HP 24o, 24uh User Guide

User Guide

Microsoft, Windows, and Windows Vista are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. This document contains proprietary information that is protected by copyright. No part of this document may be photocopied, reproduced, or translated to another language without the prior written consent of HP Company.

Second Edition (April 2016)

Document Part Number: 796262-003

This product incorporates HDMI technology.

Note: Be sure to save original box and all packing materials for future transport.

Chapter 1. Introduction

1.1 Features

Multilingual OSD adjustment Compatible with IBM VGA, extended VGA, VESA VGA, SVGA, XGA, and WXGA modes Wide range of applicable voltages (AC 100-240V 50/60Hz ) enables direct use without any

setting.

Plug-and-play VESA DDC1/ 2B Standard.

1.2 Check list

Please make sure the following items are included with your LCD monitor;

The monitor (and the pedestal) Stand Power cord VGA cable Documentation Setup poster Warranty

If any of these items are missing, please contact your dealer for technical support and customer service. To locate driver and software updates for your product, go to http://www.hp.com/support and select your country. Select Drivers & Downloads, and then follow the on-screen instructions.

1.3 Regulatory Information

For safety and regulatory information, refer to the Product Notices document provided with your monitor.

Chapter 2. Installation

2.1 Install the pedestal

Follow the steps illustrated below to install the pedestal for your model. Note: The following illustrations are for reference. Your model may have a different bezel, back cover and stand.

60.97cm/24” and 60.4 cm/23.8” Models

2.2 Connect your monitor to your computer

1. Power off and unplug your computer.

2. Connect your selected video signal cable .Use a VGA video cable or a DVI-D cable or a HDMI cable

to connect your monitor to your computer. To use DVI, you must have a DVI-compliant graphic card.

Connectors are located on the back of the monitor. Be sure the computer and monitor are turned off

and unplugged.

 To connect the VGA cable: Connect the 15-pin ends of the signal cable to the VGA port of your

monitor and the VGA OUT jack on the back of your computer. Secure the cable by tightening the screws on both ends of the signal cable.

 To connect the DVI-D cable (cable purchased separately): connect one end of the DVI-D video

cable to the back of the monitor and the other end to the DVI-D video connector on the computer. You can use this cable only if your computer has a DVI compliant graphics card installed.

 To connect the HDMI cable (cable purchased separately): connect one end of the HDMI cable to

the back of the monitor (available on select models) and the other end to the HDMI connector on the computer.

3. Connect one end of the power cord to the monitor, then connect the other end of the power cords to

the nearest electrical outlet.

WARNING! To reduce the risk of electric shock or damage to the equipment:

• Do not disable the power cord grounding plug. The grounding plug is an important safety feature.

• Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all times.

• Disconnect power from the equipment by unplugging the power cord from the electrical outlet.

• For your safety, do not place anything on power cords or cables. Arrange them so that no one may

accidentally step on or trip over them. Do not pull on a cord or cable. When unplugging from the electrical outlet, grasp the cord by the plug.

4. Power on your computer and monitor. If your monitor displays an image, the installation has been

successfully done. If the monitor does not display any image, check all the connections.

CAUTIONS: For installation, complete the signal cord connection before plugging the power cord into

the electrical outlet to avoid damaging the monitor. During installation, support the front frame with your hand at its center of gravity to avoid dropping and damaging the monitor.
