-mode OM3 2-Fiber 5.0m 1-Pack Fiber Optic Cable

AJ836A

HPE LC to LC Multi-mode OM3 2-Fiber 15.0m 1-Pack Fiber Optic Cable

AJ837A

HPE LC to LC Multi-mode OM3 2-Fiber 30.0m 1-Pack Fiber Optic Cable

AJ838A

HPE LC to LC Multi-mode OM3 2-Fiber 50.0m 1-Pack Fiber Optic Cable

AJ839A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable

QK732A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable

QK733A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable

QK734A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable

QK735A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable

QK736A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable

QK737A

witch/Router/Power Supply to PDU Power Cord - #B2B in North America, Mexico, Taiwan,

el CTO)

- #B2E Option. (Offered only in

- #AC3 Option

NOTE:

-mode OM3 2-Fiber 0.5m 1-Pack Fiber Optic Cable

-mode OM3 2-Fiber 1.0m 1-Pack Fiber Optic Cable

Page

QuickSpecs

Aruba 3810M Switch Series

Configuration

Information

19

Switch Enclosure Options

Rule #

Description

SKU

Mounting Kit

(std 0 // max 1) User Selection (min 0 // max 1) per switch

1

HPE X410 1U Universal 4-post Rackmount Kit

J9583A

Configuration Rules

Rule #

Description

1

If this switch is factory installed in HPE Network Racks, Then the J9583A#0D1 is required

Fan Tray

Aruba 3810 Switch Fan Tray

JL088A

• This is a Spare Only

Page

QuickSpecs

Aruba 3810M Switch Series

Related Options

20

Aruba 3810M Switch Series accessories

Rule #

Description

SKU

Modules

Aruba 3810M 4-port Stacking Module

JL084A

Aruba 3810M/2930M 4-port 100M/1G/10G SFP+ MACsec Module

JL083A

Aruba 3810M/2930M 1-port QSFP+ 40GbE Module

JL078A

Aruba 3810M 2QSFP+ 40GbE Module

JL079A

Transceivers

Aruba 100M SFP LC FX 2km MMF Transceiver

J9054D

Aruba 1G SFP RJ45 T 100m Cat5e Transceiver

J8177D

Aruba 1G SFP LC SX 500m OM2 MMF Transceiver

J4858D

Aruba 1G SFP LC LX 10km SMF Transceiver

J4859D

Aruba 1G SFP LC LH 70km SMF Transceiver

J4860D

Aruba 10G SFP+ LC SR 300m OM3 MMF Transceiver

J9150D

Aruba 10G SFP+ LC LR 10km SMF Transceiver

J9151E

Aruba 10G SFP+ LC LRM 220m OM2 MMF Transceiver

J9152D

Aruba 10G SFP+ LC ER 40km SMF Transceiver

J9153D

Aruba 10G SFP+ to SFP+ 1m Direct Attach Copper Cable

J9281D

Aruba 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

J9283D

Aruba 10G SFP+ to SFP+ 7m Direct Attach Copper Cable

J9285D

Aruba 40G QSFP+ LC Bidirectional 150m MMF 2-strand Transceiver

JL308A

HPE X142 40G QSFP+ MPO SR4 Transceiver

JH231A

HPE X142 40G QSFP+ LC LR4 SM Transceiver

JH232A

HPE X142 40G QSFP+ MPO eSR4 300M Transceiver

JH233A

HPE X242 40G QSFP+ to QSFP+ 1m Direct Attach Copper Cable

JH234A

HPE X242 40G QSFP+ to QSFP+ 3m Direct Attach Copper Cable

JH235A

HPE X242 40G QSFP+ to QSFP+ 5m Direct Attach Copper Cable

JH236A

Cables

Aruba X2C2 RJ45 to DB9 Console Cable

JL448A

Aruba 3800/3810M 0.5m Stacking Cable

J9578A

Aruba 3800/3810M 1m Stacking Cable

J9665A

Aruba 3800/3810M 3m Stacking Cable

J9579A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable

QK732A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable

QK733A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable

QK734A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable

QK735A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable

QK736A

HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable

QK737A

Power Supply

Aruba X371 12VDC 250W 100-240VAC Power Supply

JL085A

Aruba X372 54VDC 680W 100-240VAC Power Supply

JL086A

Aruba X372 54VDC 1050W 110-240VAC Power Supply

JL087A

Fan Tray

Aruba 3810 Switch Fan Tray

JL088A

Mounting Kit

HPE X410 1U Universal 4-post Rackmount Kit

J9583A

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

21

Aruba 3810M 24G 1-slot Switch (JL071A)

Included accessories

1 Aruba 3810 Switch Fan Tray (JL088A)

I/O ports and slots

24 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

40GbE ports, with optional module

1 open module slot

Supports a maximum of 4 SFP+ ports or 1 40GbE ports, with optional module

Additional ports and slots

1 stacking module slot

Power supplies

2 power supply slots
1 minimum power supply required (ordered separately)

Fan tray

includes: 1 x JL088A

Switch ships with 1 JL088A fan tray installed. Spares ordered separately.

Physical characteristics

Dimensions

17.42(w) x 16.98(d) x 1.73(h) in (44.25 x 43.13 x 4.39 cm) (1U height)

Weight

12.76 lb (5.79 kg)

Memory and processor

P2020 Dual Core @ 1.2 GHz, 4 GB DDR3 SDRAM, 1 GB SD Card

Dual ARM Coretex A9 @ 1 GHz, 2 GB DDR3 SDRAM; Packet buffer size: 13.5 MB Internal

Mounting and enclosure

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); Horizontal
surface mounting only

Performance

IPv6 Ready Certified

1000 Mb Latency

< 2.8 µs (FIFO 64-byte packets)

10 Gbps Latency

40 Gbps Latency

< 1.5 µs (FIFO 64-byte packets)

Throughput

up to 95.2 Mpps (64-byte packets)

Routing/Switching
capacity

160 Gbps

Switch fabric speed

169 Gbps

Routing table size

10000 entries (IPv4), 5000 entries (IPv6)

MAC address table size

64000 entries

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

Operating relative
humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft (3 km)

Acoustic

Power: 39 dB, Pressure: 22.8 dB

Primary Airflow
Direction

Front-to-side and front-to-rear

100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only; Ports 1 - 24 support MACSec Supports a maximum of 4 SFP+ ports or 1

1 RJ-45 serial console port
1 RJ-45 out-of-band management port
1 dual-personality (RJ-45 or USB micro-B)

1 fan tray slot

< 1.8 µs (FIFO 64-byte packets)

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

22

Electrical Characteristics

Frequency

50/60Hz

Voltage

JL085A PSU: 100-127/200-240 VAC

Current

JL085A PSU (Each): 1A/0.5A

Max/Idle Power Rating

JL078A: 4W/3W

JL083A: 11W/4W

Maximum Heat
Dissipation *(Max Case)

310.31

PoE Power (Max
Possible)

N/A

NOTES:

Idle power is the actual power consumption of the device with no ports

accessories, please consult configurator.

Safety

EN 60950/IEC 60950; UL 60950; UL 60950-1; CAN/CSA 22.2 No. 60950; EN 60825; CSA 22.2

IEC 60825-1: 2007 Class1 Class 1 Laser Products / Laser Klasse 1; UL 62368-1 Ed.2

Emissions

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; EN 60950-1:2006 +A11:2009 +A1:2010
+A12:2011+A2:2013

Immunity

Generic

EN55022: 2010

EN

EN55024: 2010

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3; 3 V/m

EFT/Burst

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

Surge

IEC 61000-4-5; 1 kV/2 kV AC

Conducted

IEC 61000-4-6; 3 V

Power frequency
magnetic field

IEC 61000-4-8; 1 A/m, 50 or 60 Hz

Voltage dips and
interruptions

IEC 61000-4-11; >95% reductions, 0.5 period; 30% reduction, 25 periods

Harmonics

EN61000-3-2:2006 +A1:2009 +A2:2009 Class A

Flicker

EN61000-3-3:2008

Management

Aruba AirWave Network Management; IMC – Intelligent Management Center; Command-line interface;

band; Out-of-band management (serial RS-232c or micro usb)

Services

Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for

times in your area, please contact your local Hewlett Packard Enterprise sales office.

(Switch+ 1 PSU)

JL079A: 7W/3W
JL081A: 4W/3W

connected. Maximum power rating and maximum heat dissipation are
the worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
plugged in, and all modules populated. This is a modular product.

*Switch + 2 power supplies + one JL083A Uplink. For most accurate
heat dissipation, idle and max power for any combination of chassis and

60950-1; EN62479:2010; EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; EN
62368-1, Ed. 2; IEC 60950-1:2005 Ed.2; Am 1:2009+A2:2013; IEC 60825:2007; EN60850-1:2007 /

Web browser; Configuration menu; Out-of-band management (RJ-45 Ethernet); In-line and out-of-

details on the service-level descriptions and product numbers. For details about services and response

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

23

Aruba 3810M 48G 1-slot Switch (JL072A)

Included accessories

1 Aruba 3810 Switch Fan Tray (JL088A)

I/O ports and slots

48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

1000BASE-T: full only; Ports 1 - 48 support MACSec

1 open module slot

Supports a maximum of 4 SFP+ ports or 2 40GbE ports, with optional module

Additional ports and slots

1 stacking module slot

1 dual-personality (RJ-45 or USB micro-B)

Power supplies

2 power supply slots
1 minimum power supply required (ordered separately)

Fan tray

includes: 1 x JL088A

Switch ships with 1 JL088A fan tray installed. Spares ordered separately.

Physical characteristics

Dimensions

17.42(w) x 16.98(d) x 1.73(h) in (44.25 x 43.13 x 4.39 cm) (1U height)

Weight

13.20 lb (5.99 kg)

Memory and processor

P2020 Dual Core @ 1.2 GHz, 4 GB DDR3 SDRAM, 1 GB SD Card

Dual ARM Coretex A9 @ 1 GHz, 2 GB DDR3 SDRAM; Packet buffer size: 13.5 MB Internal

Mounting and enclosure

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); Horizontal
surface mounting only

Performance

IPv6 Ready Certified

1000 Mb Latency

10 Gbps Latency

< 1.8 µs (FIFO 64-byte packets)

40 Gbps Latency

Throughput

up to 190.5 Mpps (64-byte packets)

Routing/Switching
capacity

320 Gbps

Switch fabric speed

338 Gbps

Routing table size

10000 entries (IPv4), 5000 entries (IPv6)

MAC address table size

64000 entries

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

Operating relative
humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft (3 km)

Acoustic

Power: 38 dB, Pressure: 21.8 dB

Primary Airflow
Direction

Front-to-side and front-to-rear

100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full;

1 RJ-45 serial console port
1 RJ-45 out-of-band management port

1 fan tray slot

< 2.8 µs (FIFO 64-byte packets)

< 1.5 µs (FIFO 64-byte packets)

temperature

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

24

Electrical Characteristics

Frequency

50/60Hz

Voltage

JL085A PSU: 100-127/200-240 VAC

Current

JL085A PSU (Each): 1A/0.5A

Max/Idle Power Rating
(Switch+ 1 PSU)

95W/78W

Second PSU Power

10W

Max/Idle Uplink Power

JL078A: 4W/3W

JL083A: 11W/4W

Maximum Heat
Dissipation *(Max Case)

395.56

PoE Power (Max
Possible)

N/A

NOTES:

Idle power is the actual power consumption of the device with no ports

accessories, please consult configurator.

Safety

EN 60950/IEC 60950; UL 60950; UL 60950-1; CAN/CSA 22.2 No. 60950; EN 60825; CSA 22.2

IEC 60825-1: 2007 Class1 Class 1 Laser Products / Laser Klasse 1; UL 62368-1 Ed.2

Emissions

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; EN 60950-1:2006 +A11:2009 +A1:2010
+A12:2011+A2:2013

Immunity

Generic

EN55022: 2010

EN

EN55024: 2010

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3; 3 V/m

EFT/Burst

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

Surge

IEC 61000-4-5; 1 kV/2 kV AC

Conducted

IEC 61000-4-6; 3 V

Power frequency
magnetic field

IEC 61000-4-8; 1 A/m, 50 or 60 Hz

Voltage dips and
interruptions

IEC 61000-4-11; >95% reductions, 0.5 period; 30% reduction, 25 periods

Harmonics

EN61000-3-2:2006 +A1:2009 +A2:2009 Class A

Flicker

EN61000-3-3:2008

Management

Aruba AirWave Network Management; IMC – Intelligent Management Center; Command-line interface;

band; Out-of-band management (serial RS-232c or micro usb)

Adder

Adder

JL079A: 7W/3W
JL081A: 4W/3W

connected. Maximum power rating and maximum heat dissipation are
the worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
plugged in, and all modules populated. This is a modular product.

*Switch + 2 power supplies + one JL083A Uplink. For most accurate
heat dissipation, idle and max power for any combination of chassis and

60950-1; EN62479:2010; EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; EN
62368-1, Ed. 2; IEC 60950-1:2005 Ed.2; Am 1:2009+A2:2013; IEC 60825:2007; EN60850-1:2007 /

Web browser; Configuration menu; Out-of-band management (RJ-45 Ethernet); In-line and out-of-

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

25

Services

Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for

times in your area, please contact your local Hewlett Packard Enterprise sales office.

Aruba 3810M 24G PoE+ 1-slot Switch (JL073A)

Included accessories

1 Aruba 3810 Switch Fan Tray (JL088A)

I/O ports and slots

24 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

TX: half or full; 1000BASE-T: full only; Ports 1 - 24 support MACSec

1 open module slot

Supports a maximum of 4 SFP+ ports or 1 40GbE ports, with optional module

Additional ports and slots

1 stacking module slot

1 dual-personality (RJ-45 or USB micro-B)

Power supplies

2 power supply slots
1 minimum power supply required (ordered separately)

Fan tray

includes: 1 x JL088A

Physical characteristics

Dimensions

17.42(w) x 16.98(d) x 1.73(h) in (44.25 x 43.13 x 4.39 cm) (1U height)

Weight

13.02 lb (5.91 kg)

Memory and processor

P2020 Dual Core @ 1.2 GHz, 4 GB DDR3 SDRAM, 1 GB SD Card

Dual ARM Coretex A9 @ 1 GHz, 2 GB DDR3 SDRAM; Packet buffer size: 13.5 MB Internal

Mounting and enclosure

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); Horizontal
surface mounting only

Performance

IPv6 Ready Certified

1000 Mb Latency

< 2.8 µs (FIFO 64-byte packets)

10 Gbps Latency

< 1.8 µs (FIFO 64-byte packets)

40 Gbps Latency

Throughput

up to 95.2 Mpps (64-byte packets)

Routing/Switching
capacity

160 Gbps

Switch fabric speed

169 Gbps

Routing table size

10000 entries (IPv4), 5000 entries (IPv6)

MAC address table size

64000 entries

details on the service-level descriptions and product numbers. For details about services and response

100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-

1 RJ-45 serial console port
1 RJ-45 out-of-band management port

1 fan tray slot
Switch ships with 1 JL088A fan tray installed. Spares ordered separately

< 1.5 µs (FIFO 64-byte packets)

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

26

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

Operating relative
humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft (3 km)

Acoustic

Power: 44 dB, Pressure: 27.6 dB

Primary Airflow
Direction

Front-to-side and front-to-rear

Electrical Characteristics

Frequency

50/60Hz

Voltage

JL086A PSU: 100-127/200-240 VAC

Current

JL086A PSU (Each): 5A/2.5A
JL087A PSU (Each): 8.5A/5A

Max/Idle Power Rating
(Switch+ 1 PSU)

95W/82W

Second PSU Power
Adder

10W

Max/Idle Uplink Power

JL078A: 4W/3W

JL083A: 11W/4W

Maximum Heat
Dissipation *(Max Case)

395.56

PoE Power (Max
Possible)

840W

NOTES:

Idle power is the actual power consumption of the device with no ports

accessories, please consult configurator.

Safety

EN 60950/IEC 60950; UL 60950; UL 60950-1; CAN/CSA 22.2 No. 60950; EN 60825; CSA 22.2

IEC 60825-1: 2007 Class1 Class 1 Laser Products / Laser Klasse 1; UL 62368-1 Ed.2

Emissions

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; EN 60950-1:2006 +A11:2009 +A1:2010
+A12:2011+A2:2013

relative humidity

JL087A PSU: 110-127/200-240 VAC

Adder

JL079A: 7W/3W
JL081A: 4W/3W

connected. Maximum power rating and maximum heat dissipation are
the worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
plugged in, and all modules populated. This is a modular product.

*Switch + 2 power supplies + one JL083A Uplink. For most accurate
heat dissipation, idle and max power for any combination of chassis and

60950-1; EN62479:2010; EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; EN
62368-1, Ed. 2; IEC 60950-1:2005 Ed.2; Am 1:2009+A2:2013; IEC 60825:2007; EN60850-1:2007 /

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

27

Immunity

Generic

EN55022: 2010

EN

EN55024: 2010

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3; 3 V/m

EFT/Burst

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

Surge

IEC 61000-4-5; 1 kV/2 kV AC

Conducted

IEC 61000-4-6; 3 V

Power frequency
magnetic field

IEC 61000-4-8; 1 A/m, 50 or 60 Hz

Voltage dips and
interruptions

IEC 61000-4-11; >95% reductions, 0.5 period; 30% reduction, 25 periods

Harmonics

EN61000-3-2:2006 +A1:2009 +A2:2009 Class A

Flicker

EN61000-3-3:2008

Management

Aruba AirWave Network Management; IMC – Intelligent Management Center; Command-line interface;

band; Out-of-band management (serial RS-232c or micro usb)

Services

Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for

times in your area, please contact your local Hewlett Packard Enterprise sales office.

Web browser; Configuration menu; Out-of-band management (RJ-45 Ethernet); In-line and out-of-

details on the service-level descriptions and product numbers. For details about services and response

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

28

Aruba 3810M 48G PoE+ 1-slot Switch (JL074A)

Included accessories

1 Aruba 3810 Switch Fan Tray (JL088A)

I/O ports and slots

48 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

TX: half or full; 1000BASE-T: full only; Ports 1 - 48 support MACSec

1 open module slot

Supports a maximum of 4 SFP+ ports or 2 40GbE ports, with optional module

Additional ports and slots

1 stacking module slot

1 dual-personality (RJ-45 or USB micro-B)

Power supplies

2 power supply slots
1 minimum power supply required (ordered separately)

Fan tray

includes: 1 x JL088A

Switch ships with 1 JL088A fan tray installed. Spares ordered separately.

Physical characteristics

Dimensions

17.42(w) x 16.98(d) x 1.73(h) in (44.25 x 43.13 x 4.39 cm) (1U height)

Weight

13.62 lb (6.18 kg)

Memory and processor

P2020 Dual Core @ 1.2 GHz, 4 GB DDR3 SDRAM, 1 GB SD Card

Dual ARM Coretex A9 @ 1 GHz, 2 GB DDR3 SDRAM; Packet buffer size: 13.5 MB Internal

Mounting and enclosure

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); Horizontal
surface mounting only

Performance

IPv6 Ready Certified

1000 Mb Latency

10 Gbps Latency

40 Gbps Latency

< 1.5 µs (FIFO 64-byte packets)

Throughput

up to 190.5 Mpps (64-byte packets)

Routing/Switching
capacity

320 Gbps

Switch fabric speed

338 Gbps

Routing table size

10000 entries (IPv4), 5000 entries (IPv6)

MAC address table size

64000 entries

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

Operating relative
humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft (3 km)

Acoustic

Power: 47 dB, Pressure: 29.4 dB

Primary Airflow
Direction

Front-to-side and front-to-rear

100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-

1 RJ-45 serial console port
1 RJ-45 out-of-band management port

1 fan tray slot

< 2.8 µs (FIFO 64-byte packets)

< 1.8 µs (FIFO 64-byte packets)

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

29

Electrical Characteristics

Frequency

50/60Hz

Voltage

JL086A PSU: 100-127/200-240 VAC
JL087A PSU: 110-127/200-240 VAC

Current

JL086A PSU (Each): 5A/2.5A
JL087A PSU (Each): 8.5A/5A

Max/Idle Power Rating
(Switch+ 1 PSU)

135W/103W

Second PSU Power
Adder

10W

Max/Idle Uplink Power

JL078A: 4W/3W

JL083A: 11W/4W

Maximum Heat
Dissipation *(Max Case)

531.96

PoE Power (Max
Possible)

1440W

NOTES:

Idle power is the actual power consumption of the device with no ports

accessories, please consult configurator.

Safety

EN 60950/IEC 60950; UL 60950; UL 60950-1; CAN/CSA 22.2 No. 60950; EN 60825; CSA 22.2

IEC 60825-1: 2007 Class1 Class 1 Laser Products / Laser Klasse 1; UL 62368-1 Ed.2

Emissions

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; EN 60950-1:2006 +A11:2009 +A1:2010
+A12:2011+A2:2013

Immunity

Generic

EN55022: 2010

EN

EN55024: 2010

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3; 3 V/m

EFT/Burst

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

Surge

IEC 61000-4-5; 1 kV/2 kV AC

Conducted

IEC 61000-4-6; 3 V

Power frequency

IEC 61000-4-8; 1 A/m, 50 or 60 Hz

Voltage dips and
interruptions

IEC 61000-4-11; >95% reductions, 0.5 period; 30% reduction, 25 periods

Harmonics

EN61000-3-2:2006 +A1:2009 +A2:2009 Class A

Flicker

EN61000-3-3:2008

Management

Aruba AirWave Network Management; IMC – Intelligent Management Center; Command-line interface;

band; Out-of-band management (serial RS-232c or micro usb)

Adder

JL079A: 7W/3W
JL081A: 4W/3W

connected. Maximum power rating and maximum heat dissipation are
the worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
plugged in, and all modules populated. This is a modular product.

*Switch + 2 power supplies + one JL083A Uplink. For most accurate
heat dissipation, idle and max power for any combination of chassis and

60950-1; EN62479:2010; EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; EN
62368-1, Ed. 2; IEC 60950-1:2005 Ed.2; Am 1:2009+A2:2013; IEC 60825:2007; EN60850-1:2007 /

magnetic field

Web browser; Configuration menu; Out-of-band management (RJ-45 Ethernet); In-line and out-of-

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

30

Services

Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for

times in your area, please contact your local Hewlett Packard Enterprise sales office.

Aruba 3810M 16SFP+ 2-slot Switch (JL075A)

Included accessories

1 Aruba 3810 Switch Fan Tray (JL088A)

I/O ports and slots

16 SFP+ fixed 1000/10000 SFP+ ports; Duplex: 100BASE-TX: half or full; 1000BASE-T: full only;
2 open module slots

Supports a maximum of 8 SFP+ ports or 2 40GbE ports, with optional module

Additional ports and slots

1 stacking module slot

Power supplies

2 power supply slots
1 minimum power supply required (ordered separately)

Fan tray

includes: 1 x JL088A

Switch ships with 1 JL088A fan tray installed. Spares ordered separately.

Physical characteristics

Dimensions

17.42(w) x 16.98(d) x 1.73(h) in (44.25 x 43.13 x 4.39 cm) (1U height)

Weight

13.28 lb (6.02 kg)

Memory and processor

P2020 Dual Core @ 1.2 GHz, 4 GB DDR3 SDRAM, 1 GB SD Card

Dual ARM Coretex A9 @ 1 GHz, 2 GB DDR3 SDRAM; Packet buffer size: 13.5 MB Internal

Mounting and enclosure

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); Horizontal
surface mounting only

Performance

IPv6 Ready Certified

1000 Mb Latency

10 Gbps Latency

< 1.8 µs (FIFO 64-byte packets)

40 Gbps Latency

< 1.5 µs (FIFO 64-byte packets)

Throughput

up to 285.7 Mpps (64-byte packets)

Routing/Switching
capacity

480 Gbps

Switch fabric speed

508 Gbps

Routing table size

10000 entries (IPv4), 5000 entries (IPv6)

MAC address table size

64000 entries

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

Operating relative
humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft (3 km)

Acoustic

Power: 39 dB, Pressure: 22.3 dB

Primary Airflow
Direction

Front-to-side and front-to-rear

details on the service-level descriptions and product numbers. For details about services and response

Ports 1 - 16 support MACSec

1 RJ-45 serial console port
1 RJ-45 out-of-band management port
1 dual-personality (RJ-45 or USB micro-B)

1 fan tray slot

< 2.8 µs (FIFO 64-byte packets)

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

31

Electrical Characteristics

Frequency

50/60Hz

Voltage

JL085A PSU: 100-127/200-240 VAC

Current

JL085A PSU (Each): 1A/0.5A

Max/Idle Power Rating
(Switch+ 1 PSU)

120W/95W

Second PSU Power
Adder

10W

Max/Idle Uplink Power

JL078A: 4W/3W

JL083A: 11W/4W

Maximum Heat
Dissipation *(Max Case)

480.81

PoE Power (Max
Possible)

N/A

NOTES:

Idle power is the actual power consumption of the device with no ports

accessories, please consult configurator

Safety

EN 60950/IEC 60950; UL 60950; UL 60950-1; CAN/CSA 22.2 No. 60950; EN 60825; CSA 22.2

IEC 60825-1: 2007 Class1 Class 1 Laser Products / Laser Klasse 1; UL 62368-1 Ed.2

Emissions

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; EN 60950-1:2006 +A11:2009 +A1:2010
+A12:2011+A2:2013

Immunity

Generic

EN55022: 2010

EN

EN55024: 2010

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3; 3 V/m

EFT/Burst

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

Surge

IEC 61000-4-5; 1 kV/2 kV AC

Conducted

IEC 61000-4-6; 3 V

Power frequency
magnetic field

IEC 61000-4-8; 1 A/m, 50 or 60 Hz

Voltage dips and
interruptions

IEC 61000-4-11; >95% reductions, 0.5 period; 30% reduction, 25 periods

Harmonics

EN61000-3-2:2006 +A1:2009 +A2:2009 Class A

Flicker

EN61000-3-3:2008

Management

Aruba AirWave Network Management; IMC – Intelligent Management Center; Command-line interface;

band; Out-of-band management (serial RS-232c or micro usb)

Adder

JL079A: 7W/3W
JL081A: 4W/3W

connected. Maximum power rating and maximum heat dissipation are
the worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
plugged in, and all modules populated. This is a modular product.

*Switch + 2 power supplies + one JL083A Uplink. For most accurate
heat dissipation, idle and max power for any combination of chassis and

60950-1; EN62479:2010; EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; EN
62368-1, Ed. 2; IEC 60950-1:2005 Ed.2; Am 1:2009+A2:2013; IEC 60825:2007; EN60850-1:2007 /

Web browser; Configuration menu; Out-of-band management (RJ-45 Ethernet); In-line and out-of-

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

32

Services

Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for

Aruba 3810M 40G 8 HPE Smart Rate PoE+ 1-slot Switch (JL076A)

Included accessories

1 Aruba 3810 Switch Fan Tray (JL088A)

I/O ports and slots

40 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

TX: half or full; 1000BASE-T: full only; Ports 1 - 40 support MACSec

8 RJ-45 HPE Smart Rate Multi-Gigabit ports (100M, 1/2.5/5GBASE-T and 10GBASE-T); Ports 1 - 8
support MACSec

1 open module slot

Supports a maximum of 4 SFP+ ports or 2 40GbE ports, with optional module

Additional ports and slots

1 stacking module slot

Power supplies

2 power supply slots
1 minimum power supply required (ordered separately)

Fan tray

includes: 1 x JL088A

Physical characteristics

Dimensions

17.42(w) x 16.98(d) x 1.73(h) in (44.25 x 43.13 x 4.39 cm) (1U height)

Weight

13.61 lb (6.17 kg)

Memory and processor

P2020 Dual Core @ 1.2 GHz, 4 GB DDR3 SDRAM, 1 GB SD Card

Dual ARM Coretex A9 @ 1 GHz, 2 GB DDR3 SDRAM; Packet buffer size: 13.5 MB Internal

Mounting and enclosure

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); Horizontal
surface mounting only

Performance

IPv6 Ready Certified

1000 Mb Latency

< 2.8 µs (FIFO 64-byte packets)

10 Gbps Latency

40 Gbps Latency

< 1.5 µs (FIFO 64-byte packets)

Throughput

up to 273.8 Mpps (64-byte packets)

Routing/Switching
capacity

480 Gbps

Switch fabric speed

508 Gbps

Routing table size

10000 entries (IPv4), 5000 entries (IPv6)

MAC address table size

64000 entries

details on the service-level descriptions and product numbers. For details about services and response
times in your area, please contact your local Hewlett Packard Enterprise sales office.

100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-

1 RJ-45 serial console port
1 RJ-45 out-of-band management port
1 dual-personality (RJ-45 or USB micro-B)

1 fan tray slot
Switch ships with 1 JL088A fan tray installed. Spares ordered separately.

< 1.8 µs (FIFO 64-byte packets)

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

33

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

Operating relative
humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft (3 km)

Acoustic

Power: 49 dB, Pressure: 31.5 dB

Primary Airflow
Direction

Front-to-side and front-to-rear

Electrical Characteristics

Frequency

50/60Hz

Voltage

JL086A PSU: 100-127/200-240 VAC

Current

JL086A PSU (Each): 5A/2.5A
JL087A PSU (Each): 8.5A/5A

Max/Idle Power Rating
(Switch+ 1 PSU)

190W/158W

Second PSU Power
Adder

10W

Max/Idle Uplink Power

JL078A: 4W/3W

JL083A: 11W/4W

Maximum Heat
Dissipation *(Max Case)

719.51

PoE Power (Max
Possible)

1440W

NOTES:

Idle power is the actual power consumption of the device with no ports

accessories, please consult configurator.

Safety

EN 60950/IEC 60950; UL 60950; UL 60950-1; CAN/CSA 22.2 No. 60950; EN 60825; CSA 22.2

IEC 60825-1: 2007 Class1 Class 1 Laser Products / Laser Klasse 1; UL 62368-1 Ed.2

Emissions

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; EN 60950-1:2006 +A11:2009 +A1:2010
+A12:2011+A2:2013

relative humidity

JL087A PSU: 110-127/200-240 VAC

Adder

JL079A: 7W/3W
JL081A: 4W/3W

connected. Maximum power rating and maximum heat dissipation are
the worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
plugged in, and all modules populated. This is a modular product.

*Switch + 2 power supplies + one JL083A Uplink. For most accurate
heat dissipation, idle and max power for any combination of chassis and

60950-1; EN62479:2010; EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; EN
62368-1, Ed. 2; IEC 60950-1:2005 Ed.2; Am 1:2009+A2:2013; IEC 60825:2007; EN60850-1:2007 /

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

34

Immunity

Generic

EN55022: 2010

EN

EN55024: 2010

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3; 3 V/m

EFT/Burst

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

Surge

IEC 61000-4-5; 1 kV/2 kV AC

Conducted

IEC 61000-4-6; 3 V

Power frequency
magnetic field

IEC 61000-4-8; 1 A/m, 50 or 60 Hz

Voltage dips and
interruptions

IEC 61000-4-11; >95% reductions, 0.5 period; 30% reduction, 25 periods

Harmonics

EN61000-3-2:2006 +A1:2009 +A2:2009 Class A

Flicker

EN61000-3-3:2008

Management

Aruba AirWave Network Management; IMC – Intelligent Management Center; Command-line interface;

band; Out-of-band management (serial RS-232c or micro usb)

Services

Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for

times in your area, please contact your local Hewlett Packard Enterprise sales office.

Web browser; Configuration menu; Out-of-band management (RJ-45 Ethernet); In-line and out-of-

details on the service-level descriptions and product numbers. For details about services and response

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

35

Aruba 3810M 48G PoE+ 4SFP+ 680W Switch (JL428A)

Included accessories

1 Aruba 3810M 48G PoE+ 1-slot Switch (JL074A)

1 Aruba 3810 Switch Fan Tray (JL088A)

I/O ports and slots

48 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

TX: half or full; 1000BASE-T: full only; Ports 1 - 48 support MACSec

1 open module slot

Supports a maximum of 4 SFP+ ports or 2 40GbE ports, with optional module

Additional ports and slots

1 stacking module slot

1 dual-personality (RJ-45 or USB micro-B)

Power supplies

2 power supply slots
1 minimum power supply required (ordered separately)

Fan tray

includes: 1 x JL088A

Switch ships with 1 JL088A fan tray installed. Spares ordered separately.

Physical characteristics

Dimensions

17.42(w) x 16.98(d) x 1.73(h) in (44.25 x 43.13 x 4.39 cm) (1U height)

Weight

13.62 lb (6.18 kg)

Memory and processor

P2020 Dual Core @ 1.2 GHz, 4 GB DDR3 SDRAM, 1 GB SD Card

Dual ARM Coretex A9 @ 1 GHz, 2 GB DDR3 SDRAM; Packet buffer size: 13.5 MB Internal

Mounting and enclosure

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); Horizontal
surface mounting only

Performance

IPv6 Ready Certified

1000 Mb Latency

10 Gbps Latency

< 1.8 µs (FIFO 64-byte packets)

40 Gbps Latency

Throughput

up to 190.5 Mpps (64-byte packets)

Routing/Switching
capacity

320 Gbps

Switch fabric speed

338 Gbps

Routing table size

10000 entries (IPv4), 5000 entries (IPv6)

MAC address table size

64000 entries

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

Operating relative
humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft (3 km)

Acoustic

Power: 47 dB, Pressure: 29.4 dB

Primary Airflow
Direction

Front-to-side and front-to-rear

1 Aruba X372 54VDC 680W Power Supply (JL086A)
1 Aruba 3810M 4SFP+ Module (JL083A)

100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-

1 RJ-45 serial console port
1 RJ-45 out-of-band management port

1 fan tray slot

< 2.8 µs (FIFO 64-byte packets)

< 1.5 µs (FIFO 64-byte packets)

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

36

Electrical Characteristics

Frequency

50/60Hz

Voltage

JL085A PSU: 100-127/200-240 VAC

Current

JL085A PSU (Each): 1A/0.5A

Max/Idle Power Rating
(Switch+ 1 PSU)

70W/55W

Second PSU Power
Adder

10W

Max/Idle Uplink Power

JL078A: 4W/3W

JL083A: 11W/4W

Maximum Heat
Dissipation *(Max Case)

310.31

PoE Power (Max
Possible)

N/A

NOTES:

Idle power is the actual power consumption of the device with no ports

accessories, please consult configurator.

Safety

EN 60950/IEC 60950; UL 60950; UL 60950-1; CAN/CSA 22.2 No. 60950; EN 60825; CSA 22.2

1:2007 /

IEC 60825-1: 2007 Class1 Class 1 Laser Products / Laser Klasse 1; UL 62368-1 Ed.2

Emissions

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; EN 60950-1:2006 +A11:2009 +A1:2010
+A12:2011+A2:2013

Immunity

Generic

EN55022: 2010

EN

EN55024: 2010

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3; 3 V/m

EFT/Burst

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

Surge

IEC 61000-4-5; 1 kV/2 kV AC

Conducted

IEC 61000-4-6; 3 V

Power frequency
magnetic field

IEC 61000-4-8; 1 A/m, 50 or 60 Hz

Voltage dips and
interruptions

IEC 61000-4-11; >95% reductions, 0.5 period; 30% reduction, 25 periods

Harmonics

EN61000-3-2:2006 +A1:2009 +A2:2009 Class A

Flicker

EN61000-3-3:2008

Management

Aruba AirWave Network Management; IMC – Intelligent Management Center; Command-line interface;

band; Out-of-band management (serial RS-232c or micro usb)

Adder

JL079A: 7W/3W
JL081A: 4W/3W

connected. Maximum power rating and maximum heat dissipation are
the worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
plugged in, and all modules populated. This is a modular product.

*Switch + 2 power supplies + one JL083A Uplink. For most accurate
heat dissipation, idle and max power for any combination of chassis and

60950-1; EN62479:2010; EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; EN
62368-1, Ed. 2; IEC 60950-1:2005 Ed.2; Am 1:2009+A2:2013; IEC 60825:2007; EN60850-

Web browser; Configuration menu; Out-of-band management (RJ-45 Ethernet); In-line and out-of-

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

37

Services

Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for

times in your area, please contact your local Hewlett Packard Enterprise sales office.

Aruba 3810M 48G PoE+ 4SFP+ 1050W Switch (JL429A)

Included accessories

1 Aruba 3810M 48G PoE+ 1-slot Switch (JL074A)

1 Aruba 3810 Switch Fan Tray (JL088A)

I/O ports and slots

48 RJ-45 autosensing 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type

TX: half or full; 1000BASE-T: full only; Ports 1 - 48 support MACSec

1 open module slot

Supports a maximum of 4 SFP+ ports or 2 40GbE ports, with optional module

Additional ports and slots

1 stacking module slot

1 dual-personality (RJ-45 or USB micro-B)

Power supplies

2 power supply slots
1 minimum power supply required (ordered separately)

Fan tray

includes: 1 x JL088A 1 fan tray slot

Physical characteristics

Dimensions

17.42(w) x 16.98(d) x 1.73(h) in (44.25 x 43.13 x 4.39 cm) (1U height)

Weight

13.62 lb (6.18 kg)

Memory and processor

P2020 Dual Core @ 1.2 GHz, 4 GB DDR3 SDRAM, 1 GB SD Card

Dual ARM Coretex A9 @ 1 GHz, 2 GB DDR3 SDRAM; Packet buffer size: 13.5 MB Internal

Mounting and enclosure

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); Horizontal
surface mounting only

Performance

IPv6 Ready Certified

1000 Mb Latency

< 2.8 µs (FIFO 64-byte packets)

10 Gbps Latency

40 Gbps Latency

< 1.5 µs (FIFO 64-byte packets)

Throughput

up to 190.5 Mpps (64-byte packets)

Routing/Switching
capacity

320 Gbps

Switch fabric speed

338 Gbps

Routing table size

10000 entries (IPv4), 5000 entries (IPv6)

MAC address table size

64000 entries

details on the service-level descriptions and product numbers. For details about services and response

1 Aruba X372 54VDC 1050W Power Supply (JL087A)
1 Aruba 3810M 4SFP+ Module (JL083A)

100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3at PoE+); Duplex: 10BASE-T/100BASE-

1 RJ-45 serial console port
1 RJ-45 out-of-band management port

Switch ships with 1 JL088A fan tray installed. Spares ordered separately.

< 1.8 µs (FIFO 64-byte packets)

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

38

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

Operating relative
humidity

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft (3 km)

Acoustic

Power: 47 dB, Pressure: 29.4 dB

Primary Airflow
Direction

Front-to-side and front-to-rear

Electrical Characteristics

Frequency

50/60Hz

Voltage

JL085A PSU: 100-127/200-240 VAC

Current

JL085A PSU (Each): 1A/0.5A

Max/Idle Power Rating

70W/55W

Second PSU Power
Adder

10W

Max/Idle Uplink Power

JL078A: 4W/3W

JL083A: 11W/4W

Maximum Heat
Dissipation *(Max Case)

310.31

PoE Power (Max

N/A

NOTES:

Idle power is the actual power consumption of the device with no ports

accessories, please consult configurator.

Safety

EN 60950/IEC 60950; UL 60950; UL 60950-1; CAN/CSA 22.2 No. 60950; EN 60825; CSA 22.2

1:2007 /

IEC 60825-1: 2007 Class1 Class 1 Laser Products / Laser Klasse 1; UL 62368-1 Ed.2

Emissions

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; EN 60950-1:2006 +A11:2009 +A1:2010
+A12:2011+A2:2013

relative humidity

(Switch+ 1 PSU)

Adder

JL079A: 7W/3W
JL081A: 4W/3W

Possible)

connected. Maximum power rating and maximum heat dissipation are
the worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
plugged in, and all modules populated. This is a modular product.

*Switch + 2 power supplies + one JL083A Uplink. For most accurate
heat dissipation, idle and max power for any combination of chassis and

60950-1; EN62479:2010; EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; EN
62368-1, Ed. 2; IEC 60950-1:2005 Ed.2; Am 1:2009+A2:2013; IEC 60825:2007; EN60850-

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

39

Immunity

Generic

EN55022: 2010

EN

EN55024: 2010

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3; 3 V/m

EFT/Burst

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

Surge

IEC 61000-4-5; 1 kV/2 kV AC

Conducted

IEC 61000-4-6; 3 V

Power frequency
magnetic field

IEC 61000-4-8; 1 A/m, 50 or 60 Hz

Voltage dips and
interruptions

IEC 61000-4-11; >95% reductions, 0.5 period; 30% reduction, 25 periods

Harmonics

EN61000-3-2:2006 +A1:2009 +A2:2009 Class A

Flicker

EN61000-3-3:2008

Management

Aruba AirWave Network Management; IMC – Intelligent Management Center; Command-line interface;

band; Out-of-band management (serial RS-232c or micro usb)

Services

Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for

times in your area, please contact your local Hewlett Packard Enterprise sales office.

Aruba 3810M 24SFP+ 250W Switch (JL430A)

Included accessories

1 Aruba 3810M 16SFP+ 2-slot Switch (JL075A)

1 Aruba 3810 Switch Fan Tray (JL088A)

I/O ports and slots

16 SFP+ fixed 1000/10000 SFP+ ports; Duplex: 100BASE-TX: half or full; 1000BASE-T: full only;

Supports a maximum of 8 SFP+ ports or 2 40GbE ports, with optional module

Additional ports and slots

1 stacking module slot

1 dual-personality (RJ-45 or USB micro-B)

Power supplies

2 power supply slots
1 minimum power supply required (ordered separately)

Fan tray

includes: 1 x JL088A

Switch ships with 1 JL088A fan tray installed. Spares ordered separately.

Physical characteristics

Dimensions

17.42(w) x 16.98(d) x 1.73(h) in (44.25 x 43.13 x 4.39 cm) (1U height)

Weight

13.28 lb (6.02 kg)

Memory and processor

P2020 Dual Core @ 1.2 GHz, 4 GB DDR3 SDRAM, 1 GB SD Card

Dual ARM Coretex A9 @ 1 GHz, 2 GB DDR3 SDRAM; Packet buffer size: 13.5 MB Internal

Mounting and enclosure

Mounts in an EIA-standard 19 in. telco rack or equipment cabinet (hardware included); Horizontal
surface mounting only

Performance

IPv6 Ready Certified

1000 Mb Latency

< 2.8 µs (FIFO 64-byte packets)

Web browser; Configuration menu; Out-of-band management (RJ-45 Ethernet); In-line and out-of-

details on the service-level descriptions and product numbers. For details about services and response

1 Aruba X371 12VDC 250W Power Supply (JL085A)
2 Aruba 3810M 4SFP+ Module (JL083A)

Ports
1 - 16 support MACSec
2 open module slots

1 RJ-45 serial console port
1 RJ-45 out-of-band management port

1 fan tray slot

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

40

10 Gbps Latency

< 1.8 µs (FIFO 64-byte packets)

40 Gbps Latency

Throughput

up to 285.7 Mpps (64-byte packets)

Routing/Switching
capacity

480 Gbps

Switch fabric speed

508 Gbps

Routing table size

10000 entries (IPv4), 5000 entries (IPv6)

MAC address table size

64000 entries

Environment

Operating temperature

32°F to 113°F (0°C to 45°C)

Operating relative

15% to 95% @ 104°F (40°C), noncondensing

Nonoperating/Storage
temperature

-40°F to 158°F (-40°C to 70°C)

Nonoperating/Storage
relative humidity

15% to 90% @ 149°F (65°C), noncondensing

Altitude

up to 10,000 ft (3 km)

Acoustic

Power: 39 dB, Pressure: 22.3 dB

Primary Airflow
Direction

Front-to-side and front-to-rear

Electrical Characteristics

Frequency

50/60Hz

Voltage

JL085A PSU: 100-127/200-240 VAC

Current

JL085A PSU (Each): 1A/0.5A

Max/Idle Power Rating
(Switch+ 1 PSU)

142W/103W

Second PSU Power
Adder

10W

Max/Idle Uplink Power

JL078A: 4W/3W

Maximum Heat
Dissipation *(Max Case)

310.31

PoE Power (Max
Possible)

N/A

NOTES:

Idle power is the actual power consumption of the device with no ports

accessories, please consult configurator.

Safety

EN 60950/IEC 60950; UL 60950; UL 60950-1; CAN/CSA 22.2 No. 60950; EN 60825; CSA 22.2

1:2007 /

IEC 60825-1: 2007 Class1 Class 1 Laser Products / Laser Klasse 1; UL 62368-1 Ed.2

< 1.5 µs (FIFO 64-byte packets)

humidity

Adder

JL079A: 7W/3W
JL081A: 4W/3W
JL083A: 11W/4W

connected. Maximum power rating and maximum heat dissipation are
the worst case theoretical maximum numbers provide for planning the
infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports
plugged in, and all modules populated. This is a modular product.

*Switch + 2 power supplies + one JL083A Uplink. For most accurate
heat dissipation, idle and max power for any combination of chassis and

60950-1; EN62479:2010; EN 60950-1:2006 +A11:2009 +A1:2010 +A12:2011+A2:2013; EN
62368-1, Ed. 2; IEC 60950-1:2005 Ed.2; Am 1:2009+A2:2013; IEC 60825:2007; EN60850-

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

41

Emissions

FCC Class A; VCCI Class A; EN 55022/CISPR 22 Class A; EN 60950-1:2006 +A11:2009 +A1:2010
+A12:2011+A2:2013

Immunity

Generic

EN55022: 2010

EN

EN55024: 2010

ESD

IEC 61000-4-2

Radiated

IEC 61000-4-3; 3 V/m

EFT/Burst

IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)

Surge

IEC 61000-4-5; 1 kV/2 kV AC

Conducted

IEC 61000-4-6; 3 V

Power frequency
magnetic field

IEC 61000-4-8; 1 A/m, 50 or 60 Hz

Voltage dips and
interruptions

IEC 61000-4-11; >95% reductions, 0.5 period; 30% reduction, 25 periods

Harmonics

EN61000-3-2:2006 +A1:2009 +A2:2009 Class A

Flicker

EN61000-3-3:2008

Management

Aruba AirWave Network Management; IMC – Intelligent Management Center; Command-line interface;
Web browser; Configuration menu; Out
band; Out-of-band management (serial RS-232c or micro usb)

Services

Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
details on the service
times in your area, please contact your local Hewlett Packard Enterprise sales office.

-of-band management (RJ-45 Ethernet); In-line and out-of-

-level descriptions and product numbers. For details about services and response

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

42

Standards and protocols

(applies to all products in series)

General Protocols

• UDLD (Uni-directional Link Detection)

BGP

• RFC 5492 Capabilities Advertisement with BGP-4

• IEEE 802.1ad Q-in-Q

• IEEE 802.1AX-2008 Link Aggregation

• IEEE 802.1D MAC Bridges

• IEEE 802.1p Priority

• IEEE 802.1Q VLANs

• IEEE 802.1s Multiple Spanning Trees

• IEEE 802.1v VLAN classification by Protocol and Port

• IEEE 802.1w Rapid Reconfiguration of Spanning Tree

• IEEE 802.3ad Link Aggregation Control Protocol (LACP)

• IEEE 802.3af Power over Ethernet

• IEEE 802.3az Energy Efficient Ethernet

• IEEE 802.3x Flow Control

• IEEE 802.3bz 2.5Gb/s and 5Gb/s interfaces

• RFC 768 UDP

• RFC 783 TFTP Protocol (revision 2)

• RFC 792 ICMP

• RFC 793 TCP

• RFC 826 ARP

• RFC 854 TELNET

• RFC 868 Time Protocol

• RFC 951 BOOTP

• RFC 1058 RIPv1

• RFC 1350 TFTP Protocol (revision 2)

• RFC 1519 CIDR

• RFC 1542 BOOTP Extensions

• RFC 1918 Address Allocation for Private Internet

• RFC 2030 Simple Network Time Protocol (SNTP) v4

• RFC 2131 DHCP

• RFC 2453 RIPv2

• RFC 2548 (MS-RAS-Vendor only)

• RFC 3046 DHCP Relay Agent Information Option

• RFC 3575 IANA Considerations for RADIUS

• RFC 3576 Ext to RADIUS (CoA only)

• RFC 3768 VRRP

• RFC 4675 RADIUS VLAN & Priority

• RFC 5798 VRRP (exclude Accept Mode and sub-sec timer)

• RFC 5880 Bidirectional Forwarding Detection

• RFC 5905 Network Time Protocol Version 4: Protocol and Algorithms Specification

• RFC 1997 BGP Communities Attribute

• RFC 2918 Route Refresh Capability

• RFC 4271 A Border Gateway Protocol 4 (BGP-4)

• RFC 4456 BGP Route Reflection: An Alternative to Full Mesh Internal BGP (IBGP)

• RFC 4724 Graceful Restart Mechanism for BGP

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

43

IPv6

• RFC 6620 FCFS SAVI

Device Management

•

Denial of service protection

• CPU DoS Protection

• RFC 1981 IPv6 Path MTU Discovery

• RFC 2080 RIPng for IPv6

• RFC 2081 RIPng Protocol Applicability Statement

• RFC 2082 RIP-2 MD5

• RFC 2375 IPv6 Multicast Address Assignments

• RFC 2460 IPv6 Specification

• RFC 2464 Transmission of IPv6 over Ethernet Networks

• RFC 2710 Multicast Listener Discovery (MLD) for IPv6

• RFC 2925 Definitions of Managed Objects for Remote Ping, Traceroute, and Lookup Operations (Ping only)

• RFC 3019 MLDv1 MIB

• RFC 3315 DHCPv6 (client only)

• RFC 3484 Default Address Selection for IPv6

• RFC 3587 IPv6 Global Unicast Address Format

• RFC 3596 DNS Extension for IPv6

• RFC 3810 MLDv2 for IPv6

• RFC 4022 MIB for TCP

• RFC 4087 IP Tunnel MIB

• RFC 4113 MIB for UDP

• RFC 4213 Basic Transition Mechanisms for IPv6 Hosts and Routers

• RFC 4251 SSHv6 Architecture

• RFC 4252 SSHv6 Authentication

• RFC 4253 SSHv6 Transport Layer

• RFC 4254 SSHv6 Connection

• RFC 4291 IP Version 6 Addressing Architecture

• RFC 4293 MIB for IP

• RFC 4294 IPv6 Node Requirements

• RFC 4419 Key Exchange for SSH

• RFC 4443 ICMPv6

• RFC 4541 IGMP & MLD Snooping Switch

• RFC 4861 IPv6 Neighbor Discovery

• RFC 4862 IPv6 Stateless Address Auto-configuration

• RFC 5095 Deprecation of Type 0 Routing Headers in IPv6

• RFC 5340 OSPFv3 for IPv6

• RFC 5453 Reserved IPv6 Interface Identifiers

• RFC 5519 Multicast Group Membership Discovery MIB (MLDv2 only)

• RFC 5722 Handling of Overlapping IPv6 Fragments

• RFC 1591 DNS (client)

• RFC 2576 (Coexistence between SNMP V1, V2, V3)

• RFC 2579 (SMIv2 Text Conventions)

• RFC 2580 (SMIv2 Conformance)

• RFC 3416 (SNMP Protocol Operations v2)

• RFC 3417 (SNMP Transport Mappings)

HTML and telnet management

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

44

IP Multicast

• RFC 4601 PIM Sparse Mode

OSPF

• RFC 5340 OSPFv3 for IPv6

QoS/CoS

• RFC 2598 DiffServ Expedited Forwarding (EF)

MIBs

• RFC 7331 BFD MIB

• RFC 3376 IGMPv3

• RFC 3973 PIM Dense Mode

• RFC 2328 OSPFv2

• RFC 3101 OSPF NSSA

• RFC 3623 Graceful OSPF Restart (Unplanned Outages only)

• RFC 2474 DiffServ Precedence, including 8 queues/port

• RFC 2475 DiffServ Architecture

• RFC 2597 DiffServ Assured Forwarding (AF)

• IEEE 802.1ap (MSTP and STP MIB's only)

• IEEE 8021-Bridge-MIB (2008)

• IEEE 8021-Q-Bridge-MIB (2008)

• RFC 1155 Structure & ID of Mgmt Info for TCP/IP Internets

• RFC 1213 MIB II

• RFC 1493 Bridge MIB

• RFC 1724 RIPv2 MIB

• RFC 1850 OSPFv2 MIB

• RFC 2021 RMONv2 MIB

• RFC 2096 IP Forwarding Table MIB

• RFC 2578 Structure of Management Information Version 2 (SMIv2)

• RFC 2613 SMON MIB

• RFC 2618 RADIUS Client MIB

• RFC 2620 RADIUS Accounting MIB

• RFC 2665 Ethernet-Like-MIB

• RFC 2668 802.3 MAU MIB

• RFC 2674 802.1p and IEEE 802.1Q Bridge MIB

• RFC 2737 Entity MIB (Version 2)

• RFC 2787 VRRP MIB

• RFC 2863 The Interfaces Group MIB

• RFC 2925 Ping MIB

• RFC 2932 IP (Multicast Routing MIB)

• RFC 2933 IGMP MIB

• RFC 4836 Managed Objects for 802.3 Medium Attachment Units (MAU)

Page

QuickSpecs

Aruba 3810M Switch Series

Technical Specifications

45

Network Management

• XRMON

Security

• SSHv2 Secure Shell

• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

• RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events)

• RFC 3176 sFlow

• RFC 3411 SNMP Management Frameworks

• RFC 3412 Message Processing and Dispatching for the Simple Network Management Protocol (SNMP)

• RFC 3413 Simple Network Management Protocol (SNMP) Applications

• RFC 3414 User-based Security Model (USM) for version 3 of the Simple Network Management Protocol (SNMPv3)

• RFC 3415 View-based Access Control Model (VACM) for the Simple Network Management Protocol (SNMP)

• RFC 3418 Management Information Base (MIB) for the Simple Network Management Protocol (SNMP)

• RFC 5424 Syslog Protocol

• ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED)

• SNMPv1/v2c/v3

• IEEE 802.1X Port Based Network Access Control

• RFC 1321 The MD5 Message-Digest Algorithm

• RFC 2698 A Two Rate Three Color Marker

• RFC 2818 HTTP Over TLS

• RFC 2865 RADIUS (client only)

• RFC 2866 RADIUS Accounting

• RFC 3579 RADIUS Support For Extensible Authentication Protocol (EAP)

• RFC 6614 Transport Layer Security (TLS) Encryption over Radius (RadSec)

• RFC 7030 Enrollment over Secure Transport

• Secure Sockets Layer (SSL)

Page

QuickSpecs

Aruba 3810M Switch Series

Summary of Changes

46

Date

Version History

Action

Description of Change

06-Apr-2020

Version 21

Changed

Standard Features- Warranty and Configuration Information sections were
updated.

01-Jul-2019

Version 20

Changed

Standard Features and Technical Specifications sections were updated.
Obsolete SKUs were removed.

04-Mar-2019

Version 19

Changed

SKU J9151D was replaced with J9151E
03-Dec-2018

Version 18

Changed

Software feature update: Key features, Product overview and Enhanced
Capabilities updated

02-Jul-2018

Version 17

Changed

Software feature update

07-May-2018

Version 16

Added

Edits made on Configuration section and Technical Specifications

05-Mar-2018

Version 15

Changed

Configuration section updated.

05-Feb-2018

Version 14

Changed

Configuration section updated.
Document name updated to match Product Master.

08-Jan-2018

Version 13

Changed

Software feature update

07-Aug-2017

Version 12

Added

SKU added: JL308A

03-Jul-2017

Version 11

Added

SKU added: JL448A

08-May-2017

Version 10

Changed

Configuration section updated

03-Apr-2017

Version 9

Changed

Modules updated on Configuration section

17-Feb-2017

Version 8

Changed

Configuration section updated (Adding #B2B, #B2C, and #B2E Options on
SKUs JL428A; JL429A and JL430A)

09-Jan-2017

Version 7

Added

Models added: JL428A, JL429A, JL430A

07-Nov-2016

Version 6

Changed

Product overview, Features and Benefits updated

19-Aug-2016

Version 5

Changed

Configuration section updated. Minor changes made on Technical
Specifications.

06-June-2016

Version 4

Changed

Features and Benefits, Standards and Protocols, Accessories updated. SKU
descriptions updated.

18-Mar-2016

Version 3

Changed

Minor edits on Features and Benefits, Switch family photo added.

11-Dec-2015

Version 2

Changed

Standards and protocols and Configuration Menu updated

01-Dec-2015

Version 1

Created

Document creation

Sign up for updates

© Copyright 2020 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties for Hewlett Packard Enterprise products and
services are set forth in the express warranty statements accompanying such pro
Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise
shall not be liable for technical or editorial errors or omissions contained herein.

To learn more, visit:

c04843019 - 15438 - Worldwide - V21 - 06-April-2020

CTO models were removed.
Obsolete SKUs were removed.

http://www.hpe.com/networking

ducts and services.

Page
