HP 6200 User Manual

HP Compaq Business PC Hardware Reference Guide

8200 Elite Series Convertible Minitower 8200 Elite Series Microtower 8200 Elite Series Small Form Factor 8200 Elite Series Ultra-Slim Desktop 6200 Pro Series Microtower 6200 Pro Series Small Form Factor

Microsoft, Windows, and Windows Vista are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

This document contains proprietary information that is protected by copyright. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of Hewlett-Packard Company.

HP Compaq Business PC Hardware Reference Guide

8200 Elite Series Convertible Minitower

8200 Elite Series Microtower

8200 Elite Series Small Form Factor

8200 Elite Series Ultra-Slim Desktop

6200 Pro Series Microtower

6200 Pro Series Small Form Factor

First Edition (December 2010)

Document part number: 636509-001

About This Book

This guide provides basic information for upgrading HP Compaq Business PCs.

WARNING! Text set off in this manner indicates that failure to follow directions could result in bodily

harm or loss of life.

CAUTION: Text set off in this manner indicates that failure to follow directions could result in

damage to equipment or loss of information.

NOTE: Text set off in this manner provides important supplemental information.

ENWW iii

iv About This Book ENWW

Table of contents

1 Product Features ............................................................................................................................................ 1

Standard Configuration Features ......................................................................................................... 1

Convertible Minitower (CMT) Front Panel Components ....................................................................... 3

Microtower (MT) Front Panel Components .......................................................................................... 4

Small Form Factor (SFF) Front Panel Components ............................................................................. 5

Ultra-Slim Desktop (USDT) Front Panel Components ......................................................................... 6

Convertible Minitower (CMT) Rear Panel Components ....................................................................... 7

Microtower (MT) Rear Panel Components ........................................................................................... 8

Small Form Factor (SFF) Rear Panel Components ............................................................................. 9

Ultra-Slim Desktop (USDT) Rear Panel Components ........................................................................ 10

Media Card Reader Components ....................................................................................................... 11

Keyboard ............................................................................................................................................ 12

Using the Windows Logo Key ............................................................................................ 13

Serial Number Location ...................................................................................................................... 14

2 Convertible Minitower (CMT) Hardware Upgrades .................................................................................... 17

Serviceability Features ....................................................................................................................... 17

Warnings and Cautions ...................................................................................................................... 17

Removing the Computer Access Panel .............................................................................................. 18

Replacing the Computer Access Panel .............................................................................................. 19

Removing the Front Bezel .................................................................................................................. 20

Removing Bezel Blanks ..................................................................................................................... 21

Replacing the Front Bezel .................................................................................................................. 22

System Board Connections ................................................................................................................ 23

Installing Additional Memory .............................................................................................................. 24

DIMMs ............................................................................................................................... 24

DDR3-SDRAM DIMMs ...................................................................................................... 24

Populating DIMM Sockets ................................................................................................. 25

Installing DIMMs ................................................................................................................ 26

Removing or Installing an Expansion Card ........................................................................................ 28

Drive Positions ................................................................................................................................... 32

Removing a Drive from a Drive Bay ................................................................................................... 33

ENWW v

Installing Drives .................................................................................................................................. 37

Installing a 5.25-inch Drive into a Drive Bay ...................................................................... 38

Installing a Hard Drive into an Internal Drive Bay .............................................................. 41

Changing from a Minitower to a Desktop Configuration ..................................................................... 45

Changing from a Desktop to a Minitower Configuration ..................................................................... 47

Installing a Security Lock .................................................................................................................... 50

HP/Kensington MicroSaver Security Cable Lock ............................................................... 50

Padlock .............................................................................................................................. 50

HP Business PC Security Lock .......................................................................................... 51

Front Bezel Security .......................................................................................................... 55

3 Microtower (MT) Hardware Upgrades ......................................................................................................... 57

Serviceability Features ....................................................................................................................... 57

Warnings and Cautions ...................................................................................................................... 57

Removing the Computer Access Panel .............................................................................................. 58

Replacing the Computer Access Panel .............................................................................................. 59

Removing the Front Bezel .................................................................................................................. 60

Removing Bezel Blanks ..................................................................................................................... 61

Replacing the Front Bezel .................................................................................................................. 61

System Board Connections ................................................................................................................ 62

Installing Additional Memory .............................................................................................................. 64

DIMMs ............................................................................................................................... 64

DDR3-SDRAM DIMMs ...................................................................................................... 64

Populating DIMM Sockets ................................................................................................. 65

Installing DIMMs ................................................................................................................ 65

Removing or Installing an Expansion Card ........................................................................................ 67

Drive Positions ................................................................................................................................... 71

Installing and Removing Drives .......................................................................................................... 72

Removing a 5.25-inch or 3.5-inch Drive from a Drive Bay ................................................. 74

Installing a 5.25-inch or 3.5-inch Drive into a Drive Bay .................................................... 76

Removing a Hard Drive from a Drive Bay .......................................................................... 79

Installing a Hard Drive into an Internal Drive Bay .............................................................. 80

Installing a Security Lock .................................................................................................................... 84

HP/Kensington MicroSaver Security Cable Lock ............................................................... 84

Padlock .............................................................................................................................. 84

HP Business PC Security Lock .......................................................................................... 85

Front Bezel Security .......................................................................................................... 89

4 Small Form Factor (SFF) Hardware Upgrades ........................................................................................... 91

Serviceability Features ....................................................................................................................... 91

Warnings and Cautions ...................................................................................................................... 91

vi ENWW

Removing the Computer Access Panel .............................................................................................. 92

Replacing the Computer Access Panel .............................................................................................. 93

Removing the Front Bezel .................................................................................................................. 94

Removing Bezel Blanks ..................................................................................................................... 95

Replacing the Front Bezel .................................................................................................................. 95

Changing from Desktop to Tower Configuration ................................................................................ 96

System Board Connections ................................................................................................................ 97

Installing Additional Memory .............................................................................................................. 99

DIMMs ............................................................................................................................... 99

DDR3-SDRAM DIMMs ...................................................................................................... 99

Populating DIMM Sockets ............................................................................................... 100

Installing DIMMs .............................................................................................................. 100

Removing or Installing an Expansion Card ...................................................................................... 103

Drive Positions ................................................................................................................................. 107

Installing and Removing Drives ........................................................................................................ 108

Removing a 5.25-inch Drive from a Drive Bay ................................................................. 110

Installing a 5.25-inch Drive into a Drive Bay .................................................................... 112

Removing a 3.5-inch Drive from a Drive Bay ................................................................... 115

Installing a 3.5-inch Drive into a Drive Bay ...................................................................... 117

Removing and Replacing the Primary 3.5-inch Internal Hard Drive ................................ 119

Installing a Security Lock .................................................................................................................. 123

HP/Kensington MicroSaver Security Cable Lock ............................................................. 123

Padlock ............................................................................................................................ 123

HP Business PC Security Lock ........................................................................................ 124

Front Bezel Security ........................................................................................................ 128

5 Ultra-Slim Desktop (USDT) Hardware Upgrades ...................................................................................... 130

Serviceability Features ..................................................................................................................... 130

Warnings and Cautions .................................................................................................................... 130

Connecting the Power Cord ............................................................................................................. 131

Removing the Computer Access Panel ............................................................................................ 132

Replacing the Computer Access Panel ............................................................................................ 133

Removing the Front Bezel ................................................................................................................ 134

Removing a Bezel Blank .................................................................................................................. 135

Replacing the Front Bezel ................................................................................................................ 135

Changing from Desktop to Tower Configuration .............................................................................. 136

System Board Connections .............................................................................................................. 137

Installing Additional Memory ............................................................................................................ 138

SODIMMs ........................................................................................................................ 138

DDR3-SDRAM SODIMMs ............................................................................................... 138

Populating SODIMM Sockets .......................................................................................... 139

ENWW vii

Installing SODIMMs ......................................................................................................... 140

Replacing the Optical Drive .............................................................................................................. 142

Removing the Optical Drive ............................................................................................. 142

Preparing the New Optical Drive ..................................................................................... 143

Installing the New Optical Drive ....................................................................................... 144

Replacing the Hard Drive ................................................................................................................. 145

Installing and Removing a Port Cover .............................................................................................. 149

Installing a Security Lock .................................................................................................................. 150

HP/Kensington MicroSaver Security Cable Lock ............................................................. 150

Padlock ............................................................................................................................ 151

HP Business PC Security Lock ........................................................................................ 151

Front Bezel Security ........................................................................................................ 155

Appendix A Battery Replacement ................................................................................................................ 157

Appendix B Removing and Replacing a Removable 3.5-inch SATA Hard Drive ..................................... 160

Appendix C Unlocking the Smart Cover Lock ............................................................................................ 165

Smart Cover FailSafe Key ................................................................................................................ 165

Using the Smart Cover FailSafe Key to Remove the Smart Cover Lock ......................................... 166

Appendix D Electrostatic Discharge ............................................................................................................ 168

Preventing Electrostatic Damage ..................................................................................................... 168

Grounding Methods .......................................................................................................................... 168

Appendix E Computer Operating Guidelines, Routine Care and Shipping Preparation ......................... 169

Computer Operating Guidelines and Routine Care .......................................................................... 169

Optical Drive Precautions ................................................................................................................. 170

Operation ......................................................................................................................... 170

Cleaning ........................................................................................................................... 170

Safety ............................................................................................................................... 170

Shipping Preparation ........................................................................................................................ 170

Index ................................................................................................................................................................. 171

viii ENWW

1 Product Features

Standard Configuration Features

Features may vary depending on the model. For a complete listing of the hardware and software installed in the computer, run the diagnostic utility (included on some computer models only).

Figure 1-1 Convertible Minitower Configuration

NOTE: The HP Compaq Convertible Minitower computer can be easily converted to a desktop. For

more information, see guide.

Figure 1-2 Microtower Configuration

ENWW Standard Configuration Features 1

Changing from a Minitower to a Desktop Configuration on page 45 in this

Figure 1-3 Small Form Factor Configuration

NOTE: The Small Form Factor computer can also be used in a tower orientation. For more

information, see

Changing from Desktop to Tower Configuration on page 96 in this guide.

Figure 1-4 Ultra-Slim Desktop Configuration

2 Chapter 1 Product Features ENWW

Convertible Minitower (CMT) Front Panel Components

Drive configuration may vary by model. Some models have a bezel blank covering one or more drive bays.

Figure 1-5 Front Panel Components

Table 1-1 Front Panel Components

1 5.25-inch Optical Drives 5 Microphone/Headphone Connector

2 5.25-inch Media Card Reader (optional) 6 Power On Light

3 Dual-State Power Button 7 Headphone Connector

4 Hard Drive Activity Light 8 USB (Universal Serial Bus) Ports

CAUTION: The bottom 5.25-inch drive bay has a shorter depth than the upper two bays. The bottom bay

supports a half-height drive or other device that is no more than 14.5 cm (5.7 inches) in depth. Do not try to force a larger drive, such as an optical drive, into the bottom bay. This could cause damage to the drive and the system board. The use of unnecessary force when installing any drive into the drive bay may result in damage to the drive.

NOTE: When a device is plugged into the Microphone/Headphone Connector, a dialog box will pop up asking if

you want to use the connector for a microphone Line-In device or a headphone. You can reconfigure the connector at any time by double-clicking the Realtek HD Audio Manager icon in the Windows taskbar.

NOTE: The Power On Light is normally green when the power is on. If it is flashing red, there is a problem with

the computer and it is displaying a diagnostic code. Refer to the Maintenance and Service Guide to interpret the code.

ENWW Convertible Minitower (CMT) Front Panel Components 3

Microtower (MT) Front Panel Components

Drive configuration may vary by model. Some models have a bezel blank covering one or more drive bays.

Table 1-2 Front Panel Components

1 5.25-inch Optical Drives 5 3.5-inch Media Card Reader (optional)

2 Hard Drive Activity Light 6 Dual-State Power Button

3 Microphone/Headphone Connector 7 Power On Light

4 USB (Universal Serial Bus) 2.0 Ports 8 Headphone Connector

NOTE: When a device is plugged into the Microphone/Headphone Connector, a dialog box will pop up asking if

NOTE: The Power On Light is normally green when the power is on. If it is flashing red, there is a problem with

the computer and it is displaying a diagnostic code. Refer to the Maintenance and Service Guide to interpret the code.

4 Chapter 1 Product Features ENWW

Small Form Factor (SFF) Front Panel Components

Drive configuration may vary by model. Some models have a bezel blank covering one or more drive bays.

Figure 1-6 Front Panel Components

Table 1-3 Front Panel Components

1 5.25-inch Optical Drive 5 Microphone/Headphone Connector

2 Dual-State Power Button 6 3.5-inch Media Card Reader (optional)

3 Power On Light 7 Hard Drive Activity Light

4 USB (Universal Serial Bus) Ports 8 Headphone Connector

NOTE: When a device is plugged into the Microphone/Headphone Connector, a dialog box will pop up asking if

NOTE: The Power On Light is normally green when the power is on. If it is flashing red, there is a problem with

the computer and it is displaying a diagnostic code. Refer to the Maintenance and Service Guide to interpret the code.

ENWW Small Form Factor (SFF) Front Panel Components 5

Ultra-Slim Desktop (USDT) Front Panel Components

Drive configuration may vary by model. Some models have a bezel blank covering the optical drive bay.

Figure 1-7 Front Panel Components

Table 1-4 Front Panel Components

1 Optical Drive 5 Microphone/Headphone Connector

2 Power On Light 6 USB (Universal Serial Bus) Ports

3 SD Media Card Reader (optional) 7 Hard Drive Activity Light

4 Headphone Connector 8 Dual-State Power Button

NOTE: When a device is plugged into the Microphone/Headphone Connector, a dialog box will pop up asking if

NOTE: The Power On Light is normally green when the power is on. If it is flashing red, there is a problem with

the computer and it is displaying a diagnostic code. Refer to the Maintenance and Service Guide to interpret the code.

6 Chapter 1 Product Features ENWW

Convertible Minitower (CMT) Rear Panel Components

Figure 1-8 Rear Panel Components

Table 1-5 Rear Panel Components

1 Power Cord Connector 6 Line-Out Connector for powered audio

NOTE: An optional second serial port and an optional parallel port are available from HP.

When a device is plugged into the blue Line-In Audio Connector, a dialog box will pop up asking if you want to use the connector for a line-in device or a microphone. You can reconfigure the connector at any time by doubleclicking the Realtek HD Audio Manager icon in the Windows taskbar.

The monitor connectors on the system board are inactive when a graphics card is installed in the computer.

If a graphics card is installed into one of the system board slots, the connectors on the graphics card and the system board may be used at the same time. Some settings may need to be changed in Computer Setup to use both connectors.

PS/2 Keyboard Connector (purple) 7 Line-In Audio Connector (blue)

VGA Monitor Connector 8 PS/2 Mouse Connector (green)

DisplayPort Monitor Connector 9 Serial Connector

Universal Serial Bus (USB) ports 10 RJ-45 Network Connector

devices (green)

ENWW Convertible Minitower (CMT) Rear Panel Components 7

Microtower (MT) Rear Panel Components

Figure 1-9 Rear Panel Components

Table 1-6 Rear Panel Components

1 Power Cord Connector 6 Line-Out Connector for powered audio

NOTE: An optional second serial port and an optional parallel port are available from HP.

The monitor connectors on the system board are inactive when a graphics card is installed in the computer.

If a graphics card is installed into one of the motherboard slots, the connectors on the graphics card and the system board may be used at the same time. Some settings may need to be changed in Computer Setup to use both connectors.

Line-In Audio Connector (blue) 7 PS/2 Keyboard Connector (purple)

PS/2 Mouse Connector (green) 8 VGA Monitor Connector

Serial Connector 9 DisplayPort Monitor Connector

RJ-45 Network Connector 10 Universal Serial Bus (USB) ports

devices (green)

8 Chapter 1 Product Features ENWW

Small Form Factor (SFF) Rear Panel Components

Figure 1-10 Rear Panel Components

1 RJ-45 Network Connector 6 DisplayPort Monitor Connector

4 Power Cord Connector 9

NOTE: An optional second serial port and an optional parallel port are available from HP.

The monitor connectors on the system board are inactive when a graphics card is installed in the computer.

Serial Connector 7 VGA Monitor Connector

PS/2 Mouse Connector (green) 8 PS/2 Keyboard Connector (purple)

Line-Out Connector for powered audio devices (green)

Universal Serial Bus (USB) ports 10 Line-In Audio Connector (blue)

ENWW Small Form Factor (SFF) Rear Panel Components 9

Ultra-Slim Desktop (USDT) Rear Panel Components

Figure 1-11 Rear Panel Components

Table 1-7 Rear Panel Components

1 Line-Out Connector for powered audio

NOTE: On some models the optional TV tuner is replaced by an optional wireless antenna. On other models,

there are no optional components in this location.

devices (green)

PS/2 Keyboard Connector (purple) 7 TV Tuner (optional)

Universal Serial Bus (USB) ports 8 Line-In Audio Connector (blue)

DisplayPort Monitor Connector 9 PS/2 Mouse Connector (green)

VGA Monitor Connector 10 RJ-45 Network Connector

6 Power Cord Connector

10 Chapter 1 Product Features ENWW

Media Card Reader Components

The media card reader is an optional device available on some models only. Refer to the following illustration and table to identify the media card reader components.

Figure 1-12 Media Card Reader Components

Table 1-8 Media Card Reader Components

No. Slot Media

1 xD ● xD-Picture Card (xD)

2 MicroSD ● MicroSD (T-Flash) ● MicroSDHC

3 Media Card Reader

Activity Light

4 SD/MMC+/miniSD

5 USB ● USB (Universal Serial

6 CompactFlash I/II ● CompactFlash Card

7 MS PRO/MS PRO DUO ● Memory Stick (MS)

Secure Digital (SD)

●

● Secure Digital High

Capacity (SDHC)

MiniSD

●

Bus) Port

Type 1

MagicGate Memory

●

Stick (MG)

MagicGate Memory

●

Duo

MiniSDHC

●

● MultiMediaCard

(MMC)

Reduced Size

●

MultiMediaCard (RS MMC)

● CompactFlash Card

Type 2

● Memory Stick Select

Memory Stick Duo

●

(MS Duo)

Memory Stick PRO

●

(MS PRO)

MultiMediaCard 4.0

●

(MMC Plus)

● Reduced Size

MultiMediaCard 4.0 (MMC Mobile)

● MMC Micro (adapter

required)

● MicroDrive

● Memory Stick PRO

Duo (MS PRO Duo)

● Memory Stick PRO-

HG Duo

Memory Stick Micro

●

(M2) (adapter required)

ENWW Media Card Reader Components 11

Keyboard

Figure 1-13 Keyboard Components

Table 1-9 Keyboard Components

1 Function Keys Perform special functions depending on the software application being used.

2 Editing Keys Includes the following: Insert, Home, Page Up, Delete, End, and Page Down.

3 Status Lights Indicate the status of the computer and keyboard settings (Num Lock, Caps

Lock, and Scroll Lock).

4 Numeric Keys Work like a calculator keypad.

5 Arrow Keys Used to navigate through a document or Web site. These keys allow you to

6 Ctrl Keys Used in combination with another key; their effect depends on the application

Application Key

Windows Logo Keys

9 Alt Keys Used in combination with another key; their effect depends on the application

Keys available in select geographic regions.

move left, right, up, and down, using the keyboard instead of the mouse.

software you are using.

Used (like the right mouse button) to open pop-up menus in a Microsoft Office application. May perform other functions in other software applications.

Used to open the Start menu in Microsoft Windows. Used in combination with other keys to perform other functions.

software you are using.

12 Chapter 1 Product Features ENWW

Using the Windows Logo Key

Use the Windows Logo key in combination with other keys to perform certain functions available in the Windows operating system. Refer to

Table 1-10 Windows Logo Key Functions

The following Windows Logo Key functions are available in Microsoft Windows XP, Microsoft Windows Vista, and Microsoft Windows 7.

Windows Logo Key Displays or hides the Start menu

Windows Logo Key + d Displays the Desktop

Windows Logo Key + m Minimizes all open applications

Shift + Windows Logo Key + m Undoes Minimize All

Windows Logo Key + e Launches My Computer

Windows Logo Key + f Launches Find Document

Windows Logo Key + Ctrl + f Launches Find Computer

Windows Logo Key + F1 Launches Windows Help

Windows Logo Key + l Locks the computer if you are connected to a network domain,

Keyboard on page 12 to identify the Windows Logo key.

or allows you to switch users if you are not connected to a network domain

Windows Logo Key + r Launches the Run dialog box

Windows Logo Key + u Launches the Utility Manager

Windows Logo Key + Tab Windows XP - Cycles through the Taskbar buttons

Windows Vista and Windows 7 - Cycles through programs on the Taskbar using the Windows Flip 3-D

In addition to the Windows Logo Key functions described above, the following functions are also available in Microsoft Windows Vista and Windows 7.

Ctrl + Windows Logo Key + Tab Use the arrow keys to cycle through programs on the Taskbar

by using Windows Flip 3-D

Windows Logo Key + Spacebar Brings all gadgets to the front and select Windows Sidebar

Windows Logo Key + g Cycles through Sidebar gadgets

Windows Logo Key + t Cycles through programs on the taskbar

Windows Logo Key + u Launches Ease of Access Center

Windows Logo Key + any number key Launches the Quick Launch shortcut that is in the position that

In addition to the Windows Logo Key functions described above, the following functions are also available in Microsoft Windows 7.

Windows Logo Key + Ctrl + b Switches to the program that displayed a message in the

corresponds to the number (for example, Windows Logo Key + 1 launches the first shortcut in the Quick Launch menu)

notification area

Windows Logo Key + p Choose a presentation display mode

Windows Logo Key + up arrow Maximizes the window

Windows Logo Key + left arrow Snaps the window to the left side of the screen

ENWW Keyboard 13

Table 1-10 Windows Logo Key Functions (continued)

Windows Logo Key + right arrow Snaps the window to the right side of the screen

Windows Logo Key + down arrow Minimizes the window

Windows Logo Key + Shift + up arrow Stretches the window to the top and bottom of the screen

Windows Logo Key + Shift + left arrow or right

arrow

Windows Logo Key + + (on numpad) Zooms in

Windows Logo Key + - (on numpad) Zooms out

Serial Number Location

Each computer has a unique serial number and a product ID number that are located on the top cover of the computer. Keep these numbers available for use when contacting customer service for assistance.

Figure 1-14 Convertible Minitower Serial Number and Product ID Location

Moves a window from one monitor to another

14 Chapter 1 Product Features ENWW

Figure 1-15 Microtower Serial Number and Product ID Location

Figure 1-16 Small Form Factor Serial Number and Product ID Location

ENWW Serial Number Location 15

Figure 1-17 Ultra-Slim Desktop (USDT) Serial Number and Product ID Location

16 Chapter 1 Product Features ENWW

2 Convertible Minitower (CMT) Hardware

Upgrades

Serviceability Features

The computer includes features that make it easy to upgrade and service. No tools are needed for most of the installation procedures described in this chapter.

Warnings and Cautions

Before performing upgrades be sure to carefully read all of the applicable instructions, cautions, and warnings in this guide.

WARNING! To reduce the risk of personal injury from electrical shock, hot surfaces, or fire:

Disconnect the power cord from the wall outlet and allow the internal system components to cool before touching.

Do not plug telecommunications or telephone connectors into the network interface controller (NIC) receptacles.

Do not disable the power cord grounding plug. The grounding plug is an important safety feature.

Plug the power cord in a grounded (earthed) outlet that is easily accessible at all times.

To reduce the risk of serious injury, read the Safety & Comfort Guide. It describes proper workstation, setup, posture, and health and work habits for computer users, and provides important electrical and mechanical safety information. This guide is located on the Web at

WARNING! Energized and moving parts inside.

Disconnect power to the equipment before removing the enclosure.

Replace and secure the enclosure before re-energizing the equipment.

CAUTION: Static electricity can damage the electrical components of the computer or optional

equipment. Before beginning these procedures, ensure that you are discharged of static electricity by briefly touching a grounded metal object. See information.

When the computer is plugged into an AC power source, voltage is always applied to the system board. You must disconnect the power cord from the power source before opening the computer to prevent damage to internal components.

Electrostatic Discharge on page 168 for more

http://www.hp.com/ergo.

ENWW Serviceability Features 17

Removing the Computer Access Panel

To access internal components, you must remove the access panel:

1. Remove/disengage any security devices that prohibit opening the computer.

2. Remove all removable media, such as compact discs or USB flash drives, from the computer.

3. Turn off the computer properly through the operating system, then turn off any external devices.

4. Disconnect the power cord from the power outlet and disconnect any external devices.

CAUTION: Regardless of the power-on state, voltage is always present on the system board

as long as the system is plugged into an active AC outlet. You must disconnect the power cord to avoid damage to the internal components of the computer.

5. Lift up on the access panel handle (1) then lift the access panel off the computer (2).

Figure 2-1 Removing the Computer Access Panel

18 Chapter 2 Convertible Minitower (CMT) Hardware Upgrades ENWW

Replacing the Computer Access Panel

Slide the lip on the front end of the access panel under the lip on the front of the chassis (1) then press the back end of the access panel onto the unit so that it locks into place (2).

Figure 2-2 Replacing the Computer Access Panel

ENWW Replacing the Computer Access Panel 19

Removing the Front Bezel

1. Remove/disengage any security devices that prohibit opening the computer.

2. Remove all removable media, such as compact discs or USB flash drives, from the computer.

3. Turn off the computer properly through the operating system, then turn off any external devices.

4. Disconnect the power cord from the power outlet and disconnect any external devices.

CAUTION: Regardless of the power-on state, voltage is always present on the system board

as long as the system is plugged into an active AC outlet. You must disconnect the power cord to avoid damage to the internal components of the computer.

5. Remove the computer access panel.

6. Lift up the three tabs on the side of the bezel (1), then rotate the bezel off the chassis (2).

Figure 2-3 Removing the Front Bezel

20 Chapter 2 Convertible Minitower (CMT) Hardware Upgrades ENWW

Removing Bezel Blanks

On some models, there are bezel blanks covering the 5.25-inch drive bays that need to be removed before installing a drive. To remove a bezel blank:

1. Remove the access panel and front bezel.

2. Gently pull the subpanel, with the bezel blanks secured in it, away from the front bezel, then

remove the desired bezel blank.

CAUTION: Hold the subpanel straight when you pull it away from the front bezel. Pulling the

subpanel away at an angle could damage the pins that align it within the front bezel.

Figure 2-4 Removing Bezel Blanks from the Subpanel (Desktop Shown)

NOTE: When replacing the subpanel, ensure that the aligning pins and any remaining bezel blanks

are in their proper orientation. The logo on the subpanel should be located at the bottom of the subpanel when properly oriented.

ENWW Removing Bezel Blanks 21

Replacing the Front Bezel

Insert the three hooks on the bottom side of the bezel into the rectangular holes on the chassis (1) then rotate the top side of the bezel onto the chassis (2) and snap it into place.

Figure 2-5 Replacing the Front Bezel

22 Chapter 2 Convertible Minitower (CMT) Hardware Upgrades ENWW

+ 151 hidden pages
