About This Guide
This guide provides information on monitor features, setting up the monitor, using the
software and technical specifications.
WARNING! Text set off in this manner indicates that failure to follow directions
could result in bodily harm or loss of life.
CAUTION: Text set off in this manner indicates that failure to follow directions
could result in damage to equipment or loss of information.
NOTE: Text set off in this manner provides important supplemental information.
ii
Page 4
Table of Contents
About This Guide
1. Product Features
2. Safety and Maintenance Guidelines
Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Maintenance Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Cleaning the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3. Setting Up the Monitor
Unpacking the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing the Monitor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connecting Monitor Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
High-Bandwidth Digital Content Protection (HDCP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting the Power Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Adjusting the Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4. Operating the Monitor
Downloading the monitor driver from the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Front-Panel Controls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Using the On-Screen Display (OSD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Assigning the Function buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Using Auto-Sleep Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Selecting Video Input Connectors 15
Identifying Monitor Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Adjusting Screen Quality (VGA only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Power-Saver Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
A. Troubleshooting
Solving Common Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Getting Support from hp.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Preparing to Call Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Locating the Rating Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
B. Technical Specifications
18.5 in/47 cm Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
19.5 in/49.4 cm Models. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
20.7 in / 52.6 cm and 21.5 in / 54.6 cm Models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Preset Video Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
LCD Monitor Quality and Pixel Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
ENWW 1
Page 5
1. Product Features
The HP LCD (liquid crystal display) monitors have an active matrix, thin-film transistor
(TFT) screen with the following features:
• Large diagonal display
• Maximum graphics resolution:
1366 x 768 @ 60Hz (18.5 in.)
1440 x 900 @ 60Hz (19.5 in.)
1920 x 1080 @ 60Hz (20.7 in. 21.5 in.)
Plus full-screen support for lower resolutions
• VGA analog signal
• DVI digital signal (Select Models)
• Easy viewing from a sitting or standing position, or while moving from one side of
the monitor to the other
• Tilt adjustment
• Removable base
• Built in stereo speakers
• Security lock slot for a locking security cable (security cable sold separately)
• Plug and Play capability, if supported by your computer system
• On-Screen Display (OSD) adjustments in several languages for easy setup and
screen optimization
• Power Saver to reduce energy consumption
• HDCP (High Bandwidth Digital Content Protection) on DVI input
NOTE: For safety and regulatory information, refer to the Product Notices
provided in your documentation kit. To locate updates to the user guide for your
product, go to http://www.hp.com/support, and select your country. Select Drivers &
Downloads, and then follow the on screen instructions.
ENWW 1
Page 6
2. Safety and Maintenance Guidelines
Important Safety Information
A power cord is included with the monitor. If another cord is used, use only a power
source and connection appropriate for this monitor. For information on the correct
power cord set to use with the monitor, refer to the Product Notices provided on your
media disc, if one is included, or in your documentation kit.
WARNING! To reduce the risk of electric shock or damage to the equipment:
• Do not disable the power cord grounding feature. The grounding plug is an
important safety feature.
• Plug the power cord in a grounded (earthed) outlet that is easily accessible at all
times.
• Disconnect power from the product by unplugging the power cord from the
electrical outlet.
For your safety, do not place anything on power cords or cables. Arrange them so that
no one may accidentally step on or trip over them. Do not pull on a cord or cable.
When unplugging from the electrical outlet, grasp the cord by the plug.
To reduce the risk of serious injury, read the Safety and Comfort Guide. It describes
proper workstation, setup, posture, and health and work habits for computer users,
and provides important electrical and mechanical safety information. This guide is
located on the Web at
http://www.hp.com/ergo.
power cords for the computer and its peripheral devices (such as a monitor, printer,
scanner) to some form of surge protection device such as a power strip or
Uninterruptible Power Supply (UPS). Not all power strips provide surge protection; the
power strips must be specifically labeled as having this ability. Use a power strip
whose manufacturer offers a Damage Replacement Policy so you can replace the
equipment, if surge protection fails.
Use the appropriate and correctly sized furniture designed to properly support your
HP LCD monitor.
cases, shelves, desks, speakers, chests, or carts may fall over and cause personal
injury. Care should be taken to route all cords and cables connected to the LCD
monitor so that they can not be pulled, grabbed, or tripped over.
Safety Precautions
• Use only a power source and connection compatible with this monitor, as
• Be sure the total ampere rating of the products connected to the outlet does not
• Install your monitor near a power outlet that you can easily reach. Disconnect the
CAUTION: For the protection of the monitor, as well as the computer, connect all
WARNING: LCD monitors that are inappropriately situated on dressers, book
indicated on the label/back plate of the monitor.
exceed the current rating of the electrical outlet, and the total ampere rating of the
products connected to the power cord does not exceed the rating of the power
cord. Look on the power label to determine the ampere rating (Amps or A) for
each device.
monitor by grasping the plug firmly and pulling it from the outlet. Never disconnect
the monitor by pulling the cord.
2 Chapter 2. Safety and Maintenance Guidelines ENWW
Page 7
• Do not allow anything to rest on the power cord. Do not walk on the cord.
Maintenance Guidelines
To enhance the performance and extend the life of the monitor:
• Do not open the monitor cabinet or attempt to service this product yourself. Adjust
only those controls that are covered in the operating instructions. If the monitor is
not operating properly or has been dropped or damaged, contact an authorized
HP dealer, reseller, or service provider.
• Use only a power source and connection appropriate for this monitor, as indicated
on the label/back plate of the monitor.
• Be sure the total ampere rating of the products connected to the outlet does not
exceed the current rating of the electrical outlet, and the total ampere rating of the
products connected to the cord does not exceed the rating of the cord. Look on
the power label to determine the ampere rating (AMPS or A) for each device.
• Install the monitor near an outlet that you can easily reach. Disconnect the
monitor by grasping the plug firmly and pulling it from the outlet. Never disconnect
the monitor by pulling the cord.
• Turn the monitor off when not in use. You can substantially increase the life
expectancy of the monitor by using a screen saver program and turning off the
monitor when not in use
• Slots and openings in the cabinet are provided for ventilation. These openings
must not be blocked or covered. Never push objects of any kind into cabinet slots
or other openings.
• Do not drop the monitor or place it on an unstable surface.
• Do not allow anything to rest on the power cord. Do not walk on the cord.
• Keep the monitor in a well-ventilated area, away from excessive light, heat or
moisture.
• When removing the monitor base, you must lay the monitor face down on a soft
area to prevent it from getting scratched, defaced, or broken.
Cleaning the Monitor
1. Turn off the monitor and the computer.
2. Unplug the monitor from the wall outlet or the power brick.
3. Clean the monitor plastics with a clean cloth dampened with water.
4. Clean the monitor screen with an antistatic screen cleaner.
CAUTION: Do not use benzene, thinner, ammonia, or any other volatile
substances to clean the monitor or the screen. These chemicals may damage the
cabinet finish as well as the screen.
ENWW Maintenance Guidelines 3
Page 8
3. Setting Up the Monitor
Unpacking the Monitor
1. Unpack the monitor. Make sure all contents are included. Store the packing box.
2. Turn off the computer and other attached devices.
3. Prepare a flat area to assemble the monitor. You may need a flat, soft, protected
area for placing the monitor screen-down while preparing it for installation.
Installing the Monitor
You can install the monitor on a desktop or wall-mount it. Place the monitor in a
convenient, well-ventilated location near your computer. Connect the monitor cables
after you have installed the monitor.
Preparing the monitor for desktop use
1. Set the monitor screen face down on a flat, soft, protected table or desk surface
with the support column overhanging the edge.
CAUTION: The screen is fragile. Avoid touching or applying pressure to the LCD
screen; doing so can cause damage.
2. Press the column onto the monitor support column until it locks in place.
ENWW Unpacking the Monitor 4
Page 9
3. Press the base into the column until it locks in position.
4. Lift the monitor to an upright position and place on a flat, stable surface.
Preparing the monitor for wall-mounting
1. Check the stability of the wall-mounting fixture.
WARNING! To reduce the risk of personal injury or of damage to the equipment,
check that the wall-mounting fixture is adequately installed and secured before
attaching the monitor. Refer to the instructions supplied with the wall-mounting fixture
and check that it is capable of supporting the monitor.
2. Disconnect the power cable and any other cables from the monitor.
3. Place the monitor face down on a flat, protected surface.
ENWW Installing the Monitor 5
Page 10
4. Remove the base and slide it away from the bottom of the monitor.
5. Four threaded holes are exposed on the back panel of the monitor. These holes
are for screws to attach the swing arm or other mounting fixture to the back of the
monitor.
6. Follow the instructions included with the mounting fixture to ensure that the
monitor is safely attached. The four threaded holes that are on the back of the
panel are compliant with the VESA standard for mounting flat-panel monitors.
7. Attach a swing arm or other mounting fixture.
NOTE: This apparatus is intended to be supported by UL or CSA Listed wall mount
bracket.
CAUTION: This monitor supports the VESA industry standard 100 mm mounting holes.
To attach a third-party mounting solution to the monitor, four 4 mm, 0.7 pitch, and 10 mm
long screws are required. Longer screws must not be used because they may damage the
monitor. It is important to verify that the manufacturer’s mounting solution is compliant with
the VESA standard and is rated to support the weight of the monitor display panel. For best
performance, it is important to use the power and video cables provided with the monitor.
ENWW Installing the Monitor 6
Page 11
Connecting Monitor Cables
Connecting the VGA (Analog) Cable or DVI-D (Digital) Cable
Use a VGA video cable or a DVI-D cable to connect your monitor to your computer. To
use DVI, you must have a DVI-compliant graphic card. Connectors are located on the
back of the monitor. Be sure the computer and monitor are turned off and unplugged.
1. To connect the VGA cable:
Connect one end of the VGA video cable to the back of the monitor and the other end
to the VGA video connector on the computer.
2. To connect the DVI-D cable (Select Models):
Connect one end of the DVI-D video cable to the back of the monitor and the other
end to the DVI-D video connector on the computer. You can use this cable only if your
computer has a DVI compliant graphics card installed. The monitor DVI-D connector
and cable are included.
NOTE: Connector locations may vary.
VGA DVI
OR
NOTE: When using a VGA or DVI signal, you must connect your audio
separately because a VGA or DVI signal converts only video data, not audio data.
High-Bandwidth Digital Content Protection (HDCP)
Your monitor supports HDCP and can receive high-definition content. High-definition
content is available in many sources, such as Blue-ray Disc devices or HDTV air or
cable broadcasts. If you do not have an HDCP-enabled monitor, you will see a blank
screen or a lower resolution picture when playing high-definition protected content.
Your computer graphics card and monitor must both support HDCP to display
protected content.
ENWW Connecting Monitor Cables 7
Page 12
Connecting the Power Cable
1. Follow all Electrical and Power Warnings
WARNING! To reduce the risk of electric shock or damage to your equipment:
Do not disable the power cord grounding plug. The grounding plug is an important
safety feature.
Plug the power cord into a grounded (earthed) electrical outlet.
Be sure that the grounded power outlet you plug the power cord into is easily
accessible to the operator and located as close to the equipment as possible. A power
cord should be routed so that it is not likely to be walked on or pinched by items that
are placed upon it or against it.
Do not place anything on power cords or cables. Arrange them so that no one may
accidentally step on or trip over them. Do not pull on a cord or cable.
See"Technical Specification" (Appendix B) for additional information.
2. Connect one end of the power cable to the monitor and the other end to a
grounded electrical outlet.
WARNING! To prevent injury from electrical shock, you should do one of the
following if a properly grounded electrical outlet is not available: (1) You should use an
electrical outlet adapter that provides proper grounding. (2) You should have a
properly grounded electrical outlet installed.
ENWW Connecting the Power Cable 8
Page 13
Adjusting the Tilt
For optimal viewing, adjust the screen tilt to your own preference, as follows:
1. Face the front of the monitor and hold the base so that you do not topple the
2. Adjust the tilt by moving the top edge of the monitor either toward or away from
monitor while changing the tilt.
you, without touching the screen.
ENWW Adjusting the Tilt 9
Page 14
4. Operating the Monitor
NOTE: You might need to install the digitally signed monitor drivers (INF or ICM
files). If you determine that you need to update the drivers, you can install the monitor
driver INF and ICM files from the Internet.
Downloading the monitor driver from the Internet
To download the latest version of drivers and software files from the HP Support site:
1. Refer to: http://www.hp.com/support.
2. Select Drivers & Downloads, type your monitor model in the find by product
search field, and click Go.
3. If necessary, select your monitor from the list.
4. Select your operating system, and then click Next.
5. Click Driver - Display/Monitor to open the list of drivers.
6. Click on the driver.
7. Click the System Requirements tab, and then verify that your system meets the
program minimum requirements.
8. Click Download and follow the on-screen instructions to download the software.
ENWW 10
Page 15
Front-Panel Controls
The monitor buttons are located on the bottom of the front panel
321
No. Icon Description
1 Menu
button
Opens and closes the OSD menu.
NOTE: To activate the Menu button and the Function buttons, press any
of the buttons so that the button labels appear on the screen.
2 Function
buttons
Use these buttons to navigate through the OSD menu based on the
indicators next to the buttons that are activated while the OSD menu is
open.
NOTE: You can reconfigure the Function buttons in the OSD menu to
quickly select the most commonly used operations.
3 Power
button
Turns the monitor on or off.
ENWW Front-Panel Controls 11
Page 16
Using the On-Screen Display (OSD)
Use the On-Screen Display (OSD) menu to adjust the monitor screen image based on
your preferences. You can access and make adjustments in the OSD menu using the
buttons on the monitor's front bezel.
To access the OSD menu and make adjustments, do the following:
1. If the monitor is not already on, press the Power button to turn on the monitor.
2. To access the OSD menu, press one of the four front bezel Function buttons to
activate the buttons, and then press the Menu button to open the OSD.
3. Use the three Function buttons to navigate, select, and adjust the menu choices.
The button labels are variable depending on the menu or submenu that is active.
The following table lists the menu selections in the OSD menu.
Main Menu Description
Brightness Adjusts the brightness level of the screen.
Contrast Adjusts the screen contrast.
Color Control Selects and adjusts the screen color.
Input Control Selects the video input signal.
Image Control Adjusts the screen image.
Power Control Adjusts the power settings.
Menu Control Adjusts the on-screen display (OSD) and Function
button controls.
Management Enables/disables DDC/CI support and returns all OSD
menu settings to the factory default settings.
Language Selects the language in which the OSD menu is
displayed. The factory default is English.
Information Displays important information about the monitor.
Exit Exits the OSD menu screen.
ENWW Using the On-Screen Display (OSD) 12
Page 17
Assigning the Function buttons
Pressing one of the four front bezel Function buttons activates the buttons and
displays the icons above the buttons. The factory default button icons and functions
are shown below.
Button Function
Menu Opens the OSD (On-Screen Display) menu.
Information
(Function button 1 assignable)
Next Active Input
(Function button 2 assignable)
Return (Function button
3 - assignable)
You can change the Function buttons from their default values so that when the
buttons are activated you can quickly access commonly used menu items.
To assign the Function buttons:
1. Press one of the four front bezel buttons to activate the buttons, and then press
the Menu button to open the OSD.
2. In the OSD menu, select Menu Control > Assign Buttons and then select one of
the available options for the button you want to assign.
NOTE: You can only assign the three Function buttons. You can not reassign the
Menu button or the Power button.
Opens the Information menu.
Switches the monitor's input source to the next active
input.
Return to the previous menu level.
ENWW Assigning the Function buttons 13
Page 18
Using Auto-Sleep Mode
The monitor supports an OSD (On-Screen Display) menu option called Auto-Sleep
Mode that allows you to enable or disable a reduced power state for the monitor.
When Auto-Sleep Mode is enabled (enabled by default), the monitor will enter a
reduced power state when the host PC signals low power mode (absence of either
horizontal or vertical sync signal).
Upon entering this reduced power state (sleep mode), the monitor screen is blanked,
the backlight is turned off and the power LED indicator turns amber. The monitor
draws less than 0.5 W of power when in this reduced power state. The monitor will
wake from the sleep mode when the host PC sends an active signal to the monitor (for
example, if you activate the mouse or keyboard).
You can disable Auto-Sleep Mode in the OSD. Press one of the four front bezel
Function buttons to activate the buttons, and then press the Menu button to open the
OSD. In the OSD menu select Power Control > Auto- Sleep Mode > Off.
ENWW Using Auto-Sleep Mode 14
Page 19
Selecting Video Input Connectors
The input connectors are:
• VGA connector (analog)
• DVI-D connector (digital) (Select Models)
The monitor automatically determines which inputs have valid video signals, and
displays the image.
You can connect the VGA cable or the DVI-D cable, or both. If both cables are
installed, the default input selection is DVI.The source of input can be switched using
the Input Select option in the OSD menu.
Identifying Monitor Conditions
Special messages will appear on the monitor screen when identifying the following
monitor conditions:
• Monitor Status - When the monitor is powered on or when the input source signal
is changed, a Monitor Status message is displayed for five seconds. The
message shows which input is the current active signal, the status of the autoswitch source setting (On or Off), the default source signal, the current preset
display resolution, and the recommended preset display resolution.
• Input Signal Out of Range - Change resolution setting to1366 x 768 @ 60Hz (18.5
in.) or 1440 x 900 @ 60Hz (19.5 in.) or 1920 x 1080 @ 60Hz (20.7 in. 21.5 in.).
Indicates the monitor does not support the input signal because the resolution
and/or refresh rate are set higher than the monitor supports.
• No Source Signal - Indicates the monitor is not receiving a video signal from the
PC on the monitor video input connector. Check to determine if the PC or input
signal source is off or in the power saving mode.
• Auto Adjustment in Progress - Indicates the auto-adjustment function is active.
• Monitor Going to Sleep - Indicates the screen display is entering a sleep mode.
• Check Video Cable - Indicates the video cable is not properly connected to the
computer.
• OSD Lockout - The OSD can be enabled or disabled by pressing and holding the
Menu button on the front panel for 10 seconds. If the OSD is locked, the warning
message OSD Lockout displays for ten seconds.
• If the OSD is locked, press and hold the Menu button for 10 seconds to unlock
the OSD.
• If the OSD is unlocked, press and hold the Menu button for 10 seconds to lock
the OSD.
• Power Button Lockout - Indicates the power button is locked. If the power button is
locked, the warning message Power Button Lockout displays.
• If the power button is locked, press and hold the power button for 10 seconds
to unlock the power button function.
• If the power button is unlocked, press and hold the power button for 10
seconds to lock out the power button function.
• Dynamic Contrast Ratio On - Indicates that Dynamic Contrast Ratio has been
turned on. This occurs if Dynamic Contrast Ratio is turned on in the Image Control
OSD menu.
• Dynamic Contrast Ratio Off - Indicates that Dynamic Contrast Ratio has been
turned off. This occurs if Dynamic Contrast Ratio is turned off in the Image Control
OSD menu.
ENWW Identifying Monitor Conditions 15
Page 20
Adjusting Screen Quality (VGA only)
The auto adjustment feature automatically fine-tunes the image quality for display
size, position, clock, and phase each time a new video mode is displayed. For more
precise adjustments of VGA input, run the Auto Adjustment software available on your
product support site at www.hp.com/support. If you want additional image quality
improvement, use the Clock and Phase controls of the monitor to fine tune the image.
See "Optimizing Analog Video" in this chapter.
Optimizing Analog Video
Some monitors contain advanced circuitry that allow the monitor to function as a
standard analog monitor. Two controls in the OSD menu can be adjusted to improve
analog image performance:
Clock - Increase or decrease the value to minimize any vertical bars or stripes visible
on the screen background.
Phase - Increase or decrease the value to minimize video distortion or video jitter.
Use these controls only when the auto adjustment function does not provide a
satisfactory monitor image in analog mode. To obtain the best results:
1. Allow the monitor to warm up for 30 minutes before adjusting.
2. Access the OSD menu, then select Image Setup.
3. Set the main Clock settings correctly first, because the Phase settings depend on
the main Clock settings.When adjusting the Clock and Phase values, if the
monitor images become distorted, continue adjusting the values until the
distortion disappears. To restore the factory settings, access the OSD menu,
select Factory Reset, and then select Yes.
Power-Saver Feature
When the monitor is in normal operating mode, the Power light is blue and the monitor
uses the normal watts of power. For power usage, refer to "Technical Specification"
(Appendix B). The monitor also supports a power-saver mode that is controlled by the
computer. When the monitor is in the reduced-power state, the monitor screen is
blank, the backlight is off, and the Power light is amber. The monitor uses minimum
power. When the monitor is "awakened", a brief warm-up period occurs before the
monitor returns to normal operating mode. The energy-saving reduced power state
activates if the monitor does not detect either the horizontal sync signal or the vertical
sync signal. The power-saver feature must be activated on your computer for this
feature to work. Refer to your computer documentation for instructions on setting
energy-saver features (sometimes called power-management features).
NOTE: The energy-saver feature works only when the monitor is connected to
computers that have energy-saver features.
ENWW Adjusting Screen Quality (VGA only) 16
Page 21
A. Troubleshooting
Solving Common Problems
The following table lists possible problems, the possible cause of each problem, and the
recommended solutions:
Problem Possible Cause Solutions
Screen is blank or video is
flashing.
Image appears blurred,
indistinct, or too dark.
Check Video Cable is
displayed on screen.
Input Signal Out of Range is
displayed on screen.
The monitor is off but it did
not seem to enter into sleep
mode.
Power cord is disconnected. Power cord is disconnected.
Monitor is off. Press the front bezel Power button.
NOTE: If pressing the Power button has no
effect, press and hold the Power button for 10
seconds to disable the Power button lockout
feature.
Video cable is improperly
connected.
System is in sleep mode. Press any key on the keyboard or move the
Video card is incompatible. Open the OSD menu and select the Input
Brightness is too low. Open the OSD menu and select Brightness to
Monitor video cable is
disconnected.
Video resolution and/or
refresh rate are set higher
than what the monitor
supports.
The monitor's power saving
control is disabled.
Connect the video cable properly. See
Connecting the cables for more information.
mouse to exit sleep mode.
Control menu. Set Auto-Switch Input to Off and
manually select the input.
adjust the brightness scale as needed.
Connect the appropriate video signal cable
between the computer and monitor. Be sure
that the computer power is off while you
connect the video cable.
Change the settings to a supported setting. See
Preset display resolutions for more information.
Open the OSD menu and select Power Control
> Auto-Sleep Mode and set auto-sleep to On.
OSD Lockout is displayed. The monitor's OSD Lockout
function is enabled.
Power Button Lockout is
displayed.
ENWW 17
The monitor's Power Button
Lockout function is enabled.
Press and hold the Menu button on the front
bezel for 10 seconds to disable the OSD
Lockout function.
Press and hold the Power button for 10
seconds to disable the Power Button Lockout
function.
Page 22
Getting Support from hp.com
Before you contact customer service, refer to HP Technical Support at:
http://www.hp.com/support
Select your country/region, and then follow the links to the support page for your
monitor.
Preparing to Call Technical Support
If you cannot solve a problem by using the troubleshooting tips in this section, you
might have to call technical support. For technical support contact information, refer to
the printed documentation included with the monitor.
Have the following information available when you call:
• Monitor model number (located on label on back of monitor)
• Monitor serial number (located on label on back of monitor or in the OSD display
in the Informationmenu)
• Purchase date on invoice
• Conditions under which the problem occurred
• Error messages received
• Hardware configuration
• Name and version of hardware and software you are using
Locating the Rating Label
The rating label on the monitor provides the product number and serial number. You
may need these numbers when contacting HP about your monitor model.
The rating label is on the back of the monitor.
18 Appendix A. Troubleshooting ENWW
Page 23
B. Technical Specifications
All specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
Face treatment: Glare polarizer with hard coating
Input terminal:
VGA connector
DVI-D connector (Select Models)
18.5 in/47 cm Models
Specifications:
Display Type: TFT LCD active matrix
Viewable Image Size 47 cm (18.5 in.) diagonal
Tilt -3.5 (+/-1.5)~+13.5 (+/-1.5)
Maximum Weight (unpacked) 2.36 kg (5.2 lbs)
Dimensions (w x h x d) 44.1cm x 34.5cm x 19.84cm
17.36 x13.58 x 7.81 in
Maximum Graphics Resolution 1366 x 768 @ 60 Hz
Optimum Graphics Resolution 1366 x 768 @ 60 Hz
Text Mode 720 x 400
Dot Pitch 0.3 x 0.3 mm / 0.012 x 0.012 in
Horizontal Frequency (analog
mode)
Vertical Frequency (analog mode) 50 to 75 Hz
Operating Temperature 41 to 95F (5 to 35C)
Non-Operating Temperature -4 to 140F (-20 to 60C)
Operating Humidity 20% to 80%
Non-Operating Humidity 5% to 95%
Power Source 100-240V~, 50/60 Hz
24 to 70 kHz
ENWW 19
Page 24
19.5 in/49.4 cm Models
Specifications:
Display Type: TFT LCD active matrix
Viewable Image Size 49.4 cm (19.5 in.) diagonal
Tilt -3.5 (+/-1.5)~+21.5 (+/-1.5)
Maximum Weight (unpacked) 2.49 kg (5.49 lbs) / 2.5 kg (5.51 lbs)
Dimensions (w x h x d) 45.07cm x 40.3cm x 19.0cm 17.74 x15.87 x 0.75 in
Maximum Graphics Resolution 1440 x 900 @ 60 Hz
Optimum Graphics Resolution 1440 x 900 @ 60 Hz
Text Mode 720 x 400
Dot Pitch 0.2907 x 0.2915 mm/0.011 x 0.011 in
Horizontal Frequency (analog
mode)
Vertical Frequency (analog mode) 50 to 75 Hz
Operating Temperature 41 to 95F (5 to 35C)
Non-Operating Temperature -4 to 140F (-20 to 60C)
Operating Humidity 20% to 80%
Non-Operating Humidity 5% to 95%
Power Source 100-240V~, 50/60 Hz
24 to 70 kHz
ENWW 20
Page 25
20.7 in / 52.6 cm and 21.5 in / 54.6 cm Models
Specifications:
Display Type: TFT LCD active matrix
Viewable Image Size 52.6 cm (20.7 in.) diagonal
54.6 cm (21.5 in.) diagonal
Tilt -3.5 (+/-1.5)~+13.5 (+/-1.5)
Maximum Weight (unpacked) 20.7 in: 2.99 kg (6.59 lbs)
21.5 in: 3.59 kg (7.92 lbs)
Dimensions (w x h x d) 20.7 in / 52.6 cm: 48.94 cm x 37.25 cm x 22.34 cm
19.26 x14.67 x 8.8 in
21.5 in / 54.6 cm: 50.76 cm x 38.25 cm x 22.34 cm
19.98 x15.06 x 8.8 in
Maximum Graphics Resolution 1920 x 1080 @ 60 Hz
Optimum Graphics Resolution 1920 x 1080 @ 60 Hz
Text Mode 720 x 400
Dot Pitch 20.7 in / 52.6 cm: 0.2385 x 0.2385 mm/0.01 x 0.01 in
21.5 in / 54.6 cm: 0.24825×0.24825mm/0.01 x 0.01 in
Horizontal Frequency (analog
mode)
Vertical Frequency (analog mode) 50 to 76 Hz
Operating Temperature 41 to 95F (5 to 35C)
Non-Operating Temperature -4 to 140F (-20 to 60C)
Operating Humidity 20% to 80%
Non-Operating Humidity 5% to 95%
Power Source 100-240V~, 50/60 Hz
24 to 80 kHz
ENWW 21
Page 26
Preset Video Modes
The monitor automatically recognizes many preset video input modes that will appear
properly sized and centered on the screen.
18.5 in/47 cm Models
Item Preset Resolution
1 640 x 480 31.47 59.94
2 720 x 400 31.47 70.09
3 800 x 600 37.88 60.32
4 1024 x 768 48.36 60.00
5 1280 x720 45.00 60.00
6 1280 x800 49.70 59.81
7 1280 x 1024 63.98 60.02
8 1366 x 768 55.93 59.88
19.5 in/49.4 cm Models
Item Preset Resolution
1 640 x 480 31.47 59.94
2 720 x 400 31.47 70.09
3 800 x 600 37.88 60.32
Horizontal
Frequency (kHz)
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Vertical Frequency
(Hz)
4 1024 x 768 48.36 60.00
5 1280 x720 45.00 60.00
6 1280 x800 49.70 59.81
7 1280 x 1024 63.98 60.02
8 1440 x 900 55.93 59.88
ENWW 22
Page 27
20.7 in / 52.6 cm Models
Item Preset Resolution
1 640 x 480 31.47 59.94
2 720 x 400 31.47 70.09
3 800 x 600 37.88 60.32
4 1024 x 768 48.36 60.00
5 1280 x720 45.00 60.00
6 1280 x800 49.70 59.81
7 1280 x 1024 63.98 60.02
8 1440 x 900 55.93 59.88
9 1600 x 900 60.00 60.00
10 1680 x 1050 65.30 59.95
11 1920 x 1080 67.50 60.00
21.5 in / 54.6 cm Models
Item Preset Resolution
Horizontal Frequency
(kHz)
Horizontal Frequency
(kHz)
Vertical Frequency
(Hz)
Vertical Frequency
(Hz)
1 640 x 480 31.47 59.94
2 720 x 400 31.47 70.09
3 800 x 600 37.88 60.32
4 1024 x 768 48.36 60.00
5 1280 x720 45.00 60.00
6 1280 x800 49.70 59.81
7 1280 x 1024 63.98 60.02
8 1440 x 900 55.93 59.88
9 1600 x 900 60.00 60.00
10 1680 x 1050 65.30 59.95
11 1920 x 1080 67.50 60.00
ENWW 23
Page 28
LCD Monitor Quality and Pixel Policy
Your LCD Monitor uses high-precision technology, manufactured according to high
standards, to help guarantee trouble-free performance. Nevertheless, the display may
have cosmetic imperfections that appear as small bright or dark spots. This is
common to all LCD displays used in products supplied by all vendors and is not
specific to your LCD Monitor. These imperfections are caused by one or more
defective pixels or subpixels.
A pixel consists of one red, one green, and one blue subpixel. A defective whole pixel
is always turned on (a bright spot on a dark background), or it is always off (a dark
spot on a bright background). The first is the more visible of the two. A defective
subpixel (dot defect) is less visible than a defective whole pixel, and is small and only
visible on a specific background.
To locate defective pixels, the monitor should be viewed under normal operating
conditions and in normal operating mode at a supported resolution and refresh rate,
from a distance of approximately 50 cm (16 inches). We expect that, over time, the
industry will continue to improve its ability to produce displays with fewer cosmetic
imperfections, and we will adjust guidelines as improvements are made. For more
information about your LCD Monitor, refer to the HP Web site at:
http://www.hp.com/support.
ENWW 24
Loading...
