QuickSpecs
HP EliteBook Revolve 810 G2 Tablet PC
Overview
HP EliteBook Revolve 810 G2 Tablet PC
Front, Right
1.
WLAN antennas
9
MicroSD slot
2.
Dual-microphone array
10.
Speaker
3.
Webcam LED
11.
Volume up/down button
4.
720p HD Webcam
12.
Rotation lock button
5.
Home button
13.
Power button
6.
WWAN antennas*
14.
Clickpad image sensor
7.
Side docking connector
15.
Ambient light sensor
8.
Audio jack
* WWAN is an optional, add-on feature and is planned to be available in March 2014. WWAN use requires separately purchased service contract. Check with service provider for coverage and availability in your area. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE is not available in all regions and requires Windows.
QuickSpecs
HP EliteBook Revolve 810 G2 Tablet PC
Overview
Rear
1.
RJ-45 (Ethernet) jack
4.
DisplayPort 1.2
2.
USB 3.0 port
5.
USB 3.0 charging port
3.
Security lock slot
6.
Power connector
Left
1.
Vent
2.
Speaker
QuickSpecs
HP EliteBook Revolve 810 G2 Tablet PC
Overview
Bottom
1.
Service cover
4.
Battery bay cover release latch
2.
Vents
5.
Battery bay
3.
Near Field Communication (NFC) antenna
QuickSpecs
HP EliteBook Revolve 810 G2 Tablet PC
Overview
At A Glance
• Windows 8.1 Pro 64, Windows 8.1 64, Windows 7 Professional 64 (available through downgrade rights from Windows 8.1 Pro 64), Windows 7 Professional 64, Windows 7 Home Premium 64, or FreeDOS 2.0
• 11.6-inch diagonal LED-backlit, ultra-slim, HD UWVA display (1366 x 768) with capacitive multi-touch screen
• Industrial, business rugged HP DuraCase construction features a full magnesium alloy chassis, wear-resistant HP
DuraFinish, and stainless steel hinges
• Full-sized backlit (optional), spill-resistant keyboard with bottom-case drain
• Clickpad image sensor
• Choice of 4th Generation Intel® Core™ i7, i5 Core with Turbo Boost Technology or 4th Generation Intel® Core™ i3 Core
• Intel vPro technology enables you to remotely monitor, diagnose, and repair PCs over the network, even if a system's OS
is inoperable or it is powered off (vPro not available with Core i3-4010U or Core i5-4200U.)
• Choice of up to 256 GB M.2 Solid State Drive or 256 GB SED M.2 Solid State Drive
• Flexible wireless connectivity options:
o Integrated WWAN modules with GPS support (optional, available March 2014) o Integrated Intel 802.11 (2x2) a/b/g/n ac, or a/b/g/n with Bluetooth 4.0 combo card o Integrated Intel 802.11a/b/g/n (2x2) wireless LAN module
• 6-cell polymer long life battery (44 WHr)
• Integrated Intel HD 4400 Graphics
• Integrated 720p HD Webcam
• DTS Studio Sound with integrated stereo speakers and dual microphone array
• Security features including HP Client Security, Common Criteria Certified Discrete TPM 1.2 Embedded Security Chip, and
security lock slot
• Separate launch buttons for easy access to the following features: Windows, power, rotation lock, volume up and down
• DisplayPort v1.2 for high resolution support
• Optional HP 2013 UltraSlim docking station
• Sensors include Gyroscope, Accelerometer, Compass, Ambient Light Sensor, Near Field Communication (NFC)
• microSD slot
NOTE: See important legal disclosures for all listed specs in their respective features sections.
QuickSpecs
HP EliteBook Revolve 810 G2
Features
PRODUCT NAME
HP EliteBook Revolve 810 G2 Tablet
OPERATING SYSTEM
Preinstalled
Windows 8.1 Pro 64* Windows 8.1 64* Windows 7 Professional 64 (available through downgrade rights from Windows 8.1 Pro 64)** Windows 7 Professional 64*** Windows 7 Home Premium 64*** FreeDOS 2.0
Supported
Windows 8.1 Enterprise 64* Windows 7 Professional 32*** Windows 7 Enterprise 32*** Windows 7 Enterprise 64*** Windows 7 Ultimate 32*** Windows 7 Ultimate 64*** Windows 7 Home Premium 32*** Windows 7 Home Basic 32*** Windows 7 Home Basic 64***
* Not all features are available in all editions of Windows 8.1. Systems may require upgraded and/or separately purchased hardware, drivers and/or software to take full advantage of Windows 8.1 functionality. See http://www.microsoft.com/ ** This system is preinstalled with Windows® 7 Pro software and also comes with a license and media for Windows 8 Pro software. You may only use one version of the Windows software at a time. Switching between versions will require you to uninstall one version and install the other version. You must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid loss of your data ** Systems may require upgraded and/or separately purchased hardware to take full advantage of Windows 7 functionality. See http://www.microsoft.com/windows/windows-7/ for details.
PROCESSOR*
4th Generation Intel® Core™ i7-4600U with Intel HD Graphics 4400 (2.1 GHz, 4 MB L3 cache, 2 cores, 15 W)* Up to 3.3 GHz with Intel Turbo Boost Technology** 4th Generation Intel® Core™ i5-4300U with Intel HD Graphics 4400 (1.9 GHz, 3 MB L3 cache, 2 cores, 15 W)* Up to 2.9 GHz with Intel Turbo Boost Technology 4th Generation Intel® Core™ i5-4200U with Intel HD Graphics 4400 (1.6 GHz, 3 MB L3 cache, 2 cores, 15 W)* Up to 2.6 GHz with Intel Turbo Boost Technology** 4th Generation Intel® Core™ i3-4010U with Intel HD Graphics 4400 (1.7 GHz, 3 MB L3 cache, 2 cores, 15 W)*
* Multi-Core is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. 64-bit computing on Intel® architecture requires a computer system with a processor, chipset, BIOS, operating system, device drivers, and applications enabled for Intel® 64 architecture. Processors will not operate (including 32-bit operation) without an Intel® 64 architecture-enabled BIOS. Performance will vary depending on your hardware and software configurations. Intel's numbering is not a measurement of higher performance. ** Intel® Turbo Boost technology requires a PC with a processor with Intel Turbo Boost capability. Intel Turbo Boost
QuickSpecs
HP EliteBook Revolve 810 G2
Features
performance varies depending on hardware, software and overall system configuration. See www.intel.com/technology/turboboost for more information. NOTE: Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.
CHIPSET
Mobile Intel® QM87 (vPro support available with Core i7-4600 or Core i5-4300)
INTEL CORE I5 WITH VPRO/CORE I7 WITH VPRO TECHNOLOGY CAPABLE
Intel Core i5 with vPro and Core i7 with vPro technology is a selectable feature that is available on units configured with select processors, an Intel Centrino® Advanced-N or Ultimate-N WLAN module and a preinstalled Windows operating system. It provides advances in remote manageability, security, energy efficient performance, and wireless connectivity. Intel Active Management Technology 9.0 (iAMT) offers built-in manageability and proactive security for networked notebook PCs, even when they are powered off* or when the operating system is inoperable. It can help identify threats before they reach the network, isolate infected systems, and update PCs regardless of their power state.
*Requires a Windows operating system, network hardware and software, connection with a power source, and a direct (non­VPN) corporate network connection which is either cable or wireless LAN.
NOTE: Some functionality of this technology, such as Intel® Active management technology and Intel Virtualization technology, requires additional 3rd party software in order to run. Availability of future "virtual appliances" applications for Intel vPro technology is dependent on 3rd party software providers. Microsoft Windows required. For hard drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 30 GB for Windows 8 is reserved for system recovery software.
GRAPHICS
Integrated: UMA: Intel HD Graphics 4400
DISPLAY
Internal
11.6-inch diagonal LED-backlit, anti-glare, HD* AG UWVA Touchpanel (1366 x 768)
• Ultra- Wide-viewing angle
• LVDS – low voltage differential signaling
• Capacitive multitouch screen with digitizer
• Tough, durable Corning Gorilla Glass 3
External Up to 32-bit per pixel color depth
DisplayPort v1.2 Supports resolutions up to 2560 x 1600, 30-bit color depth at 60 Hz, and full HD (1920 x 1080) monitors, 24-bit color depth
QuickSpecs
HP EliteBook Revolve 810 G2
Features
at 120 Hz
Number of Supported Displays
Number of Displays with 2013 UltraSlim Docking Station
UMA
Discrete
EliteBook Revolve 810 G2
3
n/a
* HD content required to view HD images.
NOTE: Resolutions are dependent upon monitor capability, and resolution and color depth settings.
STORAGE AND DRIVES
Solid State Drive
128/180/256 GB M.2 Solid State Drives 256 GB SED M.2 Solid State Drive NOTE: For hard drives and solid state drives, GB = 1 billion bytes. Actual formatted capacity is less. Up to 16 GB (for Windows
7) and 30 GB (for Windows 8.1) of system disk is reserved for the system recovery software
MEMORY
Standard
DDR3L PC3-12800 SDRAM (1600 MHz) One SODIMM slot supporting dual-channel memory plus 4 GB soldered down 4 GB and 8 GB SODIMMs
Maximum Upgradeable to 12288 MB with optional 8192 MB SODIMM in slot 1 and 4096 MB soldered down Dual-channel Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory slots.
NOTE: Maximum memory capacities assume Windows 64-bit operating systems. With Windows 32-bit operating systems, memory above 3 GB may not all be available due to system resource requirements. NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed.
NETWORKING/COMMUNICATIONS
Wireless
Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the latest industry standards. Broadband Wireless (WWAN) requires a Windows operating system and is available in select countries as a standard, factory configurable feature only. Integrated Bluetooth is also available as both a factory configurable and after­market option and can be combined with any of the supported wireless LAN and wireless WAN options.
Broadband Wireless (WWAN)
HP hs3110 HSPA+ Mobile Broadband* HP lt4111 LTE/EV-DO/HSPA+ Mobile Broadband Module*,** (US)
QuickSpecs
HP EliteBook Revolve 810 G2
Features
HP lt4112 LTE/HSPA+ Mobile Broadband Module*,** (EMEA, APJ)
Wireless LAN (WLAN)
Intel Dual Band Wireless-AC 7260 802.11 ac (2x2) WiFi + BT 4.0 combo***, **** Intel Dual Band Wireless-N 7260AN 802.11 a/b/g/n (2x2) WiFi + BT 4.0 combo*** Intel Dual Band Wireless-N 7260NB 802.11 a/b/g/n (2x2) WiFi***
* WWAN is an optional, add-on feature and is planned to be available in March 2014. WWAN use requires separately purchased service contract. Check with service provider for coverage and availability in your area. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE is not available in all regions and requires Windows.
** 4G LTE not available on all products, in all regions and only available on products featuring Intel processors. ***WLAN is an optional feature. Wireless access point and Internet service is required and is not included. Availability of public wireless access points limited. **** The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices.
Communications
Integrated Intel 82579LM Gigabit* Network Connection (vPro configurations) * The term "10/100/1000" or "Gigabit" Ethernet indicates compatibility with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.
AUDIO/MULTIMEDIA
Audio
DTS Studio Sound Integrated stereo speakers Integrated microphone (dual-microphone array) Buttons for volume up and down Headphone/microphone combo jack
Webcam Integrated 720p HD webcam
• HD format (widescreen)
• Supports videoconferencing and still image capture
• High quality fixed focus lens
• Video capture at various resolutions up to 1280x720 resolution (720p) and up to 30fps
• M-JPEG compression supports higher frame rates for video capture and videoconferencing
• Improved low light sensitivity
• Improved dynamic range
KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS
Keyboard
QuickSpecs
HP EliteBook Revolve 810 G2
Features
The HP backlit (optional), spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a drain system that funnels fluid through a hole in the bottom of the notebook. This minimizes the risk of damage to sensitive components underneath. The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right control and alt keys, and 12 function keys. U.S. and International key layouts are available. Other features include an integrated numeric keypad, hotkeys for instant access to power conservation, brightness, and other features, 19 mm x 19 mm key pitch (center­to-center spacing), 2.0 mm stroke, and comfort-dished keycaps.
Pointing Devices Clickpad image sensor
Buttons and Function Keys
Function keys are: F1 - Ambient Light Sensor F2 - Battery Gauge F3 - Sleep F4 - Display Switching F5 - Speaker Mute F6 - Volume Down F7 - Volume Up F8 - mic mute F9 - Brightness Down F10 - Brightness Up F11 – Backlit keyboard F12 - WiFi toggle
SENSORS
Accelerometer Compass Ambient Light Sensor Near Field Communication (NFC)
SOFTWARE AND SECURITY
Preinstalled Software with Windows Operating System
Security
Absolute Data Protect Computrace (removed from UI on activation)1 Device Access Manager with Just In Time Authentication DigitalPersona Fingerprint Driver Drive Encryption2 HP Client Security (incl. Cred Mgr and Password Mgr) HP Trust Circles Standard3 Microsoft Defender Microsoft Security Essentials4 Privacy Manager (Web only)
QuickSpecs
HP EliteBook Revolve 810 G2
Features
Validity Fingerprint Driver
BIOS Features
Absolute Persistence Module (for all Absolute products) 1 HP Sure Start5 HP Automatic Drive Lock HP BIOS Protection6 (Follow NIST 800-147, 155 Guidelines) HP Disk Sanitizer7 (Not for SSD) HP DriveLock HP SpareKey8 Hybrid Boot Master Record Security (backup/restore) Measured Boot Power On Authentication Pre-Boot Security Secure Boot Secure Erase9 (SSD & HDD) Update via Network
HP Value Add
HP Ceement Digital ENERGY STAR® Logo W8 Getting Started with Windows 8 HP 3D DriveGuard HP ePrint Driver10 HP Firmware & Driver Installer HP Hotkey Support HP Manageability HP PageLift App HP PageLift Desktop App HP Performance Advisor HP Quick Start HP Recovery Manager HP Registration App HP Remote Graphics HP Setup HP Software Setup HP Support Assistant HP Recovery Disc Creator (HPRDC) HP WallPaper Internet Explorer 9 Internet Explorer 10 IE Home System Default Settings for Win8 UEFI System Diagnostics W8 Wireless Button Driver
3rd Party
Adobe® Flash Player (Commercial)
QuickSpecs
HP EliteBook Revolve 810 G2
Features
Amazon Kindle App PDF Complete, Corporate Edition Box.Net (UK only) Box 50GB CMIT Cloud Offer BTB Host and ISP Stub BTB Host End Block Bing Search for IE9 Bing Search for IE10 Netflix App Skype Desktop App11 Skype App11
Microsoft Products
Office Home & Business 2013 Office Professional 2013 Lync Optimized12
1
The Absolute Persistence agent is shipped turned off, and is activated with customer purchase of a subscription. Service may be limited. Check with Absolute for availability outside the U.S. The optional subscription service of Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit:
http://www.absolute.com/company/legal/agreements/computrace-agreement. If Data Delete is utilized, the Recovery
Guarantee payment is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either create a PIN or purchase one or more RSA SecurID tokens from Absolute Software
2
Requires Windows. Data is protected prior to Drive Encryption login. Turning the PC off or into hibernate logs out of Drive
Encryption and prevents data access. Drive encryption planned to be available in October 2013.
3
HP Trust Circles Standard, when included, allows up to 5 Trust Circles with up to 5 contacts in each Trust Circle. Optional Trust Circles Professional required for unrestricted number of Trust Circles and members contacts. Trust Circles Reader is available to allow a contact to participate in an invited Trust Circle. Requires Windows.
4
Opt in and internet connection required for updates.
5
HP Sure Start is available only on EliteBook 800 and Workstation ZBook series products. HP Tools partition with HP BIOS
required for automatic recovery.
6
HP Tools partition with an HP BIOS required for automatic recovery.
7
For the use cases outlined in the DOD 5220.22-M Supplement. Does not support Solid State Drives (SSDs). Initial setup
required. Web history deleted only in Internet Explorer and Firefox browsers and must be user enabled.
8
Requires initial user set up.
9
For the methods outlined in the National Institute of Standards and Technology Special Publication 800-88.
10
Requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of eligible printers, supported documents and image types and other HP ePrint details, see www.hp.com/go/eprintcenter).Requires optional broadband module. Broadband use requires separately purchased service contract. Check with service provider for coverage and availability in your area. Separately purchased data plans or usage fees may apply. Print times and connection speeds may vary.
11
Requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of eligible printers, supported documents and image types and other HP ePrint details, see www.hp.com/go/eprintcenter).Requires optional broadband module. Broadband use requires separately purchased service contract. Check with service provider for coverage and availability in your area. Separately purchased data plans or usage fees may apply. Print times and connection speeds may vary.
12
Lync software is sold separately. Requires internet access.
Security
QuickSpecs
HP EliteBook Revolve 810 G2
Features
Standard Common Criteria EAL4+ Augmented Certified Discrete TPM 1.2 Embedded Security Chip Security lock slot HP Sure Start HP BIOS (BIOS Protection) Secure Erase1 Computrace Persistence2 DriveLock and Automatic DriveLock Preboot Security Master Boot Record recovery (Windows 7 only) HP Client Security Software:
• Drive Encryption
• Credential Manager
• Password Manager
• Absolute Data Protect (Windows 8 and 8.1 only)6
• Computrace (Windows 7 only)7
• Face Recognition6
• One Step Logon
• SpareKey3
Device Access Manager with Just In Time Authentication Embedded Security (Windows 7 only) Privacy Manager (Windows 7 only) Microsoft Security Essentials (Windows 7 only)4 DigitalPass (Windows 7 only) Central Management capable5
Optional HP Combo Lock
1
For the methods outlined in the National Institute of Standards and Technology Special Publication 800-88.
2
Computrace agent is shipped turned off, and must be activated by customers when they purchase a subscription. Subscriptions can be purchased for terms ranging for multiple years. Service is limited, check with Absolute for availability outside the U.S
3
Requires initial user setup.
4
Opt-in and Internet connection required for updates
5
In order to deploy and receive updated policies, the client needs to be connected to the network server and requires separately purchased DigitalPersona Pro software. System access may not prevent users from logging into the system on the first attempt if policy updates haven't yet been received and applied.
6
HP Revolve with Windows 8 and 8.1 includes includes a 4 year license of Absolute Data Protect to locate your device, lock and prevent unauthorized access and remotely delete personal data. See http://www.absolute.com/landing/2012/computrace-hp for complete details. Absolute Data Protect agent is shipped turned off, and must be activated by customers. Service may be limited, check with Absolute for availability outside the U.S. The optional subscription service of Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit: http://www.absolute.com/company/legal/agreements/computrace-agreement. If Data Delete is utilized, the Recovery Guarantee payment is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either create a PIN or purchase one or more RSA SecurID tokens from Absolute Software.
7
HP Revolve with Windows 7 includes the Computrace agent, shipped turned off, and is activated with customer purchase of
QuickSpecs
HP EliteBook Revolve 810 G2
Features
a subscription. Service may be limited. Check with Absolute for availability outside the U.S. The optional subscription service of Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit: http://www.absolute.com/company/legal/agreements/computrace-agreement. If Data Delete is utilized, the Recovery Guarantee payment is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either create a PIN or purchase one or more RSA SecurID tokens from Absolute Software.
For more information on HP security solutions refer to: http://www.hp.com/go/security.
Management
LANDesk Management Suite (optional)
1, 2
LANDesk Security Suite(optional)
1, 2
HP System Software Manager (available at no charge as a download from the web) HP Softpaq Download Manager (available at no charge as a download from the web)
1
Sold separately or as an optional feature.
2
LANDesk software is sold separately. Managed devices must be connected to the management server. Location based functionality requires active LANdesk maintenance service. Wipe functionality performs a "Windows 8 Reset" and requires Windows 8. Lock performs a Windows "Lock Computer."
POWER
Power Supply
External HP 45W Slim Smart AC Adapter External 65W EM Smart AC Adapter (Asia, PRC, India only) Power cord is configurable; either 3.2 feet or 6 feet (1.0 or 1.8 meter)
Primary Battery HP 6-cell polymer long life (44WHr)
Battery Life HP 6-cell polymer long life battery (44WHr)
Up to TBD Hours*,**
System Standby Time Up to 137 hours
Power Conservation Supports enhanced Intel SpeedStep technology (allows Battery Optimized Mode, Maximum Performance Mode, or Automatic mode) Intel Display Power Saving technology Hibernation Standby ACPI compliance
* Windows 7 battery life will vary depending on various factors including product model, configuration, loaded applications, features, use, wireless functionality, and power management settings. The maximum capacity of the battery will naturally decrease with time and usage. See www.bapco.com for additional details. ** Windows 8 testing conducted by HP consisting of full battery discharge while running a series of productivity scripts against the following applications (which may or may not be included with your particular product): Adobe ® AcrobatReader
7.0, Adobe® Illustrator® CS2, Adobe® Photoshop® CS2, Apple® Quicktime 7.1, Intervideo® WinDVD® 8, Macromedia® Flash 8,
QuickSpecs
HP EliteBook Revolve 810 G2
Features
Microsoft® Office® 2003 Pro, Microsoft® Project 2003, and Winzip® 10.0. Prior to testing, the system was fully charged, display brightness was set at 60 nits, wireless was turned off, and auto dim, suspend, hibernate and all other non-essential operation programs, utilities, and services to operation and battery testing were disabled. Battery life will vary depending on the product model, configuration, loaded applications, features, use, wireless functionality and power management settings. The maximum capacity of the battery will naturally decrease with time and usage.
ENVIRONMENTAL
• US ENERGY STAR ®
• IT ECO declaration
• EPEAT® Gold registered in the U.S. (with Microsoft OS). EPEAT status varies by country- please see epeat.net for
registration status in your country.
• US Federal Energy Management Program (FEMP)
WEIGHTS & DIMENSIONS
Weight
Starting at 3.08 lb (1.40 kg) (weight will vary by configuration)
Dimensions (w x d x h)
8.34 x 11.22 x 0.80 in (at front) / 212 x 285 x 22.2 mm (at front)
NOTE: Height varies depending upon where on the notebook the measurement is made. Weight varies by configuration and components. Weight includes 6-cell battery, lightest SSD, and 1 SODIMM.
PORTS/SLOTS
Ports
DisplayPort – One (v1.2) Stereo headphone/microphone combo jack – One Power Connector – One Side Docking Connector – One RJ-45 (Ethernet) – One USB 3.0 – One USB 3.0 Charging – One
Digital Media Slots microSD Media Reader Slot - supports SD, SDHC, SDXC
SERVICE AND SUPPORT
Limited, 90-day warranty, depending on country); 1 and 3 year limited warranty options available. 3-year limited warranty on battery. Optional HP Care Pack Services are extended service contracts which go beyond your standard warranties. For more details visit: http://www.hp.com/go/cpc
NOTE: Certain restrictions and exclusions apply. Consult the HP Customer Support Center for details. http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
SYSTEM UNIT
Stand-Alone Power Requirements (AC Power)
Nominal Operating Voltage
110/220 V
Average Operating Power
10.2 W
Max Operating Power
< 45 W
Temperature
Operating
32° to 95° F (0° to 35° C) (not writing optical) 41° to 95° F (5° to 35° C) (writing optical)
Non-operating
-4° to 140° F (-20° to 60° C)
Relative Humidity
Operating
10% to 90%, non-condensing
Non-operating
5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature
Shock
Operating
40 G, 2 ms, half-sine
Non-operating
200 G, 2 ms, half-sine
Random Vibration
Operating
0.75 grms
Non-operating
1.50 grms
Altitude (unpressurized)
Operating
-50 to 10,000 ft (-15.24 to 3,048 m)
Non-operating
-50 to 40,000 ft (-15.24 to 12,192 m)
Planned Industry Standard Certifications
UL
Yes
CSA
Yes
FCC Compliance
Yes
ENERGY STAR®
Select models*
EPEAT
Gold**
ICES
Yes
Australia / NZ A-Tick Compliance
Yes
CCC
Yes
Japan VCCI Compliance
Yes
KC
Yes
BSMI
Yes
CE Marking Compliance
Yes
BNCI or BELUS
Yes
CIT
Yes
GOST
Yes
Saudi Arabian Compliance (ICCP)
Yes
SABS
Yes
UKRSERTCOMPUTER
Yes
* Configurations of the HP EliteBook Revolve 810 G2 that are ENERGY STAR qualified are identified as HP EliteBook Revolve 810 G2 ENERGY STAR on HP websites and on www.energystar.gov. ** EPEAT® Gold registered in the U.S. See www.epeat.net for registration status by country.
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
For accessibility information on HP products, please visit: http://www.hp.com/accessibility.
DISPLAYS
11.6-inch diagonal LED HD (1366 x 768)
Active Area
9.88 x 5.67 in (25.61 x 14.40 cm)
Dimensions (W x H)
11.53 x 6.49 in (29.3 x 16.5 cm)
Diagonal Size
11.6 in (29.46 cm)
Contrast Ratio
300:1 (typical)
Refresh Rate
60 Hz
Brightness
400 nit (typical)
Pixel Resolution
Format
1366 x 768
Configuration
RGB Stripe
Backlight
LED
Viewing Angle
40/40/15/30 (Left/Right/Down/Up) (typical)
STORAGE AND DRIVES
Internal Storage
128 GB* M.2 Solid State Drive
Drive Weight
10 grams
Capacity
128 GB
Height
0.091 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
SATA 3 (6 Gb/s)
Performance
Maximum Sequential Read
Maximum Sequential Write
Up to 500 MB/s
Up to 250 MB/s
Logical Blocks
250,069,680
Operating Temperature
32° to 158°F (0° to 70°C) [case temp]
Features
ATA Security; ATA-8; SATA 3.0; DIPM; TRIM
180 GB* M.2 Solid State Drive
Drive Weight
10 grams
Capacity
180 GB
Height
0.091 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
SATA Gen 3 (6 Gb/s)
Performance
Maximum Sequential Read
Maximum Sequential Write
Up to 520 MB/s
Up to 490 MB/s
Logical Blocks
351,651,888
Operating Temperature
32° to 158°F (0° to 70°C) [case temp]
Features
ATA Security; ATA-8, SATA 3.0; DIPM; TRIM
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
256 GB* M.2 Solid State Drive
Drive Weight
10 grams
Capacity
256 GB
Height
0.091 in (2.3 mm)
Width
0.87 in (22 mm)
Interface
SATA Gen 3 (6 Gb/s)
Performance
Maximum Sequential Read
Maximum Sequential Write
Up to 500 MB/s
Up to 350 MB/s
Logical Blocks
500,118,192
Operating Temperature
32° to 158°F (0° to 70°C) [case temp]
Features
ATA Security; ATA-8, SATA 3.0; DIPM; TRIM
* For solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 16 GB (for Windows 7) and 30 GB (for Windows 8.1) of system disk is reserved for the system recovery software.
NETWORKING/COMMUNICATIONS
Intel® 82579LM Gigabit Network Connection
Ethernet Features
10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14) 100 10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-14) 100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30) 1000 Mbti/s operation (1000BASE-T; IEEE 802.3ab; IEEE 8023. Clauses 40) Auto-Negotiation (Automatic Speed Selection) Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s IEEE 802.1p QoS (Quality of Service) Support IEEE 802.1q VLAN support IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable) IEEE 802.3az EEE(Energy Efficient Ethernet) Jumbo Frame 9K Auto MDI/MDIX Crossover cable detection
Power Management
ACPI compliant - multiple power modes Energy Detect Low Power Mode(Green Ethernet)
Performance Features
TCP/IP/UDP Checksum Offload (configurable) Protocol Offload( ARP & NS) Large send offload and Giant send offload Receiving Side Scaling MACSec Offload (802.3ae) Intel vPro iSCSI Boot
Manageability
Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only) PXE 2.1 Remote Boot Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30)) Comprehensive diagnostic and configuration software suite Virtual Cable Doctor for Ethernet cable status
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
Interface
PCI Express 1.1 x1 to fully support ASPM L0s/L1 and CLKREQ. NOTE: Intel 82579 PCIe interface is not PCIe compliant. It operates at half of PCIe specification V1.1 (2.5GT/S) speed.
NIC Device Driver Name
Intel 82579LM/82579V Ethernet Network Connection
HP hs3110/3114 HSPA+ Mobile Broadband Module
Technology/Operating bands
Modes: WCDMA/HSDPA/HSUPA/HSPA+/AWS/GSM/EDGE/GPRS Penta-band WCDMA/HSDPA/HSUPA/HSPA+/AWS: 850/900/1900/2100/AWS MHz GSM/GPRS/EDGE: 850/900/1800/1900 MHz
Wireless protocol standards
GSM/GPRS/EDGE: Class B, Multi-slot class 33, coding schemes CS1 - CS4 and MSC1 - MSC9. UMTS/WCDMA: Release 99 and Release 7 Advanced Receiver Type 3i
GPS
GPS Standalone, A-GPS: L1 (Internet- and Network assisted)
Wireless parametric standards
Complies with 3GPP specifications
Maximum data rates
GPRS/EDGE: Multi-slot Class 33, Class B WCDMA PS: UL (384 kbps) / DL (384 kbps) UL/DL HSPA: UL (5.76 Mbps)/ DL (7.2 Mbps) UL/DL HSPA+: UL (5.76 Mbps)/ DL (21Mbps)
Maximum output power
WCDMA/HSPA/HSPA+ 2100/1900/900/850/AWS MHz: +24dBm (Power Class 3) GPRS 1900/1800 MHz: +30dBm (Power Class 1) GPRS 900/850 MHz: +33dBm (Power Class 4) EDGE 1900/1800 MHz: +26dBm (Power Class E2) EDGE 900/850 MHz: +27dBm (Power Class E2)
Maximum power consumption
2500mA (peak); 600mA (average)
Power consumption, sleep mode
3.6 mA
Power management
USB selective suspend, Connected Standby Integrated notebook wireless button
Antenna type
Dual high efficiency 5 band antennae with spatial diversity, mounted in the display enclosure
Form Factor
M.2 Socket 2, USB 2.0 interface high speed
Weight
<6 g
Dimensions (Length x Width x Thickness)
2.01 x 1.18 x 0.18 in (42 x 30 x 2.3 mm)
SIM card supply voltage
1.8 V/3.0 V UICC (SIM/UICC/USIM)
Voltage, Operating
3.135V~4.4V (3.3 V recommended)
Temperature, operating
14° to 131° F (-10° to 55° C) (Normal operation)
-4° to 158° F (-20° to 70° C) (Extended operation)
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
Temperature, storage
-40° to 185° F (-40° to 85° C)
Humidity
5% to 95%
Configuration utilities
HP Connection Manager
LED activity
LED Off - Radio Off; Solid LED On - Radio On
HP lt4111 LTE/EV­DO/HSPA+ 4G WWAN*
Technology/Operating Bands
LTE FDD all bands with diversity: 1900 MHz (Band II)1, 1700/2100MHz (Band IV (AWS), 850 MHz (Band V), 700MHz (Band XIII), 700MHZ (Band XVII), 1900MHz G Block (Band XXV) WCDMA/HSDPA/HSUPA/HSPA+: all bands with diversity: 2100 MHz (Band I), 1900 MHz (Band II) , AWS 1700/2100MHz (Band IV), 850 MHz (Band V), 800 MHz (Band VIII) GSM/GPRS/EDGE: 1900 MHz, 1800 MHz , 850 MHz , 900 MHz CDMA: Cellular 800MHz (BC0), PCS 1900MHz (BC1)
Wireless Protocol Standards
3GPP Release 8 LTE Specification WCDMA R99, 3GPP Release 5, 6 and 7 UMTS Specification EVDO Release 0 and Release A
Wireless Parametric Standards
Complies with 3GPP specifications Release 8 for LTE
Maximum Data Rates
LTE (Category 3): 100 Mbps (Download), 50Mbps (Upload) DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload) HSPA+: 21.6 Mbps (Download), 5.76 Mbps (Upload) EDGE: 236.8 kbps (Download), 236.8 kbps (Upload) GPRS: 85.6 kbps(Download), 85.6 kbps (Upload)
GPS
Standalone GPS, A-GPS, GPS XTRA
GPS Bands
1575.42 MHz (± 1.023 MHz), GLONASS 1596-1607MHz
Maximum Output Power
LTE: +23 dBm (+/- 1 dBm) WCDMA: +23 dBm (+/- 1 dBm) GSM850/900, GMSK: +32dBm (+/- 1dBm) GSM850/900, 8PSK: +27dBm (+/- 1dBm) DCS1800 / PCS 1900, GMSK: +29dBm (+/- 1dBm) DCS1800 / PCS 1900, 8PSK: +26dBm (+/- 1dBm) CDMA: +24dBm (+/- 1dBm)
Maximum Power Consumption
LTE: 1,200 mA (peak); <900 mA (average) WCDMA: 1,100 mA (peak); <800 mA (average) EGPRS: 2,500 mA (peak); <700 mA (average)
Power Consumption, Sleep Mode
2 mA
Power Management
USB selective suspend, Integrated notebook wireless button
Antenna Type
Dual high efficiency multi-band antennae with spatial diversity
Form Factor
M.2, 3042-S3 Key B
Weight
6 g
Dimensions (Length x Width x Thickness)
42 mm × 30 mm × 2.3 mm
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
Voltage, Operating
3.135 V to 4.4 V (3.3 V +1.1V/-0.165V)
Temperature, operating (from TIA/EIA/IS-98-D)
-13° to 140° F (-25° to 60° C)
Temperature, non­operating, 96 hours (from
MIL-STD 202 Method 108)
-40° to 185° F (-40° to 85° C)
Humidity, Non-operating
95% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)
LED Activity
LED Off - Radio Off; Solid LED On - Radio On
1
1900 MHz (Band II) and 850 MHz (Band V) not supported at launch but support planned in a future firmware update. * 4G LTE not available on all products, in all regions and only available on products featuring Intel processors. WWAN use requires separately purchased service contract. Check with service provider for coverage and availability in your area. Connection speeds will vary due to location, environment, network conditions, and other factors.
HP lt4112 LTE/HSPA+ Gobi 4G Module*
Technology/Operating Bands
LTE FDD all bands with diversity: 2100 MHz (Band I), 1900 MHz (Band II), 1800 MHz (Band III), 850 MHz (Band V), 2600 MHz (Band VII), 900 MHz (Band VIII), 800 MHz (Band XX, DD800) WCDMA/HSDPA/HSUPA/HSPA+ all bands with diversity: 2100 MHz (Band I), 1900 MHz (Band II), 800 MHz (Band V), 900 MHz (Band VIII) GSM/GPRS/EDGE: 1900 MHz (Band II), 1800 MHz (Band III), 850 MHz (Band V), 900 MHz (Band VIII)
Wireless Protocol Standards
3GPP Release 8 LTE Specification WCDMA R99, 3GPP Release 5, 6 and 7 UMTS Specification
Wireless Parametric Standards
Complies with 3GPP specifications Release 8 for LTE
Maximum Data Rates
LTE (Category 3): 100 Mbps (Download), 50Mbps (Upload) DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload) HSPA+: 21.6 Mbps (Download), 5.76 Mbps (Upload) EDGE: 236.8 kbps (Download), 236.8 kbps (Upload) GPRS: 85.6 kbps(Download), 85.6 kbps (Upload)
GPS
Standalone
GPS Bands
1575.42 MHz (± 1.023 MHz), GLONASS 1596-1607MHz
Maximum Output Power
LTE: +23 dBm (+/- 2 dBm) WCDMA: +23.5 dBm (+/- 1 dBm) GPRS Band II, III: +29.5 dBm (+/- 1 dBm) GPRS Band V, VIII: +32.5 dBm (+/- 1 dBm) EGPRS Band II, III: +26.5 dBM (+/-1.5 dBm) EGPRS Band V, VIII: +27.5 dBM (+/-1.5 dBm)
Maximum Power Consumption
LTE: 1,200 mA (peak); <900 mA (average) WCDMA: 1,100 mA (peak); <800 mA (average) EGPRS: 2,800 mA (peak); <700 mA (average)
Power Consumption, Sleep Mode
3 mA
Power Management
USB selective suspend, Integrated notebook wireless button
Antenna Type
Dual high efficiency multi-band antennae with spatial diversity
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
Form Factor
M.2, USB 2.0 interface
Weight
6 g
Dimensions (Length x Width x Thickness)
42 mm × 30 mm × 2.3 mm
Voltage, Operating
3.135 V to 4.4 V (3.3 V +1.1V/-0.165V)
Temperature, operating (from TIA/EIA/IS-98-D)
14° to 131° F (-10° to 55° C)
Temperature, non­operating, 96 hours (from
MIL-STD 202 Method 108)
-40° to 185° F (-40° to 85° C)
Humidity, Non-operating
95% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)
LED Activity
LED Off - Radio Off; Solid LED On - Radio On
* 4G LTE not available on all products or in all regions. WWAN use requires separately purchased service contract. Check with service provider for coverage and availability in your area. Connection speeds will vary due to location, environment, network conditions, and other factors.
Intel Dual Band Wireless­N 7260AN 802.11 a/b/g/n (2x2) WiFi + Bluetooth 4.0 Combo Adaptor*
Wireless LAN Standards
IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
2.402 - 2.482 GHz
802.11a/n
4.9 - 4.95 GHz (Japan)
5.15 - 5.25 GHz
5.25 - 5.35 GHz
5.47 - 5.725 GHz
5.825 - 5.850 GHz
Antenna Structure
2 transmit; 2 receive (2x2)
Data Rates
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: card will support rates for NSS=1 and NSS=2 for RX and TX for 20 and 40 MHz channels. Short and long guard interval shall be supported.
Modulation
Direct Sequence Spread Spectrum CCK, BPSK, QPSK, 16-QAM, 64-QAM
Security1
• IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• IEEE 802.11i
• Cisco Certified Extensions, all versions through CCX4 and CCX Lite
• WAPI
Sub-channels
Multinational support with frequency bands and channels compliant to
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
local regulations.
Network Architecture Models
Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between band Access Points
Output Power2
• 2.4G: +13.5dBm minimum
• 5G: +12dBm minimum
Power Consumption
Transmit: 2.0 Watts Receive: 1.6 Watts Idle mode3: 250 mW (WLAN Associated) Idle mode: 100 mW (WLAN unassociated) Radio off: 75 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity4
802.11g:-90 dBm (6 Mbps), -89 dBm (9 Mbps), -87 dBm (12 Mbps), -85 dBm (18 Mbps), -82 dBm (24 Mbps), -79 dBm (36 Mbps), -76 dBm (48 Mbps), -74 dBm (54 Mbps)
802.11b:-95 dBm (1 Mbps), -93 dBm (2 Mbps), -91 dBm (5.5 Mbps), -88 dBm (11 Mbps)
802.11g:-90 dBm (6 Mbps), -89 dBm (9 Mbps), -87 dBm (12 Mbps), -85 dBm (18 Mbps), -82 dBm (24 Mbps), -79 dBm (36 Mbps), -76 dBm (48 Mbps), -74 dBm (54 Mbps)
802.11n:-69 dBm (150 Mbps), -66 dBm (300 Mbps)
Antenna Connections
2 U.FL type connectors (output impedance of 50 ± 2 ohms)
Form Factor
PCI-Express Half-MiniCard
Dimensions
0.12 x 1.06 x 1.18 in (3.1 x 26.8 x 30.0 mm)
Weight
3.1g
Operating Voltage
3.3v +/- 9%
Temperature
Operating Non-operating
14° to 158° F (-10° to 70° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating Non-operating
10% to 90% (non-condensing) 5% to 95% (non-condensing)
Altitude
Operating Non-operating
0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)
LED Activity
LED Off - Radio OFF; Solid LED On - Radio ON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. In Power Save Polling mode and on battery power.
4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).
5. WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
supplier IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows Vista.
HP Integrated Module with Bluetooth 4.0+EDR Wireless Technology
Bluetooth Specification
4.0+EDR Compliant
Dimensions
1.18 x 0.26 x 0.13 in (30 x 6.5 x 3.25 mm)
Frequency Band
2402 to 2480 MHz
Number of Available Channels
79 (1 MHz) available channels
Data Rates and Throughput
3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric or 1306.9 kbps symmetric
Transmit Power
-1.5 dBm to 4 dBm (Bluetooth Class II)
Receiver Sensitivity
Better than -20 dBM at 0.1 % raw bit error rate
Power Consumption
Peak (Tx) 264 mW Peak (Rx) 231 mW Sleep <1 mW
Antenna
Internally integrated within module
Range
Up to 33 ft (10 m)
Electrical Interface
USB 2.0 compliant
Microsoft Windows Plug and Play compliant
Bluetooth Software Supported
Broadcom Bluetooth for Windows
Microsoft Windows Bluetooth Software
Link Topology
Point to Point, Multipoint Pico Nets up to 7 slaves
Security
Full support of Bluetooth Security Provisions
Power Management
Microsoft Windows ACPI, and USB Bus Support
Self configurable to optimize power conservation in all operating modes, including Standby, Hold, Park, and Sniff
Certifications
All necessary regulatory approvals for supported countries, including:
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
Bluetooth Profiles Supported
Serial Port Profile (SPP)1 Service Discovery Application Profile (SDAP) Dial-Up Networking (DUN)
1,2
Generic Object Exchange Profile (GOEP)
1,2
Object Push Profile (OPP)
1,2
File Transfer Profile (FTP) Synchronization Profile (SYNC) Hard Copy Cable Replacement (HCRP)
1,2
Personal Area Networking Profile (PAN)
1,2
Human Interface Device Profile (HID)
1,2
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)
1. indicates the profile is supported by Microsoft Windows XP SP2
2. indicates the profile is part of Windows Vista * Wireless access point and internet service required. Availability of public wireless access points limited.
Intel Dual Band Wireless­AC 7260 802.11 ac (2x2) WiFi + BT 4.0 combo Adapter*
Wireless LAN Standards
IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
• 2.402 - 2.482 GHz
802.11a/n
• 4.9 - 4.95 GHz (Japan)
• 5.15 - 5.25 GHz
• 5.25 - 5.35 GHz\
• 5.47 - 5.725 GHz
• 5.825 - 5.850 GHz
• 2.402 - 2.482 GHz
Data Rates
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
• 802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and
80MHz)
Modulation
Direct Sequence Spread Spectrum BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security1
• IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• IEEE 802.11i
• Cisco Certified Extensions, all versions through CCX4 and CCX Lite
• WAPI
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
Network Architecture Models
Network Architecture Models
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
• 2.4G: +13.5dBm minimum
• 5G: +12dBm minimum
• Maximum output power must be able to achieve modular
regulatory certification with notebooks that have antennas >20cm from the user and peak gain of +3dBi at 2.4GHz and +4dBi at 5GHz
Power Consumption
Transmit: 2.0 W (max) Receive: 1.6 W (max) Idle mode (PSP): 250 mW (WLAN Associated) Idle mode: 100 mW (WLAN unassociated) Radio disabled: 75 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b:-95 dBm (1 Mbps), -93 dBm (2 Mbps), -91 dBm (5.5 Mbps), -88 dBm (11 Mbps)
802.11a/g:-90 dBm (6 Mbps), -89 dBm (9 Mbps), -87 dBm (12 Mbps), -85 dBm (18 Mbps), -82 dBm (24 Mbps), -79 dBm (36 Mbps), -76 dBm (48 Mbps), -74 dBm (54 Mbps)
802.11n:-69 dBm (72.2 Mbps), -66 dBm (300 Mbps)
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications
Form Factor
PCI-Express Half-MiniCard
Dimensions
0.19 x 1.06 x 1.18 in (4.75 x 26.8 x 30 mm)
Weight
3.1g
Operating Voltage
3.3v +/- 9%
Temperature
Operating Non-operating
14° to 158° F (-10° to 70° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating Non-operating
10% to 90% (non-condensing) 5% to 95% (non-condensing)
Altitude
Operating Non-operating
0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)
LED Activity
LED Off - Radio OFF; Solid LED On - Radio ON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).
Bluetooth Specification
V4.0 High Speed, V2.1+EDR, backwards compatible with V1.1, 1.2 and 2.0
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
Number of Available Channels
79 (1 MHz) available channels
Data Rates and Throughput
3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric or 1306.9 kbps symmetric
Transmit Power
-6 dBm to 4 dBm (Bluetooth Class II)
Receiver Sensitivity
Better than -80 dBM at 0.1 % raw bit error rate
Power Consumption
Peak (Tx) 330 mW Peak (Rx) 230 mW Sleep <17 mW
Antenna
Internally integrated within module
Range
Up to 33 ft (10 m)
Electrical Interface
USB 2.0 compliant Microsoft Windows Plug and Play compliant
Bluetooth Software Supported
Broadcom Bluetooth for Windows Microsoft Windows Bluetooth Software
Link Topology
Point to Point, Multipoint Pico Nets up to 7 slaves
Security
Full support of Bluetooth Security Provisions
Power Management
Microsoft Windows ACPI, and USB Bus Support Self-configurable to optimize power conservation in all operating modes, including Standby, Hold, Park, and Sniff
Certifications
All necessary regulatory approvals for supported countries, including: FCC (47 CFR) Part 15C, Section 15.247 & 15.249 ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark
Bluetooth Profiles Supported
Generic Access Profile (GAP) Service Discovery Application Profile (SDAP) Serial Port Profile (SPP) Dial_Up Networking Profile (DUN) Generic Object Exchange Profile (GOEP) Object Push Profile (OPP) File Transfer Profile (FTP) Synchronization Profile (SYNC) Hard Copy Cable Replacement (HCRP) Personal Area Networking Profile (PAN) Human Interface Device Profile (HID) Generic Audio/Video Distribution Profile (GAVDP) Advanced Audio/Video Distribution Profile (A2DP) FAX Profile (FAX) Basic Imaging Profile (BIP) Headset Profile (HSP) Hands Free Profile (HFP)
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
Basic Printing Profile (BPP) VDP (Video Distribution Profile) AVRCP (Audio Video Remote Control Profile)
* Wireless access point and internet service required. Availability of public wireless access points limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices
Intel Dual Band Wireless­N 7260NB 802.11 a/b/g/n (2x2) WiFi Adapter*
Wireless LAN Standards
IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
2.402 - 2.482 GHz
802.11a/n
4.9 - 4.95 GHz (Japan)
5.15 - 5.25 GHz
5.25 - 5.35 GHz
5.47 - 5.725 GHz
5.825 - 5.850 GHz
Antenna Structure
2 transmit; 2 receive (2x2)
Data Rates
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: card will support rates for NSS=1 and NSS=2 for RX and TX for 20 and 40 MHz channels. Short and long guard interval shall be supported.
Modulation
Direct Sequence Spread Spectrum CCK, BPSK, QPSK, 16-QAM, 64-QAM
Security1
• IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only
• AES-CCMP: 128 bit in hardware
• 802.1x authentication
• WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
• WPA2 certification
• IEEE 802.11i
• Cisco Certified Extensions, all versions through CCX4 and CCX Lite
• WAPI
Sub-channels
Multinational support with frequency bands and channels compliant to local regulations.
Network Architecture Models
Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between band Access Points
Output Power2
• 2.4G: +13.5dBm minimum
• 5G: +12dBm minimum
Power Consumption
Transmit: 2.0 Watts Receive: 1.6 Watts
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
Idle mode3: 250 mW (WLAN Associated) Idle mode: 100 mW (WLAN unassociated) Radio off: 75 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity4
802.11g:-90 dBm (6 Mbps), -89 dBm (9 Mbps), -87 dBm (12 Mbps), -85 dBm (18 Mbps), -82 dBm (24 Mbps), -79 dBm (36 Mbps), -76 dBm (48 Mbps), -74 dBm (54 Mbps)
802.11b:-95 dBm (1 Mbps), -93 dBm (2 Mbps), -91 dBm (5.5 Mbps), -88 dBm (11 Mbps)
802.11g:-90 dBm (6 Mbps), -89 dBm (9 Mbps), -87 dBm (12 Mbps), -85 dBm (18 Mbps), -82 dBm (24 Mbps), -79 dBm (36 Mbps), -76 dBm (48 Mbps), -74 dBm (54 Mbps)
802.11n:-69 dBm (150 Mbps), -66 dBm (300 Mbps)
Antenna Connections
2 U.FL type connectors (output impedance of 50 ± 2 ohms)
Form Factor
PCI-Express Half-MiniCard
Dimensions
0.12 x 1.06 x 1.18 in (3.1 x 26.8 x 30.0 mm)
Weight
3.1g
Operating Voltage
3.3v +/- 9%
Temperature
Operating Non-operating
14° to 158° F (-10° to 70° C)
-40° to 176° F (-40° to 80° C)
Humidity
Operating Non-operating
10% to 90% (non-condensing) 5% to 95% (non-condensing)
Altitude
Operating Non-operating
0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)
LED Activity
LED Amber - Radio OFF; Solid LED On - Radio ON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
3. In Power Save Polling mode and on battery power.
4. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).
5. WLAN supplier's client utility is required for Cisco Compatible Extensions support with Microsoft Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN supplier IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows Vista. * Wireless access point and internet service required. Availability of public wireless access points limited.
AUDIO/MULTIMEDIA
Audio
DTS Studio Sound (Windows OS only)
Hardware
Implementation
IDT 92HD91 High Definition CODEC
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
Function Key Volume Controls
Volume up, volume down, and mute
Mute Buttons
Playback and Record mute buttons with LED indicator
Full Duplex
Yes
Microphone In
Stereo
Headphone/Line Out
Stereo
Integrated Microphone
Yes, dual digital microphone array
Audio Output Quality
Frequency Response
20 Hz – 20 kHz
Signal to Noise Ratio
>85 dB
Total Harmonic Distortion
0.01%
Noise Floor
-110 dB
Play/Record Sampling Rate(s)
8 kHz - 48kHz
DAC
16, 20 or 24-bit
ADC
16 or 20-bit
Integrated Stereo Speakers
Power Rating
1 Watt
Impedance
8 Ohms
POWER
HP 45W Slim Smart AC Adapter
Dimensions (H x W x D)
9.60 x 4.95 x 2.24 cm
Input
90 to 265 VAC
Input Efficiency
87% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
1.4 A at 90 VAC and maximum load
Output
Output power
45W
DC output
19.5V
Hold-up time
5 msec at 115 VAC input
Output current limit
<8A, Over voltage protection- 29V max automatic shutdown
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Operating temperature
32° to 95° F (0° to 35° C)
Non-operating (storage) temperature
-4° to 121° F (-20° to 85° C)
Altitude
0 to 16,405 ft (0 to 5,000 m)
Humidity
0% to 95%
Storage Humidity
0% to 95%
QuickSpecs
HP EliteBook Revolve 810 G2
Technical Specifications
EMI and Safety Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals
- C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE; Reliability - failure rate of less than 0.1% annually within the first three years of operation.
HP 6-cell (44 WHr) Polymer Primary battery
Dimensions (H x W x L)
1.11 x 28.1 x 10.3 cm
Weight (max)
3.10g
Cells/Type
6-cell Polymer
Energy
Voltage
11.1V
Amp-hour capacity
4.0Ah
Watt-hour capacity
44Wh
Temperature
Operating (Charging)
32° to 113° F (0° to 45° C)
Operating (Discharging)
14° to 122° F(-10° to 50° C)
Non-operating
-4° to 122° F (-20° to 50° C)
Battery Re-Charge Time
System in OFF or Standby Mode
2.5 hours System ON
3-5 hours
Fuel Gauge LED
No
Optional Travel Battery Available
No
ENVIRONMENTAL
TBD
COUNTRY OF ORIGIN
TBD
QuickSpecs
HP EliteBook Revolve 810 G2
Options and Accessories (sold separately and availability may vary by country)
Type
Description
Part #
Memory
HP 2GB DDR3 1600 PC3-12800 SODIMM
H2P63AA#xxx
HP 4GB DDR3 1600 PC3-12800 SODIMM
H2P64AA#xxx
HP 8GB DDR3 1600 PC3-12800 SODIMM
H2P65AA#xxx
Cases
HP Slim Ultrabook Messenger (up to 15.6" x .88"/22/5mm)
F3W14AA
HP Slim Ultrabook Top Load (up to 15.6" x .88"/22/5mm)
F3W15AA
HP Slim Ultrabook Backpack (up to 15.6" x .88"/22/5mm)
F3W16AA
HP Essential Top Load Case (up to 15.6")
H2W17AA#xxx
HP Essential Backpack (up to 15.6")
H1D24AA
HP Essential Messenger Case (up to 17.3")
H1D25AA
HP Professional Series Carrying Case (up to 15.6")
H4J90AA
HP Professional Series Carrying Case TSA (up to 15.6")
H4J92AA
HP Professional Series Backpack (up to 15.6")
H4J93AA
HP Professional Leather Case (up to 17.3")
H4J94AA
HP Business Slim Top Load (up to 14.1" x .75" thick)
H2T13AA
Docking
HP 2013 UltraSlim Docking Station
D9Y32AA#xxx
HP Dual Hinge II Notebook Stand
E8F99AA#xxx
HP Display and Notebook Stand II
E8G00AA#xxx
HP Adjustable Dual Monitor Stand
AW664AA#xxx
HP Adjustable Display Stand
AW663AA#xxx
HP LCD Monitor Stand
QM196AA
HP USB 2.0 Port Replicator
H1L07AA#xxx
HP USB 3.0 Port Replicator
H1L08AA#xxx
Input/Output - Mice
HP USB Optical Travel mouse
RH304AA
HP Wireless Mobile Mouse
H2L63AA
HP USB Essential Keyboard/Mouse
H2S75AA
HP X6000 Mouse
H2L62AA#XXX
HP 3-button USB Laser Mouse
H4B81AA
HP X4000b Bluetooth Mouse
H3T50AA#xxx
Input/Output - Keyboard
HP Stylish Wireless KB/Mouse
H4B79AA
HP Stylish USB KB/Mouse
H4B80AA
HP Slim BT Keyboard US
H4Q44AA#ABA
Input/Output - Other
HP USB Ethernet Adapter
XZ613AA#ABA
USB Graphics Adapter (DBU PL)
NL571AA
QuickSpecs
HP EliteBook Revolve 810 G2
Options and Accessories (sold separately and availability may vary by country)
Adapters
HP DP to HDMI 1.4 Adapter
F3W43AA
90W Slim Combo Adapter
H4A41AA#xxx
90W w/USB Universal Adapter
H4A43AA#ABA
90W Smart AC/Auto/Air Combo Adapter
AJ652AA#xxx
90W Smart Auto/Truck Adapter
ED493AA
HP Smart 65W Travel AC Adapter
AU155AA#xxx
HP 65W Slim Adapter
AX727AA#xxx
65W Smart AC Adapter
ED494AA#xxx
90W Smart AC Adapter
ED495AA#xxx
90W Slim Adapter
BT796AA#xxx
Storage - External Storage
HP External USB Optical Drive
F2B56AA
Platform Battery
HP OD06XL Long Life Notebook Battery
H6L25AA
Health and Education
20 Notebook Managed Charging Cart
QL489AA#xxx
20 Notebook Charging Cart
QL488AA
30 Notebook Managed Charging Cart
QL490AA
30 Notebook Charging Cart
H4F31AA#ABA
Security
HP Docking Station Cable Lock
AU656AA#xxx
HP UltraSlim Keyed Cable Lock
H4D73AA
Monitors
HP U160 15.6-inch LED Backlit Monitor
C4M77AA or
D4T56AA#xxx
(check region for which
sku is available)
HP EliteDisplay E271i 27-inch IPS LED Monitor
D7Z72AA/A8/AS/AT
HP EliteDisplay E231 23-inch LED Monitor
C9V75AA/A8/AS/AT
HP EliteDisplay E201 20-inch LED Monitor
C9V73AA/A8/AS/AT
HP ProDisplay P221 21.5" LED Monitor
C9E49AA/A8/AS/AT
HP ProDisplay P201 20" LED Monitor
C9F26AA/A8/AS/AT
Copyright © 2013 Hewlett-Packard Development Company, L.P.
All rights reserved. Intel and Core are registered trademarks or trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation. Adobe is a trademark of Adobe Systems Incorporated. ENERGY STAR is a registered mark owned by the U.S. government.
QuickSpecs
HP EliteBook Revolve 810 G2
Options and Accessories (sold separately and availability may vary by country)
The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
