Your microprocessor-based, digitally controlled color monitor is
a high-performance and easy-to-use product. It employs the latest
on-screen menu technology.
Kit Contents
The monitor kit contains:
■ CRT monitor
■ Monitor Base (preinstalled on select models)
■ AC power cord (select models)
■ Documentation kit
1
Introduction
Reference Guide www.hp.com 1–1
Safety and Maintenance
Safety Guidelines
Power Requirements
Refer to the “Power Cord Set Requirements” section in “Agency
Regulatory Notices,” for information on the correct power cord
set for this device.
Important Safety Information
WARNING: To reduce the risk of electric shock or damage to your
Å
equipment, do not disable the power cord grounding feature. This
equipment is designed to be connected to a grounded (earthed)
power outlet that is easily accessible to the operator. The grounding
plug is an important safety feature.
2
Guidelines
WARNING: For your safety, be sure that the power outlet you plug
Å
the power cord into is easily accessible and located as close to the
equipment as possible. When you need to disconnect the power to
the equipment, unplug the power cord from the power outlet by
grasping the plug firmly. Never pull on the cord.
Reference Guide www.hp.com 2–1
Safety and Maintenance Guidelines
CAUTION: For the protection of your monitor, as well as your
Ä
computer, connect all power cords for your computer and its
peripheral devices (such as a monitor, printer, scanner) to some form
of surge protection device such as a power strip or Uninterruptible
Power Supply (UPS). Not all power strips provide surge protection;
the power strips must be specifically labeled as having this ability.
Use a power strip whose manufacturer offers a Damage Replacement
Policy so you can replace your equipment if surge protection fails.
Maintenance Guidelines
To enhance the performance and extend the life of your monitor,
follow these guidelines:
■ Do not open your monitor cabinet or attempt to service this
product yourself. If your monitor is not operating properly, or
has been dropped or damaged, first unplug from power outlet,
then contact your Hewlett-Packard authorized dealer, reseller,
or service provider.
■ Adjust only those controls that are discussed in the operating
instructions.
■ Place your monitor at least 3 inches (76 mm) away from
walls or other enclosures.
■ Use only a power source and connection appropriate for this
monitor, as indicated on the label/back plate of the monitor.
■ Be sure the total ampere rating of the products connected to
the outlet does not exceed the current rating of the electrical
outlet, and the total ampere rating of the products connected
to the cord does not exceed the rating of the cord. Look on the
power label to determine the ampere rating (AMPS or A) for
each device.
2–2 www.hp.com Reference Guide
Safety and Maintenance Guidelines
■ Install your monitor near an outlet that you can easily reach.
Disconnect the monitor by grasping the plug firmly and
pulling it from the outlet. Never disconnect the monitor by
pulling the cord.
■ Turn your monitor off when not in use. You can substantially
increase the life of your monitor by using a screen saver
program and turning off the monitor when not in use.
■ Unplug your monitor from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning. If the screen requires additional cleaning,
use an antistatic CRT screen cleaner.
CAUTION: Do not use benzene, thinner, ammonia, or any other
Ä
volatile substances to clean your monitor or the screen. These
chemicals may damage the cabinet finish as well as the screen.
■ Slots and openings in the cabinet are provided for ventilation.
These openings must not be blocked or covered. Never push
objects of any kind into cabinet slots or other openings.
■ Do not place plants on top of your monitor. Water or dirt from
the plant may get into the vents.
■ Do not drop your monitor or place it on an unstable surface.
■ Do not allow anything to rest on the power cord. Do not walk
on the cord.
■ Keep your monitor in a well-ventilated area, away from
excessive light, heat or moisture. Keep your monitor away
from high-capacity transformers, electric motors, and other
devices with strong magnetic fields.
■ In a two-monitor system, place your monitors as far apart
from one another as possible to lessen interference between
them.
Reference Guide www.hp.com 2–3
■ Do not place the monitor face down. Damage could result to
the front panel controls or the monitor screen.
Removing the Monitor Base
In the event that you need to disassemble the base from the
monitor, follow these instructions:
1. If you must remove the base attachment, release the catch and
slide the base toward the back of your monitor.
2. Lift the base up and away from your monitor.
2–4 www.hp.com Reference Guide
Monitor Base Installation
On some monitors, the base must be attached prior to monitor
installation. If you need to attach the base, follow these steps:
1. Align the hooks on the base with the sockets on the bottom of
the monitor and attach
the base.
3
Installation
Reference Guide www.hp.com 3–1
Installation
2. Push the base toward the front of the monitor until it stops.
Monitor Installation
Before installing your monitor, place it in a convenient,
well-ventilated location near your computer.
1. Turn off the power to your computer and other peripheral
devices.
2. Connect the video cable (blue connector) 1 from the back of
the monitor to the blue 15-pin connector on the back of the
computer. Tighten the cable screws to secure the cable to the
connector.
CAUTION: To avoid damaging the video cable, ensure that the
Ä
cable aligns with the 15-pin connector. Do not force the cable onto
the connector.
3. Connect the power cord 2 to the back of the monitor, then
connect the power cord to a power outlet.
3–2 www.hp.com Reference Guide
4. Power on your computer and monitor.
If your monitor fails to function properly, refer to
✎
“Troubleshooting.”
Installation
5. If necessary, adjust the front panel monitor controls
according to your personal preference. See “Front Panel
Controls” for detailed information.
Your monitor installation is now complete.
Reference Guide www.hp.com 3–3
Information Files
The CD-ROM included with this monitor contains two data files
that must be installed onto your computer: an .INF file and an
.ICM file.
The .INF file designates software and defines monitor resources
used by Microsoft Windows to ensure monitor compatibility with
the graphics adapter in your computer.
The .ICM file provides color matching consistency between your
monitor screen and your printer. Once installed, this file is
activated by graphics programs that have this color-matching
feature.
To install these files on your computer:
1. Insert the Software and Reference Guide CD-ROM in your
computer's optical drive.
4
Operation
2. When the CD-ROM menu launches, select Install INF and
ICM Files.
3. To get the latest .INF and .ICM files, download them from the
HP Web site. Access
your monitor model to download the appropriate files.
Reference Guide www.hp.com 4–1
http://www.hp.com/go/support and select
Operation
Front Panel Controls
Front Panel Controls
Item Icon Name Function
Select Launches on-screen displays,
1
Left Adjustment Moves backward through menu
2
Right Adjustment Moves forward through menu
3
Power/LED Controls power to the monitor.
4
4–2 www.hp.com Reference Guide
selects functions and
adjustments, and exits menus
and On-Screen Display.
options or decreases adjustment
levels.
options or increases adjustment
levels.
The LED on the power button
indicates the state of the
monitor.
On-Screen Display
The On-Screen Display (OSD) adjusts the screen image based on
your viewing preferences. To access the OSD, do the following:
1. If the monitor is not already on, press the Power button to
turn on the monitor.
2. Press the Select button to display the On-Screen Display
menu. A screen similar to this one appears. For a description
of the icons that appear on the screen, see “On-Screen
Display Functions” later in this chapter.
Operation
Not all OSD features are available on all models. The OSD for
✎
your monitor may be different. See “On-Screen Display
Functions” for a features list for your model.
3. To move to a function, press the Right-Adjustment or
Left-Adjustment button on the front panel of your monitor
until the function is highlighted.
Reference Guide www.hp.com 4–3
Operation
4. Press the Select button on the monitor choose the function.
5. The adjustment window displays. Press the Right-Adjustment
or Left-Adjustment buttons to increase (Right) or decrease
(Left) the level of adjustment.
6. Press Select to save the new adjustment.
7. To exit the On-Screen Display, select the Exit icon and press
the Select button once.
On-Screen Display Functions
Use the Right-Adjustment and Left-Adjustment buttons found on
the front control panel of your monitor to adjust these functions.
The shaded area indicates that this function is available in the
✎
model indicated.
On-Screen Display Icons and Functions
Icon Function Description 5500
7500
&
7550 9500
Contrast Right-Adjustment
increases the contrast
and Left-Adjustment
decreases the contrast.
Brightness Right-Adjustment
increases the
brightness and
Left-Adjustment
decreases the
brightness.
Horizontal
Position
4–4 www.hp.com Reference Guide
Right -Adjustment moves
the image to the right
and Left-Adjustment
moves the image to the
left.
On-Screen Display Icons and Functions (Continued)
7500
&
Icon Function Description 5500
7550 9500
Operation
Horizontal
Size
Vertical
Position
Vertical
Size
Pincushion Right-Adjustment makes
Trapezoid Right-Adjustment
Pin Balance Right-Adjustment moves
Right-Adjustment
increases the horizontal
size and
Left-Adjustment
decreases the
horizontal size.
Right -Adjustment moves
the image up and
Left-Adjustment moves
the image down.
Right-Adjustment
increases the vertical
size and
Left-Adjustment
decreases the vertical
size.
the image sides convex
and Left-Adjustment
makes the image
concave.
adjusts the image so
the top is larger and
Left-Adjustment adjusts
the image so that the
bottom is larger.
the top and bottom of
the image to the right
and Left-Adjustment
moves the top and
bottom of the image to
the left.
Reference Guide www.hp.com 4–5
Operation
On-Screen Display Icons and Functions (Continued)
7500
&
Icon Function Description 5500
7550 9500
Parallelogram
Tilt
(Rotation)
Moire Right-Adjustment
Degauss This control
This control corrects the
tilted vertical edges of
the image on both
sides of the screen that
are in the same
direction.
Right-Adjustment tilts
the sides of the image
to the right and
Left-Adjustment tilts the
sides of the image to
the left.
increases the Moire
correction and
Left-Adjustment
decreases the Moire
correction.
demagnetizes the
screen to reduce color
impurities.
Hewlett-Packard
suggests you not
degauss more than
once within a
30-minute period of
time.
4–6 www.hp.com Reference Guide
On-Screen Display Icons and Functions (Continued)
7500
&
Icon Function Description 5500
Color Temp Right-Adjustment
selects the color
temperature to the right
and Left-Adjustment
selects the color
temperature to the left.
Reset This control resets the
monitor to factory
default values.
Exit This control exits the
OSD menu.
7550 9500
Operation
Reference Guide www.hp.com 4–7
Operation
Monitor Messages
No Signal Message
If a No Signal message displays on your monitor, check to be sure
your video cable is properly connected and ensure that your
computer is powered on.
4–8 www.hp.com Reference Guide
Out of Frequency Range Message
If an Out of Frequency Range message displays on your monitor,
your video resolution and/or refresh rate are set higher than the
levels your monitor supports.
Operation
To change the video resolution or refresh rate on your monitor,
follow these steps:
1. Restart your computer.
2. Enter Safe Mode on your computer. Refer to your computer’s
operating system Help for instructions on entering Safe
Mode.
3. Change your display settings to a supported setting (see
“Technical Specifications”).
4. Restart your computer so that the new settings take effect.
Reference Guide www.hp.com 4–9
Operation
Using the Energy Saver Mode
Your monitor is designed to meet strict Environmental Protection
Agency (EPA) Energy Star requirements for reduced power
consumption. Using a combination of hardware and software
functions, this energy-saving feature allows your computer to
control your monitor’s power consumption and reduce your
monitor’s power state when not in use.
Power Management Status for 5500/15” Series
Monitors
LED
State
On Green < 80 watts Normal Operation
Sleep Amber < 5 watts Monitor screen is blank. High voltage
Color
Power
Consumption Description
is off. Heater voltage is off. There is a
brief warm-up period before returning
to full power mode.
Power Management Status for 7500 and 7550/17”
Series Monitors
Power
State LED Color
On Green < 100 watts Normal Operation
Sleep Amber < 5 watts Monitor screen is blank. High voltage
4–10 www.hp.com Reference Guide
Consumption Description
is off. Heater voltage is off. There is a
brief warm-up period before
returning to full power mode.
Power Management Status for 9500/19” Series
Monitors
LED
State
On Green < 130 watts Normal Operation
Sleep Amber < 5 watts Monitor screen is blank. High voltage
Color
Power
Consumption Description
is off. Heater voltage is off. There is a
brief warm-up period before returning
to full power mode.
Your monitor’s energy saver feature works only when your
✎
monitor is connected to a computer that also has energy saver
features.
The Energy Saver utility, with its energy saving features, is
available with all Microsoft Windows operating systems. Some
features are also available in DOS. Refer to your computer’s user
guide for instructions on setting energy saver features (also
referred to as power management features).
Reference Guide www.hp.com 4–11
Troubleshooting
Solving Common Problems
The following table lists possible problems, the possible cause of
each problem, and the recommended solutions.
Problem Possible Cause Solution
Screen is blank. Power cord is disconnected. Connect the power
cord.
Power switch is off. Turn on power.
A
Video cable is improperly
connected.
Screen blanking utility is
active.
Image appears
blurred, indistinct, or
too dark.
Color is abnormal. A magnetic object may be
Reference Guide www.hp.com A–1
Brightness and contrast are too
low.
nearby.
Connect video cable
properly.
Depress any key on
the keyboard or move
the mouse.
Press the SELECT
button to access the
On-Screen Display.
Select the Brightness
and/or Contrast
icons to adjust as
needed.
Move the object
farther away.
Troubleshooting
Problem Possible Cause Solution
Monitor may have been
moved or inadvertently
bumped.
Image is too large or
too small.
Image is not centered. Horizontal position may need
Horizontal width may need
adjustment.
Vertical height may need
adjustment.
adjustment.
Press the SELECT
button to access the
On-Screen Display.
Select Degauss to
activate.
Hewlett-Packard
suggests you not
degauss more than
once within a
30-minute period of
time.
Press the SELECT
button to access the
On-Screen Display.
Select H. Size to
adjust as needed.
Press the SELECT
button to access the
On-Screen Display.
Select V. Size to
adjust as needed.
Press the SELECT
button to access the
On-Screen Display.
Select H. Position to
adjust as needed.
Vertical position may need
adjustment.
A–2 www.hp.com Reference Guide
Press the SELECT
button to access the
On-Screen Display.
Select V. Position to
adjust as needed.
Troubleshooting
Problem Possible Cause Solution
“No Signal” is
displayed on screen.
“Out of Frequency” is
displayed on screen.
Monitor is
overheating.
Monitor video cable is
disconnected.
Video resolution and/or
refresh rate are set higher than
what your monitor supports.
There is not enough air space
to allow proper ventilation.
Connect the 15-pin
monitor video cable
to the computer. Be
sure that the
computer power is
on.
Restart your computer
and enter Safe
Mode. Change your
settings to a
supported setting (see
“Technical
Specifications”).
Restart your computer
so that the new
settings take effect.
Leave at least 3
inches (76 mm) of
ventilation space
around the monitor,
and do not place
objects on top of the
monitor.
Reference Guide www.hp.com A–3
Using the Worldwide Web
Before contacting customer services, refer to the support Web site
at: http://www.hp.com/go/support.
Preparing to Call Technical Support
If you cannot solve a problem using the troubleshooting tips in
this section, you may need to call technical support. Have the
following information available when you call:
■ The monitor
■ Monitor model number
■ Serial number for the monitor
■ Purchase date on invoice
■ Conditions under which the problem occurred
■ Error messages received
■ Hardware configuration
■ Hardware and software you are using
A–4 www.hp.com Reference Guide
Technical Specifications
5500/15” Series Monitor
Screen Size 15” (38 cm) visual diagonal
Viewable screen size 13.8” (35 cm)
Dot Pitch 0.28 mm (Diagonal)
Display Area Default 199 x 265 (mm) typical
Display Colors Infinite
Display Resolutions
640 x 480
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
1024 x 768
Synchronization (Horizontal) 30 to 54 KHz
Refresh Rates
60 Hz
75 Hz
85 Hz
70 Hz
75 Hz
85 Hz (preferred resolution)
60 Hz (maximum resolution)
B
Synchronization (Vertical) 50 to 120 Hz
Max Pixel Clock 70 MHz Max.
Input Signal Video RGB Analog Sync. TTL Separate
Video Cable 15-pin D-sub connector
Power Input Voltage Frequency 100 to 240V AC
50 +3 to 60 +3 Hz
Inrush Current 30 amps @ 120V
60 amps @ 220V
Reference Guide www.hp.com B–1
Technical Specifications
(Continued)
Power Consumption 80 W (Max.)
Dimension (W x H x D)
Unpacked w/attached base
Weight 29 lb Max.
Operating Temperature 50
14.4 x 15.7 x 16.5 inches (maximum)
365 x 400 x 418 mm (maximum)
13 kg Max.
o
F to 95o F
o
C to 35o C
10
Storage Temperature -22o F to 140o F
o
-30
C to 60o C
Humidity 20% to 80% (non-condensing)
Altitude Up to 10,000 ft./3048 meters
TCO’99 Some models meet TCO’99
MPRII Some models meet MPRII
Plug and Play Yes
B–2 www.hp.com Reference Guide
7500/17” Series Monitor
Screen Size 17” (43 cm) visual diagonal
Viewable screen size 16” (40.6 cm)
Dot Pitch 0.28 mm (Diagonal)
Display Area Default 234 x 312 (mm) typical
Display Colors Infinite
Technical Specifications
Display Resolutions
640 x 480
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
1024 x 768
1024 x 768
1280 x 1024
Synchronization
(Horizontal)
Synchronization (Vertical) 50 to 140 Hz
Max Pixel Clock 110 MHz Max.
Input Signal Video RGB Analog Sync. TTL Separate
Video Cable 15-pin D-sub connector
Power Input Voltage
Frequency
Inrush Current 30 amps @ 120V
Power Consumption 100 W (Max.)
Refresh Rates
60 Hz
75 Hz
85 Hz
70 Hz
75 Hz
85 Hz
75 Hz
85 Hz (preferred user resolution)
60 Hz (maximum resolution)
30 to 70 KHz
100 to 240V AC
50 +
3 to 60 +3 Hz
60 amps @ 220V
Dimension (W x H x D)
Unpacked w/attached
base
Reference Guide www.hp.com B–3
16.6 x 17 x 17.5 inches (maximum)
410 x 432 x 445 mm (maximum)
Technical Specifications
Weight 38 lb Max.
17 kg Max.
Operating Temperature 50o F to 95o F
o
10
C to 35o C
Storage Temperature -22o F to 140o F
o
-30
C to 60o C
Humidity 20% to 80% (non-condensing)
Altitude Up to 10,000 ft./3048 meters
TCO’99 Some models meet TCO’99
MPRII Some models meet MPRII
Plug and Play Yes
B–4 www.hp.com Reference Guide
7550/17” Flat CRT Monitor
Screen Size 17” (43 cm) visual diagonal
Viewable screen size 16” (40.6 cm)
Anti-Glare Coating
Dot Pitch 0.25 to 0.28 mm (variable)
Display Area Default 234 x 312 (mm) typical
Display Colors Infinite
Technical Specifications
Display Resolutions
640 x 480
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
1024 x 768
1024 x 768
1280 x 1024
1600 x 1200
Synchronization (Horizontal) 30 to 86 KHz
Synchronization (Vertical) 50 to 140 Hz
Max Pixel Clock 180 MHz Max.
Input Signal Video RGB Analog Sync. TTL Separate
Video Cable 15-pin D-sub connector
Power Input Voltage
Frequency
Inrush Current 30 amps @ 120V
Power Consumption 100 W (Max.)
Refresh Rates
60 Hz
75 Hz
85 Hz
70 Hz
75 Hz
85 Hz
75 Hz
85 Hz (preferred user resolution)
75 Hz
65 Hz (maximum resolution)
100 to 240V AC
50 +
3 to 60 +3 Hz
60 amps @ 220V
Dimension (W x H x D)
Unpacked w/attached base
Reference Guide www.hp.com B–5
16.1 x 17 x 17.4 inches (maximum)
410 x 432 x 442 mm (maximum)
Technical Specifications
Weight 42 lb Max.
19 kg Max.
Operating Temperature 50o F to 95o F
o
10
C to 35o C
Storage Temperature -22o F to 140o F
o
-30
C to 60o C
Humidity 20% to 80% (non-condensing)
Altitude Up to 10,000 ft./3048 meters
TCO’99 Some models meet TCO’99
MPRII Some models meet MPRII
Plug and Play Yes
B–6 www.hp.com Reference Guide
9500/19” Series Monitor
Screen Size 19” (48 cm) visual diagonal
Viewable screen size 18” (46 cm)
Anti-Glare Coating
Dot Pitch 0.26 mm (Diagonal)
0.22 mm (Horizontal)
Display Area Default 264 x 352 (mm) typical
Display Colors Infinite
Technical Specifications
Display Resolutions
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
1024 x 768
1024 x 768
1280 x 1024
1280 x 1024
1600 x 1200
Synchronization (Horizontal) 30 to 96 KHz
Synchronization (Vertical) 50 to 160 Hz
Max Pixel Clock 210 MHz Max.
Input Signal Video RGB Analog Sync. TTL Separate
Video Cable 15-pin D-sub connector
Power Input Voltage Frequency 100 to 240V AC
Inrush Current 30 amps @ 120V
Refresh Rates
60 Hz
85 Hz
70 Hz
75 Hz
85 Hz
75 Hz
85 Hz
75 Hz
85 Hz (preferred user resolution)
75 Hz (maximum resolution)
50 +
3 to 60 +3 Hz
60 amps @ 220V
Power Consumption 130 W (Max.)
Reference Guide www.hp.com B–7
Dimension (W x H x D)
Unpacked w/attached base
Weight 44 lb Max.
Operating Temperature 50
17.9 x 18.5 x 18.7 inches (maximum)
455 x 470 x 475 mm (maximum)
20 kg Max.
o
F to 95o F
o
10
C to 35o C
Storage Temperature -22o F to 140o F
o
-30
C to 60o C
Humidity 20% to 80% (non-condensing)
Altitude Up to 10,000 ft./3048 meters
TCO’99 Some models meet TCO’99
MPRII Some models meet MPRII
Plug and Play Yes
B–8 www.hp.com Reference Guide
Agency Regulatory Notices
Federal Communications
Commission Notice
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of
the following measures:
■ Reorient or relocate the receiving antenna.
■ Increase the separation between the equipment and the
receiver.
■ Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
■ Consult the dealer or an experienced radio or television
technician for help.
C
Modifications
The FCC requires the user to be notified that any changes or
modifications made to this device that are not expressly approved
by Hewlett Packard Company may void the user's authority to
operate the equipment.
Reference Guide C–1
Agency Regulatory Notices
Cables
Connections to this device must be made with shielded cables
with metallic RFI/EMI connector hoods to maintain compliance
with FCC Rules and Regulations.
Declaration of Conformity for
Products Marked with FCC Logo,
United States Only
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
For questions regarding your product, contact:
Hewlett Packard Company
P. O. Box 692000, Mail Stop 530113
Houston, Texas 77269-2000
Or, call1
1-800- 652-6672
For questions regarding this FCC declaration, contact:
Hewlett Packard Company
P. O. Box 692000, Mail Stop 510101
Houston, Texas 77269-2000
Or, call
(281) 514-3333
To identify this product, refer to the Part, Series, or Model
number found on the product.
C–2 Reference Guide
Canadian Notice
This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Avis Canadien
Cet appareil numérique de la classe B respecte toutes les
exigences du Règlement sur le matériel brouilleur du Canada.
European Notice
Products with the CE Marking comply with both the EMC
Directive (89/336/EEC) and the Low Voltage Directive
(73/23/EEC) issued by the Commission of the European
Community.
Compliance with these directives implies conformity to the
following European Norms (in brackets are the equivalent
international standards):
■ EN55022 (CISPR 22) - Electromagnetic Interference
Agency Regulatory Notices
■ EN55024 (IEC61000-4-2,3,4,5,6,8,11) - Electromagnetic
Immunity
■ EN61000-3-2 (IEC61000-3-2) – Power Line Harmonics
■ EN61000-3-3 (IEC61000-3-3) – Power Line Flicker
■ EN60950 (IEC950) - Product Safety
Japanese Notice
Reference Guide C–3
Agency Regulatory Notices
Korean Notice
EPA Energy Star Compliance
Monitors that are marked with the Energy Star Logo meet the
requirements of the EPA Energy Star program. As an Energy Star
Partner, Hewlett Packard Company has determined that this
product meets the Energy Star guidelines for energy efficiency.
Specific details on using the Energy Saving features can be found
in the energy saver or power management section of the computer
manual.
Power Cord Set Requirements
The monitor power supply is provided with Automatic Line
Switching (ALS). This feature allows the monitor to operate on
input voltages between 100-120V or 200-240V.
The power cord set (flexible cord or wall plug) received with the
monitor meets the requirements for use in the country where you
purchased the equipment.
If you need to obtain a power cord for a different country, you
should purchase a power cord that is approved for use in that
country.
The power cord must be rated for the product and for the voltage
and current marked on the product's electrical ratings label. The
voltage and current rating of the cord should be greater than the
voltage and current rating marked on the product. In addition, the
cross-sectional area of the wire must be a minimum of 0.75 mm²
C–4 Reference Guide
Agency Regulatory Notices
or 18AWG, and the length of the cord must be between 6 feet
(1.8 m) and 12 feet (3.6 m). If you have questions about the type
of power cord to use, contact your HP authorized service
provider.
A power cord should be routed so that it is not likely to be walked
on or pinched by items placed upon it or against it. Particular
attention should be paid to the plug, electrical outlet, and the
point where the cord exits from the product.
Reference Guide C–5
D
TCO‘99 Requirements
You have just purchased a TCO'99 approved and labelled
product. Your choice has provided you with a product developed
for professional use. Your purchase has also contributed to
reducing the burden on the environment and also to the further
development of environmentally adapted electronics products.
Why do we have environmentally labelled computers?
In many countries, environmental labelling has become an
established method for encouraging the adaptation of goods and
services to the environment. The main problem, as far as
computers and other electronics equipment are concerned, is that
environmentally harmful substances are used both in the products
and during their manufacture. Since it is not so far possible to
satisfactorily recycle the majority of electronics equipment, most
of these potentially damaging substances sooner or later enter
nature.
Reference Guide D–1
TCO‘99 Requirements
There are also other characteristics of a computer, such as energy
consumption levels, that are important from the viewpoints of
both the work (internal) and natural (external) environments.
Since all methods of electricity generation have a negative effect
on the environment (for example, acidic and climate-influencing
emissions, radioactive waste), it is vital to save energy.
Electronics equipment in offices is often left running
continuously and thereby consumes a lot of energy.
What does labelling involve?
This product meets the requirements for the TCO'99 scheme
which provides for international and environmental labelling of
personal computers. The labelling scheme was developed as a
joint effort by the TCO (The Swedish Confederation of
Professional Employees), Svenska Naturskyddsforeningen (The
Swedish Society for Nature Conservation) and Statens
Energimyndighet (The Swedish National Energy
Administration).
Approval requirements cover a wide range of issues:
environment, ergonomics, usability, emission of electric and
magnetic fields, energy consumption and electrical and fire
safety.
The environmental demands impose restrictions on the presence
and use of heavy metals, brominated and chlorinated flame
retardants, CFCs (freons) and chlorinated solvents, among other
things. The product must be prepared for recycling and the
manufacturer is obligated to have an environmental policy which
must be adhered to in each country where the company
implements its operational policy.
The energy requirements include a demand that the computer
and/or display, after a certain period of inactivity, shall reduce its
power consumption to a lower level in one or more stages. The
length of time to reactivate the computer shall be reasonable for
the user.
D–2 Reference Guide
Labelled products must meet strict environmental demands, for
example, in respect of the reduction of electric and magnetic
fields, physical and visual ergonomics and good usability.
Below you will find a brief summary of the environmental
requirements met by this product. The complete environmental
criteria document may be ordered from:
TCO Development
SE-114 94 Stockholm, Sweden
Fax: +46 8 782 92 07
Email (Internet): development@tco.se
Current information regarding TCO'99 approved and labelled
products may also be obtained via the Internet, using the address:
http://www.tco-info.com
Environmental Requirements
Flame Retardants
TCO‘99 Requirements
Flame retardants are present in printed circuit boards, cables,
wires, casings and housings. Their purpose is to prevent, or at
least to delay the spread of fire. Up to 30% of the plastic in a
computer casing can consist of flame retardant substances. Most
flame retardants contain bromine or chloride, and those flame
retardants are chemically related to another group of
environmental toxins, PCBs. Both the flame retardants containing
bromine or chloride and the PCBs are suspected of giving rise to
severe health effects, including reproductive damage in
fish-eating birds and mammals, due to the bioaccumulative
processes. Flame retardants have been found in human blood and
researchers fear that disturbances in foetus development may
occur.
Reference Guide D–3
TCO‘99 Requirements
The relevant TCO'99 demand requires that plastic components
weighing more than 25 grams must not contain flame retardants
with organically bound bromine or chlorine. Flame retardants are
allowed in the printed circuit boards since no substitutes are
available.
Bioaccumulative is defined as substances which accumulate
✎
within living organisms.
Cadmium
Cadmium is present in rechargeable batteries and in the
color-generating layers of certain computer displays. Cadmium
damages the nervous system and is toxic in high doses. The
relevant TCO'99 requirement states that batteries, the
color-generating layers of display screens and the electrical or
electronics components must not contain any cadmium.
Cadmium is a heavy metal that is Bioaccumulative.
✎
Mercury
Mercury is sometimes found in batteries, relays and switches. It
damages the nervous system and is toxic in high doses. The
relevant TCO'99 requirement states that batteries may not contain
any mercury. It also demands that mercury is not present in any of
the electrical or electronics components associated with the
labelled unit. There is however one exception. Mercury is, for the
time being, permitted in the back light system of flat panel
monitors as there today is no commercially available alternative.
TCO aims on removing this exception when a mercury free
alternative is available.
D–4 Reference Guide
Mercury is a heavy metal that is Bioaccumulative.
✎
CFCs (Freons)
The relevant TCO'99 requirement states that neither CFCs nor
HCFCs may be used during the manufacture and assembly of the
product. CFCs (freons) are sometimes used for washing printed
circuit boards. CFCs break down ozone and thereby damage the
ozone layer in the stratosphere, causing increased reception on
earth of ultraviolet light with e.g. increased risks of skin cancer
(malignant melanoma) as a consequence.
Lead
Lead can be found in picture tubes, display screens, solders and
capacitors. Lead damages the nervous system and in higher
doses, causes lead poisoning. The relevant TCO´99 requirement
permits the inclusion of lead since no replacement has yet been
developed.
Lead is a heavy metal that is Bioaccumulative.
✎
Reference Guide D–5
