HP 3070 B611 User Manual

HP Deskjet 3070 B611 All-in-One series

1 How Do I?............................................................................................................................................................................3

2 Get to know the HP All-in-One

Printer parts..........................................................................................................................................................................5

Control panel features..........................................................................................................................................................6

Wireless Settings..................................................................................................................................................................6

Status Lights.........................................................................................................................................................................7

Auto Power-Off ....................................................................................................................................................................8

3Print

Print photos..........................................................................................................................................................................9

Print documents.................................................................................................................................................................10

Print Quick Forms...............................................................................................................................................................10

Print envelopes...................................................................................................................................................................11

Tips for print success..........................................................................................................................................................11

4 ePrint from anywhere

ePrint from anywhere.........................................................................................................................................................15

5 Paper basics

Recommended papers for printing.....................................................................................................................................17

Load media.........................................................................................................................................................................18

6 Copy and scan

Copy...................................................................................................................................................................................23

Scan to a computer............................................................................................................................................................24

Tips for copy success.........................................................................................................................................................26

Tips for scan success.........................................................................................................................................................26

Contents

7 Work with cartridges

Check the estimated ink levels...........................................................................................................................................29

Order ink supplies..............................................................................................................................................................29

Replace the cartridges.......................................................................................................................................................30

Cartridge warranty information...........................................................................................................................................32

8 Connectivity

WiFi Protected Setup (WPS – requires WPS router).........................................................................................................33

Traditional wireless connection (requires router)...............................................................................................................33

USB Connection (non-network connection).......................................................................................................................34

Change from a USB connection to a wireless network......................................................................................................34

Connect a new printer........................................................................................................................................................34

Change network settings....................................................................................................................................................35

Tips for setting up and using a networked printer..............................................................................................................35

Advanced printer management tools (for networked printers)...........................................................................................35

9 Solve a problem

Improve print quality...........................................................................................................................................................37

Clear a paper jam...............................................................................................................................................................38

Unable to print....................................................................................................................................................................39

Networking..........................................................................................................................................................................45

HP support..........................................................................................................................................................................45

10 Technical information

Notice.................................................................................................................................................................................47

Cartridge chip information..................................................................................................................................................47

Specifications.....................................................................................................................................................................48

Environmental product stewardship program.....................................................................................................................50

Regulatory notices..............................................................................................................................................................53

Index........................................................................................................................................................................................57

Contents

1 How Do I?

Learn how to use your HP All-in-One

• Printer parts on page 5

• Load media on page 18

• Replace the cartridges on page 30

• Clear a paper jam on page 38

How Do I?

How Do I? 3

How Do I?

Chapter 1

4 How Do I?

2 Get to know the HP All-in-One

• Printer parts Control panel features

• Wireless Settings

• Status Lights

• Auto Power-Off

•

Printer parts

• Front and top views of the HP All-in-One

1 Display

2 Control panel

3 Paper tray

4 Paper tray extender (also referred to as the tray extender)

5 Glass

6 Lid-backing

7 Lid

8 Cartridge door

9 Cartridge access area

10 Cleanout door

• Rear view of the HP All-in-One

11 Rear USB port

12 Power connection

Get to know the HP All-in-One

Get to know the HP All-in-One 5

Chapter 2

Control panel features

Get to know the HP All-in-One

1 Back: Returns to the previous screen.

2 Cancel: Stops the current operation, restores default settings.

3 Setup: Opens the Setup menu where you can check ink levels, change Auto Power-Off setting, perform maintenance tasks,

and set language and region settings.

4 Selection buttons: Use buttons to select menu items on the printer display.

5 Wireless status light and button: Blue light indicates wireless connection. Pressing button opens wireless menu. Press and

hold until light blinks to start WPS push button mode.

6 ePrint light and button: White light indicates ePrint is connected. Pressing button displays printer's email address and ePrint

menu options.

7 On button

Wireless Settings

Press the Wireless button to view wireless status and menu options.

• If the printer has an active connection to a wireless network, the printer display will show Connected and the

printer’s IP.

• If wireless is disabled (wireless radio off) and the wireless network is not available, the display screen shows

Wireless Off.

• If wireless is enabled (wireless radio on) and you do not have a wireless connection , the display screen shows

that it is either in the process of Connecting or Not Connected.

You can use the printer display to retrieve information about your wireless network, establish a wireless connection, and more.

How do I? Instructions

Print network configuration page.

The network configuration page will display the network status, hostname, network name, and more.

1. Press the Wireless button to display the

Wireless Menu.

2. From the Wireless Menu, select Print

Reports.

3. From the Print Reports menu select

Configuration.

6 Get to know the HP All-in-One

(continued)

How do I? Instructions

Print wireless network test report.

The wireless network test report will display the diagnostics results for the status of the wireless network, wireless signal strength, detected networks, and more.

View signal strength of wireless connection. 1. Press the Wireless button to display the

Restore network settings to default settings. 1. Press the Wireless button to display the

Turn wireless on or off. 1. Press the Wireless button to display the

Establish a Wi-Fi Protected Setup (WPS) connection. WiFi Protected Setup (WPS – requires WPS

1. Press the Wireless button to display the

Wireless Menu.

2. From the Wireless Menu, select Print

Reports.

3. From the Print Reports menu select Wireless

Test.

Wireless Menu.

2. From the Wireless Menu, select Connected

IP XXX.XXX.XX.XX.

3. Printer display will show wireless signal

strength.

Wireless Menu.

2. From the Wireless Menu, select Settings.

3. From the Settings menu, select Restore

Defaults.

4. Confirm selection to restore defaults.

Wireless Menu.

2. From the Wireless Menu, select Wireless

Settings.

3. From the Settings menu, select Wireless On/

Off.

4. From the Wireless On/Off menu select On or

Off.

router) on page 33

Get to know the HP All-in-One

Status Lights

• Wireless Status Light ePrint Status Light

• On Button Light

•

Wireless Status Light

Light behavior Solution

Off Wireless is off. Press Wireless button to access

Slow blinking Wireless is on but not connected to a network. If

Fast blinking Wireless error has occurred. Refer to messages on

On Wireless connection has been established and you

wireless menu on the printer display. Use wireless menu to enable wireless printing.

connection cannot be established, make sure printer is within range of wireless signal.

printer display.

can print.

Status Lights 7

Chapter 2

ePrint Status Light

Light behavior Solution

Off ePrint is disabled. Press ePrint button to access

On ePrint is on and connected.

On Button Light

Light behavior Solution

Off The device is powered off.

Get to know the HP All-in-One

Pulsing Indicates the device is in sleep mode. The device

Fast blinking Error has occurred. Refer to messages on printer

On Printer is on and ready to print.

Auto Power-Off

Auto Power-Off is automatically enabled by default when you turn on the printer. When Auto Power-Off is enabled, the printer automatically turns off after 2 hours of inactivity to help reduce energy use. Auto Power-Off is automatically disabled when the printer establishes a wireless or Ethernet (if supported) network connection. You can change the Auto Power-Off setting from the control panel. Once you change the setting, the printer maintains the setting. Auto

Power-Off turns the printer off completely, so you must use the power button to turn the printer back on.

ePrint menu on the printer display.

automatically enters sleep mode after 5 minutes of inactivity.

display.

To change Auto Power-Off setting

1. From the Control Panel home screen, which displays Copy, Scan, and Quick Forms, press the Setup button.

NOTE: If you do not see the home screen, press the Back button until you can see it.

2. From the Setup menu on the printer display, select Auto Power-Off.

3. From the Auto Power-Off menu select Enabled or Disabled, and then confirm the setting.

TIP: If you are printing over a wireless or Ethernet connected network, Auto Power-Off should be disabled to

ensure that print jobs do not get lost. Even when Auto Power-Off is disabled, the printer enters Sleep mode after 5 minutes of inactivity to help reduce energy use.

8 Get to know the HP All-in-One

3Print

Choose a print job to continue.

See Tips for print success on page 11 for more information.

Print photos on page 9

Print documents on page 10

Print envelopes on page 11

Print Quick Forms on page 10

Print photos

To print a photo on photo paper

1. Pull out the paper tray.

2. Remove all paper from the paper tray, and then load the photo paper with side to be printed on facing down.

NOTE: If the photo paper you are using has perforated tabs, load photo paper so that tabs face outward.

See Load media on page 18 for more information.

3. On the File menu in your software application, click Print.

4. Make sure the product is the selected printer.

5. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or Preferences.

6. Select the appropriate options.

•On Layout tab select Portrait or Landscape orientation.

•On Paper/Quality tab select the appropriate paper type and print quality from the Media drop-down list.

Print

Print 9

Chapter 3

NOTE: For maximum dpi resolution, go to the Paper/Quality tab and select Photo Paper, Best Quality

from the Media drop-down list. Then go to the Advanced tab and select Yes from the Print in Max DPI drop-down list. If you want to print Max DPI in grayscale, select High Quality Grayscale from Print in

Grayscale on the drop-down list, and then select Max DPI, after selecting Photo Paper, Best Quality.

7. Click OK to return to the Properties dialog box.

8. Click OK, and then click Print or OK in the Print dialog box.

NOTE: Do not leave unused photo paper in the input tray. The paper might start to curl, which could reduce

the quality of your printout. Photo paper should be flat before printing.

Print documents

To print from a software application

1. Make sure the paper tray is open.

2. Make sure you have paper loaded in the paper tray.

See Load media on page 18 for more information.

3. From your software application, click the Print button.

4. Make sure the product is the selected printer.

5. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or Preferences.

6. Select the appropriate options.

•On Layout tab select Portrait or Landscape orientation.

•On Paper/Quality tab select the appropriate paper type and print quality from the Media drop-down list.

7. Click OK to close the Properties dialog box.

8. Click Print or OK to begin printing.

NOTE: 1 You can print your document on both sides of the paper, instead of just one side. Click on the

Advanced button on the Paper/Quality or Layout tab. From the Pages to Print drop-down menu select Print Odd Pages Only. Click OK to print. After the odd numbered pages of the document have been printed, remove

the document from the output tray. Reload the paper in the input tray with the blank side facing up. Return to the Pages to Print drop-down menu and then select Print Even Pages Only. Click OK to print.

NOTE: 2 If your printed documents are not aligned within the margins of the paper, make sure that you have

selected the correct language and region. On the printer display, select Setup, then select Language/Region. Select your language, and then region from the options provided. The correct Language/Region settings ensure that the printer will have the appropriate default paper size settings.

Print Quick Forms

10 Print

Use Quick Forms to print Office Forms, Paper Types, and Games.

Print Quick Forms

1. Select Quick Forms from the printer display menu.

TIP: If the Quick Forms option does not appear on the printer display menu, press the Back button until

the Quick Forms option appears.

2. Press the selction buttons to select Office Forms, Paper Type, or Games. Then select OK.

3. After you have selected the type of Selection that you want to print, select the number of copies, then press

OK.

Print envelopes

You can load one or more envelopes into the input tray of the HP All-in-One. Do not use shiny or embossed envelopes or envelopes that have clasps or windows.

NOTE: For specific details on how to format text for printing on envelopes, consult the help files in your word

processing software. For best results, consider using a label for the return address on envelopes.

To print envelopes

1. Make sure the paper tray is open.

2. Slide the paper guides outward.

3. Place the envelopes in the center of the tray. The side to be printed on should face down. The flap should be

on the left side. See Load media on page 18 for more information.

4. Push the envelopes into the printer until they stop.

5. Slide the paper guides firmly against the edges of the envelopes.

6. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or Preferences.

7. Select the appropriate options.

•On Paper/Quality tab select the appropriate paper type and print quality from the Media drop-down list.

8. Click OK, and then click Print or OK in the Print dialog box.

Tips for print success

To successfully print, the HP cartridges should be functioning properly with sufficient ink, the paper should be loaded correctly, and the product should have the appropriate settings.

Ink tips

• Use genuine HP ink cartridges.

• Install the yellow, magenta, cyan, and black cartridges correctly.

For more information, see Replace the cartridges on page 30.

• Check the estimated ink levels in the cartridges to make sure there is sufficient ink.

For more information, see Check the estimated ink levels on page 29.

Tips for print success 11

Chapter 3

• For more information, see Improve print quality on page 37.

• If you are seeing ink smears on the back of the pages that you printed, use the Tools menu to clean.

◦ From the home screen, which displays Copy, Scan, and Quick Forms, press the Setup button.

NOTE: If you do not see the home screen, press the Back button until you can see it.

◦ Scroll through the Tools menu until you see Clean Ink Smear, then select OK. ◦ Follow the onscreen instructions.

Paper loading tips

• Load a stack of paper (not just one page). All of the paper in the stack should be the same size and type to avoid

a paper jam.

• Load paper with side to be printed on facing down.

• Ensure that paper loaded in the paper tray lays flat and the edges are not bent or torn.

• Adjust the paper-width guides in the paper tray to fit snugly against all paper. Make sure the paper-width guide

does not bend the paper in the paper tray.

• For more information, see Load media on page 18.

Printer settings tips

• On the Paper/Quality tab of the print driver, select the appropriate paper type and print quality from the

Media drop-down list.

• Select the appropriate size from the Paper Size drop-down list on the Paper/Quality tab.

• Click the HP All-in-One desktop icon to open the Printer Software. In the Printer Software, click Printer

Actions and then click Set Preferences to access the print driver.

NOTE: You can also access the Printer Software by clicking Start > Programs > HP > HP Deskjet 3070

B611 series > HP Deskjet 3070 B611 series

Notes

• Genuine HP ink cartridges are designed and tested with HP printers and papers to help you easily produce great

results, time after time.

NOTE: HP cannot guarantee the quality or reliability of non-HP supplies. Product service or repairs required

as a result of using a non-HP supply will not be covered under warranty.

If you believe you purchased genuine HP ink cartridges, go to:

www.hp.com/go/anticounterfeit

• Ink level warnings and indicators provide estimates for planning purposes only.

NOTE: When you receive a low-ink warning message, consider having a replacement cartridge available

to avoid possible printing delays. You do not need to replace the cartridges until print quality becomes unacceptable.

• Software settings selected in the print driver only apply to printing, they do not apply to copying or scanning.

• You can print your document on both sides of the paper, instead of just one side.

NOTE: Click the Advanced button on the Paper/Quality or Layout tab. From the Pages to Print drop-

down list select Print Odd Pages Only. Click OK to print. After the odd numbered pages of the document have been printed, remove the document from the output tray. Reload the paper in the input tray with the blank side facing up. Return to the Pages to Print drop-down list and then select Print Even Pages Only. Click OK to print.

12 Print

• Print using black ink only

NOTE: If you want to print a black and white document using black ink only, click the Advanced button.

From the Print in Grayscale drop-down menu select Black Ink Only, then click the OK button.

Print using the maximum dpi

Use maximum dots per inch (dpi) mode to print high-quality, sharp images on photo paper.

See technical specifications for the print resolution of the maximum dpi mode.

Printing in maximum dpi takes longer than printing with other settings and requires a large amount of disk space.

To print in Maximum dpi mode

1. Make sure you have photo paper loaded in the input tray.

2. On the File menu in your software application, click Print.

3. Make sure the product is the selected printer.

4. Click the button that opens the Properties dialog box.

Depending on your software application, this button might be called Properties, Options, Printer Setup, Printer, or Preferences.

5. Click the Paper/Quality tab.

6. In the Media drop-down list, click Photo Paper, Best Quality.

NOTE: Photo Paper, Best Quality must be selected from the Media drop-down list on the Paper/

Quality tab to enable printing in maximum DPI.

7. Click the Advanced button.

8. In the Printer Features area, select Yes from the Print in Max DPI drop-down list.

9. Select Paper Size from Paper/Output drop-down list.

10. Click OK to close the advanced options.

11. Confirm Orientation on Layout tab, then click OK to print.

Print using the maximum dpi 13

Chapter 3

14 Print

4ePrint from anywhere

The ePrint feature on your product provides convenience printing that allows you to print from anywhere. Once enabled, ePrint assigns an email address to your product. To print, simply send an email containing your document to that address. You can print images, Word, PowerPoint, and PDF documents. It's easy!

ePrint from anywhere

•

ePrint from anywhere

To ePrint a document from anywhere

1. Find your ePrint email address.

a. Press the ePrint button on the control panel. You will see the web services Settings menu on the printer

display.

b. Select Display Email Address from the printer display to view the printer’s email address.

NOTE: To use ePrint, web services must first be enabled. If web services have not been enabled, you will

see a message directing you to the Printer Software. Open the Printer Software, select ePrint, then follow the onscreen instruction to enable.

TIP: To print the email address or registration url, select Print Info Sheet from the Settings menu on the

printer display.

2. Compose and send email.

a. Create a new email and type the product email address in the To box. b. Type text in the body of the email and attach the documents or images that you want to print. c. Send the email.

The product prints your email.

NOTE: To receive email, your product must be connected to the Internet. Your email will print as soon

as it is received. As with any email, there is no guarantee when or if it will be received. When you register online with ePrint, you can check the status of your jobs.

TIP: If you have enabled Auto Power-Off, you should disable it before using ePrint. For more information,

see Auto Power-Off on page 8

NOTE: 1 Device must be connected wirelessly and on an active network.

NOTE: 2 Documents printed with ePrint may appear different from the original. Style, formatting, and text flow

may differ from the original document. For documents that need to be printed with a higher quality (such as legal documents), we recommend that you print from the software application on your computer, where you will have more control over what your printout looks like.

Click here to go online for more information.

ePrint from anywhere

ePrint from anywhere 15

Chapter 4

ePrint from anywhere

16 ePrint from anywhere

+ 42 hidden pages
